PROFESSIONAL CD PLAYER

DN-C620

OPERATING INSTRUCTIONS

1. GENERAL INFORMATION

FEATURES

Standard Functions of Professional CD Player

Slot-In Disc Drive

Reads and Displays CD TEXT & MP3 ID3 Tags

Quick Track Search with Jog Wheel

Cue to Music

Balanced Audio Output with Trim

2 Sets of Unbalanced Audio Outputs (1 Fixed / 1 Variable level)

SPDIF Digital Audio Output

Plays Back Audio Files from a CD Data Disc

Reads CD-R / CD-RW discs

Supports CD-DA, WAVE, MPEG-1 Layer III (MP3)

Advanced CD Playback

Quick Replay (Skip Back) (Time programmable)

+/– 12% Variable Pitch Control

Program Play

Single, All, A-B Repeat modes

Random Play mode

User – Selectable Play Mode

(Stop, Next, Recue, Continuous, Random)

Auto Cue

End Monitor

End of Message (EOM) indicator

19-inch 1U rack space

IR Remote Control (Remote controller RC-1061 included)

External Remote Control

Serial control (RS232C)

Parallel control

RC In Control (IR FLASH)

PART NAMES AND FUNCTIONS

(1) Front panel

6 2

POWER ON/OFF

PHONES

CD PLAYER

DN-C620

EJECT

4

SHIFT

MENU/STORE DISPLAY

LOCK

1 3 5 7 8 9 0

- = ~ ! @

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON PITCH

PUSH

ENTER

# $ % ^ &

POWER ON/OFF switch and indicator

• Press this to turn the Power ON or OFF.

• The indicator lights when the power is turned on.

LEVEL control

• Use this to adjust the output level of the headphones.

Warning!

• When using headphones, take care not to turn the volume too high. Listening at high volumes for extended periods of time may result in permanent hearing damage.

PHONES Jack

• For private listening, you can connect your headphones to this jack.

DISC slot

• Insert a CD into the slot, label side upwards.

EJECT button

• Press this to eject the disc. The EJECT button is locked when Eject Lock is on in the preset menu and the unit is in PLAY mode.

2

y

Display unit

• Refer to page 5 for details.

Remote control sensor

i

SHIFT button

• Press and hold while you press other controls to activate alternate functions.

o

MENU/STORE button

• Press to enter the preset menu or to store changes in the preset menu.

! 0

DISPLAY/LOCK button

• Press this to change the time mode on the display.

• Press this button while pressing the SHIFT button to lock or unlock the controls on the front panel.

! 1

PITCH button and indicator (Amber)

• Press this button to switch the PITCH on or off.

! 2

A-B/REPEAT button

• Use this to play a set section repeatedly. When the button is pressed once during playback, that position is set as the A point and the “A-” indicator flashes on the display.

• When the button is pressed again, that position is set as the B point, the “A-B” indicator stops flashing (remaining lit), and the A-B section begins playing repeatedly.

• When the button is pressed again, A-B repeat is canceled and the mode returns to the normal play mode.

• Press this button while pressing the SHIFT button to select the repeat mode.

! 3

PLAY MODE/TEXT button

• Press this button to select the play mode.

• Press this button while pressing the SHIFT button to display the text information.

1. GENERAL INFORMATION

! 4 ! 5

5

6 / – INDEX/DIR + button

• These buttons are used to accurately change the positions where playback will start or operate as FF or FR when held down.

• Use this button while pressing the SHIFT button to select the index (Audio CDs) or directory (music file discs).

! 6

9 /CANCEL button

• Press this button to stop playback.

• Press this to cancel a selection in program setting.

• During preset setting operations, press to cancel all entries made and return to stop mode.

! 7

SKIP BACK button

• Press this button for instant replay at the currently playing audio. The amount of time skipped back is adjustable in the preset menu.

! 8

CUE button and indicator (Amber)

• When pressed during playback, the pickup returns to the position at which playback last started or the next track and the CUE mode is set.

• When pressed during manual search, the CUE mode is set at that position.

! 9

2 / ; /END MON button and indicator (Green)

• Use this button to start playback or pause playback. (play or panse button)

• Press this button while pressing the SHIFT button to start the End Monitor.

Jog wheel with PUSH/ENTER button

• Turn the jog wheel clockwise by one click to move one track forward, counterclockwise by one click to move one track backward.

