New LED

Product Offerings

from

light

.

2

TCP

®

LED

NEW Product

Offerings

LED Indoor Lighting

PL Lamps

EdgeLit Downlights

HID

DirecT8/DirecT5

T8/T5 Tubes

Liscio

by TCP

Linear Accent Lighting

Luxterior

by TCP

Flat Panel Luminaires

General Purpose Strip Luminaires

General Purpose Strip Retrofi t Kits

Industra

by TCP

High Bay Luminaire

Round High Bay Luminaire

LED Outdoor Lighting

Elements

by TCP

Canopy

Non-Cutoff Wall Pack

Polycarbonate Wall Pack

Wall Mount

Flood Light

w e k n o w

light

.

CONTACT your TCP Sales Representative for availability and pricing

LED PL Lamps

These energy effi cient lamps are the perfect solution for replacing fl uorescent PL lamps. Designed for use in commercial downlights, they are ideal for a variety of retail, offi ce and hospitality applications.

Fits G24q / GX24q bases.

GREAT FEATURES & BENEFITS

Replaces 26W, 32W, 42W quad and triple-tube

PL fl uorescent lamps

Contains no mercury

Long life: 50,000 hours

Instant on/off

Dimmable

Ballast compatible

120-277V

Horizontal and vertical operation options

The base of the horizontal lamp can be rotated to fi t any application

TCP LED

9W PL Horizontal

9W PL Vertical BR30

17W PL Vertical BR30

19W PL Vertical BR40

REPLACEMENT

26W

26W

26-42W

26-42W

AVERAGE

LUMENS

AVERAGE

LPW

950

1000

1600

2250

105.5

111.1

94.1

118.4

LIMITLESS APPLICATIONS

General Lighting

Ceiling Fixtures

Sconces

No rewiring of fi xture— simply replace fl uorescent lamp with LED lamp

Fits G24q / GX24q bases

L19PLVD50

L9PLHD50

Dimmable

L17PLVD50 L9PLVD50

Base of L9PLHD50 rotates

180° to fi t any application

180°

Color Temperatures

Visit tcpi.com for more information

3

4

LED EdgeLit Downlights

TCP’s new Dimmable EdgeLit Downlights are the perfect choice for new construction and retrofi t opportunities when a sleek, integrated look is preferred.

GREAT FEATURES & BENEFITS

Long life: 40,000 hours

Excellent color consistency (CRI)

Dimmable

Highly effi cient LEDs and Driver

UL approved for damp locations

Easy installation

TCP LED

6” 11.6W Edgelit Downlight

4” 8.5W EdgeLit Downlight

AVERAGE

LUMENS

800

500

AVERAGE

LPW

69

58.8

Fully

Dimmable

5/6" EdgeLit Downlight

Color Temperatures

LIMITLESS APPLICATIONS

6” and 4” Diameter Sizes

Retrofi ts

New Construction

Ideal for retrofi t or new construction downlight applications

Visit tcpi.com for more information

LED HID Lamps

TCP’s energy effi cient LED HID lamps are an excellent choice for replacing traditional metal halide products. Designed for indoor and outdoor use where low maintenance and high lumen output is required.

Fits EX39/E39/E26 bases.

GREAT FEATURES & BENEFITS

Replaces 400W, 250W, 175W, 100W and 70W metal halide lamps

Operates on less energy than traditional metal halides

Long life: 50,000 hours

Excellent color consistency & CRI

360° (omni-directional) beam angle

Universal 100-277V

UL approved for damp locations

TCP LED

100W MH400

80W MH250

45W MH175

45W MH175

24W MH100

19W MH70

BASE

EX39

EX39

EX39

E26

E26

E26

REPLACEMENT

400W

250W

175W

175W

100W

70W

AVERAGE

LUMENS

AVERAGE

LPW

13500

10400

5850

5850

3120

2565

130

130

130

130

130

130

LIMITLESS APPLICATIONS

Street Lights

Parking Lots

Roadways

Warehouses

Landscape Lighting

Industrial Lighting

L100MHX3950 L80MHX3950

L24MHE2650 L19MHE2650

Color Temperatures

Fits EX39/E39/E26 bases

L45MHE2650

Visit tcpi.com for more information

5

6

LED T8

&

T5 Tubes

TCP has a new generation of LED compatible replacement tubes for linear fi xtures. These T8 and T5 tubes are dimmable and feature multiple ballast compatibility including Instant Start and Rapid Start.

