OWNER’S MANUAL
Real Surround Blu-ray
TM
Disc /DVD Home Cinema
System
Please read this manual carefully before operating
your set and retain it for future reference.
MODEL
HB805PH (HB805PH, SH85PH-F/S/C/W)
P/NO : MFL63290033
HB805PH-D0_BGBRLL_ENG_0033.indd 1
2010-08-19
6:49:30
HB805PH-D0_BGBRLL_ENG_0033.indd 2
2010-08-19
6:49:33
3
Safety Information
1
Safety Information
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This lightning flash with arrowhead
symbol within an equilateral
triangle is intended to alert the
user to the presence of uninsulated
dangerous voltage within the
product’s enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the product.
Cautions and Warnings
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
Safety Information
CAUTION
1
WARNING: Do not install this equipment in a
confined space such as a book case or similar unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a builtin installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION: This product employs a Laser System.
To ensure proper use of this product, please read
this owner’s manual carefully and retain it for future
reference. Shall the unit require maintenance,
contact an authorized service centre.
Use of controls, adjustments or the performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try
to open the enclosure. Visible laser radiation when
open. DO NOT STARE INTO BEAM.
HB805PH-D0_BGBRLL_ENG_0033.indd 3
2010-08-19
6:49:33
4
Safety Information
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon a
dedicated circuit;
1
Safety Information
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specification page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or fire. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an exact
replacement part by an authorized service centre.
Protect the power cord from physical or mechanical
abuse, such as being twisted, kinked, pinched, closed
in a door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where the cord
exits the appliance. To disconnect power from the
mains, pull out the mains cord plug. When installing
the product, ensure that the plug is easily accessible.
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the battery
from the equipment: Remove the old battery
or battery pack, follow the steps in reverse order
than the assembly. To prevent contamination of
the environment and bring on possible threat
to human and animal health, the old battery or
the battery put it in the appropriate container at
designated collection points. Do not dispose of
batteries or battery together with other waste.
It is recommended that you use local, free
reimbursement systems batteries and accumulators.
The battery shall not be exposed to excessive heat
such as sunshine, fire or the lile.
HB805PH-D0_BGBRLL_ENG_0033.indd 4
CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects filled
with liquids, such as vases, shall be placed on the
apparatus.
Disposal of your old appliance
1. When this crossed-out wheeled bin
symbol is attached to a product it
means the product is covered by the
European Directive 2002/96/EC.
2. All electrical and electronic products
should be disposed of separately
from the municipal waste stream
via designated collection facilities
appointed by the government or the
local authorities.
3. The correct disposal of your old
appliance will help prevent potential
negative consequences for the
environment and human health.
4. For more detailed information about
disposal of your old appliance,
please contact your city office, waste
disposal service or the shop where
you purchased the product.
EEE Compliance with Directive. (for Turkey only)
LG Electronics hereby declares that this/
these product(s) is/are in compliance
with the essential requirements and
other relevant provisions of Directive
2004/108/EC, 2006/95/EC, and 2009/125/
EC.
European representative :
LG Electronics Service Europe B.V.
Veluwezoom 15, 1327 AE Almere, The
Netherlands (Tel : +31–(0)36–547–8888)
2010-08-19
6:49:33
5
Safety Information
Important Notice for TV colour system
• Because AACS (Advanced Access Content System)
is approved as content protection system for BD
format, similar to use of CSS (Content Scramble
System) for DVD format, certain restrictions are
imposed on playback, analogue signal output,
etc., of AACS protected contents. The operation of
this product and restrictions on this product may
vary depending on your time of purchase as those
restrictions may be adopted and/or changed by
AACS after the production of this product.
The colour system of this player differs according to
currently playing discs.
• Furthermore, BD-ROM Mark and BD+ are
additionally used as content protection systems
for BD format, which imposes certain restrictions
including playback restrictions for BD-ROM
Mark and/or BD+ protected contents. To obtain
additional information on AACS, BD-ROM Mark,
BD+, or this product, please contact an authorized
Customer Service Centre.
• Many BD-ROM/DVD discs are encoded with
copy protection. Because of this, you should only
connect your player directly to your TV, not to a
VCR. Connecting to a VCR results in a distorted
picture from copy-protected discs.
For example, when the player plays the disc recorded
in the NTSC colour system, the image is outputted as
a NTSC signal.
Only the multi system colour TV can receive all
signals outputted from the player.
• If you have a PAL colour system TV, you will see
just distorted images when using discs or video
contents recorded in NTSC.
• The multi system colour TV changes the colour
system automatically according to input signals.
In case that the colour system is not changed
automatically, turn it off and then on to see
normal images on screen.
1
Safety Information
Notes on Copyrights
• Even if the disc recorded in NTSC colour system
are well displayed on your TV, these may not be
recorded correctly on your recorder.
• This product incorporates copyright protection
technology that is protected by U.S. patents
and other intellectual property rights. Use of
this copyright protection technology must be
authorized by Rovi Corporation, and is intended
for home and other limited viewing uses only
unless otherwise authorized by Rovi Corporation.
Reverse engineering or disassembly is prohibited.
• Under the U.S. Copyright laws and Copyright
laws of other countries, unauthorized recording,
use, display, distribution, or revision of television
programmes, videotapes, BD-ROM discs, DVDs,
CDs and other materials may subject you to civil
and/or criminal liability.
HB805PH-D0_BGBRLL_ENG_0033.indd 5
2010-08-19
6:49:33
6
Contents
3
Installation
1
16
Assembling the speaker stand to
the speaker
17
Speaker Connection
17
Safety Information
3
Cautions and Warnings
18
19
Attaching the speakers to
the player
Positioning the system
Connecting to Your TV
19
HDMI Connection
2
20
What is SIMPLINK?
Preparation
21
Component Video
Connection
8
21
Video Connection
8
8
Introduction
About the “ ” Symbol
Display
22
23
Antenna connection
Symbols Used in this
Manual
23
Connections with external device
Resolution Setting
23
AUX Connection
24
PORT. IN connection
9
Supplied Accessories
9
Playable Discs
11
File compatibility
12
Regional Code
12
AVCHD (Advanced Video
Codec High Definition)
12
Certain System
Requirements
28
USB device connection
30
Settings
Compatibility Notes
30
12
24
25
OPTICAL IN connection
Connecting to your Home Network
25
Wired network connection
26
Wired Network Setup
Adjust the Setup Settings
13
Remote control
30
[DISPLAY] Menu
14
Front panel
32
[LANGUAGE] Menu
15
Rear panel
32
[AUDIO] Menu
34
[LOCK] Menu
35
[NETWORK] Menu
35
36
HB805PH-D0_BGBRLL_ENG_0033.indd 6
[OTHERS] Menu
Sound Effect
2010-08-19
6:49:33
7
4
6
Operation
Troubleshooting
37
66
General
37
General Playback
Playing Discs
67
38
Using the disc menu
67
Sound
39
Resume playback
68
Network
1
40
Advanced Playback
44
On-Screen display
47
Enjoying BD-LIVE
7
48
Playing a movie file and VR disc
Appendix
50
Viewing a photo
69
Controlling a TV with the Supplied
Remote Control
70
Area Code List
71
Language code List
72
Network Software Update
51
Options while viewing a
51
Listening to music while
slide show
52
Listening to music
53
Audio CD Recording
54
Displaying MP3 music
information (ID3 Tag)
55
56
Radio Operations
TM
Using NetCast
Access
Entertainment
56
YouTubeTM
60
PicasaTM Web Albums
63
Using the AccuWeather
2
72
Network update notification
72
Software Update
74
Video output resolution
75
Trademarks and Licences
77
Specifications
79
Important Information Relating to
Network Services
80
Open source software notice
3
4
5
6
8
5
Warranty
Maintenance
83
65
Notes on Discs
65
Handling the Unit
7
GUARANTEE
8
HB805PH-D0_BGBRLL_ENG_0033.indd 7
2010-08-19
6:49:33
8
Preparation
2
Preparation
2
Introduction
Preparation
About the “ ” Symbol Display
“ ” may appear on your TV display during
operation and indicates that the function
explained in this owner’s manual is not
available on that specific media.
Symbols Used in this Manual
NOTE
Indicates special notes and operating features.
A section whose title has one of the following
symbols are applicable only to the disc
represented by the symbol.
BD
BD-ROM disc
DVD
DVD-Video, DVD±R/RW in
Video mode or VR mode
and finalized
AVCHD
DVD±R/RW in AVCHD
format
ACD
Audio CDs
MOVIE
Movie files
MUSIC
Music files
Photo files
CAUTION
Indicates cautions for preventing possible
damages from abuse.
HB805PH-D0_BGBRLL_ENG_0033.indd 8
2010-08-19
6:49:33
Preparation
Supplied Accessories
9
Playable Discs
Blu-ray Disc
- Discs such as movies that can
be purchased or rented.
- BD-R/RE discs that contain
Movie, Music or Photo files.
Battery (1)
Remote control (1)
FM antenna (1)
Speaker cables (3)
DVD-VIDEO
8 / 12 cm disc
Discs such as movies that can be
purchased or rented.
DVD±R
8 / 12 cm disc
- Video mode and finalized only
- Supports the dual layer disc
also
- Finalized AVCHD format
- DVD±R discs that contain
Movie, Music or Photo files
2
Preparation
Video cable (1)
DVD-RW
8 / 12 cm disc
- VR mode, Video mode and
finalized only
- Finalized AVCHD format
- DVD-RW discs that contain
Movie, Music or Photo files.
DVD+RW
8 / 12 cm disc
- Video mode and finalized only
- AVCHD format
- Finalized AVCHD format
- DVD+RW discs that contain
Movie, Music or Photo files.
Audio CD
8 / 12 cm disc
CD-R/RW
8 / 12 cm disc
- CD-R/RW discs that contain
audio titles, Movie, Music or
Photo files.
HB805PH-D0_BGBRLL_ENG_0033.indd 9
2010-08-19
6:49:34
10
Preparation
NOTE
• Depending on the conditions of the recording
equipment or the CD-R/RW (or DVD±R/RW)
disc itself, some CD-R/RW (or DVD±R/RW) discs
cannot be played on the unit.
2
• Depending on the recording software & the
finalization, some recorded discs (CD-R/RW,
DVD±R/RW, BD-R/RE) may not be playable.
Preparation
• BD-R/RE, DVD±R/RW and CD-R/RW discs
recorded using a personal computer or a DVD or
CD Recorder may not play if the disc is damaged
or dirty, or if there is dirt or condensation on the
player’s lens.
• If you record a disc using a personal computer,
even if it is recorded in a compatible format,
there are cases in which it may not play because
of the settings of the application software used
to create the disc. (Check with the software
publisher for more detailed information.)
• This player requires discs and recordings to meet
certain technical standards in order to achieve
optimal playback quality.
