Samsung | YP-F1Z | Samsung YP-F1Z User Manual

AH68-01755B (Rev 0.0)
Contents
I Before You Begin
Safety Instructions ..............................................................................................................................................4
Features ..............................................................................................................................................................6
Components ........................................................................................................................................................8
Location of Controls ............................................................................................................................................9
Charging the Battery ........................................................................................................................................11
I Connection Procedures
Connecting the Player to Your PC ....................................................................................................................12
Manual Installation of the USB Driver ..............................................................................................................16
Using the Player as a Removable Disk ............................................................................................................19
● Downloading/Uploading Files ........................................................................................................................19
● Disconnecting the USB Cable ......................................................................................................................20
● Formatting the Player on Your PC ................................................................................................................21
Installing Music Studio ....................................................................................................................................22
● To View Help on Music Studio ....................................................................................................................23
I Basic Usage
Playing Music ....................................................................................................................................................24
Recording Voice ................................................................................................................................................25
Searching for Music/Voice Files ........................................................................................................................26
Listening to FM Radio ........................................................................................................................................27
Recording FM ....................................................................................................................................................29
2
Contents
I Additional Usage
Loop Repeating ................................................................................................................................................29
MENU Options ..................................................................................................................................................30
Using Navigation ..............................................................................................................................................31
Setting Playlist ..................................................................................................................................................34
Setting the Advanced Functions ........................................................................................................................35
Selecting the Play Mode ..................................................................................................................................36
Sound Settings ..................................................................................................................................................37
Display Settings ..............................................................................................................................................39
Language Settings ............................................................................................................................................41
FM Radio Settings ............................................................................................................................................42
Time Settings ....................................................................................................................................................43
Managing File ....................................................................................................................................................45
Setting the System ............................................................................................................................................46
I Appendix
MENU Table ......................................................................................................................................................48
I Customer Support
Troubleshooting..................................................................................................................................................49
Specifications ....................................................................................................................................................51
3
Safety Instructions
Safety Instructions
Read and understand all the instructions to avoid injury to yourself and damage to the equipment.
Do not expose to extreme temperatures (above 35°C or below -5°C).
Do not expose to moisture.
Be careful not to subject the
player to excessive pressure
when wearing it round your neck.
Do not expose to direct sunlight
or heat sources.
I Earphones
Follow Traffic Safety Instructions
● Do not use the earphones while driving an automobile or riding a bicycle.
It’s not only dangerous, but also against the law.
● To avoid an accident, do not turn up the volume of the earphones too high while walking.
Protect Your Ears
● Do not turn up the volume too high. Doctors warn against prolonged exposure to high volume.
● Stop using the device or turn the volume down if you have ringing in your ears.
● Take care so that the earphone cable is not caught by your arm or other objects while walking or exercise.
Do not subject the unit to severe
impact, or place heavy objects
on it.
Do not expose to chemicals such
as benzene and thinners.
Do not store in dusty areas.
I Ambient Operating Conditions
● Ambient temperature : 5°C ~ 35°C
Humidity : 10 ~ 75%
I Environmental Information
Do not let any foreign matter spill
into the device.
4
Do not try to disassemble and
repair the device yourself.
● Follow local guidelines for waste disposal when discarding packages, batteries, and old electronic appliances.
✽ Please be aware that we claim no
responsibility for damage from data
loss due to breakdown, repair or
other causes.
● Your player is packaged with cardboard, polyethylene etc., and does not use any unnecessary materials.
5
Features
MP3, WMA, Audio ASF and Ogg
Playback
● The player supports playback of MP3, WMA, Audio ASF, and Ogg(Ogg Vorbis)
✻ OGG is a new audio compression format that is free, open and unpatented.
For more info, see www.vorbis.com
Features
USB 2.0 Support
●
Maximum data speed transfer of 18Mbps
Upgradable
●
You can upgrade the built-in programs when available.
Please check the home page (www.samsung.com) for upgrades.
Removable Storage Device
●
You can easily copy and paste files to the player using Windows Explorer.
FM Reception
●
Listening to an FM program is made easy with Auto Search and Frequency
Memory functions.
SRS WOW Surround Sound
●
6
Built-In Rechargeable Li-Polymer Battery
● The built-in rechargeable lithium battery provides up to 10 hours of play time.
