LG CK99 Owner's manual
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ENGLISH
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE
PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
T his lightning flash with arrowhead symbol
within an equilateral triangle is intended to
alert the user to the presence of
uninsulated dangerous voltage within the
product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
T he exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the product.
SIMPLE MANUAL
Mini Hi-Fi
System
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE.
WARNING: Do not install this equipment in a confined
space such as a book case or similar unit.
CAUTION: Do not use high voltage products around
this product. (ex. Electrical swatter) This product may
malfunction due to electrical shock.
CAUTION: No naked flame sources, such as lighted
candles, should be placed on the apparatus.
CAUTION: Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product
and to protect it from over heating. The openings shall be
never be blocked by placing the product on a bed, sofa,
rug or other similar surface. This product shall not be
placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
Please read this manual carefully before operating your set and retain it for future reference.
To view the instructions of advanced features, visit http://www.lg.com and then download
Owner’s Manual. Some of the content in this manual may differ from your unit.
Use of controls, adjustments or the performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to
open the enclosure.
CAUTION concerning the Power Cord
The Power Plug is the disconnecting device. In case of an
emergency, the Power Plug must remain readily accessible.
CAUTION: The apparatus should not be exposed to water
(dripping or splashing) and no objects filled with liquids,
such as vases, should be placed on the apparatus.
NOTICE: For safety marking information including product
identification and supply ratings, please refer to the main
label on the bottom or the other surface of the product.
yy The appliance is not intended for use by young
children or infirm persons without supervision.
yy Young Children should be supervised to ensure
that they do not play with appliance.
yy If the appliance is supplied from a cord extension
set or an electrical portable outlet device, the
cord extension set on electrical portable outlet
device must be positioned so that it is not subject
to splashing (of water or any form of liquid) or
ingress of moisture.
RF Radiation Exposure Statement
This equipment should be installed and operated with
minimum distance 20 cm between the radiator and your
body.
Symbols
~
Refers to alternating current (AC).
0
Refers to direct current (DC).
Refers to class II equipment.
1
Refers to stand-by.
!
Refers to “ON” (power).
Refers to dangerous voltage.
MODEL
CK99
www.lg.com
MFL70405720
CK99-FS.DAUSLLLK_SIM (Sheet)_MFL70405720.indd 1,4
CAUTION: This product employs a Laser System. To
ensure proper use of this product, please read this owner’s
manual carefully and retain it for future reference. Shall the
unit require maintenance, contact an authorized service
center.
Copyright © 2018 LG Electronics Inc. All Rights Reserved.
2018-04-10
9:52:39
Top Panel
kSide 1 / Basic controls (CD / USB 1 / BLUETOOTH / RADIO
only)
a 1 (Standby)
Turns the power on or off.
b USB REC / DEMO
- Records to USB 1.
- To stop Recording, press and hold for 3 seconds.
- In power off status, if you press USB REC / DEMO, show
DEMO mode.
c USB 1 Port
You can play sound files by connecting the USB device.
d Display window
e TEMPO A -/+
Adjusts TEMPO in USB 1 function.
MASTER VOL. (Volume) -/+
Adjusts speaker volume.
TEMPO B -/+
Adjusts TEMPO in USB 2 function.
f USB 2 Port
You can play sound files by connecting the USB device.
gF (Function)
- Selects the function and input source.
- Press and hold to select the PARTY LINK.
h 3 WIRELESS LINK
- Selects MAIN or OTHER on WIRELESS PARTY LINK mode.
- Enable or disable WIRELESS PARTY LINK mode.
i MIC (Microphone) VOLUME -/+
Adjusts microphone volume.
j VOCAL EFFECTS
Selects VOCAL EFFECTS mode.
MIC ECHO
Selects ECHO mode.
VOICE CANCELLER
You can reduce the vocal tones during music playback from
various input sources.
Z (Stop)
Stops playback or cancels DELETE function.
C/V (Skip/Search)
- Skips backward or forward.
- Searches for a section within a track/file.
- Selects the radio stations.
N (Play/Pause)
- Starts or pauses playback.
- Selects stereo/mono.
SEARCH
Moves to folder or file in selection mode.
OK
Selects a folder when searching a file.
DJ LOOP
Selects DJ LOOP mode.
(DJ LOOP mode can use during USB playback.)
REGION EQ / BASS BLAST (or BASS BLAST+)
- Chooses region equalizer.
- Press and hold to select BASS BLAST (or BASS BLAST+)
effect directly.
LIGHTING
Selects lighting mode.
oB (Open/Close)
Opens and closes the disc tray.
pCLUB, DRUM, USER (DJ PRO)
Selects CLUB, DRUM or USER sound effect to mix.
(If you want to use USER, you have to register a source with
“Music Flow Bluetooth” app.)