• In the preset mode, turn the jog wheel to select the preset item and push to enter.

• Use this jog wheel while pressing the SHIFT button to set the pitch value.

• In the stop mode or in the play/pause mode, push this to start playback.

3

(3) Display

Specific Icons and Character displays inform you of the current operating status and menu items of the device.

[Basic CD Operation]

“TOTAL” illuminates to indicate that the time displayed is the TOTAL time of the track or file.

“TOTAL” can also be lit with “TRACK” in stop mode to indicate the total number of tracks or files in the current disc or directory.

“REMAIN” illuminates to indicate that the time displayed is the remaining time of the currently playing track.

“REMAIN” can also be lit with the “TOTAL” icon to indicate the TOTAL REMAINING time of the disc.

Both icons off indicates that the time displayed is the ELAPSED time of the currently playing track or file.

Lights in repeat playback mode.

Lights in random playback mode.

Light when auto cue mode is on.

Lights when program playback mode is on.

Lights when single playback mode is on.

Either of icons lights according to the play mode.

Flashing while end of message is working.

Displays the pitch control setting.

Track number /

Total number of Tracks

Index number Playing time (minute and second)

Displays various information and text message

Frame number

1. GENERAL INFORMATION

5

1. GENERAL INFORMATION

[Audio file Operation]

Lights when selected audio file is in root directory of the disc.

Lights when the audio data disc is loaded.

Lights when the sampling frequency or bitrate of the file playing is available and displayed.

Lights when the playing time is displayed in the character display.

(4) Remote control unit (RC-1061)

! 4

! 5

! 6

! 7

! 8

! 9

Track number /

Total number of Tracks

Playing time (hour, minute, second and frame number)

Displays file information, recorded time, and the other information y i o

! 0

! 1

! 2

! 3

6

POWER button

Press this to turn the power on or off.

PITCH +/– buttons

Press these buttons to adjust the Pitch up(+) or down(-).

PITCH ON/OFF button

Press this to turn the pitch control function on or off.

0-9 buttons

Press these to select the desired track in the stop mode.

DISPLAY button

Press this to change the time mode on the display.

TEXT button

Press this to display the CD Text or ID3 tag information.

y

A-B button

Press this to set or cancel the A-B repeat function.

END MON button

Press this to start the End Monitor funciton.

i

UTILITY button

This button is invalid for the DN-C620.

o

3

/ 4 / 1 / 2 buttons

Use these for menu selection and 1 / 2 for track selection.

! 0

INDEX+/– buttons

Press this to select the index (Audio CDs) or directory (Audio data discs).

! 1

STOP button

Press this to stop the playback.

! 2

SKIP BACK button

Press this for instant replay of the currently playing audio.

! 3 ∞

/ § buttons

Press these to skip from track to track or file to file.

1. GENERAL INFORMATION

! 4

EJECT button

Press this to eject the disc.

! 5

LOCK button

Press this to lock or unlock the buttons on the front panel.

! 6

RANDOM button

Press this to set the random playback mode.

! 7

PROGRAM button

Press this to enter the program mode.

! 8

RECALL button

Press this to recall the programmed track.

! 9

CANCEL button

Press this to cancel a selection in program setting.

0

REPEAT button

Press this to set repeat playback.

1

NETWORK button

This button is invalid for the DN-C620.

2

MENU/STORE button

Press this to enter the preset menu or to store changes made in the preset menu.

3

VOL+/– buttons

Press these to change the playback volume output through the unbalanced VARIABLE

Output jacks.

ENTER button

Press this to confirm selections in the menus.

2 / ; button

Press this to start playback or pause playback.

CUE button

Press this to return to the position at which playback started or the next track.

5 / 6 buttons

Press this to accurately change the positions where playback will start or operate as FF or

FR when held down.

7

3. DEVICE OPERATION

SUPPORTED AUDIO CD

In addition to standard CD-DA discs, the DN-C620 can read several other CD-DA formats.

Please refer to page 22 for detail of reading and operation of data discs.

Compact Disc Digital Audio (CD-DA)

INSERTING AND EJECTING A DISC

Inserting and Ejecting a disc is only available when the unit is powered on.

1. If the unit is OFF, press the POWER ON/OFF switch to turn on the power.

2. Hold the disc by the edges and insert it in the DISC slot.

(Do not touch the signal surface, i.e., glossy side.)

