LG | LE5008D-NH | LG LE5008D-NH Owner’s Manual

OWNER’S MANUAL
Hybrid Digital Video
Recorder
Please read this manual carefully before operating
your set and retain it for future reference.
MODELS
LE5016/LE5008 Series
LE4016/LE4008 Series
1304 (V3.0)
2
Safety Information
1
Safety Information
1
Safety Information
CAUTION
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme
NMB-003 du Canada.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning: Do not install this equipment in a confined space such as
a bookcase or similar unit.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Warning: Wiring methods shall be in accordance with the National
Electric Code, ANSI/NFPA 70.
Warning: This is a class A product. In a domestic environment this
product may cause radio interference in which case the user may
be required to take adequate measures.
This lightning flash with arrowhead symbol
within an equilateral triangle is intended
to alert the user to the presence of
uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
Warning: To reduce a risk of fire or electric shock, do not expose
this product to rain or moisture.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the product.
Caution: The apparatus should not be exposed to water (dripping
or splashing) and no objects filled with liquids, such as vases, should
be placed on the apparatus.
FCC WARNING: This equipment may generate or use radio
frequency energy. Changes or modifications to this equipment may
cause harmful interference unless the modifications are expressly
approved in the instruction manual. The user could lose the
authority to operate this equipment if an unauthorized change or
modification is made.
Caution: This installation should be made by a qualified service
person and should conform to all local codes.
Caution: To avoid electrical shock, do not open the cabinet. Refer
servicing to qualified personnel only.
Caution:
This product employs a Laser System. To ensure proper use of this
product, please read this owner’s manual carefully and retain it
for future reference. Should the unit require maintenance, contact
an authorized service center. Use of controls, adjustments, or the
performance of procedures other than those specified herein may
result in hazardous radiation exposure. To prevent direct exposure
to laser beam, do not try to open the enclosure.
REGULATORY INFORMATION: FCC Part 15
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to
correct the interference at his own expense.
•
A suitable conduit entries, knock-outs or glands shall be
provided in the cable entries of this product in the end user.
•
Caution: Danger of explosion if battery is incorrectly replaced.
Replaced only with the same or equivalent type recommended
by the manufacturer. Dispose of used batteries according to the
manufacturer’s instructions.
•
Holes in metal, through which insulated wires pass, shall
have smooth well rounded surfaces or shall be provided with
brushings.
To disconnect power from mains, pull out the mains cord plug.
When installing the product, ensure that the plug is easily
accessible.
LG Electronics hereby declares that this/these
product(s) is/are in compliance with the essential
requirements and other relevant provisions of
Directive 2004/108/EC, 2006/95/EC, and 2011/65/
EU.
Contact office for compliance of this product :
LG Electronics Inc.
EU Representative, Krijgsman 1,
1186 DM Amstelveen, The Netherlands
Safety Information
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is
attached to a product it means the product is
covered by the European Directive 2002/96/EC.
3. The correct disposal of your old appliance will help
prevent potential negative consequences for the
environment and human health.
4. For more detailed information about disposal of
your old appliance, please contact your city office,
waste disposal service or the shop where you
purchased the product.
EEE Compliance with Directive. (for Turkey only)
Safety way to remove the battery or the battery from the
equipment:
Remove the old battery or battery pack, follow the steps in
reverse order than the assembly. To prevent contamination of the
environment and bring on possible threat to human and animal
health, the old battery or the battery put it in the appropriate
container at designated collection points. Do not dispose of
batteries or battery together with other waste. It is recommended
that you use local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to excessive heat
such as sunshine, fire or the lile.
Disposal of waste batteries/accumulators
1. When this crossed-out wheeled bin symbol
is attached to batteries/accumulators of Your
product it means they are covered by European
Directive 2006/66/EC.
IMPORTANT SAFETY
INSTRUCTIONS
1
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or groundingtype plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
2. This symbol may be combined with chemical
symbols for mercury(Hg), cadmium(Cd) or lead(Pb)
if the battery Contains more that 0.0005% of
mercury, 0.002% of cadmium or 0.004% of lead.
3. All batteries/accumulators should be disposed
separately from the municipal waste stream via
designated collection facilities appointed by the
government or the local authorities.
4. The correct disposal of Your old batteries/
accumulators will help to prevent potential
negative consequences for the environment,
animal and human health.
5. For more detailed information about disposal of
Your old batteries/accumulators, please contact
Your city office, waste disposal service or the shop
where You purchased the product.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
Safety Information
2. All electrical and electronic products should
be disposed of separately from the municipal
waste stream via designated collection facilities
appointed by the government or the local
authorities.
3
4
Safety Information
Safety warnings and Cautions
1
Safety Information
The following are warnings and cautions for the safety of the users and for the prevention of any property damage. Please read the following
carefully.
WARNING
•
Turn off the system before installation. Do not plug in several electric devices to the same outlet.
--
•
-•
This may cause fire, over heating or electric shock.
When the system’s battery is depleted, replace it with the same or equivalent type of battery specified by the manufacturer. Depleted
batteries should be discarded according to the manufacturer’s instructions.
--
•
This may cause system breakdown or serious injury.
The power outlet must be placed on the ground, and the voltage range must be within 10 % of the voltage rate. Do not use the same
outlet with a hair dryer, iron, refrigerator, or any heating appliances.
--
•
This may cause fire.
Install the system on a plain surface with sufficient air ventilation. Do not place the system on an elevated surface.
--
•
This may cause fire, electric shock, or injury.
Install the system in a cool place without direct sunlight and always maintain room temperature. Avoid candlelight and heat generating
devices such as heaters. Keep the system away from places where many people pass.
--
•
This may cause fire or electric shock.
Keep a distance of at least 15 cm between the back of the system and the wall for the cables connected to the system otherwise, they may
be bent, damaged, or cut.
--
•
This may cause fire, electric shock, or serious injury.
Check for any danger signs such as a moist floor, a loosened or damaged power cable, or an unstable surface. If you encounter any
problems, ask your dealer for assistance.
--
•
This may cause fire or electric shock.
Do not attempt to disassemble, repair, or modify the system on your own. It is extremely dangerous due to the high voltage running
through the system.
--
•
This can cause fire or electric shock.
When pulling the power cable from the plug, do so gently. Do not touch the plug with wet hands and avoid using the plug if the holes in
the outlet are too loose.
--
•
This may damage the surface of the system and can cause a system breakdown or electric shock.
Avoid any place with moisture, dust, or soot.
--
•
This may cause fire.
Clean the dust around the system on a regular basis. When cleaning the system, always use a dry cloth. Do not use a wet cloth or other
organic solvents.
--
•
If liquid is poured onto the system, it can cause a system breakdown or fire.
Prevent the power cable from being severely bent or having pressure exerted on it by a heavy object.
--
•
This may cause heating, fire, or electric shock.
Do not place any liquid container on the system, such as water, coffee, or other beverage.
This may cause an explosion.
If the system’s HDD exceeds its life span, you may not be able to recover any data stored inside the HDD. If the video on the system screen
appears ‘damaged’ while playing a recording stored inside the system’s HDD, it must be replaced with a new one. Ask for an engineer’s
assistance for HDD replacement from your dealer.
--
LG Electronics is not responsible for deleted data caused by user mishandling.
Safety Information
5
CAUTION
Please beware of the following precautions before installing the DVR.
Avoid positioning the product in any place where the unit may come into contact with moisture, dust, or soot.
•
Avoid placing in direct sunlight or near heating appliances.
•
Keep the product away from electric sparks or magnetic substances.
•
Do not place any conductive material through the ventilation grills.
•
Keep the system turned off before installation.
•
Ensure enough space is left for cable connections.
•
Place the system on a solid surface with sufficient air ventilation. Avoid any surface that vibrates.
•
Placing the system near electronic devices such as a radio or a TV may cause the product to breakdown.
•
Do not disassemble the product without seeking assistance from LG Electronics.
•
Do not place any heavy object on the system.
•
Prevent any substances from being inserted into the system.
--
•
Install the system in a place with sufficient air ventilation.
--
•
This may cause system breakdown.
Install the system on a stable, level surface.
--
•
Do not install the system in a place with magnetic objects, electric frequencies, or vibration.
Do not place any heavy object on the system.
--
•
Keep at least 15 cm distance between the back of the system and the wall, and at least 5 cm distance between the side of the system
and the wall.
Do not install the system in a place with high magnetic, electric wave, or wireless devices such as a radio or a TV.
--
•
This may cause system breakdown.
The system may not operate properly.
Install the system in a place with appropriate moisture and temperature levels.
--
Avoid installing the system in a place with high (over 40 °C) or low (under 0 °C) temperature.
•
The system can be damaged from a strong impact or vibration. Avoid throwing objects within the vicinity of the system.
•
Avoid direct sunlight or any heating appliances.
--
•
Recommended operating temperature is over 0 °C (32 °F).
Ventilate the air inside the system operation room, and tighten the system cover firmly.
--
System breakdown may be caused by an inappropriate environment. It is recommended to use AVR (Automatic Voltage Regulator)
for a stable power supply. It is recommended to coil the core-ferrite around the connector of the system to avoid electromagnetic
interference.
•
The outlet must be placed on the ground.
•
If there is strange sound or smell, unplug the power cable immediately and contact the service center.
--
•
•
This may cause fire or electric shock.
In order to maintain stable system performance, have your system checked regularly by the service center.
--
LG Electronics is not held responsible for system breakdown caused by user mishandling.
--
There is a risk of explosion if a battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.
Do not overturn the product during use.
1
Safety Information
•
6
Contents
Contents
1
20
Main Monitor Screen
21
Selecting the Main Monitor screen mode
22
Selecting the Spot Monitor screen mode
22
PTZ Camera Control
23
Using the Digital Zoom function
24
Viewing System Information
24
Viewing the System Log List
25
Export the recorded data
Safety Information
26
Configuration menu
27
System settings
3
27Properties
IMPORTANT SAFETY INSTRUCTIONS
2
27
TCP/IP v4
27
TCP/IP v6
28Network
Preparation
28
8Introduction
29NTP
8Features
29Controller
8Accessories
29Update
9
Front Panel
30Backup
11
Rear Panel
12
Remote Control
31
Device settings
31Camera
31PTZ
32
3
Network Streaming
29Date/Time
IP Camera
33ATM/POS
Installation
13Connections
13Precautions
33Storage
34
Display settings
34OSD
34Sequence
34
Channel Composition
34
Video Adjustment
13
Basic Connection Overview
14
Connecting Camera
14
Connecting Display device
35
14
Connecting Audio device
35Schedule
15
Connecting USB device
35
15
Connecting E-SATA device
15
Connecting ATM/POS
36
16
Connecting Network
36Normal
16
Connecting RS-485 device
37Sensor
17
Connecting Alarm Input and Alarm Output
37Motion
18
HDD INSTALLATION
Record settings
To Set the Recording Schedule for a Typical
Day of the Week
Copying the Recording Schedule
37Text
38Instant/Panic
18
Note for Hard Disk Drive
18
Installing the Hard Disk Drive
38
19
Replacing the Hard Disk Drive
38Sensor
19
Recommended HDD
38Motion
19
System Operation
19
System Shutdown
20
General Explanation of the Live
Screen on the Main Monitor
Event settings
39
ATM/POS Data Format
39
Event Popup
40Notification
40Mail
40Emergency
Contents
41SNMP
67
Emergency Agent Program
41Output
68
Export Viewer Program
42Buzzer
69
Web Viewer Program
42
42
1
User settings
Group Authority
43User
4
Operation
44
Instant Recording
44
Panic Recording
45
Instant Playback
45
Search and Playback
6
Troubleshooting
Appendix
74
74
Recommended USB Memory list
74
Recommended External Device list
74
Recommended CD/DVD Media list
45
Event Search
75
Supported function list for device
46
Bookmark Search
75
Supported PTZ Camera list
46
ATM/POS Search
75
Supported IP Camera Audio/Video Codec
47
Export Search
47
Smart Search
76
Time zones
77
Factory Default Configuration Settings
83
Recording Time Table (250GB HDD)
86Specifications
5
3
Recommended Devices
Date and Time Search
Functions Available During Playback
2
7
45
48
7
4
5
6
LG Network Client Program
49Introduction
49
Recommended PC Requirements
49
Before install the program
49
Getting Started
49
Install the LG Network Client on your PC
49
Starting the LG Network Client
50
LG Network Client Overview
52
Operation and settings
52
Register the Site Name or Group Name
52
Connect to the DVR/NVR
53
Connect the group device
53
Disconnect the site name or group name
53
Export the connection list
53
Import the connection list
53
Using the Live function
56
Using the Search function
58
Using the Remote Setup function
65
Using the Export function
66
Using the E-Map function
67
Using the Multiple Window function
67
Additional Programs
7
8
Preparation
2
Preparation
2
Preparation
Introduction
Model LE5016D (16 Channel) is used for the description, operation
and details provided in this operating guide.
Features
•
Automatic backup by schedule.
•
Image authentication (Watermark).
•
Three USB 2.0 ports for backup interface.
•
Setup configuration export/import with USB memory stick.
•
Easy system S/W update with USB memory stick.
•
Clients S/W can manage max 300 DVR servers.
•
Max five clients can access one DVR server simultaneously.
•
Network bandwidth throttle.
•
Stable embedded Linux operating system.
•
Journal filing system for HDD file recovery following power
recovery.
•
Remote alarm notification via client software or E-mail.
•
Small file sizes with H.264 compression.
•
Time and date sync from NTP server.
•
Internal storage expandable to 4TB. (Expandable if new high
capacity HDD is launched)
•
Daylight saving mode.
•
NTSC and PAL selectable video format.
•
Covert camera protection.
•
Full real-time recording.
•
Support Gigabit Ethernet.
•
E-SATA storage interface.
•
Two-way audio.
•
Text Input for ATM and POS device.
•
User management (User level control).
•
PTZ Control.
NTSC
PAL
•
NTSC
D1(704x480), Half D1(704x240), CIF(352x240)
PAL
D1(704x576), Half D1(704x288), CIF(352x288)
Dome camera telemetry control (Dome OSD control).
Accessories
Software
Install CD
Screws
Mouse
Rack Mount
Bracket
Remote
Control
Power Plug
AAA type
batteries
SATA cable(s)
5 step quality level (Highest, High, Standard, Low, Lowest).
Optical mouse, Full function IR remote controller
Powerful multiplex function.
--
•
--
Automatically adjust a bandwidth according to network
speed status of unit.
Easy operation using various user interface & user friendly GUI.
--
•
Up to 400 IPS @ 704x576, LE5016 Series
Up to 200 IPS @ 704x576, LE5008 Series
Up to 400 IPS @ 352x288, LE4016 Series
Up to 200 IPS @ 352x288, LE4008 Series
Various recording resolutions and quality levels.
-•
Up to 480 IPS @ 704x480, LE5016 Series
Up to 240 IPS @ 704x480, LE5008 Series
Up to 480 IPS @ 352x240, LE4016 Series
Up to 240 IPS @ 352x240, LE4008 Series
--
Simultaneous live display, recording, playback, network
transmission, back-up.
Various search function.
--
Date/time search (calendar search), event search, bookmark
search.
•
Event data protection by event partition recording.
•
Pre-alarm recording (Up to 1 minute).
•
Motion event recording and preview test function of motion
sensitivity.
•
Recording image rate & quality adjustment per individual
camera.
•
Powerful record scheduling.
•
Instant playback in live mode.
•
Perfect audio/video synchronization.
Preparation
9
Front Panel
Front of the LE5016/LE4016 series
a
b
c
d
e
f
gh i j
k
2
Preparation
l
m
n
op
q or
s
t
Front of the LE5008/LE4008 series
a
b
a
l
c
m
d
n
e
f
op
gh i j
q or
k
s
t
1 (Power): Turns DVR on or off. Press and hold for more than 2 seconds to turn on or off.
bIndicator
•
NET: Lights when the network is connected.
•
HDD: Blinks when the HDD is accessed.
•
ALARM: Lights when the alarm out is in progress.
•
BACK UP: Lights when the data back up is in progress.
c
Remote Sensor: Point the remote control here.
d
SHIFT button: If you use the Sub-function of the channel button, the button is activated.
e
Channel Buttons: You can input a number with channel buttons. You can also use the channel buttons for sub-function with SHIFT
button (11 to 16 buttons of 8 channel DVR are used for sub-function without SHIFT button.).
•
The LED in the button indicates the status as follows:
--
Off: The current status is for live mode.
--
Red: Recording mode.
--
Blinks when an event occurs.
10
Preparation
•
2
Sub-functions
Preparation
Button number
Function
Description
3/4
FOCUS / FOCUS +
5
OSD
Accesses or removes the System Control Bar (OSD).
6
INFO
Displays or removes system information.
7/8
IRIS - / IRIS +
9
ALM.OFF
10/0
LOG
Displays or removes the System Log List.
11
SET
Registers the PTZ camera’s preset position.
12
CLEAR
Deletes a memorized preset position.
13
COPY
Copies the recording data to an external device.
14
MARK
Sets the mark point for recording search.
15
MOVE
Moves the camera to the preset position.
16
TOUR
Tours all registered preset positions in the camera.
Adjusts focus position.
Adjust iris position.
Cancels alarm activation and returns the system to the condition before the alarm was
activated.
f
PTZ: Switches this unit to PTZ mode to control the PTZ camera connected.
g
Arrow Buttons
•
wsad: Select or move between the menu options.
•
ENTER: Confirms menu selections.
h
LOCK: Displays the lock menu to change the user type or disable the system operation.
i
SETUP/ESC: Displays the setup menu or cancels operation on the setup menus.
j
SEARCH: Displays the search menu.
k
Shuttle Ring: Fast forward or reverse picture search when the dial is rotated.
l
Playback Control Buttons
•
M: Pauses playback.
•
c, C/aM: Searches the recorded images in reverse or skips the recorded images.
•
ad: Playback or reverse playback of recorded images.
•
v, V/Md: Forward searches the recorded images or skips the recorded images.
•
Z: Stops playback.
m
Disc Tray: Insert a disc here.
n
OPEN: Opens or closes the disc tray.
o
ZOOM + / -: Zooms in/out on playback window.
p
MAIN: Displays or removes the screen setup menu for MAIN monitor.
q
SPOT: Displays or removes the screen setup menu for SPOT monitor.
r
REC: Starts or stops instant recording.
s
JOG Dial: Allows a forward or reverse frame search. In pause mode, plays recorded images frame by frame through rotation. Increases
or decreases the options value.
t
USB Port: Connects an external USB device for backup or playback.
Preparation
11
Rear Panel
Rear of the LE5016/LE4016 series
a
bc
2
Preparation
d e fghi j
k
l
mn
o
Rear of the LE5008/LE4008 series
a
d
e
f
g
h
pq
b nkp
i
j
l m
c
o
q
a
VIDEO INPUT: Connect the camera’s video output to these BNC connectors.
b
LOOP OUT: The signal from VIDEO INPUT connector is looped out to this connector.
c
Power Cord Inlet (AC IN): Connect the power plug.
d
RS-485 Terminals: Connect RS-485 compatible cameras.
e
RELAY-OUT Terminals: Output terminals for alarm (relay) signal.
f
CONSOLE: Used to connect to a host device equipped with RS-232C connector (such as a personal computer).
g
SPOT-OUT (BNC Type Connector): Connect to spot monitor or display device.
h
MAIN-OUT (BNC Type Connector): Connect to main monitor or display device.
i
ATM/POS: Used to connect to a ATM/POS device.
j
VGA: Connect a VGA monitor.
k
AUDIO OUT 1: Connect to an active speaker with a built-in amplifier.
l
LAN Port: Connect the ethernet 10/100/1000 Mbps network cable for controlling this unit via a PC network.
m
USB Ports: Connect an optional extension USB device.
n
AUDIO INPUT: Connect the audio output of an external device.
o
ALARM-IN Terminals: Input terminals for alarm (relay) signal.
p
AUDIO OUT 2: Connect to an active speaker with a built-in amplifier. Two-way audio output.
q
E-SATA: Connect the external SATA device.
12
Preparation
Remote Control
Button
POWER (1)
LOCK
Description
Turns DVR on or off.
Displays the lock menu to change user type or disable system operation.
2
ID
Preparation
MAIN
Displays or removes the screen setup menu for MAIN monitor.
SPOT
Displays or removes the screen setup menu for SPOT monitor.
ALM.OFF
OSD
SETUP/ESC
wsad
Set the appropriate DVR system ID to operate via the IR Remote Controller when
using the multiple DVR. Press the ID button then press the number button within
2 seconds to select the system ID of the DVR. If you set the system ID to “0”, you
can control multiple DVR at the same time.
Cancels alarm activation and returns the system to the condition before the alarm
was activated.
Accesses or removes the system control bar.
Displays the setup menu or cancels operation of the setup menu.
Selects or moves between the menu options.
ENTER
Confirms menu selections.
COPY
Copies the recording data to an external device.
SEARCH
MARK
Displays the search menu.
Sets the mark point for recording search. You can set the mark point during the
single or multi channel playback of recorded data.
PAUSE (M)
Pauses playback.
STOP (Z)
Stops playback.
REC (X)
Starts or stops recording.
c, C/aM
ad
Searches the recorded images in reverse or skips the recorded images.
Playback or reverse playback of recorded images.
v, V/Md
Forward searches the recorded images or skips the recorded images.
Number Buttons
To select the PTZ preset number, ID, or channel.
INFO
Displays or removes the system information window.
LOG
Displays or removes the System Log List window.
PTZ
Switches this unit to PTZ mode to control the connected PTZ camera.
TOUR
Tours all registered preset positions in the camera.
ZOOM + / -
Zooms in/out on the playback window.
If you click the [ZOOM +] button, the digital zoom function is activated in live one
channel with full screen mode or one channel playback with full screen mode. If
you click [ZOOM -] button on the digital zoom mode, the digital zoom function is
deactivated and previous mode screen is displayed.
