LG | 21FA2RGE-TY | LG 14D7RBE-TY Owner’s Manual

Colour Television
OWNER'S MANUAL
Please read this manual carefully before operating your set.
Retain it for future reference.
Record model number and serial number of the set.
See the label attached on the back cover and quote this
information to your dealer when you require service.
Chassis : MC-019E
P/No. : 38289U0513A (Rev. No. 00)
Contents
Installation
Safety/Installation
3
Location and function of controls
5
Remote control handset
Front panel
Basic operation
8
On and Off / Programme selection / Volume adjustment /
Quick view / Mute function / On screen language selection (option)
On screen menus
9
Menu selection
Setting up TV stations
10
Auto programme tuning / Manual programme tuning /
Assigning a programme name / Fine tuning / Programme edit /
Swapping programme / Skipping a programme number /
Selecting a programme in the programme table /
Paging through a programme table
Picture adjustment
14
PSM (Picture Status Memory) / Picture adjustment /
Eye (option) / Turbo picture selection (option) /
ARC (Aspect Ratio Control) / Standard / Zoom /
Sound adjustment (option)
16
SSM (Sound Status Memory) / Sound frequency adjustment (Equalizer) /
Equalizer Key / Balance adjustment / TURBO SOUND (option) /
CBC (Calibrated Bass Control) (Option) / Sound output selection /
Other functions
18
Auto AV switching (option) / Child lock / Auto sleep / Blue back /
AVL (Auto Volume Leveler) / CSM ( Colour Status Memory) /
Sleep timer / Game (option) / Space Fighter (Option) /
Remote control for game (option) / Time functions / ON Time /
On programme number/On Volume / Off Time /Programme surfing /
Connection of external equipment
22
Aerial socket / Audio Video in/out sockets (option) /
Euro scart socket (option) / Component in sockets (option) /
Headphone socket (option)
Troubleshooting check list
23
2
Important Precautions
This unit has been engineered and manufactured to assure your personal safety, however
improper use may result in potential electrical shock or fire hazards. In order to allow the proper
operation of all safeguards incorporated in this TV set, observe the following basic rules for its
installation, use and servicing. Keep it in an accessible place for future reference.
On Safety
The power supply cord is used as the main disconnect device. Ensure that the socket-outlet
is easily accessible after installation.
Operate the TV set only from a power source indicated in the specifications of this manual or
listed on the TV set. If you are not sure what type of power supply you have in your home,
consult with your dealer.
Overloaded AC outlets and extension cords are dangerous. So are frayed power cords and
broken plugs. They may result in a shock or fire hazard. Call your service technician for
replacement.
Hands must be dry when holding the power plug to avoid an electric shock.
Do not damage the power cord by disassembling, bending, pulling or heating up, it can cause
fire or electric shock.
Make sure to completely insert the power plug. Insecure connections can cause fire.
Do not Open the TV set
There are no user serviceable components inside.
There are Dangerous High Voltages inside, even when the power is OFF.
Contact your dealer if the TV is not operating properly.
To Avoid Personal Injury :
Do not place the TV set on a sloping shelf unless properly secured.
Use only fixed wooden stand. The TV shall be positioned 5cm behind the front
edge of an open fronted with 1cm free space along the sides top and 5cm
depth behind the TV.
Do not try to roll a stand with small casters across thresholds or deep pile
carpets.
To Prevent Fire or Hazards:
Always turn the TV set OFF if you leave the room for more than a short period
of time. Never leave the TV set ON when leaving the house.
Keep children from dropping or pushing objects into the TV cabinet
openings. Some internal parts carry hazardous voltages.
Do not add accessories that have not been designed for this TV set.
During a lighting storm or when the TV set is to be left unattended for an
extended period of time, unplug it from the wall outlet and extreme socket.
Do not bring magnetic devices such as magnets or motors near the picture tube.
3
Important Precautions
On Installation
Do not allow anything to rest upon or roll over the power cord, and do not place the TV set
where the power cord is subject to damage.
Power
This set operates on an AC mains supply, the voltage is as indicated on the label on the back
cover. Never apply DC power to the set. In the event of thunderstorms or powercuts, please
pull out the aerial and mains plugs.
Service
Do not attempt to service the TV set yourself, as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
Aerial
Connect the aerial cable to the socket market
75 W on the back cover. For the best reception
an outdoor aerial should be used.
Location
Do not use this TV near water such as near bathtub, washbowl, kitchen sink, laundary tub,
in a wet basement, or near a swimming pool.
TV set are provided with ventilation openings in the cabinet to allow the release of heat
generated during operation. If these openings are blocked, built-up heat can cause failures
which may result in a fire hazard. There fore,
The ventilation should not be impeded by covering the ventilation openings with items such as
newspaper, table cloths, curtains, etc.
Never place the TV set in a built-in enclosure unless proper ventilation is provided.
No naked flame source such as lighted candles should be placed on the TV.
