DB2 Stored Procedure Builder
IBM VisualAge® for Java™, Version 3.5
®
DB2 Stored Procedure Builder
򔻐򗗠򙳰
Note!
Before using this information and the product it supports, be sure to read the general
information under Notices.
Edition notice
This edition applies to Version 3.5 of IBM VisualAge for Java and to all subsequent releases and modifications until
otherwise indicated in new editions.
© Copyright International Business Machines Corporation 1999, 2000. All rights reserved.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.
Contents
Chapter 1. Overview of DB2 Stored
Procedure Builder . . . . . . . . . . 1
What are stored procedures? . . . . . . . .
What are the benefits of using stored procedures? .
What is DB2 Stored Procedure Builder? . . . .
How has DB2 Stored Procedure Builder changed the
process of creating stored procedures? . . . . .
Overview of debugging stored procedures . . .
. 1
. 2
. 3
. 4
. 8
Chapter 2. Managing Stored Procedure
Builder projects . . . . . . . . . . . 11
Setting project properties . . . . . .
Setting environment properties . . . .
Ways to create stored procedures . . .
Modifying existing Java stored procedure
code . . . . . . . . . . . . .
Modifying existing SQL stored procedure
code . . . . . . . . . . . . .
© Copyright IBM Corp. 1999, 2000
. .
. .
. .
source
. .
source
. .
.
.
.
. 11
. 12
. 12
.
. 15
.
. 16
Browsing and modifying stored procedure
properties . . . . . . . . . . . . . . .
Copying and pasting stored procedures to another
database . . . . . . . . . . . . . . .
Editing generated code . . . . . . . . . .
Managing multiple database connections in a project
Running stored procedures . . . . . . . . .
Dropping stored procedures . . . . . . . . .
Finding more information on DB2 Stored Procedure
Builder . . . . . . . . . . . . . . . .
17
18
18
19
20
21
21
Notices . . . . . . . . . . . . . . 23
Programming interface information . . 25
Trademarks and service marks . . . . 27
iii
iv
DB2 Stored Procedure Builder
Chapter 1. Overview of DB2 Stored Procedure Builder
DB2 Stored Procedure Builder assists you with creating a stored procedure that
runs on a database server. You must write the client application separately. For
information about writing a client application that calls a stored procedure, see the
following guides:
v IBM DB2 Universal Database™ Application Development Guide, for information about
designing and programming DB2 applications
v IBM DB2 Universal Database Application Building Guide, for information about
compiling and linking DB2 applications
v IBM DB2 Universal Database for OS/390® Application Programming and SQL Guide
v IBM DB2 Universal Database Application Development Guide—Embedded SQL
What is DB2 Stored Procedure Builder?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Managing Stored Procedure Builder projects
Ways to create stored procedures
Finding more information on DB2 Stored Procedure Builder
What are stored procedures?
All database access must go across the network which, in some cases, results in
poor performance. For each SQL statement, a database manager application must
initiate a separate communication with DB2(R).
Stored procedures are programs that have the following characteristics:
v Run on DB2 servers and access data in DB2 databases
v Contain blocks of procedural constructs and embedded SQL statements that are
stored in databases and can be called by name
v Allow an application program to be run in two parts—-the calling application on
the client and the stored procedure on the server
The following figure shows how a database manager application that does not use
stored procedures accesses a database located on a database server.
To improve application performance, you can create stored procedures that run on
your database server. A client application can call the stored procedure to obtain a
result.
A typical stored procedure contains one or more SQL statements and some
manipulative or logical processing in a programming language. The client
application program uses the SQL CALL statement to invoke the stored procedure.
When the stored procedure runs, it locally accesses the database on the database
server and returns requested information to the client application.
The following figure shows how an application using a stored procedure accesses a
database server.
© Copyright IBM Corp. 1999, 2000
1
To create a stored procedure, you write two separate programs: the stored
procedure itself, which runs on a database server, and a client application, which
runs on a client workstation or a middleware server (such as a Web server). The
client application calls the stored procedure by using one of the available API
methods.
A stored procedure follows certain conventions for exchanging data with a client
application. A stored procedure does not connect to the database itself, but relies
on the database connection already established by the client. The call across the
network includes parameters required by the stored procedure. The stored
procedure uses the parameters to complete its logic, runs, and can return a set of
values, rows, or modified parameters to the calling client application.
What is DB2 Stored Procedure Builder?
What are the benefits of using stored procedures?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Ways to create stored procedures
Managing Stored Procedure Builder projects
Finding more information on DB2 Stored Procedure Builder
What are the benefits of using stored procedures?
Applications using stored procedures have the following advantages:
v Reduced network traffic between clients and servers
A client application passes control to a stored procedure on the database server.
The stored procedure performs intermediate processing on the database server,
without transmitting unnecessary data across the network. Only those records
that are actually required by the client application are transmitted. Using a
stored procedure can result in reduced network traffic and better overall
performance.
Also, applications that execute SQL statements one at a time typically generate
two trips across the network for each SQL statement. A stored procedure can
group SQL statements together and generate only two trips across the network
for each group of SQL statements. The more SQL statements you group together
in a stored procedure, the more you reduce network traffic and the time that
database locks are held. Reducing network traffic and the time of database locks
improves overall network performance and reduces lock contention problems.
