SRP-X700P Digital Powered Mixer

SRP-X700P Digital Powered Mixer
SRP-X700P
Digital Powered Mixer
www.sonybiz.net/media
Digital Powered Mixer
SRP-X700P
The SRP-X700P Digital Powered Mixer has been designed for the type of
modern presentation system which is required to process material from a
wide range of sources whether they be microphones, video, audio, DVD
or PC graphics.
Features
The unit provides the functionality of up to seven traditional presentation
devices in a compact 3U and rack-mounting chassis:
• RGB switcher
• Video switcher
• Wireless tuner base unit
• Audio mixer
• Power amplifier
• Feedback reducer
• EQ
Improved system efficiency
The SRP-X700P is supplied with two PC applications: the SRP-X700P
‘Manager’ and the ‘User Control Panel’. The ‘Manager’ is a ‘set and
forget’ application – it allows the unit to be fully configured during
installation and provides a complete set of control GUIs. The User Control
Panel provides a simple control GUI for real-time presenter control.
Furthermore, the 20 internal scene memories, four of which can
be recalled from the front User Control Panel, allow an instant recall
of user-designated internal processing, thus minimising downtime
between operating modes.
Utilising digital processing and control technology, the SRP-X700P
combines an impressive set of features with high quality processing, while remaining user-friendly.
Six into one, multi-media switcher
The SRP-X700P has a ‘six into one’ switcher that allows a wide
range of audio, video and PC graphics material to be routed to
the presentation system. The SRP-X700P can handle the latest
presentation signal sources such as PC graphics, wireless/wired
microphones, DVD playback and surround sound audio.
• Six picture inputs: 3 RGB/Component, 3 Composite/S Video
• Six audio inputs: 4 stereo and 2 surround sound
• High resolution Component signal processing, including 480p
or 1080i
• High-performance switching, with a 150 MHz frequency response
for RGB signals (1280 x 1024 pixels, SXGA)
SRP-X700P Manager – Example Block Screen
2
Conference and Training Room Presentations
6-mono and 2-stereo channels audio mixing with
extensive processing to maximise sound quality
Integrated machine control and automation control
interfacing
The SRP-X700P can mix and process 6 mono (4 mic, 2 mic/line) and
2 stereo line inputs into 10 outputs (8 general purpose outputs and
a stereo record output). With comprehensive audio processing such
as EQ, dynamics, routing and delay, the quality of the audio signals can
be maximised and room acoustics can be corrected.
The SRP-X700P has extensive machine control capabilities with four
CRTL-S control ports (allowing a wired machine control interface to
Sony CD, MD and VTRs). Moreover, parallel and serial RS-232C
control ports provide extensive control from professional presentation
controllers.
• High quality audio A/D and D/A conversion (24-bit, 48 kHz sampling
frequency).
• RS-232C port allows for remote control of Sony projector and PDP
• USB, RS-232C and parallel input ports for remote control from
an external PC (or other control systems)
• Control-S ports on the unit allow for remote operation of Sony VTRs,
DVD players, CD players, MD recorders and projectors *1
• Parallel output port for remote control of devices such as video
screen (up/down), window curtains (open/close), projector
(up/down), lighting (on/off), etc *2
Advanced audio processing functions –
‘Feedback Reducer’ and ‘Automixer’
Two special audio processing tools are included to allow professional
quality audio processing to be set up at the touch of a button.
The ‘Feedback Reducer’ works by analysing and ‘nulling out’ potential
howl round frequencies. The ‘Automix’ function allows the
SRP-X700P to analyse, in real time, the incoming signals and make
adjustments to maintain the quality of the output.
Multiple operating modes with 10 outputs and
the on-board stereo power amplifier
A routing function allows the SRP-X700P to offer many different
operating modes to support surround sound matrix switching or ‘Zoned’
speaker configurations. In addition the on-board 150 W stereo
power amplifier can be switched between high and low
impedance modes.
*1 In case of control of projector with the Control-S port, it is unable to switch between RGB
and Component Video.
*2 Requires Interface Box between SRP-X700P and the devices.
Integrated wireless tuner unit slots
Up to two Sony WRU-806 wireless tuner units (option) can be
directly installed into the SRP-X700P, making it simple to integrate a high
quality Sony wireless microphone system into the presentation
system.
