User Guide
This is a 「User Guide」 installed on the TV.
The contents of this guide are subject to change without prior notice for quality
improvement.
❐❐To view programme information
Displays information on current programme and / or current time, etc.
1 Move the pointer of the Magic remote control to the top of the TV screen.
2 Click the activated channel banner area.
3 The programme details will be displayed at the bottom of the TV screen.
✎✎ Image shown may differ from your TV.
Prev./Next
Pr. Change
Watch
Thu.
PM 4 : 28
PM 4 : 43
Current time
UP
DOWN
Programme name
Detail information on programme
(for digital broadcast)
❐❐To set favourite programmes
SMART
➾ Settings ➙ SETUP ➙ Programme Edit
1 Move to the desired programme and press Wheel (OK) button. Programme is
selected.
2 Press Set as Favourite.
3 Select the desired Favourite Pr. Group.
4 Select OK. Favourite is set.
❐❐To use Favourite
SMART
➾ Pr. List
Programme list will appear. Selects the desired preset favourite programme
from Favourite List A to D.
SMART
➾ TV Guide
[In Digital Mode Only]
Obtains information about programmes and airing times. Obtains programme
information and schedules viewing / recording.
[Image shown may differ from your TV.]
TV Guide
Today
OO OO. OOOO AM 9:00
Press Wheel (OK) button after moving to a
programme of your choice to view or view /
record.
Select schedule by date
Schedule List
P
-24H
P
+24H
After viewing the schedule list, makes
revisions or deletions.
Makes schedule reservation by selecting date / time /
programme. Makes repeat schedule reservation.
❐❐Automatically Setting Up Programme
SMART
➾ Settings ➙ SETUP ➙ Auto Tuning
Automatically tunes the programmes.
1 Select Country where the TV is used. Programme settings change depending
on the country you choose.
2 Initiate Auto Tuning.
3 Select Input Source of your choice.
4 Set Auto Tuning following screen instructions.
✎✎ If Input Source is not connected properly, programme registration may not
work.
✎✎ Auto Tuning only finds programmes that are currently broadcasting.
✎✎ If Lock System is turned on, a pop-up window will appear asking for
password.
❌❌Cable DTV Setting option
When searching for programmes using FULL setting it can take a long time.
The following values are needed in order to search all available programmes
quickly and correctly. The commonly used values are provided as “default”.
Frequency
Symbol rate
Modulation
Network ID
Start Frequency
End Frequency
Enter a user-defined frequency.
Speed at which a device such as modem sends symbols to
a programme.
Loading of audio or video signals onto carrier.
Unique identifier allocated for each user.
Enter a user-defined start frequency range.
Enter a user-defined end frequency range.
❌❌Satellite Setting Option
Satellite
LNB Frequency
Transponder
22KHz Tone
Select your desired Satellite.
[Depending on country]
Select one value from 9750/10600, 9750/10750, 9750,
10600,10750, 5150, MDU1, MDU2, MDU3, MDU4, MDU5.
If you select 9750/10600, 9750/10750(MHz), 22KHz
Tone is disabled. If you cannot find the LNB frequency
value from the list, select User and manually enter the
frequency.
Select the transponder you want to tune.
When using 22KHz Tone switch, select A or B. If you use
22KHz Tone, Unicable and Motor Type are disabled.
To enable the power supply for the LNB, select On. If you
select Off, Motor Type is disabled.
When using DiSEqC, select one option from A~D/ToneA~B.
DiSEqC
If you use DiSEqC, Unicable and Motor Type are disabled.
Select On to use Unicable and set the Unicable in the
Unicable Settings Unicable Setting menu. When Unicable is enabled, 22KHz
Tone, DiSEqC, Motor Type are disabled.
Select Motor Type to use Motor and set the Motor in the
Motor Type
Motor Setting menu. When Motor is enabled, 22KHz Tone,
DiSEqC, Unicable are disabled.
LNB Power
✎✎ If you set satellite to others, you must add a transponder using Manual
Tuning.
✎✎ When selecting 22KHz Tone and DiSEqC, you must connect them in the
same position as displayed on the OSD.
✎✎ If you delete a Satellite, all programmes stored in the Satellite are deleted.
❌❌Motor Setting Option
• DiSEqC 1.2 : Control motor to change satellite dish position.
Drive Direction
Drive Mode
Test TP
Select the direction in which you want to move the motor.
Two modes are available : Step and Continuous.
• Step : The motor moves based on the value you enter
(from 1 to 128).
• Continuous : The motor moves continuously until you
press the Stop.
Select the test TP you want to tune.
Set Limit
Go To Zero
Store
Set the motor movement to east or west to have the motor
move only within the direction set.
• On : You can limit the movement to the current
direction by selecting the West/East.
• Off : You can cancel the limit you set.
You can move the motor to Zero.
You can save the motor’s current direction.
• USALS : Set your current location (Longitude/Latitude).
❐❐Cable DTV Setting
SMART
➾ Settings ➙ SETUP ➙ Cable DTV Setting
[If the program mode is set to Cable]
Set Service Operator.
Service Operator When changing Service Operator, the existing saved
programmes are deleted and Auto Tuning runs.
• On : You can update information for all the programmes
that can be updated, including the programme currently
Channel Auto
being watched.
Update
• Off : You can only update information for the programme
currently being watched.
✎✎ The range that a user can select from the Service Operator menu differs
depending on number of Service Operator supported by each country.
✎✎ If number of supported Service Operator for each country is 1, corresponding
function becomes inactive.
✎✎ You can not select the Cable DTV Setting when the service operator is set to
“Ziggo”.
❐❐Satellite Setting
SMART
➾ Settings ➙ SETUP ➙ Satellite Setting
[If the programme mode is set to Satellite]
You can add/delete/set the satellite you want.
❐❐Tivu Programme List Update
SMART
➾ Settings ➙ SETUP ➙ Tivu Programme List Update
[Only Italy]
[If the programme mode is set to Satellite]
It updates the changed Programme List information by based on country
broadcasting circumstance and satellite.
It updates the Programme List when the TV turn off all the time. After updates,
the Programme List may be changed. If not want, select Off.
❐❐Programme List Update SMART
➾ Settings ➙ SETUP ➙ Programme List Update
[If the programme mode is set to Satellite]
It updates the changed Programme List information by based on country
broadcasting circumstance and satellite.
It updates the Programme List when the TV turn off all the time. After updates,
the Programme List may be changed. If not want, select Off.
✎✎ For Austria, Czech, France, Slovakia, Spain, Turkey, Norway, Sweden,
Finland, Denmark, Germany, Poland and Russia, this function is supported
when Service Operator is not set to None.
❐❐Regional Programme
SMART
➾ Settings ➙ SETUP ➙ Regional Programme
[Only Austria]
[If the programme mode is set to Satellite]
Set region broadcasting and watch region broadcasting at a specific time.
✎✎ To set Service Operator of Satellite, AKTIV must be selected.
❐❐Transponder Edit
SMART
➾ Settings ➙ SETUP ➙ Transponder Edit
[If the programme mode is set to Satellite]
You can add/modify/delete a transponder.
✎✎ If Country is set to Russia, press the Register as Home TP button on the
screen to set the desired transponder to Home.
[In Russia, satellite SO is set to NTV-PLUS and Tricolor TV.]
❐❐To use Manual Tuning
SMART
➾ Settings ➙ SETUP ➙ Manual Tuning
Adjusts programmes manually and saves the results.
For digital broadcasting, signal strength and signal quality can be checked.
✎✎ You can also adjust the frequency (KHz) and Bandwidth.
❐❐To edit programmes
SMART
➾ Settings ➙ SETUP ➙ Programme Edit
Edits the saved programmes.
Set as favourite programme, block/unblock programme, skip programme etc. of
the selected programme.
SMART
➾ Settings ➙ SETUP ➙ Programme Mode
This function allows you to watch a tuned program in Antenna, Cable, Satellite,
or CAM Mode.
✎✎ You can only watch programs in the selected mode.
✎✎ The CAM menu is only available when the CAM Mode is enabled. The menu
name may vary depending on the CAM type.
(Magic Remote Control) ➾
(Screen Remote Control)
(or press the TEXT button.)
[Depending on country]
Teletext is a free service provided by the TV station that offers text-based
information about TV programmes, news and weather.
The teletext decoder of this TV can support the SIMPLE, TOP and FASTEXT
systems.
Colour button
Number button
ꔵ
To select the preceding or following page.
Enters the page number to move to.
To select the preceding or following page.
❐❐Special Teletext Function
(Magic Remote Control) ➾
(Screen Remote Control)
(or press the T. OPT button.)
Select the Text Option menu.
ꔻ Index
ꔾ Time
ꕀ Hold
Select each index page.
When viewing a TV programme, select this menu to display the
time at the top right hand corner of the screen.
Stops the automatic page change which will occur if a teletext
page consists of 2 or more sub pages.
ꔽ Reveal
ꔼ Update
Language
Select this menu to display concealed information, such as
solutions to riddles or puzzles.
Displays the TV picture on the screen while waiting for a new
teletext page.
[In Digital Mode Only]
Sets Teletext language.
(Magic Remote Control) ➾
(Screen Remote Control)
(or press the TEXT button.)
[In UK/Ireland only]
The TV gives you access to digital teletext which gives much better text,
graphics etc. than older analogue teletext. This digital teletext can access
special digital teletext services and specific services which broadcast digital
teletext.
❌❌Teletext within digital service
1 Press the numeric or ꔵ button to select a certain service which broadcasts
digital teletext.
2 Follow the indications on digital teletext and move onto the next step by
pressing
(Magic Remote Control), TEXT, Navigation, Red, Green, Yellow,
Blue or NUMBER buttons etc..
3 Press the number or ꔵ button to use a different digital teletext service.
❌❌Teletext in digital service
1 Press the numeric or ꔵ button to select a certain service which broadcasts
digital teletext.
2 Press the TEXT or colour button to switch on teletext.
3 Follow the indications on digital teletext and move onto the next step by
pressing
(Magic Remote Control), Navigation, Red, Green, Yellow, Blue or
NUMBER buttons etc..
4 Press the TEXT or colour button to switch off digital teletext and return to TV
viewing.
❐❐To Set MHP Auto Start
SMART
➾ Settings➙ OPTION ➙ MHP Auto Start
[Depending on model] [In Italy only]
This function Auto Starts the MHP function, Italian data broadcast. Use in
programme with MHP signal. Data broadcast function may not be smooth due to
situation from the broadcasting station.
✎✎ MHP is not available while using Time Machine Ⅱ.
❐❐What is HbbTV?
[Depending on model] [Depending on Country]
The HbbTV or Hybrid Broadcast Broadband TV replaces existing analogue
teletext services with a new-generation, web-based interactive broadcasting
service. Similar to digital text and EPG, HbbTV can be used to provide a
variety of services in addition to standard broadcast content.
The functionality and quality of the HbbTV service may vary depending on
your broadcast service provider.
This function may not be available in some countries.
In France, the HbbTV service is available via terrestrial broadcasting.
In Germany, it is available via terrestrial, cable and satellite broadcasting.
In Spain, the HbbTV service is available via terrestrial broadcasting. The
content and the applications depends on the Broadcaster.
For more information about HbbTV, visit www.hbbtv.org.
❐❐To use HbbTV
SMART
➾ Settings ➙ OPTION ➙ HbbTV Sets HbbTV to On. Enjoy a variety of content on the HbbTV service.
✎✎ The service may be limited when the device is not connected to the
internet.
✎✎ You can control HbbTV using the direction keys, and point and click function
of the Magic Remote Control are not supported.
✎✎ If HbbTV is set to On, the PenTouch function does not work. (Only PenTouch
TV.)
SMART
➾ Settings ➙ OPTION ➙ Data Service
[Depending on country]
This function allows users to choose between MHEG (Digital Teletext) and
Teletext if both exist at the same time.
If only one of them exists, either MHEG or Teletext is enabled regardless of
which option you selected.
SMART
➾ Settings ➙ SETUP ➙ CI Information
• This function enables you to watch some encrypted services (pay services).
• If you remove the CI Module, you cannot watch pay services.
• CI (Common Interface) functions may not be possible depending upon the
country broadcasting circumstances.
• When the module is inserted into the CI slot, you can access the module
menu.
• To purchase a module and smart card, contact your dealer.
• When the TV is turned on after inserting a CI Module, you may not have any
sound output. The Smart Card may not be compatible with the CI module.
• When using a CAM(Conditional Access Module), please make sure it meets
fully the requirements of either DVB-CI or CI plus.
• An abnormal process of CAM(Conditional Access Module) may cause a
bad picture.
• [Depending on model] If the TV does not display any video and audio when
CI+ CAM is connected, please contact to the Terrestrial/Cable/Satellite
Service Operator.
SMART
➾ Settings ➙ PICTURE ➙ Aspect Ratio
Selects the screen aspect ratio.
16:9
Just Scan
Original
Resizes images to fit the screen width.
Displays video images in the original size without removing parts
of the edge of the image.
✎✎ In DTV/HDMI/Component (over 720p) mode, Just Scan is
available.
When your TV receives a wide screen signal it will automatically
change to the picture format broadcasted.
Full Wide
4:3
14:9
Zoom
Cinema
Zoom
When TV receives the wide screen signal, it will let you adjust
the picture horizontally or vertically, in a linear proportion, to fill
the entire screen fully.
4:3 and 14:9 video is supported in full screen without any video
distortion through DTV input.
✎✎ In Analog/DTV/AV/Scart mode, Full Wide is available.
Resizes images to the previous standard 4:3.
You can view a picture format of 14:9 or a general TV
programme in the 14:9 mode. The 14:9 screen is viewed in the
same way as in 4:3, but is moved up or down.
Resizes the image to fit the screen width. The top and bottom
parts of the image may be cut off.
Choose Cinema Zoom when you want to enlarge the picture in
correct proportion.
✎✎ While viewing an external device, these cases may result in image burn:
- a video with stationary caption (such as network name)
- 4 : 3 aspect ratio mode for an extended period
Take caution when using these functions.
✎✎ Available picture size may differ depending on the input signal.