Applications that process large amounts of SQL-generated data, but present only
a subset of the data to the user, can generate excessive network traffic because
all of the data is returned to the client before final processing. A stored
procedure can do the processing on the server, and transmit only the required
data to the client, which reduces network traffic.
v Enhanced hardware and software capabilities
Applications using stored procedures have access to increased memory and disk
space if the server computer is so equipped and access to software installed only
on the database server.
v Improved security by encapsulating database privileges for stored procedures
that use static SQL
2
DB2 Stored Procedure Builder
The database administrator (DBA) or developer who builds the stored procedure
must have the database privileges the stored procedure requires, but the users of
the client applications that call the stored procedure do not need such privileges.
v Reduced development cost and increased reliability from reusing common
routines in multiple applications
In a database application environment, many situations are recurrent, such as
returning a fixed set of data, or performing the same set of multiple requests to
a database. Stored procedures provide a highly efficient way to address these
recurrent situations by reusing one common procedure.
v Centralized security, administration, and maintenance for common routines
You can simplify security, administration, and maintenance by managing shared
logic in one place at the server, instead of managing multiple copies of the same
business logic on client workstations. Client applications can call stored
procedures that run SQL queries with little or no additional processing. By using
stored procedures, you gain centralized maintenance and authorization and can
potentially encapsulate the database tables.
What are stored procedures?
Ways to create stored procedures
Finding more information on DB2 Stored Procedure Builder
What is DB2 Stored Procedure Builder?
DB2 Stored Procedure Builder is a graphical application that supports the rapid
development of DB2 stored procedures. Using Stored Procedure Builder, you can
perform the following tasks:
v Create stored procedures
v Build stored procedures on local and remote DB2 servers
v Modify and rebuild existing stored procedures
v Run stored procedures for testing and debugging the execution of installed
stored procedures
Tip: Using Stored Procedure Builder, you can also run stored procedures that
you created in another editor and that use a language other than Java or the
SQL procedure language. You might want to test the execution of existing
installed stored procedures.
Stored Procedure Builder provides a single development environment that
supports the entire DB2 family ranging from the workstation to OS/390(R). You can
launch Stored Procedure Builder as a separate application from the DB2 Universal
Database program group or from any of the following development applications:
v IBM VisualAge(R) for Java Version 3.0 or later
v Microsoft(R) Visual C++(R) Version 5 and Version 6
v Microsoft Visual Basic(R) Version 5 and Version 6
v IBM DB2 Control Center
Stored Procedure Builder is implemented with Java and all database connections
are managed by using a Java Database Connectivity (JDBC) API. Using a JDBC
driver, you can connect to any DB2 database by using a local alias.
The following diagram illustrates the Stored Procedure Builder topology:
Chapter 1. Overview of DB2 Stored Procedure Builder
3
What are stored procedures?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Overview of debugging stored procedures
Ways to create stored procedures
Managing Stored Procedure Builder projects
Modifying existing Java stored procedure source code
Modifying existing SQL stored procedure source code
Running stored procedures
Finding more information on DB2 Stored Procedure Builder
How has DB2 Stored Procedure Builder changed the process of
creating stored procedures?
DB2 Stored Procedure Builder provides an easy-to-use development environment
for creating, installing, and testing stored procedures. Using Stored Procedure
Builder allows you to focus on creating your stored procedure logic rather than the
details of registering, building, and installing stored procedures on a DB2 server.
Additionally, with Stored Procedure Builder, you can develop stored procedures on
one operating system and build them on other server operating systems.
Creating Stored Procedure Builder projects
Stored Procedure Builder manages your work by using projects. Each Stored
Procedure Builder project saves the following information:
v Your connections to specific databases.
v The filters you created to display subsets of the stored procedures on each
database. When opening a new or existing Stored Procedure Builder project, you
can filter stored procedures so that you view stored procedures based on their
name, schema, language, or collection ID (for OS/390 only).
v Stored procedure objects that have not been successfully built to a target
database.
You can identify Stored Procedure Builder project files by their SPP file extension.
The Project window shows all of the stored procedures on the DB2 database to
which you are connected. See the following diagram, which describes the parts of
the Project window.
4
DB2 Stored Procedure Builder
The tree pane, which shows all the objects in your project
The messages and result pane, which shows the messages that Stored
Procedure Builder generates when you build or run a stored procedure and the
result sets returned when running a stored procedure
The contents pane, which shows detailed information for each stored
procedure in a connection
In the tree pane, the following objects appear in this order: the project folder, the
database connection, the Stored Procedures folder, and stored procedures.
Depending on their state and language, stored procedures have different icons:
Java stored procedure
SQL stored procedure
Stored procedure created in a language other than Java or SQL
Java stored procedure that has not been built to the database or that has
changed since it was last built to the database
SQL stored procedure that has not been built to the database or that has
changed since it was last built to the database
Creating stored procedures
Stored Procedure Builder greatly simplifies the process of creating and installing
stored procedures on a DB2 database server. When you build a stored procedure
on a target database, you no longer have to manually register the stored procedure
with DB2 by using the CREATE PROCEDURE statement.
