User Manual.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: To reduce the risk of electric shock, do no remove the front or back covers.
No user-serviceable parts inside. Refer servicing to qualified service personnel only.
The lightning flash with arrow-head
within a triangle is intended to inform
the user that parts inside the product
are a risk of electric shock.
The exclamation point within a triangle
is intended to tell the user that important
operating and servicing instructions are
explained.
WARNINGS & PRECAUTIONS
To prevent damage which may result in fire or shock hazard, do not expose this product to rain or
moisture.
To prevent electric shock, do not remove cover. No user serviceable parts are inside. Refer servicing to
qualified service personnel only.
Keep monitor away from excessive dust, high temperatures, moisture or direct sunlight.
Use in a well-ventilated area and do not cover ventilation openings.
Unauthorized modification this equipment or usage of an unshielded connecting cable may cause
excessive interference.
When the monitor is not in use for a long period of time, disconnect it from the electric outlet.
If the picture displayed is in any way abnormal, turn off the unit and disconnect it from the electric
outlet. Verify your signal wire connections and reconnect the monitor to the electric outlet.
Disconnect from the electric outlet before cleaning. Do not use liquid or aerosol cleaners. Use only a
slightly damp cloth for cleaning.
Do not place this product on an unstable cart, stand or table. The product may fall, causing serious
damage.
Do not place the unit on a bed, sofa, rug, or other similar surfaces. Never place the unit near or over a
radiator or heat source. Do not install unit in an enclosed area unless proper ventilation is provided.
The unit should be operated from the type of power source indicated on the label. If the type of available
power is unknown, consult your dealer or local power company.
The unit is equipped with a 3-pin grounded plug. The plug will only fit into a grounded power outlet. This
is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician. Do not
alter the plug; this will defeat the safety feature.
Do not rest objects on the power cord & avoid placing power cord near high traffic areas.
Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.
Disconnect the unit from the main supply and refer servicing to qualified service personnel under the
following conditions:
• Power cord or plug is damaged or frayed.
• Liquid has been spilled into the product.
• Unit has been exposed to water or moisture.
• Unit does not operate normally when the operating instructions are followed. Adjust only those
controls that are covered by the operating instructions, improper adjustment of other controls may
result in damage which often requires extensive work by a qualified technician to restore the unit to
normal operation.
• Unit has been dropped or the cabinet has been damaged.
• Unit exhibits a distinct change in performance, indicating a need for service.
1
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ............................................................................................
TABLE OF CONTENTS ....................................................................................................................
FCC STATEMENT ............................................................................................................................
Wichtige Sicherheitshinweise ...........................................................................................................
CLEANING AND MAINTENANCE ....................................................................................................
PACKAGE CONTENTS ....................................................................................................................
UNDERSTANDING YOUR MONITOR
Front View ...........................................................................................................................
Rear View ...........................................................................................................................
CONNECTING THE MONITOR
Connecting a PC .................................................................................................................
USING THE MONITOR - BASICS
Powering ON/OFF ...............................................................................................................
Selecting Signal Source ......................................................................................................
ADVANCED FUNCTIONS
Widescreen (16:9 Aspect Ratio) Viewing Modes .................................................................
On-Screen Display (OSD) Settings .....................................................................................
Sleep Timer Settings ...........................................................................................................
Signal Frequency Information Display ..................................................................................
ADJUSTING PICTURE
For RGB / DVI .....................................................................................................................
TROUBLESHOOTING ......................................................................................................................
SPECIFICATIONS ............................................................................................................................
WALL MOUNT (OPTIONAL) INSTALLATION ....................................................................................
2
1
2
3
4
5
6
7
7
8
9
9
9
10
10
11
12
13
14
19
FCC STATEMENT
FCC Compliance Statement
The equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
strict accordance with the instruction manual, may cause harmful interference to radio communications.
There is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures
•
•
•
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at the user’s own expense.
Shielded interconnected cables and shield power cords must be employed with this equipment to insure
compliance with the pertinent RF emission limits governing this device.
Changes or modifications not expressly approved by the manufacturer could void the user's authority to
operate the equipment and invalidate the warranty.
Canadian Compliance Statement
This Class A digital apparatus meets all requirements of the Canadian Interference Causing Equipment
Regulations.