✎✎ The screen aspect ratios on HDMI-PC input are available in 4:3 and 16:9 only.
✎✎ [For models supporting 2160p] When a 2160p signal is input or your PC
resolution is set to 3840 x 2160, the Aspect Ratio is fixed to Just Scan.
SMART
➾ Settings ➙ PICTURE ➙ Energy Saving
Reduces power consumption by adjusting screen brightness.
Off
Turns off Energy Saving mode.
Minimum /
Medium /
Maximum
Applies the pre-set Energy Saving mode.
Screen Off
Screen is turned off and only sound is played.
Press any button except Power button on the remote
control to turn the screen back on.
SMART
➾ Quick Menu ➙ AV Mode
Sets the best picture / audio optimized for different AV modes.
Off
Cinema
Game
Operates with the value set in the picture / sound menu.
Optimizes picture and audio settings for movies.
Optimizes picture and audio settings for games.
❐❐To adjust pictures with Picture Wizard
SMART
➾ Settings ➙ PICTURE ➙ Picture Wizard Ⅱ
Use the remote control and follow the instructions of the Picture Wizard to
calibrate and adjust for optimum picture quality without expensive pattern
devices or help from a specialist.
Follow the instructions to obtain the optimum picture quality.
❐❐To select Picture Mode
SMART
➾ Settings ➙ PICTURE ➙ Picture Mode
Selects the picture mode optimized for the viewing environment or the
programme.
Vivid
Standard
Eco
Cinema / Game
Heightens contrast, brightness and sharpness to
display vivid images.
Displays images in standard levels of contrast,
brightness and sharpness.
The Energy Saver feature changes settings on the TV
to reduce power consumption.
Displays the optimum picture for movie, game.
ꕋ Expert
Menu for adjusting picture quality that allows experts
and amateurs to enjoy the best TV viewing. This menu
is ISF-certified and provided for picture tuning experts.
(ISF logo can only be used on ISF-certified TV units.)
ISFccc : Imaging Science Foundation Certified
Calibration Control
✎✎ Depending on the input signal, the available range of picture modes may
differ.
✎✎ ꕋ Expert mode is for picture tuning professionals to control and fine-tune
using a specific image. For normal images, the effects may not be dramatic.
❐❐To fine-tune picture mode
SMART ➾ Settings ➙ PICTURE ➙ Picture Mode ➙ Backlight /
Contrast / Brightness / Sharpness / Colour / Tint / Colour Temp.
First select a Picture Mode of your choice.
Backlight
Adjusts the display brightness by varying the brightness of
the LCD panel.
Contrast
Adjusts the difference between bright and dark regions of the
screen.
Brightness
Adjusts the overall screen brightness.
Sharpness
Adjusts the sharpness of the borders between bright and
dark.
Colour
Tint
Colour Temp.
Adjusts the colours on the screen darker or lighter.
Adjusts the red/green colour balance.
Adjusts the overall tone of colours to warm or cool.
✎✎ Depending on the input signal or other picture settings, the range of detailed
items for adjustment may differ.
❐❐To set advanced control
SMART ➾ Settings ➙ PICTURE ➙ Picture Mode ➙ Advanced
control/Expert Control
Calibrates the screen for each picture mode or adjusts picture settings for a
special screen.
First select a Picture Mode of your choice.
Dynamic Contrast
Dynamic Colour
Adjusts the contrast to the optimal level according to the
brightness of the image.
Adjusts colours for more natural-looking colours.
Skin Colour : Skin colour spectrum can be separately set to
implement the skin colour as defined by the user.
Preferred Colour
Grass Colour : Natural colour spectrum (meadows, hills,
etc.) can be separately set.
Sky Colour : Sky colour is set separately.
Super Resolution
Gamma
Provides a crystal-clear picture by improving the details in
areas where the picture is blurry or unclear.
Sets the gradation curve according to the output of the
picture signal in relation to the input signal.
Colour Gamut
Selects the range of colours that can be expressed.
Edge Enhancer
Shows clearer and distinctive yet natural edges of the
video.
xvYCC
[Depending on model] Expresses richer colours.
Colour Filter
Filters a specific colour spectrum in RGB colours to finetune colour saturation and hue accurately.
Expert Pattern
Patterns used for expert adjustment.
White Balance
Adjusts the overall tone of the screen as desired.
In Expert mode, detailed fine-tuning can be set via the
Method / Pattern etc.
Colour
Management
System
This is a function used by experts when they adjust colours
using a test pattern of six colours (Red / Green / Blue /
Cyan / Magenta / Yellow) without affecting other colour
areas. For normal images, adjustments may not result in
noticeable colour changes.
✎✎ Depending on input signal or other picture settings, the range of detailed
items for adjustment may differ.
❐❐To set additional picture options
SMART
➾ Settings ➙ PICTURE ➙ Picture Mode ➙ Picture Option
Adjusts detailed setting for images.
Noise Reduction
Reduces screen noise in the video.
MPEG Noise
Reduction
Reduces noise caused by compressing digital video.
Black Level
Adjusts the brightness or darkness of the screen to suit the
black level of the picture input using the degree of darkness
(black level) of the screen.
Real Cinema
Optimizes the screen for movie viewing.
Eye Care
Motion Eye Care
[Depending on model]
Adjusts screen brightness to prevent eye glare.
[Depending on model]
Saves power consumption by adjusting the brightness
corresponding to the movement of the image on the
screen.
✎✎ It does not work while watching 3D images.
✎✎ Depending on input signal or other picture settings, the range of detailed
items for adjustment may differ.
❐❐To reset Picture Mode
SMART
➾ Settings ➙ PICTURE ➙ Picture Mode ➙ Picture Reset
Resets values customized by the user.
Each picture mode is reset. Select the picture mode you wish to reset.
SMART ➾ Settings ➙ PICTURE ➙ Picture Mode ➙ Picture Option ➙
TruMotion
Corrects images to display smoother motion sequences.
Smooth
Clear
User
De-Judder value is set to 3.
De-Judder value is set to 7.
De-Judder can be set manually.
• De-Judder : This function adjusts juddering of the screen.
✎✎ If the video signal is 60Hz, TruMotion may not work.
❐❐To use Sound Mode
SMART
➾ Settings ➙ SOUND ➙ Sound Mode
Optimizes TV audio to the selected sound mode.
Standard
Music / Cinema /
Sport / Game
User Setting
Suitable for all types of video.
[Depending on model]
Sets audio optimized for a specific genre.
Adjusts the volume to a level of your choice using the
User EQ.
❐❐To fine-tune the volume
SMART
➾ Settings ➙ SOUND ➙ Sound Mode ➙ User EQ
Sets Sound Mode at User Setting first.
100 Hz / 300 Hz / 1 kHz /
Sets EQ by manual adjustment of sound bands.
3 kHz / 10 kHz
Reset
Resets the equalizer value changed by the user.
❐❐To use Smart Sound Mode
SMART
➾ Settings ➙ SOUND ➙ Smart Sound Mode
Provides the optimized sound adjusted for each content type.
✎✎ If the Smart Sound Mode function is enabled, Sound Mode, Virtual Surround
Plus and Clear Voice ll are automatically adjusted.
❐❐To use Virtual Surround sound
SMART
➾ Settings ➙ SOUND ➙ Virtual Surround plus
LG’s proprietary audio processing technology allows 5.1ch-like surround sound
from two speakers.
✎✎ If Clear Voice ll is set to ON, Virtual Surround plus will not be chosen.
❐❐To use Clear Voice ll function
SMART
➾ Settings ➙ SOUND ➙ Clear Voice ll
Boosts voice clarity.
❐❐To set Volume Mode
SMART
➾ Settings ➙ SOUND ➙ Volume Mode
Sets various modes for volume control.
Auto Volume
Volume Control
Sets Auto Volume to On. Different volume outputs from
programme to programme. They are then automatically
adjusted for convenient TV watching, when clicking through
different programme.
Using a single volume curve may result in an inaudible or
loud sound depending on the environment. Adjusts volume
levels depending on the time of day (day/night).
❐❐To synchronize audio and video
SMART
➾ Settings ➙ SOUND ➙ AV Sync. Adjust
Synchronizes video and audio directly when they do not match.
If you set AV Sync. Adjust to ON, you can adjust the sound output (TV
speakers or SPDIF) to the screen image.
TV Speaker
[Depending on model]
Adjusts the synchronization of the sound from the TV's internal
speakers.
The "-" button makes the sound output faster and the "+"
button slower than the default value.
External
Speaker
Bypass
Adjusts how the sound is synced from external speakers, such
as an external speaker connected to the digital audio output
port, LG audio device and headphone.
The "-" button makes the sound output faster and the "+"
button slower than the default value.
✎✎ LG audio device is supported only for models with the
optical digital port.
Outputs broadcasting signals or the audio of an external
device without audio delay. Audio may be output before video
as it takes time to process video input into the TV.
❐❐To use Sound Option Setting
[Depending on model]
SMART
➾ Settings ➙ SOUND ➙ Sound Option Setting
❌❌Analogue Out
[Depending on model]
Allows the user to select the Headphone or External Speaker (Audio Out) menu
depending on the device connected.
❌❌Balance
[Depending on model]
Adjusts left/right audio balance.
❌❌Sound Optimizer
[Depending on model]
Allows optimized sound for custom TV installation.
Normal
Wall Mount Type
Stand Type
General sound mode.
Optimizes sound for a wall-mounted TV.
Optimizes sound for a stand-mounted TV.
❐❐To use TV’s speakers
[Depending on model]
SMART
➾ Settings ➙ SOUND ➙ Sound Out ➙ TV Speaker
Sound is output through the TV speaker.
❐❐To use External Speaker
SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ External Speaker
(Optical/HDMI ARC)
[Only available for models with an optical or HDMI (ARC) port]
Sound is output through the speaker connected to the optical port.
✎✎ SimpLink is supported.
❐❐To use Digital Sound Out
SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ External
Speaker(Optical/HDMI ARC) ➙ Digital Sound Out
Sets up Digital Sound Output.
Item
Auto
PCM
Sound Input
MPEG
Dolby Digital
Dolby Digital Plus
All
Digital Sound output
PCM
Dolby Digital
Dolby Digital
PCM
❐❐To connect and use LG audio device
LG audio device allows you to enjoy rich powerful sound easily.
❌❌Wired Connection
SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ LG Sound Sync
(Optical)
Connect LG audio device with the
logo to the optical digital audio output port.
✎✎ Only available for models with the optical digital port.
❌❌Wireless Connection
SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ LG Sound Sync
(Wireless)
LG audio device with the
logo can be connected wirelessly.
✎✎ You can use the TV remote control to adjust the volume of the connected
device.
✎✎ When wirelessly connecting, attach the dongle and connect it if the model
needs the Magic Remote Control dongle. (AN-MR400, sold separately)
✎✎ For wireless connection, if the device fails to connect. Check the device
power to connect and if the LG Audio device is in a proper operating
condition.
✎✎ If you select LG Sound Sync (Wireless), devices available for connection are
searched and one of searched devices is automatically connected. When a
device is connected, its name is shown.
✎✎ If two or more devices are detected, the first detected device is connected
first. To view more detected devices to connect, press the Show More button.
✎✎ If LG Sound Sync (Wireless) is being selected and you turn on the TV, it
search and try to connect the device which recently connected.
❐❐To connect and use a Bluetooth headset
SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ LG Sound Sync
(Wireless)
Sound output is through the Bluetooth headset.
✎✎ The devices that can be connected are:
LG BTS1, LG HBS-700, LG HBS-730, LG HBS-800
(Product availability may vary by country.)
✎✎ When wirelessly connecting, attach the dongle and connect it if the model
needs the Magic Remote Control dongle. (AN-MR400, sold separately)
✎✎ For wireless connection, if the device fails to connect. Check the device
power to connect and if the LG Audio device is in a proper operating
condition.
✎✎ If two or more devices are detected, the first detected device is connected
first. To view more detected devices to connect, press the Show More button.
❐❐To use Analogue Out/Headphone
[Depending on model]
SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ External Speaker
(Audio Out) / Headphone
Select Headphone or External Speaker (Audio Out) depending on the device
connected to set the analogue out.
✎✎ The available menu may vary depending on whether you select Headphone
or External Speaker (Audio Out) in Sound Option Setting > Analogue Out.
✎✎ Some models may support the Headphone function only.
✎✎ If you connect headphones while the TV is powered on, it automatically
detects the headphones and sounds through them.
❐❐DTV Sound Setting
SMART
➾ Settings ➙ SOUND ➙ DTV Sound Setting
[Depending on model]
When different audio types exist in an input signal, this function allows you to
select the audio type you want.
If set to AUTO the search order is Dolby Digital+ → Dolby Digital → MPEG and
output is produced in the first Audio Format found.
✎✎ The following search order may change depending on the country: Dolby
Digital+ → Dolby Digital → MPEG.
✎✎ If the selected Audio Format is not supported, another Audio Format may
be used for output.
❐❐To select an external input
SMART
➾ Input List
Selects external input.
INPUT LIST
Select an input device to view.
Selects speaker.
TV Speaker
Selects input.
Antenna
HDMI1
HDMI2
Change Device Name
Edits the name of external
device connected to
external terminal.
USB
SIMPLINK Setting
DLNA
AV2
Set the Universal Control
Sets SIMPLINK.
Programme Mode
Sets the Programme mode.
[Depending on country]
Sets OSS.
[Depending on country]
❐❐To use SIMPLINK
SIMPLINK is a feature that enables you to control and manage various
multimedia devices conveniently using the TV remote control only via the
SIMPLINK menu.
1 Connect the TV's HDMI IN terminal with the SIMPLINK device's HDMI output
terminal using an HDMI cable. For home theatre units with a SIMPLINK
function, connect HDMI terminals as above, and use an optical cable to
connect Optical Digital Audio Out from the TV to Optical Digital Audio In of the
SIMPLINK device.
2 Select SMART ➾ SIMPLINK. SIMPLINK menu window appears.
3 Select SIMPLINK Setting on SIMPLINK menu window. SIMPLINK setup
window appears.
