SyncMaster 230TSN/230MXN
LCD Display
User Manual
The color and the appearance may differ depending on the
product, and the specifications are subject to change
without prior notice to improve the performance.
Safety Instructions
Notational
Note
These safety instructions must be followed to ensure your safety and prevent property damage.
Make sure to read the instructions carefully and use the product in the correct manner.
Warning / Caution
Failure to follow directions noted by this symbol could result in bodily
harm or damage to the equipment.
Note
Prohibited
Important to read and understand at all times
Do not disassemble
Disconnect the plug from the
outlet
Do not touch
Ground to prevent an electric
shock
Power
When not used for extended period of time, set your computer to DPM.
If using a screen saver, set it to active screen mode.
The images here are for reference only, and are not applicable in all cases
(or countries).
Shortcut to Anti-Afterimage Instructions
Do not use a damaged power cord or plug or a damaged or
loose power outlet.
•
Otherwise, this may result in electric shock or fire.
Do not touch the power plug with wet hands when removing or
plugging the plug into the outlet.
•
Otherwise, this may result in electric shock.
Make sure to connect the power cord to a grounded power outlet.
•
Otherwise, it may result in electric shock or personal injury.
Safety Instructions
Ensure that the power plug is plugged into the power outlet
firmly and correctly.
•
Otherwise, this may result in fire.
Do not forcefully bend or pull the power plug and do not place
any heavy material on it.
•
Otherwise, this may result in fire.
Do not connect multiple appliances to the same power outlet.
•
Otherwise, this may cause fire due to overheating.
Do not disconnect the power cord while using the product.
•
Otherwise, this may result in damage to the product due to
electric shock.
To disconnect the apparatus from the mains, the plug must be
pulled out from the mains socket, therefore the mains plug shall
be readily operable.
•
Otherwise, this may cause electric shock or fire.
Use only the power cord provided by our company. Do not use
the provided power cord of another product.
•
Otherwise, this may result in fire or electric shock.
Installation
Be sure to contact an authorized Service Center when installing your
monitor in a location with heavy dust, high or low temperatures, high humidity, and exposed to chemical substances and where it operates for 24
hours such as at airports, train stations etc.
Failure to do so may cause serious damage to your monitor.
Do not drop the monitor when moving it.
•
This may cause damage to the product or the person carrying
it.
When installing the product in a cabinet or rack, make sure that
the front end of the bottom of the product does not project out.
•
Otherwise, it may fall or cause personal injury.
•
Use a cabinet or rack of a size appropriate to the product.
DO NOT PLACE CANDLES, MOSQUITO REPELLANT, CIGARETTES AND ANY HEATING APPLIANCES NEAR THE
PRODUCT.
•
Otherwise, this may result in fire.
Safety Instructions
Keep heating appliances as far away from the power cord or the
product as possible.
•
Otherwise, this may result in electric shock or fire.
Do not install it in a badly ventilated location such as a bookcase
or closet.
•
Otherwise, this may result in fire due to an increase in the internal temperature.
When putting the product down, make sure to put it down softly.
•
Otherwise, this may result in damage to the screen display.
Do not place the front of the product on the floor.
•
Otherwise, this may result in damage to the screen display.
Ensure that an authorized installation company installs the wall
mount.
•
Otherwise, it may fall and cause personal injury.
•
Make sure to install the specified wall mount.
Install your product in a well ventilated location. Ensure that
there is a clearance of more than 4 inches (10 cm) from the wall.
•
Otherwise, it may result in fire due to an increase in the internal
temperature.
Ensure that the packaging vinyl is kept away from children.
•
Otherwise, it may result in serious harm (suffocation) if children
play with it.
If the height of your monitor is adjustable, do not place any object or part of your body on the stand when lowering it.
•
This may cause damage to the product or the person carrying
it.
Clean
When cleaning the monitor case or the surface of the TFT-LCD screen,
wipe with a slightly moistened, soft fabric.
Do not spray cleaner directly onto the surface of the product.
•
Otherwise, this may result in the discoloration and distortion of
the structure and the screen surface may peel off.
Clean the product using a soft cloth with a monitor cleaner only.
If you must use a cleaner other than the monitor cleaner, dilute it
with water at a ratio of 1:10.
Safety Instructions
When cleaning the power plug pins or dusting the power outlet,
clean it with a dry cloth.
•
Otherwise, it may result in fire.
When cleaning the product, make sure to disconnect the power
cord.
•
Otherwise, it may result in electric shock or fire.
When cleaning the product, disconnect the power cord and
clean it softly with a dry cloth.
•
Do not use chemicals such as wax, benzene, alcohol, thinner,
mosquito repellant, lubricant, or cleaner. These may change
the appearance of the product surface and peel off the indication labels on the product.
Since the product housing is easily scratched, make sure to use
the specified cloth only.
•
Use the specified cloth adding only a little water. As the product
may be scratched if there is any foreign material on the cloth,
make sure to shake it thoroughly before using it.
When cleaning the product, do not spray water directly onto the
main body of the product.
•
Ensure that water does not enter the product and that it is not
wet.
•
Otherwise, this may result in electric shock, fire or a malfunction.
Others
The product is a high voltage product. Do not disassemble, repair or modify the product yourself.
•
Otherwise, this may result in electric shock or fire. If the product
needs to be repaired, contact a Service Center.
If there is a strange smell or a strange sound or smoke is coming
from the product, disconnect the power plug immediately and contact a Service Center.
•
Otherwise, this may result in electric shock or fire.
Do not place this product in a location exposed to moisture, dust,
smoke, water, or in a car.
•
Otherwise, this may result in electric shock or fire.
When you drop the product or the case is broken, turn the power
off and disconnect the power cord. Contact a Service Center.
•
Otherwise, this may result in electric shock or fire.
Safety Instructions
If thunder or lightning is occurring, do not touch the power cord
or antenna cable.
•
Otherwise, this may result in electric shock or fire.
Do not try to move the monitor by pulling only the wire or the
signal cable.
•
Otherwise, it may fall and result in electric shock, damage to
the product or fire due to damage to the cable.
Do not lift or move the product back and forwards or right and
left while only holding the power cord or signal cables.
•
Otherwise, it may fall and result in electric shock, damage to
the product or fire due to damage to the cable.
Make sure that the ventilating opening is not blocked by a table
or curtain.
•
Otherwise, it may result in fire due to an increase in the internal
temperature.
Do not place any containers containing water, vases, flowerpots, medicines as well as any metal on the product.
•
If water or a foreign material enters the product, disconnect the
power cord and contact a Service Center.
•
This may result in a product malfunction, electric shock, or fire.
Do not use or keep combustible spray or flammable material
near the product.
•
Otherwise, this may result in an explosion or fire.
Do not insert any metal, such as chopsticks, coins, pins and
steel, or flammable objects, such as matches or paper, inside the
product (through the ventilating openings, input and output terminals, etc).
•
If water or foreign material enters the product, disconnect the
power cord and contact a Service Center.
•
Otherwise, this may result in electric shock or fire.
When using a fixed screen for a long time, an afterimage or stain
may occur.
•
If you are not using your product for a long period of time, put
it into sleep mode or use a moving screen saver.
Set a resolution and frequency appropriate to the product.
•
Otherwise, your eyesight may be damaged.
When using headphones or earphones, do not turn the volume
too high.
•
Having the sound too loud may damage your hearing.
Safety Instructions
To avoid eyestrain, do not sit too close to the product.
Take a rest for at least five (5) minutes after using the monitor
for one (1) hour.
This reduces eye fatigue.
Do not install it in an unstable location such as an unstable rack
or uneven surface or a location exposed to vibrations.
•
Otherwise, it may fall and cause personal injury and/or damage
the product.
•
If you use the product in a location exposed to vibrations, it may
damage the product and result in fire.
When moving the product, turn the power off and disconnect
the power plug, antenna cable, and all the cables connected to the
product.
•
Otherwise, it may result in electric shock or fire.
Ensure that children do not hang onto the product or climb up
onto the product.
•
The product may fall and cause personal injury or death.
If you do not use the product for a long period of time, disconnect
the power cord from the power outlet.
•
Otherwise, this may result in overheating or fire due to dust,
and may result in fire due to electric shock or leakage.
Do not place any heavy items or toys or confectionery, such as
cookies etc. that may attract the attention of children and to the
product.
•
Your children may hang onto the product causing it to fall and
this may result in personal injury or death.
Be careful that children do not place the battery in their mouths
when removed from the remote control. Place the battery in a location that children or infants cannot reach.
•
If children have had the battery in their mouths, consult your
doctor immediately.
When replacing the battery, insert it with the right polarity (+, -).
•
Otherwise, the battery may become damaged or it may cause
fire, personal injury or damage due to leakage of the internal
liquid.
Use only the specified standardized batteries, and do not use a
new battery and a used battery at the same time.
•
Otherwise, the batteries may be damaged or cause fire, personal injury or damage due to a leakage of the internal liquid.
Safety Instructions
The batteries (and rechargeable batteries) are not ordinary refuse and must be returned for recycling purposes. The customer
is responsible for returning the used or rechargeable batteries for
recycling.
•
The customer can return used or rechargeable batteries to a
nearby public recycling center or to a store selling the same
type of the battery or rechargeable battery.
Do not place the product in a location exposed to direct sunlight
or near any heat such as a fire or heater.
•
This may reduce the lifetime of the product, and may result in
fire.
Do not drop any objects onto the product or cause any impact
to the product.
•
Otherwise, this may result in electric shock or fire.
Do not use a humidifier near the product.
•
Otherwise, this may result in electric shock or fire.
When there is a gas leak, do not touch the product or the power
plug; ventilate immediately.
•
If a spark occurs, it may cause an explosion or fire.
If the product has been turned on for a long time, the display
panel becomes hot. Do not touch it.
•
Keep the small accessories in a location out of the reach of
children.
Be careful when adjusting the angle of the product or the height
of the stand.
•
This may result in personal injury as your hand or fingers may
become caught.
•
Also, if you tilt the product too far, it may fall and cause personal
injury.
Do not install the product in a location low enough for children
to reach.
•
Otherwise, it may fall and result in personal injury.
•
Since the front part of the product is heavy, install the product
on a level and stable surface.
Do not put any heavy objects on the product.
•
This may result in personal injury and/or damage to the product.
Good Postures When Using the Monitor
Safety Instructions
Maintain the correct posture when using this product.
•
Straighten your back.
•
Keep a distance of 45~50 cm(18~ 20inches) from
your eyes to the screen. Look down at the screen
and face the screen forwards.
•
Maintain the correct posture when using this product.
•
Adjust the angle of the product so that light is not
reflected onto the screen.
•
Keep your elbow at a right angle and keep your arm
level with the back of your hand.
•
Keep your elbow at a right angle.
•
Place your heels flat on the ground while keeping
your knees at an angle of 90 degrees or higher and
maintain the position of your arm so that your arm
is below your heart.
Introduction
Package Contents
Note
Please make sure the items below are included with your LCD Display.
If any items are missing, contact your dealer.
Contact a local dealer to buy items that are sold separately.
Unpacking
LCD Display
Manuals
Quick Setup Guide
Warranty Card
(Not available in all locations)
Cables
Power Cord
D-Sub Cable
MagicInfo Software DVD /
User manual
Introduction
Others
Remote Control
Batteries (AAA X 2)
Ferrite Core for LAN cable
(Not available in all locations)
Sold separately - Not included with the monitor.
Wall Mount KIT
LAN Cable
HDMI Cable
RS232C Cable
USB Cable
Ferrite Core
•
The ferrite cores are used to shield the cables from interference.
•
When connecting a cable, open the ferrite core and clip it
around the cable near the plug.
Installing a Wall Mount
This product is compatible with a 100 mm x 100 mm VESA compliant wall mount.
Above: A 100 mm x 100 mm VESA compliant wall mount.
A. Wall Mount Base
Introduction
B. Wall Mount Kit (Optional)
To attach a wall mount to your monitor, follow these steps:
1.
Turn the product off, and then unplug the power cord from the wall outlet.
2.
Place a soft cloth or cushion on a flat surface to protect the panel and place the product
face down.
3.
Remove the stand as described previously.
4.
Align the groove of the Monitor's wall mount base with the groove in the wall mount kit
and firmly fix the wall mount kit by fastening the screws.
Note
•
If you use a screw that is longer than the standard specifications, the inside of the product
may be damaged.
•
For wall mounts that are not compatible with the standard VESA specifications, the length
of the screw may differ depending on the corresponding specifications.
•
Do not use screws that are incompatible with the standard VESA specifications and do
not screw them in using excessive force.
This may result in damage to the product or injury due to the product falling. Samsung
shall not be held liable for any damage or injury.
•
Samsung shall not be held liable for any damage to the product or injury caused by using
a wall mount that is not compatible with the specified specifications or due to an installation
not performed by an authorized installation engineer.
•
When installing the product using a wall mount, purchase a wall mount that provides at
least 4 inches (10 cm) of clearance from the wall.
•
Samsung shall not be held liable for any problems caused by using a stand that is not
compatible with the specified specifications.
•
Use a wall mount according to specifications of your country.
Your LCD Display
Front
SOURCE/[
] button
When the OSD menu is not on the screen, switches from PC mode to Video
mode. Selects the input source that an external device is connected to in
the order below:
Introduction
[PC] → [HDMI] → [MagicInfo]
When the OSD Menu is displayed, activates a highlighted menu item.
MENU button [MENU]
Opens the on-screen menu and exits from the menu. Also use to exit the
OSD menu or return to the previous menu.
- VOL +
Moves from one menu item to another horizontally or adjusts selected
menu values. When OSD is not on the screen, press the button to adjust
volume.
SEL
Moves from one menu item to another vertically or adjusts selected menu
values.
Power button [
]
Use this button to turn your LCD Display on and off.
Brightness Sensor
Automatically detects the ambient brightness and adjusts the brightness
of the monitor accordingly.
Power indicator
Shows PowerSaver mode by blinking green
Note
See PowerSaver described in the manual for further information regarding
power saving functions. For energy conservation, turn your LCD Display
OFF when it is not needed or when leaving it unattended for long periods.
Remote Control Sensor
Aim the remote control towards this spot on the LCD Display.