Never place the TV set near or over a radiator or heat source.
Position your set so that no bright light or sunlight falls directly onto the screen.
On Cleaning
Unplug the TV set before cleaning the face of the TV screen.
Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the TV screen because
overspray may cause electric shock.
On Repacking
Do not throw away the carton and packing materials. They make an ideal container in which to
transport the unit. When shipping the unit to another location, repack it in its original material.
Caution: Please do not use stabilizer with TV set as this set has inbuilt voltage
stabilizer. Use of Inferior quality stabilizer may damage the set.
Battery installation
The remote control handset is powered by two AA/AAA type batteries. To load the batteries, turn the remote
control handset over and open the battery compartment. Install two batteries as indicated by the polarity
symbols ( + and - ) marked inside the compartment.
Note: To avoid damage from possible battery leakage, remove the batteries if you do not plan to use the
Remote control handset for an extended period of time.
4
Location and function of controls
All the functions can be controlled with the remote control
handset. Some functions can also be adjusted with the buttons
on the front panel of the set.
Remote control handset
Before you use the remote control handset, please install the
batteries. See the previous page.
MUTE
POWER
1
9
1
2
7
2
3
4
5
6
7
8
9
PSM
0
CBC
16
EQ/*
SSM
Q-VIEW
3. MENU
selects a menu.
14
12
6
3
SLEEP
5
2. NUMBER BUTTONS
switches the set On from standby or directly select a
Programme number.
LIST
18
13
VOL
PR
MENU
VOL
OK
8
PR
4
10
TV/AV
ARC
SOUND
1. POWER
switches the set from On to standby or standby to On.
EYE/*
4. EYE/ * (option)
switches the eye function On or Off.
5.
/ (Programme Up/Down)
selects a programme or a menu item.
switches the set on from standby.
(Volume Up/Down)
adjusts the volume.
adjusts menu settings.
OK
accepts your selection or displays the current mode.
6. Q. VIEW
returns to the previously viewed programme.
17
15
I/II
TURBO
11
7. PSM (Picture Status Memory)
recalls your preferred picture setting.
8. TURBO SOUND (option)
selects TURBO SOUND (On /Off ).
9. MUTE
switches the sound On or Off.
(For Stereo Models)
10. TV/AV
selects TV or AV mode.
clears the menu / text from the screen. switches the set on
from Standby.
11. I/II/ (option)
selects the language during dual language broadcast
(option).
Selects the sound output.
12. LIST
5
Location and function of controls
POWER
MUTE
9
1
2
13. SLEEP
sets the sleep timer.
3
1
5
2
8
9
7
PSM
14. SSM (option) (Sound status Memory)
recalls your preferred sound setting.
6
4
0
ARC
7
15
MENU
3
PR
5
VOL
OK
PR
12
6
SLEEP
TV/AV
16. CBC/ (option)(Calibrated bass control)
Desired bass can be adjusted.
18. Equalizer /* (option)
direct access key for equalizer.
LIST
10
13
15. ARC (option)
change picture format (zoom/wide/standard).
17. TURBO PICTURE (option)
Selects Turbo picture.
VOL
Q-VIEW
displays the programme table.
press TV/AV to clear the LIST table from the screen.
EYE
4
COLOURED BUTTONS : When Menu is On some of these buttons are
used for programme edit/ game.
Remarks :
1. Some keys in remote can be non-functional, these keys are
use in other models.
2. Keys marked * are non functional.
(For Mono Models)
6
FRONT PANEL / SIDE PANEL
Shown below is a simplified representation of front or side panel, here shown may be somewhat different from your set.
VIDEO
VIDEO
(L)
I
AUDIO
(R)
9
AUDIO
MENU OK/
ON/OFF
1
2 6
3
PR
VOL
4
VIDEO (L)-AUDIO-(R)
5
9
8
7
8
8
VIDEO
VIDEO
AUDIO
MENU
ON/OFF
(L)
I
AUDIO
(R)
9
1
2
6
3
4
8
MENU
1.
4
7
MAIN POWER
switches the set on or off.
OK/
PR
VOL
VIDEO L/MONO AUDIO R
VIDEO
3.
5
3
4
MENU
2
67
21FE46 series
5.
PR
AUDIO R
ON/OFF
VOL
1
5
6
2
MENU
selects a menu.
4. OK /
It accepts your selectionwhen it is in menu.
Otherwise it selects input (TV or AV)
OK/
L
8
OK/
POWER/STANDBY INDICATOR
illuminates brightly when the set is in standby
mode. dims when the set is switched On and
blinks when signal is input from the remote control
or front panel key is pressed.
1
AV
9
VOL
2.
21FD56 series
ON/OFF
9
PR
5
3
(Side Panel)
AV
PR
VOL
7
6.
/
(Programme Up/Down)
selects a programme or a menu item.
switches the set on from standby.
/
(Volume Down/Up)
adjusts the volume.
adjusts menu settings.