4 Set SIMPLINK to On in SIMPLINK setup window.
5 Close SIMPLINK setup window.
6 Select the device to control from SMART ➾ SIMPLINK.
✎✎ This function only works on devices with the SIMPLINK logo (
Verify that the external device has a SIMPLINK logo.
).
✎✎ To use the SIMPLINK function, you need to use a high-speed HDMIⓇ cable
(with CEC, or Consumer Electronics Control, feature added). High-speed
HDMIⓇ cables have the No. 13 pin connected for information exchange
between devices.
✎✎ Turn on or select the media of a device with home theatre features to see
the speaker switch to External Speaker.
✎✎ Connect with an Optical cable (sold separately) to use External Speaker.
✎✎ Switching to external input causes devices operating with SIMPLINK to stop.
✎✎ Use of a third-party device with HDMI-CEC features may cause malfunctions.
✎✎ Optical cable connection is supported only for models with the optical digital
port.
❌❌Explanation of SIMPLINK features Direct Play
Plays the multimedia device on the TV instantly.
Select
multimedia
device
Selects the desired device via the SIMPLINK menu to
control it from the TV screen instantly.
Disc playback
Manages the multimedia device with the TV remote
control.
Power off all
devices
If the Auto Power function is set to On in the SIMPLINK
settings, turning the TV off will turn the power off on all
SIMPLINK-connected devices.
Sync Power on
If the Auto Power function is set to On in the SIMPLINK
settings, turning on a SIMPLINK device will turn the TV on.
Speaker
Selects speaker either on the home theatre unit or the TV.
❐❐To use Sleep Timer
SMART
➾ Settings ➙ TIME ➙ Sleep Timer
Turns off the TV after a preset number of minutes.
To cancel the Sleep Timer, select Off.
❐❐To set current time
SMART
➾ Settings ➙ TIME ➙ Clock
Checks or changes the time while watching TV.
Auto
Manual
Synchronizes the TV clock to the digital time information sent by
the TV station.
Sets the time and date manually if the auto setup does not
correspond to the current time.
❐❐To set the TV to turn on and off automatically
SMART
➾ Settings ➙ TIME ➙ On Time/Off Time
Sets On/Off time.
Select Off on Repeat to discontinue On Time/Off Time.
✎✎ To use On Time/Off Time, set the current time correctly.
✎✎ Even when the On Time function is on, the TV will turn off automatically in
120 minutes when no button is pressed within that time.
❐❐To set Automatic Standby
SMART
➾ Settings ➙ TIME ➙ Automatic Standby
[Depending on model]
If you do not press any button on the TV or remote control for a certain period,
the TV will automatically switch to standby mode.
✎✎ This function does not work on Store Demo mode or while software update.
❐❐To set password
SMART
➾ Settings ➙ LOCK ➙ Set Password
Sets or changes TV password.
✎✎ The initial password is set as 「0000」.
When France is selected for Country, password is not 「0000」 but 「1234」.
When France is selected for Country, password cannot be set as 「0000」.
❐❐To lock system
SMART
➾ Settings ➙ LOCK ➙ Lock System
Permits only specific programmes by blocking channels or external input.
Select the Lock System to On.
Block
Programme
Blocks the programmes that contain inappropriate contents for
children. The programmes can be selected but the screen is
blank and the audio is muted.
To watch a locked programme, enter the password.
Parental
Guidance
Input Block
Application
Lock
This function operates according to information from the
broadcasting station. Therefore if the signal has incorrect
information, this function does not operate.
Prevents children from watching certain adult’s TV
programmes, according to the ratings limit set.
Enter a password to watch a blocked programme.
Rating differs by country.
Block the input sources.
Lock the Application.
SMART
➾ Settings ➙ OPTION ➙ Language(Language)
Selects Menu Language and Audio Language displayed on the screen.
Menu Language
Selects a language for the display text.
[In Digital Mode Only]
Audio Language When watching a digital broadcast containing several audio
languages, you can select the language you want.
[In Digital Mode Only]
Use the Subtitle function when two or more subtitle
Subtitle
languages are broadcast.
Language
✎✎ If subtitle data in a selected language is not broadcast,
the default language subtitle will be displayed.
Text Language
Voice
Recognition
Language
[In Digital Mode Only]
Use the Text language function when two or more Text
languages are broadcast.
✎✎ If teletext data in a selected language is not broadcast,
the default Text language will be displayed.
✎✎ If you select the wrong local country, teletext may not
appear correctly on the screen and some problems may
occur during teletext operation.
Select the language to make voice search.
✎✎ Only the voice search adopted model can support this
setting.
SMART
➾ Settings ➙ OPTION ➙ Country
[Depending on country]
Sets the country that the TV uses.
TV settings are changed according to the broadcast environment of the selected
country.
✎✎ If the country setting is changed, the Auto Tuning information screen may
appear.
✎✎ In a country that Digital broadcasting regulation isn’t fixed, some DTV
functions may not work depending on digital broadcasting circumstances.
✎✎ If the country setting is set to “--”, European terrestrial digital standard
broadcasting programmes are available, but some DTV functions may not
work properly.
SMART
➾ Settings ➙ OPTION ➙ Disability Assistance
Audio commentary or subtitles are provided for those who are hard of hearing or
visually impaired.
Hard of Hearing
Audio
Description
This function is used for the hearing impaired.
If it is set to on, the subtitle is displayed by default.
This function is for the blind, and provides explanatory
audio describing the current situation in a TV programme in
addition to the basic audio.
When Audio Description is selected On, basic audio and
Audio Description are provided only for those programmes
that have Audio Description included.
❐❐To register the Magic Remote Control
To use the Magic Remote Control, register it with your TV first.
Register Magic Remote Control as follows before use.
1 Turn on the TV and wait for about 10 seconds and then press Wheel(OK)
button while pointing the remote control at the TV.
2 The remote control is automatically registered and the registration completion
message appears on the TV screen.
✎✎ If you failed to register the Magic Remote Control, turn off the TV and try
again.
❐❐To re-register the Magic Remote Control
1 Press the SMART and BACK buttons together for about 5 seconds.
2 Press the Wheel (OK) button towards the TV to re-register the Magic Remote
Control.
✎✎ Press the SMART button and BACK button at the same time, for five
seconds, to reset the Magic Remote Control.
✎✎ Press the BACK button while pointing the remote control at the TV for five
seconds to reset and re-register it.
❐❐To set the pointer of the Magic Remote Control
SMART
➾ Settings ➙ OPTION ➙ Pointer
Sets the speed and shape of the pointer that appears on the TV screen.
Speed
Sets the moving speed of the pointer.
Shape
Selects a pointer shape from various options.
Size
Chooses the size of the pointer.
Set to On. If there is any misalignment between the pointer
and the actual direction the remote control indicates, move the
Magic Remote Control left and right to realign. The pointer will
Alignment
automatically realign to the centre, making it easier to control.
✎✎ If it is set to Off, the Alignment function will not work even
when you move the Magic Remote Control left and right.
✎✎ If the pointer has not been used for a certain period of time, it will disappear.
When the pointer disappears from the screen, shake the Magic Remote
Control to the right and left. Then, it appears again.
✎✎ If you press the Navigation button while moving the pointer on the screen,
the pointer disappears, and the Magic remote control works as a common
remote control.
✎✎ Use within an effective distance of 33 ft. (10 metres). Using the Remote
Control from greater distances or when obstructions block the sight line may
cause malfunctions.
✎✎ Electronic devices nearby may cause communication interference. Devices
such as microwave ovens and wireless LANs use the same frequency range
(2.4 GHz) as the Magic Remote Control and may cause interference.
✎✎ The Magic Remote Control may be broken if dropped or damaged in any other
way.
✎✎ Take care not to bang it against other hard objects such as furniture or the
floor.
❐❐To use the pattern gesture function
Press the Wheel(OK) button with the normal video screen on and draw a pattern
toward the screen.
Previous channel: Moves back to the previous channel.
Recent list: Shows channels recently watched.
123
Shows channel lists which be related to pattern. Choose the
channel.
✎✎ It may not work when certain windows are open.
❐❐To set Power Indicator
SMART
➾ Settings ➙ OPTION ➙ Standby Light
[Depending on model]
Turns the standby light in the front panel of the TV on/off.
❐❐To adjust the front LG Logo Light
SMART
➾ Settings ➙ OPTION ➙ LG Logo Light
[Depending on model]
You can adjust the LED brightness of the LG logo at the bottom of the TV.
Brightness
You can set the brightness of LG Logo Light to Off/Low/
Medium/High when the TV power is off.
When TV is on
You can set the off time of LG Logo Light when the TV
power is on.
• Off right now : The light is turned off as the TV power is
on.
• Off after 10 min : The light is turned off after 10 minutes
when the TV power is on.
✎✎ The initial brightness is set to Low when the TV power is
on.
❐❐To change TV mode
SMART
➾ Settings ➙ OPTION ➙ Mode Setting
Selects Home Use or Store Demo.
For use at home, select Home Use.
Store Demo is a mode used for store display.
❐❐To return to initial settings
SMART
➾ Settings ➙ OPTION ➙ Factory Reset
Deletes all optional settings and returns to initial default mode.
Once initialization is complete, the TV will turn off and on by itself.
✎✎ If Lock System is activated, a pop-up password prompt will appear.
✎✎ Do not turn off the power during initialisation.
❐❐To use Home Screen
Press SMART
button on the remote control.
With all Smart TV features on one screen, everyone can access a wealth of
content and applications conveniently via the quick and easy-to-use menu,
arranged by themes such as Live TV, Card, My Apps, etc.
Sign in
Premium
Cinema
Weather
More...
News
11-1 MBC HD
July 4 8:30 pm
Tron
Toy story
Monster
Ghost
Abata
UP
Thanks
My Boy
More...
Sports
Map
Card Edit
SMART
SHARETM
Viral Video
Game
More
Input List
Settings
Internet
Search
Photos
Smart Sh...
LG Smart...
Game Wo...
User Guide
Pr.List
MY CARD
Select a card that you want
to use.
My Apps
❐❐To use and edit MY CARD
SMART
➾ MY CARD
To enable you to easily check and access a wide variety of content and
functions, the main functions are grouped into categories and displayed on
cards.
By selecting the card name, you can go to that category page.
Select Edit at the top of the home screen to switch the position of the cards or
create your own card. (You cannot edit the Live and Premium cards.)
❐❐To use My Apps
SMART
➾ More
Select More at the bottom of the home screen.
Select More to check apps pre-installed apps and apps you have
downloaded.
More
Input List
Settings
Internet
Search
Photos
Select the app you want to run.
Smart Sh...
LG Smart...
Game Wo...
User Guide
Pr.List
❐❐To edit items in My Apps
SMART
➾ More ➙My Apps ➙ Edit
On the My Apps page, select Edit at the top of the screen to move or delete
apps. Please note that system apps can be moved, but cannot be deleted.
✎✎ Changes orders / deletes items by dragging the app icons if your device
has a Magic Remote Control.
MY APPS
A wireless or wired network connection is required to use Smart features.
When connected to the network, you can use Premium content, LG Smart World,
DLNA and more.
❐❐One-click network connection
Connects easily to a wired/wireless network.
SMART ➾ Settings ➙ NETWORK ➙ Network Connection to connect to an
available network automatically. Follow the prompts on the TV.
❐❐To connect to a network through Set Expert
SMART
➾ Settings ➙ NETWORK ➙ Network Connection
For use in special circumstances such as in offices (in cases where a static IP is
used).
1 Select a network connection, either Wired or Wireless.
2 When connecting via Wi-Fi, use the one of the following network connection
methods.
AP List
Enter the SSID
Connects to the network selected from the AP List.
Connects to the wireless AP typed in.
WPS-PBC
Connects easily when the button of a wireless AP supporting
PBC is pressed.
WPS-PIN
Connects easily when the PIN of the wireless AP that you
wish to connect to is entered in to the AP website.
❐❐To use the Wi-Fi direct function
SMART
➾ Settings ➙ NETWORK ➙ Wi-Fi direct
Wi-Fi Direct is a function that allows your TV to connect with a Wi-Fi Direct
device without Internet connection. With SmartShareTM, you can watch the
files stored on a device connected via Wi-Fi Direct.
1 Set Wi-Fi direct to On. (If you do not use it, please change it to Off.)
2 Enable the Wi-Fi Direct settings on the device that you want to connect to.
3 A list of devices that can be connected to the TV is displayed.
4 Select a device to connect.
5 Select Yes, when the connection request message appears.
6 If the device that you want to connect accepts the request, Wi-Fi direct is
connected.
❐❐To use the Miracast™/Intel’s WiDi function
SMART
➾ Settings ➙ NETWORK ➙ Miracast™/Intel’s WiDi
You can view the screen of a device with Miracast™ and Intel’s WiDi
technologies on your TV.
1 Set Miracast™/Intel’s WiDi to On. (If you do not use it, please change it to
Off.)
2 Enable the Miracast™/Intel’s WiDi settings on the device that you want to
connect to.
3 A list of devices that can be connected to the TV is displayed.
4 Select a device to connect.
5 Select Yes, when the connection request message appears.
6 If the device that you want to connect accepts the request, Miracast™/
Intel’s WiDi is connected.
✎✎ Some models may provide the Intel’s WiDi function only.
✎✎ When Wi-Fi Direct is set to Off, if you set Miracast™/Intel’s WiDi to On,
Wi-Fi Direct is automatically set to On.
✎✎ When you set the Miracast™ / Intel’s WiDi function to Off, Wi-Fi Direct
returns to the previous setting.
✎✎ It is recommended to connect a laptop using Intel’s WiDi within close range.
✎✎ Though Intel’s WiDi can be connected without a wireless router, it is
recommended to connect the wireless router first for optimal performance.
✎✎ You may not connect your TV to a non-LG Electronics device even when it is
detected.
✎✎ It is recommended you to connect a device to a 5GHz router.
✎✎ The response rate may vary depending on the user’s environment.
✎✎ For more information on the device you want to connect to, refer to its
owner’s manual.
