TomTom app

1.

Getting started

Getstarted

To start the TomTom app, tap the icon in your iPhone.

The language used for buttons and menus in the TomTom app is the same as the language you selected in the iPhone settings.

Note

: There are some languages that are not supported by the TomTom app. In this case,

US English is used for buttons and menus in the application.

Updating

If you have a previous version of the TomTom app on your iPhone or iPod touch, you need to update it. To do this, go to the Apple App Store and download your free update before continuing to read this guide.

GPS reception

The iPod touch and some models of the iPhone do not include a GPS receiver. To use these devices for navigation, you need to use them with a GPS accessory, such as the

TomTom car kit.

The car kit includes a GPS receiver, a speaker for playing navigation instructions, and a microphone for making hands-free calls while you are driving. We recommend using the

TomTom car kit with all iPhones and the iPod touch.

For more information, go to

tomtom.com/iphone

.

When you first start the TomTom app, it may need a few minutes to determine your GPS position and show your current position on the map.

To make sure you have good GPS reception, you should use your device outdoors. Large objects such as tall buildings can sometimes interfere with reception.

Note:

If your device has no GPS reception, TomTom app uses position information from

WiFi networks or mobile phone towers. This information is used to find your approximate position and for route planning. TomTom app cannot give you route instructions until it has GPS reception.

2

2.

Planning a route

Planroute

Important:

For safety reasons, always plan your route before you start your trip.

Planning routes with the TomTom app is easy. To plan a route, follow the steps below.

1. Tap the screen to open the Main Menu.

Note

: When you start the TomTom app for the first time, the Main Menu is shown.

2. Tap

Navigate To...

3. Tap

Address.

Note

: When planning a trip for the first time the TomTom app asks you to choose a state or country. Your choice is saved and used for all routes you plan. You can change this setting at any time by tapping the country flag. To view the country flag, tap the button next to the search box.

4. Start to type the name of the place where you want to go.

As you type, the names of the towns that match what you have typed are shown. When your destination appears in the list, tap the name of the town to set the destination.

5. Start to type the name of the street and select it when it is shown.

Just as for place names, the names of the streets that match what you have typed are shown. When your destination appears in the list, tap the name of the street to set the destination.

Tip:

To show more search results and hide the keyboard, tap this button. This also shows the navigation bar so that you can return to the previous screen.

6. Now enter the house number of your destination and then tap

Select.

You can also select the point where two streets meet by tapping

Crossing

.

The route is calculated. If available on your map, IQ Routes information is used to plan the best possible route taking into account the real average speeds measured on the roads.

By default, the fastest route is planned. To set the type of route that should be planned by default, go to the Advanced settings in the Settings menu.

7. When the route has been calculated, tap

Done.

3

The TomTom app immediately begins to guide you to your destination, using both spoken instructions and on-screen directions.

Route summary

After planning a route, you see a summary of your route.

The route summary shows an overview map of your route and the total trip time including delays caused by both incidents and busy roads.

You can see the route summary at any time by tapping the right side of the status bar.

Other destination options

When you tap

Navigate To...

, you can set your destination in many ways, not just by entering the address. The other options are listed below:

Home

Tap this button to navigate to your Home location.

If you haven’t set your Home location, you can do so by tapping

Home

. You can also set your Home location in the Settings menu.

Tap this button to select a Favorite as your destination.

Favorite

Tap this button to enter an address as your destination.

Address

Tap this button to select your destination from a list of places you have recently used as destinations.

Recent

Destination

Tap this button to do a local search and then use one of the search results as your destination.

Local Search

4

Tap this button to navigate to a Point of Interest (POI).

Point of Interest

Tap this button to navigate to the address of a contact on your device.

Contact

Tap this button to enter a ZIP code as a destination.

Note:

This option is not available in all countries.

ZIP code

Tap this button to select a point on the map as your destination using the Map Browser.

Point on Map

Finding alternative routes

Once you have planned a route, you may want to change something about the route, without changing your destination. It could be for one of these reasons:

• You can see a roadblock or a line of traffic ahead.

• You want to travel via a particular location, to pick someone up, stop for lunch or fill up with gas.

• You want to avoid a difficult intersection or a road you don’t like.

Find Alternative

To change your route, tap

Find Alternative...

in the

Route Options

menu.

You can open the route options as follows:

• Tap

Route Options

in the Main Menu.

Note

: The

Route Options

button is only shown if you have planned a route.

• Tap

Options

on the Route Summary screen after you plan a route.

• Tap the right hand section of the status bar in the Driving View to open the Route Summary screen, then tap

Options

.

Then select one of the following options:

Minimize Delays

Tap this button to re-plan your route based on the latest traffic information.

This button is only available if you have a subscription to TomTom

Traffic.

5

Calculate

Alternative

Tap this button to calculate an alternative to the route already planned.

The TomTom app looks for another route from your current location to your destination.

If you decide you would prefer to use the original route after all, tap

Recalculate Original

.

Apart from the roads near your position and near your destination, the new route uses totally different roads to reach your destination.

This is an easy way of calculating a totally different route.

Tap this button to return to the original route. This ignores any previous instructions you have given to avoid roadblocks or travel via a particular location.

Recalculate

Original

Avoid

Roadblock

Travel Via...

Avoid Part of

Route

Tap this button if you can see a roadblock or a line of traffic ahead.

You then have to choose how much of the route ahead you want to avoid.

Choose from the different options available. The TomTom app recalculates your route avoiding the section of the route for the distance you selected.

Don’t forget that once a new route is calculated, you may have to turn off the road you are on very soon.

If the roadblock suddenly clears, tap

Recalculate Original

to return to your original route.

Tap this button to change your route so that it passes a particular location, perhaps to pick someone up on the way. When you do this, a marker is shown on the map for the location you choose to travel via.

You choose the location you want to pass in the same way as you choose a destination. This means you can select from all the same options that are offered when you choose a destination, for example,

Address

,

Favorite

,

Point of Interest

and

Point on Map

.

The TomTom app will calculate a new route to your destination that passes the location you chose. Unlike your final destination, the

TomTom app does not inform you when you pass by this location.

