Owner’s manual
Please read this manual carefully before
operating your device.
The actual device may differ from the image.
MODEL : PD233/PD233P
Bluetooth®
QR Code for PocketPhoto App
ENGLISH
Bluetooth®
Safety information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK) NO USERSERVICEABLE PARTS INSIDE REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
This lightning flash with arrowhead
symbol within an equilateral triangle is
intended to alert the user to the presence
of uninsulated dangerous voltage within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying the
product.
2
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
confined space such as a book case or similar unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided
for ventilation and to ensure reliable operation of
the product and to protect it from over heating.
The openings shall never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a builtin installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon a
dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specification page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or fire. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an exact
replacement part by an authorized service center.
Protect the power cord from physical or mechanical
abuse, such as being twisted, kinked, pinched, closed
in a door, or walked upon. Pay particular attention to
plugs, wall outlets, and the point where the cord exits
the appliance. To disconnect power from the mains,
pull out the mains cord plug. When installing the
product, ensure that the plug is easily accessible.
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the battery
from the equipment: Remove the old battery
or battery pack, follow the steps in reverse order
than the assembly. To prevent contamination of
the environment and bring on possible threat
to human and animal health, the old battery or
the battery put it in the appropriate container
at designated collection points. Do not dispose
of batteries or battery together with other
waste. It is recommended that you use local, free
reimbursement systems batteries and accumulators.
The battery shall not be exposed to excessive heat
such as sunshine, fire or the like.
NOTICE: For safety making information including
product identification and supply ratings, please
refer to the main label inside the apparatus.
NOTICE: Only use the AC adaptor supplied with this
device. Do not use a power supply from another
device or another manufacturer. Using any other
power cable or power supply may cause damage to
the device and void your warranty.
3
CAUTION:
yy The apparatus should not be exposed to water
(dripping or splashing) and no objects filled with
liquids, such as vases, should be placed on the
apparatus.
yy Minimum distance around the apparatus for
sufficient ventilation, no less than 5 cm.
yy The ventilation should not be impeded by
covering the ventilation openings with items, such
as newspapers, table-cloth, curtains etc.
yy No naked flame sources, such as lighted candles,
should be placed on the apparatus.
yy Internal lithium battery in the unit should not be
replaced by user because of danger of explosion
if battery is incorrectly replaced ,and must be
replaced with the same type battery by expert.
,,Note
Device operating temperature
When operating in cold weather, the device
shall not print. Bring it inside from the cold and
give about 10 min to adjust to the specified
operating temperature (5 °C - 40 °C). Then try
printing again. (For the appropriate use, it is
recommended not to operate it outdoors in
winter.)
>>Caution
CAUTION when using this product in
environments of low humidity
yy It may cause static electricity in
environments of low humidity.
yy It is recommended to use this product after
touching any metal object which conducts
electricity.
4
Contents
Safety information . . . . . . . . . . . . . . . . . . . . . . 2
STEP 1 Getting Started . . . . . . . . . . . . . . . . . . 6
Supplied items . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . 6
Power On / Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing App for iPhone . . . . . . . . . . . . . . . . 12
Setting Bluetooth of iPhone . . . . . . . . . . . . . 12
STEP 5 Printing Photo . . . . . . . . . . . . . . . . . . 13
Printing using Android phone . . . . . . . . . . . 13
Printing using iPhone . . . . . . . . . . . . . . . . . . . . 16
Notes on the printing . . . . . . . . . . . . . . . . . . 18
STEP 2 Charging Battery . . . . . . . . . . . . . . . . 7
Checking Label . . . . . . . . . . . . . . . . . . . . . . . . 19
STEP 3 Inserting Photo Paper . . . . . . . . . . . . 9
Cleaning printer head using Smart Sheet . 9
Paper Jam Solution . . . . . . . . . . . . . . . . . . . . . . 10
About LED Indicator . . . . . . . . . . . . . . . . . . . 20
STEP 4 Installing App . . . . . . . . . . . . . . . . . . 10
Installing App for Android phone . . . . . . . 10
App Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 22
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5
STEP 1 Getting Started
Product Overview
Reset hole
Supplied items
Paper exit slot
LG Pocket Photo Printer
USB cable
Charger
Paper insert door
Micro USB port
(for recharging)
Button
(Power)
Paper insert slot
ZINK Photo Paper
6
Owner’s manual
STEP 2 Charging Battery
Power On / Off
On : Press and hold
for 4 sec.
