Victa TTS2226 Instruction manual

Trimmer
Instruction Manual
MODELS
R
ep No
ro t fo
du r
ct
io
n
STB2224
TTB2226
TTS2226
RTS1226
Read and follow the operating instructions and safety information
before using for the first time.
Specifications subject to change without notice.
IMPORTANTNOTES
Please read the following
Thank you for purchasing your VICTA trimmer. VICTA prides itself in the quality and
performance of all its products.
This instruction manual will aid in the assembly, safe operation and maintenance of your
trimmer.
Please read the following warnings to ensure safety and the long life of your product.
General safety regulations
Always switch off the
machine and pull out the
spark plug boot
Read the directions
for use before
operating the machine.
Before carrying out any
maintenance work.
Wear safety goggles,
a helmet and ear
protection.
Do not use rigid cutting
disk.
Wear sturdy, non-slip
safety boots.
Do not use solid saw
edged blades.
Wear safety gloves.
All bystanders must be
kept at least 15 m from the
machine.
R
ep No
ro t fo
du r
ct
io
n
Warning!
2
Protect the machine
from rain and damp.
Tool continues to run some
seconds after switching off
motor.
Be careful of objects
being thrown out!
CAUTION: Hot machine
parts. Keep your distance.
Table of Contents
Features & Definitions
Feature Definitions
4
Safety Instructions
10
Safety & Handling
Hazards
12
Personal Safety Equipment
12
Assembly Procedures
13
16
Handle
17
ep No
ro t fo
du r
ct
io
n
Cast Trimmer Head
Split Shaft & Connection Types
Guards
18
Shoulder Strap
18
Operating Instructions
Fuelling Procedures
19
Starting Instructions
20
Stopping Instructions
22
Cutting Techniques
22
Routine Maintenance
24
R
Maintenance & Care
Storage
26
Maintenance
27
Troubleshooting
28
Model Details
30
Accessories & Spare Parts
31
Warranty
32
Troubleshooting
Technical specifications
VICTA Products
Warranty
3
Machine Layout & Supplied Items straight shaft TTS2226
Cast trimmer head
2
3mmØ Nylon line
3
Straight shaft guard
4
Lower straight shaft
5
Handle
6
Engine stop switch
7
Throttle lever "release"
8
Throttle lever
9
Throttle lever "lock"
10
Choke lever
11
Starter cord
13
14
15
16
17
18
19
20
21
22
4
Spark plug boot
Air filter housing cover
Fuel Tank (Use 2-Stroke Fuel & Oil Mix, see pg.19)
Cowling
Fuel pump "primer"
Shoulder strap
Shaft split connection
Spark plug wrench
Allen key (4mm)
Allen key (5mm)
R
12
ep No
ro t fo
du r
ct
io
n
1
Spanner
Do not operate the VICTA Trimmer
before reading all Safety &
Handling sections.
Trimmer Parts Description straight shaft TTS2226
9
7
8
12
15
10
13
5
16
14
17
ep No
ro t fo
du r
ct
io
n
4
11
18
3
1
R
6
1
2
4
18
19
17
5
20
21
22
3
5
Machine Layout & Supplied Items bent shaft TTB2226/STB2224
Cast trimmer head
2
3mmØ Nylon line
3
Bent shaft guard
4
Lower bent shaft
5
Universal handle (TTB2226) / Classic handle (STB2224)
6
Engine stop switch
7
Throttle lever "release"
8
Throttle lever
9
Throttle lever "lock"
10
Choke lever
11
Starter cord
13
14
15
16
17
18
19
20
21
22
6
Spark plug boot
Air filter housing cover
Fuel Tank (Use 2-Stroke Fuel & Oil Mix, see pg.19)
Cowling
Fuel pump "primer"
Shoulder strap
Shaft split connection
Spark plug wrench
Allen key (4mm)
Allen key (5mm)
R
12
ep No
ro t fo
du r
ct
io
n
1
Spanner
Do not operate the VICTA Trimmer
before reading all Safety &
Handling sections.
Trimmer Parts Description bent shaft TTB2226/STB2224
9
7
8
12
15
5 (STB2224)
10
5 (TTB2226)
13
16
14
17
ep No
ro t fo
du r
ct
io
n
4
11
18
3
1
R
6
1
2
4
18
5 (STB2224)
19
17
5 (TTB2226)
20
21
22
3
7
Machine Layout & Supplied Items solid shaft RTS1226
Cast trimmer head
2
3mmØ Nylon line
3
Straight shaft guard
4
Solid straight shaft
5
Handle
6
Engine stop switch
7
Throttle lever "release"
8
Throttle lever
9
Throttle lever "lock"
10
Choke lever
11
Starter cord
12
13
14
15
16
17
18
19
20
Spark plug boot
Air filter housing cover
Fuel Tank (Use 2-Stroke Fuel & Oil Mix, see pg.19)
Cowling
Fuel pump "primer"
Shoulder strap
Spark plug wrench
Allen key (4mm)
Allen key (5mm)
Spanner
R
21
ep No
ro t fo
du r
ct
io
n
1
8
Do not operate the VICTA Trimmer
before reading all Safety &
Handling sections.