Cet appareil numérique de la Classe A respecte toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
3
Wichtige Sicherheitshinweise
1. Bitte lesen Sie sich diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine
Flüssig- oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung.
4. Umeine Beschädigung des Gerätes zu vermeiden sollten Sie nur Zubehörteile
verwenden, die vom Hersteller zugelassen sind.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen oder
Fallen könnte Verletzungen hervorrufen. Verwenden Sie nur sichere Standorte und
beachten Sie die Aufstellhinweise des Herstellers.
7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät vor Überhitzung schützt.
Sorgen Sie dafür, daß diese Öffnungen nicht abgedeckt werden.
8. Beachten Sie beim Anschluß an das Stromnetz die Anschlußwerte.
9. Die Netzanschlußsteckdose muß aus Gründen der elektrischen Sicherheit einen
Schutzleiterkontakt haben.
10. Verlegen Sie die Netzanschlußleitung so, daß niemand darüber fallen kann. Es sollte
auch nichts auf der Leitung abgestellt werden.
11. Alle Hinweise und Warnungen die sich am Geräten befinden sind zu beachten.
12. Wird das Gerät uber einen längeren Zeitraum nicht benutzt, sollten Sie es vom Stromnetz
trennen.Somit wird im Falle einer Überspannung eine Beschädigung vermieden.
13. Durch die Lüftungsäffnungen dürfen niemals Gegenstände oder Flussigkeiten in das
Gerät gelangen. Dies könnte einen Brand bzw. elektrischen Schlag auslösen.
14. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen Sicherheit
nur von authorisiertem Servicepersonal geöffnet werden.
15. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und von
einer qualifizierten Servicestelle zu überprufen:
Netzkabel oder Netzstecker sind beschädigt.
Flussigkeit ist in das Gerät eingedrungen.
Das Gerät war Feuchtigkeit ausgesetzt.
Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder Sie mit
Hilfe dieser Anleitung keine Verbesserung erzielen.
Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
16. Bei Reparaturen dürfen nur Orginalersatzteile bzw. Den Orginalteilen entsprechende Teile
verwendet werden. Der Einsatz von ungeeigneten Ersatzteilen kann eine weitere
Beschädigung hervorrufen.
17. Wenden Sie sich mit allen Fragen die Service und Reparatur betreffen an Ihren
Servicepartner. Somit stellen Sie die Betriebssicherheit des Gerätes sicher.
4
CLEANING AND MAINTENANCE
Cautions When Using the Plasma Display
Do not bring your hands, face or objects close to the ventilation holes of the plasma
display. Top of plasma display is usually very hot due to the high temperature of exhaust
air being released through the ventilation holes. Burns or personal injuries may ocurr if
any body parts are brought too close. Placing any object near the top of the display
could also result in heat related damages to the object as well as the display itself.
Be sure to disconnect all cables before moving the plasma display. Moving the display with its cables
attached may damage the cables and thus case fire or electric shock danger.
Disconnect the power plug from the wall outlet as a safety precaution before carrying out any type of
cleaning or maintenance procedure.
Front Panel Cleaning Instructions
The front of the display has been specially treated. Wipe the surface gently using only a cleaning cloth
or a soft, lint-free cloth.
If the surface is particular dirty, soak a soft, lint-free cloth in a mild detergent solution. Wring the cloth
to remove excess liquid. Wipe the surface of the display to remove dirt. Then use a dry cloth of the
same type to dry.
Do not scratch or hit the surface of the panel with fingers or hard objects of any kind.
Do not use volatile substances such as insect sprays, solvents and thinners.
Cabinet Cleaning Instructions
If the cabinet becomes dirty, wipe the cabinet with a soft, dry cloth.
If the cabinet is extremely dirty, soak a lint-free cloth in a mild detergent solution. Wring
the cloth to remove as much moisture possible. Wipe the cabinet. Use another dry cloth
to wipe over until the surface is dry.
Do not allow any water or detergent to come into contact with the surface of the display.
If water or moisture gets inside the unit, operating problems, electrical and shock hazards may result.
Do not scratch or hit the cabinet with fingers or hard objects of any kind.
Do not use volatile substances such as insect sprays, solvents and thinners on the cabinet.
Do not place anything made from rubber or PVC near the cabinet for any extended periods of time.