✻ Time may vary depending on usage pattern.
Voice Recording Function
●
You can make high quality voice recordings.
The 3D surround(SRS) feature adds spaciousness to the sound.
7
Components
Location of Controls
I Replacing the Player Cover
Connecting the
Necklace Earphones
Player Cover
● Open the groove on the cover with your fingertips, take off the cover and put on another
cover of your desired color.
Necklace
Earphones
Necklace
Earphones
Player
✍ Caution
Connection
Link
Installation CD
User Manual
- Take care not to injure your fingertips when
you open the cover with your fingertips.
USB Cable
I Resetting the Player
Model
YP-F1 V
YP-F1 X
YP-F1 Z
Built-in memory
256MB
512MB
1GB
● Take off the Player Cover and press the RESET Hole using a pointed object such as a safety clip.
● The capacity of the useable built-in memory is less than indicated as the internal
firmware uses part of the memory as well.
● The accessories' design is subject to change for the purpose of improvement, without notice.
RESET Hole
8
9
Components
Charging the battery
1 Connect the USB cable to the USB port on your computer.
1
1
2
3
7
4
8
5
9
1
2
3
4
5
6
7
8
Volume Control
Menu/Navigation Button
USB Cable Connection Port, Earphone Port
Skip Track/Speed Search Button
2 Connect the other end of the USB cable to the USB Cable Connection Port on
top of the player.
✽ When recharging is complete, “Fully Charged” is shown in the display window.
✽ Battery recharge time in normal operation is approximately 2 hours and 30 minutes.
Skip Track/Speed Search Button
Display
Microphone
USB Cable
(Long) Record Button,
(Brief) Loop Repeating Button
9
Play/Pause Button
6
I Display
Equalizer, SRS Indicator
Track Number
Play/Stop/Pause Indicator
Play Mode
Remaining Battery Power Indicator
Title (Track Title and Artist)
Track Progress Indicator
Playtime Indicator
✍ Note
- The screen pictures are for illustration purposes only. The actual screen may differ.
10
✍ Caution
- When using the rechargeable battery for the first time or after several months of non-use, fully charge
it first.
- To avoid the risk of fire, do not charge longer than 12 hours.
- Overcharging will reduce the battery life.
- The rechargeable battery is a consumable item and its capacity will decrease gradually.
- To prolong the life of your battery, use the fully charged battery until it is completely discharged, and
then fully charge it again before use. If you charge the battery that is not completely drained, the
battery operating time will decrease. In this case, fully cycle (fully charge and then fully discharge) the
battery several times.
- If you connect the player through a USB hub, the connection may be unstable. Please connect the
player to the computer directly.
11
Connecting the Player to Your PC
Connecting the Player to Your PC
Make sure to install the USB driver before connecting the player to your PC.
If 'Add Hardware wizard' appears, click the [Cancel] button and install the USB driver.
▼ System Requirements.
The PC system must meet the
following specifications:
● Pentium 200MHz or greater
● Windows 98 SE/ME/2000/XP
● 40MB of available hard disc space
● CD-ROM drive
(double speed or greater)
● USB port (2.0) supported
● Direct X 8.0 or above
✍ Note
2 Follow the instructions in the window to complete the installation.
- Install the operating system in Administrator Account
(main user) for Windows 2000 or XP.
Otherwise, installation will not be completed.
- Windows ME, 2000 and XP can recognize the driver
without installing the provided program. However,
you must install the program in order to format the player
and upgrade firmware.
- If the YP-F1 program has not been installed in Windows
98 SE, then it will not communicate with your removable
disc. You must install the USB driver file first.
I Installing Software
1 Insert the installation CD into the
CD-ROM drive.
Select [Install Player USB Driver].
When the software installation is complete, connect the player to the computer and use
it as the following page shows.
Continued...
12
13
Connecting the Player to Your PC
I Connecting the player to PC with the USB cable
1 Connect the USB cable to the USB port on your computer.
2 Connect the other end of the USB cable to the USB Cable Connection Port on
Connecting the Player to Your PC
How to check if USB driver is properly installed
Windows 98:
Control Panel ➝ System ➝ Device Manager ➝ Disk Drives ➝ Samsung YP-F1
Windows 2000/XP:
Start ➝ Settings ➝ Control Panel ➝ System ➝ Hardware ➝ Device Manager ➝ Disk Drives
➝ Samsung YP-F1 USB Device
top of the player.
