LG 255LG Owner's manual
OWNER’S MANUAL Blu-ray Disc™/DVD Player Please read this manual carefully before operating your set and retain it for future reference. BD600 / BD620 BD650 / 255LG MFL67463701_Rev 1.0 2 Getting Started Safety Information 1 CAUTION Getting Started RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. WARNING: Do not install this equipment in a confined space such as a book case or similar unit. CAUTION: Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over heating. The openings shall be never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product shall not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instruction has been adhered to. CAUTION: This product employs a Laser System. To ensure proper use of this product, please read this owner’s manual carefully and retain it for future reference. Shall the unit require maintenance, contact an authorized service centre. Use of controls, adjustments or the performance of procedures other than those specified herein may result in hazardous radiation exposure. To prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser radiation when open. DO NOT STARE INTO BEAM. CAUTION concerning the Power Cord Most appliances recommend they be placed upon a dedicated circuit; That is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner’s manual to be certain. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized service centre. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance. To disconnect power from the mains, pull out the mains cord plug. When installing the product, ensure that the plug is easily accessible. Getting Started 3 This device is equipped with a portable battery or accumulator. CAUTION: The apparatus shall not be exposed to water (dripping or splashing) and no objects filled with liquids, such as vases, shall be placed on the apparatus. 1 Getting Started Safety way to remove the battery or the battery from the equipment: Remove the old battery or battery pack, follow the steps in reverse order than the assembly. To prevent contamination of the environment and bring on possible threat to human and animal health, the old battery or the battery put it in the appropriate container at designated collection points. Do not dispose of batteries or battery together with other waste. It is recommended that you use local, free reimbursement systems batteries and accumulators. The battery shall not be exposed to excessive heat such as sunshine, fire or the like. 4 Getting Started Notes on Copyrights 1 Getting Started yy Because AACS (Advanced Access Content System) is approved as content protection system for Blu-ray Disc format, similar to use of CSS (Content Scramble System) for DVD format, certain restrictions are imposed on playback, analogue signal output, etc., of AACS protected contents. The operation of this product and restrictions on this product may vary depending on your time of purchase as those restrictions may be adopted and/or changed by AACS after the production of this product. yy Furthermore, BD-ROM Mark and BD+ are additionally used as content protection systems for Blu-ray Disc format, which imposes certain restrictions including playback restrictions for BD-ROM Mark and/or BD+ protected contents. To obtain additional information on AACS, BDROM Mark, BD+, or this product, please contact an authorized Customer Service Centre. yy Many BD-ROM/DVD discs are encoded with copy protection. Because of this, you should only connect your player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy-protected discs. yy This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Rovi, and is intended for home and other limited viewing uses only unless otherwise authorized by Rovi. Reverse engineering or disassembly is prohibited. yy Under the U.S. Copyright laws and Copyright laws of other countries, unauthorized recording, use, display, distribution, or revision of television programs, videotapes, BD-ROM discs, DVDs, CDs and other materials may subject you to civil and/ or criminal liability. Important Notice for TV colour system The colour system of this player differs according to currently playing discs. For example, when the player plays the disc recorded in the NTSC colour system, the image is output as an NTSC signal. Only the multi system colour TV can receive all signals output from the player. yy If you have a PAL colour system TV, you will see just distorted images when using discs or video contents recorded in NTSC. yy The multi system colour TV changes the colour system automatically according to input signals. In case that the colour system is not changed automatically, turn it off and then on to see normal images on screen. yy Even if the disc recorded in NTSC colour system are well displayed on your TV, these may not be recorded correctly on your recorder. Table of Contents Table of Contents 1 Getting Started 2 6 11 12 12 Safety Information Introduction Remote control Front panel Rear panel 2 Connecting 13 13 14 15 16 17 17 Connecting to Your TV – HDMI Connection – Video/Audio (Left/Right) Connection – Resolution Setting Connecting to an Amplifier USB device connection – Playback content in the USB device 3 System Setting 18 18 18 20 20 21 22 Settings – Adjust the Setup Settings – [DISPLAY] Menu – [LANGUAGE] Menu – [AUDIO] Menu – [LOCK] Menu – [OTHERS] Menu 4 Operating 23 23 23 23 24 24 24 24 25 25 25 General Playback – Using [HOME] menu – Playing a Disc – Playing a file on a disc/USB device – Basic operations for video and audio content – Basic operations for photo content – Using the disc menu – Resume playback Advanced Playback – Repeat Playback – Repeating a specific portion 25 26 26 27 27 27 28 28 28 29 29 29 30 30 30 30 31 31 – Enlarge the playback image – Marker Search – Using the search menu – Changing content list view – Viewing content information – Selecting a subtitle file – Last Scene Memory – Options while viewing a photo – Listening to music while slide show On-Screen display – Displaying content information onscreen – Playing from selected time – Hearing a different audio – Selecting a subtitle language – Watching from a different angle – Changing the TV Aspect Ratio – Changing the Picture Mode – Changing subtitle code page 5 1 2 3 4 5 Troubleshooting 32 32 33 33 33 33 Troubleshooting – General – Picture – Sound – Customer Support – Open source software notice 6 Appendix 34 35 36 37 38 39 Area Code List Language Code List Trademarks and Licenses Audio Output Specifications Specifications Maintenance 5 6 6 Getting Started Introduction 1 Playable Discs and symbols used in this manual Getting Started Media/Term Logo Symbol e Blu-ray y u i r DVD-ROM Description yy Discs such as movies that can be purchased or rented. yy BD-R/RE discs that are recorded in BDAV format. yy BD-R/RE discs that contain Movie, Music or Photo files. yy ISO 9660+JOLIET, UDF and UDF Bridge format yy Discs such as movies that can be purchased or rented. yy Video mode and finalized only yy Supports the dual layer disc also DVD-R DVD-RW DVD+R DVD+RW (8 cm / 12 cm disc) o Finalized AVCHD format y u i yy DVD±R/RW discs that contain Movie, Music or Photo files. yy ISO 9660+JOLIET, UDF and UDF Bridge format DVD-RW (VR) (8 cm / 12 cm disc) r Audio CD (8 cm / 12 cm disc) t CD-R/RW (8 cm / 12 cm disc) y u i yy CD-R/RW discs that contain Movie, Music or Photo files. , > Indicates special notes and operating features. VR mode and finalized only Note – Caution – Audio CD yy ISO 9660+JOLIET, UDF and UDF Bridge