Colour Television
OWNER'S MANUAL
Please read this manual carefully before operating your set.
Retain it for future reference.
Record model number and serial number of the set.
See the label attached on the back cover and quote this
information to your dealer when you require service.
P/NO : 3828VA0A18C(MC019A/C,00)
Installation
Power
This set operates on an AC mains supply, the voltage is as indicated on the label on the back
cover. Never apply DC power to the set. In the event of thunderstorms or powercuts, please
pull out the aerial and mains plugs.
Warning
To prevent fire or shock hazard, do not expose the set to rain or moisture.
Service
Never remove the back cover of the set as this can expose you to very high voltage and other
hazards. If the set does not operate properly, unplug it and call your dealer.
Aerial
Connect the aerial cable to the socket marked
reception an outdoor aerial should be used.
75 W on the back cover. For the best
Location
Position your set so that no bright light or sunlight falls directly onto the screen. Care should
be taken not to expose the set to any unnecessary vibration, moisture, dust or heat. Also
ensure that the set is placed in a position to allow a free flow of air. Do not cover the ventilation
openings on the back cover.
Battery installation
The remote control handset is powered by two AAA/AA type batteries. To load the batteries,
turn the remote control handset over and open the battery compartment. Install two batteries
as indicated by the polarity symbols (¯ and ) marked inside the compartment.
Note : To avoid damage from possible battery leakage, remove the batteries if you do not plan
to use the remote control handset for an extended period of time.
Caution: Please do not use stabilizer with TV set as this set has inbuilt voltage stabilizer. Use
of Inferior quality stabilizer may damage the set.
2
Location and function of controls
All the functions can be controlled with the remote control
handset. Some functions can also be adjusted with the buttons
on the front panel of the set.
Remote control handset
Before you use the remote control handset, please install the
batteries. See the next page.
1.
POWER
switches the set from on to standby or standby to on.
2.
NUMBER BUTTONS
switches the set on from standby or directly select a
Programme number.
3.
MENU
selects a menu.
4.
EYE/* (option)
switches the eye function on or off.
5.
( )
( ) (Programme Up/Down)
selects a programme or a menu item.
switches the set on from standby.
scans programmes automatically(option).
(Volume Up/Down)
adjusts the volume.
adjusts menu settings.
OK
accepts your selection or displays the current mode.
6.
Q. VIEW
returns to the previously viewed programme.
selects a favorite programme.
7.
PSM (Picture Status Memory)
recalls your preferred picture setting.
8.
TURBO PICTURE / SOUND BUTTON (option)
selects Turbo picture and sound.
9.
MUTE
switches the sound on or off.
2
SSM
PSM
14
7
POWER
ME
NU
E
UT
M
1
3
9
5
CBC
16
Q-VIE
T
LIS
W
12
6
ARC
15
13
11
SLEEP
I/II
EYE
SOUND
TV/AV
10
4
8
TURBO
(For AV Stereo)
TYPE-A
POWER
MUTE
9
1
2
3
4
5
6
7
8
9
I/II
0
TV/AV
1
2
11
4
ME
NU
EYE
10
3
5
7
16
15
12
8
PSM
SSM
CBC
ARC
Q.VIEW
LIST
SLEEP
PICTURE SOUND
TURBO
14
6
13
10. TV/AV
selects TV or AV mode.
clears the menu / text from the screen. switches the set on
from Standby.
11. I/II/ (option)
selects the language during dual language broadcast
(option).
selects the sound output.
12. LIST
displays the programme table.
press TV/AV to clear the LIST table from the screen.
13. SLEEP
sets the sleep timer.
14. SSM/ (option) (Sound Status Memory)
recalls your preferred sound setting.
15. ARC (option)
change picture format (zoom/wide/standard)
(For AV Stereo/Mono) 16. CBC/ (option)
TYPE-B
calibrated bass control.
COLOURED BUTTONS : These buttons are used for programme
edit.
Remarks : Some keys in remote can be non-functional, these
keys are use in other models.
3
Location and function of controls
Shown below is a simplified representation of front or side panel,
here shown may be somewhat different from your set.
Front panel
VIDEO
VIDEO
6
(L)
I
AUDIO
(R)
AUDIO
ON/OFF
1
MENU OK
2 3 4
VIDEO (L)-AUDIO-(R)
PR
VOL
5
6
P-TURBO-S
7
7
ON/OFF
7
(L)
I
AUDIO
(R)
6
AUDIO
(Side Panel)
SOUND PICTURE
ON/OFF
2 3 4
5
MENU
VOL
6
7
8
TURBO
PR
VOL
PR
OK
SOUND PICTURE
5
2 3 4
9
8
9
1. MAIN POWER (ON/OFF)
switches the set on or off.