❐❐Setting a network - warning
✎✎ Use a standard LAN cable (Cat5 or higher with RJ45 connector, 10 Base-T or
100 Base TX LAN port).
✎✎ Resetting your modem can cause network connection problems. To resolve
the problem, turn the power off, disconnect and reconnect, and then turn the
power back on.
✎✎ LG Electronics is not responsible for any network connection problems or any
faults, malfunctions and errors caused by an network connection.
✎✎ A network connection may not work properly depending on the Internet
service provider.
✎✎ A DSL modem is required for a DSL service; a cable modem is required
for a cable service. Only a limited number of network connections may be
available, and TV network setting may not be available depending on your
contract with your Internet Service Provider (ISP). (If only one device is
allowed per line and the PC is already connected, other devices cannot be
used.)
✎✎ Wireless networks can be subject to interference from other devices
operating at a frequency of 2.4 GHz (wireless phones, Bluetooth devices
or microwave ovens). There may also be interference from devices with a
frequency of 5 GHz, same as other Wi-Fi devices.
✎✎ The surrounding wireless environment can cause the wireless network
service to run slowly.
✎✎ If you do not turn off the entire local home network, network traffic may
occur on some devices.
✎✎ For an AP connection, an access point device that supports wireless
connection is required and the wireless connection feature must be enabled
on the device. Contact your service provider regarding availability of wireless
connection on your access point.
✎✎ Check the SSID and security settings of the AP for AP connection. Refer to
the appropriate documentation for SSID and security settings of the AP.
✎✎ Invalid settings on network devices (wired/wireless line sharer, hub) can
cause the TV to run slowly or not operate properly. Install the devices
correctly according to the appropriate manual and set the network.
✎✎ Connection method may differ according to the AP manufacturer.
❐❐What is Tag On?
Tag On is a data transmission technology that can be used on smartphones
with NFC (Near Field Communication). Simply by tapping your smartphone to
a Tag On sticker, you can share content between your smartphone and TV.
To connect your smartphone to the TV using Tag On, they must be connected
on the same Wi-Fi network or Miracast™/Intel’s WiDi of the smart TV is set
to On.
✎✎ Do not attach the sticker to a metal part of the TV. Otherwise, your
smartphone cannot recognise the Tag On sticker.
✎✎ Do not crumple or fold the Tag On sticker. Otherwise, the Tag On is not
recognised.
✎✎ To purchase a Tag On sticker, please contact the LG Electronics Service
Centre.
✎✎ This function is supported only on a smartphone with Android 4.0 (ICS) or
later.
❐❐To start Tag On for the first time
To connect your smartphone to the TV using NFC, install the Tag On app on
the smartphone and complete the authentication process.
1 Make sure that the smart TV is on the same network as your smartphone.
If Wi-Fi cannot be enabled, go to SMART ➾ Settings ➙ Network ➙
MiracastTM/Intel's WiDi and set to On.
2 Enable the smartphone's NFC function and set to Read/Write and P2P
Mode.
For more information on enabling NFC and setting the mode, refer to the
owner's manual of your smartphone.
3 Tap your smartphone to a Tag On sticker.
Make sure to follow the instructions on the smartphone screen and install
the Tag On app and LG TV Remote app.
4 Tap the smartphone to the Tag On sticker again.
5 Enter the pairing key displayed on the smart TV into the smartphone.
When two or more TVs are detected, the pairing key is displayed only after
the TV you want to connect to is selected in the device list.
6 When the connection is made properly, you can use Tag On.
✎✎ The information of the connected TV is saved in the Tag On sticker.
You can change or reset the information in the Settings menu of the
smartphone Tag On app.
❐❐To use the Tag On
Follow the steps below to share content on your NFC-enabled smartphone.
1 Tap the NFC-enabled smartphone to a Tag On sticker.
2 The Tag On app starts running on the smartphone to connect to the smart
TV.
- To use a Wi-Fi network, make sure that the smart TV is on the same
network as your smartphone.
- If the smart TV and the smartphone are not on the same network, use
Wi-Fi Direct.
✎✎ If the Tag On app is not installed, the installation page appears
automatically.
✎✎ For more information on how to share content between your smartphone
and TV, refer to the Tag On app's help. Click to run the Tag On app on your
smartphone and select the Settings menu to view the help.
❐❐To connect a USB device
Connect a USB storage device (external HDD, USB memory) to the USB port of
TV to enjoy the content files stored in the USB device on your TV.
To remove a USB storage device, select the Quick Menu ➙ USB Device that
you wish to remove; do not remove physically until you see the message that
the USB has been removed. If detached early, an error may occur on the TV or
the USB storage device.
✎✎ Once a USB device has been selected for removal, it can no longer be read.
Remove the USB storage device and then re-connect it.
❐❐Using a USB storage device - warning
✎✎ If the USB storage device has a built-in auto recognition program or uses its
own driver, it may not work.
✎✎ Some USB storage devices may not work or may work incorrectly.
✎✎ If you use a USB extension cable, the USB device may not be recognized or
may not work properly.
✎✎ Use only USB storage devices formatted with the Windows FAT32 or NTFS
file system.
✎✎ For external USB HDDs, it is recommended that you use devices with a
rated voltage of less than 5 V and a rated current of less than 500 mA.
✎✎ It is recommended to use a USB hub or hard disk drive with power supplied.
(If the power supplied is not enough, the USB storage device may not be
detected properly.)
✎✎ It is recommended that you use USB memory sticks of 32 GB or less and USB
HDDs of 2 TB or less.
✎✎ If a USB HDD with power-saving function does not work properly, turn the
power off and on. For more information, refer to the user manual of the USB
HDD.
✎✎ Data in USB storage device can be damaged so be sure to back up important
files to other devices. Data maintenance is the user's responsibility and the
manufacturer is not responsible for data loss.
❐❐To use SmartShare™
SMART
➾ SmartShare™
Provides photo / music / video files on your TV by connecting to a USB device or
home network (DLNA).
SmartShare™
Recent
Recently Played
Video
000
001
002
003
004
005
006
007
008
009
011
012
013
014
Music
Recorded TV
Linked Device
Displays photo / music /
video files on all devices
connected to the TV.
Newly Added
010
Settings
Delete History
Connecting guide
Shows how to connect PC,
smartphone/device, and USB.
❐❐To control video playback
Controls playback and sets options while viewing videos.
Selects the desired point and plays
Option
Plays
Sets options.
❐❐To control photo view
Controls playback and sets options while viewing pictures in full screen.
Option
Displays photos as a
slideshow.
Plays background music.
Sets options.
Sets the filter.
[Depending on model]
Rotates or enlarges the picture.
❐❐To control music playback
Controls playback and sets options while playing music.
Selects the desired point and
plays
Sets options
Plays
Sets the repeat/random
function.
Listens to music with the monitor
turned off.
✎✎ You can control playback using the ꕚ , ꕖ and ꕙ keys on a standard
remote control.
✎✎ If you use the USB device, time information will be not shown on screen.
❐❐To set SmartShare™ related functions
SMART
➾ SmartShare™ ➙ Settings
Changes settings related to SmartShareTM content playback.
❌❌Advanced Setting
My TV Name
Changes the name that appears when searching for the TV
from other devices.
Network Status Checks the network connection.
Wi-Fi Direct
Allows use of wireless connection functions such as Wi-Fi
direct and WiDi.
Auto Play on
Receive
Accepts / rejects content transferred from other devices.
DivX(R) VOD
Registers or releases DivX.
Checks DivX Registration Code for playing DivX-protected
videos. Register at http://vod.divx.com.
Uses Registration Code to rent or purchase movies at www.
divx.com/vod.
✎✎ Rented/purchased DivX files cannot be played if the DivX
Registration Code of a different device is used. Use only
the DivX Registration Code granted to this device.
✎✎ Converted files not conforming to the DivX Codec
Standard may not play or may produce abnormal images
and sound.
❌❌Delete History
To delete contents history, press Delete History button below. Use the contents
at Recent menu.
❐❐SmartShare™ supporting file
Maximum data transfer rate :
20 Mbps (megabits per second)
External subtitle formats supported : *.smi, *.srt, *.sub (MicroDVD, SubViewer 1.0/2.0),
*.ass, *.ssa, *.txt (TMPlayer), *.psb (PowerDivX), *.dcs (DLP Cinema)
Internal subtitle formats supported : XSUB (supports internal subtitles generated from DivX6)
❌❌Video Supported Codec
Maximum: 1920 x 1080 @30p
Extension
.asf
.wmv
.divx
.avi
.mp4
.m4v
.mov
Codec
Video
Audio
Video
Audio
VC-1 Advanced Profile, VC-1 Simple and Main Profile
WMA Standard, WMA 9 Professional
DivX3.11, DivX4, DivX5, DivX6, XViD, H.264/AVC,
Motion Jpeg, MPEG-4 Part 2
MPEG-1 Layer I, II, MPEG-1 Layer III (MP3),
Dolby Digital, Dolby Digital Plus, LPCM, ADPCM, DTS
Video
H.264/AVC, MPEG-4 Part 2
Audio
MPEG-1 Layer III (MP3)
Extension
.3gp
.3g2
.mkv
.ts
.trp
.tp
.mts
.m2ts
.vob
.mpg
.mpeg
Codec
Video
Audio
Video
Audio
Video
H.264/AVC, MPEG-4 Part 2
AMR-NB, AMR-WB
H.264/AVC
Dolby Digital
H.264/AVC, MPEG-2, VC-1
Audio
MPEG-1 Layer I, II, MPEG-1 Layer III (MP3)
Dolby Digital, Dolby Digital Plus
Video
Audio
Video
Audio
MPEG-1, MPEG-2
Dolby Digital, MPEG-1 Layer I, II, DVD-LPCM
MPEG-1, MPEG-2
MPEG-1 Layer I, II, MPEG-1 Layer III(MP3)
❌❌Available music file
File type
mp3
Item
Info
Bit rate
32 Kbps - 320 Kbps
Sample freq. 16 kHz - 48 kHz
Support
MPEG1, MPEG2, Layer2, Layer3
❌❌Available photo file
File type
2D
(jpeg, jpg, jpe)
Item
JPEG
Profile
Minimum: 64 x 64
Maximum:
Normal Type: 15360 (W) x 8640 (H)
Progressive Type: 1920 (W) x 1440 (H)
❐❐Playing video - warning
✎✎ Some subtitles created by users may not work properly.
✎✎ The video and subtitle files should be placed in the same folder. For subtitles
to display correctly, the video and subtitle files must have the same name.
✎✎ Subtitles on an NAS (Network Attached Storage) device may not be
supported depending on the manufacturer and model.
✎✎ We do not support any stream that contains GMC (Global Motion
Compensation) or Qpel (Quarterpel Motion Estimation).
✎✎ Only H.264 / AVC profile level 4.1 and lower is supported.
✎✎ The file size limit is dependent on the encoding environment.
✎✎ It works only the above version of Window Media Audio V2.
✎✎ Video files created by some encoders may not be played back.
✎✎ Video files in formats other than the ones specified here may not be played
back.
✎✎ Playback of video files stored on the USB device that do not support High
Speed, may not work properly.
✎✎ The TV supports DTS audio codec when the USB/HDMI video file playback.
DLNA stands for Digital Living Network Alliance, which allows you to enjoy video
/ music / photo files stored on a PC or server on your TV via home networking.
❐❐To connect a DLNA-authenticated Smartphone
The TV and the smartphone should be on the same network.
1
2
3
4
5
6
7
Ensure that Wi-Fi is enabled on the smartphone.
Install / run the app to share content on the smartphone.
Run “Share my mobile phone Content”.
Select the kind of content (video / music / photo) you wish to play.
Select the video, music or photo file to play on the TV.
Select Add to Play List.
Select TV model name on the device you want to play content from.
(TV model name is on the label of the device.)
8 Play ▶ Shows the selected file on TV.
❐❐To connect DLNA DMR (Digital Media Renderer)
If the PC's operating system is Windows 7 or Windows 8 or the DLNA-certified
device (e.g. mobile phone) is connected via a network, you can play music /
videos / photos on TV without installing a separate program.
1 Configure TV and PC on the same network. Configure Windows 7 or Windows
8-installed PC on the network.
2 Right-click the music / video / photo file that you want to play and use the
“Remote Playback” feature that comes with Windows 7 or Windows 8.
To play content from a device such as a mobile phone, refer to the user
guide for the device.
3 Content will be played on one device only even if more than one TV or
device is connected. Play speed can vary depending on network speed.
❐❐To connect DLNA DMP (Digital Media Player)
With a PC having SmartShare PC Software, music / video / photo files may be
replayed on the TV by linking them via home networking.
1 Configure TV and PC on the same network. The TV and each device should
be connected through a single access point to enable DLNA service.
2 Install SmartShare PC Software on the PC from the website. Before
installation, close all running programs including firewall and anti-virus
programs.
3 The sever should be running in order to watch the shared file on your TV.
✎✎ For the website information, go to SMART
Product/Service Info.
➾ Settings ➙ SUPPORT ➙
✎✎ For how to use the SmartShare PC software, refer to the software help.
❌❌In case of a DLNA malfunction
✎✎ If the DLNA feature does not work properly, check your network settings.
✎✎ A 5-GHz access point is needed to view 1080p videos via DLNA. A 2.4-GHz
access point may cause frequent buffering or other problems.
✎✎ DLNA may not work properly in the wireless network. It is recommended to
connect to the wired network.
✎✎ When playing video in DLNA mode, Multi Audio and internal subtitles are not
supported.
✎✎ If more than one TV is connected to a single server in DLNA mode, the
content may not play depending on server performance.
✎✎ Subtitles may not be supported depending on the DLNA device.
✎✎ DLNA feature may not work properly depending on the network environment.
✎✎ DLNA feature cannot be used with some access points that do not support
multicasting. For more information, refer to the access point manual or
consult the manufacturer.
✎✎ Supported file types may differ depending on DLNA server environment, even
for file types supported by the TV.
✎✎ Too many sub-folders and files in one folder may cause malfunction.
✎✎ The information about the file from the DLNA server may not be displayed
correctly.
✎✎ When viewing video subtitles on a DLNA server, we recommend that you use
SmartShare PC Software.
✎✎ If subtitle file is added later, turn off the shared folder and reset.