● If you disconnect the USB cable from your PC while implementing a
command or initializing during USB driver installation, your PC may not
function correctly.
3 The USB driver is installed with a message saying that it is searching for a new
device. You may not see the display screen during installation.
Go to the Device Manager to check that installation has been successfully
completed.
4 When the USB driver is successfully installed, "Samsung YP-F1 USB Device"
will appear in the [System Properties] ➝ [Device Manager].
USB Cable
14
5 When the USB driver is not installed automatically, refer to the next page.
15
Manual Installation of the USB Driver
If the USB driver has successfully installed, go to "Downloading/Uploading Files"(P19). If the
USB driver is not automatically installed, follow the procedures below.
I When an error occurs during installation of the USB
driver
Manual Installation of the USB Driver
4 After selecting the driver,
5 Click [Next].
click [Update Driver].
1 Check the device manager.
Windows 98SE:
Control Panel ➝ System ➝ Device Manager
Windows 2000/XP :
Control Panel ➝ System ➝ Hardware ➝
Device Manager
2 Check if there is a device listed with an exclamation point or a question mark
6 Select [Search for a suitable driver 7 Click [Next] to finish.
for my device] and then click [Next].
(displayed as unknown device or USB device).
3 Double click on the device listed with an exclamation point or a question mark.
✍ Note
- If the USB driver is not automatically installed in Windows 2000, download and install the latest
service pack from Windowsupdate.microsoft.com
- The installation method may vary depending on the type of PC or operating system.
Contact your PC dealer or service center for installation information.
- If errors occur continuously when you install the USB driver, reconnect the USB cable after
rebooting your system.
16
17
Manual Installation of the USB Driver
I In Windows 98
Using the Player as a Removable Disk
I Downloading/Uploading Files
Follow the instructions in the window to complete the installation.
1 Connect the player to your PC with the supplied USB cable.
2 Open Windows Explorer on your PC.
● Removable Disc is displayed in Windows Explorer.
3 Select the file to save and drag-and-drop it into the removable disc icon.
(Files will appear In numerical, alphabetical order)
● If you change the name of music files in Windows Explorer to 001* * * , 002* * *...,
music files will be played in the order of number indicated.
USB driver location
[CD ROM]ÍUSB DriverÍDrivers
✍ Caution
- The “Transferring” message will appear during file
download or upload. Disconnecting the USB cable while
“Transferring” is displayed may cause malfunction of
the unit.
: You must reboot your computer to complete the installation.
- The music file order displayed in Windows Explorer may
differ from the play order on your device.
✍ Note
- You cannot use it as a removable disc in Windows 98 if the YP-F1 program is not installed.
Make sure to install the USB driver file first.
18
19
Using the Player as a Removable Disk
I Disconnecting the USB Cable
After completing the file transfer, you must disconnect the cable in the following way:
1 Double-click on the green arrow in the taskbar on the
Using the Player as a Removable Disk
I Formatting the Player on your PC
1 Select the removable disc icon
and click the right mouse button
to select [Format].
bottom right of the Desktop.
2 Press the [Start] button.
● All saved files will be formatted.
● You can change the name of removable disc
by selecting [Volume label].
2 Select the USB device and click the [Stop] button. When the [Stop a Hardware
Device] screen appears, click the [OK] button and then disconnect the USB
cable.
✍ Caution
- By formatting, all previously preset menus will be reset, and any pre-existing song or
data files will be erased.
- Care must be taken as formatted files can not be recovered.
20
21
Installing Music Studio
Installing Music Studio
Music Studio is a program that enables you to play back music files on your PC.
1 Insert the Installation CD into CD-ROM drive.
2 Select language.
Select [Install Samsung Music Studio].
I To View Help on Music Studio
Launch Music Studio and press the F1 key on the keyboard.
● Help will be displayed.
Move the arrow to the top of Music Studio and right click on the
mouse. The following selection window will appear.
● Click on Help and the Help window will appear.
3 Follow the instructions in the window to complete the installation.
● Please refer to Help for more in formation on how to use Music Studio.