2. POWER/STANDBY INDICATOR
Illuminates brightly when the set is in standby mode.
dims when the set is switched on.
blinks when signal is input from the remote control.
AV
7
R
AUDIO
3. REMOTE CONTROL SENSOR
L
6
1
1
RF-21FC80Q/E
RF-21FC81Q
VIDEO
4. MENU
selects a menu.
POWER
MUTE
1
9
2
ARC
PSM
7
MENU
SLEEP
3
13
5
10
4
TV/AV
12
VIDEO (L)-AUDIO-(R)
PR
VOL
9
VIDEO
VIDEO
15
MENU OK
8
TURBO
EYE
Q-VIEW
LIST
6
5. OK
Accepts your selection or displays the current mode.
(Volume Up/Down)
adjusts the volume.
adjusts menu settings.
(Programme Up/Down)
selects a programme or a menu item.
switches the set on from standby.
6. AUDIO/VIDEO IN SOCKETS (AV) (option)
Connect the audio/video out sockets of external
equipment to these sockets.
Note : a. If audio input is only L or R select L+L or R+R
through I/II/ key on remote control.
b. Front AV and rear AV not to be use simultaneously.
7. HEADPHONE SOCKET (option)
Connect the headphone plug to this socket.
8. TURBO SOUND/PICTURE (option)
switches Turbo sound or Turbo picture on or off.
9. EYE (option)
adjusts picture according to the surrounding conditions.
(For Mono)
4
Basic operation
On and off
1. Press the main power button to switch the set on.
2. If the set is in standby mode, press the POWER,
,
TV/AV or NUMBER buttons on the remote control
handset to switch it on fully.
3. Press the POWER button on the remote control
handset.
The set reverts to standby mode.
4. Press the main power button again to switch the set off.
Note : If, while the set is switched on, the mains plug is
disconnected the set will switch to standby or power on
when the mains plug is replaced in the mains power socket.
SSM
POWER
Programme selection
ME
NU
E
UT
M
You can select a programme number with the
NUMBER Buttons.
or
Volume adjustment
Press the
Q-VIEW
T
LIS
button to adjust the volume.
Quick view
Press the Q.VIEW button to view the last programme you
were watching.
I/II/*
SOUND
TURBO/*
Note : This function works only when Favorite programme
is set to Off. Otherwise each press of this button will select a
stored favorite programme.
Mute function
Press the MUTE button. The sound is switched off and the
display
appears.
You can cancel it by pressing the MUTE,
, SSM/*,
TURBO SOUND button.
Auto Demonstration (option)
To review all the menus programmed in the set, press the
OK button of the front panel control for about 5 seconds. To
stop auto demonstration, press any button of the front panel
control or POWER button of the remote control.
On screen language selection (option)
The menu can be displayed on the screen in desired
language. First select your language.
1. Press the MENU button to select the Station menu.
2. Press the button and then
button to select
Language.
3. Press the button and then
button to select your
desired language.
All the on screen displays will appear in the selected
language.
4. Press the TV/AV button to return to normal TV viewing.
5
On screen menus
The dialogue between you and your set takes place on
screen with an operator menu. The buttons required for the
operating steps are also displayed.
Menu selection
PSM
SSM
ME
NU
1. Repeatedly press the MENU button to display each
menu.
2. Press the
button and then
button to select a
menu item.
3. Press the
button to display the sub menu or the pulldown menu.
4. Change the setting of an item in the sub or pull-down
menu with
or
.
You can move to the higher level menu with OK button and
to move to the lower level menu press the button.
Note :
a. In the AV mode the Station menu is not displayed.
b. In the teletext mode, menus are not displayed
c. In mono models the Sound menu does not appear.
Note : In sound menu woofer/turbo bass system
is optional.
6
Setting up TV stations
Up to 200 stations can be stored by programme numbers
(0 to199). Once you have preset the stations you will be
able to use the
or NUMBER buttons to scan the stations
you programmed. Stations can be tuned using automatic or
manual modes.
Note : In some models up to 100 TV stations can be stored.
SSM
PSM
ME
NU
Auto programme tuning
All stations that can be received are stored by this method. It
is recommended that you use auto programme during
installation of this set.