• Pre-recorded DVDs are automatically set to
these standards. There are many different
types of recordable disc formats (including
CD-R containing MP3 or WMA files) and these
require certain pre-existing conditions to ensure
compatible playback.
• Customers should note that permission is
required in order to download MP3 / WMA files
and music from the Internet. Our company has
no right to grant such permission. Permission
should always be sought from the copyright
owner.
• You have to set the disc format option to
[Mastered] in order to make the discs compatible
with the LG players when formatting rewritable
discs. When setting the option to Live System,
you cannot use it on LG player. (Mastered/Live
File System : Disc format system for windows
Vista)
HB805PH-D0_BGBRLL_ENG_0033.indd 10
2010-08-19
6:49:43
Preparation
File compatibility
NOTE
Overall
• HD movie files contained on the CD or USB
1.0/1.1 may not played properly. BD, DVD or USB
2.0 are recommended to play back HD movie
files.
•
Some “.wav” files are not supported on this
player.
•
The file name is limited to 180 characters.
• This player supports H.264/MPEG-4 AVC profile
Main, High at Level 4.1. For a file with higher
level, the warning message will appear on the
screen.
•
Depending on the size and number of the
files, it may take several minutes to read the
contents on the media.
• This player does not support the files that are
recorded with GMC*1 or Qpel*2. Those are video
encoding techniques in MPEG4 standard, like
DivX or XVID have.
Maximum Files/Folder: Less than 2 000 (total
number of files and folders)
CD-R/RW, DVD±R/RW, BD-R/RE Format:
ISO 9660+JOLIET, UDF and UDF Bridge format
*1 GMC – Global Motion Compensation
*2 Qpel – Quarter pixel
• This player supports UTF-8 files even it contains
Unicode subtitle contents. This player can not
support the pure Unicode subtitle files.
• Depending on the types of file or ways of
recording, it may not play back.
• A disc which was recorded by multi-session on
normal PC is not supported on this player.
• To be playback a movie file, movie file name and
Subtitle file name must be the same.
• If video codec is MPEG2 TS or MPEG2 PS, subtitle
does not play back.
MOVIE
•
Not all the WMA and AAC Audio format is
compatible with this unit.
Sampling frequency:
within 32 kHz to 48 kHz (WMA),
within 16 kHz to 48 kHz (MP3)
Bit rate:
within 32 kbps to 192 kbps (WMA),
within 32 kbps to 320 kbps (MP3)
2
Preparation
Available File extensions:
“.jpg”, “.jpeg”, “.png”, “.avi”, “.divx”, “.mpg”, “.mpeg”,
“.mkv”, “.mp4”, “.mp3”, “.wma”, “.wav”, “.gif”
Available resolution size:
1 920 x 1 080 (W x H) pixels
Playable subtitle: SubRip (.srt / .txt), SAMI
(.smi), SubStation Alpha (.ssa/.txt), MicroDVD
(.sub/.txt), VobSub (.sub), SubViewer 1.0 (.sub),
SubViewer 2.0 (.sub/.txt), TMPlayer (.txt), DVD
Subtitle System (.txt)
Playable Codec format: “DIVX3.xx”, “DIVX4.xx”,
“DIVX5.xx”, “XVID”, “DIVX6.xx” (Standard playback
only), H.264/MPEG-4 AVC, MPEG2 PS, MPEG2 TS
Playable Audio format: “Dolby Digital”, “DTS”,
“MP3”, “WMA”, “AAC”, “AC3”
11
MUSIC
Sampling frequency:
within 32 kHz to 48 KHz (WMA),
within 11 kHz to 48 kHz (MP3)
Bit rate:
within 8 kbps to 320 kbps (WMA, MP3),
NOTE
The total playback time indicated on the screen
may not correct for VBR files.
Recommended size:
Less than 4 000 x 3 000 x 24 bit/pixel
Less than 3 000 x 3 000 x 32 bit/pixel
•
HB805PH-D0_BGBRLL_ENG_0033.indd 11
Progressive and lossless compression photo
image files are not supported.
2010-08-19
6:49:43
12
2
Preparation
Regional Code
Certain System Requirements
This unit has a regional code printed on the
rear of the unit. This unit can play only BD-ROM
or DVD discs labeled same as the rear of the
unit or “ALL”.
For high definition video playback:
AVCHD (Advanced Video Codec
High Definition)
Preparation
•
This player can playback AVCHD format
discs. These discs are normally recorded and
used in camcorders.
•
The AVCHD format is a high definition
digital video camera format.
•
The MPEG-4 AVC/H.264 format is capable
of compressing images at higher efficiency
than that of the conventional image
compressing format.
•
Some AVCHD discs use the “x.v.Colour”
format.
•
This player can playback AVCHD discs using
“x.v.Colour” format.
•
Some AVCHD format discs may not play,
depending on the recording condition.
•
AVCHD format discs need to be finalized.
•
“x.v.Colour” offers a wider colour range than
normal DVD camcorder discs.
HB805PH-D0_BGBRLL_ENG_0033.indd 12
•
High definition display that has
COMPONENT or HDMI input jacks.
•
BD-ROM disc with high definition content.
•
HDMI or HDCP capable DVI input on your
display device is required for some content
(as specified by disc authors).
•
For up-conversion of standard definition
DVD, a HDMI or HDCP capable DVI input
on your display device is required for copy
protected content.
Compatibility Notes
•
Because BD-ROM is a new format,
certain disc, digital connection and other
compatibility issues are possible. If you
experience compatibility problems, please
contact an authorized Customer Service
Centre.
•
Viewing high-definition content and upconverting standard DVD content may
require a HDMI-capable input or HDCPcapable DVI input on your display device.
•
Some BD-ROM and DVD discs may restrict
the use of some operation commands or
features.
•
You can use a USB device that is used
to store some disc related information,
including downloaded on-line content. The
disc you are using will control how long this
information is retained.
2010-08-19
6:49:43
Preparation
13
Remote control
• • • • • • •c • • • • • •
RADIO&INPUT: Changes input
mode.
SPEAKER LEVEL: Sets the sound
level of desired speaker.
MARKER: Marks any point during
playback.
SOUND EFFECT: Selects a sound
effect mode.
1 (POWER): Switches the player
ON or OFF.
VOL +/- : Adjusts speaker volume.
Z OPEN/CLOSE: Opens and
closes the disc tray.
Coloured (R, G, Y, B) buttons: Use
to navigate on menus.
INFO/DISPLAY: Displays or
exits On-Screen Display.
RDS: Radio Data System.
DISC MENU: Accesses menu on a
disc.
• • • • • • •b • • • • • •
PRESET (U/u) : Selects PROGRAMME
of Radio.
TUNING (-/+) : Tunes in the
desired radio station.
U/u/I/i (up/ down/ left/
right): Used to navigate on-screen
displays.
ENTER: Acknowledges menu
selection.
O RETURN: Exits the menu or
resumes playback.
TITLE/POPUP: Displays the DVD
title menu or BD-ROM’s pop-up
menu, if available.
x STOP: Stops playback.
B PLAY: Starts playback.
X PAUSE/STEP: Pauses playback
Remove the battery cover
on the rear of the Remote
Control, and insert two R03
(size AAA) battery with
and matched correctly.
HB805PH-D0_BGBRLL_ENG_0033.indd 13
MUTE: Mute the unit.
SEARCH: Displays or exits the
search menu.
HOME: Displays or exits the
[Home Menu].
Battery Installation
OPTICAL: Changes input mode to
optical directly.
2
Preparation
• • • • • • •a • • • • • •
PTY: Views the programme type
of the RDS.
PTY SEARCH:
Searches programme type.
MONO/STEREO: Selects mono/
stereo in FM mode.
SLEEP: Sets a certain period of
time after which the unit will
switch to off.
z REC: Records an audio CD.
ZOOM: Displays or exits the
[Zoom] menu.
0-9 numerical buttons: Selects
numbered options in a menu.
CLEAR: Removes a mark on the
search menu or a number when
setting the password.
REPEAT: Repeats a desired
section or sequence.
• • • • • • •d • • • • • •
TV Control Buttons: See page 69.
*: This button is not available.
m/M SCAN: Searches
backward or forward.
./> SKIP: Goes to the next
or previous chapter / track / file.
2010-08-19
6:49:43
14
Preparation
Front panel
1
2
3
4
5
6
2
8
6
Preparation
7
a 1/\ (POWER) Button
g PORT. IN
b Disc Tray
h USB Port
c Remote sensor
i Operation buttons
>/ıı (PLAY / PAUSE)
x (STOP)
ı<</ >>ı (SKIP), <</ >> (SCAN)
F (Function)
Changes the input source or function.
d Display window
e Volume control
f Z (OPEN/CLOSE)
1
2
7
8
HB805PH-D0_BGBRLL_ENG_0033.indd 14
3
4
5
6
9
2010-08-19
6:49:43
1
2
3
4
5
6
7
Preparation
15
Rear panel
8
9
10
1
11
2
3
4
5
6
1
2
3
4
7
5
a AC Power cord
Plug into the power source.
8
9
Preparation
2
10
6
g AUX (L/R) INPUT
h COMPONENT VIDEO (Y PB PR)
OUTPUT (PROGRESSIVE SCAN)
b Speakers connectors
i HDMI OUT (type A, Version 1.3)
Connect to TV with HDMI inputs.
c Cooling Fan
d Antenna Connector
e VIDEO OUT
7
LAN port
j
8
9
10
11
12
10
11
f OPTICAL IN
1
2
3
4
5
6
HB805PH-D0_BGBRLL_ENG_0033.indd 15
7
8
9
2010-08-19
6:49:43
16
Installation
3
Installation
Assembling the
speaker stand to the
speaker
Attach the speakers to the speaker stands by
rotateing the screws.
3
Installation
Before connecting the speakers, assemble
the speakers. Please check the items for
assembling the speakers.
Pakage contents
Speaker
Stand
HB805PH-D0_BGBRLL_ENG_0033.indd 16
2010-08-19
6:49:44
Installation
Attaching the speakers to the
player
Connect the wires hooked up to the speaker
to the unit.
To connect the cable to the unit, press each
plastic finger pad to open the connection
terminals on the unit. Insert the wire and
release the finger pad.
Connect the black end of each wire to the
terminals marked - (minus) and the other end
to the terminals marked + (plus).
colour
Speaker
Position
Grey
Rear
Rear right
Blue
Rear
Rear left
Green
Centre
Centre
Orange
Sub
woofer
Any front position
Red
Front
Front right
White
Front
Front left
HB805PH-D0_BGBRLL_ENG_0033.indd 17
CAUTION
• Be careful to make sure children not to put their
hands or any objects into the *speaker duct.
*Speaker duct: A hole for plentiful bass sound
on speaker cabinet (enclosure).
• Place the centre speaker at a safe distance from
the child’s reach.
