LG BB4330A Owner's manual
OWNER’S MANUAL Network 3D Blu-ray™ Sound Bar Please read this manual carefully before operating your set and retain it for future reference. BB4330A (BB4330A, S43A3-D) Getting Started 3 Safety Information CAUTION CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. WARNING: Do not install this equipment in a confined space such as a book case or similar unit. CAUTION: Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over heating. The openings shall be never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product shall not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instruction has been adhered to. CAUTION : CLASS 1M VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. DO NOT VIEW DIRECTLY WITH OPTICAL INSTRUMENTS Use of controls, adjustments or the performance of procedures other than those specified herein may result in hazardous radiation exposure. CAUTION concerning the Power Cord Most appliances recommend they be placed upon a dedicated circuit; That is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner’s manual to be certain. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized service center. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance. To disconnect power from the mains, pull out the mains cord plug. When installing the product, ensure that the plug is easily accessible. 1 Getting Started RISK OF ELECTRIC SHOCK DO NOT OPEN 4 Getting Started This device is equipped with a portable battery or accumulator. 1 Getting Started Safety way to remove the battery or the battery from the equipment: Remove the old battery or battery pack, follow the steps in reverse order than the assembly. To prevent contamination of the environment and bring on possible threat to human and animal health, the old battery or the battery put it in the appropriate container at designated collection points. Do not dispose of batteries or battery together with other waste. It is recommended that you use local, free reimbursement systems batteries and accumulators. The battery shall not be exposed to excessive heat such as sunshine, fire or the like. CAUTION: The apparatus shall not be exposed to water (dripping or splashing) and no objects filled with liquids, such as vases, shall be placed on the apparatus. Notes on copyrights yy Because AACS (Advanced Access Content System) is approved as content protection system for Blu-ray Disc format, similar to use of CSS (Content Scramble System) for DVD format, certain restrictions are imposed on playback, analog signal output, etc., of AACS protected content. The operation of this product and restrictions on this product may vary depending on your time of purchase as those restrictions may be adopted and/or changed by AACS after the production of this product. yy Furthermore, BD-ROM Mark and BD+ are additionally used as content protection systems for Blu-ray Disc format, which imposes certain restrictions including playback restrictions for BD-ROM Mark and/or BD+ protected content. To obtain additional information on AACS, BD-ROM Mark, BD+, or this product, please contact an authorized Customer Service Center. yy Many BD-ROM/DVD discs are encoded with copy protection. Because of this, you should only connect your player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy-protected discs. yy This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Rovi Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Rovi Corporation. Reverse engineering or disassembly is prohibited. yy Under the U.S. Copyright laws and Copyright laws of other countries, unauthorized recording, use, display, distribution, or revision of television programs, videotapes, BD-ROM discs, DVDs, CDs and other materials may subject you to civil and/ or criminal liability. Getting Started 5 Important Notice for TV colour system The colour system of this player differs according to currently playing discs. Only the multi system colour TV can receive all signals output from the player. yy If you have a PAL colour system TV, you will see just distorted images when using discs or video contents recorded in NTSC. yy The multi system colour TV changes the colour system automatically according to input signals. In case that the colour system is not changed automatically, turn it off and then on to see normal images on screen. yy Even if the disc recorded in NTSC colour system are well displayed on your TV, these may not be recorded correctly on your recorder. >>Caution yy Watching a 3D content for a long period time may cause dizziness or tiredness. yy It is not recommended to watch a movie in 3D mode for infirm, child and pregnant woman. yy If you are experiencing headache, tiredness or dizziness while viewing contents in 3D, it is strongly recommended to stop the playback and rest until you feel normal. 1 Getting Started For example, when the player plays the disc recorded in the NTSC colour system, the image is output as an NTSC signal. 6 Table of Contents Table of Contents 1 Getting Started 2 Safety Information 8Introduction 8 – Playable discs and symbols used in this manual 9 – About the “7” symbol display 9 – Regional code 9 – System Select 10 Remote Control 11 Front panel 12 Rear panel 12 Active woofer 2Connecting 13 15 15 16 17 17 18 19 19 19 20 20 21 21 22 Mounting the main unit on a wall Setting up – Wireless connection Connecting to your TV – What is SIMPLINK? – ARC (Audio Return Channel) function – Resolution setting Antenna connection Connections with external device – PORT. IN connection – OPTICAL IN connection – HDMI IN connection Connecting to your Home Network – Wired network connection – Wired network setup 3 System Setting 24 Initial Setup 25Settings 25 – Adjust the setup settings 26 – [NETWORK] menu 27 – [DISPLAY] menu 28 – [LANGUAGE] menu 29 – [AUDIO] menu 30 – [LOCK] menu 31 – [OTHERS] menu 4Operating 34 34 35 35 35 36 36 36 37 38 39 39 39 40 40 41 41 41 41 42 42 43 43 44 45 45 45 45 46 46 46 46 47 47 47 48 48 49 49 50 50 50 51 Sound Effect 3D Sound Effect Home Menu Display – Using [HOME] menu – Using the Smart Share Playing the Linked Devices – Playing a disc – Playing Blu-ray 3D disc – Playing a file on disc/USB device – Playing a file on a network server Using Home Network Server for PC – Installing Nero MediaHome 4 Essentials – Sharing files and folders – About Nero MediaHome 4 Essentials – System requirements General Playback – Basic operations for video and audio content – Basic operations for photo content – Using the disc menu – Resume playback – Last scene memory On-Screen Display – To control video playback – To control photo view Advanced Playback – Repeat playback – Repeating a specific portion – Playing from selected time – Selecting a subtitle language – Hearing a different audio – Watching from a different angle – Changing the TV Aspect Ratio – Changing subtitle Code Page – Changing the Picture Mode – Viewing content information – Changing content list view – Selecting a subtitle file – Listening to music during slide show – Converting 2D content to 3D Advanced Features – Enjoying BD-Live™ – LG AV Remote – Audio CD recording Table of Contents 51 52 52 52 54 54 54 54 54 54 55 55 56 56 57 57 58 58 – Recording from FM radio or PORTABLE source Playing the iPod – Enjoying iPod on the screen – Enjoying the iPod IN mode Radio Operations – Listening to the radio – Presetting the Radio Stations – Deleting a saved station – Deleting all the saved stations – Improving poor FM reception Using an USB keyboard or mouse Using the Premium Using the LG Smart World – Signing in – Searching online content Using the My Apps Menu Using Bluetooth technology – Listening to music stored on the Bluetooth devices 7 66 – File requirement 67 – AVCHD (Advanced Video Codec High Definition) 68 – About DLNA 68 – Certain system requirements 68 – Compatibility notes 69 Audio Output Specifications 70 Area Code List 71 Language Code List 72 Trademarks and Licenses 74Specifications 76Maintenance 76 – Handling the unit 76 – Notes on discs 77 Important Information relating to Network Services 1 2 3 4 5Troubleshooting 60Troubleshooting 60 – General 61 – Network 62 – Picture 62 – Sound 62 – Customer Support 62 – Open Source Software Notice 6Appendix 63 Controlling a TV with the Supplied Remote Control 63 – Setting up the remote to control your TV 64 Network Software Update 64 – Network update notification 64 – Software update 66 Additional Information Some of the content in this manual may differ from your player depending on the software of the player or your service provider. 5 6 8 Getting Started Introduction 1 Playable discs and symbols used in this manual Getting Started Media/Term Logo Symbol e Description yy Discs such as movies that can be purchased or rented. yy “Blu-ray 3D” discs and “Blu-ray 3D ONLY” discs. yy BD-R/RE discs that are recorded in BDAV format. Blu-ray y u i r DVD-ROM yy BD-R/RE discs that contain Movie, Music or Photo files. yy ISO 9660+JOLIET, UDF and UDF Bridge format yy Discs such as movies that can be purchased or rented. yy Movie mode and finalized only yy Supports the dual layer disc also DVD-R DVD-RW DVD+R DVD+RW (12 cm) DVD-RW (VR) (12 cm) Audio CD (12 cm) CD-R/RW (12 cm) Note – Caution – o Finalized AVCHD format y u i yy DVD±R/RW discs that contain Movie, Music or Photo files. yy ISO 9660+JOLIET, UDF and UDF Bridge format r VR mode and finalized only t Audio CD y u i yy CD-R/RW discs that contain Movie, Music or Photo files. , > Indicates special notes and operating features. yy ISO 9660+JOLIET, UDF and UDF Bridge format Indicates cautions for preventing possible damages from abuse. Getting Started ,,Note yy Depending on the recording software & the finalization, some recorded discs (CD-R/RW, DVD±R/RW, BD-R/RE) may not be playable. yy BD-R/RE, DVD±R/RW and CD-R/RW discs recorded using a personal computer or a DVD or CD Recorder may not play if the disc is damaged or dirty, or if there is dirt or condensation on the player’s lens. yy If you record a disc using a personal computer, even if it is recorded in a compatible format, there are cases in which it may not play because of the settings of the application software used to create the disc. (Check with the software publisher for more detailed information.) yy This player requires discs and recordings to meet certain technical standards in order to achieve optimal playback quality. yy Pre-recorded DVDs are automatically set to these standards. There are many different types of recordable disc formats (including CD-R containing MP3 or WMA files) and these require certain pre-existing conditions to ensure compatible playback. yy Customers should note that permission is required in order to download MP3 / WMA files and music from the Internet. Our company has no right to grant such permission. Permission should always be sought from the copyright owner. yy You have to set the disc format option to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live System, you cannot use it on LG player. (Mastered/Live File System : Disc format system for windows Vista) About the “7” symbol display “7” may appear on your TV display during operation and indicates that the function explained in this owner’s manual is not available on that specific media. Regional code This unit has a regional code printed on the rear of the unit. This unit can play only BD-ROM or DVD discs labeled same as the rear of the unit or “ALL”. System Select Press B (OPEN/CLOSE) when a disc is inserted, and do not remove the disc. Press and hold M (PAUSE) for more than five seconds while [OPEN] is displayed in the display window. 1 Getting Started yy Depending on the conditions of the recording equipment or the CD-R/RW (or DVD±R/RW) disc itself, some CD-R/RW (or DVD±R/RW) discs cannot be played on the unit. 9 10 Getting Started Remote Control 1 • • • • • • a • • • • • • Getting Started 1 (POWER): Switches the player ON or OFF. B (OPEN/CLOSE): Ejects a disc. FUNCTION: Changes input mode. 0-9 numerical buttons: Selects numbered options in a menu. CLEAR: Removes a number when setting the password or network connection. REPEAT (h): Repeats a desired section or sequence. • • • • • • b • • • • • • c/v (SCAN): Searches backward or forward. C/V (SKIP): Goes to the next or previous chapter / track / file. Z (STOP): Stops playback. z (PLAY): Starts playback. M (PAUSE): Pauses playback. SPEAKER LEVEL: Sets the sound level of desired speaker. SOUND EFFECT: Selects a sound effect mode. VOL +/-: Adjusts speaker volume. OPTICAL/TV SOUND: Changes input mode to optical directly. Battery Installation MUTE: Mute the unit. • • • • • • c • • • • • • HOME ( ): Displays or exits the [Home]. 3D SOUND: Selects a 3D sound effect mode. Remove the battery cover on the rear of the Remote Control, and insert two R03 (size AAA) batteries with 4 and 5 matched correctly. INFO/MENU (m): Displays or exits On-Screen Display. Direction buttons: Selects an option in the menu. PRESET +/-: Selects programme of Radio. TUNING +/-: Tunes in the desired radio station. ENTER (b): Acknowledges menu selection. BACK ( ): Exits the menu or returns to the previous screen. TITLE/POPUP: Displays the DVD title menu or BD-ROM’s popup menu, if available. DISC MENU: Accesses menu on a disc. • • • • • • d • • • • • • Coloured (R, G, Y, B) buttons: - Use to navigate BD-ROM menus. They are also used as shortcut buttons for specific menus. - B button: Selects mono/ stereo in FM mode. SUBTITLE: Selects a subtitle language. AUDIO: Selects an audio language or audio channel. SLEEP: Sets a certain period of time after which the unit will switch to off. ? : This button is not available. MIC/ECHO (Optional): Selects the microphone mode or microphone’s echo mode. After selecting the desired mode, press VOL +/- to adjust microphone volume or microphone’s echo volume. X (REC): Records from an Audio CD, FM radio, or PORTABLE source to USB. TV Control Buttons: See page 63. Getting Started 11 Front panel a b 1 Getting Started e c d a Disc Slot b Operation buttons 1/! (Power) -/+ (Volume) DM (Play / Pause) Z (Stop) F (Function) Changes the input source or function. R (Open / Close) c iPod/ iPhone/ iPad/ USB Port d Display Window e MIC (Optional) >>Caution Precautions in using the touch buttons yy Use the touch buttons with clean and dry hands. - In a humid environment, wipe out any moisture on the touch buttons before using. yy Do not press the touch buttons hard to make it work. - If you apply too much strength, it can damage the sensor of the touch buttons. yy Touch the button that you want to work in order to operate the function correctly. yy Be careful not to have any conductive material such as metallic object on the touch buttons. It can cause malfunctions. 