Trimmer Parts Description
9
7
8
12
15
10
13
5
16
14
17
ep No
ro t fo
du r
ct
io
n
4
11
3
R
6
solid shaft RTS1226
1
2
18
17
5
19
20
21
3
9
HANDLING
Safety Instructions
Do not operate the VICTA Trimmer before reading all Safety &
Handling sections.
Operator Safety
• Wear the necessary safety equipment, as listed on page (12), in Personal Safety
Equipment.
• Always wear heavy, long pants. Do not wear loose clothing, jewellery, short pants,
sandals or go barefoot. Secure hair so it is above shoulder length.
• Do not operate the unit if you are tired, ill or under the influence of alcohol, drugs or
medication.
ep No
ro t fo
du r
ct
io
n
Unit Safety
• Inspect the entire unit and cutting head before each use.
• Ensure that the guard is properly attached.
• Do not use the unit if it is running erratically. Have it serviced promptly.
• Keep handles free of oil and fuel.
• Learn how to stop the engine quickly in an emergency.
• Stop the engine when the unit is unattended, even for a moment.
• Never allow children or unauthorised persons to operate the unit.
• Do not leave the unit on dry cuttings when it is Hot, as a risk of fire is present.
• Do not cover muffler or restrict airflow to muffler.
• Do not touch the muffler or exhaust - Danger of burns.
R
Fuel Safety
• Use a container approved for fuel and a funnel to avoid spillage.
• Mix and pour fuel outdoors where there are no sparks or flames.
• Frequently check for fuel leaks and clean carbon from the muffler at exhaust outlet.
• Do not smoke or allow smoking near fuel, or near the unit, or while using the unit.
• Add fuel before starting the unit.
• Never remove the fuel tank cap while the engine is running or hot, allow to cool
before refuelling.
• Never allow the unit to run out of fuel before refuelling.
• Move at least three metres away from the fuelling site before starting the engine.
• Wipe all traces of fuel on the unit before starting the engine.
• Change your clothes before starting the unit if fuel has been spilt on them.
10
Safety Instructions
Starting Safety
• Start the engine with feet well away from the cutting head.
• Ensure that the area of starting and operation is clear of sticks, stones, glass, nails,
wire, string and debris, which could be thrown by the cutting head.
Cutting Safety
• Use only in good visibility and favourable weather conditions.
• Keep children, animals and bystanders outside the 15 metre hazard zone. Stop the
engine immediately if approached.
• Keep the engine to the right of your body, holding the unit with both hands.
• Keep a firm footing and balance. Do not over reach.
• Keep the cutting head below waist level and do not raise the engine above your
shoulder. The cutting head can come dangerously close to your body.
ep No
ro t fo
du r
ct
io
n
• Keep your body away from the cutting head and muffler when the unit is running.
• Do not strike objects that may cause harm or damage to the unit.
Maintenance Safety
• Stop the engine and disconnect the spark plug before clearing blockages, checking
or working on the unit.
• Stop the engine, disconnect the spark plug and inspect the unit if it begins to vibrate
abnormally or if it strikes a foreign object.
• Use only genuine VICTA trimmer line. Never use wire, rope, string, etc.
• Use only genuine VICTA replacement parts.
Transporting and Storage
• Hand carry the unit with the engine stopped, the muffler away from your body.
• Allow the engine to cool, empty the fuel tank and secure the unit before storing or
transporting in a vehicle.
R
r
HANDLING
• Empty the fuel tank after each use and before storing the unit.
• Store the unit and fuel well away from sparks or open flames from water heaters,
electric motors, switches or furnaces, etc.
• Store the unit out of reach of children and unauthorised persons.
11
HANDLING
Hazards
The following safety precautions must be strictly observed to avoid the risk of damage or
personal injury.
Prior to using the unit, clear the operating area of objects which may
be thrown up by the cutting head, such as rocks, glass and other
debris.
Do not start or operate the unit inside a closed room or building.
Breathing exhaust fumes can kill.
Be careful when operating the unit on slippery ground or overgrown
terrain. Be attentive for concealed hazards, such as ditches, tree
stumps and roots.
ep No
ro t fo
du r
ct
io
n
Maintain solid footing and balance while operating the unit. Cut only
on ground level.
Never use the unit without the guard securely in place.
Do not touch the cutting head in motion. When handling blades for
assembly or maintenance tasks, always wear protective gloves.
