Lenovo ThinkServer TS430 044111G Tower Server
Xeon E3 (1220) 3.1GHz 4GB (1x4GB) DVD±RW LAN
(Black)
The ThinkServer TS430 combines latest Intel performance, legendary Think quality and powerful manageability tools
to deliver a feature-rich, scalable and highly reliable server solution for Managed Solution Providers (MSPs),
branch offices and small businesses. Combining sophisticated SAS RAID, up to 8 hot swap drives and redundant power
choices, the TS430 offers small businesses a scalable tower solution with plenty of room to grow. Its powerful IPMI
2.0-compliant ThinkServer Management Module with available iKVM allows MSPs to remotely and cost effectively manage
end user environments. An expansive options and services portfolio make it easy to customize the perfect TS430 for
your needs. Choose from an extensive array of hard drive choices, memory, RDX solutions and RAID protection - all
ThinkServer tested and proven. TS430 offers feature-rich performance in an Energy Star-certified, whisper-quiet
compact tower chassis - perfect for retail or back office applications.
Warranty
Three years, on-site.
Barcode
5052181487496
Processor
Intel Xeon (Quad Core) E3 (1220) 3.1GHz 8MB (L3 Cache)
Processors (Max)
1 (1)
Dimensions
19.5cm (W) x 43.0cm (D) x 59.5cm (H) - Weight 25.0kg
Memory (Maximum)
4GB (32GB) 1333MHz DDR3
Hard Disk
0GB
Optical Drive Type
DVDRW
Network Card
Ethernet 10/100/1000MBps
Operating Systems Supported
Windows Server 2008 R2 (Foundations, Standard Edition) Windows
Small Business Server 2011 (Essentials, Standard, Premium
Add-On), SLES 11.1, RedHat 6.0 VMWare ESX/ESXi 4.0, 4.1
Features
* Lenovo ThinkServer TS430 Tower
* Intel Xeon Quad Core E3 (1220) 3.1GHz Processor with 1333MHz FSB and 8MB L3 Cache
* 4GB (1x4GB) 1333MHz DDR3 UDIMM
* DVD±RW Drive
* Integrated Dual Gigabit Ethernet
* 8 x 3.5-inch HS SAS/SATA HDD support
* SubSystem LED Indicators
(c)2011 Memory Express Ltd and Openrange. E&OE; Page 1
Memory Express Ltd
51 Park Royal Road,
London,
NW10 7LQ
Tel: 020 8453 9700
Web: www.memory-express.co.uk
Email: [email protected]
Lenovo ThinkServer TS430 044111G Tower Server
Xeon E3 (1220) 3.1GHz 4GB (1x4GB) DVD±RW LAN
(Black)
* 420W Redundant Power Supply
* Three years, on-site warranty
Specification
General
The ThinkServer TS430 combines latest Intel performance, legendary Think quality and powerful manageability tools
to deliver a feature-rich, scalable and highly reliable server solution for Managed Solution Providers (MSPs),
branch offices and small businesses. Combining sophisticated SAS RAID, up to 8 hot swap drives and redundant power
choices, the TS430 offers small businesses a scalable tower solution with plenty of room to grow. Its powerful IPMI
2.0-compliant ThinkServer Management Module with available iKVM allows MSPs to remotely and cost effectively manage
end user environments. An expansive options and services portfolio make it easy to customize the perfect TS430 for
your needs. Choose from an extensive array of hard drive choices, memory, RDX solutions and RAID protection - all
ThinkServer tested and proven. TS430 offers feature-rich performance in an Energy Star-certified, whisper-quiet
compact tower chassis - perfect for retail or back office applications.
Information
We have very limited data about this product. Please contact us from more information.
General
Warranty
Three years, on-site.