FOCUS + / -
Adjusts the focus of a camera.
IRIS + / SET
Adjusts the iris of a camera.
Registers the PTZ camera’s preset positions.
CLEAR
Deletes a memorized preset position.
MOVE
Moves the camera to the preset position.
F1
This button is not available.
Installation
13
3
Installation
Connections
Precautions
3
Depending on the camera and other equipment there are various ways to connect the unit. Please refer to the camera manual or manuals
for other devices as necessary for additional connection information.
•
Be sure to switch off the camera before installation and connection.
Basic Connection Overview
Connect the coaxial-type cameras
Connect the Monitor, DVR, VCR, or others.
Connect ATM/POS unit.
For audio amplifier
Connect power
cord.
Connect the external SATA device.
Connect the
alarm (relay)
Connect alarm sensors.
Connect audio (line input)
Connect an external USB device for
backup or playback.
Connect a mouse device.
Connect PTZ
cameras, DVRs
or keypads
(optional).
Connect network cable for client control or IP camera input.
Connect VGA monitor.
Connect BNC type monitor.
Connect BNC type spot monitor.
Installation
•
14
Installation
Connecting Camera
VGA Monitor connection
Connect the video output of your camera to the unit, using a
standard 75 Ω video coaxial cable with BNC connector.
Connect the VGA jacks on the rear of the unit to the corresponding
input jacks on the TV or monitor using the VGA cable.
Camera connection
VGA Monitor connection
3
Installation
Connecting Display device
This unit can be outputted simultaneously from the VGA and MAIN
OUT jack. The video signal connection between the DVR and the
monitor.
CCTV(Composite Video Type) Monitor connection
SPOT Monitor connection
Connect the unit to the SPOT monitor via 75 Ω video coaxial cables
with BNC connector.
SPOT Monitor connection
Connect the unit to the CCTV monitor via 75 Ω video coaxial cables
with BNC connector.
CCTV Monitor connection
Connecting Audio device
Connect the AUDIO OUT jacks on the unit to the mono audio in
jacks on your audio device.
Microphone and Speaker connection
Installation
Connecting USB device
USB device connection
15
Connecting E-SATA device
You can use E-SATA storage for data back-up or recording.
E-SATA device connection
3
Installation
Connecting ATM/POS
Connect the ATM/POS unit to the ATM/POS port.
ATM/POS device connection
USB Memory device
Insert the memory device into the USB port. The system
automatically recognizes the device. Using a USB memory device
the system software can be easily upgraded.
USB External device
Connect the external device to the USB port.
(Example: External HDD or other external storage.)
Mouse
Connect the mouse for function control of the unit.
16
Installation
NOTE
•
The following device has been tested and compatibility is
ensured. When you use the multiple ATM/POS device use the
recommended device.
--
•
NOTE
AVE Products
››
VSI-PRO: Video serial interface
››
Regcom: RS-485 networker
››
Hydra: RS-485 to RS-232 converter
This unit can be supported IPv4 and IPv6 network.
Connecting RS-485 device
This DVR has two data terminals. Use this port to connect PTZ
cameras, DVRs or keypads (optional).
RS-485 Terminal
The installation and connection work should be done by
qualified service personnel or system installers and should
conform to all local codes.
3
D - (DATA -)
Data Transmission/Reception
D + (DATA +)
Data Transmission/Reception
GND
Installation
Connecting Network
You can control and monitor the system via network. With
the remote control (monitoring), you can change the system
configuration or monitors the image via network. After the
installation, check the network settings for the remote control and
monitoring work.
Description
Shield
Connecting the PTZ device
Connecting the PTZ serial communication lines to the
RS-485 terminal.
PTZ device connection
Network connection
Router
Broadband
Service
5~7 mm
LAN connection
Connect the LAN port to an available 10/100/1000 base-T port with
a straight ethernet cable (not supplied). The NET indicator on the
front panel will be lit.
PTZ units
(RS-485 type)
PTZ units
(RS-485 type)
IP Camera connection
Connect the IP camera. After the installation, check the IP camera
settings on the setup menu.
NOTE
•
The DVR can automatically obtain and configure the network
interface via DHCP.
When connecting lines, connect the “D -” of the DVR to “RX -”
of the PTZ unit and “D +” of the DVR to “RX +” of the PTZ unit
correctly.
•
Recommended initial data are 9600 Baud Rate, 8 Data bits,
1 Stop bit and No parity.
Manually configure network
•
When connecting PTZ cameras to DVRs it is necessary to set
the setup menu for this unit according to the RS-485 settings
of the camera and DVRs.
Automatic network configuration
The DVR may be manually configured by assigning an IP address,
subnet mask, gateway and DNS.
Installation
Connecting LKD1000 controller
Connect the LKD1000 controller to control the DVR. (Refer to the
manuals of the LKD1000 controller for more details.) The LKD1000
controller has to be connected to the 2 (DATA 2) port as shown
illustration. If you connect the LKD1000 controller to the 1 (DATA 1)
port, the LKD1000 controller will not be activated.
17
Sensor input connection
LKD1000 controller connection
3
Installation
TX-
TX+
Alarm sensor
LKD1000 Controller
NOTE
Do not connect a PTZ camera and LKD1000 controller at the same
time to the D1 or D2 port. It may cause a malfunction.
Connecting Alarm Input and Alarm
Output
Alarm terminals are used to connect the alarm devices such as
sensors, door switches, etc.
Alarm Input
You can connect up to 16 alarm sensors (LE5008/LE4008: 8 alarm
sensors). Each alarm sensor should be connected with G (GND).
The signal state is adjustable to N/O (Normal Open) or N/C (Normal
Close) through the setup menu.
Alarm sensor
Terminal No.
Description
1
Sensor Input 1
2
Sensor Input 2
3
Sensor Input 3
4
Sensor Input 4
G
Ground
5
Sensor Input 5
6
Sensor Input 6
7
Sensor Input 7
8
Sensor Input 8
G
Ground
9
Sensor Input 9
10
Sensor Input 10
11
Sensor Input 11
12
Sensor Input 12
G
Ground
13
Sensor Input 13
14
Sensor Input 14
15
Sensor Input 15
16
Sensor Input 16
G
Ground
18
Installation
Alarm Output
Connect the alarm device to the alarm output. Alarm signal output
at an event occurrence.
HDD INSTALLATION
Note for Hard Disk Drive
Alarm output connection
The internal hard disk drive (HDD) is a fragile piece of equipment.
Please follow the guidelines below when using the DVR to protect
against possible HDD failure. We recommend that you back up your
important recordings onto an external backup device in order to
prevent accidental loss.
Make sure that the power is turned OFF when attaching or
removing the HDD.
3
Installation
Alarm device
Terminal No.
Alarm device
•
Do not move the DVR while the power is on.
•
Do not use the DVR in excessively hot or humid places, or in
places that may be subject to sudden changes in temperature.
Sudden changes in temperature can cause condensation to
form inside the DVR. This can be a cause of HDD failure.
•
While the DVR is switched on, do not unplug from the wall
socket or switch the electricity off from the breaker switch.
•
If there’s a power failure while the DVR is on, some data on the
HDD may be lost.
•
Do not drop the HDD. Also do not put the metallic object such
as coins or screwdrivers into the HDD tray.
•
When a power failure occurs during recording, avoid adding,
replacing or transporting the HDD as the recorded data may be
erased. In this case, turn the power back on to boot up the unit
normally with the HDD that was being used at the time of the
power failure attached. Then add, replace, or transport the HDD.
•
The HDD is very delicate. Handle the HDD with care and follow
the precautions below because even a tiny shock may damage
the internal components of the HDD.
Description
G
Ground
1
Alarm Output 1
2
Alarm Output 2
3
Alarm Output 3
4
Alarm Output 4
NOTE
The internal switching relays are rated for 0.3 A at 125 V AC or 1 A
at 30 V DC. If the electric current is higher than that the unit can
be damaged.
•
--
Do not place the HDD on the desk or table directly. Put a
thick cushion under the HDD because even a small shock
may damage the internal components of the HDD.
--
Do not use an electric screwdriver. Vibrations and shocks
caused by an electric screwdriver may damage the internal
components of the HDD.
--
When replacing the HDD, do not knock the HDD with other
components such as another HDD and the HDD tray.
--
Do not knock the HDD with tools such as a driver when
replacing the HDD.
Protect the hard disk drives from static electricity.
Installing the Hard Disk Drive
You can install up to 4 HDDs.
Improper installation or setup may disturb HDD recognition or
normal product operation. So you should consult with an expert
from the store where the product was purchased.
1. Detach the top case by sliding it after removing the screws.
2. Remove the screws and detach the hard disk mounting brackets
from the unit.
3. Attach the HDD onto the hard disk mounting brackets with four
screws.
4. Attach the hard disk mounting brackets with the screws.
5. Connect the HDD power cable to the HDD.
6. Connect the SATA cable to the HDD.
Installation
7. Connect the SATA cable to the SATA connector on the main
board.
19
System Operation
8. Assemble the top case.
9. Fix the screws.
10. When you turn the power of the unit on, the new HDD is
detected and formatted automatically.
1. Turn on the unit. System booting will commence. The LG logo
image will be displayed on the main monitor during the system
booting.
Replacing the Hard Disk Drive
2. When the booting is complet the live window will be displayed.
Click the LOCK icon on the system control bar or press the LOCK
button on the remote control to display the log-in window.
Turn the power of the unit off and detach the power plug from the
outlet.
1. Follow steps 1 to 2 described in “Installing the Hard Disk Drive”.
2. Remove the connector from the HDD.
4. Remove the HDD from the hard disk mounting bracket.
5. Install the new HDD.
6. After replacing the hard disk drive, insert the power plug into
the outlet and turn the power of the unit on. The new HDD is
detected and formatted automatically.
4. Enter the password by using the virtual keyboard. (Note that the
default administrator password is “000000”.)
5. Press the LOCK button or click the [OK] icon.
You can see the live screen and operate the system.
NOTE
•
This DVR is based on a VGA monitor using OSD. We
recommend to using the VGA monitor with this unit. If you
use a composite monitor, the OSD quality may be low to read
it.
•
If the DVR is turned off accidently and then turned on again,
the DVR may take a long time to be rebooted.
NOTE
•
Make sure that each of the SATA cables is connected to the
connector housing through its holes.
•
Do not use an electric screwdriver to fix them.
Recommended HDD
The following HDD has been tested and compatibility is ensured.
When you attach multiple HDDs use the recommended HDDs.
NOTE
If you do not use the recommended HDD, the system may not be
operated normally.
Maker
RPM
Capacity Interface
Model No.
7,200
250 GB
SATA
7,200
500 GB
SATA
5,400
1 TB
SATA
ST31000424CS
Hitachi
5,700
1 TB
SATA
HCS5C1010CLA382
WD
5,000
2 TB
SATA
WD20EURS63S48Y0
Seagate
ST3250311SV
ST3500410SV
ST3500411SV
System Shutdown
1. First, you must stop playback and exit the setup menu. In
playback, press STOP.
2. Press and hold 1 (POWER) button until the beep sounds and
the logout window will be displayed.
3. Enter the password by using the virtual keyboard.
4. Press the LOCK button or click the [OK] icon. The system will
shutdown.
3
Installation
3. Remove the screws from the hard disk drive on the left/right
side of the hard disk mounting bracket.
3. Select a user name by using the mouse or arrow and the ENTER
button on the remote control or front panel. For the first time,
you can select the ADMINISTRATOR user name only. You can
register a new user with various access rights using the user
setup menu.
20
Installation
General Explanation of the Live
Screen on the Main Monitor
e Live Screen
Displays the current surveillance live screen.
f System Control Bar
Displays the current date and time.
Main Monitor Screen
ab c
d
e
f
Displays the setup menu.
Displays the search menu.
3
Installation
Displays the PTZ remote control window.
Displays the screen division selection
window for the main monitor.
Displays the screen division selection
window for the spot monitor.
a Channel Number
Displays the channel number.
b Channel Name
Displays the edited channel name.
Displays the lock menu to change the
user type or disable system operation.
Turns the alarm off.
Displays the system log list window.
NOTE
If you set the channel name to Korean or Japanese, you
should set the system language to Korean or Japanese to
display the channel name correctly.
c Selected Channel
Displays the selected channel with white box.
d Camera Status Icon
Displays the PTZ camera status.
Displays the input audio status.
Green “C” indicates continuous recording.
Green “I” indicates Instant recording.
Red “S” indicates sensor triggered recording.
Blue “M” indicates motion detection recording.
White “N” indicates the channel is not being recorded.
Violet “T” indicates text event recording.
Displays the system information window.
Pause playback.
Jump to the beginning of the current
data recorded on the same date.
Select the required scanning speed.
Starts instant playback in selected
recording channel. If the recorded data is
empty, a warning message is displayed.
Jump to the last minute of the current
data recorded on the same date.
Stop playback.
Display playback status.
Click this button to activate the digital
zoom function or to deactivate the
digital zoom function on digital zoom
mode.
Installation
You can capture and save the current
image in JPEG file format. You should
connect the external device to save the
capture image.
Selecting the Main Monitor screen mode
1. Playback the recorded data.
1. Press MAIN or click the
2. Pause the playback at a desired point
during playback.
3. Click this button. The device
selection window is displayed.
21
You can select the live screen mode to display a full, 4-split, 6-split,
8-split, 9-split or 16-split screens on the main monitor.
icon in the system control bar.
Screen mode select menu of main monitor is displayed on the
main monitor.
2. Select screen mode.
Selected Main Channel
4. Select a device and click [OK].
5. After saving the JPEG file, the
confirmation window is displayed.
Click [OK].
Channel Buttons
Click at a desired point to be marked
during playback. Up to 15 points can be
marked.
3
Installation
Display copy (export) menu.
NOTE
To display / remove the system control bar
Use OSD with the SHIFT button on the front panel or click the right
mouse button in live screen mode and then the system control
bar will be displayed or removed.
Screen split mode
Sequence mode
•
Channel Number: Press the 1 to 16 channel button to see
the current surveillance images in selected live screens on
the main monitor.
•
Full Screen Mode: When you see the selected channel on
the full screen.
•
4, 9, 16, 1+5 and 1+7 Split Mode: Displays selected split
screens on the main monitor.
•
Sequence: View all channels in sequence. You cannot use
sequence mode with the 16 split (LE5008/LE4008 series: 8
split).
3. Select [OK] and press ENTER to confirm your selection.
NOTE
To display the screen you desire to watch in full screen mode,
double click the desired channel.
22
Installation
Selecting the Spot Monitor screen mode
PTZ Camera Control
You can select the live screen mode to full or 4-split screens on the
spot monitor.
You can control the cameras connected via the data port of RS-485
terminal or Network. You must set the configuration between the
PTZ camera and the DVR.
1. Press SPOT or Click the
icon in the system control bar.
Screen mode select menu of spot monitor is displayed on the
main monitor.
2. Select screen mode.
Selected Spot Channel
Channel Buttons
1. Select the PTZ camera channel on the main monitor you want
to control.
2. Press PTZ or Click the
icon in the system control bar.
Virtual PTZ remote control is displayed on the main monitor.
3. Use each item to control the PTZ camera.
Button
Function
Remove the PTZ virtual remote
control.
3
Use to pan/tilt the camera.
Installation
Confirm the preset position.
Select the Pan/Tilt/Zoom
speed.
To adjust the camera zoom.
To manually adjust the focus of
a camera.
To manually adjust the iris of a
camera.
Displays the Selected Preset
number.
Screen split mode
Sequence mode
•
Channel Number: Press the 1 to 16 channel button to see
the current surveillance image on the spot monitor.
•
Full Screen Mode: When you see the selected channel on
the full screen.
•
4 Split Mode: Displays 4 split screens on the spot monitor.
•
Sequence: Views the all channels in sequence.
To input the preset number.
To register preset positions.
To move the camera to the
preset position.
To delete a memorized preset
position.
3. Select [OK] and press ENTER to confirm your selection.
To start a preset tour.
To displays the setup menu of
the PTZ camera.
Preset Settings
Preset position is the function to register camera monitoring
positions (preset positions) associated with position numbers.
By entering the position numbers, you can move cameras to the
preset positions.
NOTE
To activate this function, you need to register the preset positions
of the PTZ cameras.
Installation
To Register Preset Positions
Setup for PTZ Cameras
1. Move the camera to a point you wish by using the
,
,
,
buttons.
You can adapt the camera to your requirements by setting up the
respective items in menus.
3. Select the preset number you wish to register.
1. Click the
icon.
The setup menu appears in the selected window of the main
monitor.
4. Press ENTER or click the
2.Use
2. Press SET or click the
23
icon.
icon.
,
The position and its number are memorized.
Refer to the manuals of the PTZ camera for more details.
•
Some PTZ cameras may not operated correctly with this unit.
•
You cannot control the other functions when the PTZ virtual
remote control is displayed.
icon.
2. Use number buttons to enter the memorized preset position’s
icon. The
camera moves to the preset position and the picture of the
camera in that position appears on the monitor.
Using the Digital Zoom function
You can enlarge the current screen 2 times using the digital zoom
function on the live one channel with full screen mode or one
channel playback with full screen mode.
1. Click the [ZOOM +] button on the live one channel with full
screen mode or one channel playback with full screen mode.
2. You can use the zoom screen as following.
To Clear the Preset Position
You can clear a memorized preset position.
icon.
This function may not be available depending on PTZ cameras.
To Tour The Preset Positions
You can tour all preset positions.
1. Press the TOUR button or Click the
icon.
All registered preset positions in the camera will be selected
and the camera position image will be switched on the active
monitor.
•
You can move the zoom screen by using the mouse. Drag &
drop a point to the specific point to move the zoom screen.
NOTE
icon to clear the
NOTE
You can move the position of the zoom screen by using the
w/s/a/d buttons.
3. Click the [ZOOM -] button to exit.
2. Use number buttons to enter the memorized preset index
preset positions.
•
The zoom function is deactivated when below case.
•
When double click the left mouse button.
•
Press the specific channel or function button which front
panel of the unit.
•
Press the STOP button during the playback.
3
Installation
The following function is available only with cameras provided with
the preset function. The preset function makes the combination
camera move to the programmed preset position. It is necessary to
program preset positions for the combination camera beforehand.
2. You can stop the tour by pressing the TOUR
button or clicking the
icon.
, and
•
Changing to a Picture in a Preset Position
number then press ENTER or Click the
,
NOTE
Preset numbers from 0 to 255 are available on this unit but the
actual preset range differs depending on PTZ cameras.
1. Press the CLEAR button or Click the
,
buttons to set the options.
NOTE
index number then press ENTER or click the
,
,
5. Repeat steps 1 to 4 to add additional positions.
1. Press the MOVE button or click the
,
24
Installation
Viewing System Information
To view system information:
Refer to the following system log list.
No.
Log Message
1
Power On
2
Power Off
3
Login (Remote)
4
Logout (Remote)
5
Login (Local)
6
Logout (Local)
3
7
Configuration Changed
Installation
1. Press the INFO button or click the
icon in the system
control bar. The system information window is displayed on the
main monitor.
NOTE
8
Configuration Imported
9
Factory Default Set
10
Power Recovery
11
Backup Started
12
Backup Finished
13
Backup Failed
14
Export Started
15
Export Finished
16
Export Failed
17
S/W Updated
18
System Fan Failure
19
HDD Damaged
20
HDD Added
21
HDD Deleted
22
HDD Formatted
23
HDD Changed
•
Refresh: Press this button to update the system information.
•
HDD: This button is displayed when you change the format
of the storage by using the [Device>Storage>E-SATA
Recording Support] option of the setup menu. Press this
button to display the detail information of the HDD.
2. Press the INFO button or click the [Exit] button to exit the
window.
NOTE
If you set the DVR name to Korean or Japanese, you should set the
system language to Korean or Japanese to display the DVR name
correctly.
Viewing the System Log List
To view the system log list:
1. Press the LOG button or click the
icon in the system
control bar. The system log list window is displayed on the main
monitor.
2.Use a/d to see the previous or next log list.
3. Press the LOG button or click the [Exit] button to exit the
window.
Installation
Export the recorded data
NOTE
This unit can manually copy recorded images and audio from builtin HDD to the external recording devices.
•
Check the export device before you proceed.
1. Press COPY or click the
•
You can also use the COPY button on the front panel for
export function.
•
You can export the recorded data only in the live mode.
•
If you use the external device, the external device has to be
formatted on this unit.
icon in the system control bar.
The export menu window appears.
25
1. Connect the external device to the USB port on the front
or the rear of the DVR.
2. Select the [Format] icon then press ENTER.
Confirm window is displayed after format is completed.
3. Select [OK] and press ENTER to close the window.
3.Use a/d to select a target device to export.
4. Press ENTER to confirm it.
5. Select the one of file format on the drop-down list of the [File
Format].
•
Native: The Native file is saved with the extention of “*.exp”.
The saved native file can playback using the Export Viewer
program.
•
AVI LG: To playing AVI LG file, you have to install the LG DVR
Codec. If you install the LG Network Client, do not need to
install the LG DVR Codec.
•
Check the size of the selected data and free space of the
external device. If the device does not have enough space,
create space on the device or erase the previously stored data.
•
Export can not be executed while the backup is in progress.
•
You can search the exported data with the supplied viewer
software.
•
When you export the recorded data, the video data, audio
data, the system log and event log data will also be exported.
•
When you export the recorded data the export viewer
program will also be exported in the [ExportViewer] folder of
the device. The exported data file name is made automatically
as the [Channel name_export date_export time.exp] type.
•
Do not remove the USB device while the export is in progress,
it may cause a malfunction.
•
The warning message appears for the conditions listed below.
AVI: If you select AVI file format, it can play on any media
player.
6. Select the channel number and press ENTER. Repeat this step to
select multi channels.
7. Set the [Start Date/Time] and [End Date/Time] to copy.
•
a/d/w/s: Moves to the options.
•
a/d: Sets the selected option.
•
ENTER: Selects option or confirms the setting.