R
Bystanders must be at least 15 metres away during operation of
the unit (fig 1), as rocks and other materials may be thrown at high
velocities. Switch the unit off immediately if approached.
Keep body away from hot muffler parts.
Personal Safety Equipment
Always use the following safety equipment when working with your trimmer:
• A safety helmet fitted with a visor or suitable eye protection.
• A set of ear muffs.
• A pair of protective gloves.
• A pair of safety boots.
12
Fitting Trimmer Head
Blade
protector
BENT SHAFT (Sabre & Tornado)
1.
Replace blade protector.
2.
Align hole in flange and housing.
3.
Insert Allen Key (supplied) into hole in
flange and housing to prevent rotation.
4.
Grip the cast head and rotate
anti-clockwise to remove.
5.
Refitting is in reverse order.
Line
cutting
blade
Ensure the blade on guard is covered.
Housing
2. Align housing slot with key hole
ep No
ro t fo
du r
ct
io
n
Flange
Always disconnect spark plug H.T.
lead before any work is done on
the trimmer.
3. Allen Key
STRAIGHT SHAFT (Tornado Plus and Razor)
1.
Replace blade protector.
2.
Align hole in flange and housing.
3.
Insert Allen Key (supplied) into hole in flange and housing to prevent rotation.
4.
Grip the cast head and rotate clockwise to remove.
5.
Refitting is in reverse order.
Ensure the blade on guard is covered.
R
r
ASSEMBLYPROCEDURES
2. Align housing slot with key hole
Housing
Trimmer Flange
Always disconnect spark
plug H.T. lead before
any work is done on the
trimmer.
3. Allen Key
Flange
NOTE: Not aligning the flange to the housing hole will cause damage.
Trimmer nylon line will deteriorate with time resulting in more frequent
line breakages.
13
ASSEMBLYPROCEDURES
Fitting Trimmer Line
1
2
Bend middle
3
Slot in
cast
head
6
8
R
7
ep No
ro t fo
du r
ct
io
n
5
4
(1) Cut a length of line to 44cm, or use Victa part number TR00200A. Bend it in half
(equal ends). Use only 3mm diameter Nylon line (Fig: 1)
(2) Push the bent end of the line under the lug of the trimmer head
(3) Push one end of the line into the hole on the same side of the head as the line end.
Pull the line through the hole until loops or slack between the hole and centre lug is
removed.
(4) Repeat step 3 for opposite side. (5) Refer to image for correct complete assembly of
the nylon line into the head.
Removing Trimmer Line
(6) To remove used line, bend new line as in (1), slide new line under used line through
slot in cast head.
14
(7) Holding both ends of the new line together, pull the old line out of the cast head.
Repeat process for the other side (8).
ASSEMBLYPROCEDURES
Fitting Trimmer Line
Only use genuine VICTA 3mm diameter nylon trimmer line.
Always trim with the correct length of nylon line.
Always ensure that all components are firmly fastened before
starting any operation.
ep No
ro t fo
du r
ct
io
n
Unequal lengths will cause vibration and damage to unit.
Excessive trimmer line length will damage guard and clutch.
Replace line when 50mm from trimmer head body
R
Remove used line by pushing back into trimmer head or by levering
out.
15
ASSEMBLYPROCEDURES
Shaft Assembly
Fig. 1
Assembling the split shaft
(Sabre, Tornado, Tornado Plus only)
1. Slacken the star grip screw (1) on the split shaft
connection. (see Fig 1)
2. Then press lever on the shaft split connection (2)
and carefully slide the lower shaft (4) into the
shaft split connection (3). (see Fig 1 & 2)
When doing so, take care to ensure the
drive shafts on the insides of the tubes
slide into each other.
(turn the trimmer head gently if required)
Fig. 3
STANDARD CONNECTION
SHOWN
ep No
ro t fo
du r
ct
io
n
3. Ensure that the lever on the shaft split connection
locks into the corresponding hole (5). (see Fig 3)
4. Then re tighten the star grip screw (1). (see Fig 4)
5. To dismantle, proceed in reverse order.
Fig. 2
Fig. 4
Take care when
when fitting
& tightening.
Beware of
pinch points
Connection Types - Victa Trimmers have two types of split shaft connections;
1. Standard Connection (Fig 5) - Drive shafts may require alignment before sliding together.
2. “EASY LINK” Connection (Fig 6) - Drive shafts will automatically align when sliding together.
R
The two illustrations below will help identify which type of connection you have purchased.
Please refer to this information when fitting alternative Victa Attachments.
DO NOT MIX DRIVE SHAFT CONNECTION TYPES
Standard Connection
Easy Link Connection
16
Fig. 5
Fig. 6
ASSEMBLYPROCEDURES
Classic Handle
Fitting the handle
1 Slacken the wing nut on the fastening screw on the handle.
2 Remove the wing nut, washer and fastening screw from the handle.
3 Push the Classic handle onto the shaft.
ep No
ro t fo
du r
ct
io
n
4 Replace fastening screw and tighten with the wing nut.
Not too loose or too tight. Over tightening may damage the unit.