3. Press the EJECT button to eject the disc.

Compact Disc TEXT (CD TEXT)

Enhanced Music CD (CD EXTRA)

NOTE:

• Some copy-controlled CDs may not conform to official CD standards. They are special discs and may not play on the DN-C620.

PLAY

DE

Messages

Messages may appear on the display while using the DN-C620.

The meanings of the messages are explained below.

Message

No Disc

Eject Locked

Meaning

No disc is inserted.

Unit is playing and Eject lock is on in the preset menu.

CAUTIONS:

• Do not push in the disc manually when the power is off as this may cause malfunction and damage the CD player.

11

3. DEVICE OPERATION

NORMAL CD PLAYBACK

(1) Before Starting Playback

1. Press the POWER ON/OFF switch to turn on the power.

CD PLAYER

DN-C620

POWER ON/OFF

0

LEVEL

10

PHONES

EJECT

(3) Pausing playback at any point

Playback can be temporarily halted and then continued from the same point in the track.

1. Press the 2 / ; /END MON button on the front panel or the 2 / ; button on the remote control unit during playback. (Button Flashes when in PAUSE mode)

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON

PITCH

PUSH

ENTER

2. Load the disc you want to play.

3. Make sure the Preset Menu settings are set accordingly for the intended use. (See Page

25.)

2. To continue playback, press the 2 / ; /END MON button on the front panel or the 2 / ; button on the remote control unit.

(2) Starting Playback

1. Press the 2 / ; /END MON button on the front panel or the 2 / ; button on the remote control unit.

(4) Returning to the position at which playback started

Set the CUE mode to RECUE in the preset menu and press the CUE button during playback, the pickup returns to the position at which playback started and the pause mode is set.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON

PITCH

PUSH

ENTER

PITCH A-B PLAYMODE

REPEAT

CANCEL SKIP BACK

TEXT

CUE

- INDEX/DIR +

END MON PITCH

PUSH

ENTER

Press the

3 button

Press the

;

button

Play internal

Press the 3 button

Play internal

Back cue operation

Press the

CUE button

Position on the disc

(5) Stopping playback

1. Press the STOP/CANCEL button.

12

(6) Advancing to the next track during playback

1. Turn the jog wheel clockwise or press the § button during playback.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON

PITCH

PUSH

ENTER

• The pickup will advance to the beginning of the next track and playback will continue when the Start mode is set to “Play” in the preset menu.

• The pickup will advance to the beginning of the next track and remain in CUE mode when the Start mode is set to “Stop” or “Cue” in the preset menu.

(See Page 27 for Start Mode Settings)

NOTE:

• When the Next track reserve mode is set to "ON" in the preset menu, if you turn the jog

wheel during playback, the track number indication of the display will blink and you can select the track to play next.

(7) Returning to the beginning of the current track during playback

1. Turn the jog wheel counterclockwise or press the ∞ button during playback.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON

PITCH

PUSH

ENTER

3. DEVICE OPERATION

(8) Audible quick search

• Using this function, you can search for a desired point quickly within a track in the both forward or reverse direction.

• When a SEARCH button is pressed during the pause mode and the button is released, the pause mode is cancelled at that point with the sound being output.

Manual search forward

1. Press the SEARCH (6) button during playback.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON

PITCH

PUSH

ENTER

• The playback mode is cancelled, and the search point is reproduced repeatedly.

• Every time the SEARCH (6) button is pressed the playback point advances one frame.

• Playback of the track is sped up while the SEARCH (6) button is pressed.

Manual search in reverse

1. Press the SEARCH (5) button during playback.

PITCH A-B PLAYMODE

REPEAT

CANCEL SKIP BACK

TEXT

CUE

- INDEX/DIR +

END MON

PITCH

PUSH

ENTER

• The playback mode is cancelled, and the search point is reproduced repeatedly.

• Every time the SEARCH (5) button is pressed the playback point retreats one frame.

• Playback of the track is sped up while the SEARCH (5) button is pressed.

• The pickup will return to the beginning of the current track and playback will continue when the Start mode is set to “Play” in the preset menu.

• The pickup will return to the beginning of the current track and remain in CUE mode when the Start mode is set to “Stop” or “Cue” in the preset menu.

NOTE:

• When the Next track reserve mode is set to "ON" in the preset menu, if you turn the jog

wheel during playback, the track number indication of the display will blink and you can select the track to play next.