This device uses built-in battery. Before using it,
charge the battery in full. (Refer to below)
Off : Press and hold
for 2 sec.
,,Note
button
yy When turning the device on, the
flashes for 5 sec. Then printing is available.
button) shows the
yy The LED indicator (
device condition. For more information, see
“About LED indicator” on page 20.
Battery charging time : 1.5 hours
button
Checking the charging status with
/ 100 % :
(When power-off )
yy Charging :
yy 10 % : flashes for about 3 sec.
yy 0 % : flashes for about 30 sec. and turns off.
yy LG Pocket Photo is always charged when
connected to the power supply except for being
printed.
7
Charger (AC Adapter)
yy Model : MCS-01ET
yy Manufacturer : TEN PAO INTERNATIONAL LTD.
yy Input : 100 - 240 V ~, 50 / 60 Hz
yy Output : 5 V 0 1.2 A
>>Caution
y Handle with care during charging to prevent
y
electric shock.
yy Do not place near heating appliance.
yy Do not disassemble or deform.
yy Do not give shock on.
yy Avoid too high or low temperature or
humidity.
8
,,Note
yy You can connect the device to PC using the
supplied USB cable, but charging time can
be longer.
yy The operating time on battery may vary
depending on the battery status, operational
status and environment conditions.
yy When the battery is discharged, printing is
available after charging it for more than 10
min. (Charge in full to print in a row.)
STEP 3 Inserting Photo
Paper
1. Open the Paper insert door.
Photo Paper
with White
side up
K
IN
Z
2. Unwrap the pack of the photo papers.
3. Slide Smart Sheet (Blue) and photo papers
together into the Paper insert slot. Smart Sheet
will be ejected automatically before first printing.
yy Do not insert more than 1 pack (10 Photo papers
and 1 Smart Sheet). Otherwise 2 papers may be
ejected at once or paper jam may occur.
yy Refill the device after using up the papers in.
yy Do not push the papers deeper into Paper insert
slot.
Smart Sheet
with Barcode
side down
Cleaning printer head using Smart
Sheet
Smart Sheet cleans printer head and calibrates colors
on photo. Keep the best print quality by using it
repeatedly.
9
Paper Jam Solution
,,Note
Do not pull the paper out. Turn the device off and on
again, the paper will be ejected automatically.
yy Handle with care when you touch the paper
not to get dirt on.
If this problem is not solved, please refer to
“Troubleshooting”.
yy Ensure to use the papers within its valid
date.
>>Caution
y Do not forcefully pull the paper out during
y
printing. It may result in malfunction.
yy Once unpacked, the papers may begin
to curl up after a period of time. It is
recommended to use them as soon as
possible.
yy Do not damage or bend the papers.
yy Using soiled paper may result in malfunction.
yy Using photo papers from other company
may result in malfunction or paper jam.
STEP 4 Installing App
yy Do not place inside a car or, expose to direct
sunlight or moisture.
Installing App for Android phone
yy Do not leave in a place where the
temperature or humidity is too high or low. It
may reduce the quality of the printed photo.
Search for “LG Pocket Photo”.
From Play Store (Android market)
Using QR code
Scan the QR code on the product box or the cover of
this manual.
10
Bluetooth®
Using NFC
Refer to “Printing using NFC” on page 14.
* NFC : Near Field Communication
** GPS : Global Positioning System using a satellite
App Setting
For more information about the App, touch “Help”.
See “Help” for details
Bluetooth®
Set the options in [Setting].
*
yy NFC : Prints using NFC (NFC-enabled phone only)
yy Bluetooth : Prints using Bluetooth
**
yy GPS : Saves the location where you took a photo
11
Installing App for iPhone
From App Store
Search for “LG Pocket Photo”.
Using QR code
Scan the QR code on the product box or the cover of
this manual.
Setting Bluetooth of iPhone
1. On your iPhone’s home screen, touch [Settings].
2. Touch “Bluetooth” and touch the slider to turn
Bluetooth [On].
3. To connect your Pocket Photo device to the
iPhone, turn on your device and make sure it is
discoverable mode.
4. When your iPhone found the device, touch the
name of Pocket Photo on the iPhone screen.
12
See “Help” for details
For more information about the App, touch “Help”.