Avoid Still Images
Do not allow a still picture to be displayed for extended periods of time. This can cause a
permanent image to remain on the plasma display. Examples of still images may
include: still computer images, still video game images, still logos or pictures, text and
images displayed in 4:3 Normal mode.
Contents of this manual is subject to change without notice.
Trademark Credits
VGA is a trademark of IBM Corporation.
Macintosh is a registered trademark of Apple Computer Corporation.
SVGA is a registered trademark of the Video Electronics Standard Association.
BBE is a registered trademark of BBE Sound Inc.
SRS and
symbol are trademarks of SRS Labs Inc.
SRS technology is incorporated under license from SRS Labs, Inc.
All other trademarks are the properties of theri respective owners.
R
5
PACKAGE CONTENTS
Supplied Accessories
Please verify that you received the following items with your package content:
Plasma Monitor
Power Cable
6
User Manual
VGA Cable
UNDERSTANDING YOUR MONITOR
Front View
Power (Standby) Button
Turns power on/off from standby mode. There is a 3second wait between on/off cycles.
Status LED
Not Illuminated - No AC Power detected
If the main power switch (rear of panel) is turned
off, this LED will not illuminate.
Solid Yellow - Standby (Power OFF) with AC
power detected
The LED will illuminate in yellow color if the
monitor is shut-off but the main power cord is
plugged into the back of the unit.
Solid Green - Power ON
Input Button
Use this button to switch between available inputs.
Menu +/- Buttons
Use this menu to engage the On Screen Display
menu.
Volume Adjustment +/- Buttons
Use these buttons to adjust settingt when On
Screen Display is engaged.
Rear View
RGB / Computer Related Connectors
7
CONNECTING THE MONITOR
Connecting a PC
Using RGB or DVI Video Input
For most PC’s, connect the 15-pin D-Sub RGB connector from the back of the PC to the RGB-IN Connector
located on the back of the monitor. If you have a PC that is equipped with a DVI (Digital Visual Interface),
you may connect the PC DVI connector from the back of the PC to the DVI-In Connector located on the
back of the monitor.
Notes:
A RGB loop-out labeled “RGB Out” will allow another RGB monitor to be connected. The RGB loop-out
will display the same signal as the RGB In signal source.
The physcial display resolution is a maximum of 640x480 dots when aspect ratio is set to “4:3”, and
852x480 dots when set to “16:9”. If the PC’s display resolution exceeds these maximums, the monitor
will have to artificially eliminate dots in order to fit within the physical dot capability of the display;
therefore, it is possible that the monitor may not be able to show details with adequate clarity.
8
USING THE MONITOR - BASICS
Powering ON / OFF
Using Front Panel or Remote Control
1. Make sure the monitor is plugged into the wall
outlet and the main AC switch located in the
rear of the monitor is switched to ON position.
If the power is plugged in and the AC switch is
on, the STATUS LED will illuminate in solid
yellow color.
2. Press the POWER button on the front panel or
the remote control.
3. The monitor will now turn on after a brief pause.
The STATUS LED will now turn green to indicate
power on status.
4. To turn power off, simply press the POWER
button on the front panel or the remote control
once again.
POWER (Toggle)
Status LED
Not Illuminated - No AC
Power detected
If the main power switch
(rear of panel) is turned
off, this LED will not
illuminate.
Solid Yellow - Standby
(Power OFF) with AC
power detected
The LED will illuminate in
yellow color if the monitor
is shut-off but the main
power cord is plugged into
the back of the unit.
Solid Green - Power ON
Selecting Signal Source
Input Select
(Toggle)
Using Front Panel or Remote Control
1. Press the INPUT key on the front panel or the
INPUT SELECT key on the remote control.
2. Pressing the INPUT key will cycle the monitor
thru all available input signal sources in the
following order:
Widescreen Viewing Modes
Accessing Widescreen Viewing Modes using OSD
You can use the OSD menu to access the
widescreen function. To access these modes using
OSD:
1. Press the MENU +/- keys on the front control
panel.
2. Make sure that the following “Picture” OSD menu
is displayed.
3. Use the MENU +/- keys to navigate to SCREEN
WIDTH and use the ADJ +/- keys to switch
between 4:3 or 16:9.