REMOTE CONTROL SENSOR
Note : Only use the supplied remote control
handset. (When you use others, they’ll be
not able to function)
7.
EYE (option)
adjusts picture according to the sur-rounding
conditions.
8.
HEADPHONE SOCKET (option)
Connect the headphone plug to this socket.
9.
AUDIO/VIDEO IN SOCKETS (AV) (option)
Connect the audio/video out sockets of
external equipment to these sockets.
Note : a. If audio input is only L or R select
L+L or R+R through I/II/ * key on
Remote control.
b. Front AV and rear AV not to be use
Simultaneously.
7
Basic operation
On and Off
1. Press the main power button to switch the set On.
2. If the set is in standby mode, press the POWER,
TV/AV
or NUMBER buttons on the remote control handset to switch it
On fully.
3. Press the POWER button on the remote control handset.
The set reverts to standby mode.
4. Press the main power button again to switch the set Off.
MUTE
POWER
Note : while the set is switched On and mains plug is disconnected,
if mains plugged again then set will switch to standby or power On.
2
3
Programme selection
4
5
6
You can select a programme number with the
Buttons.
7
8
9
1
PSM
CBC
SSM
0
EQ/*
Q-VIEW
LIST
or NUMBER
Volume adjustment
Press the
button to adjust the volume.
Quick view
Press the Q.VIEW button to view the last programme
SLEEP
VOL
PR
MENU
OK
VOL
Mute function
Press the MUTE button. The sound is switched Off and the display
appears.
PR
TV/AV
ARC
EYE/*
SOUND PICTURE
I/II
TURBO
You can cancel it by pressing the MUTE,
SOUND, EQUALIZER and CBC button.
, SSM, TURBO
On screen language selection (option)
The menu can be displayed on the screen in desired language. First
select your language.
1. Repeatedly press the Menu button to select the special
menu.
2. Press the
button after selecting language by pressing
button.
3. Press the
button to selects the desired language.
All the on screen display will appear in the selected language.
4. Press the TV/AV button to return to normal TV viewing.
8
On screen menus
The dialogue between you and your set takes place on screen with
an operator menu. The buttons required for the operating steps are
also displayed.
MUTE
POWER
1
2
3
4
5
6
7
8
9
PSM
CBC
SSM
0
EQ/*
Q-VIEW
Menu selection
1. Repeatedly press the MENU button to display each menu.
2. Press the button and then
button to select a menu item.
3. Press the
button to display the sub menu or the pull-down
menu.
4. Change the setting of an item in the sub or pull-down menu
with
or
.
You can move to the higher level menu with OK button and to move
to the lower level menu press the button.
Note :
a. In the AV mode the Programme menu is not displayed.
b. In mono models the Sound menu does not appear.
AUTO PROGRAMME
MANUAL PROGRAMME
PROGRAMME EDIT
SYSTEM
STORAGE FROM
NORMAL SEARCH
TURBO SEARCH
LIST
PROGRAMME MENU
SLEEP
VOL
PR
MENU
OK
VOL
PR
TV/AV
ARC
PSM :
EYE/*
SOUND PICTURE
I/II
CONTRAST
BRIGHTNESS
colour
SHARPNESS
TURBO
SEARCH
FINE
STORAGE
SYSTEM
NAME
CHANNEL
USER
PICTURE MENU
EQUALIZER
BALANCE
SWAP
SOUND MENU
CHILD LOCK
AUTO SLEEP
BLUE BACK
AVL
CSM
GAME
TIME FUNCTION
LANGUAGE
SPECIAL MENU
9
SKIP
M
Setting up TV stations
PROGRAMME MENU
AUTO PROGRAMME
MANUAL PROGRAMME
PROGRAMME EDIT
Up to 200 programmes can be stored by programme numbers
(0 to199). Once you have preset the stations you will be able to use
the
or NUMBER buttons to scan the stations you programmed.
Programmes can be tuned using automatic or manual modes.
Note : In some models up to 100 TV stations can be stored.
MUTE
POWER
1
2
3
4
5
6
7
8
9
PSM
CBC
SLEEP
VOL
Q-VIEW
PR
MENU
OK
VOL
EYE/*
SOUND PICTURE
I/II
M
LIST
PR
TV/AV
ARC
SYSTEM
STORAGE FROM
NORMAL SEARCH
TURBO SEARCH
SSM
0
EQ/*
Auto programme tuning
All channel that can be received are stored by this method. It is
recommended that you use auto programme during installation of
this set.
1 . Repeatedly press the MENU button to select the
Programme menu.
2. Press the
button and then
button to select Auto
programme.
3. Press the button to display the Auto programme menu.
TURBO
4. Press the
button to select System. Select a TV system with
the button on the System
pull-down menu;
BG : (India/New Zealand/M.East/Africa/Australia)
I
: (Hong Kong/South Africa)
DK : (East Europe/China/Africa/CIS)
M
: (USA/Korea/Philippines)
5. Press the
button to select Storage from.