Rear
Note
For detailed information concerning cable connections, refer to Connecting Cables under
Setup. The LCD Display 's configuration at the back may vary slightly depending on the model.
Introduction
POWER S/W ON [ │ ] / OFF [O]
Switches the LCD Display On/Off.
POWER
The power cord plugs into the LCD Display
and the wall outlet.
RGB IN
Connect the RGB IN terminal at the back of
your product to your computer.
VIDEO OUT
Connect the [VIDEO OUT] port on the product and the D-Sub port on your monitor using
a D-Sub cable.
HDMI IN
Connect the HDMI terminal at the back of
your LCD Display to the HDMI terminal of
your digital output device using a HDMI cable.
AUDIO OUT
Headphone/External speaker output terminal.
LAN
LAN Connection Terminal
USB Keyboard / Mouse, Mass Storage Device Compatible.
Introduction
AUDIO IN
Connect the audio cable for your product to
the audio port on the back of your computer.
RS232C IN
MDC(Multiple Display Control) Program Port
Kensington Lock Slot
A Kensington Lock is a device used to physically fix your monitor when you use it in a
public place. The locking device has to be
purchased separately. The appearance and
locking method may differ from the illustration depending on the manufacturer. Refer to
the manual provided with the Kensington
Lock for proper use. The locking device has
to be purchased separately.
Note
The location of the Kensington Lock slot may
be different depending on the model.
Using the Anti-Theft Kensington
Lock
1.
Insert the locking device into the Kensington slot on the Monitor
it in the locking direction
and turn
.
2.
Connect the Kensington Lock cable.
3.
Fix the Kensington Lock to a desk or a
heavy stationary object.
Note
See Connecting Cables for further information regarding cable connections.
Remote Control
Note
The performance of the remote control may be affected by a TV or other electronic device
operating near the LCD Display due to interference with the remote's operating frequency.
Introduction
POWER
OFF
Number Buttons
DEL
/ GUIDE button
+ VOL SOURCE
D.MENU
TOOLS
Up-Down Left-Right buttons
INFO
COLOR BUTTONS
TTX/MIX
MTS/DUAL
ENTER/PRE-CH
MUTE
CH/P
TV
MENU
RETURN
EXIT
MagicInfo
1.
POWER
Turns the product On.
2.
OFF
Turns the product Off.
3. Number Buttons
Used to enter the password during the OSD adjustment or
to use MagicInfo.
The "-" button is used to select Digital channels.
4. DEL
ton
/ GUIDE but-
Electronic Program Guide (EPG) display.
* This function does not work for this LCD Display.
5. + VOL 6.
SOURCE
Adjusts the audio volume.
Press this button to change the input signal SOURCE.
You can only change to sources that have external devices
connected them.
7.
D.MENU
DTV menu display
* This function does not work for this LCD Display.
Introduction
8. TOOLS
Use to quickly select frequently used functions.
* This function does not work for this LCD Display.
9. Up-Down Left-Right buttons
Moves from one menu item to another horizontally or vertically, or adjusts selected menu values.
10.
INFO
Displays current picture information on the upper left corner
of the screen.
11. COLOR BUTTONS
Press to add or delete channels and to store channels to the
favorites channel list in the “Channel List” menu.
* This function does not work for this LCD Display.
TTX/MIX
12.
TV channels provide written information services via teletext.
- Teletext Buttons
* This function does not work for this LCD Display.
13. MTS/DUAL
* This function does not work for this LCD Display.
MTSYou can select MTS (Multichannel Television Stereo) mode.
FM Stereo
Audio Type
MTS/S_Mode
Default
Mono
Mono
Stereo
Mono ↔ Stereo
Manual
Change
SAP
Mono ↔ SAP
Mono
DUALSTEREO/MONO, DUAL l / DUAL ll and MONO/NICAM
MONO/NICAM STEREO can be operated depending on the
broadcasting type by using the DUAL button on the remote
control while watching TV.
ENTER/PRE-CH
14.
This button is used to return to the immediately previous
channel.
* This function does not work for this LCD Display.
15.
MUTE
Pauses (mutes) the audio output temporarily. The audio
comes back on if MUTE or - VOL + is pressed in the Mute
mode.
16.
CH/P
In TV mode, selects TV channels.
* This function does not work for this LCD Display.
17. TV
Selects the TV mode directly.
* This function does not work for this LCD Display.
Introduction
18.
MENU
Opens the on-screen menu and exits from the menu or
closes the adjustment menu.
19.
RETURN
Returns to the previous menu.
20.
EXIT
Exits from the menu screen.
21. MagicInfo
MagicInfo Quick Launch Button.
Connections
Connecting a Computer
Connect the power cord for your LCD Display to the power port on the back
of the LCD Display. Turn the power switch on the back of the LCD Display
on.
Connect the D-sub cable the 15-pin, RGB port on the back of your LCD
Display and the 15 pin D-sub Port on the computer.
Connect the audio cable for your LCD Display to the audio port on the back
of your computer.
Notes
•
Turn on both your computer and the LCD Display.
•
Contact a local SAMSUNG Electronics Service Center to buy optional items.
Connecting to Other Devices
Note
You can connect AV output devices such as DVD players, VCRs, or camcorders as well as
your computer to the LCD Display. For detailed information on connecting AV output devices,
refer to the contents under Adjusting Your LCD Display.
Connections
Connecting a HDMI Cable
Notes
•
Connect input devices such as a Blu-Ray/DVD player to the HDMI IN terminal of the LCD
Display using an HDMI cable.
•
You cannot connect a PC to the HDMI terminal.
Connecting a DVI to HDMI Cable
Notes
•
Connect the DVI output terminal of a digital output device to the HDMI terminal of the LCD
Display using a DVI to HDMI cable.
•
Connect the red and white plugs of an RCA to stereo mini-plug cable (for PC) to the red
and white audio output terminals of the digital output device. Connect the mini-plug side
of the cable to the to the AUDIO IN terminal of the LCD Display.
Connecting to another Monitor
Connect a D-Sub cable between the [VIDEO OUT] port on the product and the D-Sub in port
on the other monitor.
Connections
Note
•
Connect to the [VIDEO OUT] port to display the same picture on another monitor.
(For presentation purposes)
Connecting to an Audio System
Note
•
Connect a set of audio cables between the AUX L, R jacks on the AUDIO SYSTEM and
[AUDIO OUT] on LCD Display.
Connections
Connecting a LAN Cable
Note
Connect the LAN cable.
Connecting a USB device
You can connect USB devices such as a mouse or keyboard.
Using the Software
Monitor Driver
Note
When prompted by the operating system for the monitor driver, insert the CDROM included with this monitor. Driver installation is slightly different from one
operating system to another. Follow the directions appropriate for the operating system you have.
If you have lost or misplaced the CD, you can download the monitor driver by
clicking Support > Downloads at http://www.samsung.com/, and then following the directions on the web site After you have downloaded the file, double
click the file, and then follow the directions that appear on your screen.
Installing the Monitor Driver Automatically - All Windows Operating Systems
1.
Insert the CD into the CD-ROM drive.
2.
Click "Windows".
3.
Choose your monitor model from the model list, and then click the "OK" button.
4.
If you have Windows XP or Windows 2000 and you see the following message window,
click the "Continue Anyway" button. On the next window, click the "OK" button.
Using the Software
Note
This monitor driver is certified by Microsoft, and installing it will not damage your system.
If you see the window above, you may have an older install disk. To get the certified
driver, please access the download page for your monitor.
To access the download page, go to http://www.samsung.com/, click Support, and then
Downloads.
Installing the Monitor Driver Manually
Microsoft® Windows Vista™ Operating System
1.
Insert your CD into your CD-ROM drive.
2.
Click Start
tion".
3.
Click "Personalization", and then "Display Settings".
4.
Click "Advanced Settings...".
5.
Click "Properties" in the "Monitor" tab. If the "Properties" button is deactivated, it means
the configuration for your monitor is completed. The monitor can be used as is.
> "Control Panel". Then, double-click on "Appearance and Personaliza-
Using the Software
If the message "Windows needs..." is displayed, as shown in the figure below, click
"Continue".
Note
This monitor driver is certified by Microsoft, and installing it will not damage your system.
If you see the window above, you may have an older install disk. To get the certified
driver, please access the download page for your monitor.
To access the download page, go to http://www.samsung.com/, click Support, and then
Downloads.
6.
Click "Update Driver..." in the "Driver" tab.
7.
Check the "Browse my computer for driver software" checkbox, and then click "Let me
pick from a list of device drivers on my computer".
8.
Click "Have Disk...” and select the CD or DVD drive (for example, D:\) where the driver
setup file is located, and then click "OK".
Using the Software
9.
Select the model that matches your monitor from the list of monitor models on the screen,
and click "Next".
10. Click "Close" → "Close" → "OK" → "OK" on the following screens displayed in sequence.
Microsoft® Windows® XP Operating System
Using the Software
1.
Insert the CD the CD-ROM drive.
2.
Click Start > Control Panel, and then click the Appearance and Themes icon.
3.
Click the "Display" icon and choose the "Settings" tab, and then click "Advanced...".
4.
Click the "Properties" button on the "Monitor" tab, and then select "Driver" tab.
5.
Click "Update Driver..." and, select "Install from a list or...", and then click the "Next"
button.
6.
Select "Don't search, I will...", click "Next", and then click "Have disk".
Using the Software
7.
Click the "Browse" button, and then choose the driver disk location (for example, D:\).
Choose your monitor model in the model list, and then click the "Next" button.
8.
If you see can see following message window, click the "Continue Anyway" button. Then
click "OK" button.
Note
This monitor driver is certified by Microsoft, and installing it will not damage your system.
If you see the window above, you may have an older install disk. To get the certified
driver, please access the download page for your monitor.
To access the download page, go to http://www.samsung.com/, click Support, and then
Downloads.
9.
Click the "Close" button, then click the "OK" button continually.
Using the Software
10. Monitor driver installation is completed.
Microsoft® Windows® 2000 Operating System
If you can see "Digital Signature Not Found" on your monitor, follow these steps.
1.
Choose the "OK" button on the "Insert disk" window.
2.
Click the "Browse" button on the "File Needed" window.
3.
Choose A:(D:\Driver), click the "Open" button, and then click the "OK" button.
How to install
1.
Click Start > Setting > Control Panel.
2.
Double click the "Display" icon.
3.
Select the "Settings" tab, and then click the "Advanced Properties" button.
4.
Choose "Monitor".
Case1 : If the "Properties" button is inactive, it means your monitor is properly configured.
Please stop installation.
Case2 : If the "Properties" button is active, click the "Properties" button, and then follow
the next steps.
5.
Click "Driver", click on "Update Driver...", and then click on the "Next" button.
6.
Choose "Display a list of the known drivers for this device so that I can choose a specific
driver" , click "Next", and then click "Have disk".
7.
Click the "Browse" button, and then choose A:(D:\Driver).
8.
Click the "Open" button, and then click "OK" button.
9.
Choose your monitor model, and then click the "Next" button. Then, click "Next" button.
10. Click the "Finish" button, and then the "Close" button.
Using the Software
If you can see the "Digital Signature Not Found" window, Then click the "Yes" button.
Then click the "Finish" button and the "Close" button.
Microsoft® Windows® Millennium Operating System
1.
Click Start>Setting>Control Panel.
2.
Double click the "Display" icon.
3.
Select the "Settings" tab, and then click the "Advanced Properties" button.
4.
Select the "Monitor" tab.
5.
Click the "Change" button in the "Monitor Type" area.
6.
Choose "Specify the location of the driver".
7.
Choose "Display a list of all the drivers in a specific location...", and then click "Next"
button.
8.
Click the "Have Disk" button.
9.
Specify A:\(D:\driver), and then click the "OK" button.
10. Select "Show all devices" and choose the monitor that corresponds to the one you connected to your computer, and then click "OK".
11. Continue choosing the "Close" button and the "OK" button until you close the Display
Properties dialogue box.
Microsoft® Windows® NT Operating System
1.
Click Start>Setting>Control Panel, and then double-click "Display" icon.
2.
In the Display Registration Information window, click Settings Tab, and then click "All
Display Modes".
3.
Select a mode that you wish to use (Resolution, Number of colors, and Vertical frequency) and then click "OK".
4.
Click "Test". If you see the screen working normally, click the “Apply” button. If the screen
is not normal, change to a different mode (lower mode of resolution, colors, or frequency).
Note
If there is no Mode at All Display Modes, select the level of resolution and vertical frequency
by referring to the Preset Timing Modes in the user guide.
Linux Operating System
To execute X-Window, you need to make the X86Config file, which is a type of system setting
file.
1.
Press "Enter" at the first and the second screen after executing the X86Config file.
2.
The third screen is for setting your mouse.
3.
Set a mouse for your computer.
4.
The next screen is for selecting a keyboard.
Using the Software
5.
Set a Keyboard for your computer.
6.
The next screen is for setting your monitor.
7.
Set a horizontal frequency for your monitor. (You can enter the frequency directly.)
8.
Set a vertical frequency for your monitor. (You can enter the frequency directly.)
9.
Enter the model name of your monitor. This information will not affect the actual execution
of X-Window.
10. You have finished setting up your monitor. Execute X-Window after setting other requested hardware.
MDC (Multi-Display Channel)
Installation
1.
Insert the installation CD into the CD-ROM drive.
2.
Click the MDC installation file.
Note
If the installation window does not appear, access the CD using Windows Explorer, and
then double click the MDC executable file on the CD to launch the installation.
3.
When the Installation Shield Wizard window appears, click "Next".
4.
Select "I agree to the terms of the license agreement" to accept the terms of use.
5.
Click "Install".
6.
The "Installation Status" window appears.
7.
Click "Finish".
8.
When the installation is complete, the MDC executable icon appears on your desktop.
Double-click the icon to start the program.
The MDC execution icon may not appear depending on the specifications of your
computer system or monitor. If this happens, press the F5 Key.
Installation Problems
The installation of MDC can be affected by such factors as the video card, motherboard and
the network environment.
Uninstall
To uninstall the MDC program, use the "Add or Remove Programs" option in the Windows® Control Panel.
Using the Software
Uninstall
To uninstall the MDC program, use the "Add or Remove Programs" option in the Windows® Control Panel.