Otherwise it may result in the speaker falling
down and causing personal injury and/or
property damage.
• The speakers contain magnet parts, so
colorirregularity may occur on the TV screen or
PC monitor screen. Please use the speakers far
away from either TV screen or PC monitor.
3
Installation
Speaker Connection
17
2010-08-19
6:49:44
18
Installation
Positioning the system
The following illustration shows an example
of positioning the system. Note that the
illustrations in these instructions differ from the
actual unit for explanation purposes.
For the best possible surround sound, all the
speakers other than the subwoofer should be
placed at the same distance from the listening
position (A).
C
A
G
Installation
F
A
A
A
A
D
A
HB805PH-D0_BGBRLL_ENG_0033.indd 18
Place the front speakers to the sides of the
monitor or screen and as flush with the screen
surface as possible.
C Centre speaker:
Place the centre speaker above or below the
monitor or screen.
D Surround left speaker (L)/
E Surround right speaker (R):
Place these speakers behind your listening
position, facing slightly inwards.
B
3
A Front left speaker (L)/
B Front right speaker (R):
E
F Subwoofer:
The position of the subwoofer is not so
critical, because low bass sounds are not
highly directional. But it is better to place
the subwoofer near the front speakers. Turn
it slightly toward the centre of the room to
reduce the wall reflections.
G Unit
2010-08-19
6:49:45
Installation
Connecting to Your TV
Make one of the following connections,
depending on the capabilities of your existing
equipment.
•
HDMI connection (pages 19-20)
•
Component Video connection (page 21)
•
Video connection (page 21)
NOTE
19
HDMI Connection
If you have a HDMI TV or monitor, you
can connect it to this player using a HDMI
cable(Type A, Version 1.3). Connect the HDMI
OUT jack on the player to the HDMI IN jack on
a HDMI compatible TV or monitor.
HDMI Connection
Player
3
• Please refer to the manuals of your TV, stereo
system or other devices as necessary to make
the best connections.
Installation
• Depending on your TV and other equipment
you wish to connect, there are various ways you
could connect the player. Use only one of the
connections described in this manual.
TV
• Make sure the player is connected directly to
the TV. Tune the TV to the correct video input
channel.
• Do not connect your player via your VCR. The
image could be distorted by the copy protection
system.
Set the TV’s source to HDMI (refer to TV’s
Owner’s manual).
HB805PH-D0_BGBRLL_ENG_0033.indd 19
2010-08-19
6:49:45
20
Installation
What is SIMPLINK?
NOTE
• Changing the resolution when the connection
has already been established may result in
malfunctions. To solve the problem, turn off the
player and then turn it on again.
• When the HDMI connection with HDCP is not
verified, TV screen is changed to black screen.
In this case, check the HDMI connection, or
disconnect the HDMI cable.
3
• If there is noise or lines on the screen, please
check the HDMI cable (length is generally
limited to 4.5 m and use a high speed HDMI
cable (version 1.3).
Installation
• If a connected HDMI device does not accept the
audio output of the player, the HDMI
device’s audio sound may be distorted or may
not output.
• When you use HDMI connection, you can
change the resolution for the HDMI output.
(Refer to “Resolution Setting” on page 22.)
• Select the type of video output from the HDMI
OUT jack using [HDMI Color Setting] option on
the [Setup] menu (see page 31).
• When you connect a HDMI or DVI compatible
device make sure of the following:
- Try switching off the HDMI/DVI device and this
player. Next, switch on the HDMI/DVI device
and leave it for around 30 seconds, then switch
on this player.
- The connected device’s video input is set
correctly for this unit.
- The connected device is compatible with
720 x 576p, 1 280 x 720p, 1 920 x 1 080i or
1 920 x 1 080p video input.
Some functions of this unit are controlled by
the TV’s remote control when this unit and LG
TV’s with SIMPLINK are connected through
HDMI connection.
Controllable functions by LG TV’s remote
control; Play, Pause, Scan, Skip, Stop, Power Off,
etc.
Refer to the TV owner’s manual for the details
of SIMPLINK function.
LG TV’s with SIMPLINK function has the logo as
shown above.
NOTE
• Depending on the disc type or playing status,
some SIMPLINK operation may differ from your
purpose or not work.
• When you use SIMPLINK function, you have
to connect to the OPTICAL IN jack to enjoy TV
sound to your speaker system.
• Not all HDCP-compatible HDMI or DVI devices
will work with this player.
- The picture will not be displayed properly with
non-HDCP device.
- This player does not playback and TV screen is
changed to black screen.
HB805PH-D0_BGBRLL_ENG_0033.indd 20
2010-08-19
6:49:45
Installation
Component Video Connection
Video Connection
Connect the COMPONENT VIDEO OUT jacks on
the player to the corresponding input jacks on
the TV using Y PB PR cables. You can hear the
sound the through the system’s speaker.
Connect the VIDEO OUT jack on the player to
the video in jack on the TV using a video cable.
You can hear the sound through the system’s
speakers.
Component Connection
Player
21
Video Connection
Player
Green
Blue
Red
Installation
3
Yellow
TV
TV
NOTE
When you use COMPONENT VIDEO OUT
connection, you can change the resolution for the
output. (Refer to “Resolution setting” on page 22.)
HB805PH-D0_BGBRLL_ENG_0033.indd 21
2010-08-19
6:49:45
22
Installation
Resolution Setting
The player provides several output resolutions
for HDMI OUT and COMPONENT VIDEO OUT
jacks. You can change the resolution using
[Setup] menu.
1. Press HOME (
).
2. Use I/i to select the [Setup] and press
ENTER ( ). The [Setup] menu appears.
NOTE
• If your TV does not accept the resolution you
have set on the player, you can set resolution to
576p as follows:
Press x for more than 5 seconds.
• Since several factors affect the resolution of
video output, see “Video Output Resolution” on
page 74.
3
Installation
3. Use U/u to select [DISPLAY] option then
press i to move to the second level.
4. Use U/u to select the [Resolution] option
then press ENTER ( ) or i to move to the
third level.
5. Use U/u to select the desired resolution
then press ENTER ( ) to confirm your
selection.
HB805PH-D0_BGBRLL_ENG_0033.indd 22
2010-08-19
6:49:45
Installation
Antenna connection
23
Connections with
external device
Connect the supplied antenna for listening to
the radio.
AUX Connection
Antenna Connection
You can enjoy the sound of your component
with the analogue audio output jacks from the
speakers of the system.
You can also use F button on the front panel to
select the input mode.
3
Installation
Connect the analogue audio output jacks of
your component into the AUX L/R (INPUT) on
this unit. And then select the [AUX] option by
pressing RADIO&INPUT and ENTER ( ).
AUX Connection
Player
Player
Player
NOTE
After connecting the FM wire antenna, keep it as
horizontal as possible. Be sure to fully extend the
FM wire antenna.
Red
White
To the audio output jacks
of your component
(TV, VCR, etc.)
HB805PH-D0_BGBRLL_ENG_0033.indd 23
2010-08-19
6:49:46
24
Installation
PORT. IN CONNECTION
You can enjoy the sound of your portable
audio player from the speakers of the system.
Connect the headphones (or line out ) jack of
the portable audio player into the PORT. IN
of this unit. And then select the [PORTABLE]
option by pressing RADIO&INPUT and ENTER
( ).
You can also use F button on the front panel to
select the input mode.
3
OPTICAL IN CONNECTION
You can enjoy the sound of your component
with the digital optical connection from the
speakers of the system.
Connect the optical output jack of your
component into the OPTICAL IN jacks on the
unit. And then select the [OPTICAL IN] option
by pressing RADIO&INPUT and ENTER
( ). Or press OPTICAL to select directly.
You can also use F button on the front panel to
select the input mode.
PORT.IN Connection
Installation
Optical Connection
To the digital
optical output jack
of your component
MP3 player, etc ...
HB805PH-D0_BGBRLL_ENG_0033.indd 24
2010-08-19
6:49:46
Installation
Connecting to your
Home Network
25
Wired Network Connection
Router
This player can be connected to a local area
network (LAN) via the LAN port on the rear
panel.
By connecting the unit to a broadband home
network, you have access to services such as
software updates, BD-LIVE interactivity and
streaming services.
Broadband
Service
WAN
LAN 1
LAN 2
PC
PC
LAN 3
3
Installation
Wired network connection
Connect the player’s LAN port to the
corresponding port on your Modem or Router
using a commercially available LAN or Ethernet
cable (CAT5 or better with RJ45 connector).
Player
NOTE
• When plugging or unplugging the LAN cable,
hold the plug portion of the cable. When
unplugging, do not pull on the LAN cable but
unplug while pressing down on the lock.
• Do not connect a modular phone cable to the
LAN port.
• Since there are various connection
configurations, please follow the specifications
of your telecommunication carrier or internet
service provider.
HB805PH-D0_BGBRLL_ENG_0033.indd 25
2010-08-19
6:49:46
26
Installation
Wired Network Setup
Before setting the wired network, you need to
connect the broadband internet to your home
network.
3. Select [OK] and press ENTER ( ) to apply
network settings.
4. The player will ask you to test the network
connection. Select [OK] and press ENTER
( ) to complete the network connection.
If there is a DHCP server on the local area
network (LAN) via wired connection, this player
will automatically be allocated an IP address.
After making the physical connection, a small
number of home networks may require the
player’s network setting to be adjusted. Adjust
the [NETWORK] setting as follow.
3
1. Select [Connection Setting] option in the
[Setup] menu then press ENTER ( ).
Installation
5. If you select [Test] and press ENTER
( ) at step 4 above, the network
connection status is displayed on the
screen.
You can also test it on the
[Connection Status] in the [Setup] menu.
2. Use U/u/I/i to select the IP mode
between [Dynamic] and [Static].
Normally, select [Dynamic] to allocate an IP
address automatically.
NOTE
If there is no DHCP server on the network and you
want to set the IP address manually, select [Static]
then set the [IP Address], [Subnet Mask], [Gateway]
and [DNS Server] using U/u/I/i and numerical
buttons. If you make a mistake while entering a
number, press CLEAR to clear the highlighted part.
HB805PH-D0_BGBRLL_ENG_0033.indd 26
2010-08-19
6:49:46
Notes on Network Connection:
•
Many network connection problems during
set up can often be fixed by re-setting the
router or modem. After connecting the
player to the home network, quickly power
off and/or disconnect the power cable of
the home network router or cable modem.
Then power on and/or connect the power
cable again.
•
Depending on the internet service provider
(ISP), the number of devices that can
receive internet service may be limited by
the applicable terms of service. For details,
contact your ISP.
•
Our company is not responsible for
any malfunction of the player and/or
the internet connection feature due to
communication errors/malfunctions
associated with your broadband internet
connection, or other connected equipment.