✍ Note
- Music recognition technology and related data are provided by Gracenote and Gracenote
CDDB® Music Recognition ServiceSM.
- Gradenote and CDDB are the registered trademarks of Gracenote.
Gracenote logo and symbol, Gracenote CDDB logo and "Powered by Gracenote" logo are the
registered trademarks of Gracenote.
Music Recognition Service and MRS are the registered service trademarks of Gracenote.
22
23
Playing Music
Recording Voice
I Turning Power On and Off
Power On : Press and hold the
Power Off : Press and hold the
button to turn on the power.
button to turn off the power.
I Playing Music (Power On)
Press the
✽ To move to other modes from the Voice mode,
refer to “Changing Mode”.
1 Press and hold the REC button to start voice recording.
2 Press the REC button again to stop the recording and save the voice file.
button.
● Playback starts automatically.
I Pausing Music (Power Off)
Press the
button to pause playback.
● If no buttons are pressed within 15 seconds (or custom settings),
the player automatically powers off.
● While in Pause mode, press the
button again to resume playback.
I Adjusting the Volume
Use
,
✍ Note
- The files are recorded in the order of V001,V002......, and WAV in the VOICE folder after
recording.
- If the Memory is full, Voice Recording will be disabled automatically.
- Voice Recording does not work in FM Mode.
to adjust the volume from 00 to 30.
✍ Note
- If the file name is not displayed correctly, move to [Settings] ➔ [Language] ➔ [ID3-Tag] and then
change the language setting.
- WMA files can only be played as music files with a compression rate of 48Kbps-192Kbps.
- The power off time can be set in the menu.
24
25
Searching for Music/Voice Files
I To Search for Specific Parts During Play
● Press and hold the
,
button during playback to search for the part you
want to listen to.
● Release the button to resume play normally.
I To Change Tracks During Play
● Press the
button briefly during playback to play the next track.
● Press the
button briefly within 5 seconds after playback starts to move to and
play the previous track. Press the
button briefly after 5 seconds to play the
current track from the beginning.
I To Change Tracks when Stopped
● Press the
,
button in stop/pause mode to move to the previous/next track.
Listening to FM Radio
Press and hold the “M” key. If the menu appears, select FM Radio.
I Manual Search for a Frequency
● Press the
,
button briefly to to search manually for the frequency you want.
I Manual Storage of a Frequency
● Press the A↔B button after moving to the frequency
to save.
● For the frequency by using the
,
button, and
then press the A↔B button.
I Automatic Search for a Frequency
● Press and hold the
,
button to search for and stop at
frequencies with reception.
✍ Note
- VBR(Variable Bit Rate) file: A file that constantly changes the compression rate according to the
type of sounds, such as their pitch, in the file.
- When playing a VBR file, you cannot move to and play the previous track even if you press
the
within 5 seconds after playback starts.
- Files that were downloaded in MP2 or MP1 and had their file extension changed to MP3
may not play.
- You can change the search speed and skip interval by selecting [Settings] ➔ [System] ➔
[Search Speed], [Skip Interval].
26
✍ Note
- To exit from FM mode, press and hold “M” key.
- Mono or Stereo is automatically selected.
- To save frequencies automatically, select [Settings] ➔ [FM Radio] ➔ [Auto Preset].
27
Listening to FM Radio
I Searching Stored Frequencies
1 Press the “M” key in the FM mode.
● PRESET screen appears.
2 Use the
,
button to move to
the frequency you want.
Recording FM
1 Press and hold the REC button while receiving FM.
● Recording of the current FM channel begins.
2 Press the REC button again.
● A recording file is created and the recording stops.
● Files are recorded in the order F001, F002, F003... and saved as MP3 files in FM_ENC
folder.
I Deleting Stored Frequencies
Loop Repeating
1 After moving to the PRESET number
you want to delete,
press the A ↔B button.
2 After selecting the “YES”,
press the “M” Key.
● The saved PRESET number will be deleted.
I Mute Function
1 Press the
button in the FM mode.
● “MUTE” message appears and no sound will be heard.
2 Press the
button again.
● Then the Mute function is canceled.
✍ Note
- You can store up to 20 frequencies.
- Press the “M” key in the PRESET screen to exit the PRESET mode.
28
I Starting Point
While playing music files, press the A↔B button
briefly at the beginning of the loop you want to set.