Tap this button to avoid a part of the route. Use this button if you see that your route includes a road or junction you don’t like, or which is well-known for traffic problems.

You then choose the road you want to avoid from a list of the roads on your route.

Planning a route in advance

You can use the TomTom app to plan a route in advance, selecting your starting point and your destination. You could, for example, do the following:

• Find out how long a trip is going to take before you start.

You can also compare trip times for the same route at different times of the day or on different days of the week. The TomTom app uses IQ Routes when planning a route. IQ

Routes calculates routes based on the real average speeds measured on roads.

6

• Check the route of a trip you are planning.

• Check a route for someone who is coming to visit you and then explain the route to them.

To plan a route in advance, follow these steps:

1. Tap the screen to bring up the main menu.

2. Tap

Advanced Planning

.

Advanced Planning

3. Select the starting point for your trip in the same way that you would select your destination.

4. Set the destination for your trip.

5. Choose the type of route that should be planned.

Fastest Route

- the route which takes the least time.

Shortest Route

- the shortest distance between the locations you set. This may not be the quickest route, especially if the shortest route is through a town or city.

Avoid Highways

- a route which avoids highways.

Walking Route

- a route designed for making the trip on foot.

Bicycle Route

- a route designed for making the trip on a bicycle.

Limited Speed

- a route for a vehicle which can only be driven at a limited speed. You have to specify the maximum speed.

6. If IQ Routes is supported by your map, you can choose when you will make the journey you are planning. You can set the date and time in 5 minute intervals.

The TomTom app uses IQ Routes to work out the best possible route at that time, using the real average speeds measured on roads. In this way you can compare how long a trip takes at different times of day, or on different days of the week.

7. The TomTom app plans the route between the two locations you selected.

7

3.

Driving View

Driving View

1. Music button.

2. Your current position.

3. The remaining distance of your trip and your current speed. If known, the speed limit is also shown.

4. Navigation instruction for the road ahead.

Tap this area to open the volume control and to repeat the previous instruction.

5. The remaining trip time and the estimated arrival time.

Tap this area to open the Route Summary screen.

6. Traffic button.

Tap this button to buy a traffic subscription or to open the traffic sidebar.

The following items are only available if you have a traffic subscription:

7. Information about the traffic incident that this box points to on the traffic sidebar.

8. Traffic sidebar.

Moving around in the Driving View

After you plan a route, you are shown the Driving View along with detailed information about your current location.

Tap the center of the screen at any time to open the Main Menu.

Zoom by tapping the screen twice with one finger to zoom in, or tap once with two fingers at the same time to zoom out.

You can also zoom in and out by pinching your fingers together and apart on the screen.

Setting the volume

Tap the left hand side of the status bar in the Driving View to see the volume control.

Move the slider from left to right to increase the volume for both music and voices at the same time.

8

Playing music

Tap the music button to play or pause music.

You can tap play/pause, next and previous to control the music track that is currently playing.

The buttons disappear on their own after a few seconds or you can tap the musical note again to make the buttons disappear yourself.

Driving View options

Use these buttons in the Main Menu to change the Driving View:

Mute Sound

Tap this button to mute all sounds from the TomTom app.

If the sound is muted, this button changes to

Enable Sound

. Tap the button again to switch sound back on.

When the sound is muted, the mute sound indicator is shown in the bottom left corner of the Driving View.

Tap this button to use night colors on the map. If night colors are being used, this button changes to

Day Colors.

Tap the button again to switch back to day colors.

Night Colors

2D Map

Tap this button to use a 2D map in the Driving View.

If the 2D map is being used, this button changes to

3D Map

. Tap the button again to use the 3D map.

Map settings

To set the appearance of the map, tap

Change Settings

in the Main Menu, then tap

Map

to change these settings:

Day Colous / Night Colors

Tap

Day Colors

to select a day color scheme consisting of bright colors.

Tap

Night Colors

to select a night color scheme consisting of darker colors.

If

Auto-Switch

is on, your TomTom app automatically switches from day to night colors and back again according to the time of day.

2D Map North Up

When this setting is on, the 2D map is fixed in place with north at the top of the screen.

When this setting is off, the 2D map moves so that your current direction is always at the top of the screen.

Show Current Street

9

When this setting is on, the current street name or number is shown in the Driving View, just below your position on the map.

Streets on Map

When this setting is on, the names of streets are shown on the map.

POIs on Map

When this setting is on, POIs are shown on the map. Use the setting

POI Types

to select which POIs are shown.

10

4.

Advanced Lane Guidance

Advanc

Guid-

Advanced Lane Guidance

Your TomTom app helps you prepare for highway exits and intersections by showing you which lane you should be in.

Note

: This information is not available for all junctions or in all countries.

For some exits and junctions, an image shows the lane you should be in. To turn the images off, switch

Lane images

to off in the Advanced Settings menu.

For other exits and junctions, your TomTom app shows the lane you should take in the status bar.

11

5.

Route options

Route

Options

You can find out more information about your route or change the route using the route options.

You can open the route options as follows:

• Tap

Route Options

in the Main Menu.

Note

: The

Route Options

button is only shown if you have planned a route.

• Tap

Options

on the Route Summary screen after you plan a route.

• Tap the right hand section of the status bar in the Driving View to open the Route Summary screen, then tap

Options

.

Finding alternative routes

Once you have planned a route, you may want to change something about the route, without changing your destination. It could be for one of these reasons:

• You can see a roadblock or a line of traffic ahead.

• You want to travel via a particular location, to pick someone up, stop for lunch or fill up with gas.

• You want to avoid a difficult intersection or a road you don’t like.

Find Alternative

To change your route, tap

Find Alternative...

in the

Route Options

menu.

You can open the route options as follows:

• Tap

Route Options

in the Main Menu.

Note

: The

Route Options

button is only shown if you have planned a route.

• Tap

Options

on the Route Summary screen after you plan a route.

• Tap the right hand section of the status bar in the Driving View to open the Route Summary screen, then tap

Options

.

Then select one of the following options:

Minimize Delays

Tap this button to re-plan your route based on the latest traffic information.

This button is only available if you have a subscription to TomTom

Traffic.

12

Calculate

Alternative

Tap this button to calculate an alternative to the route already planned.