9
ADVANCED FUNCTIONS
On-Screen Display (OSD) Settings
Accessing OSD Settings Menu
You can set various OSD display settings from the OSD menu.
1. Press the MENU +/- keys on the front control panel.
2. Use the ADJ +/- keys to navigate to “OTHER” OSD sub-menu as displayed below.
OSD Timeout
Turns on OSD timer when set to ON. When set to ON, the OSD will
automatically disappear from the display if no key action is detected
for the set number of seconds. If set to OFF, then OSD will remain
on the screen.
OSD Time Setting
Sets the number of seconds the OSD will remain active on the
display before turning itself off. OSD TIMEOUT must be set to ON
for this setting to function.
OSD Brightness
Sets the brightness level of OSD screen between 1 and 10.
OSD Background
You can set the OSD menu’s background to transparent or with a
blue background. Set to OFF if you want a transparent setting. Set
to ON if you want a blue background.
Note:
To prevent permanent after-image, we strongly suggest setting the
“OSD Timout” to ON.
Sleep Timer Settings
Setting Sleep Timer Using OSD
To set the sleep timer using the OSD screen:
1. Press the MENU +/- keys on the front control panel.
2. Use the ADJ +/- keys to navigate to “OTHER” OSD sub-menu as
displayed below.
3. Use the MENU +/- keys to navigate to SLEEP function.
4. Use the ADJ +/- keys to set to ON.
5. The monitor will function normally until the 1-minute mark. At the 1minute mark, the sleep timer will display a second by second countdown clock to notify that you that the monitor is about to turn off.
Sleep Timer On/Off
To turn on sleep timer,
switch to ON position. To
turn OFF sleep timer, switch
to OFF.
Timer Setting
You can set the turn-off
timer from 1 to 120 minutes.
Use the ADJ +/- keys to set
any number between 1 and
120.
10
Power Off Warning
SLEEP TIMER
0:59
ADVANCED FUNCTIONS
Signal Frequency Information Display
Displaying Frequency of Signal
This monitor is capable of displaying the frequency level of the signal being displayed. To see signal
frequency information:
1. Press the MENU +/- keys on front control panel.
2. Use the ADJ +/- keys to navigate to the “OTHER” OSD sub-menu.
INPUT H-FREQ (KHZ)
Displays the horizontal signal frequency of the signal currently
displayed. Please use the frequency cross reference tables below
to see which type of signal is being displayed under various input
modes.
INPUT V-FREQ (HZ)
Displays the vertical signal frequency of the signal currently
displayed. Please use the frequency cross reference tables below
to see which type of signal is being displayed under various input
modes.
When Using RGB & DVI Inputs
Mode Horizontal Vertical Format
1
31.5
59.9
640×480 (VGA)
2
37.9
72.8
640×480 (VGA)
3
37.5
75.0
640×480 (VGA)
4
43.3
85.0
640×480 (VGA)
5
35.1
56.3
800x600 (SVGA)
6
37.9
60.3
800x600 (SVGA)
7
48.1
72.2
800x600 (SVGA)
8
46.9
75.0
800x600 (SVGA)
9
53.7
85.0
800x600 (SVGA)
10
48.4
60.0
1024x768 (XGA)
11
56.5
70.0
1024x768 (XGA)
12
60.0
75.0
1024x768 (XGA)
13
68.7
85.0
1024x768 (XGA)
14
64.0
60.0
1280x1024 (SXGA)
15* 80.0
75.0
1280x1024 (SXGA)
16* 91.1
85.0
1280x1024 (SXGA)
18
31.5
70.0
720x400 (DOS)
19
31.5
50.0
640x480 (VGA)
20* 45.2
60.0
1280x720P (HDTV)
21* 33.8
60i
1920x1080i (HDTV)
22
31.5
70.0
640x350 (VGA)
23
31.7
60.4
852x480 (WVGA)
24
35.0
66.7
640x480 (Apple)
25
49.7
74.6
832x624 (Apple)
26
68.7
75.0
1152x870 (Apple)
RGB
M: 05
Refresh
60
72
75
85
56
60
72
75
85
60
70
75
85
60
75
85
70
50
60
60
70
60
67
75
75
Notes:
When using RGB mode, the OSD will display a mode
number that references the table above.
