HP ProLiant servers

HP ProLiant servers

HP ProLiant servers

Simple, affordable computing

Solution Guide

Entrusting your business to a server helps you protect important information and enhance the efficiency of key processes, while also laying a reliable foundation for growth in whatever direction – and at whatever pace – suits you.

Choosing an HP ProLiant server makes it simple and affordable. And this guide outlines why.

What this guide contains

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Why deploy your first server? . . . . . . . . . . . . . . . . . . . . 4

Why upgrade an existing server network? . . . . . . . . . . . 6

New technologies for advanced capabilities . . . . . . . . . . 8

Choosing a suitable server . . . . . . . . . . . . . . . . . . . . . 10

Scenario 1: First server network . . . . . . . . . . . . . . . . . . 12

Scenario 2: More advanced server network . . . . . . . . . 14

Making your IT easier to own . . . . . . . . . . . . . . . . . . . 16

HP ProLiant server portfolio overview . . . . . . . . . . . . . . 18

The reliable answer to business change

If there’s one constant in business, it’s change.

For companies that rely on paper-based processes, it might be as simple as a client switching to e-mail, meaning you can no longer invoice by fax. And even with some basic IT in place, you must protect and share information while ensuring you can flex on demand. Relying on PCs alone can lead to information being lost. A server offers a much more robust and flexible solution.

For companies with limited or no IT staff, identifying, deploying and managing the right server may seem a daunting and expensive challenge. In fact, you can purchase a server for as little as the cost of a sophisticated desktop. And the cost of deploying and maintaining it is lower than that of data loss or inefficient resource sharing.

How can this guide help?

HP ProLiant server solutions – part of the HP Smart Office Portfolio – combine smart advice, smart technology and smart services to help ensure simplicity and affordability from the start.

This guide can help, by focusing on the process and benefits of:

• Deploying a first server

• Upgrading and expanding an existing server network

• Selecting the appropriate model, options and services

Plus, you can always turn to a local HP partner for any further details.

3

Why deploy your first server?

Until now, you may have relied on interconnected PCs to share files, printers and resources, perhaps using one PC as a central storage resource. Although adequate for one to five users, this “peer-to-peer” setup can restrict growth, reduce access speeds, and make it difficult to protect information so it’s available when you need it.

A server-based network provides the same essential networking capabilities (e.g., data access, e-mail and applications for other computers), but adds a host of other essential capabilities too.

Superior reliability

To keep operations running, server components are engineered for reliability. E.g., data can be “mirrored” from one hard drive to another so that, if the primary drive fails, you can still access your data. This redundancy feature is available on components such as power supplies and cooling fans too.

Robust data protection

Whereas peer-to-peer setups can be highly susceptible to attack, servers provide a more robust foundation for data and business protection. You can easily install a firewall, anti-virus software, or connect simple backup-and-restore devices (e.g., tape drives).

Enhanced productivity

With the ability to access a centralised repository of applications and data at speeds typically two to three times quicker than on peer-to-peer networks, staff are instantly more efficient.

Reduced administration and cost

A server enables better control of hardware and data assets. Users can access information and applications without conflicts, and support partners can manage effectively with a single view of the network.

4

Why choose HP ProLiant servers?

For business protection

• World-class reliability, availability and security based on engineering excellence, intensive testing and industry-leading partnerships

• Wide selection of optional or standard redundant components

• Add optional HP StorageWorks tape drives with HP One-Button Disaster

Recovery for rapid data backup and restore

For outstanding value

• Broad range of affordable servers, configurations and options

• Flexible approach – select only what you need to help keep acquisition costs low

• HP experts help you make the best choices, boosting efficiencies and reducing costs over a lifetime of ownership

For hassle-free ownership

• Single point of contact for end-to-end coverage and unmatched expertise

• Microsoft Windows Server ™ on some models

2003 operating system available preloaded

• Range of HP Care Pack Services available for installation, startup and ongoing support from a local partner

• Comprehensive management via HP Systems Insight Manager software – support partners can monitor server health and fix potential failures before they affect operations

For a simple visual representation of a first server network, turn to page 14.