12 Getting Started Rear panel 1 Getting Started a b d e f c a LAN Port d Antenna Connector b HDMI OUT TO TV e PORT. IN c HDMI IN f OPTICAL IN Active woofer a b a LED (connection status) Yellow-green: The connection is completed. Yellow-green (blink): The woofer is trying to connect. RED: The connection is in standby mode or failed. c b Speaker duct >>Caution Be careful to make sure children not to put their hands or any objects into the speaker duct. c PAIRING button Connecting Mounting the main unit on a wall You can mount the main unit on a wall. Prepare screws and brackets supplied. 13 2. When you mount it on a wall (concrete), use the wall plugs (Not supplied). You should drill some holes. A guide sheet (WALL BRACKET INSTALL GUIDE) is supplied to drill. Use the sheet to check the point to drill. Preperation 2 WALL BRACKET INSTALL GUIDE 1. Match the TV BOTTOM LINE of WALL BRACKET INSTALL GUIDE with the bottom of TV and attach to the position. TV Connecting Unit Wall bracket ,,Note Screws and Wall Plugs are not supplied for mounting the unit. We recommend the Hilti (HUD-1 6 x 30) for the mounting. Please purchase it. 3. Remove the WALL BRACKET INSTALL GUIDE. 4. Fix it with screws (not supplied) as shown in the illustration below. 14 Connecting 5. Hang the main unit onto the brackets, as shown below. >>Caution yy Do not hang onto the installed unit and avoid any impact to the unit. yy Secure the unit firmly to the wall so that it does not fall off. If the unit falls off, it may result in an injury or damage to the product. 2 yy When the unit is installed on a wall, please make sure that a child does not pull any of connecting cables, as it may cause it to fall. Connecting ,,Note Detach the unit from the bracket as shown below. Connecting Setting up Pairing wireless subwoofer LED indicator of wireless subwoofer Status Yellow-green The wireless subwoofer is receiving the signal of the unit. Yellow-green (blink) The wireless subwoofer is trying to connect. Red The Wireless subwoofer is in standby mode. Off (No display) The power cord of wireless subwoofer is disconnected. Setting up the wireless subwoofer for the first time 1. Connect the power cord of the Wireless subwoofer to the outlet. 2. Turn on the main unit : The main unit and wireless subwoofer will be automatically connected. Manually pairing wireless subwoofer When your connection is not completed, you can see the red LED on the woofer and woofer is not made sound. To solve the problem, follow the below steps. 1. Press and hold Z STOP button on the unit and MUTE button on the remote control simultaneously. - Displays the “REMATE”. 2. Press PAIRING on back of the woofer. - The Yellow-green LED will flicker. 3. Turn off and on the unit. - If you see “Yellow-green” LED, it’ s successful. 4. If you don’t see “Yellow-green” LED, try again Step 1 - Step 3. ,,Note yy If there is a strong electromagnetic wave product nearby, interference may occur. Put the unit (Wireless subwoofer and main unit) away from there. yy If you operate main unit then wireless subwoofer (rear speakers) sound within a few seconds in standby mode. yy Set the distance between this unit and subwoofer Receiver within 10 m (32 ft.). yy Optimum performance can be implemented only when the unit and the Wireless subwoofer within distance of 2 m (6 ft.) to 10 m (32 ft.) is used since communication failure may occur if longer distance is used. yy It takes a few seconds (and may take longer) for the Wireless Transmitter and subwoofer to communicate with each other. 2 Connecting LED Color 15 16 Connecting Connecting to your TV If you have a HDMI TV or monitor, you can connect it to this player using a HDMI cable (Type A, High Speed HDMI™ Cable). Connect the HDMI jack on the player to the HDMI jack on a HDMI compatible TV or monitor. 2 Connecting Rear of the unit Additional information for HDMI yy When you connect a HDMI or DVI compatible device make sure of the following: -- Try switching off the HDMI/DVI device and this player. Next, switch on the HDMI/DVI device and leave it for around 30 seconds, then switch on this player. -- The connected device’s video input is set correctly for this unit. -- The connected device is compatible with 720x576p, 1280x720p, 1920x1080i or 1920x1080p video input. yy Not all HDCP-compatible HDMI or DVI devices will work with this player. -- The picture will not be displayed properly with non-HDCP device. HDMI cable TV Set the TV’s source to HDMI (refer to TV’s owner’s manual). ,,Note Please refer to the manuals of your TV, Stereo System or other devices as necessary to make the best connections. ,,Note yy If a connected HDMI device does not accept the audio output of the player, the HDMI device’s audio sound may be distorted or may not output. yy When you use HDMI connection, you can change the resolution for the HDMI output. (Refer to “Resolution setting” on page 18) yy Select the type of video output from the HDMI OUT jack using [HDMI Color Setting] option on the [Settings] menu (page 28). yy Changing the resolution when the connection has already been established may result in malfunctions. To solve the problem, turn off the player and then turn it on again. yy When the HDMI connection with HDCP is not verified, TV screen is changed to black screen. In this case, check the HDMI connection, or disconnect the HDMI cable. yy If there are noises or lines on the screen, please check the HDMI cable (length is generally limited to 4.5 m (15 ft.)). Connecting What is SIMPLINK? Some functions of this unit are controlled by the TV’s remote control when this unit and LG TV’s with SIMPLINK are connected through HDMI connection. Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power Off, etc. LG TV’s with SIMPLINK function has the logo as shown above. ,,Note Depending on the disc type or playing status, some SIMPLINK operation may differ from your purpose or not work. ARC (Audio Return Channel) function The ARC function enables an HDMI capable TV to send the audio stream to HDMI OUT of this player. To use this function: -- Your TV must support the HDMI-CEC and ARC function and the HDMI-CEC and ARC must be set to On. -- The setting method of HDMI-CEC and ARC may differ depending on the TV. For details about ARC function, refer to your TV manual. -- You must use the HDMI cable (Type A, High Speed HDMI™ cable with Ethernet). -- You must connect with the HDMI IN that supports the ARC function using the HDMI OUT on this player. -- You can connect only one Home Theater to TV compatible with ARC. ,,Note To activate [SIMPLINK / ARC] function, set this option to [On] (page 33). 2 Connecting Refer to the TV owner’s manual for the details of SIMPLINK function. 17 18 Connecting Resolution setting The player provides several output resolutions for HDMI OUT jack. You can change the resolution using [Settings] menu. 1. Press HOME ( ). 2. Use A/D to select the [Settings] and press ENTER (b). The [Settings] menu appears. 2 3. Use W/S to select [DISPLAY] option then press D to move to the second level. Connecting 4. Use W/S to select the [Resolution] option then press ENTER (b) to move to the third level. 5.Use W/S to select the desired resolution then press ENTER (b) to confirm your selection. ,,Note yy If your TV does not accept the resolution you have set on the player, you can set resolution to 576p as follows: 1. Press HOME ( ) to disappear the HOME menu. 2.Press Z (STOP) for more than 5 seconds. yy If you select a resolution manually and then connect the HDMI jack to TV and your TV does not accept it, the resolution setting is set to [Auto]. yy If you select a resolution that your TV does not accept, the warning message will appear. After resolution change, if you cannot see the screen, please wait 20 seconds and the resolution will automatically revert back to the previous resolution. yy The 1080p video output frame rate may be automatically set to either 24 Hz or 50 Hz depending both on the capability and preference of the connected TV and based on the native video frame rate of the content on the BD-ROM disc. Connecting Antenna connection Connect the supplied antenna for listening to the radio. 19 Connections with external device PORT. IN connection Rear of the unit You can enjoy the sound from your portable audio player through the speakers of this system. You can also use the F (Function) button on the front panel to select the input mode. Rear of the unit ,,Note After connecting the FM wire antenna, be sure to fully extend it. MP3 player, etc... 2 Connecting Connect the headphones (or line out ) jack of the portable audio player into the PORT. IN socket of this unit. And then select the [PORTABLE] option by pressing FUNCTION. 20 Connecting OPTICAL IN connection HDMI IN connection You can enjoy the sound from your component with a digital optical connection through the speakers of this system. You can enjoy the pictures and sound from your component through this connection. Connect the optical output jack of your component into the OPTICAL IN jack on the unit. And then select the [OPTICAL] option by pressing FUNCTION. Or press OPTICAL/TV SOUND to select directly. 2 Connect the HDMI OUT jack of your component into the HDMI IN jack on this unit. And then select the [HDMI IN] option by pressing FUNCTION. You can also use the F (Function) button on the front panel to select the input mode. You can also use the F (Function) button on the front panel to select the input mode. Connecting Rear of the unit Rear of the unit To the HDMI OUT jack of your component (set-top box, digital satellite receiver, video game machine, etc.) To the digital optical output jack of your component ,,Note yy You cannot change the video resolution in the HDMI IN mode. Change the video resolution of the connected component. yy If the video output signal is abnormal when your personal computer is connected to HDMI IN jack, change the resolution of your personal computer to 576p, 720p, 1080i or 1080p. yy The player sends audio from the HDMI inputs to both the HDMI output and to the unit’s speakers. Connecting Connecting to your Home Network 21 Broadband service This player can be connected to a local area network (LAN) via the LAN port on the rear panel. By connecting the unit to a broadband home network, you have access to services such as software updates, BD-Live interactivity and online content services. Wired network connection Using a wired network provides the best performance, because the attached devices connect directly to the network and are not subject to radio frequency interference. Please refer to the documentation for your network device for further instructions. DLNA certified servers Connect the player’s LAN port to the corresponding port on your Modem or Router using a commercially available LAN or Ethernet cable. ,,Note yy When plugging or unplugging the LAN cable, hold the plug portion of the cable. When unplugging, do not pull on the LAN cable but unplug while pressing down on the lock. yy Do not connect a modular phone cable to the LAN port. yy Since there are various connection configurations, please follow the specifications of your telecommunication carrier or internet service provider. yy If you want to access content from DLNA servers, this player must be connected to the same local area network with them via a router. yy To set your PC as a DLNA server, install the supplied Nero MediaHome 4 on your PC (page 39). Rear of the unit 2 Connecting Router 22 Connecting 2 Wired network setup Advanced Setting If there is a DHCP server on the local area network (LAN) via wired connection, this player will automatically be allocated an IP address. After making the physical connection, a small number of home networks may require the player’s network setting to be adjusted. Adjust the [NETWORK] setting as follow. If you want to set the network settings manually, use W/S to select [Advanced Setting] on the [Network Setting] menu and press ENTER (b). 1.Use W/S/A/D to select the IP mode between [Dynamic] and [Static]. Normally, select [Dynamic] to allocate an IP address automatically. Preparation Connecting Before setting the wired network, you need to connect the broadband internet to your home network. 1. Select [Connection Setting] option in the [Settings] menu then press ENTER (b). ,,Note If there is no DHCP server on the network and you want to set the IP address manually, select [Static] then set [IP Address], [Subnet Mask], [Gateway] and [DNS Server] using W/S/ A/D and numerical buttons. If you make a mistake while entering a number, press CLEAR to clear the highlighted part. 2. Read the preparations for the network settings and then press ENTER (b) while [Start] is highlighted. Network will automatically be connected to the unit. 2. Select [Next] and press ENTER (b) to apply network settings. Network connection status is displayed on the screen. 3. Press ENTER (b) while [OK] is highlighted to finish the wired network settings. Connecting 23 Notes on network connection yy Many network connection problems during set up can often be fixed by re-setting the router or modem. After connecting the player to the home network, quickly power off and/ or disconnect the power cable of the home network router or cable modem. Then power on and/or connect the power cable again. yy Our company is not responsible for any malfunction of the player and/or the internet connection feature due to communication errors/malfunctions associated with your broadband internet connection, or other connected equipment. yy The features of BD-ROM discs made available through the Internet Connection feature are not created or provided by our company, and our company is not responsible for their functionality or continued availability. Some disc related material available by the Internet Connection may not be compatible with this player. If you have questions about such content, please contact the producer of the disc. yy Some internet content may require a higher bandwidth connection. yy Even if the player is properly connected and configured, some internet content may not operate properly because of internet congestion, the quality or bandwidth of your internet service, or problems at the provider of the content. yy Some internet connection operations may not be possible due to certain restrictions set by the Internet service provider (ISP) supplying your broadband Internet connection. yy Any fees charged by an ISP including, without limitation, connection charges are your responsibility. yy A 10 Base-T or 100 Base-TX LAN port is required for wired connection to this player. If your internet service does not allow for such a connection, you will not be able to connect the player. yy You must use a Router to use xDSL service. 