1 . Repeatedly press the MENU button to select the
Station menu.
2. Press the button and then
button to select Auto
programme.
3. Press the
button to display the Auto programme
menu.
T
Q-VEIW
ARC
SLEEP
I/II
SOUND
EYE
LIS
TV/AV
4. Press the
button to select System. Select a TV
system with the
button on the System pull-down
menu;
BG
: (Asia/New Zealand/M.East/Africa/Australia)
I
: (Hong Kong/South Africa)
DK : (East Europe/China/Africa/CIS)
M
: (USA/Korea/Philippines)
5. Press the
button to select Storage from.
6. Select the beginning programme number with the
button or NUMBER buttons on the Storage from
pull-down menu. Any number under 10 is entered with a
numeric '00' in front of it, i.e. '005' for 5.
7. Press the
button to select Normal or Turbo search.
Note :
a. Turbo search is further faster than Normal Search and
in some models, these searches will automatically store
all receivable stations.
b. lf the programmed station has poor quality sound,
select the system again in the Manual programme
menu.
(Normal search)
(Turbo search)
8. Press the button to begin auto programming.
All receivable stations are stored.
To stop auto programming, press the MENU button.
When auto programming is completed the Programme
edit menu appears on the screen. See the 'Programme
edit' section to edit the stored programme.
9. Press the TV/AV button to return to normal TV viewing.
7
Setting up TV stations
Auto programme scan (option)
To automatically scan the pictures of stored programmes,
press the ( ) or ( ) button for about 3 seconds. The
picture of stored programmes appears on the screen one by
one.
To stop auto programme scanning, press any button.
Manual programme tuning
Manual programme lets you manually tune and arrange the
stations in whatever order you desire. Also you can assign a
station name with five characters to each programme number.
SSM
POWER
ME
NU
E
UT
M
Q-VEIW
ARC
SLEEP
I/II
EYE
SOUND
T
LIS
TV/AV
TURBO
1. Repeatedly press the MENU button to select the Station
menu.
2. Press the button and then
button to select Manual
programme.
3. Press the button to display the Manual programme
menu.
4. Press the
button to select System. Select a TV system
with the
button on the System pull-down menu;
BG : (Asia/New Zealand/M.East/Africa/Australia)
I
: (Hong Kong/South Africa)
DK : (East Europe/China/Africa/CIS)
M : (USA/Korea/Philippines)
5. Press the
button to select Channel. Press the
button to select V/UHF or Cable on the Channel pull-down
menu.
If possible, select the channel number 1 to 69 (V/UHF) and 1
to 47 (cable) directly with the number buttons, Any number
under 10 is entered with a numeric '0' in front of it i.e. '05 'for5
.
6. Press the
button to select Search. Press the
button
to commence searching on the Search pull-down menu. If a
station is found the search will stop.
7. If this station is the one required, press the
button to
select Storage. Select the desired programme number (0 to
199) with the
button or NUMBER buttons on the
Storage. pull-down menu. Any number under 10 is entered
with a numeric '00' in front of it, i.e. '005' for 5.
8. Press the OK button to store it. The display Stored will
appear.
9. To store another station, repeat steps 4 to 8.
Assigning a station name
1.
2.
3.
4.
5.
Repeat the 'Manual programme tuning' steps 1 to 3.
Press the
button to select Name.
Press the button on the Name pull-down menu. You
can use a blank, +, -, the numeric 0 to 9 and the
alphabet A to Z.
With the button you can select in the opposite direction.
Select the next position by pressing the button and then
take your choice of the second character, and so on.
Repeat the 'Manual programme tuning' steps 7 to 8.
8
Setting up TV stations
Fine tuning
Normally fine tuning is only necessary if reception is poor.
1. Repeat the 'Manual programme tuning' steps 1 to 3.
2. Press the
button to select Fine.
3. Press the
button to fine tune for the best picture
and sound on the Fine pull-down menu.
4. Repeat the 'Manual programme tuning' steps 7 to 8.
5. Press the TV/AV button to return to normal TV viewing.
The finely tuned programme will be indicated by red
number during programme selection.
6. Change of “
” from Yellow to red indicates tuning is
proper.
Programme edit
This function enables you to delete or skip the stored
programmes.
Also you can move some stations to other programme
numbers or insert a blank station data into the selected
programme number.
1. Repeatedly press the MENU button to select the Station
menu.
2. Press the
button and then
button to select
programme edit.