8. Press COPY or click the [Export] icon to start exporting. The
exported data will be authorized by the unit before saving and
it can only be played back with the exclusive player.
--
When the start date/time and end date/time are the same
value.
--
When the start date/time is later than the end date/time.
--
The export media does not have enough space.
--
When you set the time for data that does not exist.
•
An external media has to be formatted on this unit to prevent
a malfunction.
•
DVD+RW and DVD-RW discs have to be initialized before
using.
•
The disc burning is carried out by a multi session mode.
3
Installation
2. Select [Target Device] then press ENTER.
•
26
Installation
Configuration menu
Setting the Menu Using the Front Panel Buttons or
Remote Control Buttons
Front Panel
The features and options of the DVR are configured through the
menu. The operations of this unit can be set via a menu displayed
on the main monitor. You can select and set the operational
conditions by using the buttons on the front panel and the remote
control or using a Mouse connected to the unit.
Only administrator-level users have permission to access the Setup
menu and configure the DVR.
Description
Use these buttons to select the
menu options or adjust the
options value.
Select the option or confirm the
setting.
First level
Return to the previous menu or
level.
Second level
3
Remote
Control
Third level
Installation
1. Press SETUP/ESC to display the setup menu.
2.Use w/s to select the desired menu item, then press ENTER to
display the submenu.
3.Use w/s to select the desired submenu item, then press
ENTER to display the setting options.
4.Use w/s to select the desired option then press ENTER to set
the value.
5.Use a/d to select the desired setting then press ENTER to
confirm your selection.
6. Press SETUP/ESC repeatedly to exit the Setup menu.
If the save message appears, select [OK] and press ENTER to
save the settings.
NOTE
•
When you operate the function menu by using the remote
control and front panel buttons, both buttons are operated in
the same way to control the function menu.
•
To use other functions of number buttons on the front panel
as shown below.
1. Press SHIFT. The button indicator turns red.
2. Select the function button you want.
•
All the operation explanations are based on using the remote
control.
Help menu
Using a mouse to set a menu
Use the left or right mouse buttons to set the menu.
Button
Left button
Right button
1. Click the
Function
•
Use to select a required item or
decrease the options value.
•
If you double click the button,
you can see the selected
channel on the full screen.
Use to increase the options value.
icon on the System control bar with the left
mouse button to display a setup menu.
2. Click the desired option with the left mouse button to display
the second or third level menu options.
3. Click the desired option with the left mouse button.
4. Set the selected options value.
5. Click the
icon to exit setup menu.
If the save message appears, click [OK] with the left mouse
button to save the settings.
Installation
System settings
27
TCP/IP v4
Properties
3
DVR Name: Enter the DVR name by using alphabetic letter and
numeric digit up to 21 characters.
NOTE
•
If you set the DVR name by Korean or Japanese, use the
system setting menu of the LG Network Client program.
•
If you set the DVR name to Korean or Japanese, you
should set the system language to Korean or Japanese to
display the DVR name correctly.
•
Language: Select a language for the setup menu and
information display.
•
Button Beep: Marks up to activate the button beep. The button
beep is activated when using the buttons.
•
Video format: Selects the video format to NTSC or PAL according
to your video system format. If you change the video format, the
HDD is formatted with selected video format. After the HDD has
been formatted, the confirmation message is displayed. Select
[OK] and press ENTER. The system will reboot.
DHCP: Select this option when a DHCP server is installed on the
network to allow IP address assignment. With this setting, the IP
address is assigned automatically.
•
IP Address: Enter the IP address.
•
Subnet Mask: Enter the subnet mask address.
•
Gateway: Enter the gateway address.
•
Primary DNS: Enter the Primary domain name server that
translates the hostnames into IP address.
•
Secondary DNS : Enter the Secondary DNS server address that
backups the Primary DNS.
TCP/IP v6
NOTE
All cameras must be disconnected before you change the
video format to prevent malfunction.
•
Configuration Import: Import the DVRs configuration data from
the USB memory stick.
•
Configuration Export: Export the configuration data from this
DVR to the USB memory stick.
•
Factory Default: You can reset the DVR to its original factory
settings. Some options cannot be reset (date, time, daylight
saving, time zone and user password settings).
•
Auto: Select this option to assign the IP address automatically.
•
IP Address: Enter the IP address.
•
Subnet Prefix Length: Enter the Subnet Prefix length.
An IPv6 prefix indicates the portion of the address used for
routing or for identifying an address range.
•
Gateway: Enter the gateway address.
•
Primary DNS: Enter the Primary domain name server that
translates the hostnames into IP address.
•
Secondary DNS : Enter the Secondary DNS server address that
backups the Primary DNS.
Installation
•
•
28
Installation
Network
When you want to change DDNS host name
If you want to change the registered host name to new one, follow
as shown below.
1. Enter a new host name in the [Host Name] option.
2. Press the [Update] button. The confirmation window will be
displayed to change your host name.
3. Click the [OK] button. When host name is properly changed, the
changed host name will be displayed in the [Registered Host]
option. If host name is not changed after updating, please check
network connection.
Network Streaming
3
Installation
•
TCP/IP Port No.: Enter the TCP/IP Port number. You can watch
the live surveillance image over the network with the PC Client
program. The factory default port for transmission of video and
audio data is 9001. However in some cases it is better to change
this port number for added flexibility or security. You can edit
this port between 1 025 and 65 535.
•
Web Server Port No.: Enter the Web Sever Port number. You can
watch the live surveillance image over the network with a web
browser. Typically the TCP port used by HTTP is 80. However in
some cases it is better to change this port number for added
flexibility or security. You can edit this port to 80 or between
1025 and 65 535.
•
Audio Port No.: Enter the Audio Port number. You can edit this
port between 1025 and 65 535.
•
Bandwidth Throttle: Enter the Bandwidth to adjust the data
traffic.
•
RTSP Port: Enter the RTSP Port number. You can edit this port
between 1025 and 65 535. Default Port number is 554.
•
DDNS Service: Marks up to activate the DDNS function.
This free service is very useful when combined with the LG
DDNS Server. It allows the user to connect the IP device using
the URL, rather than an IP Address. This also solves the problem
of having a dynamic IP address.
•
Host Name: Enter the host name you want to use.
You can not use the “www”, “mail”, “http”, “ftp”, “com”, “lg”, “lge”,
“lgddns”, “lgeddns”, “ddns” for host name.
•
Registered Host: The registered host name appears.
•
Update: Register the host name you typed in [Host Name] to LG
DDNS server.
How to register DDNS host name
With the DDNS function, you can easily use LG DVR.
When you use the DDNS function for the first time after you
purchased LG DVR
1. Displays the DVR setup menu.
2. Select [System] > [Network] option.
3. Marks up for the [DDNS Service] option.
4. Enter the host name in the [Host Name] option.
5. Press the [Update] button. If host registration is properly
completed, the host name will be displayed in the [Registered
Host] option. If the host name is not registered after updating,
please check network connection.
•
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution. Each group such as
“Ch1 to Ch8” and “Ch9 to Ch16” is set the same resolution.
•
Quality: Selects the recording picture quality.
•
Frame Rate: Selects the frame rate. The frame rate is the number
of transportable frames per second. According to resolution, the
frame rate is set automatically. If you wish to set manually, refer
to the below.
Resolution
NTSC
PAL
Frame Rate
352*240
1, 3, 5, 7.5, 10, 15
704*240
1, 3, 5, 7.5
704*480
1, 3
352*288
1, 3, 5, 6, 7.5, 12.5
704*288
1, 3, 5, 6
704*576
1, 3
Installation
Date/Time
29
NOTE
If the NTP option is not set to this system, there can be a
gap between the system time and actual time. Using NTP is
recommended.
Controller
3
Date: Select the current year, month and day.
•
Time: Select the current time.
•
Date Format: Select the date display format.
•
Time Format: Select the time display format.
•
Time Zone: Select the time zone in the area where the DVR is
installed.
•
Daylight Saving: Mark up when you use the daylight saving
function.
•
Daylight Saving Start: Select the Daylight Saving start time.
•
Daylight Saving End: Select the Daylight Saving end time.
NTP
Installation
•
•
IR Remote ID: Select the IR Remote ID for this unit. If you use
multi systems set the IR Remote ID for each DVR unit.
•
Remote Controller ID: Select the Remote Controller ID for this
unit. If you use multi systems, set the Remote Controller ID for
each DVR unit. You can control the DVR by using the LKD1000
controller. (For more details refer to the LKD1000 owner’s
manual.)
Update
The update feature allows you to upgrade DVR software and add/
upgrade PTZ protocols. In this case, the current DVR settings are not
deleted or replaced during the update process.
•
NTP: Marks up, if you want to synchronize the DVR’s date and
time with those of the time server called NTP. (Network Time
Protocol) Specify the NTP server’s name.
•
Server: For most cases select public. The DVR will obtain the
average time among 5 public servers (time.nist.gov, time-a.nist.
gov, time-b.nist.gov, ntp.nasa.gov, clock.isc.org).
•
Private Time Server: Enter the private time server’s IP address or
host name using the virtual keyboard.
1. Selects the update method.
•
Sync. Interval: You can set synchronized intervals with the NTP
time server to 1 day, 1 week, 1 month and 1 hour.
2. Selects the device included update file or enter the FTP server
name.
•
NTP Test: Select [NTP Test] to test the NTP server.
30
Installation
NOTE
If you select the update method to [LOCAL], the [FTP Server]
option will be disabled and the [Device] option is activated.
And if you select update method to [NETWORK], the [Device]
option will be disabled and [FTP Server] option is activated.
3. Select the [Search] button and press ENTER. The update file is
displayed in the list.
4. Choose the update file from the list.
5. Select the [Update] button and press ENTER. The confirmation
window is displayed.
3
Installation
6. Select [OK] to begin the update process or click [Cancel] to stop
and exit. After the update process is completed, the system
displays the Restart the system dialog box.
7. Click [OK] to restart the DVR.
NOTE
•
Do not turn the power off during the update process to
prevent the malfunction.
•
Do not remove the external device or CD/DVD disc for update
whilst the update is in progress. It may cause a malfunction.
Backup
•
Erase Media: To erase the media.
Instant Backup
1. Connect the backup USB device or insert a recordable disk to
the disc driver for backup.
2. Select the partition you want to backup.
3. Select INSTANT from the schedule options.
4. Select the backup device.
5. Select the Time Range Date, Time Range Start time, and Time
Range End time for backup.
6. Select the [Estimate Size] icon and press ENTER.
7. Check the size of the selected data and free space. If the device
does not have enough space, create space on the device or
erase the previously stored data.
8. Select the [Start Backup] icon and press ENTER to start backup.
9. Exit the setup menu. You can check the backup status on the
system control bar in backup progress.
Daily/Weekly backup
1. Connect the USB device for backup. You cannot use the CD or
DVD writer for daily or weekly backup.
2. Select WEEKLY or DAILY on the schedule options.
3. Select the backup device.
4. Enter the date and/or time to start backup on the schedule start
option.
5. Enter the day of week and/or time on the Time Range Start
option.
6. Enter the day of week and/or time on the Time Range End
option.
7. Select the [Estimation Size] icon and press ENTER.
8. Check the size of selected data and free space of USB device. If
the USB device does not have enough space, change the USB
device to a USB which has enough space or erase data of the
connected USB device.
•
Partition Selection: Select a backup partition.
•
Schedule: You can set the backup schedule.
--
OFF: All options are disabled.
--
WEEKLY or DAILY: The backup data will be automatically
saved according to the setting.
--
INSTANT: The backup data is saved manually.
•
Device: Select a backup device.
•
Schedule Start: Set the schedule start date (A day of the week
and time).
•
Time Range Date: Enter the backup time range. Enter the date
you want to backup.
•
Time Range Start: Enter the start day of the week or time.
•
Time Range End: Enter the end day of the week or time.
•
Estimate Size: Displays the size of backup data and the free
space of external devices.
•
Start Backup: To start backup.
Installation
Device settings
NOTE
•
The backup function is not supported on the external USB
CD-ROM driver.
•
Available external device for backup.
Device
USB HDD
E-SATA HDD
Camera
Capacity
Less than 1 TB.
Up to 2 TB.
Use the recommended external USB devices for preventing
malfunction (See the page 74).
•
The CD-R, DVD-R or DVD+R discs cannot be formatted.
•
DVD+RW and DVD-RW discs have to be initialized before
using.
•
An external media has to be formatted on this unit to prevent
malfunction.
•
You cannot use the [Estimate size], [Start Backup] and [Erase
Media] options in backup progressing.
•
Do not remove the external device while the backup is in
progress, it may cause a malfunction.
•
If you format the external media by using a PC with FAT32, the
media may not be used on this unit.
Check the size of the selected data and free space of the
external device. If the device does not have enough space,
create space on the device or erase the previously stored data.
3
Installation
•
•
31
•
Ch: Displays the channel number.
•
Name: Set the channel name by using alphabetic letter and
numeric digit up to 21 characters.
NOTE
1. Select the [Estimate Size] icon and press ENTER.
The size of the selected data and free space is displayed.
•
If you set the name by Korean or Japanese, use the system
setting menu of the LG Network Client program.
•
If you set the name to Korean or Japanese, you should set
the system language to Korean or Japanese to display the
name correctly.
2. Select [OK] and press ENTER to close the window.
•
You cannot stop the backup in backup progress.
•
The warning message will appear for the conditions listed
below.
--
When the start time and end time are the same value.
--
When the start time is later than the end time.
--
When you set the time for data that does not exist.
--
When the start time and end time setting are wrong.
--
A media does not have enough space.
--
When the selected USB device is disconnected.
•
If you use the CD/DVD writer device for backup, it is making
ISO image and then writing the backup data to the CD/DVD.
•
You can see the backup progress status on the system control
bar.
•
The estimated size of backup data is only the approximate size.
So you must prepare sufficient space on the media to prevent
lack of space.
•
At the scheduled recording time, you can check the backup
status on the system control bar.
•
While export is in progress or searching the backup data
from the external USB device, the scheduled backup will
not be started. After the export or backup search is finished,
scheduled backup will be restarted.
•
When you set the schedule backup, the backup data size is
estimated from the recording settings of the Setup menu. If
the real recorded data size is over the estimated recording
data size, the schedule backup may not be activated.
•
Audio: Select the input audio channel. You can hear from the
selected input audio channel. If you set to ON for the IP channel,
you can hear the input audio of the IP camera.
PTZ
Settings for the PTZ cameras connected via the data port of the
RS-485 terminal.
•
Channel: Selects the desired channel to set the connected PTZ
camera.
32
Installation
NOTE
IP Camera
If you set the channel name to Korean or Japanese, you should
set the system language to Korean or Japanese to display the
channel name correctly.
3
Installation
•
Port: Selects the connected data port of the RS-485 terminal
on the rear panel. The DATA 2 port is used to control the PTZ
camera connected to DVR or to control by using the LKD1000
controller. If you want to use the PTZ camera via DATA 2 port,
you should set the [Remote Controller ID] to [NONE]. If you use
the LKD1000 controller to control the DVR via DATA 2 port, you
should set the [Remote Controller ID] number between 1 and
16.
•
Control ID: Selects the PTZ camera ID. Make the same settings
as the PTZ camera.
•
Protocol: Selects the protocol supported by PTZ camera.
•
Baud Rate: Selects the communication speed.
•
PTZ Test: After the PTZ setting, you can test the pan/tilt function
for the selected PTZ camera. You can see the test screen from
the preview windows on the right side of the PTZ test option.
--
a/d: Test the pan direction.
--
w/s: Test the tilt direction.
•
NOTE
If you set the channel name to Korean or Japanese, you should
set the system language to Korean or Japanese to display the
channel name correctly.
NOTE
The supported PTZ camera list is on page 75 for reference.
Channel: Selects the desired channel to set the connected IP
camera.
•
Driver: Selects the IP camera driver from the drop-down list.
•
Profile: Select the camera stream on the drop-down box.
•
Host Name: Enter the IP address of the IP camera.
•
User Name: Enter the user ID.
•
Password: Enter the user password.
•
RTSP Port: Enter the RTSP port number.
•
HTTP Port: Enter the HTTP port number. HTTPS is not supported.
•
Test: Select [Test] to test the connection with the IP camera.
NOTE
•
The Supported IP camera specifications.
Specification
•
Description
Vendor
LGE, AXIS
Recording mode
Continuous, Instant
Video Codec
H.264 Baseline Profile
Audio recording and
playback
Support
Resolution
CIF, Half D1(2CIF), D1(4CIF), UXGA,
720p, 1080p
Stream
LGE (Master, Slave),
AXIS (H.264)
PTZ
Support
Sensor/Motion input
Not support
If the Resolution is over the D1, you can not operate the
system to view the live image and playback in this unit. In this
case, you should use the client program.
Installation
ATM/POS
NONE: Selects when the ATM/POS device is connected with
the DVR directly.
--
AVE Hydra: Selects when the ATM/POS device is connected
via the AVE Hydra device to the DVR. If you set to AVE Hydra,
the [Camera], [Baud Rate], [Data Bits], [Stop Bits] and [Parity]
options are dimmed and these options are not set.
•
Camera: Select the camera number for mapping with ATM/POS
device.
•
Baud Rate: Select the desired parameter to set the
communication speed between DVR and ATM/POS device.
•
Data Bits: Select the number of the data bits for RS-485
communication.
•
Stop Bits: Select the desired parameter. The stop bit, added to
the last of data, in asynchronous communication.
•
Parity: Select the desired parameter. The parity bit, added to the
data, to perform parity check.
Storage
--
ALL: Overwrite recording is possible when the normal
partition and event partition of HDD have fully recorded.
--
NORMAL PARTITION: Overwrite recording is possible for
normal partition of HDD when the normal partition of HDD
has fully recorded.
--
EVENT PARTITION: Overwrite recording is possible for event
partition of HDD when the event partition of HDD has fully
recorded.
--
OFF: Do not use overwriting.
•
Full Warning: When the HDD has overflowed a warning message
is displayed.
•
Auto Delete: Set the auto delete date. If you set the auto delete
date, the recorded data will be deleted except the data within
the selected date period of time. The Auto Delete function is
activated every 35 minutes.
•
Event Partition: Set the space of event partition for event
recording. The motion and sensor recording data are saved in
the event partition area of the HDD. You should set the space of
event partition before event recording.
•
Format: Initializes the HDD (Hard Disk Drive). All data on the
HDD will be erased.
•
Insert: Use the selected E-SATA storage for recording data.
•
Eject: Use the selected E-SATA storage for data back-up.
Interface Device: Select the interface device from the dropdown list.
--
Overwrite:
NOTE
If you change the value of event partition, the current recorded
data of HDD is deleted and the partition is reset. The partitions will
be formatted automatically and the system will be restarted.
How to format the HDD
1. Select the [Event Partition] option and set the event partition
rate of the HDD. If you set the event partition to 60 %, the
remaining space of 40 % is set to normal partition automatically.
•
Event Partition: To save space of the HDD for motion and
sensor recording data.
•
Normal Partition: To save space of the HDD for instant or
normal recording data.
2. Select the [Format] icon and press ENTER.
3. Select [OK] and press ENTER to start format.
•
Storage: Selects the E-SATA device or internal device name.
•
Serial Number: Displays the serial number of the selected
storage.
3
Installation
•
•
33
34
Installation
Display settings
Channel Composition
OSD
3
Installation
•
Channel Name: Mark up to display or remove the channel name
in the channel window.
•
Channel Status: Mark up to display or remove the channel status
in the channel window.
•
Font Size: Selects the font size of characters such as the channel
name and playback time which displayed on the channel
window.
•
Position: Selects the position of characters such as the channel
name and playback time which displayed on the channel
window.
•
Ch: Displays the channel number.
•
Name: Selects the desired channel. You can set the IP channel
only one time.
NOTE
If you set the channel name to Korean or Japanese, you should
set the system language to Korean or Japanese to display the
channel name correctly.
Video Adjustment
Adjust the brightness, contrast and color settings of each camera
channel. You can see the settings screen from the preview windows.
Sequence
•
Channel: Selects the desired channel to adjust.
NOTE
View all the channels in sequence in the selected screen division
mode. You cannot use sequence mode with the 16 split (LE5008/
LE4008 series: 8 split). While the sequence mode condition, if you
change the screen division mode, the sequence function will be
canceled.
If you set the channel name to Korean or Japanese, you should
set the system language to Korean or Japanese to display the
channel name correctly.
•
•
Main Dwell Time: Selects the channel sequence time for main
monitor.
•
•
Spot Dwell Time: Selects the channel sequence time for spot
monitor.
•
•
Brightness: Adjust the brightness value from 0 to 100 for the
selected channel.
Contrast: Adjust the contrast value from 0 to 100 for the selected
channel.
Color: Adjust the color value from 0 to 100 for the selected
channel.
Restore to default: Sets to default setting value.
Installation
35
Record settings
Schedule
A schedule recording can be activated at preset times, in a repeating
pattern on selected weekdays. The DVR can record according to a
schedule set by the user. It can also record manually regardless of
date and time. The recording can be made either continuously or
triggered by events (alarm and motion detection).
The recording schedule screen displays one day of the week
showing the schedule of all channels over a 24-hour period. For
each 1-hour cell block the recording method can be specified. The
recording method for each block is shown in color for easy viewing.
3
Time Line
3. Select the time cell block for the start time.
4. Press ENTER or click the left mouse button to select a recording
mode. The color of the cell blocks will change automatically.
•
Gray: No schedule recording.
•
Light Green (Continuous recording): Recording starts
automatically from the preset time.
•
Red (Sensor event recording): Recording starts automatically
when the sensor alarm occurs within a designated time.
•
Green (Motion event recording): Recording starts
automatically when motion is detected within a designated
time.
•
Violet (Text event recording): Recording starts automatically
when text input is detected within a designated time.
•
Yellow (Sensor+Motion recording): Recording starts
automatically when the sensor alarm signal has input or
motion has been detected.