✎✎ DRM file located on a SmartShare PC Software server cannot be played.
✎✎ ULTRA HD video (3840 X 2160) file does not work.
❐❐To use Premium
SMART ➾ Premium
This service gives you easy access to a wide variety of content, such as video,
news and, UCC, at any time, as long as you are connected to the network.
Premium content includes specialized country-specific services taking regional
cultural sensitivities into account as well as global content.
PREMIUM
Premium content
Select Content that
you want to use.
Sign in
Search
WEB
Movie
Map
SNS
Play
NEWS
Comic
Entertainment
Information
TV
Add to My Apps
Add to My Apps
Sets options
Option
❐❐To use paid content
A fee is payable for some Premium content.Fee-paying services are paid for
either through LG Electronics’ proprietary billing system or through that of the
relevant content provider.
Before using the LG billing system, you will need to sign up for membership
and register payment information on TV or the website (www.lgappstv.com) to
purchase paid content.
You can sign up for membership on the login screen on your TV or our website.
You can then log into both the TV and the website with one ID.
1 Click Sign In button on the upper-right side of the screen on the Home page
to sign in.
2 Moves to the desired Premium service.
(For some premium services, separate sign-in is required after signing up for
the premium service.)
3 After reviewing the pricing and service information for the content, click
the Purchase button. (There may be limitations on the available period and
number of times depending on content.)
4 Once the purchasing process is complete, view your purchased content by
clicking the Buy button.
5 Select your ID on upper menu of Home screen and check history of
purchases from My Page ➙ Payment inquiry. It is also available on My Page
➙ Purchase History of web site (www.lgappstv.com).
❐❐To reset Premium
SMART
➾ Premium ➙ Option ➙ Initialisation of Premium
Resets Premium list, Premium information, country setting and user sign-in
information. Resetting will resolve errors occurring during Premium update.
✎✎ Content offered by service providers are subject to change or deletion
without prior notice to enhance their service quality. Refer to the website
of the relevant content provider for questions, troubleshooting or the latest
information about content. LG Electronics assumes no legal responsibility
for content services and related information, even when a service is
discontinued by the service provider.
✎✎ The quality of your Premium service may be affected by your Internet
connection. For any questions related to Internet speed or other service
problems, consult your Internet service provider.
✎✎ For best service quality, we recommend that you subscribe to an Internet
service providing a speed of 4.0 Mbps (1.5 Mbps or faster). If you
experience any Internet speed problem, contact your Internet service
provider.
✎✎ Some content providers may provide content that is unsuitable for minors.
Parental discretion is advised.
❐❐To use LG Smart World
[This function may not be applied some countries.]
SMART
➾ LG Smart World
LG Smart World is a TV application service available through Smart TV Service.
You can download and enjoy various kinds of hot paid/free apps including
education, entertainment, life and news.
SMART WORLD
All
Hot
Top Paid
Top Free
New
18+
All
My Apps
Sign in.
When you sign in, ID is displayed.
When you select the ID, you can select
My Page and Sign Out.
Game
Entertainment
Life
Education
News/Info.
Select the app to install.
❐❐To sign up with LG Smart World
SMART
➾ Sign In
Sign up is required to download and run apps.
1 Select Sign Up and agree to Legal Notice.
2 Enter ID and password.
3 In Confirm Password box, enter password again.
4 Select OK to complete sign-up process.
✎✎ You can sign up for membership on either your TV or the website (www.
lgappstv.com).
✎✎ After signing up for membership, log into your TV and our website with the
same ID.
✎✎ You can sign in to up to five TVs with a single ID.
❐❐To install an app on your TV
SMART
1
2
3
4
5
➾ LG Smart World
Click the Sign In button at the top of the home screen to log in.
Select the LG Smart World card.
Select an app you want from the list.
Check the details of the app, then select the Install or Buy button.
Check that you have the functions or TV accessories required to install the
app, then select the OK button.
6 For paid apps, payment and purchase authentication is required.
7 Select Run once installation is complete to run the app immediately. If you do
not want to run immediately, select Close. If you want to run the app later,
select My Apps to check the list of apps installed on TV.
✎✎ You can purchase apps via PC or TV, but you must use the TV to install and
run them.
✎✎ If you have insufficient storage space on your TV, you can download apps
to a USB storage device connected through the TV's terminal for USB apps.
Apps stored on USB can be run / deleted / moved from the My Apps screen.
✎✎ A USB Memory Stick containing apps cannot be used for other data. (For
USB Apps Only)
❐❐To manage my information
SMART
1
2
3
4
➾ LG Smart World
Sign in.
Select the currently signed-in ID at the top of the screen.
Select My Page.
Manages by examining Member Information, My Purchased Apps List and TV
Installed Apps List.
My Information
Shows basic information about the ID currently signed
in. To change your member information, visit www.
lgappstv.com on your PC.
Payment Inquiry
Shows Payment History of the signed-in ID.
Purchased Apps
Shows My Purchased Apps List for the signed-in ID.
You can delete/re-install the purchased apps.
SMART
➾ Search
You can search apps and contents using the Search function of LG Smart TV.
When you enter keywords using the input device, such as the remote
control, you can find apps of LG Smart World and some contents of the
Premium service. Links are also provided to go for web search. If you are
using SmartShareTM, you can also search contents of SmartShareTM. The Search
categories and content types vary depending on the country and will be kept
updating.
Enter search
terms.
SEARCH
Related Keywords
All
Premium
Search
Search results
Smart World
Category of
search results
APP Contents
Youtube
News
Detailed information
about the search item
SMART
➾ Internet
Types URL manually on TV or visits websites added to Favourite.
Types in the web address.
Chooses when you
open several web
browsers.
Add the current page to favorites.
✎✎ Internet supports up to Flash 11 but does not support platform-dependent
technology like ActiveX.
✎✎ Internet only works with a pre-installed plug-in.
✎✎ Internet may not play any media file format other than the following:
JPEG / PNG / GIF
✎✎ Internet will be forcibly closed when there is insufficient memory.
✎✎ For the Internet, fonts installed on the TV are used and may not be
displayed normally depending on the content played.
✎✎ Internet does not support file and font download.
✎✎ Internet is made for TV so it may have a different function to browsers made
for PC.
✎✎ Internet is a TV browser and may not work properly when playing some
content files.
❐❐To start a video call (Skype)
You can make a video call to a Skype contact connected using the Smart TV
camera.
1 Connect the TV to a network.
2 Prepare the Smart TV camera for use. If your Smart TV is not equipped
with a camera, install an LG video call camera (Sold separately). (For more
information, please refer to the installation manual or owner's manual of
the camera.)
3 Go to SMART ➾ Premium ➙ Skype.
4 First, sign in to your Skype account.
✎✎ You can log in with your existing Skype account or a Skype account that is
merged with your Microsoft account.
To create a new Skype account that is already merged with your Microsoft
account, please refer to their websites for further information.
❐❐To use Skype
When you sign in to Skype, you can use the call service of Skype.
Information of the signed in account
Broman Bill
KRW 9.542.78
Contacts
Call phones
History
My information
Settings
Call/Settings tab
Skype screen
Option
Add Contact
Zoom
Conference call
Back
Exit
Control buttons
Each screen shows the functions that can
be controlled on it.
❌❌Call/Settings tab
Contacts
Call phones
History
When you select a Skype contact, you can make
(Video Call) or
(Voice Call).
You can add or delete a new contact.
✎✎ If there are more than 500 contacts, the list's
performance and stability may be affected.
You can make a call by pressing dial numbers.
✎✎ To use the Call phones function, you must purchase
Skype credit. For more details, visit the website of
Skype (www.skype.com).
You can check All calls sent or received and Voice message/
Contact requests received.
My information
Settings
Once you have signed in, you can set My status, Change
picture, My profile, or View account.
✎✎ The maximum number of photos that can be saved using
snapshot is limited.
Once you have signed in, you can set Notification settings,
Call forwarding, Privacy settings, Video settings, or Change
password.
✎✎ It takes several minutes until the changes become
effective.
❐❐To make a voice call
❌❌To make a video call
In Contacts, select a contact you want to call and select
(Video Call).
❌❌To make a voice call
In Contacts, select a contact you want to call and select
(Voice Call).
✎✎ You can perform call-related functions such as adding a contact during a call.
❐❐To answer a call
When a call is received while watching TV, a message appears at the bottom
right of the screen.
You can answer a video call/voice call or Decline it.
✎✎ You cannot use input devices such as keyboard while using Skype.
✎✎ Video calls cannot be made to a Mac with Skype 2.8 or earlier.
✎✎ Available content is subject to change by the content provider. For more
information on the content service, please visit the website of your content
provider.
✎✎ The software update screen will automatically appear when an update is
available.
No emergency calls
Skype is not a replacement for your ordinary telephone
and cannot be used for emergency calling.
Sign-up is required to use LG Smart World.
Free apps are available immediately after signing up, but you should register
your payment method in order to use paid apps.
You can sign up and register payment methods on the TV or on our website
(www.lgappstv.com).
Problem
Solution
When entering menu,
the "Initialising" message
always appears.
• The “Initialising” message appears while the
microprocessor and hardware are rebooted, network
communications are set up, and communication with
SDP (device authentication and basic information
download) is established. This takes about 20 seconds
and is a normal process.
There is no content shown
on the Premium card.
• Content may not be shown if you change the country
setting on Smart TV. Change country in SMART
➾
Settings ➙ OPTION ➙ Service Country Setting.
Problem
Solution
While using internet
features, some websites
contain empty spaces.
• The TV's internet supports up to Flash 11 and only plays
files in the following formats :
JPEG, PNG, GIF
Internet closes
automatically when
visiting a website.
• The internet may be forced to close if memory is
insufficient for the volume of information on a web page.
I have already signed
up on the TV. Do I need
to sign up again on the
website (www.lgappstv.
com)?
• If you sign up on your TV, no additional sign-up on the LG
website (www.lgappstv.com) is required.
After signing up on TV, you can sign into the website
by using the same ID and password and entering the
additional information to complete the email verification
process.
Problem
Can each family member
use a different ID on a
single TV?
Solution
• You can register and use more than one ID on one TV.
• You can view the IDs registered on the TV in SMART
➾ Sign in ➙ ID List.
• You can check the list of apps purchased by each ID.
However, you can see all apps installed by each ID in
SMART
➾ Sign in ➙ My Page.
• If you signed up via a PC, use the "Forgot ID?" feature on
the website (www.lgappstv.com).
What should I do if I forget
my ID?
• If you signed up on the TV, IDs can be viewed in SMART
➾ Sign in ➙ Find ID.
Problem
Solution
I purchased an app
from the website (www.
lgappstv.com). How can I
use it on the TV?
• If you want to check an app you purchased on the TV, sign
in and view it on the Purchased Apps menu.
Select the ID at the top of Home and check the app in My
Page ➙ Purchased Apps.
Can I see my purchased
apps history?
• Select the ID at the top of Home and check the app in My
Page ➙ Purchased Apps.
• Sign in to the website (www.lgappstv.com) and select My
Page ➙ Purchase History.
Problem
Solution
I deleted a paid app - do I
have to purchase it again
to download it?
• If a purchased app is accidentally deleted, you can
download and reinstall it without having to buy it again, as
long as it is still in service.
Select the ID at the top of Home and re-download apps in
My Page ➙ Purchased Apps. (Previously owned apps may
not be re-downloaded or run depending on the software
version.)
• Check if the TV model supports LG Smart World.
• Apps from LG Smart TV's LG Smart World can only be run
Can I use apps from LG
on LG Smart TV.
Smart TV's LG Smart
• Also, you can purchase apps from the website (www.
World on both TV and PC?
lgappstv.com) but cannot use them on PC or Mac so be
careful when purchasing them.
Problem
Solution
How can I find out which
ID is currently signed in to
the TV?
• Select the ID at the top of Home and check the currently
signed-in ID in My Page ➙ My Information.
I installed an app on my
TV. Where can I see the
installed app?
• Select SMART
➾ My Apps. All paid and free apps
installed on the TV are displayed.
The app size shown on
screen differs from the
actual app size installed
on the TV.
• The app size shown on screen includes the additional
space needed for installing apps and may differ from the
app size as actually installed.
Problem
I forgot my TV password.
What should I do?
Solution
• If you only provide the ID and password when signing up
on your TV, you cannot recover your password when it is
lost. Create a new ID and sign up with the ID.
• If you provide other information than the ID and password
when signing up on your TV or the LG website (www.
lgappstv.com), you can recover your password on the
website.
Problem
Solution
Do I have to save the
payment information to
purchase paid apps?
• To purchase paid apps, you should have a credit card
registered on TV or the website (www.lgappstv.com) or
have credit. If you do not want your credit card details to
be saved, charge credit in advance. Charging credit is only
available on our website, and you cannot purchase paid
apps if your credit card details are not registered or you
don’t have enough credit.
Can I return an app that I
have purchased?
• As a member, you may not request a refund if you change
your mind after purchase.
• If there is a defect in the product or a problem of using the
product, which does not caused by your fault, you can ask
for a refund. However, the valid reason for refund must be
provided.
Problem
Solution
I signed up on my TV, but
I cannot purchase paid
apps.
• To purchase paid apps, you need to have a credit card
registered with the website (www.lgappstv.com).
Also, you can have your credit ready by charging it on the
website to purchase them.
You cannot purchase paid apps if your credit card details
are not registered with us or you don’t have enough credit.
• For new sign-up members, the ID format has changed
from a combination of numbers and alphabets to the email
Should I only use an email
address.
address for my ID?
• You can only use the email address for your ID when
signing up.
Problem
Solution
Do I need to change my
ID format to the email
address?
• For new sign-up members, the ID format has changed
from a combination of numbers and alphabets to the email
address.
• If you are already a member, you can still use your existing
ID or change it to the email address.
What is the LG account?
• The LG account allows you to sign into all of the LG Smart
service with a single ID and password.
You can use the following services with your LG account:
‌LG Smart TV, LG Smart World (excluding some countries),
LG Smart ThinQ and LG Smart air conditioning, etc.
• Additional information may be required depending on the
service.