With Stored Procedure Builder, you create stored procedures in Java and the SQL
procedure language. Creating stored procedures in Java and the SQL procedure
language produces stored procedures that are highly portable among operating
systems.
Chapter 1. Overview of DB2 Stored Procedure Builder
5
Using a stored procedure wizard and SQL Assistant facilitate the development of
stored procedures. You launch a stored procedure wizard from the Project window
by selecting the Stored Procedures folder; then, use the Selected menu to create a
new stored procedure. You can use a stored procedure wizard to create your basic
SQL structure; then, you can use the code editor to add highly sophisticated stored
procedure logic.
You can also create stored procedures without using a stored procedure wizard.
You can create stored procedures by using a template that creates the stored
procedure structure but does not include any SQL statements. After generating the
basic stored procedure structure, you can use the code editor to further modify the
generated code to add logic and SQL statements.
See Ways to create stored procedures for more information.
When creating a stored procedure, you can choose to return a single result set,
multiple result sets, or output parameters only. You might choose not to return a
result set or output parameters when your stored procedure creates or updates
database tables.
You can use a stored procedure wizard to define input and output parameters for
a stored procedure so that it receives values for host variables from the client
application. Additionally, you can create multiple SQL statements in a stored
procedure; the stored procedure receives a case expression and selects one of a
number of queries.
Editing stored procedures
Stored Procedure Builder includes a fully-functional code editor that is language
sensitive depending on whether the stored procedure was written in Java or the
SQL procedure language. Once you have created a stored procedure, you can
easily modify it by opening the source code in the Stored Procedure Builder code
editor. When you open a stored procedure, the source code is displayed in the
editor pane on the right side.
6
DB2 Stored Procedure Builder
Using the code editor, you can add parameters, result sets, and additional stored
procedure logic. By modifying a Java stored procedure, you can add methods to
the code to include sophisticated stored procedure logic. For Java stored
procedures, you can add logic to the method that is called when the stored
procedure starts. In Java stored procedures and SQL stored procedures, you can
add calls to other stored procedures and run other SQL statements.
See the following topics for detailed information about how you can use the code
editor in Stored Procedure Builder:
v Modifying existing Java stored procedure source code
v Modifying existing SQL stored procedure source code
v Editing generated code
Working with existing stored procedures
After you successfully build a stored procedure on a database server, you are
ready to rebuild, run, and test the procedure. Running a stored procedure within
Stored Procedure Builder allows you to ensure that the stored procedure is
correctly installed and that the stored procedure logic is working as expected.
When you run a stored procedure, depending on how you set it up, it can return
result sets and output parameters based on test input parameter values that you
enter. When you run a stored procedure that has input parameters, you are
prompted for any required parameters.
For Java stored procedures, you can view the Data Definition Language (DDL)
statements by right-clicking a stored procedure in the tree and selecting Show
SQL.
From the Project window, you can drop a stored procedure or copy it to another
database connection.
You can search for specific text in the contents page of the Stored Procedure
Builder Project window by selecting the Stored Procedures folder and clicking the
Search toolbar button. Stored Procedure Builder notifies you when no matches are
found.
See the following topics for detailed information about how you can work with
existing stored procedures:
v Running stored procedures
v Copying and pasting stored procedures to another database
v Dropping stored procedures
Remotely debugging stored procedures
Using Stored Procedure Builder and the IBM Distributed Debugger, you can
remotely debug a stored procedure installed on a DB2 server. When you have
enabled debugging for a stored procedure, the IBM Distributed Debugger starts
automatically when you run the stored procedure. You are not required to debug
the stored procedure from within an application program. You can separate testing
your stored procedure from testing the application program.
When a stored procedure is built to a workstation database, you can view who has
the authority to change, add, or remove debug records in the stored procedures
debug table. When a stored procedure is built to an OS/390 server, the debugging
options are stored in a DB2 catalog table.
Chapter 1. Overview of DB2 Stored Procedure Builder
7
The Stored Procedure Properties notebook contains information about the debug
options set for a stored procedure. If you are a database administrator (DBA) or
you created the selected stored procedure, you can grant database authorization to
other users to debug the stored procedure.
For information about debugging stored procedures, see Overview of debugging
stored procedures.
What is DB2 Stored Procedure Builder
What are stored procedures?
Browsing and modifying stored procedure properties
Setting project properties
Setting environment properties
Copying and pasting stored procedures to another database
Finding more information on DB2 Stored Procedure Builder
Overview of debugging stored procedures
Using DB2 Stored Procedure Builder, the IBM Distributed Debugger (available
separately as part of VisualAge for Java), and the debugger component running on
the DB2 server, you can remotely debug a stored procedure installed on a DB2
server. You are not required to debug a stored procedure from within an
application program because you can run a stored procedure in debug mode
within Stored Procedure Builder. Therefore, you can separate debugging your
stored procedure from debugging the client application program that calls the
stored procedure.
When you build a stored procedure for debugging and run it in Stored Procedure
Builder, DB2 initializes the debugger component on the database server. The
debugger component on the DB2 server uses the IP address and port that you set
in Stored Procedure Builder to launch the IBM Distributed Debugger on your
workstation.
The IBM Distributed Debugger reviews each programming instruction and
displays the states of the variables in the executing stored procedure as it runs on
the DB2 server.