To uninstall MDC, follow these steps:
1.
Select "Setting/Control Panel" on the "Start" menu, and then double-click "Add/Delete a
program".
2.
Select MDC from the program list, and then click the "Add/Delete" button.
Using MDC
Introduction
A Multiple Display Control (MDC) is an application allowing various displays to be easily and simultaneously
operated on a PC. RS-232C, a standard of serial communication, is used for the communication between a PC and
a display. Therefore, a serial cable should be connected between the serial port on a PC and the serial port on a
display.
Main Screen
Click Start > Program > Samsung > MDC System to start the program.
Select a set to see the volume of the selected set within the slider.
Main Icons
Select Button
Remocon
Info Grid
Safety Lock
Display Selection
Port Selection
Control Tools
1. Use the main icons to switch into each screen.
2. Allows you to enable or disable the remote control signal receiving function of the display unit.
3. Set the Safety Lock function.
When setting the Lock function, you can only operate power and lock buttons on the remote control and set.
4. The setting for the PC Serial Port can change. The original value is COM1.
5. Click Select all or Clear to select or clear all displays.
6. Use Grid to view brief information on selected display.
7. Select a display from Display Selection.
8. Use Control Tools to control displays.
<Note> The remote control Enable/Disable function operates whether or not the power is On/Off, and this
applies to all displays connected to the MDC. However, regardless of the status at the time the MDC is
shut down, the remote control signal receiving function of all displays is initialized to Enable when the
MDC is closed.
Port Selection
1. The Multiple Display Control is originally set to COM1.
2. If any port other than COM1 is used, COM1 through COM4 can be selected in the Port Selection Menu.
3. If the exact port name that is connected to the LCD Display using a serial cable is not selected, communication will
be unavailable.
4. The selected port is stored in the program and used for the next program as well.
Power Control
1. Click Power Control of the main icons and the Power Control screen appears.
Info Grid shows some basic information necessary to Power Control.
1)
(Power Status)
2) Input
3) Image Size
4) On Timer
5) Off Timer
2. Use the Select All button or Check Box to choose a display to control.
Power Control allows controlling some of the functions of the selected display.
1) Power On/Off
- Turns the power of the selected display On/Off.
2) Volume
- Controls the volume level of the selected display.
It receives the volume value of the selected display from the sets and displays it in the slider.
(When you cancel the selection or choose Select All, the value returns to the default value 10)
3)
(Mute On/Off)
- Turns on/off the Mute function of the selected display.
When selecting one set at a time, turn on the Mute function for the selected set.
The Mute function is disabled automatically when you adjust the volume level.
(The values return to the default settings when you undo the selections or choose "Select All".)
The Power Control feature is available for all displays.
The Volume Control and Mute features are available only for the displays whose power status is ON.
Input Source
1. Click Input Source of the main icons and the Input Source control screen appears.
Click Select All or use Check Box to select a display to control.
• TV Mode
• PC Mode
Info Grid shows some basic information necessary to Input Source Control.
1)
PC
- Changes the Input Source of the selected display to PC.
2)
BNC
- Changes the Input Source of the selected display to BNC.
3)
DVI
- Changes the Input Source of the selected display to DVI.
4)
TV
- Changes the Input Source of the selected display to TV.
5)
DTV
- Changes the Input Source of the selected display to DTV.
6)
AV
- Changes the Input Source of the selected display to AV.
7)
S-Video
- Changes the Input Source of the selected display to S-Video.
8)
Component
- Changes the Input Source of the selected display to Component.
9)
MagicInfo
- The Input source of MagicInfo works only on MagicInfo model.
10)
HDMI
- Changes the Input Source of the selected display to HDMI.
11)
Channel
- Channel arrow appears when the Input Source is TV.
TV Source can be selected only in products with TV and controlling channels is allowed only when
Input Source is TV.
The Input Source Control feature is available only for the displays whose power status is ON.
Image Size
PC, BNC, DVI
1. Click Image Size of the main icons and the Image Size control screen appears.
Info Grid shows some basic information necessary to Image Size Control.
1)
( Power Status)
- Shows the power status of the current display.
2) Image Size
- Shows the current Image Size of the display in use.
3) Input
- Info Grid displays only the displays whose Input Source is PC, BNC, DVI.
4) PC Source
- When you click Image Size, the PC Source tab first appear.
- The Image Size Control button controls Image Size available for PC, BNC, DVI.
5) Video Source
- Click the Video Source tab to control Image Size for respective Input Source.
The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
Image Size Control is available only for the displays for which power status is ON.
Image Size
TV, AV, S-Video, Component, DVI(HDCP), HDMI, DTV
1. Click Image Size of the main icons and the Image Size control screen appears.
Info Grid shows some basic information necessary to Image Size Control.
1) Click the Video Source tab to adjust Image Size for TV, AV, S-Video, Component, DVI(HDCP), HDMI, DTV.
Click Select All or use Check Box to select a display to control.
2) Info Grid displays only the display having TV, AV, S-Video, Component or DVI(HDCP) as input source.
3) Switch Image Size of the selected display randomly.
Note: Auto Wide, Zoom1 and Zoom2 are not available for selection when the input signal type for
Component and DVI (HDCP) is 720p or 1080i.
(The Auto Wide mode is available only for TV, AV, and S-Video.)
4) The screen modes can only be adjusted when a TV (PAL only) is connected and the Image Size item is set to Auto
Wide.
The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
The Image Size Control feature is available only for the displays whose power status is ON.
Time
1. Click Time of the main icons and the Time Control screen appears.
Info Grid shows some basic information necessary to Time Control.
1) Current Time
- Set the current time for the selected display (PC Time).
- To change the current time, first change the PC Time.
2) On Time Setup
- Set the Hour, Minute, AM/PM of On Time Setup, Status, Source, Volume of the selected display.
3) Off Time Setup
- Set the Hour, Minute, and AM/PM, Status for Off Time Setup of the selected display.
4) Shows the On Time settings.
5) Shows the Off Time settings.
The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
Time Control is available only for the displays for which the power status is ON.
At On Time Setup, TV Source functions only for TV Model.
At On Time Setup, MagicInfo Source functions only for MagicInfo Model.
PIP
PIP Size
1. Click PIP of the main icons and the PIP control screen appears.
Click Select All or use Check Box to select a display to control.
Info Grid shows some basic information necessary to PIP Size Control.
1) PIP Size
- Shows the current PIP Size of the display in use.
2) OFF
- Turns off the PIP of the selected display.
3) Large
- Turns on the PIP of the selected display and changes the size to Large.
4) Small
- Turns on the PIP of the selected display and changes the size to Small.
5) Double 1
- Turns on the PIP of the selected display and changes the size to Double 1.
6) Double 2
- Turns on the PIP of the selected display and changes the size to Double 2.
7) Double 3 (Picture By Picture)
- Turns on the PBP of the selected display and changes the size to Double 3.
The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
PIP Size can be controlled with turning on the LCD Display power.
PIP
PIP Source
1. Click PIP of the main icons and the PIP control screen appears.
Info Grid shows some basic information necessary to PIP Source Control.
1) PIP Source
- PIP Source can be controlled with turning on the LCD Display power.
2) PC
- Changes the source of the PIP of the selected display to PC.
3) BNC
- Changes the source of the PIP of the selected display to BNC.
4) DVI
- Changes the source of the PIP of the selected display to DVI.
5) AV
- Changes the source of the PIP of the selected display to AV.
6) S-Video
- Changes the source of the PIP of the selected display to S-Video.
7) Component
- Changes the source of the PIP of the selected display to Component.
8) HDMI
- Changes the source of the PIP of the selected display to HDMI.
Note: Some of the PIP Sources may not be available for selection, depending on the input source type
of the Main Screen.
The Input source of MagicInfo works only on MagicInfo model.
The PIP Control feature is available only for the displays whose power status is ON and the PIP
function is set to ON.
Settings
1. Click Settings of the main icons and the Settings Control screen appears.
Info Grid shows some basic information necessary to Settings Control.
When each function is selected, the set value of the selected function is displayed in the slide.When selected, each
function fetches the value for the set and displays it on the slide bar. When "Select All" is chosen, the default value
is displayed. Changing a value in this screen will automatically change the mode to "CUSTOM."
1) Picture
- Available only for TV, AV, S-Video, Component, HDMI, DTV.
2) Contrast
- Adjusts Contrast of the selected display.
3) Brightness
- Adjusts Brightness of the selected display.
4) Sharpness
- Adjusts Sharpness of the selected display.
5) Color
- Adjusts Color of the selected display.
6) Tint
- Adjusts Tint of the selected display.
- Available only for NT.
7) Color Tone
- Adjusts the Color Tone for the selected display.
8) Color Temp
- Adjusts the Color Temp for the selected display.
9) Brightness Sensor
- Adjusts the Brightness Sensor for the selected display.
10) Dynamic Contrast
- Adjusts the Dynamic Contrast for the selected display.
The Input source of MagicInfo works only on MagicInfo model.
Color Temp is only enabled if the Color Tone is set to Off.
The Input source of TV works only on TV model.
This feature is available only for the displays whose power status is ON and if no selection is made, the
factory default is displayed.
Settings
Picture PC
1. Click Settings of the main icons and the Settings Control screen appears.
Info Grid shows some basic information necessary to Settings Control. When each function is selected, the set value
of the selected function is displayed in the slide. When selected, each function fetches the value for the set and
displays it on the slide bar. When "Select All" is chosen, the default value is displayed. Changing a value in this
screen will automatically change the mode to "CUSTOM."
1) Picture PC
- Available only for PC, BNC, DVI.
2) Contrast
- Adjusts Contrast of the selected display.
3) Brightness
- Adjusts Brightness for the selected display.
4) Red
- Adjusts red Color of the selected display.
- Available only for NT.
5) Green
- Adjusts green Color of the selected display.
- Available only for NT.
6) Blue
- Adjusts blue Color of the selected display.
- Available only for NT.
7) Color Tone
- Adjusts the Color Tone for the selected display.
8) Color Temp
- Adjusts the Color Temp for the selected display.
9) Brightness Sensor
- Adjusts the Brightness Sensor for the selected display.
10) Dynamic Contrast
- Adjusts the Dynamic Contrast for the selected display.
The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
Color Temp is only enabled if the Color Tone is set to Off.
This feature is available only for the displays whose power status is ON and if no selection is made, the
factory default is displayed.
Settings
Audio
1. Click Settings of the main icons and the Settings Control screen appears.
Info Grid shows some basic information necessary to Settings Control. When each function is selected, the set value
of the selected function is displayed in the slide. When selected, each function fetches the value for the set and
displays it on the slide bar. When "Select All" is chosen, the default value is displayed. Changing a value in this
screen will automatically change the mode to "CUSTOM."
1) Audio
- Controls audio settings for all input sources.
2) Bass
- Adjusts Bass of the selected display.
3) Treble
- Adjusts Treble of the selected display.
4) Balance
- Adjusts Balance of the selected display.
5) SRS TS XT
- SRS TS XT Sound ON/OFF of the selected display.
6) Sound Select
- Select either Main or Sub when PIP is On.
The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
This feature is available only for the displays whose power status is ON and if no selection is made, the
factory default is displayed.
Settings
Image Lock
1. Click Settings of the main icons and the Settings Control screen appears.
Info Grid shows some basic information necessary to Settings Control.
1) Image Lock
- Available only for PC, BNC.
2) Coarse
- Adjusts Coarse of the selected display.
3) Fine
- Adjusts Fine of the selected display.
4) Position
- Adjusts Position of the selected display.
5) Auto Adjustment
- Self-Adjust to the incoming PC signal.
The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
Settings Control is available only for the displays for which the power status is ON.
Maintenance
Lamp Control
1. Click on the "Maintenance" icon in the Main Icon column to display the Maintenance screen.
An "Info Grid" showing several basic data items appears.
1) Maintenance
- Allows the Maintenance Control function for all input sources.
2) Auto Lamp Control
- Automatically adjusts the backlight of the selected display at a specified time.
The Manual Lamp Control automatically turns off if you adjust using the Auto Lamp Control.
3) Manual Lamp Control
- Allows you to adjust the backlight of the selected display regardless of the time.
The Auto Lamp Control automatically turns off if you adjust using the Manual Lamp Control.
The Maintenance Control feature is available only for the displays whose power status is ON.
The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
Maintenance
Scroll
1. Click on the "Maintenance" icon in the Main Icon column to display the Maintenance screen.
1) Scroll
- This function is used to remove the afterimages that occur when a still screen is displayed on the selected
display
for a long time.
2) Pixel Shift
- This allows the screen to be moved finely at the specified time interval.
3) Safety Screen
- The Safety Screen function is used to prevent afterimages from occurring when a still screen is displayed on the
monitor for a long time. The Interval item is used to set the repetition cycle in hour units and the Time item is
used to set the time when the Safety Screen function must be performed.
The Type item can be set to Scroll, Pixel, Bar, Eraser, All White, or Pattern.
4) Safety Screen2
- This function is used to prevent afterimages from occurring. There are five (5) types that you can select and
control with this function.
For the Scroll type, the Time item can be set to 1, 2, 3, 4 or 5. For the Bar and Eraser types, it can be set
to 10, 20, 30, 40 or 50. For the All White and Pattern type, it can be set to 1, 5, 10, 20 or 30.
The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
The Maintenance Control feature is available only for the displays whose power status is ON.
Maintenance
Video Wall
1. Click on the "Maintenance" icon in the Main Icon column to display the Maintenance screen.
1) Video Wall
- A Video Wall is a set of video screens that are connected together, so that each screen shows a part of the whole
picture or so that the same picture is repeated on each screen.
2) Video Wall (Screen divider)
- The screen can be divided into.
You can select a number of screens with a different layout when dividing.
z Select a mode from Screen divider.
z Select a display from Display Selection.
z The place will be set up by pressing a number in the selected mode.
z The MDC program supplied by Samsung supports up to 5x5 LCD Displayes.
3) On / Off
- Turns on/off the Video Wall function of the selected display.
4) Format
- The format can be selected to see a divided screen.
z Full
z Natural
You may not operate this function in MagicInfo.
The Input source of TV works only on TV model.
The Maintenance Control function is available only for the displays where the power status is ON.