• Power rating 200 W + 200 W (4 Ω), 150 W + 150 W (8 Ω),
Max 150 W (70 V Line)
3
Dimensions
Front and rear view
350
300
Unit=mm
4
482
132
430
Block diagram
+48V
TRIM
A/D
WL 1,2
FR
LCF
3 BAND
PEQ
MIC 3,4
A/D
Line
FR
LCF
Muting
FR
LCF
A/D
3 BAND
PEQ
COMP
DELAY
Fader
2 BAND
PEQ
A/D
Signal
TRIM
D/A
Line OUT 1,2
D/A
Line OUT 3-8
D/A
REC OUT
+4/0/-5/-10
14 IN
Muting
Signal
4BAND
PEQ
10 OUT
Automatic
Line 3
Output
Meter
11BAND
PEQ
Fader
Muting Fader
TRIM
SP OUT 1,2
Level
Meter
Over
Gain
COMP
Signal
TRIM
MIC 5/Line 1
MIC 6/Line 2
SELECTOR
3 BAND
PEQ
POWER
AMP
Fader
Signal
TRIM
D/A
MODE
Muting
Clip
Protection
Muting
COMP
ANT a,b
+48V
70V Line
Over
Gain
Signal
MIC 1,2
Muting
DELAY
+4/0/-5/-10
Fader
Mixer
Muting
Fader
+4/0/-5/-10
Line 4 A
4A
Input
Select
Line 4 D,E
RL/RR/C/W
2 BAND
PEQ
A/D
RC-232C for
projector control
Remote
USB
RC-232C for external
system controller
RC-232C
Parallel Remote
Muting Fader
Line 4
Composite
Video IN
A
B
C
Composite
Video OUT
Line 4
S Video IN
A
B
C
S Video OUT
Line 4
Component
/RGB IN
LOCK
MAIN
Projector CTRL-S IN
CPU
Projector CTRL-S OUT
CTRL-S OUT 1,2,3,4
Component
/RGB IN
A
USB (front)
B
C
USB (back)
System example
Install
Mobile
PC
Desktop PC
Touch Panel
& Controller
Control Panel
Mobile PC
User Control Panel
IR Transmitter
Light
DVD Player
or
or
Screen
VTR
Windows Curtain
Document Camera
Digital Powered
Mixer SRP-X700P
Projector
CD Player
MD Recorder
Wireless Tuner
WRU-806
Microphone
Wireless Microphone
4
Antenna
AN-820A
Speaker
Legend:
RGB
Component Video
Composite Video
Audio
RC-232C Remote
Control-D (IR) Remote
Parallel Remote
USB
RF
Specifications
Speaker Outputs
Output
Connector
CH1
Impedance
Screw
type binding
terminal x 4
CH2
70V LINE
Rated Power
4 Ω-16 Ω
150 W (8 Ω) 200 W (4 Ω)
4 Ω-16 Ω
150 W (8 Ω) 200 W (4 Ω)
32 Ω-10 kΩ
Max 150 W
Audio Inputs/Outputs
Input
Connector
Circuit
Channel
Reference/Peak Level
Impedance
MIC/WL 1,
2 XLR-3-31type
Balanced
Mono
-60 to -45 dBu/-37 to -22 dBu
more than 2.2 kΩ
MIC 3, 4
XLR-3-31type
Balanced
Mono
-60 to -45 dBu/-37 to -22 dBu
more than 2.2 kΩ
MIC 5, 6
XLR-3-31type
Balanced
Mono
(LINE 1, 2)
-60 to -45 dBu/-37 to -22 dBu
more than 2.2 kΩ
-10 to +4 dBu/-+10 to +24 dBu
more than 10 kΩ
LINE 3
Phono x 2
Unbalanced
Stereo
-10 to 0 dBu/+10 dBu to +20 dBu more than 10 kΩ
LINE 4
Phono x 2
Unbalanced
Stereo
-10 to 0 dBu/+10 dBu to +20 dBu more than 10 kΩ
(A, B, C, F)
LINE 4 (D, E)
Phono x 6
Unbalanced
Stereo/Surround -10 to 0 dBu/+10 dBu to +20 dBu more than 10 kΩ
Output
Connector
Circuit
Channel
Reference/Peak Level
Load impedance
LINE 1, 2
XLR-3-32type
Balanced
Mono
+4 dBu/+24 dBu
more than 600 Ω
LINE
Phono x 1
Unbalanced
Mono
-5 dBu/+15 dBu
more than 10 kΩ
Phono x 1
Unbalanced
Mono
-5 dBu/+15 dBu
more than 10 kΩ
3, 4, 5, 6, 7, 8
REC 1, 2
Video/RGB Inputs/Outputs
Input
Connector
LINE 4 (A, B, C)
Signal Type
Phono x 1
Composite
4-pin Mini Din
S Video
LINE 4 (D, E, F)
D-sub 15-pin
Component/RGB
Output
Connector
Signal Type
R/R-Y G/Y B/B-Y SYNC/HD VD
BNC x 5
Component/RGB
S VIDEO
4-pin Mini Din
S Video
VIDEO
BNC x 1
Composite
* Can switch inputs of Sony applicable Projectors automatically by using RS-232C control function
when the switcher of SRP-X700P is operated.