2 Connecting yy Depending on the internet service provider (ISP), the number of devices that can receive internet service may be limited by the applicable terms of service. For details, contact your ISP. yy A DSL modem is required to use DSL service and a cable modem is required to use cable modem service. Depending on the access method of and subscriber agreement with your ISP, you may not be able to use the internet connection feature contained in this player or you may be limited to the number of devices you can connect at the same time. (If your ISP limits subscription to one device, this player may not be allowed to connect when a PC is already connected.) 24 System Setting Initial Setup When you turn on the unit for the first time, the initial setup wizard appears on the screen. Set the display language and network settings on the initial setup wizard. 4. Select [Next] and press ENTER (b). 5. You can listen to TV sound through this unit’s speaker automatically when TV is turned on. TV and this unit should be connected with optical cable. 1.Press 1 (POWER). The initial setup wizard appears on the screen. 2.Use W/S/A/D to select a display language and press ENTER (b). Press W to move and press A/D to select [On] or [Off ]. Select [Next] and press ENTER (b). 3 System Setting 6. Check all the settings that you have set in the previous steps. 3. Read and prepare the preparations for the network settings and then press ENTER (b) while [Start] is highlighted. Press ENTER (b) while [Finish] is highlighted to finish the initial setup settings. If there is any settings to be changed, use W/S/A/D to select 1 and press ENTER (b). If wired network is connected, the network connection setting will automatically be finished. If you have security on your access point, you need to input the security code as necessary. 7. Displays private sound mode guide. Press ENTER (b). System Setting 25 Settings Adjust the setup settings You can change the settings of the player in the [Settings] menu. 1. Press HOME ( ). 3 3.Use W/S to select the first setup option, and press D to move to the second level. 4.Use W/S to select a second setup option, and press ENTER (b) to move to the third level. 5.Use W/S to select a desired setting, and press ENTER (b) to confirm your selection. System Setting 2.Use A/D to select the [Settings] and press ENTER (b). The [Settings] menu appears. 26 System Setting [NETWORK] menu The [NETWORK] settings are needed to use the software update, BD-Live and online content services. [Country Setting] Connection Setting [Initialize] If your home network environment is ready to connect the player, the player needs to be set the wired network connection for network communication. (See “Connecting to your Home Network” on page 21.) Depending on the region, [Initialize] function may not be available. Connection Status 3 Smart Service Setting System Setting If you want to check the network status on this player, select the [Connection Status] options and press ENTER (b) to check whether a connection to the network and the internet have been established. BD-LIVE connection You can restrict Internet access when BD-Live functions are used. [Permitted] Internet access is permitted for all BD-Live content. [Partially permitted] Internet access is permitted only for BD-Live content which have content owner certificates. Internet access and AACS Online functions are prohibited for all BD-Live content without a certificate. [Prohibited] Internet access is prohibited for all BD-Live content. Select your area for displaying proper online content service. Device Name You can make a network name using virtual keyboard. This player will be recognised by the name you are entering on your home network. Network Play This function allows you to control the playback of media streamed from DLNA media server by a DLNA certified smartphone. Most DLNA certified smartphone has a function to control the playback media on your home network. Set this option to [On] for allowing your smartphone to control this unit. Refer to instructions of your DLNA certified smartphone or the application for more detailed information. ,,Note yy This unit and the DLNA Certified Smartphone must be connected to the same network. yy To use the [Network Play] function using a DLNA certified smartphone, press HOME ( ) to display the home menu before connecting to this unit. yy While controlling the unit using the [Network Play] function, the remote control may not work. yy Available file formats described on page 66 are not always supported on [Network Play] function. System Setting 27 [DISPLAY] menu Resolution TV Aspect Ratio Sets the output resolution of the HDMI video signal. Refer to page 18 for details about the resolution setting. Select a TV aspect ratio option according to your TV type. [Auto] Select when a standard 4:3 TV is connected. Displays theatrical images with masking bars above and below the picture. If the HDMI OUT jack is connected to TVs providing display information (EDID), automatically selects the resolution best suited to the connected TV. [4:3 Pan Scan] [1080p] Select when a standard 4:3 TV is connected. Displays pictures cropped to fill your TV screen. Both sides of the picture are cut off. [1080i] [4:3 Letter Box] Select when a 16:9 wide TV is connected. The 4:3 picture is displayed with an original 4:3 aspect ratio, with black bars appearing at the left and right sides. [16:9 Full] Select when a 16:9 wide TV is connected. The 4:3 picture is adjusted horizontally (in a linear proportion) to fill the entire screen. ,,Note You cannot select [4:3 Letter Box] and [4:3 Pan Scan] option when the resolution is set to higher than 720p. Outputs 1080 lines of interlaced video. [720p] Outputs 720 lines of progressive video. [576p] Outputs 576 lines of progressive video. Ultra HD Upscaling This feature allows the unit to up-scale the original video resolution to Ultra HD resolution and output via HDMI connection. [Auto] If you connect a display capable of displaying Ultra HD resolution, this unit will output video signals in Ultra HD resolution automatically. [Off] The unit will turn off the Up-scaling feature. ,,Note yy This unit will output video signals in Ultra HD resolution when it plays BD-ROM disc formatted in 24 Hz. yy The playback pictures may be momentarily interrupted when the resolutions switch. 3 System Setting [16:9 Original] Outputs 1080 lines of progressive video. 28 System Setting 1080p Display Mode When the resolution is set to 1080p, select [24 Hz] for smooth presentation of film material (1080p/24 Hz) with a HDMI-equipped display compatible with 1080p/24 Hz input. ,,Note yy When you select [24 Hz], you may experience some picture disturbance when the video switches video and film material. In this case, select [50 Hz]. 3 yy Even when [1080p Display Mode] is set to [24 Hz], if your TV is not compatible with 1080p/24 Hz, the actual frame frequency of the video output will be 50 Hz to match the video source format. System Setting HDMI Color Setting Select the type of output from the HDMI OUT jack. For this setting, please refer to the manuals of your display device. [YCbCr] Select when connecting to a HDMI display device. [RGB] Select when connecting to a DVI display device. 3D Mode Select the type of output mode for Blu-ray 3D disc playback. [Off] Blu-ray 3D disc playback will output as 2D mode like a normal BD-ROM disc playback. [On] Blu-ray 3D disc playback will output as 3D mode. Home Menu Guide This function allows you to display or delete the guide bubble on the [HOME] menu. Set this option to [On] for displaying guide. [LANGUAGE] menu Display Menu Select a language for the [Settings] menu and onscreen display. Disc Menu / Disc Audio / Disc Subtitle Select the language you prefer for the audio track (disc audio), subtitles, and the disc menu. [Original] Refers to the original language in which the disc was recorded. [Other] Press ENTER (b) to select another language. Use number buttons then press ENTER (b) to enter the corresponding 4-digit number according to the language code list on page 71. [Off] (Disc Subtitle only) Turn off Subtitle. ,,Note Depending on the disc, your language setting may not work. System Setting 29 [AUDIO] menu DRC (Dynamic Range Control) Each disc has a variety of audio output options. Set the player’s Audio options according to the type of audio system you use. This function allows you to listen to a movie at a lower volume without losing clarity of sound. ,,Note Since many factors affect the type of audio output, see “Audio Output Specifications” on page 69 for details. Digital Output [PCM Stereo] (HDMI only) [PCM Multi-Ch] (HDMI only) Select if you connect this unit’s HDMI OUT jack to a device with multi-channel digital decoder. [DTS Re-Encode] (HDMI only) Select if you connect this unit’s HDMI OUT jack to a device with DTS decoder. [BitStream] (HDMI only) Select if you connect this unit’s HDMI OUT jack to a device with LPCM, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS and DTS-HD decoder. ,,Note yy When [Digital Output] option is set to [PCM Multi-Ch], the audio may output as PCM Stereo if the PCM Multi-Ch information is not detected from HDMI device with EDID. yy If the [Digital Output] option is set to [DTS Re-Encode], the DTS Re-Encode audio is outputted for BD-ROM discs with secondary audio and the original audio is outputted for the other discs (like [BitStream]). yy This setting is not available on the input signal from an external device. The dynamic range of the Dolby TrueHD audio output is specified by itself. And the dynamic range of the Dolby Digital and Dolby Digital Plus are operated as same as the [On] mode. [On] Compress the dynamic range of the Dolby Digital, Dolby Digital Plus or Dolby TrueHD audio output. [Off] Turns off this function. ,,Note The DRC setting can be changed only when a disc is not inserted or the unit is in complete stop mode. 3 System Setting Select if you connect this unit’s HDMI OUT jack to a device with two-channel digital stereo decoder. [Auto] 30 System Setting HD AV Sync [LOCK] menu Sometimes Digital TV encounters a delay between picture and sound. If this happens you can compensate by setting a delay on the sound so that it effectively ‘waits’ for the picture to arrive: this is called HD AV Sync. Use A D to scroll up and down through the delay amount, which you can set at anything between 0 and 300 ms. The [LOCK] settings affect only Blu-ray Disc and DVD playback. Auto Volume 3 With Auto Volume function on, the unit automatically adjusts the outputted volume level to make it raised or lowered if the sound is too loud or small. So you can enjoy the sound at comportable level not too loud or small. System Setting Semi Karaoke When a chapter/ title is fully finished, this function shows the score on the screen with a fanfare sound. [On] When you finished singing a score will appear on the screen. To access the any features in [LOCK] settings, you must enter the 4-digit security code you have created. If you have not entered a password yet, you are prompted to do so. Enter a 4-digit password twice, and press ENTER (b) to create a new password. Password You can create or change the password. [None] Enter a 4-digit password twice, and press ENTER (b) to create a new password. [Change] Enter the current password and press ENTER (b). Enter a 4-digit password twice, and press ENTER (b) to create a new password. If you forget your password [Off] If you forget your password, you can clear it using the following steps: Fanfare and score do not appears on the screen. 1. Remove any disc that might be in the player. ,,Note 3. Use Number buttons to enter “210499”. The password is cleared. hen you watch movies, “Off ” the Semi yy W Karaoke at the Setup menu or enjoy it without connecting the microphone if the fanfare or score appears during changing a chapter. yy T he Semi Karaoke function is available only when a microphone is connected. yy The fanfare and score is applied for only BDROM and DVD-title playback. 2. Select [Password] option in the [Settings] menu. ,,Note If you make a mistake before pressing ENTER (b), press CLEAR. Then input the correct password. DVD Rating Blocks playback of rated DVD based on their content. (Not all discs are rated.) [Rating 1-8] Rating one (1) has the most restrictions and rating eight (8) is the least restrictive. [Unlock] If you select [Unlock], parental control is not active and the disc plays in full. System Setting Blu-ray Disc Rating [OTHERS] menu Set an age limit of BD-ROM play. Use number buttons to input an age limit for BD-ROM viewing. Pointer  Sets the speed and size of an USB mouse’s pointer. All BD-ROM can be played. [Speed] [0-254] Sets the moving speed of an USB mouse. Prohibits play of BD-ROM with corresponding ratings recorded on them. [Size] ,,Note The [Blu-ray Disc Rating] will be applied only for the Blu-ray disc that containing the Advanced Rating Control. Enter the code of the area whose standards were used to rate the DVD video disc, based on the list on page 70. Chooses the pointer size of an USB mouse. ,,Note The Pointer function is optimized for convenience of Internet usage. DivX(R) VOD ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified® device that plays DivX video. Visit divx.com for more information and software tools to convert your files into DivX videos. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod. divx.com for more information on how to complete your registration. [Register] Displays the registration code of your player. [Deregister] Deactivate your player and display the deactivation code. ,,Note All the downloaded videos from DivX(R) VOD with this player’s registration code can only be played on this unit. 3 System Setting Area Code 31 32 System Setting Quick Start This player can stay in standby mode with low power consumption, so that the player can instantly boot without delay when you turn on this unit. Set this option to [On] for activating [Quick Start] function. TV Sound Connecting You can listen to TV sound through this unit’s speaker automatically when TV is turned on. TV and this unit should be connected with optical cable. ,,Note yy [Quick Start] function may not be available at the moment. This function will become available through at software update. 