SOFTWARE SPECIFICATION
Healthcare Provider
Expands Wi-Fi Applications
1. 802.11 a/b/g Wireless LAN
802.11a (5GHz) and 802.11b/g
(2.4GHz)
WMM for QoS
WMM-PS (U-APSD) ultra battery
life Equivalent to CCX v4 ASD***
SQ-3500
2. Wireless Security
WEP (64 /128 bits)
WPA-PSK 802.1x EAP-MD5,
EAP-TTLS, PEAP, EAP-TLS*
WPA/WPA2 Personal and
Enterprise
Healthcare
Healthcare Provider Expands Wi-Fi Applications.
Deploy one unified network to converge data, video and
voice applications and reduce operation costs
Improve communications between doctors and nurses to
enhance patient care
Facilitate network scalability to support facility expansion
and integration of new Wi-Fi phone applications solution
UniData Wireless IP Phones make it possible for nurses to
interact with patients and communicatewith other medical
staff quickly and easily. Simplified network management
resulted in the consolidation of IT staff while improving
efficiency and realizing huge time and cost savings.
Direct communications with nurses expedited response time
and decision-making, thus improving patient care.
3. Dynamic Network Binding
Pre-configured 5 Network
profiles (including instant
network connection)
Wireless LAN Site Survey
Simple WLAN profile
configuration for instant network
connection
DHCP / Static IP
DiffServ(ToS) Tagging
STUN NAT Traversal
Automatic roaming between APs
Layer 3 hands-over
4. Voice and video over IP
RFC3261 SIP
Secure RTP for encrypted and
authenticated media
Narrowband Voice Codec: G.711,
G.729AB, G.726*, iLBC*, Speex*,
GSM-AMR*
Wideband Voice Codec: G.722,
G.722.2(AMR-WB)*, Speex
Video Codec: H.263, H.263+,
H.264, MPEG-4* : up to 30fps
QVGA
In-band DTMF / Out-of-band
DTMF (INFO, RFC2833)
SIP MESSAGE
5. Call Features
3-way voice & video conference*
Mute / Hold / Transfer
(attended/unattended)
Waiting / Forwarding
(busy / no answer / unconditional)
Visual caller ID display / Call ID
blocking
6. Phone Features
MP3 live bell / SP-MIDI* / Vibrator
Full duplex speaker phone with
acoustic echo canceller
Call history (Inbound / Outbound /
Missed / Memo, 100 records)
Phone book (1,000 contacts) /
Speed dial (99 records)
Distinctive ringing (by individuals
and / or groups)
Search call history, or phone book
search during a phone call
7. Applications
Simple HTML browser *
(Google mobile, customizable
multimedia service)
Full web browser*
Network game over the phone *
RTSP based streaming service*
Alarm / Calendar / Unit Converter /
Memo pad
MP3 Audio / H.264 Video Player
Digital Photo Frame
Digital steel camera
3. Dynamic Network Binding
Pre-configured 5 Network
profiles(including instant network
connection)
Wireless LAN Site Survey
Simple WLAN profile
configuration for instant network
connection
DHCP / Static IP
DiffServ (ToS) Tagging
STUN NAT Traversal
Automatic roaming between APs
Layer 3 hands-over
4. Voice and Video over IP
RFC3261 SIP
Secure RTP for encrypted and
authenticated media
Narrowband Voice Codec:
G.711, G.729AB,G.726*,
iLBC*, Speex*, GSM-AMR*
Wideband Voice Codec: G.722,
G.722.2(AMR-WB)*, Speex
Video Codec: H.263, H.263+,
H.264,
MPEG-4* : up to 30fps QVGA
In-band DTMF / Out-of-band
DTMF (INFO, RFC2833)
SIP MESSAGE
Many Air Ports have already adopted VoIP as the preferred
solution for providing various services.
UniData's wireless phones allow staff to communicate in
real-time from anywhere on the property and can expand
communications beyond voice and video.
Application integration allows for real-time video to improve
response to requests.
The other great benefit of VOIP is the ability to take your
device anywhere and make calls just like you were at home.