Universal Handle
1
Toggle open position
2
R
3
Toggle closed position
Fitting the handle
(1) Components - 2 nuts, 'D' Grip Handle, Toggle
handle and 'U' Bolt.
Correct
Wrong
(2) Place Universal Handle (2) over shaft.
(3) Insert Toggle Handle (3) around shaft and into
holes in Universal Handle.
(4) Screw on nuts (1) onto threads of 'U' Bolt by
fingers only, with toggle in open position.
(5) Be sure only to thread nuts (1) down so the
Toggle Handle has enough grip onto the shaft,
when levered into the close position.
Not too loose or too tight. Over tightening may damage the unit.
17
ASSEMBLYPROCEDURES
Before Assembly
Fitting the bent shaft guard
• Slacken the fastening screw on the guard with the help of the Allen key provided and
then remove.
• Then clip the guard to the lower bent shaft.
ep No
ro t fo
du r
ct
io
n
• Screw the guard hood tightly in position with the fastening screw.
Make sure the guard is located on the housing before securing in
position.
Fig: 1
Fig: 2
Fig: 3
Fitting the straight shaft guard
1. Remove two screws from guard (Fig 1).
Position guard under the securing saddle (Fig 2).
3,
Secure the two screws into the guard (Fig 3).
R
2.
Fitting the carrying strap
• The strap is intended to help you work safely and ergonomically with the petrol grass
trimmer.
• Hook the strap into the fastening eyelet.
• Slip the strap over the shoulder.
18
• Set the length of the shoulder strap in such a way that the trimmer head runs parallel
to the ground. In order to establish the optimum length of the strap, you should then
make a few swinging movements without starting the engine.
OPERATINGINSTRUCTIONS
Before Starting Machine
Check the position & operation of controls to ensure you are
comfortable before you start using the machine. Triggers, starter cord
and grip position should provide smooth operation, balance & comfort
before starting the machine. Check that all screws are securely fastened
and also check all the safety devices.
Always use the shoulder strap when using the appliance.
Switch off the engine before you take off the shoulder strap.
Check the machine for the following each time before use:
s That there are no leaks in the fuel system
s That the cutting unit and all safety devices are in perfect condition
s That all screws are securely fastened
Recommended fuels
ep No
ro t fo
du r
ct
io
n
Fuel and oil
s Victa Trimmers require a mixture of petrol and oil in the fuel tank.
s Use only a mixture of normal unleaded petrol and 2-stroke engine oil. Mix the fuel
mixture as indicated on the fuel mixing table.
s Start the machine at least 3 m away from the refuelling site to avoid the possible risk
of fire.
s Do not smoke whilst refuelling or working with the machine.
s Do not use the trimmer near inflammable liquids or gases. This could result in an
explosion and/or fire.
Do not use a fuel mixture which has been kept for longer than 90
days, it may damage the unit.
R
Use Non-Victa makes of 2-stroke oil at the mixing ration of 25:1
If inadequate lubrication causes engine damage, the
manufacturer's engine warranty will be void.
Only use containers designed and approved for the purpose to
transport and store fuel.
s Pour the correct quantities of petrol and 2-stroke oil into a container. Then shake the
container well, before filling the trimmer fuel tank.
Fuel mixture table
Petrol (unleaded)
5 litre
2-stroke oil
200 ml (Non Victa Formula V 2-Stroke Oil)
Mixing procedure: 25 parts petrol to 1 part oil
5 litre
100 ml (Only for Victa Formula V 2-Stroke Oil)
Mixing procedure: 50 parts petrol to 1 part oil
USE Clean fresh “Regular Unleaded Fuel”
Fuel with up to 10% ethanol can be used - 25:1 Fuel/Oil Ratio
19
OPERATINGINSTRUCTIONS
Operation
A blade on the underside of the guard
hood automatically cuts the cutting
line to the optimum length. This is
covered by a guard. Remove the guard
before you start working and replace it
when you have finished working.
Blade
protector
Line cutting
blade
ep No
ro t fo
du r
ct
io
n
Starting the engine when cold
Fill the tank with the required amount of oil/petrol mix. See Fuel and oil.
PR
IM
ER
Choke
(1) Set the machine down on a hard, level surface.
(2) Set the choke lever to the ‘COLD’ position.
(3) Press the fuel pump (primer) 10 times (this is found under the air filter housing).
(4) Ensure the 'STOP SWITCH' (4) is set to the 'ON' position.
secure throttle lever:
Press throttle release (1)
Press throttle lever (2)
Press throttle lock (3)
Let go of the throttle release (1)
& throttle lever (2).