•
The features of BD-ROM discs made
available through the Internet Connection
feature are not created or provided
by our company, and our company is
not responsible for their functionality
or continued availability. Some disc
related material available by the Internet
Connection may not be compatible with
this player. If you have questions about such
content, please contact the producer of the
disc.
•
Some internet contents may require a
higher bandwidth connection.
•
Even if the player is properly connected and
configured, some internet contents may
not operate properly because of internet
congestion, the quality or bandwidth of
your internet service, or problems at the
provider of the content.
HB805PH-D0_BGBRLL_ENG_0033.indd 27
•
Some internet connection operations may
not be possible due to certain restrictions
set by the Internet service provider (ISP)
supplying your broadband Internet
connection.
•
Any fees charged by an ISP including,
without limitation, connection charges are
your responsibility.
•
A 10 Base-T or 100 Base-TX LAN port is
required for wired connection to this player.
If your internet service does not allow for
such a connection, you will not be able to
connect the player.
•
You must use a Router to use xDSL service.
•
A DSL modem is required to use DSL service
and a cable modem is required to use cable
modem service. Depending on the access
method of and subscriber agreement with
your ISP, you may not be able to use the
internet connection feature contained in
this player or you may be limited to the
number of devices you can connect at the
same time. (If your ISP limits subscription
to one device, this player may not be
allowed to connect when a PC is already
connected.)
•
The use of a “Router” may not be allowed
or its usage may be limited depending on
the policies and restrictions of your ISP. For
details, contact your ISP directly.
•
Turn off all unused network equipment in
your local home network. Some devices
may generate network traffic.
2010-08-19
27
3
Installation
Installation
6:49:46
28
Installation
USB device
connection
2. Select [Movie], [Photo] or [Music] using
I/i, and press ENTER ( ).
3. Select a file using U/u/I/i, and press PLAY
or ENTER ( ) to play the file.
You can check the space of the USB device
on the screen.
This player can play movie, music and photo
files contained in the USB device.
1. Insert a USB device to the USB port until it
fits into place.
USB Connection - 1
3
Installation
4. Select the other mode. And withdraw the
USB device carefully.
USB Connection - 2
When you connect the USB device on
the HOME menu, the player plays a music
file contained in the USB storage device
automatically. If the USB storage device is
containing various types of files, a menu for
the file type selection will appear.
File loading may takes few minutes depending
on the number of content stored in the USB
storage device. Press ENTER ( ) while [Cancel]
is selected to stop loading.
HB805PH-D0_BGBRLL_ENG_0033.indd 28
2010-08-19
6:49:46
Installation
29
NOTE
• This player supports USB flash memory/external
HDD formatted in FAT16, FAT32 and NTFS when
accessing files (music, photo, movie). However,
for BD-LIVE and Audio CD recording, only FAT16
and FAT32 formats are supported. Use the USB
flash memory/external HDD formatted in either
FAT16 or FAT32 when using BD-LIVE and Audio
CD recording.
• The USB device can be used for the local storage
for enjoying BD-LIVE discs with Internet.
• This unit can support up to 4 partitions of the
USB device.
3
Installation
• Do not extract the USB device during operation
(play, etc.).
• An USB device which requires additional
programme installation when you have
connected it to a computer, is not supported.
• USB device: USB device that support USB 1.1
and USB 2.0.
• Movie, music and photo files can be played.
For details of operations on each file, refer to
relevant pages.
• Regular back up is recommended to prevent
data loss.
• If you use a USB extension cable, USB HUB or
USB Multi-reader, the USB device may not be
recognised.
• Some USB device may not work with this unit.
• Digital camera and mobile phone are not
supported.
• USB Port of the unit cannot be connected to PC.
The unit cannot be used as a storage device.
HB805PH-D0_BGBRLL_ENG_0033.indd 29
2010-08-19
6:49:47
30
Installation
4. Use U/u to select a second setup option,
and press ENTER ( ) to move to the third
level.
Settings
Adjust the Setup Settings
You can change the settings of the player in
the [Setup] menu.
1. Press HOME (
).
5. Use U/u to select a desired setting, and
press i or ENTER ( ) to confirm your
selection.
3
Installation
[DISPLAY] Menu
2. Use I/i to select the [Setup] and press
ENTER ( ). The [Setup] menu appears.
TV Aspect Ratio
Select a TV aspect ratio option according to
your TV type.
[4:3 Letter Box]
Select when a standard 4:3 TV is connected.
Displays theatrical images with masking
bars above and below the picture.
3. Use U/u to select a first setup option, and
press i to move to the second level.
[4:3 Pan Scan]
Select when a standard 4:3 TV is connected.
Displays pictures cropped to fill your TV
screen. Both sides of the picture are cut off.
[16:9 Original]
Select when a 16:9 wide TV is connected.
The 4:3 picture is displayed with an original
4:3 aspect ratio, with black bars appearing
at the left and right sides.
[16:9 Full]
Select when a 16:9 wide TV is connected.
The 4:3 picture is adjusted horizontally (in a
linear proportion) to fill the entire screen.
HB805PH-D0_BGBRLL_ENG_0033.indd 30
2010-08-19
6:49:47
Installation
31
1080p Display Mode
NOTE
You cannot select [4:3 Letter Box] and [4:3 Pan
Scan] option when the resolution is set to higher
than 720p.
When the resolution is set to 1080p, select
[24 Hz] for smooth presentation of film material
(1080p/ 24 Hz) with a HDMI-equipped display
compatible with 1080p/ 24 Hz input.
NOTE
Sets the output resolution of the Component
and HDMI video signal. Refer to page 22 and
74 or details about the resolution setting.
[Auto]
If the HDMI OUT jack is connected to
TVs providing display information (EDID),
automatically selects the resolution
best suited to the connected TV. If the
COMPONENT VIDEO OUT is only connected,
this changes the resolution to 1080i as
default resolution.
[1080p]
Outputs 1080 lines of progressive video.
[1080i]
Outputs 1080 lines of interlaced video.
[720p]
Outputs 720 lines of progressive video.
[576p]
Outputs 576 lines of progressive video.
• When you select [24 Hz], you may experience
some picture disturbance when the video
switches video and film material. In this case,
select [50 Hz].
• Even when [1080p Display Mode] is set to
[24 Hz], if your TV is not compatible with
1080p/ 24 Hz, the actual frame frequency of
the video output will be 50 Hz to match the
video source format.
HDMI Color Setting
3
Installation
Resolution
Select the type of output from the HDMI
OUT jack. For this setting, please refer to the
manuals of your display device.
[YCbCr]
Select when connecting to a HDMI display
device.
[RGB]
Select when connecting to a DVI (RGB)
display device.
[576i]
Outputs 576 lines of interlaced video.
HB805PH-D0_BGBRLL_ENG_0033.indd 31
2010-08-19
6:49:47
32
Installation
[LANGUAGE] Menu
[AUDIO] Menu
Display Menu
Speaker Setup
Select a language for the [Setup] menu and
on-screen display.
To obtain the best possible sound, use the
speaker setup display to specify the volume
of the speakers you have connected and their
distance from your listening position. Use the
test to adjust the volume of the speakers to the
same level.
Disc Menu/ Disc Audio/
Disc Subtitle
Select the language you prefer for the audio
track (disc audio), subtitles, and the disc menu.
3
Installation
[Original]
Refers to the original language in which the
disc was recorded.
[Other]
Press ENTER ( ) to select another language.
Use number buttons then ENTER to
enter the corresponding 4-digit number
according to the language code list on
page 71.
[Off ] (for Disc Subtitle only)
Turn off Subtitle.
NOTE
Depending on the disc, your language setting may
not work.
[Speaker]
Select a speaker that you want to adjust.
[Volume]
Adjust the output level of each speaker.
[Distance]
Adjust the distance between each speaker
and the listening position.
[Test/ Stop test tone]
The speakers will emit a test tone.
[OK]
Confirms the setting.
[Cancel]
Cancels the setting.
HB805PH-D0_BGBRLL_ENG_0033.indd 32
2010-08-19
6:49:47
Installation
HD AV Sync
DRC (Dynamic Range Control)
Sometimes Digital TV encounters a delay
between picture and sound. If this happens
you can compensate by setting a delay on the
sound so that it effectively ‘waits’ for the picture
to arrive: this is called HD AV Sync. Use U u to
scroll up and down through the delay amount,
which you can set at anything between 0 and
300 ms.
This function allows you to listen to a movie at
a lower volume without losing clarity of sound.
[Off ]
Turns off this function.
[On]
Compress the dynamic range of the Dolby
Digital, Dolby Digital Plus or Dolby TrueHD
audio output.
HB805PH-D0_BGBRLL_ENG_0033.indd 33
3
Installation
[Auto]
The dynamic range of the Dolby TrueHD
audio output is specifi ed by itself. And the
dynamic range of the Dolby Digital and
Dolby Digital Plus are operated as same as
the [On] mode.
The delay will vary depending on which digital
TV channel you are on. If you change channel
you may need to readjust the HD AV Sync.
33
NOTE
The DRC setting can be changed only when a
disc is not inserted or the unit is in complete stop
mode.
2010-08-19
6:49:47
34
Installation
DVD Rating
[LOCK] Menu
To access the any features in [LOCK] settings,
you must enter the 4-digit security code you
have created.
If you have not entered a password yet, you are
prompted to do so. Enter a 4-digit password
twice, and press ENTER ( ) to create a new
password.
Password
You can create or change the password.
3
Installation
[None]
Enter a 4-digit password twice, and press
ENTER ( ) to create a new password.
[Change]
Enter the current password and press ENTER
( ). Enter a 4-digit password twice, and
press ENTER ( ) to create a new password.
NOTE
If you make a mistake before pressing ENTER ( ),
press CLEAR. Then input the correct password.
Blocks playback of rated DVD based on their
content. (Not all discs are rated.)
[Rating 1-8]
Rating one (1) has the most restrictions and
rating eight (8) is the least restrictive.
[Unlock]
If you select this, parental control is not
active and the disc plays in full.
BD Rating
Set an age limit of BD-ROM play. Use number
buttons to input an age limit for BD-ROM
viewing.
[255]
All BD-ROM can be played.
[0-254]
Prohibits play of BD-ROM with
corresponding ratings recorded on them.
NOTE
The [BD Rating] will be applied only for the BD disc
that containing the Advanced Rating Control.
If you forget your password,
If you forget your password, you can clear it using
the following steps:
1. Remove any disc that might be in the player.
2. Select [Lock] option in the [Setup] menu.
Area Code
Enter the code of the area whose standards
were used to rate the DVD video disc, based
on the list on page 70.
3. Use number buttons to enter “210499” on the
[Password] Menu. The password is cleared.
HB805PH-D0_BGBRLL_ENG_0033.indd 34
2010-08-19
6:49:47
Installation
The [NETWORK] settings are needed to use the
software update, BD Live and NetCast features.