A↔ appears in the display.
I Ending Point
Press the A↔B button briefly again to set the
end of the loop.
A↔B appears in the display.
The loop is played repeatedly.
✍ Note
- The minimum allowed period of time for Loop Repeat is 4 seconds.
- Press the A↔B button briefly to cancel the loop.
- Loop Repeat is automatically released if you Speed Search with the
,
button.
29
MENU Options
Using Navigation
You can easily search for files or switch modes using the Navigation function.
Press and hold the “M” key to switch to the Menu mode.
Use
,
to move and press the “M” key briefly to select the menu you want.
Press and hold the “M” key again to exit the MENU mode.
1 Press the “M” key to enter Navigation mode or press and hold the “M” Key to
move to Menu and then select Navigation in Menu.
2 Select the file or folder that you want to play.
Music
FM Radio
Playlist
Navigation
Exit
● Music : To check the file currently playing.
● FM Radio : To listen to FM radio.
● Navigation : To move to Navigation Mode.
● Playlist : To play back only the files you want.
● Settings : To set the functions.
● Exit : To exit the menu.
✍ Note
- Menu mode will be cancelled if no buttons are pressed within 20 seconds.
30
●
: To move to a higher-level folder.
●
: To move to a lower-level folder.
●
, : To move to a file or folder in the same directory.
● M : Move to the next folder down. When there is not a lower folder,
the selected file will be designated as part of the playlist.
3 Press the
button.
● The selected file will be played.
✍ Note
- Press and hold the “M” key in Navigation mode to exit the Navigation mode.
31
Using Navigation
Using Navigation
I Changing Mode
I Playing/Exiting Folder
● You can change the mode in the following method.
Ex) To change from the Voice mode to the Music mode
[ Playing Folder ]
1 Press the “M” key to move to the Navigation mode.
1 Press the “M” key in the Voice mode.
2 Use
,
● When "
2 Use the
3 Use
,
to move to the folder you want and press the
button.
" appears, the selected folder will be played.
button to move to the upper folder.
to move to the music file you want and press the
● As it is changed to the Music mode, the selected file will be played.
button.
[ Exiting Folder Play ]
1 Press the “M” key during folder playback to move to the Navigation mode.
2 Use
,
to move to the file you want and press the
● After folder play is exited, "
button.
" mark will appear and the selected file will be played.
✍ Note
- To change to the FM mode, refer to “Menu Options”.
32
33
Setting Playlist
Setting the Advanced Functions
I Setting Playlist
- Move to the file you want in Navigation mode and press the “M” key.
1 Select Settings from the menu. (Refer to "Menu Options")
2 In Settings, use
● The selected file will be marked.
● To exit the playlist setting, move to the marked file in Navigation mode and
press the “M” key again.
I Playing Playlist
, to move to the function you want and
press the “M” key to select.
● To move to a previous menu, use
Play Mode
Play Mode
Sound Effect
Display
Sound Effect
Display
Play Mode
Sound Effect
Display
FM Radio
Time
FM Radio
Time
FM Radio
Time
1 Select Playlist from the menu.
● The playlist you set will be displayed.
2 Move to the file you want to play and press the
●“
34
button.
or select Return.
File
File
System
Return
System
Return
” mark appears and the selected file will be played.
35
Selecting the Play mode
Sound Settings
Select Sound Effect in Settings.
I Preset EQ
1 Select Play Mode in Settings.
2 In Play mode, use
, to move to the mode you want and
press the “M” key to select.
Normal
Repeat One
Repeat All
Shuffle All
Intro
Return
● Normal : To play all the files in order one time.
● Repeat One : To repeat one file.
● Repeat All : To repeat all files.
● Shuffle All : To play files at random.
● Intro : To play the first few seconds of a music file.
● Return : To move to a previous menu.
● Use , to move to the sound mode you want and then press the “M” key.
● SRS → TruBass → WOW → Normal → Classic → Jazz → Rock → User EQ
● Select User EQ to set the EQ as desired.
● SRS : You will hear 3D surround sound.
● TruBass : This is a bass boost feature that adds fullness to the sound.
● WOW : Consists of SRS and TruBass functions. Provides rich bass and 3D surround sound at
the same time.