5

Why upgrade an existing server network?

If you already operate a small server network, there are a number of reasons to consider upgrading or expanding it with the capabilities of new or additional servers.

Increased performance and availability

Under pressure to keep services available and achieve more in less time?

Technologies to boost server availability and performance are constantly advancing. For instance, with HP you can easily upgrade or refresh existing servers without a huge acquisition cost.

Migrating from an outdated operating system

If you run either Microsoft ® Windows NT ® 4.0 or Windows ® 2000, you’re potentially at risk from, for example, new virus threats because Microsoft no longer supports these outdated systems. Migrating to the newer Microsoft

Windows Server ™ 2003, on up-to-date server hardware built to run it, ensures ongoing performance and security.

Coping with increased workloads

If your server is now running far more than the one or two applications you originally deployed it for, performance may be slow and unreliable. By spreading the load over two or more servers, you can dedicate mail and messaging, database, web hosting and more to only the departments that need them, for greater performance, reliability and cost efficiency.

For file and print, you may wish to deploy a storage server, with superior storage capacity and expansion possibilities. HP ProLiant storage servers even come with the optimised operating system, Windows Storage Server 2003, preinstalled.

6

Why choose HP ProLiant servers?

To capitalise on change

• Consistently first in delivering breakthrough technologies at affordable prices

• Comprehensive choice of servers, configurations, operating systems, processors, storage, software and more to help you expand in the right direction

• Consistency in components (e.g., hard drives, memory and network adaptors) means there’s no need to start over or re-train staff when you grow

To simplify network management

• HP Systems Insight Manager (HP SIM) provides single-console monitoring and management of your expanded IT infrastructure

• HP ProLiant Essentials software provides modular tools to expand server capabilities with rapid deployment, remote management and more

• Reliable, easy-to-own technologies integrate seamlessly with each other, and your existing HP and standards-based IT

To grow with confidence

• HP’s heritage of standards-based innovation helps lower costs and mitigate risk by delivering a better fit across products and solutions

• Get the right technology at the right price – and do business where and how you want – with HP or one of thousands of resellers and service partners

• Overcome any budget restrictions by acquiring your solution with flexible financing terms

To see how a more advanced network using several dedicated servers might look, turn to page 16.

7

New technologies for advanced capabilities and a lower cost of ownership

To protect current investments in HP technology, the following options are engineered for seamless integration with each other, and with previous-generation HP products, components and management software. They are also ideal for first-time server purchasers seeking advanced capabilities from day one.

Dual-core processors from AMD and Intel

®

HP offers a broad portfolio of ProLiant servers featuring dual-core processors from both AMD and Intel. The new HP ProLiant BL25p, BL30p and BL45p blade servers feature the latest AMD Opteron ™ 200 series dual-core processors to help eliminate system architecture challenges and bottlenecks, while the HP ProLiant ML110 G3

Server features Intel Pentium compact chassis.

® D dual-core processors for greater performance in a

Optimum storage performance

To meet your specific storage needs adequately and affordably, all HP platforms now support universal hard disk drives. A choice of traditional SCSI or next-generation

Serial Attached SCSI (SAS) drives available from HP means you can allocate storage according to the importance of the data you wish to store. This new serial interface augments performance and allows greater density by reducing drive size to small form factor.

So, when you need storage to support high workloads or mission-critical applications, choose SAS drives. Their benefits include:

• High performance (3-Gb/s transfer speeds)

• Superior reliability

• 50% lower power consumption (with 2.5-inch drives)

For data that you access less often, you can save unnecessary expense by using lowcost SATA drives instead. And, to optimise your storage, you can install a mix of both

SAS and SATA drives in the same enclosure*, for a future-proof infrastructure that also protects your existing storage investments.

* So long as the system is an inherent SAS system.