3. Press the button to display the programme edit
menu.
Deleting a programme
1. Select a programme to be deleted with the
or
button.
2. Press the RED button twice.
The selected programme is deleted, all the following
programmes are shifted up one position.
Copying a programme
1. Select a programme to be copied with the
or
button.
2. Press the GREEN button.
All the following programmes are shifted down one
position.
9
Setting up TV stations
Moving a programme
1 . Select a programme to be moved with the
button.
2. Press the YELLOW button.
or
3. Move the programme to the desired programme number
with the
or
button.
4. Press the YELLOW button again to release this function.
Skipping a programme number
1. Select a programme number to be skipped with the
or
button.
2. Press the BLUE button. The skipped programme turns to
blue.
3. Press the BLUE button again to release the skipped
programme.
When a programme number is skipped it means that you will
be unable to select it using the
button during normal TV
viewing.If you want to select the skipped programme,
directly enter the programme number with the NUMBER
buttons or select it in the programme edit or table menu.
Press the TV/AV button to return to normal TV viewing.
Favorite programme
This function lets you select your favorite programmes
directly.
1. Repeatedly press the MENU button to select the
Station menu.
2. Press the
button and then
button to select
Favorite. Programme.
3. Press the button to display the Favorite programme
menu.
SSM
PSM
POWER
ME
Q-VIEW
ARC
SLEEP
I/II
EYE
SOUND
NU
T
LIS
TV/AV
TURBO
4. Press the
button to select
5. Select a desired programme with the
button or
NUMBER buttons. Any number under 10 is entered
with a numeric ‘00’ in front of it, i.e. ‘005’ ' for 5.
6. To store another programme, repeat steps 4 to 5. You
can store up to 5 programmes.
7. Press the TV/AV button to return to normal TV viewing.
Repeatedly press the Q. VIEW button to select stored
favorite programmes.
Calling the programme table
You can check the programmes stored in the memory by
displaying the programme table.
Displaying programme table
Press the LIST button to display the Programme table
menu. The programme table appears on the screen. One
programme table contains ten programmes as follow.
10
Setting up TV stations
Note :
a. You may find some blue programmes. They have been
set up to be skipped by auto programming or in the
programme edit mode.
b. Some programmes with the channel number shown in
the programme table indicate there is no station name
assigned.
Selecting a programme in the programme table
Select a programme with the
or
button.
Then press the OK button.
The set switches to the chosen programme number.
Paging through a programme table
There are 20 programme table pages in which contain 200
programmes.
Pressing the
or
button repeatedly turns the pages.
Press the TV/AV button to return to normal TV viewing.
Picture adjustment
PSM (Picture Status Memory)
1. Repeatedly press the MENU button to select the Picture
menu.
2. Press The button and then
button to select PSM.
3. Press the
button to select a picture setting on the
PSM pull-down menu.
4. Press the TV/AV button to return to normal TV viewing.
You can also recall a desired picture (Dynamic, Standard,
Mild Game, or User) with PSM button on the remote
control. The picture Dynamic, Standard, Mild and Game
are programed for good picture reproduction at the factory
and cannot be changed.
Picture adjustment
You can adjust picture contrast, brightness, colour intensity,
sharpness and tint (NTSC input only) to the levels you
prefer.
1. Repeatedly press the MENU button to select the Picture
menu.
2. Press the
button and then
button to select User.
3. Press the
button to select the desired picture item
on the User pull-down menu.
11
Picture adjustment
4. Press the
button to make appropriate adjustments
on each sub menu.
You can also select other User items directly with
but
and adjust them with
button.
5. Press the OK button to store it for the picture User.
6. Press the TV/AV button to return to normal TV viewing.
Eye (option)
On some models, the set will automatically adjust the
picture according to the surrounding conditions. This will
enable you to enjoy the most suitable picture according to
the surroundings.
Press the EYE/ button to switch the eye function on or off.
When the eye function is on, the most suitable picture is
automatically adjusted according to the surrounding
conditions.
At this time the display........ in green does not appear
continuously but the display........in yellow appears each
time the picture condition changes.
Note : If you press the PSM or TURBO PlCTURE button
with the eye function, the eye function is automatically
switched off.
Turbo picture selection (option)
When this function is on, picture will be more brilliant and
distinct picture than normal picture. You can enjoy the Turbo
picture so much better than normal picture.
Repeatedly press the TURBO PICTURE button to switch
on or off.