3.
1.
4.
R
(5) To
a.
b.
c.
d.
Note: By repressing the throttle lever this will
release the throttle lever from the locked position.
2.
(6) Hold the machine firmly and pull out the starter cord until you feel it start to resist.
Then tug sharply on the starter cord 4 times. The machine should start.
Never allow the starter cord to snap back. This may damage the machine.
(7) Once the engine has started, move the choke lever immediately to the ‘HOT’ position
and allow the machine to warm up for approx. 10 seconds.
• If the engine does not start up, repeat steps 6-7 above.
20
OPERATINGINSTRUCTIONS
Operation
Since the throttle lever is secured, the cutting tool starts to operate
when the engine is started. Release the throttle lock by simply pressing the
throttle lever (the engine then returns to running in idle mode).
If the engine does not start up even after several attempts, read the
section on Troubleshooting
Always pull the starter cord out in a straight line.
IF THIS IS NOT FOLLOWED, STARTER CORD WILL BE FRAYED
AND CORD WILL BREAK!
This is not covered by the Product Warranty.
ep No
ro t fo
du r
ct
io
n
Starting the engine when warm
If the machine has not been switched off for more than 15-20 minutes
• Set the machine down on a hard, level surface.
• Move the 'STOP' SWITCH to 'ON'.
• Secure the throttle lever (in the same way as described in Starting the engine when
cold).
R
• Hold the machine firmly and pull out the starter until you feel it start to resist. Then tug
sharply on the starter. The machine should start after 1-2 tugs. If the machine still fails
to start after 6 pulls, repeat steps 1-7 for starting the engine when cold.
21
OPERATINGINSTRUCTIONS
Switching Off the Engine
Emergency Stop procedure
• If it becomes necessary to stop the machine immediately. Let go of the throttle lever
and move the stop switch to 'OFF'.
Practical tips
• Practice all operating techniques with the engine switched off before you start to use
the machine.
DO NOT use steel wire or plastic-coated steel wire of any kind with
your Trimmer. Serious operator injury can result.
ep No
ro t fo
du r
ct
io
n
Periodically remove weed wrap to prevent overheating the drive shaft.
Weed wrap occurs when strands of weed become entangled around
the shaft beneath the debris shield. This condition prevents the shaft
from being properly cooled.
• Stop engine – Remove spark plug H.T. lead from spark plug.
• Remove Weed/Grass wrapped around Head/Shaft.
Trimming Procedures
• When properly equipped with a guard and cutting head, your unit will trim unsightly
weeds and tall grass in those hard-to-reach areas – along fences, walls, foundations
and around trees. It can also be used for scalping to remove vegetation down to the
ground for easier preparation of a garden or to clean out a particular area.
R
Even with care, trimming around foundations, brick or stone walls,
curves, etc. will result in above normal string wear.
22
Trimming / Mowing
• Swing trimmer with a sickle-like motion from side to side. Do not tilt the cutting head
during the procedure. Test area to be trimmed for proper cutting height. Keep string
head at same level for even depth of cut.
OPERATINGINSTRUCTIONS
Trimming Procedures continued
Be aware of the trimmer head rotation.
Bent shaft
= Clockwise.
Straight shaft = Anti-Clockwise
Fence / Foundation Trimming
• Approach trimming around chain link fences, picket fences, rock walls and
foundations slowly to cut close without whipping string against the barrier. If the string
comes in contact with rock, brick walls, or foundations, it will break or fray. If string
snags fencing, it will snap off.
ep No
ro t fo
du r
ct
io
n
Trimming Around Trees
• Trim around tree trunks with a slow approach so string does not contact bark. Walk
around the tree trimming from left to right. Approach grass or weeds with the tip of
the string and tilt cutting head slightly forward.
R
Use extreme caution when SCALPING. Keep a distance of 100 feet
(30 metres) between operator, other people and animals during these
operations.
Scalping
Scalping refers to removal of all vegetation down to the ground. To do this, tilt the
cutting head to about 30 degree angle to the left. By adjusting the handle you will have
better control during this operation. Do not attempt this procedure if there is any chance
flying debris could injure operator, other people or cause damage to property.
23
Maintenance Chart
Maintenance
• Always switch off the machine and pull off spark plug H.T. lead before carrying out
any maintenance work.
ep No
ro t fo
du r
ct
io
n
Maintenance of the air filter
Tongue
Location
Dirty air filters reduce the engine output by restricting air to the carburettor.
R
Regular checks are therefore essential. The air filter should be checked monthly and
cleaned if necessary. If the air contains a lot of dust, the air filter should be checked
more frequently.