Modes 15, 16, 20, 21 under RGB mode is not available
when using with DVI input.
Modes 24-26 are for use with Apple Macintosh
computers.
11
PICTURE ADJUSTMENT
For RGB / DVI
Accessing Picture Adjustment Mode
Various picture adjustments can be set using the Picture
Adjustment OSD menu. To access the OSD menu:
1. Press the MENU +/- keys on the front control panel.
2. The first menu displayed is the PICTURE menu.
Make sure that the “Picture” OSD menu is displayed.
3. Use the MENU +/- keys to move up and down to
choose the option you wish to adjust. An explanation
of each adjustment is listed below.
4. Use the ADJ +/- keys to change the setting.
CONTRAST
Adjust Contrast to increase the level of “white” in the video picture.
Increasing contrast will make white areas of the video picture brighter.
Contrast works in conjuction with BRIGHTNESS.
BRIGHTNESS
Adjust brightness to enhance the level of dark areas in the video picture
such as night scenes and shadow scenes. Increasing brightness will
make dark areas more visible.
COLOR TEMPERATURE
Select the color temperature for white balance. There are four settings to
choose from: (1) 6500D - sets the white balance to 6500D; (2) LOW - sets
to 5500K; (3) MID - sets to 9300K; (4) HIGH - sets to 13800K
CLOCK PHASE
Use clock phase to fine-tune the monitor to perfectly synchronize the
video’s signal source.
SCREEN WIDTH
Use to change various screen width modes. There are two selections
available: 16:9 and 4:3.
V-SIZE
Use to change vertical size of the picture. Increase to enlarge the picture
size in the vertical direction. Decrease to reduce the picture size in the
vertical direction.
V-CENTER
Use to change vertical position of the picture. Increase to shift the picture
up. Decrease to shift the picture down.
H-WIDTH
Use to change horizontal size of the picture. Increase to enlarge the
picture size in the horizontal direction. Decrease to reduce the picture
size in the horizontal direction.
H-POSITION
Use to change horizontal position of the picture. Increase to shift the
picture to the right. Decrease to shift the picturn to the left.
Notes:
1. Each of the (4) color temperature settings may not be exactly equal to the temperature setting as
defined; however, it will be approximately close.
12
TROUBLESHOOTING
Troubleshoot Common Conditions
The following list represents possible anomalies that you may encounter and methods for remedy. Please
refer to this checklist prior to contacting a service representative.
Symptom
No picture is displayed
Possible Cause
1.
2.
3.
4.
Remedy
The power cord is disconnected.
The main power switch on the back of the
monitor is not switched on.
The selected input has no connection.
The monitor is in standby mode in RGB
mode.
1.
2.
3.
4.
Plug in the power cord.
Make sure the power switch is
switched on.
Connect a signal connection to the
monitor.
Press any key on your keyboard.
Interference displayed on
the monitor
1.
Caused by surrounding electrical
appliances, cars/motorcycles or fluorescent lights.
1.
Move the monitor to another location to
see if the interference is reduced.
Color is abnormal
1.
The signal cable is not connected
properly.
1.
Make sure that the signal cable is
attached firmly to the back of the
monitor.
Picture is distorted with
abnormal patterns
1.
The signal cable is not connected
properly.
The input signal is beyond the capabilities
of the monitor.
1.
Make sure that the signal cable is
attached firmly.
Check the signal source to see if it is
beyond the range of the monitor.
Please verify its specifications with
this monitor’s specification section.
2.
2.
Display image doesn’t fill up
the full size of the screen
1.
If under RGB mode, the H-Size and V-Size
is incorrectly set.
1.
Use H-Size and V-Size to adjust the
size of the video.
Some picture elements do
not light up
1.
Some pixels of the plasma display may not
turn on.
1.
This monitor is manufactured using an
extremely high level of precision
technology; however, sometimes some
pixels of the monitor may not display.
This is not a malfuction. Please see the
enclosed warranty card for more
information.
After-Images can still be
seen on the monitor after
the monitor is powered off.
(Examples of still pictures
include logos, video games,
computer images, and
images displayed in 4:3
normal mode)
1.
A still picture is displayed for an over
extended period of time.
1.
Do not allow a still image to be
displayed for an extended period of
time as this can cause a permanent
after-image to remain on the monitor.