Troubleshooting
1. The display you wish to control does not appear on the Power Control Info Grid
- Check the connection of RS232C. (Check if it is properly connected to the Com1 port)
- Check the displays to see if any of the other displays connected have the same ID. If more than one displays have
the same ID, those displays are not properly detected by the program due to data conflict.
- Check if the Display Set ID is a number between 0 and 25. (Adjust using the Display menu)
Note :
A Display Set ID must be a value between 0 and 25 .
2. The display you wish to control does not appear on the other Control Info Grids
- Check to see if the display power is ON. (You can check this in Power Control Info Grid)
- Check if you can change the input source of the display.
3. The dialogue box appears repeatedly.
- Check to see if the display you wish to control is selected.
4. Both On Timer and Off Timer have been set but different time is showing.
- Apply current time to synchronize the display clocks.
5. The remote may not function properly when you turn off the remote Function, disconnect the RS-232C cable, or exit
the program in an Irregular manner. Rerun the program and turn the remote function again to Restore normal
functions.
<Note> This program may malfunction due to problems in communication circuits or interference from electronic
appliances nearby.
Settings Value Display In Multiple Display Mode
When there are more than one displays connected, the settings values are displayed as follows.
1. No selection: Displays the Factory Default Value.
2. Selected one display: Fetches and displays the settings value for the selected display.
3. Selected one display (ID1) and add another display (ID3): The program, which was displaying the settings value of
ID 1, fetches and displays the value of ID3.
4. Selected all sets using Select All: Returns to the Factory Default Value.
Software Control Panel (230TSN)
Main Tab
This tab covers touch sensor calibration as well as basic support information.
Calibration
The calibration process aligns the touch sensor with the underlying video. Specifically, calibration defines the dimensions of the active area of the sensor and locates the center of the
sensor. If the sensor is not calibrated, the active area of the sensor may not be aligned properly or may be unnecessarily small.
You should calibrate the touch sensor in the following cases:
•
Any time you change the size and position of the video image by adjusting the horizontal
and vertical controls on your display.
•
Any time the cursor does not follow the movement of your finger, or does not reach the
edges of the touch sensor. If you continue to need additional accuracy along the edges,
use the Edge Adjustment tab.
Calibrating the Touch Sensor
1.
Select the Main tab.
2.
Click the Calibrate button.
Note
If you are using a stylus (pen) and you are in Pen/Finger mode, a dialog will ask whether
you wish to calibrate using Pen or Finger. Calibrate using each option separately and
when you are done, MT 7 will restore your touch mode to Pen/Finger.
3.
A calibration target appears in the lower left corner of the touch sensor.
Using the Software
Note
If you press Escape or do not touch the sensor within twenty seconds, the system automatically cancels the calibration process with no change to the current settings.
4.
Touch the sensor positioning your fingertip to completely cover the green target. This
position is calculated upon liftoff and when you remove your finger, the target should turn
red.
When touching the calibration target, make sure to:
•
Perform the calibration in the position (sitting or standing) you expect to normally use
the touch sensor.
•
Touch the calibration target firmly and precisely with your fingertip. During Calibration, be careful to keep your fingernails and other fingers away from the touch sensor
as you touch the target.
5.
Repeat these instructions for additional calibration targets.
6.
Once you have calibrated the touch sensor, a dialog box will appear to ask if you wish
to test, accept or cancel this calibration.
•
If you select Accept, then the new calibration settings are automatically accepted.
•
If you select Test, then a Draw (refer to the Tools tab for more details) screen appears.
When you exit Draw mode, a dialog will prompt, “Are you satisfied with the results?”
•
•
Selecting Yes will keep the new calibration settings.
•
Selecting No will restore the original (pre-calibration) settings.
If you select Cancel, the original settings will be restored without change.
Testing the Calibration
If you accidentally liftoff from the sensor in the wrong place during calibration, you will distort
the touch sensor calibration. Test by touching several points on the sensor to make sure you
are satisfied with the calibration results. The cursor should be located underneath your finger
or pen when you touch the sensor. Repeat the Calibration process until you are satisfied.
Recalibrate the touch sensor if any of the following tests fail.
•
Touch random points on the sensor. The cursor should be located underneath your finger
or pen when you touch the sensor.
•
Drag your finger across the sensor and check that the cursor follows your movements.
Using the Software
•
Touch each corner and along the edges of the sensor. Verify that the cursor reaches the
full image area of the sensor. Be sure you can touch and activate all icons and menus
across the entire sensor.
•
If you are using a pen stylus, be sure to perform the calibration procedure using the pen.
•
If you need to recalibrate the sensor, make sure to touch the targets carefully. It is possible
that one of your touches did not register properly or you accidentally touched the sensor
in the wrong place during calibration. For example, if you touch beyond the targets or into
the non-image area, you will distort the sensor calibration.
Support Information
This information helps identify your system setup for troubleshooting purposes. If for any
reason you need to call Technical Support, this information will be useful.
Controller ID
On the Main tab, this is an information-only field in a single controller situation - if you have
more than one controller you can select the specific controller you want to adjust.
Controller Type
This field displays the type of controller currently attached to your system. This data may be
useful for Technical Support issues.
Firmware Version
These digits represent the version number and revision level of the touch controller firmware.
Touch Screen Status
Touch Screen Status refers to whether or not the sensor has been found and is operational.
Touch Settings Tab
The Touch Settings tab enables you to customize the response of your touch sensor. You
can change the way the system responds to your touch, add a right-click tool to your desktop,
tell your system to beep on touch, and define the double-click speed and area of your touch.
Touch Modes
The available Touch Modes options are Drawing, Touchdown, and Liftoff.
Drawing Mode (Default Value)
Drawing Mode is most useful for draw, paint, illustration, and graphics
applications. In Drawing Mode, a touch is equivalent to pressing and
Using the Software
holding down the mouse button. This is considered the easiest mode to
use with an immediate reaction to touch. Lifting off is equivalent to
releasing the mouse button.
•
To click, touch the object. Lift off the sensor.
•
To double-click; touch the object twice quickly at the same location.
•
To drag, touch the object. Slide your finger to the new location. Lift off the sensor
Touchdown Mode
Touchdown Mode enables you to create an immediate button action as soon as you touch
the sensor. In Touchdown Mode, you cause a button down at the cursor location, with a
short pause and then a button up. You can leave your finger on the sensor but only a single
touch is registered until you lift your finger off the sensor and touch down again.
Touching the sensor is equivalent to pressing and releasing the mouse button. The action
occurs as soon as you touch the sensor. This mode is best for button-based applications (like
a calculator). Drawing or dragging is not supported in this mode.
Liftoff Mode
Liftoff Mode enables you to position the cursor where you want before creating a button
action. In Liftoff Mode, the cursor will follow your finger for a more accurate touch.When you
want to select an item, lifting your finger off the sensor will cause a button down, short pause,
and then a button up to occur.
Touching the sensor is equivalent to moving the mouse position. The button down/button up
action occurs when you remove your finger from the sensor. This mode is useful for applications requiring greater accuracy because it lets you carefully position the cursor before
acting on it. Drawing or dragging is not supported in this mode.
Right-Click Tool (not available on Linux)
This option places an icon on the desktop (always on top of your application) that allows you
to select which mouse button to activate on touch. Note that this works for the next click action
only. Control returns to the left mouse button as soon as you are done.
You can position this icon anywhere on your desktop by selecting it, pausing until the fourpointed arrow appears, and dragging it wherever you want.
Left button is typically used for normal select and normal drag. Right button is typically used
for applet properties such as context menu and special drag.
Double-Click Speed (not available on Windows® CE or Linux®)
Double-click speed defines how quickly you must touch the sensor for the system to interpret
your actions as a double-click. Set the double-click speed in the slow to medium range for
optimum performance with a touch sensor.
Touch the globe twice to test the double-click speed and area settings. If the globe begins to
spin, the sensor recognized your touch as a double-click.
Note
Changing this setting will affect the double-click setting of the mouse.
Using the Software
Double-Click Area (not available on Windows® CE or Linux®)
Double-click area defines the space in which you must touch the sensor for the system to
interpret your actions as a double-click. Set the double-click area in the medium to high range
for optimum performance with a touch sensor.
Touch the globe twice to test the double-click speed and area settings. If the globe begins to
spin, the sensor recognized your touch as a double-click.
Note
Changing this setting will affect the double-click setting of the mouse.
Edge Adjustment Tab
Once you calibrate the touch sensor, the cursor should be located directly beneath your finger
when you touch the sensor. However, this may make it difficult to touch items at the very
edges of the sensor. The Edge Adjustment tab enables you to define an offset area in which
the cursor moves closer to the edges of the sensor so you can easily and more precisely
select small items, such as single words, the Windows™ Start button, check boxes, or radio
buttons.
For example, if you have a row of buttons along the left edge of your touch sensor, you may
want to set an edge adjustment to enable users to easily activate these buttons.Because
each edge is independent of the other, you only need to adjust the left margin to accommodate
this row of buttons.
Edge Adjustment Setting
To set the Edge Adjustment, move the sliders inward to define the offset area. These
changes take effect immediately. Click Test to preview your choices. The area you have
defined appears as a colored area as shown below. Within this colored area, the cursor will
automatically move ahead of your finger so you can more easily touch items closer to the
edge.
Determine if the area you have defined is sufficient for your needs. Can you touch into the
corners and along the edges of the sensor? Click Escape, End Test, or Return to go back
to the Edge Adjustment tab. If you are satisfied with the selections you have made - you are
done. If not, adjust the sliders to better accommodate your needs.
Using the Software
Tools Tab
The Tools tab enables you to perform a variety of diagnostics to optimize the performance
of your touch sensor. This tab is also the gateway to advanced touch options.
Component Versions
This is an informational screen for diagnostic purposes that details the building blocks of MT
7 and its version numbers.
Draw Test
Note
You must be in Draw mode for this to work properly.
The Draw program lets you test the operation of the touch sensor and pen by checking the
accuracy and speed with which the system responds to your touch. To draw, simply touch
the sensor and drag your finger or pen.
The following options will help you use the draw program more
effectively:
•
Press B (blank) to clear the screen and display a blank drawing canvas.
Using the Software
•
Press G (grid) to clear the screen and display a grid that you can use as a drawing guide
(default setting).
•
Press L (line) to draw solid lines on the screen (default setting).
•
Press D (dots) to draw dotted lines on the screen, where each dot represents a point
reported by the touch sensor.
•
Press the Space Bar to clear the screen.
Restore Factory Settings
Software
The Reset Software option is useful if you have reconfigured the MT 7 software and need to
get back to a working state. This option will restore supplier factory configuration settings. If
none exist, it will reset to 3M Touch System defaults.
Controller
The Restore Controller option is useful if you have reconfigured the controller and need to
get back to a working state. Pressing this button restores 3M Touch System factory-set system defaults.
If after restoring controller factory defaults, you lose touch, you will need to reboot in order to
restore touch.
Note
You must perform a calibration after restoring controller defaults.
Reset Controller
Use this only at the direction of Technical Support. This command initializes the hardware
and the firmware, causes the controller to stop sending data, and recalculates the environmental conditions (for example, stray and offset values). The Reset command also cancels
existing commands and returns the controller to normal operation.
Advanced Touch Options
Note
Important Note: Executing the Advanced Options may alter the performance of your touch
sensor or render it inoperable. You should be aware of expected results before executing any
option. If you are not familiar with the outcome of these settings, you should not be using
these options.
Using the Software
This option controls certain advanced functions for your controller. Depending on the options
you have selected and the availability of that function for your given controller, you can choose
certain Advanced Options from this screen.
•
Enable manual linearization
•
Enable frequency selection
Refer to the Controller Tab for a discussion of the various options associated with these
Advanced Options settings.
Controller Tab
The Controller tab contains different choices depending on the type of touch controller(s)
you have attached to your system and which options you selected from the Advanced Options from the Tools tab.
Controller Type
If you have more than one controller attached to your system, this field displays the controller
currently selected on the Main tab. This data may be useful for Technical Support issues.
Linearization
With certain controllers, you can perform a linearization to fine-tune your touch sensor. It
should be performed only at the direction of 3M Touch Systems, Inc. Technical Support.Linearization consists of touching 25 targets on the screen followed by 16 additional points to
determine specific point accuracy over the face of the display.
The EX, CX, and some RX series touch controllers support Linearization:
To perform a 25-point linearization of the touch sensor:
1.
Make sure the video image is centered in the screen area using the horizontal and vertical
controls.
2.
Open the touch control panel and select the Controller tab.
Using the Software
3.
Click Linearize. This will bring up, one at a time, 25 linearization targets on the screen.
Note
If you press Escape or do not touch the sensor within 20 seconds, the system automatically cancels the linearization process with no change to the current settings.
4.
Touch the sensor and position your fingertip to completely cover the green target.
When touching the target, make sure you:
5.
•
Face the display directly.
•
Perform the linearization in the position (sitting or standing) you expect to use the
touch sensor.
•
Touch the target firmly and precisely with your fingertip. Be careful to keep your other
fingers away from the sensor as you touch the target. Hold a steady touch over the
target until you hear a beep or until the target turns red.
Repeat these instructions until all 25 targets have been touched.
•
Face the display directly.
A dialog will appear asking if you wish to “Test, Accept, or Cancel”.
•
If you select Accept, then the new calibration settings are automatically accepted.
•
If you select Cancel, the original settings will be restored without change.
•
If you select Test, the 25 targets will now be replaced with a set of 16 targets used
to verify the linearization performed in steps 1 through 5.
These targets are yellow to begin with. If you successfully touch the target, it turns green.
If you are off, it turns red and returns a percentage error number. If the linearization is
not within acceptable tolerances, you should perform the linearization process again.
Repeat the previous process for each of these targets. This process automatically returns
to the control panel once complete. If you are using a pen stylus, repeat the linearization
procedure with the pen.
To test the accuracy of the linearization process, use the Draw Test program (found on
the Tools Tab) to draw some lines on the screen. Check that they are smooth, straight,
and thin. You do not want lines to look keystoned or curved.
To exit this program at any time during the process, press Escape.
Touch Screen Frequency
Note
This option applies to capacitive EX and CX-series controllers.