The TomTom app looks for another route from your current location to your destination.

If you decide you would prefer to use the original route after all, tap

Recalculate Original

.

Apart from the roads near your position and near your destination, the new route uses totally different roads to reach your destination.

This is an easy way of calculating a totally different route.

Tap this button to return to the original route. This ignores any previous instructions you have given to avoid roadblocks or travel via a particular location.

Recalculate

Original

Avoid

Roadblock

Travel Via...

Avoid Part of

Route

Tap this button if you can see a roadblock or a line of traffic ahead.

You then have to choose how much of the route ahead you want to avoid.

Choose from the different options available. The TomTom app recalculates your route avoiding the section of the route for the distance you selected.

Don’t forget that once a new route is calculated, you may have to turn off the road you are on very soon.

If the roadblock suddenly clears, tap

Recalculate Original

to return to your original route.

Tap this button to change your route so that it passes a particular location, perhaps to pick someone up on the way. When you do this, a marker is shown on the map for the location you choose to travel via.

You choose the location you want to pass in the same way as you choose a destination. This means you can select from all the same options that are offered when you choose a destination, for example,

Address

,

Favorite

,

Point of Interest

and

Point on Map

.

The TomTom app will calculate a new route to your destination that passes the location you chose. Unlike your final destination, the

TomTom app does not inform you when you pass by this location.

Tap this button to avoid a part of the route. Use this button if you see that your route includes a road or junction you don’t like, or which is well-known for traffic problems.

You then choose the road you want to avoid from a list of the roads on your route.

Route Demo

Tap this button to watch a demo of the trip. To stop a demo, tap

Stop

Demo

in the

Route Options

menu, when a demo is running.

Route Demo

13

Clear Route

Tap this button to clear the currently planned route.

Clear Route

Instructions

Tap this button for a list of all the turn instructions on the route.

Instructions

Map of Route

Tap this button to see an overview of the route using the Map Browser.

Map of Route

14

6.

Settings

To change the way the TomTom app looks and behaves, tap

Change Settings

in the Main

Menu.

Set Home Location

Tap this option to set or change your Home location. Set your Home location in the same way that you select a destination.

Having a Home location means that you have a quick and easy way to navigate there, by tapping the Home button in the

Navigate To...

menu

Your Home location can be a place you go often, for example, your office. It can be your actual home address, but it can also be any address you like.

Voice

Tap this option to select the voice used for instructions. The TomTom app has two different kinds of voices:

• Computer voices

The TomTom app makes use of text-to-speech technology to generate computer voices. They provide spoken instructions while you are driving and can pronounce street names and status messages.

A text-to-speech program converts written text, for example an instruction like “Turn right”, into the sound of a human voice.

Note

: Computer voices are not available in all regions or for all languages.

If you select a human voice, this can give instructions but is not able to read street names aloud. If you would like street names to be included with instructions, you need to select a computer voice.

• Human voices

These are recorded by an actor.

When you select a voice, a sample of that voice is played.

You can select a voice in any language. The language used for menus and buttons does not change if you select a voice in a different language.

Alerts

Tap this option to turn on safety alerts.

Note:

Alerts are not available in all regions.

Safety Camera

15

Use this setting to switch on visual warnings in the Driving View. You can also choose an alert sound.

If both visual warnings and sounds are set to on, the safety camera location is shown on the map and a warning sound is played. This warns you that you are approaching an area where a safety camera is located.

Speed Limit

Use this setting to warn you when you are driving above the speed limit. You can also choose an alert sound.

Note:

Speed limit alerts should not be relied on exclusively when driving. To ensure you have the latest safety camera information, regularly check the App Store for updates for the TomTom app.

Audio

Tap this option to set the following music and volume options:

Fade Music

Use this setting to fade the music when instructions and warnings are given.

When this setting is off, the music pauses instead of fading when instructions and warnings are given.

Voice Volume

Use this setting to set the volume of voice instructions as a percentage of the music volume. For example, move the slider to the middle of the slider bar to set the volume of voice instructions to be 50% of the music volume.

If the slider is set to off, the music volume and voice volume are set to the same level.

Tip:

The

Voice Volume

option always applies and is independent of the

Fade Music

option. You cannot set the volume of voice instructions to be louder than the music volume.

Map

Day Colous / Night Colors

Tap

Day Colors

to select a day color scheme consisting of bright colors.

Tap

Night Colors

to select a night color scheme consisting of darker colors.

If

Auto-Switch

is on, your TomTom app automatically switches from day to night colors and back again according to the time of day.

2D Map North Up

When this setting is on, the 2D map is fixed in place with north at the top of the screen.

When this setting is off, the 2D map moves so that your current direction is always at the top of the screen.

Show Current Street

When this setting is on, the current street name or number is shown in the Driving View, just below your position on the map.

Streets on Map

When this setting is on, the names of streets are shown on the map.

16

POIs on Map

When this setting is on, POIs are shown on the map. Use the setting

POI Types

to select which POIs are shown.

Route planning

Using the Route planning settings, you can set how routes are planned.

Default Route Type

Use this option to select the type of route planned when you plan a route.

You can choose from these types of routes:

Fastest

- the fastest route to your destination.

Shortest

- the shortest route to your destination. This may take much longer than the fastest route.

Avoid Highways

- this type of route avoids all highways.

Walking Routes

- this type of route is optimized for walking.

Bicycle Routes

- this type of route is optimized for bicycles.

Limited Speed

- if you select this type of route, you must enter a maximum speed for your vehicle. The route planned takes this restriction into account.

Always Ask Me

- if you select this option, you will always be asked to select the type of route that should be planned.

You can also set how these types of roads are handled when a route is planned:

Toll Roads

Ferry Crossing

HOV Lanes

Unpaved Lanes

For each of these types of roads you can select from the following options:

Avoid

- the type of road is always avoided automatically.

Don’t Avoid

- the type of road is not avoided automatically.

Always Ask

- when the route is planned, you have to select how to handle these roads when they occur on your route.

Distance Units

You can choose to use either Kilometers or Miles for all distances and speeds.

About

Tap

About

for information about the application and map version as well as copyright and the license notices.

