ProxKey® II
1346
Proximity Keyfob
Application
The RF-programmable ProxKey® II proximity keyfob
incorporates proximity technology into a convenient
device approximately the size of an automotive key.
Features
•
•
•
•
•
Offers universal compatibility with all HID proximity
readers.
Provides an external number for easy identification
and control.
Can be placed on a key ring for convenient entry.
Supports formats up to 85 bits, with over 137 billion
codes.
Using HID’s ProxProgrammer, card vendors can
ship proximity keyfobs, custom programmed to
their customers’ requirements, from their own
inventory. Enables smaller order quantities and
overnight delivery. (Check with vendor for
availability.)
Works with HID’s pcProx!
An ASSA ABLOY Group company
ProxKey® II
Features
Specifications
Proven, Reliable Technology
Offers extremely consistent read range. Unaffected by body
shielding or variable environmental conditions, even when
close to keys and coins.
Typical Maximum* Read Range
ProxPoint® Plus reader-up to 1.5" (3.7 cm)
MiniProx™ reader-up to 2" (5 cm)
ThinLine II® reader-up to 2" (5 cm)
ProxPro® reader-up to 3" (7.5 cm)
ProxPro®II reader-up to 4” (10.2 cm)
Prox80TM-up to 2” (5.1 cm)
MaxiProx® reader-up to 12" (28 cm)
Small and Convenient
Can be carried with keys in pocket or handbag.
Cross-reference
A cross-reference list correlating the external card number
and the programmed ID number is provided for easy system
administration.
Security
Offers over 137 billion unique codes.
Long Life
Passive, no-battery design allows for an infinite number of
reads.
Durability
ABS package is resistant to cracking and breaking.
Warranty
Lifetime warranty against defects in materials and
workmanship (see complete sales policy for details).
*Dependent on local installation conditions.
Dimensions
1.90" x 0.900" x 0.550"
(4.3 x 2.29 x 1.4 cm)
Keyfob Construction
Ultrasonically welded, ABS shell
Operating Temperature
-50° to 160° F (-45° to 70° C)
Weight
0.26 oz. (7.4 gm)
Part Number
Base Part No. 1346
Description
RF-programmable, 125 kHz, charcoal gray,
customer-specified ID Numbers,
key ring included.
Options
• External card numbering (inkjet or
laser engraving)
(Please see “How to Order Guide” for a
description of the options and associated
part numbers.)
LIT1346DS 8/02, supersedes 6/01
www.HIDCorp.com
Printed in the U.S.A.
Specifications subject to change without notice.
9292 Jeronimo Road
Irvine, CA 92618-1905 U.S.A.
(949) 598-1600 (800) 237-7769
FAX (949) 598-1690
©2002 HID Corporation