Remote Control Terminal
RS-232C ports
Connector
Function
Projector Control
D-sub 9-pin x 1, male,
Input Selection, Power On/Standby
(RS-232C)
inch standard
(applicable Projectors/PDP: Sony VPL-FX50,
RS-232C
D-sub 9-pin x 1, male,
VPL-PX21/31/32, PFM-42B1)*1*2
Fully controlled Audio and Switch functions
inch standard
USB ports
Connector
Function
USB (Front/Rear)
Series B connector x 2
Fully controlled Audio and Switch functions
Parallel I/O ports
Connector
Function
Type
AV Selection(LINE 4), Power On/Off,
Make-Contact
Scene Recall, Volume, Volume Up/Down,
CMOS level, active low
Electrical Chacteristics
Composite Video/S Video
Colour system
NTSC/PAL/SECAM
Frequency response
50 Hz - 10 MHz
Level
1 Vp-p (75 Ω)
Component Video
Colour system
NTSC/PAL/SECAM
Frequency response
50 Hz - 150 MHz
Level
Y: 1 Vp-p (75 Ω)
R-Y: 0.7 Vp-p (75 Ω)
B-Y: 0.7 Vp-p (75 Ω)
RGB
Frequency response
50 Hz - 150 MHz
Resolution
1280 x 1024 pixels, 60 Hz (SXGA)
Level
G: 0.7 Vp-p (75 Ω)
B: 0.7 Vp-p (75 Ω)
R: 0.7 Vp-p (75 Ω)
SYNC/HD, VD
1-5 V (47 kΩ) sync positive/negative
Audio (analogue)
Frequency response
Line in - Line out: 20 Hz - 20 kHz
T.H.D
Line in - Line out: Less than 0.01 % (1 kHz)
S/N ratio
Line in - Line out: More than 104 dB (IHF A)
Crosstalk
Line in - Line out: Less than -90 dB (1 kHz)
Others
ANTENNA IN a-b
BNC x 2, DC 9 V OUT
Microphone power supply
DC 48 V, MIC1-6 Inputs
General
Power requirement
120/220/230 V AC, 50/60 Hz
Power consumption
150 W
Operating temperature
0 °C to +40 °C (+32 °F to +104 °F)
Storage temperature
-20 °C to +60 °C (-4 °F to +140 °F)
Dimensions
482 (W) x 132 (H) x 350 (D) mm, 3U
(19 x 5 1/4 x 13 7/8 inches)
Mass
Approx. 13 kg (28 lb 11 oz)
Supplied accessories
AC Power cord (1), Operating manual (1), IR
Transmitter (1), Foot (4), Control software disk (1)
* Requires Microsoft Windows 98SE/ME/ 2000/XP
Parallel IN (12-pin)
Muting, Remote control of connected
D-sub 25-pin x 1,
Parallel OUT (10-pin)
female, milli standard
products with Control-S
Output status of Pallalel Input Function
Optional accessories
WRU-806 UHF Synthesised Tuner Unit
AN-820A UHF Antenna
UWP-X Series Wireless Microphones
Open collector
(expect for status of Controlled products
with Control-S)
Control-S ports
Connector
Output 1-4
Mini Jack x 4
Function
Play, Stop, Pause, FF, REC, PREV, NEXT
(applicable AV Products: Sony VHS/8mmVTR/Betamax
VTR/DV/CD/CDR/MD equiped with Control-S terminal,
DVD by using supplied IR Transmitter)
Projector IN
Mini Jack x 1
Projector OUT
Mini Jack x 1
For the connection of Projector remote commander
Input Selection, Power On/Standby
(applicable Projectors: Sony’s VPL-PX15/10, PS10, CX11/10)*1
*1 When both RGB and Component Video are used, it is necessary to connect RS-232C port of
X700P to Projector/PDP. Because Control-S control function is unable to switch between RGB
and Component Video.
5
SERVICES FROM SONY
Recognising that every company and every challenge
is unique, we offer a complete and comprehensive
range of services all the way through consulting,
planning, financing, implementation, training,
servicing, maintenance and support. Choose exactly
what’s right for you, when and where you need it.
Sony Specialist Dealers receive extensive training on all our
products and services. They combine this with an in-depth
knowledge of the market, ensuring you get advice that meets your
needs before and after purchase. To find your nearest Sony
Specialist Dealer visit our "dealer locator" at:
Sony Professional Services: Tailor-made design, installation
and project management of audio-visual and IT (AV/IT)
systems using skills developed over 25 years of systems
integration.
www.sonybiz.net/dealer
Sony Financial Services: Innovative and flexible finance
solutions designed to meet budgetary and financial
requirements and constraints, enabling businesses
to always have the most current technology.
Sony Training Services: A range of off-the-shelf or
customised training services from basic operation
through to high-level technical maintenance.
Sony Prime Support Services: Fully integrated and
customised support for products and systems throughout
their operational life, combining proactive and reactive
technical services.
Not all services are available in all countries.
If you’d like to find out more about what we do,
who we do it for and how we do it, visit
www.sonybiz.net or contact your local Sony office.
© 2007 Sony Corporation. All rights reserved.
Sony is a registered trademark of the Sony corporation, Japan.
Design, features and specifications are subject to change without notice.
All non-metric weights and measures are approximate.
CA SRP-X700P/GB- / /2007
www.sonybiz.net/media
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