Advanced

Tap this option to set the following options:

Lane Images

Use this setting to turn lane images on and off.

17

Lane images help you prepare for highway exits and junctions by showing you which lane you should be in.

IQ Routes™

Use this setting to turn IQ Routes on and off.

IQ Routes is used when you plan a route. Your route is calculated using information about the real average speeds measured on roads, so your route may change depending on the time of day and day of the week.

Note:

IQ Routes is not available in all regions.

Traffic

The TomTom Traffic service is a subscription service.

If you have a subscription and use this setting to turn it on, traffic incidents are shown in a traffic sidebar and in the Browse Map screen. When planning a route, delays are displayed and taken into account.

For more information about services and subscriptions, go to

tomtom.com/services

.

Note

: TomTom traffic information services are not supported in all countries.

GPS Enhancer

Use this setting to turn the TomTom GPS Enhancer on and off. The GPS Enhancer helps the GPS receiver in your device locate your position more accurately.

Reset to Defaults

Tap this setting to restore the factory settings to the TomTom app.

All your settings, including Favorites and your Home location, are deleted and the application closes.

18

7.

Main Menu

To open the Main Menu from the Driving View, tap the screen.

When you start the TomTom app, and no route is planned, the Main Menu opens.

To return to the Driving View at any time, tap

Cancel

.

These buttons are available in the Main Menu:

Tap this button to start planning a route.

Navigate To...

Tap this button to find out more information about your route or change the route.

Note

: This button is only shown if a route is planned.

Route

Options

Mute Sound

Tap this button to mute all sounds from the TomTom app.

If the sound is muted, this button changes to

Enable Sound

. Tap the button again to switch sound back on.

When the sound is muted, the mute sound indicator is shown in the bottom left corner of the Driving View.

Tap this button to use night colors on the map. If night colors are being used, this button changes to

Day Colors.

Tap the button again to switch back to day colors.

Night Colors

2D Map

Tap this button to use a 2D map in the Driving View.

If the 2D map is being used, this button changes to

3D Map

. Tap the button again to use the 3D map.

Tap this button to plan a route in advance, selecting your starting point and your destination.

Advanced

Planning

Tap this button to browse the map in the same way as you might look at a traditional paper map.

Browse Map

19

TomTom

Traffic

Help Me

Tap this button to go to the TomTom Store and select a traffic subscription.

If you have a Traffic subscription, tap this button to see your subscription status.

Tap this button to call or drive to the nearest emergency services.

The Help Me menu also gives a description of your location so you can tell the emergency services where you are.

Tap this button to create and manage your Favorites. Favorites are places that you go often. You can create Favorites so that you don’t have to enter the address every time you want to navigate there.

Manage

Favorites

Tap this button to call a POI. You can, for example, search for a restaurant and call to make a reservation.

Call POI

Tap this button to change how the TomTom app behaves.

Change

Settings

Navigate To menu

When you tap

Navigate To

in the Main Menu, you can choose from the following options to set your destination:

Home

Tap this button to navigate to your Home location.

If you haven’t set your Home location, you can do so by tapping

Home

. You can also set your Home location in the Settings menu.

Tap this button to select a Favorite as your destination.

Favorite

Tap this button to enter an address as your destination.

Address

Tap this button to select your destination from a list of places you have recently used as destinations.

Recent

Destination

Tap this button to do a local search and then use one of the search results as your destination.

Local Search

20

Tap this button to navigate to a Point of Interest (POI).

Point of Interest

Tap this button to navigate to the address of a contact on your device.

Contact

Tap this button to enter a ZIP code as a destination.

Note:

This option is not available in all countries.

ZIP code

Tap this button to select a point on the map as your destination using the Map Browser.

Point on Map

21

8.

Browse map

Tap

Browse Map

in the Main Menu to open the Map Browser. Using the Map Browser you can browse the map in the same way as you might look at a traditional paper map.

You can move around the map by dragging it across the screen with your finger.

Zoom in and out by pinching your fingers together and apart on the screen. You can also zoom by tapping the screen twice with one finger to zoom in, or tap once with two fingers at the same time to zoom out.

The cursor

Tap the map to place the cursor at the location you tap.

You can also drag the cursor around the map by holding your finger on it until it expands.

When you drag the cursor, the area within the expanded cursor is magnified.

When you place the cursor, a part of the map is selected. Details of this location are shown, along with an arrow.

Tap the arrow to use the cursor position. You can choose from these options:

Navigate There

- tap this button to plan a route from your current location to the cursor position.

Local Search

- tap this button to do a local search and plan a route to a location.

22

Find POI Nearby

- tap this button to search for a Point of Interest (POI) near the cursor position.

Call...

- tap this button to call a POI at the cursor position. This option is only shown if a

POI with a phone number is selected.

Center on Map

- tap this button to move the map so that the cursor position is in the center of the screen. The map zooms in on the cursor position.

Add as Favorite

- tap this button to add the cursor position as a Favorite. You have to give the Favorite a name.

Travel Via...

- tap this button to travel via the cursor position in the trip that is currently planned. This option is only shown if you have already planned a route.

Tap this button to center the map on your current location.

Tap this button to show traffic incidents in the Map Browser. Traffic is a subscription service.

Tap this button to search for a location on the map. Select the location in the same way as you select a destination when planning a trip. The cursor moves to the location you select.

Tap this button to select the information shown on the map. You can select to show the following information:

Traffic

Favorites

Names

Coordinates

POI

Tap

POI Types

to select which POIs are shown on the map.

23

9.

Points of Interest (POIs)

Points

(POIs)

Points of Interest or POIs are useful places on the map. Here are some examples:

• Restaurants

• Hotels

• Museums

• Parking garages

• Gas stations

There are several places where you can use POIs in the TomTom app:

• Selecting your destination when planning a route.

• Calling a POI from the Main Menu.

• Selecting which POIs to show on the map.

Selecting a POI

You can use a POI as your destination. For example, if you are traveling to an unfamiliar city, you could search the POIs to help find a restaurant.

If your device has a phone feature, you can also call that POI to make a reservation. Tap the button showing the phone number to dial it immediately. If your device does not have a phone feature, you are shown the number so you can dial using another device.