1. Remove the air filter cover
2. Remove the filter element
3. Clean the filter element by washing in soapy water and allowing it to dry completely.
4. Soak in a mixture of 25:1 2 stroke fuel / oil and squeeze off excess. (Use Gloves)
5. Assemble in reverse order.
Never clean the air filter with harsh solvents or chemicals.
Make sure Air Filter is fitted correctly, (warranty will be void if engine
is damaged due to incorrect fitment)
24
Maintenance Chart
Maintenance of the spark plug (Victa HA25735A = NGK BMPR7A)
Spark plug gap = 0.025 inch (0.7 mm).
ep No
ro t fo
du r
ct
io
n
Tighten the spark plug with a torque of 12-15 Nm.
Check the spark plug for dirt and grime after 10 hours of operation and if necessary
clean. Thereafter service the spark plug after every 50 hours of operation.
R
1. Pull off the spark plug boot by twisting.
2. Remove the spark plug with the supplied spark plug tube spanner.
3. Assemble in reverse order.
25
Storage
If you fail to follow these instructions correctly, deposits may form on
the interior of the carburettor which may result in the engine being
more difficult to start or the machine suffering permanent damage.
• Carry out all the maintenance work.
• Drain the fuel out of the tank.
• When the fuel has been drained, start the engine.
• Allow the engine to run at idling speed until it stops. This will clean the remainder of
the fuel out of the carburettor.
• Leave the machine to cool (approx. 5 minutes).
• Remove the spark plug.
ep No
ro t fo
du r
ct
io
n
• Place a teaspoon full of 2-stroke engine oil into the combustion chamber. Pull the
starter cable several times carefully to wet the internal components with the oil. Fit the
spark plug again.
• Clean the exterior housing of the machine.
• Store the machine in a cold, dry place where it is out of the reach of ignition sources
and inflammable substances.
Fertilizers and other chemical garden products often contain substances that accelerate
the rate of corrosion of metals. Do not store the machine on or near fertilizers or other
chemicals.
Restarting After Storage
• Remove the spark plug (page 25).
• Pull the starter cord several times to clean the oil residue out of the combustion
chamber.
• Clean the spark plug contacts or fit a new spark plug.
R
• Fill the tank. See the section entitled Fuel and oil.
• Complete steps 1-7 described under the point entitled Starting the engine from cold.
Transport
To transport the machine, first empty the petrol tank. Pump the primer to completely
remove fuel from the carburettor & empty excess from the tank.
Clean coarse dirt off the machine with a brush or hand brush.
Dismantle the split shaft as described (pg.16) if preferred.
26
Throttle trigger
interlock
Check
•
Stop switch
Check
•
Fuel tank
Clean Outside
Cutting Head Assy
Check & clean
Gearbox
Grease (straight shaft)
Air filter
Check
•
•
•
•
•
ep No
ro t fo
du r
ct
io
n
•
Replace (Depending on conditions)
Clean
Cylinder fins
Clean
Spark plug
Clean & readjust gap
Nylon Line
Stock replacement
Cast Trimmer Head
Clean
R
Muffler
Inspect
Inspect spark arresting screen
•
•
•
•
•
•
•
•
•
•
Replacement
All accessible fasteners Retighten
•
•
•
•
Clean
Cowling
As required
Check operation
If damaged
Throttle lever
Yearly
Visual inspection (leaks)
Monthly
Requirements
Trimmer
Refuelling
Features
After Use
Refer to the following table for routine maintenance.
Before Use
Maintenance Chart
•
•
•
•
•
•
•
Clean or replace
•
•
•
Always stop the engine before any maintenance is done on the unit.
When all parts have stopped rotating, remove the spark plug lead to
begin maintenance work.
Never repair cutting attachments by welding, straightening or
changing the shape. This may result in serious injury.
Never attempt maintenance that is not outlined in this manual. All
repair work must be carried out by a VICTA Authorised Service Centre.
27
TROUBLESHOOTING
If the unit does not start, or runs erratically, the problem may be solved by reference to
the chart below.