(Turbo Picture off)
(Turbo Picture on)
Note : If you press the PSM or EYE/ button with the Turbo
picture function, the Turbo picture function is automatically
switched off.
Picture Format (option)
You can watch TV in various picture formats; Standard,
Wide, Zoom. Repeatedly press the ARC button to select
your desired picture format.
Standard
This picture format is 4 to 3 of general TV.
Wide
You can enjoy the cinema wide the picture format of wide or
general TV program through the mode. In AV mode wide
function does not work.
Zoom
You can enjoy the cinema in vast screen through the Zoom
mode. The screen 4:3 is magnified to the upper/lower sides
so that the screen 16:9 is full. The bottom and top of the
picture may be lost.
Note : When you switch the set to standby or off, the wide or
Zoom picture format is reset to the Standard (4:3).
12
Sound adjustment (option)
SSM (Sound Status Memory)
You can select your preferred sound setting; Flat,
Music, Movie or Speech and you can also adjust the
sound frequency of equalizer.
1. Repeatedly press the MENU button to select the
Sound menu.
2. Press the button and then
button to select SSM.
3. Press the
button to select a sound setting on the
SSM pull-down Menu.
SSM
PSM
POWER
ME
N
U
E
UT
M
Sound Frequency Adjustment
a. Press the button in User to display the User sub
menu.
b. Select a sound band by pressing the
button.
c. Make appropriate sound level with the
button.
T
Q-VEIW
ARC
SLEEP
I/II
EYE
SOUND
LIS
TV/AV
TURBO
d. Press the OK button to store it for the sound User.
The display Stored appears.
Press the TV/AV button to return to normal TV viewing.
You can also recall a desired sound (Flat, Music, Movie,
Speech or User) with SSM/ button on the remote control.
The sound Flat, Music, Movie and Speech are programmed
for good sound reproduction at the factory and cannot be
changed.
Note : If you press the SSM/ button after making
appropriate adjustment on the User sub menu, the display
User automatically appears even though you have already
set a factory preset setting; Flat, Music, Movie or Speech.
Balance adjustment
You can adjust balance.
1. Repeatedly press the MENU button to select the Sound
menu.
2. Press the button and then
button to select Balance.
3. Make desired adjustment with the
on the Balance pulldown menu.
4. Press the TV/AV button to return to normal TV viewing.
Woofer/Turbo Bass System on/off (option)
You can turn woofer/turbo bass system on/off
1. Press MENU button repeatedly to select sound menu.
2. Press the button and then
button to select woofer/turbo
bass system.
3. Press the button and turn woofer/turbo bass system On or
Off by pressing
button.
4. Press OK button to store current status.
5. Press the TV/AV button to return to normal TV viewing.
13
Sound adjustment (option)
/Turbo Bass System
Turbo sound selection (option)
When this function is on, sound will be more emphasized
and amplified sound than normal sound. You can enjoy the
Turbo Sound so much better than normal Sound.
Repeatedly press the TURBO SOUND button to switch on
or off.
(Turbo Sound off)
(Turbo Sound on)
CBC (Calibrated Bass Control) (Option)
By using this function you can adjust the desired bass level.
Sound output selection
In AV mode, you can select output sound for the left and
right loudspeakers.
Repeatedly press the I/II/ button to select the sound
output.
L+R :
Audio signal from audio L input is sent to left loudspeaker and audio signal from audio R input is sent
to right loudspeaker.
L+L :
Audio signal from audio L input is sent to left and
right loudspeakers.
R+R : Audio signal from audio R input is sent to left and
right loudspeakers.
Note : In sound menu woofer/turbo bass system is optional
Other functions
Special
Menu
TV and AV modes
Inputs can be set for TV or AV mode. AV mode is used when
a video cassette recorder (VCR), or other equipment is
connected to the set.
Note : When a VCR is connected via the aerial socket the
set is used in TV mode. See the Connection of external
equipment section.
1 . Repeatedly press the MENU button to select the Special
menu.
2. Press the
button and then
button to select Input.
3. Press the
button to select TV/AV (option) on the
Input pull-down menu.
AV : VCR connected to the Euro scart socket or AV sockets
on the set.
Note: a. If audio input is only L or R select L+L or R+R
through I/II/ key on remote control.
b. Front AV and rear AV not to be used simultaneously.
To return to TV mode, press the
or NUMBER buttons.
Alternatively you can select the TV or AV mode by pressing
the TV/AV button.
