LG LE4016D-NH Owner's manual
OWNER’S MANUAL
Hybrid Digital Video
Recorder
Please read this manual carefully before operating
your set and retain it for future reference.
MODELS
LE5016/LE5008 Series
LE4016/LE4008 Series
P/NO : MFL60560470
1012 (V1.1)
2
Safety Information
1
Safety Information
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the product.
FCC WARNING: This equipment may generate or use radio
frequency energy. Changes or modifications to this equipment may
cause harmful interference unless the modifications are expressly
approved in the instruction manual. The user could lose the
authority to operate this equipment if an unauthorized change or
modification is made.
REGULATORY INFORMATION: FCC Part 15
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to
correct the interference at his own expense.
•
A suitable conduit entries, knock-outs or glands shall be
provided in the cable entries of this product in the end user.
•
Caution: Danger of explosion if battery is incorrectly replaced.
Replaced only with the same or equivalent type recommended
by the manufacturer. Dispose of used batteries according to the
manufacturer’s instructions.
•
Holes in metal, through which insulated wires pass, shall
have smooth well rounded surfaces or shall be provided with
brushings.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme
NMB-003 du Canada.
Warning: Do not install this equipment in a confined space such as
a bookcase or similar unit.
Warning: Wiring methods shall be in accordance with the National
Electric Code, ANSI/NFPA 70.
Warning: This is a class A product. In a domestic environment this
product may cause radio interference in which case the user may
be required to take adequate measures.
Warning: To reduce a risk of fire or electric shock, do not expose
this product to rain or moisture.
Caution: This installation should be made by a qualified service
person and should conform to all local codes.
Caution: To avoid electrical shock, do not open the cabinet. Refer
servicing to qualified personnel only.
Caution: The apparatus should not be exposed to water (dripping
or splashing) and no objects filled with liquids, such as vases, should
be placed on the apparatus.
Caution:
This product employs a Laser System. To ensure proper use of this
product, please read this owner’s manual carefully and retain it
for future reference. Should the unit require maintenance, contact
an authorized service center. Performing controls, adjustments,
or carrying out procedures other than those specified herein may
result in hazardous radiation exposure. To prevent direct exposure to
laser beam, do not try to open the enclosure. Visible laser radiation
when open. DO NOT STARE INTO BEAM.
To disconnect power from mains, pull out the mains cord plug.
When installing the product, ensure that the plug is easily
accessible.
Safety Information
LG Electronics hereby declares that this/these
product(s) is/are in compliance with the essential
requirements and other relevant provisions of
Directive 2004/108/EC, 2006/95/EC, and 2009/125/
EC.
LG Electronics Service Europe B.V. Veluwezoom 15,
1327
AE Almere. The Netherlands
(Tel : +31-(0)36-547-8888)
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is
attached to a product it means the product is
covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should
be disposed of separately from the municipal
waste stream via designated collection facilities
appointed by the government or the local
authorities.
3. The correct disposal of your old appliance will help
prevent potential negative consequences for the
environment and human health.
4. For more detailed information about disposal of
your old appliance, please contact your city office,
waste disposal service or the shop where you
purchased the product.
EEE Compliance with Directive. (for Turkey only)
Safety way to remove the battery or the battery from the
equipment:
Remove the old battery or battery pack, follow the steps in
reverse order than the assembly. To prevent contamination of the
environment and bring on possible threat to human and animal
health, the old battery or the battery put it in the appropriate
container at designated collection points. Do not dispose of
batteries or battery together with other waste. It is recommended
that you use local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to excessive heat
such as sunshine, fire or the lile.
IMPORTANT SAFETY
INSTRUCTIONS
1
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or groundingtype plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
Safety Information
European representative :
3
4
Safety Information
Safety warnings and Cautions
1
Safety Information
The following are warnings and cautions for the safety of the users and for the prevention of any property damage. Please read the following
carefully.
WARNING
•
Turn off the system before installation. Do not plug in several electric devices to the same outlet.
--
•
-•
This may cause fire, over heating or electric shock.
When the system’s battery is depleted, replace it with the same or equivalent type of battery specified by the manufacturer. Depleted
batteries should be discarded according to the manufacturer’s instructions.
--
•
This may cause system breakdown or serious injury.
The power outlet must be placed on the ground, and the voltage range must be within 10% of the voltage rate. Do not use the same
outlet with a hair dryer, iron, refrigerator, or any heating appliances.
--
•
This may cause fire.
Install the system on a plain surface with sufficient air ventilation. Do not place the system on an elevated surface.
--
•
This may cause fire, electric shock, or injury.
Install the system in a cool place without direct sunlight and always maintain room temperature. Avoid candlelight and heat generating
devices such as heaters. Keep the system away from places where many people pass.
--
•
This may cause fire or electric shock.
Keep a distance of at least 15cm between the back of the system and the wall for the cables connected to the system otherwise, they may
be bent, damaged, or cut.
--
•
This may cause fire, electric shock, or serious injury.
Check for any danger signs such as a moist floor, a loosened or damaged power cable, or an unstable surface. If you encounter any
problems, ask your dealer for assistance.
--
•
This may cause fire or electric shock.
Do not attempt to disassemble, repair, or modify the system on your own. It is extremely dangerous due to the high voltage running
through the system.
--
•
This can cause fire or electric shock.
When pulling the power cable from the plug, do so gently. Do not touch the plug with wet hands and avoid using the plug if the holes in
the outlet are too loose.
--
•
This may damage the surface of the system and can cause a system breakdown or electric shock.
Avoid any place with moisture, dust, or soot.
--
•
This may cause fire.
Clean the dust around the system on a regular basis. When cleaning the system, always use a dry cloth. Do not use a wet cloth or other
organic solvents.
--
•
If liquid is poured onto the system, it can cause a system breakdown or fire.
Prevent the power cable from being severely bent or having pressure exerted on it by a heavy object.
--
•
This may cause heating, fire, or electric shock.
Do not place any liquid container on the system, such as water, coffee, or other beverage.
This may cause an explosion.
If the system’s HDD exceeds its life span, you may not be able to recover any data stored inside the HDD. If the video on the system screen
appears ‘damaged’ while playing a recording stored inside the system’s HDD, it must be replaced with a new one. Ask for an engineer’s
assistance for HDD replacement from your dealer.
--
LG Electronics is not responsible for deleted data caused by user mishandling.
Safety Information
5
CAUTION
Please beware of the following precautions before installing the DVR.
Avoid positioning the product in any place where the unit may come into contact with moisture, dust, or soot.
•
Avoid placing in direct sunlight or near heating appliances.
•
Keep the product away from electric sparks or magnetic substances.
•
Do not place any conductive material through the ventilation grills.
•
Keep the system turned off before installation.
•
Ensure enough space is left for cable connections.
•
Place the system on a solid surface with sufficient air ventilation. Avoid any surface that vibrates.
•
Placing the system near electronic devices such as a radio or a TV may cause the product to breakdown.
•
Do not disassemble the product without seeking assistance from LG Electronics.
•
Do not place any heavy object on the system.
•
Prevent any substances from being inserted into the system.
--
•
Install the system in a place with sufficient air ventilation.
--
•
This may cause system breakdown.
Install the system on a stable, level surface.
--
•
Do not install the system in a place with magnetic objects, electric frequencies, or vibration.
Do not place any heavy object on the system.
--
•
Keep at least 15cm distance between the back of the system and the wall, and at least 5cm distance between the side of the system
and the wall.
Do not install the system in a place with high magnetic, electric wave, or wireless devices such as a radio or a TV.
--
•
This may cause system breakdown.
The system may not operate properly.
Install the system in a place with appropriate moisture and temperature levels.
--
Avoid installing the system in a place with high (over 40°C) or low (under 0°C) temperature.
•
The system can be damaged from a strong impact or vibration. Avoid throwing objects within the vicinity of the system.
•
Avoid direct sunlight or any heating appliances.
--
•
Recommended operating temperature is over 0°C (32°F).
Ventilate the air inside the system operation room, and tighten the system cover firmly.
--
System breakdown may be caused by an inappropriate environment. It is recommended to use AVR (Automatic Voltage Regulator)
for a stable power supply. It is recommended to coil the core-ferrite around the connector of the system to avoid electromagnetic
interference.
•
The outlet must be placed on the ground.
•
If there is strange sound or smell, unplug the power cable immediately and contact the service center.
--
•
•
This may cause fire or electric shock.
In order to maintain stable system performance, have your system checked regularly by the service center.
--
LG Electronics is not held responsible for system breakdown caused by user mishandling.
--
There is a risk of explosion if a battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.
Do not overturn the product during use.
1
Safety Information
•
6
Contents
Contents
3
4
5
Properties
27
Network
28
Network Streaming
28
DDNS
28
Date/Time
Safety Information
29
NTP
29
Controller
3
29
Update
30
Backup
1
IMPORTANT SAFETY INSTRUCTIONS
2
31
7
Device settings
Preparation
31
Camera
31
PTZ
8
32
IP Camera
ATM/POS
Introduction
8
Features
32
8
Accessories
33
9
11
12
Front Panel
Rear Panel
Remote Control
3
6
Configuration menu
System settings
27
1
2
26
27
33
Storage
Display settings
33
OSD
33
Sequence
34
Channel Composition
34
Video Adjustment
Installation
34
34
Schedule
13
34
To Set the Recording Schedule for a Typical
Connections
Record settings
Day of the Week
13
Precautions
13
Basic Connection Overview
36
Copying the Recording Schedule
14
Connecting Camera
36
Normal
14
Connecting Display device
36
Sensor
14
Connecting Audio device
37
Motion
15
Connecting USB device
37
Text
15
Connecting ATM/POS
37
Instant/Panic
16
Connecting Network
38
16
Connecting RS-485 device
38
17
Connecting Alarm Input and Alarm Output
38
Sensor
18
HDD INSTALLATION
IP camera
Event settings
38
Motion
18
Note for Hard Disk Drive
39
ATM/POS Data Format
18
Installing the Hard Disk Drive
39
Event Popup
19
Replacing the Hard Disk Drive
39
Notification
19
Recommended HDD
40
Mail
19
19
20
System Operation
System Shutdown
General Explanation of the Live
Screen on the Main Monitor
40
Emergency
40
Output
41
Buzzer
20
Main Monitor Screen
41
21
Selecting the Main Monitor screen mode
22
Selecting the Spot Monitor screen mode
4
22
PTZ Camera Control
24
Viewing System Information
24
Viewing the System Log List
41
User settings
Group Authority
Operation
43
Instant Recording
Contents
43
44
44
Panic Recording
Instant Playback
Search and Playback
44
Date and Time Search
44
Event Search
45
Bookmark Search
45
ATM/POS Search
46
Export Search
47
78
81
7
Recording Time Table (250GB HDD)
Specifications
1
2
Functions Available During Playback
5
LG Network Client Program
48
48
48
48
Introduction
Recommended PC Requirements
Before install the program
Getting Started
48
Install the LG Network Client on your PC
48
Starting the LG Network Client
49
LG Network Client Overview
51
Operation and settings
51
Register the Site Name or Group Name
51
Connect to the DVR
51
Connect the group device
52
Disconnect the site name or group name
52
Using the Live function
55
Using the Search function
56
Using the Remote Setup function
61
Using the Export function
62
Using the E-Map function
63
Additional Programs
63
Emergency Agent Program
64
Export Viewer Program
65
Web Viewer Program
6
Troubleshooting
7
Appendix
69
3
Recommended Devices
69
Recommended USB Memory list
69
Recommended External Device list
69
Recommended CD/DVD Media list
70
Supported function list for device
70
Supported PTZ Camera list
71
72
Time zones
Factory Default Configuration Settings
4
5
6
7
8
Preparation
2
Preparation
2
Preparation
Introduction
Model LE5016D (16 Channel) is used for the description, operation
and details provided in this operating guide.
Features
•
Automatic backup by schedule.
•
Image authentication (Watermark).
•
Three USB 2.0 ports for backup interface.
•
Setup configuration export/import with USB memory stick.
•
Easy system S/W update with USB memory stick.
•
Clients S/W can manage max 100 DVR servers.
•
Max five clients can access one DVR server simultaneously.
•
Network bandwidth throttle.
•
Stable embedded Linux operating system.
•
Journal filing system for HDD file recovery following power
recovery.
•
Remote alarm notification via client software or E-mail.
•
Small file sizes with H.264 compression.
•
Time and date sync from NTP server.
•
Internal storage expandable to 4TB. (Expandable if new high
capacity HDD is launched)
•
Daylight saving mode.
•
NTSC and PAL selectable video format.
•
Covert camera protection.
•
Full real-time recording.
•
Support Gigabit Ethernet.
•
E-SATA storage interface.
•
Two-way audio.
•
Text Input for ATM and POS device.
•
User management (User level control).
•
PTZ Control.
NTSC
PAL
•
NTSC
D1(704x480), Half D1(704x240), CIF(352x240)
PAL
D1(704x576), Half D1(704x288), CIF(352x288)
Dome camera telemetry control (Dome OSD control).
Accessories
Software
Install CD
Screws
Mouse
Rack Mount
Bracket
Remote
Control
Power Plug
AAA type
batteries
SATA cable(s)
5 step quality level (Highest, High, Standard, Low, Lowest).
Optical mouse, Full function IR remote controller
Powerful multiplex function.
--
•
--
Automatically adjust a bandwidth according to network
speed status of unit.
Easy operation using various user interface & user friendly GUI.
--
•
Up to 400 IPS @ 704x576, LE5016 Series
Up to 200 IPS @ 704x576, LE5008 Series
Up to 400 IPS @ 352x288, LE4016 Series
Up to 200 IPS @ 352x288, LE4008 Series
Various recording resolutions and quality levels.
-•
Up to 480 IPS @ 704x480, LE5016 Series
Up to 240 IPS @ 704x480, LE5008 Series
Up to 480 IPS @ 352x240, LE4016 Series
Up to 240 IPS @ 352x240, LE4008 Series
--
Simultaneous live display, recording, playback, network
transmission, back-up.
Various search function.
--
Date/time search (calendar search), event search, bookmark
search.
•
Event data protection by event partition recording.
•
Pre-alarm recording (Up to 1 minute).
•
Motion event recording and preview test function of motion
sensitivity.
•
Recording image rate & quality adjustment per individual
camera.
•
Powerful record scheduling.
•
Instant playback in live mode.
•
Perfect audio/video synchronization.
Preparation
9
Front Panel
Front of the LE5016/LE4016 series
a
c
b
d
e
f
ghi j
k
2
Preparation
l
m
n
op
qor
s
t
Front of the LE5008/LE4008 series
a
a
b
c
b
l
m
d
n
e
f
ghi j
op
qor
k
s
t
1 (Power): Turns DVR on or off. Press and hold for more than 2 seconds to turn on or off.
Indicator
•
NET: Lights when the network is connected.
•
HDD: Blinks when the HDD is accessed.
•
ALARM: Lights when the alarm out is in progress.
•
BACK UP: Lights when the data back up is in progress.
c
d
Remote Sensor: Point the remote control here.
e
Channel Buttons: You can input a number with channel buttons. You can also use the channel buttons for sub-function with SHIFT
button (11 to 16 buttons of 8 channel DVR are used for sub-function without SHIFT button.).
SHIFT button: If you use the Sub-function of the channel button, the button is activated.
•
The LED in the button indicates the status as follows:
--
Off: The current status is for live mode.
--
Red: Recording mode.
--
Blinks when an event occurs.
10
Preparation
•
2
Sub-functions
Preparation
Button number
Function
Description
3/4
FOCUS / FOCUS +
5
OSD
Accesses or removes the System Control Bar (OSD).
6
INFO
Displays or removes system information.
7/8
IRIS - / IRIS +
9
ALM.OFF
10/0
LOG
Displays or removes the System Log List.
11
SET
Registers the PTZ camera’s preset position.
12
CLEAR
Deletes a memorized preset position.
13
COPY
Copies the recording data to an external device.
14
MARK
Sets the mark point for recording search.
15
MOVE
Moves the camera to the preset position.
16
TOUR
Tours all registered preset positions in the camera.
Adjusts focus position.
Adjust iris position.
Cancels alarm activation and returns the system to the condition before the alarm was
activated.
f
PTZ: Switches this unit to PTZ mode to control the PTZ camera connected.
g
Arrow Buttons
•
•
b B v V: Select or move between the menu options.
ENTER: Confirms menu selections.
h
i
LOCK: Displays the lock menu to change the user type or disable the system operation.
j
k
SEARCH: Displays the search menu.
l
Playback Control Buttons
SETUP/ESC: Displays the setup menu or cancels operation on the setup menus.
Shuttle Ring: Fast forward or reverse picture search when the dial is rotated.
•
•
•
•
X: Pauses playback.
m, ./c: Searches the recorded images in reverse or skips the recorded images.
bB: Playback or reverse playback of recorded images.
M, >/C: Forward searches the recorded images or skips the recorded images.
•
x: Stops playback.
Disc Tray: Insert a disc here.
m
n
OPEN: Opens or closes the disc tray.
o
ZOOM + / -: Zooms in/out on playback window.
p
q
MAIN: Displays or removes the screen setup menu for MAIN monitor.
r
s
REC: Starts or stops instant recording.
t
USB Port: Connects an external USB device for backup or playback.
SPOT: Displays or removes the screen setup menu for SPOT monitor.
JOG Dial: Allows a forward or reverse frame search. In pause mode, plays recorded images frame by frame through rotation. Increases
or decreases the options value.
Preparation
11
Rear Panel
Rear of the LE5016/LE4016 series
a
b
c
2
Preparation
d
e f g h i
Rear of the LE5008/LE4008 series
a
d
e f g h i
j
k
lm no
p q
b nkp
j lm
c
o
a
b
VIDEO INPUT: Connect the camera’s video output to these BNC connectors.
q
LOOP OUT: The signal from VIDEO INPUT connector is looped out to this connector.
c
Power Cord Inlet (AC IN): Connect the power plug.
d
e
RS-485 Terminals: Connect RS-485 compatible cameras.
f
g
CONSOLE: Used to connect to a host device equipped with RS-232C connector (such as a personal computer).
h
i
MAIN-OUT (BNC Type Connector): Connect to main monitor or display device.
j
k
VGA: Connect a VGA monitor.
l
m
LAN Port: Connect the ethernet 10/100/1000 Mbps network cable for controlling this unit via a PC network.
n
o
AUDIO INPUT: Connect the audio output of an external device.
p
q
AUDIO OUT 2: Connect to an active speaker with a built-in amplifier. Two-way audio output.
RELAY-OUT Terminals: Output terminals for alarm (relay) signal.
SPOT-OUT (BNC Type Connector): Connect to spot monitor or display device.
ATM/POS: Used to connect to a ATM/POS device.
AUDIO OUT 1: Connect to an active speaker with a built-in amplifier.
USB Ports: Connect an optional extension USB device.
ALARM-IN Terminals: Input terminals for alarm (relay) signal.
E-SATA: Connect the external SATA device.
12
Preparation
Remote Control
Button
POWER (1)
LOCK
Description
Turns DVR on or off.
Displays the lock menu to change user type or disable system operation.
2
ID
Preparation
MAIN
Displays or removes the screen setup menu for MAIN monitor.
SPOT
Displays or removes the screen setup menu for SPOT monitor.
ALM.OFF
OSD
Set the appropriate DVR system ID to operate via the IR Remote Controller when
using the multiple DVR. Press the ID button then press the number button within
2 seconds to select the system ID of the DVR. If you set the system ID to “0”, you
can control multiple DVR at the same time.
Cancels alarm activation and returns the system to the condition before the alarm
was activated.
Accesses or removes the system control bar.