8

Ongoing data protection

As you change and grow your disk storage, it’s important to protect your business and its data assets. HP Smart Array controllers ensure the flexibility, reliability and manageability you need, enabling you to:

• Safely deploy large-capacity drives and create large storage volumes

• Establish cost-effective data protection

• Implement highest-level fault tolerance – e.g., through

RAID 6 or ADG (Advanced Data Guarding) technology

Compatibility between controllers makes them simple to upgrade and expand into larger, shared-storage environments. They support both SATA and SAS universal hard drives. And your technical support team or partner can easily optimise, troubleshoot and expand configurations using a single, consistent interface.

Increased network efficiency

HP continues to evolve traditional networking technologies to keep you working at the speeds you demand. With HP multifunction network adaptors, for example, you can run either cluster, storage (iSCSI) or network interconnection from the same device reducing TCO while increasing server performances with support of TOE

(TCP/IP Offload Engine) and RDMA (Remote Direct Memory Access) functionalities.

For even greater efficiency, you can manage and adapt network paths dynamically using the HP ProLiant Essentials Intelligent Networking Pack, increasing performance and availability without adding the cost of a complicated network hardware solution.

It also provides Virus Throttle technology to reduce virus threats before they spread to the entire network.

9

Choosing a suitable server

The following table provides a simplified guide to choosing the most appropriate server for your business needs and environment, based on the applications you need to use it for and the number of users it is intended to support. Detailed information, including recommended servers for database applications, is available from local HP channel partners.

HP ProLiant options

HP offers a complete portfolio of options built around ProLiant servers to help you adapt to continuously changing business needs, simply and affordably. These ensure best-in-class hardware, software and services integration, and enable you to meet your specific needs for performance, capacity, availability, manageability and infrastructure – thereby unleashing the full power of your HP ProLiant solution. Find out more at: www.hp.com/eur/hpoptions

Application

Pure file and print

Microsoft Windows Small

Business Server

Messaging

Web server

(SBS 2003) – can be preloaded on select server configurations

1 – 25 users

HP ProLiant ML110

Storage Server

HP ProLiant ML110 Server

HP ProLiant ML150 Server

HP ProLiant ML310 Server

25 – 75 users

HP ProLiant ML110

Storage Server

HP ProLiant ML350

Storage Server

HP ProLiant ML150 Server

HP ProLiant ML350 Server

75 – 400 users

HP ProLiant ML350

Storage Server

HP ProLiant ML370

Storage Server

N/A

(SBS solutions support up to 100 users approx.)

Linux ® Small Business Suite – can be preloaded on select server configurations

File and print + all-purpose on Linux

(Novell OES, Red Hat, SuSE)

File and print + all-purpose on

Microsoft

HP ProLiant ML150 Server or

HP ProLiant ML350 Server

HP ProLiant ML150 Server

HP ProLiant ML110 Server

HP ProLiant ML310 Server

HP ProLiant ML150 Server

HP ProLiant ML350 Server

HP ProLiant ML350 Server

HP ProLiant ML370 Server

Domain controller

(concurrent users)

2003

Security (IP nodes)

(concurrent users/min)

HP ProLiant ML150 Server

HP ProLiant ML350 Server

HP ProLiant ML110 Server

HP ProLiant ML150 Server

HP ProLiant ML110 Server

HP ProLiant ML150 Server

HP ProLiant ML150 Server

HP ProLiant ML350 Server

400 – 1000 users

HP ProLiant ML370

Storage Server

Things to consider

• Amount of memory will determine print-management speed.

• All ProLiant storage servers come pre-configured with Microsoft Windows Storage Server 2003.

HP ProLiant ML370 Server

• Install requires at least 768 MB of memory.

• Allocate up to 2.5 GB of disk space per user.

• SBS requires a Client Access License (CAL) for every user or shared device.

• Choice of SBS 2003 Standard and Premium editions available; both can be pre-installed on. selected ProLiant server models – find out more at www.hp.com/go/windowssbs

• At least 1 GB of memory, required by the multiple applications contained in SBS.

• Allocate 0.5– 2.5 GB for each user for data storage.

• HP offers the OS factory-installed or on CD.

• File and print is not CPU-intensive. Adding a second processor for this alone will have no significant impact, but is recommended for running additional applications.