Normal
Classic
Jazz
Rock
User EQ
Return
✍ Note
-
is a trademark of SRS Labs, Inc.
WOW technology is incorporated under license from SRS labs, Inc.
- Please adjust the volume to a suitable level, as the volume may increase in the SRS setting.
- This unit supports sampling frequencies of 32KHz, 44.1KHz or 48KHz.
I Bass Booster
● Use , to select Bass Booster On or Off and then press
the“M” key.
● Bass Booster function is applied only when you select Normal,
Classic, Jazz or Rock in the Preset EQ.
● On: When the music is played back, the bass is enhanced in the
preset sound.
● Off: Music is played back in the preset sound.
36
Bass Booster
On
Off
37
Sound Settings
Display Settings
I WOW Set
● Use
Select Display in Settings.
to select the SRS function you want, and then press the “M” key.
● The SRS function is applied only when you select the SRS, TruBass or WOW
in the Preset EQ.
,
● SRS :
You will hear 3D surround sound.
Use , to adjust SRS from 0 to 10.
I Scroll
● Use ,
to set the scroll speed from X1 to X5 to adjust
the speed of the track title movement.
● TruBass : A bass boost feature that adds fullness to the sound.
Use , to adjust TruBass from 0 to 10.
● Focus :
Return
You can enjoy clearer tone during playback.
Use , to set Focus and then press the “M” key.
High → Middle → Low
● Optimum : Optimize the SRS function according to the device
connected to the main unit.
Use , to move to the connected device and
then press the“M” key.
Earphone → Headphone →
Speaker → Car pack
Earphone
Headphone
Speaker
High
Middle
Low
Car Pack
Return
I LCD Time
● Use , to set the LCD light-on time.
● You can select 5sec ➔ 15sec ➔ 30sec ➔ 1min ➔ Always on.
● When set to Always on, the Light stays on continuously
LCD Time
I User EQ Set
● If User EQ is selected in Preset EQ, EQ can be set to your
preference in the User EQ Set.
● Use the
,
button to move to right or left and use ,
to adjust the level.
Press the “M” key after completing the setting.
38
39
Language Settings
Display Settings
Select Language in Settings.
I Screen Saver
● Use , to set Screen Saver.
● You can set Screen Saver to Clock, Screen Saver1 or
Screen Saver2. When the LCD light is turned off, the
Screen Saver screen appears.
● When you make a recording, the Recording Screen Saver
appears regardless of the set screen saver.
I Menu
Clock
Screen Saver1
Screen Saver2
I Screen Saver Term
● Use , to set the time to show screen saver.
● You can select Always on ➔5sec ➔10sec ➔ 30sec ➔1min ➔
5min ➔10min ➔ off.
● If you select Always on, screen saver will always be displayed.
Return
Screen Saver Term
I Contrast
● Use , to set Contrast.
● You can adjust the Contrast from 0 to 10.
Contrast
I Tag
● Use , to select Tag On or Off.
● On: Display the Tag information if the music file has
Tag information. Display the file name if the music file has no
Tag information.
● Off: Display the name of music file.
40
● Use , to select a desired language for the menu.
● You can select Chinese(S) → Chinese(T) → Dutch → English → French → German →
Hungarian → Italian → Japanese → Korean → Polish → Portuguese → Russian →
Spanish → Swedish.
I ID3-Tag
● Use , to select a desired language for tag information.
● You can select Afrikaans → Basque → Catalan → Chinese(S) → Chinese(T) → Czech →
Danish → Dutch → English → Estonian → Finnish → French → German → Greek →
Hrvatski → Hungarian → Icelandic → Italian → Japanese → Korean → Norwegian →
Polish → Portuguese → Romany → Russian → Slovak → Slovene → Spanish →
Swedish → Turkish → Vietnamese.
Return
Tag
On
Off
✍ Note
- What is an ID3 Tag ?
This is what is attached to an MP3 to carry information relevant to the file, such as the title, artist,
album, year, genre and a comment field.
- Supported languages can be changed or added.
41
FM Radio Settings
Time Settings
Select FM Radio in Settings.
Select Time in Settings.
I Auto Preset
I Auto Off Time
● Use , to set the Auto Off time.
● You can select Off ➔ 5sec ➔ 10sec ➔ 15sec ➔ 30sec ➔
1min ➔ 5min.