STEP 5 Printing Photo
Printing using Android phone
Printing using Bluetooth (
Bluetooth®
)
Preparation : Turn the device on, and start printing
with the white LED (
button) turning on.
Bluetooth®
1. Run LG Pocket Photo App on Android phone.
2. Select a photo to print, and touch [
].
3. Touch [OK], then it will start searching for
Bluetooth devices.
4. When LG Pocket Photo is paired for the first time,
[Bluetooth pairing request] appears. To start
printing, touch [Pairing] or input the PIN code ‘0000’.
yy If Smart Sheet is in the device, it will be ejected
before starting printing.
,, You can print photos directly from Android
phones or PC via Bluetooth without the App.
Choose a photo and select [Bluetooth] in [Share]
or [Menu].
13
Printing using NFC (
)
Check whether your Android phone supports NFC
first.
Bluetooth®
yy How to read NFC tag : Make smartphone get near
to NFC tag on the device.
NFC
3. Choose a photo to print and tag, then printing is
started immediately. From this time, you can run
the App and print a photo by just tagging.
Setting Pocket Photo App of Android phone
You can check remaining battery, the number of the
photos printed, device version, MAC address, and
change the setting of print mode, etc.
1. Tagging for the first time, it links to Play Store
where you can download LG Pocket Photo App.
2. Go to [Setting] in the App installed, and check
[NFC].
14
1. Run LG Pocket Photo App on Android phone.
(To check [Device information], set to [On] the
Bluetooth of smartphone.)
2. Go to [Setting].
3. Touch [Device Information].
Auto Exposure
Corrects color in the image.
(ON/OFF)
Paper Full
Prints without white space. (The
edge of the image can be cut
off.)
Image Full
Prints an image as a whole.
(White space can occur at the
edge of the paper.)
Auto Power Off
Set a time so that the device
turns itself off.
(Default is [5 min]. If you set to
[Off ], the device can be on for up
to 2.5 hours when fully charged.)
15
Printing using iPhone
Printing using Bluetooth (
)
Bluetooth®
Preparation : Turn the device
on, and start printing
with the white LED (
button) turning on.
1. Run LG Pocket Photo App on iPhone.
2. Select a photo to print, and touch [
].
3. “Do you want to print?” message will be appeared.
Touch [OK] to start printing.
yy If Bluethooth is not connected, “ Paired device
not found” message is appeared. (refer to the
Bluetooth setting for iPhone.)
yy If Smart Sheet is in the device, it will be ejected
before starting printing.
16
Setting iPhone Pocket Photo App
You can check remaining battery, the number of the
photos printed, device version, MAC address, and
change the setting of print mode, etc.
1. Run LG Pocket Photo App on iPhone.
(To check [Device information], set to [On] the
Bluetooth of iPhone.)
Auto Exposure
Corrects color in the image.
(ON/OFF)
Paper Full
Prints without white space. (The
edge of the image can be cut
off.)
Image Full
Prints an image as a whole.
(White space can occur at the
edge of the paper.)
Auto Power Off
Set a time so that the device
turns itself off.
(Default is [5 min]. If you set to
[Off ], the device can be on for up
to 2.5 hours when fully charged.)
2. Go to [Setting].
3.Touch Setting options to change.
17
Notes on the printing
>>Caution
yy The color of impression can be different between
printed photo and image on smartphone’s display.
yy Do not pull paper out by force during
printing.
yy Once the battery is fully charged, you can print up
to 25 papers in a row. It depends on the battery
condition.
yy Do not open the paper insert door during
printing.
yy The Bluetooth searching and transferring may
fail depending on its environment. Check the
Bluetooth condition on your phone and try again.
yy If there are more than a LG Pocket Photo device,
check MAC address on the label to choose one
you want to use.
(Refer to “Checking Label” on page 19.)
18
yy Do not place an object at the front of the
Paper exit slot.
yy If the device is vibrated or given shock, the
quality of the printed photo may be reduced.
Checking Label
In case there are more than a LG Pocket Photo device,
check MAC address on the product label to choose
one you want to use.
3. You can find the product label.
1. Open the Paper insert door.
>>Caution
yy Be sure the device is off before opening.
Be sure the Paper insert door is opened
when you close the Upper Cover.
yy It is recommended not to open the Upper
cover as possible except for checking the
label.