Problem
Possible cause
Engine will not start
Electrode is wet or fouled
Dry spark plug or replace
Carbon deposit on electrode
Clean spark plug
Cracked insulator
Replace spark plug
Spark plug (no spark)
STOP SWITCH in OFF position
Switch to ON
Too small or large electrode gap
Adjust gap to 0.7mm (0.025")
Burned electrode
Replace spark plug
Coil burned out, coil insulation
failure
Contact Service Centre
Break in coil wire, transistor
burned out
Contact Service Centre
Engine flooded
Crank engine choke off to
discharge fuel
Excessively thick fuel
Contact Service Centre
Use of incorrect fuel
Drain and replace with correct
fuel
Excessive wear on cylinder,
piston, rings
Contact Service Centre
ep No
ro t fo
du r
ct
io
n
Ignition system (no spark)
Remedy
Engine won't start - Good
compression, sufficient fuel (with
spark)
Poor compression, sufficient fuel
(with spark)
Loose spark plug
Tighten spark plug
No fuel in tank
Refuel
Loose fuel line fitting
Contact Service Centre
Clogged fuel line
Contact Service Centre
Plugged air vent in fuel tank
Clean vent/Contact Service
Centre
Insufficient power
Clogged air filter
Clean
Blockages
Carbon build up in muffler
Contact Service Centre
Fuel line/passage clogged
Contact Service Centre
Piston seizure, diaphragm
inoperative
Contact Service Centre
Water in fuel
Contact Service Centre
R
No fuel in carburettor (with
spark)
Overheating
28
Wide throttle position
Contact Service Centre
Excessively lean fuel mixture
Contact Service Centre
Carbon deposits on piston
Contact Service Centre
TROUBLESHOOTING
Troubleshooting
Problem
Engine makes knocking noise
Possible cause
Remedy
Improper fuel mixing ratio
Replace with correct 25:1 fuel
mix
Machine is overworked
Operate properly – do not
overload
Fan cover, cylinder fins, etc. dirty
Clean and remove dirt and
debris
Clean fins
Use of incorrect fuel
Replace with correct fuel
Poor acceleration
Fuel filter clogged
Contact Service Centre
Fuel system clogged
Excessively low idle
Speed up idle/Contact Service
Centre
Excessively lean carburettor
setting
Contact Service Centre
ep No
ro t fo
du r
ct
io
n
Cylinder overheating
Clogged air filter
Clean filter
Loose carburettor
Contact Service Centre
Loose fuel pick up tube
Insert firmly/Contact Service
Centre
Engine stops during operation
Switch is bumped
Keep hands clear of switch
Engine stops abruptly
Shorting of spark plug
Clean spark plug
Piston scored, ignition failure
Contact Service Centre
Fuel tank empty
Refuel
Air leakage
Miscellaneous
Contact Service Centre
Overheated engine
Run at idle
Overheating or electrical fault
Overheated spark plug
Clean and adjust gap to 0.7mm
(0.025")
Defective kill switch
Contact Service Centre
R
Carburettor or fuel tank clogged
Engine is difficult to shut off
Poor contact of ground wire
Contact Service Centre
Unit main body
Loose trimmer head
Tighten firmly
Irregular vibration or trimmer
head spins with engine idling
Broken clutch spring, bent main
shaft
Contact Service Centre
Worn shaft bearings
Contact Service Centre
Loose gearhead
Tighten bolt securely/Contact
Service Centre
If running difficulties continue, contact your closest VICTA Authorised Service Centre in
Australia and New Zealand.
Please look up and locate your local Authorised Service Centre on www.victa.com.au
or contact Victa Lawncare Customer Service (02 8778 5555).
N.Z. Customers (09 912 0747)
29
TECHNICALSPECIFICATIONS
Model Details
Features
Sabre
Tornado
Tornado Plus
Razor
STB2224
TTB2226
TTS2226
RTS1226
One cylinder,
air cooling
One cylinder,
air cooling
One cylinder,
air cooling
One cylinder,
air cooling
24
26
26
26
Carburettor type
Diaphragm
Diaphragm
Diaphragm
Diaphragm
Spark plug type
Victa HA25735A
NGK BPM R7A
Victa HA25735A
NGK BPM R7A
Victa HA25735A
NGK BPM R7A
Victa HA25735A
NGK BPM R7A
0.7
0.7
0.7
0.7
Code number
Engine
Displacement (cc)
Ignition
ep No
ro t fo
du r
ct
io
n
Spark plug gap (mm)
Electronic
Electronic
Electronic
Electronic
STANDARD
STANDARD
STANDARD
STANDARD
Shoulder strap
Yes
Yes
Yes
Yes
Anti-vibration rubber
Yes
Yes
Yes
Yes
400ml
400ml
400ml
600ml
5.0
5.0
5.2
5.2
80
80
79
80
Shaft type
Bent
Bent
Straight
Straight
Split
Yes
Yes
Yes
No
Drive
Flexible
Flexible
Flexible
Rigid
Direction *
Clock-wise
Clock-wise
Anti Clock-wise
Anti Clock-wise
Cut width
400mm
400mm
420mm
420mm
Blade guard
Fuel tank (litres)
R
Weight (kg)
Noise level dBA
* Direction of cutting head rotation facing from the normal user operating position
30
VICTAPRODUCTS
Accessories & Spare Parts
VICTA provides a range of safety equipment and spare parts that may be purchased at
any VICTA Authorised Service Centre.
VIC TA S afety ear muf fs
ep No
ro t fo
du r
ct
io
n
VIC TA S afety glasses
VICTA Trimmer Line
VICTA Formula V, Spark plug and Filter
VICTA recommends the use of its Formula V High Performance 2 Stroke Oil for
your fuel mixture.