• Amount of memory will determine print-management speed.

• Windows requires at least 256 MB of storage space; 512 MB is recommended.

• With an additional 512-MB memory, this file-and-print server can also be used as the domain controller.

• Having separate domain controllers in an SMB environment is highly unlikely; an existing system is often used as the domain controller. In the past, HP has recommended using a file and print server as the domain controller. The easiest approach is to add 512 MB of memory to any system that is going to be a domain controller.

HP ProLiant ML350 Server

HP ProLiant ML350 Server

HP ProLiant ML370 Server

• Disk I/O is important in e-mail performance.

• If running third-party anti-virus/anti-spam software on the same server, add a CPU and an additional 512 MB of memory for every 100 users.

• At least 1 GB of memory is required.

• HP provides pre-installed HP Firewall/VPN ProLiant Server models for rapid deployment.

• Web-server performance is determined by the type of content. Static content changes very little, and mostly affects the amount of storage required (it has minimum impact on CPU). Response times can be increased by the addition of more memory thanks to memory content coaching. Dynamic content consists of scripts, java code, etc – and can change often. It impacts all facets of the server, therefore requiring faster processors, more memory and faster disk drive speeds.

Need help choosing the right server? Contact your local HP representative or visit our server and storage

10

expertise centre at: www.hp.com/eur/ssec

11

Typical small business server solutions

The following are typical “before and after” scenarios showing how companies can deploy HP ProLiant servers to suit specific business needs, situations and environments.

First server network

HP Compaq dc7600

Business Desktop

HP T750

Uninterruptible

Power Supply

(UPS)

Recommended: integrated tape drive for backup and restore, e.g., HP StorageWorks DAT 72

USB Tape Drive:

• 72-GB capacity with data compression

• Instant backup, ready to use in under 60 seconds

HP ProLiant

Server ML310

ProCurve Switch 2600-PWR series models

Color LaserJet 4730

Multifunction Printer

Microsoft Windows Small Business Server 2003

• File/print

• Communication/collaboration

• Secure Internet/intranet

• Backup and restore

HP ProCurve Secure

Router 7000dl series

Internet

Power

LAN

12

This scenario shows a simple client/server network setup, in which several user

PCs access a central resource for data and applications, Internet connection, e-mail, printer sharing and more.

Before

A company that relies solely on interconnected PCs may experience the following limitations in its IT setup:

• Suitable only for 1– 5 users

• Insufficient security for important information and processes

• Poor reliability – especially when the central ‘server’ PC is used as a workstation too

• Limited performance and expansion possibilities

• Long print queues and regular printing errors

• Individual dial-up or inefficient Internet/e-mail systems

• Unsuitable for database applications

After

By moving to a client/server network built around an HP ProLiant server preloaded with Microsoft Windows Small Business Server 2003 (part of the Microsoft Windows

Server System family), the same company can introduce an infrastructure that:

• Provides faster access and processing for 5–100 users; more effective file, application and resource sharing; and greater expansion possibilities

• Works with any application – including shared database applications

• Offers secure remote access and firewall capabilities

(via the HP ProCurve Secure Router)

• Can be managed centrally (via HP Systems Insight Manager software)

• Ensures greater reliability through disk mirroring and component redundancy, plus extra resilience against power surges/failures with the HP T750 UPS (which can protect up to six separate devices)

• Protects the business thanks to easy-to-connect backup technologies (via the HP

StorageWorks DAT 72 USB Tape Drive)

• Gives the network more enhanced file-sharing capabilities (through applications such as Windows SharePoint Services)

13

London

More advanced server network

Main office

SAN

HP StorageWorks Modular

Smart Array 1000 (MSA1000)

• Incl. backup and restore (shared storage)

HP xw4300

Workstation

HP ProLiant DL380 Server

• Mail and messaging

• Application server

• Database

HP ProLiant

DL360 Server

• Security

• Web server

HP ProCurve Secure

Router 7000dl series

ProCurve Switch 2600-PWR series models

Home office

HP R1500

XR UPS

Remote office

Internet

VPN

HP ProCurve

Secure Router

7000dl series

14

HP ProLiant

ML150 Server

• Application server

HP ProLiant ML110

Storage Server

• File and Print

ProCurve Switch

2600-PWR series models

Color LaserJet 9500

Multifunction Printer

HP Compaq dc7600

Business Desktops

Teleworkers

HP UPS T750

This more advanced example shows how simple client/server networks can be expanded to support distributed business operations conducted across several locations. A tiered server environment provides secure communications and access to multiple servers dedicated to specific applications, as well as to a back-end database with shared storage.