•
Light Green+Red (Continuous+Sensor event recording):
Recording starts automatically from the preset time. When
the sensor alarm occurs within a designated time, change
the continuous recording mode to sensor event recording
mode and recording starts automatically.
•
Light Green+Green (Continuous+Motion event recording):
Recording starts automatically from the preset time. When
the motion is detected within a designated time, change
the continuous recording mode to motion event recording
mode and recording starts automatically.
•
Light Green+Violet (Continuous+Text event recording):
Recording starts automatically from the preset time. When
the text input occurs within a designated time, change the
continuous recording mode to text event recording mode
and recording starts automatically.
•
Light Green+Yellow (Continuous+Sensor+Motion event
recording): Recording starts automatically from the preset
time. When the sensor alarm signal has input or motion has
been detected, change the continuous recording mode
to motion event recording mode and recording starts
automatically.
•
Yellow+Violet (Sensor+Motion+Text event recording):
When the sensor alarm signal has input, motion has been
detected or the text input occurs and then recording starts
automatically.
Recording mode
To Set the Recording Schedule for a
Typical Day of the Week
1. Select a day of the week.
2. Select the desired channel to schedule recording.
Installation
Channel numbers
36
Installation
•
Sky blue (Continuous+Sensor+Motion+Text event
recording): Recording starts automatically from the preset
time. When the sensor alarm signal has input, motion has
been detected or the text input occurs within a designated
time, change the continuous recording mode to occurred
event recording mode and recording starts automatically.
5. Select the next time cell block of schedule time cell blocks to
confirm the schedule time.
6. Press ENTER or click the left mouse button repeatedly to select
gray to set the time for the end of the schedule. The settings cell
block is highlighted.
Checking the Special Day Schedule List
1. Press [ZOOM -] when the [SP] button is selected.
The special day scheduled list appears.
2. Select a special day title on the list and press ENTER.
The title color turns orange.
3. Select the [Edit] icon then press ENTER to edit the special day or
press [ZOOM -] to delete the special day schedule.
4. Press ESC to exit the special day schedule list.
NOTE
If the special day recording schedule is duplicated with the other
recordings, only the special day recording is possible.
3
Installation
Copying the Recording Schedule
Copying from the Scheduled Data of the Channel
You can copy the schedule data of the channel to the other
channel(s) within the selected day of the week. You can not copy
the schedule data of the IP channel.
1. Select the day of the week and press ENTER.
2. Select channel that you want to copy.
3. Press COPY then the channel selection menu appears.
7. Press SETUP/ESC to move to the previous menu.
If the save message appears, select [OK] and press ENTER to
save the settings.
4. Use a/d to move to the left or right column then press ENTER
to select the target channel(s).
You can cancel the selected channel by pressing ENTER.
5. Use w/s to select [OK] then press ENTER to confirm your
selection.
8. Press SETUP/ESC repeatedly to exit the Setup menu.
Copying from the Scheduled Data of the Day
To Set a Recording Schedule for a Special Day
In addition to the weekly schedule, up to 10 specific date/time
periods can be defined. To configure the specific recording schedule
select Specific Dates.
1. Select the [SP] button on the schedule setting menu.
You can copy the scheduled day of the week to another day of the
week, weekday and weekend using the COPY button.
1. Select the day of week that you want to copy.
2. Press COPY then the select date(s) menu appears.
3. Use a/d to select the target date(s).
2. Select a cell block.
4. Use w/s to select [OK] then press ENTER to confirm your
selection.
3. Press the [ZOOM +] button or click the [Add] icon on the special
day setting menu.
The specific date selection menu appears.
Normal
4. Enter the necessary information for year, month and date.
•
w/s/a/d: Press to move the columns, [OK] or [Cancel]
buttons.
•
a/d (or left/right mouse button): Changes the value at
the current position.
5. Use w/s/a/d to select the [OK] button and press ENTER.
The virtual keyboard menu appears.
6. Enter the name of the special day. Use w/s/a/d to select a
character then press ENTER to confirm your selection.
7. Use w/s to select the [OK] icon then press ENTER to fix the
date of the special day and return to the special day menu
screen.
8. Select the schedule time and set the recording method for each
channel.
Settings concerning normal recording.
Installation
•
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution.
•
Quality: Selects the recording picture quality.
•
Frame Rate: Selects the frame rate. The frame rate is the number
of recorded frames per second. According to resolution, the
frame rate is set automatically.
37
Motion
Settings concerning motion recording.
NOTE
In case of the LE4000 series models, the resolution setting is
possible in the Normal setting menu only. Each group such as
“Ch1 to Ch4”, “Ch5 to Ch8”, “Ch9 to Ch12” and “Ch13 to Ch16” is set
the same resolution.
If you change the resolution of the Normal option, the resolution
of the Motion, Sensor, Text and Instant/Panic options will be
changed automatically with the same resolution.
3
Installation
Sensor
Settings concerning sensor recording.
•
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution. The LE4000 series
models are display only.
•
Quality: Selects the recording picture quality.
•
Frame Rate: Selects the frame rate. The frame rate is the number
of recorded frames per second. According to resolution, the
frame rate is set automatically.
•
Prealarm: Specify the pre-event recording time. When the Event
signal is detected, the DVR is recording the data before the
event during the setting time.
•
Postalarm: Specify the post-event recording time. When the
Event signal is detected, the DVR is recording the data after the
event during the setting time.
Text
•
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution. The LE4000 series
models are displayed only.
•
Quality: Selects the recording picture quality.
•
Frame Rate: Selects the frame rate. The frame rate is the number
of recorded frames per second. According to resolution, the
frame rate is set automatically.
•
Prealarm: Specify the pre-event recording time. When the Event
signal is detected, the DVR is recording the data before the
event during the setting time.
•
Postalarm: Specify the post-event recording time. When the
Event signal is detected, the DVR is recording the data after the
event during the setting time.
Settings concerning text recording.
•
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution. The LE4000 series
models are display only.
•
Quality: Selects the recording picture quality.
•
Frame Rate: Selects the frame rate. The frame rate is the number
of recorded frames per second. According to resolution, the
frame rate is set automatically.
38
Installation
•
Prealarm: Specify the pre-event recording time. When the Event
signal is detected, the DVR is recording the data before the
event during the setting time.
•
Postalarm: Specify the post-event recording time. When the
Event signal is detected, the DVR is recording the data after the
event during the setting time.
Event settings
Sensor
Instant/Panic
Settings concerning instant/panic recording.
3
Installation
•
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution. The LE4000 series
models are display only.
•
Quality: Selects the recording picture quality
•
Frame Rate: Selects the frame rate. The frame rate is the number
of recorded frames per second. According to resolution, the
frame rate is set automatically.
•
In: Displays the number of the ALARM-IN terminal.
•
Sensor Type: The sensor state can be set to either N.O. (Normally
Open) or N.C. (Normally Closed).
•
Camera: Select the connected camera channel to the ALARM-IN
terminal.
•
Relay Output: Select the alarm (relay) output number for the
RELAY-OUT terminal for the output alarm (relay) signal.
•
Preset: Select the preset number. When the input is activated,
the camera moves to the selected preset position and the
picture of the camera in that position appears on the monitor.
Motion
•
Channel: Select the channel to set motion detection.
NOTE
If you set the channel name to Korean or Japanese, you should
set the system language to Korean or Japanese to display the
channel name correctly.
•
Sensitivity: Set the level of sensitivity for the created motion
detection area. Sensitivity can be set from level 01 to 10 or OFF.
Installation
•
Relay Output: Select the number of the RELAY-OUT terminal for
the output alarm (relay) signal when motion is detected.
•
Area: Select the desired motion detection area on the preview
window screen.
•
Delimiter: Enter the character(s) that the device uses to
indicate the end of a line. Refer to the device manufacturer’s
documentation for Line Delimiter character(s).
•
Ignore String: Enter the any strings of text that you want the DVR
to ignore. Refer to the device manufacturer’s documentation
for text strings that the device sends during transactions, so you
will know which ones you do not want recorded.
--
w/s/a/d: Moves the yellow cell box to another cell
zone.
--
ENTER: Selects or cancels the motion detection area at the
current cell position.
•
Time Out: Select the Recording end time.
Press ESC to exit the settings.
•
Relay Output:
--
--
01 to 04: Outputs the alarm (relay) signal via the RELAY-OUT
terminal. When the DVR detects text input, it triggers output
signals on all the associated RELAY-OUT connectors.
--
NONE: Not used.
NOTE
•
--
To select the area: Drag & drop a cell to the right to select
the motion detection area.
--
To cancel area: Drag & drop a cell point of a selected cell
area to the left to cancel the motion detection area.
3
NOTE
ATM/POS Recording Information.
Option setting
In the condition that illumination is low and the outline of
object is not clear enough to see, regardless of sensitivity,
Motion Event could be possible not to happen. You must
check Motion Event before setting.
ATM/POS Recording Action
Recording is started automatically
When the Transaction
when the Transaction start data is
Start and Transaction End detected. When the Transaction
options are set.
end data is detected the recording
is stopped after post-alarm time.
Recording is started automatically
when the transaction data is
When the Transaction
detected. When the transaction
Start and Transaction End data is not detected the recording
is stopped after post-alarm time
option is not set.
and the time you set of the Time
Out option.
ATM/POS Data Format
The DVR can be set to react to text input from devices such as
ATMs (Automated Teller Machines) and POS (Point of Sale; i.e., cash
registers). This screen allows you to configure the DVR for your input
device.
Event Popup
•
Input Channel: Select the mapping camera channel.
NOTE
If you set the channel name to Korean or Japanese, you should
set the system language to Korean or Japanese to display the
channel name correctly.
•
Transaction Start: Enter a Transaction Start string. Refer to the
device manufacturer’s documentation for the text string that
the device first sends when a transaction starts.
•
Transaction End: Enter a Transaction End string. Refer to the
device manufacturer’s documentation for the text string that
the device sends when a transaction ends.
•
Spot Monitor: Select the event type for the spot monitor display
when the event is activated.
Installation
•
You can select the motion detection area by using the mouse.
39
40
Installation
Notification
•
User Name: Enter the user name.
Marks up when you want to activate the selected option. If the
selected notification option is activated, the device will notify the
user about the information of selected option by E-mail.
•
Password: Enter the password.
•
TLS: Marks up when using the TLS (Transport Layer Security)
function.
•
Mail Address (1 to 3): Enter the mail address.
You can input up to 3 e-mail addresses.
•
E-mail Test: Select [E-mail Test] to test send an e-mail.
NOTE
The SMTP server, SMTP port no., user name or password settings
are optional. The DVR can send e-mail directly without the use of
an SMTP server or MTA (message transfer agent). In certain cases
all e-mail should be forwarded to a specific SMTP server. Specify
the server host name or IP address in such a case. For more detail
on SMTP setup, ask your network administrator and/or mail service
provider.
3
Installation
Emergency
•
Sensor On: Sends an e-mail when a sensor has occurred.
•
Motion Detection: Sends an e-mail when a motion detection
has occurred.
•
Text In: Sends an e-mail when a text input is detected.
•
Admin Password Changed: Sends an e-mail when the
administrator password has changed.
•
Video Loss: Sends an e-mail when a video signal from the
camera has stopped because of a cable disconnection or
malfunction of a camera.
•
Power On/Off: Sends an e-mail when power is on or off.
•
Disk Full: Sends an e-mail when the HDD has fully recorded.
Mail
•
Notification: Marks up to notify the unit operating information
according to notification settings by e-mail.
•
SMTP Server: Enter the SMTP Server address.
If notification option is not mark up and the SMTP server option
is empty, the SMTP Port, User Name, Password and TLS options
cannot be set.
•
SMTP Port: Enter the SMTP Port Number. Typically the port used
for SMTP is 25. However in some cases it is better to change this
port number for added flexibility or security. You can edit this
port between 1 and 65 535.
•
Notification: Marks up to notify the emergency agent about unit
operating information according to your notification settings.
•
Host Name/Port: Enter the Host Name and port number of the
emergency agent program. The factory default port for this
function is 9002. However in some cases it is better to change
this port number for added flexibility or security. You can edit
this port between 1 025 and 65 535.
You can set up to 9 Host Name and port numbers.
Installation
SNMP
41
Output
The Simple Network Management Protocol (SNMP) is an application
protocol to exchange the management information of network
devices.
3
•
SNMP Version: Selects a SNMP version if SNMP is allowed to
access to this device.
•
Port: Enter the number for SNMP port.
•
Community String (V2 only): Specifies the SNMP management
community in which you want to enable this system (e.g.
lgecommunity or public).
•
User (V3 only): Enter the security name for the SNMP.
•
Authentication (V3 only): Select a mode for the SNMP
Authentication. (MD5 or SHA)
•
Password (V3 only): Enter the password for the SNMP
Authentication.
•
Privacy (V3 only): Select a privacy mode for the SNMP
Authentication. (DES or AES)
•
Password (V3 only): Enter the password for the privacy mode.
•
Trap IP Address: Specifies the IP address of the computer you
intend to use as your network management station and to
which SNMP traps will be sent.
•
Trap Community String: Specifies the SNMP trap community in
which you want to enable this system (e.g. lgecommunity or
public).
Relay Off
--
ALARM ACKNOWLEDGE: Use the ALM.OFF button to stop
alarm.
--
POST-ALARM TIME: The alarm is stopped after post-alarm
time.
•
System Alarm Out: Outputs the alarm (relay) signal via the
selected alarm out terminal number when the system has some
problem. If you do not use this function, select [NONE] option.
•
HDD Fail Alarm Out: Outputs the alarm (relay) signal via the
selected alarm out terminal number when the HDD is failed. If
you do not use this function, select [NONE] option.
•
Video Loss Alarm Out: Outputs the alarm (relay) signal via the
selected alarm out terminal number when a video signal from
the camera has stopped because of a cable disconnection or
malfunction of a camera. If you do not use this function, select
[NONE] option.
•
Fan Fail Alarm Out: Outputs the alarm (relay) signal via the
selected alarm out terminal number when the fan is failed. If
you do not use this function, select [NONE] option.
Installation
•
42
Installation
Buzzer
Marks up when you want to activate the selected option.
User settings
Group Authority
You can register a new user group with various access rights.
3
Installation
•
Sensor: Makes a sound when a sensor occurs.
•
Motion : Makes a sound when a motion is detected.
•
Text: Makes a sound when the DVR detects text input.
•
System: Makes a sound when a cooling fan is not activated or
the HDD has bad sector.
•
Group ID: Select the group ID to assign authority.
--
GUEST: The GUEST group has the limited authority of the
system. Users in this group are available to see the live
image and to set the covert function of the Main or Spot
channel.
--
ADMINISTRATOR: The ADMINISTRATOR group has the
unlimited authority of the system. Users in this group are
available to use all of the functions.
--
[Group 01] to [Group 08]: Users in this group are available to
set the authority of the function manually.
NOTE
•
Data cannot be saved in HDD which is occurred bad sector.
But if HDD is installed more than 2 on this unit, data is saved in
other normal HDD.
•
When HDD has bad hold, can not operate normally. Replace
the HDD immediately .
NOTE
The GUEST and ADMINISTRATOR group are set initially for the
authority. You cannot change the initial settings and group name
(GUEST and ADMINISTRATOR).
•
Group Name: If you select one of the group numbers from the
Group ID option, you can register the group name. Enter the
group name.
--
•
Setup, Search/Play, Export, PTZ, Power Off, Instant Record:
Set the authority for the selected group. Marks up the
option to activate it.
Main Channel/Spot Channel: Selects the channel to allow the
operation for the group user. The LG logo is displayed on the
covert channel(s).
Installation
43
User
You can set the user name for the selected User ID.
3
2. Enter the user name of the selected user ID.
3. Select the user group from the drop-down list.
4. Enter the Password.
5. Select the auto user logout time from the drop-down list.
6. Press the ESC button to display the confirmation window.
7. Select [OK] to save the setting or [Cancel] to cancel the setting.
NOTE
•
If you set the user ID to [ADMINISTRATOR], you cannot change
the [User Name] and [Group] option but you can change the
password.
•
The user name and password are case-sensitive.
Installation
1. Select [User ID] from the drop-down list.
44
Operation
4
Operation
Instant Recording
4
Images from a camera will be recorded on the built-in hard disk.
Ensure all the cameras are connected and that time and date have
been set correctly.
Before you start recording, first check the repeat recording settings
in the recording menu of the system setup, and then make the
recording settings.
NOTE
•
External recording devices can be used as copy areas for
images recorded on the hard disk. It is impossible to record
images on the external recording devices directly.
•
You can record instantly with the left mouse button.
1. Move the cursor to the desired channel screen on the
main monitor.
Operation
2. Click the recording type indicator with the left mouse
button and recording starts. Click it once again and the
instant record stops and the recording type indicator
will be changed into the scheduled recording mode
(Continuous / Alarm / Motion record). If the schedule is
not set, the recording type indicator turns white.
1. Press the REC button and then press the channel button you
want to record. The recording type indicator turns green on the
selected channel screen of the main monitor.
•
You can instant record that the channels scheduled such as
alarm, motion or continuous.
•
Once you stop instant recording, the recording type indicator
will be changed to the scheduled recording mode.
•
You can not record the Instant and Continuous recording in
following conditions.
------
2. Press the REC button and then press the channel button you
want to stop recording. If you stop instant recording, the
recording mode will be changed into the scheduled recording
mode (Continuous/ Alarm/ Motion records). If the schedule is
not set, the button indicator turns off and the recording type
indicator turns white on the selected channel screen of the
main monitor.
Panic Recording
•
You can not record the Alarm and Motion recording in
following conditions.
-------
•
--
This function is activated for a live channel only.
1. Press and hold the REC button until the Recording Type
indicator turns green on the all live channel screens.
The DVR will start recording.
•
2. Press and hold the REC button until the Recording Type
indicator turns white on the all live channel screens. The DVR
will stop recording.
•
A HDD is not attached.
A HDD is not formatted.
The channel has no video input for display.
Overwrite sets to “OFF” or “NORMAL PARTITION”, and event
partition is full.
On the HDD setting, the event partition is set to 0 %.
The schedule (Alarm/Motion) record is not set.
HDD partition according to a recording type.
--
You can record the all channels at the same time.
A HDD is not attached.
A HDD is not formatted.
The channel has no video input for display.
Overwrite sets to “OFF” or “EVENT PARTITION”, and normal
partition is full.
On the HDD setting, the event partition is set to 100 %.
Normal Partition: It is the space in the HDD that stores the
continuous and instant recorded data. Once the normal
partition is set to 0 % (the event partition is 100 %), you
can not record the continuous or instant recordings.
Event Partition: It is the space in the HDD that stores the
alarm and motion recorded data. Once the event partition
is set to 0 %, you can not record the alarm and motion
recording.
Priority of record.
Instant record > Alarm record > Motion record > Continuous
record.
The Warning message is displayed when the HDD problem
occurs during the recording.
Operation
Instant Playback
45
6. Press ad (Play) button or click the [Play] button to start
playback.
The picture(s) is (are) displayed on the main monitor.
7. Press STOP (Z) to stop playback and return to the search menu.
It is possible to play a recorded image without stopping recording.
8. Press SETUP/ESC to exit the[Date/Time] menu.
1. Select a channel you want to playback.
2. Press ad (Play) button to play a recorded image of the
previous 1 or 2 minutes of recording. The playback image will
be displayed on the full screen window.
3. Press Z (STOP) button to stop the playback.
Using the calendar icon to select the date
1. Select calendar icon then press ENTER.
2. Select year or month column then press ENTER.
3. Use a/d button to input the year or month.
4. Press ENTER to confirm it.
Search and Playback
5. Use w/s/a/d to select date then press ENTER.
6. Select [OK] button and press ENTER to confirm the settings.
NOTE
The various search functions of this unit can be used to go to the
beginning of the desired picture.
When the SEARCH button is pressed the search menu is displayed.
Use to search recorded pictures by specifying date, hour and
minute.
While the backup is in progress, you can not search the data
on the backup device.
•
Do not remove the external USB device whilst the backup
search is in progress from the USB device. It may cause a
malfunction.
•
Recorded data shown on the time graph will be displayed in
different colors depending on the recording type.
•
--
Light Green: Continuous recording.
--
Red: Sensor recording.
--
Green: Motion-detection recording.
--
Gray: No recording.
--
Violet: ATM/POS recording.
Use the ZOOM + button to view the detailed time by 6 hour
intervals.
Event Search
Search a recorded picture by date and type of event.
1. Use w/s button to select the [Date/Time] icon then press
ENTER.
2. Select the desired source device.
•
INTERNAL HDD: Plays back or searches recorded contents of
the internal HDD device.
•
Source Device: Plays back or searches backup contents of
the source device.
3. Set the year, month, date and time. •
a/d: Moves to the previous or next column.
•
w/s: Changes the value at the current position.
•
ENTER: Selects the column or confirms the setting.
4. Select the [Search] icon then press ENTER.
The search result is displayed.
1. Use w/s button to select the [Event] icon then press ENTER.
5. Use w/s button to select the channel and press ENTER. Repeat
this step to select the other channels.
3. Set the year, month, date and time.
2. Select the desired source device.
•
a/d: Moves to the previous or next column.
•
w/s: Changes the value at the current position.
•
ENTER: Selects the column or confirms the setting.
4
Operation
Date and Time Search
•
46
Operation
4. Use w/s/a/d button to select the channel and press ENTER
button to confirm the selection. If you want to select the all
channels, marks up the [All Channels] option.
5. Select the [Event Type] then press ENTER.
ATM/POS Search
Search the recorded text information by ATM/POS device.
This function is available with backup data of the internal or external
HDD only.
6. Use w/s to select the event type then press ENTER.
7. Select the [Search] icon then press ENTER.
The event list menu appears.
8. Select the recording data on the event list then press ad (Play)
button, click [Play] or double click the selected data to start
playback.
The picture is displayed on the main monitor.