6. Select the beginning programme number with the
button or
NUMBER buttons on the Storage from pull-down menu. Any
number under 10 is entered with a numeric '00' in front of it, i.e.
'005' for 5.
7. Press the
button to select Normal or Turbo search.
Note : a. Turbo search is further faster than Normal Search and in
some models, these searches will automatically store all
receivable stations.
b. lf the programmed station has poor quality sound, select
the system again in the Manual programme menu.
SYSTEM
STORAGE FROM
NORMAL SEARCH
TURBO SEARCH
(Normal search)
SYSTEM
STORAGE FROM
NORMAL SEARCH
TURBO SEARCH
(Turbo search)
8. Press the button to begin auto programming.
All receivable stations are stored.
To stop auto programming, press the MENU button.
When auto programming is completed the Programme edit
menu appears on the screen. See the 'Programme edit' section
to edit the stored programme.
9. Press the TV/AV button to return to normal TV viewing.
10
Setting up TV stations
PROGRAMME MENU
AUTO PROGRAMME
MANUAL PROGRAMME
PROGRAMME EDIT
Manual programme tuning
Manual programme offer you to manually tune and arrange the
programme in whatever order you desire. Also you can assign a
programme name with five characters to each.
1. Press the MENU button and select the Programme menu.
2. Press the button and then
button to select Manual
programme.
3. Press the button to display the Manual programme menu.
1
2
3
4
5
6
7
8
9
PSM
0
CBC
SLEEP
VOL
SSM
Q-VIEW
EQ/*
PR
LIST
MENU
OK
VOL
PR
TV/AV
ARC
SEARCH
FINE
STORAGE
SYSTEM
NAME
CHANNEL
MUTE
POWER
EYE/*
SOUND PICTURE
I/II
TURBO
4. Press the
button to select Search. Press the
button to
commence searching on the Search pull-down menu. If a
programme is found the search will stop. Press OK button to
store the programme. If programme reception is poor go for
fine tunning.
5. If this station is the one required, press the
button to select
Storage. Select the desired programme number (0 to 199) with
the
button or NUMBER buttons on the Storage. pull-down
menu. Any number under 10 is entered with a numeric '00' in
front of it, i.e. '005' for 5. Press OK button to store theprogramme.
6. Press the
button to select System. Select a TV system with
the
button on the System pull-down menu;
BG : (India/New Zealand/M.East/Africa/Australia)
I
: (Hong Kong/South Africa)
DK : (East Europe/China/Africa/CIS)
M : (USA/Korea/Philippines) (option)
7. Press the
button to select Channel. Press the
button
to select V/UHF or Cable on the Channel pull-down menu.
If possible, select the channel number 1 to 69 (V/UHF) and 1
to 47 (cable) directly with the number buttons, Any number
under 10 is entered with a numeric '0' in front of it i.e. '05 'for 5 .
8. Press the OK button to store it. The display Stored will
appear.
SEARCH
FINE
STORAGE
SYSTEM
NAME
CHANNEL
9. To store another station, repeat steps 4 &5.
11
Setting up TV stations
PROGRAMME MENU
SEARCH
FINE
STORAGE
SYSTEM
NAME
CHANNEL
Assigning a programme name
1. Repeat the 'Manual programme tuning' steps 1 to 3.
2. Press the
button to select Name.
3. Press the button on the Name pull-down menu. You can use a
blank, +, -, the numeric 0 to 9 and the alphabet A to Z.
With the button you can select in the opposite direction.
4. Select the next position by pressing the button and then take
your choice of the second character, then press OK button.
5. Repeat the 'Manual programme tuning' steps 5 to 8.
MUTE
POWER
Fine tuning
Normally fine tuning is only necessary if reception is poor.
1
2
3
4
5
6
7
8
9
PSM
0
CBC
SLEEP
VOL
TV/AV
ARC
EQ/*
1. Repeat the 'Manual programme tuning' steps 1 to 3.
2. Press the
button to select Fine.
3. Press the
button to fine tune for the best picture and sound
on the Fine pull-down menu, then press OK button to store the
setting.
SEARCH
FINE
STORAGE
SYSTEM
NAME
CHANNEL
SSM
Q-VIEW
PR
LIST
MENU
OK
VOL
4. Press the TV/AV button to return to normal TV viewing.
5. Change of “
” from Yellow to red indicates tuning is proper.
Programme edit
PR
This function enables you to swap or skip the stored programmes.
EYE/*
SOUND PICTURE
1. Repeatedly press the MENU button to select the programme menu.
2. Press the button and then
button to select programme edit.
3. Press the button to display the programme edit menu.
I/II
TURBO
PROGRAMME MENU
AUTO PROGRAMME
MANUAL PROGRAMME
PROGRAMME EDIT
SWAP
12
SKIP
Setting up TV stations
PROGRAMME MENU
AUTO PROGRAMME
MANUAL PROGRAMME
PROGRAMME EDIT
Swapping programme
1 . Select a programme to be swapped by pressing
button.