Connection Setting
If your home network environment is ready
to connect the player, the player needs to
be set the network connection for network
communication. (See “Connecting to your
Home Network” on page 25.)
Connection Status
If you want to check the network status on
this player, select the [Connection Status]
options and press ENTER ( ) to check whether
a connection to the network and the internet
have been established.
BD-LIVE connection
You can restrict Internet access when BD-LIVE
functions are used.
[Permitted]
Internet access is permitted for all BD-LIVE
contents.
[OTHERS] Menu
DIVX VOD
ABOUT DIVX VIDEO: DivX® is a digital video
format created by DivX, Inc. This is an official
DivX Certified device that plays DivX video.
Visit www.divx.com for more information and
software tools to convert your files into DivX
video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certified® device must be registered in order to
play DivX Video-on-Demand (VOD) content.
To generate the registration code, locate the
DivX VOD section in the device setup menu.
Go to vod.divx.com with this code to complete
the registration process and learn more about
DivX VOD.
3
Installation
[NETWORK] Menu
35
[Register]
Displays the registration code of your player.
[Deregister]
Deactivate your player and display the
deactivation code.
NOTE
[Partially permitted]
Internet access is permitted only for BDLIVE contents which have content owner
certificates. Internet access and AACS
Online functions are prohibited for all BDLIVE contents without a certificate.
All the downloaded videos from DivX VOD with
this player’s registration code can only be played
back on this unit.
[Prohibited]
Internet access is prohibited for all BD-LIVE
contents.
HB805PH-D0_BGBRLL_ENG_0033.indd 35
2010-08-19
6:49:47
36
Installation
Auto Power Off
The screen saver appears when you leave
the player in Stop mode for about five
minutes. If you set this option to [On], the unit
automatically turns itself off after the Screen
Saver is displayed for 20 minutes.
Set this option to [Off ] to leave the screen
saver until the unit is operated by the user.
Initialize
Factory Set
You can reset the player to its original
factory settings.
3
Installation
BD Storage Clear
Initializes the BD contents from the
connected USB storage.
NOTE
If you reset the player to its original factory settings
using [Factory Set] option, you have to set all the
activation for the on-line services and network
settings again.
Software
Information
Displays the current software version.
Update
You can update the software by connecting
the unit directly to the software update
server (see page 72-73).
Disclaimer Notice
Sound Effect
You can select a suitable sound mode. Press
SOUND EFFECT repeatedly until the desired
mode appears on the front panel display or the
TV screen. The displayed items for the equalizer
maybe diff erent depending on sound sources
and effects.
[NATURAL]: You can enjoy comfortable and
natural sound.
[BYPASS]: Software with multichannel
surround audio signals is played according to
the way it was recorded.
[BASS]: Reinforce the bass sound effect from
front left and right speaker and subwoofer.
[CLRVOICE]: This mode makes voice sound
clear, improving the quality of voice sound.
[VIRTUAL]: You can enjoy more dynamic
sound with improved centre channel.
[GAME]: You can enjoy more virtual sound
while playing video games.
[NIGHT]: This may be useful when you want to
watch movies at low volumes late at night.
[RETOUCH]: When listening to MP3 files or
other compressed music, you can enhance the
sound. This mode is available only to 2 channel
sources.
[LOUNDNESS]: Improves bass and treble
sound.
[NAT PLUS]: You can enjoy the natural sound
effect same as 5.1 channel.
Press ENTER ( ) to view the notice of Network
Service Disclaimer on page 78.
HB805PH-D0_BGBRLL_ENG_0033.indd 36
2010-08-19
6:49:47
Operation
37
4
Operation
General Playback
4. Select [Movie], [Photo] or [Music] using I/
i, and press ENTER ( ).
5. Select the [Disc] option using I/i, and
press ENTER ( ).
Playing Discs
1. Press OPEN/CLOSE (Z), and place a disc on
the disc tray.
When you connect up to two devices, it
appears as above.
2. Press OPEN/CLOSE( Z) to close the disc
tray.
For the most Audio CD, BD-ROM and
DVD-ROM discs, playback starts
automatically.
3. Press HOME (
).
Operation
4
6. Select a file using U/u/I/i, and press B
(PLAY) or ENTER ( ) to play the file.
NOTE
• Playback functions described in this manual are
not always available in every files and medium.
Some functions can be restricted depending on
many factors.
• Depending on the BD-ROM titles, a USB device
connection may be needed for the proper
playback.
HB805PH-D0_BGBRLL_ENG_0033.indd 37
2010-08-19
6:49:47
38
Operation
To stop playback
Press x (STOP) while playback.
Using the disc menu
BD
DVD
AVCHD
To pause playback
To display the disc menu
Press X (PAUSE) while playback.
Press B (PLAY) to resume playback.
The menu screen may be displayed first after
loading a disc which contains a menu. If you
want to display the disc menu while playback,
press DISC MENU.
To play frame-by-frame
Press X (PAUSE) while movie playback.
Press X (PAUSE) repeatedly to play Frame-byFrame playback.
Use U/u/I/i buttons to navigate through
menu items.
To display the Pop-up menu
To scan forward or backward
Press m or M to play fast forward or fast
reverse during playback.
You can change the various playback speeds
by pressing m or M repeatedly.
4
Some BD-ROM discs contain Pop-up menu
that appears while playback.
Press TITLE/POPUP while playback, and use
U/u/I/i buttons to navigate through menu
items.
Operation
To slow down the playing speed
While the playback is paused, press M
repeatedly to play various speeds of slow
motion.
To skip to the next/previous
chapter/track/file
During playback, press . or > to go to
the next chapter/track/file or to return to the
beginning of the current chapter/track/file.
Press . twice briefly to step back to the
previous chapter/track/file.
HB805PH-D0_BGBRLL_ENG_0033.indd 38
2010-08-19
6:49:47
Operation
39
Resume playback
BD
MUSIC
DVD
AVCHD MOVIE
ACD
The unit records the point where you pressed
the x (STOP) depending on the disc.
If “Xx (Resume Stop)” appears on the screen
briefly, press B (PLAY) to resume playback
(from the scene point).
If you press x (STOP) twice or unload the disc,
“x” (Complete Stop) appears on the screen.
The unit will clear the stopped point.
NOTE
• The resume point may be cleared when a
button is pressed (for example; 1 (POWER),
Z (OPEN/CLOSE), etc).
• On BD-Video discs with BD-J, the resume
playback function does not work.
Operation
4
• If you press x (STOP) once during BD-ROM
interactive title playback, the unit will be in
Complete Stop mode .
HB805PH-D0_BGBRLL_ENG_0033.indd 39
2010-08-19
6:49:47
40
Operation
Advanced Playback
DVD
AVCHD
ACD
MUSIC
During playback, press REPEAT repeatedly to
select a desired repeat mode.
BDs/DVDs
A- – Selected portion will be repeated
continually.
Chapter – The current chapter will be
played back repeatedly.
Title – The current title will be played
back repeatedly.
4
BD
DVD
AVCHD
ACD
This player can repeat a portion you have
selected.
Repeat Playback
BD
Repeating a specific portion
To return to normal playback, press REPEAT
repeatedly to select [Off ].
Operation
Audio CDs/Music files
– The current track or file will be
played back repeatedly.
– All the tracks or files will be played
back repeatedly.
– The tracks or files will be played back
in random order.
– All the tracks or files will be
played back repeatedly in random order.
– Selected portion will be repeated
continually. (Audio CD only)
To return to normal playback, press CLEAR.
1. While playback, press REPEAT to select [A-]
at the beginning of the portion you wish to
repeat. And then press ENTER ( ).
2. Press ENTER ( ) at the end of the portion.
Your selected portion will be repeated
continually.
3. To return to normal playback, press REPEAT
repeatedly to select [OFF] or press CLEAR.
NOTE
You cannot select a portion less than 3 seconds.
Enlarge the playback image
1. During playback or pause mode, press
ZOOM to display the [Zoom] menu.
2. Use red (R) or green (G) colored button to
zoom out or in the picture.
You can move through the zoomed picture
using U/u/I/i buttons.
3. To return to the normal picture size, press
yellow (Y) colored button.
4. Press RETURN(O) to exit the [Zoom] menu.
NOTE
• If you press > once during Repeat Chapter/
Track playback, the repeat playback cancels.
• This function may not work on some disc or title.
HB805PH-D0_BGBRLL_ENG_0033.indd 40
2010-08-19
6:49:47
Operation
Marker Search
BD
DVD
AVCHD MOVIE
You can start playback from up to nine
memorized points.
41
To delete a Marker
1. Press SEARCH and the search menu appears
on the screen.
To enter a marker
1. While playback, press MARKER at the
desired point. The Marker icon appears on
the TV screen briefly.
2. Press u to highlight a marker number. Use
I/i to select a marked scene that you
want to delete.
2. Repeat step 1 to add up to nine markers.
3. Press CLEAR and the marked scene is erased
from the search menu.
To recall a marked scene
2. Press a number button to select a marker
number that you want to recall. Playback
starts from the marked scene.
NOTE
• This function may not work depending on discs,
titles, server ability.
• All marked points are cleared if the title is in
complete stop (x) mode, the title is changed or
if you unload the disc.
• If the total length of the title is less than
10 seconds, this function is not available.
HB805PH-D0_BGBRLL_ENG_0033.indd 41
2010-08-19
4
Operation
1. Press SEARCH and the search menu appears
on the screen.
6:49:48
42
Operation
Using the search menu
BD
DVD
AVCHD MOVIE
Changing content list view
MOVIE MUSIC PHOTO
Using search menu, you can easy to find the
point where you want to start playback.
On the [Movie], [Music], [Photo] menu, you can
change the content list view.
To search a point
Method 1
1. During playback, press SEARCH to display
the search menu.
Press red (R) coloured button repeatedly.
2. Press I/i to skip the playback 15 seconds
forward or backward. You can select a
point that you want to skip by pressing and
holding I/i button.
4
Operation
To start playback from a marked
scene
1. Press SEARCH and the search menu appears
on the screen.
2. Press u to highlight a marker number. Use
I/i to select a marked scene that you
want to start playback from.
3. Press ENTER ( ) to start playback from the
marked scene.
NOTE
This function may not work depending on discs,
titles, server ability.
HB805PH-D0_BGBRLL_ENG_0033.indd 42
2010-08-19
6:49:48
Operation
1. On the content list, press INFO/DISPLAY ( )
to display the option menu.
2. Use U/u to select the [View Change]
option.
3. Press ENTER ( ) to change the content list
view.
Viewing content information
MOVIE
The player can display the content information.
1. Select a file using U/u/I/i.
2. Press INFO/DISPLAY ( ) to display the
option menu.
3. Select the [Information] option using U/u,
and press ENTER ( ).