SETUP/ESC
Displays the setup menu or cancels operation of the setup menu.
bBvV
Selects or moves between the menu options.
ENTER
Confirms menu selections.
COPY
Copies the recording data to an external device.
SEARCH
MARK
Displays the search menu.
Sets the mark point for recording search. You can set the mark point during the
single or multi channel playback of recorded data.
PAUSE (X)
Pauses playback.
STOP (x)
Stops playback.
REC (z)
Starts or stops recording.
m, ./c
bB
Searches the recorded images in reverse or skips the recorded images.
Playback or reverse playback of recorded images.
M, >/C
Forward searches the recorded images or skips the recorded images.
Number Buttons
To select the PTZ preset number, ID, or channel.
INFO
Displays or removes the system information window.
LOG
Displays or removes the System Log List window.
PTZ
Switches this unit to PTZ mode to control the connected PTZ camera.
TOUR
Tours all registered preset positions in the camera.
ZOOM + / -
Zooms in/out on the playback window.
FOCUS + / -
Adjusts the focus of a camera.
IRIS + / SET
Adjusts the iris of a camera.
Registers the PTZ camera’s preset positions.
CLEAR
Deletes a memorized preset position.
MOVE
Moves the camera to the preset position.
F1
This button is not available.
Installation
13
3
Installation
Connections
Precautions
3
Depending on the camera and other equipment there are various ways to connect the unit. Please refer to the camera manual or manuals
for other devices as necessary for additional connection information.
•
Be sure to switch off the camera before installation and connection.
Basic Connection Overview
Connect the coaxial-type cameras
Connect the Monitor, DVR, VCR, or others.
Connect ATM/POS unit.
For audio amplifier
Connect power
cord.
Connect the external SATA device for backup.
Connect the
alarm (relay)
Connect alarm sensors.
Connect audio (line input)
Connect an external USB device for
backup or playback.
Connect a mouse device.
Connect PTZ
cameras, DVRs
or keypads
(optional).
Connect network cable for client control or IP camera input.
Connect VGA monitor.
Connect BNC type monitor.
Connect BNC type spot monitor.
Installation
•
14
Installation
Connecting Camera
VGA Monitor connection
Connect the video output of your camera to the unit, using a
standard 75 Ω video coaxial cable with BNC connector.
Connect the VGA jacks on the rear of the unit to the corresponding
input jacks on the TV or monitor using the VGA cable.
Camera connection
VGA Monitor connection
3
Installation
Connecting Display device
This unit can be outputted simultaneously from the VGA and MAIN
OUT jack. The video signal connection between the DVR and the
monitor.
CCTV(Composite Video Type) Monitor connection
SPOT Monitor connection
Connect the unit to the SPOT monitor via 75 Ω video coaxial cables
with BNC connector.
SPOT Monitor connection
Connect the unit to the CCTV monitor via 75 Ω video coaxial cables
with BNC connector.
CCTV Monitor connection
Connecting Audio device
Connect the AUDIO OUT jacks on the unit to the mono audio in
jacks on your audio device.
Microphone and Speaker connection
Installation
Connecting USB device
USB device connection
15
Connecting ATM/POS
Connect the ATM/POS unit to the ATM/POS port.
ATM/POS device connection
3
Installation
USB Memory device
Insert the memory device into the USB port. The system
automatically recognizes the device. Using a USB memory device
the system software can be easily upgraded.
NOTE
•
USB External device
--
Connect the external device to the USB port.
(Example: External HDD or other external storage).
Mouse
Connect the mouse for function control of the unit.
The following device has been tested and compatibility is
ensured. When you use the multiple ATM/POS device use the
recommended device.
•
AVE Products
››
VSI-PRO: Video serial interface
››
Regcom: RS-485 networker
››
Hydra: RS-485 to RS-232 converter
The installation and connection work should be done by
qualified service personnel or system installers and should
conform to all local codes.
16
Installation
Connecting Network
Connecting the PTZ device
You can control and monitor the system via network. With
the remote control (monitoring), you can change the system
configuration or monitors the image via network. After the
installation, check the network settings for the remote control and
monitoring work.
Connecting the PTZ serial communication lines to the
RS-485 terminal.
PTZ device connection
Network connection
3
Installation
Broadband
Service
Router
5~7 mm
LAN connection
Connect the LAN port to an available 10/100/1000 base-T port with
a straight ethernet cable (not supplied). The NET indicator on the
front panel will be lit.
PTZ units
(RS-485 type)
IP Camera connection
Connect the IP camera. After the installation, check the IP camera
settings on the setup menu.
Automatic network configuration
The DVR can automatically obtain and configure the network
interface via DHCP.
Manually configure network
The DVR may be manually configured by assigning an IP address,
subnet mask, gateway and DNS.
Connecting RS-485 device
This DVR has two data terminals. Use this port to connect PTZ
cameras, DVRs or keypads (optional).
RS-485 Terminal
Description
D - (DATA -)
Data Transmission/Reception
D + (DATA +)
Data Transmission/Reception
GND
Shield
PTZ units
(RS-485 type)
NOTE
•
When connecting lines, connect the “D -” of the DVR to “RX -”
of the PTZ unit and “D +” of the DVR to “RX +” of the PTZ unit
correctly.
•
Recommended initial data are 9600 Baud Rate, 8 Data bits,
1 Stop bit and No parity.
•
When connecting PTZ cameras to DVRs it is necessary to set
the setup menu for this unit according to the RS-485 settings
of the camera and DVRs.
Installation
Connecting LKD1000 controller
Connecting the LKD1000 controller to control the DVR. (Refer to the
manuals of the LKD1000 controller for more details.). The LKD1000
controller have to be connected to the 2 (DATA 2) port as shown
illustration. If you connect the LKD1000 controller to the 1 (DATA 1)
port, the LKD1000 controller will not be activated.
17
Sensor input connection
LKD1000 controller connection
3
Installation
TX-
TX+
Alarm sensor
LKD1000 Controller
NOTE
Do not connect a PTZ camera and LKD1000 controller at the same
time to the D1 or D2 port. It may cause a malfunction.
Connecting Alarm Input and Alarm
Output
Alarm terminals are used to connect the alarm devices such as
sensors, door switches, etc.
Alarm Input
You can connect up to 16 alarm sensors (LE5008/LE4008: 8 alarm
sensors). Each alarm sensor should be connected with G (GND).
The signal state is adjustable to N/O (Normal Open) or N/C (Normal
Close) through the setup menu.
Alarm sensor
Terminal No.
Description
1
Sensor Input 1
2
Sensor Input 2
3
Sensor Input 3
4
Sensor Input 4
G
Ground
5
Sensor Input 5
6
Sensor Input 6
7
Sensor Input 7
8
Sensor Input 8
G
Ground
9
Sensor Input 9
10
Sensor Input 10
11
Sensor Input 11
12
Sensor Input 12
G
Ground
13
Sensor Input 13
14
Sensor Input 14
15
Sensor Input 15
16
Sensor Input 16
G
Ground
18
Installation
Alarm Output
Connect the alarm device to the alarm output. Alarm signal output
at an event occurrence.
HDD INSTALLATION
Note for Hard Disk Drive
Alarm output connection
The internal hard disk drive (HDD) is a fragile piece of equipment.
Please follow the guidelines below when using the DVR to protect
against possible HDD failure. We recommend that you back up your
important recordings onto an external backup device in order to
prevent accidental loss.
Make sure that the power is turned OFF when attaching or
removing the HDD.
3
Installation
Alarm device
Terminal No.
Alarm device
•
Do not move the DVR while the power is on.
•
Do not use the DVR in excessively hot or humid places, or in
places that may be subject to sudden changes in temperature.
Sudden changes in temperature can cause condensation to
form inside the DVR. This can be a cause of HDD failure.
•
While the DVR is switched on, do not unplug from the wall
socket or switch the electricity off from the breaker switch.
•
If there’s a power failure while the DVR is on, some data on the
HDD may be lost.
•
Do not drop the HDD. Also do not put the metallic object such
as coins or screwdrivers into the HDD tray.
•
When a power failure occurs during recording, avoid adding,
replacing or transporting the HDD as the recorded data may be
erased. In this case, turn the power back on to boot up the unit
normally with the HDD that was being used at the time of the
power failure attached. Then add, replace, or transport the HDD.
•
The HDD is very delicate. Handle the HDD with care and follow
the precautions below because even a tiny shock may damage
the internal components of the HDD.
Description
G
Ground
1
Alarm Output 1
2
Alarm Output 2
3
Alarm Output 3
4
Alarm Output 4
NOTE
The internal switching relays are rated for 0.3 A at 125 V AC or 1 A
at 30 V DC. If the electric current is higher than that the unit can
be damaged.
•
--
Do not place the HDD on the desk or table directly. Put a
thick cushion under the HDD because even a small shock
may damage the internal components of the HDD.
--
Do not use an electric screwdriver. Vibrations and shocks
caused by an electric screwdriver may damage the internal
components of the HDD.
--
When replacing the HDD, do not knock the HDD with other
components such as another HDD and the HDD tray.
--
Do not knock the HDD with tools such as a driver when
replacing the HDD.
Protect the hard disk drives from static electricity.
Installing the Hard Disk Drive
You can install up to 4 HDDs.
Improper installation or setup may disturb HDD recognition or
normal product operation. So you should consult with an expert
from the store where the product was purchased.
1. Detach the top case by sliding it after removing the screws.
2. Remove the screws and detach the hard disk mounting brackets
from the unit.
3. Attach the HDD onto the hard disk mounting brackets with four
screws.
4. Attach the hard disk mounting brackets with the screws.
5. Connect the HDD power cable to the HDD.
6. Connect the SATA cable to the HDD.
Installation
7. Connect the SATA cable to the SATA connector on the main
board.
19
System Operation
8. Assemble the top case.
9. Fix the screws.
10. When you turn the power of the unit on, the new HDD is
detected and formatted automatically.
1. Turn on the unit. System booting will commence. The LG logo
image will be displayed on the main monitor during the system
booting.
Replacing the Hard Disk Drive
2. When the booting is complet the live window will be displayed.
Click the LOCK icon on the system control bar or press the LOCK
button on the remote control to display the log-in window.
Turn the power of the unit off and detach the power plug from the
outlet.
1. Follow steps 1 to 2 described in “Installing the Hard Disk Drive”.
2. Remove the connector from the HDD.
4. Remove the HDD from the hard disk mounting bracket.
5. Install the new HDD.
4. Enter the password by using the virtual keyboard. (Note that the
default administrator password is “000000”.)
5. Press the LOCK button or click the [OK] icon.
You can see the live screen and operate the system.
6. After replacing the hard disk drive, insert the power plug into
the outlet and turn the power of the unit on. The new HDD is
detected and formatted automatically.
NOTE
•
This DVR is based on a VGA monitor using OSD. We
recommend to using the VGA monitor with this unit. If you
use a composite monitor, the OSD quality may be low to read
it.
•
If the DVR is turned off accidently and then turned on again,
the DVR may take a long time to be rebooted.
NOTE
•
Make sure that each of the SATA cables is connected to the
connector housing through its holes.
•
Do not use an electric screwdriver to fix them.
Recommended HDD
The following HDD has been tested and compatibility is ensured.
When you attach multiple HDDs use the recommended HDDs.
NOTE
If you do not use the recommended HDD, the system may not be
operated normally.
Maker
Seagate
Hitachi
RPM
Capacity Interface
Model No.
7,200
250 GB
SATA
ST3250311SV
7,200
500 GB
SATA
ST3500410SV
5,400
1 TB
SATA
ST31000424CS
5,700
1 TB
SATA
HCS5C1010CLA382
System Shutdown
1. First, you must stop playback and exit the setup menu. In
playback, press STOP.
2. Press and hold 1 (POWER) button until the beep sounds and
the logout window will be displayed.
3. Enter the password by using the virtual keyboard.
4. Press the LOCK button or click the [OK] icon. The system will
shutdown.
3
Installation
3. Remove the screws from the hard disk drive on the left/right
side of the hard disk mounting bracket.
3. Select a user name by using the mouse or arrow and the ENTER
button on the remote control or front panel. For the first time,
you can select the ADMINISTRATOR user name only. You can
register a new user with various access rights using the user
setup menu.
20
Installation
General Explanation of the Live
Screen on the Main Monitor
a
bc d
Displays the current date and time.
Displays the setup menu.
Main Monitor Screen
f System Control Bar
e
f
Displays the search menu.
Displays the PTZ remote control window.
3
Installation
Displays the screen division selection
window for the main monitor.
Displays the screen division selection
window for the spot monitor.
Displays the lock menu to change the
user type or disable system operation.
a Channel Number
Displays the channel number.
Turns the alarm off.
b Channel Name
Displays the edited channel name.
Displays the system log list window.
c Selected Channel
Displays the selected channel with white box.
Displays the system information window.
d Camera Status Icon
Displays the PTZ camera status.
Displays the input audio status.
Green “C” indicates continuous recording.
Green “I” indicates Instant recording.
Pause playback.
Jump to the beginning of the current
data recorded on the same date.
Select the required scanning speed.
Starts instant playback in selected
recording channel. If the recorded data is
empty, a warning message is displayed.
Red “S” indicates sensor triggered recording.
Jump to the last minute of the current
data recorded on the same date.
Blue “M” indicates motion detection recording.
Stop playback.
White “N” indicates the channel is not being recorded.
Violet “T” indicates text event recording.
e Live Screen
Displays the current surveillance live screen.
Display playback status.
Installation
You can capture and save the current
image in JPEG file format. You should
connect the external device to save the
capture image.
Selecting the Main Monitor screen mode
1. Playback the recorded data.
1. Press MAIN or click the
2. Pause the playback at a desired point
during playback.
3. Click this button. The device
selection window is displayed.
21
You can select the live screen mode to display a full, 4-split, 6-split,
8-split, 9-split or 16-split screens on the main monitor.
icon in the system control bar.
Screen mode select menu of main monitor is displayed on the
main monitor.
2. Select screen mode.
Selected Main Channel
4. Select a device and click [OK].
5. After saving the JPEG file, the
confirmation window is displayed.
Click [OK].
Channel Buttons
Click at a desired point to be marked
during playback. Up to 15 points can be
marked.
3
Installation
Display copy (export) menu.
NOTE
To display / remove the system control bar
Use OSD with the SHIFT button on the front panel or click the right
mouse button in live screen mode and then the system control
bar will be displayed or removed.
Screen split mode
Sequence mode
•
Channel Number: Press the 1 to 16 channel button to see
the current surveillance images in selected live screens on
the main monitor.
•
Full Screen Mode: When you see the selected channel on
the full screen.
•
4, 9, 16, 1+5 and 1+7 Split Mode: Displays selected split
screens on the main monitor.
•
Sequence: View all channels in sequence. You cannot use
sequence mode with the 16 split (LE5008/LE4008 series: 8
split).
3. Select [OK] and press ENTER to confirm your selection.
NOTE
To display the screen you desire to watch in full screen mode,
double click the desired channel.
22
Installation
Selecting the Spot Monitor screen mode
PTZ Camera Control
You can select the live screen mode to full or 4-split screens on the
spot monitor.
You can control the cameras connected via the data port of RS-485
terminal. You must set the configuration between the PTZ camera
and the DVR.
1. Press SPOT or Click the
icon in the system control bar.
Screen mode select menu of spot monitor is displayed on the
main monitor.
2. Select screen mode.
Selected Spot Channel
Channel Buttons
1. Select the PTZ camera channel on the main monitor you want
to control.
2. Press PTZ or Click the
icon in the system control bar.
Virtual PTZ remote control is displayed on the main monitor.
3. Use each item to control the PTZ camera.
Button
Function
Remove the PTZ virtual remote
control.
3
Use to pan/tilt the camera.
Installation
Confirm the preset position.
Select the Pan/Tilt/Zoom
speed.
To adjust the camera zoom.
To manually adjust the focus of
a camera.
To manually adjust the iris of a
camera.
Displays the Selected Preset
number.
Screen split mode
Sequence mode
•
Channel Number: Press the 1 to 16 channel button to see
the current surveillance image on the spot monitor.
•
Full Screen Mode: When you see the selected channel on
the full screen.
•
4 Split Mode: Displays 4 split screens on the spot monitor.
•
Sequence: Views the all channels in sequence.
To input the preset number.
To register preset positions.
To move the camera to the
preset position.
To delete a memorized preset
position.
3. Select [OK] and press ENTER to confirm your selection.
To start a preset tour.
To displays the setup menu of
the PTZ camera.
Preset Settings
Preset position is the function to register camera monitoring
positions (preset positions) associated with position numbers.
By entering the position numbers, you can move cameras to the
preset positions.
NOTE
To activate this function, you need to register the preset positions
of the PTZ cameras.
Installation
To Register Preset Positions
Setup for PTZ Cameras
1. Move the camera to a point you wish by using the
,
,
,
buttons.
You can adapt the camera to your requirements by setting up the
respective items in menus.
3. Select the preset number you wish to register.
1. Click the
icon.
The setup menu appears in the selected window of the main
monitor.
4. Press ENTER or click the
2. Use
2. Press SET or click the
23
icon.
icon.
,
The position and its number are memorized.
The following function is available only with cameras provided with
the preset function. The preset function makes the combination
camera move to the programmed preset position. It is necessary to
program preset positions for the combination camera beforehand.
icon.
2. Use number buttons to enter the memorized preset position’s
icon. The
camera moves to the preset position and the picture of the
camera in that position appears on the monitor.
To Clear the Preset Position
You can clear a memorized preset position.
icon.
2. Use number buttons to enter the memorized preset index
icon to clear the
preset positions.
NOTE
This function may not be available depending on PTZ cameras.
To Tour The Preset Positions
You can tour all preset positions.
1. Press the TOUR button or Click the
icon.
All registered preset positions in the camera will be selected
and the camera position image will be switched on the active
monitor.
2. You can stop the tour by pressing the TOUR
button or clicking the
icon.
, and
•
Refer to the manuals of the PTZ camera for more details.
•
Some PTZ cameras may not operated correctly with this unit.
•
You cannot control the other functions when the PTZ virtual
remote control is displayed.
3
Installation
Changing to a Picture in a Preset Position
number then press ENTER or Click the
,
NOTE
Preset numbers from 0 to 255 are available on this unit but the
actual preset range differs depending on PTZ cameras.
1. Press the CLEAR button or Click the
,
buttons to set the options.
NOTE
index number then press ENTER or click the
,
,
5. Repeat steps 1 to 4 to add additional positions.
1. Press the MOVE button or click the
,
24
Installation
Viewing System Information
To view system information:
1. Press the INFO button or click the
icon in the system
NOTE
Refer to the following system log list.
No.
Log Message
1
Power On
2
Power Off
3
Admin Login (Remote)
4
Admin Logout (Remote)
5
Admin Login (Local)
6
Admin Logout (Local)
3
7
Configuration Changed
Installation
8
Configuration Imported
9
Factory Default Set
10
Power Recovery
11
Backup Started
12
Backup Finished
13
Backup Failed
14
Export Started
15
Export Finished
16
Export Failed
17
S/W Updated
18
System Fan Failure
19
HDD Damaged (HDD1)
20
HDD Damaged (HDD2)
21
HDD Damaged (HDD3)
22
HDD Damaged (HDD4)
23
HDD Added (HDD1)
24
HDD Added (HDD2)
25
HDD Added (HDD3)
26
HDD Added (HDD4)
27
HDD Removed (HDD1)
28
HDD Removed (HDD2)
29
HDD Removed (HDD3)
30
HDD Removed (HDD4)
31
HDD Formatted (HDD1)
32
HDD Formatted (HDD2)
33
HDD Formatted (HDD3)
34
HDD Formatted (HDD4)
35
HDD Changed (HDD1)
36
HDD Changed (HDD2)
37
HDD Changed (HDD3)
38
HDD Changed (HDD4)
control bar. The system information window is displayed on the
main monitor.