When calling a POI or navigating to a POI, you select the POI in the same way.

1. Tap the screen to bring up the main menu.

2. Tap

Navigate To...

or

Call POI

in the Main Menu, then tap

Point of Interest

.

3. Narrow your choice of POIs by selecting the area where the POI is located.

You can select one of these options:

Tap this button to choose from a list of POIs near to your current location.

POI Near Me

Tap this button to find a POI in a particular town or city.

POI in City

24

Tap this button to choose from a list of POIs near to your Home location.

POI near Home

If a route is already planned, you can also select one of these options:

Tap this button to find a POI along your planned route.

POI Along Route

Tap this button to find a POI near your planned destination.

POI Near

Destination

4. If you selected

POI in city

, type the name of the town you want to visit and select the town when it appears in the list.

5. Select the category of POI:

Tap

Search

to search to look for a POI by name. All POIs in all categories are searched.

Tap the category of POI, if it is shown.

Tap

More

to choose from the complete list of categories. Select the category from the list.

6. From the list of POIs shown, select the POI you want to navigate to.

The table below explains the distances listed next to each POI.

POI Near You

POI in City

POI Near Home

POI Along Route

POI Near Destination

Distance from your current location

Distance from the city center

Distance from your Home location

Distance from your current location

Distance from your destination

If you have planned a route, a symbol is also shown next to each POI.

POI is on your route

POI is close to your route

POI is fairly close to your route.

POI is off your route.

Once you have selected a POI, the next screen shows more detailed information including the location of the POI on the map and the phone number of the POI, if available.

25

Tap

Select

to confirm you want to plan a route to this POI.

Tap

Call

to call the POI.

Note

: If your device does not have a phone feature, you are shown the number so you can dial using another device.

Showing POIs on the map

POIs can be shown on the map in the Driving View and also on the map in the Map

Browser.

To show POIs in the Driving View, do the following:

1. In the Main Menu, tap

Change Settings

.

2. Tap

Map

.

3. Make sure that the setting

POIs on Map

is selected.

To show POIs on the map in the Map Browser, do the following:

1. In the Main Menu, tap

Browse Map

.

2. Tap the information button in the bottom right-hand corner of the screen.

3. Make sure that the setting

POI

is selected.

Selecting which POIs to show on the map

You can select the categories of POIs that are shown, for example, gas stations, restaurants and hotels.

The selection you make is used for both maps.

To change the POI categories shown in the Settings menu, do the following:

1. In the Main Menu, tap

Change Settings

.

2. Tap

Map

.

3. Tap

POI Types

.

4. Select which POIs you want shown on the map.

To change the POI categories shown on the map in the Map Browser, do the following:

1. In the Main Menu, tap

Browse Map

.

2. Tap the information button in the bottom right-hand corner of the screen.

3. Tap

POI Types

.

4. Select which POIs you want shown on the map.

26

10.

Help Me

Help Me

provides an easy way to navigate to emergency service centers and other specialized services and contact them by phone.

For example, if you are involved in a car accident, you could use

Help Me

to call the nearest hospital and tell them your exact location.

Using Help Me to phone a local service

You can use

Help Me

to search for a service garage, make contact by phone and inform the garage about the precise details of your current location.

When you search for a service center, you are shown a list of nearby locations. Select one of the centers in the list to view their address and phone number and your current location on the map.

To use

Help Me

to locate a service garage, contact the garage by phone and navigate from your current location to the garage, do the following:

1. Tap the screen to bring up the Main Menu.

2. Tap

Help Me

.

3. Tap

Call for Help

.

4. Select the type of service you require, for example, Nearest hospital.

5. To dial, select a center from the list, the nearest is shown at the top of the list.

If your device has a phone feature, you can tap the button showing the phone number to dial it immediately. If your device does not have a phone feature, you are shown the number so you can dial using another device.

Once the call is answered, to obtain a description of your current location, open the

TomTom app again and tap

Help Me

. A description of your current location is shown.

Tap the description to copy the text. You can then paste the description into a text message or email.

6. To navigate your way to the garage by car, tap

Drive to Help

.

Your TomTom app starts guiding you to your destination.

27

11.

Favorites

Favorites are places that you often visit. You can create Favorites so that you don’t have to enter the address every time you want to navigate there.

They don’t have to be places you especially like, just useful addresses.

Creating a Favorite

To create a Favorite, tap

Manage Favorites

in the Main Menu, then

Add favorite

. You can then select the location of the Favorite from the list below.

Give your Favorite a name that is easy to remember. The TomTom app will always suggest a name, usually the address of the Favorite. If you don’t like the suggested name, delete it and enter a new one.

Tap

Save

to store your favorite.

Tap this button to set your Home location as a Favorite. You might do this if you want to change your Home location but keep the current

Home location as a Favorite.

Home

Favorite

Tap this button to create a Favorite from another Favorite.

If you actually want to rename a Favorite, tap the Favorite in the list, then tap

Name

. Then enter the new name for your Favorite.

Tap this button to enter a specific address as a Favorite.

Address

Tap this button to select a Favorite location from a list of places you have recently used as destinations.

Recent

Destination

Tap this button to do a local search and then use one of the search results as your favorite.

Local Search

Tap this button to add a Point of Interest (POI) as a Favorite.

Point of Interest

28

Tap this button to add a contact’s address as a Favorite.

Contact

Tap this button to enter a ZIP code as a Favorite.

This option is not available in all countries.

Zip code

My Location

Tap this button to add your current position as a Favorite.

For example, if you stop somewhere interesting, while you are there you can tap this button to create the Favorite.

Tap this button to create a Favorite using the Map Browser.

Select the location of the Favorite using the cursor, then tap

Select

.

Point on Map

Using a Favorite

You will normally use a Favorite as a way of navigating to a place without having to enter the address. To navigate to a Favorite, do the following:

1. Tap the screen to bring up the main menu.

2. Tap

Navigate To...

3. Tap

Favorite

.

4. Select a Favorite from the list.

The TomTom app calculates the route for you.

5. When the route is calculated, tap

Done

.

The TomTom app immediately starts guiding you to your destination with spoken instructions and visual instructions on the screen.

