User Guide
ML-254x Series
Mono Laser Printer
User’s Guide
imagine the possibilities
Thank you for purchasing a Samsung product.
copyright
© 2011 Samsung Electronics Co., Ltd. All rights reserved.
This user’s guide is provided for information purposes only. All information included herein is subject to change without notice.
Samsung Electronics is not responsible for any direct or indirect damages, arising from or related to use of this user’s guide.
•
•
•
•
•
Samsung and Samsung logo are trademarks of Samsung Electronics Co., Ltd.
PCL and PCL 6 are trademarks of Hewlett-Packard Company.
Microsoft, Internet Explorer, Windows, Windows Vista, Windows 7 and Windows 2008 Server R2 are either registered trademarks or trademarks of Microsoft
Corporation.
TrueType, LaserWriter and Macintosh are trademarks of Apple Computer, Inc.
All other brand or product names are trademarks of their respective companies or organizations.
Refer to the 'LICENSE.txt' file in the provided CD-ROM for the open source license information.
REV. 1.01
Copyright_ 2
safety information
These warnings and precautions are included to prevent injury to you and others, and to prevent any potential damage to
your machine. Be sure to read and understand all of these instructions before using the machine.
Use common sense for operating any electrical appliance and whenever using your machine. Also, follow all warnings and
instructions marked on the machine and in the accompanying literature. After reading this section, keep it in a safe place
for future reference.
Important safety symbols
This section explains the meanings of all icons and signs in the user's guide. These safety symbols are in order, according to the degree of danger.
Explanation of all icons and signs used in the user’s guide:
Warning
Hazards or unsafe practices that may result in severe personal injury or death.
Caution
Hazards or unsafe practices that may result in minor personal injury or property damage.
Do not attempt.
Do not disassemble.
Do not touch.
Unplug the power cord from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
Follow directions explicitly.
Operating environment
Warning
Do not use if the power cord is damaged or if the
electrical outlet is not grounded.
►This could result in electric shock or fire.
•
Do not place anything on top of the machine (water,
small metal or heavy objects, candles, lit cigarettes,
etc.).
►This could result in electric shock or fire.
Do not bend, or place heavy objects on the power
cord.
►Stepping on or allowing the power cord to be
crushed by a heavy object could result in electric shock
or fire.
Safety information_ 3
If the machine gets overheated, it releases smoke,
makes strange noises, or generates an odd odor,
immediately turn off the power switch and unplug
the machine.
• The user should be able to access the power outlet
in case of emergencies that might require the user to
pull the plug out.
►This could result in electric shock or fire.
Do not remove the plug by pulling on the cord; do
not handle the plug with wet hands.
►This could result in electric shock or fire.
Caution
During an electrical storm or for a period of
non-operation, remove the power plug from the
electrical outlet.
►This could result in electric shock or fire.
If the plug does not easily enter the electrical outlet, do not
attempt to force it in.
►Call an electrician to change the electrical outlet, or this
could result in electric shock.
Be careful, the paper output area is hot.
►Burns could occur.
Do not allow pets to chew on the AC power, telephone or
PC interface cords.
►This could result in electric shock or fire and/or injury to
your pet.
If the machine has been dropped, or if the cabinet
appears damaged, unplug the machine from all
interface connections and request assistance from
qualified service personnel.
►Otherwise, this could result in electric shock or
fire.
If the machine does not operate properly after these
instructions have been followed, unplug the machine from
all interface connections and request assistance from
qualified service personnel.
►Otherwise, this could result in electric shock or fire.
Operating method
Caution
Do not forcefully pull the paper out during printing.
►It can cause damage to the machine.
When printing large quantities, the bottom part of the paper
output area may get hot. Do not allow children to touch.
►Burns can occur.
Be careful not to put your hand between the
machine and paper tray.
►You may get injured.
When removing jammed paper, do not use tweezers or
sharp metal objects.
►It can damage the machine.
Do not block or push objects into the ventilation
opening.
►This could result in elevated component
temperatures which can cause damage or fire.
Do not allow too many papers to stack up in the paper
output tray.
►It can damage the machine.
Be care when replacing paper or removing jammed
paper.
►New paper has sharp edges and can cause
painful cuts.
This machine's power reception device is the power cord.
►To switch off the power supply, remove the power cord
from the electrical outlet.
Installation / Moving
Safety information_ 4
Warning
Do not place the machine in an area with dust, humidity, or water leaks.
►This could result in electric shock or fire.
Caution
Before moving the machine, turn the power off and
disconnect all cords.
Then lift the machine:
• If the machine weighs under 20 kg (44.09 lbs), lift with
1 person.
•
If the machine weighs 20 kg (44.09 lbs) - 40kg (88.18
lbs), lift with 2 people.
• If the machine weighs more than 40 kg (88.18 lbs), lift
with 4 or more people.
►The machine could fall, causing injury or machine
damage.
Use only No.26 AWGa or larger, telephone line cord, if
necessary.
►Otherwise, it can cause damage to the machine.
Do not place the machine on an unstable surface.
►The machine could fall, causing injury or machine
damage.
Do not put a cover over the machine or place it in an
airtight location, such as a closet.
►If the machine is not well-ventilated, this could result
in fire.
The machine should be connected to
the power level which is specified on the label.
►If you are unsure and want to check the power level
you are using, contact the electrical utility company.
Make sure you plug the power cord into a grounded
electrical outlet.
►Otherwise, this could result in electric shock or fire.
Do not overload wall outlets and extension cords.
►This can diminish performance, and could result in
electric shock or fire.
Use the power cord supplied with your machine for safe
operation. If you are using a cord which is longer than 2
meters (6 feet) with a 110 V machine, then the gauge
should be 16 AWG or larger.
►Otherwise, it can cause damage to the machine, and
could result in electric shock or fire.
a. AWG: American Wire Gauge
Maintenance / Checking
Caution
Unplug this product from the wall outlet before cleaning the
inside of the machine. Do not clean the machine with
benzene, paint thinner or alcohol; do not spray water
directly into the machine.
►This could result in electric shock or fire.
Safety information_ 5
•
Do not remove any covers or guards that are
fastened with screws.
• Fuser units should only be repaired by a certified
service technician. Repair by non-certified
technicians could result in fire or electric shock.
►The machine should only be repaired by a Samsung
service technician.
When you are working inside the machine replacing
supplies or cleaning the inside, do not operate the machine.
►You could get injured.
Keep cleaning supplies away from children.
►Children could get hurt.
Keep the power cable and the contact surface of the plug
clean from dust or water.
►Otherwise, this could result in electric shock or fire.
Do not disassemble, repair or rebuild the machine by
yourself.
►It can damage the machine. Call a certified
technician when the machine needs repairing.
To clean and operate the machine, strictly follow the user's
guide provided with the machine.
►Otherwise, you could damage the machine.
Supply usage
Caution
Do not disassemble the toner cartridge.
►Toner dust can be dangerous if inhaled or ingested.
When storing supplies such as toner cartridges, keep
them away from children.
►Toner dust can be dangerous if inhaled or ingested.
Do not burn any of the supplies such as toner cartridge or
fuser unit.
►This could cause an explosion or uncontrollable fire.
Using recycled supplies, such as toner, can cause
damage to the machine.
►In case of damage due to the use of recycled
supplies, a service fee will be charged.
When changing the toner cartridge or removing jammed
paper, be careful not to let toner dust touch your body or
clothes.
►Toner dust can be dangerous if inhaled or ingested.
When toner gets on your clothing, do not use hot water
to wash it.
►Hot water sets toner into fabric. Use cold water.
Safety information_ 6
regulatory information
This machine is designed for our sound environment and certified with several regulatory statements.
Laser Safety Statement
The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, chapter 1 Subchapter J for Class I(1) laser products, and
elsewhere is certified as a Class I laser product conforming to the requirements of IEC 60825-1 : 2007.
Class I laser products are not considered to be hazardous. The laser system and printer are designed so there is never any human access to
laser radiation above a Class I level during normal operation, user maintenance or prescribed service condition.
WARNING
Never operate or service the printer with the protective cover removed from Laser/Scanner assembly. The reflected beam, although invisible,
can damage your eyes.
When using this product, these basic safety precautions should always be followed to reduce risk of fire, electric shock, and injury to persons:
Ozone Safety
This product's ozone emission rate is under 0.1 ppm. Because ozone is heavier than air, keep the product in a place with good ventilation.
Power Saver
This printer contains advanced energy conservation technology that reduces power consumption when it is not in active use.
When the printer does not receive data for an extended period of time, power consumption is automatically lowered.
ENERGY STAR and the ENERGY STAR mark are registered U.S. marks.
For more information on the ENERGY STAR program see http://www.energystar.gov
For ENERGY STAR certified models, the ENERGY STAR label will be on your machine. Check if your machine is ENERGY STAR certified.
Regulatory information_ 7
Recycling
Recycle or dispose of the packaging material for this product in an environmentally responsible manner.
China only
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset,
USB cable) should not be disposed of with other household wastes at the end of its working life. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, separate this from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and
how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed
with other commercial wastes for disposal.
The United States of America only
Dispose unwanted electronics through an approved recycler. To find the nearest recycling location, go to our
website:www.samsung.com/recyclingdirect Or call, (877) 278 - 0799
Radio Frequency Emissions
FCC Information to the User
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or experienced radio TV technician for help.
Regulatory information_ 8
Change or modifications not expressly approved by the manufacturer responsible for compliance could void the user's authority to
operate the equipment.
Canadian Radio Interference Regulations
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference-causing
equipment standard entitled “Digital Apparatus”, ICES-003 of the Industry and Science Canada.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe B prescrites dans la
norme sur le matériel brouilleur: “Appareils Numériques”, ICES-003 édictée par l’Industrie et Sciences Canada.
Russia only
Turkey only
Germany only
Replacing the Fitted Plug (for UK Only)
Important
The mains lead for this machine is fitted with a standard (BS 1363) 13 amp plug and has a 13 amp fuse. When you change or examine the
fuse, you must re-fit the correct 13 amp fuse. You then need to replace the fuse cover. If you have lost the fuse cover, do not use the plug until
you have another fuse cover.
Contact the people from you purchased the machine.
The 13 amp plug is the most widely used type in the UK and should be suitable. However, some buildings (mainly old ones) do not have normal
13 amp plug sockets. You need to buy a suitable plug adaptor. Do not remove the moulded plug.
If you cut off the moulded plug, get rid of it straight away.
You cannot rewire the plug and you may receive an electric shock if you plug it into a socket.
Regulatory information_ 9
Important warning:
You must earth this machine.
The wires in the mains lead have the following color code:
• Green and Yellow: Earth
• Blue: Neutral
• Brown: Live
If the wires in the mains lead do not match the colors marked in your plug, do the following:
You must connect the green and yellow wire to the pin marked by the letter “E” or by the safety ‘Earth symbol’ or colored green and yellow or
green.
You must connect the blue wire to the pin which is marked with the letter “N” or colored black.
You must connect the brown wire to the pin which is marked with the letter “L” or colored red.
You must have a 13 amp fuse in the plug, adaptor, or at the distribution board.
Declaration of Conformity (European Countries)
Approvals and Certifications
Hereby, Samsung Electronics, declares that this [ML-254x Series] is in compliance with the essential requirements and other relevant
provisions of Low Voltage Directive (2006/95/EC), EMC Directive (2004/108/EC).
The declaration of conformity may be consulted at www.samsung.com/printer, go to Support > Download center and enter your printer
(MFP) name to browse the EuDoC.
January 1, 1995: Council Directive 2006/95/EC Approximation of the laws of the member states related to low voltage equipment.
January 1, 1996: Council Directive 2004/108/EC (92/31/EEC), approximation of the laws of the Member States related to electromagnetic
compatibility.
March 9, 1999: Council Directive 1999/5/EC on radio equipment and telecommunications terminal equipment and the mutual recognition of
their conformity. A full declaration, defining the relevant Directives and referenced standards can be obtained from your Samsung Electronics
Co., Ltd. representative.
EC Certification
Certification to 1999/5/EC Radio Equipment & Telecommunications Terminal Equipment Directive (FAX)
This Samsung product has been self-certified by Samsung for pan-European single terminal connection to the analogue public switched
telephone network (PSTN) in accordance with Directive 1999/5/EC. The product has been designed to work with the national PSTNs and
compatible PBXs of the European countries:
In the event of problems, you should contact the Euro QA Lab of Samsung Electronics Co., Ltd. in the first instance.
The product has been tested against TBR21. To assist in the use and application of terminal equipment which complies with this standard, the
European Telecommunication Standards Institute (ETSI) has issued an advisory document (EG 201 121) which contains notes and additional
requirements to ensure network compatibility of TBR21 terminals. The product has been designed against, and is fully compliant with, all of the
relevant advisory notes contained in this document.
Regulatory information_ 10
China only
Regulatory information_ 11
about this user’s guide
This user’s guide provides information about basic understanding of the machine as well as detailed explanation on each
step during actual usage. It is a valuable resource for both novice and professional users for the proper installation and
use of the machine.
•
•
•
•
•
•
•
Read the safety information before using the machine.
If you have a problem using the machine, refer to the troubleshooting chapter. (See "Troubleshooting" on page 44.)
Terms used in this user’s guide are explained in the glossary chapter. (See "Glossary" on page 61.)
All illustrations in this user’s guide may differ from your machine depending on its options or model you purchased.
The screenshots in this user's guide may differ from your machine depending on the machine’s firmware/driver version
The procedures in this user’s guide are mainly based on Windows 7.
Use Index to find information.
Convention
Some terms in this guide are used interchangeably, as below:
• Document is synonymous with original.
• Paper is synonymous with media, or print media.
• Machine refers to printer or MFP.
The following table offers the conventions of this guide:
Convention
Description
Example
Bold
For texts on the display or button names on the machine.
Note
Provides additional information or details for the machine function and feature.
The date format may differ from country
to country.
Caution
Contains information you can use to protect the machine from possible
mechanical damage or malfunction.
Do not touch the surface of the drum
located in the toner cartridge or imaging
unit.
Footnote
Provides additional information on certain words or a phrases.
a. pages per minute
(“Cross-reference”)
Refers you to additional detailed information.
(See "Finding more information" on
page 13.)
About this user’s guide_ 12
Cancel
Finding more information
You can find information about setting up and using your machine in the following resources, either as a print-out or on screen.
Material name
Description
Quick Installation
Guide
This guide provides information on setting up your machine. This guide is provided in the box with the printer.
User’s Guide
This guide provides you with step-by-step instructions for using your machine’s full features, maintaining your machine,
troubleshooting, and replacing supplies.
Printer Driver Help
This help provides you with information about the printer driver and instructions for setting up the options for printing. (See "Using help"
on page 32.)
Samsung website
If you have Internet access, you can get help, support, machine drivers, manuals, and order information from the Samsung website,
www.samsung.com/printer.
Downloadable
software
You can download useful software programs from the Samsung website.
• Samsung AnyWeb Print: helps personal users to screen-capture the website screen in Windows and Mocintosh (Internet
Explorer, Firefox and Safari). (http://solution.samsungprinter.com/personal/anywebprint)
About this user’s guide_ 13
features of your new product
Your new machine is equipped with a number of special features that improve the quality of the documents you print.
Special Features
Print with excellent quality and speed
•
•
You can print with a resolution of up to 1,200 x 1,200 dpi
effective output.
Your machine prints A4-sized paper at up to 24 ppm and
letter-sized paper at up to 24 ppm.
Handle many different types of printable material
•
•
Manual tray supports plain paper in various sizes, letterhead,
envelopes, labels, custom-sized media, postcards, and
heavy paper.
The 250-sheet tray supports plain paper.
Create professional documents
•
•
•
Print Watermarks. You can customize your documents with
words, such as “Confidential”. (See "Using watermarks" on
page 34.)
Print Posters. The text and pictures of each page of your
document are magnified and printed across the sheet of
paper and can then be taped together to form a poster. (See
"Printing posters" on page 33.)
You can use preprinted forms and letterhead with plain
paper. (See "Using overlay" on page 34.)
Save time and money
•
•
•
To save paper, you can print multiple pages on one single
sheet of paper. (See "Printing multiple pages on one sheet of
paper" on page 32.)
This machine automatically conserves electricity by
substantially reducing power consumption when not in use.
To save paper, you can print on both sides of the paper
(Manual). (See "Printing on both sides of paper (Manual)" on
page 33.)
Print in various environments
•
•
You can print with Windows as well as Linux and Macintosh
OS systems.
Your machine is equipped with a USB interface.
Features of your new product_ 14
Features by Model
Features by model include:
FEATURES
ML-254x Series
Hi-Speed USB 2.0
●
Duplex (2-sided) printing (Manual)
●
Print screen
●
( ●: Included)
Features of your new product_ 15
introduction
1.
This chapter gives you an overview of your machine:
•
•
•
•
Machine overview
Control panel overview
Understanding the LED
Turning on the machine
Machine overview
Front view
This illustration may differ from your machine depending on its model.
1
Document output tray
6
Front cover
2
Control panel
7
Manual feeder guide
3
Front cover handle
8
Output support
4
Tray 1
9
Toner cartridge
5
Manual feeder
Introduction_ 16
Rear view
This illustration may differ from your machine depending on its model.
1
Rear cover
2
USB port
3
Power receptacle
Introduction_ 17
Control panel overview
This control panel may differ from your machine depending on its model.