If no button is pressed after play stops, the player will
automatically turn off after the time you set.
● When Auto Off is set to Off, the function is disabled.
● If you select Auto Preset, frequencies within the range of
87.5MHz to 108.0MHz are automatically selected and stored.
● Frequencies are automatically stored, starting from 1.
I FM Region
● Use , to select the FM region.
● Other Country : Search FM frequency between 87.50MHz to
108.00MHz in increments of 50 KHz.
● Korea/U.S : Search FM frequency between 87.5MHz to
108.0MHz in increments of 100 KHz.
● Japan: Search FM frequency between 76.0MHz to 108.0MHz in
increments of 100 KHz.
Auto Off Time
Other country
Korea/US
Japan
I Auto Sleep
✍ Note
- The default FM region setting may vary depending on the target region of the player.
● Use , to set the Sleep Time.
● You can select Off ➔ 15min ➔ 30min➔ 60min ➔ 90min ➔
120min.
The player will automatically turn off after the time you set.
● When Auto sleep set to Off, the function is disabled.
Auto Sleep
I FM Search Level
● Use , to select the FM tuner sensitivity.
● The higher the FM tuner sensitivity, the more frequencies
can be heard.
● Use can select High ➔ Middle ➔ Low.
42
High
Middle
Low
43
Time Settings
Managing Files
Select File in Settings.
I Deleting a File
I Time Set
● Select the Time Set to set the current time.
If you have selected Clock for Screen Saver, you can view the
current time on the screen when the Screen Saver is set.
● Use , to set the clock time, and then press the
button
to move to the next stage.
● When the time setting is complete, move to OK by using ,
and press the “M” key.
1 Select Delete in File.
2 Use , to move to the file you want to delete and
then press the “M” key.
3 Use
Confirm
Cancel
to move to Confirm and then press the “M” key.
● The selected file will be deleted.
I Intro Time
● Use , to set the Intro Time.
● You can select 10sec ➔ 20sec ➔ 30sec ➔ 60sec.
If you set the Intro Time, the beginning of all files will be
played back for the seconds you set.
,
Delete
I Formatting the Player
Intro Time
1 Select Format in File.
2 Use , to move to Confirm and then
Format
Confirm
Cancel
press the “M” key.
● The player will be formatted.
✍ Note
- All files will be deleted when formatting the built-in memory.
44
45
Setting the System
Setting the System
Select System in Settings.
I Skip Interval
I Resume
● Use , to select Resume On or Off.
● On: Playback will resume from the point it was previously
stopped.
● Off: Playback will resume from the beginning of the track.
Resume
On
Off
I Default Vol
● Use , to set the default volume to a level between
0 and 30.
● If the power is turned on again after having adjusted the
volume to a level above the default volume
(for example: 20) music is played at the default volume level.
● If the power is turned on again after having adjusted the volume
at or below the default volume (for example: 20 or lower), the
music is replayed at the previous volume.
● Use , to set Skip Interval.
● You can select 1Track ➔ 5sec ➔ 10sec ➔ 15sec ➔ 30sec ➔
1min.
● Skip Interval determines the interval to be skipped when you
press the
,
button in Music mode.
● If you set the Skip Interval to 1 Track, if you press the button, the
previous or next track will be selected.
Skip Interval
✍ Note
- For a VBR or Ogg file, the Skip Interval may not be uniform.
Default Vol
I Beep
● Use , to select Beep On or Off.
● On: The unit beeps when the buttons are pressed.
● Off: The unit does not beep.
Beep
On
Off
I Search Speed
● Use , to set Search Speed.
● You can select 1sec ➔ 3sec ➔ 5sec ➔ 10sec ➔ 15sec ➔
20sec ➔ 30sec ➔ 1min.
● Search Speed determines the speed of search when you press
and hold the
,
button while listening to music.
Search Speed
I About
● If you select About, you can check the software version information, total number of
tracks and remaining capacity.
✍ Note
- For a VBR or Ogg file, the Search Speed may not be uniform.
46
47
MENU Table
Troubleshooting
The software doesn’t work
● Refer to the System Requirements
Music
FM Radio
Navigation
Playlist
Settings
Exit
The player does not work and the LCD displays nothing.
● Check the battery charge status of the player.