Before

Companies already running a server network may witness the following characteristics in their network as the business grows:

• An older operating system (e.g., Windows NT or 2000) that has less functionality than the latest solutions from the Microsoft Windows Server System family, and is not as well supported

• Multiple applications running on a single server, hampering performance

After

By upgrading systems and spreading the application workload across multiple dedicated servers (running Microsoft Windows Server 2003 or Windows Storage

Server 2003), the company can create an expanded network infrastructure that supports:

• Up to 250 users simultaneously

• Increased performance from all applications on all servers

• The most up-to-date operating systems

• Dedicated local application servers at remote offices

• Access to main office servers and applications (via the HP ProCurve Secure Router)

• Secure access for home users via easy-to-configure Virtual Private Networks (VPNs) using the HP ProCurve Secure Router

15

Making your IT easier to own

HP Smart Care Pack Services

To help get and keep systems up and running, HP has combined our most-requested support services in packages tailored specifically for HP ProLiant servers, and delivered by certified experts from one of our 3,000 local partners.

HP Smart Care Pack Services helps you plan, use and protect your investments to your best advantage, accelerating startup of your server and increasing its utilisation, performance and availability without the need for in-house IT resources. We offer competitive, preset pricing with upfront payment that makes it easy to meet budget needs, plus a single point of contact that simplifies administration.

• Startup implementation services

To save time and avoid the hassle of performing integration, startup, implementation and education yourself, choose from options including a basic installation service, or installation with product startup.

• Reactive hardware support

High-quality remote and on-site support, with a choice of response times ranging from next-business-day to 13x5 or 24x7 same-business-day coverage, right up to our 6-hour call-to-repair commitment – whereby, in 6 hours or less, an HP-certified engineer will solve the problem remotely or on-site.

• Premium support (combination packages)

Working with your IT team, HP Services engineers deliver onsite hardware support and over-the-phone software support covering HP products and selected multivendor hardware and software. This service is available 13 hours per day, 5 days a week (via Support Plus service) or 24x7 (via Support Plus 24).

Find out more at: www.hp.com/hps/servers

16

The following table indicates the recommended (bold) and other available HP Care Pack Services for the

ProLiant server models identified in this guide.

ProLiant

ML110

Startup implementation services

Installation Installation

& startup

U4444E

1

Reactive hardware support

Next business day

U4433E

4-hour

13x5

U4434E

1

4-hour

24x7

U4435E

6-hour call-to-repair

U4436E

Premium support

(combination packages)

Support Plus Support

Plus 24

ProLiant

ML150

U8195E

1

U8184E

U8192E

1

U8193E U8194E

ProLiant

ML310

ProLiant

ML330

ProLiant

ML350

ProLiant

ML370

U4456E

U4473E

U4522E

U4538E

U4457E

1

U4474E

1

U4523E

1

U4539E

1

U4445E

U4462E

U4446E

U4463E

U4512E

U4528E

U4447E

1

U4464E

1

U4513E

1

U4529E

1

U4448E

U4465E

U4514E

U4530E

MS U4458E

2

U4459E,

U6306E,

U8328E

3

MS U4475E

2

U4476E,

U6307E,

U8329E

3

MS U4524E

2

U4525E,

U6308E,

U8330E

3

MS U4540E

2

U4541E,

U6311E,

U8333E

3

UB940E

1

UB941E

ProLiant

ML110

Storage

Server

ProLiant

ML350

Storage

Server

ProLiant

ML370

Storage

Server

U7986E

U7986E

U7986E

1

1

1

UC568E

UC570E

1

Recommended (support service for 3 years)