Changing the name of a Favorite

1. Tap the screen to bring up the main menu.

2. Tap

Manage Favorites

.

3. Tap the Favorite you want to rename.

4. Tap

Name

.

5. Enter the new name for the Favorite, then tap

done

.

Deleting a Favorite

1. Tap the screen to bring up the main menu.

2. Tap

Manage Favorites

.

3. Tap

Edit

. A red symbol is shown next to each Favorite.

4. Tap the red symbol next to the Favorite you want to delete. A

Delete

button is shown for that Favorite.

5. Tap

Delete

.

29

12.

TomTom local search powered by Google

TomTo pow-

Google

Using local search, you can search the Google listings to find stores and businesses, then plan a route to the destination you choose.

Note

: In order to use local search, you need a data connection (GPRS, EDGE,

UMTS or CDMA). Your mobile operator may charge you for using a wireless data connection.

If you use local search abroad, it may cost you more than when you use this service at home.

Using local search

To find a location using local search and plan a route there, follow the steps below. In this example, you search for a restaurant near your current position.

1. Tap the screen to bring up the Main Menu, then tap

Navigate to

.

2. Tap the

Local search

button.

3. Tap

Search near me

.

4. Type "restaurant" then tap

Done

.

The locations that match your search are shown in a list.

5. Tap one of the locations in the list.

The location is shown on the map together with the address, Google rating and phone number.

Tap anywhere in the address area to see more information about this location.

6. Tap

Select

to plan a route to the location.

Your TomTom app plans a route to the location you selected.

Alternatively, tap the phone number to call your chosen restaurant.

Note:

When you tap a phone number to make a call, the TomTom app closes.

30

13.

TomTom Traffic

TomTo fic

TomTom Traffic

Traffic is a unique TomTom service for receiving up-to-date traffic information.

For more information about services and subscriptions, tap the

TomTom Traffic

button in the Main Menu.

Important:

The Traffic service is only supported on iPhone devices. To use the service and receive traffic updates, you need a continuous data connection (GPRS, EDGE, UMTS or

CDMA). Your mobile operator may charge you for using a wireless data connection.

If you are roaming with your iPhone and want to prevent the TomTom app from downloading traffic updates, tap

Change Settings

in the Main Menu. Tap

Advanced

and set

Traffic

to off.

In combination with IQ Routes, Traffic helps you plan the best possible route to your destination taking into account the latest traffic information.

Regional availability

Note

: Services are only available in the US. Traffic is not available on the iPod Touch. For more information on available services, tap the

TomTom Traffic

button in the Main Menu.

Getting a traffic subscription

Start your TomTom app and then purchase a subscription by doing the following:

31

1. Go to the TomTom Store by using any of these methods:

• Tap the

TomTom Traffic

button in the Main Menu.

• Tap the car in the top right hand corner of the Driving View.

• Tap the car button in the Map Browser.

2. Choose a subscription from the list of available traffic services.

3. When asked, create a TomTom account and log in with that new account.

Your purchase is then completed using the Apple App Store. If payment is completed successfully, the Traffic service starts working on your TomTom app in a few minutes.

Tip:

If you already own a TomTom navigation device, we recommend that you open a new

TomTom account with a different email address for your iPhone.

Checking your Traffic subscription

You can check the status of your subscription at any time, by tapping

TomTom Traffic

in the Main Menu.

Your TomTom app also warns you when your service subscription is approaching the renewal date.

Renewing your Traffic subscription

You can renew your Traffic subscription after it has expired or extend it before it reaches its expiry date.

To extend an existing subscription, tap the

TomTom Traffic

button in the Main Menu.

To renew an expired subscription, do the following:

1. Go to the TomTom Store by using any of these methods:

• Tap the

TomTom Traffic

button in the Main Menu.

• Tap the car in the top right hand corner of the Driving View.

• Tap the car button in the Map Browser.

The current status of your traffic subscription is shown.

2. Tap on the service you want to renew.

Your TomTom app confirms that you want to renew your subscription.

3. Tap

Yes

.

Your purchase is then completed using the Apple App Store.

32

Using TomTom Traffic

Tap the car in the top right hand corner of the Driving View to show the traffic sidebar.

The traffic sidebar tells you about traffic incidents on your route by showing you where they are. Each set of glowing dots is a traffic incident.

The car at the top of the traffic sidebar shows the approximate total delay time for any incidents and busy roads on your route.

The central section of the traffic sidebar shows individual traffic incidents in the order they occur on your route.

The bottom of the traffic sidebar represents your current position.

Scroll the traffic sidebar up and down using your finger to see traffic incidents at a distance from your current location.

When scrolling, the traffic sidebar automatically stops moving when it reaches the next incident.

The length of the total delay on your route is shown by the color of the car at the top of the sidebar.

Less than 2 minutes delay on your route.

Less than 15 minutes delay on your route.

More than 15 minutes delay on your route.

Traffic service updating.

No route planned, traffic up to date

.

No subscription to the Traffic service.

Traffic service not available.

Getting more information about an incident

When shown on the map, a traffic incident starts with an icon. In the case of a traffic jam, the direction of the incident is from the icon towards the other end.

33

As you scroll the traffic sidebar up and down, the panel above the status bar shows you more information about each incident. This includes the type of incident, for example road works, and the length of delay caused by this incident.

If you tap this panel, the incident viewer opens.

Tap the up and down arrow buttons to move through each incident in turn, viewing the details of each one. Scroll through the details of each individual incident.

For any incident, you can also tap

Minimize Delays

to check whether further time can be saved by using an alternative route.

Taking the fastest route

As the traffic situation changes, your TomTom app constantly looks for a faster route to your destination. If it finds one, it asks you if you want to change to that route.

To make sure you are using the fastest route, do the following:

1. Tap the screen to open the Main Menu.

34

2. Tap

Route Options

.

3. Tap

Minimize Delays

.

Checking traffic incidents in your area

Get an overview of the traffic situation in your area by using the map. To find local incidents and their details, do the following:

1. Tap

Browse map

in the Main Menu.

The map browser screen is shown.

2. Tap the traffic button in the status bar to show traffic incidents on the map.

3. If the map does not show your location, tap this button to center the map on your current location.

The map shows traffic incidents in the area.