For information about how to use the IBM Distributed Debugger, see the
VisualAge for Java documentation.
To set up a stored procedure in Stored Procedure Builder for debugging, you must:
v Build the stored procedure in debug mode
8
DB2 Stored Procedure Builder
When you create a stored procedure with a stored procedure wizard, select
Enable debugging from the Options page.
For existing stored procedures, you can enable debugging by selecting Build the
stored procedure for debugging on the Build and Debug page of the Stored
Procedure Properties notebook.
v When you are building stored procedures to a workstation server, enter debug
records for the stored procedure in the debug table to grant debugging
authorization to particular users. These records are stored in
DB2DBG.ROUTINE_DEBUG on the DB2 server. If you are a DBA or the creator
of a selected stored procedure, you can authorize other users to debug the stored
procedure by entering debug records for the stored procedure in the Stored
Procedure Properties notebook.
You can also enable or disable debugging for several stored procedures within
the same connection by right-clicking the database connection in the tree and
selecting Debug Records.
Restriction: For SQL stored procedures, the RUNOPTS column of the table
SYSIBM.SYSPROCEDURES stores the port and IP address that the debugger
uses to connect to your client workstation. Stored procedures built on a DB2 for
OS/390 database server do not use the debug table. Therefore, only one user at a
time can debug a stored procedure.
v Optional: Change the global settings (port and IP address) that Stored Procedure
Builder uses for the connection between the IBM Distributed Debugger and
stored procedures by using the Debug page in the Environment Properties
notebook. When you change these global settings, they affect stored procedures
that you subsequently create. The IP address and port setting for existing stored
procedures are not affected.
What is DB2 Stored Procedure Builder?
What are stored procedures?
Ways to create stored procedures
Finding more information on DB2 Stored Procedure Builder
Chapter 1. Overview of DB2 Stored Procedure Builder
9
10
DB2 Stored Procedure Builder
Chapter 2. Managing Stored Procedure Builder projects
DB2 Stored Procedure Builder manages your work by using projects. Stored
Procedure Builder projects save connection information and stored procedure
objects that have not yet been built to a database.Specifically, each Stored
Procedure Builder project saves the following information:
v Your connections to specific databases.
v The filters you created to display subsets of the stored procedures on each
database. For a Stored Procedure Builder project, you can filter stored
procedures so that you view stored procedures based on their name, schema,
language, or collection ID (for OS/390 only).
v Stored procedure objects that have not been successfully built to a target
database.
Tip: You can identify Stored Procedure Builder project files by their SPP file
extension.
The Project window shows all of the stored procedures on the DB2 database to
which you are connected. See the following diagram, which describes the parts of
the Project window.
Once you have created a Stored Procedure Builder project, you can create stored
procedures, add connections to databases, set project and environment properties,
run stored procedures, debug stored procedures, and drop stored procedures.
What is DB2 Stored Procedure Builder?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Managing multiple database connections in a project
Setting project properties
Finding more information on DB2 Stored Procedure Builder
Setting project properties
To edit the characteristics of a project:
1. Select File —> Project Properties. The Project Properties notebook opens to the
Project page.
2. Edit the current project name by typing over the name in the Project name
field. The project name can be up to 255 characters, including the project path
and filename extension, for example, if your project path contains 50 characters,
then your project name can contain a maximum of 205 characters. The project
name can contain alphanumeric, underscore (_), and space characters. If you
give your project the same name as an existing project, you are prompted to
overwrite the existing project when you save.
When you change the project name, Stored Procedure Builder changes the
current file name of the project to match your new project name. You are
prompted to save the project with the new file name when you save or exit the
project.
© Copyright IBM Corp. 1999, 2000
11
3. Edit the project path by typing a new path in the Project path field. When you
change the project path, you are prompted to save the project in the new
location when you save or exit the project. Click the
button to open the
Choose Directory window and select a directory for the project.
4. Optional: Type comments about the project in the Description field.
5. Optional: Click the Copyright tab to enter copyright information for this
project.
6. Click OK to apply your changes.
What is DB2 Stored Procedure Builder?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Setting environment properties
Browsing and modifying stored procedure properties
Finding more information on DB2 Stored Procedure Builder
Setting environment properties
Use the Environment Properties notebook to specify default connection, result,
debugging, and SQL type synonym and mapping information. Select File —>
Environment Properties to display the Environment Properties notebook.
Tip: If you have changed the default settings from the Environment Properties
notebook and want to restore the default settings for your environment, delete the
DB2SPB.INI file. When you open the Environment Properties notebook, Stored
Procedure Builder recreates the INI file with the default settings. You can also
delete portions of the INI file to restore only selected settings to the defaults.
What is DB2 Stored Procedure Builder?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Setting project properties
Browsing and modifying stored procedure properties
Finding more information on DB2 Stored Procedure Builder
Ways to create stored procedures
DB2 Stored Procedure Builder greatly simplifies the process of creating and
installing stored procedures on a DB2 database server. With Stored Procedure
Builder, you create stored procedures in Java and the SQL procedure language.
Stored Procedure Builder provides different ways to create stored procedures
depending on the language that you choose to create a stored procedure.
Create stored procedures
12
DB2 Stored Procedure Builder
Languages
Descriptions and benefits
Using a wizard
Java and SQL
Using a stored procedure
wizard and SQL Assistant
facilitate the development of
stored procedures.