14
Other functions
Auto AV switching (option)
If your VCR outputs switching voltage when it is switched to
playback with the VCR connected to the Euro scart socket.
The set is automatically switched to AV mode when an AV
signal is input. But if you want to keep on watching TV
mode, press the
or NUMBER buttons.
Press the TV/AV button to return to AV modes.
Child lock
The TV can be set so that the remote control handset is
needed to control it. This feature can be used to prevent
unauthorized viewing.
1. Repeatedly press the MENU button to select the
Special menu.
2. Press the button and then
button to select Child
lock.
3. Press the
button to select On or Off on the Child
lock pull- down menu.
4. Press the TV/AV button to return to normal TV viewing.
With the lock on, the display Child lock on appears on the
screen if any button on the front panel is pressed while
viewing the TV.
Note : The display Child lock on will not appear on the
screen if any button on the front panel is pressed while
displaying the menus.
Auto sleep
Special
Menu
If you select On on the Auto sleep pull-down menu, the set
will automatically switch itself to standby mode
approximately ten minutes after a TV station stops
broadcasting.
1. Repeatedly press the MENU button to select the
Special menu.
2. Press the button and then
button to select Auto
sleep.
3. Press the
button to select On or Off on the Auto
sleep pull-down menu.
4. Press the TV/AV button to return to normal TV viewing.
Blue back
If you select On on the Blue back pull-down menu, the blue
background appears on the screen when there is no or poor
signal.
SSM
PSM
POWER
ME
NU
E
UT
M
Q-VEIW
ARC
SLEEP
I/II
EYE
SOUND
T
LIS
TV/AV
TURBO
1. Repeatedly press the MENU button to select the
Special menu.
2. Press the
button and then
button to select
Blueback.
3. Press the
button to select On or Off on the Blue
back pull-down menu.
4. Press the TV/AV button to return to normal TV viewing.
Note : a. The blue background automatically appears on
the screen when there is no signal in TV mode.
b. If any OSD appears on screen, blue back will go
off.
AVL (Auto Volume Leveler)
If you select AVL. On, the set automatically keeps on an
equal volume level even if you change programmes.
1. Repeatedly press the MENU button to select the
Special menu.
2. Press the
button and then
button to select AVL.
15
Other functions
3. Press the
button to select On or Off on the AVL.
Pull-down menu.
4. Press the TV/AV button to return to normal TV viewing.
CSM ( Colour Status Memory)
You can select the picture colour status; standard, reddish,
greenish or bluish, as you prefer.
1. Repeatedly press the MENU button to select the
Special menu.
2. Press the button and then
button to select CSM.
3. Press the
button to select Standard, Reddish,
Greenish or Bluish on the CSM pull-down menu.
4. Press the TV/AV button to return to normal TV viewing.
Special
Menu
Sleep timer
You don't have to remember to switch the set off before you
go to sleep. The sleep timer automatically switches the set
to standby after the preset time elapses.
Press the SLEEP button to select the number of minutes.
The display --:-- will appear on the screen, followed by
00:10, 00:20, 00:30, 01:00, 01:30, 02:00, 03:00 and 04:00.
The timer begins to count down from the number of minutes
selected.
Note :
a. To view the remaining sleep time, press the SLEEP
button once.
b. To cancel the sleep time repeatedly press the SLEEP
button until the display
--:-- appears.
c. When you switch the set off, the set releases the preset
sleep time.
Game (option)
1. Repeatedly press the MENU button to select the Special
menu
2. Press the
button and then
button to select Game.
3. Press the
button to enter the game mode.
4. Press the
button to select the game 1 or 2 and then
press the OK button.
5. Press the
button to select a level and then press the
OK button.
SSM
PSM
POWER
ME
NU
T
LIS
E
UT
M
ARC
SLEEP
I/II
EYE
SOUND
TV/AV
TURBO
1. BLOCK
6. Press the
button to select a block to shoot or to dump.
Press the button to shoot the block aiming same color
one or press the button to dump it.
Remove all the blocks on the screen with given blocks,
whose remained number is displayed on the right bottom
of the screen. If you use up all the given blocks or the
dumped blocks are accumulated to the end, you lose.
2. BALLOON
6. Press the
button to move the arrow.
Press the button to shoot an arrow aiming balloon only.
The numbers of balloons you should hit and you have hit
are displayed on the right bottom of the screen.
If you miss a balloon, it will be accumulated and you lose
the space to move the arrow as much as the
accumulated balloon.