4. Tap on any traffic incident to get more information.

The incident viewer opens and shows you detailed information about the incident you chose.

Traffic incidents

Traffic incidents are displayed as symbols on the Driving View and the traffic incident panel. There are two type of symbols:

• Symbols shown in a red square are incidents that Traffic can help you to avoid.

• Symbols shown in a triangle are weather-related symbols and for information only. You cannot use the Traffic service to avoid them.

Traffic incident symbols:

Accident

Road works

35

One or more lanes closed

Road closed

Traffic incident

Traffic jam

Weather-related symbols:

Fog

Rain

Wind

Ice

Snow

36

14.

Add to TomTom

Add to m

When you see an

Add to TomTom

button on a website, click the button to add favorites,

POI sets, addresses, and routes to your navigation device. For example, if your favorite restaurant has an

Add to TomTom

button on their website, you can click it to add the restaurant as a Favorite, POI or destination on your device.

Other types of location that might have

Add to TomTom

buttons on their websites include supermarkets, cinemas and tourist attractions. The button that you will see on websites looks like this:

Using the "Add to TomTom" button

1. Using your iPhone, go to a website that has an

Add to TomTom

button.

2. Click the

Add to TomTom

button.

The TomTom app starts.

3. What happens next depends on what the

Add to TomTom

button that you clicked has been designed to do. One of the following things happens:

• Show the location on a map.

• Create a route from your current position to the location.

• Add the location to your Favorites.

Your new location, route or favorite is added to the TomTom app.

37

15.

Addendum

Important Safety Notices and Warnings

Global Positioning System

The Global Positioning System (GPS) is a satellite-based system that provides location and timing information around the globe. GPS is operated and controlled under the sole responsibility of the Government of the United States of America, which is responsible for its availability and accuracy. Any changes in GPS availability and accuracy, or in environmental conditions, may impact the operation of TomTom software. TomTom does not accept any liability for the availability and accuracy of GPS.

Use with Care

Even when using TomTom software and devices for navigation, you must still drive with due care and attention.

Aircraft and Hospitals

Use of devices with an antenna is prohibited on most aircraft, in many hospitals and in many other locations. TomTom software and devices must not be used in these environments.

SPECIAL NOTE REGARDING DRIVING IN CALIFORNIA AND MINNESOTA

California Vehicle Code Section 26708 (a) (1) provides that “No persons shall drive any motor vehicle with an object or material placed, displayed, installed, affixed or applied upon the windshield or side or rear windows.” Drivers in California should not use a suction mount on their windshield, side or rear windows.

Note: this section of the California Vehicle Code applies to anyone driving in California, not just California residents.

Minnesota State Legislature Statutes Section 169.71, subdivision 1, section 2 provides that

“A person shall not drive or operate with any objects suspended between the driver and the windshield other than sun visors and rearview mirrors and electronic toll collection devices.”

Note: this Minnesota Stature applies to anyone driving in Minnesota, not just Minnesota residents.

TomTom Inc. bears no responsibility for any fines, penalties or damage that may be incurred by disregarding this notice. While driving in any state with windshield mounting restrictions, TomTom recommends the use of the supplied Adhesive Mounting Disk or its

Alternative Mounting Kit, which includes multiple options for mounting TomTom devices on the dashboard and using the air vents. See tomtom.com for more information about this mounting option.

38

This Document

Great care was taken in preparing this manual. Constant product development may mean that some information is not entirely up to date. The information in this document is subject to change without notice.

TomTom shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the performance or use of this material. This document contains information protected by copyright. No part of this document may be photocopied or reproduced in any form without prior written consent from

TomTom N.V.

39

16.

Copyright notices

Copynotices

© 2010 TomTom N.V., The Netherlands. TomTom®, and the "two hands" logo, among others, are Trademarks owned by TomTom N.V. or one of its subsidiaries. Please see

www.tomtom.com/legal

for warranties and end user licence agreements applying to this product.

© 2010 TomTom N.V., Niederlande. TomTom®, das 'Zwei Hände'-Logo usw. sind registrierte Marken von TomTom N.V. oder eines zugehörigen Tochterunternehmens. Die für dieses Produkt geltenden Garantien und Endnutzerlizenzvereinbarungen finden Sie unter

www.tomtom.com/legal

.

© 2010 TomTom N.V., Pays-Bas. TomTom® et le logo composé de « deux mains », entre autres, font partie des marques commerciales appartenant à TomTom N.V. ou l'une de ses filiales. L'utilisation de ce produit est régie par notre garantie limitée et le contrat de licence utilisateur final, que vous pouvez consulter à l'adresse suivante :

www.tomtom.com/legal

© 2010 TomTom N.V., Nederland. TomTom® en het logo met twee handen zijn onder andere handelsmerken die eigendom zijn van TomTom N.V. of een van haar dochterondernemingen. Ga naar

www.tomtom.com/legal

voor garanties en licentieovereenkomsten voor eindgebruikers die van toepassing zijn op dit product.

© 2010 TomTom N.V., The Netherlands TomTom® e il logo delle "due mani", fra gli altri, sono marchi registrati di proprietà di TomTom N.V. o di una delle sue filiali. Consultare

www.tomtom.com/legal

per le garanzie e i contratti di licenza per l'utente finale applicabili a questo prodotto.

© 2010 TomTom NV, Países Bajos. TomTom™ y el logotipo "dos manos" son marcas comerciales, aplicaciones o marcas registradas de TomTom NV. Nuestra garantía limitada y nuestro acuerdo de licencia de usuario final para el software integrado son de aplicación para este producto; puede consultar ambos en

www.tomtom.com/legal

.

© 2010 TomTom N.V., Països Baixos. TomTom®, i el logotip amb les "dues mans", entre altres, formen part de les marques comercials de TomTom N.V. o d'una de les seves filials.

Visiteu

www.tomtom.com/legal

per a obtenir informació sobre les garanties i els acords de llicència d'usuari final d'aquest producte.

© 2010 TomTom N.V., Holanda. TomTom® e o logótipo das "duas mãos", entre outras, são marcas comerciais detidas pela TomTom N.V. ou por uma das suas subsidiárias. Vá a

www.tomtom.com/legal

para consultar as garantias e o contratos de licença do utilizador final aplicáveis a este produto.