To start a stored procedure
wizard:
1. From the Project window,
select the Stored
Procedures folder.
2. Select Selected —> Insert
—> Java Stored
Procedure using Wizard
or SQL Stored Procedure
using Wizard from the
menu.
Using a stored procedure
wizard, you create your basic
SQL structure; then, you can
use the code editor to add
highly sophisticated stored
procedure logic.
From a class by using a
wizard
Java
Using the Inserting Java
Stored Procedure from class
wizard allows you to create a
new Java stored procedure
from an existing Java class.
1. From the Project window,
select the Stored
Procedures folder.
2. Select Selected —> Insert
—> Java Stored
Procedure from Class
using Wizard from the
menu.
Chapter 2. Managing Stored Procedure Builder projects
13
Using a wizard to generate
stored procedures that do
not contain SQL statements
Java and SQL
Using a template provides a
quick way to create your
basic SQL structure for a
stored procedure. When you
select this option in a stored
procedure wizard, Stored
Procedure Builder creates the
stored procedure structure
but does not include any
SQL statements or an open
cursor in the stored
procedure.
1. From the Project window,
select the Stored
Procedures folder.
2. Select Selected —> Insert
—> Java Stored
Procedure using Wizard
or SQL Stored Procedure
using Wizard from the
menu.
3. Click the Pattern tab.
4. Select the Generate no
SQL statement radio
button.
14
DB2 Stored Procedure Builder
Using a template that
contains the default stored
procedure structure
SQL
Using a temple creates the
default structure for an SQL
stored procedure without
parameters or SQL
statements. The stored
procedure wizards create
stored procedures that have
simple stored procedure
logic; for example, the
wizards create stored
procedures with one SQL
statement and all variables
become parameters. If you
want your stored procedure
to contain sophisticated
business logic or you want to
reuse logic from another
stored procedure, you can
use an SQL template and
add the logic in the Stored
Procedure Builder code
editor.
1. From the Project window,
select the Stored
Procedures folder.
2. Select Selected —> Insert
—> SQL Stored
Procedure. The SQL
stored procedure code
appears in the code
editor.
3. Optional: Use the Stored
Procedure Properties
notebook to add
comments to the stored
procedure or to change
the default settings for
the build and debug
options.
What is DB2 Stored Procedure Builder?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Modifying existing Java stored procedure source code
Modifying existing SQL stored procedure source code
Editing generated code
Finding more information on DB2 Stored Procedure Builder
Modifying existing Java stored procedure source code
If you open a project that contains existing Java stored procedures, you can modify
the source code (including SQL statements) within DB2 Stored Procedure Builder.
Stored Procedure Builder drops the old stored procedure from the database and
creates a stored procedure that reflects the changes you made.
Chapter 2. Managing Stored Procedure Builder projects
15
Requirement: Java stored procedures built by Stored Procedure Builder conform to
the SQLJ Routines specification. Java stored procedures are defined in the catalog
table with LANGUAGE JAVA and PARAMETER STYLE JAVA.
Java stored procedures must follow these rules:
v The method mapped to the stored procedure must be defined as a public static
void method.
v The stored procedure must receive input parameters as host variables.
v Output and InOut parameters must be set up as single element arrays.
To modify existing Java stored procedure source code:
1. In the tree, right-click the Java stored procedure that you want to modify and
select Get Source. The source code of the stored procedure displays in the
editor pane.
Tip: You can determine which stored procedures contain Java by clicking the
Stored Procedures folder in the tree and viewing the Language column in the
Contents pane. Java stored procedures are also represented in the tree with this
icon:
2. Refer to Editing generated code for information about editing the source code
of the stored procedure.
3. Add SQL statements to the source code by using the editor or launch the SQL
Assistant by right-clicking in the editor and selecting Insert SQL. The
placement of the cursor in the editor determines where SQL Assistant places
the SQL statements.
In SQL Assistant, the tables that you can view and build queries from are those
of the current database alias.
Tip: To replace an existing SQL statement with an SQL statement created in
SQL Assistant, select the entire SQL statement in the editor and then launch
SQL Assistant to create a new query. SQL Assistant replaces the selected SQL
statements in the editor with the new SQL statement. Note that you cannot
modify an existing SQL statement by using SQL Assistant.
4. When you are finished modifying the code, you can build the stored procedure
to the database by right-clicking the stored procedure in the tree and selecting
Build. Note that a build must be performed before changes to the stored
procedure are reflected in the database.
Tip: If the build fails and build errors display in the Messages pane, you can
double-click an error message to see the referenced line highlighted in the
editor.
What is DB2 Stored Procedure Builder?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Editing generated code
Modifying existing SQL stored procedure source code
Finding more information on DB2 Stored Procedure Builder
Modifying existing SQL stored procedure source code
If you open a project that contains existing SQL stored procedures, you can modify
the source code (including SQL statements) within DB2 Stored Procedure Builder.
Stored Procedure Builder drops the old stored procedure from the database and
creates a stored procedure that reflects the changes you made.
16
DB2 Stored Procedure Builder
To modify existing SQL stored procedure source code:
1. In the tree, right-click the SQL stored procedure that you want to modify and
select Get Source. The source code of the stored procedure displays in the
editor pane.