3 System Setting yy If [Quick Start] option is set to [On] and an AC power is accidently re-connected to the player by power failure etc., the player automatically boots itself to be the standby status. Before operating the player, wait for a while until the player is in standby status. yy When [Quick Start] is set to [On], power consumption will be higher than when [Quick Start] is set to [Off ]. Auto Power Off The screen saver appears when you leave the player in Stop mode for about 5 minutes. If you set this option to [On], the unit automatically turns off within 20 minutes since the Screen Saver is displayed. Set this option to [Off ] to leave the screen saver until the unit is operated by the user. ,,Note When you set [Auto Power Off ] function in setting menu on, this unit will be off itself to save electronic consumption in the case main unit is not connected to external device and is not used for 25 minutes. So does this unit after six hours since Main unit has been connected to other device using analog input. Press W to move and press A/D to select [On] or [Off ]. Select [OK] and press ENTER (b). Initialize [Factory Set] You can reset the player to its original factory settings. [Blu-ray Storage Clear] Initializes the BD-Live content from the connected USB storage. ,,Note If you reset the player to its original factory settings using [Factory Set] option, you have to set all the activation for the online services and network settings again. System Setting 33 Software [Information] Displays the current software version. [Update] You can update the software by connecting the unit directly to the software update server (page 64). SIMPLINK / ARC -- The SIMPLINK function allows you to control this unit with LG TV’s remote control. Set this option to [On] for activating [SIMPLINK / ARC] function (page ���������� 17)�. 3 System Setting -- The ARC function enables an HDMI capable TV to send the audio stream to HDMI OUT of this player. 34 Operating Sound Effect Setting the [User EQ] You can select a suitable sound mode. Press SOUND EFFECT repeatedly until the desired mode appears on the front panel display or the TV screen. The displayed items for the equalizer maybe different depending on sound sources and effects. [Natural Plus]: You can enjoy the natural sound effect same as 3.1 channel. [Natural]: You can enjoy comfortable and natural sound. 1.Use W/S to select the desired frequency. [Bypass]: Software with multichannel surround audio signals is played according to the way it was recorded. Select [Cancel] option then press ENTER (b) to cancel the setting. Select [Reset] option then press ENTER (b) to reset the all adjustments. [Bass Blast]: Reinforce the bass sound effect from front left and right speaker and subwoofer. [Clear Voice]: This mode makes voice sound clear, improving the quality of voice sound. 4 Operating [Game]: You can enjoy more virtual sound while playing video games. [Night]: This may be useful when you want to watch movies at low volumes late at night. [Up Scaler]: When listening to MP3 files or other compressed music, you can enhance the sound. This mode is available only to 2 channel sources. [Loudness]: Improves bass and treble sound. [User EQ]: You can adjust the sound by raising or lowering the level of specific frequency. 2.Use A/D to select the desired level. 3D Sound Effect 3D Sound features create a wider spot so you can enjoy more immersive and cinematic surround sound. Press 3D SOUND repeatedly until the desired mode appears on the front panel display or the TV screen. [3D Music]: This mode delivers outstanding surround sound, providing a concert hall-like music experience in your home. [3D Movie]: This mode delivers outstanding surround sound, providing a theater-like movie experience in your home. Operating 35 Home Menu Display Using [HOME] menu The home menu appears when you press HOME ( ). Use W/S/A/D to select a category and press ENTER (b). Using the Smart Share You can play video, photo and audio content on the unit by inserting a disc, connecting an USB device or using home network (DLNA). 1. Press HOME ( ) to display the home menu. 2. Select [Smart Share] and press ENTER (b). ,,Note a Displays all linked device. b Displays video, photo or audio content. c Displays the file or folder on linked device. a [Smart Share] - Displays Smart Share menu. b [Premium] - Displays the Premium home screen (page 55). c [LG Smart World] - Displays LG Apps titles provided to the unit (page 56). d [My Apps] - Displays the [My Apps] screen (page 57). e [Input] - Changes input mode. f [Settings] - Adjusts the system settings. g [Search] - Searches for desired LG Apps and other content. h [Sign In] - Displays Sign In menu. 4 Operating Depending on the region, the [LG Smart World], [My Apps] service and [Search] function may not be available. 36 Operating Playing the Linked Devices Playing a disc erot 1. Insert a disc in the disc slot. For the most Audio CD, BD-ROM and DVD-ROM discs, playback starts automatically. 2.Press HOME ( ) and then select [Smart Share]. 4 Playing Blu-ray 3D disc e This player can play the Blu-ray 3D disc which contains separate views for the left and right eyes. Preparation In order to playback Blu-ray 3D title in stereoscopic 3D mode, you need to: yy Check your TV is 3D capable and has HDMI input(s). 3. Select disc icon. ear 3D glasses to enjoy the 3D experience yy W if it is necessary. ,,Note heck whether the BD-ROM title is the Bluyy C ray 3D disc or not. yy Playback functions described in this manual are not always available in every files and media. Some functions can be restricted depending on many factors. Operating yy Depending on the BD-ROM titles, an USB device connection may be needed for the proper playback. yy Unfinalized DVD-VR format discs may not be played in this player. yy Some DVD-VR discs are made with CPRM data by DVD RECORDER. This unit cannot support these kinds of discs. yy Connect an HDMI cable (Type A, High Speed HDMI™ Cable) between the player’s HDMI output and TV’s HDMI input. 1.Press HOME ( ), and set the [3D Mode] option on the [Settings] menu to [On] (page 28). 2. Insert a disc in the disc slot. The playback starts automatically. 3. Refer to the owner’s manual of your 3D-ready TV for the further instruction. You may need to adjust the display settings and focus on your TV’s setting for the improved 3D effect. >>Caution yy Watching a 3D content for a long period time may cause dizziness or tiredness. yy It is not recommended to watch a video in 3D mode for infirm, child and pregnant woman. yy If you are experiencing headache, tiredness or dizziness while viewing content in 3D, it is strongly recommended to stop the playback and rest until you feel normal. Operating 37 Playing a file on disc/USB device yui This player can play video, audio and photo files contained in the disc or USB device. 1. Insert a data disc in the disc slot or connect an USB device. Notes on USB device yy This player supports USB flash drive/external HDD formatted in FAT32 and NTFS when accessing files (music, photo, movie). However, for BD-Live, use the USB flash drive / external HDD formatted in FAT32. yy This unit can support up to 4 partitions of the USB device. yy Do not extract the USB device during operation (play, etc.). yy An USB device which requires additional program installation when you have connected it to a computer, is not supported. yy USB device: USB device that supports USB1.1 and USB2.0. yy Video, audio and photo files can be played. For details of operations on each file, refer to relevant pages. yy Regular back up is recommended to prevent data loss. File loading may takes few minutes depending on the number of content stored in the USB storage device. Press ENTER (b) while [Cancel] is selected to stop loading. 2.Press HOME ( ). 3. Select [Smart Share] and press ENTER (b). 4. Select the desired linked device in the category. 5. Select [Movie], [Photo] or [Music]. 6. Select a file using W/S/A/D, and press d(PLAY) or ENTER (b) to play the file. yy If you use an USB extension cable, USB HUB or USB Multi-reader, the USB device may not be recognized. yy Some USB device may not work with this unit. yy Digital camera and mobile phone are not supported. yy USB Port of the unit cannot be connected to PC. The unit cannot be used as a storage device. Operating When you connect the USB device on the HOME menu, the player plays an audio file contained in the USB storage device automatically. If the USB storage device is containing various types of files, a menu for the file type selection will appear. 4 38 Operating Playing a file on a network server yui This player can play video, audio and photo files located in a DLNA server through your home network. 1. Check the network connection and settings (page 21). 2.Press HOME ( ). 3. Select [Smart Share] and press ENTER (b). ,,Note yy The file requirements are described on page 66. yy The thumbnail of the unplayable files can be displayed, but those cannot be played on this player. yy The subtitle file name and video file name have to be the same and located at the same folder. yy The playback and operating quality may be affected by your home network condition. yy You may experience connection problems depending on your server’s environment. yy To set your PC as a DLNA server, install the supplied Nero MediaHome 4 on your PC (page 39). 4 4. Select a DLNA media server in the category. Operating 6. Select a file using W/S/A/D, and press d(PLAY) or ENTER (b) to play the file. 5. Select [Movie], [Photo] or [Music]. Operating 39 Using Home Network Server for PC MAC OS X DLNA stands for Digital Living Network Alliance, which allows users to access video, photo and audio files stored in server and enjoy them on TV via home networking. 2. Browse the CD-ROM drive and open the “MediaHome_4_Essentials_MAC” folder. Before connecting to PC to play a file , Nero MediaHome 4 Essentials program should be installed on your PC. 4. In the Nero MediaHome window, drag the Nero MediaHome icon either to the Applications folder within the window or to any other desired location. Installing Nero MediaHome 4 Essentials Windows 9. If you want to take part in the anonymous collection of data, select the check box and click the [Next] button. 10.Click the [Exit] button to complete the installation. 3. Double-click the “Nero MediaHome.dmg” image file. The Nero MediaHome window is opened. 5. You can now start the application by doubleclicking the Nero MediaHome icon in the location you dragged it to. Sharing files and folders On your computer, you must share the folder contained video, audio and/or photo content to play them on this player. This parts explains the procedure for selecting the shared folders on your computer. 1. Double-click the “Nero MediaHome 4 Essentials” icon. 2. Click [Network] icon on the left and define your network name in the [Network name] field. The Network name you enter will be recognized by your player. 3. Click [Shares] icon on the left. 4. Click [Local Folders] tab on the [Shares] screen. 5. Click [Add] icon to open the [Browse Folder] window. 6. Select the folder containing the files you want to share. The selected folder is added to the list of shared folders. 7. Click [Start Server] icon to start the server. ,,Note yy If the shared folders or files are not displayed on the player, click the folder on the [Local Folders] tab and click [Rescan Folder] at the [More] button. yy Visit www.nero.com for more information and software tools. 4 Operating Start up your computer, and insert the supplied CDROM disc into your computer’s CD-ROM drive. An installation wizard will walk you through the quick and uncomplicated installation process. To install Nero MediaHome 4 Essentials, proceed as follows: 1. Close all Microsoft Windows programs and exit any anti-virus software that may be running. 2. Insert the supplied CD-ROM disc into your computer’s CD-ROM drive. 3. Click [Nero MediaHome 4 Essentials]. 4. Click [Run] to start installation. 5. Click [Nero MediaHome 4 Essentials]. The installation is prepared and the installation wizard appears. 6. Click the [Next] button to display the serial number input screen. Click [Next] to go to the next step. 7. If you accept all conditions, click [I accept the License Conditions] check box and click [Next]. Installation is not possible without this agreement. 8. Click [Typical] and click [Next]. The installation process is started. 1. Start up your computer, and insert the supplied CD-ROM disc into your computer’s CD-ROM drive. 