3
1
Toner LED
Shows the status of the toner. (See "Understanding the LED" on page 19.)
2
Status LED
Shows the status of your machine. (See "Understanding the LED" on page 19.)
Print Screen
Press this button and the green LED will start blinking. If you want to print only the active screen, release the button when
the green LED stops blinking. If you want to print the whole screen, release the button while it’s blinking.
•
•
•
3
•
Print Screen can only be used in the Windows and Macintosh operating systems.
You can only use this function with USB-connected machine.
When printing the active window/whole monitor screen using the print screen button, the machine may use more
toner depending on what is being printed.
You can only use this function if the machine’s Easy Printer Manager program or Smart Panel program is
installed.
Cancel
Stops an operation at any time and there are more functions.
• Cancels the current job.
• Prints configuration report: Press and hold this button for about 2 to 5 seconds until the status LED blinks, and
release.
Power
You can turn the power on and off with this button.
4
5
Introduction_ 18
Understanding the LED
Turning on the machine
The color of the LEDs indicates the machine's current status.
1. Plug in the power cord.
2. Press
LED
Status
Orange
Description
Blinking •
Small amount of toner is left in the
cartridge. The estimated cartridge lifea
of toner is close. Prepare a new
cartridge for replacement. You may
temporarily increase the printing
quality by redistributing the toner. (See
"Redistributing toner" on page 44.)
On
•
A toner cartridge has almost reached
its estimated cartridge lifea. It is
recommended to replace the toner
cartridge. (See "Replacing the toner
cartridge" on page 53.)
Off
•
All Toner cartridges is at normal
capacity.
•
The machine is off-line.
(Toner
LED)
Off
(Status
LED)
Green
Blinking •
•
On
Red
•
The machine is on-line and can be
used.
Blinking •
A minor error has occurred and the
machine is waiting for the error to be
cleared. When the problem is cleared,
the machine resumes.
On
The cover is opened. Close the cover.
There is no paper in the tray. Load
paper in the tray. (See"Loading paper
in the tray" on page 27.)
The machine has stopped due to a
major error.
•
•
•
Orange
When the LED slowly bilnks, the
machine is receiving data from the
computer.
When the LED rapidly blinks, the
machine is printing data.
On
•
A paper jam has occurred.
(See "Clearing paper jams" on
page 45.)
a. Estimated cartridge life means the expected or estimated toner cartridge
life, which indicates the average capacity of print-outs and is designed
pursuant to ISO/IEC 19752. The number of pages may be affected by
operating environment, printing interval, graphics, media type and media
size. Some amount of toner may remain in the cartridge even when red
LED is on and the printer stops printing.
Samsung does not recommend using non-genuine Samsung toner
cartridge such as refilled or remanufactured. Samsung cannot
guarantee non-genuine Samsung toner cartridge's quality. Service or
repair required as a result of using non-genuine Samsung toner
cartridges will not be covered under the machine warranty.
You also can resolve the error with the guideline from the computers’s
Samsung Printer Status or Smart Panel program window. If the
problem persists, call for service.
Introduction_ 19
(power button) on the control panel.
getting started
2.
This chapter gives you step-by-step instructions for setting up the USB connected machine and software.
This chapter includes:
•
•
•
Setting up the hardware
Supplied software
System requirements
Setting up the hardware
This section shows the steps to set up the hardware, as is explained in the
Quick Installation Guide. Make sure you read the Quick Installation Guide
first and follow the steps below:
•
•
Installing USB connected machine’s driver
Sharing your machine locally
3.
4.
5.
6.
7.
Remove tape holding the machine securely.
Install the toner cartridge.
Load paper. (See "Loading paper in the tray" on page 27.)
Make sure that all cables are connected to the machine.
Turn the machine on. (See "Turning on the machine" on page 19.)
This machine will not operate when the power main fails.
Location
1. Select a stable location.
Select a level, stable place with adequate space for air circulation. Allow
extra space to open covers and trays.
The area should be well ventilated and away from direct sunlight or
sources of heat, cold, and humidity. Do not set the machine close to the
edge of your desk or table.
Supplied software
After you have set up your machine and connected it to your computer, you
must install the printer software. If you are a Windows or Macintosh OS
user, install the software from the supplied CD and if you are a Linux OS
user, download the software from the Samsung website
(www.samsung.com/printer) and install.
Machine software is occasionally updated for reasons like the release
of new operating system and etc. If needed, download the latest
version from the Samsung website (www.samsung.com/printer).
OS
Windows
Contents
•
•
•
Printing is suitable for altitudes under 1,000 m (3,281 ft). Refer to the
altitude setting to optimize your printing. (See "Altitude adjustment" on
page 25.)
Place the machine on a flat, stable surface so that there is no incline
greater than 2 mm (0.08 inch). Otherwise, printing quality may be
affected.
Macintosh •
•
Linux
•
•
•
2. Unpack the machine and check all the enclosed items.
Getting started_ 20
Printer driver: Use this driver to take full advantage of
your machine’s features.
Samsung Easy Printer Manager: Samsung Easy
Printer Manager combines device settings as well as
printing environments, settings/actions and launching. All
of these features provide a gateway to conveniently use
your Samsung machine.
Samsung Printing Status: This program allows you to
monitor the machine’s status and alerts you when an
error occurs during printing.
Printer Driver: Use this driver to take full advantage of
your machine’s features.
Samsung Easy Printer Manager: Samsung Easy
Printer Manager combines device settings as well as
printing environments, settings/actions and launching. All
of these features provide a gateway to conveniently use
your Samsung machine.
Unified Linux Driver: Use this driver to take full
advantage of your machine’s features.
Smart Panel: This program allows you to monitor the
machine’s status and alerts you when an error occurs
during printing.
Printer Settings Utility: This program allows you to set
up printer’s other options from your computer desktop.
System requirements
Macintosh
Before you begin, ensure that your system meets the following
requirements:
Microsoft® Windows®
Your machine supports the following Windows operating systems.
Mac OS X
10.4
Requirement (recommended)
Operating
system
CPU
RAM
Requirements (Recommended)
Operating
system
CPU
•
•
Intel® processors
PowerPC G4/ G5
RAM
128 MB for a
powerPC based
Mac (512 MB)
512 MB for an
Intel-based Mac
(1 GB)
•
•
free HDD
space
Free HDD
space
1 GB
Windows®
2000
Intel® Pentium® II
400 MHz (Pentium
III 933 MHz)
64 MB (128 MB)
600 MB
Mac OS X
10.5
•
•
Intel® processors
867 MHz or faster
Power PC G4/ G5
512 MB (1 GB)
1 GB
Windows®
XP
Intel® Pentium® III
933 MHz (Pentium
IV 1 GHz)
128 MB (256 MB)
1.5 GB
Mac OS X
10.6
•
Intel® processors
1 GB (2 GB)
1 GB
Windows
Server®
2003
Intel® Pentium® III
933 MHz (Pentium
IV 1 GHz)
128 MB (512 MB)
1.25 GB to
2 GB
Windows
Server®
2008
Intel® Pentium® IV
1 GHz (Pentium IV
2 GHz)
512 MB (2 GB)
10 GB
Windows
Vista®
Intel® Pentium® IV
3 GHz
512 MB (1 GB)
15 GB
Windows® 7
Intel® Pentium® IV
1 GHz 32-bit or
64-bit processor or
higher
1 GB (2 GB)
16 GB
•
•
Windows
Server®
2008 R2
•
•
•
•
Item
Support for DirectX® 9 graphics with 128 MB memory
(to enable the Aero theme).
DVD-R/W Drive
Intel® Pentium® IV
1 GHz (x86) or 1.4
GHz (x64)
processors (2 GHz
or faster)
Linux
512 MB (2 GB)
10 GB
Requirements
Operating
system
Fedora 5~13 (32/ 64 bit)
SuSE Linux 10.1 (32 bit)
OpenSuSE® 10.2, 10.3, 11.0, 11.1, 11.2 (32/64 bit)
Ubuntu 6.06, 6.10, 7.04, 7.10, 8.04, 8.10, 9.04, 9.10,
10.04 (32/64 bit)
Mandriva 2007, 2008, 2009, 2009.1, 2010 (32/64 bit)
Debian 4.0, 5.0 (32/64 bit)
Redhat® Enterprise Linux WS 4, 5 (32/64 bit)
SuSE Linux Enterprise Desktop 10, 11 (32/64 bit)
CPU
Pentium IV 2.4 GHz (IntelCore2)
RAM
512 MB (1024 MB)
Free HDD space
1 GB (2 GB)
Installing USB connected machine’s driver
A locally connected machine is a machine directly attached to your
computer using the USB cable.
Internet Explorer 6.0 or higher is the minimum requirement for all
Windows operating systems.
Users who have an administrator right can install the software.
Windows Terminal Services is compatible with this machine.
For Windows 2000, Services Pack 4 or higher is required.
Only use an USB cable no longer then 3 m (118 in.).
Windows
You can install the machine software using the typical or custom method.
The following steps below are recommended for most users who use a
machine directly connected to your computer. All components necessary for
machine operations will be installed.
1. Make sure that the machine is connected to the computer and powered
on.
If the “Found New Hardware Wizard” window appears during the
installation procedure, click Cancel in close the window.
2. Insert the supplied software CD into your CD-ROM drive.
• The software CD should automatically run and an installation window
appear.
• If the installation window does not appear, click Start and then Run.
Getting started_ 21
Type X:\Setup.exe, replacing “X” with the letter which represents
your drive. Click OK.
• If you use Windows Vista, Windows 7 and Windows 2008 Server R2
click Start > All programs > Accessories > Run.
Type X:\Setup.exe replacing “X” with the letter which represents
your drive and click OK.
• If the AutoPlay window appears in Windows Vista, Windows 7 and
Windows 2008 Server R2, click Run Setup.exe in Install or run
program field, and click Continue or Yes in the User Account
Control windows.
3. Select Install Now.
10. Click Install. All components necessary for machine operations will be
installed.
If you click Customize, you can choose individual components to install.
11. Enter the password and click OK.
12. Installing software requires you to restart your computer. Click Continue
Installation.
13. After the installation is finished, click Restart.
14. Open the Applications folder > Utilities > Print Setup Utility.
• For Mac OS X 10.5 -10.6, open the Applications folder > System
Preferences and click Print & Fax.
15. Click Add on the Printer List.
• For Mac OS X 10.5 -10.6, click the “+” folder icon; a display window
will pop up.
16. Click Default Browser and find the USB connection.
• For Mac OS X 10.5-10.6, click Default and find the USB connection.
17. For Mac OS X 10.4, if Auto Select does not work properly, select
Samsung in Print Using and your machine name in Model.
• For Mac OS X 10.5-10.6, if Auto Select does not work properly,
select Select a driver to use... and your machine name in Print
Using.
Your machine appears on the Printer List, and is set as the default
machine.
18. Click Add.
•
4. Read License Agreement, and select I accept the terms of the
License Agreement. Then, click Next.
5. Follow the instructions in the installation window.
If the printer driver does not work properly, follow the steps below to
reinstall the driver.
a) Make sure that the machine is connected to your computer and
powered on.
b) From the Start menu, select Programs or All Programs >
Samsung Printers > your printer driver name > Uninstall.
c) Follow the instructions in the installation window.
d) Insert the software CD into your CD-ROM drive and install the
driver again. (See "Installing USB connected machine’s driver" on
page 21.)
Macintosh
1. Make sure that the machine is connected to your computer and powered
on.
2. Insert the supplied software CD into your CD-ROM drive.
3. Double-click the CD-ROM icon that appears on your Macintosh desktop.
4. Double-click the MAC_Installer folder > Installer OS X icon.
5. Click Continue.
6. Read the license agreement and click Continue.
7. Click Agree to agree to the license agreement.
8. When the message that warns that all applications will close on your
computer appears, click Continue.
9. Click Continue on the User Options Pane.
•
If the printer driver does not work properly, uninstall the driver and
reinstall it.
a) Make sure that the machine is connected to your computer and
powered on.
b) Insert the supplied software CD into your CD-ROM drive.
c) Double-click the CD-ROM icon that appears on your Macintosh
desktop.
d) Double-click the MAC_Installer folder > Uninstaller OS X
icon.
e) Enter the password and click OK.
f) When the uninstall is done, click OK.
If a machine has already been added, delete it from the Print
Setup Utility or Print & Fax.
Linux
You need to download Linux software packages from the Samsung website
to install the printer software (http://www.samsung.com/printer).
Installing the Unified Linux Driver
1. Make sure that the machine is connected to your computer and
powered on.
2. When the Administrator Login window appears, type “root” in the
Login field and enter the system password.
You must log in as a super user (root) to install the machine
software. If you are not a super user, ask your system
administrator.
3. From the Samsung website, download the Unified Linux Driver
package to your computer.
4. Right-click the Unified Linux Driver package and extract the
package.
5. Double click cdroot > autorun.
6. When the welcome screen appears, click Next.
7. When the installation is complete, click Finish.
Getting started_ 22
The installation program added the Unified Driver Configurator desktop
icon and the Unified Driver group to the system menu for your
convenience. If you have any difficulties, consult the on-screen help that
is available through your system menu or from the driver package
Windows applications, such as Unified Driver Configurator or Image
Manager.
If the Host computer is directly connected to the machine with USB cable
and is also connected to the local network environment, the client computer
connected to the local network can use the shared machine through the
host computer to print.
1
2
Installing the SmartPanel
1. Make sure that the machine is connected to your computer and
powered on.
2. When the Administrator Login window appears, type in root in the
Login field and enter the system password.
You must log in as a super user (root) to install the machine
software. If you are not a super user, ask your system
administrator.
3. From the Samsung website, download the Smart Panel package to
your computer.
4. Right-click the Smart Panel package and extract the package.
5. Double click cdroot > Linux > smartpanel > install.sh.
1
2
Host computer
A computer which is directly connected to
the machine by USB cable.
Client computers
Computers which use the machine shared
through the host computer.
Windows
Setting up a host computer
Installing the Printer Settings Utility
1. Make sure that the machine is connected to your computer and
powered on.
2. When the Administrator Login window appears, type “root” in the
Login field and enter the system password.
You must log in as a super user (root) to install the machine
software. If you are not a super user, ask your system
administrator.
3. From the Samsung website, download the Printer Settings Utility
package to your computer.
4. Right-click the Printer Settings Utility package and extract the
package.
5. Double click cdroot > Linux > psu > install.sh.
If the printer driver does not work properly, uninstall the driver and
reinstall it.
a) Make sure that the machine is connected to your computer and
powered on.
b) When the Administrator Login window appears, type “root” in
the Login field and enter the system password.
You must log in as a super user (root) to uninstall the printer
driver. If you are not a super user, ask your system
administrator.
c) Click the icon at the bottom of the desktop. When the Terminal
screen appears, type in the following.
[[email protected] root]#cd /opt/Samsung/mfp/uninstall/
[[email protected] uninstall]#./uninstall.sh
d) Click Uninstall.
e) Click Next.
f) Click Finish.
1. Install your printer driver. (See "Installing USB connected machine’s
driver" on page 21.)
2. Click the Windows Start menu.
3. For Windows 2000, select Settings > Printers.
• For Windows XP/2003, select Printers and Faxes.
• For Windows 2008/Vista, select Control Panel > Hardware and
Sound > Printers.
• For Windows 7, select Control Panel > Hardware and Sound >
Devices and Printers.
• For Windows Server 2008 R2, select Control Panel > Hardware
> Devices and Printers.
4. Right click your printer icon.
5. For Windows XP/2003/2008/Vista, press Properties.
For Windows 7 and Windows Server 2008 R2, from context menus,
select the Printer properties.
If Printer properties item has ► mark, you can select other
printer drivers connected with selected printer.
6.
7.
8.
9.
Select the Sharing tab.
Check the Change Sharing Options.
Check the Share this printer.
Fill in the Share Name field. Click OK.
Setting up a client computer
1. Install your printer driver. (See "Installing USB connected machine’s
driver" on page 21.)
2. Click the Windows Start menu.
3. Select All programs > Accessories > Windows Explorer.
4. Enter the IP address of the host computer in the address bar and
press Enter in your keyboard.
Sharing your machine locally
Follow the steps below to set up the computers to share your machine
locally.
In case host computer requires User name and Password, fill
in User ID and password of the host computer account.
5. Right click the printer icon you want to share and select Connect.
6. If a set up complete message appears, click OK.
Getting started_ 23
7. Open the file you want to print and start printing.
Macintosh
The following steps are for Mac OS X 10.5~10.6. Refer to Mac Help
for other OS versions.
Setting up a host computer
1. Install your printer driver. (See "Macintosh" on page 22.)
2. Open the Applications folder > System Preferences and click
Print & Fax.
3. Select the printer to share in the Printers list.
4. Select Share this printer.
Setting up a client computer
1. Install your printer driver. (See "Macintosh" on page 22.)
2. Open the Applications folder > System Preferences and click
Print & Fax.
3. Click the “+” icon.
A display window showing the name of your shared printer appears.
4. Select your machine and click Add.
Getting started_ 24
basic setup
3.
After installation is complete, you may want to set the machine’s default settings. Refer to the next section if you would like
to set or change values. This chapter gives you step-by-step instructions for setting up the machine.