Barcode
5052181487496
CPU
Processor
Intel Xeon (Quad Core) E3 (1220) 3.1GHz 8MB (L3 Cache)
CPU Bus Speed
1.333GHz
Socket
LGA1155
Processors (Max)
1 (1)
Physical
LED Status Indicators
SubSystem LED Indicators
Case Colour
Black
(c)2011 Memory Express Ltd and Openrange. E&OE; Page 2
Memory Express Ltd
51 Park Royal Road,
London,
NW10 7LQ
Tel: 020 8453 9700
Web: www.memory-express.co.uk
Email: [email protected]
Lenovo ThinkServer TS430 044111G Tower Server
Xeon E3 (1220) 3.1GHz 4GB (1x4GB) DVD±RW LAN
(Black)
Dimensions
19.5cm (W) x 43.0cm (D) x 59.5cm (H) - Weight 25.0kg
Motherboard
Chipset
C206
PCI Express Slot
2 x PCI Express x8 1 x PCI Express x4 Slots
PCI 32 bit
1 x PCI Slots
BIOS
BIOS
Flash
Memory
Memory (Maximum)
4GB (32GB) 1333MHz DDR3
Memory Slots (Free)
4 x DIMM
Storage
Hard Disk
0GB
Internal Expansion Bays
8 x SAS/SATA Hard Drive Bays
Maximum Internal Storage
16000GB
Storage: Included Array
RAID Format
RAID Level 0, 1, 5, 10
Optical Drive
Optical Drive Type
DVDRW
Interfaces/Ports
RJ-45 Ports
2 x RJ-45
VGA Port
1 x 15-pin VGA
USB Ports
6 x USB 2.0 (2 Front, 4 Rear)
Serial Ports
1 x 9-pin RS-232
Network
Network Card
(c)2011 Memory Express Ltd and Openrange. E&OE; Page 3
Ethernet 10/100/1000MBps
Memory Express Ltd
51 Park Royal Road,
London,
NW10 7LQ
Tel: 020 8453 9700
Web: www.memory-express.co.uk
Email: [email protected]
Lenovo ThinkServer TS430 044111G Tower Server
Xeon E3 (1220) 3.1GHz 4GB (1x4GB) DVD±RW LAN
(Black)
System
Management
iBMC Remote Control Management
Security
IPMI 2.0 / SOL, TPM (Supports TCG 1.2)
System Requirements
Operating Systems Supported
Windows Server 2008 R2 (Foundations, Standard Edition) Windows
Small Business Server 2011 (Essentials, Standard, Premium
Add-On), SLES 11.1, RedHat 6.0 VMWare ESX/ESXi 4.0, 4.1
Electrical
Power Supply
Redundant
Voltage/Power/Frequency
100 to 240VAC / 50 to 60Hz
Electrical Power Available
420W
(c)2011 Memory Express Ltd and Openrange. E&OE; Page 4
Memory Express Ltd
51 Park Royal Road,
London,
NW10 7LQ
Tel: 020 8453 9700
Web: www.memory-express.co.uk
Email: [email protected]
Lenovo ThinkServer TS430 044111G Tower Server
Xeon E3 (1220) 3.1GHz 4GB (1x4GB) DVD±RW LAN
(Black)
Options
Operating Systems
Lenovo
84978HA
Lenovo Microsoft Windows Server 2008 R2 Foundations ROK for
ThinkServer Systems (Includes 15 CALs)
Call us
VIEW>
Lenovo
84978KE
Lenovo Microsoft Windows Server 2008 R2 Standard ROK for
ThinkServer Systems
Call us
VIEW>
Lenovo
84978OA
Lenovo Microsoft Windows Server 2008 R2 Standard ROK for
ThinkServer Systems (Includes 5 CALs)
Call us
VIEW>
Lenovo 160GB Internal USB Bundle (RDX Backup)
£319.67
VIEW>
High capacity removable media dr
Lenovo
67Y1394
Hard Disk Drives
Lenovo
67Y2612
Lenovo (250GB) Hard Drive (7200rpm) Serial ATA 8MB
(Internal) for ThinkServer TS130
£163.67
VIEW>
Lenovo
67Y2610
Lenovo (1TB) Hard Drive (7200rpm) Serial ATA Hot Swap
(Internal) for ThinkServer TS430
£334.33
VIEW>
Controller Cards
Lenovo
0A89407
Lenovo RAID 500 Upgrade Key for Advanced RAID for
ThinkServer TS430
£150.88
VIEW>
Lenovo
0A89406
Lenovo RAID 500 Adaptor for ThinkServer TS430
£180.29
VIEW>