From the Tools tab, you can choose the Advanced Options button. From the Advanced
Options dialog, select Enable Frequency Selection to activate this option on the Controller tab if you are using a capacitive EX-based controller.
This option adjusts the operating frequency of the touch controller. In general, you will not
need to adjust the Touch Screen Frequency. However, if you are experiencing problems
with a jittery cursor, ragged lines, or random touch points, you may want to run the Enable
Frequency Selection option.
Using the Software
Use the Enable Frequency Selection option to test the available frequency settings and
determine the best frequency. The range of frequency settings and the default setting depends on your touch controller. You can set a new operating frequency, and then check the
performance of the touch sensor at that frequency setting.
Be aware that if you choose Restore Factory Settings → Controller from the Tools tab,
you will change the Touch Screen Frequency to the factory default setting. You may need
to redo the Touch Screen Frequency at this time
Touch Screen Frequency Procedure
From the Tools tab, you can choose the Advanced Options button. From the Advanced
Options dialog, select Enable Frequency Selection to activate this option on the controller
tab if you are using a capacitive EX based controller.
In the Touch Screen Frequency box, you will see a pull down list of several frequency
options. In general, the highest possible frequency will provide the best results. Once you
change the frequency, do not touch the sensor for approximately 30 seconds. Touch will
return when the frequency has been changed. Test to see if you are satisfied.
On a pen controller system, you have the option to change the frequency for both your finger
and the pen if you are using Pen/Finger mode.
Testing the Newly Selected Frequency
Any time you adjust the Touch Screen Frequency you should test how the touch sensor is
working and verify you are satisfied with the operation of the touch sensor.
Test the sensor by touching in several places and sliding your finger around the sensor.The
cursor should hold steady and smooth. If you see erratic or jittery cursor movement, readjust
the Touch Screen Frequency.
Adjust the frequency until your touch test produces acceptable results. A good test is to go
to the Draw program and hold your finger steady on the sensor. If the resulting pattern is a
crisp and clear single dot, you should have a good frequency.
It is recommended that you recalibrate the touch sensor after you run the Touch Screen
Frequency option.
Adjusting the LCD Display
Input
Available Modes
•
PC
•
HDMI
•
MagicInfo
Source List
MENU → ENTER →
→
,
→ ENTER →
→ ENTER
Use to select PC, DVI or other external input sources connected to the LCD Display. Use to
select the screen of your choice.
1.
PC
2.
HDMI
3.
MagicInfo
Note
•
You can also select the source by pressing the SOURCE button on your remote.
Edit Name
MENU → ENTER →
→
,
→
→ ENTER →
→ ENTER
Name the input device connected to the input jacks to make your input source selection
easier.
Adjusting the LCD Display
VCR, DVD, Cable STB, HD STB, Satellite STB, AV Receiver, DVD Receiver, Game,
Camcorder, DVD Combo, DHR, PC
Picture [PC / MagicInfo Mode]
Available Modes
•
PC
•
HDMI
•
MagicInfo
MagicBright
MENU →
→
,
→ ENTER →
→ ENTER →
→ ENTER
MagicBright is a feature providing the optimum viewing environment depending on the contents of the image you are watching. Currently four different modes are available: Entertain, Internet, Text and Custom. Each mode has its own pre-configured brightness value.
(Not available when Dynamic Contrast mode is set to On.)
1.
Entertain
High brightness
For watching motion pictures such as from a DVD or VCR.
2.
Internet
Medium brightness
For working with a mixture of images such as texts and graphics.
3.
Text
Normal brightness
For documents or works involving heavy text.
4.
Custom
Although the values are carefully chosen by our engineers, the pre-configured values
may not be comfortable to your eyes depending on your taste.
If this is the case, adjust the brightness and contrast by using the OSD menu.
Adjusting the LCD Display
Custom
By using the on-screen menus, the contrast and brightness can be changed to your personal
preference.
MENU →
→ ENTER →
→
→ ENTER →
(Not available when Dynamic Contrast mode is set to On.)
Note
By adjusting the picture using the Custom function, MagicBright will change to Custom
mode.
Contrast
MENU →
→ ,
→ ENTER →
→
→ ENTER →
→ ENTER→
→ ENTER
Adjusts the Contrast.
Brightness
MENU →
→ ,
→ ENTER →
→
→ ENTER →
→
→ ENTER →
→ ENTER
Adjusts the Brightness.
Sharpness
MENU →
→ ,
→ ENTER →
→
→ ENTER →
→ ENTER
Adjusts the Sharpness.
Color Tone
MENU →
→ ENTER →
→
→
→ENTER →
→
→
→ ENTER →
Adjusting the LCD Display
→
,
→ ENTER
The color tones can be changed.
(Not available when Dynamic Contrast mode is set to On.)
1.
Off
2.
Cool
3.
Normal
4.
Warm
5.
Custom
Note
If you set the Color Tone to Cool, Normal, Warm, or Custom, the Color Temp function is
disabled.
If you set the Color Tone to Off, the Color Control function is disabled
Color Control
Adjusts individual Red, Green, Blue color balance.
MENU →
→ ENTER →
→
→
→ → ENTER →
(Not available when Dynamic Contrast mode is set to On.)
Note
If you adjust the picture by using the Color Control function, Color Tone will turn to the
Custom mode.
Red
MENU →
→
→ ,
→ ENTER →
→
→
→ → ENTER →
→ ENTER
→ ENTER
Green
MENU → → ENTER →
→
→ ,
→ → → → ENTER →
→ → ENTER
→ ENTER
Blue
MENU → → ENTER →
ENTER →
→
→
→ → ENTER →
→
→
→
Adjusting the LCD Display
→ ,
→ ENTER
Color Temp.
MENU →
→ ,
→ ENTER →
→
→
→ → ENTER →
→ ENTER
Color Temp is a measure of the 'warmth' of the image colors.
(Not available when Dynamic Contrast mode is set to On.)
Note
This function is only enabled if the Color Tone is set to Off.
Image Lock
Image Lock is used to fine-tune and get the best image by removing noise that creates
unstable images with jitters and shakiness. If satisfactory results are not obtained using the
Fine adjustment, use the Coarse adjustment and then use Fine again.
(Available in PC mode only)
(Not available when Dynamic Contrast mode is set to On.)
MENU →
→ ENTER →
→
→
→ → → ENTER →
MENU →
→
→ ENTER →
→
→
→ → → ENTER →
Coarse
→ ,
→ ENTER
→ ENTER
Removes noise such as vertical stripes. Coarse adjustment may move the screen image
area. You may relocate it to the center using the horizontal control menu.
Fine
MENU → → ENTER →
ENTER →
→ ,
→
→
→ → → ENTER →
→
→
→ ENTER
Removes noise such as horizontal stripes. If the noise persists even after Fine tuning, repeat
it after adjusting the frequency (clock speed).
Adjusting the LCD Display
H-Position
MENU → → ENTER →
→ ENTER →
→ ,
→
→
→ → → ENTER →
→
→
→
→ → → ENTER →
→
→
→ ENTER
Adjusts the screen location horizontally.
V-Position
MENU → → ENTER →
→ → ENTER →
→ ,
→
→ ENTER
Adjusts the screen location vertically.
Auto Adjustment
MENU →
→ ENTER →
→
→
→
→
→
→ ENTER →
The values of Fine, Coarse, Position are adjusted automatically. By changing the resolution
in the control panel, the auto function is performed.
(Available in PC mode only)
(Not available when Dynamic Contrast mode is set to On.)
Note
The direct button on the remote control is the 'AUTO' button.
Signal Balance
This is used to make up for the weak RGB signal transmitted by a long signal cable.
MENU →
→ ENTER →
→
→
→
→
→
→
(Available in PC mode only)
(Not available when Dynamic Contrast mode is set to On.)
Signal Balance
MENU → → ENTER →
→ ENTER →
→
→
→
→ → → → ENTER →
→ ENTER →
Adjusting the LCD Display
→
,
→ ENTER
Selects either On or Off with the signal control.
Signal Control
MENU → → ENTER →
→ ENTER → →
1.
→ ,
→ ENTER →
→ ENTER →
→
→
→
→ → →
→ ENTER →
→ ENTER →
→ ENTER
→
→
→
→ → →
→ → ENTER→
→ ENTER →
→ ENTER
→
→ ENTER →
→ ENTER → →
→ ENTER
B-Gain
MENU → → ENTER →
→ ENTER → →
→ ,
→ → → → → → → ENTER →
→ → → ENTER→
→ ENTER
→ ENTER
R-Offset
MENU → → ENTER →
→ ENTER → →
→ ,
5.
→ → → → ENTER →
G-Gain
→ ,
4.
→
→ ENTER
MENU →
3.
→
R-Gain
MENU →
2.
→
→ ENTER
G-Offset
→ → → → → → → ENTER →
→ → → → ENTER→
→ ENTER
Adjusting the LCD Display
MENU → → ENTER →
→ ENTER → →
→ ,
6.
→ → → → → → → ENTER →
→ → → → → ENTER→
→ ENTER
→ ENTER
B-Offset
MENU → → ENTER →
→ ENTER → →
ENTER
→ ,
→ → → → → → → ENTER →
→ → → → → → ENTER →
→
→ ENTER
Size
MENU →
→
,
→ ENTER →
→
→
→
→ → → → → ENTER →
→ ENTER
The Size can be switched.
(Not available when Dynamic Contrast mode is set to On.)
1.
16:9
2.
4:3
Dynamic Contrast
MENU →
→
,
→ ENTER →
→
→
→
→
→ →
→
→
→ ENTER →
→ ENTER
Dynamic Contrast automatically detects the distribution of the visual signal and adjusts to
create an optimum contrast.
Adjusting the LCD Display
1.
Off
2.
On
Brightness Sensor
MENU →
→
,
→ ENTER →
→
→
→
→ → → → → → → ENTER →
→ ENTER
Brightness Sensor automatically detects distribution of the inputted visual signal and adjusts
to create optimum brightness.
1.
Off
2.
On
Picture [ HDMI Mode]
Available Modes
•
PC
•
HDMI
•
MagicInfo
Mode
MENU →
→
,
→ ENTER →
→ ENTER →
→ ENTER
The LCD Display has four automatic picture settings ("Dynamic", "Standard", "Movie" and
"Custom") that are preset at the factory.
Dynamic, Standard, Movie, or Custom can be activated.
(Not available when Dynamic Contrast mode is set to On.)
1.
Dynamic
2.
Standard
Adjusting the LCD Display
3.
Movie
4.
Custom
Custom
By using the on-screen menus, the contrast and brightness can be changed to your personal
preference.
MENU →
→ ENTER →
→
→ ENTER →
(Not available when Dynamic Contrast mode is set to On.)
Contrast
MENU →
→ ,
→ ENTER →
→
→ ENTER →
→ ENTER→
→ ENTER
Adjusts the Contrast.
Brightness
MENU →
→ ,
→ ENTER →
→
→ ENTER →
→
→ ENTER →
→ ENTER
Adjusts the Brightness.
Sharpness
MENU →
→ ,
→ ENTER →
→
→ ENTER →
→
→
→ ENTER →
→ ENTER
Adjusts the picture Sharpness.
Color
MENU →
→
→ ,
→ ENTER →
→ ENTER
Adjusts the picture Color.
→
→ ENTER →
→
→
→
→ ENTER
Adjusting the LCD Display
Tint
MENU →
→
→ ,
→ ENTER →
→
→ ENTER →
→
→
→
→
→ → → ENTER
→ ENTER
Adds a natural tone to the display.
Color Tone
MENU →
→
,
→ ENTER →
→ ENTER →
→ ENTER
The color tones can be changed. The individual Color components are also user adjustable.
(Not available when Dynamic Contrast mode is set to On.)
1.
Off
2.
Cool2
3.
Cool1
4.
Normal
5.
Warm1
6.
Warm2
Note
If you set the Color Tone to Cool2, Cool1, Normal, Warm1, or Warm2, the Color Temp
function is disabled.
Color Temp.
MENU →
→ ,
→ ENTER →
→
→ → → ENTER →
→ ENTER
Color temp. is a measure of the 'warmth' of the image colors.
(Not available when Dynamic Contrast mode is set to On.)
Adjusting the LCD Display
Note
This function is only enabled if the Color Tone is set to Off.
Size
MENU →
→
,
→ ENTER →
→
→
→
→ → ENTER →
→ ENTER
The Size can be switched.
1.
16:9
2.
Zoom 1
3.
Zoom 2
4.
4:3
5.
Just Scan
Note
The Zoom1, Zoom2 are unavailable in HDMI mode.
Digital NR (Digital Noise Reduction)
MENU →
→
,
→ ENTER →
→
→
→
→ → → ENTER →
→ ENTER
Turns the Digital Noise Reduction feature Off/On. The Digital Noise Reduction feature allows
you to enjoy clearer and crisper images.
1.
Off
2.
On
Adjusting the LCD Display
Note
Digital NR function is not available for all resolutions.
Film Mode
MENU →
→
,
→ ENTER →
→
→
→
→
→
→
→ ENTER →
→ ENTER
The Film Mode feature offers you a theater-quality viewing experience.
(In HDMI mode, this function is available when the input signal is interlaced scan; it is not
available in progressive scan.)
1.
Off
2.
On
Dynamic Contrast
→ ENTER →
MENU →
→
,
→
→
→
→
→
→
→
→ ENTER →
→ ENTER
Dynamic Contrast automatically detects the distribution of the visual signal and adjusts to
create an optimum contrast.
1.
Off
2.
On
Brightness Sensor
MENU →
→ ENTER →
→
→
→
→ → → → → →
→ ENTER →
Adjusting the LCD Display
→
,
→ ENTER
Brightness Sensor automatically detects distribution of the inputted visual signal and adjusts
to create optimum brightness.
1.
Off
2.
On
Sound
Available Modes
•
PC
•
HDMI
•
MagicInfo
Mode
MENU →
→
,
→ → ENTER →
→ ENTER →
→ ENTER
The LCD Display has a built-in high fidelity stereo amplifier.
1.
Standard
Selects Standard for the standard factory settings.
2.
Music
Selects Music when watching music videos or concerts.
3.
Movie
Selects Movie when viewing movies.
4.
Speech
Selects Speech when watching a show that is mostly dialog (i.e., news).
5.