If the missed balloons or the hit bricks are accumulated
to the end, you lose.
Note :
a. Press the TV/AV or MENU button to return to the normal
TV viewing.
b. If you want a new game, press the RED button to start.
c. This game mode can be operated only by the remote
control.
16
Other functions
LG CLIMB (option)
As on throwing a dice you get a random number in between
1 & 6, similarly there are six blocks in the game. After
selecting a block (by pressing
buttons) when you press
OK it will display the random number contained in the blocks
and your current position will be incremented by that
number. (The block selection will reset by itself and go to
first block.)
On reaching red position you go down by certain Points and
on reaching green button your position will be incremented
by certain points. The colour of cursor is yellow and it
indicates your Present Position. Maximum attempts are 25
and on reaching 99 you will win.
SSM
PSM
POWER
ME
NU
E
UT
M
1. Press
button to move from one block to others.
2. Press OK to select the block.
The selected block number will be added to your
present cursor point.
3. Repeat steps 1 and 2 until you reach position 99
within 25 attempts.
4. Press GREEN button to restart the game.
T
Q-VEIW
ARC
SLEEP
I/II
EYE
SOUND
LIS
TV/AV
TURBO
Cricket & Car racing (option)
1. Repeatedly press the MENU button to display MENU 4
2. Press the
button to select GAME.
3. Press the OK Button enter the game mode.
4. Press the
button to select to select the game 1 or 2,
then press the OK button.
1. Cricket
5. Press the
button to selected a number of overs to
play, then press the OK button.
6. Press the
button to select your team, then press the
OK button
7. press the
button to select a computer team, then
press the OK button.
8. Press the
button select your a uniform colour of your
team then press the OK button.
9. Press the
button to select the HEADS or TAILS, then
press the OK button.
10. Press the
button to select BATTING or FIELDING,
then press
the OK button.
11. Press the
button to select a bowler type, then press
the OK button to the start the game.
For fielding, first select a ball type with the
button and
then press the OK button. Secondly select a bowl
direction with the
button and then press the OK
button to throw the ball. For batting, select a hitter
position with the
button and then press the OK
button to hit the ball. After hitting the ball, control the
hitter with the
button.
2. Car racing
5. Press the
button to select a round, then the OK
button to start the game.
control the car with the
button.
17
Other functions
Remote control for game (option)
This remote control is optional supply. if it’s supplied to you,
use it when playing the game.
POWER : switches the set on from standby or off to
standby.
MUTE
: switches the sound on off.
TV/AV
: exit game mode.
MUTE
: display game menu and exit game mode.
PR
/VOL
OK
: controls the game in the same
way as main remote do.
Note:
a. Press the TV/AV or MENU button to return to the normal
TV viewing.
b. If you want a new game, press the RED button to start
on main remote or press OK button on the game
remote.
c. Remote handset (main remote or game remote) should
be use for operating game function.
Time functions
The time uses 24 hrs. System and must be set to the correct
time before operating the set.
Special
Menu
1. Press MENU to select special menu .
2.
and
key select time function.
3. After selecting ‘Time Function’ press key to enter
‘Time’.
4. Set Time using
and
keys.
5. Press OK to store.
6. Press TV/AV to return to normal TV viewing.
Note :
a. In the event of power interruption, time must be reset.
b. And Time can be reset by switching main power OFF.
ON Time
1. After entering ‘TIME FUNCTION’ select ‘ON TIME’ with
and
key.
2. SET ON TIME (Hrs : Min) PR NO, VOL level with
and
keys. Also set ‘ON TIME’ in ON condition with
and
keys to activate the ‘ON TIME’.
Off Time
1. After entering ‘TIME FUNCTION’,select ‘OFF TIME’ with
and
key.
2. Set ‘OFF TIME’ using
and
keys.
3. Set ‘OFF TIME’ ‘ON’ using
and
keys to activate ‘
OFF TIME’.
Program surfing
The set automatically switches to a preset program at or
preset time. You must set the time correctly before using
this function.
1. After entering ‘TIME FUNCTION’ select PROGRAM
SURFING’ using
and
keys.
2. Using
and
keys set PROGRAM SURFING
‘ON’
3. Using
and
keys select the desired Program
No. and time.