Tip: You can determine which stored procedures are written in SQL by clicking
the Stored Procedures folder in the tree and viewing the Language column in
the Contents pane. SQL stored procedures are also represented in the tree with
this icon:
2. Refer to Editing generated code for information about editing the source code
of the stored procedure.
3. Add SQL statements to the source code by using the editor or launch the SQL
Assistant by right-clicking in the editor and selecting Insert SQL. The
placement of the cursor in the editor determines where SQL Assistant places
the SQL statements.
In SQL Assistant, the tables that you can view and build queries from are those
of the current database alias.
Tip: To replace an existing SQL statement with an SQL statement created in
SQL Assistant, select the entire SQL statement in the editor and then launch
SQL Assistant to create a new query. SQL Assistant replaces the selected SQL
statement in the editor with the new SQL statement. Note that you cannot
modify an existing SQL statement by using SQL Assistant.
4. Insert SQL code fragments that provide the basic structure of SQL statements
such as IF, CASE, LOOP, REPEAT, and WHILE by right-clicking in the editor
and selecting Insert Code Fragment. Add logic to these SQL statements by
using the code editor.
5. When you are finished modifying the code, you can build the stored procedure
to the database by right-clicking the stored procedure in the tree and selecting
Build. Note that a build must be performed before changes to the stored
procedure are reflected in the database.
What is DB2 Stored Procedure Builder?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Editing generated code
Modifying existing Java stored procedure source code
Finding more information on DB2 Stored Procedure Builder
Browsing and modifying stored procedure properties
Use the Stored Procedure Properties notebook to view and modify the parameters
and other characteristics of an existing stored procedure. The stored procedure
properties that you can modify with this notebook vary depending on the
language (Java or SQL) of the stored procedure and the database in which it is
built.
The characteristics that you cannot modify in the Stored Procedure Properties
notebook appear as read-only fields. For Java and SQL stored procedures, you can
change the value of many of these read-only fields by changing the values in the
stored procedure source code.
Chapter 2. Managing Stored Procedure Builder projects
17
Restriction: For stored procedures written in languages other than Java or SQL,
you cannot modify the characteristics of the stored procedures.
For information about creating stored procedures, see Ways to create stored
procedures. For information about modifying stored procedure source code, see
Modifying existing Java stored procedure source code and Modifying existing SQL
stored procedure source code.
What is DB2 Stored Procedure Builder?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Setting environment properties
Setting project properties
Finding more information on DB2 Stored Procedure Builder
Copying and pasting stored procedures to another database
DB2 Stored Procedure Builder makes moving stored procedures from one database
to another an easy process with menu-driven copy and paste commands. Copying
and pasting stored procedures between databases is useful if you want a stored
procedure to reside on multiple databases, or if you need to migrate a stored
procedure from a test to a production database.
Restriction: You can only copy and paste stored procedures to other databases that
have the same operating system; for example, you can copy a stored procedure
from a workstation server to another workstation server. You cannot copy a stored
procedure from a workstation server to an OS/390 server.
To copy and paste a stored procedure to another database:
1. Right-click the stored procedure you want to copy and select Copy Procedure.
2. Optional: Add a database connection by right-clicking the project folder and
selecting Insert Connection. The new connection appears in the tree.
3. Right-click the Stored Procedures folder under the new database connection or
an existing connection and select Paste or Paste and Build. Paste puts the
stored procedure in the tree. Paste and Build puts the stored procedure in the
tree and builds the stored procedure to the database.
What is DB2 Stored Procedure Builder?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Managing multiple database connections in a project
Finding more information on DB2 Stored Procedure Builder
Editing generated code
DB2 Stored Procedure Builder includes an editor for editing and manipulating
source code. The default editor includes standard cut, copy, and paste capabilities,
find and replace, support for menus and key combinations, colored text, and more.
You can change the default key behavior of the editor to match vi or Emacs
18
DB2 Stored Procedure Builder
keyboard commands by using the Environment Properties notebook.
Right-clicking in the editor pane when source code is displayed opens the context
menu for the editor.
What is DB2 Stored Procedure Builder?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Modifying existing Java stored procedure code
Modifying existing SQL stored procedure code
Finding more information on DB2 Stored Procedure Builder
Managing multiple database connections in a project
With DB2 Stored Procedure Builder you can maintain connections to multiple
databases.
To manage multiple database connections:
If you want to:
Then:
Insert a database connection
Right-click the project folder in the tree and
select Insert Connection.
Remove a database connection
Right-click a database connection in the tree
and select Delete.
If you have stored procedures that have not
been built to the database, you are prompted
to delete these stored procedures from the
project or cancel the removal of the
connection.
Refresh a database connection
Right-click a database connection in the tree
and select Refresh.
You might want to refresh your connection
periodically to view changes that you or
other users of the database have made.
Newly added stored procedures display in
the tree when a connection is refreshed.
View the properties of a database connection Right-click a database connection in the tree
and select Properties. The Database
Connection Properties notebook opens,
showing you the properties for the current
connection.
Filter stored procedures for a connection
Right-click a database connection in the tree
and select Filter. The Database Connection
Properties notebook opens and displays the
Filter page. Enter the search criteria and
values on which you want to filter the
stored procedures for that connection.