2. Press the YELLOW button.
3. Select a second programme to be swapped by pressing
button.
4. Press yellow (Swap) key to interchange the programme.
or
or
PR 0
SWAP
SEL PR2 AND PRESS SWAP
Skipping a programme number
1. Select a programme number to be skipped with the
or
button.
2. Press the BLUE button. The skipped programme turns to blue.
3. Press the BLUE button again to release the skipped
programme.
When a programme number is skipped it means that you will
be unable to select it using the
button during normal TV
viewing.If you want to select the skipped programme,
directly enter the programme number with the NUMBER
buttons or select it in the programme edit or table menu.
EQ/*
Press the TV/AV button to return to normal TV viewing.
Calling the programme table
You can check the programmes stored in the memory by displaying
the programme table.
SOUND PICTURE
Displaying programme table
Press the LIST button to display the Programme table menu. The
programme table appears on the screen. One programme table
contains ten programmes as follow.
TURBO
Note :
a. You may find some blue programmes. They have been set up to
be skipped by auto programming or in the programme edit mode.
b. Some programmes with the programme number shown in the
programme table indicate there is no programme name
assigned.
Selecting a programme in the programme table
Select a programme with the
or
button.
Then press the OK button.
The set switches to the chosen programme number.
Paging through a programme table
There are 20 programme table pages in which contain 200
programmes.
Pressing the
or
button repeatedly turns the pages.
Press the TV/AV button to return to normal TV viewing.
13
Picture adjustment
PROGRAMME MENU
PSM (Picture Status Memory)
AUTO PROGRAMME
MANUAL PROGRAMME
PROGRAMME EDIT
1. Press the PSM button on the remote to change for desired PSM
setting.
Note: PSM status change to user automatically when contrast,
brightness, colour and sharpness set manually.
You can also recall a desired picture (Dynamic, Standard, Mild
Game, or User) with PSM button on the remote control. The picture
Dynamic, Standard, Mild and Game are programed for good
picture reproduction at the factory and cannot be changed.
MUTE
POWER
1
2
3
4
5
6
7
8
9
PSM
0
CBC
SLEEP
VOL
EQ/*
Q-VIEW
PR
LIST
MENU
OK
VOL
EYE/*
SOUND PICTURE
I/II
1. Repeatedly press the MENU button to select the Picture menu.
2. Press the button and then
button to select Contrast,
Brightness, Colour, Sharpness or Tint.
CONTRAST
BRIGHTNESS
COLOUR
SHARPNESS
PSM :
SSM
PR
TV/AV
ARC
Picture adjustment
You can adjust picture contrast, brightness, colour intensity,
sharpness and tint (NTSC input only) to the levels you prefer.
3. Press the
sub menu.
USER
button to make appropriate adjustments on each
CONTRAST
You can also select User or standard PSM setting by directly
pressing PSM button.
4. Press the OK button to store it for the picture User.
5. Press the TV/AV button to return to normal TV viewing.
Eye (option)
In some models, the set will automatically adjust the picture
according to the surrounding conditions. This will enable you to
enjoy the most suitable picture according to the surroundings.
Press the EYE/ button to switch the eye function on or off.
TURBO
When the eye function is On, the most suitable picture is
automatically adjusted according to the surrounding conditions.
At this time the display........ in green does not appear continuously
but the display....... . in yellow appears each time the picture
condition changes.
Note : If PSM or TURBO PICTURE key is pressed or any of the
picture setting are varied, then EYE automatically switches off.
Turbo picture selection (option)
When this function is On, picture will be more brilliant and distinct
picture then normal picture.You can enjoy the Turbo picture so much
better then normal picture.
Repeatedly press the TURBO PICTURE button to switch on or off.
TURBO
Note : If you press the PSM or EYE/ * button with the Turbo picture
function, the Turbo picture function is automatically switched off.
14
Picture adjustment
PICTURE MENU
CONTRAST
BRIGHTNESS
COLOUR
SHARPNESS
PSM :
ARC (Aspect Ratio Control)
You can watch TV in various picture formats; Standard, Wide,
Zoom. Repeatedly press the ARC button to select your desired
picture format.
USER
Standard
This picture format is 4 : 3 of general TV.
MUTE
POWER
1
2
3
4
5
6
7
8
9
PSM
0
CBC
SLEEP
VOL
EQ/*
Wide
You can enjoy the cinema wide the picture format of wide or general
TV program through the mode.
Zoom
You can enjoy the cinema in vast screen through the Zoom mode.
The screen 4:3 is magnified to the upper/lower sides so that the
screen 16: 9 is full. The bottom and top of the picture may be lost.
Note :When you switch the set to standby or Off, the wide or Zoom
picture format is reset to the Standard (4:3).