❐❐To set the service country
SMART
➾ Settings ➙ OPTION ➙ Service Country Setting
You can change the country setting of your Smart TV.
The Premium service and LG Smart World that are available for the country you
selected will be provided.
Auto Setting
Manual Setting
A service country is automatically set for your Smart TV.
A service country can be set manually for your Smart TV.
✎✎ If a network is disconnected while setting the service country, it may not be
set properly.
❐❐To use Screen Remote
Press the
button on the Magic Remote Control.
Select a button on the Screen Remote displayed on the screen using the Magic
Remote Control.
❌❌To use Screen Remote
✎✎ The type of buttons on the Screen Remote varies depending on the region
or the type of a connected device.
✎✎ Image shown may differ from your TV.
Change Device tab
Exits the Screen Remote
Moves the position of the Screen Remote to left or right
Time Machine II
REC.
TV operation buttons
✎✎ The type of buttons varies depending on the model.
❐❐To control a device connected to the TV using the Screen
Remote
You can control a device connected via SimpLink or MHL using the Screen
Remote.
1 Check if the device is connected to the TV.
2 After pressing the
button on the Magic Remote Control, select the
device you want to control in the Change Device tab. The Screen Remote that
can control the device appears.
✎✎ This may not work with the
button for some models.
✎✎ For more information about SimpLink or MHL connection, please refer to
the connection section of "Owner's Manual" provided with the TV.
❐❐To use the Universal Control function
[For Magic Remote Control only]
[This function may not be applied some countries.]
With the Magic Remote Control, you can control a set-top box, Blu-ray
player, home theatre system, etc.
1 Check if a device you want to set is connected to your TV.
2 After pressing the
button on the Magic Remote Control, select the
icon of a device you want in the Change Device tab.
If there is no device you want, press the
on the tab, and select the
external device you want. Once the setup is complete, the name of the
selected device is displayed in the Change Device tab.
3 When you select a device you want in the Change Device tab, the Screen
Remote that can control the device appears on the screen.
To see more control buttons, select
at the bottom of the
Screen Remote.
❌❌To change or clear the Universal Control settings
1 After pressing the
button on the Magic Remote Control, select the
(TV/input selection) button.
2 Select Change Setting or Cancel Setting at the bottom of the device to be
changed.
✎✎ When Change Setting, check if the power of the device to be changed is
turned on.
✎✎ You can set one device per type.
✎✎ With the Screen Remote, you can only control the devices of a brand or
manufacturer that you can select in the setup screen.
✎✎ If you connect to a network before setting the universal remote control,
update for the latest manufacturer list is available.
✎✎ Some buttons may not work depending on the external device model.
✎✎ Place the device near the TV for seamless operation.
✎✎ If the device is in a drawer, open the drawer.
✎✎ Go to SMART ➾ Universal Control or SMART ➾ INPUT LIST ➙ Set the
Universal Control and add, delete, or change a device.
❐❐What is Time Machine Ⅱ?
It is a function you can use to record a programme you are currently watching
or want to watch and also rewind a programme you are watching in real time.
Immediate Rec
Scheduled Rec
Play
TimeShift
Immediately records a programme you are watching.
Selects a programme you want or sets the time to
record.
Plays back the recordings.
Rewinds a programme you are watching in real time.
✎✎ [Depending on model] You can also record digital/analogue programmes
transmitted over an RF cable and content played through the AV IN input.
✎✎ Recording copyrighted content, provided with a set-top box using an AV
jack, is not supported. Recording genuine DVD/Blu-ray titles is also not
supported.
✎✎ All broadcasts are protected by copyright; you may need to obtain
permission from the copyright owner prior to reproducing or playing back
these broadcasts. If a user records audio or video using this device, the
recordings must be for personal use only. Selling, transferring or renting
recordings protected by copyright is prohibited.
❐❐To use the immediate rec function
➾ Rec.
Time Machine II
Rec.
Display progress bar
Record from the scene you are
currently watching
✎✎ The picture may differ from the screen on the TV.
✎✎ The picture may differ from the screen on the TV. The Rec. button changes
to the Recording stop ( ) button while recording is in progress.
✎✎ You can also record immediately using the Rec. button in the Information
display window.
✎✎ Up to 3 hour of instant recording is supported. To change the end time of
the recording, press the Recording stop button and set the Recording end
time modify option.
✎✎ The recordable time may vary depending on the capacity of your USB
storage device.
✎✎ Press the Wheel (OK) button while recording to display information about
the recording in the top right of the screen.
✎✎ The Wheel (OK) button operation may vary depending on your country.
✎✎ If you force your TV to power off while recording, the programme may
not be saved. Ideally, you should stop the recording and check that the
programme has been recorded before turning the TV off.
✎✎ Some functions may not be available while recording.
❌❌To stop recording
➾
(Recording stop) ➾ Recording stop
❌❌To modify the recording end time
➾
(Recording stop) ➾ Recording end time modify
✎✎ You can set up to 5 hours for Recording end time modify.
❐❐To schedule recording
➾
(Progress bar) ➙ Schedule
This is a function that allows you to set the date and time to record a
programme you want to watch.
REC
live
Recorded TV
✎✎ You can start Schedule from SMART
Schedule List
Schedule
Option
➾ Time Machine Ⅱ ➙ Schedule.
TV Guide
Manual Timer
You can select a programme you
want to schedule for watching or
recording.
TV Guide
You can select a date, time and
channel to schedule the watching or
recording time.
Manual Timer
Manual Timer
Schedule List
-24H
+24H
TV Guide
Schedule List
✎✎ Image shown may differ from your TV.
✎✎ When no Programme Guide is available, only the Manual Timer menus are
displayed.
✎✎ The length of the scheduled recording should be at least 2 minutes.
❐❐To check or modify the schedule list
➾
(Progress bar) ➙ Schedule List
This is a function you can use to check, modify or delete the watching and
recording schedule you have set.
✎✎ Up to 30 programmes can be added to the Schedule List.
✎✎ You can start Schedule List from SMART
Schedule List.
➾ Time Machine Ⅱ ➙
❐❐To watch recordings
SMART
➾ SmartShareTM ➙ Recorded TV
You can view the recordings stored on a USB device. You can select a
recording to play or delete.
Play on previous
playtime.
Play from the start.
Delete
Resumes play of a recording you have played back
before.
Plays back the selected recording from the beginning.
Deletes the selected recording.
✎✎ Up to 600 recordings can be added in Recorded TV.
❐❐To manage recordings
SMART
➾ SmartShareTM ➙ Recorded TV
Protection
Delete
Prevents the selected recording from being automatically
deleted.
Deletes the selected recording.
❐❐To control playback of recordings
Press the Wheel (OK) button on the remote control while playing.
Select a point from which to play
Clip-Edit
Adjust picture while
playing
Repeat/save clip
✎✎ The picture may differ from the screen on the TV.
Set recordings playback option
Repeat
Option
View in 3D
(Displayed only for
models that support 3D)
❐❐To connect a USB device for Time Machine Ⅱ
1 Prepare a USB device to be used for Time Machine Ⅱ.
2 Connect a USB storage device to the port with the HDD IN label at the back
or on the side of your TV.
3 To use a USB device only for the Time Machine Ⅱ function, you must
initialise the device.
Select SMART
➾ Time Machine Ⅱ ➙ Option ➙ USB device
initialisation if you connect a device that has not been initialised. The USB
device initialisation screen appears.
4 To complete USB Device Initialisation and use TimeShift, set the TimeShift
mode to ON.
✎✎ You can use a Hard Disk Drive (HDD) or Solid State Drive (SSD) as a USB
device for Time Machine Ⅱ only.
✎✎ It is recommended that you use a USB device with a capacity between
40 GB and 2 TB.
✎✎ For an SSD, there is a limit to the amount of reading/writing that can be done.
Therefore, it is recommended that you use a HDD.
✎✎ To remove a USB device, select Quick Menu ➙ USB Device. Make sure you
receive the confirmation message that the USB device has been removed.
✎✎ If a USB device is faulty, the Time Machine Ⅱ function may not operate
normally.
✎✎ If you use a USB extension cable, the USB device may not be recognized or
may not work properly.
❐❐What is TimeShift (real-time playback)?
It is a function you can use to save the programme you are currently watching
temporarily on a USB device so you can play back a scene you missed while
watching TV. This function allows you to continue watching from where you
were previously if you go out for a while.
✎✎ You have to set the TimeShift mode to ON after connecting a USB device to
use the TimeShift function.
✎✎ [Depending on model] This function works for analogue/digital programmes
and AV input mode.
✎✎ With the TimeShift function, you can play a programme back for up to two
hours. This time may vary depending on your region.
✎✎ While in the TimeShift mode, the picture stored by this function is deleted
if you turn off the TV without recording it.
❐❐To use the TimeShift (real-time playback) function
Use the left or right navigation button on the Magic remote control to wind the
picture you are watching back or forward by 10 seconds.
REC
Live
Recorded TV
Schedule List
Schedule
Option
✎✎ You can also operate TimeShift using the left or right navigation button on a
standard remote control.
❐❐To set the Time MachineⅡ functions
SMART
➾ Time MachineⅡ ➙ Option
You can change the settings for Time MachineⅡ while using the function.
Recording Quality
TimeShift
[Depending on model]
Sets the picture quality of recordings. You can set it to
High Quality or Normal Quality.
✎✎ The recording time may vary depending on the
recording quality.
Plays back a scene that you have missed.
• ON: Enables the TimeShift function automatically
when you turn on the TV.
• OFF: Disables the TimeShift function.
Auto deleting
USB Device
initialisation
Automatically deletes old recordings when a USB device
is full in order to secure space to save new recordings.
✎✎ Protected recordings are not deleted automatically.
Sets a connected storage device to be used only for
Time Machine. All data saved on the USB device is
deleted.
✎✎ A storage device on which USB Device initialisation has been performed
will not be detected by a PC.
✎✎ Recordings saved on a USB device can be damaged. The manufacturer is
not liable for any damaged recordings since it is the user's responsibility to
manage data.
❐ ❐What is Motion Recognition?
You can control the TV simply by gesturing for the camera.
You can use the Motion Recognition function to turn the TV off, change the
channel and control the volume.
✎ ✎ Motion Recognition is only a function for watching TV and it is not supported
when using the smart menu, such as when connecting wireless devices,
including TV apps or USB ports.
TV
HDMI1
Move
Component
Select
❐ ❐To use the Motion Recognition function
1 Prepare the Smart TV camera for use. If your Smart TV is not equipped
with a camera, install an LG video call camera (Sold separately). (For more
information, please refer to the installation manual or owner's manual of
the camera.)
2 The camera is activated 20 to 30 seconds after the TV is switched on.
3 Go to SMART ➾ Settings ➙ OPTION and check if Motion Recognition is
set to On.
4 Stare at the camera while the TV is on and hold your hand up close to your
face. The motion recognition controller appears on the TV screen. (You can
check the motion recognition range of the camera in SMART ➾ Settings
➙ OPTION ➙ Camera Setting Help.)
5 Move your hand left, right, up or down to select a function. Close and open
your fist to start the function.
6 If you lower your hand out of the range of motion recognition, the controller
disappears from the screen.
✎ ✎ If you clench your fist for more than one second, the selected function is
performed repeatedly until you open your hand.
✎ ✎ If you are watching TV using a set-top box, install an IR blaster (ANBL100, sold separately) to control the volume and the channel of the settop box using Motion Recognition.
✎ ✎ The Motion Recognition may not be working properly if:
• You are in either too bright or too dark place. (Optimal ambient
brightness: 50 lux - 600 lux)
• Your face cannot be detected by the camera because of the light behind
you.
• Your face is not detected by the camera because you are wearing a hat
• The distance between you and the camera is too close or too far (Ideal
distance: 1.5 m - 4.5 m)
• Your fingers cannot be detected by the camera because you are wearing
gloves or a bandage.
• You moved your arm forward or your hand is not close enough to your
face.
• Your skin colour is similar to the background colour.
• The background is striped.
✎ ✎ A gesture may not be recognised in the following cases.
• If Motion Recognition is set to Off in SMART ➾ Settings ➙ OPTION,
: Set it to On.
• If any other menu than the motion recognition controller is displayed on
the TV screen,
: Make it disappear.
• (For the built-in camera) If the camera is not lifted up,
: Make sure to lift up the camera.
✎ ✎ Devices connected through a USB port or a wireless connection cannot be
switched via Motion Recognition.
✎ ✎ If more than one hand is detected by the camera, it works with the first
detected hand only. To use another hand to operate the controller, lower your
hand down to clear the controller from the screen and then raise your hand
up again.
✎ ✎ If you hold your hand up with it spread out or gripped, the camera may not
detect your hand. Make sure that you raise your hand with all five fingers
clearly displayed.
✎ ✎ Be careful not to move your hand too fast or make too big motion. Move
your hand slowly near your face.
✎ ✎ If Motion Recognition does not work properly, lower your hand and then lift it
up again.
✎ ✎ If you open your hand at an angle, the camera might mistake this as a fist and
perform the selected function.
You can download the LG TV Remote app from Google Play Store or Apple App
Store and use it on any TV connected with your smartphone.
• Now you can enjoy your favorite TV shows on your smartphone. (Some
models only)
• You can easily enter your account information to log in.
• You can add your favorite channels on your smartphone.
• You can use the functions such as PREMIUM, MY Apps, and SmartShareTM
directly on your smartphone.
• The text input function is supported, so you can enter text easily. (Text
cannot be entered on some screens.)
• Select the app's touch pad to control in the same way the pointer of the
Magic Remote Control works.
• You can control the game app of the TV by selecting the Game Pad in the
LG TV Remote app.
• Keypad which allows you to control the set-top box and media devices is
provided. (Some models with specified conditions only.)
• You can set the TV to the power-saving mode while watching TV on your
smartphone.
• You can capture the screen you are watching and share it through social
network services such as Twitter and Facebook.
✎✎ The supported functions may vary depending on the TV or the version of
the LG TV Remote app.
❐❐To use a USB wired/wireless mouse
Connect your mouse to the USB port. Use the mouse to move the pointer on the
TV screen and select the menu you want.