40 Operating About Nero MediaHome 4 Essentials Nero MediaHome 4 Essentials is a software for sharing video, audio and photo files stored on your computer to this unit as a DLNA-compatible digital media server. ,,Note System requirements Windows PC yy Windows® XP (Service Pack 2 or higher), Windows Vista® (no Service Pack required), Windows® 7 (no Service Pack required), Windows® XP Media Center Edition 2005 (Service Pack 2 or higher), Windows Server® 2003 yy The Nero MediaHome 4 Essentials CDROM is designed for PCs and should not be inserted in this player or in any product other than a PC. yy Windows Vista® 64-bit edition (application runs in 32-bit mode) yy The supplied Nero MediaHome 4 Essentials CD-ROM is a customized software edition only for sharing files and folders to this player. yy Hard drive space: 200 MB hard drive space for a typical installation of Nero MediaHome standalone yy The supplied Nero MediaHome 4 Essentials software does not support following functions: Transcoding, Remote UI, TV control, Internet services and Apple iTunes. yy The supplied Nero MediaHome 4 Essentials software can be downloaded at yy Windows® 7 64-bit edition (application runs in 32-bit mode) yy 1.2 GHz Intel® Pentium® III or AMD Sempron™ 2200+ processors yy Memory: 256 MB RAM yy Graphics card with at least 32 MB video memory, minimum resolution of 800 x 600 pixels, and 16bit color settings -- Windows : http://www.nero.com/ download.php?id=nmhlgewin yy Windows® Internet Explorer® 6.0 or higher -- Mac OS : http://www.nero.com/ download.php?id=nmhlgemac yy Network environment: 100 Mb Ethernet, WLAN yy This manual explains operations with the English version of Nero MediaHome 4 Essentials as examples. Follow the explanation referring to the actual operations of your language version. yy DirectX® 9.0c revision 30 (August 2006) or higher Macintosh yy Mac OS X 10.5 (Leopard) or 10.6 (Snow Leopard) yy Macintosh computer with an Intel x86 processor yy Hard drive space: 200 MB hard drive space for a typical installation of Nero MediaHome standalone yy Memory: 256 MB RAM Operating General Playback Basic operations for photo content Basic operations for video and audio content To play a slide show To stop playback To stop a slide show Press Z (STOP) during playback. To pause playback Press M (PAUSE) during playback. Press d (PLAY) to resume playback. To play frame-by-frame (Video) Press M (PAUSE) during video playback. Press M (PAUSE) repeatedly to play Frame-by-Frame playback. To scan forward or backward You can change the various playback speeds by pressing c or v repeatedly. To slow down the playing speed While the playback is paused, press v repeatedly to play various speeds of slow motion. To skip to the next/previous chapter/track/file During playback, press C or V to go to the next chapter/track/file or to return to the beginning of the current chapter/track/file. Press C twice briefly to step back to the previous chapter/track/file. In the file list menu of a server, there may have many types of content in a folder together. In this case, press C or V to go to the previous or next content with same type. Press d (PLAY) to start slide show. Press Z (STOP) while slide show. To pause a slide show Press M (PAUSE) while slide show. Press d (PLAY) to re-start the slide show. To skip to the next/previous photo While viewing a photo in full screen, press A or D to go to the previous or next photo. Using the disc menu ero To display the disc menu The menu screen may be displayed first after loading a disc which contains a menu. If you want to display the disc menu during playback, press DISC MENU. Use W/S/A/D buttons to navigate through menu items. To display the Popup menu Some BD-ROM discs contain Popup menu that appears during playback. Press TITLE/POPUP during playback, and use W/ S/A/D buttons to navigate through menu items. 4 Operating Press c or v to play fast forward or fast reverse during playback. 41 42 Operating Resume playback eroyt u The unit records the point where you pressed the Z (STOP) depending on the disc. If “MZ (Resume Stop)” appears on the screen briefly, press d (PLAY) to resume playback (from the scene point). If you press Z (STOP) twice or unload the disc, “Z(Complete Stop)” appears on the screen. The unit will clear the stopped point. ,,Note yy The resume point may be cleared when a button is pressed (for example; 1 (POWER), B (OPEN/CLOSE), etc). yy On BD-ROM discs with BD-J, the resume playback function does not work. 4 Operating yy If you press Z (STOP) once during BD-ROM interactive title playback, the unit will be in Complete Stop mode. Last scene memory er This unit memorizes the last scene from the last disc that is viewed. The last scene remains in memory even if you remove the disc from the unit or switch off the unit. If you load a disc that has the scene memorized, the scene is automatically recalled. ,,Note yy Last Scene Memory function for a previous disc is erased once a different disc is played. yy This function may not work depending on the disc. yy On BD-ROM discs with BD-J, the last scene memory function does not work. yy This unit does not memorize settings of a disc if you switch off the unit before commencing to play it. Operating 43 On-Screen Display Displaying content information onscreen You can display and adjust various information and settings about the content. eroy To control video playback eroy 2. Select an [Option] using A/D, and press ENTER (b). 1. During playback, press INFO/MENU (m). You can control playback and set options while watching videos. During playback, press INFO/MENU (m). a Progress bar - Displays the current position and total playing time. 4 c [Title/Popup] - Displays the DVD title menu or BD-ROM’s popup menu, if available. a Title – Current title number/total number of titles d [Option] - Displays playback information. b Chapter – Current chapter number/total number of chapters e [Repeat] - Repeats a desired section or sequence (page 45). f [3D] - Adjusts the 3D setting (page 49). c Time – Elapsed playing time/total playback time d Audio – Selected audio language or channel e Subtitle – Selected subtitle. f Angle – Selected angle/total number of angles g TV Aspect Ratio – Selected TV aspect ratio h Picture Mode – Selected picture mode Operating b [Disc Menu] - Accesses menu on a disc. 44 Operating ,,Note yy If no button is pressed for a few seconds, the on-screen display disappears. yy A title number cannot be selected on some discs. yy Available items may differ depending on discs or titles. Setting the slide show option You can use various options during viewing a photo in full screen. 1. While viewing pictures, press INFO/MENU (m). 2. Select an [Option] using A/D, and press ENTER (b) yy If an interactive Blu-ray Disc is playing back, some setting information is displayed on the screen but prohibited to be changed. To control photo view i Controls playback and sets options while viewing pictures in full screen. 4 a [Speed] - Use A/D to select a delaying speed between photos in a slide show. While viewing pictures, press INFO/MENU (m). b [Effect] - Use A/D to select a transition effect between photos in a slide show. Operating You can control playback and set options while viewing pictures in full screen. c [Music Select] – Select the background music for the slide show (page 49). a [Slideshow] - Starts or pause slide show. b [Music] - Select the background music for the slide show (page 49).� c [Option] - Displays slide show options. d [Rotate] - Rotates the photo clockwise. e [Zoom] - Displays the [Zoom] menu. Operating 45 Advanced Playback Repeating a specific portion eroty Repeat playback erotu y This player can repeat a portion you have selected. 1. During playback, press REPEAT (h) to select [A-B] and press ENTER (b) at the beginning of the portion you wish to repeat. Blu-ray Disc / DVD / Video files 2.Press ENTER (b) at the end of the portion. Your selected portion will be repeated continually. During playback, press REPEAT (h) to select a desired repeat mode. 3. To return to normal playback, press CLEAR. A-B – Selected portion will be repeated continually. Chapter – The current chapter will be played back repeatedly. Title – The current title will be played back repeatedly. All – All the titles or files will be played back repeatedly. ,,Note yy You cannot select a portion less than 3 seconds. yy This function may not work on some disc or title. Audio CDs/Audio files 1. During playback, press INFO/MENU (m). During playback, press REPEAT (h) repeatedly to select a desired repeat mode. 2. Select an [Option] using A/D, and press ENTER (b) – Selected portion will be repeated continually. (Audio CD only) 3. Select the [Time] option and then input the required start time in hours, minutes, and seconds from left to right. Track– The current track or file will be played back repeatedly. All – All the tracks or files will be played back repeatedly. All – All the tracks or files will be played back repeatedly in random order. – The tracks or files will be played back in random order. To return to normal playback, press CLEAR. ,,Note This function may not work on some disc or title. For example, to find a scene at 2 hours, 10 minutes, and 20 seconds, enter “21020”. Press A/D to skip the playback 60 seconds forward or backward. 4.Press ENTER (b) to start playback from selected time. ,,Note yy This function may not work on some disc or titles. yy This function may not work depending on the file type and ability of the DLNA server. 4 Operating To return to normal playback, press CLEAR. Playing from selected time eroy Off – Returns to normal playback. 46 Operating Selecting a subtitle language eroy 1. During playback, press INFO/MENU (m). 2. Select an [Option] using A/D, and press ENTER (b) 3.Use W/S to select the [Subtitle] option. If the disc contains scenes recorded at different camera angles, you can change to a different camera angle during playback. 4.Use A/D to select desired subtitle language. By pressing ENTER (b), you can set various subtitle options. 2. Select an [Option] using A/D, and press ENTER (b) 5. Press BACK (1) to exit the On-Screen display. 3.Use W/S to select the [Angle] option. ,,Note Some discs allow you to change subtitle selections only via the disc menu. If this is the case, press TITLE/POPUP or DISC MENU button and choose the appropriate subtitle from the selections on the disc menu. 4 Watching from a different angle er Operating Hearing a different audio eroy 1. During playback, press INFO/MENU (m). 2. Select an [Option] using A/D, and press ENTER (b) 3.Use W/S to select the [Audio] option. 4.Use A/D to select desired audio language, audio track or audio channel. ,,Note yy Some discs allow you to change audio selections only via the disc menu. In this case, press TITLE/POPUP or DISC MENU button and choose the appropriate audio from the selections on the disc menu. yy Immediately after you have switched sound, there may be a temporary discrepancy between the display and actual sound. yy On BD-ROM disc, the multi audio format (5.1CH or 7.1CH) is displayed with [MultiCH] in the on-screen display. yy You can select the [Audio] option on the On-Screen display directely by pressing AUDIO button. 1. During playback, press INFO/MENU (m). 4.Use A/D to select desired angle. 5. Press BACK (1) to exit the On-Screen display. Changing the TV Aspect Ratio eoy You can change the TV aspect ratio setting during playback. 1. During playback, press INFO/MENU (m). 2. Select an [Option] using A/D, and press ENTER (b) 3.Use W/S to select the [TV Aspect Ratio] option. 4.Use A/D to select desired option. 5. Press BACK (1) to exit the On-Screen display. ,,Note Even if you change the value of the [TV Aspect Ratio] option in On-Screen display, the [TV Aspect Ratio] option in the [Settings] menu is not changed. Operating 47 Changing subtitle Code Page y If the subtitle is displayed in broken letter, you can change the subtitle code page to view the subtitle file properly. 1. During playback, press INFO/MENU (m). 2. Select an [Option] using A/D, and press ENTER (b) Setting the [User setting] option 1. During playback, press INFO/MENU (m). 2. Select an [Option] using A/D, and press ENTER (b) 3.Use W/S to select the [Picture Mode] option. 4.Use A/D to select the [User setting] option, and press ENTER (b). 3.Use W/S to select the [Code Page] option. 4.Use A/D to select desired code option. 5.Use W/S/A/D to adjust the [Picture Mode] options. Select [Default] option then press ENTER (b) to reset the all video adjustments. 5. Press BACK (1) to exit the On-Screen display. Changing the Picture Mode eroy You can change the [Picture mode] option during playback. 1. During playback, press INFO/MENU (m). 2. Select an [Option] using A/D, and press ENTER (b) 3.Use W/S to select the [Picture Mode] option. 4.Use A/D to select desired option. 5. Press BACK (1) to exit the On-Screen display. Viewing content information y The player can display the content information. 1. Select a file using W/S/A/D. 2. Press INFO/MENU (m) to display the option menu. The file information appears on the screen. During video playback, you can display the file information by pressing TITLE/POPUP. ,,Note The information displayed on the screen may not correct comparing actual content information. 4 Operating 6.Use W/S/A/D to select the [Close] option, and press ENTER (b) to finish setting. 48 Operating Changing content list view yui Selecting a subtitle file y On the [Smart Share] menu, you can change the content list view. If the subtitle file name is different from the video file name, you need to select the subtitle file on the [Movie] menu before playing the movie. Press red (R) colored button repeatedly. 1.Use W/S/A/D to select the subtitle file you wish to play in the [Movie] menu. 2.Press ENTER (b). 4 Press ENTER (b) again to deselect the subtitle file. Selected subtitle file will be displayed when you play the video file. Operating ,,Note yy If you press Z (STOP) during playback, the subtitle selection is cancelled. yy This function is not available for playing file on a server via home network. Operating 49 Listening to music during slide show i You can display photo files while listening to audio files. 1. While viewing a photo in full screen, press INFO/ MENU (m) to display the option menu. 2. Select an [Option] using A/D, and press ENTER (b). 3.Use W/S to select [Music Select] option, and press ENTER (b) to display the [Music Select] menu. 4.Use W/S to select a device, and press ENTER (b). Available device may differ depending on the location of the current photo file. Available Device Disc, USB Disc, USB DLNA server DLNA server 5.Use W/S to select a file or a folder you wish to play. Select g and press ENTER (b) to display the upper directory. ,,Note When selecting audio file from a server, folder selection is not available. Only file selection is available. 6.Use D to select [OK], and press ENTER (b) to complete music selection. This function allows you to convert 2D content to 3D. You can adjust 3D’s depth and distance on the [3D] option while playing back. 1. During playback, press INFO/MENU (m). 2. Select a [3D], and press ENTER (b). 3.Use W/S/A/D to select desired options. Select [Default] option then press ENTER (b) to reset the all adjustments. 4.Use W/S/A/D to select the [Close] option, and press ENTER (b) to finish setting. ,,Note yy When you have set to Ultra HD resolution, if you select the [On] in [3D], the Ultra HD resolution is automatically changed to the original resolution. yy Movie files which is upper 30 fps (frame rate) may not be converted to 3D. 4 Operating Photo location Converting 2D content to 3D eroy 50 Operating Advanced Features Enjoying BD-Live™ e BD-ROM supporting BD-Live that has a network extension function allows you to enjoy more functions such as downloading new movie trailers by connecting this unit to the internet. 