Custom
Selects Custom if you want to adjust the settings according to your personal preferences.
Custom
The sound settings can be adjusted to suit your personal preferences.
Adjusting the LCD Display
MENU →
→ → ENTER →
→ → ENTER →
Note
•
You can hear the sound even when sound value is set to 0.
•
If you adjust sound using Custom function, Mode will turn to Custom mode.
Bass
MENU →
→ ,
→ → ENTER →
→ → ENTER →
→ENTER→
→ ENTER
Emphasizes low frequency audio.
Treble
MENU →
→ ,
→
→ ENTER →
→ → ENTER →
→
→ ENTER →
→ ENTER
Emphasizes high frequency audio.
Balance
MENU →
→ ,
→ → ENTER →
→ → ENTER →
→
→
→ ENTER
Allows you to Adjusts the sound balance between the left and right speakers.
Auto Volume
MENU →
→
,
→ → ENTER →
→ → → ENTER →
→ ENTER
Reduces the difference in volume control between broadcasters.
→ ENTER →
Adjusting the LCD Display
1.
Off
2.
On
SRS TS XT
MENU →
→
,
→ → ENTER →
→ → → → ENTER →
→ ENTER
SRS TS XT is a patented SRS technology that solves the problem of playing 5.1 multichannel
content over two speakers. TruSurround delivers a compelling, virtual surround sound experience through any two-speaker playback system, including internal television speakers. It
is fully compatible with all multichannel formats.
1.
Off
2.
On
Setup
Available Modes
•
PC
•
HDMI
•
MagicInfo
Language
MENU →
→
,
→ → → ENTER →
→ ENTER
You can choose one of 13 languages.
→ ENTER →
Adjusting the LCD Display
Note
The language chosen affects only the language of the OSD. It has no effect on any software
running on the computer.
Time
Selects from one of 4 time settings, Clock Set, Sleep Timer, On Timer, and Off Timer.
MENU →
→ → → ENTER →
→
→ ENTER →
Clock Set
→
→
→ ENTER
,
/ ,
→
→ ENTER →
MENU →
→
→ ENTER →
→ ENTER→
Current Time Setting.
Sleep Timer
MENU →
→
,
→ → → ENTER →
→
→ ENTER →
→ ENTER
Turns the LCD Display off automatically at certain times.
1.
Off
2.
30
3.
60
4.
90
5.
120
6.
150
→
→ ENTER→
Adjusting the LCD Display
7.
180
On Timer
MENU →
→
,
/ ,
→ → → ENTER →
→
→ ENTER →
→ →
→ ENTER→
→ ENTER
Turns the LCD Display on automatically at a preset time. Controls the mode and the volume
level at the time the LCD Display turns on automatically.
Off Timer
MENU →
→
→
,
/ ,
→ → → ENTER →
→
→ ENTER →
→ ENTER
Turns the LCD Display off automatically at a preset time.
Menu Transparency
MENU →
→
,
→ → → ENTER →
→ →
→ ENTER →
→ ENTER
Change the transparency of the background of the OSD.
1.
High
→ → →
→ ENTER
Adjusting the LCD Display
2.
Medium
3.
Low
4.
Opaque
Safety Lock
Change PIN
MENU → → → → ENTER →
ENTER→ [Change PIN]
→ → →
→ ENTER → [Safety Lock ]→
→ → →
→ ENTER → [Safety Lock ]→
→ [0~9]→ [0~9]→ [0~9]→ [0~9]
The password can be changed.
Lock On
MENU → → → → ENTER →
ENTER→ → ENTER→[Lock On]
→ [0~9]→ [0~9]→ [0~9]→ [0~9]
Turns Off/On the Video Wall function of the selected display Off/On.
Energy Saving
MENU →
→
,
→ → → ENTER →
→ → → →
→ ENTER →
→ ENTER
This feature adjusts the power consumption of the unit in order to save energy.
Adjusting the LCD Display
1.
Off
2.
On
HDMI Black Level
MENU →
→
,
→
→
→ ENTER →
→
→
→
→
→
→ ENTER →
→ ENTER
When a DVD or set-top box is connected to your TV via HDMI, it may cause a degradation
in the screen quality, such as an increase in the black level, a low contrast, or discoloration,
etc., depending on the external device connected. In this case, adjust the screen quality of
your TV by configuring the HDMI black level.
1.
Normal
2.
Low
Video Wall
A Video Wall is a set of video screens connected together, so that each screen shows a part
of the whole picture or where the same picture is repeated on each screen.
When the Video Wall is on, you can adjust the Video Wall screen setting.
MENU →
→
→
→ ENTER →
→
→
→
→
→
→
→ ENTER →
Note
When Video Wall is running, the Auto Adjustment, Image Lock, and Size functions are not
available. Video Wall does not operate in MagicInfo mode.
Video Wall
MENU → → → → ENTER →
→ ENTER →
→
,
→ ENTER
→ → → → → → → ENTER →
Adjusting the LCD Display
Turns Off/On the Video Wall function of the selected display Off/On.
1.
Off
2.
On
Format
MENU → → → → ENTER →
→ → ENTER →
→
,
→ → → → → → → ENTER →
→ ENTER
The Format can be selected to see a divided screen.
1.
Full
Provides a full screen without any margins.
2.
Natural
Displays a natural image with the original aspect ratio intact.
Horizontal
MENU → → → → ENTER →
→ → → ENTER →
→
,
→ → → → → → → ENTER →
→ ENTER
Sets how many parts the screen should be divided horizontally.
Five adjustment levels: 1, 2, 3, 4, and 5.
Vertical
MENU → → → → ENTER →
→ → → → ENTER →
→ → → → → → → ENTER →
Adjusting the LCD Display
→
,
→ ENTER
Sets how many parts the screen should be divided vertically.
Five adjustment levels: 1, 2, 3, 4, and 5.
Screen Divider
MENU → → → → ENTER →
→ → → → → ENTER →
→ → → → → → → ENTER →
The screen can be divided into several images. A number of screens can be selected with a
different layout when dividing.
•
Select a mode in Screen Divider.
•
Select a display in Display Selection.
•
The selection will be set up by pressing a number in the selected mode.
Safety Screen
The Safety Screen function is used to prevent afterimages that may appear when a still
picture is displayed on the screen over a long time.
•
The Safety Screen function scrolls the screen for the specified period of time.
•
This function is not available when the power is turned off.
MENU →
→ → → ENTER →
→ → → →
→
→
→ → → ENTER →
→ ENTER →
→ → → →
→ ENTER →
→
→ → → ENTER →
→ , → ENTER
→
→ ENTER →
Pixel Shift
Pixel Shift
MENU →
Adjusting the LCD Display
To prevent after-images on the screen you can use this function have pixels move on the
LCD in the horizontal or vertical direction.
1.
Off
2.
On
Horizontal Dot
MENU →
→ → → ENTER →
→ ENTER →
→ → → → →
→ → ENTER →
→
→
→ ENTER →
→ , →
→ → → → → →
→ → → ENTER →
→
→ ENTER →
→ , →
ENTER
Sets how many pixels the screen moves horizontally.
Five adjustment levels: 0, 1, 2, 3, and 4.
Vertical Line
MENU →
→ → → ENTER →
→ ENTER →
ENTER
Sets how many pixels the screen moves vertically.
Five adjustment levels: 0, 1, 2, 3, and 4.
Time
MENU →
→ → → ENTER →
→ ENTER →
→ → → → → →
→ → → → ENTER →
→ → ENTER →
→ , → ENTER
Adjusting the LCD Display
Set the time interval for performing the horizontal or vertical movement, respectively.
Timer
Timer
MENU →
→ → → ENTER →
→ → ENTER →
→ → → →
→ ENTER →
→ → → → ENTER →
→ , → ENTER
You can set the timer for Screen Burn Protection.
If you start the operation to erase any residual image, the operation will be performed for the
set period of time and then automatically finish.
1.
Off
2.
On
Mode
MENU →
→ → → ENTER →
→ → ENTER →
→
You can change the Safety Screen Type.
1.
Scroll
2.
Bar
3.
Eraser
→ → → →
→ ENTER →
→
→ → → ENTER →
→ , → ENTER
Adjusting the LCD Display
Period
MENU →
→ → → ENTER →
→ → ENTER →
→
→ → → → →
→ → ENTER →
→
→ → ENTER →
→ , → ENTER
Use this function to set the execution period for each mode set in the timer.
Time
MENU →
→ → → ENTER →
→ → ENTER →
→ → → → → →
→ → → → ENTER →
→ → ENTER →
→ , → ENTER
Within the set period of time specify a time for execution.
•
Mode-Scroll : 1~5 sec
•
Mode-Bar, Eraser : 10~50 sec
Scroll
MENU →
→ → → ENTER →
→ → → ENTER →
→ → → →
→
→
→
→ ENTER →
This function helps to remove after-images on the screen by moving all the pixels on the LCD
according to a pattern.
Use this function when there are remaining after-images or symbols on the screen, especially
when you displayed a still image on the screen for a long time.
Adjusting the LCD Display
Bar
MENU →
→ → → ENTER →
→ → → →
→ → → →ENTER →
→
→
→
→ ENTER →
This function prevents after-images on the screen by moving long black and white vertical
lines.
Eraser
MENU →
→ → → ENTER →
→ → → →
→ → → → →ENTER →
→
→
→
→ ENTER →
This function prevents after-images on the screen by moving a rectangular pattern.
Resolution Select
MENU →
→
→
,
→ → → ENTER →
→ → → →
→
→
→
→
→ENTER
→ ENTER
When the picture is not displayed properly on the screen when setting the graphics card
resolution of the computer to 1024 x 768 @ 60Hz, 1280 x 768 @ 60Hz, 1360 x 768 @ 60Hz
or 1366 x 768 @ 60Hz, by using this function(Resolution Select), you can have the picture
displayed on the screen in the specified resolution.
Note
Available in PC mode only
Adjusting the LCD Display
1.
Off
2.
1024 x 768
3.
1280 x 768
4.
1360 x 768
5.
1366 x 768
Note
Selecting the menu is only allowed when the graphics resolution is set to 1024 x 768 @ 60Hz,
1280 x 768 @ 60Hz, 1360 x 768 @ 60Hz or 1366 x 768 @ 60Hz.
Power On Adjustment
MENU →
→
→
,
→ → → ENTER →
→ → → →
→
→
→
→
→ → ENTER
→ ENTER
Adjusts the Power On time for the screen.
Side Gray
MENU → → → → ENTER →
ENTER →
→
,
→ → → →
→ ENTER
Select the brightness of the grey for the screen background.
1.
Off
2.
Light
3.
Dark
→
→
→
→
→ → →
Adjusting the LCD Display
Reset
Reverts the product settings to factory defaults. The Reset function is only available when
PC / DVI is being used.
MENU → → → → ENTER →
→ ENTER →
→ → → →
→
→
→
→
→ → →
→ → → →
→
→
→
→
→ → →
→ → → →
→
→
→
→
→ → →
→ → → →
→
→
→
→
→ → →
Image Reset
MENU → → → → ENTER →
→ ENTER →
→ ENTER →
→ , → ENTER
Note
Available in PC mode only
Note
The Reset function is not available when Video Wall is On.
Color Reset
MENU → → → → ENTER →
→ ENTER →
→ → ENTER →
→ ,
→ ENTER
OSD Rotation
MENU →
→ → → ENTER →
→ → → ENTER →
→ ,
→ ENTER
OSD Rotate
1.
Landscape
2.
Portrait
Adjusting the LCD Display
Lamp Control
MENU → → → → ENTER →
→ → ENTER →
→ ,
→ → → →
→
→
→
→
→ → →
→ ENTER
Adjusts the inverter lamp in order to reduce energy consumption.
Note
Not available when Dynamic Contrast mode is set to On.
Multi Control
Available Modes
•
PC
•
HDMI
•
MagicInfo
Multi Control
Assigns an individual ID to the SET.
MENU →
→ → →
→ ENTER →
→ ENTER
→ , → [0~9]
•
ID Setup
Assigns distinctive IDs to the SET.
•
ID Input
Use to select the transmitter functions of the individual SET. Only a SET where the ID
corresponds to the transmitter setting becomes activated.
MagicInfo
Available Modes
•
PC
•
HDMI
Adjusting the LCD Display
•
MagicInfo
Note
•
The remote control can be used to select MagicInfo. However, it is recommended to use
a separate USB keyboard to utilize MagicInfo fully.
•
For MagicInfo in Device mode, moving external devices while booting may cause errors.
Set up external devices only if the LCD Display turns on.
•
Do not unplug the LAN cable used for the network (ex: video display). Otherwise, the
program (MagicInfo) may stop. If you do unplug the cable, restart the system.
•
Do not unplug the LAN cable used by an USB device (ex: video display). Otherwise, the
program (MagicInfo) may stop.
•
To access other sources, press the SOURCE button in MagicInfo.
•
The preset password for the LCD Display is "000000".
•
The server program's Power-On option works only if the LCD Display's power is completely shut off.
Please make sure not to use the Power-On option when the LCD Display is in the process
of shutting down since this may cause system errors on the LCD Display.
•
In the OSD image of MagicInfo, Network mode is the same as Device.
•
When using MagicInfo with the MagicInfo Server Program: perform Network mode.
•
When using MagicInfo with the device directly connected to LCD Display : execute Device
mode.
•
Press ALT + F12 to directly go to the MagicInfo Window screen.
•
To setup MagicInfo on a Windows screen, a keyboard and mouse are required.
•
To setup MagicInfo on a Windows screen, refer to the MagicInfo Server Help.
It is highly recommended not to turn off the AC power during an operation.
•
For pivoted LCD Displays, ticker transparency is not supported.
•
For pivoted LCD Displays, a screen resolution of up to 720*480(SD) is supported for
movies.
•
For drive D:, EWF is not applied.
•
To save Setup contents that have been changed when EWF is in the Enable state, you
must Commit them.
•
By selecting Disable, Enable or Commit, the system is restarted.
MagicInfo
1. Select Application - step 1
Adjusting the LCD Display
You can select an Application to be executed in your computer when Windows starts.
2. Select TCP/IP - step 2
In step 2 of MagicInfo Setup Wizard, you don’t have to go to Network Setting on the desktop
to make your settings for TCP/IP. You just do that at step 2 of MagicInfo installation.