SSM
Q-VIEW
PR
LIST
MENU
OK
VOL
PR
TV/AV
ARC
EYE/*
SOUND PICTURE
I/II
TURBO
15
Sound adjustment (option)
SSM (Sound Status Memory)
You can select your preferred sound setting; Flat, Music,
Movie or Speech and you can also adjust the sound frequency
of equalizer by pressing SSM button.
SOUND MENU
EQUALIZER
BALANCE
MUTE
POWER
1
2
3
4
5
6
7
8
9
PSM
CBC
SSM
0
EQ/*
Q-VIEW
LIST
Sound frequency adjustment (Equalizer)
a. After selecting the equalizer of sound menu press button
to display the equalizer.
b. Press the SSM button to select the different sound mode.
c. User can manually select desired frequency by pressing
/ Button and set it to the desired level by pressing
.
d. Press the OK button to save it.
FLAT
Press the TV/AV button to return to normal TV viewing.
You can also recall a desired sound (Flat, Music, Movie, Speech or
User) with SSM/* button on the remote control. The sound Flat,
Music, Movie and Speech are programmed for good sound
reproduction at the factory and cannot be changed.
EQUALIZER KEY
Equalizer MENU can be accessed with this direct key.
SLEEP
VOL
PR
MENU
OK
VOL
Note : If you press the SSM/* button after making appropriate
adjustment in Equalizer menu, the display User automatically
appears even though you have already set a factory preset setting;
Flat, Music, Movie or Speech.
PR
TV/AV
ARC
EYE/*
SOUND PICTURE
I/II
TURBO
16
Sound adjustment (option)
SOUND MENU
Balance adjustment
EQUALIZER
BALANCE
You can adjust balance.
1. Press the MENU button to select the Sound menu.
2. Press the button and then
button to select Balance.
3. Make desired adjustment with the
on the Balance pull-down
menu.
4. Press the TV/AV button to return to normal TV viewing.
MUTE
POWER
1
2
3
4
5
6
7
8
9
TURBO
(Turbo Sound Effect Off)
PSM
CBC
TURBO SOUND (option)
When this function is On, sound will be more emphasized and
amplified sound than normal sound. You can enjoy the TURBO
SOUND so much better than normal Sound.
Repeatedly press the TURBO SOUND button to switch On or Off.
SSM
0
EQ/*
(Turbo Sound Effect On)
Q-VIEW
LIST
CBC (Calibrated Bass Control) (Option)
By using this function you can adjust the desired bass level.
Sound output selection
SLEEP
VOL
PR
MENU
OK
VOL
PR
TV/AV
ARC
EYE/*
SOUND PICTURE
I/II
TURBO
In AV mode, you can select output sound for the left and right
loudspeakers.
Repeatedly press the I/II/ button to select the sound output.
L+R : Audio signal from audio L input is sent to left loudspeaker and audio signal from audio R input is sent
to right loudspeaker.
L+L : Audio signal from audio L input is sent to left and
right loudspeakers.
R+R : Audio signal from audio R input is sent to left and
right loudspeakers.
17
Other functions
Auto AV switching (option)
SPECIAL MENU
CHILD LOCK
AUTO SLEEP
BLUE BACK
AVL
CSM
GAME
TIME FUNCTION
LANGUAGE
When your VCR outputs is connected to Euro scart socket and VCR
switch to playback, then set is automatically switched to AV mode
when an AV signal is input, but if you want to keep on watching TV
mode, press the
or number buttons.
Press the TV/AV button to return to AV mode.
MUTE
POWER
1
2
3
4
5
6
7
8
9
PSM
0
CBC
SLEEP
VOL
EQ/*
SSM
Q-VIEW
PR
LIST
MENU
OK
Child lock
The TV can be set so that only the remote control handset is needed
to control it. This feature can be used to prevent unauthorized
viewing.
1. Repeatedly press the MENU button to select the Special menu.
2. Press the button and then
button to select Child lock.
3. Press the
button to select On or Off on the Child lock pulldown menu.
4. Press the TV/AV button to return to normal TV viewing.
When the child lock is On, the display Child lock on appears on the
screen (if any button on the front panel is pressed while viewing the
TV).
Note : The display Child lock on will not appear on the screen if any
button on the front panel is pressed while displaying the menus.
VOL
PR
TV/AV
ARC
EYE/*
SOUND PICTURE
I/II
TURBO
18
Other functions
SPECIAL MENU
CHILD LOCK
AUTO SLEEP
BLUE BACK
AVL
CSM
GAME
TIME FUNCTION
LANGUAGE
Auto sleep
If you select On in the Auto sleep pull-down menu, the set will
automatically switch itself to standby mode approximately ten
minutes after a TV station stops broadcasting.
MUTE
POWER
1
2
3
4
5
6
7
8
9
PSM
0
CBC
SLEEP
VOL
EQ/*
SSM
Q-VIEW
PR
LIST
MENU
OK
VOL
EYE/*
SOUND PICTURE
I/II
Blue back
If you select On in the Blue back pull-down menu, the blue
background appears on the screen when there is no signal or poor
signal.