13
SPECIFICATIONS
Display Panel
Screen size
Aspect ratio
Number of pixels
Pixel Pitch
Luminance
Diagonal 42 inch
16:9 wide
852(Horizontal, RGB Trio ) X 480(Vertical)pixels
1.08mm X 1.08mm
500cd/m2,at APL13%
Power Source
Input voltage
Input current
Inrush current
Power consumption
Stand-by & DPMS
90 ~ 240 Vac , 50 / 60 Hz
3.3A
60 A p-p/20ms Max.
340±10% Watts ( at 110Vac/color bar pattern)
5 Watts Max. (at 110Vac)
Connection
Connector Types
RGB Signal
Type
Polarity
Amplitude
Frequency
DVI Signal
Type
Polarity
Frequency
9 pin D-SUB for RS232
15 pin D-SUB for RGB
24 pin DVI
TTL
Positive or Negative
RGB: 0.7Vp-p
H: support to 31K~91KHz
V: support to 50~85Hz
Digital
Positive or Negative
H: support to 31K~63KHz
V: support to 50~85Hz
Pin Assignments For D-SUB Connector (In / Loop Out)
Pin Signal Assignment Pin Signal Assignment Pin Signal Assignment
1 RED
6 RED GND
11 GND
2 GREEN
7 GREEN GND
12 SDA
3 BLUE
8 BLUE GND
13 H-SYNC
4 GND
9 NC
14 V-SYNC
5 GND
10 GND
15 SCL
Pin Assignments For 24 Pin DVI Connector(Digital Only)
Pin Signal Assignment
Pin Signal Assignment
1 TMDS Data 29 TMDS Data 12 TMDS Data 2+
10 TMDS Data 1+
3 TMDS Data 2/4 Shield 11 TMDS Data 1/3 Shield
4 TMDS Data 412 TMDS Data 35 TMDS Data 4+
13 TMDS Data 3+
6 DDC Clock
14 +5V Power
7 DDC Data
15 Ground (For +5V)
8 No Connect
16 Hot Plug Detect
14
Pin
17
18
19
20
21
22
23
24
Signal Assignment
TMDS Data 0TMDS Data 0+
TMDS Data 0/5 Shield
TMDS Data 5TMDS Data 5+
TMDS Clock Shield
TMDS Clock +
TMDS Clock -
SPECIFICATIONS
RGB/DVI For VESA Standard
Refresh Horizontal
Mode
Rate
Frequency
No.
Resolution
(Hz)
(K Hz)
1
640(VGA)×480
60
31.5
2
640(VGA)×480
72
37.9
3
640(VGA)×480
75
37.5
4
640(VGA)×480
85
43.3
5
800(SVGA)×600
56
35.1
6
800(SVGA)×600
60
37.9
7
800(SVGA)×600
72
48.1
8
800(SVGA)×600
75
46.9
9
800(SVGA)×600
85
53.7
10
1024(XGA)×768
60
48.4
11
1024(XGA)×768
70
56.5
12
1024(XGA)×768
75
60.0
13
1024(XGA)×768
85
68.7
14
1280(SXGA)×1024 60
63.98
15*
1280(SXGA)×1024 75
79.98
16*
1280(SXGA)×1024 85
91.15
18
720(DOS)×400
70
31.46
19
640(VGA)×480
50
31.5
20*
1280(HDTV)×720P 60
45.15
21*
1920(HDTV)×1080I 60(I)
33.78
22
640(VGA)×350
70
31.50
23
852(WGA)×480
60
31.72
* These modes are not supported in DVI mode.
RGB/DVI For Apple Standard
Refresh Horizontal
Mode
Rate
Resolution
No.