3. Select Language - step 3
Adjusting the LCD Display
When using multiple languages, you can choose and set a specific language among them.
4. Select Screen Type - step 4
You can select which rotation type will be applied to your device.
5. Setup Information
Adjusting the LCD Display
Shows the settings that have been selected by the user.
Note
If the MagicInfo icon is not displayed on the notification area, double click the MagicInfo
icon on the window desktop. The icon will appear.
Troubleshooting
Self-Test Feature
Note
Before you call for assistance, run a self-test to see if the monitor is working correctly. Contact
a Service Center for problems that you cannot solve by yourself.
Running a Self-Test
1.
Turn off both your computer and the LCD Display.
2.
Unplug the video cable from the back of the computer.
3.
Turn on the LCD Display.
The figure shown below ("Check Signal Cable") appears on a black background when
the LCD Display is working normally even though no video signal is detected: While in
the Self-Test mode, the LED power indicator remains green and the figure moves around
on the screen.
4.
Turn off your LCD Display and reconnect the video cable; and then turn on both your
computer and the LCD Display
If your LCD Display screen remains blank after you've run a self-test, check your video controller and computer system. Your LCD Display is functioning properly.
Warning Messages
If you set your monitor to a resolution and refresh rate it does not support, you will see the
message below for a minute on your screen. During that minute, you must reset the resolution
and refresh rate to a supported refresh rate and resolution. If the refresh rate is more than
85Hz, you will see a black screen because the LCD Display does not support a refresh rate
over 85Hz.
Note
Refer to Specifications > Preset Timing Modes for the resolutions and frequencies supported
by the LCD Display. Your LCD Display automatically supports the Preset Timing Modes.
Maintenance and Cleaning
1) Maintaining the LCD Display Case
Clean with a soft cloth after disconnecting the power cord.
Troubleshooting
•
Do not use benzene, thinner or other flammable substances.
2) Maintaining the Flat Panel Display Screen.
Clean with a soft cloth (cotton flannel).
•
Never use acetone, benzene or thinner.
(They may cause flaws or deformation of the screen
surface.)
•
The user is responsible for any damage caused by
using these substances.
Symptoms and Recommended Actions
Note
A LCD Display recreates visual signals received from the computer. Therefore, if there is a
problem with the computer or the video card, this can cause the LCD Display to become
blank, have poor coloring, become noisy, etc. If you are having one of thes problems, perform
the following checks on your computer.
1.
Check if the power cord and the video cables are properly connected to the computer.
2.
Check if the computer beeps more than 3 times when booting. If it does, it may need
service.
3.
If you installed a new video card or if you assembled the PC, check if you installed the
video adaptor driver.
4.
Check if the scanning ratio of the video screen is set to between 50 Hz ~ 85 Hz.
Important: Do not exceed 60Hz when using the maximum resolution.
5.
If you have problems in installing the video adaptor driver, boot the computer in Safe
Mode, remove the Display Adaptor in the "Control Panel −> System −> Device Administrator" and then reboot the computer to reinstall the video adaptor driver.
Check List
Note
•
The following sections lists possible problems and their solutions. Before calling for assistance, check the information in this section to see if you can remedy any problems for
yourself. If you do need assistance, please call the phone number on the Information
section or contact your dealer.
•
For more network-related information, refer to the MagicInfo Troubleshooting section.
Problems Related to the Installation (PC Mode)
Note
Problems related to the LCD Display installation and their solutions are below.
Q:
The LCD Display screen flickers.
Troubleshooting
A:
Check if the signal cable between the computer and the LCD Display is securely connected.
(Refer to Connecting a Computer)
Problems Related to the Screen
Note
Problems related to the LCD Display screen and their solutions are listed below.
Q:
The screen is blank and the power indicator is off.
A:
Ensure that the power cord is firmly connected and the LCD Display is on.
(Refer to Connecting a Computer)
Q:
"Check Signal Cable" message.
A:
Ensure that the signal cable is firmly connected to the PC or video sources.
(Refer to Connecting a Computer)
A:
Ensure that the PC or video sources are turned on.
Q:
"Not Optimum Mode" message.
A:
Check the maximum resolution and the frequency of the video adaptor.
A:
Compare these values with the data in the Preset Timing Modes Chart.
Q:
The picture rolls vertically.
A:
Check if the signal cable is securely connected. Re-connect it, if necessary.
(Refer to Connecting a Computer)
Q:
The image is not clear; picture is blurred.
A:
Run Frequency Coarse and Fine tuning.
A:
Turn on again after removing all accessories (video extension cable, etc.)
A:
Set the resolution and frequency to the recommended ranges.
Q:
The picture image is unstable and shakes.
A:
Check if the resolution and frequency set for the computer video card falls in the range
supported by the LCD Display. If not, reset them referring to the current Information
under the LCD Display menu and Preset Timing Modes
Q:
Ghost images appear in the picture.
A:
Check if the resolution and frequency set for the computer video card falls in the range
supported by the LCD Display. The optimum resolution and refresh rate for this monitor
is listed in the Specifications section under General Specifications. Other supported
resolutions and refresh rates are listed in the Preset Timing Modes table also in the
Specifications section.
Q:
The image is too light or too dark.
A:
Adjust the brightness and contrast.
Troubleshooting
(Refer to the Brightness, Contrast)
Q:
The screen color is inconsistent.
A:
Adjust color using Color under Custom in the Picture OSD menu.
Q:
The color image is distorted by dark shadows.
A:
Adjust color using Custom under OSD Color Adjustment menu.
Q:
The color white is poor.
A:
Adjust the color using Color under Custom in the Picture OSD menu.
Q:
The Power Indicator blinks.
A:
The LCD Display is currently saving the changes made in the settings to the OSD
memory.
Q:
The screen is blank and the power indicator light blinks every 0.5 or 1 seconds.
A:
The LCD Display is using its power management system. Press any key on the keyboard.
Q:
The screen is blank and it is blinking.
A:
If you see the "TEST GOOD" message on the screen when you pressing the MENU
button, check the cable connection between the LCD Display and the computer to ensure that the connector is properly connected.
Problems Related to Audio
Note
Problems related to audio signals and their solutions are listed below.
Q:
No sound.
A:
Ensure that the audio cable is firmly connected to both the audio-in port on your LCD
Display and the audio-out port on your sound card.
(Refer to Connecting a Computer)
A:
Also, check the volume level.
Q:
The sound level is too low.
A:
Check the volume level.
A:
Also, if the volume is still too low after turning the control to its maximum, check the
volume control on the computer sound card or software program.
Q:
The sound is too high or too low.
A:
Adjust the Treble and Bass to the appropriate levels.
Problems Related to the Remote Control
Note
Problems related to the remote control and their solutions are listed below.
Q:
The remote control buttons do not respond.
Troubleshooting
A:
Check if the batteries are empty.
A:
Check if the power is on.
A:
Check if the power cord is securely connected.
A:
Check if a special fluorescent or neon lamp is on in the vicinity.
Q:
How can I change the frequency?
A:
Windows XP:
Q&A
Click Start > Settings > Control Panel > Appearance and Themes > Display > Settings
> Advanced > Monitor Tab. Then, select the refresh rate frequency. The optimum refresh rate is 60 Hz..
A:
Windows ME./2000:
Click Control Panel > Display > Settings > Advance > Monitor Tab. Then, select the
refresh rate frequency. The optimum refresh rate is 60 Hz.
Q:
How can I adjust the resolution?
A:
Windows XP:
Set the resolution in the Control Panel→ Appearance and Themes → Display→ Settings.
A:
Windows ME/2000:
Set the resolution in the Control Panel→ Display→ Settings.
* Contact the video card manufacturer for details.
Q:
How can I set the Power Saving function?
A:
Windows XP:
Click Start > Settings > Control Panel → Appearance and Themes → Display → Screen
Saver.
Set the function in the BIOS-SETUP of the computer. (Refer to the Windows / Computer
Manual).
A:
Windows ME/2000:
Click Start > Settings > Control Panel → Display → Screen Saver.
Set the function in the BIOS-SETUP of the computer. (Refer to the Windows / Computer
Manual).
Q:
How can I clean the outer case/LCD Panel?
A:
Disconnect the power cord, and then clean the LCD Display with a soft cloth moistened
with a small amount of an LCD screen cleaning solution or plain water.
Do not leave any detergent or scratches on the case. Do not let any water enter the
LCD Display. Do not spray any liquid onto the LCD display. Spray on the cloth only.
Q:
How can I play the video?
Troubleshooting
A:
The video supports the MPEG1 and WMV codecs only. Install the corresponding codec
to play the video. Note that some of the codecs can be incompatible.
Note
Before calling for assistance, check the information in this section to see if you can remedy
any problems yourself. If you do need assistance, please call the phone number on the Information section or contact your dealer.
Specifications
General
General
Model Name
SyncMaster 230TSN, 230MXN
LCD Panel
Size
23 inches (58 cm)
Display area
509.76 mm (H) x 286.74 mm (V)
Pixel Pitch
0.2655 mm (H) x 0.2655 mm (V)
Synchronization
Horizontal
31 ~ 81 kHz
Vertical
56 ~ 75 Hz
Display Color
16.7 M
Synchronization
Optimum resolution
1920 x 1080 @ 60 Hz
Maximum resolution 1920 x 1080 @ 60 Hz
Input Signal, Terminated
1 RGB Analog, HDMI
0.7 Vp-p ±5 %
Separate H/V sync, Composite, SOG
TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock
164MHz (Analog,Digital)
Power Supply
This product supports 100 – 240 V.
Since the standard voltage may differ from country to country, please check the
label on the back of the product.
Less than 30Ap-p at AC 120V or 50Ap-p at AC 220V
Signal Connectors
D-sub, HDMI, RS232C In, PC Audio(Stereo) In, Audio Out, LAN, USB(4port), VGA
OUT(Network)
Dimensions (W x H x D) / Weight
SyncMaster 230TSn 557.5 x 339.0 x 79.2 mm / 21.9 x 13.3 x 3.1 inches / 8.35
kg / 18.4 lb
Specifications
Dimensions (W x H x D) / Weight
SyncMaster 230MXn 557.5 x 339.0 x 73.9 mm / 21.9 x 13.3 x 2.9 inches / 7 kg /
15.4 lb
VESA Mounting Interface
100 x 100mm
Environmental considerations
Operating
Temperature : 50°F ~ 104°F (10°C ~ 40°C)
Humidity : 10 % ~ 80 %, non-condensing
Storage
Temperature : -4°F ~ 113°F (-20°C ~ 45°C)
Humidity : 5 % ~ 95 %, non-condensing
Plug and Play Capability
This LCD Display can be installed on any Plug & Play compatible system. The
interaction of the LCD Display and the computer systems will provide the best operating conditions and LCD Display settings. In most cases, the LCD Display
installation will proceed automatically, unless the user wishes to select alternate
settings.
Dot Acceptable
TFT-LCD panels manufactured using advanced semiconductor technology with a
precision of 1ppm (one part per million) and above are used for this product.
Sometimes, pixels of RED, GREEN, BLUE and WHITE color appear to be bright
or some black pixels may be seen. This does not indicated bad quality and you can
use the monitor without any problems.
The number of TFT-LCD sub pixels contained in this product are 6,220,800.
Note
Design and specifications are subject to change without prior notice.
Class B Equipment (Information Communication equipment for residential use)
This product complies with the Electromagnetic Compatibility Directives for residential use
and can be used in all areas including common residential areas. (Class B equipment emits
less electromagnetic waves than Class A equipment.)
(USA only)
Dispose unwanted electronics through an approved recycler.
To find the nearest recycling location, go to our website:
www.samsung.com/recyclingdirect Or call, (877) 278 - 0799
PowerSaver
This LCD Display has a built-in power management system called PowerSaver. This system
saves energy by switching your LCD Display to low-power mode when it has not been used
for a certain amount of time. The LCD Display automatically returns to normal operation when
you press a key on the keyboard. For energy conservation, turn your LCD Display OFF when
it is not needed, or when leaving it unattended for long periods. The PowerSaver system
operates with a VESA DPM compliant video card installed in your computer. Use the software
utility installed on your computer to set up this feature.
Specifications
State
Normal Operation
Power saving
mode
Power off
Power Indicator
On
Blinking
Off
Power Consumption
80 watts
5 watts
0 watts
Preset Timing Modes
If you select one of the standard Display Modes listed below (for example, 800x600 or
1360x768), your monitor will automatically adjust your screen to the correct Horizontal and
Vertical frequency. However, if you attempt to use a non-standard Display Mode, the screen
may go blank even though the power LED indicates the monitor is on. Note that the optimum
and recommended Display Mode for this monitor is 1920x1080 with a refresh rate of 60 Hz.
If you select a Display Mode of 1920x1080, your monitor will automatically adjust your screen
to the correct Horizontal and Vertical frequency.
Display Mode
Horizontal Vertical Fre- Pixel Clock Sync Polarity
Frequency quency (Hz)
(MHz)
(H/V)
(kHz)
IBM, 640 x 350
31.469
70.086
25.175
+/-
IBM, 720 x 400
31.469
70.087
28.322
-/+
MAC, 640 x 480
35.000
66.667
30.240
-/-
MAC, 832 x 624
49.726
74.551
57.284
-/-
VESA, 640 x 480
31.469
59.940
25.175
-/-
VESA, 640 x 480
37.861
72.809
31.500
-/-
VESA, 640 x 480
37.500
75.000
31.500
-/-
VESA, 800 x 600
35.156
56.250
36.000
+/+
VESA, 800 x 600
37.879
60.317
40.000
+/+
VESA, 800 x 600
48.077
72.188
50.000
+/+
VESA, 800 x 600
46.875
75.000
49.500
+/+
VESA, 1024 x 768
48.363
60.004
65.000
-/-
VESA, 1024 x 768
56.476
70.069
75.000
-/-
VESA, 1152 x 864
67.500
75.000
108.000
+/+
VESA, 1280 x 800
49.702
59.810
83.500
-/+
VESA, 1280 x 800
62.795
74.934
106.500
-/+
VESA, 1280 x 960
60.000
60.000
108.000
+/+
VESA, 1280 x 1024
63.981
60.020
108.000
+/+
VESA,1440 x 900
55.935
59.887
106.500
-/+
VESA,1440 x 900
70.635
74.984
136.750
-/+
VESA,1600 x 1200
75.000
60.000
162.000
+/+
VESA,1680 x 1050
65.290
59.954
146.250
-/+
VESA,1920 x 1080
67.500
60.000
148.500
+/+
Horizontal Frequency
The time to scan one line connecting the right edge
to the left edge of the screen horizontally is called the
Horizontal Cycle and the inverse number of the Hor-
Specifications
izontal Cycle is called the Horizontal Frequency.