format Indicates cautions for preventing possible damages from abuse. Getting Started ,,Note yy Depending on the recording software & the finalization, some recorded discs (CD-R/RW, DVD±R/RW, BD-R/RE) may not be playable. yy BD-R/RE, DVD±R/RW and CD-R/RW discs recorded using a personal computer or a DVD or CD Recorder may not play if the disc is damaged or dirty, or if there is dirt or condensation on the player’s lens. yy If you record a disc using a personal computer, even if it is recorded in a compatible format, there are cases in which it may not play because of the settings of the application software used to create the disc. (Check with the software publisher for more detailed information.) yy This player requires discs and recordings to meet certain technical standards in order to achieve optimal playback quality. yy Pre-recorded DVDs are automatically set to these standards. There are many different types of recordable disc formats (including CD-R containing MP3 or WMA files) and these require certain pre-existing conditions to ensure compatible playback. yy Customers should note that permission is required in order to download MP3 / WMA files and music from the Internet. Our company has no right to grant such permission. Permission should always be sought from the copyright owner. yy You have to set the disc format option to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live System, you cannot use it on LG player. (Mastered/Live File System: Disc format system for windows Vista) About the “7” Symbol Display “7” may appear on your TV display during operation and indicates that the function explained in this owner’s manual is not available on that specific media. 1 Getting Started yy Depending on the conditions of the recording equipment or the CD-R/RW (or DVD±R/RW) disc itself, some CD-R/RW (or DVD±R/RW) discs cannot be played on the unit. 7 8 Getting Started File compatibility Movie files 1 Getting Started File Location File Extension Disc, USB “.divx”, “.avi”, “.mpg”, “.mpeg”, “.mkv”, “.mp4”, “.asf” Codec Format DIVX3.xx, DIVX4.xx, DIVX5.xx, DIVX6.xx (standard playback only), XVID, MPEG1 SS, H.264/MPEG-4 AVC, MPEG2 PS, MPEG2 TS Audio Format Dolby Digital, DTS, MP3, WMA, AAC, AC3 Subtitle SubRip (.srt / .txt), SAMI (.smi), SubStation Alpha (.ssa/.txt), MicroDVD (.sub/.txt), VobSub (.sub), SubViewer 1.0 (.sub), SubViewer 2.0 (.sub/.txt), TMPlayer (.txt), DVD Subtitle System (.txt) Music files File Location File Extension Sampling Frequency Disc, USB “.mp3”, “.wma”, “.wav”, “.m4a” (DRM free) within 32 - 48 kHz (WMA), within 16 - 48 kHz (MP3) Bitrate within 32 - 192 kbps (WMA), within 32 - 320 kbps (MP3) Note Some WAV files are not supported on this player. Photo files File Location Disc, USB File Extension “.jpg”, “.jpeg”, “.png” Recommended Size Note Less than 4,000 x 3,000 x 24 bit/pixel Progressive and lossless Less than 3,000 x 3,000 x 32 bit/pixel compression photo image files are not supported. Getting Started ,,Note yy The file name is limited to 180 characters. yy A “avi” file which is encoded “WMV 9 codec” is not supported. yy This unit cannot support the ID3 Tag embedded MP3 file. yy The total playback time of music file indicated on the screen may not correct for VBR files. yy HD video files contained on the CD or USB 1.0/1.1 may not play properly. Blu-ray Disc, DVD or USB 2.0 are recommended to play back HD video files. yy This player supports H.264/MPEG-4 AVC profile Main, High at Level 4.1. For a file with higher level, the warning message will appear on the screen. yy This player does not support files that are recorded with GMC*1 or Qpel*2. *1 GMC – Global Motion Compensation *2 Qpel – Quarter pixel yy This player supports UTF-8 files even it contains Unicode subtitle contents. This player can not support the pure Unicode subtitle files. yy Depending on the types of file or ways of recording, it may not play back. yy A disc which was recorded by multi-session on normal PC is not supported on this player. yy To be playback a movie file, movie file name and Subtitle file name must be the same. yy If video codec is MPEG2 TS or MPEG2 PS, subtitle does not play back. AVCHD (Advanced Video Codec High Definition) yy This player can playback AVCHD format discs. These discs are normally recorded and used in camcorders. yy The AVCHD format is a high definition digital video camera format. yy The MPEG-4 AVC/H.264 format is capable of compressing images at higher efficiency than that of the conventional image compressing format. yy This player can playback AVCHD discs using “x.v.Colour” format. yy Some AVCHD format discs may not play depending on the recording condition. yy AVCHD format discs need to be finalized. yy “x.v.Colour” offers a wider Colour range than normal DVD camcorder discs. 1 Getting Started yy Depending on the size and number of the files, it may take several minutes to read the contents on the media. 9 10 1 Getting Started Getting Started Certain System Requirements Compatibility Notes For high definition video playback: yy Because BD-ROM is a new format, certain disc, digital connection and other compatibility issues are possible. If you experience compatibility problems, please contact an authorized Customer Service Centre. yy High definition display that has HDMI input jack. yy BD-ROM disc with high definition content. yy HDMI or HDCP capable DVI input on your display device is required for some content (as specified by disc authors). For Dolby® Digital Plus, Dolby TrueHD and DTS-HD multi-channel audio playback: yy An amplifier/receiver with a built-in (Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS or DTS-HD) decoder. yy Main, centre, surround speakers and subwoofer as necessary for chosen format. About Digital Multi-channel sound A digital multi-channel connection provides the best sound quality. For this, you need a multichannel Audio/Video Receiver that supports one or more of the audio formats supported by your player. Check the logos on the front of the Audio/ Video receiver and the manual. (PCM Stereo, PCM Multi-Ch, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS and/or DTS-HD) System Select (Optional) Remove any disc that might be in the unit, open the disc tray using the B (OPEN/CLOSE) button and then,Press and hold PAUSE (M) for more than five seconds to be able to select a system (PAL / NTSC /AUTO). yy This unit allows you to enjoy functions such as picture-in-picture, secondary audio and Virtual packages, etc., with BD-ROM supporting BONUSVIEW (BD-ROM version 2 Profile 1 version 1.1). Secondary video and audio can be played from a disc compatible with the picture-inpicture function. For the playback method, refer to the instructions in the disc. yy Viewing high-definition content and upconverting standard DVD content may require a HDMI-capable input or HDCP-capable DVI input on your display device. yy Some BD-ROM and DVD discs may restrict the use of some operation commands or features. yy Dolby TrueHD, Dolby Digital Plus and DTS-HD are supported with maximum 7.1 channels if you use HDMI connection for the audio output of the unit. Regional Code This unit has a regional code printed on the rear of the unit. This unit can play only BD-ROM or DVD discs labelled same as the rear of the unit or “ALL”. Getting Started 11 Remote control • • • • • • c • • • • • • Battery Installation INFO/DISPLAY (m): Displays or exits On-Screen Display. Direction buttons: Selects an option in the menu. ENTER (b): Acknowledges menu selection. BACK (x): Exits the menu or resumes playback. The resume play function may not work depending on the BD-ROM disc. DISC MENU: Accesses menu on a disc. • • • • • • d • • • • • • ZOOM: Displays or exits the [Zoom] menu. • • • • • • a • • • • • • 1 (POWER): Switches the player ON or OFF. B (OPEN/CLOSE): Opens and closes the disc tray. TV Control Buttons: Control the sound volume, channel, sources, and power On/Off on TV. 0-9 numerical buttons: Selects numbered options in a menu. CLEAR: Removes a mark on the search menu or a number when setting the password. • • • • • • b • • • • • • c/v (SCAN): Searches backward or forward. C/V (SKIP): Goes to the next or previous chapter / track / file. M (PAUSE): Pauses playback. d (PLAY): Starts playback. Z (STOP): Stops playback. Remove the battery cover on the rear of the Remote Control, and insert R03 (size AAA) battery with 4 and 5 matched correctly. Code number to control TVs 1. While holding down 1 (TV POWER) button, and press the manufacturer code for your TV with the numerical buttons (see the table below). MARKER: Marks any point during playback. Manufacturer SEARCH: Displays or exits the search menu. Code Number LG 1(Default), 2 TITLE/POP-UP: Displays the DVD title menu or BD-ROM’s pop-up menu, if available. Zenith 1, 3, 4 GoldStar 1, 2 Colored (R, G, Y, B) buttons: Use to navigate BD-ROM menus. They are also used for [MOVIE], [PHOTO] or [MUSIC]. Samsung 6, 7 Sony 8, 9 Hitachi 4 REPEAT (h): Repeats a desired section or sequence. AUDIO ([): Selects an audio language. SUBTITLE (]): Selects a subtitle language. TV MUTE: Turn the TV’s volume on or off. 2. Release the 1 (TV POWER) button to complete setting. 1 Getting Started HOME (n): Displays or exits the [Home Menu]. 12 Getting Started Front panel 1 Getting Started a Disc Tray e N (PLAY / PAUSE) b Display Window f Z (STOP) c Remote Sensor g 1 (POWER) d B (OPEN/CLOSE) h USB Port Rear panel a AC power cord c AUDIO OUT (Left/Right) b VIDEO OUT d HDMI OUT Connecting Connecting to Your TV Make one of the following connections, depending on the capabilities of your existing equipment. yy HDMI connection (page 13) yy Video/Audio (Left/Right) Connection (page 14) 13 HDMI Connection If you have a HDMI TV or monitor, you can connect it to this player using a HDMI cable (Type A, High Speed HDMITM Cable). Connect the HDMI jack on the player to the HDMI jack on a HDMI compatible TV or monitor. ,,Note yy Depending on your TV and other equipment you wish to connect, there are various ways you could connect the player. Use only one of the connections described in this manual. Rear of the unit Connecting yy Please refer to the manuals of your TV, Stereo System or other devices as necessary to make the best connections. yy Do not connect the player’s AUDIO OUT jack to the phono in jack (record player) of your audio system. yy Do not connect your player via your VCR. The image could be distorted by the copy protection system. 2 HDMI cable TV Set the TV’s source to HDMI (refer to TV’s Owner’s manual). Additional Information for HDMI yy When you connect a HDMI or DVI compatible device make sure of the following: -- Try switching off the HDMI/DVI device and this player. Next, switch on the HDMI/DVI device and leave it for around 30 seconds, then switch on this player. -- The connected device’s video input is set correctly for this unit. -- The connected device is compatible with 720x576p, 1280x720p, 1920x1080i or 1920x1080p video input. yy Not all HDCP-compatible HDMI or DVI devices will work with this player. -- The picture will not be displayed properly with non-HDCP device. -- This player does not playback and TV screen is changed to black screen. 14 Connecting ,,Note yy If a connected HDMI device does not accept the audio output of the player, the HDMI device’s audio sound may be distorted or may not output. yy When you use HDMI connection, you can change the resolution for the HDMI output. (Refer to “Resolution Setting” on page 15.) 2 Connecting yy Select the type of video output from the HDMI OUT jack using [HDMI Color Setting] option on the [Setup] menu (see page 19). Video/Audio (Left/Right) Connection Connect the VIDEO OUT jack on the player to the video in jack on the TV using a video cable. Connect the left and right AUDIO OUT jacks of the player to the audio left and right IN jacks on the TV using the audio cables. Rear of the unit yy Changing the resolution when the connection has already been established may result in malfunctions. To solve the problem, turn off the player and then turn it on again. yy When the HDMI connection with HDCP is not verified, TV screen is changed to black screen. In this case, check the HDMI connection, or disconnect the HDMI cable. yy If there are noises or lines on the screen, please check the HDMI cable (length is generally limited to 4.5 m). What is SIMPLINK? Some functions of this unit are controlled by the TV’s remote control when this unit and LG TV’s with SIMPLINK are connected through HDMI connection. Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power Off, etc. Refer to the TV owner’s manual for the details of SIMPLINK function. LG TV’s with SIMPLINK function has the logo as shown above. ,,Note Depending on the disc type or playing status, some SIMPLINK operation may differ from your purpose or not work. Audio / Video cable TV Connecting Resolution Setting The player provides several output resolutions for HDMI OUT. You can change the resolution using [Setup] menu. 1. Press HOME (n). 2. Use a/d to select the [Setup] and press ENTER (b). The [Setup] menu appears. 3. Use w/s to select [DISPLAY] option then press d to move to the second level. 5. Use w/s to select the desired resolution then press ENTER (b) to confirm your selection. ,,Note yy If your TV does not accept the resolution you have set on the player, you can set resolution to 576p as follows: 1. Press B to open the disc tray. 2. Press Z (STOP) for more than 5 seconds. yy When you set the resolution to 576i with HDMI connection, actual resolution is outputted to 576p. yy If you select a resolution manually and then connect the HDMI jack to TV and your TV does not accept it, the resolution setting is set to [Auto]. yy If you select a resolution that your TV does not accept, the warning message will appear. After resolution change, if you cannot see the screen, please wait 20 seconds and the resolution will automatically revert back to the previous resolution. yy The 1080p video output frame rate may be automatically set to either 24 Hz or 50 Hz depending both on the capability and preference of the connected TV and based on the native video frame rate of the content on the BD-ROM disc. yy The resolution of the VIDEO OUT jack is always outputted at 576i resolution. 2 Connecting 4. Use w/s to select the [Resolution] option then press ENTER (b) to move to the third level. 