9. Press STOP (Z) to stop playback and return to the event list
menu.
10. Press SETUP/ESC repeatedly to exit the event search menu.
Bookmark Search
4
Search the desired picture with a bookmark registered by the
bookmark function.
Operation
1. Use w/s button to select the [ATM/POS] icon then press
ENTER.
2. Select the desired source device.
3. Set the year, month, date and time.
•
a/d: Moves to the previous or next column.
•
w/s: Changes the value at the current position.
•
ENTER: Selects the column or confirms the setting.
4. Use w/s/a/d button to select the channel and press ENTER
button to confirm the selection. If you want to select the all
channels, marks up the [All Channels] option.
5. Set the detail search options.
1. Use w/s button to select the [Bookmark] icon then press
ENTER.
2. Select the recording data on the list then press ad (Play), click
[Play] or double click the selected data to start playback.
The picture is displayed in the main monitor.
3. Press STOP (Z) to stop playback and return to the bookmark list
menu.
4. Press SETUP/ESC to exit the bookmark search menu.
NOTE
•
Backup data can not be played back by a bookmark search.
•
You can register a bookmark only in the single channel
playback.
•
If you delete the bookmark on the list, select the recording
data and select [Delete] button and press ENTER.
•
Number: Displays the preset number.
•
Option Item: Enter the text to search what you want.
•
AND /OR : Select the Boolean operator when you use the
Text search and Number search function simultaneously.
•
Value: Enter the number to search what you want.
•
>, <, <=, =, >= (compare symbols): Select the compare
symbol for number search.
>
To find the lower value than the input value.
<
To find the higher value than the input value.
<=
To find the higher or even value than the input
value.
=
To find the even value than the input value.
>=
To find the lower or even value than the input
value.
6. Select the [Search] icon then press ENTER.
7. Select the text data on the list then press ad (Play) button,
click [Play] or double click the selected text data to start
playback.
The picture is displayed on the main monitor.
8. Press STOP (Z) to stop playback and return to the ATM/POS
search list menu.
Operation
Export Search
Search an exported data from the external device or internal
DVD-ROM device.
If you want to use this function, you have to connect the external
device or insert the CD/DVD disc with exported data otherwise the
warning message will be displayed.
Check the export device before you proceed.
47
1. Use w/s to select the [Smart] icon then press ENTER.
The smart search menu is displayed.
2. Select the desired source device.
3. Specify the date, Start, Duration, Channel and sensitivity options.
•
wsad: Moves to the options.
•
w/s: Changes the value at the current position.
•
ENTER: Selects option or confirms the setting.
4. Set the motion mask setting.
The area switches between active and inactive each time you
press ENTER. Click the one point and drag & drop the end point
to select the motion using the mouse. The active areas are
indicated in red.
5. Press SETUP/ESC to exit the mask setting.
6. Select [Search] then press ENTER.
The search result is displayed on the list.
4
2. Select the desired source device.
3. Select the [Search] icon then press ENTER.
The exported file list menu appears.
4. Select the exported file on the exported file list then press ad
(Play) button or click [Play] to start playback.
The picture is displayed on the main monitor.
5. Press STOP (Z) to stop playback and return to the exported file
list menu.
Smart Search
You can be searched the recorded data by specifying the motion
detection conditions.
Operation
1. Use w/s button to select the [Export] icon then press ENTER.
48
Operation
Functions Available During
Playback
Button
System Control
Bar
Remote Control
Function
Front panel
Stop playback.
Pause playback.
4
Jump to the beginning of the current data that was recorded on the same
date. (press the button for more than 2 seconds.)
Operation
Jump to the last 1 minute of the current data that was recorded on the
same date. (press the button for more than 2 seconds.)
Press repeatedly to select the required scan speed. (dd, ddd, dddd,
dddddor aa, aaa, aaaa, aaaaa)
Press repeatedly to play frame-by-frame in pause mode.
Press to play reverse or normal playback.
+
Press MARK at a desired point to be marked during playback. Up to 15
points can be marked.
NOTE
•
If you play the recored data included the text information, the [TEXT] button is displayed on the upper right corner of the screen during
the full screen playback mode. You can show or hide the text by clicking the TEXT button.
•
You can play the backup or export data in normal speed only.
•
If you use the reverse frame skip function, a frame may be skipped.
•
Multi channel play works only in the date/time search function.
•
If you double-click the channel during the multiple channel playback, the selected channel will be played on the full screen. And if you
double-click the channel during playing full screen mode, it will return to the previous playback condition.
LG Network Client Program
49
5
LG Network Client Program
Introduction
Getting Started
The LG Network Client program is an IP-Surveillance software that
works with the LG DVR/NVR to provide video monitoring, recording
setting and event management functions. The software has multiple
search functions for recorded events. Remote viewing and playback
are also possible with the use of the LG Network Client.
This manual contains instructions on how to use and manage
the LG Network Client in your networking environment. Some
knowledge of networking environments would be beneficial to the
reader.
Should you require any technical assistance, please contact
authorized service center.
The LG Network Client program must be installed below operating
systems for best performance and stability.
Items
Requirements
Operating System
Windows XP Professional Service Pack 2 or
above
CPU
Web Browser
Intel Pentium Dual-Core or above
Microsoft Internet Explorer 6.0 or above
You can install the LG Network Client software following steps.
1. Insert the Client Program CD which will be started automatically.
If the disc does not run automatically on your PC, open the
Client Program CD and install the program manually.
2. Run the install file and install the programs to your computer
following the on-screen instructions. The [LG Emergency Agent]
and [LG Export viewer] programs will be installed with the LG
Network Client program installation.
3. After finishing installation, you will find the programs in the Start
menu or on the desktop.
Starting the LG Network Client
1. Run the LG Network Client program. To launch LG Network
Client, select LG Network Client from your Start > Programs >
LG Electronics > LG Network Client > LG Network Client or
click the LG Network Client icon on your desktop.
The client password input window is displayed.
2 GB or above RAM
2. Enter the password. (Note that the default client password are
“000000”.)
Graphics Card
128 MB or above Video RAM (Use latest
graphics card driver.)
3. Click the [OK] button and then the LG Network Client window is
displayed.
Resolution
1024 x768 (with 32 bit color) or above
Memory
Network
100 Megabit Network (Gigabit Network
recommended for larger systems)
Before install the program
•
The description pictures may differ from your OS (Operating
System) or Web Browser type.
•
The pictures used in this manual are based on Windows XP
Professional.
•
Do not use other applications with this program. This can cause
memory shortage and program malfunction.
•
Check that the LG DVR/NVR is(are) connected to the network
and that power is supplied.
NOTE
If you mark up the [Auto Connection] option, the LG Network
Client program is connected automatically at the next time.
5
LG Network Client Program
Recommended PC Requirements
Install the LG Network Client on your PC
50
LG Network Client Program
LG Network Client Overview
Selected Menu Tab
Menu Bar
File
End Backup
Search
Use to stop and exit the backup
search function.
Software Update Use to upgrade DVR/NVR software or
add/upgrade PTZ protocols.
Live window
Tool Bar
1. Log-in the Network Client
program as the permitted
user who has the Group Setup
authority.
2. Click this option. The Update
setting window is displayed.
3. Select the update device from
the list.
•
Select All: If you click this
button, the all devices in the
list are selected .
•
Clear All: If you click this
button, the all selected
devices in the list are
deselected .
4. Find and open the update file.
Playback control
Window
Information Display Window
5
5. Click the [Update] button to
begin the update process. The
DVR/NVR will be restarted after
updating.
Page
LG Network Client Program
6. Click the [Exit] button.
Menu Bar
Menu
Sub-Menu
Description
File
Client Password
You can change the password of the
Network Client program.
1. Select this option. The Client
Password Setup window is
displayed.
2. Enter the password.
3. Click [OK] to confirm your
settings.
Save to JPEG
Exit the program.
OSD
•
Channel Number: Displays or
removes the channel number in
the channel window.
•
Site Name: Displays or removes
the site name in the channel
window.
•
Camera Name: Displays or
removes the camera name in the
channel window.
•
Playback Time: Displays or
removes the date/time of
playback data in the channel
window.
•
PTZ: Displays PTZ camera icon in
the channel window.
•
Audio: Displays audio icon in the
channel window.
•
Select All: Displays all OSD
options in the channel window.
You can capture and save the current
image in JPEG file format.
1. Play the recorded data.
2. Pause the playback at a desired
point during playback.
3. Select this option. The JPEG
Export window is displayed.
4. Set the options.
5. Click the [Save] button.
Backup Search
View
Exit
Search and playback a backup data.
1. Select the Search Mode icon.
2. Select this option. The Backup
Search window is displayed.
Sequence (Dwell Select the sequence to 5 seconds, 10
Time)
seconds, 15 seconds or 20 seconds.
Sequence Mode •
3. Click the [Add] button.
4. Enter the Name.
5. Find and open the backup file.
6. Click the [OK] button.
7. Use the time line and playback
control buttons to play the
backup data.
•
Channel Sequence: Each channel
of the selected site in the
sequence mode will be displayed
in sequence.
Site Sequence: Each channel of
the logged site in the sequence
mode will be displayed in
sequence.
LG Network Client Program
View
Language
Select the language for LG Network
Client program.
Resolution
Select the resolution of the LG
Network Client program.
Video
Adjustment
1. Use : Marks up to activate the
video adjustment.
Tool Bar
Icon
Brightness : Adjust the
brightness value from 0 to
100 for the current playback
channel.
•
Contrast : Adjust the contrast
value from 0 to 100 for the
current playback channel.
•
Hue : Adjust the hue value
from 0 to 100 for the current
playback channel.
•
Saturation : Adjust the
saturation value from 0 to
100 for the current playback
channel.
4. Click [OK] to confirm your
settings.
Tools
Help
Live
Search
Camera View: You can see the
surveillance camera’s images in
the window(s) and the camera
information.
•
Pan/Tilt/Zoom: You can control the
PTZ camera.
•
Log View: You can see the system
log list.
•
Favorites: You can save the current
configuration of the camera view.
And, it is possible to return to a
previous configuration of the camera
view.
Displays the search workspace. You can
search and play the recorded data using
the search functions.
You can set the configuration of the
selected site via the network.
5
Setup
Displays the Export pop-up windows.
Export
Connection
Information
Displays the Connection List
windows. You can add, edit or delete
the site name or group name in LG
Network Client.
E-Map
Displays the E-Map pop-up windows.
This function gives a visual overview
of the cameras in your surveillance
environment using the imported
maps.
Print
Multiple
Window
[Live2] window appears and you can
see the [Live2] screen in the extended
monitor.
Full Screen
Protect
The [Protect] menu appears and you
can select a protect section.
Client
Information
•
When you click the PAUSE button to
pause the playing the recorded data
of the selected channel, the Print Icon
is activated. You can print the paused
picture of the recorded data of the
selected channel.
You can view the live window in full
screen mode. To return to the normal
screen, click the right mouse button.
When the icon is clicked, the screen
will be changed to split mode and if
the icon is clicked again, the screen will
be changed in sequence (except 64
split mode). Choose the screen division
mode.
Displays Network Client Version
Information.
NOTE
[Protect] option is not supported for models LE4008, LE4016,
LE5008 and LE5016.
Division
Sequence
You can view all the channels in
sequence. You cannot use sequence
mode with the 64 split.
LG Network Client Program
3. Default set : Reset the video
adjustment for all playback
channels to its default settings.
Description
Displays the live view workspace.
2. Adjust the brightness, contrast
and color settings of current
playback channel.
•
51
52
LG Network Client Program
Information Display Window
Add the Site Name
Displays current date and time, user information and the remaining
HDD status of the selected site name.
1. Click the [Add] button. The Connection Setup window is
displayed.
NOTE
•
Check the box of the DVR/NVR Time option to display the
DVR/NVR Server Time.
•
The DVR/NVR Time option is activated more than the LG
Network Client Version V3.0.2 and the DVR/NVR server version
V1.0.6.
•
You can select the DVR/NVR Time in live mode only.
Playback control Window
3. Enter the description of the site name.
4. Select the model type from the drop-down list.
5. Enter the IP Address or the Host Name that you entered in the
DDNS setup menu of the DVR/NVR.
In case of entering the server name instead of the IP Address.
You should set up the DDNS configuration properly in the
server. Please refer to the server manual to set up the DDNS
function.
Case
How to find the IP Address
You can playback the recorded data of the selected channel.
Using the Static IP
Address
Check the IP Address in the TCP/IP option
of the DVR/NVR setup menu.
Page
Using the Dynamic
IP Address
You have to activate the DHCP function.
Live Window are composed many pages except for 64 split mode.
The page view window indicates "current number of page / total
number of page". Click Sequence button or current devision button
to move other pages.
5
2. Select the group name from the drop-down list.
LG Network Client Program
Operation and settings
2. Check the “Network IP” options value.
Using the DDNS
function
Check the registered Host Name of the
DDNS setup menu.
The DVR/NVR is
connected to the
network through the
Broadband Router
You must set the port forwarding
according to the settings of the
broadband router. Refer to the manual
of Broadband router for more detailed
settings. If you use the multi DVR/NVR
with Broadband router, you must set the
TCP/IP port number for each DVR/NVR.
Register the Site Name or Group Name
The first time LG Network Client is started, you should register a site
name to control it by the LG Network Client program. The computer
running LG Network Client program must be on the same network
with DVR/NVR.
1. Select [Tools] > [Connection Information] option on the menu
bar. The Connection List window is displayed.
2. After completing the settings, click the [OK] button to confirm
the settings and exit the window. The registered site or group
name is(are) displayed on the [Camera View] tab window.
Create a new group name
1. Click the [Add Group] button. The Add Group window is
displayed.
2. Enter the group name.
3. Click the [OK] button to confirm it.
The registered group name is displayed on the Connection List.
Edit a group name
1. Select the required group name on the Connection List.
2. Click the [Edit] button. The Edit Group window is displayed.
1. Press INFO to display the System
Information window.
6. Enter the TCP/IP port number of the DVR/NVR. If it isn’t entered,
the port number is set by default.
7. Enter the User ID and Password. If you set the User ID and
Password, you can use the Auto connection function.
8. Click the [OK] button. The registered site name is displayed on
the Connection List.
Edit the Site Name
1. Select the required site name on the Connection List.
2. Click the [Edit] button. The Connection Setup window is
displayed.
3. Specify the Group Name, Type, IP Address, Port, User ID,
Password and click the [OK] button to confirm the settings. You
cannot edit the site name option.
Delete the Site Name
1. Select the required site name on the Connection List.
2. Click the [Delete] button. The selected site name is deleted.
3. Overwrite the existing group name with a new name that you
want.
Connect to the DVR/NVR
4. Click the [OK] button to confirm it.
1. Select the regContact office for compliance of this product :
Delete a group folder
1. Select the required group name on the Connection List.
2. Click the [Delete] button. The selected group name is deleted.
Deleting a group name will delete all site names within the
group name as well.
2. Click the right mouse button on the site name. Select the
[Connect] option. The site name is connected automatically and
the site name is activated. If the site name has no information
of the User ID and/or Password, the remote login window is
displayed. In that case, enter the User ID and the password.
LG Network Client Program
About the pop-up menu
•
User Log-In: Select to connect the DVR/NVR manually.
•
User Log-Out: Select to disconnect the site name.
•
Connect: Select to connect to the DVR/NVR automatically.
You should set the User ID and Password option of the
connection information setting menu for using this
function.
•
Disconnect: Select to disconnect to the site name.
53
Using the Live function
Camera View Tab
3. Repeat step 1 to 2 to connect the other site name.
NOTE
Up to 5 users can connect to the DVR/NVR system using the LG
Network Client program.
Connect the group device
1. Select the registered group name to connect it.
2. Click the right mouse button on the group name. Select the
[Connect] option. Each site name is connected automatically
and the site name is activated in the group name.
3. Repeat step 1 to 2 to connect the other group name.
1. Select the required site name or group name.
2. Click the right mouse button on the site name or group name.
Select the [Disconnect] option. The site name is disconnected
and deactivated.
3. Repeat step 1 to 2 for disconnection.
Export the connection list
1. Click [Export] button on the [Connection List]. [Connection List
Export] window will be displayed.
2. Select the folder on the computer to save the exported data.
3. Enter the export file name.
4. Click [Save].
Import the connection list
1. Click [Import] button on the [Connection List]. The open
window will be displayed.
2. Select and open the list file.
2. Select the activated site name and double click the left mouse
button or click the plus mark of the registered site name.
3. Select [Cameras] and double click the left mouse button or click
the plus mark.
4. Select the channel number you want to view.
5. Click the channel number and drag and drop to live window
position. If you select [Cameras] and drag and drop to a live
window then all channels are displayed.
6. Live image is displayed in the selected window.
7. Repeat steps 3 to 5 to set the other live windows.
5
LG Network Client Program
Disconnect the site name or group name
1. Select the [Camera View] tab in the live mode.
54
LG Network Client Program
Instant playback
NOTE
•
•
•
It is possible to play a recorded image without stopping recording.
To delete the camera from Live Window, Click desired channel
number on the [Cameras] and then drag drop where not Live
window position but other position.
Configuration of camera view is set the first time only. This
configuration setup is memorized for the next time and
displayed as it is.
About the camera view menu tree.
Displays the registered site name or
group name.
Displays the camera information .
1. Select the [Camera View] tab in the live mode.
2. Select a channel you want to playback.
3. Select the date.
The day is displayed in a blue text when recorded data exists.
4. Select playback start time.
When using timeline to search a start time, use the zoom in/out
icons for more detailed searches (4 step).
5. Select playback speed. Use the slider to select the playback
speed.
6. Start playback using these control buttons.
Click this button to jump to the beginning of the
data.
Displays the camera
channel name.
Click this button repeatedly to play frame-byframe playback in reverse.
Displays the
Resolution.
Click this button to play reverse or normal
playback.
Displays the Recording
Frame Rate.
Click this button to pause playback.
Displays the Quality.
5
Click this button to stop playback.
Displays the Recording
mode.
Click this button repeatedly to play frame-byframe playback.
LG Network Client Program
Displays the relay
output condition for
motion.
Click this button to jump to the last 1 minute of
the data.
Click this button to switch the speaker on and off
for the computer. The speaker button is activated
when the playback speed option is set to “1” and
the live window is set to 1 division mode.
Displays the Audio
information.
Displays the Sensor In information.
The microphone icon is not activated in playback
mode.
Displays the ON/
OFF condition of the
connected sensor.
Displays the relay
output condition for
the selected sensor
input.
Displays the camera
condition for the
selected sensor input.
Displays the Relay output information.
You can control the
relay output using the
mouse button.
1. Click the right
mouse button on
the relay output.
2. Select the ON or
OFF option.
3. The selected relay
is activated or
deactivated.
NOTE
•
If you don’t want to play with sound, click the speaker icon to
mute.
•
If you want to play with sound, the live window have to be set
to 1 division mode.
•
This function is permitted for Administrator group and other
group users who have the Search/Play authority.
Two-way audio controls
Two-way audio function is for transmitting and receiving audio
streams simultaneously in both directions.
You can transmit audio to the camera by connecting an
microphone of the computer. You can also play received audio from
the camera via a connected speaker on the computer.
These buttons are activated only when the live window is set to 1
division mode.
ON
OFF
ON
OFF
Click this button to switch the speaker on and off for
the computer.
Click this button to switch the microphone off and on
for the computer.
LG Network Client Program
Pan/Tilt/Zoom Tab
To Register Preset Positions
You can control the PTZ cameras via the network.
1. Move the camera to a point you wish.
1. Select the PTZ camera channel window in the camera view
mode.
2. Click the [SET] icon.
2. Select the Pan/Tilt/Zoom tab.
4. Click the
icon.
The position and its number are memorized.
3. Use virtual remote control buttons to control the PTZ camera.
3. Select the preset number you wish to register.
5. Repeat steps 1 to 4 to add additional positions.
NOTE
•
If someone is controlling a PTZ camera using the DVR/NVR,
you cannot use the PTZ function and vice versa.
•
This function is permitted for Administrator group and other
group users who have the PTZ authority.
Button
55
Function
Uses to pan/tilt the camera.
NOTE
Preset numbers from 0 to 255 are available on this unit but the
actual preset range differs depending on PTZ cameras.
Changing to a Picture in a Preset Position
The following function is available only with cameras provided with
the preset function. The preset function makes the combination
camera move to the programmed preset position. It is necessary to
program preset positions for the combination camera beforehand.
1. Click the [MOVE] icon.
Confirmes the preset position.
Selects the Pan/Tilt/Zoom
speed.
Adjusts the focus of a camera
manually.
Adjusts the iris of a camera
manually.
To Clear the Preset Position
You can clear a memorized preset position.
1. Click the [CLEAR] icon.
2. Use number buttons to enter the memorized preset index
number then click the
icon to clear the preset positions.
Displays the Selected Preset
number.
NOTE
This function may not be available depending on PTZ cameras.
To input the preset number.
To register preset positions.
To move the camera to the
preset position.
To delete a memorized preset
position.
To start a preset tour.
To display the setup menu of
the PTZ camera.
Preset Settings
Preset position is the function to register camera monitoring
positions (preset positions) associated with position numbers.
By entering the position numbers, you can move cameras to the
preset positions.
NOTE
To activate this function, you need to register the preset positions
of the PTZ cameras.
To Tour The Preset Positions
You can tour all preset positions.
1. Click the [TOUR] icon.
All registered preset positions in the camera will be selected
and the camera position image will be switched on the active
monitor.
2. You can stop the tour by clicking the [TOUR] icon.
Setup for PTZ Cameras
You can adapt the camera to your requirements by setting up the
respective items in menus.
1. Click the [SETUP] icon.
The setup menu appears in the selected window.
2. Use arrow and
buttons to set the options.
NOTE
•
Refer to the manuals of the PTZ camera for more details.
•
Some PTZ cameras may not be operated properly with this
program.
5
LG Network Client Program
Adjusts the camera zoom.