The best services are fully find-me, follow-me capable.
This means that wherever you happen to be, your phone
number will find you and ring at that location without
airport interference.
7. EXTERNAL CONNECTIVITY
2.5Φ Stereo Headset Jack
Micro SD Card Slot (up to 8GB)
USB 2.0 FS
3. CAMERA
Front Side Camera: 300k pixels
CMOS Image Sensor for Video Call
Rear Side Camera: 3M pixels
CMOS Image Sensor for Video
Call and Still Image
8. DIMENSIONS
Size: 4.9 x 2.3 x 0.7 in /
12.5 x 5.8 x 1.7 cm
Weight: 4.8oz / 135g
(with Battery)
4. POWER SUPPLY
Battery: Li-Ion Polymer,
3.7V/1450mAh
AC Input: 100 ~ 240Vac, 50/60Hz
DC Output: 5Vdc/2A
5. COMPLIANCE
KCC, FCC, IC, CE, UL, RoHS
9. TEMPERATURE RANGE
Operation: 32 ~ 122℉ / 0~50℃
Relative Humidity: 10% ~ 90%
10. PACKAGE CONTENTS
Handset, Battery Pack, Cradle,
Power Supply, AC Cable,
Quick Start Guide, User Manual
ASD is Application Specific Device. Several features that are exclusively
or primarily use in data applications are not required. Specificationsare
subject to change without notice.
2. Wireless Security
WEP (64 /128 bits)
WPA-PSK
802.1x EAP-MD5,
EAP-TTLS, PEAP, EAP-TLS*
WPA/WPA2 Personal and
Enterprise
Air Port
2. DISPLAY
2.8” TFT 262k Colors LCD with
Touch Panel
Resolution: 320x240 pixels
*
Optional
*** CCX (Cisco Compatible Extensions) is Cisco compatible
specification version 4 (Optional).
1. 802.11 a/b/g Wireless LAN
802.11a (5GHz) and
802.11b/g (2.4GHz)
WMM for QoS
WMM-PS (U-APSD)
ultra battery life
Equivalent to CCX v4 ASD***
Live video conference
at work, at home, even in bed
6. HANDSET KEYS
Call Control Key
(Send, End, Clear)
5-Way Navigation Key
4 Soft Key
Number Key (0~9, *, #)
Volume Up/Down
8. Management
Auto/Manual Upgrade
(TFTP / HTTP / HTTPS)
Auto Provisioning (HTTP / HTTPS)
SNTP Time Synchronization
Syslog Remote Logging
Web server for user phone book
configuration*
SOFTWARE SPECIFICATION
SQ-3000
HARDWARE SPECIFICATIONS
1. WIRELESS
IEEE 802.11 a/b/g Supported
Frequency Band: 2.400 ~ 2.483GHz,
5.15 ~ 5.25GHz, 5.725 ~ 5.850GHz
Data Rate: 1 ~ 54Mbps
Antenna Type:
Dual-band Internal Antenna
5. Call Features
3-way voice & video conference*
Mute / Hold / Transfer
(attended/unattended)
Waiting / Forwarding
(busy / no answer / unconditional)
Visual caller ID display /
Call ID blocking
6. Phone Features
MP3 live bell / SP-MIDI* / Vibrator
Full duplex speaker phone
with acoustic echo canceller
Call history (Inbound / Outbound /
Missed / Memo, 100 records)
Phone book (1,000 contacts) /
Speed dial (99 records)
Distinctive ringing
(by individuals and / or groups)
earch call history, or phone book
search during a phone call
7. Applications
Simple HTML browser*
(Google mobile, customizable
multimedia service)
Network game over the phone *
RTSP based streaming service*
Alarm / Calendar /
Unit Converter / Memo pad
MP3 Audio / H.264 Video Player
Digital Photo Frame
HARDWARE SPECIFICATIONS
1. WIRELESS
IEEE 802.11 a/b/g Supported
Frequency Band: 2.400 ~ 2.483GHz,
5.15 ~ 5.25GHz, 5.725 ~ 5.850GHz
Data Rate: 1 ~ 54Mbps
Antenna Type:
Dual-band Internal Antenna
6. HANDSET KEYS