Mouse
Magic Remote Control
Left Button
OK Button on Magic Remote Control
Wheel Button
Wheel Button on Magic Remote Control
✎✎ The right and the special buttons on the mouse do not work.
✎✎ The usability of a wireless USB mouse and keyboard may be affected by
Radio Frequency environment and the distance.
❐❐To use a USB wired/wireless keyboard
Connect your keyboard to the USB port. You can enter text with the keyboard
when using the search function and the Internet.
✎✎ Text cannot be entered on some screens.
✎✎ It is recommended to use the product which is tested for compatibility with
LG TV.
LOGITECH K200, LOGITECH K400, MICROSOFT Comfort Curve 2000,
MICROSOFT MS800, and LG Electronics ST-800
✎✎ You can change the input language by pressing the language switch key (or
the right Alt key) on your keyboard.
❐❐To use a gamepad
Connect your gamepad to the USB port on the TV if the game requires a
gamepad.
✎✎ It is recommended to use an authorized gamepad which is tested for
compatibility with LG TV.
Logitech F310, Logitech F510, Logitech F710, Logitech Rumblepad 2
Logitech Cordless Rumblepad 2, Logitech Dual Action Gamepad,
Microsoft Xbox 360 Controller (wired) and SONY PLAYSTATION(R)3 Controller
SMART
➾ Settings ➙ SUPPORT ➙ Software Update
Uses Software Update to check and obtain the latest version.
It is also possible to check manually for available updates.
Set it to On.
Software Update If an update is available, a prompt will appear to perform
the update.
Automatic
update mode
Check Update
Version
If an update is available, the update automatically starts
without prompting.
Checks the latest update version installed. When a
new update is available, the download process can be
performed manually.
✎✎ When the update starts, the update progress window appears for a short
time and disappears.
✎✎ The latest version can be obtained via the digital broadcast signal or an
internet connection.
✎✎ Changing the programme while downloading the software via a digital
broadcast signal interrupts the download process. Returning to the initial
programme allows downloading to resume.
✎✎ If software is not updated, certain functions may not work properly.
✎✎ [For Finland/Sweden/Denmark/Norway models.]
If the software update is performed via the broadcasting signal, you will
be prompted to continue the update regardless of whether the Automatic
update mode is enabled or not.
If the following symptoms occur, please carry out the checks and adjustments
described below. There may be no malfunction.
SMART
➾ Settings ➙ SUPPORT ➙ Signal Test
Shows the MUX and Service information etc. If you select Antenna & Satellite or
Cable & Satellite, a signal test only for Antenna or Cable is displayed.
❐❐General
Problem
Solution
Cannot view certain
programmes.
• Adjust the location or orientation of the antenna.
• Save the programmes you wish to view later using Auto
Tuning or Programme Edit.
There is a delay after the
TV is switched on before
the image is fully visible.
• This is not a problem. Image noise that may occur when
the TV is first switched is being cleaned up.
❐❐Pictures
SMART
➾ Settings ➙ SUPPORT ➙ Picture Test
First run a Picture Test to verify that the image signal output is normal.
If there is no problem with the test image, check external device connections
and broadcast signals.
Problem
Images from previous
programme or other
programmes linger or the
screen displays annoying
lines.
Solution
• Adjust the orientation of the antenna to the TV
transmitter, or refer to the manual for instructions on
connecting the antenna.
Problem
Solution
Vibrating horizontal/vertical
lines and fishnet patterns
appear momentarily.
• Such a problem may happen when there is strong
electronic interference. Turn off other electronic devices
such as mobile phones, power tools and other small
electrical appliances.
The screen display freezes
or does not work properly
during a digital broadcast.
• This may occur in case of a weak signal or unstable
reception. Adjust the antenna orientation and cable
connections.
• If the signal strength or quality is low on Manual Tuning,
check with the TV station or administration office.
Digital broadcasting is not
available even though the
cable is connected.
• Check with the cable operator providing your
subscription and/or signal. (Depending on your
subscription, digital broadcasting may not be
supported.)
Problem
Solution
The display is inactive or
unclear when connected to
an HDMIⓇ source.
• Check the HDMIⓇ cable specifications. If your HDMIⓇ
cable is not genuine, images may fade in and out or not
be displayed properly.
• Ensure that all cables are securely connected. When
connections are not secure, images may not be properly
displayed.
Does not work with a USB
storage device.
• Verify that the USB device and cable is version 2.0 or
higher.
❐❐Sound
SMART
➾ Settings ➙ SUPPORT ➙ Sound Test
First run a Sound Test to verify that the sound signal output is normal.
If there is no problem with the test sound, check connected external devices and
the broadcast signal.
Problem
Solution
Screen display is on but there • Check other TV programmes.
is no sound.
• Ensure the TV Speaker is set to On.
For an analogue broadcast,
stereo is not clear or sound
comes from one speaker only.
• In a poor reception area (areas with weak or unstable
signals) or if Multi Audio is not stable, select Mono on
Multi Audio.
• Adjust the Balance using the Navigation button.
Problem
Solution
TV sound is not in sync
with the image or the sound
breaks up occasionally.
• If the issue affects a specific TV programme only, it
may be caused by problems with the broadcast signal
for the individual station. Check with the TV station or
your cable operator.
The volume changes when I
change programme.
• Volume can vary from programme to programme.
• Set Auto Volume to On.
Problem
Solution
On certain programmes, there
• In Language, set Language ➙ Audio Language to
is no sound at all, or only the
the language of your choice. Even if you change the
background music can be
language on Multi Audio, you can go back to the
heard
default setup once you turn off the power or change
(in case of a programme
the programme.
created for overseas viewers).
There is no sound when
connected to HDMI / USB.
• Verify that the HDMIⓇ cable is high speed.
• Check if the USB device and cable is version 2.0 or
higher.
• Use only regular music (*mp3) files.
❐❐PC connection problem
Problem
Solution
The screen display
does not come on
after connecting to the
computer.
• Verify that the computer and the TV are securely
connected.
• Turn the TV off and back on using the remote control.
• Restart the PC with the TV on.
• Check whether the resolution is correctly set for PC input.
• To use the TV as a secondary monitor, check if the
connected desktop or laptop supports dual monitor display.
• Reconnect the HDMI cable.
There is no sound after
connecting the computer
with the HDMI cable.
• Check with manufacturer of your video card to ensure it
supports HDMI voice output. (Video cards in DVI format
require connection of a separate sound cable.)
Problem
When connected to the
computer, the display is
partially cut off or shifts
to one side.
Solution
• Set the resolution to support PC input. (If this does not
work, reboot the computer.)
❐❐Problems replaying movies in My Media
Problem
I cannot view the files on
the Movie List.
Solution
• Check whether the file on the USB storage device can be
read on a computer.
• Check whether the file extension is supported.
• Make sure that the file replays normally on the
"This file is invalid."
computer's video player. (Check for damaged files.)
message appears or the
• Check whether the resolution is supported by the
image display is not normal
computer.
even though the sound is
• Verify that the video/audio codec is supported.
OK.
• Verify that the frame rate is supported.
Problem
"Audio not supported."
message appears or the
sound is not normal even
though the image display is
OK.
Solution
• Make sure that the file replays normally on the
computer's video player. (Check for damaged files.)
• Check if the audio codec is supported by the computer.
• Verify that the bit rate is supported.
• Verify that the sample rate is supported.
Problem
Solution
Subtitles are not displayed.
• Make sure that the file replays normally on the
computer's video player. (Check for damaged files.)
• Check if the video file has the same name as the subtitle
file.
• Make sure that the video and subtitle files are in the same
folder.
• Verify that the subtitle file format is supported.
• Verify that the subtitle language is supported. (Subtitle
files can be opened in Notepad to check the language.)
✎✎ Image shown may differ from your TV.
✎✎ For information on requesting service, refer to the following menu.
SMART ➾ Settings ➙ SUPPORT ➙ Product/Service Info.
Product certified before February 15, 2013
Продукт, сертифицированный до 15
февраля 2013 г.
%=
Product certified after February 15, 2013
Продукт, сертифицированный после 15
февраля 2013 г.
ПІІ ‘ЛГ Електронікс Україна’, Україна, 01004, м. Київ, вул. Басейна, 4 (літера А),
тел.: +38 (044) 201-43-50, факс: +38 (044) 201-43-73
Обмеження України на наявність небезпечних речовин
Устаткування відповідає вимогам технічного регламенту щодо обмеженного
використання небезпечних речовин в електричному і електронному обладнанні.
Ukraine Restriction of Hazardous Substances
The equipment complies with requirements of the Technical Regulation, in terms of
restrictions for the use of certain dangerous substances in electrical and electronic
equipment.
❐❐EU Conformity Notice
LG Electronics hereby declares that this product is in
compliance with the following Directives.
R&TTE Directive 1999/5/EC
EMC Directive 2004/108/EC
LOW VOLTAGE Directive 2006/95/EC
The products described above comply with the essential requirements of the directives
specified.
This device is a 2.4 and 5 GHz wideband transmission system, intended for use in all
EU member states and EFTA countries, except in France and Italy where restrictive use
applies.
In Italy the end-user should apply for a license at the national spectrum authorities in
order to obtain authorization to use the device for setting up outdoor radio links and/or for
supplying public access to telecommunications and/or network services.
This device may not be used for setting up outdoor radio links in France and in some areas
the RF output power may be limited to 10 mW EIRP in the frequency range of 2454 – 2483.5
MHz. For detailed information the end user should contact the national spectrum authority
in France.
European representative:
LG Electronics Inc. Krijgsman 1, 1186 DM Amstelveen, The Netherlands
The product is designed for indoor use only.
CE Notified Body statement:
This is a Class B product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
❌❌ [Shqip]
Deklarata e Konformitetit për BE-në
LG Electronics nëpërmjet kësaj deklaron se
ky produkt është në përputhje me Direktivat e
mëposhtme.
Direktivën R&TTE 1999/5/KE
Direktivën EMC 2004/108/KE
Direktivën për VOLTAZHIN E ULËT 2006/95/
KE
Produktet e përshkruara më lart përputhen
me kërkesat thelbësore të direktivave të
specifikuara.
Përfaqësuesi evropian:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Holandë
Vetëm për përdorim të brendshëm.
❌❌ [Bosanski]
Napomena o usklađenosti sa propisima
EU
LG Electronics ovim putem izjavljuje da je ovaj
proizvod usklađen sa sljedećim direktivama:
Direktiva o radijskoj opremi i
telekomunikacijskoj terminalnoj opremi
1999/5/EC
Direktiva o elektromagnetskoj kompatibilnosti
2004/108/EC
Direktiva o niskonaponskoj opremi 2006/95/
EC
Opisani proizvodi usklađeni su sa ključnim
zahtjevima navedenih direktiva.
Predstavnik za Europu:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Holandija
Samo za unutarnju upotrebu.
❌❌ [Български]
Бележка относно съответствие с
нормите на ЕС
С настоящото LG Electronics декларира,
че този продукт съответства на следните
директиви.
R&TTE директива 1999/5/EC
EMC директива 2004/108/EC
Директива за НИСКО НАПРЕЖЕНИЕ
2006/95/EC
Описаният по-горе продукт съответства
на основните изисквания на посочените
директиви.
❌❌ [Česky]
Prohlášení o shodě s legislativou EU
Společnost LG Electronics tímto prohlašuje,
že tento výrobek je ve shodě s následujícími
směrnicemi.
Směrnice o radiokomunikačních a
telekomunikačních koncových zařízeních
1999/5/EC
Směrnice o elektromagnetické kompatibilitě
2004/108/EC
Směrnice o nízkém napětí 2006/95/EC
Výše popisované produkty jsou v souladu se
základními požadavky uvedených směrnic.
Европейски представител:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Нидерландия
Zastoupení v Evropě:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Nizozemsko
За употреба само в закрити помещения.
Pouze pro vnitřní použití.
❌❌ [Dansk]
EU-overensstemmelseserklæring
❌❌ [Nederlands]
Conformiteitsverklaring (EU)
LG Electronics erklærer hermed, at dette
produkt overholder følgende direktiver.
LG verklaart hierbij dat dit product voldoet
aan de volgende richtlijnen.
R&TTE-direktiv 1999/5/EC
EMC-direktiv 2004/108/EC
LOW VOLTAGE-direktiv 2006/95/EC
R&TTE-richtlijn 1999/5/EC
EMC-richtlijn 2004/108/EC
Laagspanningsrichtlijn 2006/95/EC
De produkter, der er beskrevet ovenfor,
overholder de vigtigste krav i de angivne
direktiver.
De hierboven genoemde producten voldoen
aan de essentiële voorwaarden van de
gespecificeerde richtlijnen.
Europæisk repræsentant:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Holland
Europees hoofdkantoor:
LG Electronics Inc. Krijgsman 1, 1186 DM
Amstelveen, Nederland
Kun til indendørs brug.
Alleen voor gebruik binnen.
❌❌ [Eesti]
EÜ vastavuskinnitus
❌❌ [Suomi]
EU-vaatimustenmukaisuusilmoitus
Käesolevaga kinnitab LG Electronics, et see
toode ühildub järg¬miste direktiividega.
LG Electronics vakuuttaa täten, että tämä
tuote on seuraavien direktiivien mukainen.
Raadioseadmete ja
telekommunikatsioonivõrgu lõppseadmete
direktiiv 1999/5/EÜ
Elektromagnetilise ühilduvuse direktiiv
2004/108/EÜ
MADALPINGESEADMETE direktiiv 2006/95/
EÜ
R&TTE-direktiivi 1999/5/EC
EMC-direktiivi 2004/108/EC
LOW VOLTAGE -direktiivi 2006/95/EC
Eelnimetatud tooted vastavad märgitud
direktiivide oluliste nõuetele.
Euroopa esindus:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Holland
Kasutada ainult siseruumides.
Edellä mainitut tuotteet ovat eriteltyjen
direktiivien oleellisten vaatimusten mukaisia.
Edustaja Euroopassa:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Alankomaat
Vain sisäkäyttöön.