2. Use number buttons to enter the memorized preset position’s
index number then click the
icon. The camera moves to the
preset position and the picture of the camera in that position
appears on the monitor.
56
LG Network Client Program
Log View Tab
Edit the favorite
You can see the system log list of selected site name.
1. Select the registered favorite name and click the right mouse
button.
1. Select the [Log View] tab.
2. Click the
icon and select starting and ending date.
(The selectable date is displayed in blue color.)
3. Enter starting and ending time.
4. Select a log type from the drop-down list.
5. Click the
icon.
The system log is displayed in the list.
6. You can export the system log list as a file by clicking [Export]
button.
2. Select the [Edit Favorite] option. The Edit Favorite window is
displayed.
3. Overwrite the existing name with a new name.
4. Click the [OK] button to confirm it.
Delete the favorite
1. Select the registered favorite name and click the right mouse
button.
2. Select the [Delete Favorite] option. The selected favorite name is
deleted.
Using the Search function
NOTE
Options which do not support on this unit are deactivated.
Following features are deactivated for models LE4008,
LE4016, LE5008 and LE5016:
[Protect Search Tab], The motion direction button of the [Smart
Search Tab]
5
LG Network Client Program
Date/Time Search Tab
Searches a recorded picture by specifying date, hour and minute.
Favorites Tab
You can save the current configuration of camera view.
This favorite setup is useful for the next time to display it.
Time input column
Time line
Playback control buttons
Add the favorite
Displays selected channel number.
1. Select the [Favorites] tab.
2. Select the [Favorites] option and click the right mouse button.
3. Select the [Add favorite] option. The Add Favorite window is
displayed.
4. Enter the favorite name and click the [OK] button.
The entered favorite name is displayed under the Favorites
option.
Mark up when you want to view from all
camera channel windows.
1. Select the [Date/Time Search] tab.
2. Click the
icon and select the date.
(The selectable date is displayed in blue color.)
3. Select the activated site name and double click the left mouse
button or click the plus mark of the registered site name.
4. Select [Cameras] and double click the left mouse button or click
LG Network Client Program
the plus mark.
5. Select the channel number what you want to view.
6. Click the channel number and drag and drop to live window
position.
7. Select the time using the Time line and Time input column to
search recorded data.
3. Click the
the list.
icon. All bookmark (or Protect) data is displayed in
4. Select the data in the list.
5. Play the searched bookmark data using the playback control
buttons.
8. Play the searched data using the playback control buttons.
6. If you want to delete the bookmark/protect on the list, select
the recording data and click [Delete] button.
Event Search Tab
Smart Search Tab
Searches a recorded picture by date and event type.
57
Searches the recorded data by specifying the motion detection
conditions.
5
2. Click the
icon and select starting and ending date.
(The selectable date is displayed in blue color.)
1. Select the [Smart Search] tab.
3. Enter starting and ending time.
2. Click the
icon and select starting and ending date.
(The selectable date is displayed in blue color.)
4. Select the camera channel for event search.
3. Select a camera channel.
5. Select the event type.
4. Select the start time using the timeline.
6. Click the
icon.
The event list is displayed.
5. Enter the ending time.
7. Select the event from the event list.
6. Select a motion sensitivity level and drag and drop to select
motion area on the display window.
8. You can play the searched data using the playback control
buttons.
Bookmark/Protect Search Tab
Searches the recorded data included a bookmark or the protected
section.
Select the all area.
Cancel the selected area.
Selected area within red box.
7. Select a motion direction button.
8. Click the
icon.
The smart search data is displayed.
1. Select the [Bookmark/Protect Search] tab.
9. Select the event from the list.
2. Select the [Bookmark] or [Protect] from drop-down list.
10. You can play the searched data using the playback control
LG Network Client Program
1. Select the [Event Search] tab.
58
LG Network Client Program
Using the Remote Setup function
buttons.
ATM/POS Search Tab
You can set the DVR/NVR configuration of a selected site name
using this function.
Searches the recorded text information by ATM/POS device.
This function is available with backup data of the internal or external
HDD only.
NOTE
Options which do not support on this unit are deactivated.
Following features are deactivated for models LE4008,
LE4016, LE5008 and LE5016:
[System>Properties>Resolution], [System>Network>Bandwith
Throttle Setup>Per User], [Device>Camera>IP Enable], [Device>IP
Camera>Profile2, RTP Mode],
[Display>OSD>Channel FPS], [Event>Mail>Sender, JPEG
Attachment],
System settings
1. Select the [ATM/POS Search] tab.
5
2. Click the
icon and select starting and ending date.
(The selectable date is displayed in blue color.)
LG Network Client Program
3. Enter starting and ending time.
4. Select the camera channel for ATM/POS search.
5. Set the detail search options.
•
Item: Enter the text to search what you want.
•
COMP: Select the compare symbol for number search.
•
CON: Select the Boolean operator when you use the Text
search and Number search function simultaneously.
•
Value: Enter the number to search what you want.
•
Col: Enter the column.
•
Row: Enter the row.
•
Reset: Reset all items.
6. Click the
icon.
7. You can play the searched data using the playback control
buttons.
Date/Time
•
Date Format: Select the date display format.
•
Time Format: Select the time display format.
•
Time Zone: This option setting is not available in the client
program.
•
Daylight Saving: Mark up when you use the daylight saving
function.
•
Start Time: Select the Daylight Saving start time.
•
End Time: Select the Daylight Saving end time.
Properties
•
DVR/NVR Name: Enter the DVR/NVR name by using alphabetic
letter, numeric digit and symbols up to 21 characters. The
number of maximum characters is depends on the language.
•
Language: Select a language for the setup menu and
information display of the DVR/NVR.
•
Button Beep: Mark up to activate the button beep. The button
beep is activated when using the buttons.
•
Video format: These option settings are not available in the
client program.
•
Resolution: These option settings are not available in the client
program.
Reboot DVR/NVR server: Click the [Reboot DVR/NVR server]
button to restart the DVR/NVR. It takes some minutes for the
DVR/NVR to start again.
•
LG Network Client Program
NTP
• NTP: Mark up, if you want to synchronize the DVR/NVR’s date
and time with those of the time server called NTP (Network
Time Protocol) Specify the NTP server’s name.
• Time Server: For most cases select public. The DVR/NVR will
obtain the average time among 5 public servers (time.nist.gov,
time-a.nist.gov, time-b.nist.gov, ntp.nasa.gov, clock.isc.org).
• Private Time Server: Enter the private time server’s IP address or
host name.
• Sync. Interval: You can set synchronized intervals with the NTP
time server to 1 day, 1 hour, 1 month and 1 week.
Network
These option settings are not available in the client program except
the [Bandwith Throttle Setup] option.
• Bandwith Throttle Setup: Click the [Setup] button to display the
Bandwidth Throttle Setup window.
--
ALL: Set same bandwidth to all of users.
--
Per User: You can set the bandwidth value per each user.
Select [User ID] from the left drop-down list. And then, set
the bandwidth from right drop-down list
Device settings
Camera
•
Channel: Select the channel number.
•
Name: Enter the channel name by using alphabetic letter,
numeric digit and symbols up to 21 characters. The number of
maximum characters is depends on the language.
•
Audio: Select the input audio channel. You can hear from the
selected input audio channel. If you set to ON for the IP channel,
you can hear the input audio of the IP camera.
DDNS
These option settings are not available in the client program.
Network Streaming
1. Click the [Setup] button to display the Network Streaming
configuration window.
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution. Each group
such as “Ch1 to Ch8” and “Ch9 to Ch16” are set the same
resolution.
•
Quality: Selects the recording picture quality.
•
Frame Rate: Selects the frame rate. The frame rate is the
number of transportable frames per second. According to
resolution, the frame rate is set automatically. If you wish to
set manually, refer to the below.
Resolution
Frame Rate
352*240
1, 3, 5, 7.5, 10, 15
704*240
1, 3, 5, 7.5
704*480
•
IP Enable :
--
On : Uses the camera as a IP camera.
--
Off : Uses the camera as a Analog camera.
NOTE
If the [IP Enable] is set to [ON], you cannot set the [DevicePTZ], [Record-Normal], [Record-Sensor], [Record-Motion],
[Record-Text], [Record-Instant/Panic] and [Event-Motion]
options because they are deactivated.
IP Camera
•
Channel: Selects the desired channel to set the connected IP
camera.
1, 3
•
Driver: Selects the IP camera driver from the drop-down list.
352*288
1, 3, 5, 6, 7.5, 12.5
•
704*288
1, 3, 5, 6
Profile1: Select the camera stream on the drop-down box for
recording.
704*576
1, 3
•
Profile2: Select the camera stream on the drop-down box for
streaming. For smooth live playback, the resolution of [Profile2]
set lower than resolution of [Profile1].
2. Click the [OK] button to confirm the settings.
•
Host Name: Enter the IP address of the IP camera.
Controller
•
User Name: Enter the user ID.
•
IR Remote ID: Select the IR Remote ID for this unit. If you use
multi systems set the IR Remote ID for each DVR/NVR unit.
•
Password: Enter the user password.
•
Remote Controller ID: Select the Remote Controller ID for this
unit. If you use multi systems, set the Remote Controller ID for
each DVR/NVR unit. You can control the DVR/NVR by using
the LKD1000 controller. (For more details refer to the LKD1000
owner’s manual.)
•
Port RTSP/HTTP: Enter the RTSP/HTTP port number. HTTPS is
not supported.
•
RTP Mode: Selects the RTP mode from the drop-down list.
NTSC
PAL
ATM/POS Setting
•
Interface Device: Select the interface device from the dropdown list.
•
Camera: Select the camera number for mapping with ATM/POS
device.
•
Baud Rate: Select the desired parameter to set the
communication speed between DVR and ATM/POS device.
•
Data Bits: Select the number of the data bits for RS-485
communication.
5
LG Network Client Program
•
59
60
LG Network Client Program
•
Stop Bits: Select the desired parameter. The stop bit is added to
the last of data, in asynchronous communication.
•
Parity: Select the desired parameter. The parity bit is added to
the data, to perform parity check.
Storage
• Overwrite:
-- All: Overwrite recording is possible when the partition of
HDD have fully recorded.
-- Normal Partition: Overwrite recording is possible for normal
partition of HDD when the normal partition of HDD has fully
recorded.
-- Event Partition: Overwrite recording is possible for event
partition of HDD when the event partition of HDD has fully
recorded.
-- Off: Do not use overwriting.
• Full Warning: When the HDD has overflowed a warning message
is displayed.
• Auto Delete: Set the auto delete date. If you set the auto delete
date, the recorded data will be deleted except the data within
the selected date period of time. The Auto Delete function is
activated every 35 minutes.
• Event Partition: This option setting is not available in the client
program.
5
Display settings
•
Channel: Selects the desired channel to adjust.
Channel Composition
•
Name: Selects the desired channel.
PTZ
Settings for the PTZ cameras connected via the data port of the
RS-485 terminal.
LG Network Client Program
•
Port: Selects the connected data port of the RS-485 terminal
on the rear panel. The DATA 2 port is used to control the PTZ
camera connected to DVR or to control by using the LKD1000
controller. If you want to use the PTZ camera via DATA 2 port,
you should set the [Remote Controller ID] to [NONE]. If you use
the LKD1000 controller to control the DVR via DATA 2 port, you
should set the [Remote Controller ID] number between 1 and
16. When you select [COAXIAL COMMUNICATION], [Protocol]
option is set to [PELCO_C] automatically and [Control ID], [Baud
Rate] options are deactivated.
•
Control ID: Selects the PTZ camera ID. Make the same settings
as the PTZ camera.
•
Protocol: Selects the protocol supported by PTZ camera.
•
Baud Rate: Selects the communication speed.
Video Adjustment
Adjust the brightness, contrast and color settings of each camera
channel. You can see the settings screen from the preview windows.
•
Brightness: Adjust the brightness value from 0 to 100 for the
selected channel.
•
Contrast: Adjust the contrast value from 0 to 100 for the selected
channel.
•
Color: Adjust the color value from 0 to 100 for the selected
channel.
LG Network Client Program
Motion Settings
•
Sensitivity: Set the sensitivity level for the created motion
detection area.
•
Relay Output: Select the number of the RELAY-OUT terminal for
the output alarm (relay) signal when motion is detected.
•
Area: The factory default of the Motion detection area is set as
the whole area. You can change the area by using mouse on the
preview window screen.
--
Select All: Click one point with the left mouse button and
drag & drop to the end point.
--
Clear All : Click the start point with the right mouse button
and drag & drop to the end point.
61
Record settings
NOTE
•
If you want to display the grid, mark up the [Show Grid]
option.
•
If you want to select the entire area, click the [Set All] button
or click the [Clear All] button to cancel the selected area.
1. Select a day of the week.
2. Mark up the desired recording option.
N : No schedule recording.
•
You can view all the channels in sequence in the selected screen
division mode. While the sequence mode condition, if you change
the screen division mode, the sequence function will be canceled.
C (Continuous recording): Recording starts automatically
from the preset time.
•
S (Sensor event recording): Recording starts automatically
when the sensor alarm occurs within a designated time.
•
Main Dwell Time: Selects the channel sequence time for main
monitor.
•
M (Motion event recording): Recording starts automatically
when motion is detected within a designated time.
•
Spot Dwell Time: Selects the channel sequence time for spot
monitor.
•
T (Text event recording): Recording starts automatically
when text input is detected within a designated time.
•
S+M (Sensor+Motion recording): Recording starts
automatically when the sensor alarm signal has been input
or motion has been detected.
•
C+S (Continuous+Sensor event recording): Recording starts
automatically from the preset time. When the sensor alarm
occurs within a designated time, changes the continuous
recording mode to sensor event recording mode and
recording starts automatically.
•
C+M (Continuous+Motion event recording): Recording
starts automatically from the preset time. When the
motion is detected within a designated time, changes the
continuous recording mode to motion event recording
mode and recording starts automatically.
•
C+T (Continuous+Text event recording): Recording starts
automatically from the preset time. When the text input
occurs within a designated time, changes the continuous
recording mode to text event recording mode and
recording starts automatically.
•
C+S+M (Continuous+Sensor+Motion event recording):
Recording starts automatically from the preset time. When
the sensor alarm signal has been input or motion has
been detected, changes the continuous recording mode
to motion event recording mode and recording starts
automatically.
•
S+M+T (Sensor+Motion+Text event recording): When
the sensor alarm signal has been input, motion has been
detected or the text input occurs and then recording starts
automatically.
•
C+S+M+T (Continuous+Sensor+Motion+Text event
recording): Recording starts automatically from the preset
time. When the sensor alarm signal has been input, motion
has been detected or the text input occurs within a
designated time, changes the continuous recording mode
to occurred event recording mode and recording starts
OSD
•
Channel Name: Mark up to displays or removes the channel
name in the channel window.
•
Channel FPS: Mark up to displays or removes the channel FPS
(Frame Per Seconds) in the channel window.
•
Channel Status: Mark up to displays or removes the channel
status in the channel window.
•
Font Size: Selects the font size of characters such as the channel
name and playback time which displayed on the channel
window.
•
Position: Selects the position of characters such as the channel
name and playback time which displayed on the channel
window.
5
LG Network Client Program
•
Sequence
62
LG Network Client Program
automatically.
Event Settings
3. Select the desired channel to schedule recording.
4. Click the start time cell block and drag & drop to select a time
period cell block.
or
Click the start time cell block of a channel and drag & drop
across the channels to select the time period block for multichannel setting at the same time. The color of the cell blocks
will be changed.
Schedule day copy settings
1. Select the source day to copy.
2. Click the [Schedule Copy] button to display the schedule copy
setup window.
3. Select the destination day from the day of the week, weekday or
weekend options.
4. Click the [Copy] button on the Day Copy option to copy the
scheduled data of the day.
Schedule channel copy settings
1. Select the day.
2. Click the [Schedule Copy] button to display the schedule copy
setup window.
Sensor
1. Click the [Setup] button.
2. Set the below options.
3. Select the source channel.
5
4. Select the destination channel.
LG Network Client Program
5. Click the [Copy] button on the Channel copy option to copy the
scheduled data of the channel.
Schedule Configuration Settings
1. Click the one of the buttons to display the recording setting
window.
•
In: Displays the number of the ALARM-IN terminal.
•
Sensor Type: The sensor state can be set to either N.O.
(Normally Open) or N.C. (Normally Closed).
•
Camera: Select the camera channel connected to the
ALARM-IN terminal.
•
Output: Select the alarm (relay) output number for the
RELAY-OUT terminal for the output alarm (relay) signal.
•
Preset: Select the preset number. When the input is
activated, the camera moves to the selected preset position
and the picture of the camera in that position appears on
the monitor.
2. Set the detail options.
3. Click the [OK] button to confirm the settings.
To add the Special day
3. Click the [OK] button to confirm the settings.
1. Mark up the [Special day] option.
ATM/POS Format
The DVR can be set to react to text input from devices such as
ATMs (Automated Teller Machines) and POS (Point of Sale; i.e., cash
registers). This screen allows you to configure the DVR for your input
device.
2. Click the [Add] button.
3. Enter the name of the special day. You can set the name as
Korean or Japanese.
4. Select the date to set the special day schedule and click the
[Add] button. The special day is added to the list.
5. Mark up the desired recording option.
•
Input Channel: Select the mapping camera channel.
•
Transaction Start: Enter a Transaction Start string. Refer to the
device manufacturer’s documentation for the text string that
the device first sends when a transaction starts.
•
Transaction End: Enter a Transaction End string. Refer to the
device manufacturer’s documentation for the text string that
the device sends when a transaction ends.
•
Delimiter: Enter the character(s) that the device uses to
indicate the end of a line. Refer to the device manufacturer’s
documentation for Line Delimiter character(s).
•
Ignore String: Enter the any strings of text that you want the DVR
to ignore. Refer to the device manufacturer’s documentation
for text strings that the device sends during transactions, so you
will know which ones you do not want recorded.
•
Time Out: Select the Recording end time.
•
Relay Output:
6. Set the schedule time for each channel(s).
To edit the Special day
1. Select a special day title on the list.
2. Click the [Edit] button.
3. Select the date to change the special day schedule and click the
[Edit] button.
4. Change the schedule time for each channel(s).
To delete the Special day
1. Select a special day title on the list.
2. Click the [Delete] button.
--
01 to 04: Outputs the alarm (relay) signal via the RELAY-OUT
terminal. When the DVR detects text input, it triggers output
signals on all the associated Alarm-Out connectors.
--
Off: Not used.
LG Network Client Program
NOTE
•
ATM/POS Recording Information.
Sensor On: Sends an e-mail when a sensor has occurred.
Recording is started automatically
When the Transaction
when the Transaction start data is
Start and Transaction End detected. When the Transaction
options are set.
end data is detected, the recording
is stopped after post-alarm time.
•
Motion Detection: Sends an e-mail when an motion detection
has occurred.
•
Text In: Sends an E-mail when the text input is detected.
•
Admin PW Changed: Sends an e-mail when the administrator
password has been changed.
Recording is started automatically
when the transaction data is
When the Transaction
detected. When the transaction
Start and Transaction End data is not detected, the recording
option is not set.
is stopped after post-alarm time
and the time you set in the Time
Out option.
•
Video Loss: Sends an e-mail when a video signal from the
camera has stopped because of a cable disconnection or
malfunction of a camera.
•
Power On/Off: Sends an e-mail when power is on or off.
•
Disk Full: Sends an e-mail when the HDD has fully recorded.
ATM/POS Recording Action
Event Popup
•
Notification
Mark up when you want to activate the selected option. If the
selected notification option is activate, notify the user about the
information of selected option by E-mail.
•
Option setting
Spot Monitor: Select the event type for the spot monitor display
when the event is activated.
Mail
Buzzer
Mark up when you want to activate the selected option.
•
Sensor: Makes a sound when a sensor occurs.
•
Motion : Makes a sound when a motion is detected.
•
Text: Makes a sound when the DVR detects text input .
•
System: Makes a sound when a cooling fan is not activated or
the HDD has bad sector.
1. Click the [Setup] button.
2. Set the below options.
•
•
Notification: Mark up to be notified the unit's operating
information according to notification settings by e-mail.
If notification option is not set, the other options cannot be
set.
•
Data cannot be saved in HDD which is occurred bad sector.
But if HDD is installed more than 2 on this unit, data is saved in
other normal HDD.
•
When HDD has bad hold, can not operate normally. Replace
the HDD immediately .
--
SMTP Server: Enter the SMTP Server address.
--
SMTP Port: Enter the SMTP Port Number. Typically the
port used for SMTP is 25. However in some cases it is
better to change this port number for added flexibility
or security. You can edit this port between 1 and 65 535.
SNMP
--
User Name: Enter the user name.
2. Set the below options.
--
Password: Enter the password.
•
TLS: Mark up if you want to use the TLS (Transport Layer
Security) function.
SNMP Version: Selects a SNMP version if SNMP is allowed to
access to this device.
•
Port: Enter the number for SNMP port.
--
Mail Address (1 to 3): Enter the mail address.
You can input up to 3 e-mail addresses.
•
--
Sender : Enter the sender.
Community String (V2 only): Specifies the SNMP management
community in which you want to enable this system (e.g.
lgecommunity or public).
•
User (V3 only): Enter the security name for the SNMP.
•
Authentication (V3 only): Select a mode for the SNMP
Authentication. (MD5 or SHA)
•
Password (V3 only): Enter the password for the SNMP
Authentication.
•
Privacy (V3 only): Select a privacy mode for the SNMP
Authentication. (DES or AES)
•
Password (V3 only): Enter the password for the privacy mode.
•
Trap IP Address: Specifies the IP address of the computer you
intend to use as your network management station and to
which SNMP traps will be sent.
•
Trap Community String (V3 only): Specifies the SNMP trap
community in which you want to enable this system (e.g.
lgecommunity or public).
JPEG Attachment: Click the check box to send a mail which
want to attach a JPEG file.