1. Check the network connection and settings (page 21). 2. Insert an USB storage device to the USB port. An USB storage device is needed to download bonus content. 3.Press HOME ( ), and set the [BD-LIVE connection] option on the [Settings] menu (page 26). 4 Operating Depending on a disc, the BD-Live function may not be operated if [BD-LIVE connection] option is set to [Partially Permitted]. 4. Insert a BD-ROM with BD-Live. The operations may differ depending on the disc. Refer to the manual supplied with the disc. >>Caution Do not extract the connected USB device while content is being downloaded or a Blu-ray disc is still in the disc slot. Doing so may damage the connected USB device and BD-Live features may not operate properly with the damaged USB device anymore. If the connected USB device seems damaged from such an action, you can format the connected USB device from the PC and reuse it with this player. ,,Note yy Some BD-Live content may be restrictively accessed in some territories by content provider’s own decision. yy It may take up to several minutes to load and start enjoying BD-Live content. yy For BD-Live, use the USB flash drive / external HDD formatted in FAT32 only. LG AV Remote You can control this player with your iPhone or Android phone via your home network. This player and your phone must be connected to your wireless network device such as access point. Visit “Apple iTunes” or “Google Android Market (Google Play Store)” for detailed information of “LG AV Remote”. Operating 51 ,,Note Audio CD recording You can record one desired track or all of the tracks in Audio CD to an USB storage device. 1. Insert an USB storage device to the USB port. 2. Insert an Audio CD into the player. The playback starts automatically. 3. Press (X) REC button to start [CD Recording]. Stop mode During playback Recording track All of the tracks playing track Recording time 4X speed normal speed Recording from FM radio or PORTABLE source You can record from FM radio or PORTABLE source to an USB storage device. 2. In FM radio mode, tune to the desired radio station (See “Radio Operations” on page 54) or in PORTABLE mode, start playback from the external source. 3. Press (X) REC button on the remote control. -- The recording is saved as a file in “EXT_REC” folder. yy Audio track is recorded to an audio file with 192 kbps. FM radio and PORTABLE source are recorded to an audio file with 128 kbps. yy Audio CD recording time in the table is approximate. yy Actual recording time for USB storage device varies depending on the USB storage device’s ability. yy Make sure that there is minimum of 50 MB free space is needed when recording into the USB storage device. yy The length of the recording source should be longer than 20 seconds for the proper recording. yy Do not turn off this player or extract the connected USB storage device during the recording. >>Caution The recording or copying features on this player are provided for your personal and non-commercial use. The making of unauthorized copies of copy-protected material, including computer programs, files, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal offense. This equipment should not be used for such purposes. LG expressly disclaims any responsibility for illegal distribution or use of unauthorized content in commercial purpose. Be Responsible Respect Copyrights 4 Operating 1. Insert an USB storage device to the USB port. yy For recording, use the USB flash drive / external HDD formatted in FAT32 only. 52 Operating Playing the iPod You can enjoy the sound with your iPod. For details about iPod, refer to the iPod’s User Guide. Preparation Before connecting the iPod, turn this unit off and reduce the volume of this unit to its minimum. ,,Note Use the iPod cable supplied with your iPod. 1. Connect the iPod to the USB port. If you turn this unit on, your iPod is automatically turned on and recharging starts. 4 When you connect the iPod on the HOME menu, the player plays a music automatically. 2. Select a file using W/S/A/D, and press ENTER (b) to play the file. Operating Enjoying iPod on the screen 1. Connect the iPod to the USB port. 2.Press HOME ( ). Press REPEAT (h) to select a desired repeat mode :Track (;), All (:), Shuffle All (l :), Shuffle (l), Off (No display) ,,Note If the iPod’s OSD language is selected to simple chinese, the power scroll function is not operated correctly. Enjoying the iPod IN mode Please control directly from your iPod. You can control your music in your iPod with the supplied remote control. 1. Connect the iPod to the USB port. If you turn this unit on, your iPod is automatically turned on and recharging starts. 2. Press FUNCTION to select iPod in mode. 3. Select [Smart Share] using A/D, select the iPod on the menu. W/S/A/D Selects an option in the menu. 4. Select a file using W/S/A/D, and press ENTER (b) to play. ENTER (b) Starts playback the music. M or d (PLAY) To pause while it is playing. To resume playing, press M or d (PLAY) again. (Press and hold) c/v Fast-forward or rewind a song C/V Skip the playback forward or backward . Power scroll You can search easily a content by power scroll on the screen. Select a power scroll using D and select the initial of the desired content. Operating 53 ,,Note yy An error message “CHECK” or “Connected iPod model is not supported.” appears when: -- your iPod is not available for the function to be operated. yy An error message “CHECK” or “Please update your iPod’s software.” appears when: -- your iPod has an old software version. /Update your iPod software to latest version. yy Compatibility with your iPod may vary depending on the type of your iPod. yy iPod touch, iPhone and iPad have any difference in operation other than iPod. You may need any additional control to use them with this unit. (e.g. “slide to unlock”) yy If you use an application, make a call, or send and receive SMS text message, etc. on iPod touch, iPhone or iPad, disconnect it from to the USB port of this unit and then use it. yy Depending on your iPod’s software version, it may not be possible to control your iPod from this unit. We recommend installing the latest software version. yy This unit supports the models as follows. - iPad nano 4G, 5G, 6G, 7G - iPod touch 3G, 4G, 5G - iPhone 3GS, 4, 4S, 5 - iPad, iPad2, iPad3, iPad4 - iPad mini yy If you have a problem with your iPod, please visit www.apple.com/support/ipod. 4 Operating yy If this unit displays an error message, follow the message. An error message “CHECK” or “Please check your iPod.” appears when: -- the communication between this unit and your iPod is failed. /Connect & reconnect your iPod in this unit. -- your iPod is not connected firmly. -- this unit recognises your iPod as unknown device. yy Your iPod is exceptionally low on power. /The battery needs to be charged. /If you charge the battery while iPod is extremely low in power, it may take longer to charge. 54 Operating Radio Operations Be sure that the antenna is connected. (Refer to the page 19) Listening to the radio 1. Press FUNCTION until TUNER (FM) appears in the display window. The last received station is tuned in. 4 Deleting a saved station 1. Press PRESET (- / +) to select a preset number you want to delete. 2. Press CLEAR, the preset number will blink in the display window. 3. Press CLEAR again, to delete the selected preset number. Deleting all the saved stations 2. Press and hold TUNING (-/+) for about two seconds until the frequency indication starts to change. Scanning stops when the unit tunes in a station. Or Press TUNING (-/+) repeatedly. Press and hold CLEAR for two seconds. “ERASE ALL” will flash up. Press CLEAR again. Then all the saved stations are deleted. 3. Adjust the volume by pressing VOL (+/-). Improving poor FM reception Presetting the Radio Stations Press B (blue) (MONO/STEREO) colored button on the remote control. This will change the tuner from stereo to mono and usually improve the reception. You can preset 50 stations for FM. Before tuning, make sure that you have turned down the volume. Operating 1. Press FUNCTION until the TUNER (FM) appears in the display window. 2. Select the desired frequency by using TUNING (-/+). 3. Press ENTER (b) a preset number will flash in the display window. 4. Press PRESET (-/+) to select the preset number you want. 5. Press ENTER (b). The station is stored. 6. Repeat the steps 2 to 5 to store other stations. Operating 55 Using an USB keyboard or mouse You can connect an USB keyboard and/or mouse to type text and navigate menus. 1. Connect an USB keyboard or mouse to the USB port. 2. Use the keyboard to type text, or the mouse to navigate menus. Using the Premium You can use various content services via Internet with the Premium feature. 1. Check the network connection and settings (page 21). 2.Press HOME ( ). 3. Select the [Premium] using A/D, and press ENTER (b). ,,Note The following keyboards and mice are recommended. -- Logitech Wireless Combo MK520 -- Logitech Wireless Combo MK320 -- Logitech Wireless Combo MK260 -- Microsoft Wireless Desktop 5000 -- Microsoft Wireless Desktop 3000 -- Microsoft Wireless Desktop 2000 -- Microsoft Wireless Desktop 800 4. Select an online service using W/S/A/D, and press ENTER (b). ,,Note yy The content of Premium services and service related information, including user interface, is subject to changes. Please refer to the web site of each service for most upto-date information. yy If you want to change the country setting, go to [Settings] > [NETWORK] > [Smart Service Setting] > [Country Setting]. Select [Manual] and press ENTER (b) on [Country Setting] menu. 4 Operating yy For detailed information of each service, contact to the content provider or visit support link of the service. 56 Operating Using the LG Smart World You can use the LG application services on this player via Internet. You can easily find and download various applications from LG Smart World. 1. Check the network connection and settings (page 21). 2.Press HOME ( ). 3. Select the [LG Smart World], and press ENTER (b). Signing in To use the [LG Smart World] feature, you need to sign in with your account. 1. On the home menu, select [ ENTER (b). 2. Fill the [ID] and [Password] field using the virtual keyboard. If you do not have an account, press red (R) colored button to register. 3.Use W/S/A/D to select [OK], and press ENTER (b) to sign in with your account. If you select the [Auto Sign In] check box, your ID and password are remembered and automatically signed in without entering them. ,,Note 4 Operating 4. Select a category using A/D, and press ENTER (b). 5.Use W/S/A/D to select an application, and press ENTER (b) to display the information. 6. Press ENTER (b) while [Install] icon is highlighted. The application will be installed to the player. To install an application to the player, user needs to sign in. Refer to page 56 for more information of signning in. 7. Press red (R) colored button to display the [My Apps] screen. 8. Select the installed application and press ENTER (b) to excute it. ,,Note yy Depending on the region, the [LG Smart World], [My Apps] service and [Search] function may not be available. yy To install a paid application, you need to be a paid member. Visit www.lgappstv.com for more information. ] icon and press To view the information of your account and applications, select [ ] icon and press ENTER (b) on the home menu, and select [My Page] option. Operating 57 Searching online content If you are having difficulties finding specific content from online services, you can use the all-in-one search function by entering keywords in the [ ] menu. 1.Press HOME ( ). 2. Select the [ ] icon on the home menu using W/S/A/D, and press ENTER (b). Using the My Apps Menu You can move or delete an installed application in the [My Apps] menu. 1.Press HOME ( ). 2. Select the [My Apps], and press ENTER (b). The [ ] menu appears on the screen. 3. Press ENTER (b). The virtual keyboard appears automatically. 4.Use W/S/A/D to select letters then press ENTER (b) to confirm your selection on the virtual keyboard. 3. On the [My Apps] menu, press red (R) colored button. 6.Use W/S/A/D to select a desired content, and press ENTER (b) to move to the selected content directly. Move an application ,,Note yy Depending on the region, the [LG Smart World], [My Apps] service and [Search] function may not be available. yy The [Search] function does not search content in every online services. It works only in certain online services. 1. Select an application, and press ENTER (b) to display the options. 4 2.Use W/S to select [Move], and press ENTER (b). Operating 5. When you finish entering the keyword, select [ ] and press ENTER (b) to display search result. 3.Use W/S/A/D to select a position you want to move to, and press ENTER (b). Delete an application 1. Select an application, and press ENTER (b) to display the options. 2.Use W/S to select [Delete], and press ENTER(b). 3.Use A/D to select [Yes], and press ENTER (b) to confirm. ,,Note Depending on the region, the [LG Smart World], [My Apps] service and [Search] function may not be available. 58 Operating Using Bluetooth technology About Bluetooth Bluetooth® is wireless communication technology for short range connection. The available range is within 10 meters. 4 (The sound may be interrupted when the connection interfered by the other electronic wave or you connect the bluetooth in the other rooms.) Connecting individual devices under Bluetooth® wireless technology does not incur any charges. A mobile phone with Bluetooth® wireless technology can be operated via the Cascade if the connection was made via Bluetooth® wireless technology. Available Devices : Mobile phone, MP3, Laptop, PDA Operating Bluetooth Profiles In order to use Bluetooth wireless technology, devices must be able to interpret certain profiles. This unit is compatible with following profile. A2DP (Advanced Audio Distribution Profile) Listening to music stored on the Bluetooth devices Pairing your unit and Bluetooth device Before you start the pairing procedure, make sure the Bluetooth feature is turned on in to your Bluetooth device. Refer to your Bluetooth device’s user guide. Once a pairing operation is performed, it does not need to be performed again. 1. Select the Bluetooth function by using the FUNCTION. Appears “BT READY” in display window. 