13

3. DEVICE OPERATION

(9) Index Skip

An index search can be performed during the play of a track whose index has been recorded.

This function is useful for starting play at a specific location of a long track. It returns play to a previous index which is equivalent to the number of times the INDEX – button on the unit or IR control was pressed; alternatively, it advances play to a subsequent index which is equivalent to the number of times the INDEX + button on the unit or IR control was pressed.

If the index skip function is operated for a CD with no indexes recorded, the “No Index” message appears on the main display, and play returns to the start of the track now playing.

NOTE:

• The index skip function cannot be used for discs recorded with audio files. In that instance, the index button navigate directories.

(10) Direct Jump

Select the number of the track to be played directly during the stop mode by pressing the numeric buttons (0 to 9) on the remote control unit.

To select track number 10 or above, use the numeric buttons to select the higher digit first and then select the lower digit.

The operation after the number of the track is selected depends on the start mode settings.

Example: To play track 12

1. Set the start mode to “Play”.

2. Press the “1” numeric button.

3. Within 1 second, press the “2” numeric button.

14

ADVANCED CD PLAYBACK

(1) Repeating playback of a desired interval

(Single track repeat)

1. Press the PLAY MODE/TEXT button to select “Single Stop”, “Single Next” or “Single

Recue”.

2. Press the A-B/REPEAT button on the front panel while pressing the SHIFT button.

3. DEVICE OPERATION

(All track repeat)

1. Press the PLAY MODE/TEXT button to select “Continuous”.

2. Press the A-B/REPEAT button on the front panel while pressing the SHIFT button.

• The “REPEAT 1” indicators light on the display and the single track repeat mode is set.

3. Use the select knob to select the track to be played repeatedly.

4. Press the 2 / ; /END MON button on the front panel or the 2 / ; button on the remote control unit.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON PITCH

PUSH

ENTER

• The “REPEAT” indicators light on the display and the all track repeat mode is set.

3. Press the 2 / ; /END MON button on the front panel or the 2 / ; button on the remote control unit.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON PITCH

PUSH

ENTER

• The disc is played repeatedly.

• The all track repeat mode can also be set by pressing the A-B/REPEAT button on the front panel while pressing the SHIFT button during playback.

• If the repeat function is activated during program play, the tracks are played repeatedly in the programmed order.

• To cancel the all track repeat mode, press the A-B/REPEAT button on the front panel while pressing the SHIFT button repeatedly until the “REPEAT” indicator turns off.

• Playback starts.

• Once the selected track ends, it is played again from the beginning.

• The single track repeat mode can also be set by pressing the A-B/REPEAT button on the front panel while pressing the SHIFT button during playback. The current track is played repeatedly.

• To cancel the single track repeat mode, press the A-B/REPEAT button on the front panel while pressing the SHIFT button repeatedly until the “REPEAT 1” indicator turns off.

15

3. DEVICE OPERATION

(2) Repeating playback a specific section within a track

(A-B repeat)

1. During playback, press the A-B button at the point where you want to start repeated playback (A point).

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON

PITCH

PUSH

ENTER

(3) Playing specific tracks in a specific order (Program play)

With this function, you can choose any of the tracks on the disc and program them to play in any order. Up to 99 tracks can be programmed.

Creating the program

1. Press the PROGRAM button on the remote control unit.

• The “A-” indicator flashes on the display.

2. Press the A-B button again at the point where you want to end repeated playback (B point).

• The “A-B” indicator stops flashing (remaining lit), and the A-B section begins playing repeatedly.

• If no B point is set before the current track ends, the end of the track is set as the B point.

3. To cancel A-B repeat playback, press the A-B button again.

NOTE:

• The A-B points must be separated by at least 1 seconds time to work.

• The “PGM” indicator flashes, and the program number and track number are shown on the display.

2. Press the ∞ or § button on the remote control unit to select the first track of the program.

3. Press the ENTER button on the remote control unit to select the track.

• Skip to the next desired track and press the ENTER button again.

• Repeat steps 2 and 3 to program the tracks in the desired order.

4. Press the PROGRAM button to exit the program input mode.

• “PGM” indicator lights, and the DN-C620 is ready to play your program.