•
Update: Press this button to update the system information.
2. Press the INFO button or click the [Exit] button to exit the
window.
Viewing the System Log List
To view the system log list:
1. Press the LOG button or click the
icon in the system
control bar. The system log list window is displayed on the main
monitor.
2. Use b / B to see the previous or next log list.
3. Press the LOG button or click the [Exit] button to exit the
window.
Installation
Export the recorded data
NOTE
This unit can manually copy recorded images and audio from builtin HDD to the external recording devices.
•
Check the export device before you proceed.
1. Press COPY or click the
•
You can also use the COPY button on the front panel for
export function.
•
You can export the recorded data only in the live mode.
•
If you use the external device, the external device has to be
formatted on this unit.
icon in the system control bar.
The export menu window appears.
25
1. Connect the external device to the USB port on the front
or the rear of the DVR.
2. Select the [Format] icon then press ENTER.
Confirm window is displayed after format is completed.
3. Select [OK] and press ENTER to close the window.
Check the size of the selected data and free space of the
external device. If the device does not have enough space,
create space on the device or erase the previously stored data.
2. Select [Target Device] then press ENTER.
•
Export can not be executed while the backup is in progress.
3. Use b/B to select a target device to export.
•
You can search the exported data with the supplied viewer
software.
5. Select the channel number and press ENTER. Repeat this step to
select multi channels.
•
When you export the recorded data, the audio data will also
be exported.
6. Set the [Start Date/Time] and [End Date/Time] to copy.
•
When you export the recorded data the export viewer
program will also be exported in the [ExportViewer] folder of
the device. The exported data file name is made automatically
as the [Channel name_export date_export time.exp] type.
•
Do not remove the USB device while the export is in progress,
it may cause a malfunction.
4. Press ENTER to confirm it.
•
•
b/B/v/V: Moves to the options.
b/B: Sets the selected option.
•
ENTER: Selects option or confirms the setting.
7. Press COPY or click the [Export] icon to start exporting. The
exported data will be authorized by the unit before saving and
it can only be played back with the exclusive player.
•
The warning message appears for the conditions listed below.
--
When the start date/time and end date/time are the same
value.
--
When the start date/time is later than the end date/time.
--
The export media does not have enough space.
--
When you set the time for data that does not exist.
•
An external media has to be formatted on this unit to prevent
a malfunction.
•
DVD+RW and DVD-RW discs have to be initialized before
using.
3
Installation
•
26
Installation
Configuration menu
Setting the Menu Using the Front Panel Buttons or
Remote Control Buttons
Front Panel
The features and options of the DVR are configured through the
menu. The operations of this unit can be set via a menu displayed
on the main monitor. You can select and set the operational
conditions by using the buttons on the front panel and the remote
control or using a Mouse connected to the unit.
Only administrator-level users have permission to access the Setup
menu and configure the DVR.
Description
Use these buttons to select the
menu options or adjust the
options value.
Select the option or confirm the
setting.
First level
Return to the previous menu or
level.
Second level
3
Remote
Control
Third level
Installation
1. Press SETUP/ESC to display the setup menu.
2. Use v / V to select the desired menu item, then press ENTER
to display the submenu.
3. Use v / V to select the desired submenu item, then press
ENTER to display the setting options.
4. Use v / V to select the desired option then press ENTER to set
the value.
5. Use b / B to select the desired setting then press ENTER to
confirm your selection.
6. Press SETUP/ESC repeatedly to exit the Setup menu.
If the save message appears, select [OK] and press ENTER to
save the settings.
NOTE
•
When you operate the function menu by using the remote
control and front panel buttons, both buttons are operated in
the same way to control the function menu.
•
To use other functions of number buttons on the front panel
as shown below.
1. Press SHIFT. The button indicator turns red.
2. Select the function button you want.
•
All the operation explanations are based on using the remote
control.
Help menu
Using a mouse to set a menu
Use the left or right mouse buttons to set the menu.
Button
Left button
Right button
1. Click the
Function
•
Use to select a required item or
decrease the options value.
•
If you double click the button,
you can see the selected
channel on the full screen.
Use to increase the options value.
icon on the System control bar with the left
mouse button to display a setup menu.
2. Click the desired option with the left mouse button to display
the second or third level menu options.
3. Click the desired option with the left mouse button.
4. Set the selected options value.
5. Click the
icon to exit setup menu.
If the save message appears, click [OK] with the left mouse
button to save the settings.
Installation
System settings
27
Network
Properties
3
DHCP: Select this option when a DHCP server is installed on the
network to allow IP address assignment. With this setting, the IP
address is assigned automatically.
•
IP Address: Enter the IP address.
•
DVR Name: Enter the DVR name using up to 20 characters.
•
Subnet Mask: Enter the subnet mask address.
•
Language: Select a language for the setup menu and
information display.
•
Gateway: Enter the gateway address.
•
Primary DNS: Enter the Primary domain name server that
translates the hostnames into IP address.
•
Secondary DNS : Enter the Secondary DNS server address that
backups the Primary DNS.
•
TCP/IP Port: Enter the TCP/IP Port number. You can watch the
live surveillance image over the network with the PC Client
program. The factory default port for transmission of video and
audio data is 9001. However in some cases it is better to change
this port number for added flexibility or security. You can edit
this port between 1 025 and 65 535.
•
Web Server Port: Enter the Web Sever Port number. You can
watch the live surveillance image over the network with a web
browser. Typically the TCP port used by HTTP is 80. However in
some cases it is better to change this port number for added
flexibility or security. You can edit this port to 80 or between
1 025 and 65 535.
•
Audio Port: Enter the Audio Port number. You can edit this port
between 1 025 and 65 535.
•
Bandwidth Throttle: Enter the Bandwidth to adjust the data
traffic.
•
Button Beep: Marks up to activate the button beep. The button
beep is activated when using the buttons.
•
Video format: Selects the video format to NTSC or PAL according
to your video system format. If you change the video format, the
HDD is formatted with selected video format. After the HDD has
been formatted, the confirmation message is displayed. Select
[OK] and press ENTER. The system will reboot.
NOTE
All cameras must be disconnected before you change the
video format to prevent malfunction.
•
Configuration Import: Import the DVRs configuration data from
the USB memory stick.
•
Configuration Export: Export the configuration data from this
DVR to the USB memory stick.
•
Factory Default: You can reset the DVR to its original factory
settings. Some options cannot be reset (date, time, daylight
saving, time zone and user password settings).
Installation
•
28
Installation
Network Streaming
•
Host Name: Enter the host name you want to use.
You can not use the “www”, “mail”, “http”, “ftp”, “com”, “lg”, “lge”,
“lgddns”, “lgeddns”, “ddns” for host name.
•
Registered Host: The registered host name appears.
•
Update: Register the host name you typed in [Host Name] to LG
DDNS server.
How to register DDNS host name
With the DDNS function, you can easily use LG DVR.
When you use the DDNS function for the first time after you
purchased LG DVR
1. Displays the DVR setup menu.
2. Select [System] > [DDNS] option.
3
Installation
3. Marks up for the [DDNS Service] option.
4. Enter the host name in the [Host Name] option.
•
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution. Each group such as
“Ch1 to Ch8” and “Ch9 to Ch16” are set the same resolution.
•
Quality: Selects the recording picture quality.
•
Frame Rate: Selects the frame rate. The frame rate is the number
of transportable frames per second. According to resolution, the
frame rate is set automatically. If you wish to set manually, refer
to the below.
Resolution
NTSC
PAL
Frame Rate
352*240
1, 3, 5, 7.5, 10, 15
704*240
1, 3, 5, 7.5
704*480
1, 3
352*288
1, 3, 5, 6, 7.5, 12.5
704*288
1, 3, 5, 6
704*576
1, 3
5. Press the [Update] button. If host registration is properly
completed, the host name will be displayed in the [Registered
Host] option. If the host name is not registered after updating,
please check network connection.
When you want to change DDNS host name
If you want to change the registered host name to new one, follow
as shown below.
1. Enter a new host name in the [Host Name] option.
2. Press the [Update] button. The confirmation window will be
displayed to change your host name.
3. Click the [OK] button. When host name is properly changed, the
changed host name will be displayed in the [Registered Host]
option. If host name is not changed after updating, please check
network connection.
Date/Time
DDNS
This free service is very useful when combined with the LG DDNS
Server. It allows the user to connect the IP device using the URL,
rather than an IP Address. This also solves the problem of having a
dynamic IP address.
•
•
Date: Select the current year, month and day.
•
Time: Select the current time.
•
Date Format: Select the date display format.
•
Time Format: Select the time display format.
•
Time Zone: Select the time zone in the area where the DVR is
installed.
•
Daylight Saving: Mark up when you use the daylight saving
function.
•
Daylight Saving Start: Select the Daylight Saving start time.
•
Daylight Saving End: Select the Daylight Saving end time.
DDNS Service: Marks up to activate the DDNS function.
Installation
NTP
29
Update
3
NTP: Marks up, if you want to synchronize the DVR’s date and
time with those of the time server called NTP (Network Time
Protocol) Specify the NTP server’s name.
•
Server: For most cases select public. The DVR will obtain the
average time among 5 public servers (time.nist.gov, time-a.nist.
gov, time-b.nist.gov, ntp.nasa.gov, clock.isc.org).
•
Private Time Server: Enter the private time server’s IP address or
host name using the virtual keyboard.
•
Sync. Interval: You can set synchronized intervals with the NTP
time server to 1 day, 1 week, 1 month and 1 hour.
•
NTP Test: Select [NTP Test] to test the NTP server.
NOTE
If the NTP option is not set to this system, there can be a
gap between the system time and actual time. Using NTP is
recommended.
The update feature allows you to upgrade DVR software and add/
upgrade PTZ protocols. In this case, the current DVR settings are not
deleted or replaced during the update process.
1. Connect the device including update file.
2. Select the update device from the drop-down list.
3. Select the [Search] button and press ENTER. The update file is
displayed in the list.
4. Choose the update file from the list.
5. Select the [Update] button and press ENTER. The confirmation
window is displayed.
6. Select [OK] to begin the update process or click [Cancel] to stop
and exit. After the update process is completed, the system
displays the Restart the system dialog box.
7. Click [OK] to restart the DVR.
NOTE
Controller
•
IR Remote ID: Select the IR Remote ID for this unit. If you use
multi systems set the IR Remote ID for each DVR unit.
•
Remote Controller ID: Select the Remote Controller ID for this
unit. If you use multi systems, set the Remote Controller ID for
each DVR unit. You can control the DVR by using the LKD1000
controller. (For more details refer to the LKD1000 owner’s
manual).
•
Do not turn the power off during the update process to
prevent the malfunction.
•
Do not remove the external device or CD/DVD disc for update
whilst the update is in progress. It may cause a malfunction.
Installation
•
30
Installation
Backup
3. Select the backup device.
4. Enter the date and/or time to start backup on the schedule start
option.
5. Enter the day of week and/or time on the Time Range Start
option.
6. Enter the day of week and/or time on the Time Range End
option.
7. Select the [Estimation Size] icon and press ENTER.
8. Check the size of selected data and free space of USB device. If
the USB device does not have enough space, change the USB
device to a USB which has enough space or erase data of the
connected USB device.
3
NOTE
Installation
•
Partition Selection: Select a backup partition.
•
Schedule: You can set the backup schedule.
--
OFF: All options are disabled.
--
WEEKLY or DAILY: The backup data will be automatically
saved according to the setting.
--
INSTANT: The backup data is saved manually.
•
Device: Select a backup device.
•
Schedule Start: Set the schedule start date (A day of the week
and time).
•
The backup function is not supported on the external USB CDROM driver.
•
Available external device for backup.
Device
USB HDD
E-SATA HDD
Capacity
Less than 1 TB.
Unlimited.
•
Use the recommended external USB devices for preventing
malfunction (See page 69).
•
The CD-R, DVD-R or DVD+R discs cannot be formatted.
•
DVD+RW and DVD-RW discs have to be initialized before
using.
•
An external media has to be formatted on this unit to prevent
malfunction.
•
Time Range Date: Enter the backup time range. Enter the date
you want to backup.
•
Time Range Start: Enter the start day of the week or time.
•
Time Range End: Enter the end day of the week or time.
•
•
Estimate Size: Displays the size of backup data and the free
space of external devices.
You cannot use the [Estimate size], [Start Backup] and [Erase
Media] options in backup progressing.
•
•
Start Backup: To start backup.
Do not remove the external device while the backup is in
progress, it may cause a malfunction.
•
Erase Media: To erase the media.
•
If you format the external media by using a PC with FAT32, the
media may not be used on this unit.
•
Check the size of the selected data and free space of the
external device. If the device does not have enough space,
create space on the device or erase the previously stored data.
Instant Backup
1. Connect the backup USB device or insert a recordable disk to
the disc driver for backup.
1. Select the [Estimate Size] icon and press ENTER.
The size of the selected data and free space is displayed.
2. Select the partition you want to backup.
3. Select INSTANT from the schedule options.
4. Select the backup device.
2. Select [OK] and press ENTER to close the window.
•
You cannot stop the backup in backup progress.
•
The warning message will appear for the conditions listed
below.
5. Select the Time Range Date, Time Range Start time, and Time
Range End time for backup.
--
When the start time and end time are the same value.
6. Select the [Estimate Size] icon and press ENTER.
--
When the start time is later than the end time.
--
When you set the time for data that does not exist.
--
When the start time and end time setting are wrong.
--
A media does not have enough space.
--
When the selected USB device is disconnected.
7. Check the size of the selected data and free space. If the device
does not have enough space, create space on the device or
erase the previously stored data.
8. Select the [Start Backup] icon and press ENTER to start backup.
9. Exit the setup menu. You can check the backup status on the
system control bar in backup progress.
Daily/Weekly backup
1. Connect the USB device for backup. You cannot use the CD or
DVD writer for daily or weekly backup.
2. Select WEEKLY or DAILY on the schedule options.
Installation
NOTE
The disc burning is carried out by a single session closed
format.
•
If you use the CD/DVD writer device for backup, it is making
ISO image and then writing the backup data to the CD/DVD.
•
You can see the backup progress status on the system control
bar.
•
The estimated size of backup data is only the approximate size.
So you must prepare sufficient space on the media to prevent
lack of space.
•
At the scheduled recording time, you can check the backup
status on the system control bar.
•
While export is in progress or searching the backup data
from the external USB device, the scheduled backup will
not be started. After the export or backup search is finished,
scheduled backup will be restarted.
•
When you set the schedule backup, the backup data size is
estimated from the recording settings of the Setup menu. If
the real recorded data size is over the estimated recording
data size, the schedule backup may not be activated.
Device settings
Camera
3
Installation
•
31
•
Ch: Displays the channel number.
•
Name: Enter the channel name using up to 20 characters.
•
Audio: Select the input audio channel. You can hear from the
selected input audio channel. This function is not available for IP
channels.
PTZ
Settings for the PTZ cameras connected via the data port of the
RS-485 terminal.
•
Channel: Selects the desired channel to set the connected PTZ
camera.
•
Port: Selects the connected data port of the RS-485 terminal
on the rear panel. The DATA 2 port is used to control the PTZ
camera connected to DVR or to control by using the LKD1000
controller. If you want to use the PTZ camera via DATA 2 port,
you should set the [Remote Controller ID] to [NONE]. If you use
the LKD1000 controller to control the DVR via DATA 2 port, you
should set the [Remote Controller ID] number between 1 to 16.
•
Control ID: Selects the PTZ camera ID. Make the same settings
as the PTZ camera.
•
Protocol: Selects the protocol supported by PTZ camera.
•
Baud Rate: Selects the communication speed.
32
Installation
•
PTZ Test: After the PTZ setting, you can test the pan/tilt function
for the selected PTZ camera. You can see the test screen from
the preview windows on the right side of the PTZ test option.
---
ATM/POS
b / B: Test the pan direction.
v / V: Test the tilt direction.
NOTE
The supported PTZ camera list is on page 70 for reference.
IP Camera
3
Installation
•
•
Channel: Selects the desired channel to set the connected IP
camera.
•
Vendor: Selects the IP camera vendor from the drop-down list.
•
Model Name: Enter the model name of the IP camera.
•
Host Name: Enter the IP address of the IP camera.
•
User Name: Enter the user ID.
•
Password: Enter the user password.
•
Port: Enter the port number.
•
Test: Select [Test] to test the connection with the IP camera.
NOTE
The Supported IP camera specifications.
Specification
Description
Vendor
LG, AXIS
Recording mode
Continuous, Instant
Video Codec
H.264 Baseline Profile
Audio recording and playback Not support
Resolution
CIF, Half D1(2CIF), D1(4CIF)
Stream
Master-0 only for LG camera
PTZ
Not support
Sensor/Motion input
Not support
Interface Device: Select the interface device from the dropdown list.
--
NONE: Selects when the ATM/POS device is connected with
the DVR directly.
--
AVE Hydra: Selects when the ATM/POS device is connected
via the AVE Hydra device to the DVR. If you set to AVE Hydra,
the [Camera], [Baud Rate], [Data Bits], [Stop Bits] and [Parity]
options are dimmed and these options are not set.
•
Camera: Select the camera number for mapping with ATM/POS
device.
•
Baud Rate: Select the desired parameter to set the
communication speed between DVR and ATM/POS device.
•
Data Bits: Select the number of the data bits for RS-485
communication.
•
Stop Bits: Select the desired parameter. The stop bit, added to
the last of data, in asynchronous communication.
•
Parity: Select the desired parameter. The parity bit, added to the
data, to perform parity check.
Installation
Storage
33
Display settings
OSD
3
Installation
•
Overwrite:
--
ALL: Overwrite recording is possible when the normal
partition and event partition of HDD have fully recorded.
--
NORMAL PARTITION: Overwrite recording is possible for
normal partition of HDD when the normal partition of HDD
has fully recorded.
--
--
•
Channel Name: Mark up to display or remove the channel name
in the channel window.
EVENT PARTITION: Overwrite recording is possible for event
partition of HDD when the event partition of HDD has fully
recorded.
•
Channel Status: Mark up to display or remove the channel status
in the channel window.
OFF: Do not use overwriting.
Sequence
•
Full Warning: When the HDD has overflowed a warning message
is displayed.
•
Auto Delete: Set the auto delete date. If you set the auto delete
date, the recorded data will be deleted except the data within
the selected date period of time. The Auto Delete function is
activated every 35 minutes.
•
Event Partition: Set the space of event partition for event
recording. The motion and sensor recording data are saved in
the event partition area of the HDD. You should set the space of
event partition before event recording.
•
Format: Initializes the HDD (Hard Disk Drive). All data on the
HDD will be erased.
NOTE
If you change the value of event partition, the current recorded
data of HDD is deleted and the partition is reset. The partitions will
be formatted automatically and the system will be restarted.
How to format the HDD
1. Select the [Event Partition] option and set the event partition
rate of the HDD. If you set the event partition to 60%, the
remaining space of 40% is set to normal partition automatically.
•
Event Partition: To save space of the HDD for motion and
sensor recording data.
•
Normal Partition: To save space of the HDD for instant or
normal recording data.
2. Select the [Format] icon and press ENTER.
3. Select [OK] and press ENTER to start format.
View all the channels in sequence in the selected screen division
mode. You cannot use sequence mode with the 16 split (LE5008/
LE4008 series: 8 split). While the sequence mode condition, if you
change the screen division mode, the sequence function will be
canceled.
•
Main Dwell Time: Selects the channel sequence time for main
monitor.