Resolution
(Hz)
(K Hz)
24
640×480
67
35.00
25
832 x 624
75
49.73
26
1152 x 870
75
68.68
Maximum Resolution
Vertical
Frequency
(Hz)
59.94
72.81
75
85.01
56.25
60.317
72.19
75
85.06
60.01
70.07
75.03
84.99
60.02
75.03
85.02
70.08
50
60
60
70
60.41
V-Sync
Polariy
(TTL)
+
+
+
+
+
+
+
+
+
+
+
-
Vertical
Resolution
(Hz)
66.67
74.55
75.06
V-Sync
Polarity
(TTL)
-
H-Sync
Polarity
(TTL)
+
+
+
+
+
+
+
+
+
+
-
H-Sync
Polarity
(TTL)
-
Dot rate
(MHz)
25.175
31.500
31.500
36.000
36.000
40.000
50.000
49.500
56.250
65.000
75.000
78.750
94.500
108.00
135.00
157.50
28.320
25.175
74.250
74.250
25.175
30.00
Dot rate
(MHz)
30.240
57.283
100.000
Up to 1280 x 1024
Dimensions
Width
Height
Depth
Without/Stand
With/Stand
1040mm
1040mm
648 mm
690mm
95mm
287.5 mm
Package Dimensions
Width
Height
Depth
1230 mm
960 mm
470 mm
15
SPECIFICATIONS
Weight
Net weight
Gross weight
68.8lbs/31.2 Kgs (w/o stand) 77.2lbs/ 35Kgs (w/ stand)
101.4lbs/46 Kgs
Operating
Temperature
Relative humidity
Pressure
0~40oC (32~104oF)
20~80%
800~1114hpa
Non-Operating
Temperature
Relative humidity
Pressure
Vibration
-5~50oC
20~90%
600~1114hpa
X/Y/Z, 0.5G/10~55Hz(sweep), 10 minutes
Acoustics
(IHF A-weighted 1meter)
40dB Max.
Reliability Requirement
The MTBF is 20000hrs under operation 25±5o C (Half luminosity, motion picture)
Emission Requirement
The unit meet the EMI limits in all screen modes as qualified by FCC class A part 15.
Power Management
Mode
H-sync
Normal
Pulse
Stand-by
No pulse
Power saving
Pulse
No pulse
V-sync
Pulse
No pulse
No pulse
Pulse
Video
Active
No video
blanked
Power dissipation
Normal power
Power off
Less than 5 watts
This Plasma display is Energy star compliant when used with a computer equipped with DPMS.
16
SPECIFICATIONS
Preset Timing Chart
Item
A
B
C
D
E
F
G
H
I
Description:
Total time
Active display area including borders
Active display area excluding borders
Left/Top border
Right/bottom border
Blanking time
Front porch
Sync-width
Back porch
Mode No
H Resolution
V Resolution
Refresh Rate
Pixel
Horizontal visible
Horizontal total
Horizontal front porch
Horizontal sync
Horizontal back porch
Horiz blanking time
Vertical visible
Vertical total
Vertical front porch
Vertical sync
Vertical back porch
Vertical blanking time
Horizontal frequency
Vertical frequency
Vertical sync polarity
Horiz sync polarity
Dot rate
1
640
480
60
25.175
640
800
24
96
48
160
480
525
18
2
33
45
31.469
59.94
25.175
2
640
480
72
31.5
640
832
32
40
128
192
480
520
17
3
28
40
37.9
72.81
31.5
3
640
480
75
31.5
640
840
16
64
120
200
480
500
1
3
16
20
37.5
75
31.5
4
640
480
85
36
640
832
56
56
80
192
480
509
1
3
25
29
43.3
85.01
36
5
800
600
56
36
800
1024
24
72
128
224
600
625
1
2
22
25
35.1
56.25
+
+
36
6
800
600
60
40
800
1056
40
128
88
256
600
628
1
4
23
28
37.9
60.317
+
+
40
7
800
600
72
50
800
1040
56
120
64
240
600
666
37
6
23
66
48.1
72.19
+
+
50
8
800
600
75
49.5
800
1056
16
80
160
256
600
625
1
3
21
25
46.9
75
+
+
49.5
9
800
600
85
56.25
800
1048
32
64
152
248
600
631
1
3
27
31
53.7
85.06
+
+
56.25
Hz
MHz
Dots
Dots
Dots
Dots
Dots
Dots
Lines
Lines
Lines
Lines
Lines
Lines
KHz
Hz
TTL
TTL
MHz
17
SPECIFICATIONS
Mode No
H Resolution
V Resolution
Refresh Rate
Pixel
Horizontal visible
Horizontal total
Horizontal front porch
Horizontal sync
Horizontal back porch
Horiz blanking time