This chapter includes:
•
Altitude adjustment
•
Altitude adjustment
7. Press OK.
Print quality is affected by atmospheric pressure, which is determined by the
height of the machine above sea level. The following information will guide
you on how to set your machine for the best print quality.
Before you set the altitude value, determine the altitude where you are.
0
•
•
Setting the default tray and paper
1
2
3
4
High 3
High 2
High 1
Normal
If you want to use special-sized paper-such as a billing paper,
select Edit... in the Paper tab in the Printing Preferences. (See
"Opening printing preferences" on page 32.)
Macintosh
Macintosh does not support this function. Macintosh users need to
change the default setting manually each time they want to print using
other settings.
1. Open a Macintosh application and select the file you want to print.
2. Open the File menu and click Print.
3. Go to Paper Feed pane.
4. Set appropriate tray from which you want to print.
5. Go to Paper pane.
6. Set paper type to correspond to the paper loaded in the tray from
which you want to print.
7. Click Print to print.
For Windows and Macintosh: See "Device Settings" on page 39.
For Linux: See "Using Smart Panel" on page 39.
Setting the default tray and paper
You can select the tray and paper you would like to keep using for printing
job.
From your computer
Windows
1. Click the Windows Start menu.
2. For Windows 2000, select Settings > Printers.
• For Windows XP/2003, select Printer and Faxes.
• For Windows 2008/Vista, select Control Panel > Hardware and
Sound > Printers.
• For Windows 7, select Control Panel > Hardware and Sound >
Devices and Printers.
• For Windows Server 2008 R2, select Control Panel > Hardware
> Devices and Printers.
3. Right-click your machine.
4. For Windows XP/2003/2008/Vista, press Printing Preferences.
For Windows 7 and Windows Server 2008 R2, from context menus,
select the Printing Preferences.
If Printing Preferences item has ► mark, you can select other
printer drivers connected with selected printer.
5. Click Paper tab.
6. Select tray and its options, such as paper size and type.
Basic setup_ 25
media and tray
4.
This chapter provides information on how to load print media into your machine.
This chapter includes:
•
•
•
•
•
Selecting print media
Changing the tray size
Loading paper in the tray
Selecting print media
Printing on special media
Using the output support
Media sizes supported in each mode
You can print on a variety of print media, such as plain paper, envelopes,
labels, and transparencies. Always use print media that meets the
guidelines for use with your machine and from the appropriate tray.
Mode
Size
Type
Simplex
printing
For details about
paper size, see
"Print media
specifications"
on page 57.
For details about
paper type, see
"Print media
specifications"
on page 57.
•
•
tray 1
manual tray
Duplex
printing
(Manual)a
Letter, A4,
Legal, US Folio,
Oficio
Plain, Color,
Preprinted,
Recycled, Bond,
Archive
•
tray 1
Guidelines for selecting the print media
Print media that does not meet the guidelines outlined in this user’s guide
may cause the following problems:
• Poor print quality
• Increased paper jams
• Premature wear on the machine.
Properties, such as weight, composition, grain, and moisture content, are
important factors that affect the machine’s performance and the output
quality. When you choose print materials, consider the following:
• The type, size and weight of the print media for your machine are
described in print media specifications. (See "Print media specifications"
on page 57.)
• Desired outcome: The print media you choose should be appropriate for
your project.
• Brightness: Some print media are whiter than others and produce
sharper, more vibrant images.
• Surface smoothness: The smoothness of the print media affects how
crisp the printing looks on the paper.
•
•
•
•
•
Source
a. 75 to 90 g/m2 (20~24 lb bond) only
Changing the tray size
The tray is preset to Letter or A4 size, depending on your country. To
change the size, you need to adjust the paper guides.
1
2
Some print media may meet all of the guidelines in this section and
still not produce satisfactory results. This may be the result of
improper handling, unacceptable temperature and humidity levels,
or other variables over which cannot be controlled.
Before purchasing large quantities of print media, ensure that it
meets the requirements specifications in this user’s guide and
meets your output requirements.
Using print media that does not meet these specifications may
cause problems, requiring repairs. Such repairs are not covered by
the warranty or service agreements.
Using inflammable print media can cause a fire.
Use designated print media (See "Printing on special media" on
page 28).
The use of inflammable media or foreign materials left in the printer
may lead to overheating of the unit and, in rare cases may cause a
fire.
The amount of paper put into the tray may differ according to media type
used. (See "Print media specifications" on page 57.)
Media and tray_ 26
3
1 Support guide
4
2 Paper length guide
3 Guide lock
4 Paper width guide
1. With one hand press and hold the guide lock, and with the other hand,
hold the paper length guide and support guide together. Slide the paper
length guide and support guide to locate them in the correct paper size
slot.
•
Do not use a paper with more than 6 mm curl.
Loading paper in the tray
Tray 1
2. Flex or fan the edge of the paper stack to separate the pages before
loading papers. Insert the paper into the tray.
3. After inserting paper into the tray, adjust the support guide so that it
lightly touches the paper stack.
1. Pull out the paper tray . And adjust the tray size to the media size you
are loading. (See "Changing the tray size" on page 26.)
2. Flex or fan the edge of the paper stack to separate the pages before
loading papers.
3.
And place paper with the side you want to print facing down.
4. Set the paper type and size for the tray 1. (See "Setting the default tray
and paper" on page 25.)
4. Squeeze the paper width guides and slide them to the desired paper
size marked at the bottom of the tray.
If you experience problems with paper feeding, check whether the
paper meets the media specification. (See "Print media
specifications" on page 57.)
Manual tray
The manual tray can hold special sizes and types of print material, such as
postcards, note cards, and envelopes. It is useful for single page printing on
letterhead or colored paper.
Tips on using the manual tray
•
•
•
Do not push the paper width guide too far causing the media to
warp.
If you do not adjust the paper width guide, it may cause paper
jams.
•
•
•
•
Media and tray_ 27
If you select Manual Feeder for Source from your software
application, you need to press
(cancel button) each time you print
a page and load only one type, size and weight of print media at a
time in the manual tray.
To prevent paper jams, do not add paper while printing. This also
applies to other types of print media.
Print media should be loaded face up with the top edge going into
the manual tray first and be placed in the center of the tray.
Always load the specified print media only to avoid paper jams and
print quality problems. (See "Print media specifications" on page 57.)
Flatten any curl on postcards, envelopes, and labels before loading
them into the manual tray.
1. Load the paper in the manual tray.
Types
Tray 1
Labels
●
Transparency
●
Envelope
●
Preprinted
●
Cotton
•
Do not force the paper beyond the surface with mark
when loading.
• When printing the special media, you must follow the
loading guideline. (See "Printing on special media" on
page 28.)
• When papers overlap when printing using manual tray,
open tray 1 and remove overlapping papers then try
printing again.
• When paper does not feed well while printing, push the
paper in manually until it starts feeding automatically.
Squeeze the manual tray paper guides and adjust them to the width
of the paper. Do not force them too much, or the paper will bent
resulting in a paper jam or skew.
To print from application, open an application and start the print
menu.
Open Printing Preferences. (See "Opening printing preferences" on
page 32.)
Select the Paper tab in Printing Preferences, and select an
appropriate paper type.
2.
3.
4.
5.
●
●
Archive
●
●
( ●: supported, Blank: Not supported)
The media types are shown in the Printing Preferences. This paper type
option allows you to set the type of paper to be loaded in the tray. This
setting appears in the list, so that you can select it. This will let you get the
best quality printout. If not, the desired print quality may not be achieved.
• Plain: 60 to 90 g/m2 (16 to 24 lb) plain paper.
• Thick: 90 to 105 g/m2 (24 to 28 lb) thick paper.
• Thin: 60 to 70 g/m2 (16 to 19 lb) thin paper.
• Bond: 105 to 120 g/m2 (28 to 32 lb) bond.
• Color: 75 to 90 g/m2 (20 to 24 lb) color-backgrounded paper.
• CardStock: 105 to 163 g/m2 (28 to 43 lb) cardstock.
• Labels: 120 to 150 g/m2 (32 to 40 lb) labels.
• Transparency: 138 to 146 g/m2 (37 to 39 lb) transparency paper.
• Envelope: 75 to 90 g/m2 (20 to 24 lb) envelope.
• Preprinted: 75 to 90 g/m2 (20 to 24 lb) preprinted/letterhead paper.
• Cotton: 75 to 90 g/m2 (20 to 24 lb) cotton paper.
• Recycled: 75 to 90 g/m2 (20 to 24 lb) recycled paper.
When you use recycled paper as a used paper, printouts might be
wrinkled.
•
If you are printing multiple pages, load the next sheet after the first
page prints out, and press the
(cancel button). Repeat this
step for every page to be printed.
Printing on special media
●
Recycled
For example, if you want to use a label, set the paper type to
Label.
6. Select Manual Feeder in paper source, then press OK.
7. Start printing from application.
Manual tray
Archive: 70 to 90 g/m2 (19 to 24 lb) If you need to keep the print-out for
a long period time, such as archives, select this option.
Envelope
Successful printing on envelopes depends upon the quality of the
envelopes.
To print an envelope, the stamp area is on the left side and the end of the
envelope with the stamp area enters the printer first and center of the
manual tray.
The table below shows the available special media for each tray.
When using special media, we recommend you feed one paper at a
time. Check the maximum input number of media for each tray. (See
"Print media specifications" on page 57.)
Types
Tray 1
Manual tray
Plain
●
●
Thick
●
●
Thin
●
●
Bond
●
Color
●
CardStock
●
If envelopes are printed out with wrinkles, crease or black bold lines, open
the rear cover and pull down the pressure lever and try printing again. Keep
the rear cover opened during printing.
Media and tray_ 28
overhead projector.
1 Pressure lever
•
•
•
•
•
•
•
•
•
When selecting envelopes, consider the following factors:
- Weight: The weight of the envelope paper should not exceed
90 g/m2 otherwise, jam may occur.
- Construction: Prior to printing, envelopes should lie flat with less
than 6 mm curl, and should not contain air.
- Condition: Envelopes should not be wrinkled, nicked, nor
damaged.
- Temperature: Use envelopes that are compatible with the heat and
pressure of the machine during operation.
Use only well-constructed envelopes with sharp-and well-creased folds.
Do not use stamped envelopes.
Do not use envelopes with clasps, snaps, windows, coated lining,
self-adhesive seals, or other synthetic materials.
Do not use damaged or poorly made envelopes.
Be sure the seam at both ends of the envelope extends all the way to
the corner of the envelope.
1 Acceptable
2 Unacceptable
Envelopes with a peel-off adhesive strip or with more than one flap that
folds over to seal must use adhesives compatible with the machine’s
fusing temperature (about 170°C(338 °F)) for 0.1 second. The extra
flaps and strips might cause wrinkling, creasing, or jams, and may even
damage the fuser.
For the best print quality, position margins no closer than 15 mm from
the edges of the envelope.
Avoid printing over the area where the envelope’s seams meet.
•
•
•
•
•
•
•
•
Labels
To avoid damaging the machine, use only labels designed for use in laser
machines.
•
Transparency
To avoid damaging the machine, use only transparencies designed for use
in laser printers.
In case of color printing using transparencies, the picture quality would
be lower than mono printing when the printouts are used on the
Transparencies used in the machine must be able to withstand
machine’s fusing temperature.
Place them on a flat surface after removing them from the machine.
Do not leave unused transparencies in the paper tray for long periods of
time. Dust and dirt may accumulate on them, resulting in spotty printing.
To avoid smudging caused by fingerprints, handle them carefully.
To avoid fading, do not expose printed transparencies to prolonged
sunlight.
Ensure that transparencies are not wrinkled, curled, or have any torn
edges.
Do not use transparencies that separates from the backing sheet.
To prevent transparencies from sticking to each other, do not let the
printed sheets stack up as they are begin printed out.
•
•
•
When selecting labels, consider the following factors:
- Adhesives: The adhesive material should be stable at your
machine’s fusing temperature (about 170°C(338 °F)).
- Arrangement: Only use labels with no exposed backing between
them. Labels can peel off sheets that have spaces between the
labels, causing serious jams.
- Curl: Prior to printing, labels must lie flat with no more than 13 mm
of curl in any direction.
- Condition: Do not use labels with wrinkles, bubbles, or other
indications of separation.
Make sure that there is no exposed adhesive material between labels.
Exposed areas can cause labels to peel off during printing, which can
cause paper jams. Exposed adhesive can also cause damage to
machine components.
Do not run a sheet of labels through the machine more than once. The
adhesive backing is designed for only a single pass through the
machine.
Do not use labels that are separating from the backing sheet or are
wrinkled, bubbled, or otherwise damaged.
Media and tray_ 29
Card stock/Custom-sized paper
Glossy
Postcards, cards and other custom-sized materials can be printed with this
machine.
Load one paper to the manual tray at a time, glossy side facing up.
•
•
Recommended media: Glossy paper (Letter) for this machine by HP
Brochure Paper (Product: Q6611A) only.
Recommended media: Glossy paper (A4) for this machine by HP
Superior Paper 160 glossy (Product: Q6616A).
Using the output support
The surface of the output tray may become hot if you print a large
number of pages at once. Make sure that you do not touch the
surface, and do not allow children near it.
•
•
•
Do not print on media smaller than 76 mm (3.00 inches) wide or 127 mm
(5.00 inches) long.
In the software application, set margins at least 6.4 mm (0.25 inches)
away from the edges of the material.
The printed pages stack on the output support, and the output support will
help the printed pages to align. The printer sends output to the output tray
by default. To use the output tray, make sure that the rear cover is closed.
If media weight is over 160 g/m2 (43 lb), try printing in the rear cover
(face up).
Letterhead/Preprinted paper
Single-sided
•
•
•
•
Double-sided
Tray1
Face down
Face up
Manual tray
Face up
Face down
Letterhead/ Preprinted paper must be printed with heat-resistant ink that
will not melt, vaporize, or release hazardous emissions when subjected
to the machine’s fusing temperature (about 170°C(338 °F)) for 0.1
second.
Letterhead/ Preprinted paper ink must be non-flammable and should not
adversely affect machine rollers.
Forms and letterhead should be sealed in a moisture-proof wrapping to
prevent changes during storage.
Before you load letterhead/preprinted paper, verify that the ink on the
paper is dry. During the fusing process, wet ink can come off preprinted
paper, reducing print quality.
•
Make sure not to use the inkjet photo paper with this machine. It could
cause damage to the machine.
Media and tray_ 30
printing
5.
This chapter explains common printing tasks.
This chapter includes:
•
•
•
•
•
•
•
•
•
•
Printer driver features
Basic printing
Opening printing preferences
Using help
Using special print features
•
The procedures in this chapter are mainly based on Windows 7.
Printer driver features
Macintosh basic printing. (See "Macintosh printing" on page 36.)
Linux basic printing. (See "Linux printing" on page 36.)
The following Printing Preferences window is for Notepad in Windows 7.
Your Printing Preferences window may differ, depending on your
operating system or the application you are using.
1. Open the document you want to print.
2. Select Print from the File menu. The Print window appears.
3. Select your machine from the Select Printer list.
Some models or operating system may not support the certain
feature(s) in the following table.
Printer driver
Windows
Machine quality option
●
Poster printing
●
Multiple pages per sheet
●
Booklet printing (manual)
●
Fit to page printing
●
Reduce and enlarge printing
●
Different source for first page
●
Watermark
●
Overlay
●
Double-sided printing (manual)
●
( ●: supported )
The basic print settings including the number of copies and print range
are selected within the Print window.
Basic printing
To take advantage of the printer features provided by your printer
driver, click Properties or Preferences in the application’s Print
window to change the print setting. (See "Opening printing
preferences" on page 32.)
Your machine allows you to print from various Windows, Macintosh, or
Linux applications. The exact steps for printing a document may vary
depending on the application you use.
•
When you select an option in Printing Preferences, you may see
, or
. An exclamation mark ( ) means you
a warning mark,
can select that certain option but it is not recommended, and ( )
mark means you cannot select that option due to the machine’s
setting or environment.
The following procedure describes the general steps required for printing
from various Windows applications.
Your printer drivers support the following standard features:
• Paper orientation, size, source, and media type selection
• Number of copies
In addition, you can use various special printing features. The following
table shows a general overview of features supported by your printer
drivers:
Feature
Changing the default print settings
Setting your machine as a default machine
Printing to a file (PRN)
Macintosh printing
Linux printing
4. To start the print job, click OK or Print in the Print window.
Your Printing Preferences window that appears in this user’s
guide may differ depending on the machine in use. However, the
composition of the Printing Preferences window is similar. Check
the operating system(s) that are compatible with your machine.
Refer to the OS compatibility section of Printer Specifications.
(See "System requirements" on page 21.)
Canceling a print job
If the print job is waiting in a print queue or print spooler, cancel the job as
follows:
Printing_ 31
1. Change the settings as needed on each tab.
2. Enter a name for the item in the Presets input box.
1. Click the Windows Start menu.
2. For Windows 2000, select Settings > Printers.
• For Windows XP/2003, select Printers and Faxes.
• For Windows 2008/Vista, select Control Panel > Hardware and
Sound > Printers.
• For Windows 7, select Control Panel > Hardware and Sound >
Devices and Printers.
• For Windows Server 2008 R2, select Control Panel > Hardware >
Devices and Printers.
