Food Processor Stainless Steel Cutter Mixer - 11.5 LT

Food Processor Stainless Steel Cutter Mixer - 11.5 LT
ITEM #
MODEL #
NAME #
Food Processor
Stainless Steel Cutter Mixer 11.5 LT - 2 Speed Smooth blade
SIS #
AIA #
Main Features
Construction
Food Processor
Stainless Steel Cutter Mixer - 11.5 LT - 2
Speed Smooth blade
603460 (DK120F4)
Stainless Steel Cutter Mixer 11.5 LT - 2 Speed, smooth
blade - 400-415V/3/50
Short Form Specification
• 304 AISI stainless steel bowl with leak resistant
spout and watertight seal and handles.
• 2 speeds: 1500 and 3000 rpm.
• Power: 2200 watts.
• IP65 touch button control panel.
• Transparent polycarbonate cover incorporates a
magnetic contact safety system.
Included Accessories
Item No.
Cutter-mixer for mixing and mincing. 11,5 litre capacity 304 AISI
stainless steel bowl and base hinged transparent polycarbonate cover
with a watertight seal. Lid central opening allows products to be added in
mid-cycle. Angled blades and conical base of the bowl ensure consistent
mixing. Parts in contact with food are removable and dw safe. Magnetic
control device stops the machine from working if the cover or the bowl
are not correctly positioned. A safety device stops the machine restarting
after a power cut, until the operator presses the start button. Touch
button control panel. Smooth blade rotor. Two speed rotation: 1500 and
3000 rpm and pulse function. The touch button control panel has IP65
protection with low voltage level.
• 1 of Smooth blade rotor for 11,5 lt cutter PNC 653179
mixer
• 1 of Stainless steel bowl for 11,5 lt cutter PNC 653270
mixer
Optional Accessories
• Stainless steel mobile stand. Height: 730 PNC 653017 ❑
mm
• Smooth blade rotor for 11,5 lt cutter mixer PNC 653179 ❑
• Stainless steel bowl for 11,5 lt cutter mixer PNC 653270 ❑
• Serrated blade rotor for 11,5 lt cutter mixerPNC 653299 ❑
• Serrated blade rotor for meat for 11,5 lt PNC 653538 ❑
cutter mixer
APPROVAL:
Dito Sama
www.ditosama.com
Food Processor
Stainless Steel Cutter Mixer - 11.5 LT - 2 Speed Smooth blade
• Cutter-mixer allows fast liquidizing, mixing, mincing,
chopping and pastry-making.
• Delivered with:
-11.5 liter stainless steel bowl with smooth edge “S”
blade included.
• Large central rotating shaft that allows liquids to be
mixed without overflowing.
• Angled blades and conical base of the bowl ensure
consistent mixing.
• Lid with opening to add ingredients in mid-cycle.
• Base fixed cover for a better handling.
• All parts in contact with food are removable without
the use of tools, completely dismountable and
dishwasher safe.
• Pulse function to coarse chopping.
• Productivity suitable for 100-200 meals per service.
Food Processor
Stainless Steel Cutter Mixer 11.5 LT - 2 Speed Smooth blade
Front
Electric
Supply voltage:
603460 (DK120F4)
Connected load:
Total Watts:
400...415 V/3 ph/50 Hz
2.2 kW
2.2 kW
Capacity:
Performance (up to):
Capacity:
6 - kg/Cycle
11.5 liter
Key Information:
Top
External dimensions, Height:
External dimensions, Width:
External dimensions, Depth:
Shipping weight:
517 mm
416 mm
680 mm
70 kg
EI = Electrical connection
Side
Food Processor
Stainless Steel Cutter Mixer - 11.5 LT - 2 Speed Smooth blade
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
2013.01.07