1. Repeatedly press the MENU button to select the
Special menu.
2. Press the button and then
button to select Blueback.
3. Press the
button to select On or Off on the Blue back pulldown menu.
4. Press the TV/AV button to return to normal TV viewing.
Note : a. The blue background automatically appears on the
screen when there is no signal in TV mode.
b. If any OSD appears on screen, blue back will go Off.
AVL (Auto Volume Leveler)
If you select AVL On, the set automatically keeps On an equal
volume level even if you change programmes.
PR
TV/AV
ARC
1. Repeatedly press the MENU button to select the Special menu.
2. Press the button and then
button to select Auto sleep.
3. Press the
button to select On or Off on the Auto sleep pulldown menu.
4. Press the TV/AV button to return to normal TV viewing.
TURBO
1. Repeatedly press the MENU button to select the
Special menu.
2. Press the
button and then
button to select AVL.
3. Press the
button to select On or Off on the AVL. Pull-down
menu.
4. Press the TV/AV button to return to normal TV viewing.
CSM ( Colour Status Memory)
You can select the picture colour status; standard, reddish,
greenish or bluish, as you prefer.
1. Repeatedly press the MENU button to select the Special menu.
2. Press the button and then
button to select CSM.
3. Press the
button to select Standard, Reddish,
Greenish or Bluish on the CSM pull-down menu.
4. Press the TV/AV button to return to normal TV viewing.
19
Other functions
SPECIAL MENU
Sleep timer
You don't have to remember to switch the set Off before you go to
sleep. The sleep timer automatically switches the set to standby
after the preset time elapses.
Press the SLEEP button to select the number of minutes. The
display --:-- will appear on the screen, followed by 00:10, 00:20,
00:30, 01:00, 01:30, 02:00, 03:00 and 04:00. The timer begins to
count down from the number of minutes selected.
CHILD LOCK
AUTO SLEEP
BLUE BACK
AVL
CSM
GAME
TIME FUNCTION
LANGUAGE
MUTE
POWER
1
2
3
4
5
6
7
8
9
PSM
0
CBC
SLEEP
VOL
EQ/*
Q-VIEW
PR
LIST
MENU
OK
VOL
EYE/*
SOUND PICTURE
I/II
Game (option)
1. Repeatedly press the MENU button to select the Special menu
2. Press the
button and then
button to select Game.
3. Press the
button to enter the game mode.
SSM
PR
TV/AV
ARC
Note :
a. To view the remaining sleep time, press the SLEEP button once.
b. To cancel the sleep time repeatedly press the SLEEP button until
the display
--:-- appears.
c. When you switch the set off, the set releases the preset
sleep time.
TURBO
Space Fighter (Option)
Press the button to shoot the space bugs. Press
to move the
space craft to Left/Right.To kill the bug shoot at center. If you kill all the
bugs in given time you can go to next level by pressing OK button. Game
can be paused and resumed by pressing the RED key. After game over
press RED key to restart or MENU key to exit .
Note :
a. Press the MENU button to return to the normal TV viewing.
b. Game can be played only by the remote control.
Remote control for game (option)
This remote control is optional supply. if it’s supplied to you, use it
when playing the game.
POWER : switches the set On from standby or Off to
standby.
MUTE : switches the sound On/ Off.
MENU : exit from game mode.
PR
/VOL
OK
: controls the game in the same way as
main remote do.
20
Other functions
SPECIAL MENU
Time functions
The time uses 24 hrs. system and must be set to the correct time
before operating the set.
1. Press MENU to select special menu .
2.
and
key select time function.
3. After selecting ‘Time Function’ press key to enter ‘Time’.
4. Set Time using
and
keys.
5. Press OK to store.
6. Press TV/AV to return to normal TV viewing.
CHILD LOCK
AUTO SLEEP
BLUE BACK
AVL
CSM
GAME
TIME FUNCTION
LANGUAGE
MUTE
POWER
1
2
3
4
5
6
7
8
9
PSM
0
CBC
SLEEP
VOL
EQ/*
SSM
Q-VIEW
PR
LIST
MENU
OK
VOL
PR
TV/AV
ARC
EYE/*
SOUND PICTURE
I/II
Note :
a. In the event of power interruption, time must be reset.
b. Time resets if mains is unplugged.
c. Timer accuracy is ± 3 minutes/24 hrs.
ON Time
1. After entering ‘TIME FUNCTION’ select ‘ON TIME’ with
and
key.
2. Also set ‘ON TIME’ in ON condition with
and
keys to activate
the ‘ON TIME’.
On programme number/On Volume.
By using these functions the set automatically switches on a preset
programme on a preset volume level.