16

Editing the program

1. Press the RECALL button on the remote control unit while the “PXX” is displayed.

3. DEVICE OPERATION

6. Press the PROGRAM button to exit the program edit mode.

2. Press the UP or DOWN button on the remote control unit to select the program number you want to edit.

• “PGM” indicator lights, and the DN-C620 is ready to play your program.

Playing the programs

1. Press the PLAY/PAUSE button.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON PITCH

PUSH

ENTER

3. Press the ∞ or the § button on the remote control unit to select the track of the program number.

4. Press the CANCEL button on the remote control unit to delete a track in the program.

• Program play starts.

Exit the program mode

1. Press the PROGRAM button.

• “PGM” indicator turns off.

• The program is also cleared when the EJECT button is pressed.

5. Press the ENTER button on the remote control unit to add a track.

• To enter the next track, press the ENTER button again.

• Repeat steps 2 and 3 to program the tracks in the desired order.

17

3. DEVICE OPERATION

(4) Pitch Control

Pitch Control allows the playback of audio at faster (+) or slower speeds(–).

1. Turning PITCH CONTROL On and OFF.

Press the PITCH button.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON PITCH

PUSH

ENTER

(5) Skip Back

SKIP BACK is a feature that allows instant replay of the currently playing track. When the SKIP

BACK button on the unit or SKIP BACK button on the remote control unit is pressed during playback, play will skip back by the number of seconds set in the PRESET MENU and playback will resume from that point.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON

PITCH

PUSH

ENTER

• Factory default SKIP BACK time is 10 seconds.

• For details on how to set the SKIP BACK time (See Page 28).

• The PITCH button lights up amber indicating PITCH CONTROL is ON.

• The play speed increases or decreases depending on the pitch control setting as indicated in the display.

• Press the PITCH button again to turn PITCH CONTROL Off.

• The PITCH button light turns off.

2. Adjusting the PITCH CONTROL speed.

With the unit in SHIFT mode, turn the jog wheel counterclockwise ← to reduce the Pitch and speed or turn the jog wheel clockwise

→ to increase the Pitch and speed.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON

PITCH

PUSH

ENTER

(6) End Monitor

END MONITOR is a feature that plays back the final seconds of the current track. If the Play

Mode is set to “Continuous” the DN-C620 plays back the last track of the current disc. To use this feature, press the 2/;/END MON button while pressing the SHIFT button during in CUE mode on the device or remote control unit and the unit will start playback from the position before the end of the current track as set in the PRESET MENU.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON

PITCH

PUSH

ENTER

• Factory default END MONITOR time is 10 seconds.

• For details on how to set the END MONITOR time (See Page 28).

18

(7) Play Mode

Play Mode lets you choose what happens when the end of a track is reached during playback.

Set Value

Continuous (Default)

Single Next

Single ReCue

Single Stop

Random

Description

When playback reaches the end of a track it automatically begins the next track until all tracks have been played.

The unit advances to the next track and waits in Cue Mode.

The unit returns to the beginning of the current track and waits in Cue Mode.

The unit returns to stop mode after the track has played.

The unit plays all the tracks in random sequence.

(Continuous)

1. Press the PLAY MODE/TEXT button on the front panel.

• The “Continuous” is displayed on the display and the continuous mode is set.

2. Use the select knob to select the track to be played.

3. Press the 2 / ; /END MON button on the front panel or the 2 / ; button on the remote control unit.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON

PITCH

PUSH

ENTER

• Playback starts.

• When playback reaches the end of a track it automatically begins the next track until all tracks have been played.

• After the last track ends, playback stops. The DN-C620 returns to stop mode.

3. DEVICE OPERATION

(Single Next)

1. Press the PLAY MODE/TEXT button on the front panel.

• The “Single Next” is displayed on the display and the Single Next mode is set.

2. Use the select knob to select the track to be played.

3. Press the 2 / ; /END MON button on the front panel or the 2 / ; button on the remote control unit.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON PITCH

PUSH

ENTER

• Playback starts.

• When the playback reaches the end of a track the unit advances to the next track and waits in Cue Mode.

(Single Recue)

1. Press the PLAY MODE/TEXT button on the front panel.

• The “Single Recue” is displayed on the display and the Single Recue mode is set.

2. Use the select knob to select the track to be played.

3. Press the 2 / ; /END MON button on the front panel or the 2 / ; button on the remote control unit.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON PITCH

PUSH

ENTER

• Playback starts.