2. Operate the Bluetooth device and perform the pairing operation. When searching for this unit with the Bluetooth device, a list of the devices found may appear in the Bluetooth device display depending on the type of Bluetooth device.Your unit appears as “LG-HTS”. 3. When this unit successfully paired with your Bluetooth device, Bluetooth LED of this unit lights up and “BTPAIRED” appears in the display window. ,,Note Depending on the Bluetooth device type, some device have a different pairing way. 4. Listen to music. To play a music stored on your Bluetooth device, refer to your Bluetooth device’s user guide. ,,Note If you change the function of the unit, the Bluetooth function is disconnected, operate pairing again. Operating 59 ,,Note yy The sound may be interrupted when the connection interfered by the other electronic wave. yy You cannot control the Bluetooth device with this unit. yy Pairing is limited one Bluetooth device per one unit and multi-pairing is not supported. yy Although the distance between your Bluetooth and the set is less than 10m, there are obstacles between both, your Bluetooth device cannot be connected. yy Depending on the type of the device, you may not be able to use the Bluetooth function. yy When not connected the Bluetooth, “BT READY” appears on the display window. yy When someone stands and interrupts communication between Bluetooth device and the player, the connection will be disconnected. yy If the gotten away of the distance between Bluetooth and the unit, the sound quality is lower and lower the connection will disconnect when the space between the Bluetooth and the unit gets out of the operating range of Bluetooth. yy The device with Bluetooth wireless technology is disconnected, if you turn off the main unit or put the device away from the main unit more than 10m. 4 Operating yy The Electrical malfunction due to devices using same frequency such as Medical equipment, Microwaves or wireless LAN devices, the connection will be disconnected. 60 Troubleshooting Troubleshooting General Symptom Cause & Solution The Power does not turned on. yy Plug the power cord into the wall outlet securely. The unit does not start playback. yy Insert a playable disc. (Check the disc type, color system, and regional code.) yy Place the disc with the playback side down. yy Clean the disc. yy Cancel the Rating function or change the rating level. The connected USB storage device is not recognized. yy Try using different USB cable, some USB cables may not support enough current for normal USB operation. yy If you use an USB extension cable or USB HUB, the USB devices may not be recognized. yy An USB device which requires additional program installation when you have connected it to a computer is not supported. yy This unit supports only USB Flash Drive and USB External HDD with FAT32 or NTFS format. 5 Troubleshooting The angle cannot be changed. yy Multi-angles are not recorded on the DVD Video being played. Cannot play video, photo or audio files. yy The files are not recorded in a format that the unit can play. The remote control does not work properly. yy The remote control is not pointed at the remote sensor of the unit. yy The unit does not support the codec of the video file. yy The remote control is too far from the unit. yy There is an obstacle in the path of the remote control and the unit. yy The batteries in the remote control are exhausted. The unit is plugged in, but the power will not turn on or off. The unit is not operating normally. You can reset the unit as follows. yy Unplug the power cord, wait at least five seconds, and then plug it in again. Troubleshooting 61 Network Symptom Cause & Solution BD-Live feature does not work. yy The connected USB storage may not have enough space. Connect the USB storage with at least 1GB free space. yy Ensure that the unit is correctly connected to the local area network and can access the internet (page 21). yy Your broadband speed may not fast enough to use the BD-Live features. Contact your Internet Service Provider (ISP) and increase the broadband speed is recommended. yy The [BD-LIVE connection] option in the [Settings] menu is set to [Prohibited]. Set the option to [Permitted]. Streaming video services (such as YouTube™, etc.) are often stopped or “buffer” during playback. yy Your broadband service speed may not be fast enough to stream video services. Contact your Internet Service Provider (ISP) and increase the broadband speed is recommended. Media servers are not displayed yy The firewall or anti-virus software on your media server is running. on the device list. Turn off the firewall or anti-virus software running on your media server. yy The player is not connected to the local area network that your media server is connected. 5 Troubleshooting 62 Troubleshooting Picture Symptom Cause & Solution There is no picture. yy Select the appropriate video input mode on the TV so the picture from the unit appears on the TV screen. yy Connect the video connection securely. yy Check the [HDMI Color Setting] in the [Settings] menu is set to the appropriate item that conforms to your video connection. yy Your TV may not support the resolution you have set on the player. Change the resolution that your TV accepts. yy The player’s HDMI OUT jack is connected to a DVI device that does not support copyright protection. Picture noise appears yy You are playing a disc recorded in a colour system that is different from your TV. yy Set the resolution which your TV accepts. Blu-ray 3D disc playback does not output 3D views. yy Connect the player to your TV with HDMI cable (Type A, High Speed HDMI™ Cable). yy Your TV may not support “HDMI 3D mandatory format”. yy The [3D Mode] option in the [Settings] menu is set to [Off ]. Set the option to [On]. 5 Sound Troubleshooting Symptom Cause & Solution There is no sound or the sound is distorted. yy The unit is in scan, slow motion, or pause mode. yy The sound volume is low. Customer Support You can update the Player using the latest software to enhance the products operation and/or add new features. To obtain the latest software for this player (if updates have been made), please visit http://www.lg.com or contact LG Electronics customer care center. Open Source Software Notice To obtain the corresponding source code under GPL, LGPL and other open source licenses, please visit http://opensource.lge.com. All referred license terms, warranty disclaimers and copyright notices are available to download with the source code. Appendix 63 Controlling a TV with the Supplied Remote Control You can control your TV using the buttons below. By pressing You can 1 (TV POWER) Turn the TV on or off. AV/INPUT Switch the TV’s input source between the TV and other input sources. PR/CH W/S Scan up or down through memorized channels. VOL +/– Adjust the volume of the TV ,,Note You can operate your TV with the supplied remote control. If your TV is listed in the table below, set the appropriate manufacturer code. 1. While holding down 1 (TV POWER) button, and press the manufacturer code for your TV with the numerical buttons (see the table below). Manufacturer Code number LG 1(Default), 2 Zenith 1, 3, 4 GoldStar 1, 2 Samsung 6, 7 Sony 8, 9 Hitachi 4 2. Release the 1 (TV POWER) button to complete setting. Depending on your TV, some or all buttons may not function on the TV, even after entering the correct manufacturer code. When you replace the batteries of the remote, the code number you have set may be reset to the default setting. Set the appropriate code number again. 6 Appendix Depending on the unit being connected, you may not be able to control your TV using some of the buttons. Setting up the remote to control your TV 64 Appendix Network Software Update Network update notification From time to time, performance improvements and/or additional features or services may be made available to units that are connected to a broadband home network. If there is new software available and the unit is connected to a broadband home network, the player will inform you about the update as follows. Option 1: 1. The update menu will appear on the screen when you turn off the player. 2.Use A/D to select a desired option and then press ENTER (b). Software update You can update the player using the latest software to enhance the products operation and/or add new features. You can update the software by connecting the unit directly to the software update server. ,,Note yy Before updating the software in your player, remove any disc and USB Device from the player. yy Before updating the software in your player, turn the player off and then turn it back on. yy During the software update procedure, do not turn off the player or disconnect AC power, or do not press any button. yy If you cancel the update, turn off the power and turn it on for stable performance. yy This unit cannot be updated to previous software version. 1. Check the network connection and settings (page 21). 2. Select [Software] option in the [Settings] menu then press ENTER (b). 3. Select [Update] option, and press ENTER (b). 6 Appendix [OK] Starts the software update. [Cancel] Exits the update menu and turns the power off. Option 2: If the software update is available from the update server, the “Update” icon appears in the Home menu. Press blue (B) colored button to start the update procedure. The player will check for the newest update. ,,Note yy Pressing ENTER (b) while checking for the update will end the process. yy If there is no update available, the Message, “No update is found.” appears. Press ENTER (b) to return to the [Home Menu]. Appendix 65 4. If newer version exists, the message “Do you want to download it?” appears. 5. Select [OK] to start update. (Selecting [Cancel] will end the update.) 6. The player starts downloading the newest update from the server. (Downloading will takes several minutes depending on your home network condition) 7. When downloading is completed, the message, “Download is complete. Do you want to update?” appears. 8. Select [OK] to start updating. (Selecting [Cancel] will end the update and downloaded file will not be re-usable. To update software the next time, the software update procedure has to be started from the beginning again.) >>Caution Do not turn off the power during the software update. 9. When update is completed, the power will be turned off automatically in a few seconds. 10.Turn the power back on. The system now operates with the new version. ,,Note 6 Appendix The Software Update function may not work properly depending on your internet environment. In this case, you can obtain the latest software from the authorized LG Electronics Service Center then update your player. Refer to “Customer Support” on page 62. 66 Appendix Additional Information File requirement Video files File Location File Extension Disc, USB “.avi”, ”.divx”, “.mpg”, “.mpeg”, “.mkv”, “.mp4”, “.asf”, “.wmv”, “.m4v” (DRM free), “.vob”, “.3gp”, “.mov”, “.trp”, “.m2t”, “.mpe”, “.m1v”, “.m2v”, “.wm”, ”.flv”, “.ts”, “.dat”, “.rmvb” DIVX 3.11, DIVX4, DIVX5, DIVX6 (standard playback only), XVID, MPEG1 SS, H.264/MPEG4 AVC, MPEG2 PS, MPEG2 TS, VC-1 SM (WMV3), RV30, RV40 Dolby Digital, DTS, MP3, WMA, AAC, AC3, COOK SubRip (.srt / .txt), SAMI (.smi), SubStation Alpha (.ssa/.txt), MicroDVD (.sub/.txt), VobSub (.sub), SubViewer 1.0 (.sub), SubViewer 2.0 (.sub/. txt), TMPlayer (.txt), DVD Subtitle System (.txt) “.avi”, “.mpg”, “.divx”, “.mpeg”, “.mkv”, “.mp4”, “.asf”, “.wmv”, “.m4v” (DRM free), “.mov”, “.trp”, “.m2t”, “.mpe”, “.m1v”, “.m2v”, ”.flv”, “.ts” DIVX 3.11, DIVX4, DIVX5. DIVX6 (standard playback only) XVID, MPEG1 SS, H.264/ MPEG-4 AVC, MPEG2 PS, MPEG2 TS, VC-1 SM (WMV3) Dolby Digital, DTS, MP3, WMA, AAC, AC3 SubRip (.srt / .txt), SAMI (.smi), SubStation Alpha (.ssa/.txt), MicroDVD (.sub/. txt), SubViewer 1.0 (.sub), SubViewer 2.0 (.sub/. txt), TMPlayer (.txt), DVD Subtitle System (.txt) DLNA Audio Format Codec Format Subtitle Audio files 6 File Location File Extension Appendix Disc, USB DLNA Sampling Frequency Bitrate Note “mp3”, “.wma”, “.wav”, “.m4a” (DRM free), “.flac” within 32 - 48 kHz (WMA), within 16 - 48 kHz (MP3) within 32 - 192 kbps (WMA), within 32 - 320 kbps (MP3) Some wav files are not supported on this player. “mp3”, “.wma”, “.wav”, “.m4a” (DRM free) within 32 - 48 kHz (WMA), within 16 - 48 kHz (MP3) within 32 - 192 kbps (WMA), within 32 - 320 kbps (MP3) Some wav files are not supported on this player. Photo files File Location Disc, USB, DLNA File Extension “.jpg”, “.jpeg”, “.png”, “.gif” Recommended Size Note Less than 4,000 x 3,000 x 24 bit/pixel Progressive and lossless Less than 3,000 x 3,000 x 32 bit/pixel compression photo image files are not supported. yy Supplied bundle DLNA server for Macintosh edition has limitations in file compatibility, such as ASF, WMA Appendix 67 and WMV. ,,Note yy The file name is limited to 180 characters. yy Maximum files/Folder: Less than 2000 (total number of files and folders) yy RMVB file only supports external subtitle. yy Depending on the size and number of the files, it may take several minutes to read the content on the media. yy File compatibility may differ depending on the server. yy Because the compatibility on DLNA server are tested on the bundle DLNA server (Nero MediaHome 4 Essentials Windows edition) environment, file requirements and playback functions may differ depending on media servers. yy The file requirements on page 66 are not always compatible. There may have some restrictions by file features and media server’s ability. yy Playing video subtitle files are only available on DLNA media server created by supplied Nero MediaHome 4 Essentials software on this player package. yy The files from removable media such as USB drive, DVD-drive etc. on your media server may not be shared properly. yy This unit cannot support the ID3 Tag embedded MP3 file. yy HD video files contained on the CD/DVD or USB 1.0/1.1 may not played properly. Blu-ray Disc or USB 2.0 are recommended to play back HD video files. yy This player supports H.264/MPEG-4 AVC profile Main, High at Level 4.1. A file with higher level may not be supported. yy This player does not support files that are recorded with GMC*1 or Qpel*2. *1 GMC – Global Motion Compensation *2 Qpel – Quarter pixel yy This player supports UTF-8 files even it contains Unicode subtitle content. This player can not support the pure Unicode subtitle files. yy Depending on the types of file or ways of recording, it may not play back. yy A disc which was recorded by multi-session on normal PC is not supported on this player. yy To be playback a video file, video file name and Subtitle file name must be the same. yy When you play a video file with a extension such as “.ts”, “.m2ts”, “.mts”, “.tp”, “.Trp” or “.m2t”, your player may not support subtitle files. yy The total playback time of audio file indicated on the screen may not correct for VBR files. yy Video / Audio codec compatibility may differ depending on video file. AVCHD (Advanced Video Codec High Definition) yy This player can playback AVCHD format discs. These discs are normally recorded and used in camcorders. yy The AVCHD format is a high definition digital video camera format. yy The MPEG-4 AVC/H.264 format is capable of compressing images at higher efficiency than that of the conventional image compressing format. yy This player can playback AVCHD discs using “x.v.Color” format. yy Some AVCHD format discs may not play depending on the recording condition. yy AVCHD format discs need to be finalized. yy “x.v.Color” offers a wider color range than normal DVD camcorder discs. 