•
Spot Dwell Time: Selects the channel sequence time for spot
monitor.
34
Installation
Channel Composition
Record settings
Schedule
A schedule recording can be activated at preset times, in a repeating
pattern on selected weekdays. The DVR can record according to a
schedule set by the user. It can also record manually regardless of
date and time. The recording can be made either continuously or
triggered by events (alarm and motion detection).
The recording schedule screen displays one day of the week
showing the schedule of all channels over a 24-hour period. For
each 1-hour cell block the recording method can be specified. The
recording method for each block is shown in color for easy viewing.
3
Installation
Channel numbers
Time Line
•
Ch: Displays the channel number.
•
Name: Selects the desired channel. You can set the IP channel
only one time.
Video Adjustment
Adjust the brightness, contrast and color settings of each camera
channel. You can see the settings screen from the preview windows.
Recording mode
To Set the Recording Schedule for a
Typical Day of the Week
1. Select a day of the week.
•
Channel: Selects the desired channel to adjust.
•
Brightness: Adjust the brightness value from 0 to 100 for the
selected channel.
•
Contrast: Adjust the contrast value from 0 to 100 for the selected
channel.
•
Color: Adjust the color value from 0 to 100 for the selected
channel.
2. Select the desired channel to schedule recording.
Installation
•
35
Sky blue (Continuous+Sensor+Motion+Text event
recording): Recording starts automatically from the preset
time. When the sensor alarm signal has input, motion has
been detected or the text input occurs within a designated
time, change the continuous recording mode to occurred
event recording mode and recording starts automatically.
5. Select the next time cell block of schedule time cell blocks to
confirm the schedule time.
6. Press ENTER or click the left mouse button repeatedly to select
gray to set the time for the end of the schedule. The settings cell
block is highlighted.
3
Installation
3. Select the time cell block for the start time.
4. Press ENTER or click the left mouse button to select a recording
mode. The color of the cell blocks will change automatically.
•
Gray: No schedule recording.
•
Green (Continuous recording): Recording starts
automatically from the preset time.
•
Red (Sensor event recording): Recording starts automatically
when the sensor alarm occurs within a designated time.
•
Blue (Motion event recording): Recording starts
automatically when motion is detected within a designated
time.
•
Violet (Text event recording): Recording starts automatically
when text input is detected within a designated time.
•
Yellow (Sensor+Motion recording): Recording starts
automatically when the sensor alarm signal has input or
motion has been detected.
8. Press SETUP/ESC repeatedly to exit the Setup menu.
•
Green+Red (Continuous+Sensor event recording):
Recording starts automatically from the preset time. When
the sensor alarm occurs within a designated time, change
the continuous recording mode to sensor event recording
mode and recording starts automatically.
To Set a Recording Schedule for a Special Day
•
•
•
•
Green+Blue (Continuous+Motion event recording):
Recording starts automatically from the preset time. When
the motion is detected within a designated time, change
the continuous recording mode to motion event recording
mode and recording starts automatically.
7. Press SETUP/ESC to move to the previous menu.
If the save message appears, select [OK] and press ENTER to
save the settings.
In addition to the weekly schedule, up to 10 specific date/time
periods can be defined. To configure the specific recording schedule
select Specific Dates.
1. Select the [SP] button on the schedule setting menu.
2. Select a cell block.
3. Press the [ZOOM +] button or click the [Add] icon on the special
day setting menu.
The specific date selection menu appears.
Green+Violet (Continuous+Text event recording): Recording
starts automatically from the preset time. When the
text input occurs within a designated time, change the
continuous recording mode to text event recording mode
and recording starts automatically.
4. Enter the necessary information for year, month and date.
Green+Yellow (Continuous+Sensor+Motion event
recording): Recording starts automatically from the preset
time. When the sensor alarm signal has input or motion has
been detected, change the continuous recording mode
to motion event recording mode and recording starts
automatically.
5. Use b / B / v / V to select the [OK] button and press ENTER.
The virtual keyboard menu appears.
Yellow+Violet (Sensor+Motion+Text event recording):
When the sensor alarm signal has input, motion has been
detected or the text input occurs and then recording starts
automatically.
•
b / B / v / V: Press to move the columns, [OK] or
[Cancel] buttons.
•
b / B (or left/right mouse button): Changes the value at
the current position.
6. Enter the name of the special day. Use v/V/b/B to select a
character then press ENTER to confirm your selection.
7. Use v / V to select the [OK] icon then press ENTER to fix the
date of the special day and return to the special day menu
screen.
8. Select the schedule time and set the recording method for each
channel.
36
Installation
Checking the Special Day Schedule List
1. Press [ZOOM -] when the [SP] button is selected.
The special day scheduled list appears.
Normal
Settings concerning normal recording.
2. Select a special day title on the list and press ENTER.
The title color turns orange.
3. Select the [Edit] icon then press ENTER to edit the special day or
press [ZOOM -] to delete the special day schedule.
4. Press ESC to exit the special day schedule list.
NOTE
If the special day recording schedule is duplicated with the other
recordings, only the special day recording is possible.
3
Installation
Copying the Recording Schedule
Copying from the Scheduled Data of the Channel
You can copy the schedule data of the channel to the other
channel(s) within the selected day of the week. You can not copy
the schedule data of the IP channel.
•
Ch: Displays the channel number.
1. Select the day of the week and press ENTER.
•
Resolution: Selects the recording resolution.
2. Select channel that you want to copy.
•
Quality: Selects the recording picture quality.
3. Press COPY then the channel selection menu appears.
•
Frame Rate: Selects the frame rate. The frame rate is the number
of recorded frames per second. According to resolution, the
frame rate is set automatically.
4. Use b / B to move to the left or right column then press
ENTER to select the target channel(s).
You can cancel the selected channel by pressing ENTER.
5. Use v / V to select [OK] then press ENTER to confirm your
selection.
Copying from the Scheduled Data of the Day
You can copy the scheduled day of the week to another day of the
week, weekday and weekend using the COPY button.
1. Select the day of week that you want to copy.
2. Press COPY then the select date(s) menu appears.
3. Use b / B to select the target date(s).
4. Use v / V to select [OK] then press ENTER to confirm your
selection.
NOTE
In case of the LE4000 series models, the resolution setting is
possible in the Normal setting menu only. Each group such as
“Ch1 to Ch4”, “Ch5 to Ch8”, “Ch9 to Ch12” and “Ch13 to Ch16” are
set the same resolution.
If you change the resolution of the Normal option, the resolution
of the Motion, Sensor, Text and Instant/Panic options will be
changed automatically with the same resolution.
Sensor
Settings concerning sensor recording.
•
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution. The LE4000 series
models are displayed only.
Installation
•
Quality: Selects the recording picture quality
•
Frame Rate: Selects the frame rate. The frame rate is the number
of recorded frames per second. According to resolution, the
frame rate is set automatically.
•
Prealarm: Specify the pre-event recording time. When the Event
signal is detected, the DVR is recording the data before the
event during the setting time.
•
Postalarm: Specify the post-event recording time. When the
Event signal is detected, the DVR is recording the data after the
event during the setting time.
37
Text
Settings concerning text recording.
Motion
Settings concerning motion recording.
3
Installation
•
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution. The LE4000 series
models are display only.
•
Quality: Selects the recording picture quality.
•
Frame Rate: Selects the frame rate. The frame rate is the number
of recorded frames per second. According to resolution, the
frame rate is set automatically.
•
Prealarm: Specify the pre-event recording time. When the Event
signal is detected, the DVR is recording the data before the
event during the setting time.
•
Postalarm: Specify the post-event recording time. When the
Event signal is detected, the DVR is recording the data after the
event during the setting time.
•
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution. The LE4000 series
models are display only.
•
Quality: Selects the recording picture quality.
•
Frame Rate: Selects the frame rate. The frame rate is the number
of recorded frames per second. According to resolution, the
frame rate is set automatically.
•
Prealarm: Specify the pre-event recording time. When the Event
signal is detected, the DVR is recording the data before the
event during the setting time.
•
Postalarm: Specify the post-event recording time. When the
Event signal is detected, the DVR is recording the data after the
event during the setting time.
Instant/Panic
Settings concerning instant/panic recording.
•
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution. The LE4000 series
models are display only.
•
Quality: Selects the recording picture quality
•
Frame Rate: Selects the frame rate. The frame rate is the number
of recorded frames per second. According to resolution, the
frame rate is set automatically.
38
Installation
Event settings
IP camera
Settings concerning IP camera recording.
Sensor
3
Installation
•
Ch: Displays the IP camera channel number.
•
Resolution: Selects the recording resolution.
•
Quality: Selects the recording picture quality
•
Frame Rate: Selects the frame rate. The frame rate is the number
of recorded frames per second. According to resolution, the
frame rate is set automatically.
NOTE
•
If the video of some IP cameras is not displayed, you should
set the [Resolution] option to CIF (352x240 or 352x288).
•
If you want to set the Frame Rate manually for each recoding
setting menu, refer to the below.
LE5016/LE5008 Series
Resolution
Frame Rate
•
In: Displays the number of the ALARM-IN terminal.
•
Sensor Type: The sensor state can be set to either N.O. (Normally
Open) or N.C. (Normally Closed).
•
Camera: Select the connected camera channel to the ALARM-IN
terminal.
•
Relay Output: Select the alarm (relay) output number for the
RELAY-OUT terminal for the output alarm (relay) signal.
•
Preset: Select the preset number. When the input is activated,
the camera moves to the selected preset position and the
picture of the camera in that position appears on the monitor.
Motion
352*240
NTSC
704*240
1, 3, 5, 7.5, 10, 15, 30
704*480
352*288
PAL
704*288
1, 3, 5, 6, 7.5, 12.5, 25
704*576
LE4016/LE4008 Series
Resolution
NTSC
PAL
Frame Rate
352*240
1, 3, 5, 7.5, 10, 15, 30
704*240
1, 3, 5, 7.5, 10, 15
704*480
1, 3, 5, 7.5
352*288
1, 3, 5, 6, 7.5, 12.5, 25
704*288
1, 3, 5, 6, 7.5, 12.5
704*576
1, 3, 6
•
Channel: Select the channel to set motion detection.
•
Sensitivity: Set the level of sensitivity for the created motion
detection area. Sensitivity can be set from level 01 to 10 or OFF.
•
Relay Output: Select the number of the RELAY-OUT terminal for
the output alarm (relay) signal when motion is detected.
•
Area: Select the desired motion detection area on the preview
window screen.
--
b / B / v / V: Moves the yellow cell box to another cell
zone.
Installation
--
ENTER: Selects or cancels the motion detection area at the
current cell position.
--
Press ESC to exit the settings.
NOTE
ATM/POS Recording Information.
Option setting
NOTE
•
•
To select the area: Drag & drop a cell to the right to select
the motion detection area.
--
To cancel area: Drag & drop a cell point of a selected cell
area to the left to cancel the motion detection area.
ATM/POS Recording Action
Recording is started automatically
When the Transaction
when the Transaction start data is
Start and Transaction End detected. When the Transaction
options are set.
end data is detected the recording
is stopped after post-alarm time.
You can select the motion detection area by using the mouse.
--
ATM/POS Data Format
Event Popup
•
•
Input Channel: Select the mapping camera channel.
•
Transaction Start: Enter a Transaction Start string. Refer to the
device manufacturer’s documentation for the text string that
the device first sends when a transaction starts.
•
Transaction End: Enter a Transaction End string. Refer to the
device manufacturer’s documentation for the text string that
the device sends when a transaction ends.
•
Delimiter: Enter the character(s) that the device uses to
indicate the end of a line. Refer to the device manufacturer’s
documentation for Line Delimiter character(s).
•
Ignore String: Enter the any strings of text that you want the DVR
to ignore. Refer to the device manufacturer’s documentation
for text strings that the device sends during transactions, so you
will know which ones you do not want recorded.
•
Time Out: Select the Recording end time.
•
Relay Output:
--
01 to 04: Outputs the alarm (relay) signal via the RELAY-OUT
terminal. When the DVR detects text input, it triggers output
signals on all the associated RELAY-OUT connectors.
--
NONE: Not used.
Spot Monitor: Select the event type for the spot monitor display
when the event is activated.
Notification
Marks up when you want to activate the selected option. If the
selected notification option is activated, the device will notify the
user about the information of selected option by E-mail.
3
Installation
Recording is started automatically
when the transaction data is
When the Transaction
detected. When the transaction
Start and Transaction End data is not detected the recording
option is not set.
is stopped after post-alarm time
and the time you set of the Time
Out option.
In the condition that illumination is low and the outline of
object is not clear enough to see, regardless of sensitivity,
Motion Event could be possible not to happen. You must
check Motion Event before setting.
The DVR can be set to react to text input from devices such as
ATMs (Automated Teller Machines) and POS (Point of Sale; i.e., cash
registers). This screen allows you to configure the DVR for your input
device.
39
40
3
Installation
•
Sensor On: Sends an e-mail when a sensor has occurred.
•
Motion Detection: Sends an e-mail when a motion detection
has occurred.
•
Text In: Sends an e-mail when a text input is detected.
•
Admin Password Changed: Sends an e-mail when the
administrator password has changed.
•
Video Loss: Sends an e-mail when a video signal from the
camera has stopped because of a cable disconnection or
malfunction of a camera.
•
Power On/Off: Sends an e-mail when power is on or off.
•
Disk Full: Sends an e-mail when the HDD has fully recorded.
Emergency
Mail
Installation
•
Notification: Marks up to notify the emergency agent about unit
operating information according to your notification settings.
•
Host Name/Port: Enter the Host Name and port number of the
emergency agent program. The factory default port for this
function is 9002. However in some cases it is better to change
this port number for added flexibility or security. You can edit
this port between 1 025 and 65 535.
You can set up to 9 Host Name and port numbers.
Output
•
Notification: Marks up to notify the unit operating information
according to notification settings by e-mail.
•
SMTP Server: Enter the SMTP Server address.
If notification option is not mark up and the SMTP server option
is empty, the SMTP Port, User Name, Password and TLS options
cannot be set.
•
SMTP Port: Enter the SMTP Port Number. Typically the port used
for SMTP is 25. However in some cases it is better to change this
port number for added flexibility or security. You can edit this
port between 1 and 65 535.
•
User Name: Enter the user name.
•
Password: Enter the password.
•
TLS: Marks up when using the TLS (Transport Layer Security)
function.
•
Mail Address (1 to 3): Enter the mail address.
You can input up to 3 e-mail addresses.
•
E-mail Test: Select [E-mail Test] to test send an e-mail.
NOTE
The SMTP server, SMTP port no., user name or password settings
are optional. The DVR can send e-mail directly without the use of
an SMTP server or MTA (message transfer agent). In certain cases
all e-mail should be forwarded to a specific SMTP server. Specify
the server host name or IP address in such a case. For more detail
on SMTP setup, ask your network administrator and/or mail service
provider.
•
•
Relay Off
--
ALARM ACKNOWLEDGE: Use the ALM.OFF button to stop
alarm.
--
POST-ALARM TIME: The alarm is stopped after post-alarm
time.
System Alarm Out: Outputs the alarm (relay) signal via the
selected alarm out terminal number below cases. If you do not
use this function, select [NONE] option.
--
When the HDD has a bad sector.
--
When a video signal from the camera has stopped because
of a cable disconnection or malfunction of a camera.
Installation
Buzzer
Marks up when you want to activate the selected option.
41
User settings
Group Authority
You can register a new user group with various access rights.
3
Sensor: Makes a sound when a sensor occurs.
•
Motion : Makes a sound when a motion is detected.
•
Text: Makes a sound when the DVR detects text input .
•
System: Makes a sound when a cooling fan is not activated or
the HDD has bad sector.
Installation
•
•
Group ID: Select the group ID to assign authority.
--
GUEST: The GUEST group has the limited authority of the
system. Users in this group are available to see the live
image and to set the covert function of the Main or Spot
channel.
--
ADMINISTRATOR: The ADMINISTRATOR group has the
unlimited authority of the system. Users in this group are
available to use all of the functions.
--
[Group 01] to [Group 08]: Users in this group are available to
set the authority of the function manually.
NOTE
The GUEST and ADMINISTRATOR group are set initially for the
authority. You cannot change the initial settings and group name
(GUEST and ADMINISTRATOR).
•
Group Name: If you select one of the group numbers from the
Group ID option, you can register the group name. Enter the
group name.
--
•
Setup, Search/Play, Export, PTZ, Power Off, Instant Record:
Set the authority for the selected group. Marks up the
option to activate it.
Main Channel/Spot Channel: Selects the channel to allow the
operation for the group user. The LG logo is displayed on the
covert channel(s).
42
Installation
User
You can set the user name for the selected User ID.
3
Installation
1. Select [User ID] from the drop-down list.
2. Enter the user name of the selected user ID.
3. Select the user group from the drop-down list.
4. Enter the Password.
5. Select the auto user logout time from the drop-down list.
6. Press the ESC button to display the confirmation window.
7. Select [OK] to save the setting or [Cancel] to cancel the setting.
NOTE
•
If you set the user ID to [ADMINISTRATOR], you cannot change
the [User Name] and [Group] option but you can change the
password.
•
The user name and password are case-sensitive.
Operation
43
4
Operation
Instant Recording
Images from a camera will be recorded on the built-in hard disk.
Ensure all the cameras are connected and that time and date have
been set correctly.
Before you start recording, first check the repeat recording settings
in the recording menu of the system setup, and then make the
recording settings.
NOTE
•
External recording devices can be used as copy areas for
images recorded on the hard disk. It is impossible to record
images on the external recording devices directly.
•
You can record instantly with the left mouse button.
1. Move the cursor to the desired channel screen on the
main monitor.
2. Press the REC button and then press the channel button you
want to stop recording. If you stop instant recording, the
recording mode will be changed into the scheduled recording
mode (Continuous/ Alarm/ Motion records). If the schedule is
not set, the button indicator turns off and the recording type
indicator turns white on the selected channel screen of the
main monitor.
Panic Recording
•
You can instant record that the channels scheduled such as
alarm, motion or continuous.
•
Once you stop instant recording, the recording type indicator
will be changed to the scheduled recording mode.
•
You can not record the Instant and Continuous recording in
following conditions.
•
•
--
A HDD is not attached.
--
A HDD is not formatted.
--
The channel has no video input for display.
--
Overwrite sets to “OFF” or “EVENT PARTITION”, and normal
partition is full.
--
On the HDD setting, the event partition is set to 100 %.
You can not record the Alarm and Motion recording in
following conditions.
--
A HDD is not attached.
--
A HDD is not formatted.
--
The channel has no video input for display.
--
Overwrite sets to “OFF” or “NORMAL PARTITION”, and event
partition is full.
--
On the HDD setting, the event partition is set to 0 %.
--
The schedule (Alarm/Motion) record is not set.
HDD partition according to a recording type.
--
Normal Partition: It is the space in the HDD that stores the
continuous and instant recorded data. Once the normal
partition is set to 0% (the event partition is 100%), you can
not record the continuous or instant recordings.
--
Event Partition: It is the space in the HDD that stores the
alarm and motion recorded data. Once the event partition
is set to 0%, you can not record the alarm and motion
recording.
You can record the all channels at the same time.
This function is activated for a live channel only.
1. Press and hold the REC button until the Recording Type
indicator turns green on the all live channel screens.
The DVR will start recording.
2. Press and hold the REC button until the Recording Type
indicator turns white on the all live channel screens. The DVR
will stop recording.
•
Priority of record.
Instant record > Alarm record > Motion record > Continuous
record.
4
Operation
2. Click the recording type indicator with the left mouse
button and recording starts. Click it once again and the
instant record stops and the recording type indicator
will be changed into the scheduled recording mode
(Continuous / Alarm / Motion record). If the schedule is
not set, the recording type indicator turns white.