15 16 Connecting Connecting to an Amplifier Make one of the following connections, depending on the capabilities of your existing equipment. yy HDMI Audio connection yy 2CH Analogue Audio connection 2 Connecting Since many factors affect the type of audio output, see “Audio Output Specifications” for details (page 37). Connect the amplifier’s HDMI output jack to HDMI input jack on your TV using a HDMI cable if your amplifier has HDMI output jack. You will need to activate the player’s digital output. (See “[AUDIO] Menu” on page 20.) Connecting to an Amplifier via 2 Channel Audio Output Connect the Left and Right AUDIO OUT jacks on the player to the audio left and right in jacks on your amplifier, receiver, or stereo system using audio cables. Connecting to an Amplifier via HDMI Output Rear of the unit Connect the player’s HDMI OUT jack to the corresponding in jack on your amplifier using a HDMI cable. Rear of the unit Audio cable HDMI cable Receiver/Amplifier HDMI cable TV Receiver/Amplifier Connecting ,,Note Playback content in the USB device yy This player supports USB flash drive/external HDD formatted in FAT16, FAT32 and NTFS when accessing files (music, photo, movie). However, for Blu-ray contents, only FAT16 and FAT32 formats are supported. Use the USB flash drive/external HDD formatted in either FAT16 or FAT32 when enjoying Blu-ray contents. 1. Insert a USB device to the USB port until it fits into place. yy The USB device can be used for the local storage for enjoying Blu-ray contents. 2 yy This unit can support up to 4 partitions of the USB device. Connecting USB device connection 17 This player can play movie, music and photo files contained in the USB device. yy Do not extract the USB device during operation (play, etc.). yy A USB device which requires additional program installation when you have connected it to a computer, is not supported. When you connect the USB device on the HOME menu, the player plays a music file contained in the USB storage device automatically. If the USB storage device is containing various types of files, a menu for the file type selection will appear. File loading may take few minutes depending on the number of content stored in the USB storage device. Press ENTER (b) while [Cancel] is selected to stop loading. yy USB device: USB device that supports USB1.1 and USB2.0. yy Movie, music and photo files can be played. For details of operations on each file, refer to relevant pages. yy Regular back up is recommended to prevent data loss. 2. Press HOME (n). yy If you use a USB extension cable, USB HUB or USB Multi-reader, the USB device may not be recognized. 3. Select [Movie], [Photo] or [Music] using a/d, and press ENTER (b). yy Some USB device may not work with this unit. 4. Select the [USB] option using w/s, and press ENTER (b). yy Digital camera and mobile phone are not supported. yy USB Port of the unit cannot be connected to PC. The unit cannot be used as a storage device. 5. Select a file using w/s/a/d, and press PLAY (d) or ENTER (b) to play the file. 6. Withdraw the USB device carefully. 18 System Setting Settings [DISPLAY] Menu TV Aspect Ratio Adjust the Setup Settings You can change the settings of the player in the [Setup] menu. 1. Press HOME (n). Select a TV aspect ratio option according to your TV type. [4:3 Letter Box] Select when a standard 4:3 TV is connected. Displays theatrical images with masking bars above and below the picture. [4:3 Pan Scan] 3 System Setting 2. Use a/d to select the [Setup] and press ENTER (b). The [Setup] menu appears. Select when a standard 4:3 TV is connected. Displays pictures cropped to fill your TV screen. Both sides of the picture are cut off. [16:9 Original] Select when a 16:9 wide TV is connected. The 4:3 picture is displayed with an original 4:3 aspect ratio, with black bars appearing at the left and right sides. [16:9 Full] 3. Use w/s to select the first setup option, and press d to move to the second level. Select when a 16:9 wide TV is connected. The 4:3 picture is adjusted horizontally (in a linear proportion) to fill the entire screen. ,,Note You cannot select [4:3 Letter Box] and [4:3 Pan Scan] option when the resolution is set to higher than 720p. 4. Use w/s to select a second setup option, and press ENTER (b) to move to the third level. 5. Use w/s to select a desired setting, and press ENTER (b) to confirm your selection. System Setting 19 Resolution HDMI Color Setting Sets the output resolution HDMI video signal. Refer to page 15 for details about the resolution setting. Select the type of output from the HDMI OUT jack. For this setting, please refer to the manuals of your display device. [Auto] If the HDMI OUT jack is connected to TVs providing display information (EDID), automatically selects the resolution best suited to the connected TV. [YCbCr] [1080p] Select when connecting to a DVI display device. Outputs 1080 lines of progressive video. [1080i] Outputs 1080 lines of interlaced video. [720p] [576p] Outputs 576 lines of progressive video. [576i] Outputs 576 lines of interlaced video. 1080p Display Mode When the resolution is set to 1080p, select [24 Hz] for smooth presentation of film material (1080p/24 Hz) with a HDMI-equipped display compatible with 1080p/24 Hz input. ,,Note yy When you select [24 Hz], you may experience some picture disturbance when the video switches video and film material. In this case, select [50 Hz]. yy Even when [1080p Display Mode] is set to [24 Hz], if your TV is not compatible with 1080p/24 Hz, the actual frame frequency of the video output will be 50 Hz to match the video source format. [RGB] Wallpaper Changes the background of the initial screen. 3 System Setting Outputs 720 lines of progressive video. Select when connecting to a HDMI display device. 20 System Setting [LANGUAGE] Menu [AUDIO] Menu Display Menu Each disc has a variety of audio output options. Set the player’s Audio options according to the type of audio system you use. Select a language for the [Setup] menu and onscreen display. Disc Menu/Disc Audio/ Disc Subtitle Select the language you prefer for the audio track (disc audio), subtitles, and the disc menu. [Original] 3 Refers to the original language in which the disc was recorded. System Setting [Other] ,,Note Since many factors affect the type of audio output, see “Audio Output Specifications” on page 37 for details. HDMI [PCM Stereo] Select if you connect this unit’s HDMI OUT jack to a device with two-channel digital stereo decoder. Press ENTER (b) to select another language. Use number buttons then press ENTER (b) to enter the corresponding 4-digit number according to the language code list on page 35. [PCM Multi-Ch] [Off] (Disc Subtitle only) [DTS Re-Encode] Turn off Subtitle. ,,Note Depending on the disc, your language setting may not work. Select if you connect this unit’s HDMI OUT jack to a device with multi-channel digital decoder. Select if you connect this unit’s HDMI OUT jack to a device with DTS decoder. [Primary Pass-Thru] Select if you connect this unit’s HDMI OUT jack to a device with LPCM, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS and DTS-HD decoder. ,,Note yy When [HDMI] option is set to [PCM MultiCh], the audio may output as PCM Stereo if the PCM Multi-Ch information is not detected from HDMI device with EDID. yy If the [HDMI] option is set to [DTS ReEncode], the DTS Re-Encode audio is outputted for BD-ROM discs with secondary audio and the original audio is outputted for the other discs (like [Primary Pass-Thru]). System Setting Sampling Freq. (Digital Audio Output) [192 kHz] Select this if your A/V Receiver or Amplifier is capable of handling 192 kHz signals. [96 kHz] Select this if your A/V Receiver or Amplifier is not capable of handling 192 kHz signals. When this choice is made, this unit automatically converts any 192 kHz signals to 96 kHz so your system can decode them. 21 [LOCK] Menu The [LOCK] settings affect only Blu-ray Disc and DVD playback. To access the any features in [LOCK] settings, you must enter the 4-digit security code you have created. If you have not entered a password yet, you are prompted to do so. Enter a 4-digit password twice, and press ENTER (b) to create a new password. Password You can create or change the password. [None] Select this if your A/V Receiver or Amplifier is not capable of handling 192 kHz and 96 kHz signal. When this choice is made, this unit automatically converts any 192 kHz and 96 kHz signals to 48 kHz so your system can decode them. Enter a 4-digit password twice, and press ENTER (b) to create a new password. [Change] Enter the current password and press ENTER (b). Enter a 4-digit password twice, and press ENTER (b) to create a new password. Check the documentation for your A/V Receiver or Amplifier to verify its capabilities. If you forget your password DRC (Dynamic Range Control) If you forget your password, you can clear it using the following steps: This function allows you to listen to a movie at a lower volume without losing clarity of sound. 