GREAT FEATURES & BENEFITS

>50% energy savings

Long life: 50,000 hours

Dimmable

Programmable, Instant Start, Rapid Start ballast compatible or compatible with most traditional fl uorescent ballast

No rewiring of fi xture—simply replace fl uorescent lamp with LED lamp

Instant on/off

Mercury free

Rated for enclosed fi xtures

2’, 3’, 4’ and U6 options

TCP LED DIMMABLE

REPLACEMENT

32W

AVERAGE

LUMENS

2050 15W 4’ T8 Shatterproof Instant Start/Rapid Start/

Electronic Ballast Compatible

12W 4’ T8 Instant Start/Rapid Start Dimmable

11W 4’ T8 Instant Start/Rapid Start

HIgh Effi cacy Dimmable

11W 3’ T8 Instant Start/Rapid Start Dimmable

9W 2’ T8 Instant Start/Rapid Start Dimmable

32W

32W

25W

17W

25.5W 4’ T5 Shatterproof Electronic Ballast Compatible 54W HO

13W 4’ T5 Shatterproof Electronic Ballast Compatible 28W

1800

1900

1500

1200

3190

1850

13W U6 Instant Start/Rapid Start Dimmable 32W 1850

LIMITLESS APPLICATIONS

Offi ces

Lobbies

Restaurants

Retail Stores

Schools

Health Care

4’, 3’ and 2’

LED T8 Glass Tubes

4’ shatterproof available

4’ LED T5 Shatterproof f

Glass Tube

Fully

Dimmable

Color Temperatures

TCP LED tube replacements for

2, 3, 4 foot linear and 6 inch u-bend fi xtures, featuring multiple ballast compatibility including

Instant Start/Rapid Start

Visit tcpi.com for more information

7

8

LED Linear

Accent Lighting

TCP’s LED Linear Accent Lighting combines superior light quality, high CRI and excellent uniformity to fi t a variety of architectural accent and display lighting applications.

This system features an unique optical design to provide even light distribution within the space. The slim, low-profi le light bars discreetly fi t into shallow spaces and come in multiple lengths that can be linked together for long runs of continuous light.

A variety of power supplies, switches, mounting clips and other accessories allow designers to mix-and-match components for a customizable solution that best fi ts their application.

GREAT FEATURES & BENEFITS

Energy effi cient

Long life: 50,000 hour

Sleek, low-profi le design with integrated LEDs

Dimming and motion sensor options available

High 90+ CRI

Multiple lengths & accessories available

Linkable

Easy to install—mounting brackets

LIMITLESS APPLICATIONS

Under Cabinet Lighting

Offi ce Task Lighting

Under Shelf Display Lighting

Shallow Cove

Architectural Accent Lighting

Coming Soon

Fully

Dimmable

Color Temperatures

Available in multiple lengths that can be linked together for just the right fi t

Visit tcpi.com for full options and accessories

LED Flat Panel Luminaires

TCP’s LED Flat Panel luminaires feature a slim, low-profi le design with full panel diffusion and uniformity. Multiple sizes, color temperatures and mounting kits are available to meet a variety of architectural designs and aesthetic needs.

It offers a cost effective solution to maximize savings and take advantage of utility rebates without sacrifi cing performance.

1 x 4

2 x 4

GREAT FEATURES

& BENEFITS

Up to 58% less energy than fl uorescent alternatives

Long 50,000 hour rated life

Excellent color consistency & CRI

Mercury free

Fits standard 1” and 9/16”

T-bar grid ceilings

Utilizes edge-lit technology

Slim, low-profi le design

Fully

Dimmable

Color Temperatures

LIMITLESS APPLICATIONS

Offi ces Schools

Restaurants

Retail Stores

Hospitality

Health Care

Grid Ceilings

LED Flat Panel Luminaires are offered in multiple color temperatures, sizes, and mounting options to seamlessly fi t into your designs

2 x 2

Visit tcpi.com for full options

9

10

LED General Purpose Strip

LUMINAIRES

TCP’s LED General Purpose Strip Luminaires are designed to efficiently deliver robust performance while maximizing savings.

These integrated LED luminaires significantly reduce energy consumption compared to fluorescent systems, providing instant energy savings along with the ability to take advantage of potential utility rebates. A long 50,000 hour rated life significantly decreases maintenance labor and material costs over the life of the fixture.

TCP’s General Purpose Strip incorporates a ribbed, frosted white diffuser lens to protect the LEDs and minimize glare, while delivering bright, uniform light.