1. Press the REC button and then press the channel button you
want to record. The recording type indicator turns green on the
selected channel screen of the main monitor.
44
Operation
Instant Playback
8. Press SETUP/ESC to exit the[Date/Time] menu.
Using the calendar icon to select the date
It is possible to play a recorded image without stopping recording.
1. Select a channel you want to playback.
2. Press bB (Play) button to play a recorded image of the previous
1 or 2 minutes of recording. The playback image will be
displayed on the full screen window.
3. Press x (STOP) button to stop the playback.
1. Select calendar icon then press ENTER.
2. Select year or month column then press ENTER.
3. Use b/B button to input the year or month.
4. Press ENTER to confirm it.
5. Use v/V/b/B to select date then press ENTER.
6. Select [OK] button and press ENTER to confirm the settings.
NOTE
Search and Playback
4
The various search functions of this unit can be used to go to the
beginning of the desired picture.
When the SEARCH button is pressed the search menu is displayed.
•
While the backup is in progress, you can not search the data
on the backup device.
•
Do not remove the external USB device whilst the backup
search is in progress from the USB device. It may cause a
malfunction.
•
Recorded data shown on the time graph will be displayed in
different colors depending on the recording type.
Operation
--
Green: Continuous recording.
Date and Time Search
--
Red: Sensor recording.
Use to search recorded pictures by specifying date, hour and
minute.
--
Blue: Motion-detection recording.
--
Gray: No recording.
--
Violet: ATM/POS recording.
•
Use the ZOOM + button to view the detailed time by 6 hour
intervals.
Event Search
Search a recorded picture by date and type of event.
1. Use v/V button to select the [Date/Time] icon then press
ENTER.
2. Select the desired source device.
•
INTERNAL HDD: Plays back or searches recorded contents of
the internal HDD device.
•
Source Device: Plays back or searches backup contents of
the source device.
3. Set the year, month, date and time.
•
•
b/B: Moves to the previous or next column.
v/V: Changes the value at the current position.
•
ENTER: Selects the column or confirms the setting.
4. Select the [Search] icon then press ENTER.
The search result is displayed.
5. Use v/V button to select the channel and press ENTER. Repeat
this step to select the other channels.
6. Press bB (Play) button or click the [Play] button to start
playback.
The picture(s) is (are) displayed on the main monitor.
7. Press STOP (x) to stop playback and return to the search menu.
1. Use v/V button to select the [Event] icon then press ENTER.
2. Select the desired source device.
3. Set the year, month, date and time.
•
•
b/B: Moves to the previous or next column.
v/V: Changes the value at the current position.
•
ENTER: Selects the column or confirms the setting.
4. Use v/V/b/B button to select the channel and press ENTER
button to confirm the selection. If you want to select the all
channels, marks up the [All Channels] option.
5. Select the [Event Type] then press ENTER.
6. Use v/V to select the event type then press ENTER.
Operation
7. Select the [Search] icon then press ENTER.
The event list menu appears.
8. Select the recording data on the event list then press bB (Play)
button, click [Play] or double click the selected data to start
playback.
The picture is displayed on the main monitor.
45
ATM/POS Search
Search the recorded text information by ATM/POS device.
This function is available with backup data of the internal or external
HDD only.
9. Press STOP (x) to stop playback and return to the event list
menu.
10. Press SETUP/ESC repeatedly to exit the event search menu.
Bookmark Search
Search the desired picture with a bookmark registered by the
bookmark function.
4
2. Select the desired source device.
3. Set the year, month, date and time.
•
•
b/B: Moves to the previous or next column.
v/V: Changes the value at the current position.
•
ENTER: Selects the column or confirms the setting.
4. Use v/V/b/B button to select the channel and press ENTER
button to confirm the selection. If you want to select the all
channels, marks up the [All Channels] option.
1. Use v/V button to select the [Bookmark] icon then press
ENTER.
2. Select the recording data on the list then press bB (Play), click
[Play] or double click the selected data to start playback.
The picture is displayed in the main monitor.
3. Press STOP (x) to stop playback and return to the bookmark list
menu.
4. Press SETUP/ESC to exit the bookmark search menu.
NOTE
5. Set the detail search options.
•
Number: Displays the preset number.
•
Option Item: Enter the text to search what you want.
•
AND /OR : Select the Boolean operator when you use the
Text search and Number search function simultaneously.
•
Value: Enter the number to search what you want.
•
>, <, <=, =, >= (compare symbols): Select the compare
symbol for number search.
>
To find the lower value than the input value.
•
Backup data can not be played back by a bookmark search.
<
To find the higher value than the input value.
•
You can register a bookmark only in the single channel
playback.
<=
To find the higher or even value than the input
value.
•
If you delete the bookmark on the list, select the recording
data and select [Delete] button and press ENTER.
=
To find the even value than the input value.
>=
To find the lower or even value than the input
value.
6. Select the [Search] icon then press ENTER.
7. Select the text data on the list then press bB (Play) button, click
[Play] or double click the selected text data to start playback.
The picture is displayed on the main monitor.
8. Press STOP (x) to stop playback and return to the ATM/POS
search list menu.
Operation
1. Use v/V button to select the [ATM/POS] icon then press ENTER.
46
Operation
Export Search
Search an exported data from the external device or internal
DVD-ROM device.
If you want to use this function, you have to connect the external
device or insert the CD/DVD disc with exported data otherwise the
warning message will be displayed.
Check the export device before you proceed.
4
Operation
1. Use v/V button to select the [Export] icon then press ENTER.
2. Select the desired source device.
3. Select the [Search] icon then press ENTER.
The exported file list menu appears.
4. Select the exported file on the exported file list then press bB
(Play) button or click [Play] to start playback.
The picture is displayed on the main monitor.
5. Press STOP (x) to stop playback and return to the exported file
list menu.
Operation
47
Functions Available During Playback
Button
System Control
Bar
Remote Control
Function
Front panel
Stop playback.
Pause playback.
Jump to the beginning of the current data that was recorded on the same
date. (press the button for more than 2 seconds.)
4
Press repeatedly to select the required scan speed. (M, MB, MM ,
MBM or m, bm, mm, bmm)
Press repeatedly to play frame-by-frame in pause mode.
Press to play reverse or normal playback.
+
Press MARK at a desired point to be marked during playback. Up to 15
points can be marked.
NOTE
•
You can play the backup or export data in normal speed only.
•
If you use the reverse frame skip function, a frame may be skipped.
•
Multi channel play works only in the date/time search function.
•
If you double-click the channel during the multiple channel playback, the selected channel will be played on the full screen. And if you
double-click the channel during playing full screen mode, it will return to the previous playback condition.
Operation
Jump to the last 1 minute of the current data that was recorded on the
same date. (press the button for more than 2 seconds.)
48
LG Network Client Program
5
LG Network Client Program
Introduction
Getting Started
The LG Network Client program is an IP-Surveillance software that
works with the LG DVR to provide video monitoring, recording
setting and event management functions. The software has multiple
search functions for recorded events. Remote viewing and playback
are also possible with the use of the LG Network Client.
This manual contains instructions on how to use and manage
the LG Network Client in your networking environment. Some
knowledge of networking environments would be beneficial to the
reader.
Should you require any technical assistance, please contact
authorized service center.
5
LG Network Client Program
Recommended PC Requirements
The LG Network Client program must be installed below operating
systems for best performance and stability.
Items
Requirements
Operating System
Windows XP Professional Service Pack 2 or
above
CPU
Web Browser
Memory
Graphics Card
Resolution
Network
Intel Pentium IV or above
Microsoft Internet Explorer 6.0 or above
Install the LG Network Client on your PC
You can install the LG Network Client software following steps.
1. Insert the Client Program CD which will be started automatically.
If the disc does not run automatically on your PC, open the
Client Program CD and install the program manually.
2. Run the install file and install the programs to your computer
following the on-screen instructions. The [LG Emergency Agent]
and [LG Export viewer] programs will be installed with the LG
Network Client program installation.
3. After finishing installation, you will find the programs in the Start
menu or on the desktop.
Starting the LG Network Client
1. Run the LG Network Client program. To launch LG Network
Client, select LG Network Client from your Start > Programs >
LG Electronics > LG Network Client > LG Network Client or
click the LG Network Client icon on your desktop.
The client password input window is displayed.
512 MB or above RAM
2. Enter the password. (Note that the default client password are
“000000”.)
128 MB or above Video RAM (Use latest
graphics card driver.)
3. Click the [OK] button and then the LG Network Client window is
displayed.
1024 x768 (with 32bit color) or above
100 Megabit Network (Gigabit Network
recommended for larger systems)
Before install the program
•
The description pictures may differ from your OS (Operating
System) or Web Browser type.
•
The pictures used in this manual are based on Windows XP
Professional.
•
Do not use other applications with this program. This can cause
memory shortage and program malfunction.
•
Check that the LG DVR is(are) connected to the network and
that power is supplied.
NOTE
If you mark up the [Auto Connection] option, the LG Network
Client program is connected automatically at the next time.
LG Network Client Program
LG Network Client Overview
Selected Menu Tab
Menu Bar
File
End Backup
Search
49
Use to stop and exit the backup
search function.
Software Update Use to upgrade DVR software or add/
upgrade PTZ protocols.
Live window
Tool Bar
1. Log-in the Network Client
program as the permitted
user who has the Group Setup
authority.
2. Click this option. The Update
setting window is displayed.
3. Select the update device from
the list.
•
Select All: If you click this
button, the all devices in the
list are selected .
•
Clear All: If you click this
button, the all selected
devices in the list are
deselected .
4. Find and open the update file.
5. Click the [Update] button to
begin the update process.
The DVR will be restarted after
updating.
Playback control Window
Information Display Window
Menu Bar
Menu
Sub-Menu
Description
File
Client Password
You can change the password of the
Network Client program.
1. Select this option. The Client
Password Setup window is
displayed.
2. Enter the password.
3. Click [OK] to confirm your
settings.
Save to JPEG
Exit the program.
OSD
•
Channel Number: Displays or
removes the channel number in
the channel window.
•
Site Name: Displays or removes
the site name in the channel
window.
•
Camera Name: Displays or
removes the camera name in the
channel window.
•
Playback Time: Displays or
removes the date/time of
playback data in the channel
window.
•
PTZ: Displays PTZ camera icon in
the channel window.
•
Audio: Displays audio icon in the
channel window.
•
Select All: Displays all OSD
options in the channel window.
You can capture and save the current
image in JPEG file format.
1. Play the recorded data.
2. Pause the playback at a desired
point during playback.
3. Select this option. The JPEG
Export window is displayed.
4. Set the options.
5. Click the [Save] button.
Backup Search
View
Exit
Search and playback a backup data.
1. Select the Search Mode icon.
2. Select this option. The Backup
Search window is displayed.
Sequence (Dwell Select the sequence to 5 seconds, 10
Time)
seconds, 15 seconds or 20 seconds.
Sequence Mode •
3. Click the [Add] button.
4. Enter the Name.
5. Find and open the backup file.
6. Click the [OK] button.
7. Use the time line and playback
control buttons to play the
backup data.
•
Channel Sequence: Each channel
of the selected site in the
sequence mode will be displayed
in sequence.
Site Sequence: Each channel of
the logged site in the sequence
mode will be displayed in
sequence
5
LG Network Client Program
6. Click the [Exit] button.
50
LG Network Client Program
View
Tools
Help
Language
Select the language for LG Network
Client program.
Resolution
Select the resolution of the LG
Network Client program.
Connection
Information
Displays the Connection List
windows. Add, Edit or Delete the site
name or group name in LG Network
Client.
E-Map
Displays the E-Map pop-up windows.
This function gives a visual overview
of the cameras in your surveillance
environment using the imported
maps.
Client
Information
Displays Network Client Version
Information.
When the icon is clicked, the screen
will be changed to split mode and if
the icon is clicked again, the screen will
be changed by sequence (except 36
split mode). Choose the screen division
mode.
Division
Sequence
View all the channels in sequence. You
cannot use sequence mode with the 36
split.
Information Display Window
Displays current date and time, user information and the remaining
HDD status of the selected site name.
Tool Bar
Icon
Description
Displays the live view workspace.
•
Camera View: You can see the
surveillance camera’s images in
the window(s) and the camera
information.
•
Pan/Tilt/Zoom: You can control the
PTZ camera.
•
Log View: You can see the system
log list.
•
Favorites: You can save the current
configuration of the camera view.
And, it is possible to return to a
previous configuration of the camera
view.
5
LG Network Client Program
Live
Search
Displays the search workspace. You can
search and play the recorded data using
the search functions.
You can set the configuration of the
selected site via the network.
Setup
Displays the Export pop-up windows.
Export
Print
Full Screen
When you click the PAUSE button to
pause the playing the recorded data
of the selected channel, the Print Icon
is activated. You can print the paused
picture of the recorded data of the
selected channel.
You can view the live window in full
screen mode. To return to the normal
screen, click the right mouse button.
Playback control Window
You can playback the recorded data of the selected channel.
LG Network Client Program
Operation and settings
The DVR is
connected to the
network through the
Broadband Router
Register the Site Name or Group Name
The first time LG Network Client is started, you should register a site
name to control it by the LG Network Client program. The computer
running LG Network Client program must be on the same network
with DVR.
1. Select [Tools] > [Connection Information] option on the menu
bar. The Connection List window is displayed.
2. After completing the settings, click the [OK] button to confirm
the settings and exit the window. The registered site or group
name is(are) displayed on the [Camera View] tab window.
Create a new group name
1. Click the [Add Group] button. The Add Group window is
displayed.
2. Enter the group name.
3. Click the [OK] button to confirm it.
The registered group name is displayed on the Connection List.
Edit a group name
1. Select the required group name on the Connection List.
3. Overwrite the existing group name with a new name that you
want.
4. Click the [OK] button to confirm it.
You must set the port forwarding
according to the settings of the
broadband router. Refer to the manual
of Broadband router for more detailed
settings. If you use the multi DVR with
Broadband router, you must set the TCP/
IP port number for each DVR.
5. Enter the TCP/IP port number of the DVR. If it isn’t entered, the
port number is set by default.
6. Enter the User ID and Password. If you set the User ID and
Password, you can use the Auto connection function.
7. Click the [OK] button. The registered site name is displayed on
the Connection List.
Edit the Site Name
1. Select the required site name on the Connection List.
2. Click the [Edit] button. The Connection Setup window is
displayed.
3. Specify the Group Name, IP Address, Port, User ID, Password and
click the [OK] button to confirm the settings. You cannot edit
the site name option.
Delete the Site Name
1. Select the required site name on the Connection List.
2. Click the [Delete] button. The selected site name is deleted.
Connect to the DVR
1. Select the registered site name to connect it.
Delete a group folder
1. Select the required group name on the Connection List.
2. Click the [Delete] button. The selected group name is deleted.
Deleting a group name will delete all site names within the
group name as well.
2. Click the right mouse button on the site name. Select the
[Connect] option. The site name is connected automatically and
the site name is activated. If the site name has no information
of the User ID and/or Password, the remote login window is
displayed. In that case, enter the User ID and the password.
About the pop-up menu
Add the Site Name
•
User Log-In: Select to connect the DVR manually.
1. Click the [Add] button. The Connection Setup window is
displayed.
•
User Log-Out: Select to disconnect the site name.
•
Connect: Select to connect to the DVR automatically.
You should set the User ID and Password option of the
connection information setting menu for using this
function.
•
Disconnect: Select to disconnect to the site name.
2. Select the group name from the drop-down list.
3. Enter the description of the site name.
4. Enter the IP Address or the Host Name that you entered in the
DDNS setup menu of the DVR.
In case of entering the server name instead of the IP Address.
You should set up the DDNS configuration properly in the
server. Please refer to the server manual to set up the DDNS
function.
Case
How to find the IP Address
Using the Static IP
Address
Check the IP Address in the TCP/IP option
of the DVR setup menu.
Using the Dynamic
IP Address
You have to activate the DHCP function.
1. Press INFO to display the System
Information window.
2. Check the “Network IP” options value.
Using the DDNS
function
Check the registered Host Name of the
DDNS setup menu.
3. Repeat step 1 to 2 to connect the other site name.
NOTE
Up to 5 users can connect to the DVR system using the LG
Network Client program.
Connect the group device
1. Select the registered group name to connect it.
2. Click the right mouse button on the group name. Select the
[Connect] option. Each site name is connected automatically
and the site name is activated in the group name.
3. Repeat step 1 to 2 to connect the other group name.
5
LG Network Client Program
2. Click the [Edit] button. The Edit Group window is displayed.
51
52
LG Network Client Program
Disconnect the site name or group name
NOTE
1. Select the required site name or group name.
2. Click the right mouse button on the site name or group name.
Select the [Disconnect] option. The site name is disconnected
and deactivated.
•
Configuration of camera view is set the first time only. This
configuration setup is memorized for the next time and
displayed as it is.
3. Repeat step 1 to 2 for disconnection.
•
About the camera view menu tree.
Using the Live function
Camera View Tab
Displays the registered site name or
group name.
Displays the camera information .
Displays the camera
channel name.
Displays the
Resolution.
Displays the Recording
Frame Rate.
Displays the Quality.
Displays the Recording
mode.
Displays the relay
output condition.
Displays the Audio
information.
5
LG Network Client Program
Displays the Sensor In information.
1. Select the [Camera View] tab in the live mode.
2. Select the activated site name and double click the left mouse
button or click the plus mark of the registered site name.
Displays the ON/
OFF condition of the
connected sensor.
4. Select the channel number you want to view.
Displays the relay
output condition for
the selected sensor
input.
5. Click the channel number and drag and drop to live window
position. If you select [Cameras] and drag and drop to a live
window then all channels are displayed.
Displays the camera
condition for the
selected sensor input.
3. Select [Cameras] and double click the left mouse button or click
the plus mark.
6. Live image is displayed in the selected window.
7. Repeat steps 3 to 5 to set the other live windows.
Displays the Relay output information.
You can control the
relay output using the
mouse button.
1. Click the right
mouse button on
the relay output.
2. Select the ON or
OFF option.
3. The selected relay
is activated or
deactivated.
LG Network Client Program
Instant playback
Pan/Tilt/Zoom Tab
It is possible to play a recorded image without stopping recording.
You can control the PTZ cameras via the network.
1. Select the [Camera View] tab in the live mode.
1. Select the PTZ camera channel window in the camera view
mode.
2. Select a channel you want to playback.
3. Select the date.
The day is displayed in a blue text when recorded data exists.
4. Select playback start time.
When using timeline to search a start time, use the zoom in/out
icons for more detailed searches (4 step).
5. Select playback speed. Use the slider to select the playback
speed.
6. Start playback using these control buttons.
Click this button to jump to the beginning of the
data.
Click this button repeatedly to play frame-byframe playback in reverse.
53
2. Select the Pan/Tilt/Zoom tab.
3. Use virtual remote control buttons to control the PTZ camera.
NOTE
•
If someone is controlling a PTZ camera using the DVR, you
cannot use the PTZ function and vice versa.
•
This function is permitted for Administrator group and other
group users who have the PTZ authority.
Button
Click this button to play reverse or normal
playback.
Function
Use to pan/tilt the camera.
Click this button to pause playback.
Confirm the preset position.
Click this button repeatedly to play frame-byframe playback.
Select the Pan/Tilt/Zoom
speed.
Click this button to jump to the last 1 minute of
the data.
To adjust the camera zoom.
Click this button to switch the speaker on and off
for the computer. The speaker button is activated
when the playback speed option is set to “1” and
the live window is set to 1 division mode.
To manually adjust the focus of
a camera.