R
For all VICTA Spare parts and service, look for the sign of confidence.
For details of your closest VICTA Authorised Service Centre call the following:
Ring (02) 8778 5555 Australia, or
(09) 912 0747 within New Zealand
www.victa.com
31
WARRANTY
Warranty
Consumer Rights
The buyer should be aware that in relation to goods which are of a kind ordinarily
acquired for personal, domestic or household use or consumption, certain provisions
such as the Trade Practices Act, 1974 (Aust) and the Consumer Guarantees Act, 1993
(NZ) apply. The terms set out below do not exclude rights and remedies implied by
a statute which are non-excludable and which may be more extensive than those
provided by this warranty.
Warranty Service
Warranty Service under both the Express Warranty and the warranties implied by law
is available at any VICTA Authorised Service Centre. These centres are staffed and
equipped to provide expert service.
Warranty Period
Model
Dome stic Use
2
2
2
2
Year/24
Year/24
Year/24
Year/24
Months
Months
Months
Months
Commercial Use
3
3
3
3
Months/90
Months/90
Months/90
Months/90
ep No
ro t fo
du r
ct
io
n
STB2224
TTB2226
TTS2226
RTS1226
Days
Days
Days
Days
VICTA Express Warranty
The VICTA Express Warranty is additional to the conditions and warranties which are
mandatorily implied by the laws and regulations of the individual States and Territories
of Australia and the Trade Practices Act, 1974 (Aust) and the Consumer Guarantees Act
in New Zealand and any non-excludable laws.
R
Under Express Warranty the 'Trimmer' is warranteed from the date of purchase against
mechanical defects and faulty workmanship or material. Express Warranty covers only
the replacement, repair or adjustment of parts which fail due to a fault in manufacture.
Defective parts will be replaced or serviced by an Authorised VICTA representative
without charge for labour or materials, subject to conditions. Repairs or adjustments
required by normal use or by failure to follow the manufacturer's instructions are
chargeable to the owner.
VICTA Service Representatives or agents are authorised to determine whether a claim
will be covered under warranty, or payable by the owner on completion.
You should seek independent legal advice to determine whether a claim not covered by
the Express Warranty is covered by any warranties implied by law.
Conditions
s Express Warranty applies to the original purchaser only. Proof of purchase date must
be provided prior to Express Warranty work.
s Use of parts other than genuine VICTA Spare Parts cancels the Express Warranty.
s Repairs other than by a VICTA Authorised Service Centre cancels the Express
Warranty.
32
WARRANTY
Warranty continued
• Altering the product (including governed speed) cancels the Express Warranty..
• A trimmer run with incorrect fuel or oil, or oil level, is not covered by the Express
Warranty.
• Failure to properly service cooling or air filtration systems cancels the Express
Warranty.
• Failure to follow the instruction manual or labels attached cancels the Express
Warranty.
• Fair and reasonable wear is not covered by the Express Warranty.
• Damage from an accident, misuse or neglect is not covered by the Express Warranty.
• Costs of transportation of the trimmer are to be paid by the owner.
ep No
ro t fo
du r
ct
io
n
• Trimmer line, air filter and spark plugs are not covered by the Express Warranty.
Limitations of Warranty
Nothing in these terms shall exclude, restrict or modify any term, condition, warranty or
liability implied into this contract by statute, where to do so would be unlawful or would
render any provision of this contract void. Subject to that, all warranties implied by
statute in respect of the goods are hereby expressly negated and VICTA's liability for
the goods is limited to any warranties issued in writing by VICTA and VICTA is excluded
from any liability whether under this contract or otherwise to the buyer of any third party
for any loss, injury, cost or damage (direct, indirect, special, consequential, or otherwise
and whether or not arising from a negligent act or omission of VICTA), incurred or
suffered by reason for the goods, their use, their design or any failure to deliver or delay
in delivering them. Where it is legal to do so, any remaining liability implied by statute
or resulting from breach of any term, condition or warranty implied by statute is limited
to, at VICTA's sole option:
• the replacement of the goods or the supply of equivalent goods;
R
• the repair of goods;
• the payment of the cost of replacing the goods or of acquiring equivalent goods; or
• the payment of having the cost of the goods repaired.
In particular, your rights and remedies under the Trade Practices Act (Aust) and the
Consumer Guarantees Act (NZ) are not excluded.
33
ep No
ro t fo
du r
ct
io
n
R
NOTES
34
ep No
ro t fo
du r
ct
io
n
R
NOTES
35
ep No
ro t fo
du r
ct
io
n
R
©2007 Victa Lawncare Pty Ltd
Victa is a trademark of Victa Ltd.
All rights reserved. No part of this booklet may be reproduced by any means
without prior written permission. All information herein is subject to change without notice.
LR00817A-C1

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