3. For Windows 2000, XP, 2003, Vista and 2008, double-click your
machine.
For Windows 7 and Windows Server 2008 R2, right click your printer
icon > context menus > See what’s printing.
If See what’s printing item has ► mark, you can select other
printer drivers connected with selected printer.
3. Click
saved.
4. From the Document menu, select Cancel.
You can also access this window by simply double-clicking the
machine icon (
) in the Windows task bar.
You can also cancel the current job by pressing
the control panel.
(Add). When you save Presets, all current driver settings are
Select more options and click
(Update), settings will be added to
the Presets you made. To use a saved setting, select it from the
Presets drop-down list. The machine is now set to print according to
the settings you have selected. To delete saved settings, select it from
(cancel button) on
(Delete).
the Presets drop-down list and click
You can also restore the printer driver’s default settings by selecting
Default Preset from the Presets drop-down list.
Opening printing preferences
You can preview the settings you selected on the upper right of the Printing
Preferences.
1. Open the document you want to print.
2. Select Print from the file menu. The Print window appears.
3. Select your machine from the Select Printer.
4. Click Properties or Preferences.
Using help
Click the option you want to know on the Printing Preferences window and
press F1 on your keyboard.
Using special print features
Special print features include:
• "Printing multiple pages on one sheet of paper" on page 32.
• "Printing posters" on page 33.
• "Printing booklets (Manual)" on page 33.
• "Printing on both sides of paper (Manual)" on page 33.
• "Change percentage of your document" on page 34.
• "Fitting your document to a selected paper size" on page 34.
• "Using watermarks" on page 34.
• "Using overlay" on page 34.
Printing multiple pages on one sheet of paper
Using a favorite setting
The Presets option, which is visible on each preferences tab except for the
Samsung tab, allows you to save the current preferences for future use.
To save a Presets item, follow these steps:
You can select the number of pages to print on a single sheet of paper. To
print more than one page per sheet, the pages will be reduced in size and
arranged in the order you specify. You can print up to 16 pages on one
sheet.
1. To change the print settings from your software application, access
Printing Preferences. (See "Opening printing preferences" on
page 32.)
2. Click the Basic tab, select Multiple Pages Per Side in the Type
drop-down list.
3. Select the number of pages you want to print per sheet (2, 4, 6, 9, or 16)
in the Pages per Side drop-down list.
4. Select the page order from the Page Order drop-down list, if necessary.
Printing_ 32
5. Check Print Page Border to print a border around each page on the
sheet.
6. Click the Paper tab, select the Size, Source, and Type.
7. Click OK or Print until you exit the Print window.
Printing posters
This feature allows you to print a single-page document onto 4, 9, or 16
sheets of paper, for the purpose of pasting the sheets together to form one
poster-size document.
The Booklet Printing option is not available for all paper sizes. In
order to find out the available paper size for this feature, select the
available paper size in the Size option on the Paper tab.
If you select an unavailable paper, booklet option will be
automatically canceled. The available paper is the one without
or
mark.
4. Click OK or Print until you exit the Print window.
5. After printing, fold and staple the pages.
Printing on both sides of paper (Manual)
You can print on both sides of a paper; duplex. Before printing, decide how
you want your document oriented. You can use this feature with Letter,
Legal, A4, US Folio, or Oficio sized paper. (See "Print media specifications"
on page 57.)
•
1. To change the print settings from your software application, access
Printing Preferences. (See "Opening printing preferences" on
page 32.)
2. Click the Basic tab, select Poster Printing in the Type drop-down list.
3. Select the page layout you want.
Specification of the page layout:
• Poster 2x2: Document will be enlarged and be divided into 4 pages.
• Poster 3x3: Document will be enlarged and be divided into 9 pages.
• Poster 4x4: Document will be enlarged and be divided into 16
pages.
4. Select the Poster Overlap value. Specify Poster Overlap in millimeters
or inches by selecting the radio button on the upper right of Basic tab to
make it easier to paste the sheets together.
We recommend not to print on both sides of the special media,
such as labels, envelopes, or thick paper to print on both sides of
paper. It may cause a paper jam or damage the machine.
• The Double-Sided Printing (Manual) feature is available only for
the tray 1.
1. To change the print settings from your software application, access
Printing Preferences. (See "Opening printing preferences" on
page 32.)
2. Click the Advanced tab.
3. From the Double-Sided Printing (Manual) section, select the binding
option you want.
• None
• Long Edge: This option is the conventional layout used in
bookbinding.
•
5. Click the Paper tab, select the Size, Source, and Type.
6. Click OK or Print until you exit the Print window.
7. You can complete the poster by pasting the sheets together.
Short Edge: This option is the conventional layout used in
calendars.
Printing booklets (Manual)
This feature prints your document on both sides of a paper and arranges the
pages so that the paper can be folded in half after printing to produce a
booklet.
If you want to make a booklet, you need to print on Letter, Legal, A4,
US Folio, or Oficio sized print media.
8
4. Click the Paper tab, select the Size, Source, and Type.
5. Click OK or Print until you exit the Print window.
If your machine does not have a duplex unit, you should complete the
printing job manually. The machine prints every other page of the
document first. After that, a message appears on your computer.
Follow the on-screen instructions to complete the printing job.
9
1. To change the print settings from your software application, access the
Printing Preferences. (See "Opening printing preferences" on
page 32.)
2. Click the Basic tab, select Booklet Printing from the Type drop-down
list.
3. Click the Paper tab, select the Size, Source, and Type.
Printing_ 33
Change percentage of your document
3. Click OK or Print until you exit the print window.
You can change the size of a document to appear larger or smaller on the
printed page by typing in a percentage you want.
Creating a watermark
1. To change the print settings from your software application, access
Printing Preferences. (See "Opening printing preferences" on
page 32.)
2. From the Advanced tab, select Edit from the Watermark drop-down
list. The Edit Watermarks window appears.
3. Enter a text message in the Watermark Message box. You can
enter up to 256 characters. The message displays in the preview
window.
When the First Page Only box is checked, the watermark prints on
the first page only.
4. Select watermark options.
You can select the font name, style, size, and shade from the Font
Attributes section, as well as set the angle of the watermark from
the Message Angle section.
5. Click Add to add a new watermark to the Current Watermarks list.
6. When you have finished editing, click OK or Print until you exit the
Print window.
To stop printing the watermark, select None from the Watermark
drop-down list.
1. To change the print settings from your software application, access
Printing Preferences. (See "Opening printing preferences" on
page 32.)
2. Click the Paper tab.
3. Enter the scaling rate in the Percentage input box.
You can also click the up/down arrows to select the scaling rate.
4. Select the Size, Source, and Type in Paper Options.
5. Click OK or Print until you exit the Print window.
Fitting your document to a selected paper size
This printer feature allows you to scale your print job to any selected paper
size regardless of the document size. This can be useful when you want to
check fine details on a small document.
Editing a watermark
A
1. To change the print settings from your software application, access
Printing Preferences. (See "Opening printing preferences" on
page 32.)
2. Click the Advanced tab, select Edit from the Watermark drop-down
list. The Edit Watermarks window appears.
3. Select the watermark you want to edit from the Current Watermarks
list and change the watermark message and options.
4. Click Update to save the changes.
5. Click OK or Print until you exit the Print window.
1. To change the print settings from your software application, access
Printing Preferences. (See "Opening printing preferences" on
page 32.)
2. Click the Paper tab.
3. Select the paper size you want from the Fit to Page.
4. Select the Size, Source, and Type in Paper Options.
5. Click OK or Print until you exit the Print window.
Deleting a watermark
1. To change the print settings from your software application, access
Printing Preferences. (See "Opening printing preferences" on
page 32.)
2. Click the Advanced tab, select Edit from the Watermark
drop-down list. The Edit Watermarks window appears.
3. Select the watermark you want to delete from the Current
Watermarks list and click Delete.
4. Click OK or Print until you exit the Print window.
Using watermarks
The watermark option allows you to print text over an existing document.
For example, you use it when you want to have large gray letters reading
“DRAFT” or “CONFIDENTIAL” printed diagonally across the first page or all
pages of a document.
Using overlay
There are several predefined watermarks that come with the machine. They
can be modified, or you can add new ones to the list.
Using an existing watermark
An overlay is text and/or images stored in the computer hard disk drive
(HDD) as a special file format that can be printed on any document.
Overlays are often used to take the place of letterhead paper. Rather than
using preprinted letterhead, you can create an overlay containing exactly
the same information that is currently on your letterhead. To print a letter
with your company’s letterhead, you do not need to load preprinted
letterhead paper in the machine just print the letterhead overlay on your
document.
1. To change the print settings from your software application, access
Printing Preferences. (See "Opening printing preferences" on
page 32.)
2. Click the Advanced tab, and select the desired watermark from the
Watermark drop-down list. You will see the selected watermark in
the preview image.
Printing_ 34
Creating a new page overlay
To use a page overlay, you must create a new page overlay containing
your logo or image.
1. Create or open a document containing text or an image for use in a
new page overlay. Position the items exactly as you wish them to
appear when printed as an overlay.
2. To save the document as an overlay, access Printing Preferences.
(See "Opening printing preferences" on page 32.)
3. Click the Advanced tab, and select Edit from the Text drop-down
list. Edit Overlay window appears.
4. In the Edit Overlay window, click Create.
5. In the Save As window, type a name of up to eight characters in the
File name box. Select the destination path, if necessary. (The
default is C:\Formover.)
6. Click Save. The name appears on the Overlay List.
7. Click OK or Print until you exit the Print window.
8. The file is not printed. Instead, it is stored on your computer hard disk
drive.
The overlay document size must be the same as the document
you print with the overlay. Do not create an overlay with a
watermark.
Using a page overlay
After an overlay has been created, it is ready to be printed with your
document. To print an overlay with a document:
1. Create or open the document you want to print.
2. To change the print settings from your software application, access
Printing Preferences. (See "Opening printing preferences" on
page 32.)
3. Click the Advanced tab.
4. Select the desired overlay from the Text drop-down list.
5. If the overlay file you want does not appear in the Text drop-down
list, select Edit from the list and click Load. Select the overlay file
you want to use.
If you have stored the overlay file you want to use in an external
source, you can also load the file when you access the Open
window.
After you select the file, click Open. The file appears in the Overlay
List box and is available for printing. Select the overlay from the
Overlay List box.
6. If necessary, check Confirm Page Overlay When Printing box. If
this box is checked, a message window appears each time you
submit a document for printing, asking you to confirm your wish to
print an overlay on your document.
If this box is not checked and an overlay has been selected, the
overlay automatically prints with your document.
7. Click OK or Print until you exit the Print window.
The selected overlay prints on your document.
The resolution of the overlay document must be the same as that
of the document you will print with the overlay.
Deleting a page overlay
You can delete page overlays that you no longer use.
1. In the Printing Preferences window, click the Advanced tab.
2. Select Edit in the Overlay drop down list.
3. Select the overlay you want to delete from the Overlay List box.
4. Click Delete.
5. When a confirming message window appears, click Yes.
6. Click OK or Print until you exit the Print window.
Changing the default print settings
Most Windows applications will override settings you specify in the
printer driver. Change all print settings available in the software
application first, and change any remaining settings using the printer
driver.
1. Click the Windows Start menu.
2. For Windows 2000, select Settings > Printers.
• For Windows XP/2003, select Printers and Faxes.
• For Windows 2008/Vista, select Control Panel > Hardware and
Sound > Printers.
• For Windows 7, select Control Panel > Hardware and Sound >
Devices and Printers.
• For Windows Server 2008 R2, select Control Panel > Hardware >
Devices and Printers.
3. Right-click your machine.
4. For Windows XP/2003/2008/Vista, press Printing Preferences.
For Windows 7 and Windows Server 2008 R2, from context menus,
select the Printing preferences.
If Printing preferences item has ► mark, you can select other
printer drivers connected with selected printer.
5. Change the settings on each tab.
6. Click OK.
If you want to change the settings for each print job, change it in
Printing Preferences.
Setting your machine as a default machine
1. Click the Windows Start menu.
2. For Windows 2000, select Settings > Printers.
• For Windows XP/2003, select Printers and Faxes.
• For Windows 2008/Vista, select Control Panel > Hardware and
Sound > Printers.
• For Windows 7, select Control Panel > Hardware and Sound >
Devices and Printers.
• For Windows Server 2008 R2, select Control Panel > Hardware >
Devices and Printers.
3. Select your machine.
4. Right-click your machine and select Set as Default Printer.
For Windows 7 and Windows Server 2008 R2
If Set as default printer item has ► mark, you can select other
printer drivers connected with selected printer.
Printing to a file (PRN)
You will sometimes need to save the print data as a file.
To create a file:
Printing_ 35
1. Check the Print to file box at the Print window.
The machine prints the selected number of pages to print on one sheet
of paper.
Using help
Click the question mark on the bottom-left corner of the window and click on
the topic you want to know about. A pop-up window appears with
information about that option's feature, which is provided from the driver.
2. Click Print.
3. Type in the destination path and the file name, and then click OK.
For example c:\Temp\file name.
If you type in only the file name, the file is automatically saved in
My Documents.
Macintosh printing
Linux printing
Some features may not be available depending on models or options.
It means that the features are not supported.
Printing a document
When you print with a Macintosh, you need to check the printer driver
settings in each application you use. Follow the steps below to print from a
Macintosh:
1. Open the document to print.
2. Open the File menu and click Page Setup (Document Setup in some
applications).
3. Choose your paper size, orientation, scaling, other options, and make
sure that your machine is selected. Click OK.
4. Open the File menu and click Print.
5. Choose the number of copies and indicate which pages to print.
6. Click Print.
Some features may not be available depending on models or options.
It means that the features are not supported.
Printing from applications
There are a lot of Linux applications that allow you to print using Common
UNIX Printing System (CUPS). You can print on your machine from any
such application.
1. Open an application, and select Print from the File menu.
2. Select Print directly using lpr.
3. In the LPR GUI window, select the model name of your machine from
the printer list and click Properties.
Changing printer settings
You can use advanced printing features when using your machine.
Open an application and select Print from the File menu. The machine
name, which appears in the printer properties window, may differ depending
on the machine in use. Except for the name, the composition of the printer
properties window is similar to the following.
Printing multiple pages on one sheet
You can print more than one page on a single sheet of paper. This feature
provides a cost-effective way to print draft copies.
1. Open an application, and select Print from the File menu.
2. Select Layout from the drop-down list under Orientation. In the Pages
per Sheet drop-down list, select the number of pages you want to print
on one sheet of paper.
3. Select the other options to use.
4. Click Print.
Printing_ 36
4. Change the print job properties using the following four tabs displayed at
the top of the window.
•
General: This option allows you to change the paper size, the paper
type, and the orientation of the documents. It enables the duplex
feature, adds start and end banners, and changes the number of
pages per sheet.
Automatic/manual duplex printing may not be available
depending on models. You can alternatively use the lpr printing
system or other applicaions for odd-even printing.
•
•
•
Text: This option allows you to specify the page margins and set the
text options, such as spacing or columns.
Graphics: This option allows you to set image options that are used
when printing images/files, such as color options, image size, or
image position.
Advanced: This option allows you to set the print resolution, paper
source and special print features.
If an option is grayed out, it means that the grayed out option is not
supported.
5. Click Apply to apply the changes and close the Properties window.
6. Click OK in the LPR GUI window to start printing.
7. The Printing window appears, allowing you to monitor the status of your
print job.
To abort the current job, click Cancel.
Configuring printer properties
Using the Printer Properties window provided by the Printers
configuration, you can change the various properties for your machine as
a printer.
1. Open the Unified Driver Configurator.
If necessary, switch to Printers configuration.
2. Select your machine on the available printers list and click Properties.
3. The Printer Properties window opens.
The following five tabs display at the top of the window:
• General: This option allows you to change the printer location and
name. The name entered in this tab displays on the printer list in
Printers configuration.
• Connection: This option allows you to view or select another port. If
you change the machine port from USB to parallel or vice versa
while in use, you must re-configure the machine port in this tab.
• Driver: Allows you to view or select another printer driver. By
clicking Options, you can set the default device options.
• Jobs: This option shows the list of print jobs. Click Cancel job to
cancel the selected job and select the Show completed jobs check
box to see previous jobs on the job list.
• Classes: This option shows the class that your machine is in. Click
Add to Class to add your machine to a specific class or click
Remove from Class to remove the machine from the selected
class.
4. Click OK to apply the changes and close the Printer Properties
window.
Printing files
You can print many different types of files on your machine using the
standard CUPS way, directly from the command line interface. The CUPS
lpr utility allows you to do that. But the drivers package replaces the
standard lpr tool by a much more user-friendly LPR GUI program.
To print any document file:
1. Type lpr <file_name> from the Linux shell command line and press
Enter. The LPR GUI window appears.
When you type only lpr and press Enter, the Select file(s) to print
window appears first. Just select any files you want to print and click
Open.
2. In the LPR GUI window, select your machine from the list, and change
the print job properties.
3. Click OK to start printing.
Printing_ 37
management tools
6.
This chapter introduces management tools provided to help you make full use of your machine.
This chapter includes:
•
•
•
•
•
•
Introducing useful management tools
Using Samsung AnyWeb Print
Using Samsung Easy Printer Manager
Using Samsung Printer Status
Using Smart Panel
Using the Unified Linux Driver Configurator
Introducing useful management tools
The screenshot may differ depending on operating system you are
using.