To manually adjust the iris of a
camera.
The microphone icon is not activated in playback
mode.
Displays the Selected Preset
number.
To input the preset number.
NOTE
•
If you don’t want to play with sound, click the speaker icon to
mute.
To register preset positions.
•
If you want to play with sound, the live window have to be set
to 1 division mode.
To move the camera to the
preset position.
•
This function is permitted for Administrator group and other
group users who have the Search/Play authority.
To delete a memorized preset
position.
To start a preset tour.
Two-way audio controls
Two-way audio function is for transmitting and receiving audio
streams simultaneously in both directions.
You can transmit audio to the camera by connecting an
microphone of the computer. You can also play received audio from
the camera via a connected speaker on the computer.
These buttons are activated only when the live window is set to 1
division mode.
ON
OFF
ON
OFF
Click this button to switch the speaker on and off for
the computer.
Click this button to switch the microphone off and on
for the computer.
To display the setup menu of
the PTZ camera.
Preset Settings
Preset position is the function to register camera monitoring
positions (preset positions) associated with position numbers.
By entering the position numbers, you can move cameras to the
preset positions.
NOTE
To activate this function, you need to register the preset positions
of the PTZ cameras.
5
LG Network Client Program
Click this button to stop playback.
54
LG Network Client Program
To Register Preset Positions
Log View Tab
1. Move the camera to a point you wish.
You can see the system log list of selected site name.
2. Click the [SET] icon.
1. Select the [Log View] tab.
3. Select the preset number you wish to register.
2. Click the
icon and select the day.
(The selectable days are displayed in blue color.)
4. Click the
icon.
The position and its number are memorized.
5. Repeat steps 1 to 4 to add additional positions.
3. Click the
icon.
The system log is displayed in the list.
NOTE
Preset numbers from 0 to 255 are available on this unit but the
actual preset range differs depending on PTZ cameras.
Changing to a Picture in a Preset Position
The following function is available only with cameras provided with
the preset function. The preset function makes the combination
camera move to the programmed preset position. It is necessary to
program preset positions for the combination camera beforehand.
1. Click the [MOVE] icon.
5
2. Use number buttons to enter the memorized preset position’s
index number then click the
icon. The camera moves to the
preset position and the picture of the camera in that position
appears on the monitor.
LG Network Client Program
To Clear the Preset Position
You can clear a memorized preset position.
1. Click the [CLEAR] icon.
Favorites Tab
You can save the current configuration of camera view.
This favorite setup is useful for the next time to display it.
2. Use number buttons to enter the memorized preset index
number then click the
icon to clear the preset positions.
NOTE
This function may not be available depending on PTZ cameras.
To Tour The Preset Positions
You can tour all preset positions.
1. Click the [TOUR] icon.
All registered preset positions in the camera will be selected
and the camera position image will be switched on the active
monitor.
2. You can stop the tour by clicking the [TOUR] icon.
Setup for PTZ Cameras
You can adapt the camera to your requirements by setting up the
respective items in menus.
1. Click the [SETUP] icon.
The setup menu appears in the selected window.
2. Use arrow and
buttons to set the options.
NOTE
•
Refer to the manuals of the PTZ camera for more details.
•
Some PTZ cameras may not be operated correctly with this
program.
Add the favorite
1. Select the [Favorites] tab.
2. Select the [Favorites] option and click the right mouse button.
3. Select the [Add favorite] option. The Add Favorite window is
displayed.
4. Enter the favorite name and click the [OK] button.
The entered favorite name is displayed under the Favorites
option.
Edit the favorite
1. Select the registered favorite name and click the right mouse
button.
2. Select the [Edit Favorite] option. The Edit Favorite window is
displayed.
3. Overwrite the existing name with a new name.
4. Click the [OK] button to confirm it.
LG Network Client Program
55
Event Search Tab
Delete the favorite
1. Select the registered favorite name and click the right mouse
button.
Search a recorded picture by date and event type.
2. Select the [Delete Favorite] option. The selected favorite name is
deleted.
Using the Search function
Date/Time Search Tab
Use to search a recorded picture by specifying date, hour and
minute.
1. Select the [Event Search] tab.
2. Click the
icon and select the day.
(The selectable days are displayed in blue color.)
3. Select the camera channel for event search.
4. Select the start time.
5. Select the event type.
7. Select the event from the event list.
Time input column
8. You can play the searched data using the playback control
buttons.
Time line
Playback control buttons
Displays selected channel number.
Bookmark Search
Search the desired picture with a registered bookmark using the
bookmark function.
1. Select the [Bookmark Search] tab.
Mark up when you want to view from all
camera channel windows.
2. Click the
icon. All bookmark data is displayed in the list.
3. Select the data in the list.
4. Play the searched data using the playback control buttons.
1. Select the [Date/Time Search] tab.
2. Click the
icon and select the day.
(The selectable days are displayed in blue color.)
3. Select the channel window you want to view.
4. Select the time using the Time line and Time input column to
search recorded data.
5. Play the searched data using the playback control buttons.
5
LG Network Client Program
6. Click the
icon.
The event list is displayed.
56
LG Network Client Program
ATM/POS Search Tab
Search the recorded text information by ATM/POS device.
This function is available with backup data of the internal or external
HDD only.
Date/Time
•
Date Format: Select the date display format.
•
Time Format: Select the time display format.
•
Time Zone: This option setting is not available in the client
program.
•
Daylight Saving: Mark up when you use the daylight saving
function.
•
Start Time: Select the Daylight Saving start time.
•
End Time: Select the Daylight Saving end time.
Properties
•
DVR Name: Enter the DVR name using up to 20 characters.
•
Language: Select a language for the setup menu and
information display of the DVR.
•
Button Beep: Marks up to activate the button beep. The button
beep is activated when using the buttons.
NTP
1. Select the [ATM/POS Search] tab.
2. Click the
icon and select the day.
(The selectable days are displayed in blue color.)
5
3. Select the camera channel for event search.
4. Select the start time.
LG Network Client Program
5. Set the detail search options.
•
NTP: Marks up, if you want to synchronize the DVR’s date and
time with those of the time server called NTP (Network Time
Protocol) Specify the NTP server’s name.
•
Time Server: For most cases select public. The DVR will obtain
the average time among 5 public servers (time.nist.gov, time-a.
nist.gov, time-b.nist.gov, ntp.nasa.gov, clock.isc.org).
•
Private Time Server: Enter the private time server’s IP address or
host name.
•
Sync. Interval: You can set synchronized intervals with the NTP
time server to 1 day, 1 hour, 1 month and 1 week.
•
Item: Enter the text to search what you want.
•
COMP: Select the compare symbol for number search.
•
CON: Select the Boolean operator when you use the Text
search and Number search function simultaneously.
•
Value: Enter the number to search what you want.
•
Col: Enter the column.
•
Row: Enter the row.
DDNS
These option settings are not available in the client program.
•
Reset: Reset all items.
Network Streaming
6. Click the
icon.
7. Play the searched data using the playback control buttons.
Using the Remote Setup function
You can set the DVR configuration of a selected site name using this
function.
System settings
Network
These option settings are not available in the client program except
the [Bandwith Throttle] option.
•
Bandwidth Throttle: Enter the Bandwidth to adjust the data
traffic.
1. Click the [Setup] button to display the Network Streaming
configuration window.
•
Ch: Displays the channel number.
•
Resolution: Selects the recording resolution. Each group
such as “Ch1 to Ch8” and “Ch9 to Ch16” are set the same
resolution.
•
Quality: Selects the recording picture quality.
•
Frame Rate: Selects the frame rate. The frame rate is the
number of transportable frames per second. According to
resolution, the frame rate is set automatically. If you wish to
set manually, refer to the below.
Resolution
NTSC
PAL
Frame Rate
352*240
1, 3, 5, 7.5, 10, 15
704*240
1, 3, 5, 7.5
704*480
1, 3
352*288
1, 3, 5, 6, 7.5, 12.5
704*288
1, 3, 5, 6
704*576
1, 3
2. Click the [OK] button to confirm the settings.
LG Network Client Program
Device settings
•
Full Warning: When the HDD has overflowed a warning message
is displayed.
•
Auto Delete: Set the auto delete date. If you set the auto delete
date, the recorded data will be deleted except the data within
the selected date period of time. The Auto Delete function is
activated every 35 minutes.
•
Event Partition: This option setting is not available in the client
program.
57
Display settings
Camera
•
Channel: Select the channel number.
•
Channel Name: Enter the channel name using up to 20
characters.
•
Audio: Select the input audio channel. You can hear from the
selected input audio channel. This function is not available for IP
channels.
5
IP Camera
Channel: Selects the desired channel to set the connected IP
camera.
•
•
Vendor: Selects the IP camera vendor from the drop-down list.
Channel Composition
•
Model Name: Enter the model name of the IP camera.
•
•
Host Name: Enter the IP address of the IP camera.
PTZ
•
User Name: Enter the user ID.
•
Password: Enter the user password.
Settings for the PTZ cameras connected via the data port of the
RS-485 terminal.
•
Port: Enter the port number.
•
Port: Selects the connected data port of the RS-485 terminal
on the rear panel. The DATA 2 port is used to control the PTZ
camera connected to DVR or to control by using the LKD1000
controller. If you want to use the PTZ camera via DATA 2 port,
you should set the [Remote Controller ID] to [NONE]. If you use
the LKD1000 controller to control the DVR via DATA 2 port, you
should set the [Remote Controller ID] number between 1 to 16.
ATM/POS Setting
Channel: Selects the desired channel to adjust.
Name: Selects the desired channel.
•
Interface Device: Select the interface device from the dropdown list.
•
Camera: Select the camera number for mapping with ATM/POS
device.
•
Baud Rate: Select the desired parameter to set the
communication speed between DVR and ATM/POS device.
•
Control ID: Selects the PTZ camera ID. Make the same settings
as the PTZ camera.
•
Data Bits: Select the number of the data bits for RS-485
communication.
•
Protocol: Selects the protocol supported by PTZ camera.
•
Stop Bits: Select the desired parameter. The stop bit, added to
the last of data, in asynchronous communication.
•
Baud Rate: Selects the communication speed.
•
Parity: Select the desired parameter. The parity bit, added to the
data, to perform parity check.
Video Adjustment
Adjust the brightness, contrast and color settings of each camera
channel. You can see the settings screen from the preview windows.
Storage
•
Overwrite:
--
All: Overwrite recording is possible when the normal
partition and event partition of HDD have fully recorded.
--
Normal Partition: Overwrite recording is possible for normal
partition of HDD when the normal partition of HDD has fully
recorded.
--
Event Partition: Overwrite recording is possible for event
partition of HDD when the event partition of HDD has fully
recorded.
--
Off: Do not use overwriting.
•
Brightness: Adjust the brightness value from 0 to 100 for the
selected channel.
•
Contrast: Adjust the contrast value from 0 to 100 for the selected
channel.c
•
Color: Adjust the color value from 0 to 100 for the selected
channel.
LG Network Client Program
•
58
LG Network Client Program
Motion Settings
when the sensor alarm is occurs within a designated time.
•
Sensitivity: Set the sensitivity level for the created motion
detection area.
•
M (Motion event recording): Recording starts automatically
when motion is detected within a designated time.
•
Relay Output: Select the number of the RELAY-OUT terminal for
the output alarm (relay) signal when motion is detected.
•
T (Text event recording): Recording starts automatically
when text input is detected within a designated time.
•
Area: The factory default of the Motion detection area is set as
the whole area. You can change the area by using mouse on the
preview window screen.
•
S+M (Sensor+Motion recording): Recording starts
automatically when the sensor alarm signal has input or
motion has been detected.
--
Select area: Click one point with the left mouse button and
drag & drop to the end point.
•
--
Clear area : Click the start point with the right mouse button
and drag & drop to the end point.
C+S (Continuous+Sensor event recording): Recording starts
automatically from the preset time. When the sensor alarm
occurs within a designated time, change the continuous
recording mode to sensor event recording mode and
recording starts automatically.
•
C+M (Continuous+Motion event recording): Recording
starts automatically from the preset time. When the
motion is detected within a designated time, change the
continuous recording mode to motion event recording
mode and recording starts automatically.
•
C+T (Continuous+Text event recording): Recording starts
automatically from the preset time. When the text input
occurs within a designated time, change the continuous
recording mode to text event recording mode and
recording starts automatically.
•
C+S+M (Continuous+Sensor+Motion event recording):
Recording starts automatically from the preset time.
When the sensor alarm signal has input or motion has
been detected, change the continuous recording mode
to motion event recording mode and recording starts
automatically.
•
S+M+T (Sensor+Motion+Text event recording): When
the sensor alarm signal has input, motion has been
detected or the text input occurs and then recording starts
automatically.
•
C+S+M+T (Continuous+Sensor+Motion+Text event
recording): Recording starts automatically from the preset
time. When the sensor alarm signal has input, motion has
been detected or the text input occurs within a designated
time, change the continuous recording mode to occurred
event recording mode and recording starts automatically.
NOTE
•
If you want to display the grid, mark up the [Show Grid]
option.
•
If you want to select the entire area, click the [Set All] button
or click the [Clear All] button to cancel the selected area.
Sequence
5
LG Network Client Program
View all the channels in sequence in the selected screen division
mode. You cannot use sequence mode with the 16 split (LE5008/
LE4008 series: 8 split). While the sequence mode condition, if you
change the screen division mode, the sequence function will be
canceled.
•
Main Dwell Time: Selects the channel sequence time for main
monitor.
•
Spot Dwell Time: Selects the channel sequence time for spot
monitor.
OSD
•
Channel Name: Mark up to displays or removes the channel
name in the channel window.
•
Channel Status: Mark up to displays or removes the channel
status in the channel window.
Record settings
3. Select the desired channel to schedule recording.
4. Click the start time cell block and drag & drop to select a time
period cell block.
or
Click the start time cell block of a channel and drag & drop
across the channels to select the time period block for multichannel setting at the same time. The color of the cell blocks
will change.
Schedule day copy settings
1. Select the source day to copy.
2. Click the [Schedule Copy] button to display the schedule copy
setup window.
3. Select the destination day from the day of the week, weekday or
weekend options.
1. Select a day of the week.
2. Mark up the desired recording option.
•
N : No schedule recording.
•
C (Continuous recording): Recording starts automatically
from the preset time.
•
S (Sensor event recording): Recording starts automatically
4. Click the [Copy] button on the Day Copy option to copy the
scheduled data of the day.
LG Network Client Program
Schedule channel copy settings
•
Relay Output: Select the alarm (relay) output number for the
RELAY-OUT terminal for the output alarm (relay) signal.
•
Preset: Select the preset number. When the input is
activated, the camera moves to the selected preset position
and the picture of the camera in that position appears on
the monitor.
1. Select the day.
2. Click the [Schedule Copy] button to display the schedule copy
setup window.
3. Select the source channel.
4. Select the destination channel.
5. Click the [Copy] button on the Channel copy option to copy the
scheduled data of the channel.
3. Click the [OK] button to confirm the settings.
2. Set the detail options.
•
Input Channel: Select the mapping camera channel.
3. Click the [OK] button to confirm the settings.
•
Transaction Start: Enter a Transaction Start string. Refer to the
device manufacturer’s documentation for the text string that
the device first sends when a transaction starts.
•
Transaction End: Enter a Transaction End string. Refer to the
device manufacturer’s documentation for the text string that
the device sends when a transaction ends.
•
Delimiter: Enter the character(s) that the device uses to
indicate the end of a line. Refer to the device manufacturer’s
documentation for Line Delimiter character(s).
•
Ignore String: Enter the any strings of text that you want the DVR
to ignore. Refer to the device manufacturer’s documentation
for text strings that the device sends during transactions, so you
will know which ones you do not want recorded.
To add the Special day
1. Mark up the [Special day] option.
2. Click the [Add] button.
3. Enter the name of the special day.
4. Select the date to set the special day schedule and click the
[Add] button. The special day is added to the list.
5. Mark up the desired recording option.
6. Set the schedule time for each channel(s).
To edit the Special day
1. Select a special day title on the list.
2. Click the [Edit] button.
3. Select the date to change the special day schedule and click the
[Edit] button.
•
Time Out: Select the Recording end time.
•
Relay Output:
4. Change the schedule time for each channel(s).
--
01 to 04: Outputs the alarm (relay) signal via the RELAY-OUT
terminal. When the DVR detects text input, it triggers output
signals on all the associated Alarm-Out connectors.
--
Off: Not used.
To delete the Special day
1. Select a special day title on the list.
2. Click the [Delete] button.
Event Settings
NOTE
ATM/POS Recording Information.
Option setting
ATM/POS Recording Action
Recording is started automatically
When the Transaction
when the Transaction start data is
Start and Transaction End detected. When the Transaction
options are set.
end data is detected the recording
is stopped after post-alarm time.
Recording is started automatically
when the transaction data is
When the Transaction
detected. When the transaction
Start and Transaction End data is not detected the recording
option is not set.
is stopped after post-alarm time
and the time you set of the Time
Out option.
Event Popup
•
Sensor
1. Click the [Setup] button.
2. Set the below options.
•
Sensor: Displays the number of the ALARM-IN terminal.
•
Sensor Type: The sensor state can be set to either N.O.
(Normally Open) or N.C. (Normally Closed).
•
Linked Camera: Select the connected camera channel to
the ALARM-IN terminal.
Spot Monitor: Select the event type for the spot monitor display
when the event is activated.
5
LG Network Client Program
1. Click the one of the buttons to display the recording setting
window.
ATM/POS Format
The DVR can be set to react to text input from devices such as
ATMs (Automated Teller Machines) and POS (Point of Sale; i.e., cash
registers). This screen allows you to configure the DVR for your input
device.
Schedule Configuration Settings
59
60
LG Network Client Program
Mail
Emergency
1. Click the [Setup] button.
1. Click the [Setup] button.
2. Set the below options.
2. Set the below options.
•
•
Notification: Marks up to notify the unit operating
information according to notification settings by e-mail.
If notification option is not set, the other options cannot be
set.
--
SMTP Server: Enter the SMTP Server address.
--
SMTP Port: Enter the SMTP Port Number. Typically the
port used for SMTP is 25. However in some cases it is
better to change this port number for added flexibility
or security. You can edit this port between 1 and 65 535.
--
User Name: Enter the user name.
--
Password: Enter the password.
TLS: Marks up when using the TLS (Transport Layer Security)
function.
--
5
LG Network Client Program
The SMTP Server, SMTP Port, user name or password settings are
optional. The DVR can send e-mail directly without the use of an
SMTP server or MTA (message transfer agent). In certain cases all
e-mail should be forwarded to a specific SMTP server. Specify the
server host name or IP address in such a case. For more detail on
SMTP setup, ask your network administrator and/or mail service
provider.
Notification: Marks up to notify the emergency agent about
unit operating information according to your notification
settings.
•
Host Name/Port: Enter the Host Name and port number of
the emergency agent program. The factory default port for
this function is 9002. However in some cases it is better to
change this port number for added flexibility or security.
You can edit this port between 1 025 and 65 535.
You can set up to 9 Host Name and port numbers.
3. Click the [OK] button to confirm the settings.
Output
•
Mail Address (1 to 3): Enter the mail address.
You can input up to 3 e-mail addresses.
NOTE
•
•
Relay Off
--
Alarm Acknowledged: Use the ALM.OFF button to stop
alarm.
--
Post Alarm Time: The alarm is stopped after post-alarm time.
System Alarm Out: Outputs the alarm (relay) signal via the
selected alarm out terminal number below cases. If you do not
use this function, select [None] option.
--
When the HDD has a bad sector.
--
When a video signal from the camera has stopped because
of a cable disconnection or malfunction of a camera.