6 Appendix yy The total playback time of audio file indicated on the screen may not correct for VBR files. ,,Note yy A “avi” file which is encoded “WMV 9 codec” is not supported. 68 Appendix About DLNA Compatibility notes This Player is a DLNA Certified digital media player that can display and play video, photo and audio content from your DLNA-compatible digital media server (PC and Consumer Electronics). yy Because BD-ROM is a new format, certain disc, digital connection and other compatibility issues are possible. If you experience compatibility problems, please contact an authorized Customer Service Center. The Digital Living Network Alliance (DLNA) is a cross-industry organization of consumer electronics, computing industry and mobile device companies. Digital Living provides consumers with easy sharing of digital media through your home network. The DLNA certification logo makes it easy to find products that comply with the DLNA Interoperability Guidelines. This unit complies with DLNA Interoperability Guidelines v1.5. When a PC running DLNA server software or other DLNA compatible device is connected to this player, some setting changes of software or other devices may be required. Please refer to the operating instructions for the software or device for more information. Certain system requirements For high definition video playback: yy High definition display that has HDMI input jack. yy BD-ROM disc with high definition content. yy HDMI or HDCP capable DVI input on your display device is required for some content (as specified by disc authors). 6 yy This unit allows you to enjoy functions such as picture-in-picture, secondary audio and Virtual packages, etc., with BD-ROM supporting BONUSVIEW (BD-ROM version 2 Profile 1 version 1.1). Secondary video and audio can be played from a disc compatible with the picture-inpicture function. For the playback method, refer to the instructions in the disc. yy Viewing high-definition content and upconverting standard DVD content may require a HDMI-capable input or HDCP-capable DVI input on your display device. yy Some BD-ROM and DVD discs may restrict the use of some operation commands or features. yy You can use an USB device to store some disc related information, including downloaded online content. The disc you are using will control how long this information is retained. Appendix Appendix 69 Audio Output Specifications Jack/Setting Source HDMI OUT PCM Stereo PCM Multi-Ch DTS Re-encode *3 BitStream *1 *2 Dolby Digital PCM 2ch PCM 5.1ch DTS Dolby Digital Dolby Digital Plus PCM 2ch PCM 5.1ch DTS Dolby Digital Plus Dolby TrueHD PCM 2ch PCM 5.1ch DTS Dolby TrueHD DTS PCM 2ch PCM 5.1ch DTS DTS DTS-HD PCM 2ch PCM 5.1ch DTS DTS-HD Linear PCM 2ch PCM 2ch PCM 2ch DTS Linear PCM 2ch Linear PCM 5.1ch PCM 2ch PCM 5.1ch DTS Linear PCM 5.1ch Linear PCM 7.1ch PCM 2ch PCM 5.1ch DTS Linear PCM 7.1ch *1 The secondary and interactive audio may not be included in the output bitstream if [Digital Output] option is set to [BitStream]. (Except LPCM Codec : the output always include interactive and secondary audio.) *2 This player automatically selects the HDMI audio according to the decoding capability of the connected HDMI device even though [Digital Output] option is set to [BitStream]. yy With digital audio connection (HDMI OUT), Disc Menu button sounds of BD-ROM may not be heard if the [Digital Output] option is set to [BitStream]. yy If the audio format of the digital output does not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all. yy Multi-channel Digital Surround Sound via digital connection can only be obtained if your receiver is equipped with a Digital Multi-channel decoder. yy This setting is not available on the input signal from an external device. 6 Appendix *3 If the [Digital Output] option is set to [DTS reencode], the audio output is limited to 48 kHz and 5.1Ch. If the [Digital Output] option is set to [DTS re-encode], the DTS Re-encode audio is outputted for BD-ROM discs, and the original audio is outputted for the other discs (like [BitStream]). yy The audio is outputted as PCM 48 kHz/16 bit for MP3/WMA file and PCM 44.1kHz/16 bit for Audio CD during playback. 70 Appendix Area Code List Choose an area code from this list. AreaCode AreaCode AreaCode AreaCode 6 Appendix Afghanistan AF Fiji FJ Monaco MC Singapore SG Argentina AR Finland FI Mongolia MN Slovak Republic SK Australia AU France FR Morocco MA Slovenia Austria AT Germany DE Nepal NP South Africa ZA Belgium BE Great Britain GB Netherlands NL South Korea KR Bhutan BT Greece GR Antilles AN Spain ES Bolivia BO Greenland GL New Zealand NZ Sri Lanka LK Brazil BR Hong Kong HK Nigeria NG Sweden SE Cambodia KH Hungary HU Norway NO Switzerland CH Canada CA India IN Oman OM Taiwan TW Chile CL Indonesia ID Pakistan PK Thailand China CN Israel IL Panama PA Turkey TR Colombia CO Italy IT Paraguay PY Uganda UG Congo CG Jamaica JM Philippines PH Ukraine UA Costa Rica CR Japan JP Poland PL United States US Croatia HR Kenya KE Portugal PT Uruguay UY Czech Republic CZ Kuwait KW Romania RO Uzbekistan UZ Denmark DK Libya Ecuador EC Luxembourg EG Malaysia Vietnam RU Zimbabwe SA ZW Egypt LY Russian LU Federation MY Saudi Arabia El Salvador SV Maldives MV Senegal SN Ethiopia ET Mexico MX SI TH VN Appendix 71 Language Code List Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu]. LanguageCode LanguageCode LanguageCode LanguageCode Afar 6565 French 7082 Lithuanian 7684 Sindhi 8368 Afrikaans 6570 Frisian 7089 Macedonian 7775 Singhalese 8373 Albanian 8381 Galician 7176 Malagasy 7771 Slovak 8375 Amharic 6577 Georgian 7565 Malay 7783 Slovenian 8376 Arabic 6582 German 6869 Malayalam 7776 Spanish 6983 Armenian 7289 Greek 6976 Maori 7773 Sudanese 8385 Assamese 6583 Greenlandic 7576 Marathi 7782 Swahili 8387 Aymara 6588 Guarani 7178 Moldavian 7779 Swedish 8386 Azerbaijani 6590 Gujarati 7185 Mongolian 7778 Tagalog 8476 Bashkir 6665 Hausa 7265 Nauru7865 Tajik 8471 Basque 6985 Hebrew 7387 Nepali 7869 Tamil 8465 Bengali; Bangla 6678 Hindi 7273 Norwegian 7879 Telugu 8469 Bhutani 6890 Hungarian 7285 Oriya 7982 Thai 8472 Bihari 6672 Icelandic 7383 Panjabi 8065 Tonga 8479 Breton 6682 Indonesian 7378 Pashto, Pushto 8083 Turkish 8482 Bulgarian 6671 Interlingua 7365 Persian 7065 Turkmen 8475 Burmese 7789 Irish 7165 Polish 8076 Twi 8487 Byelorussian 6669 Italian 7384 Portuguese 8084 Ukrainian 8575 Chinese 9072 Japanese 7465 Quechua 8185 Urdu 8582 Croatian 7282 Kannada 7578 Rhaeto-Romance 8277 Uzbek 8590 6 Czech 6783 Kashmiri 7583 Rumanian 8279 Vietnamese 8673 Danish 6865 Kazakh 7575 Russian 8285 Volapük 8679 Dutch 7876 Kirghiz 7589 Samoan 8377 Welsh 6789 English 6978 Korean 7579 Sanskrit 8365 Wolof 8779 Appendix Esperanto 6979 Kurdish 7585 Scots Gaelic 7168 Xhosa 8872 Estonian 6984 Laotian 7679 Serbian 8382 Yiddish 7473 Faroese 7079 Latin 7665 Serbo-Croatian 8372 Yoruba 8979 Fiji 7074 Latvian, Lettish 7686 Shona 8378 Zulu 9085 Finnish 7073 Lingala 7678 72 Appendix Trademarks and Licenses Blu-ray Disc™, Blu-ray™, Blu-ray 3D™, BD-Live™, BONUSVIEW™ and the logos are trademarks of the Blu-ray Disc Association. 6 Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535; 7,392,195; 7,272,567; 7,333,929; 7,212,872 & other U.S. and worldwide patents issued & pending. DTS-HD, the Symbol, & DTS-HD and the Symbol together are registered trademarks & DTS-HD Master Audio | Essential is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved. “DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation. “AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation. Java is a trademark of Oracle and/or its affiliates. DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license. Appendix HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. “x.v.Color” is a trademark of Sony Corporation. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. DLNA®, the DLNA Logo and DLNA CERTIFIED® are trademarks, service marks, or certification marks of the Digital Living Network Alliance. Appendix 73 Cinavia Notice “Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone, or iPad may affect wireless performance. Bluetooth® wireless technology is a system which allows radio contact between electronic devices within a max. range of 10 meters. Connecting individual devices under Bluetooth® wireless technology does not incur any charges. A mobile phone with Bluetooth® wireless technology can be operated via the Cascade if the connection was made via Bluetooth® wireless technology. This product uses Cinavia technology to limit the use of unauthorized copies of some commerciallyproduced film and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be interrupted. More information about Cinavia technology is provided at the Cinavia Online Consumer Information Center at http://www.cinavia.com. To request additional information about Cinavia by mail, send a postcard with your mailing address to: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, USA. This product incorporates proprietary technology under license from Verance Corporation and is protected by U.S. Patent 7,369,677 and other U.S. and worldwide patents issued and pending as well as copyright and trade secret protection for certain aspects of such technology. Cinavia is a trademark of Verance Corporation. Copyright 2004-2012 Verance Corporation. All rights reserved by Verance. Reverse engineering or disassembly is prohibited. The Bluetooth® word mark and logos are owned by the Bluetooth® SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners. 6 Appendix 74 Appendix Specifications General Power requirements Refer to main label. Power consumption Refer to main label. Dimensions (W x H x D) Approx. 950 mm x 136 mm x 75 mm Net Weight (Approx.) 4.5 kg Operating temperature 5 °C to 35 °C (41 °F to 95 °F) Operating humidity 5 % to 90 % Inputs/Outputs HDMI IN/OUT (video/audio) 19 pin (Type A, HDMI™ Connector) DIGITAL IN (OPTICAL) 3 V (p-p), Optical jack x 1 PORT. IN 0.5 Vrms (3.5 mm stereo jack) x 1 Tuner FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz Amplifier Power output, (RMS), THD 10 % 6 Appendix Total 330 W Front 60 W x 2 Center 30 W x 2 Sub-Woofer 150 W Appendix 75 System Laser Semiconductor laser wavelength 405 nm / 650 nm Signal system Standard PAL/NTSC color TV system LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX Bus Power Supply (USB) DC 5 V 0 2.1 A MAX Speakers Subwoofer Type 1 Way 1 speaker Max. Input power 300 W Impedance Rated 3Ω Net Dimensions (W x H x D) 196 mm x 390 mm x 398 mm Input Power 150 W Net Weight 7.4 kg Power requirements Refer to main label. Power consumption Refer to main label. yy Design and specifications are subject to change without notice. 6 Appendix 76 Appendix Maintenance Notes on discs Handling discs Handling the unit When shipping the unit Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory. Cleaning the unit To clean the player, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit. Keeping the exterior surfaces clean yy Do not use volatile liquids such as insecticide spray near the unit. yy Wiping with strong pressure may damage the surface. yy Do not leave rubber or plastic products in contact with the unit for a long period of time. Maintaining the unit 6 Appendix The unit is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished. For details, please contact your nearest authorized service center. Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints do not get on the surface. Never stick paper or tape on the disc. Storing discs After playing, store the disc in its case. Do not expose the disc to direct sunlight or sources of heat and never leave it in a parked car exposed to direct sunlight. Cleaning discs Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the center to out. Do not use strong solvents such as alcohol, benzine, thinner, commercially available cleaners, or anti-static spray intended for older vinyl records. Appendix 77 Important Information relating to Network Services All information, data, documents, communications, downloads, files, text, images, photographs, graphics, videos, webcasts, publications, tools, resources, software, code, programs, applets, widgets, applications, products and other content (“Content”) and all services and offerings (“Services”) provided or made available by or through any third party (each a “Service Provider”) is the sole responsibility of the Service Provider from whom it originated. The availability of and access to Content and Services furnished by the Service Provider through the LGE Device are subject to change at any time, without prior notice, including, but not limited to the suspension, removal or cessation of all or any part of the Content or Services. Should you have any inquiry or problem related to the Content or Services, you may refer to the Service Provider’s website for the most up-todate information. LGE is neither responsible nor liable for customer service related to the Content and Services. Any question or request for service relating to the Content or Services should be made directly to the respective Content and Service Providers. 6 Appendix Please note that LGE is not responsible for any Content or Services provided by the Service Provider or any changes to, removal of, or cessation of such Content or Services and does not warrant or guaranty the availability of or access to such Content or Services.