2

For Microsoft Windows systems

3

Part numbers listed are for Microsoft Windows, SuSE Linux and Red Hat Linux respectively

UB995E

1

UC549E

1

UC544E

UC550E

HP Care Pack Education Services

To help you make the most of your ProLiant server solution, HP Care Pack Education Services offers costeffective, targeted training to ease implementation, streamline technology migration and consolidation, and shorten the time to return on investment. You can ensure a more efficient and effective IT environment, and stay informed about new applications and technologies to strengthen your competitive edge.

Find out more at: http://education.hp.com

17

HP ProLiant server portfolio overview

The following pages outline the key features of the HP ProLiant server and storage server models identified in this guide – ideal for customers seeking their first server purchase or a simple, affordable upgrade to their existing network capabilities.

HP ProLiant servers – ML line

Processor Memory NIC Hard drive bays Redundancy

HP ProLiant

ML110 G3

Server

2 x 1.0" non-hot-plug

SCSI or

2 x non-hot-plug SATA

Optional SCSI or

SATA RAID controller

HP ProLiant

ML110 G2

Storage

Server

1 x Intel Pentium D 3.0

GHz (2x1-MB cache) or Intel Pentium 4 3.2

GHz (2-MB cache) or Intel Celeron ® 2.53

GHz (256-KB cache)

512 MB std.,

8 GB max.

1 x Pentium 4

3.2 GHz or

Celeron 2.8 GHz

(256-KB cache)

256 or 512 MB std.,

4 GB max.

Broadcom 5721

Gigabit Adapter

10/100/1000

Intel 82541PI

Gigabit Adapter

10/100/1000

Up to 4 SATA hard drives pre-installed

(depends on model)

Software or hardware

RAID (depending on model)

HP ProLiant

ML150 G2

Server

Up to 2 x Intel Xeon ™

DP 3.2 GHz

(2-MB cache)

512 MB std.,

8 GB max.

HP ProLiant

ML310 G3

Server

Broadcom 5721

Gigabit Adapter

10/100/1000

Up to 6 x 1.0" hot-plug or non-hot-plug SCSI or SATA (depends on model)

Optional SCSI or

SATA RAID controller

NC320i Gigabit

Adapter

10/100/1000

4x 1" hot-plug SCSI or

SAS/SATA

Optional hot-plug hard drives

HP ProLiant

ML350

G4 Server

1x Intel Pentium D

3.2 GHz

(2x1-MB cache) or

Intel Pentium 4

3.4 GHz

(2-MB cache)

Up to 2 x Xeon DP

3.4 GHz

(2-MB cache)

512 MB std,

8 GB max.

512 MB std.,

12 GB max.

NC7761 Gigabit

Adapter

10/100/1000

6 x hot-plug SCSI,

6 x hot-plug SATA/SAS

(on G4p models)

Optional hot-plug redundant power and system fan

HP ProLiant

ML350

G4 Storage

Server

HP ProLiant

ML370

G4 Server

1 x Xeon up to

3.2 GHz

(1-MB L2 cache)

512 MB or 1 GB std.,

8 GB max.

NC7761 Gigabit

Adapter

10/100/1000

Up to 2 x Xeon DP

3.6 GHz

(2-MB cache)

1 GB std., 16 GB max.

NC7781 Gigabit

Adapter

10/100/1000

2 x 1" hot-plug preinstalled for the OS, up to 4 x hot-plug pre-installed for the user data, choice of

SCSI or SATA models

Optional hot-plug redundant power and system fan, hardware

RAID 0,1, 1+0, 5

6+2 x hot-plug SCSI or

8 x hot-plug SATA/SAS

Zoned system cooling, hot-plug components and optional fully redundant fans (3+3)

HP ProLiant

ML370

G4 Storage

Server

1 x Xeon 3.4 GHz

(1-MB L2 cache); dual processors on

High Performance

Model (HPM)

1 GB std. (or 2 GB std.

on HPM), 4 GB max.