User Settings
3. Click the [OK] button to confirm the settings.
Notification
Marks up when you want to activate the selected option. If the
selected notification option is activate, notify the user about the
information of selected option by E-mail.
•
Sensor On: Sends an e-mail when a sensor has occurred.
•
Motion Detection: Sends an e-mail when an motion detection
has occurred.
•
Text In: Sends an E-mail when the text input is detected.
•
Admin PW Changed: Sends an e-mail when the administrator
password has changed.
•
Video Loss: Sends an e-mail when a video signal from the
camera has stopped because of a cable disconnection or
malfunction of a camera.
•
Power On/Off: Sends an e-mail when power is on or off.
•
Disk Full: Sends an e-mail when the HDD has fully recorded.
Buzzer
Marks up when you want to activate the selected option.
•
Sensor: Makes a sound when a sensor occurs.
•
Motion : Makes a sound when a motion is detected.
•
Text: Makes a sound when the DVR detects text input .
•
System: Makes a sound when a cooling fan is not activated or
the HDD has bad sector.
Group Authority
You can register a new user group with various access rights.
•
Group ID: Select the group ID to assign authority.
--
Guest: The GUEST group has the limited authority of the
system. Users in this group are available to see the live
image and to set the covert function of the Main or Spot
channel.
--
Administrator: The ADMINISTRATOR group has the unlimited
authority of the system. Users in this group are available to
use all of the functions.
--
[Group 01] to [Group 08]: Users in this group are available to
set the authority of the function manually.
NOTE
The GUEST and ADMINISTRATOR group are set initially for the
authority of all functions. You cannot change the initial settings
and group name (GUEST and ADMINISTRATOR).
LG Network Client Program
•
Group Name: If you select a one of the group number from the
Group ID option, you can register the group name. Enter the
group name.
--
•
Group Setup, Search/Play, Export, PTZ, Power Off, Instant
Record: Set the authority for the selected group. Marks up
the option to activate it.
61
Using the Export function
You can copy the recorded images and audio data from the DVR
unit to the PC. This function is permitted for Administrator and other
group users who have the Export authority.
Main Channel/Spot Channel: Selects the channel to allow the
operation for the group user. The LG logo is displayed on the
covert channel(s).
User
1. Select the [User ID] from the drop-down list.
2. Enter the user name of the selected user ID.
3. Select the user group from the drop-down list.
4. Enter the Password.
5. Select the auto user logout time from the drop-down list.
NOTE
If you set the user ID to [ADMINISTRATOR], you cannot change
the [User Name] and [Group] option but you can change the
password.
Server: Displays the selected server name.
•
Channel: Select a channel(s) to export the data.
•
Audio: Set to On or Off to export the audio data.
•
Start: Set the start date/time to copy.
•
End: Set the end date/time to copy.
•
Save Path: Displays the current exported data save folder. You
can select (or make) the folder on the computer to save the
exported data. The initial save folder is “C:\LG Exported Files”. If
you want to change the storage folder, click the [...] button and
select the new folder.
•
Data Type: You can select the saving file format between “Native
[*.exp]” and “AVI”. The Native file is saved with the extention of
“*.exp” and the AVI file is saved with the extention of “*.avi”. The
saved “*.exp” file can playback using the Export Viewer program
and “*.avi” file can playback using the Windows Media Player or
the other “.avi” file player.
•
Add: Add the export setting schedule to the list.
•
Edit: Edit the selected export setting on the list.
•
Delete: Delete the selected export setting schedule from the list.
•
Export: Click to start export the data of the selected export
setting.
•
Cancel: Click it to cancel data exporting.
•
Exit: Click to exit the window.
How to export the data
1. Set the Channel options. You have to select more than one
channel.
2. Select the audio option.
•
On: Select when the Audio data is exported.
•
Off: Select when the Audio data is not exported.
3. Set the Date/Time options.
4. Select the folder on the computer to save the exported data.
5. Select the data type.
6. Click [Add] button. Listing the configured server, start time, end
time and Status.
7. Select the registered export setting schedule in the list.
8. Click the [Export] button to begin the export.
The export status will be displayed on the Status column.
5
LG Network Client Program
•
62
LG Network Client Program
Add the Map
NOTE
•
•
The exported data file name is made automatically as the
[Server name_Channel number_export start time.exp(or “avi”)]
type.
If you do not assign the export directory, the export directory
will be set to default directory and sub directory will be
created with start date.
•
If you log-out from the network client, the export sequence
will be terminated.
•
If you set the time for data that does not exist, the export
function is not activated.
•
The warning message appears for the conditions listed below.
--
When the start date/time and end date/time are the same.
--
When the start date/time is later than the end date/time.
--
When the channel is not selected.
1. Click the [Add E-Map] button. The Add E-Map window is
displayed.
2. Click the [...] button in the [E-Map path] option.
3. Find and open the map image file. If you want to change the
E-Map name, select the [E-Map Name] option and overwrite the
existing name with a new name.
4. Drag-and-drop camera channel or sensor on the Map.
NOTE
To delete the registered camera or sensor, follow these steps:
4.1 Select the camera or sensor.
4.2 Click right mouse button on the selected camera or sensor.
4.3 Select [Delete] option to delete it.
5. Click the [OK] button to save settings and close the window.
6. Repeat steps 1 to 5 to add the other E-Maps up to 16.
Using the E-Map function
This function gives a visual overview of the cameras in your
surveillance environment.
5
Activate the Map
1. Select the required E-Map from the E-Map List.
2. Drag and drop the E-Map on the required position of the E-Map
View window.
3. Repeat steps 1 to 2 to activate the other E-Maps.
LG Network Client Program
E-Map Overview
Map View Division Mode selection icons
E-Map setup icon
E-Map View window
Edit the Map
1. Select the required E-Map from the E-Map View window.
2. Click the [Edit E-Map] button. The E-Map View window is
displayed.
3. Edit the camera position, E-Map name or delete the camera.
4. Click the [OK] button to save E-Map and exit the window.
Delete the Map
1. Select the required E-Map from the E-Map List.
2. Click the [Delete E-Map] button. The selected E-Map is deleted.
Delete the event
1. Select the event in the event list.
2. Click the [Delete List] button to delete the event.
If you select the [Select All] option, all events are deleted.
Event list
Current event live view window
E-Map List
•
Map View Division Mode selection icons: When the icon is
clicked, the screen will be changed to split mode. Choose the
Map View division mode.
•
E-Map setup icon: Click to set the operation time.
•
E-Map List: Displays the imported E-Maps.
•
E-Map View window: Displays the registered E-Maps.
LG Network Client Program
Additional Programs
Emergency Agent Program
The system sends a message according to the Notification and
Emergency settings in the event setup menu.
Emergency Agent Overview
Display the received message list.
Detailed view of the received message.
63
To activate the Emergency Agent program
1. Run the [LG Emergency Agent] program. The Emergency icon is
displayed in the system tray.
2. Whenever a notification function occurs, a message box is
displayed on the bottom right of the screen.
The message box is displayed for 5 seconds.
3. Check the message.
4. Click the message box within 5 seconds to display the [Received
Messages] window.
or
Right click the mouse on the program icon in the system tray
and select the [Check Message Box] option to display the
[Received Messages] window.
5. You can check all the subjects of received messages.
6. Click the [CLOSE] button to close the [Received Messages]
window.
Port Setting
1. Click the [Setup] button. The option window is displayed.
2. Enter the port number of the emergency agent listening port.
The factory default port is 9002. However in some cases it
is better to change this port number for added flexibility or
security.
3. Click the [OK] button to exit.
5
Message Search
LG Network Client Program
1. Click the [SEARCH] button. The message search window is
displayed.
2. Select the search method.
•
Event Search: Search by selected type of event for the
message.
•
Date Search: Search by selected date.
3. Click the [Search] button.
The search message is displayed on the [Received Messages]
window.
Deletes the selected
message from the list.
Closes the [Received Messages]
window.
Delete the Message from the List
1. Select the message(s) you want to delete.
2. Click the [DELETE] button. The confirmation window is
displayed.
3. Click the [Yes] button to delete the message(s).
Refreshes the received
message on the list.
Displays the search window.
Displays the port change window.
64
LG Network Client Program
Export Viewer Program
Playback control buttons
You can playback from the export data on the PC using this
program. The export viewer program is saved automatically when
you install the client program or export the data.
Jumps to the beginning of the file.
Pauses playback.
Export Viewer Overview
Menu Bar
Starts playback.
Stops playback.
Jumps to the end of the file.
Watermark Setting window
The warning window will appear with watermark option, if the file
which is in playback differs from the file that is originally recorded.
Video Information window
5
LG Network Client Program
Video Information window.
Playback control buttons.
•
File Name: Displays the file name.
•
Video Format: Displays the video type of the data.
•
Date/Time: Displays the recorded date and time of data.
•
Recording Mode: Displays the save mode of the data.
•
Camera Number: Displays the camera channel number of
recorded data.
To play the exported data
1. Run the LG Export Viewer program on the PC or in the Export
Viewer folder of the external USB device.
If you insert the exported data CD or DVD disc, the export
viewer program run automatically.
Watermark setting window.
Progressive bar
2. Select [File] > [Open]. The open window is displayed.
Menu Bar
Menu
File
Sub-Menu
Description
Open
Open the data file.
Print
Prints the current playback image.
Save to JPEG
You can capture and save the current
image in JPEG file format.
5. Click the [STOP] button to stop playback.
1. Play the recorded data.
Progressive bar
2. Pause the playback at a desired
point during playback.
3. Select this option. The JPEG
Export window is displayed.
4. Set the options.
5. Click the [Save] button.
View
Help
3. Select the root directory of the USB device and search&select
the desired file.
An example of playable file format is “Channel name_date_time.
exp”.
Exit
Exit the program.
Language
Select the language for Export Viewer
program.
Video Size
Select the video size of the data file.
About Export
Viewer
Displays Export Viewer information.
4. Click the [Open] button. The selected data is played back
automatically.
You can search the image directly using the progressive bar.
Click and hold the Slider bar and move to the other point you want
and then release it. Or, Click the point on the progressive bar you
want to playback.
LG Network Client Program
Web Viewer Program
65
Live screen display window.
Logging in the Web Viewer
1. Start the web browser. The recommended browser is Internet
Explorer with Windows.
2. In the Address Box, enter “HTTP://” and the IP Address of the
DVR. You can use the Host Name that you entered in the DDNS
setup menu of the DVR.
3. Press the ENTER button on the keyboard and then the Web
viewer and the Remote Login menu will be displayed.
4. Enter the User Name and Password.
5. Click the [OK] button.
Live screen control
•
Left mouse button: Select the channel. If you want to set the 1
split mode, double click the selected channel. To return to the
normal screen double click again.
•
Right mouse button: If you want to exit the full screen mode,
right click the mouse to return to the normal screen.
PTZ View control
1. Click the [PTZ View] icon to change into the PTZ view mode. The
PTZ virtual remote control is displayed.
NOTE
•
If the Web Viewer is not displayed, check the TCP/IP settings of
the DVR.
2. Use virtual remote control buttons to control the PTZ camera.
•
If you connect the DVR for the first time, the Security Warning
window is displayed. You must click [Install] on the Security
Warning window to install the program for use the Web
Viewer. If you click [Don’t Install], the Web Viewer program is
not available.
Playback of Recorded Data
Web Viewer Overview
Click to change into the Live View mode.
Click to change into the PTZ View mode
2. Select the date.
The day is displayed in a blue text when recorded data exists.
3. Select playback start time.
When using timeline to search a start time, use the zoom in/out
icons for more detailed searches (4 step).
4. Select the channel you want to playback. If you check “Select All”
option, you can playback the all channels simultaneously from
all camera channel windows.
5. Select playback speed.
6. Start playback using these control buttons.
Click to display the WebViewer Control
Properties pop-up windows.
Click to display the Remote Export popup windows.
You can view the live window in full
screen mode. To return to the normal
screen, click the right mouse button.
Screen Mode selection icons.
View all the channels in sequence. You
cannot use sequence mode with the 16
split.
You can capture and save the current
image in JPEG file format. The initial save
folder is “C:\LG Exported Files”. If you
want to change the storage folder, set
the [Save Path] option on the WebViewer
Control Properties Window.
1. Select the channel window.
2. Mark up the selected channel name.
3. Search the recorded data and then
play the recorded data.
4. Click this button when you want to
capture the current image.
NOTE
This function is permitted for Administrator and other group users
who have the Search/Play authority.
Using the WebViewer Control Properties window
1. Click the [Setup] button.
WebViewer Control Properties window is displayed.
2. Set the below options.
•
OSD: Mark up to display or remove the selected option in
the channel window.
•
Sequence: Selects the channel sequence time.
•
Video Display: Marks up when using the DirectX function.
•
Snapshot Save Path: Displays the storage folder for the
captured image file. If you want to change the storage
folder, click the [...] button and select the new folder.
3. Click the [OK] button to exit.
5
LG Network Client Program
You can control the live image using the Web Viewer.
1. Select the camera’s display window.
66
Troubleshooting
6
Troubleshooting
Check the following guide for the possible cause of a problem before contacting service.
Symptoms
Resolutions
Check the power cable is connected correctly.
The system power does not
turn on.
Check the input voltage is correct.
If the system power does not turn on even if the power cable is connected correctly, please contact the
service center.
Check the monitor power cable is connected properly.
The system power is turned on
but no video data is displayed
on the monitor.
Make sure the monitor is turned on.
Check the video output cable of the LG DVR is properly connected to the monitor.
Unplug the power cable and plug in again.
6
Troubleshooting
Check the camera video output is connected to the DVR system correctly.
The camera numbers are
displayed on the screen but the
camera images are not
displayed.
Check the power cable on the camera is connected correctly.
Check there is no problem with the video cable connection from the camera to the LG DVR system.
Turn off the DVR system and turn it on again.
Check the recording mode in the record setting menu.
The camera video is shown on
the screen but the system does
not record the video.
Check the HDD detection status in the System Information window.
If the HDD detection status is abnormal, check the HDD formatting and the connection of the HDD.
Check the recordable disk space in the HDD.
Check the overwrite option in the setup menu for overwrite recording.
Check if there is recorded video data at the time that you are trying to search on the table.
If there is no recorded video data, check the recording mode in the record setting menu.
It is impossible to search
through the recorded video.
Check the HDD detection status in the system information window.
If the HDD detection status is abnormal, check the HDD formatting and the connection of the HDD.
Check the user type. The search function is not available for a normal user.
Troubleshooting
Symptoms
67
Resolutions
Check the audio recording option is correctly set for the camera you wish to record audio.
Audio data recorded with
video data is not playing.
Check the speaker and audio (line input) on the rear of system are connected correctly.
Check the connected speaker is working properly.
If the camera connected to the system has a problem, make sure that the camera is not damaged by
trying another camera into a working video output.
The colors of some camera
videos are strange or videos
are displayed abnormally.
Check the video format setting of the unit is the same as the connected camera’s video format.
Depending on your region, the camera’s video format can support either PAL or NTSC. Depending on the
camera’s video format, the video process can differ greatly, therefore it can be difficult to recognize the
video data if the video format setting is different from the camera’s video format.
Check if the video signal output from the camera has a problem. Ensure the camera is not damaged by
trying another camera with a working video output.
Check if the video cable connection between the camera and the DVR is cut, crosswired or shorted.
There is a lot of (screen) noise
accompanying the image.
Check if there is a high voltage wire around the video cable connection between camera and DVR
system. It can cause interference and affect video quality.
Check the video cable connection between the camera and the DVR system is the correct video cable.
When a normal power-supplying cable is used instead of the video cable, screen noise can be generated.
Check the type of sensor in the camera setting is the same as with the connected sensor.
The connected sensor is not
operating.
Check the system is set to use the sensor in the recording schedule window in the recording setting
menu.
Check the system is set to use the PTZ camera in the camera setting menu.
Check the power cable of the PTZ camera is properly connected.
The connected PTZ camera is
not operating.
Check the signal cable of the PTZ camera is properly connected.
Check the selected channel to control the PTZ camera.
Check the user type. The PTZ camera control is not available for a normal user.
Troubleshooting
Check the sensor is properly connected to the ALARM-IN.
6
68
Troubleshooting
Symptoms
Resolutions
E-mail reception failed without SMTP server setting.
•
Make sure the network is correctly set.
•
Make sure the mail address is input correctly.
•
Check the spam mail setting of the inputted mail address.
(If you set the spam mail, some mails are deleted automatically or classified in the spam mail box)
•
Some of SMTP mail services do not support an E-mails from private SMTP servers. In this case use the
public SMTP server.
E-mail reception failed even if the SMTP server was set.
An E-mail sent from this
product was not received.
•
•
•
The remote control does not
work properly.
6
When the [Please check the SMTP information or internet cable] message is displayed.
--
Check the SMTP server address.
--
Check the SMTP port number. (Default setting is 25).
--
Check the network settings.
When the [Please check the authentication information] message is displayed.
--
Check the user name.
--
Check the password.
The mail reception failed without error message.
--
Check the receiver’s mail address.
--
Check your E-mail is not classified as a spam mail on the receiver's mail setting.
Check the batteries in the remote control.
Check the ID setting for the remote control (See the page 29).
NOTE
Troubleshooting
If you observe any of the following symptoms:
•
Some of the front panel LEDs do not light.
•
The DVR does not operate normally.
You can reboot the DVR as follows:
1. Turn off the DVR and turn it on again after a few seconds.
2. When the recorder does not work normally after rebooting, contact the service center.
Appendix
69
7
Appendix
Recommended Devices
Recommended USB Memory list
No.
Maker
Model Name
Capacity
1
LG Electronics
XTICK Mini Slide / Slide
1 G/2 G/4 G
2
IOCELL
CellDisk Swing
1 G/2 G/4 G/8 G
3
Sony
MicroVault
1 G/2 G/4 G
4
HP
S100 / M100 / V210W
1 G/2 G/4 G
5
SANDISK
Cruzer Micro
512 M/1 G
6
TRANSCEND
JF
1 G/2 G
7
IMATION
Flash Drive Nano / Icon
1 G/2 G
8
Samsung Electronics
Classic&Simple
1 G/2 G/4 G/8 G
NOTE
Some USB memory devices other than the ones on the above table may not work properly, even if this DVR reads them.
Recommended External Device list
Device
Capacity
Backup search function for the client
program
Yes
No
USB HDD
Up to 1 TB.
FAT 32
(This file system is compatible with Windows and Linux system.)
E-SATA HDD
Unlimited.
EXT4 (Linux file system)
This file system is not compatible with Windows system.
Recommended CD/DVD Media list
Maker
CD-R
CD-RW
DVD-R
DVD-RW
DVD+R
DVD+RW
Imation
O
O
O
O
O
O
Memorex
O
O
O
O
O
O
MITSUBISHI
O
O
O
O
O
O
PHILIPS
O
O
O
O
O
O
SONY
O
O
O
O
O
O
Verbatim
O
O
O
O
O
O
NOTE
8 cm (1.4 GB) Mini CD/DVD and the Dual Layer type media (DVD) are not supported.
7
Appendix
File system
70
Appendix
Supported function list for device
Device
Instant backup
Schedule backup
Export
Configuration Import/Export
CD/DVD
O
X
O
X
USB memory
O
O
O
O
USB HDD
O
O
O
O
E-SATA HDD
O
O
O
O
NOTE
If you use a USB memory stick or USB HDD for configuration import/export you must disconnect the other external USB devices.