© 2010 TomTom NV, Holland. TomTom™ og logoet med "de to hænder" er blandt de varemærker, produkter og registrerede varemærker, der tilhører TomTom International

B.V. Vores begrænsede garanti og slutbrugerlicensaftale for indlejret software gælder for dette produkt; begge dokumenter findes på

www.tomtom.com/legal

.

© 2010 TomTom N.V., Alankomaat. Muun muassa TomTom® ja kaksi kättä -logo ovat

TomTom N.V:n tai sen tytäryhtiöiden omistamia tavaramerkkejä. Katso osoitteesta

www.tomtom.com/legal

tätä tuotetta koskevat takuut ja käyttöehtosopimukset.

40

© 2010 TomTom N.V., Nederland. TomTom®, og de "to hender"-logoen, blant andre, er varemerker eid av TomTom N.V. eller en av deres underleverandører. Vennligst se

www.tomtom.com/legal

for gjeldende garantier og lisensavtaler for sluttbrukere for dette produktet.

© 2010 TomTom NV, Nederländerna. TomTom™ och logotypen "två händer" tillhör de varumärken, programvaror eller registrerade varumärken som ägs av TomTom International

B.V. Vår begränsade garanti och vårt slutanvändarlicensavtal för inbyggd programvara kan gälla för denna produkt. Du kan läsa dem båda på

www.tomtom.com/legal

.

© 2010 TomTom N.V., Nizozemsko. TomTom® a logo „dvou rukou“ jsou, mimo jiné, ochranné známky spole č nosti TomTom N.V. nebo jejích pobo č ek. Navštivte prosím adresu

www.tomtom.com/legal

, kde naleznete informace o zárukách a licen č ních smlouvách s koncovým uživatelem vztahujících se k tomuto výrobku.

© 2010 TomTom N.V., Hollandia. A TomTom®, és a „két kéz” embléma, többek között, a

TomTom N.V. vagy leányvállalatai védjegye. A termékre vonatkozó garanciáról és a végfelhasználói licencszerz ő désekr ő l részleteket a

www.tomtom.com/legal

oldalon olvashat.

© 2010 TomTom N.V., Holandia. TomTom™ i logo z dwiema d ł o ń mi, oraz inne, s ą zarejestrowanymi znakami towarowymi firmy TomTom N.V. lub jednej z jej spó ł ek zale ż nych.

Informacje o gwarancjach i umowach licencyjnych dla ko ń cowego u ż ytkownika tego produktu znajduj ą si ę na stronie

www.tomtom.com/legal

.

© 2010 TomTom N.V., Holandsko. TomTom® a logo „dve ruky“ sú okrem ď alších ochranné známky, ktoré vlastní spolo č nos ť TomTom N.V. alebo jedna z jej dcérskych spolo č ností. Pozrite si stránku

www.tomtom.com/legal

, ak chcete informácie o zárukách a dohody o licencii pre koncového používate ľ a týkajúce sa tohto produktu.

© 2010 TomTom N.V., Madalmaad. TomTom® ja "kahe käe" logo kuuluvad nende kaubamärkide hulka, mille omanikuks on TomTom N.V. või mõni selle filiaal. Tootele kehtivad garantiid ja lõppkasutaja litsentsilepingud leiad aadressilt

www.tomtom.com/legal

.

© 2010 TomTom N.V., Nyderlandai. TomTom® ir "dviej ų plaštak ų " formos logotipas, kaip ir daugelis kit ų , priklauso TomTom N.V. arba kuriai nors dukterinei į monei. Apie šiam produktui taikomas garantijas ir licencijavimo galutiniam vartotojui sutartis skaitykite internete adresu

www.tomtom.com/legal

.

© 2010 TomTom N.V., Nyderlandai. TomTom® ir "dviej ų plaštak ų " formos logotipas, kaip ir daugelis kit ų , priklauso TomTom N.V. arba kuriai nors dukterinei į monei. Apie šiam produktui taikomas garantijas ir licencijavimo galutiniam vartotojui sutartis skaitykite internete adresu

www.tomtom.com/legal

.

© 2010 TomTom N.V., Hollanda. TomTom® ve di ğ er logolar ile birlikte "iki el" logosunun mülkiyeti, TomTom N.V. veya ba ğ l ı ş irketlerine aittir. Bu ürün için geçerli garanti ve son kullan ı c ı lisans sözle ş meleri için

www.tomtom.com/legal

sayfas ı na bak ı n.

© 2010 TomTom N.V., Holanda. TomTom® e o logotipo "duas mãos" entre outros, são marcas comerciais de propriedade da TomTom N.V. ou de uma de suas subsidiárias. Consulte

www.tomtom.com/legal

para obter garantias e contratos de licença de usuário final que se aplicam a este produto.

Data Source

© 2010 Tele Atlas N.V. Based upon:

Topografische ondergrond Copyright © dienst voor het kadaster en de openbare registers, Apeldoorn 2006.

© Ordnance Survey of Northern Ireland.

© IGN France.

© Swisstopo.

41

© BEV, GZ 1368/2003.

© Geonext/DeAgostini.

© Norwegian Mapping Authority, Public Roads Administration / © Mapsolutions.

© DAV, violation of these copyrights shall cause legal proceedings.

This product includes mapping data licensed from Ordnance Survey with the permission of the Controller of Her Majesty’s Stationery Office. © Crown copyright and/or database right 2010. All rights reserved. Licence number 100026920.

© Roskartographia

Data Source

© 2010 Tele Atlas North America. Inc. All rights reserved.

Compatible with all iPhone models

“Works with iPhone” means that an electronic accessory has been designed to connect specifically to iPhone and has been certified by the developer to meet Apple performance standards.

Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.

iPhone is a registered trademark of Apple Inc.

Some images are taken from NASA’s Earth Observatory.

The purpose of NASA’s Earth Observatory is to provide a freely-accessible publication on the Internet where the public can obtain new satellite imagery and scientific information about our home planet.

The focus is on Earth’s climate and environmental change: earthobservatory.nasa.gov/

42

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