Color Temperatures

Fully

Dimmable

GREAT FEATURES & BENEFITS

Energy efficient design delivers >130 LPW

Long life: 50,000 hour

Excellent color consistency & CRI

0-10V dimming driver comes standard

Mercury free—great for all environments

UL damp location rated

Occupancy sensor with daylight harvesting (optional)

Emergency backup (optional)

TCP’s LED General Purpose

Strips are available in 2, 4 and 8 foot strip fixtures

Easy installation— surface mount, suspended or pendant

LIMITLESS APPLICATIONS

General Lighting Storage

Task Lighting

Aisles

Manufacturing Facilities

Retail

Warehouses

Visit tcpi.com for full options and accessories

LED General Purpose Strip

RETROFIT KITS

TCP’s LED General Purpose Strip Retrofit Kits are designed to easily replace the fluorescent lamps and ballast in an existing fluorescent strip fixture with an integrated LED lighting solution. The universal design fits most 4.25” and 5.25” wide T8/T12 fluorescent strips.

These LED retrofit kits significantly reduce energy consumption compared to the existing fluorescent systems, providing instant energy savings along with the ability to take advantage of potential utility rebates. A long 50,000 hour rated life significantly decreases maintenance labor and material costs over the life of the system.

TCP’s LED General Purpose Strip Retrofit Kits incorporate a ribbed, frosted white diffuser lens to protect the LEDs and minimize glare, while delivering bright, uniform light.

Color Temperatures

Fully

Dimmable

GREAT FEATURES & BENEFITS

Energy efficient design delivers >130 LPW

Long life: 50,000 hour

Excellent color consistency & CRI

0-10V dimming driver comes standard

Mercury free—great for all environments

UL damp location rated

Occupancy sensor with daylight harvesting (optional)

LIMITLESS APPLICATIONS

General Lighting

Task Lighting

Aisles

Warehouses

Storage

Manufacturing Facilities

Retail

TCP’s LED General Purpose

Strip Retrofit Kits easily replace existing fluorescent lamp and ballasts with an integrated LED system in 4 and 8 foot strip fixtures

Easy installation—surface mounts to existing fluorescent strip fixture housing

Visit tcpi.com for more information

11

12

LED High Bay

for mounting heights up to 60 feet.

uniform light to maximize energy savings and utility rebates. The long

50,000 hour rated life signifi cantly decreases maintenance labor and easy integration with a variety of controls options.

GREAT FEATURES & BENEFITS

Energy effi cient design delivers >130 LPW

Long life: 50,000 hour

Multiple lumen packages

Mercury free—great for all environments

Heavy duty steel housing

LIMITLESS APPLICATIONS

Warehouses & Distribution Centers

Commercial Facilities

Aisles (open & stock)

Retailers

Schools & Municipalities

Field Houses & Gymnasiums

Open Ceiling Designs

Coming Soon

Fully

Dimmable

Color Temperatures

The LED High Bay’s uniquely designed housing discreetly hides drivers, sensors and other components to maintain a sleek, modern look. An integrated lens protects the

LEDs, while minimizing glare and improving overall aesthetics.

Visit tcpi.com for full options and accessories

LED Round High Bay

TCP’s is bringing the benefi ts of LED to an easy-to-install Round

High Bay fi xture. This robust fi xture can be paired with optional acrylic or aluminium refl ectors to meet a variety of application needs.

A 0-10V dimming driver enables easy integration with a variety of controls options.

GREAT FEATURES & BENEFITS

Energy effi cient design delivers >130 LPW

Long life: 50,000 hour

Sleek, circular design with integrated LEDs

Multiple lumen packages

Mercury free—great for all environments

IP65 rated

Acrylic and aluminium refl ectors (optional)

LED Round High Bay with acrylic refl ector

by

LED Round High Bay

Color Temperatures

LIMITLESS APPLICATIONS

Warehouses & Distribution Centers

Commercial Facilities

Aisles (open & stock)

Retailers

Schools & Municipalities

Field Houses & Gymnasiums

Open Ceiling Designs

Coming Soon

Dimmable

Multiple acrylic and aluminum refl ectors options to meet a variety of application and aesthetic needs

Visit tcpi.com for full options and accessories

13

14

LED Canopy

OUTDOOR LUMINAIRE

TCP’s LED Canopy lights are a brilliant alternative to metal halide fi xtures.

They effi ciently deliver bright, uniform light for energy savings and rebate eligibility. The long 50,000 hour rated life signifi cantly decreases maintenance labor and material costs over the life of the fi xture.

The sleek die-cast aluminum housing mounts directly to the recessed junction box using the included quick-mount plate. A low-profi le, frosted white, polycarbonate lens protects the LEDs while minimizing glare. An integrated photosensor comes standard for dusk-to-dawn control.