1. Remove any disc that might be in the player. [Off] Turns off this function. [On] Compress the dynamic range of the Dolby Digital, Dolby Digital Plus or Dolby TrueHD audio output. [Auto] The dynamic range of the Dolby TrueHD audio output is specified by itself. And the dynamic range of the Dolby Digital and Dolby Digital Plus are operated as same as the [On] mode. ,,Note The DRC setting can be changed only when a disc is not inserted or the unit is in complete stop mode. 2. Select [Password] option in the [Setup] menu. 3. Use number buttons to enter “210499”. The password is cleared. ,,Note If you make a mistake before pressing ENTER (b), press CLEAR. Then input the correct password. DVD Rating Blocks playback of rated DVD based on their content. (Not all discs are rated.) [Rating 1-8] Rating one (1) has the most restrictions and rating eight (8) is the least restrictive. [Unlock] If you select [Unlock], parental control is not active and the disc plays in full. 3 System Setting [48 kHz] 22 System Setting Blu-ray Disc Rating Auto Power Off Set an age limit of BD-ROM play. Use number buttons to input an age limit for BD-ROM viewing. The screen saver appears when you leave the player in Stop mode for about five minutes. If you set this option to [On], the unit automatically turns itself off after the Screen Saver is displayed for 20 minutes. Set this option to [Off ] to leave the screen saver until the unit is operated by the user.  All BD-ROM can be played. [0-254] Prohibits play of BD-ROM with corresponding ratings recorded on them. ,,Note 3 The [Blu-ray Disc Rating] will be applied only for the Blu-ray Disc that containing the Advanced Rating Control. System Setting Area Code Enter the code of the area whose standards were used to rate the DVD video disc, based on the list on page 34. [OTHERS] Menu DivX® VOD ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified® device that plays DivX video. Visit divx.com for more information and software tools to convert your files into DivX videos. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx. com for more information on how to complete your registration. [Register] Displays the registration code of your player. [Deregister] Deactivate your player and display the deactivation code. ,,Note All the downloaded videos from DivX VOD with this player’s registration code can only be played back on this unit. Initialize [Factory Set] You can reset the player to its original factory settings. [Blu-ray Storage Clear] Initializes the Blu-ray contents from the connected USB storage. Software [Information] Displays the current software version. Operating 23 General Playback Using [HOME] menu The home menu appears when you press HOME (n). Use a/d to select a category and press ENTER (b). ,,Note yy Playback functions described in this manual are not always available in every file and media. Some functions can be restricted depending on many factors. yy Depending on the BD-ROM titles, a USB device connection may be needed for the proper playback. yy Unfinalized DVD-VR format discs may not be played in this player. yy Some DVD-VR discs are made with CPRM data by DVD RECORDER. This unit cannot support these kinds of discs. Playing a file on a disc/USB device yui a [Movie] - Plays video contents. d [Setup] - Adjusts the system settings. Playing a Disc ert 1. Press B (OPEN/CLOSE), and place a disc on the disc tray. 2. Press B (OPEN/CLOSE) to close the disc tray. For the most Audio CD, BD-ROM and DVD-ROM discs, playback starts automatically. 3. Press HOME (n). 4. Select [Movie] or [Music] using a/d, and press ENTER (b). 5. Select [Blu-ray Disc], [DVD], [VR] or [Audio] option using w/s, and press ENTER (b). 1. Insert a data disc on the tray or connect a USB device. ( When you insert the USB device, the USB option menu will be appeared to select for [Movie], [Photo] or [Music]. ) 2. Select [Movie], [Photo] or [Music] using a/d, and press ENTER (b). 3. Select [Data] or [USB] option using w/s, and press ENTER (b). 4. Select a file using w/s/a/d, and press d (PLAY) or ENTER (b) to play the file. 4 Operating b [Photo] - Plays photo contents. c [Music] - Plays audio contents. This player can play video, audio and photo files contained in the disc or USB device. 24 Operating Basic operations for video and audio content Basic operations for photo content To stop playback To play a slide show Press Z (STOP) while playback. Press d (PLAY) to start slide show. To pause playback To stop a slide show Press M (PAUSE) while playback. Press d (PLAY) to resume playback. Press Z (STOP) while slide show. To play frame-by-frame (Video) Press M (PAUSE) while movie playback. Press M (PAUSE) repeatedly to play Frame-by-Frame playback. To scan forward or backward Press c or v to play fast forward or fast reverse during playback. 4 To pause a slide show Press M (PAUSE) while slide show. Press d (PLAY) to re-start the slide show. To skip to the next/previous photo While viewing a photo in full screen, press a or d to go to the previous or next photo. Operating You can change the various playback speeds by pressing c or v repeatedly. Using the disc menu ero To slow down the playing speed To display the disc menu While the playback is paused, press v repeatedly to play various speeds of slow motion. The menu screen may be displayed first after loading a disc which contains a menu. If you want to display the disc menu while playback, press DISC MENU. To skip to the next/previous chapter/track/file During playback, press C or V to go to the next chapter/track/file or to return to the beginning of the current chapter/track/file. Press C twice briefly to step back to the previous chapter/track/file. Use w/s/a/d buttons to navigate through menu items. To display the Pop-up menu Some BD-ROM discs contain Pop-up menu that appears while playback. Press TITLE/POP-UP while playback, and use w/s/a/d buttons to navigate through menu items. Resume playback eroyt u The unit records the point where you pressed the Z (STOP) depending on the disc. If “MZ (Resume Stop)” appears on the screen briefly, press d (PLAY) to resume playback (from the scene point). If you press Z (STOP) twice or unload the disc, “Z(Complete Stop)” appears on the screen. The unit will clear the stopped point. Operating 25 ,,Note yy The resume point may be cleared when a button is pressed (for example; 1 (POWER), B (OPEN/CLOSE), etc). yy On BD-ROM discs with BD-J, the resume playback function does not work. yy If you press Z (STOP) once during BD-ROM interactive title playback, the unit will be in Complete Stop mode. ,,Note yy If you press V once during Repeat Chapter/Track playback, the repeat playback cancels. yy This function may not work on some disc or title. Repeating a specific portion eroty Advanced Playback This player can repeat a portion you have selected. Repeat Playback erotu y 2. Press ENTER (b) at the end of the portion. Your selected portion will be repeated continually. During playback, press REPEAT (h) repeatedly to select a desired repeat mode. jA- – Selected portion will be repeated continually. jChapter – The current chapter will be played back repeatedly. jTitle – The current title will be played back repeatedly. jAll – All the tracks or files will be played back repeatedly. 