Last Scene Memory
BD
DVD
This unit memorizes the last scene from the
last disc that is viewed. The last scene remains
in memory even if you remove the disc from
the unit or switch off the unit. If you load a disc
that has the scene memorized, the scene is
automatically recalled.
NOTE
• Last Scene Memory function for a previous disc
is erased once a different disc is played.
• This function may not work depending on the
disc.
• This unit does not memorize settings of a disc if
you switch off the unit before commencing to
play it.
4
Operation
Method 2
43
The file information appears on the screen.
While movie playback, you can display the file
information by pressing TITLE/POPUP.
NOTE
The information displayed on the screen may not
correct comparing actual content information.
HB805PH-D0_BGBRLL_ENG_0033.indd 43
2010-08-19
6:49:48
44
Operation
On-Screen display
2. Select an option using U/u.
3. Use I/i to adjust the selected option
value.
You can display and adjust various information
and settings about the content.
4. Press RETURN (O) to exit the On-Screen
display.
NOTE
Displaying content information
on-screen
BD
DVD
• If no button is pressed for a few seconds, the onscreen display disappears.
• A title number cannot be selected on some
discs.
AVCHD MOVIE
1. While playback, press INFO/DISPLAY ( ) to
show various playback information.
a
• Available items may differ depending on discs
or titles.
• If BD interactive title is playing back, some
setting information is displayed on the screen
but prohibited to be changed.
b
c
4
Operation
d
e
f
g
h
a Title – Current title number/total number
of titles
b Chapter – Current chapter number/total
number of chapters
c Time – Elapsed playing time/Total
playback time
d Audio – Selected audio language or
channel
e Subtitle – Selected subtitle
f Angle – Selected angle/total number of
angles
g TV Aspect Ratio – Selected a TV aspect
Ratio
h Picture Mode – Selected picture mode
HB805PH-D0_BGBRLL_ENG_0033.indd 44
2010-08-19
6:49:48
Operation
Playing from selected time
DVD
NOTE
AVCHD MOVIE
1. Press INFO/DISPLAY ( ) during playback.
The time search box shows the elapsed
playing time.
2. Select the [Time] option and then input
the required start time in hours, minutes,
and seconds from left to right.
For example, to find a scene at 2 hours, 10
minutes, and 20 seconds, enter “21020”.
Press I/i to skip the playback 60 seconds
forward or backward.
3. Press ENTER ( ) to start playback from
selected time.
• Some discs allow you to change audio selections
only via the disc menu. If this is the case, press
TITLE/POPUP or DISC MENU button and choose
the appropriate audio from the selections on
the disc menu.
• Immediately after you have switched sound,
there may be a temporary discrepancy between
the display and actual sound.
• On BD-ROM disc, the multi audio format (5.1CH
or 7.1CH) is displayed with [MultiCH] in the onscreen display.
Selecting a subtitle language
BD
NOTE
This function may not work on some disc or titles.
DVD
AVCHD MOVIE
1. During playback, press INFO/DISPLAY ( ) to
display the on-screen display.
2. Use U/u to select the [Subtitle] option.
3. Use I/i to select desired subtitle language.
Hearing a different audio
BD
DVD
AVCHD MOVIE
1. During playback, press INFO/DISPLAY ( ) to
display the on-screen display.
2. Use U/u to select the [Audio] option.
3. Use I/i to select desired audio language,
audio track or audio channel.
HB805PH-D0_BGBRLL_ENG_0033.indd 45
4
Operation
BD
45
4. Press RETURN(O) to exit the On-Screen
display.
NOTE
Some discs allow you to change subtitle selections
only via the disc menu. If this is the case, press
TITLE/POPUP or DISC MENU button and choose
the appropriate subtitle from the selections on the
disc menu.
2010-08-19
6:49:48
46
Operation
Watching from a different
angle
BD
DVD
If the disc contains scenes recorded at different
camera angles, you can change to a different
camera angle during playback.
Changing the Picture Mode
BD
DVD
AVCHD MOVIE
You can change the [Picture mode] option
while playback.
1. During playback, press INFO/DISPLAY ( ) to
display the on-screen display.
1. During playback, press INFO/DISPLAY ( ) to
display the on-screen display.
2. Use U/u to select the [Picture Mode]
option.
2. Use U/u to select the [Angle] option.
3. Use I/i to select desired option.
3. Use I/i to select desired angle.
4. Press RETURN (O) to exit the On-Screen
display.
4. Press RETURN (O) to exit the On-Screen
display.
Setting the [User setting] option
Changing the TV Aspect Ratio
4
BD
DVD
AVCHD MOVIE
Operation
You can change the TV aspect ratio setting
while playback.
1. During playback, press INFO/DISPLAY ( ) to
display the on-screen display.
1. During playback, press INFO/DISPLAY ( ) to
display the on-screen display.
2. Use U/u to select the [Picture Mode]
option.
3. Use I/i to select the [User setting] option,
and press ENTER ( ).
2. Use U/u to select the [TV Aspect Ratio]
option.
3. Use I/i to select desired option.
4. Press RETURN (O) to exit the On-Screen
display.
NOTE
Even if you change the value of the [TV Aspect
Ratio] option in On-Screen display, the [TV Aspect
Ratio] option in the [Setup] menu is not changed.
HB805PH-D0_BGBRLL_ENG_0033.indd 46
4. Use U/u/I/i to adjust the [Picture Mode]
options.
Select [Default] option then press ENTER
( ) to reset the all adjustments.
5. Use U/u/I/i to select the [Close] options,
and press ENTER ( ) to finish setting.
2010-08-19
6:49:48
Operation
This unit allows you to enjoy functions such as
picture-in-picture, secondary audio and Virtual
packages, etc., with BD-Video supporting
BONUSVIEW (BD-ROM version 2 Profile 1
version 1.1/ Final Standard Profile).
Secondary video and audio can be played from
a disc compatible with the picture-in-picture
function. For the playback method, refer to the
instructions in the disc.
In addition to the BONUSVIEW function, BDVideo supporting BD-LIVE (BD-ROM version
2 Profile 2) that has a network extension
function allows you to enjoy more functions
such as downloading new movie trailers by
connecting this unit to the internet.
1. Check the network connection and settings
(pages 25-27).
2. Insert a USB storage device to the USB port
on the front panel.
A USB storage device is needed to
download bonus content.
3 . Press Home ( ), and set the [BD-LIVE
connection] option on the [Setup] menu
(page 35).
Depending on a disc, the BD-LIVE
function may not be operated if [BDLIVE connection] option is set to [Partially
Permitted].
4 . Insert a BD-ROM with BD-LIVE.
The operations are differ depending on the
disc. Refer to the manual supplied with the
disc.
NOTE
• Do not extract the connected USB device while
content is being downloaded or a Blu-ray disc is
still in the disc tray. Doing so may damage the
connected USB device and BD-LIVE features may
not operate properly with the damaged USB
device anymore. If the connected USB device
seems damaged from such an action, you can
format the connected USB device from the PC
and reuse it with this player.
• Some BD-LIVE contents may be restrictively
accessed in some territories by contents
provider’s own decision.
4
Operation
Enjoying BD-LIVE
47
• It may take up to several minutes to load and
start enjoying BD-LIVE contents.
USB Connection
HB805PH-D0_BGBRLL_ENG_0033.indd 47
2010-08-19
6:49:48
48
Operation
Playing a movie file
and VR disc
NOTE
• The file requirements are described on page 11.
• You can use various playback functions. Refer to
pages 37-46.
You can play DVD-RW discs that are recorded
in Video Recording (VR) format and movie files
contained in a disc or USB device.
1. Press HOME (
).
• Unfinalized DVD VR format discs may not be
played in this player.
• Some DVD-VR disc are made with CPRM data
by DVD recorder. This unit cannot support these
kinds of discs.
What is CPRM?
CPRM is a copy protection system (with
scramble system) only allowing the recording of
‘copy once’ broadcast programmes. CPRM stands
for Content Protection for Recordable Media.
4
2. Select [Movie] using I/i, and press ENTER
( ).
Operation
3. Select the device using I/i, and press
ENTER ( ).
When you connect up to two devices, it
appears as above.
4. Select a file using U/u/I/i, and press PLAY
or ENTE ( ) R to play the file.
HB805PH-D0_BGBRLL_ENG_0033.indd 48
2010-08-19
6:49:49
Operation
Selecting a subtitle file
Changing subtitle code page
MOVIE
MOVIE
If a movie file name and the subtitle file
name are the same, subtitle file is played
automatically when playing the movie file.
If the subtitle is not displayed properly, you
can change the subtitle code page to view the
subtitle file properly.
If the subtitle file name is different with the
movie file name, you need to select the subtitle
file on the [Movie] menu before playing the
movie.
1. During playback, press INFO/DISPLAY ( ) to
display the on-screen display.
1. Use U/u/I/i to select the subtitle file you
wish to play in the [Movie] menu.
49
2. Use U/u to select the [Code Page] option.
3. Use I/i to select desired code option.
2. Press ENTER ( ).
Press ENTER ( ) again to deselect the
subtitle file. Selected subtitle file will be
displayed when you play the movie file.
Operation
4
4. Press RETURN (O) to exit the On-Screen
display.
NOTE
If you press x (STOP) while playback, the subtitle
selection is cancelled.
HB805PH-D0_BGBRLL_ENG_0033.indd 49
2010-08-19
6:49:49
50
Operation
Viewing a photo
You can view photo files using this player.
1. Press HOME (
To play a slide show
Press B (PLAY) to start slide show.
To stop a slide show
Press x (STOP) while slide show.
).
To pause a slide show
Press X (PAUSE) while slide show.
Press B (PLAY) to re-start the slide show.
To skip to the next/previous photo
2. Select [Photo] using I/i, and press ENTER
( ).
4
3. Select the device using I/i, and press
ENTER ( ).
While viewing a photo in full screen, press
I or i to go to the previous or next photo.
NOTE
• The file requirements are described on page 11.
Operation
• You can use various playback functions. Refer to
pages 37-46.
When you connect up to two devices, it
appears as above.
4. Select a file using U/u/I/i, and press
ENTER ( ) to view the photo.
HB805PH-D0_BGBRLL_ENG_0033.indd 50
2010-08-19
6:49:49
Operation
Options while viewing a photo
You can use various options during viewing a
photo in full screen.
1. While viewing a photo in full screen, press
INFO/DISPLAY ( ) to display the option
menu.
51
Listening to music while slide
show
You can display photo files while listening to
music files.
1. Press HOME (
).
2. Select an option using U/u.
a
b
c
d
e
f
g
h
2. Select [Photo] using I/i, and press ENTER
( ).
3. Select the [Disc] or [USB] option using I/i,
and press ENTER ( ).