● Connect the player to PC and run YP-F1 Updater in the desktop to update the player.
● Open the cover of the player and press the RESET hole.
In Play mode, music is not played after pressing the Play button.
● Check to see if MP3 or WMA files are saved in the memory.
Files cannot be downloaded.
Play Mode
Sound Effect
Display
Language
FM Radio
Time
File
System
Normal
Preset EQ
Scroll
Auto Preset
Auto Off Time
Delete
Resume
Repeat One
Bass Booster
LCD Time
FM Region
Auto Sleep
Format
Default Vol
Repeat All
WOW Set
Screen Saver
FM Search Level
Shuffle All
User EQ Ser
Screen Saver Term
Intro
Time Set
Search Speed
Intro Time
Skip Interval
Contrast
Beep
Tag
About
● Check to see if the driver is installed correctly in the computer.
● Check the USB connectivity between the player and the computer.
● Operating system limits the number of files you can save.
Please save your music files by creating a subfolder.
● Check if the memory is full.
● Open the cover of the player and press the RESET hole.
LCD display is invisible.
● Check that the LCD Time setting.
Buttons on the player does not work.
● Open the cover of the player and press the RESET hole.
●
48
Use the “M” key to move and select.
49
Troubleshooting
The player is automatically turned off.
● In Stop mode, the power may automatically be turned off depending on settings.
● Check to see if there are files saved in it.
Play Time is not displayed correctly during playback.
● Check to see if the file is a VBR(Variable Bit Rate) file.
LCD display is dark.
● Check the Contrast setting.
The file name and Tag information are not displayed correctly.
● Select [Settings] ➔ [Language] ➔ [ID3-Tag] from the menu and change the Language
setting.
There is a file saved in the player, but “No File” appears in the screen.
● After checking whether the folder is played, use the Navigation function to change the
folder.
● Connect the player to the computer and run YP-F1 Updater from the Desktop to update
the player. When the Update screen appears, select [Format Data Area] in the Download
option and update.
I cannot properly connect the player to the computer.
● Win98 : Try to connect again after installing the driver.
● WinME : Remove the driver program and the select the Start and then Windows Update on
the Desktop. After selecting important update and service pack, execute update all.
● Win2000/XP : Try to connect it again after rebooting the computer.
50
Specifications
Model
Built-in Memory capacity
Voltage
Playing time
Dimensions/Weight
Case
Noise Ratio
YP-F1
256MB(YP-F1 V), 512MB(YP-F1 X), 1GB(YP-F1 Z)
3.7V (Li-polymer)
lasts up to 10hours(On the basis of measurement by the company)
29 X 63.5 X15 mm / 32 g
Plastic/Steel
92dB with 20KHz LPF
Earphones Jack Output Power 14mW(France 5mW/CH) (16 Ω)
Output Frequency Range
Operating Temperature Range
FM Frequency
FM Signal to Noise Ratio
FM T.H.D
FM Useable Sensitivity
File Support
20Hz~20KHz
-5 ~ +35°C(23~95°F)
87.5 ~ 108.0 MHz
58dB
1%
10dB
MPEG1/2/2.5 Layer3(8Kbps ~ 320Kbps, 8KHz ~ 48KHz)
WMA, ASF (48Kbps ~ 192Kbps, 8KHz ~ 48KHz), Ogg
51
Specifications
The product unit accompanying this user manual is licensed under certain
intellectual property rights of certain third parties. This license is limited to
private non-commercial use by end-user consumers for licensed contents.
No rights are granted for commercial use. The license does not cover any
product unit other than this product unit and the license does not extend to any
unlicensed product unit or process conforming to ISO/IEC 11172-3 or ISO/IEC
13818-3 used or sold in combination with this product unit. The license only
covers the use of this product unit to encode and/or decode audio files
conforming to the ISO/IEC 11172-3 or ISO/IEC 13818-3. No rights are granted
under this license for product features or functions that do not conform to the
ISO/IEC 11172-3 or ISO/IEC 13818-3.
52
Specifications
This marking shown on the product or its literature, indicates that it should not
be disposed with other household wastes at the end of its working life.
To prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
product, or their local government office, for details of where and how they can
take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract.
This product should not be mixed with other commercial wastes for disposal.
53
Download PDF