3. To return to normal playback, press REPEAT (h) repeatedly to select [Off ]. ,,Note yy You cannot select a portion less than 3 seconds. yy This function may not work on some discs or titles. Enlarge the playback image eroyi To return to normal playback, press REPEAT (h) repeatedly to select [Off ]. 1. During playback or pause mode, press ZOOM to display the [Zoom] menu. Audio CDs/Audio files 2. Use red (R) or green (G) coloured button to zoom out or in the picture. You can move through the zoomed picture using w/s/a/d buttons. kA-B – Selected portion will be repeated continually. (Audio CD only) ;Track– The current track or file will be played back repeatedly. :All – All the tracks or files will be played back repeatedly. l:All – All the tracks or files will be played back repeatedly in random order. l – The tracks or files will be played back in random order. To return to normal playback, press CLEAR. 3. To return to the normal picture size, press yellow (Y) coloured button. 4. Press BACK (x) to exit the [Zoom] menu. 4 Operating Blu-ray discs/DVDs/ MOVIE 1. While playback, press REPEAT (h) to select [A-] at the beginning of the portion you wish to repeat. 26 Operating Marker Search eroy Using the search menu eroy You can start playback from up to nine memorized points. Using search menu, you can easily to find the point where you want to start playback. To enter a marker To search a point 1. While playback, press MARKER at the desired point. The Marker icon appears on the TV screen briefly. 1. During playback, press SEARCH to display the search menu. 2. Repeat step 1 to add up to nine markers. To recall a marked scene 1. Press SEARCH and the search menu appears on the screen. 2. Press a number button to select a marker number that you want to recall. Playback starts from the marked scene. 4 To delete a Marker Operating 1. Press SEARCH and the search menu appears on the screen. 2. Press s to highlight a marker number. Use a/d to select a marked scene that you want to delete. 3. Press CLEAR and the marked scene is erased from the search menu. ,,Note yy This function may not work depending on discs, titles and file type. yy All marked points are cleared if the title is in complete stop (Z) mode, the title is changed or if you unload the disc. yy If the total length of the title is less than 10 seconds, this function is not available. 2. Press a/d to skip the playback 15 seconds forward or backward. You can select a point that you want to skip by pressing and holding a/d button. To start playback from a marked scene 1. Press SEARCH and the search menu appears on the screen. 2. Press s to highlight a marker number. Use a/d to select a marked scene that you want to start playback. 3. Press ENTER (b) to start playback from the marked scene. ,,Note This function may not work depending on discs, titles and file type. Operating 27 Changing content list view yui Viewing content information y On the [Movie], [Music] or [Photo] menu, you can change the content list view. The player can display the content information. Method 1 2. Press INFO/DISPLAY (m) to display the option menu. Press red (R) coloured button repeatedly. 1. Select a file using w/s/a/d. 3. Select the [Information] option using w/s, and press ENTER (b). The file information appears on the screen. While movie playback, you can display the file information by pressing TITLE/POP-UP. ,,Note The information displayed on the screen may not be correct compared with actual content information. If the subtitle file name is different from the movie file name, you need to select the subtitle file on the [Movie] menu before playing the movie. 1. Use w/s/a/d to select the subtitle file you wish to play in the [Movie] menu. 2. Press ENTER (b). Method 2 1. On the content list, press INFO/DISPLAY (m) to display the option menu. 2. Use w/s to select the [View Change] option. 3. Press ENTER (b) to change the content list view. Press ENTER (b) again to deselect the subtitle file. Selected subtitle file will be displayed when you play the movie file. ,,Note If you press Z (STOP) while playback, the subtitle selection is cancelled. 4 Operating Selecting a subtitle file y 28 Operating Last Scene Memory er e Rotate – Press ENTER (b) to rotate the photo clockwise. This unit memorizes the last scene from the last disc that is viewed. The last scene remains in memory even if you remove the disc from the unit or switch off the unit. If you load a disc that has the scene memorized, the scene is automatically recalled. g Effect – Use a/d to select a transition effect between photos in a slide show. ,,Note yy Last Scene Memory function for a previous disc is erased once a different disc is played. yy This function may not work depending on the disc. yy On BD-ROM discs with BD-J, the last scene memory function does not work. yy This unit does not memorize settings of a disc if you switch off the unit before commencing to play it. 4 Operating Options while viewing a photo i You can use various options during viewing a photo in full screen. 1. While viewing a photo in full screen, press INFO/ DISPLAY (m) to display the option menu. f Zoom – Press ENTER (b) to display the [Zoom] menu. h Speed – Use a/d to select a delaying speed between photos in a slide show. 3. Press BACK (x) to exit the option menu. Listening to music while slide show i You can display photo files while listening to audio files. 1. While viewing a photo in full screen, press INFO/ DISPLAY (m) to display the option menu. 2. Use w/s to select [Music Select] option, and press ENTER (b) to display the [Music Select] menu. 3. Use w/s to select a device, and press ENTER (b). 4. Use w/s to select a file or a folder you wish to play. 2. Select an option using w/s. Select g and press ENTER (b) to display the upper directory. ,,Note a Current photo/Total number of photos – Use a/d to view previous/next photo. b Slide Show – Press ENTER (b) to start or pause slide show. c Music Select – Select the background music for the slide show (page 28). d Music –Press ENTER (b) to start or pause background music. When selecting music file from a folder selection is not available. Only file selection is available. 5. Use d to select [OK], and press ENTER (b) to complete music selection. Operating 29 On-Screen display 2. Select an option using w/s. You can display and adjust various information and settings about the content. 4. Press BACK (x) to exit the On-Screen display. Displaying content information on-screen eroy 1. While playback, press INFO/DISPLAY (m) to show various playback information. 