Unit: kHz
Vertical Frequency
Like a fluorescent lamp, the screen has to repeat the
same image many times per second to display an
image to the user. The frequency of this repetition is
called the Vertical Frequency or Refresh Rate. Unit:
Hz
Information
For Better Display
For the best picture quality, adjust the computer resolution and screen injection
rate (refresh rate) on the computer to the resolution and refresh rate listed below..
•
Resolution: 1920 X 1080
•
Vertical frequency (refresh rate): 60 Hz
TFT-LCD panels manufactured using advanced semiconductor technology
with a precision of 1ppm (one part per million) and above are used for this product.
Sometimes, the pixels of RED, GREEN, BLUE and WHITE color seem to be bright
or some black pixels may be seen. This does not indicate bad quality and you can
use the monitor without any problems.
•
The number of TFT-LCD sub pixels contained in this product is 6,220,800.
To clean the monitor and the panel outside, apply the recommended small
amount of cleaner to a clean, soft cloth and then rub softly, especially when cleaning the LCD area. Using excessive force can permanently damage the screen.
If you are not satisfied with the picture quality, you can get a better quality
picture by using the Auto Adjustment function in the OSD Menu. If there's still noise
after the automatic adjustment, use the Fine/Coarse adjustment functions. Note
that the Auto Adjustment functon works in Analog mode only.
When viewing a fixed screen for an extended period of time, a residual image
or blurriness may appear. To prevent this, change the mode to energy save or set
up a screensaver that displays a moving the picture when you need to be away
from the monitor for an extended period of time.
PRODUCT INFORMATION (Image Retention Free)
LCD Monitors and TVs may have image retention when switching from one image to another
especially after displaying a stationary image for a long time.
This guide is to demonstrate correct usage of LCD products in order to protect them from
Image retention.
Warranty
Warranty does not cover any damage caused by image retention.
Burn-in is not covered by the warranty.
What is Image retention ?
During normal operation of a LCD panel, pixel image retention doesn't occur. However, if the same image is displayed for a long time, a slight difference in electric
charge accumulates between the two electrodes which encase the liquid crystal.
This may cause the liquid crystal to build up in a certain areas of the display. Thus,
the previous image is retained when switching to a new video image. All display
products, including LCD, are subject to image retention. This is not a product defect.
Information
Please follow the suggestions below to protect your LCD from image retention.
Power Off, Screen Saver, or Power Save Mode
Ex)
•
•
Turn the power off when using a stationary pattern.
•
Turn the power off for 4 hours after 20 hours in use
•
Turn the power off for 2 hours after 12 hours in use
Use a Screen saver if possible
•
•
Screen saver in one color or a moving image is recommended.
Set the Monitor to power off with the PC Display Properties Power Scheme.
Suggestions for specific applications
Ex) Airports, Transit Stations, Stock Markets, Banks, and Controlling Systems We
recommend that you follow set up of your display system program as below:
Display Information together with Logo or Moving image cycle.
Ex) Cycle : Display Information for 1 hour followed by a Display Logo or moving
image for 1 minute.
Change the Color Information periodically (Use 2 different colors).
Ex) Rotate the Color Information with 2 colors every 30 minutes.
Avoid using a combination of characters and background color with large difference
in luminance.
Avoid using Grey colors, which can cause Image retention easily.
•
Avoid: Colors with big difference in luminance (Black & White, Grey)
Ex)
•
Recommended settings: Bright colors with little difference in luminance
•
Change the characters color and background color every 30 minutes
Ex)
Information
•
Every 30 minutes, change the characters with movement.
Ex)
The best way to protect your monitor from Image retention is to set your PC or
System to operate a Screen Saver program when you are not using it.
Image retention may not occur when a LCD panel is operated under normal conditions.
Normal conditions are defined as continuously changing video patterns. When the
LCD panel is operated for a long time with a fixed pattern (-over 12 hours-), there
may be slight difference in voltage between electrodes that work the liquid crystal
(LC) in a pixel. The voltage difference between electrodes increases with time,
forcing the liquid crystal to lean. When this occurs, the previous image may be seen
when the pattern is changed.
To prevent this, the accumulated voltage difference must be decreased.
Information
Our LCD Monitor satisfies ISO13406-2 Pixel fault Class II
Appendix
Contact SAMSUNG WORLDWIDE
Note
If you have any questions or comments relating to Samsung products, please contact the
SAMSUNG customer care center.
North America
CANADA
1-800-SAMSUNG (726-7864) www.samsung.com
MEXICO
01-800-SAMSUNG
(726-7864)
U.S.A
1-800-SAMSUNG(726-7864) www.samsung.com
www.samsung.com
Latin America
ARGENTINA
0800-333-3733
http://www.samsung.com
BRAZIL
0800-124-421, 4004-0000
http://www.samsung.com
CHILE
800-SAMSUNG (726-7864)
http://www.samsung.com
COLOMBIA
01-8000112112
http://www.samsung.com
COSTA RICA
0-800-507-7267
http://www.samsung.com
DOMINICA
1-800-751-2676
http://www.samsung.com
ECUADOR
1-800-10-7267
http://www.samsung.com
EL SALVADOR
800-6225
http://www.samsung.com
GUATEMALA
1-800-299-0013
http://www.samsung.com
HONDURAS
800-27919267
http://www.samsung.com
JAMAICA
1-800-234-7267
http://www.samsung.com
NICARAGUA
00-1800-5077267
http://www.samsung.com
PANAMA
800-7267
http://www.samsung.com
PERU
0-800-777-08
http://www.samsung.com
PUERTO RICO
1-800-682-3180
http://www.samsung.com
TRINIDAD & TO- 1-800-SAMSUNG (726-7864) http://www.samsung.com
BAGO
VENEZUELA
0-800-100-5303
http://www.samsung.com
Europe
ALBANIA
42 27 5755
-
AUSTRIA
0810 - SAMSUNG (7267864, http://www.samsung.com
€ 0.07/min)
BELGIUM
02-201-24-18
http://www.samsung.com/be
(Dutch)
http://www.samsung.com/
be_fr (French)
BOSNIA
05 133 1999
-
BULGARIA
07001 33 11
http://www.samsung.com
CROATIA
062 SAMSUNG (062 726 http://www.samsung.com
7864)
Appendix
Europe
CZECH
800
(800-726786)
SAMSUNG http://www.samsung.com
DENMARK
70 70 19 70
http://www.samsung.com
FINLAND
030 - 6227 515
http://www.samsung.com
FRANCE
01 48 63 00 00
http://www.samsung.com
GERMANY
01805
SAMSUNG http://www.samsung.com
(726-7864, € 0,14/Min)
GREECE
2106293100
HUNGARY
06-80-SAMSUNG (726-7864) http://www.samsung.com
ITALIA
800-SAMSUNG (726-7864)
http://www.samsung.com
KOSOVO
+381 0113216899
-
LUXEMBURG
261 03 710
http://www.samsung.com
MACEDONIA
023 207 777
-
MONTENEGRO
020 405 888
-
NETHERLANDS
0900-SAMSUNG
http://www.samsung.com
(0900-7267864) ( € 0,10/Min)
NORWAY
815-56 480
POLAND
0 801 1SAMSUNG (172678) http://www.samsung.com
http://www.samsung.com
http://www.samsung.com
022-607-93-33
PORTUGAL
80820
(7267864)
SAMSUNG http://www.samsung.com
RUMANIA
http://www.samsung.com
SERBIA
0700 SAMSUNG (0700 726 http://www.samsung.com
7864)
SLOVAKIA
0800 - SAMSUNG(0800-726 http://www.samsung.com/sk
786)
SPAIN
902 - 1 - SAMSUNG (902 172 http://www.samsung.com
678)
SWEDEN
0771 726 7864 (SAMSUNG) http://www.samsung.com
SWITZERLAND
0848 - SAMSUNG (7267864, http://www.samsung.com/ch
CHF 0.08/min)
http://www.samsung.com/
ch_fr/(French)
U.K
0330 SAMSUNG (7267864)
http://www.samsung.com
EIRE
0818 717100
http://www.samsung.com
LITHUANIA
8-800-77777
http://www.samsung.com
LATVIA
8000-7267
http://www.samsung.com
ESTONIA
800-7267
http://www.samsung.com
TURKEY
444 77 11
http://www.samsung.com
CIS
RUSSIA
8-800-555-55-55
http://www.samsung.com
Appendix
CIS
GEORGIA
8-800-555-555
-
ARMENIA
0-800-05-555
-
AZERBAIJAN
088-55-55-555
-
KAZAKHSTAN
8-10-800-500-55-500 (GSM: http://www.samsung.com
7799)
UZBEKISTAN
8-10-800-500-55-500
http://www.samsung.com
KYRGYZSTAN
00-800-500-55-500
http://www.samsung.com
TADJIKISTAN
8-10-800-500-55-500
http://www.samsung.com
UKRAINE
0-800-502-000
http://www.samsung.com/ua
http://www.samsung.com/
ua_ru
BELARUS
810-800-500-55-500
-
MOLDOVA
00-800-500-55-500
-
Asia Pacific
AUSTRALIA
1300 362 603
http://www.samsung.com
NEW ZEALAND
0800 SAMSUNG (0800 726 http://www.samsung.com
786)
CHINA
400-810-5858
http://www.samsung.com
HONG KONG
(852) 3698 - 4698
http://www.samsung.com/hk
http://www.samsung.com/
hk_en/
INDIA
3030 8282, 1800 3000 8282 http://www.samsung.com
INDONESIA
0800-112-8888,
021-5699-7777
http://www.samsung.com
JAPAN
0120-327-527
http://www.samsung.com
MALAYSIA
1800-88-9999
http://www.samsung.com
PHILIPPINES
1-800-10-SAMSUNG
(726-7864)
http://www.samsung.com
1-800-3-SAMSUNG
(726-7864)
1-800-8-SAMSUNG
(726-7864)
02-5805777
SINGAPORE
1800-SAMSUNG (726-7864) http://www.samsung.com
THAILAND
1800-29-3232, 02-689-3232
http://www.samsung.com
TAIWAN
0800-329-999
http://www.samsung.com
VIETNAM
1 800 588 889
http://www.samsung.com
Middle East
IRAN
021-8255
http://www.samsung.com
OMAN
800-SAMSUNG (726-7864)
http://www.samsung.com
KUWAIT
183-2255
http://www.samsung.com
Appendix
Middle East
BAHRAIN
8000-4726
http://www.samsung.com
EGYPT
08000-726786
http://www.samsung.com
JORDAN
800-22273
http://www.samsung.com
MOROCCO
080 100 2255
http://www.samsung.com
SAUDI ARABIA
9200-21230
http://www.samsung.com
U.A.E
800-SAMSUNG (726-7864)
http://www.samsung.com
Africa
NIGERIA
0800 - SAMSUNG (726-7864) http://www.samsung.com
SOUTH AFRICA
0860 - SAMSUNG (726-7864) http://www.samsung.com
Terms
Dot Pitch
The image on a monitor is composed of red, green and blue
dots. The closer the dots, the higher the resolution. The distance between two dots of the same color is called the 'Dot
Pitch'. Unit: mm
Vertical Frequency
The screen must be redrawn several times per second in
order to create and display an image for the user. The frequency of this repetition per second is called the Vertical
Frequency or Refresh Rate. Unit: Hz
Example: If the same light repeats itself 60 times per second, this is regarded as 60 Hz.
Horizontal Frequency
The time to scan one line connecting the right edge to the
left edge of the screen horizontally is called the Horizontal
Cycle. The inverse number of the Horizontal Cycle is called
Horizontal Frequency. Unit: kHz
Interlace and Non-Interlace
Methods
Showing the horizontal lines of the screen from the top to
the bottom sequentially is called the Non-Interlace method
while showing odd lines and then even lines in turn is called
the Interlace method. The Non-Interlace method is used for
the majority of monitors to ensure a clear image. The Interlace method is the same as that used in TVs.
Plug & Play
This is a function that provides the best quality screen for
the user by allowing the computer and the monitor to exchange information automatically. This monitor follows the
international standard VESA DDC for the Plug & Play function.
Resolution
The number of horizontal and vertical dots used to compose
the screen image is called the 'resolution'. This number
shows the accuracy of the display. A high resolution is good
for performing multiple tasks as more image information can
be shown on the screen.
Example: If the resolution is 1920 x 1080, this means the
screen is composed of 1920 horizontal dots (horizontal resolution) and 1080 vertical lines (vertical resolution).
Appendix
SRS TS XT
This feature outputs sonorous and vivid 3D sound as for 5.1
channel speaker sound but through a 2-channel speaker. It
has a good effect when stereo signals are input.
Correct Disposal
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking on the product, accessories or literature
indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not
be disposed of with other household waste at the end
of their working life. To prevent possible harm to the
environment or human health from uncontrolled
waste disposal, please separate these items from
other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer
where they purchased this product, or their local government office, for details of where and how they can
take these items for environmentally safe recycling.
Business users should contact their supplier and
check the terms and conditions of the purchase contract. This product and its electronic accessories
should not be mixed with other commercial wastes
for disposal.
Correct disposal of batteries in this product
(Applicable in the European Union and other European countries with separate battery return systems.)
This marking on the battery, manual or packaging indicates that the batteries in this product should not
be disposed of with other household waste at the end
of their working life. Where marked, the chemical
symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference
levels in EC Directive 2006/66. If batteries are not
properly disposed of, these substances can cause
harm to human health or the environment.
To protect natural resources and to promote material
reuse, please separate batteries from other types of
waste and recycle them through your local, free battery return system.
Note
The rechargeable battery incorporated in this product is not user replaceable. For information
on its replacement, please contact your service provider.