NC7781 Gigabit

Adapter

10/100/1000

2 x 1" hot-plug SCSI pre-installed for the

OS,up to 6 x hot-plug

SCSI pre-installed for the user data

Optional hot-plug hard drives, optional redundant 1+1 power supply and 3+3 fans

(standard on HPM), hardware RAID 0, 1,

1+0, 5, ADG

For further details and complete specifications, visit:

www.hp.com/go/proliant and www.hp.com/go/nas and www.hp.com/eur/hpoptions

Equivalent rack server

HP ProLiant

DL320 Server

Warranty Recommended services

• 4-hour, 13x5 Hardware Support

Recommended options

• UPS (e.g., HP T750)

• Gigabit Ethernet switch (e.g., HP NC150T)

• 1x4 USB/PS2 KVM Switch (desktop)

• Backup tape drive (e.g., HP StorageWorks

DAT 24 internal)

• The ML110 G2 Storage Server is an optimised configuration that requires no options

HP ProLiant DL100

Storage Server

HP ProLiant DL140

Server

• Support Plus (13x5 on-site hardware and software support)

• HP Installation Service

1-1-1; optional upgrade to 3-3-3

• HP Installation Service

HP ProLiant DL320

Server

HP ProLiant DL360

Server

HP ProLiant DL380

Storage Server

• 4-hour, 24x7 Hardware Support

• Installation & Startup Service

• Support Plus (13x5 on-site hardware and software support)

• HP Installation Service

• UPS (e.g., HP T750)

• 1x4 USB/PS2 KVM Switch (desktop)

• HP 1-GB UNREG PC3200 1 x 1-GB Memory ALL

• Backup tape drive (e.g., HP StorageWorks

DAT 40 internal)

• UPS (e.g., HP T750)

• Gigabit Ethernet switch (e.g., HP NC150T)

• KVM Switch (e.g., 1x4)

• Backup tape drive (e.g., HP StorageWorks

DAT 72 internal)

• UPS (e.g., HP T1000 XR)

• HP 1-GB memory upgrade

• 72-GB 15K Ultra320 SCSI 3.5-inch, 3-Gb/s SAS

3.5-inch LFF universal hot-pluggable or 250-GB

7.2K HP SATA

• Backup tape drive (e.g., HP StorageWorks

DAT 72 internal)

• For increased redundancy, consider a 2nd NIC and an additional power supply

3-3-3

HP ProLiant DL380

Server

HP ProLiant DL380

Storage Server

• 4-hour, 24x7 Hardware Support

• Installation & Startup Service

• Support Plus (13x5 on-site hardware and software support)

• HP Installation Service

• UPS (e.g., HP T1000 XR)

• 72-GB 10K 3Gb/s SAS 2.5-inch SFF universal hot-pluggable

• HP 2-GB memory upgrade

• Mid-range backup tape drive (e.g.,

HP StorageWorks Ultrium 215 internal)

• For increased redundancy, consider a 2nd NIC and an additional power supply

Get your ideal IT solution, simply and affordably

It’s quick and easy to acquire your complete IT solution with HP Smart Finance

Services. Our simple, affordable, pay-as-you-go leasing and financing

1

options span the entire lifecycle of your HP solution – including the hardware, software, services and any third-party components – to deliver the following benefits:

• Fiscal fitness

• Increased budget reach

• Protection from technology obsolescence

• Safe disposal of old IT assets

Find out more at: www.hp.com/uk/go/hpfinancialservices

1

All financial services are subject to HP Financial Services credit committee acceptance.

Need help choosing the right server?

Contact your local HP representative or visit our server and storage expertise centre at: www.hp.com/eur/ssec

© Copyright 2005 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services.

Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Intel, Pentium, Celeron and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft, Windows, Windows NT and Windows

Server are trademarks or registered trademarks of Microsoft Corporation in the United

States and/or other countries. Linux is a registered trademark of Linus Torvalds.

4AA0-1238EEE. October 2005

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