3. Use a/d to adjust the selected option value. ,,Note yy If no button is pressed for a few seconds, the on-screen display disappears. yy A title number cannot be selected on some discs. yy Available items may differ depending on discs or titles. yy If an interactive Blu-ray Disc is playing back, some setting information is displayed on the screen but prohibited to be changed. Playing from selected time eroy 2. Select the [Time] option and then input the required start time in hours, minutes, and seconds from left to right. a Title – current title number/total number of titles b Chapter – current chapter number/total number of chapters c Time – elapsed playing time/total playback time d Audio – selected audio language or channel e Subtitle – selected subtitle. f Angle – selected angle/total number of angles g TV Aspect Ratio – selected TV aspect Ratio h Picture Mode – selected picture mode For example, to find a scene at 2 hours, 10 minutes, and 20 seconds, enter “21020”. Press a/d to skip the playback 60 seconds forward or backward. 3. Press ENTER (b) to start playback from selected time. ,,Note This function may not work on some disc or titles. 4 Operating 1. Press INFO/DISPLAY (m) during playback. The time search box shows the elapsed playing time. 30 Operating Hearing a different audio eroy 1. During playback, press INFO/DISPLAY (m) to display the On-Screen display. 2. Use w/s to select the [Audio] option. 3. Use a/d to select desired audio language, audio track or audio channel. ,,Note yy During playback, you can also switch between the available audio language by pressing AUDIO([) repeatedly. yy Some discs allow you to change audio selections only via the disc menu. In this case, press TITLE/POP-UP or DISC MENU button and choose the appropriate audio from the selections on the disc menu. 4 yy Immediately after you have switched sound, there may be a temporary discrepancy between the display and actual sound. Operating yy On BD-ROM disc, the multi audio format (5.1CH or 7.1CH) is displayed with [MultiCH] in the on-screen display. Watching from a different angle er If the disc contains scenes recorded at different camera angles, you can change to a different camera angle during playback. 1. During playback, press INFO/DISPLAY (m) to display the On-Screen display. 2. Use w/s to select the [Angle] option. 3. Use a/d to select desired angle. 4. Press BACK (x) to exit the On-Screen display. Changing the TV Aspect Ratio eroy You can change the TV aspect ratio setting while playback. 1. During playback, press INFO/DISPLAY (m) to display the On-Screen display. 2. Use w/s to select the [TV Aspect Ratio] option. 3. Use a/d to select desired option. Selecting a subtitle language eroy 1. During playback, press INFO/DISPLAY (m) to display the On-Screen display. 2. Use w/s to select the [Subtitle] option. 3. Use a/d to select desired subtitle language. 4. Press BACK (x) to exit the On-Screen display. ,,Note yy During playback, you can also select a desired subtitle languge by pressing SUBTITLE(]) repeatedly. yy Some discs allow you to change subtitle selections only via the disc menu. If this is the case, press TITLE/POP-UP or DISC MENU button and choose the appropriate subtitle from the selections on the disc menu. 4. Press BACK (x) to exit the On-Screen display. ,,Note Even if you change the value of the [TV Aspect Ratio] option in On-Screen display, the [TV Aspect Ratio] option in the [Setup] menu is not changed. Operating 31 Changing the Picture Mode eroy Changing subtitle code page y You can change the [Picture mode] option while playback. If the subtitle is displayed in broken letter, you can change the subtitle code page to view the subtitle file properly. 1. During playback, press INFO/DISPLAY (m) to display the On-Screen display. 2. Use w/s to select the [Picture Mode] option. 3. Use a/d to select desired option. 4. Press BACK (x) to exit the On-Screen display. 1. During playback, press INFO/DISPLAY (m) to display the playback menu. 2. Use w/s to select the [Code Page] option. 3. Use a/d to select desired code option. Setting the [User setting] option 1. During playback, press INFO/DISPLAY (m) to display the On-Screen display. 2. Use w/s to select the [Picture Mode] option. 3. Use a/d to select the [User setting] option, and press ENTER (b). 4. Use w/s/a/d to adjust the [Picture Mode] options. Select [Default] option then press ENTER (b) to reset the all video adjustments. 5. Use w/s/a/d to select the [Close] option, and press ENTER (b) to finish setting. 4 Operating 4. Press BACK (x) to exit the On-Screen display. 32 Troubleshooting Troubleshooting General Symptom Cause & Solution The Power does not turn on. yy Plug the power cord into the wall outlet securely. The unit does not start playback. yy Insert a playable disc. (Check the disc type, colour system, and regional code.) yy Place the disc with the playback side down. yy Place the disc on the disc tray correctly inside the guide. yy Clean the disc. yy Cancel the Rating function or change the rating level. The angle cannot be changed. yy Multi-angles are not recorded on the DVD Video being played. Cannot play movie, photo or music files. yy The files are not recorded in a format that the unit can play. The remote control does not work properly. yy The remote control is not pointed at the remote sensor of the unit. yy The unit does not support the codec of the movie file. yy The remote control is too far from the unit. yy There is an obstacle in the path of the remote control and the unit. 5 yy The batteries in the remote control are exhausted. Troubleshooting The unit is plugged in, but the power will not turn on or off. The unit is not operating normally. You can reset the unit as follows. yy Unplug the power cord, wait at least five seconds, and then plug it in again. Troubleshooting 33 Picture Symptom Cause & Solution There is no picture. yy Select the appropriate video input mode on the TV so the picture from the unit appears on the TV screen. yy Connect the video connection securely. yy Check the [HDMI Color Setting] in the [Setup] menu is set to the appropriate item that conforms to your video connection. yy Your TV may not support the resolution you have set on the player. Change the resolution that your TV accepts. yy The player’s HDMI OUT jack is connected to a DVI device that does not support copyright protection. Picture noise appears. yy You are playing a disc recorded in a colour system that is different from your TV. yy Set the resolution which your TV accepts. Sound Cause & Solution There is no sound or the sound is distorted. yy Connect the audio connection securely. yy The input source setting on the amplifier or the connection to the amplifier is incorrect. yy The unit is in scan, slow motion, or pause mode. yy The sound volume is low. yy Check that the connected amplifier is compatible with audio format output from the unit. yy The unit’s HDMI OUT jack is connected to a DVI device. The DVI jack does not accept audio signal. yy Check the device connected to unit’s HDMI OUT jack is compatible with audio format output from the unit. Customer Support You can update the Player using the latest software to enhance the products operation and/or add new features. To obtain the latest software for this player (if updates have been made), please visit http://www.lg.com/global/support or contact LG Electronics customer care centre. Open source software notice To obtain the corresponding source code under GPL, LGPL and other open source licenses, please visit http://opensource.lge.com. All referred license terms, warranty disclaimers and copyright notices are available to download with the source code. 5 Troubleshooting Symptom 34 Appendix Area Code List Choose an area code from this list. Area Code Area Code Area Code Area