The Project windows indicates when a filter
is set for a connection.
Chapter 2. Managing Stored Procedure Builder projects
19
Add or modify debug records for stored
procedures
Right-click a database connection in the tree
and select Debug Records. The Database
Connection notebook opens. The Database
Connection notebook allows you to create
debug records for all stored procedures on a
database without having to rebuild
individual stored procedures.
Restriction: You can only add or modify
debug records for stored procedures built to
workstation databases.
What is DB2 Stored Procedure Builder?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Overview of debugging stored procedures
Managing Stored Procedure Builder projects
Copying and pasting stored procedures to another database
Finding more information on DB2 Stored Procedure Builder
Running stored procedures
DB2 Stored Procedure Builder allows you to run a stored procedure for testing
purposes. When you use Stored Procedure Builder to run stored procedures, you
can determine whether the build was successful and if a result set exists. Running
a stored procedure will help you test stored procedure logic and the accuracy of
output arguments and result sets.
To run a stored procedure:
1. Right-click the stored procedure and select Run. If you have made changes to
the stored procedure since the last build, the Run Confirmation window opens.
2. Select to build the stored procedure to the database before running to reflect
the latest changes, or select to run the stored procedure that exists in the
database, without the latest changes.
3. Click OK after you have made your selection in the Run Confirmation window.
If the stored procedure requires user-supplied variables, the Specify Variable
Values window opens, listing the name and type of all input parameters.
4. Type a value in the Value field. The value must conform to the parameter type
specified in the Type column. String parameters can be empty or null.
5. If you do not intend to specify an input string and your stored procedure is not
written to handle null inputs, deselect the Treat empty strings as nulls check
box.
6. Click OK to run the stored procedure. Input variables display in the Messages
pane; output variables and result sets display in the Result pane.
Overview of debugging stored procedures
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
20
DB2 Stored Procedure Builder
Modifying existing Java stored procedure source code
Modifying existing SQL stored procedure source code
Finding more information on DB2 Stored Procedure Builder
Dropping stored procedures
DB2 Stored Procedure Builder allows you to drop a stored procedure from a
project and a database simultaneously.
To drop a stored procedure:
1. Optional: To save the source code from your stored procedure before dropping
the stored procedure, click the stored procedure in the tree and select File —>
Save as.
2. Right-click the stored procedure and select Drop. If the stored procedure has
already been built to the database, the Drop Item window opens.
3. In the Drop Item window, select whether to drop the stored procedure from the
database and the project or just from the database.
4. Click Yes to drop the stored procedure.
Requirement: To drop a stored procedure from the database, you must have
ownership of the stored procedure and the proper database privileges, which
include at least one of the following privileges or authorities:
v The DELETE privilege
v The DROPIN privilege for the schema or all schemas
v SYSADM or SYSCTRL authority
Contact your database administrator for more information.
What is DB2 Stored Procedure Builder?
How has DB2 Stored Procedure Builder changed the process of creating stored
procedures?
Copying and pasting stored procedures to another database
Finding more information on DB2 Stored Procedure Builder
Finding more information on DB2 Stored Procedure Builder
After starting DB2 Stored Procedure Builder, you can obtain full procedural
information about Stored Procedure Builder by selecting Help —> General Help
in the Project window. You can also get help for the current window.
To get help for the current window:
v Click the Help button.
v Press F1. In most windows, pressing F1 is the same as clicking Help.
v Select a field and press F1 to display the help for the field or control. The
wizards and notebooks have more detailed help known as infopops. If the
Show pop-up information for interface controls check box in the Environment
Properties notebook is selected, you can also see an infopop by
holding the mouse cursor over a field or control. The infopops appears within
two seconds.
Chapter 2. Managing Stored Procedure Builder projects
21
The Stored Procedure Builder help has these features:
v Notebook overviews. A notebook is a window that has multiple pages. You can
perform multiple tasks from a notebook. Therefore, when you click Help in a
notebook, an overview page appears that shows all the tasks available from the
notebook.
v Task steps. Choose from a list of tasks if more than one can be performed from
the window.
v Getting started information in the table of contents section "Before you create
stored procedures." This section of help provides information that you should
read before creating stored procedures.
What is DB2 Stored Procedure Builder?
Managing Stored Procedure Builder projects
22
DB2 Stored Procedure Builder
Notices
Note to U.S. Government Users Restricted Rights — Use, duplication or disclosure
restricted by GSA ADP Schedule Contract with IBM Corp.
This information was developed for products and services offered in the U.S.A.
IBM may not offer the products, services, or features discussed in this document in
other countries. Consult your local IBM representative for information on the
products and services currently available in your area. Any reference to an IBM
product, program, or service is not intended to state or imply that only that IBM
product, program, or service may be used. Any functionally equivalent product,
program, or service that does not infringe any IBM intellectual property right may
be used instead. However, it is the user’s responsibility to evaluate and verify the
operation of any non-IBM product, program, or service.
IBM may have patents or pending patent applications covering subject matter
described in this document. The furnishing of this document does not give you
any license to these patents. You can send license inquiries, in writing, to:
IBM Director of Licensing
IBM Corporation
North Castle Drive
Armonk, NY 10504-1785
U.S.A.