4
Operation
a Current photo/Total number of photos
– Use I/i to view previous/next photo.
b Slide Show – Press ENTER ( ) to start or
pause slide show.
c Music Select – Select the background
music for the slide show.
d Music –Press ENTER ( ) to start or pause
background music.
4. Select a file using U/u/I/i, and press
ENTER ( ) to view the photo.
e Rotate – Press ENTER ( ) to rotate the
photo clockwise.
5. Press INFO/DISPLAY ( ) to display the
option menu.
f Zoom – Press ENTER ( ) to display the
[Zoom] menu.
6. Use U/u to select [Music Select] option,
and press ENTER ( ) to display the [Music
Select] menu.
g Effect – Use I/i to select a transition
effect between photos in a slide show.
h Speed – Use I/i to select a delaying
speed between photos in a slide show.
3. Press RETURN (O) to exit the option menu.
HB805PH-D0_BGBRLL_ENG_0033.indd 51
2010-08-19
6:49:50
52
Operation
7. Use U/u to select a device, and press ENTER
( ).
Device that you can select are differ
depending on the location of the photo file
you are displaying in full screen.
Photo location
Available Device
Disc
Disc, USB
Listening to music
The player can play Audio CDs and music files
1. Press HOME (
).
USB
Disc, USB
8. Use U/u to select a file or a folder you wish
to play.
2. Select [Music] using I/i, and press ENTER
( ).
3. Select the device using I/i, and press
ENTER ( ).
4
Operation
Select a folder and press ENTER ( ) to
display the lower directory.
Select and press ENTER ( ) to display
the upper directory.
9. Use i to select [OK], and press ENTER ( )
to complete music selection.
When you connect up to two devices, it
appears as above.
4. Select a music file or audio track using
U/u/I/i, and press ENTER ( ) to play the
music.
NOTE
• The file requirements are described on page 11.
• You can use various playback functions. Refer to
pages 37-46.
HB805PH-D0_BGBRLL_ENG_0033.indd 52
2010-08-19
6:49:50
Operation
53
Audio CD Recording
You can record one desired track or all of the
tracks in Audio CD to a USB storage device.
1. Insert a USB storage device to the USB port
on the front panel.
Press Z (OPEN/CLOSE) to close the disc
tray. The playback starts automatically.
3. Press INFO/DISPLAY ( ) to display the
option menu.
Or
Press z REC button on the remote control.
You can record all musics in the audio CD.
4. Use U/u to select [CD Recording] option,
and press ENTER ( ) to display the [CD
Recording] menu.
Repeat this step to select tracks as many as
you can.
If you want to create a new folder, use
U/u/I/i to select [New Folder] and press
ENTER ( ).
Enter a folder name using virtual keyboard,
and press ENTER ( ) while [OK] is selected.
8. Use U/u/I/i to select [OK], and press
ENTER ( ) to start Audio CD recording.
If you want to stop in progressing Audio CD
recording, press ENTER ( ) while [Cancel] is
highlighted.
9. A message appears when Audio CD
recording is completed. Press ENTER
( ) to check the music file created in the
destination folder.
5. Use U/u to select a track you wish to copy
on the menu, and press ENTER ( ).
4
Operation
2. Press Z (OPEN/CLOSE), and place an Audio
CD on the disc tray.
Repeat this step to select tracks as many as
you can.
Select all the tracks on an Audio
CD.
Selects an encoding option from
the pop-up menu (128 kbps,
192 kbps, 320 kbps or Lossless).
Cancels the recording and
returns to the previous screen.
6. Use U/u/I/i to select [Start], and press
ENTER ( ).
7. Use U/u/I/i to select the destination
folder to be copied.
HB805PH-D0_BGBRLL_ENG_0033.indd 53
2010-08-19
6:49:50
54
Operation
Displaying MP3 music
information (ID3 Tag)
NOTE
• The table below shows the average recording
time from an audio track with 4 minutes of
playback time to a music file with 192 kbps as an
example.
stop mode
while playback
1 min.
4 min.
• All times in the above table are approximate.
• Actual recording time for USB storage device
varies depending on the USB storage device’s
ability.
1. Select a music file using U/u/I/i
2. Press INFO/DISPLAY ( ) to display the
option menu.
3. Select [Information] option using U/u, and
press ENTER ( ).
4. The music information will be displayed on
the screen.
• Make sure that there is minimum of 50 MB free
space is needed when recording into the USB
storage device.
• The length of the music should be longer than
20 seconds for the proper recording.
4
Operation
• Do not turn off this player or extract the
connected USB storage device during Audio CD
recording.
NOTE
The making of unauthorized copies of
copy-protected material, including computer
programmes, files, broadcasts and sound
recordings, may be an infringement of copyrights
and constitute a criminal offense.
This equipment should not be used
for such purposes.
Be responsible
Respect copyrights
HB805PH-D0_BGBRLL_ENG_0033.indd 54
Depending on the MP3 files, information may not
be displayed on the screen.
2010-08-19
6:49:50
Operation
Radio Operations
55
Deleting all the saved stations
Press and hold CLEAR for two seconds.
“ERASE ALL” will flash up. Then all the saved
stations are deleted.
Deleting a saved station
Listening to the radio
1. Press PRESET - / + to Select a preset number
you want to delete.
1. Press RADIO&INPUT until TUNER (FM)
appears in the display window. The last
received station is tuned in.
2. Press CLEAR, the preset number will blink in
the display window.
2. Press and hold TUNING (-/+) for about two
seconds until the frequency indication
starts to change. Scanning stops when the
unit tunes in a station. Or Press TUNING (-/+)
repeatedly.
3. Adjust the volume by rotating VOLUME on
the front panel or by pressing VOL (+/- ) on
the remote control.
Presetting the Radio Stations
You can preset 50 stations for FM.
Before tuning, make sure that you have turned
down the volume.
1. Press RADIO&INPUT until the TUNER (FM)
appears in the display window.
2. Select the desired frequency by using
TUNING (-/+).
3. Press ENTER ( ) a preset number will flash
in the display window.
4. Press PRESET (-/+) to select the preset
number you want.
5. Press ENTER ( ). The station is stored.
3. Press CLEAR again, to delete the selectd
preset number.
Improving poor FM reception
Press B (blue) (MONO/STEREO) coloured
button on the remote control. This will change
the tuner from stereo to mono and usually
improve the reception.
See information about a radio
station
The FM tuner is supplied with the RDS (Radio
Data System) facility. This shows information
about the radio station being listened to. Press
RDS repeatedly to cycle through the various
data types:
PS
(Programme Service Name)
The name of the channel will appear in
the display
PTY
(Programme Type Recognition)
The programme type (e.g. Jazz or News)
will appear in the display.
RT
(Radio Text)
A text message contains special
information from the broadcast station.
This text may scroll across the display.
CT
(Time controlled by the channel)
This shows the time and date as broadcast
by the station.
6. Repeat the steps 2 to 5 to store other
stations.
HB805PH-D0_BGBRLL_ENG_0033.indd 55
4
Operation
Be sure that the antenna is connected.
(Refer to the page 23)
2010-08-19
6:49:51
56
Operation
Using NetCastTM
Entertainment Access
YouTubeTM
You can use various content services via
Internet with NetCast Entertainment Access
feature.
You can browse, search and watch YouTubeTM
videos over the internet to your TV via your LG
Blu-ray disc player.
1. Check the network connection and settings
(pages 25-27).
Watch YouTubeTM videos on your TV
2. Press HOME (
).
3. Select the [NetCast] using I/i, and press
ENTER ( ).
4. Select an option using I/i, and press
ENTER ( ).
4
YouTubeTM – See pages 56-59
Operation
PicasaTM Web Albums – See pages 60-62
1. On the player, select the [YouTubeTM] option
in the [NetCast] menu using I/i, and press
ENTER ( ).
2. Press U to select the option menu bar.
3. Use I/i to select an option and press
ENTER ( ) to search videos.
4. Use I/i to select a video and press ENTER
( ) or B (play) to play the video.
AccuWeather – See pages 63-64
5. While enjoying on-line content from
NetCast, press blue (B) coloured button to
go to NetCast Home screen.
NOTE
• The content of NetCast services and service
related information, including user interface, is
subject to changes. Please refer to the web site
of each service for most up-to-date information.
• The background image on the NetCast home
indicates the weather of your favorite city in the
AccuWeather feature.
HB805PH-D0_BGBRLL_ENG_0033.indd 56
Button
Operation
B or ENTER Starts playback the video with
content detail.
INFO/
DISPLAY
Toggle between playback in
full screen and playback screen
with content detail.
X
To pause a video while it is
playing. To resume playing a
paused video, press B again.
x
Stops the video and displays
related videos list.
./>
Skip the playback forward or
backward .
2010-08-19
6:49:51
Operation
57
About the YouTubeTM menu
NOTE
• The YouTubeTM menu can display 5 videos in the
videos list. Press green (G) or yellow (Y) buttons
to display previous/next 5 videos.
Recent Videos – The most recently updated
videos list will be displayed.
• If you select the [Most Viewed] or [Top Rated]
option in the YouTubeTM menu, the period
options appear at the bottom of the screen.
Use U/u/I/i to select a period option and
press ENTER ( ) to display the videos list within
the selected period.
Most Viewed – The most viewed videos list
will be displayed. The period option appears
at the bottom of the screen.
• The videos list searched from the player may
differ with the list searched from a web browser
on PC.
Top Rated – The best rated videos list from
YouTubeTM server will be displayed. The period
option appears at the bottom of the screen.
• The playback of YouTubeTM videos may be
paused, stopped or buffering occurring often
depending on your broadband speed.
We recommend a minimum connection speed
of 1.5 Mbps. For the best playback condition, a
connection speed of 4.0 Mbps is required.
Sometimes your broadband speed varies based
on your ISP’s network conditions.
Contact your ISP if you have problems
maintaining a fast connection that is reliable, or
if you want to increase your connection speed.
Many ISPs offer a variety of broadband speed
options.
Featured – The featured videos list will be
displayed.
Search – The virtual keyboard will be
displayed. See “Searching videos” on page 59
for more detail.
History – The videos list that you previously
played on this unit will be displayed.
Maximum of 25 videos can be stored.
Favorites – This option will be appeared only
when the unit is in sign-in status. Displays the
videos list that is arranged in the YouTubeTM
server with your account. Some videos may
not appear on the [Favorites] list, even if the
videos are arranged in the server.
4
Operation
There are various options on the YouTubeTM
menu. Use U/u/I/i to select an option
and press ENTER ( ) to select the options as
described below.
Sign in (Sign Out) – Displays the virtual
keyboard to sign in or returns to the sign-out
status.
See “Sign in with your YouTubeTM account” on
page 59 for more details.
Local site – Choose which country’s videos
you would like to view. The countries listed on
the [Local Site] menu may different with those
listed on the YouTubeTM web site.