The programs below help you to use your machine conveniently.
• "Using Samsung AnyWeb Print" on page 38.
• "Using Samsung Easy Printer Manager" on page 38.
• "Using Samsung Printer Status" on page 39
• "Using Smart Panel" on page 39
• "Using the Unified Linux Driver Configurator" on page 40
Using Samsung AnyWeb Print
Available for Windows and Macintosh OS users only.
This tool helps you screen-capture, preview, scrap, and print pages more
easily, than when you use an ordinary program.
To open the program:
• For Windows: Select Start > All Programs > Samsung Printers >
Samsung AnyWeb Print > Download the latest version.
• For Macintosh: Open the Applications folder > Samsung folder >
Samsung AnyWeb Print.
Using Samsung Easy Printer Manager
•
•
Available for Windows and Macintosh OS users only.
For Windows, Internet Explorer 6.0 or higher is the minimum
requirement for Samsung Easy Printer Manager.
Samsung Easy Printer Manager is an application that combines Samsung
machine settings into one location. Samsung Easy Printer Manager
combines device settings as well as printing environments, settings/actions
and launching. All of these features provide a gateway to conveniently use
your Samsung machine. Samsung Easy Printer Manager provides two
different user interfaces for the user to choose from: the basic user interface
and the advanced user interface. Switching between the two interfaces is
easy: just click
1
Printer List
The printer list displays the installed printer icons on
your computer.
Printer
Information
This area gives you general information about your
machine. You can check information, such as the
machine’s model name, IP address (or Port name),
and machine status.
2
User’s Guide button: This button opens
Troubleshooting Guide when an error
occurs. You can directly open the necessary
section in the user’s guide.
button.
Application
information
Understanding Samsung Easy Printer Manager
To open the program:
• For Windows: Select Start > Programs or All Programs > Samsung
Printers > Samsung Easy Printer Manager > Samsung Easy Printer
Manager.
• For Macintosh: Open the Applications folder > Samsung folder >
Samsung Easy Printer Manager
The Samsung Easy Printer Manager interface is comprised of various basic
sections as described in the table that follows:
3
Includes links for changing to the advanced settings,
preference, help, and about.
The
button is used to change the user
interface to the advanced settings user
interface.
Quick links
4
Management tools_ 38
Displays Quick links to machine specific functions.
This section also includes links to applications in the
advanced settings.
Contents
Area
5
Order
Supplies
6
Displays information about the selected machine,
remaining toner level, and paper. The information
will vary based on the machine selected. Some
machines do not have this feature.
Icon
Click on the Order button from the supply ordering
window. You can order replacement toner
cartridge(s) from online.
Click the Help ( ) button from the upper-right corner of the window
and click on any option you want to know about.
Mean
Description
Normal
The machine is in ready mode and experiencing no
errors or warnings.
Warning
The machine is in a state where an error might
occur in the future. For example, it might be in toner
low status, which may lead to toner empty status.
Error
The machine has at least one error.
Advanced settings user interface overview
The advanced user interface is intended to be used by the person
responsible for managing the machines.
Device Settings
You can configure various machine settings such as machine setup,
paper, layout, emulation, network, and print information.
Alert Settings (Windows only)
This is menu includes settings related to error alerting.
• Printer Alert: Provides settings related to when alerts will be
received.
• Email Alert: Povides options relating to receiving alerts via email.
• Alert History: Provides a history of device and toner related alerts.
Understanding Easy Capture Manager
Capture your screen and launch Easy Capture Manager by simply pressing
the Print Screen key on the keyboard. Now you can easily print your
captured screen as captured or edited.
Toner Level
You can view the level of toner remaining in
each toner cartridge. The machine and the
number of toner cartridge(s) shown in the
above window may differ depending on the
machine in use. Some machines do not have
this feature.
Alert Settings
Select the settings you want from the options
window.
Order Supplies
You can order replacement toner cartridge(s)
from online.
Troubleshooting
You can directly open the troubleshooting
section in the user’s guide.
Close
Close the window.
1
Using Samsung Printer Status
•
•
Available for Windows OS users only.
The Samsung Printer Status window and its contents shown in this
user’s guide may differ depending on the machine or operating
system in use.
• Check the operating system(s) that are compatible with your
machine. (See "System requirements" on page 21.)
The Samsung Printer Status is a program that monitors and informs you of
the machine status.
Samsung Printer Status overview
If an error occurs while operating, you can check the error from the
Samsung Printer Status. Samsung Printer Status is installed automatically
when you install the machine software.
You can also launch Samsung Printer Status manually. Go to the Printing
Preferences , click the Basic tab > Printer Status button.
These icons appear on the Windows task bar:
2
3
4
5
Using Smart Panel
•
•
Available for Linux OS user only.
The Smart Panel window and its contents shown in this user’s
guide may differ depending on the machine or operating system in
use.
• Check the operating system(s) that are compatible with your
machine. (See "System requirements" on page 21.)
Smart Panel is a program that monitors and informs you of the machine’s
status, and allows you to customize the machine’s settings. You can
download Smart Panel from the Samsung website. (See "Installing the
SmartPanel" on page 23.)
Management tools_ 39
Smart Panel overview
If an error occurs while operating, you can check the error from the Smart
Panel. You can also launch Smart Panel manually.
Double-click the Smart Panel icon (
) in the Notification Area.
2
3
4
1
Toner Level
1
2
Buy Now
You can order replacement toner cartridge(s)
from online.
User’s Guide
You can view the online User’s Guide.
This button opens the Troubleshooting
Guide when an error occurs. You can
directly open the troubleshooting section
in the user’s guide.
3
Printer Setting
4
You can view the level of toner remaining in
each toner cartridge. The machine and the
number of toner cartridge(s) shown in the above
window may differ depending on the machine in
use. Some machines do not have this feature.
1 Printers
Configuration
2 Ports
Configuration
To use the on screen help, click Help.
3. After changing the configurations, click Exit to close the Unified Driver
Configurator.
Printers configuration
Printers configuration has the two tabs: Printers and Classes.
Printers tab
View the current system’s printer configuration by clicking on the
machine icon button on the left side of the Unified Driver Configurator
window.
You can configure various machine settings in
the Printer Settings Utility window. Some
machines do not have this feature.
Changing Smart Panel ‘s settings
Right-click on the Smart Panel icon and select Configure Smart Panel.
Select the settings you want from the Configure Smart Panel window.
Using the Unified Linux Driver Configurator
The Unified Driver Configurator is a tool primarily intended for configuring
machine devices. You need to install Unified Linux Driver to use Unified
Driver Configurator. (See "Installing the Unified Linux Driver" on page 22.)
After the driver is installed on your Linux system, the Unified Driver
Configurator icon will automatically be created on your desktop.
Opening the Unified Driver Configurator
1. Double-click the Unified Driver Configurator on the desktop.
You can also click the Startup Menu icon and select Samsung Unified
Driver > Unified Driver Configurator.
2. Click each button on the left to switch to the corresponding configuration
window.
1
Switches to Printers configuration.
2
Shows all of the installed machine.
3
Shows the status, model name and URI of your machine.
The printer control buttons are, as follows:
• Refresh: Renews the available machines list.
• Add Printer: Allows you to add a new machines.
Management tools_ 40
•
•
•
•
•
Remove Printer: Removes the selected machine.
Set as Default: Sets the current selected machine as a default
machine.
Stop/Start: Stops/starts the machine.
Test: Allows you to print a test page to ensure the machine is
working properly.
Properties: Allows you to view and change the printer properties.
Ports configuration
In this window, you can view the list of available ports, check the status of
each port and release a port that is stalled in a busy state when its owner
has terminated the job for any reason.
Classes tab
The Classes tab shows a list of available machine classes.
•
•
1
Shows all of the machine classes.
2
Shows the status of the class and the number of machines in the
class.
•
•
•
1
Switches to Ports configuration.
2
Shows all of the available ports.
3
Shows the port type, device connected to the port, and status.
Refresh: Renews the available ports list.
Release port: Releases the selected port.
Refresh: Renews the classes list.
Add Class: Allows you to add a new machine class.
Remove Class: Removes the selected machine class.
Management tools_ 41
maintenance
7.
This chapter provides information for maintaining your machine and the toner cartridge.
This chapter includes:
•
•
Printing a configuration report
Cleaning a machine
•
•
Printing a configuration report
You can print a configuration page to view current printer settings, or to help
troubleshoot printer problems.
In ready mode, press and hold the
seconds.
A configuration page prints out.
Storing the toner cartridge
Tips for moving & storing your machine
1. Turn the machine off and unplug the power cord. Wait for the machine to
cool down.
2. Open the front cover and pull the toner cartridge out. Set it on a clean
flat surface
(cancel button) for about 2 to 5
Cleaning a machine
If printing quality problems occur or if you use your machine in a dusty
environment, you need to clean your machine regularly to keep the best
printing condition and use your machine longer.
•
•
Cleaning the cabinet of the machine with cleaning materials
containing large amounts of alcohol, solvent, or other strong
substances can discolor or distort the cabinet.
If your machine or the surrounding area is contaminated with
toner, we recommend you use cloth or tissue dampened with
water to clean it. If you use a vacuum cleaner, toner blows in the
air and might be harmful to you.
Cleaning the outside
Clean the machine cabinet with a soft, lint-free cloth. Dampen the cloth
slightly with water, but be careful not to let any water drip onto or into the
machine.
•
To prevent damage to the toner cartridge, do not expose it to
light for more than a few minutes. Cover it with a piece of
paper, if necessary.
• Do not touch the green surface underside of the toner
cartridge. Use the handle on the cartridge to avoid touching
this area.
3. With a dry, lint-free cloth, wipe away any dust and spilled toner from the
toner cartridge area.
Cleaning the inside
During the printing process, paper, toner, and dust particles can accumulate
inside the machine. This buildup can cause print quality problems, such as
toner specks or smearing. Cleaning the inside of the machine clears and
reduces these problems.
While cleaning the inside of the machine, be careful not to damage
the transfer roller or any other inside parts. Do not use solvents
such as benzene or thinner to clean. Printing quality problems can
occur and cause damage to the machine.
Maintenance_ 42
4. Locate the long strip of glass (LSU) inside the machine and gently swab
the glass to see if dirt turns the white cotton black.
brand toner cartridge.
Estimated cartridge life
Estimated cartridge life (the life of the toner cartridge yield) depends on the
amount of toner that print jobs require. The actual print-out number may
vary depending on the print density of the pages you print on, operating
environment, printing interval, media type, and/or media size. For example,
if you print a lot of graphics, the consumption of the toner is high and you
may need to change the cartridge more often.
Tips for moving & storing your machine
•
•
5. Reinsert the toner cartridge and close the front cover.
6. Plug in the power cord and turn the machine on.
When moving the machine, do not tilt or turn it upside down. Otherwise,
the inside of the machine may be contaminated by toner, which can
cause damage to the machine or bad print quality.
When moving the machine, make sure at least two people are holding
the machine securely.
Storing the toner cartridge
Toner cartridges contain components that are sensitive to light,
temperature, and humidity. Samsung suggests users follow the
recommendations to ensure the optimum performance, highest quality, and
longest life from your new Samsung toner cartridge.
Store this cartridge in the same environment as the printer it will be used in;
this should be in controlled office temperature and humidity conditions. The
toner cartridge should remain in its original, unopened package until
installation – If original packaging is not available, cover the top opening of
the cartridge with paper and store in a dark cabinet.
Opening the cartridge package prior to use dramatically shortens its useful
shelf and operating life. Do not store on the floor. If the toner cartridge is
removed from the printer, always store the cartridge:
• Inside the protective bag from the original package.
• Store lying flat (not standing on end) with the same side facing up as if
they were installed in the machine.
• Do not store consumables in;
- Temperature greater than 40°C (104°F).
- Humidity range less than 20% or greater than 80%.
- An environment with extreme changes in humidity or temperature.
- Direct sunlight or room light.
- Dusty places.
- A car for a long period of time.
- An environment where corrosive gases are present.
- An environment with salty air.
Handling instructions
•
•
•
Do not touch the surface of the photosensitive drum in the cartridge.
Do not expose the cartridge to unnecessary vibrations or shock.
Never manually rotate the drum, especially in the reverse direction; this
can cause internal damage and toner spillage.
Use of non-Samsung and refilled toner cartridge
Samsung Electronics does not recommend or approve the use of
non-Samsung brand toner cartridges in your printer including generic, store
brand, refilled, or remanufactured toner cartridges.
Samsung’s printer warranty does not cover damage to the machine
caused by the use of a refilled, remanufactured, or non-Samsung
Maintenance_ 43
troubleshooting
8.
This chapter gives helpful information for what to do if you encounter an error.
This chapter includes:
•
•
•
•
•
Redistributing toner
Tips for avoiding paper curls
Tips for avoiding paper jams
Redistributing toner
Clearing paper jams
Solving other problems
place completely.
When the toner cartridge is near the end of its life:
• White streaks or light printing occurs.
• The
LED blinks orange.
If this happens, you can temporarily improve print quality by redistributing
the remaining toner in the cartridge. In some cases, white streaks or light
printing will still occur even after you have redistributed the toner.
1. Open the front cover.
2. Pull the toner cartridge out.
5. Close the front cover. Ensure that the cover is securely closed.
If the output tray is closed, open the output tray.
Tips for avoiding paper curls
1. Open the rear cover.
2. Pull down the pressure lever on each side.
3. Thoroughly roll the cartridge five or six times to distribute the toner
evenly inside the cartridge.
If toner gets on your clothing, wipe it off with a dry cloth and wash
clothing in cold water. Hot water sets toner into fabric.
Do not touch the green underside of the toner cartridge. Use the
handle on the cartridge to avoid touching this area.
4. Hold the toner cartridge by the handle and slowly insert the cartridge into
the opening in the machine.
Tabs on the sides of the cartridge and corresponding grooves within the
machine will guide the cartridge into the correct position until it locks into
Troubleshooting_ 44
1 Pressure lever
Keep the rear cover opened during printing.
Only use when the printout has more than 20 mm curl.
Tips for avoiding paper jams
3. Remove the jammed paper by gently pulling it straight out.
By selecting the correct media types, most paper jams can be avoided.
When a paper jam occurs, refer to the next guidelines.
• Ensure that the adjustable guides are positioned correctly. (See
"Loading paper in the tray" on page 27.)
• Do not overload the tray. Ensure that the paper level is below the paper
capacity mark on the inside of the tray.
• Do not remove paper from the tray while your machine is printing.
• Flex, fan, and straighten paper before loading.
• Do not use creased, damp, or highly curled paper.
• Do not mix paper types in a tray.
• Use only recommended print media.
• Ensure that the recommended side of the print media is facing down in
the tray, or facing up in the manual tray.
Clearing paper jams
If a paper jam occurs, the
LED on the control panel lights orange. Find
and remove the jammed paper.
To resume printing after clearing paper jams, you must open and close the
front cover.
To avoid tearing the paper, pull the jammed paper out slowly and
gently. Follow the instructions in the following sections to clear the
jam.
If the paper does not move when you pull, or if you do not see the paper
in this area, check the fuser area around the toner cartridge. (See
"Inside the machine" on page 45.)
4. Insert tray back into the machine until it snaps into place. Printing
automatically resumes.
If the output tray is closed, open the output tray.
In the manual tray
Click this link to open an animation about clearing a jam.
1. If the paper is not feeding properly, pull the paper out of the machine.
In tray
Click this link to open an animation about clearing a jam.
1. Open and close the front cover. The jammed paper is automatically
ejected from the machine.
If the paper does not exit, go to the next step.
2. Pull out tray.
2. Open and close the front cover to resume printing.
If the output tray is closed, open the output tray.
Inside the machine
Click this link to open an animation about clearing a jam.
The fuser area is hot. Take care when removing paper from the
machine.
Troubleshooting_ 45
1. If the output support tray is opened, close the output tray first.
2. Open the front cover and pull the toner cartridge out, lightly pushing it
down.
1
2
1 Pressure lever
If you do not see the jammed paper, go to next step.
5. Pull the fuser cover levers down and remove the paper.
Return the fuser cover levers to their original position.
3. Remove the jammed paper by gently pulling it straight out.
1
2
4. Replace the toner cartridge and close the front cover. Printing
automatically resumes.
If the output tray is closed, open the output tray.
In exit area
The fuser area is hot. Take care when removing paper from the
machine.
Click this link to open an animation about clearing a jam.
1. Open and close the front cover. The jammed paper is automatically
ejected from the machine.
If you do not see the jammed paper, go to next step.
2. Gently pull the paper out of the output tray.
6. Close the rear cover.
7. Open and close front cover, printing automatically resumes.
If you do not see the jammed paper or if there is any resistance when
you pull, stop and go to the next step.
3. Open the rear cover.
4. Pull the pressure levers down and remove the paper.
Return the pressure levers to their original position.
Troubleshooting_ 46
If the output tray is closed, open the output tray.
Solving other problems
Condition
The following chart lists some conditions that may occur and the
recommended solutions. Follow the suggested solutions until the problem is
corrected. If the problem persists, call for service.
Paper does not feed
into the machine.
Suggested solutions
•
•
Power problems
•
Click this link to open an animation about power problems.
•
Condition
The machine is
not receiving
power,
or the connection
cable between the
computer and the
machine is not
connected
properly.