Vertical visible
Vertical total
Vertical front porch
Vertical sync
Vertical back porch
Vertical blanking time
Horizontal frequency
Vertical frequency
Vertical sync polarity
Horiz sync polarity
Dot rate
10
1024
768
60
65
1024
1344
24
136
160
320
768
806
3
6
29
38
48.4
60.01
65
11
1024
768
70
75
1024
1328
24
136
144
304
768
806
3
6
29
38
56.5
70.07
75
12
1024
768
75
78.75
1024
1312
16
96
176
288
768
800
1
3
28
32
60
75.03
+
+
78.75
13
1024
768
85
94.5
1024
1376
48
96
208
352
768
808
1
3
36
40
68.7
84.99
+
+
94.5
14
1280
1024
60
108
1280
1688
48
112
248
408
1024
1066
1
3
38
42
63.98
60.02
+
+
108
15
1280
1024
75
135
1280
1688
16
144
248
408
1024
1066
1
3
38
42
79.98
75.03
+
+
135
Mode No
H Resolution
V Resolution
Refresh Rate
Pixel
Horizontal visible
Horizontal total
Horizontal front porch
Horizontal sync
Horizontal back porch
Horiz blanking time
Vertical visible
Vertical total
Vertical front porch
Vertical sync
Vertical back porch
Vertical blanking time
Horizontal frequency
Vertical frequency
Vertical sync polarity
Horiz sync polarity
Dot rate
20
1280
720P
60
74.250
1266
1650
42
63
279
384
687
750
1
6
56
63
45.15
60
74.25
21
1920
1080i
60i
74.25
1901
2201
68
63
169
300
518
562.5
0.5
6
38
44.5
33.78
60
74.25
22
640
350
70
25.175
640
800
16
96
48
160
350
449
37
2
60
99
31.50
70
25.175
23
852
480
60
30
852
955
19
48
36
103
480
525
10
2
33
45
31.72
60.41
30
24
640
480
67
30.240
640
864
64
64
90
224
480
525
3
3
39
45
35.00
66.67
30.24
25
832
624
75
57.283
832
1152
32
64
224
320
624
667
1
3
39
43
49.73
74.55
57.283
18
16
1280
1024
85
157.5
1280
1728
64
160
224
448
1024
1072
1
3
44
48
91.15
85.02
+
+
157.5
26
1152
870
75
100.000
1152
1456
32
128
144
304
870
915
3
3
39
45
68.68
75.06
100.000
18
720
400
70
28.320
720
900
18
108
54
180
400
449
12
2
35
49
31.46
70.08
+
28.32
19
640
480
50
25.175
640
800
16
96
48
160
480
629
62
2
85
149
31.5
50
25.175
Hz
MHz
Dots
Dots
Dots
Dots
Dots
Dots
Lines
Lines
Lines
Lines
Lines
Lines
KHz
Hz
TTL
TTL
MHz
Hz
MHz
Dots
Dots
Dots
Dots
Dots
Dots
Lines
Lines
Lines
Lines
Lines
Lines
KHz
Hz
TTL
TTL
MHz
WALL MOUNT INSTALLATION (OPTIONAL)
Package Content
Left Wall Mounting
Angle Module
Right Wall Mounting
Angle Module
Screws for Fix Angle x 8
Screws for Wall
Mounting x 8
Horizontal Support
19
WALL MOUNT INSTALLATION (OPTIONAL)
Set up Steps
Step 1.
Set up Fix Angles to Left and Right Wall
Mounting Angle Module.
Step 2.
Install the Wall Mount Bracket onto the wall.
Note:
The screws in this package is for mounting
onto a cement wall. Different kind of walls
(like a wooden wall) need different type
screws. Please consult with authorized
dealers’ qualified installer.
You can adjust the mounting direction and
inclination angle (0, 5, 10, 15 degrees) by
adjusting the screws position on the Wall
Mounting Angle Module.
20
WALL MOUNT INSTALLATION (OPTIONAL)
Step 3.
Remove the pedestal table-top stand on the unit, install the unit onto the wall mount bracket.
Note:
Wall mount bracket is an optional accessory, please contact with authorized dealers for
purchasing.
This type of equipment is to be installed by the dealer’s qualified installer, please contact
with authouized dealer for installation.
The force for mounting wall should be 120 kg or above.
21
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