GREAT FEATURES & BENEFITS

Energy effi cient

Long life: 50,000 hours

Sleek, low-profi le style with integrated LEDs

Mercury free—great for all environments

Integrated 120-277V photosensor

UL approved for wet locations

Easy to install—surface or pendant mount

LIMITLESS APPLICATIONS

Canopies

Entryways

Parking Garages

Exterior Ceilings

Security Lighting

Color Temperature

Unique quick mount design for easy surface mount installation

Visit tcpi.com for more information

15

16

LED Wall Pack

NON-CUTOFF OUTDOOR LUMINAIRE

TCP’s LED Non-Cutoff Wall Pack combines the look of a traditional wall pack with the benefi ts of LED. An effi cient alternative to metal halide, these wall packs deliver bright, uniform light while providing energy savings and rebate eligibility. A long 50,000 hour rated life signifi cantly decreases maintenance labor and material costs over the life of the fi xture.

The robust die-cast aluminum housing incorporates an impact resistant borosilicate glass lens. An integrated photosensor comes standard for dusk-to-dawn control. It mounts directly to a standard junction box for easy retrofi t of traditional fi xtures.

GREAT FEATURES & BENEFITS

Energy effi cient

Long life: 50,000 hour

Mercury free—great for all environments

Traditional fi xture style with integrated LEDs

Integrated 120-277V photosensor

UL approved for wet locations

Easy to install—mounts to standard junction box

LIMITLESS APPLICATIONS

Site Lighting

Security Lighting

Pathways

Entrances

Perimeters

Color Temperature

Die-cast aluminum housing with impact resistant glass lens matches look of traditional wall packs, but with all of the benefi ts of LED

Visit tcpi.com for more information

LED Wall Pack

POLYCARBONATE OUTDOOR LUMINAIRE

TCP’s LED Polycarbonate Wall Pack is an effi cient alternative to traditional metal halide and fl uorescent wall packs. It delivers bright, white light while providing energy and maintenance savings over the life of the fi xture.

The bronze polycarbonate housing has a die-cast aluminum mounting plate and features a prismatic lens for uniform light distribution. The integrated photosensor comes standard for dusk-to-dawn control.

GREAT FEATURES & BENEFITS

Energy effi cient

Long life: 50,000 hour

Integrated 120-277V photosensor

UL approved for wet locations

Easy to install—mounts to standard junction box

LIMITLESS APPLICATIONS

Security Lighting

Entrances

Pathways

Perimeters

Color Temperature

Polycarbonate housing features a die-cast aluminum mounting plate and prismatic lens

Visit tcpi.com for more information

17

18

LED Wall Mount

OUTDOOR LUMINAIRE

TCP’s LED wall mounted luminaire offers a stylish alternative to traditional jelly jar fi xtures. It effi ciently delivers bright, uniform light and a long 50,000 hour life for energy and maintenance savings over the life of the fi xture.

The sleek die-cast aluminum housing is IP65 wet location rated and incorporates a slim, high-impact lens to protect the LEDs and minimize glare. An integrated photosensor comes standard for dusk-to-dawn control. The luminaire easily mounts directly to the recessed junction box using the included quick-mount plate.

GREAT FEATURES & BENEFITS

Long 50,000 hour rated life

Mercury free—great for all environments

High-impact polycarbonate lens

Integrated 120-277V photosensor

UL approved for wet locations

LIMITLESS APPLICATIONS

Doorways

Security Lighting

Perimeters

Walkways

Color Temperature

TCP’s LED wall mounted outdoor luminaire is a sleek alternative to traditional jelly jar fi xtures to fi t a variety of aesthetic needs

Visit tcpi.com for full options

LED Flood Light

OUTDOOR LUMINAIRE

TCP’s LED Small Flood Light effi ciently delivers bright, white light and robust performance. The long 50,000 hour rated life signifi cantly decreases maintenance labor and material costs over the life of the fi xture.

The compact die-cast aluminum housing is wet location rated and includes a knuckle for easy installation. An integrated photosensor comes standard for dusk-to-dawn control.

GREAT FEATURES & BENEFITS

Energy effi cient

Long life: 50,000 hour

Integrated 120V photosensor

UL approved for wet locations

Easy to install—standard junction box or PVC pipe

LIMITLESS APPLICATIONS

Security Lighting

Landscapes

Building Facades

Signage

Color Temperature

Illuminate outdoor spaces with this versatile compact fl ood light

Visit tcpi.com for more information

19

©TCP 2017/WF76914

To view our DLC qualifi ed products, please consult the DLC Qualifi ed Products List at www.designlights.org/qpl.

For more information on the quality and care that TCP ® can deliver, call us at

800.324.1496

or visit tcpi.com

325 Campus Drive | Aurora, Ohio 44202 | P: 800.324.1496 | F: 877.487.0516

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Related manuals

Download PDF

advertisement