Code Afghanistan AF Fiji FJ Monaco MC Singapore SG Argentina AR Finland FI Mongolia MN Slovak Republic SK Australia AU France FR Morocco MA Slovenia Austria AT Germany DE Nepal NP South Africa ZA Belgium BE Great Britain GB Netherlands NL South Korea KR Bhutan BT Greece GR Antilles AN Spain ES Bolivia BO Greenland GL New Zealand NZ Sri Lanka LK SI Brazil BR Hong Kong HK Nigeria NG Sweden SE Cambodia KH Hungary HU Norway NO Switzerland CH Canada CA India IN Oman OM Taiwan TW Chile CL Indonesia ID Pakistan PK Thailand China CN Israel IL Panama PA Turkey TR Colombia CO Italy IT Paraguay PY Uganda UG Congo CG Jamaica JM Philippines PH Ukraine UA Costa Rica CR Japan JP Poland PL United States US Croatia HR Kenya KE Portugal PT Uruguay UY Czech Republic CZ Kuwait KW Romania RO Uzbekistan UZ Denmark DK Libya Ecuador EC Luxembourg LY Russian LU Federation Egypt EG Malaysia 6 El Salvador SV Maldives MY Saudi Arabia MV Senegal Appendix Ethiopia ET Mexico MX Vietnam RU Zimbabwe SA SN TH VN ZW Appendix 35 Language Code List Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu]. Language Code Language Code Language Code Language Code Afar 6565 French Afrikaans 6570 Frisian 7082 Lithuanian 7684 Sindhi 8368 7089 Macedonian 7775 Singhalese Albanian 8381 8373 Galician 7176 Malagasy 7771 Slovak Ameharic 8375 6577 Georgian 7565 Malay 7783 Slovenian 8376 Arabic 6582 German 6869 Malayalam 7776 Spanish 6983 Armenian 7289 Greek 6976 Maori 7773 Sudanese 8385 Assamese 6583 Greenlandic 7576 Marathi 7782 Swahili 8387 Aymara 6588 Guarani 7178 Moldavian 7779 Swedish 8386 Azerbaijani 6590 Gujarati 7185 Mongolian 7778 Tagalog 8476 Bashkir 6665 Hausa 7265 Nauru 7865 Tajik 8471 Basque 6985 Hebrew 7387 Nepali 7869 Tamil 8465 Bengali; Bangla 6678 Hindi 7273 Norwegian 7879 Telugu 8469 Bhutani 6890 Hungarian 7285 Oriya 7982 Thai 8472 Bihari 6672 Icelandic 7383 Panjabi 8065 Tonga 8479 Breton 6682 Indonesian 7378 Pashto, Pushto 8083 Turkish 8482 Bulgarian 6671 Interlingua 7365 Persian 7065 Turkmen 8475 Burmese 7789 Irish 7165 Polish 8076 Twi 8487 Byelorussian 6669 Italian 7384 Portuguese 8084 Ukrainian 8575 8185 Urdu 8582 9072 Japanese 7465 Quechua Croatian 7282 Kannada 7578 Rhaeto-Romance 8277 Uzbek 8590 Czech 6783 Kashmiri 7583 Rumanian 8279 Vietnamese 8673 Danish 6865 Kazakh 7575 Russian 8285 Volapük 8679 Dutch 7876 Kirghiz 7589 Samoan 8377 Welsh 6789 English 6978 Korean 7579 Sanskrit 8365 Wolof 8779 6979 Kurdish 7585 Scots Gaelic 7168 Xhosa 8872 Estonian 6984 Laothian 7679 Serbian 8382 Yiddish 7473 Faroese 7079 Latin 7665 Serbo-Croatian 8372 Yoruba 8979 Fiji 7074 Latvian, Lettish 7686 Shona 8378 Zulu 9085 Finnish 7073 Lingala 7678 Esperanto 6 Appendix Chinese 36 Appendix Trademarks and Licenses Blu-ray Disc™, Blu-ray™, BONUSVIEW™ and the logos are trademarks of the Blu-ray Disc Association. Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, & DTS and the Symbol together are registered trademarks & DTS 2.0+Digital Out is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved. Java is a trademark of Oracle and/or its affiliates. “DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation. “x.v.Colour” is a trademark of Sony Corporation. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. 6 Appendix Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. “AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation. DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license. Appendix 37 Audio Output Specifications Jack/Setting HDMI OUT Analog 2CH Output PCM Stereo PCM Multi-Ch DTS Re-encode*3 Primary Pass-Thru *1 *2 Dolby Digital PCM 2ch PCM 2ch PCM 2ch DTS Dolby Digital Dolby Digital Plus PCM 2ch PCM 2ch PCM 2ch DTS Dolby Digital Plus Dolby TrueHD PCM 2ch PCM 2ch PCM 2ch DTS Dolby TrueHD AAC AAC PCM 2ch PCM 2ch PCM 2ch DTS DTS PCM 2ch PCM 2ch PCM 2ch DTS DTS DTS-HD PCM 2ch PCM 2ch PCM 2ch DTS DTS-HD Linear PCM 2ch PCM 2ch PCM 2ch PCM 2ch DTS Linear PCM 2ch Linear PCM 5.1ch PCM 2ch PCM 2ch PCM 5.1ch DTS Linear PCM 5.1ch Linear PCM 7.1ch PCM 2ch PCM 2ch PCM 7.1ch DTS Linear PCM 7.1ch Source *1 The secondary and interactive audio may not be included in the output bitstream if [HDMI] option is set to [Primary Pass-Thru]. (Except LPCM Codec : the output always includes interactive and secondary audio.) *2 This player automatically selects the HDMI audio according to the decoding capability of the connected HDMI device even though [HDMI] option is set to [Primary Pass-Thru]. *3 If the [HDMI] option is set to [DTS re-encode], the audio output is limited to 48 kHz and 5.1Ch. If the [HDMI] option is set to [DTS re-encode], the DTS Re-encode audio is outputted for BDROM discs, and the original audio is outputted for the other discs (like [Primary Pass-Thru]). yy The audio is outputted as PCM 48 kHz/16 bit for MP3/WMA file and PCM 44.1kHz/16 bit for Audio CD while playback. yy You must select an audio output and a maximum sampling frequency that your Amplifier (or AV receiver) accepts using [HDMI] and [Sampling Freq.] options on the [Setup] menu (see page 21). yy With digital audio connection (HDMI), Disc Menu button sounds of BD-ROM may not be heard if the [HDMI] option is set to [Primary Pass-Thru]. yy If the audio format of the digital output does not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all. 6 Appendix yy Multi-channel Digital Surround Sound via digital connection can only be obtained if your receiver is equipped with a Digital Multi-channel decoder. 38 Appendix Specifications General Power requirements Refer to main label on the rear panel. Power consumption 13 W Dimensions (W x H x D) Approx. 360 x 40 x 190 mm Net Weight (Approx.) 1.3 kg Operating temperature 5 °C to 35 °C Operating humidity 5 % to 90 % Outputs VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1 HDMI OUT (video/audio) 19 pin (Type A, HDMITM Connector) ANALOG AUDIO OUT 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1 System 6 Laser Semiconductor laser Wavelength 405 nm / 650 nm Signal system Standard NTSC / PAL colour TV system Frequency response 20 Hz to 20 kHz (48 kHz, 96 kHz, 192 kHz sampling) Signal-to-noise ratio More than 90 dB (ANALOG OUT connectors only) Harmonic distortion Less than 0.02% Dynamic range More than 95 dB Bus Power Supply (USB) DC 5 V 0 500 mA Appendix yy Design and specifications are subject to change without notice. Appendix 39 Maintenance Notes on Discs Handling Discs Handling the Unit When shipping the unit Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory. Cleaning the unit To clean the player, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit. Keeping the exterior surfaces clean yy Do not use volatile liquids such as insecticide spray near the unit. Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints do not get on the surface. Never stick paper or tape on the disc. Storing Discs After playing, store the disc in its case. Do not expose the disc to direct sunlight or sources of heat and never leave it in a parked car exposed to direct sunlight. Cleaning Discs Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the centre to out. Do not use strong solvents such as alcohol, benzine, thinner, commercially available cleaners, or anti-static spray intended for older vinyl records. yy Wiping with strong pressure may damage the surface. yy Do not leave rubber or plastic products in contact with the unit for a long period of time. Maintaining the Unit 6 Appendix The unit is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished. For details, please contact your nearest authorized Service Centre.