Suggested solutions
•
Plug in the power cord and press
on the control panel.
(power)
The paper keeps
jamming.
•
•
•
Disconnect the machine cable and reconnect
it.
Condition
Use only transparencies specifically designed
for laser printers. Remove each transparency as
it exits from the machine.
Envelopes skew or
fail to feed correctly.
Ensure that the paper guides are against both
sides of the envelopes.
Suggested solutions
Paper jams during
printing.
Clear the paper jam. (See "Clearing paper jams"
on page 45.)
Paper sticks
together.
•
•
•
•
There is too much paper in the tray. Remove
excess paper from the tray. If you are printing
on special materials, use the manual tray.
An incorrect type of paper is being used. Use
only paper that meets the specifications
required by the machine. (See "Print media
specifications" on page 57.)
There may be debris inside the machine.
Open the front cover and remove any debris.
Transparencies stick
together in the paper
exit.
Paper feeding problems
Multiple sheets of
paper do not feed.
•
Remove any obstructions from inside the
machine.
Paper has not been loaded correctly. Remove
paper from the tray and reload it correctly.
There is too much paper in the tray. Remove
excess paper from the tray.
The paper is too thick. Use only paper that
meets the specifications required by the
machine. (See "Print media specifications" on
page 57.)
Check the maximum paper capacity of the
tray. (See "Print media specifications" on
page 57.)
Make sure that you are using the correct type
of paper. (See "Print media specifications" on
page 57.)
Remove paper from the tray and flex or fan
the paper.
Humid conditions may cause some paper to
stick together.
Different types of paper may be stacked in the
tray. Load paper of only one type, size, and
weight.
Troubleshooting_ 47
Printing problems
Condition
The machine
does not print.
Condition
Possible cause
Suggested solutions
The machine is
not receiving
power.
Check the power cord
connections.
The machine is
not selected as
the default
machine.
Select your machine as your
default machine in your Windows.
Check the machine for the following:
• The front cover is not closed. Close the front cover.
• Paper is jammed. Clear the paper jam. (See
"Clearing paper jams" on page 45.)
• No paper is loaded. Load paper. (See "Loading
paper in the tray" on page 27.)
• The toner cartridge is not installed. Install the toner
cartridge.
If a system error occurs, contact your service
representative.
The connection
cable between
the computer and
the machine is
not connected
properly.
Disconnect the machine cable and
reconnect it.
The connection
cable between
the computer and
the machine is
defective.
If possible, attach the cable to
another computer that is working
properly and print a job. You can
also try using a different machine
cable.
The port setting
is incorrect.
Check the Windows printer setting
to make sure that the print job is
sent to the correct port. If the
computer has more than one port,
make sure that the machine is
attached to the correct one.
The machine
does not print.
Possible cause
Suggested solutions
The document
size is so big that
the hard disk
space of the
computer is
insufficient to
access the print
job.
Get more hard disk space and
print the document again.
The output tray is
full.
It can hold up to 80 sheets of plain
paper. Once the paper is removed
from the output tray, the machine
resumes printing.
The machine
selects print
materials from
the wrong
paper source.
The paper option
that was selected
in the Printing
Preferences
may be incorrect.
For many software applications,
the paper source selection is
found under the Paper tab within
the Printing Preferences. Select
the correct paper source. See the
printer driver help screen. (See
"Opening printing preferences" on
page 32.)
A print job is
extremely slow.
The job may be
very complex.
Reduce the complexity of the page
or try adjusting the print quality
settings.
Half the page is
blank.
The page
orientation
setting may be
incorrect.
Change the page orientation in
your application. See the printer
driver help screen.
The paper size
and the paper
size settings do
not match.
Ensure that the paper size in the
printer driver settings matches the
paper in the tray.
Or, ensure that the paper size in
the printer driver settings matches
the paper selection in the software
application settings you use.
The machine
cable is loose or
defective.
Disconnect the machine cable and
reconnect. Try a print job that you
have already printed successfully.
If possible, attach the cable and
the machine to another computer
that you know works and try a print
job. Finally, try a new machine
cable.
The machine
prints, but the
text is wrong,
garbled, or
incomplete.
The machine
may be
configured
incorrectly.
Check the Printing Preferences
to ensure that all of the print
settings are correct. (See
"Opening printing preferences" on
page 32.)
The printer driver
may be
incorrectly
installed.
Repair the machine software. (See
"Installing USB connected
machine’s driver" on page 21.)
The wrong
printer driver was
selected.
Check the application’s printer
selection menu to ensure that your
machine is selected.
The machine is
malfunctioning.
•
The software
application is
malfunctioning.
Try printing a job from another
application.
The operating
system is
malfunctioning.
Exit Windows and reboot the
computer. Turn the machine off
and back on again.
•
Check the LEDs on the control
panel to see if the machine is
indicating a system error.
Contact a service
representative.
Checking an error message is
also possible from the Smart
Panel on your computer.
Troubleshooting_ 48
Condition
Pages print, but
they are blank.
Possible cause
Suggested solutions
The toner
cartridge is
defective or out
of toner.
Redistribute the toner, if
necessary.
If necessary, replace the toner
cartridge.
The file may
have blank
pages.
Check the file to ensure that it
does not contain blank pages.
Some parts, such
as the controller
or the board,
may be
defective.
Contact a service representative.
The machine
does not print
PDF file
correctly. Some
parts of
graphics, text,
or illustrations
are missing.
Incompatibility
between the PDF
file and the
Acrobat
products.
Printing the PDF file as an image
may enable the file to print. Turn
on Print As Image from the
Acrobat printing options.
The print
quality of
photos is not
good. Images
are not clear.
The resolution of
the photo is very
low.
Reduce the photo size. If you
increase the photo size in the
software application, the resolution
will be reduced.
Before printing,
the machine
emits vapor
near the output
tray.
Using damp
paper can cause
vapor during
printing.
This is not a problem. Just keep
printing.
The machine
does not print
special- sized
paper, such as
billing paper.
Paper size and
paper size
setting do not
match.
Set the correct paper size in the
Edit... in the Paper tab in the
Printing Preferences. (See
"Opening printing preferences" on
page 32.)
Printing quality problems
If the inside of the machine is dirty or paper has been loaded improperly,
there might be a reduction in print quality. See the table below to clear the
problem.
Condition
Suggested solutions
Light or faded print •
•
•
It will take longer to print
when you print a PDF file as
an image.
•
•
If a vertical white streak or faded area
appears on the page, the toner supply is low.
You may be able to temporarily extend the
toner cartridge life. (See "Redistributing toner"
on page 44.) If this does not improve the print
quality, install a new toner cart
The paper may not meet paper specifications;
for example, the paper may be too moist or
rough. (See "Print media specifications" on
page 57.)
If the entire page is light, the print resolution
setting is too low or the toner save mode is
on. Adjust the print resolution and turn the
toner save mode off. See the help screen of
the printer driver.
A combination of faded or smeared defects
may indicate that the toner cartridge needs
cleaning. (See "Cleaning the inside" on
page 42.)
The surface of the LSU part inside the
machine may be dirty. (See "Cleaning the
inside" on page 42.)
The top half of the
paper is printed
lighter than the
rest of the paper
The toner might not adhere properly to this type
of paper.
• Change the printer option and try again.
Go to the Printing Preferences, click the
Paper tab, and set the paper type to
Recycled.
Toner specks
•
A aB bC c
A aB bC c
A aB bC c
A aB bC c
A aB bC c
Troubleshooting_ 49
•
•
The paper may not meet specifications; for
example, the paper may be too moist or
rough. (See "Print media specifications" on
page 57.)
The transfer roller may be dirty. Clean the
inside of your machine. Contact a service
representative.
The paper path may need cleaning. Contact a
service representative.
Condition
Dropouts
A aBb C
A aBb C
A aBb C
A aBb C
A aBb C
White Spots
Suggested solutions
Condition
If faded areas, generally rounded, occur
randomly on the page:
• A single sheet of paper may be defective.
Try reprinting the job.
• The moisture content of the paper is uneven
or the paper has moist spots on its surface.
Try a different brand of paper. (See "Print
media specifications" on page 57.)
• The paper lot is bad. The manufacturing
processes can cause some areas to reject
toner. Try a different kind or brand of paper.
• Change the printer option and try again. Go
to Printing Preferences, click Paper tab,
and set type to Thick. (See "Opening
printing preferences" on page 32.)
• If these steps do not correct the problem,
contact a service representative.
If white spots appear on the page:
• The paper is too rough and a lot of dirt from a
paper falls to the inner devices within the
machine, so the transfer roller may be dirty.
Clean the inside of your machine. (See
"Cleaning the inside" on page 42.)
• The paper path may need cleaning. (See
"Cleaning the inside" on page 42.)
Vertical lines
If black vertical streaks appear on the page:
• The surface (drum part) of the toner
cartridge inside the machine has probably
been scratched. Remove the toner cartridge
and install a new one. (See "Replacing the
toner cartridge" on page 53.)
If white vertical streaks appear on the page:
• The surface of the LSU part inside the
machine may be dirty. (See "Cleaning the
inside" on page 42.)
Black background
If the amount of background shading becomes
unacceptable:
• Change to a lighter weight paper. (See "Print
media specifications" on page 57.)
• Check the environmental conditions: very
dry conditions or a high level of humidity
(higher than 80% RH) can increase the
amount of background shading.
• Remove the old toner cartridge and, install a
new one. (See "Replacing the toner
cartridge" on page 53.)
Suggested solutions
Toner smear
If toner smears on the page:
• Clean the inside of the machine. (See
"Cleaning the inside" on page 42.)
• Check the paper type and quality. (See "Print
media specifications" on page 57.)
• Remove the toner cartridge and then, install
a new one. (See "Replacing the toner
cartridge" on page 53.)
Vertical repetitive
defects
If marks repeatedly appear on the printed side of
the page at even intervals:
• The toner cartridge may be damaged. If you
still have the same problem, remove the
toner cartridge and, install a new one. (See
"Replacing the toner cartridge" on page 53.)
• Parts of the machine may have toner on
them. If the defects occur on the back of the
page, the problem will likely correct itself
after a few more pages.
• The fusing assembly may be damaged.
Contact a service representative.
Background
scatter
Background scatter results from bits of toner
randomly distributed on the printed page.
• The paper may be too damp. Try printing
with a different batch of paper. Do not open
packages of paper until necessary so that
the paper does not absorb too much
moisture.
• If background scatter occurs on an envelope,
change the printing layout to avoid printing
over areas that have overlapping seams on
the reverse side. Printing on seams can
cause problems.
• If background scatter covers the entire
surface area of a printed page, adjust the
print resolution through your software
application or in Printing Preferences. (See
"Opening printing preferences" on page 32.)
A
Toner particles are
around bold
characters or
pictures
Troubleshooting_ 50
The toner might not adhere properly to this type
of paper.
• Change the printer option and try again.
Go to the Printing Preferences, click the
Paper tab, and set the paper type to
Recycled.
Condition
Misformed
characters
Suggested solutions
•
Condition
If characters are improperly formed and
producing hollow images, the paper stock
may be too slick. Try different paper. (See
"Print media specifications" on page 57.)
Solid Color or
Black pages
A aBb
A aBb C
A aBb C
A aBb C
A aBb C
Cc
Curl or wave
•
•
•
•
•
•
•
•
Back of printouts
are dirty
Loose toner
•
•
•
•
•
•
Wrinkles or
creases
Ensure that the paper is loaded properly.
Check the paper type and quality. (See "Print
media specifications" on page 57.)
Ensure that the guides are not too tight or too
loose against the paper stack.
•
•
A
Page skew
Suggested solutions
Ensure that the paper is loaded properly.
Check the paper type and quality. Both high
temperature and humidity can cause paper
curl. (See "Print media specifications" on
page 57.)
Turn the stack of paper over in the tray. Also
try rotating the paper 180° in the tray.
Ensure that the paper is loaded properly.
Check the paper type and quality. (See "Print
media specifications" on page 57.)
Turn the stack of paper over in the tray. Also
try rotating the paper 180° in the tray.
Character Voids
A
Horizontal stripes
A aBb C
A aBb C
A aBb C
A aBb C
A aBb C
Check for leaking toner. Clean the inside of the
machine. (See "Cleaning the inside" on
page 42.)
Curl
Troubleshooting_ 51
The toner cartridge may not be installed
properly. Remove the cartridge and reinsert it.
The toner cartridge may be defective.
Remove the toner cartridge and install a new
one. (See "Replacing the toner cartridge" on
page 53.)
The machine may require repair. Contact a
service representative.
Clean the inside of the machine. (See
"Cleaning the inside" on page 42.)
Check the paper type and quality. (See "Print
media specifications" on page 57.)
Remove the toner cartridge and then, install a
new one. (See "Replacing the toner cartridge"
on page 53.)
If the problem persists, the machine may
require repair. Contact a service
representative.
Character voids are white areas within parts of
characters that should be solid black:
• If you are using transparencies, try another
type of transparency. Because of the
composition of transparencies, some
character voids are normal.
• You may be printing on the wrong surface of
the paper. Remove the paper and turn it
around.
• The paper may not meet paper
specifications. (See "Print media
specifications" on page 57.)
If horizontally aligned black streaks or smears
appear:
• The toner cartridge may be installed
improperly. Remove the cartridge and
reinsert it.
• The toner cartridge may be defective.
Remove the toner cartridge and install a new
one. (See "Replacing the toner cartridge" on
page 53.)
• If the problem persists, the machine may
require repair. Contact a service
representative.
If the printed paper is curled or paper does not
feed into the machine:
• Turn the stack of paper over in the tray. Also
try rotating the paper 180° in the tray.
• Change the printer option and try again. Go
to Printing Preferences, click Paper tab,
and set type to Thin. (See "Opening printing
preferences" on page 32.)
Condition
Suggested solutions
condition
Suggested solutions
An unknown image
repetitively
appears on a few
sheets or loose
toner, light print, or
contamination
occurs.
Your machine is probably being used at an
altitude of 1,000 m (3,281 ft) or above.
The high altitude may affect the print quality,
such as loose toner or light imaging. Change the
correct altitude setting to your machine. (See
"Altitude adjustment" on page 25.)
The machine does
not print whole
pages, and output is
printed on half the
page.
It is a known problem that occurs when a color
machine is used on version 8.51 or earlier of
Ghostscript, 64-bit Linux OS, and has been
reported to bugs.ghostscript.com as Ghostscript
Bug 688252. The problem is solved in AFPL
Ghostscript v. 8.52 or above. Download the
latest version of AFPL Ghostscript from
http://sourceforge.net/projects/ghostscript/ and
install it to solve this problem.
I encounter error
“Cannot open port
device file” when
printing a document.
Avoid changing print job parameters (via LPR
GUI, for example) while a print job is in progress.
Known versions of CUPS server break the print
job whenever print options are changed and
then try to restart the job from the beginning.
Since Unified Linux Driver locks the port while
printing, the abrupt termination of the driver
keeps the port locked and unavailable for
subsequent print jobs. If this situation occurs, try
to release the port by selecting Release port in
Port configuration window.
Common Windows problems
Condition
Suggested solutions
“File in Use”
message appears
during installation.
Exit all software applications. Remove all
software from the startup group, then restart
Windows. Reinstall the printer driver.
“General Protection
Fault”, “Exception
OE”, “Spool 32”, or
“Illegal Operation”
messages appear.
Close all other applications, reboot Windows
and try printing again.
“Fail To Print”, “A
printer timeout error
occurred” messages
appear.
These messages may appear during printing.
Just keep waiting until the machine finishes
printing. If the message appears in ready mode
or after printing has been completed, check the
connection and/or whether an error has
occurred.
Refer to Microsoft Windows User’s Guide that came with your
computer for further information on Windows error messages.
Common Linux problems
condition
The machine does
not print.
Suggested solutions
•
•
•
Check if the printer driver is installed in your
system. Open Unified Driver Configurator and
switch to the Printers tab in Printers
configuration window to look at the list of
available machines. Make sure that your
machine is displayed on the list. If not, open
Add new printer wizard to set up your
device.
Check if the machine is started. Open
Printers configuration and select your
machine on the printers list. Look at the
description in the Selected printer pane. If its
status contains Stopped string, press the
Start button. After that normal operation of
the machine should be restored. The
“stopped” status might be activated when
some problems in printing occurred.
Check if your application has special print
option such as “-oraw”. If “-oraw” is specified
in the command line parameter, then remove
it to print properly. For Gimp front-end, select
“print” -> “Setup printer” and edit command
line parameter in the command item.
Refer to Linux User’s Guide that came with your computer for further
information on Linux error messages.
Common Macintosh problems
condition
Suggested solutions
The machine does
not print PDF files
correctly. Some
parts of graphics,
text, or illustrations
are missing.
Printing the PDF file as an image may enable
the file to print. Turn on Print As Image from the
Acrobat printing options.
Some letters are not
displayed normally
during the Cover
page printing.
Mac OS cannot create the font during the Cover
page printing. The English alphabet and
numbers are displayed normally on the Cover
page.
When printing a
document in
Macintosh with
Acrobat Reader 6.0
or higher, colors
print incorrectly.
Make sure that the resolution setting in your
machine driver matches the one in Acrobat
Reader.
It will take longer to print when you print a
PDF file as an image.