1, 2, 3, 4, 5, 6 (DJ PRO PAD)
Press a desired sound pad.
Grounding
Cross fader
Move the cross fader to adjust the sound volume of mixed
sound when using MIXER ON.
(Except for devices which are not grounded.) Ensure that you
connect the earth ground wire to prevent possible electric shock
(i.e. a Audio with a three-prong grounded AC plug must be
connected to a three-prong grounded AC outlet). If grounding
methods are not possible, have a qualified electrician install
a separate circuit breaker. Do not try to ground the unit by
connecting it to telephone wires, lightening rods, or gas pipes.
r PARTY ACCELERATOR lever
Slide the lever to create a party atmosphere.
Front Panel
DJ EFFECT
Selects a desired DJ EFFECT.
a MIC (Microphone) 1/2
jack
DJ LOOP
Selects DJ LOOP mode.
(DJ LOOP mode can use during CD/USB playback.)
b Disc tray
Speaker Connection
b c
a
c
L
L
L
R
R
R
de
yy Connect the power cord to wall outlet directly if possible. Or
when you use an extension cable, it is highly recommended
to use an extension cable of 110 V / 15 A or 230 V / 15 A,
otherwise the unit may not operate properly because of the
lack of power supply.
d PORT. (Portable) IN jack
eH/P (Headphone) jack
Rear Panel
Z (Stop)
Stops playback or cancels DELETE function.
L
L
L
R
R
R
C/V (Skip/Search)
- Skips backward or forward.
- Searches for a section within a track/file.
OK
Selects a folder when searching a file.
Additional Information
Specifications
n Side 2 / Basic controls (USB 2 only)
yy Avoid turning up max volume in a small enclosed space. The
powerful and intense output of the speakers can shake the
ceiling and get the objects in the room falling.
yy Do not overload the extension cord with excessive electrical load.
H/P (Headphone) MODE
Press to select a headphone monitor mode.
SEARCH
Moves to folder or file in selection mode.
yy Do not place objects on the speakers. It may cause the objects
to fall and make property damage.
yy Allow more than 20 cm of free space between the main set
and the speakers when you install the main set on the ground.
High sound pressure from the speakers can make the set
tremble to disturb the CD playback.
(Remote sensor)
m KEY CHANGER (l/L)
Changes the key to suit your vocal range.
Caution
yy When you use the multiple socket, it is advisable to use 15 A
socket. 10 A socket may cause power off due to lack of power
supply.
yy To protect from hearing damage, keep the sufficient distance
from the speaker. The overwhelming sound from the speaker
may cause a person’s hearing damage.
lH/P (Headphone) VOLUME -/+
Adjusts headphone volume.
N (Play/Pause)
Starts or pauses playback.
a bc d
d ef
a Power cord
dSPEAKERS connector
b AUX IN 1/2 (L/R)
eSPEAKER LIGHTING
Connect the speaker
lighting cables.
AUX OUT (L/R)
c ANTENNA (FM)
Power Requirements
Refer to the main label on the unit.
Power Consumption
Refer to the main label on the unit.
Dimensions (W x H x D)
Approx. 470 mm x 213 mm x
423 mm
Bus Power Supply (USB)
5 V 0 500 mA
Amplifier
(Total RMS output power)
5,000 W RMS
Design and specifications are subject to change without notice.
Controller App
LG Sound Sync (Wireless)
fLighting LED
Download the Music Flow Bluetooth App to your
device. (Android only)
CK99-FS.DAUSLLLK_SIM (Sheet)_MFL70405720.indd 5-8
yy If the illumination brightness is glaring, switch on the room
lights or turn off the LIGHTING of the unit.
yy Install the speakers on a firm surface not to slide. The vibration
caused by the strong output can shake and move the speakers.
USER EQ
Selects the sound effect created by your own.
(R03)
MIX
Mixes audio sound.
PARTY ACCELERATOR MODE
Selects PARTY ACCELERATOR MODE.
Note
yy Do not look directly at the light emitting part when the
LIGHTING is turned on.
DJ SCRATCH / SEARCH & LEVEL
- Turns clockwise or counterclockwise to make scratch sound.
- Turns clockwise or counterclockwise to control the
USER EQ level.
- Searches a folder or a file.
- Adjusts DJ EFFECT level.
- Selects vocal effects.
Replacement of battery
q AUTO SYNC
When using MIX, you can synchronize the tempo of audio files
being played in USB 1 and USB 2 by pressing AUTO SYNC.
Additional Information
)
DJ SCRATCH / SEARCH & MULTI
- Turns clockwise or counterclockwise to make scratch sound.
- Searches a folder or a file.
- Selects the lighting effects.
(R03
For more information, download the online owner’s
manual. http://www.lg.com