4. Press OK and the TV/AV for normal viewing.
18
Other functions
Note :
a. If the same time is set for the on time and the off time
then off time operates.
b. The set must be put in to standby mode with the
POWER button on the remote control to operate the
on time functions.
c. Two hrs after the set in switched ON by ON TIME
function it will automatically switch back to stand by
mode unless a button the has been pressed.
d. Once the on or off time in set, these functions operate
daily at preset time, if time is set.
Connection of external equipment
You can connect additional equipment, such as VCRs,
camcorders etc. to your set.
Here shown may be somewhat different from your set.
Aerial socket
1. Connect the RF out socket of the VCR to the aerial
socket on the back of the set.
2. Connect the aerial cable to the RF aerial in socket of the
VCR.
3. Store the VCR channel on a desired programme
number using the 'Manual programme tuning' section.
4. Select the programme number where the VCR channel
is stored.
5. Press the PLAY button on the VCR.
Audio Video in/out sockets (option)
1. Connect the audio/video out sockets of the VCR to
audio/video in sockets of the set and in sockets of the
VCR to out sockets of the set.
2. If the VCR is connected to the AV sockets on the set,
press the TV/AV button to select AV.
3. Press the PLAY button on the VCR.
The VCR playback picture appears on the screen.
You can also record programmes received by the TV on
video tape via audio/video out sockets.
Note: a. If audio input is only L or R select L+L or R+R
through I/II/ key on remote control.
b. Front AV and rear AV not to be used
simultaneously.
c. If you have a mono VCR, connect the audio cable
from the VCR to the AUDIO (L/MONO) socket on
the back of the set.
WOOFER OUT (option)
1.
2.
3.
4.
Sw1
Sw2
Woofer
NC
First three are the woofer out sockets, insert the woofer
connectors to these sockets. (whichever is available)
NC means no connection. Woofer connector not to be
inserted in this socket.
Euro scart socket (option)
1. Connect the Euro scart socket of the VCR to the Euro
scart socket of the set.
2. Press the PLAY button on the VCR.
If your VCR outputs a switching voltage connect to Euro
scart socket, the set will switch to AV mode
automatically. But if you want to keep on watching TV
mode, press the
or NUMBER buttons.
Otherwise press the TV/AV button on the remote control
handset to select AV. The VCR playback picture
appears on the screen.
You can also record programmes received by the TV on
video tape.
19
Connection of external equipment
Component in sockets (option)
1. Connect the COMPONENT video output sockets (Y Cb Cr,
Y Pb Pr or Y B-YR-Y) of the COMPONENT (480) to the
COMPONENT INPUT sockets ( Y PB PR ) on the set.
2. Connect the audio cable from the COMPONENT to AUDIO
sockets of COMPONENT INPUT.
3. Press the TV/AV button to select COMPONENT.
4. Press the PLAY button on the COMPONENT.
THE COMPONENT playback picture appears on the
screen.
PR
VIDEO
Headphone socket (option)
AUDIO
AV
In some models which have a headphone socket can perform
this function.
Insert the headphone plug to the headphone socket of the set.
You can listen to the sound through the headphone. To adjust
the headphone volume, press the / button.
If you press the MUTE button the sound from the headphone
and TV's speakers are switched off.
Note: When you are using head phone switch Off the woofer
by woofer on/off functions.
Troubleshooting check list
Symptoms
No picture, no sound
Sound OK, poor picture
Picture OK, poor sound
Picture blurred
Lines or streaks in picture
Poor reception on some channels
No colour
Poor colour
Remote control does not work
Check following items and try
to adjust these
The mains plug-(plugged in and
switched on)
Is the TV switched on
Try another channel (weak signal)
Check aerial (plugged into TV?)
Check aerial (broken lead?)
Check aerial
Check for local interference
Adjust contrast
Adjust brightness
Adjust colour
Adjust volume
Check the batteries in remote control
Check Audio/Video sockets (VCR only)
NOTE :
i)
ii)
Colour patch might appear in your TV set if you rotate or shift the position of the set while it is on or in standby mode. If patch
appears in your TV set try the following before calling your service centre or dealer. Place the TV set in desired position and
switch it off by the main power switch. Allow the set to cool down for atleast 30 minutes and then switch it on. The degaussing
circuit (inbuilt) in your set will remove the patch automatically. Please call service only in case this operation does not help.
In case of no sound on all channels, check for system. It should be 'BG' for India. In case of some other system select 'BG' and do
Auto Programming.
LG Electronics

advertisement

Was this manual useful for you? Yes No
Thank you for your participation!

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project

Related manuals

Download PDF

advertisement