Refer to Macintosh User’s Guide that came with your computer for
further information on Macintosh error messages.
Troubleshooting_ 52
supplies
9.
This chapter provides information on purchasing supplies and maintenance parts available for your machine.
This chapter includes:
•
•
How to purchase
Available supplies
•
•
Available maintenance parts
Replacing the toner cartridge
Samsung does not recommend using non-genuine Samsung toner
cartridge such as refilled or remanufactured toner. Samsung cannot
guarantee non-genuine Samsung toner cartridge's quality. Service or
repair required as a result of using non-genuine Samsung toner
cartridges will not be covered under the machine’s warranty.
Available accessories may differ from country to country. Contact your
sales representatives to obtain the list of available supplies, and
maintenance parts.
How to purchase
Available maintenance parts
To order Samsung-authorized supplies, accessories and, maintenance
parts, contact your local Samsung dealer or the retailer where you
purchased your machine. You can also visit www.samsung.com/supplies,
select your country/region, and obtain information on calling for service.
To avoid print quality and paper feed problems resulting from worn parts
and to maintain your machine in top working condition, the following parts
will need to be replaced after printing the specified number of pages or
when the life span of each item has expired.
Available supplies
Parts
When supplies reach their lifespan, you can order the following types of
supplies for your machine:
Type
Average
yielda
Part name
Standard
yield toner
cartridge
Approx.
•
1,500 pages •
105 (MLT-D105S)
High yield
toner
cartridge
Approx.
•
2,500 pages
105L (MLT-D105L)
102L (MLT-D102L)
Region Ab: 1052 (MLT-D1052S)
•
Region Ab: 1052L (MLT-D1052L)
•
Region Bc: 102L (MLT-D102L)
•
Region Cd: 102L (MLT-D102L)
- ML-2541, ML-2547/XIL: MLT-D102L/XIL
- ML-2547/XSW: MLT-D102L/XSW
Average yielda
Transfer roller
Approx. 50,000 pages
Fuser unit
Approx. 50,000 pages
Pickup roller
Approx. 50,000 pages
Cassette unit
Approx. 50,000 pages
a. It will be affected by operating system used, computing performance,
application software, connecting method, media type, media size and
job complexity.
To purchase maintenance parts, contact the source where you bought the
machine.
Replacing maintenance parts can be performed only by an authorized
service provider, dealer, or the retailer where you bought the machine. The
warranty does not cover the replacement of any maintenance parts after
their lifespan.
a. Declared yield value in accordance with ISO/IEC 19752.
Replacing the toner cartridge
b. Region A: Albania, Austria, Belgium, Bosnia, Bulgaria, Croatia, Cyprus,
Czech Republic, Denmark, Finland, France, Germany, Greece,
Hungary, Italy, Macedonia, Netherlands, Norway, Poland, Portugal,
Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, UK.
Click this link to open an animation about replacing a toner cartridge.
c. Region B: India.
d. Region C: China.
To replace a toner cartridge see "Replacing the toner cartridge" on page 53.
Depending on the options and job mode used, the toner cartridge’s
lifespan may differ.
When the toner cartridge reaches its estimated cartridge life.
• The Samsung Printer Status (or Smart Panel) program window appears
on the computer telling you the toner cartridge needs to be replaced.
• The machine stops printing.
At this stage, the toner cartridge needs to be replaced. Check the type of the
toner cartridge for your machine. (See "Available supplies" on page 53.)
When purchasing new toner cartridges or other supplies, these must
be purchased in the same country as the machine you are using.
Otherwise, new toner cartridges or other supplies will be incompatible
with your machine due to different configurations of toner cartridges
and other supplies according to the specific country conditions.
Supplies_ 53
Tabs on the sides of the cartridge and corresponding grooves within the
machine will guide the cartridge into the correct position until it locks into
place completely.
1. Open the front cover.
2. Pull the toner cartridge out.
3. Take a new toner cartridge out of its package.
4. Remove the paper protecting the toner cartridge by pulling the packing
tape.
8. Close the front cover. Make sure that the cover is securely closed.
5. Locate the sealing tape at the end of the toner cartridge. Carefully pull
the tape completely out of the cartridge and discard it.
•
The sealing tape should be longer than 60 cm when correctly
removed.
• Holding the toner cartridge, pull the sealing tape straight to
remove it from the cartridge. Be careful not to cut the tape. If
this happens, you cannot use the toner cartridge.
• Refer to the helpful pictures on the cartridge wrapping paper.
6. Slowly shake the cartridge five or six times to distribute the toner evenly
inside the cartridge. It will assure maximum copies per cartridge.
If toner gets on your clothing, wipe it off with a dry cloth and wash
clothing in cold water. Hot water sets toner into fabric.
Do not touch the green underside of the toner cartridge. Use the
handle on the cartridge to avoid touching this area.
7. Hold the toner cartridge by the handle and slowly insert the cartridge into
the opening in the machine.
Supplies_ 54
If the output tray is closed, open the output tray.
specifications
10.
This chapter guides you about this machine’s specifications.
This chapter include:
•
•
•
•
Hardware specifications
Environmental specifications
Electrical specifications
Print media specifications
The specification values listed below are subject to change without notice. See www.samsung.com/printer for possible changes in information.
Hardware specifications
Item
Dimension
Weight
Description
Height
197 mm (7.76 inches)
Depth
389 mm (15.31 inches)
Width
358 mm (14.09 inches)
Machine with consumables
7.24 Kg (15.96 Ibs)
Environmental specifications
Item
Noise Levela
Temperature
Humidity
Description
Ready mode
26 dB(A)
Printing mode
53 dB(A)
Operation
10 to 32 °C (50 to 90 °F)
Storage (unpacked)
0 to 40 °C (32 to 104 °F)
Operation
20 to 80% RH
Storage (unpacked)
10 to 80% RH
a. Sound Pressure Level, ISO 7779. Configuration tested: machine basic installation, A4 paper, simplex printing.
Electrical specifications
Power requirements are based on the country/region where the device is sold. Do not convert operating voltages. Doing so might damage the device and
void the product warranty.
Item
Power ratinga
Power consumption
Description
110 volt models
AC 110 - 127 V
220 volt models
AC 220 - 240 V
Average operating mode
Less than 360 W
Ready mode
Less than 60 W
Power save mode
Less than 5.0 W
Power off mode
Less than 0.5 W
Specifications_ 55
a. See the rating label on the machine for the correct voltage, frequency (hertz) and type of current for your machine.
Specifications_ 56
Print media specifications
Type
Size
Print media weighta/Capacityb
Dimensions
Tray1
Plain paper
Letter
216 x 279 mm (8.50 x 11.00 inches)
Manual tray
60 to 90 g/m2 (16 to 24 lb bond)
•
2
250 sheets of 80 g/m (20 lb
bond)
Legal
216 x 356 mm (8.50 x 14.00 inches)
US Folio
216 x 330 mm (8.50 x 13.00 inches)
A4
210 x 297 mm (8.27 x 11.69 inches)
Oficio
216 x 343 mm (8.50 x 13.50 inches)
JIS B5
182 x 257 mm (7.17 x 10.12 inches)
60 to 90 g/m2 (16 to 24 lb bond)
ISO B5
176 x 250 mm (6.93 x 9.84 inches)
•
Executive
184 x 267 mm (7.25 x 0 inches)
A5
148 x 210 mm (5.83 x 8.27 inches)
A6
105 x 148 mm (4.13 x 5.83 inches)
Envelope Monarch
98 x 191 mm (3.87 x 7.50 inches)
Envelope No. 10
105 x 241 mm (4.12 x 9.50 inches)
Envelope DL
110 x 220 mm (4.33 x 8.66 inches)
Envelope C5
162 x 229 mm (6.38 x 9.02 inches)
Envelope C6
114 x 162 mm (4.49 x 6.38 inches)
Thick paper
Refer to the Plain
paper section
Thin paper
Envelope
60 to 220 g/m2 (16 to 43 lb bond)
• 1 sheet stacking
150 sheets of 80 g/m2 (20 lb
bond)
Not available in tray1.
75 to 90 g/m2 (20 to 24 lb bond)
• 1 sheet stacking
Refer to the Plain paper section
90 g/m2 (24 lb bond)
90 g/m2 (24 lb bond)
• 1 sheet stacking
Refer to the Plain
paper section
Refer to the Plain paper section
60 to 70 g/m2 (16 to 19 lb bond)
60 to 70 g/m2 (16 to 19 lb bond)
• 1 sheet stacking
Transparency
Refer to the Plain
paper section
Refer to the Plain paper section
Not available in tray1.
138 to 146 g/m2 (36.81 to 38.91
lb bond)
• 1 sheet stacking
Labelsc
Letter, Legal, US
Folio, A4, JIS B5, ISO
B5, Executive, A5,
Statement
Refer to the Plain paper section
Not available in tray1.
120 to 150 g/m2 (32 to 40 lb
bond)
• 1 sheet stacking
Card stock
Letter, Legal, US
Folio, A4, JIS B5, ISO
B5, Executive, A5,
Statement, PostCard
4x6
Refer to the Plain paper section
Not available in tray1.
105 to 163 g/m2 ( 28 to 43 lb
bond)
• 1 sheet stacking
Minimum size (custom)
76 x 127 mm (3.00 x 5.00 inches)
60 to 163 g/m2 (16 to 43 lb bond)
Maximum size (custom)
216 x 356 mm (8.50 x 14.02 inches)
a. If media weight is over 120 g/m2 (32 lb), load a paper into the tray one by one.
b. Maximum capacity may differ depending on media weight, thickness and environmental conditions.
c. Smoothness: 100 to 250 (sheffield).
Specifications_ 57
contact samsung worldwide
If you have any comments or questions regarding Samsung products, contact the Samsung customer care center.
Country/Region
Customer Care Center
Web Site
ALBANIA
42 27 5755
ARGENTINE
0800-333-3733
ARMENIA
0-800-05-555
AUSTRALIA
1300 362 603
www.samsung.com
AUSTRIA
0810-SAMSUNG (7267864, € 0.07/min)
www.samsung.com
AZERBAIJAN
088-55-55-555
BAHRAIN
8000-4726
BELARUS
810-800-500-55-500
BELGIUM
02-201-24-18
BOSNIA
05 133 1999
BRAZIL
0800-124-421
4004-0000
www.samsung.com
BULGARIA
07001 33 11
www.samsung.com
CANADA
1-800-SAMSUNG (726-7864)
www.samsung.com
CHILE
800-SAMSUNG (726-7864)
www.samsung.com
CHINA
400-810-5858
www.samsung.com
COLOMBIA
01-8000112112
www.samsung.com
COSTA RICA
0-800-507-7267
www.samsung.com
CROATIA
062 SAMSUNG (062 726 7864)
www.samsung.com
CZECH REPUBLIC
800-SAMSUNG (800-726786)
www.samsung.com
www.samsung.com
www.samsung.com
www.samsung.com/be (Dutch)
www.samsung.com/be_fr (French)
Samsung Zrt., česká organizační složka, Oasis Florenc, Sokolovská394/17, 180 00, Praha 8
DENMARK
70 70 19 70
www.samsung.com
DOMINICA
1-800-751-2676
www.samsung.com
ECUADOR
1-800-10-7267
www.samsung.com
EGYPT
0800-726786
www.samsung.com
EIRE
0818 717100
www.samsung.com
EL SALVADOR
800-6225
www.samsung.com
ESTONIA
800-7267
www.samsung.com
FINLAND
030-6227 515
www.samsung.com
FRANCE
01 48 63 00 00
www.samsung.com
GERMANY
01805 - SAMSUNG (726-7864 € 0,14/min)
www.samsung.com
GEORGIA
8-800-555-555
Contact SAMSUNG worldwide_ 68
Country/Region
Customer Care Center
Web Site
GREECE
IT and Mobile : 80111-SAMSUNG (80111 7267864) from land line, local charge/
from mobile, 210 6897691
Cameras, Camcorders, Televisions and Household Appliances
From mobile and fixed 2106293100
www.samsung.com
GUATEMALA
1-800-299-0013
www.samsung.com
HONDURAS
800-27919267
www.samsung.com
HONG KONG
(852) 3698-4698
www.samsung.com/hk
www.samsung.com/hk_en/
HUNGARY
06-80-SAMSUNG (726-7864)
www.samsung.com
INDIA
3030 8282
1800 3000 8282
www.samsung.com
INDONESIA
0800-112-8888
021-5699-7777
www.samsung.com
IRAN
021-8255
www.samsung.com
ITALY
800-SAMSUNG (726-7864)
www.samsung.com
JAMAICA
1-800-234-7267
www.samsung.com
JAPAN
0120-327-527
www.samsung.com
JORDAN
800-22273
www.samsung.com
KAZAKHSTAN
8-10-800-500-55-500 (GSM:7799)
www.samsung.com
KOSOVO
+381 0113216899
KUWAIT
183-2255
www.samsung.com
KYRGYZSTAN
00-800-500-55-500
www.samsung.com
LATVIA
8000-7267
www.samsung.com
LITHUANIA
8-800-77777
www.samsung.com
LUXEMBURG
261 03 710
www.samsung.com
MALAYSIA
1800-88-9999
www.samsung.com
MACEDONIA
023 207 777
MEXICO
01-800-SAMSUNG (726-7864)
MOLDOVA
00-800-500-55-500
MONTENEGRO
020 405 888
MOROCCO
080 100 2255
www.samsung.com
NIGERIA
080-SAMSUNG(726-7864)
www.samsung.com
NETHERLANDS
0900-SAMSUNG (0900-7267864) (€ 0,10/min)
www.samsung.com
NEW ZEALAND
0800 SAMSUNG (0800 726 786)
www.samsung.com
NICARAGUA
00-1800-5077267
www.samsung.com
NORWAY
815-56 480
www.samsung.com
OMAN
800-SAMSUNG (726-7864)
www.samsung.com
PANAMA
800-7267
www.samsung.com
PERU
0-800-777-08
www.samsung.com
Contact SAMSUNG worldwide_ 69
www.samsung.com
Country/Region
Customer Care Center
Web Site
PHILIPPINES
1800-10-SAMSUNG (726-7864)
1-800-3-SAMSUNG (726-7864)
1-800-8-SAMSUNG (726-7864)
02-5805777
www.samsung.com
POLAND
0 801 1SAMSUNG (172678)
022-607-93-33
www.samsung.com
PORTUGAL
80820-SAMSUNG (726-7864)
www.samsung.com
PUERTO RICO
1-800-682-3180
www.samsung.com
RUMANIA
08010 SAMSUNG (08010 726 7864) only from landline, local network
Romtelecom - local tariff /
021 206 01 10 for landline and mobile, normal tariff.
www.samsung.com
RUSSIA
8-800-555-55-55
www.samsung.com
SAUDI ARABIA
9200-21230
www.samsung.com
SERBIA
0700 SAMSUNG (0700 726 7864)
www.samsung.com
SINGAPORE
1800-SAMSUNG (726-7864)
www.samsung.com
SLOVAKIA
0800-SAMSUNG (726-7864)
www.samsung.com
SOUTH AFRICA
0860 SAMSUNG (726-7864)
www.samsung.com
SPAIN
902-1-SAMSUNG(902 172 678)
www.samsung.com
SWEDEN
0771 726 7864 (SAMSUNG)
www.samsung.com
SWITZERLAND
0848-SAMSUNG (7267864, CHF 0.08/min)
www.samsung.com/ch
www.samsung.com/ch_fr/
TADJIKISTAN
8-10-800-500-55-500
www.samsung.com
TAIWAN
0800-329-999
www.samsung.com
THAILAND
1800-29-3232
02-689-3232
www.samsung.com
TRINIDAD & TOBAGO
1-800-SAMSUNG (726-7864)
www.samsung.com
TURKEY
444 77 11
www.samsung.com
U.A.E
800-SAMSUNG (726-7864)
www.samsung.com
U.K
0330 SAMSUNG (726-7864)
www.samsung.com
U.S.A
1-800-SAMSUNG (726-7864)
www.samsung.com
UKRAINE
0-800-502-000
www.samsung.com/ua
www.samsung.com/ua_ru
UZBEKISTAN
8-10-800-500-55-500
www.samsung.com
VENEZUELA
0-800-100-5303
www.samsung.com
VIETNAM
1 800 588 889
www.samsung.com
Contact SAMSUNG worldwide_ 70
glossary
The following glossary helps you get familiar with the product by
understanding the terminologies commonly used with printing as well
as mentioned in this user’s guide.
client. BOOTP enables 'diskless workstation' computers to obtain an IP
address prior to loading any advanced operating system.
CCD
802.11
Charge Coupled Device (CCD) is a hardware which enables the scan
job. CCD Locking mechanism is also used to hold the CCD module to
prevent any damage when you move the machine.
802.11 is a set of standards for wireless local area network (WLAN)
communication, developed by the IEEE LAN/MAN Standards
Committee (IEEE 802).
Collation
802.11b/g/n
802.11b/g/n can share same hardware and use the 2.4 GHz band.
802.11b supports bandwidth up to 11 Mbps, 802.11n supports
bandwidth up to 150 Mbps. 802.11b/g/n devices may occasionally suffer
interference from microwave ovens, cordless telephones, and Bluetooth
devices.