2. Open the Upper cover.
yy Do not detach the black rubber pad. It may
cause malfunction.
19
About LED Indicator
The LED indicator (
condition.
button) shows the device
Error/
On
No paper, Paper
jam, Cancelled,
Opened, Low
temperature,
Unsupported file
format
Low battery/ To print, charge
On
the device.
LED color
20
Condition/
Power
Description
Waiting/
On
Waits for printing.
Device turns
itself off
if it is left unused
for a while.
Full charge/
Off
To print, turn on
the device.
Charging/
Off
To print, turn on
the device.
Printing/
On
Transferring data
via Bluetooth,
Printing
Cooling
mode/
On
After continuous
prints the device
may automatically
cool down
its internal
temperature. Wait
for a while to print
again.
Specifications
LED indicator
Power / Waiting / Bluetooth
transmitting / Charged /
Discharged / Error / Condition
of printer
Photo size
50 mm x 76 mm (Dot size : 640
x 1224)
Image file type/
size
JPEG (Baseline) / less than 10 MB
(Progressive JPEG is not
supported.)
Communication
Media paper
used
ZINKTM Photo Paper (exclusive
for LG)
External
connector
Micro USB port for charging
battery
Media paper
storage
environment
Temperature : 20 - 25 °C
Humidity : 40 - 55 % RH
Bus Power
Supply (USB)
DC 5 V 0 1.2 A
Device
operation
environment
Temperature : 5 - 40 °C
Humidity : less than 70 % (35 °C)
(An temperature alert pops up
in the App.)
Battery life
500 mAh Li-Polymer
rechargeable battery
Maximum 25 prints when fully
charged
Optimum print
environment
Temperature : 15 - 32 °C
Humidity : less than 70 % (32 °C)
Power supply
500 mAh Li-Polymer
rechargeable battery
AC adapter (DC 5 V 0 1.2 A)
resolution
More than 1280 x 2448 pixels
Bluetooth 2.1 + EDR
Operation distance : about 10 m
21
Dimensions (W
x D x H)
72.4 mm x 120.9 mm x 24 mm
Net Weight
212 g
yy Your phone may be incompatible with the device
depending on its manufacturer, environment or
(Android or iOS) operating system.
yy Design and specifications are subject to change
without prior notice.
Troubleshooting
Symptom
No power
Bluetooth
paring does
not work
well.
The paper
jammed
before
printing.
The paper
jammed
during
printing.
22
Cause / Solution
The battery is discharged.
Be sure the device is connected
to charger or PC properly when
charging.
Switch Bluetooth off and on again
on your smartphone, then pair with
the device in the smartphone’s
settings.
Turn on the device and try printing
(pairing) again in 5 sec.
Be sure the device is on.
1. Turn the device off and on
again then paper is ejected
automatically.
2. If above solution does not work,
open the Upper cover and
arrange the papers. Then insert
them with Smart Sheet (Blue)
or pull the paper out slowly and
gently.
The printed
photo has
lines.
No or
incomplete
image is
printed.
The edge of
the image on
the photo is
cut off.
White space
appears at
the edge of
the paper.
Open the Upper cover, arrange
the papers and insert them with
Smart Sheet locating at the bottom.
Then try printing again. (To open
the Upper cover, refer to “Checking
Label” on page 19.)
Set [Print mode] to [Image Full] in
the App’s setting then the image is
printed as a whole.
When [Print mode] is set to [Image
Full], white space may appears if the
aspect ratio of the paper and your
image is not the same.
When [Paper Full], the edge of the
image can be cut off or little white
space at the edge of the paper may
appear.
Quality of
printed
photo is too
low.
Device does
not print.
Device is
turned off
automatically.
Above
solutions do
not work.
In case you magnify an image using
[ ] menu in the App, the quality of
the printed photo may be reduced.
Turn off the device and insert Smart
Sheet locating at the bottom of the
papers. Then try printing again.
Be sure the photo size is bigger
than the proper resolution.(1280 x
2448 pixels)
Be sure there are papers in the
device.
It may take time to print after Smart
Sheet is ejected.
Be sure the photo file is less than
10 MB.
Baseline JPEG format is supported
only.
Check [Auto Power Off ] time in the
App’s setting.
Press Reset hole with a pointed
thing like mechanical pencil to
initialize.
23
Download PDF