NOTE
•
NOTE
The SMTP server, SMTP port no., user name or password
settings are optional. The DVR can send e-mail directly without
the use of an SMTP server or MTA (message transfer agent).
In certain cases all e-mail should be forwarded to a specific
SMTP server. Specify the server host name or IP address in
such a case. For more detail on SMTP setup, ask your network
administrator and/or mail service provider.
•
[JPEG Attachment] option is operated when event of [Sensor
In], [Motion Detection] and [Text In] is occurred.
•
In case of an IP Camera, ONVIF JPEG Snapshot feature must be
supported to attach a JPEG file.
3. Click the [OK] button to confirm the settings.
1. Click the [Setup] button.
5
LG Network Client Program
•
63
64
LG Network Client Program
Emergency
User Settings
1. Click the [Setup] button.
2. Set the below options.
•
Notification: Mark up to be notified the emergency agent
about the unit's operating information according to your
notification settings.
•
Host Name/Port: Enter the Host Name and port number of
the emergency agent program. The factory default port for
this function is 9002. However in some cases it is better to
change this port number for added flexibility or security.
You can edit this port between 1 025 and 65 535.
You can set up to 9 Host Name and port numbers.
3. Click the [OK] button to confirm the settings.
Output
•
•
5
Relay Off
--
Alarm Acknowledged: Use the ALM.OFF button to stop
alarm.
--
Post Alarm Time: The alarm is stopped after post-alarm time.
System Alarm Out: Outputs the alarm (relay) signal via the
selected alarm out terminal number when the system has some
problem. If you do not use this function, select [None] option.
LG Network Client Program
•
HDD Fail Alarm Out: Outputs the alarm (relay) signal via the
selected alarm out terminal number when the HDD is failed. If
you do not use this function, select [None] option.
•
Video Loss Alarm Out: Outputs the alarm (relay) signal via the
selected alarm out terminal number when a video signal from
the camera has stopped because of a cable disconnection or
malfunction of a camera. If you do not use this function, select
[None] option.
•
Fan Fail Alarm Out: Outputs the alarm (relay) signal via the
selected alarm out terminal number when the fan is failed. If
you do not use this function, select [None] option.
Group Authority
You can register a new user group with various access rights.
•
Group ID: Select the group ID to assign authority.
--
Guest: The GUEST group has the limited authority of the
system. Users in this group are available to see the live
image and to set the covert function of the Main or Spot
channel.
--
Administrator: The ADMINISTRATOR group has the unlimited
authority of the system. Users in this group are available to
use all of the functions.
--
[Group 01] to [Group 08]: Users in this group are available to
set the authority of the function manually.
NOTE
The GUEST and ADMINISTRATOR group are set initially for the
authority of all functions. You cannot change the initial settings
and group name (GUEST and ADMINISTRATOR).
•
Group Name: If you select a one of the group number from the
Group ID option, you can register the group name. Enter the
group name.
--
•
Group Setup, Search/Play, Export, PTZ, Power Off, Instant
Record: Set the authority for the selected group. Mark up
the option to activate it.
Main Channel/Spot Channel: Selects the channel to allow the
operation for the group user. The LG logo is displayed on the
covert channel(s).
User
1. Select the [User ID] from the drop-down list.
2. Enter the user name of the selected user ID.
3. Select the user group from the drop-down list.
4. Enter the Password.
5. Select the auto user logout time from the drop-down list.
NOTE
If you set the user ID to [ADMINISTRATOR], you cannot change
the [User Name] and [Group] option but you can change the
password.
LG Network Client Program
Using the Export function
How to export the data
You can copy the recorded images and audio data from the DVR/
NVR unit to the PC. This function is permitted for Administrator and
other group users who have the Export authority.
2. Select the audio option.
65
1. Set the Channel options. You have to select more than one
channel.
•
On: Select when the Audio data is exported.
•
Off: Select when the Audio data is not exported.
3. Set the Date/Time options.
4. Select the folder on the computer to save the exported data.
5. Select the data type.
6. Click [Add] button. The list of the configured server, start time,
end time and Status appears.
7. Select the registered export setting schedule in the list.
8. Click the [Export] button to begin the export.
The export status will be displayed on the Status column.
NOTE
Server: Displays the selected server name.
•
Channel: Select a channel(s) to export the data.
•
Audio: Set to On or Off to export the audio data.
•
Start: Set the start date/time to copy.
•
End: Set the end date/time to copy.
•
Save Path: Displays the current exported data save folder. You
can select (or make) the folder on the computer to save the
exported data. The initial save folder is “C:\LG Exported Files”. If
you want to change the storage folder, click the [...] button and
select the new folder.
•
The exported data file name is made automatically as the
[Server name_Channel number_export start time.exp(or “avi”)]
type.
•
If you do not assign the export directory, the export directory
will be set to default directory and sub directory will be
created with start date.
•
If you log-out from the network client, the export sequence
will be terminated.
•
If you set the time for data that does not exist, the export
function is not activated.
•
The warning message appears for the conditions listed below.
Data Type: You can select the saving file format.
--
Native: The Native file is saved with the extention of “*.exp”.
The saved native file can playback using the Export Viewer
program.
--
AVI LG: To playing AVI LG file, you have to install the LG DVR
Codec. If you install the LG Network Client, do not need to
install the LG DVR Codec.
--
AVI: If you select AVI file format, it can play on any media
player.
•
Add: Adds the export setting schedule to the list.
•
Edit: Edits the selected export setting on the list.
•
Delete: Deletes the selected export setting schedule from the
list.
•
Export: Click to start the data exporting according to the
selected export setting.
•
Cancel: Click it to cancel data exporting.
•
Exit: Click to exit the window.
•
--
When the start date/time and end date/time are the same.
--
When the start date/time is later than the end date/time.
--
When the channel is not selected.
When you export the data by using the LG network client
program, the log information will not be exported.
5
LG Network Client Program
•
•
66
LG Network Client Program
Using the E-Map function
Add the Map
This function gives a visual overview of the cameras in your
surveillance environment.
1. Click the [Add E-Map] button. The Add E-Map window is
displayed.
E-Map Overview
3. Find and open the map image file. If you want to change the
E-Map name, select the [E-Map Name] option and overwrite the
existing name with a new name.
Map View Division Mode selection icons
E-Map setup icon
E-Map View window
2. Click the [...] button in the [E-Map path] option.
4. Drag-and-drop camera channel or sensor on the Map.
NOTE
To delete the registered camera or sensor, follow these steps:
4.1 Select the camera or sensor.
4.2 Click right mouse button on the selected camera or sensor.
4.3 Select [Delete] option to delete it.
5. Click the [OK] button to save settings and close the window.
6. Repeat steps 1 to 5 to add the other E-Maps up to 16.
Activate the Map
1. Select the required E-Map from the E-Map List.
2. Drag and drop the E-Map on the required position of the E-Map
View window.
5
3. Repeat steps 1 to 2 to activate the other E-Maps.
LG Network Client Program
Edit the Map
1. Select the required E-Map from the E-Map View window.
Event list
Current event live view window
E-Map List
•
Map View Division Mode selection icons: When the icon is
clicked, the screen will be changed to split mode. Choose the
Map View division mode.
•
E-Map setup icon: Click to set the operation time.
•
E-Map List: Displays the imported E-Maps.
•
E-Map View window: Use the map of the E-Map list to register
each channel. If you click the camera or sensor of the displayed
on the map, you can view the image of the camera or sensor.
2. Click the [Edit E-Map] button. The E-Map View window is
displayed.
3. Edit the camera position or E-Map name, or delete the camera.
4. Click the [OK] button to save E-Map and exit the window.
Delete the Map
1. Select the required E-Map from the E-Map List.
2. Click the [Delete E-Map] button. The selected E-Map is deleted.
Delete the event
1. Select the event in the event list.
2. Click the [Delete List] button to delete the event.
If you select the [Select All] option, all events are deleted.
LG Network Client Program
Using the Multiple Window function
This function allows you to see a live screen maximum 64 channel
by using two monitor.
1. Click the
67
Additional Programs
to change to the live mode.
2. Select the [Mutiple Window] option on the [Tools] menu.
The [Live 2] window appears.
Emergency Agent Program
The system sends a message according to the Notification and
Emergency settings in the event setup menu.
Emergency Agent Overview
Displays the received message list.
Detailed view of the received message.
3. Move the [Live 2] window to the second monitor.
[Live 2] window shows the camera channels that is not visible in
the main window.
5
LG Network Client Program
Deletes the selected
message from the list.
NOTE
•
The [Live 2] window will be closed if you select the Search,
Setup or 64 split mode.
Closes the [Received Messages]
window.
Refreshes the received
message on the list.
Displays the search window.
Displays the port change window.
68
LG Network Client Program
To activate the Emergency Agent program
1. Run the [LG Emergency Agent] program. The Emergency icon is
displayed in the system tray.
2. Whenever a notification function occurs, a message box is
displayed on the bottom right of the screen.
The message box is displayed for 5 seconds.
3. Check the message.
4. Click the message box within 5 seconds to display the [Received
Messages] window.
or
Right click the mouse on the program icon in the system tray
and select the [Check Message Box] option to display the
[Received Messages] window.
Export Viewer Program
You can play back the exported data on the PC using this program.
The export viewer program is saved automatically in the external
storage when you install the client program or export the data. You
can adjust the size of Export Viewer window by dragging the edge
of window.
Export Viewer Overview
Menu Bar
5. You can check all the subjects of received messages.
6. Click the [CLOSE] button to close the [Received Messages]
window.
Port Setting
1. Click the [Setup] button. The option window is displayed.
2. Enter the port number of the emergency agent listening port.
The factory default port is 9002. However in some cases it
is better to change this port number for added flexibility or
security.
5
3. Click the [OK] button to exit.
LG Network Client Program
Message Search
1. Click the [SEARCH] button. The message search window is
displayed.
2. Select the search method.
•
Event Search: Searches by selected type of event for the
message.
•
Date Search: Searches by selected date.
3. Click the [Search] button.
The search message is displayed on the [Received Messages]
window.
Delete the Message from the List
Video Information window.
Playback control buttons.
Option setting window.
Progressive bar
Menu Bar
1. Select the message(s) you want to delete.
Menu
2. Click the [DELETE] button. The confirmation window is
displayed.
File
3. Click the [Yes] button to delete the message(s).
Sub-Menu
Description
Open
Opens the data file.
Print
Prints the current playback image.
Save to JPEG
You can capture and save the current
image in JPEG file format.
1. Play the recorded data.
2. Pause the playback at a desired
point during playback.
3. Select this option. The JPEG
Export window is displayed.
4. Set the options.
5. Click the [Save] button.
View
Help
Exit
Exits the program.
Language
Select the language for Export Viewer
program.
Video Size
Select the video size of the data file.
Date Format
Select the date display format.
About Export
Viewer
Displays Export Viewer information.
LG Network Client Program
Playback control buttons
Jumps to the beginning or end of the file.
Click this button repeatedly to play frame-byframe playback in reverse.
Click this button to play reverse or normal
playback.
Click this button repeatedly to play frame-byframe playback.
Web Viewer Program
Logging in the Web Viewer
1. Start the web browser. The recommended browser is Internet
Explorer with Windows.
2. In the Address Box, enter “HTTP://” and the IP Address of the
DVR. You can use the Host Name that you entered in the DDNS
setup menu of the DVR.
Pauses playback.
3. Press OK button on the keyboard and then the Web viewer and
the Remote Login menu will be displayed.
Stops playback.
5. Click the [OK] button.
4. Enter the User Name and Password.
NOTE
Option Setting window
•
Set Watermark: The warning window will appear with watermark
option, if the file which is in playback differs from the file that is
originally recorded.
•
DVR/NVR Time: If you check this option, the time of the
DVR/NVR time zone is displyed during playing back the
exported file . If not, the time of the client time zone is displayed.
69
•
If the Web Viewer is not displayed, check the TCP/IP settings of
the DVR.
•
If you connect the DVR for the first time, the Security Warning
window is displayed. You must click [Install] on the Security
Warning window to install the program for use the Web
Viewer. If you click [Don’t Install], the Web Viewer program is
not available.
Video Information window
File Name: Displays the file name.
•
Video Format: Displays the video type of the data.
•
Recording Mode: Displays the save mode of the data.
•
Camera Number: Displays the camera channel number of
recorded data.
You can control the live image using the Web Viewer.
Displays the live view workspace.
•
Camera View: You can see the
surveillance camera’s images in
the window(s) and the camera
information.
•
Pan/Tilt/Zoom: You can control the
PTZ camera.
To play the exported data
1. Run the LG Export Viewer program on the PC or in the Export
Viewer folder of the external USB device.
If you insert the exported data CD or DVD disc, the export
viewer program run automatically.
2. Select [File] > [Open]. The open window is displayed.
3. Select the root directory of the USB device and search&select
the desired file.
An example of playable file format is “Channel name_date_time.
exp”.
4. Click the [Open] button. The selected data is played back
automatically.
5. Select playback speed. Use the slider to select the playback
speed.
6. Click the [STOP] button to stop playback.
5
Web Viewer Overview
Displays the search workspace. You can
search and play the recorded data using
the search functions.
Click to display the WebViewer Control
Properties pop-up windows.
Click to display the Remote Export popup windows.
You can view the live window in full
screen mode. To return to the normal
screen, click the right mouse button.
Screen Mode selection icons.
To play the AVI file on a media player
•
The exported data of [AVI LG] file format is always displayed
OSD. To playing AVI LG file, you have to install the LG DVR Codec.
•
If you select AVI file format, it can play on any media player. But
OSD may not be displayed on some media player.
•
It is recommended that the exported AVI file play on the
Windows Media Player.
Progressive bar
You can search the image directly using the progressive bar.
Click and hold the Slider bar and move to the other point you want
and then release it. Or, Click the point on the progressive bar you
want to playback.
You can view all the channels in
sequence. You cannot use sequence
mode with the 16 split.
LG Network Client Program
•
70
LG Network Client Program
You can capture and save the current
image in JPEG file format. The initial save
folder is “C:\LG Exported Files”. If you want
to change the storage folder, set the
[Save Path] option on the WebViewer
Control Properties Window.
Event Search
1. Select the channel window.
4. Select the camera channel for event search.
2. Mark up the selected channel name.
5. Select the event type.
3. Search the recorded data and then
play the recorded data.
6. Click the
icon.
The event list is displayed.
4. Click this button when you want to
capture the current image.
7. Select the event from the event list.
Live screen display window.
1. Select the [Event Search] tab.
2. Click the
icon and select starting and ending date.
(The selectable date is displayed in blue color.)
3. Enter starting and ending time.
8. You can play the searched data using the playback control
buttons.
Using the WebViewer Control Properties window
Displays current date and time, user
information and the remaining HDD
status of the selected site name.
Live screen control
5
LG Network Client Program
•
Left mouse button: Select the channel. If you want to set the 1
split mode, double click the selected channel. To return to the
normal screen double click again.
•
Right mouse button: If you want to exit the full screen mode,
right click the mouse to return to the normal screen.
1. Click the [Setup] button.
WebViewer Control Properties window is displayed.
2. Set the below options.
•
OSD: Mark up to display or remove the selected option in
the channel window.
•
Sequence: Selects the channel sequence time.
•
Video Display: Mark up when using the DirectX function.
•
Snapshot Save Path: Displays the storage folder for the
captured image file. If you want to change the storage
folder, click the [...] button and select the new folder.
3. Click the [OK] button to exit.
PTZ View control
1. Click the [Pan/Tilt/Zoom] tab. The PTZ virtual remote control is
displayed.
2. Use virtual remote control buttons to control the PTZ camera.
Playback of Recorded Data
1. Select the camera’s display window.
2. Select the date.
The day is displayed in a blue text when recorded data exists.
3. Select playback start time.
When you use the time line to search a start time, use the zoom
in/out icons for more detailed searches (4 steps).
4. Select the channel you want to playback. If you check “Select All”
option, you can playback the all channels simultaneously from
all camera channel windows.
5. Select playback speed.
6. Start playback using these control buttons.
NOTE
This function is permitted for Administrator and other group users
who have the Search/Play authority.
Copylight Information
The Video decoder used in this client program of the product
has modified by using the FFmpeg (http://ffmpeg.sourceforge.
net) and the FFmpeg License is follow the LGPL.
The source of the modified FFmpeg has included on the
accompanying CD.
Troubleshooting
71
6
Troubleshooting
Check the following guide for the possible cause of a problem before contacting service.
Symptoms
Resolutions
Check the power cable is connected correctly.
The system power does not
turn on.
Check the input voltage is correct.
If the system power does not turn on even if the power cable is connected correctly, please contact the
service center.
Check the monitor power cable is connected properly.
The system power is turned on
but no video data is displayed
on the monitor.
Make sure the monitor is turned on.
Check the video output cable of the LG DVR is properly connected to the monitor.
Unplug the power cable and plug in again.
6
The camera numbers are
displayed on the screen but the
camera images are not
displayed.
Check the power cable on the camera is connected correctly.
Check there is no problem with the video cable connection from the camera to the LG DVR system.
Turn off the DVR system and turn it on again.
Check the recording mode in the record setting menu.
The camera video is shown on
the screen but the system does
not record the video.
Check the HDD detection status in the System Information window.
If the HDD detection status is abnormal, check the HDD formatting and the connection of the HDD.
Check the recordable disk space in the HDD.
Check the overwrite option in the setup menu for overwrite recording.
Check if there is recorded video data at the time that you are trying to search on the table.
If there is no recorded video data, check the recording mode in the record setting menu.
It is impossible to search
through the recorded video.
Check the HDD detection status in the system information window.
If the HDD detection status is abnormal, check the HDD formatting and the connection of the HDD.
Check the user type. The search function is not available for a normal user.
Troubleshooting
Check the camera video output is connected to the DVR system correctly.
72
Troubleshooting
Symptoms
Resolutions
Check the audio recording option is correctly set for the camera you wish to record audio.
Audio data recorded with
video data is not playing.
Check the speaker and audio (line input) on the rear of system are connected correctly.
Check the connected speaker is working properly.
If the camera connected to the system has a problem, make sure that the camera is not damaged by
trying another camera into a working video output.
The colors of some camera
videos are strange or videos
are displayed abnormally.
Check the video format setting of the unit is the same as the connected camera’s video format.
Depending on your region, the camera’s video format can support either PAL or NTSC. Depending on the
camera’s video format, the video process can differ greatly, therefore it can be difficult to recognize the
video data if the video format setting is different from the camera’s video format.
Check if the video signal output from the camera has a problem. Ensure the camera is not damaged by
trying another camera with a working video output.
Check if the video cable connection between the camera and the DVR is cut, crosswired or shorted.
There is a lot of (screen) noise
accompanying the image.
Check if there is a high voltage wire around the video cable connection between camera and DVR
system. It can cause interference and affect video quality.
Check the video cable connection between the camera and the DVR system is the correct video cable.
When a normal power-supplying cable is used instead of the video cable, screen noise can be generated.
Check the type of sensor in the camera setting is the same as with the connected sensor.
6
The connected sensor is not
operating.
Check the system is set to use the sensor in the recording schedule window in the recording setting
menu.
Troubleshooting
Check the sensor is properly connected to the ALARM-IN.
Check the system is set to use the PTZ camera in the camera setting menu.
Check the power cable of the PTZ camera is properly connected.
The connected PTZ camera is
not operating.
Check the signal cable of the PTZ camera is properly connected.
Check the selected channel to control the PTZ camera.
Check the user type. The PTZ camera control is not available for a normal user.
Troubleshooting
Symptoms
73
Resolutions
E-mail reception failed without SMTP server setting.
•
Make sure the network is correctly set.
•
Make sure the mail address is input correctly.
•
Check the spam mail setting of the inputted mail address.
(If you set the spam mail, some mails are deleted automatically or classified in the spam mail box)
•
Some of SMTP mail services do not support an E-mails from private SMTP servers. In this case use the
public SMTP server.
E-mail reception failed even if the SMTP server was set.
An E-mail sent from this
product was not received.
•
•
•
The remote control does not
work properly.
When the [Please check the SMTP information or internet cable] message is displayed.
--
Check the SMTP server address.
--
Check the SMTP port number. (Default setting is 25)
--
Check the network settings.
When the [Please check the authentication information] message is displayed.
--
Check the user name.
--
Check the password.
The mail reception failed without error message.
--
Check the receiver’s mail address.
--
Check your E-mail is not classified as a spam mail on the receiver's mail setting.
Check the batteries in the remote control.
Check the ID setting for the remote control (See the page 29).
NOTE
•
Some of the front panel LEDs do not light.
•
The DVR does not operate normally.
You can reboot the DVR as follows:
1. Turn off the DVR and turn it on again after a few seconds.
2. When the recorder does not work normally after rebooting, contact the service center.
Troubleshooting
If you observe any of the following symptoms:
6
74
Appendix
7
Appendix
Recommended Devices
Recommended USB Memory list
No.
Maker
Model Name
Capacity
1
LG Electronics
XTICK Mini Slide / Slide
1 G/2 G/4 G
2
IOCELL
CellDisk Swing
1 G/2 G/4 G/8 G
3
Sony
MicroVault
1 G/2 G/4 G
4
HP
S100 / M100 / V210W
1 G/2 G/4 G
5
SANDISK
Cruzer Micro
512 M/1 G
6
TRANSCEND
JF
1 G/2 G
7
IMATION
Flash Drive Nano / Icon
1 G/2 G
8
Samsung Electronics
Classic&Simple
1 G/2 G/4 G/8 G
NOTE
Some USB memory devices other than the ones on the above table may not work properly, even if this DVR reads them.
Recommended External Device list
7
Device
Capacity
Backup search function for the
client program
File system
Appendix
USB HDD
Up to 1 TB.
FAT 32 (This file system is compatible with Windows and Linux
system.)
Yes
E-SATA HDD
Up to 2 TB.
EXT4, XFS (Linux file system)
This file system is not compatible with Windows system.