❌❌ [Français]
Notice de conformité UE
❌❌ [Deutsch]
EU-Konformitätserklärung
LG Electronics atteste que ces produits est en
conformité avec les Directives suivantes.
LG Electronics erklärt hiermit, dass dieses
Produkt den folgenden Richtlinien entspricht:
Directive 1999/5/CE des R&TTE
Directive 2004/108/CE EMC
Directive 2006/95/CE des appareils basse
tension
R&TTE-Richtlinie 1999/5/EC
EMC-Richtlinie 2004/108/EC
Niederspannungsrichtlinie 2006/95/EC
Les produits décrits ci-dessus sont en
conformité avec les exigences essentiels des
directives spécifiées.
Représentant en Europe :
LG Electronics Inc. Krijgsman 1, 1186 DM
Amstelveen, Pays-Bas
Usage intérieur uniquement.
Die oben beschriebenen Produkte
entsprechen den grundlegenden
Anforderungen der angegebenen Richtlinien.
Vertreter für Europa:
LG Electronics Inc. Krijgsman 1, 1186 DM
Amstelveen, Niederlande
Nur zur Verwendung in Innenräumen.
❌❌ [ΕΛΛΗΝΙΚΑ]
Δήλωση συμμόρφωσης Ε.Ε.
Η LG Electronics δηλώνει ότι το παρόν
προϊόν συμμορφώνεται με τις εξής Οδηγίες:
Οδηγία 1999/5/ΕΚ περί Ραδιοεξοπλισμού και
Τηλεπικοινωνιακού Τερματικού Εξοπλισμού
(R&TTE)
Οδηγία 2004/108/EΚ περί
Ηλεκτρομαγνητικής Συμβατότητας
Οδηγία 2006/95/EΚ περί Χαμηλής Τάσης
Τα παραπάνω προϊόντα συμμορφώνονται
με τις ουσιώδεις απαιτήσεις των ανωτέρω
οδηγιών.
Ευρωπαϊκός αντιπρόσωπος:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Ολλανδία
Μόνο για εσωτερική χρήση.
❌❌ [Magyar]
EU megfelelőségi nyilatkozat
Az LG Electronics ezúton kijelenti, hogy a
termék megfelel a következő irányelvek
előírásainak:
1999/5/EK R&TTE irányelv
2004/108/EK EMC irányelv
2006/95/EK KISFESZÜLTSÉGŰ irányelv
A fentiekben bemutatott termékek teljesítik a
megadott irányelvek alapvető előírásait.
Európai képviselet:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Hollandia
Csak beltéri használatra.
❌❌ [Italiano]
Avviso di conformità EU
LG dichiara che questo prodotto è conforme
alle seguenti direttive.
Direttiva R&TTE 1999/5/CE
Direttiva EMC 2004/108/CE
Direttiva BASSA TENSIONE 2006/95/CE
I prodotti descritti sopra sono conformi ai
requisiti essenziali delle direttive specificate.
Rappresentante europeo:
LG Electronics Inc. Krijgsman 1, 1186 DM
Amstelveen, Paesi Bassi
Solo per uso interno.
❌❌ [Қазақша]
ЕО сәйкестік туралы ескертуі
LG Electronics осы құжат арқылы бұл
құрылғының мына директиваларға сай
екенін мәлімдейді.
Радио және телекоммуникациялық
жабдықтардың 1999/5/EC директивасы
2004/108/EC электромагниттік
үйлесімділік директивасы
Төмен кернеулі жабдықтардың 2006/95/
EC директивасы
Жоғарыда сипатталған өнімдер
көрсетілген директивалардың негізгі
талаптарына сай келеді.
Еуропадағы өкілдік:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Нидерланд
Тек ғимарат ішінде қолдануға арналған.
❌❌ [Latviešu]
Paziņojums par atbilstību ES direktīvām
LG Electronics ar šo paziņo, ka šis
izstrādājums atbilst turpmāk minētajām
direktīvām.
R&TTE direktīva 1999/5/EK
Elektromagnētiskās savietojamības direktīva
2004/108/EK
Direktīva par zemspriegumu 2006/95/EK
Iepriekš aprakstītie izstrādājumi atbilst
norādīto direktīvu būtiskajām prasībām.
Pārstāvniecība Eiropā:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Nīderlande
Tikai lietošanai telpās.
❌❌ [Lietuvių k.]
EB atitikties deklaracija
„LG Electronics“ pareiškia, kad šis produktas
atitinka tokias direktyvas.
R&TTE direktyvą 1999/5/EB
EMS direktyvą 2004/108/EB
Žemos įtampos direktyvą 2006/95/EB
Aukščiau įvardinti produktai atitinka nurodytų
direktyvų esminius reikalavimus.
Atstovas Europoje:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Nyderlandai
Naudoti tik patalpose.
❌❌ [Македонски]
Известување за усогласеност со ЕУ
❌❌ [Norsk]
Samsvarsmerknad for EU
LG Electronics јавно изјавува дека овој
производ е во согласност со следните
директиви.
LG Electronics erklærer herved at dette
produktet er i henhold til de følgende
direktivene.
R&TTE директива 1999/5/EC
EMC директива 2004/108/EC
Директива за НИЗОК НАПОН 2006/95/EC
R&TTE-direktiv 1999/5/EC
EMC-direktiv 2004/108/EC
Lavspenningsdirektiv 2006/95/EC
Производите опишани погоре ги
исполнуваат основните услови од
посочените директиви.
Produktene som beskrives ovenfor,
overholder kravene i de angitte direktivene.
Европски претставник:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Холандија
За употреба само во затворени простории.
Europeisk representant:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Nederland
Bare til innendørs bruk.
❌❌ [Polski]
Deklaracja zgodności z normami UE
Firma LG Electronics niniejszym zaświadcza,
że ten produkt spełnia wymagania
poniższych dyrektyw.
Dyrektywa 1999/5/WE w sprawie
urządzeń radiowych i końcowych urządzeń
telekomunikacyjnych
Dyrektywa 2004/108/WE dotycząca
kompatybilności elektromagnetycznej
Dyrektywa 2006/95/WE dotycząca sprzętu
elektrycznego przeznaczonego do stosowania
w określonych granicach napięcia
Powyżej wymienione produkty spełniają
zasadnicze wymagania wymienionych
dyrektyw.
Przedstawiciel na Europę:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Holandia
Tylko do użytku wewnątrz pomieszczeń.
❌❌ [Português]
Aviso de conformidade da UE
A LG Electronics declara por este meio que
este produto está em conformidade com as
seguintes Directivas.
Directiva R&TTE 1999/5/CE
Directiva relativa à compatibilidade
electromagnética 2004/108/CE
Directiva para equipamentos de BAIXA
TENSÃO 2006/95/CE
Os produtos acima descritos estão em
conformidade com os requisitos essenciais
das directivas especificadas.
Representante europeu:
LG Electronics Inc. Krijgsman 1, 1186 DM
Amstelveen, Holanda
Apenas para uso em espaços interiores.
❌❌ [Română]
Declaraţie de conformitate UE
Prin prezenta, LG Electronics declară că
acest produs este conform cu următoarele
Directive.
Directiva R&TTE 1999/5/CE
Directiva EMC 2004/108/CE
Directiva pentru tensiune joasă 2006/95/CE
Produsul descris mai sus este conform cu
cerinţele esenţiale ale directivelor specificate.
Reprezentant european:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Olanda
Doar pentru utilizare în interior.
❌❌ [Русский]
Уведомление о соответствии
нормам ЕС
Компания LG Electronics настоящим
заявляет о том, что данное изделие
соответствует следующим директивам.
Директива R&TTE 1999/5/EC
Директива EMC 2004/108/EC
Директива LOW VOLTAGE 2006/95/EC
Описанные выше изделия соответствуют
основным требованиям указанных
директив.
Представительство в Европе:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Нидерланды
Только для использования в помещении.
❌❌ [Srpski]
Napomena o usklađenosti sa
standardima
❌❌ [Hrvatski]
Napomena o sukladnosti s EU
standardima
LG Electronics ovim izjavljuje da je ovaj
proizvod usklađen sa sledećim direktivama:.
LG Electronics ovim putem izjavljuje da je ovaj
proizvod sukladan sljedećim Direktivama.
R&TTE direktiva 1999/5/EC
EMC direktiva 2004/108/EC
NISKONAPONSKA direktiva 2006/95/EC
R&TTE direktiva 1999/5/EC
R&EMC direktiva 2004/108/EC
Direktiva o niskonaponskim uređajima
2006/95/EC
Prethodno opisani proizvodi usklađeni su s
osnovnim zahtevima iz navedenih direktiva.
Evropski predstavnik:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Holandija
Koristite samo u zatvorenom prostoru.
Gore opisan proizvod sukladan je osnovnim
zahtjevima navedenih direktiva.
Zastupnik za Europu:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Nizozemska
Korištenje isključivo u zatvorenom prostoru.
❌❌ [Slovenčina]
Vyhlásenie o zhode pre oblasť EÚ
Spoločnosť LG Electronics týmto vyhlasuje,
že tento výrobok dosahuje súlad s
nasledujúcimi smernicami.
Smernica R&TTE 1999/5/ES
Smernica EMC 2004/108/ES
Smernica o slaboprúde 2006/95/ES
Vyššie popísané výrobky vyhovujú základným
požiadavkám uvedených smerníc.
Európske zastupiteľstvo:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Holandsko
Len na použitie v interiéri.
❌❌ [Slovenščina]
Izjava o skladnosti EU
LG Electronics izjavlja, da je ta izdelek v
skladu z naslednjimi direktivami.
Direktiva 1999/5/ES o radijski opremi in
telekomunikacijski terminalski opremi ter
medsebojnem priznavanju skladnosti te
opreme
Direktiva 2004/108/ES o elektromagnetni
združljivosti
Direktiva 2006/95/ES o nizki napetosti
Zgoraj opisani izdelki izpolnjujejo bistvene
zahteve navedenih direktiv.
Evropski zastopnik:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Nizozemska
Samo za uporabo v zaprtih prostorih.
❌❌ [Español]
Aviso de conformidad con la UE
Por la presente, LG Electronics declara que
este producto cumple con las siguientes
directivas.
Directiva sobre equipos radioeléctricos y
equipos terminales de telecomunicación
1999/5/CE
Directiva sobre compatibilidad
electromagnética 2004/108/CE
Directiva sobre baja tensión 2006/95/CE
❌❌ [Svenska]
Meddelande om EU-regelefterlevnad
LG Electronics intygar härmed att den här
produkten uppfyller följande gällande direktiv:
R&TTE-direktivet 1999/5/EG
EMC-direktivet 2004/108/EG
Lågspänningsdirektivet 2006/95/EG
Ovan nämnda produkter stämmer överens
med de grundläggande kraven som anges i
direktiven.
Los productos descritos anteriormente
cumplen con los requisitos esenciales de las
directivas especificadas.
Europeisk representant:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Nederländerna
Representante europeo:
LG Electronics Inc. Krijgsman 1, 1186 DM
Amstelveen, Países Bajos
Används endast inomhus.
Sólo para uso en interiores.
❌❌ [Türkçe]
AB Uygunluk Bildirimi
LG Electronics, burada bu ürünün aşağıdaki
Direktifler ile uyumlu olduğunu beyan eder.
R&TTE Direktifi 1999/5/EC
EMC Direktifi 2004/108/EC
DÜŞÜK VOLTAJ Direktifi 2006/95/EC
Yukarıda anlatılan ürünler, belirtilen
direktiflerin gereklilikleri ile uyumludur.
Avrupa temsilciliği :
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Hollanda
Sadece kapalı alanda kullanım.
❌❌ [Укрaїнcькa]
Підтвердження відповідності
стандартам ЄС
Цим компанія LG Electronics підтверджує
відповідність цього продукту вимогам
директив, що перелічені нижче.
Директива R&TTE, 1999/5/EC
Директива EMC, 2004/108/EC
Директива НИЗЬКОЇ НАПРУГИ, 2006/95/EC
Описані вище продукти відповідають
основним вимогам вказаних директив.
Уповноважена особа у Європі:
LG Electronics Krijgsman 1, 1186 DM
Amstelveen, Нідерланди
Призначено лише для використання в
приміщенні.
❐❐Information for recycling (take-back offer)
This product may contain parts which could be hazardous to the environment.
It is important that this product be recycled after use.
LGE handles all waste products through an environmentally acceptable recycling method.
There are several take-back and recycling systems currently in operation worldwide.
Many parts will be reused and recycled, while harmful substances and heavy metals are
treated by an environmentally friendly method. If you want to find out more information
about our recycling program, please contact your local LG vendor or a corporate
representative of LG. and Information of Regional Take back Schemes can be found at :
http://www.lg.com/global/sustainability/environment/take-back-recycling.jsp
❐❐Disposal of waste batteries (applicable in the European Union and other
European countries with separate collection systems)
This symbol on the battery or on the packaging indicates that the
battery provided with this product shall not be treated as household
waste.
By ensuring these batteries are disposed of correctly, you will help
prevent potentially negative consequences for the environment and
human health which could otherwise be caused by inappropriate waste handling of the
battery. The recycling of the materials will help to conserve natural resources.
Pb
In case of products that for safety, performance or data integrity reasons require a
permanent connection with an incorporated battery, this battery should be replaced by
qualified service staff only.
To ensure that the battery will be treated properly, hand over the product at end-of-life to
the applicable collection point for the recycling of electrical and electronic equipment.
For all other batteries, please view the section on how to remove the battery from the
product safely. Hand the battery over to the applicable collection point for the recycling of
waste batteries.
For more detailed information about recycling of this product or battery, please contact
your local authority, your household waste disposal service or the shop where you
purchased the product.
❐❐Energy Saving
Energy efficiency cuts energy consumption and thus saves money by reducing electricity
bills.
The following indications allow to reduce power consumption when the television is not
being watched:
• turning the television off at its mains supply, or un-plugging it, will cut energy use to
zero for all televisions, and is recommended when the television is not being used for a
long time, e.g. when on holiday,
• putting the television into standby mode, will reduce energy consumption, but will still
draw some power,
• reducing the brightness of the screen will reduce energy use.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