Call Control Key
(Send, End, Clear)
5-Way Navigation Key
4 Soft Key
Number Key (0~9, *, #)
Volume Up/Down
2. DISPLAY
2.8” TFT 262k Colors LCD with
Touch Panel
Resolution: 320x240 pixels
7. EXTERNAL CONNECTIVITY
2.5Φ Stereo Headset Jack
Micro SD Card Slot (up to 8GB)
USB 2.0 FS
3. CAMERA
300k pixels CMOS Image Sensor
for Video Call
8. DIMENSIONS
Size: 4.9 x 2.3 x 0.7 in /
12.5 x 5.8 x 1.7 cm
Weight: 4.8oz / 135g
(with Battery)
4. POWER SUPPLY
Battery: Li-Ion Polymer,
3.7V/1450mAh
AC Input: 100 ~ 240Vac, 50/60Hz
DC Output: 5Vdc/2A
5. COMPLIANCE
KCC, FCC, CE, UL, RoHS
9. TEMPERATURE RANGE
Operation: 32 ~ 122℉ / 0~50℃
Relative Humidity: 10% ~ 90%
10. PACKAGE CONTENTS
Handset, Battery Pack, Cradle,
Power Supply, AC Cable,
Quick Start Guide, User Manual
8. Management
Auto/Manual Upgrade
(TFTP/HTTP/HTTPS)
Auto Provisioning (HTTP/HTTPS)
SNTP Time Synchronization
Syslog Remote Logging
Web server for user phone
book configuration*
*
Optional
*** CCX (Cisco Compatible Extensions) is Cisco compatible
specification version 4 (Optional).
ASD is Application Specific Device. Several features that are exclusively
or primarily use in data applications are not required. Specificationsare
subject to change without notice.
SQ-3100
HARDWARE SPECIFICATIONS
1. INTERFACE
Docking Port for
SQ-3000/SQ-3500
2 Port 10/100Base-T Ethernet
Handset Connector
2.5Φ Stereo Headset Jack
The SQ-3100 Video Conference Handset Cradle extends
the functionality of the SQ-3000 & SQ-3500
Video Conference Handset
combining the convenience
and mobility of a handheld,
with the functionality of a
desktop phone
2. LED INDICATION
2 Charger LEDs
(Phone and Battery Pack)
Speaker-phone LED
MIC-mute LED
Video Disable LED
3. POWER SUPPLY
AC Input: 100 ~ 240Vac, 50/60Hz
DC Output: 5Vdc/2A
4. KEYS
Speaker-phone, MIC-mute,
Video Disable, Volume Up/Down
UniData Voice over Internet Protocol (VoIP) services offer
your business the ability to unite and simplify its
communications infrastructure.
Whether your employees are located at headquarters, a
remote office or even on-the-road, our uniqueVoIP
capabilities instantly turn any place into awork place.
SMB
As your company grows, adding new capacity and capability
is super-fast and easy. It is possibleto just add new devices
and software without adding or updating the wiring
infrastructure or PBX. All of our phones have been tested
with Asterisk, Avaya, Nortel, and Broad-soft, etc. Again,
Unidata dedication to QOS really is evident in every
product they produce, from the superb sound quality,
exceptionally smooth transition between access
points, to the auto-provisioning capabilities
that save a great deal of time when managing larger
installations.
(Small Medium Business)
5. DIMENSIONS
Size: 6.1 x 8.1 x 6.4 in /
15.5 x 20.5 x 16.2 cm
Weight: 24.9oz / 704g
6. TEMPERATURE RANGE
Operation: 32 ~ 122℉ / 0~50℃
Relative Humidity: 10% ~ 90%
7. PACKAGE CONTENTS
Main-unit, Handset, LAN Cable,
Power Supply, AC Cable,
Quick Start Guide
8. COMPLIANCE
KCC, FCC, IC, CE, UL, RoHS
9. OPTION
Wall Mount Bracket
PoE(Power over Ethernet)