For license inquiries regarding double-byte (DBCS) information, contact the IBM
Intellectual Property Department in your country or send inquiries, in writing, to:
IBM World Trade Asia Corporation
Licensing
2-31 Roppongi 3-chome, Minato-ku
Tokyo 106, Japan
The following paragraph does not apply to the United Kingdom or any other
country where such provisions are inconsistent with local law:
INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS
PUBLICATION "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OR CONDITIONS OF NON-INFRINGEMENT,
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states
do not allow disclaimer of express or implied warranties in certain transactions,
therefore, this statement may not apply to you.
This information could include technical inaccuracies or typographical errors.
Changes are periodically made to the information herein; these changes will be
incorporated in new editions of the publication. IBM may make improvements
and/or changes in the product(s) and/or the program(s) described in this
publication at any time without notice.
Any references in this information to non-IBM Web sites are provided for
convenience only and do not in any manner serve as an endorsement of those Web
sites. The materials at those Web sites are not part of the materials for this IBM
product and use of those Web sites is at your own risk.
IBM may use or distribute any of the information you supply in any way it
believes appropriate without incurring any obligation to you.
© Copyright IBM Corp. 1999, 2000
23
Licensees of this program who wish to have information about it for the purpose
of enabling: (i) the exchange of information between independently created
programs and other programs (including this one) and (ii) the mutual use of the
information which has been exchanged, should contact:
Lab Director
IBM Canada Ltd.
1150 Eglinton Avenue East
Toronto, Ontario M3C 1H7
Canada
Such information may be available, subject to appropriate terms and conditions,
including in some cases, payment of a fee.
The licensed program described in this document and all licensed material
available for it are provided by IBM under terms of the IBM Customer Agreement,
IBM International Program License Agreement or any equivalent agreement
between us.
Information concerning non-IBM products was obtained from the suppliers of
those products, their published announcements or other publicly available sources.
IBM has not tested those products and cannot confirm the accuracy of
performance, compatibility or any other claims related to non-IBM products.
Questions on the capabilities of non-IBM products should be addressed to the
suppliers of those products.
This information contains examples of data and reports used in daily business
operations. To illustrate them as completely as possible, the examples may include
the names of individuals, companies, brands, and products. All of these names are
fictitious and any similarity to the names and addresses used by an actual business
enterprise is entirely coincidental.
COPYRIGHT LICENSE:
This information contains sample application programs in source language, which
illustrates programming techniques on various operating platforms. You may copy,
modify, and distribute these sample programs in any form without payment to
IBM, for the purposes of developing, using, marketing or distributing application
programs conforming to the application programming interface for the operating
platform for which the sample programs are written. These examples have not
been thoroughly tested under all conditions. IBM, therefore, cannot guarantee or
imply reliability, serviceability, or function of these programs. You may copy,
modify, and distribute these sample programs in any form without payment to
IBM for the purposes of developing, using, marketing, or distributing application
programs conforming to IBM’s application programming interfaces.
Each copy or any portion of these sample programs or any derivative work, must
include a copyright notice as follows:
© (your company name) (year). Portions of this code are derived from IBM Corp.
Sample Programs. © Copyright IBM Corp. 1997, 2000. All rights reserved.
24
DB2 Stored Procedure Builder
Programming interface information
Programming interface information is intended to help you create application
software using this program.
General-use programming interfaces allow the customer to write application
software that obtain the services of this program’s tools.
However, this information may also contain diagnosis, modification, and tuning
information. Diagnosis, modification and tuning information is provided to help
you debug your application software.
Warning: Do not use this diagnosis, modification, and tuning information as a
programming interface because it is subject to change.
© Copyright IBM Corp. 1999, 2000
25
26
DB2 Stored Procedure Builder
Trademarks and service marks
The following terms are trademarks of International Business Machines
Corporation in the United States, or other countries, or both:
v AIX
v AS/400
v DB2
v CICS
v CICS/ESA
v
v
v
v
v
v
v
v
IBM
IMS
Language Environment
MQSeries
Network Station
OS/2
OS/390
OS/400
v RS/6000
v
v
v
v
S/390
VisualAge
VTAM
WebSphere
Lotus, Lotus Notes and Domino are trademarks or registered trademarks of Lotus
Development Corporation in the United States, or other countries, or both.
Tivoli Enterprise Console and Tivoli Module Designer are trademarks of Tivoli
Systems Inc. in the United States, or other countries, or both.
Encina and DCE Encina Lightweight Client are trademarks of Transarc Corporation
in the United States, or other countries, or both.
Java and all Java-based trademarks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the United States and other countries.
ActiveX, Microsoft, SourceSafe, Visual C++, Visual SourceSafe, Windows, Windows
NT, Win32, Win32s and the Windows logo are trademarks or registered trademarks
of Microsoft Corporation in the United States, or other countries, or both.
UNIX is a registered trademark in the United States and other countries licensed
exclusively through X/Open Company Limited.
Intel and Pentium are trademarks of Intel Corporation in the United States, or
other countries, or both.
Other company, product, and service names, which may be denoted by a double
asterisk(**), may be trademarks or service marks of others.
© Copyright IBM Corp. 1999, 2000
27
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