• When the playback reaches the end of a track the unit returns to the beginning of the current track and waits in Cue Mode.

19

3. DEVICE OPERATION

(Single Stop)

1. Press the PLAY MODE/TEXT button on the front panel.

• The “Single Stop” is displayed on the display and the Single Stop mode is set.

2. Use the select knob to select the track to be played.

3. Press the 2 / ; /END MON button on the front panel or the 2 / ; button on the remote control unit.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON PITCH

PUSH

ENTER

• Playback starts.

• When the playback reaches the end of a track the unit returns to stop mode.

(Random)

1. Press the PLAY MODE/TEXT button on the front panel.

• The “Random” is displayed on the display and the Random playback mode is set.

2. Press the 2 / ; /END MON button on the front panel or the 2 / ; button on the remote control unit.

PITCH A-B PLAYMODE

REPEAT TEXT

CUE

CANCEL SKIP BACK

- INDEX/DIR +

END MON

PITCH

PUSH

ENTER

• Playback starts.

• The unit plays all the tracks in random sequence.

20

3. DEVICE OPERATION

PLAYING AUDIO FILES

In addition to standard CD-DA discs, the DN-C620 can read audio files from two different types of Data discs. For a list of compatible compressed and uncompressed audio files, see following section: Audio File Format Specifications.

Supported data discs

Compact Disc Recordable (CD-R)

Compact Disc ReWritable (CD-RW)

NOTE:

• The DN-C620 supports following file system for the data discs.

ISO9660 Level1 and Level2, Joliet, UDF version 1.50 and 2.00

• The DN-C620 cannot read unfinalized CD-R disc.

• The DN-C620 can only read the 1st session of a multi-session disc.

• There are the following conditions in the data discs that can be read.

– Maximum number of directories: 254

999 – Maximum number of files:

If there are more than 1,000 files, only the first 999 files are played.

– Folder layers: 8 layers, including root

• The DN-C620 does not support two byte character sets.

Audio file format specifications

The DN-C620 supports PCM, MP3 audio formats.

PCM

MP3

File Extension

wav mp3

System

16-Bit Linear PCM

ISO/IEC11172-3 MPEG1- L3

Sample Rate

48kHz, 44.1kHz, 32kHz

48kHz, 44.1kHz, 32kHz

Bit Rate

32 kbps – 320 kbps

Resolution

16-bit

16-bit

21

3. DEVICE OPERATION

Functions not supported by playing audio file

The following functions are not supported when the DN-C620 encounters discs recorded with these types of audio files.

• Index skip function is not available.

• Playback of half-rate audio files MPEG2-L3 (24 kHz, 22.05 kHz, 16 kHz) is not available.

• If an audio file includes content protection, it may not be played.

Handled audio files as “track” and playing audio file

A directory (also called a “folder”) is a hierarchical level on disc media.

After loading a data disc and searching all audio files, the DN-C620 assigns each audio file a track number.

Only the files within the selected directory will be the target of your operations, and functions such as program playback and repeat playback will all occur within the same directory.

For example in the illustration below, at first each audio file is assigned a track number.

Directory-AAA, directory-BBB and directory-DDD contain audio files and can be selected for operations, but directory-CCC is excluded from operations.

If directory-AAA is selected, CD operations such as program playback are effective only to audio files of directory-AAA, it means aaa001.mp3/track# 003 and bbb001.mp3/track# 004 are effective for operation.

ROOT (Dir01)

AAA (Dir02)

BBB (Dir03) bbb001.mp3 (Track# 004)

CCC bbb003.txt

aaa001.mp3 (Track# 003)

DDD (Dir04) ddd001.mp2 (Track# 005) rrr001.mp3 (Track# 001) rrr002.wav (Track# 002)

Displays information

When a data disc is inserted into the DN-C620, various kind of information are displayed on the 13-digit alphanumeric part of the display unit.

When in play, pause, search, end mon. or cue state, the following information is displayed in order by pressing the DISPLAY/LOCK button.

– Elapsed time

– Remaining time

– File name

– File information

: sample frequency, bit rate or resolution, and file format

(PCM, MP3)

- Recorded date

: year, month and day. [MMMDD YYY]

- Recorded time

: hour, minute and second. [HH:mm:SS]

- Channel

: “Stereo” or “Mono”

22

Text information

When a data disc with MP3 files, is inserted into the DN-C620, in addition to above information various kind of text information are displayed on the 13-digit alphanumeric part of the display unit. This information is recorded in a MP3 file as ID3 tag.