Supported PTZ Camera list
7
Appendix
Protocol Name
Maker
LG_MULTIX
LG
LG_MULTIX EXTENTION
LG
LG_SD168
LG
LG_LS903
LG
LG_ZOOM
LG
LPT_A100L
LG
PELCO_D
PELCO
PELCO_P
PELCO
GANZ_DSCP
CBC
GANZ_P360V1
CBC
GE KALATEL_CYBERDOM
KALATEL
PANASONIC_CS850
PANASONIC
BOSCH_AUTODOME
BOSCH
SAMSUNG_SCC
SAMSUNG
Pan/Tilt
Zoom
Speed control
YES
YES
YES
NO
NO
YES
NO
NO
YES
YES
YES
NO
NO
NO
NO
NO
No
YES
NO
NO
YES
NO
NO
NO
YES
YES
YES
NO
YES
YES
YES
NO
YES
YES
YES
YES
YES
YES
YES
NO
YES
YES
YES
NO
YES
YES
YES
NO
YES
YES
YES
YES
YES
YES
YES
NO
Focus
Iris
Preset
Tour
Setup
YES
YES
YES
YES
YES
YES
YES
NO
NO
YES
YES
YES
YES
YES
YES
NO
NO
NO
NO
YES
YES
YES
NO
NO
YES
NO
NO
NO
NO
NO
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
YES
NO
YES
YES
YES
YES
NO
YES
YES
YES
YES
YES
YES
YES
YES
YES
NO
YES
YES
YES
YES
YES
Appendix
71
Time zones
Timezone
Abbreviation
Timezone
Eniwetok, Kwajalein
EK
-12:00
Midway Island, Samoa
MIS
-11:00
Timezone name
DST
Hawaii
HAW
-10:00
Alaska
ALA
-09:00
-08:00
Pacific Time (US and Canada); Tajuana
PST
-08:00
-07:00
Mountain Time (US and Canada), Chihuahua, La Paz,
Mazatlan, Arizona
MST
-07:00
-06:00
Central Time (US and Canada), Saskatchewan, Guadalajara, Mexico City, Monterrey,
Central America
CST
-06:00
-05:00
Eastern Time (US and Canada), Indiana (East), Bogota, Lima, Quito
EST
-05:00
-04:00
Atlantic Time (Canada), Caracas, La Paz, Santiago
AST
-04:00
Newfoundland
NWF
-03:30
Brasilia, Buenos Aires, Georgetown, Greenland
BBA
-03:00
Mid-Atlantic
MAT
-02:00
Azores, Cape Verde Islands
AZO
-01:00
Greenwich Mean Time: Dublin, Edinburgh, Lisbon, London, Casablanca, Monrovia
GMT
0
+01:00
Amsterdam, Belgrade, Bratislava, Budapest, Ljubljana, Prague, Sarajevo, Skopje, Warsaw,
Zagreb, Brussels, Copenhagen, Madrid, Paris, Berlin, Bern, Rome, Stockholm, Vienna, West
Central Africa
AMS
+01:00
+02:00
Athens, Istanbul, Minsk
AIM
+02:00
+03:00
Bucharest, Cairo, Pretoria, Jerusalem, Harare, Pretoria
BCP
+02:00
+03:00
Helsinki, Riga, Israel, Kyiv, Sofia, Tallinn, Vilnius
HRI
+02:00
+03:00
Baghdad, Kuwait, Riyadh, Nairobi
BKR
+03:00
+04:00
Moscow, St.Petersburg, Volgograd
MSV
+03:00
+04:00
7
Tehran
THE
+03:30
+04:30
Abu Dhabi, Muscat, Baku, Tbilisi, Yerevan
ABT
+04:00
Appendix
Kabul
KAB
+04:30
Ekaterinburg, Islamabad, Karachi, Tashkent
EIK
+05:00
Bombay, Calcutta, Madras, New Delhi, Chennai, Kolkata
BCD
+05:30
Almaty, Dhaka, Colombo, Astana, Sri Jayawardenepura, Novosibirsk
ADC
+06:00
Bangkok, Hanoi, Jakarta, Krasnoyarsk
BHJ
+07:00
Beijing, Changqing, Hong Kong, Uramqi
BHU
+08:00
Perth, Singapore, Taipei, Beijing, Chongqing, Hong Kong SAR, Urumqi, Kuala Lumpur,
Irkutsk, Ulaan Bataar
SST
+08:00
Osaka, Sapporo, Tokyo
OST
+09:00
Seoul, Yakutks
SYA
+09:00
Adlaide, Darwin
ADA
+09:30
Brisbane, Guam, Port Moresby
BGP
+10:00
Canberra, Melbourne, Sydney
CMS
+10:00
Hobart, Vladivostok
HVL
+10:00
Magadan, Solomon Islands, New Caledonia
MSN
+11:00
Auckland, Wellington
AWE
+12:00
Fiji Islands, Kamchatka, Marshall Islands
FKM
+12:00
-02:30
+12:00
72
Appendix
Factory Default Configuration Settings
3rd level
Default Setting
Factory
Default setting
DVR Name
NULL
YES
Language
The option depends on the model.
YES
Button Beep
OFF
YES
Video Format
NTSC or PAL
NO
Configuration Import
-
-
Configuration Export
-
-
Factory Default
-
-
DHCP
ON
YES
IP Address
NULL
YES
Subnet Mask
NULL
YES
Gateway
NULL
YES
Primary DNS
NULL
YES
Secondary DNS
NULL
YES
TCP/IP Port
9001
YES
Web Server Port
80
YES
7
Audio Port
9003
YES
Appendix
Bandwidth Throttle
100 Mbps
YES
Ch
-
-
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
15 (NTSC)/12.5 (PAL)
YES
DDNS Service
OFF
YES
Host Name
NULL
YES
Registered Host
NULL
YES
Update
-
-
1st level
2nd level
System
Properties
Network
Network Streaming
DDNS
Appendix
NTP
Controller
Update
Backup
Device
Camera
Date
(2010.01.01)
NO
Time
Current Time
NO
Date Format
YYYY/MM/DD
YES
Time Format
12 HR
YES
Time Zone
The option depends on the model.
NO
Daylight Saving
OFF
NO
Daylight Saving Start
JAN, 1st, SUN, 00
NO
Daylight Saving End
JAN, 1st, SUN, 00
NO
NTP
OFF
YES
Server
PUBLIC SERVER
YES
Private Time Server
NULL
YES
Sync. Interval
1 Day
YES
NTP test
-
-
IR Remote ID
1
YES
Remote Controller ID
NONE
YES
Device
-
YES
Search
-
-
No
-
-
File Name
NULL
-
Update
-
-
Partition Selection
ALL
YES
7
Schedule
OFF
YES
Device
-
YES
Appendix
Date/Time
73
Schedule Start
SUN, 00, 00
YES
Time Range Date
Current Date
YES
Time Range Start
SUN, 00, 00
YES
Time Range End
SUN, 00, 00
YES
Estimate Size
-
-
Start Backup
-
-
Erase Media
-
-
Ch
-
-
Name
CH 01 to CH 16, IP 01, IP 02
YES
Audio
01 to 04, NONE
YES
74
Appendix
Channel
CH 01
YES
Port
NONE
YES
Control ID
00
YES
Protocol
LG_MULTIX
YES
Baud Rate
9600
YES
PTZ Test
-
-
Channel
IP 01
-
Vendor
NONE
YES
Model Name
NULL
YES
Host Name
NULL
YES
User Name
NULL
YES
Password
NULL
YES
Port
554
YES
Test
-
-
Interface Device
NONE
YES
Camera
CH 01
YES
Baud rate
9600
YES
Data Bits
8
YES
Stop Bits
1
YES
Parity
NONE
YES
7
Overwrite
ALL
YES
Appendix
Full Warning
OFF
YES
Auto Delete
OFF
YES
Event Partition
50%
NO
Format
-
-
Channel Name
ON
YES
Channel Status
ON
YES
Main Dwell Time
2 SEC
YES
Spot Dwell Time
2 SEC
YES
Ch
-
-
Name
CH 01 to CH 16
YES
Channel
CH 01
-
Brightness
50
YES
Contrast
50
YES
Color
50
YES
PTZ
IP Camera
ATM/POS
Storage
Display
OSD
Sequence
Channel Composition
Video Adjustment
Appendix
Schedule
Normal
Sensor
Motion
Text
SUN
S+M
YES
MON
S+M
YES
TUE
S+M
YES
WED
S+M
YES
THU
S+M
YES
FRI
S+M
YES
SAT
S+M
YES
SP
S+M
YES
List
-
-
Add
-
-
Ch Copy
-
-
Day Copy
-
-
Ch
-
-
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
30 (NTSC)/25 (PAL)
YES
Ch
-
-
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
30 (NTSC)/25 (PAL)
YES
Prealarm
OFF
YES
7
Postalarm
10SEC
YES
Ch
-
-
Appendix
Record
75
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
30 (NTSC)/25 (PAL)
YES
Prealarm
OFF
YES
Postalarm
10SEC
YES
Ch
-
-
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
30 (NTSC)/25 (PAL)
YES
Prealarm
OFF
YES
Postalarm
10SEC
YES
76
Appendix
Instant/Panic
IP Camera
Event
Sensor
Motion
7
ATM/POS Data Format
Appendix
Event Popup
Notification
Ch
-
-
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
30 (NTSC)/25 (PAL)
YES
Ch
-
-
Resolution
352X240 (NTSC)/352X288 (PAL)
YES
Quality
STANDARD
YES
Frame Rate
30 (NTSC)/25 (PAL)
YES
In
-
YES
Sensor Type
N.O.
YES
Camera
01 to 16
YES
Relay Output
NONE
YES
Preset
NONE
YES
Channel
CH 01
YES
Sensitivity
05
YES
Relay Output
NONE
YES
Area
All selected
-
Input Channel
CH 01
YES
Transaction Start
NULL
YES
Transaction End
NULL
YES
Delimiter
CARRIAGE RETURN
YES
Ignore String
NULL
YES
Time Out
10 Min
YES
Relay Output
NONE
YES
Spot Monitor
OFF
YES
Sensor On
OFF
YES
Motion Detection
OFF
YES
Text In
OFF
YES
Admin Password Changed
OFF
YES
Video Loss
OFF
YES
Power On/Off
OFF
YES
Disk Full
OFF
YES
Appendix
Emergency
Output
Buzzer
User
Group Authority
User
Notification
OFF
YES
SMTP Server
NULL
YES
SMTP Port
25
YES
User Name
NULL
YES
Password
NULL
YES
TLS
OFF
YES
Mail Address 1
NULL
YES
Mail Address 2
NULL
YES
Mail Address 3
NULL
YES
E-mail Test
-
-
Notification
OFF
YES
Host name
NULL
YES
Port
9002
YES
Relay Off
ALARM ACKNOWLEDGE
YES
System Alarm Out
NONE
YES
Sensor
OFF
YES
Motion
OFF
YES
Text
OFF
YES
System
OFF
YES
Group ID
GUEST
YES
Group Name
GUEST
YES
7
Setup
OFF
YES
Search/Play
OFF
YES
Appendix
Mail
77
Export
OFF
YES
PTZ
OFF
YES
Power OFF
OFF
YES
Instant Record
OFF
YES
Main Channel
All Enable
YES
Spot Channel
All Enable
YES
User ID
ADMINISTRATOR
YES
User Name
ADMINISTRATOR
YES
Group
NULL
YES
Password
“000000”
YES
Auto user logout
OFF
YES
78
Appendix
Recording Time Table (250GB HDD)
Recording Time(Hr)
Resolution
(NTSC/PAL)
Quality
LOWEST
LOW
7
352x240 /
352x288
STANDARD
Appendix
HIGH
HIGHEST
FPS
(NTSC/PAL)
Video(NTSC/PAL)
Video + Audio(NTSC/PAL)
8ch
16ch
8ch
16ch
30/25
1022/800
511/400
838/683
461/368
15/12.5
1188/1142
594/571
947/917
527/509
10/8
1508/1416
754/708
1139/1086
649/615
7.5/6
1573/1588
787/794
1176/1185
673/679
5/5
2095/1658
1047/829
1445/1223
855/704
3/3
2441/2023
1220/1011
1602/1411
967/831
1/1
3182/2677
1591/1338
1891/1700
1186/1040
30/25
765/574
383/287
657/511
354/270
15/12.5
996/779
498/390
820/668
450/360
10/8
1162/963
581/481
930/798
517/436
7.5/6
1220/1098
610/549
967/889
539/491
5/5
1342/1130
671/565
1042/910
587/504
3/3
1408/1160
704/580
1082/929
612/516
1/1
1765/1493
882/746
1280/1131
742/643
30/25
668/497
334/249
584/449
312/236
15/12.5
881/671
441/336
741/587
403/313
10/8
975/805
487/402
806/686
441/370
7.5/6
1033/939
517/470
846/782
465/427
5/5
1178/950
589/475
940/789
523/431
3/3
1331/1114
666/557
1035/899
582/497
1/1
1605/1370
802/685
1194/1059
685/597
30/25
541/411
271/206
485/378
256/197
15/12.5
686/542
343/271
598/486
319/256
10/8
794/671
397/336
678/587
366/313
7.5/6
819/770
409/385
696/661
376/356
5/5
994/787
497/393
819/673
449/363
3/3
1032/802
516/401
845/684
464/369
1/1
1166/990
583/495
933/816
518/447
30/25
511/342
256/171
461/318
242/165
15/12.5
618/471
309/236
545/428
290/224
10/8
692/578
346/289
603/514
322/272
7.5/6
736/681
368/341
636/594
341/317
5/5
859/721
430/360
726/624
393/334
3/3
998/823
499/412
822/700
451/378
1/1
1247/1064
624/532
984/866
550/477
Appendix
LOW
704x240 /
704x288
STANDARD
HIGH
HIGHEST
30/25
563/425
281/212
502/389
265/203
15/12.5
764/602
382/301
657/533
353/283
10/8
899/771
449/385
753/661
410/356
7.5/6
949/888
474/444
788/746
431/405
5/5
1175/925
587/463
938/772
522/421
3/3
1235/980
617/490
976/810
545/443
1/1
1553/1337
777/669
1165/1039
666/585
30/25
469/330
235/165
426/308
223/159
15/12.5
625/465
312/233
551/423
293/222
10/8
724/577
362/288
627/513
336/272
7.5/6
774/695
387/348
664/605
357/323
5/5
924/713
462/357
771/619
420/331
3/3
1065/853
533/427
867/721
478/391
1/1
1347/1152
673/576
1045/924
588/513
30/25
369/251
185/125
342/238
178/122
15/12.5
479/343
240/171
435/319
228/165
10/8
544/437
272/218
487/399
257/209
7.5/6
571/514
286/257
509/463
269/244
5/5
666/530
333/265
583/476
311/251
3/3
731/537
365/268
632/481
339/254
1/1
843/697
422/348
714/606
387/324
30/25
293/222
147/111
276/212
142/109
15/12.5
398/312
199/156
366/292
191/151
10/8
457/391
228/196
416/361
218/188
7.5/6
496/472
248/236
448/429
235/225
7
5/5
567/492
283/246
505/445
267/234
3/3
691/569
345/285
602/507
322/268
1/1
828/752
414/376
703/647
380/348
Appendix
LOWEST
79
30/25
254/192
127/96
241/185
124/94
15/12.5
340/266
170/133
317/252
164/129
10/8
386/334
193/167
357/312
186/161
7.5/6
418/398
209/199
384/367
200/191
5/5
489/401
244/201
442/370
232/192
3/3
507/406
254/203
458/374
241/195
1/1
630/545
315/273
555/488
295/258
80
Appendix
LOWEST
LOW
704x480 /
704x576
7
STANDARD
HIGH
Appendix
HIGHEST
30/25
302/236
151/118
284/224
146/115
15/12.5
430/337
215/169
394/315
206/163
10/8
470/435
235/217
427/398
224/208
7.5/6
573/516
287/258
511/465
270/245
5/5
712/536
356/268
618/481
331/254
3/3
876/683
438/342
738/596
401/318
1/1
1250/999
625/500
986/823
551/451
30/25
236/169
118/84
225/163
115/83
15/12.5
322/237
161/118
301/225
156/115
10/8
381/307
191/153
352/288
183/149
7.5/6
412/368
206/184
378/341
197/177
5/5
500/372
250/186
451/345
237/179
3/3
516/404
258/202
465/372
245/194
1/1
682/559
341/280
595/499
318/264
30/25
198/138
99/69
190/134
97/68
15/12.5
272/194
136/97
257/186
132/95
10/8
317/253
159/127
297/240
154/123
7.5/6
351/304
176/152
327/286
169/147
5/5
418/317
209/159
383/297
200/153
3/3
503/365
252/183
454/339
239/176
1/1
663/552
332/276
581/494
310/261
30/25
160/113
80/57
155/110
79/56
15/12.5
217/160
108/80
207/154
106/78
10/8
255/207
127/103
242/198
124/101
7.5/6
277/249
138/125
261/237
134/121
5/5
322/265
161/133
301/251
156/129
3/3
339/315
170/158
316/295
164/153
1/1
445/377
223/189
406/349
212/181
30/25
139/104
69/52
135/102
68/51
15/12.5
200/150
100/75
192/145
98/74
10/8
236/196
118/98
224/188
115/96
7.5/6
266/237
133/119
252/226
130/116
5/5
312/242
156/121
292/230
151/118
3/3
318/306
159/153
297/287
154/148
1/1
422/371
211/185
387/343
202/178
NOTE
This recording time table is for reference only.
The recording time can be different depending on your surveillance environment.
Appendix
81
Specifications
LE5008 Series
LE5016 Series
LE4008 Series
LE4016 Series
8
16
Loop Through
8
16
Composite
1
1
VGA
1
1
Spot
1
1
Input
2
4
Output
2
2
Input
8
16
Output
2
4
Model
Input
Video
Output
Audio
Alarm
Pre-Alarm Recording
NTSC
Recording
Frame Rate
(/Second)
PAL
Search
Serial I/F
Network
Security
Up to 240 IPS @ 352x240
Up to 480 IPS @ 352x240
Up to 200 IPS @ 704x576
Up to 400 IPS @ 704x576
Up to 200 IPS @ 352x288
Up to 400 IPS @ 352x288
FF, FB, Frame Advance, Go to First, Go to Last
Search Mode
Date/Time, Calendar, Event (Motion, Alarm), Bookmark, Text
Frame Rate
(/Second)
Internal HDD
Backup
Up to 480 IPS @ 704x480
Playback Function
NTSC
240 IPS (Real time per each channel)
480 IPS (Real time per each channel)
PAL
200 IPS (Real time per each channel)
400 IPS (Real time per each channel)
1, 4, 9, 1+5, 1+7
1, 4, 9, 16, 1+5, 1+7
Division Mode
Storage
Up to 240 IPS @ 704x480
External HDD
Max Capacity
4 TB (Up to 4 HDDs)
Interface Type
E-SATA
Max Capacity
Unlimited
Backup Interface
USB 2.0 (x3), E-SATA, Network
Supportable Devices
Memory Stick, CD-RW, DVD-RW, External HDD
PTZ Control Interface
RS-485 (x2)
Serial Interface
RS-232C (D-SUB9) (x2)
Network Connection
Ethernet 10/100/1000 Mbps (RJ-45)
Network Transmission Speed
Up to 240 IPS
Bandwidth Control
Yes
Password Protection
Yes
Image Authentication
Yes
7
Appendix
Display
Up to 60 seconds
82
Appendix
Power
AC Free 100~240 V, 50/60 Hz
Power Consumption
Maximum 80 W (with 4 HDD)
Dimension (WxDxH)
430 mm x 430 mm x 96 mm
Net Weight (without HDD)
Operation Temp. / Humidity
7
6.85 kg
6.97 kg
0 ºC to 40 ºC / 0 %RH to 80 %RH
Appendix
AB28