No
NOTE
The E-SATA device with the FireLynx Series of Malgn Technology is supported only for data storage. Other device or manufacture may cause a
malfunction.
Recommended CD/DVD Media list
Maker
CD-R
CD-RW
DVD-R
DVD-RW
DVD+R
DVD+RW
Imation
O
O
O
O
O
O
Memorex
O
O
O
O
O
O
MITSUBISHI
O
O
O
O
O
O
PHILIPS
O
O
O
O
O
O
SONY
O
O
O
O
O
O
Verbatim
O
O
O
O
O
O
NOTE
8 cm (1.4 GB) Mini CD/DVD and the Dual Layer type media (DVD) are not supported.
Appendix
75
Supported function list for device
Device
Instant backup
Schedule backup
Export
Configuration Import/Export
CD/DVD
O
X
O
X
USB memory
O
O
O
O
USB HDD
O
O
O
O
E-SATA HDD
O
O
O
O
NOTE
If you use a USB memory stick or USB HDD for configuration import/export you must disconnect the other external USB devices.
Supported PTZ Camera list
Maker
LG_MULTIX
LG
LG_MULTIX EXTENTION
LG
LG_SD168
LG
LG_LS903
LG
LG_ZOOM
LG
LPT_A100L
LG
PELCO_D
PELCO
PELCO_P
PELCO
GANZ_DSCP
CBC
GANZ_P360V1
CBC
GE KALATEL_CYBERDOM
KALATEL
PANASONIC_CS850
PANASONIC
BOSCH_AUTODOME
BOSCH
SAMSUNG_SCC
SAMSUNG
SAMSUNG_E
SAMSUNG
Pan/Tilt
Zoom
Speed control
YES
YES
YES
NO
NO
YES
NO
NO
YES
YES
YES
NO
NO
NO
NO
NO
NO
YES
NO
NO
YES
NO
NO
NO
YES
YES
YES
NO
YES
YES
YES
NO
YES
YES
YES
YES
YES
YES
YES
NO
YES
YES
YES
NO
YES
YES
YES
NO
YES
YES
YES
YES
YES
YES
YES
NO
YES
YES
YES
NO
Focus
Iris
Preset
Tour
Setup
YES
YES
YES
YES
YES
YES
YES
NO
NO
YES
YES
YES
YES
YES
YES
NO
NO
NO
NO
YES
YES
YES
NO
NO
YES
NO
NO
NO
NO
NO
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
NO
YES
YES
YES
YES
NO
YES
YES
YES
YES
YES
YES
YES
YES
YES
NO
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
Supported IP Camera Audio/Video Codec
Item
Codec
Video
H.264 Base Profile
Audio
G.711, G.726, AAC, PCMU 8 Khz, PCMA 8 Khz
7
Appendix
Protocol Name
76
Appendix
Time zones
Timezone
Abbreviation
Timezone
Eniwetok, Kwajalein
EK
-12:00
Midway Island, Samoa
MIS
-11:00
Hawaii
HAW
-10:00
Alaska
ALA
-09:00
-08:00
Pacific Time (US and Canada); Tajuana
PST
-08:00
-07:00
Mountain Time (US and Canada), Chihuahua, La Paz,
Mazatlan, Arizona
MST
-07:00
-06:00
Central Time (US and Canada), Saskatchewan, Guadalajara, Mexico City, Monterrey,
Central America
CST
-06:00
-05:00
Eastern Time (US and Canada), Indiana (East), Bogota, Lima, Quito
EST
-05:00
-04:00
Atlantic Time (Canada), Caracas, La Paz, Santiago
AST
-04:00
Newfoundland
NWF
-03:30
Brasilia, Buenos Aires, Georgetown, Greenland
BBA
-03:00
Mid-Atlantic
MAT
-02:00
Azores, Cape Verde Islands
AZO
-01:00
Greenwich Mean Time: Dublin, Edinburgh, Lisbon, London, Casablanca, Monrovia
GMT
0
+01:00
Amsterdam, Belgrade, Bratislava, Budapest, Ljubljana, Prague, Sarajevo, Skopje, Warsaw,
Zagreb, Brussels, Copenhagen, Madrid, Paris, Berlin, Bern, Rome, Stockholm, Vienna, West
Central Africa
AMS
+01:00
+02:00
Athens, Istanbul, Minsk
AIM
+02:00
+03:00
Bucharest, Cairo, Pretoria, Jerusalem, Harare, Pretoria
BCP
+02:00
+03:00
Helsinki, Riga, Israel, Kyiv, Sofia, Tallinn, Vilnius
HRI
+02:00
+03:00
Baghdad, Kuwait, Riyadh, Nairobi
BKR
+03:00
+04:00
7
Moscow, St.Petersburg, Volgograd
MSV
+03:00
+04:00
Appendix
Tehran
THE
+03:30
+04:30
Abu Dhabi, Muscat, Baku, Tbilisi, Yerevan
ABT
+04:00
Kabul
KAB
+04:30
Ekaterinburg, Islamabad, Karachi, Tashkent
EIK
+05:00
Bombay, Calcutta, Madras, New Delhi, Chennai, Kolkata
BCD
+05:30
Almaty, Dhaka, Colombo, Astana, Sri Jayawardenepura, Novosibirsk
ADC
+06:00
Bangkok, Hanoi, Jakarta, Krasnoyarsk
BHJ
+07:00
Beijing, Changqing, Hong Kong, Uramqi
BHU
+08:00
Perth, Singapore, Taipei, Beijing, Chongqing, Hong Kong SAR, Urumqi, Kuala Lumpur,
Irkutsk, Ulaan Bataar
SST
+08:00
Osaka, Sapporo, Tokyo
OST
+09:00
Seoul, Yakutks
SYA
+09:00
Adlaide, Darwin
ADA
+09:30
Brisbane, Guam, Port Moresby
BGP
+10:00
Canberra, Melbourne, Sydney
CMS
+10:00
Hobart, Vladivostok
HVL
+10:00
Magadan, Solomon Islands, New Caledonia
MSN
+11:00
Auckland, Wellington
AWE
+12:00
Fiji Islands, Kamchatka, Marshall Islands
FKM
+12:00
Timezone name
DST
-02:30
+12:00
Appendix
77
Factory Default Configuration Settings
1st level
2nd level
System
Properties
TCP/IP v4
TCP/IP v6
Network Streaming
Default Setting
Factory
Default setting
DVR Name
NULL
YES
Language
The option depends on the
model.
YES
Button Beep
OFF
YES
Video Format
NTSC or PAL
NO
Configuration Import
-
-
Configuration Export
-
-
Factory Default
-
-
DHCP
ON
YES
IP Address
NULL
YES
Subnet Mask
NULL
YES
Gateway
NULL
YES
Primary DNS
NULL
YES
Secondary DNS
NULL
YES
Auto
OFF
YES
IP Address
NULL
YES
Subnet Prefix Length
64
64
Gateway
NULL
YES
Primary DNS
NULL
YES
Secondary DNS
NULL
YES
TCP/IP Port No.
9001
YES
Web Server Port No.
80
YES
Audio Port No.
9003
YES
Bandwidth Throttle
100 Mbps
YES
DDNS Service
OFF
YES
Host Name
NULL
YES
Registered Host
NULL
YES
Update
-
-
Ch
-
-
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
7.5 (NTSC)/12.5 (PAL)
YES
7
Appendix
Network
3rd level
78
Appendix
Date
(2010.01.01)
NO
Time
Current Time
NO
Date Format
YYYY/MM/DD
YES
Time Format
12 HR
YES
Time Zone
The option depends on the
model.
NO
Daylight Saving
OFF
NO
Daylight Saving Start
JAN, 1st, SUN, 00
NO
Daylight Saving End
JAN, 1st, SUN, 00
NO
NTP
OFF
YES
Server
PUBLIC SERVER
YES
Private Time Server
NULL
YES
Sync. Interval
1 Day
YES
NTP test
-
-
IR Remote ID
1
YES
Remote Controller ID
NONE
YES
Method
LOCAL
YES
Device
-
YES
FTP Server
-
YES
Search
-
-
No
-
-
File Name
NULL
-
Update
-
-
Partition Selection
ALL
YES
7
Schedule
OFF
YES
Appendix
Device
-
YES
Schedule Start
SUN, 00, 00
YES
Time Range Date
Current Date
YES
Time Range Start
SUN, 00, 00
YES
Time Range End
SUN, 00, 00
YES
Estimate Size
-
-
Start Backup
-
-
Erase Media
-
-
Ch
-
-
Name
CH 01 to CH 16, IP 01, IP 02
YES
Audio
01 to 04, OFF
YES
Channel
CH 01
YES
Port
NONE
YES
Control ID
00
YES
Protocol
LG_MULTIX
YES
Baud Rate
9600
YES
PTZ Test
-
-
System
Date/Time
NTP
Controller
Update
Backup
Device
Camera
PTZ
Appendix
Device
IP Camera
ATM/POS
Storage
OSD
Sequence
Channel Composition
Video Adjustment
IP 01
-
Driver
NONE
YES
Profile
NULL
YES
Host Name
NULL
YES
User Name
NULL
YES
Password
NULL
YES
RTSP Port
554
YES
HTTP Port
16
YES
Test
-
-
Interface Device
NONE
YES
Camera
CH 01
YES
Baud rate
9600
YES
Data Bits
8
YES
Stop Bits
1
YES
Parity
NONE
YES
Storage
ALL
YES
Serial Number
-
-
Overwrite
ALL
YES
Full Warning
OFF
YES
Auto Delete
OFF
YES
Event Partition
50 %
NO
Format
-
-
Insert
-
-
Eject
-
-
E-SATA Recording Support
-
-
Channel Name
ON
YES
Channel Status
ON
YES
Font Size
12
YES
Position
TOP
YES
Main Dwell Time
2 SEC
YES
Spot Dwell Time
2 SEC
YES
Ch
-
-
Name
CH 01 to CH 16
YES
Channel
CH 01
-
Brightness
50
YES
Contrast
50
YES
Color
50
YES
Restore to Default
-
-
7
Appendix
Display
Channel
79
80
Appendix
Record
Schedule
Normal
Sensor
7
Appendix
Motion
Text
Instant/Panic
SUN
S+M
YES
MON
S+M
YES
TUE
S+M
YES
WED
S+M
YES
THU
S+M
YES
FRI
S+M
YES
SAT
S+M
YES
SP
N
YES
List
-
-
Add
-
-
Ch Copy
-
-
Day Copy
-
-
Ch
-
-
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
30 (NTSC)/25 (PAL)
YES
Ch
-
-
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
30 (NTSC)/25 (PAL)
YES
Prealarm
10 SEC
YES
Postalarm
10 SEC
YES
Ch
-
-
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
30 (NTSC)/25 (PAL)
YES
Prealarm
10 SEC
YES
Postalarm
10 SEC
YES
Ch
-
-
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
30 (NTSC)/25 (PAL)
YES
Prealarm
10 SEC
YES
Postalarm
10 SEC
YES
Ch
-
-
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
30 (NTSC)/25 (PAL)
YES
Appendix
Event
Sensor
Motion
ATM/POS Data Format
Event Popup
Notification
Emergency
-
YES
Sensor Type
N.O.
YES
Camera
01 to 16
YES
Relay Output
NONE
YES
Preset
NONE
YES
Channel
CH 01
YES
Sensitivity
05
YES
Relay Output
NONE
YES
Area
All selected
-
Input Channel
CH 01
YES
Transaction Start
NULL
YES
Transaction End
NULL
YES
Delimiter
CARRIAGE RETURN
YES
Ignore String
NULL
YES
Time Out
10 Min
YES
Relay Output
NONE
YES
Spot Monitor
OFF
YES
Sensor On
OFF
YES
Motion Detection
OFF
YES
Text In
OFF
YES
Admin Password Changed
OFF
YES
Video Loss
OFF
YES
Power On/Off
OFF
YES
Disk Full
OFF
YES
Notification
OFF
YES
SMTP Server
NULL
YES
SMTP Port
25
YES
User Name
NULL
YES
Password
NULL
YES
TLS
OFF
YES
Mail Address 1
NULL
YES
Mail Address 2
NULL
YES
Mail Address 3
NULL
YES
E-mail Test
-
-
Notification
OFF
YES
Host name
NULL
YES
Port
9002
YES
7
Appendix
Mail
In
81
82
Appendix
Event
SNMP
Output
Buzzer
User
7
Group Authority
Appendix
User
SNMP Version
NONE
YES
Port
161
YES
Community String
public
YES
User
NULL
YES
Authentication
NONE
YES
Password
NULL
YES
Privacy
NONE
YES
Password
NULL
YES
Trap IP Address
NULL
YES
Trap Community String
NULL
YES
Relay Off
ALARM ACKNOWLEDGE
YES
System Alarm Out
NONE
YES
HDD Fail Alarm Out
NONE
YES
Video Loss Alarm Out
NONE
YES
Fan Fail Alarm Out
NONE
YES
Sensor
OFF
YES
Motion
OFF
YES
Text
OFF
YES
System
OFF
YES
Group ID
GUEST
YES
Group Name
GUEST
YES
Setup
OFF
YES
Search/Play
OFF
YES
Export
OFF
YES
PTZ
OFF
YES
Power OFF
OFF
YES
Instant Record
OFF
YES
Main Channel
All Enable
YES
Spot Channel
All Enable
YES
User ID
ADMINISTRATOR
YES
User Name
ADMINISTRATOR
YES
Group
NULL
YES
Password
“000000”
YES
Auto user logout
OFF
YES
Appendix
83
Recording Time Table (250GB HDD)
Recording Time(Hr)
Resolution
(NTSC/PAL)
Quality
LOW
352x240 /
352x288
STANDARD
HIGH
HIGHEST
Video(NTSC/PAL)
Video + Audio(NTSC/PAL)
8ch
16ch
8ch
16ch
30/25
1022/800
511/400
838/683
461/368
15/12.5
1188/1142
594/571
947/917
527/509
10/8
1508/1416
754/708
1139/1086
649/615
7.5/6
1573/1588
787/794
1176/1185
673/679
5/5
2095/1658
1047/829
1445/1223
855/704
3/3
2441/2023
1220/1011
1602/1411
967/831
1/1
3182/2677
1591/1338
1891/1700
1186/1040
30/25
765/574
383/287
657/511
354/270
15/12.5
996/779
498/390
820/668
450/360
10/8
1162/963
581/481
930/798
517/436
7.5/6
1220/1098
610/549
967/889
539/491
5/5
1342/1130
671/565
1042/910
587/504
3/3
1408/1160
704/580
1082/929
612/516
1/1
1765/1493
882/746
1280/1131
742/643
30/25
668/497
334/249
584/449
312/236
15/12.5
881/671
441/336
741/587
403/313
10/8
975/805
487/402
806/686
441/370
7.5/6
1033/939
517/470
846/782
465/427
5/5
1178/950
589/475
940/789
523/431
7
3/3
1331/1114
666/557
1035/899
582/497
1/1
1605/1370
802/685
1194/1059
685/597
30/25
541/411
271/206
485/378
256/197
Appendix
LOWEST
FPS
(NTSC/PAL)
15/12.5
686/542
343/271
598/486
319/256
10/8
794/671
397/336
678/587
366/313
7.5/6
819/770
409/385
696/661
376/356
5/5
994/787
497/393
819/673
449/363
3/3
1032/802
516/401
845/684
464/369
1/1
1166/990
583/495
933/816
518/447
30/25
511/342
256/171
461/318
242/165
15/12.5
618/471
309/236
545/428
290/224
10/8
692/578
346/289
603/514
322/272
7.5/6
736/681
368/341
636/594
341/317
5/5
859/721
430/360
726/624
393/334
3/3
998/823
499/412
822/700
451/378
1/1
1247/1064
624/532
984/866
550/477
84
Appendix
LOWEST
LOW
704x240 /
704x288
7
STANDARD
HIGH
Appendix
HIGHEST
30/25
563/425
281/212
502/389
265/203
15/12.5
764/602
382/301
657/533
353/283
10/8
899/771
449/385
753/661
410/356
7.5/6
949/888
474/444
788/746
431/405
5/5
1175/925
587/463
938/772
522/421
3/3
1235/980
617/490
976/810
545/443
1/1
1553/1337
777/669
1165/1039
666/585
30/25
469/330
235/165
426/308
223/159
15/12.5
625/465
312/233
551/423
293/222
10/8
724/577
362/288
627/513
336/272
7.5/6
774/695
387/348
664/605
357/323
5/5
924/713
462/357
771/619
420/331
3/3
1065/853
533/427
867/721
478/391
1/1
1347/1152
673/576
1045/924
588/513
30/25
369/251
185/125
342/238
178/122
15/12.5
479/343
240/171
435/319
228/165
10/8
544/437
272/218
487/399
257/209
7.5/6
571/514
286/257
509/463
269/244
5/5
666/530
333/265
583/476
311/251
3/3
731/537
365/268
632/481
339/254
1/1
843/697
422/348
714/606
387/324
30/25
293/222
147/111
276/212
142/109
15/12.5
398/312
199/156
366/292
191/151
10/8
457/391
228/196
416/361
218/188
7.5/6
496/472
248/236
448/429
235/225
5/5
567/492
283/246
505/445
267/234
3/3
691/569
345/285
602/507
322/268
1/1
828/752
414/376
703/647
380/348
30/25
254/192
127/96
241/185
124/94
15/12.5
340/266
170/133
317/252
164/129
10/8
386/334
193/167
357/312
186/161
7.5/6
418/398
209/199
384/367
200/191
5/5
489/401
244/201
442/370
232/192
3/3
507/406
254/203
458/374
241/195
1/1
630/545
315/273
555/488
295/258
Appendix
LOW
704x480 /
704x576
STANDARD
HIGH
HIGHEST
30/25
302/236
151/118
284/224
146/115
15/12.5
430/337
215/169
394/315
206/163
10/8
470/435
235/217
427/398
224/208
7.5/6
573/516
287/258
511/465
270/245
5/5
712/536
356/268
618/481
331/254
3/3
876/683
438/342
738/596
401/318
1/1
1250/999
625/500
986/823
551/451
30/25
236/169
118/84
225/163
115/83
15/12.5
322/237
161/118
301/225
156/115
10/8
381/307
191/153
352/288
183/149
7.5/6
412/368
206/184
378/341
197/177
5/5
500/372
250/186
451/345
237/179
3/3
516/404
258/202
465/372
245/194
1/1
682/559
341/280
595/499
318/264
30/25
198/138
99/69
190/134
97/68
15/12.5
272/194
136/97
257/186
132/95
10/8
317/253
159/127
297/240
154/123
7.5/6
351/304
176/152
327/286
169/147
5/5
418/317
209/159
383/297
200/153
3/3
503/365
252/183
454/339
239/176
1/1
663/552
332/276
581/494
310/261
30/25
160/113
80/57
155/110
79/56
15/12.5
217/160
108/80
207/154
106/78
10/8
255/207
127/103
242/198
124/101
7.5/6
277/249
138/125
261/237
134/121
7
5/5
322/265
161/133
301/251
156/129
3/3
339/315
170/158
316/295
164/153
1/1
445/377
223/189
406/349
212/181
Appendix
LOWEST
85
30/25
139/104
69/52
135/102
68/51
15/12.5
200/150
100/75
192/145
98/74
10/8
236/196
118/98
224/188
115/96
7.5/6
266/237
133/119
252/226
130/116
5/5
312/242
156/121
292/230
151/118
3/3
318/306
159/153
297/287
154/148
1/1
422/371
211/185
387/343
202/178
NOTE
This recording time table is for reference only.
The recording time can be different depending on your surveillance environment.
86
Appendix
Specifications
LE5008 Series
LE5016 Series
LE4008 Series
LE4016 Series
8
16
Loop Through
8
16
Composite
1
1
VGA
1
1
Spot
1
1
Input
2
4
Output
2
2
Input
8
16
Output
2
4
Model
Input
Video
Output
Audio
Alarm
Pre-Alarm Recording
NTSC
Recording
Frame Rate
(/Second)
PAL
Search
Appendix
Serial I/F
Network
Security
Up to 240 IPS @ 352x240
Up to 480 IPS @ 352x240
Up to 200 IPS @ 704x576
Up to 400 IPS @ 704x576
Up to 200 IPS @ 352x288
Up to 400 IPS @ 352x288
Search Mode
Date/Time, Calendar, Event (Motion, Alarm), Bookmark, Text
Frame Rate
(/Second)
Internal HDD
Backup
Up to 480 IPS @ 704x480
FF, FB, Frame Advance, Go to First, Go to Last
NTSC
240 IPS (Real time per each channel)
480 IPS (Real time per each channel)
PAL
200 IPS (Real time per each channel)
400 IPS (Real time per each channel)
1, 4, 9, 1+5, 1+7
1, 4, 9, 16, 1+5, 1+7
Division Mode
Storage
Up to 240 IPS @ 704x480
Playback Function
7
Display
Up to 60 seconds
External HDD
Max Capacity
8 TB (Up to 4 HDDs)
Interface Type
E-SATA
Max Capacity
8 TB (Up to 4 HDDs)
Backup Interface
USB 2.0 (x3), E-SATA, Network
Supportable Devices
Memory Stick, CD-RW, DVD-RW, External HDD
PTZ Control Interface
RS-485 (x2)
Serial Interface
RS-232C (D-SUB9) (x2)
Network Connection
Ethernet 10/100/1000 Mbps (RJ-45)
Network Transmission Speed
Up to 240 IPS
Bandwidth Control
Yes
Password Protection
Yes
Image Authentication
Yes
Appendix
Power
AC Free 100~240 V, 50/60 Hz
Power Consumption
Maximum 80 W (with 4 HDD)
Dimension (WxDxH)
430 mm x 430 mm x 96 mm
Net Weight (without HDD)
Operation Temp. / Humidity
6.85 kg
87
6.97 kg
0 ºC to 40 ºC / 0 % RH to 80 % RH
7
Appendix