Access point
Access Point or Wireless Access Point (AP or WAP) is a device that
connects wireless communication devices together on wireless local
area networks (WLAN), and acts as a central transmitter and receiver of
WLAN radio signals.
ADF
An Automatic Document Feeder (ADF) is a scanning unit that will
automatically feed an original sheet of paper so that the machine can
scan some amount of the paper at once.
Collation is a process of printing a multiple-copy job in sets. When
collation is selected, the device prints an entire set before printing
additional copies.
Control Panel
A control panel is a flat, typically vertical, area where control or
monitoring instruments are displayed. They are typically found in front of
the machine.
Coverage
It is the printing term used for a toner usage measurement on printing.
For example, 5% coverage means that an A4 sided paper has about 5%
image or text on it. So, if the paper or original has complicated images or
lots of text on it, the coverage will be higher and at the same time, a
toner usage will be as much as the coverage.
CSV
AppleTalk
AppleTalk is a proprietary suite of protocols developed by Apple, Inc for
computer networking. It was included in the original Macintosh (1984)
and is now deprecated by Apple in favor of TCP/IP networking.
Comma Separated Values (CSV). A type of file format, CSV is used to
exchange data between disparate applications. The file format, as it is
used in Microsoft Excel, has become a de facto standard throughout the
industry, even among non-Microsoft platforms.
DADF
BIT Depth
A computer graphics term describing the number of bits used to
represent the color of a single pixel in a bitmapped image. Higher color
depth gives a broader range of distinct colors. As the number of bits
increases, the number of possible colors becomes impractically large for
a color map. 1-bit color is commonly called as monochrome or black and
white.
BMP
A bitmapped graphics format used internally by the Microsoft Windows
graphics subsystem (GDI), and used commonly as a simple graphics file
format on that platform.
BOOTP
Bootstrap Protocol. A network protocol used by a network client to
obtain its IP address automatically. This is usually done in the bootstrap
process of computers or operating systems running on them. The
BOOTP servers assign the IP address from a pool of addresses to each
Glossary_ 61
A Duplex Automatic Document Feeder (DADF) is a scanning unit that
will automatically feed and turn over an original sheet of paper so that
the machine can scan on both sides of the paper.
Default
The value or setting that is in effect when taking a printer out of its box
state, reset, or initialized.
DHCP
A Dynamic Host Configuration Protocol (DHCP) is a client-server
networking protocol. A DHCP server provides configuration parameters
specific to the DHCP client host requesting, generally, information
required by the client host to participate on an IP network. DHCP also
provides a mechanism for allocation of IP addresses to client hosts.
DIMM
Dual Inline Memory Module (DIMM), a small circuit board that holds
memory. DIMM stores all the data within the machine like printing data,
received fax data.
Emulation focuses on exact reproduction of external behavior, which is
in contrast to simulation, which concerns an abstract model of the
system being simulated, often considering its internal state.
Ethernet
DLNA
The Digital Living Network Alliance (DLNA) is a standard that allows
devices on a home network to share information with each other across
the network.
DNS
The Domain Name Server (DNS) is a system that stores information
associated with domain names in a distributed database on networks,
such as the Internet.
Ethernet is a frame-based computer networking technology for local
area networks (LANs). It defines wiring and signaling for the physical
layer, and frame formats and protocols for the media access control
(MAC)/data link layer of the OSI model. Ethernet is mostly standardized
as IEEE 802.3. It has become the most widespread LAN technology in
use during the 1990s to the present.
EtherTalk
A suite of protocols developed by Apple Computer for computer
networking. It was included in the original Macintosh (1984) and is now
deprecated by Apple in favor of TCP/IP networking.
Dot Matrix Printer
A dot matrix printer refers to a type of computer printer with a print head
that runs back and forth on the page and prints by impact, striking an
ink-soaked cloth ribbon against the paper, much like a typewriter.
DPI
Dots Per Inch (DPI) is a measurement of resolution that is used for
scanning and printing. Generally, higher DPI results in a higher
resolution, more visible detail in the image, and a larger file size.
FDI
Foreign Device Interface (FDI) is a card installed inside the machine to
allow a third party device such as a coin operated device or a card
reader. Those devices allow the pay-for-print service on your machine.
FTP
A File Transfer Protocol (FTP) is a commonly used protocol for
exchanging files over any network that supports the TCP/IP protocol
(such as the Internet or an intranet).
DRPD
Distinctive Ring Pattern Detection. Distinctive Ring is a telephone
company service which enables a user to use a single telephone line to
answer several different telephone numbers.
Duplex
A mechanism that will automatically turn over a sheet of paper so that
the machine can print (or scan) on both sides of the paper. A printer
equipped with a Duplex Unit can print on both sides of paper during one
print cycle.
Duty Cycle
Duty cycle is the page quantity which does not affect printer
performance for a month. Generally the printer has the lifespan limitation
such as pages per year. The lifespan means the average capacity of
print-outs, usually within the warranty period. For example, if the duty
cycle is 48,000 pages per month assuming 20 working days, a printer
limits 2,400 pages a day.
Fuser Unit
The part of a laser printer that fuses the toner onto the print media. It
consists of a heat roller and a pressure roller. After toner is transferred
onto the paper, the fuser unit applies heat and pressure to ensure that
the toner stays on the paper permanently, which is why paper is warm
when it comes out of a laser printer.
Gateway
A connection between computer networks, or between a computer
network and a telephone line. It is very popular, as it is a computer or a
network that allows access to another computer or network.
Grayscale
A shades of gray that represent light and dark portions of an image
when color images are converted to grayscale; colors are represented
by various shades of gray.
Halftone
ECM
Error Correction Mode (ECM) is an optional transmission mode built into
Class 1 fax machines or fax modems. It automatically detects and
corrects errors in the fax transmission process that are sometimes
caused by telephone line noise.
An image type that simulates grayscale by varying the number of dots.
Highly colored areas consist of a large number of dots, while lighter
areas consist of a smaller number of dots.
Mass storage device
Emulation
Emulation is a technique of one machine obtaining the same results as
another.
An emulator duplicates the functions of one system with a different
system, so that the second system behaves like the first system.
Glossary_ 62
Mass storage device, commonly referred to as a hard drive or hard disk,
is a non-volatile storage device which stores digitally-encoded data on
rapidly rotating platters with magnetic surfaces.
IEEE
The Institute of Electrical and Electronics Engineers (IEEE) is an
international non-profit, professional organization for the advancement
of technology related to electricity.
arrangements between different countries to allow international phone
calls. A -T out of ITU-T indicates telecommunication.
ITU-T No. 1 chart
Standardized test chart published by ITU-T for document facsimile
transmissions.
IEEE 1284
The 1284 parallel port standard was developed by the Institute of
Electrical and Electronics Engineers (IEEE). The term "1284-B" refers to
a specific connector type on the end of the parallel cable that attaches to
the peripheral (for example, a printer).
Intranet
A private network that uses Internet Protocols, network connectivity, and
possibly the public telecommunication system to securely share part of
an organization's information or operations with its employees.
Sometimes the term refers only to the most visible service, the internal
website.
IP address
An Internet Protocol (IP) address is a unique number that devices use in
order to identify and communicate with each other on a network utilizing
the Internet Protocol standard.
IPM
The Images Per Minute (IPM) is a way of measuring the speed of a
printer. An IPM rate indicates the number of single-sided sheets a printer
can complete within one minute.
IPP
The Internet Printing Protocol (IPP) defines a standard protocol for
printing as well as managing print jobs, media size, resolution, and so
forth. IPP can be used locally or over the Internet to hundreds of
printers, and also supports access control, authentication, and
encryption, making it a much more capable and secure printing solution
than older ones.
JBIG
Joint Bi-level Image Experts Group (JBIG) is an image compression
standard with no loss of accuracy or quality, which was designed for
compression of binary images, particularly for faxes, but can also be
used on other images.
JPEG
Joint Photographic Experts Group (JPEG) is a most commonly used
standard method of lossy compression for photographic images. It is the
format used for storing and transmitting photographs on the World Wide
Web.
LDAP
The Lightweight Directory Access Protocol (LDAP) is a networking
protocol for querying and modifying directory services running over
TCP/IP.
LED
A Light-Emitting Diode (LED) is a semiconductor device that indicates
the status of a machine.
LSU
LSU is a laser scanning unit that forms electric potential images on the
OPC drum by focusing a laser beam off the rotating polygon mirror then
through the lens.
MAC address
Media Access Control (MAC) address is a unique identifier associated
with a network adapter. MAC address is a unique 48-bit identifier usually
written as 12 hexadecimal characters grouped in pairs (e. g.,
00-00-0c-34-11-4e). This address is usually hard-coded into a Network
Interface Card (NIC) by its manufacturer, and used as an aid for routers
trying to locate machines on large networks.
IPX/SPX
IPX/SPX stands for Internet Packet Exchange/Sequenced Packet
Exchange. It is a networking protocol used by the Novell NetWare
operating systems. IPX and SPX both provide connection services
similar to TCP/IP, with the IPX protocol having similarities to IP, and
SPX having similarities to TCP. IPX/SPX was primarily designed for
local area networks (LANs), and is a very efficient protocol for this
purpose (typically its performance exceeds that of TCP/IP on a LAN).
MFP
Multi Function Peripheral (MFP) is an office machine that includes the
following functionality in one physical body, so as to have a printer, a
copier, a fax, a scanner and etc.
ISO
The International Organization for Standardization (ISO) is an
international standard-setting body composed of representatives from
national standards bodies. It produces world-wide industrial and
commercial standards.
MH
ITU-T
The International Telecommunication Union is an international
organization established to standardize and regulate international radio
and telecommunications. Its main tasks include standardization,
allocation of the radio spectrum, and organizing interconnection
Glossary_ 63
Modified Huffman (MH) is a compression method for decreasing the
amount of data that needs to be transmitted between the fax machines
to transfer the image recommended by ITU-T T.4. MH is a
codebook-based run-length encoding scheme optimized to efficiently
compress white space. As most faxes consist mostly of white space, this
minimizes the transmission time of most faxes.
MMR
PDF
Modified Modified READ (MMR) is a compression method
recommended by ITU-T T.6.
Portable Document Format (PDF) is a proprietary file format developed
by Adobe Systems for representing two dimensional documents in a
device independent and resolution independent format.
Modem
PostScript
A device that modulates a carrier signal to encode digital information,
and also demodulates such a carrier signal to decode transmitted
information.
PostScript (PS) is a page description language and programming
language used primarily in the electronic and desktop publishing areas. that is run in an interpreter to generate an image.
MR
Modified Read (MR) is a compression method recommended by ITU-T
T.4. MR encodes the first scanned line using MH. The next line is
compared to the first, the differences determined, and then the
differences are encoded and transmitted.
Printer Driver
A program used to send commands and transfer data from the computer
to the printer.
Print Media
NetWare
The media like paper, envelopes, labels, and transparencies which can
be used in a printer, a scanner, a fax or, a copier.
A network operating system developed by Novell, Inc. It initially used
cooperative multitasking to run various services on a PC, and the
network protocols were based on the archetypal Xerox XNS stack.
Today NetWare supports TCP/IP as well as IPX/SPX.
PPM
OPC
Organic Photo Conductor (OPC) is a mechanism that makes a virtual
image for print using a laser beam emitted from a laser printer, and it is
usually green or rust colored and has a cylinder shape.
An imaging unit containing a drum slowly wears the drum surface by its
usage in the printer, and it should be replaced appropriately since it gets
worn from contact with the cartridge development brush, cleaning
mechanism, and paper.
Pages Per Minute (PPM) is a method of measurement for determining
how fast a printer works, meaning the number of pages a printer can
produce in one minute.
PRN file
An interface for a device driver, this allows software to interact with the
device driver using standard input/output system calls, which simplifies
many tasks.
Protocol
Originals
The first example of something, such as a document, photograph or text,
etc, which is copied, reproduced or translated to produce others, but
which is not itself copied or derived from something else.
A convention or standard that controls or enables the connection,
communication, and data transfer between two computing endpoints.
PS
See PostScript.
OSI
Open Systems Interconnection (OSI) is a model developed by the
International Organization for Standardization (ISO) for communications.
OSI offers a standard, modular approach to network design that divides
the required set of complex functions into manageable, self-contained,
functional layers. The layers are, from top to bottom, Application,
Presentation, Session, Transport, Network, Data Link and Physical.
PSTN
The Public-Switched Telephone Network (PSTN) is the network of the
world's public circuit-switched telephone networks which, on industrial
premises, is usually routed through the switchboard.
RADIUS
PABX
A private automatic branch exchange (PABX) is an automatic telephone
switching system within a private enterprise.
PCL
Printer Command Language (PCL) is a Page Description Language
(PDL) developed by HP as a printer protocol and has become an
industry standard. Originally developed for early inkjet printers, PCL has
been released in varying levels for thermal, dot matrix printer, and laser
printers.
Remote Authentication Dial In User Service (RADIUS) is a protocol for
remote user authentication and accounting. RADIUS enables
centralized management of authentication data such as usernames and
passwords using an AAA (authentication, authorization, and accounting)
concept to manage network access.
Resolution
The sharpness of an image, measured in Dots Per Inch (DPI). The
higher the dpi, the greater the resolution.
SMB
Server Message Block (SMB) is a network protocol mainly applied to
share files, printers, serial ports, and miscellaneous communications
Glossary_ 64
UNC Path
between nodes on a network. It also provides an authenticated
Inter-process communication mechanism.
Uniform Naming Convention (UNC) is a standard way to access network
shares in Window NT and other Microsoft products. The format of a
UNC path is: \\<servername>\<sharename>\<Additional directory>
SMTP
Simple Mail Transfer Protocol (SMTP) is the standard for e-mail
transmissions across the Internet. SMTP is a relatively simple,
text-based protocol, where one or more recipients of a message are
specified, and then the message text is transferred. It is a client-server
protocol, where the client transmits an email message to the server.
URL
Uniform Resource Locator (URL) is the global address of documents
and resources on the Internet. The first part of the address indicates
what protocol to use, the second part specifies the IP address or the
domain name where the resource is located.
SSID
Service Set Identifier (SSID) is a name of a wireless local area network
(WLAN). All wireless devices in a WLAN use the same SSID in order to
communicate with each other. The SSIDs are case-sensitive and have a
maximum length of 32 characters.
USB
Universal Serial Bus (USB) is a standard that was developed by the
USB Implementers Forum, Inc., to connect computers and peripherals.
Unlike the parallel port, USB is designed to concurrently connect a
single computer USB port to multiple peripherals.
Subnet Mask
The subnet mask is used in conjunction with the network address to
determine which part of the address is the network address and which
part is the host address.
TCP/IP
The Transmission Control Protocol (TCP) and the Internet Protocol (IP);
the set of communications protocols that implement the protocol stack
on which the Internet and most commercial networks run.
Watermark
A watermark is a recognizable image or pattern in paper that appears
lighter when viewed by transmitted light. Watermarks were first
introduced in Bologna, Italy in 1282; they have been used by
papermakers to identify their product, and also on postage stamps,
currency, and other government documents to discourage
counterfeiting.
WEP
Wired Equivalent Privacy (WEP) is a security protocol specified in IEEE
802.11 to provide the same level of security as that of a wired LAN. WEP
provides security by encrypting data over radio so that it is protected as
it is transmitted from one end point to another.
TCR
Transmission Confirmation Report (TCR) provides details of each
transmission such as job status, transmission result and number of
pages sent. This report can be set to print after each job or only after
failed transmissions.
WIA
TIFF
Tagged Image File Format (TIFF) is a variable-resolution bitmapped
image format. TIFF describes image data that typically come from
scanners. TIFF images make use of tags, keywords defining the
characteristics of the image that is included in the file. This flexible and
platform-independent format can be used for pictures that have been
made by various image processing applications.
Toner Cartridge
A kind of bottle or container used in a machine like a printer which
contains toner. Toner is a powder used in laser printers and
photocopiers, which forms the text and images on the printed paper.
Toner can be fused by by a combination of heat/pressure from the fuser,
causing it to bind to the fibers in the paper.
TWAIN
An industry standard for scanners and software. By using a
TWAIN-compliant scanner with a TWAIN-compliant program, a scan can
be initiated from within the program. It is an image capture API for
Microsoft Windows and Apple Macintosh operating systems.
Glossary_ 65
Windows Imaging Architecture (WIA) is an imaging architecture that is
originally introduced in Windows Me and Windows XP. A scan can be
initiated from within these operating systems by using a WIA-compliant
scanner.
WPA
Wi-Fi Protected Access (WPA) is a class of systems to secure wireless
(Wi-Fi) computer networks, which was created to improve upon the
security features of WEP.
WPA-PSK
WPA-PSK (WPA Pre-Shared Key) is special mode of WPA for small
business or home users. A shared key, or password, is configured in the
wireless access point (WAP) and any wireless laptop or desktop
devices. WPA-PSK generates a unique key for each session between a
wireless client and the associated WAP for more advanced security.
WPS
The Wi-Fi Protected Setup (WPS) is a standard for establishing a
wireless home network. If your wireless access point supports WPS, you
can configure the wireless network connection easily without a
computer.
XPS
XML Paper Specification (XPS) is a specification for a Page Description
Language (PDL) and a new document format, which has benefits for
portable document and electronic document, developed by Microsoft. It
is an XML-based specification, based on a new print path and a
vector-based device-independent document format.
Glossary_ 66