When in play, pause, search, end mon. or cue state, the following information is displayed in order by pressing the PITCH/TEXT button with the unit in SHIFT mode.

– [Above information]

– Title

– Artist

– Album

NOTE:

• Only standard ID3 information that has been accurately recorded in the file will be displayed.

3. DEVICE OPERATION

23

3. DEVICE OPERATION

(1) Playing audio files on a disc

1. Load a disc containing audio files.

• The display will change to “Loading.”. When the contents of the disc have been read, the total number of tracks will be displayed.

2. Turn the jog wheel to select a file you want to listen to.

• The file name scrolls and back to the number of track on the display.

3. Press the 2 / ; / END MON button.

(2) Advanced music files playback

The following "Advanced CD playback" functions are possible with audio files on a disc in the same way as a standard CD-DA disc.

See page 16 for detail of an operation.

Single track repeat

All track repeat

A-B repeat

Program play

Pitch control

Skip back

End monitor

(Directory skip)

1. In shift mode, press the INDEX/DIR +/– button to select a folder.

• The display will indicate each name of all folders including sub-folders.

2. Press the 2 / ; / END MON button.

• Playback will be started from the top file within the selected folder.

24

PRESET FUNCTIONS AND OPERATIONS

(1) Changing the PRESETS

[ Using the front panel ]

1. With the unit in stop mode, press the MENU/STORE button.

CD PLAYER

DN-C620

0

LEVEL

10

PHONES

EJECT

SHIFT

MENU/STORE DISPLAY

LOCK

3. DEVICE OPERATION

[ Using the remote control unit ]

1. With the unit in stop mode, press the MENU/STORE button.

The last active preset item appears on the display.

The last active preset item appears on the display.

2. Turn the jog wheel to select the preset item you wish to modify.

3. Press the jog wheel to confirm your selection.

Preset setting data appears on the display. You will now be able to edit the preset item.

For details of each preset item, see page 27.

4. Turn the jog wheel to adjust the parameters for that item.

Press the jog wheel to confirm your setting/action.

Repeat steps 2-4 as needed.

5. Press the MENU/STORE button to save changes or STOP/CANCEL button to cancel all changes and return to stop mode.

2. Press the 3 button or the 4 button to select the preset item you wish to modify.

3. Press the ENTER button to confirm your selection.

Preset setting data appears on the display. You will now be able to edit the preset item.

For details of each preset item, see page 27.

4. Press the 3 button or the 4 button to adjust the parameters for that item.

Press the ENTER button to confirm your setting/action.

Repeat steps 2-4 as needed.

5. Press the MENU/STORE button to save changes or STOP button to cancel all changes and return to stop mode.

25

5. TROUBLESHOOTING

Make sure of the followings before you consider as any malfunctions :

1. Are all the connections correct?

2. Are all system components being operated correctly in accordance with the operating instructions?

3. Are the speakers and amplifier/receiver functioning correctly?

If the Unit still does not function properly, check the symptom against the list below. If the symptom does not correspond to the check list, please contact your dealer.

Problem Cause

Disc is not ejected.

• Power operation switch is not turned on.

When a disc is loaded, “TOC Error” or "No Disc" is displayed.

• Disc is not properly loaded.

When a disc is loaded, “Disc Error” is displayed.

When the PLAY button is pressed, playback does not start.

• The disc is not properly recorded.

• Disc is dirty or scratched.

There is no sound, or it is distorted.

A specific section of the disc will not play.

Program play does not work.

Remote control is not working.

• Output cord is not properly connected.

• Amplifier adjustment is inappropriate.

• Disc is dirty or scratched.

• Program play operation has been performed improperly.

• No batteries or flat batteries.

File does not play.

• Decoding Error.

Remedy

• Turn the power operation switch on.

• Reload the disc.

• Turn the power off and on again to eject the disc.

• Clean the disc.

• Connect the output cord properly.

• Readjust the amplifier.

• Clean the disc.

• Restart Program play.

• Ensure that batteries are correctly inserted.

• Replace the batteries with a flesh set.

• Check that the file you are trying to play has a supported file extension and is a format that the DN-C620 supports.

41

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