1. SET ON TIME (Hrs : Min) PR NO, VOL level
2. Press the
button to select On programme/On Volume
3. Select programme number by pressing
buttons. Select and
adjust volume by pressing
buttons.
4. Repeatedly press the OK button to return normal
viewing.
Off Time
1. After entering ‘TIME FUNCTION’,select ‘OFF TIME’ with
and
key.
2. Set ‘OFF TIME’ using
and
keys.
3. Set ‘OFF TIME’ ‘ON’ using
and
keys to activate ‘ OFF TIME’.
Programme surfing
The set automatically switches to a preset programme at or preset
time. You must set the time correctly before using this function.
TURBO
1. After entering ‘TIME FUNCTION’ select PROGRAMME
SURFING’ using
and
keys.
2. Using
and
keys set PROGRAMME SURFING ‘ON’
3. Using
and
keys select the desired Programme No. and
time.
4. Press OK and the TV/AV for normal viewing.
TIME
OFF TIME
ON TIME
PROGRAMME SURFING
OFF
PR --- -- : -- AM
PR --- -- : -- AM
PR --- -- : -- AM
PR --- -- : -- AM
PR --- -- : -- AM
Note :
a. If the same time is set for the On time and the Off time then Off
time operates.
b. To operate the On Time Function, the set must be put in
standby mode with the POWER button on theremote control.
c. Once the On or Off time is set, these functions operate daily at
preset time, if time is set.
21
Connection of external equipment
You can connect additional equipment, such as VCRs, camcorders
etc. to your set.
Here shown may be somewhat different from your set.
Aerial socket
1. Connect the RF out socket of the VCR to the aerial socket on the
back of the set.
2. Connect the aerial cable to the RF aerial in socket of the VCR.
3. Store the VCR channel on a desired programme number using
the 'Manual programme tuning' section.
4. Select the programme number where the VCR channel is stored.
5. Press the PLAY button on the VCR.
Audio Video in/out sockets (option)
1. Connect the audio/video out sockets of the VCR to audio/video
in sockets of the set and in sockets of the VCR to out sockets of
the set.
2. If the VCR is connected to the AV sockets on the set, press the
TV/AV button to select AV.
3. Press the PLAY button on the VCR.
The VCR playback picture appears on the screen.
You can also record programmes received by the TV on
video tape via audio/video out sockets.
Note: a. If audio input is only L or R select L+L or R+R through
I/II/ key on remote control.
b. Front AV and rear AV not to be used simultaneously.
c. If you have a mono VCR, connect the audio cable from the
VCR to the AUDIO (L/MONO) socket onthe back of the set.
Euro scart socket (option)
1. Connect the Euro scart socket of the VCR to the Euro scart
socket of the set.
2. Press the PLAY button on the VCR.
If your VCR outputs a switching voltage connect to Euro scart
socket, the set will switch to AV mode automatically. But if you
want to keep on watching TV mode, press the
or NUMBER
buttons.
Otherwise press the TV/AV button on the remote control
handset to select AV. The VCR playback picture a p p e a r s o n
the screen.
You can also record programmes received by the TV on video tape.
Component in sockets (option)
1. Connect the COMPONENT video output sockets (Y Cb Cr, Y Pb
Pr or Y B-YR-Y) of the COMPONENT (480) to the
COMPONENT INPUT sockets ( Y PB PR ) on the set.
2. Connect the audio cable from the COMPONENT to AUDIO
sockets of COMPONENT INPUT.
3. Press the TV/AV button to select COMPONENT.
4. Press the PLAY button on the COMPONENT.
THE COMPONENT playback picture appears on the screen.
PR
VIDEO
AUDIO
AV
Headphone socket (option)
In some models which have a headphone socket can perform this
function.
Insert the headphone plug to the headphone socket of the set. You
can listen to the sound through the headphone. To adjust the
headphone volume, press the / button.
If you press the MUTE button the sound from the headphone and
TV's speakers are switched Off.
22
Troubleshooting check list
Symptoms
No picture, no sound
Sound OK, poor picture
Picture OK, poor sound
Picture blurred
Lines or streaks in picture
Poor reception on some channels
No colour
Poor colour
Remote control does not work
Check following items and try
to adjust these
The mains plug-(plugged in and
switched on)
Is the TV switched on
Try another channel (weak signal)
Check aerial (plugged into TV?)
Check aerial (broken lead?)
Check aerial
Check for local interference
Adjust contrast
Adjust brightness
Adjust colour
Adjust volume
Check the batteries in remote control
Check Audio/Video sockets (VCR only)
NOTE :
I) Colour patch might appear in your TV set if you rotate or shift the position of the set while it is on or
in standby mode. If patch appears in your TV set try the following before calling your service
centre or dealer. Place the TV set in desired position and switch it off by the main power switch.
Allow the set to cool down for at least 30 minutes and then switch it on. The degaussing circuit
(inbuilt) in your set will remove the patch automatically. Please call service only in case this
operation does not help.
24
Download PDF

advertising