HB805PH-D0_BGBRLL_ENG_0033.indd 57
2010-08-19
6:49:51
58
Operation
Using the virtual keyboard
Keypad Mode
On the virtual keyboard, there are two input
mode for the entering a character. Press the
yellow (Y) coloured button to toggle display
between keyboard mode and keypad mode.
This mode allows you to enter letters by
pressing the buttons on the remote control.
Press the buttons with the required letter once,
twice, three or four times until the letter is
displayed.
Keyboard Mode
Use U/u/I/i to select a letter on the screen,
and press ENTER ( ) to confirm your selection.
Button
Operation
CLEAR
Deletes the previous character
at the cursor position.
[Space] – Inserts a space at the cursor
position.
REPEAT
Inserts a space at the cursor
position.
[Backspace] – Deletes the previous character
at the cursor position.
M/.
Change the character set of
the remote control (#+-=&,
123, ABC or abc)
[Cancel] – Return to the previous screen.
4
Operation
[ABC / abc / #+-=&] – Changes the virtual
keyboard settings to capital letters, small
letters or symbols.
Press CLEAR to clear all entered characters.
To enter a letter with an accent mark:
NOTE
The keypad mode is available only in the
[YouTubeTM] and [PicasaTM Web Albums] features.
1. Select a letter using U/u/I/i on the virtual
key board.
2. Press INFO/DISPLAY ( ) to display the
extended character set.
3. Use I/i to select a character then press
ENTER ( ).
Available languages to enter on the keyboard
mode are as follows: English, Spanish, Italian,
French, German, Dutch, Portuguese, Swedish,
Polish and Czech.
HB805PH-D0_BGBRLL_ENG_0033.indd 58
2010-08-19
6:49:51
Operation
You can search for videos by entering search
words of up to 128 characters.
3. When you finish entering the user name
and the password, select [OK] and press
ENTER ( ) to sign in.
1. Use I/i to select [Search] option from the
menu and press ENTER ( ) to display the
virtual keyboard.
4. If you want to sign out, select the [Sign Out]
from the YouTubeTM menu and press ENTER
( ).
Searching videos
Refer to “Using the virtual keyboard” on
page 58 for using virtual keyboard.
59
This unit can automatically store up to 5 user
names which were previously signed-in. The
user name list appears when you select the
[Sign In] option.
Select a stored user name on the list and press
ENTER ( ) to display the keyboard menu with
the selected user name is entered. You will
then only need to enter the password to sign
in.
When you entering a character, maximum
of 5 suggestion words will be displayed.
4
Sign in with your YouTubeTM account
To watch videos from your [Favorites] video
list on the YouTubeTM server with your account,
you need to sign in with your YouTubeTM
account.
Operation
2. When you finish entering the search words,
select [OK] and press ENTER ( ) to display
the related video list.
Select the [X] symbol and press ENTER ( ) to
delete the stored user name.
1. Use I/i to select [Sign In] option from the
menu and press ENTER ( ) to display the
virtual keyboard.
2. Use U/u/I/i to select a character then
press ENTER ( ) to confirm your selection
on the virtual keyboard.
Refer to “Using the virtual keyboard” on
page 58 for using virtual keyboard.
HB805PH-D0_BGBRLL_ENG_0033.indd 59
2010-08-19
6:49:51
60
Operation
PicasaTM Web Albums
Options while viewing a photo
You can use various options during viewing a
photo in full screen.
Enjoy photo albums from friends and family on
the PicasaTM Web Albums on-line service.
1. While viewing a photo in full screen, press
INFO/DISPLAY ( ) to display the option
menu.
2. Select an option using U/u.
View PicasaTM Web Albums on your
TV
1. On the player, select the [PicasaTM Web
Albums] option in the [NetCast] menu
using I/i, and press ENTER ( ).
Featured photos are appeared on the
screen.
2. Use U/u/I/i to select a photo and press
ENTER ( ) to view the photo in full screen.
4
a
b
c
d
e
f
g
Operation
Button
Operation
a Current photo/Total number of photos
– Use I/i to view previous/next photo.
B
Starts a slide show.
INFO/
DISPLAY
Displays the photo option
menu.
b Slide Show – Press ENTER ( ) to start or
pause slide show.
X
Pauses a slide show. To resume
slide show, press B again.
d Rotate – Press ENTER ( ) to rotate the
photo clockwise.
x
Stops the slide show and
return to the PicasaTM Web
Albums menu.
e Zoom – Press ENTER ( ) to display the
[Zoom] menu.
I/i
Moves to the next or previous
photo.
c Add to NetCast Friends List – Add the
current photo owner to my friend list.
f Effect – Use I/i to select a transition
effect between photos in a slide show.
g Speed – Use I/i to select a delaying
speed between photos in a slide show.
3. Press RETURN (O) to exit the option menu.
HB805PH-D0_BGBRLL_ENG_0033.indd 60
2010-08-19
6:49:52
Operation
There are various options on the PicasaTM Web
Albums menu. Use U/u/I/i to select an
menu option and press ENTER ( ) to select
the options as described below.
Home – The featured photo list will be
displayed.
NetCast Friends – List of your friends will be
displayed.
Search – Enter a search word to find related
photos. The virtual keyboard will be displayed
(page 62).
My Photos – Displays the photos organised
in my PicasaTM Web Albums. This option is
available only when the unit is in sign-in
status.
Adding friends
If you add your friends on the [NetCast Friends]
menu, you can see the photos of your friend’s
public photos directly.
1. Select the [NetCast Friends] on the PicasaTM
Web Albums menu using U/u/I/i, and
press ENTER ( ).
2. Press ENTER ( ) to display the virtual
keyboard.
3. Enter a name using the virtual keyboard.
Refer to “Using the virtual keyboard” on
page 58 for using virtual keyboard.
4. Select [OK] using U/u/I/i, and press
ENTER ( ) to display the web album of
your friend.
4
Operation
About the PicasaTM Web Albums
menu
61
NOTE
Favorites – Displays up to 50 favorite web
albums that are arranged in the PicasaTM Web
Albums server with your account. This option
is available only when the unit is in sign-in
status.
• If you want to delete your friend from the list,
press green (G) coloured button while the web
album is selected.
Sign in (Sign Out) – Displays the virtual
keyboard to sign in or returns to the sign-out
status (page 62)
• You can add more web albums of your friends
up to 50.
• If you want to add more friends, press red (R)
coloured button on the list.
NOTE
Photos displayed in [My Photos] and [Favorites]
may differ with the photos from a web browser on
PC.
HB805PH-D0_BGBRLL_ENG_0033.indd 61
2010-08-19
6:49:52
62
Operation
Searching photos
You can enter a search word to find related
photos.
1. Select the [Search] on the PicasaTM Web
Albums menu using U/u/I/i, and press
ENTER ( ).
2. Enter a search word using the virtual
keyboard.
Refer to “Using the virtual keyboard” on
page 58 for using virtual keyboard.
3. Select [OK] using U/u/I/i, and press
ENTER ( ) to display the search result.
NOTE
The search result from the player may differ with
the result searched from a web browser on PC.
3. Enter the password using the virtual
keyboard, and press ENTER ( ) while [OK] is
selected.
Your web album is appeared on the screen.
4. If you want to sign out, select the [Sign Out]
from the PicasaTM Web Albums menu and
press ENTER ( ).
This unit can automatically store up to 5 user
names which were previously signed-in. The
user name list appears when you select the
[Sign In] option.
Select a stored user name on the list and press
ENTER ( ) to display the virtual keyboard with
the selected user name is entered. You will
then only need to enter the password to sign
in.
4
Operation
Signing in with your account
To display photos in your web album on the
screen, you need to sign in with your PicasaTM
Web Albums account.
1. Select the [Sign In] on the PicasaTM Web
Albums menu using U/u/I/i, and press
ENTER ( ).
Select the [X] symbol and press ENTER ( ) to
delete the stored user name.
2. Enter your user name using the virtual
keyboard, and press ENTER ( ) while [OK] is
selected.
Refer to “Using the virtual keyboard” on
page 58 for using virtual keyboard.
HB805PH-D0_BGBRLL_ENG_0033.indd 62
2010-08-19
6:49:52
Operation
Using the AccuWeather
63
5. Select a city using U/u/I/i, and press
ENTER ( ).
6. Use U/u/I/i to select [Home] and press
ENTER ( ) to display weather information
of the selected city.
See on-line local and global weather forcasts
from AccuWeather.com.
Viewing weather information
The city selection menu appears on the
screen.
Press red (R) coloured button to toggle
display between Fahrenheit or Celsius
thermometre.
7. Use I/i to select previous or next city, and
press ENTER ( ) to display the weather
information.
This step works only when you add more
than 1 cities to the [Favorite city List].
NOTE
2. Press ENTER ( ) while [Add City to Favorite
City List] is selected.
• The weather information is not always correct.
3. Select a region using U/u, and press ENTER
( ).
• The weather information may be displayed in
English, if your own language is not available on
the AccuWeather service.
4
Operation
1. On the player, select the [AccuWeather]
option in the [NetCast] menu using I/i,
and press ENTER ( ).
4. Select a, country using U/u/I/i, and press
ENTER ( ).
HB805PH-D0_BGBRLL_ENG_0033.indd 63
2010-08-19
6:49:52
64
Operation
Adding more cities
1. Use I/i to select [Favorite City List] on the
AccuWeather menu, and press ENTER ( ).
2. Press ENTER ( ) while [Add City to Favorite
City List] is selected.
3. Select a region, country and city using
U/u/I/i and ENTER ( ).
4. Repeats step 2-3 to add up to 5 cities.
4
Select the [X] symbol and press ENTER ( )
to delete the stored favorite city.
Operation
5. Use U/u to select a city from the [Favorite
City List], and press ENTER ( ) to display
the weather information.
HB805PH-D0_BGBRLL_ENG_0033.indd 64
2010-08-19
6:49:53
Maintenance
65
5
Maintenance
Notes on Discs
Handling the Unit
Handling Discs
When shipping the unit
Please save the original shipping carton and
packing materials. If you need to ship the unit,
for maximum protection, re-pack the unit as it
was originally packed at the factory.
Storing Discs
After playing, store the disc in its case. Do not
expose the disc to direct sunlight or sources of
heat and never leave it in a parked car exposed
to direct sunlight.
Cleaning Discs
Keeping the exterior surfaces clean
•
Do not use volatile liquids such as
insecticide spray near the unit.
•
Wiping with strong pressure may damage
the surface.
•
Do not leave rubber or plastic products in
contact with the unit for a long period of
time.
Cleaning the unit
To clean the player, use a soft, dry cloth. If
the surfaces are extremely dirty, use a soft
cloth lightly moistened with a mild detergent
solution. Do not use strong solvents such as
alcohol, benzine, or thinner, as these might
damage the surface of the unit.
Do not use strong solvents such as alcohol,
benzine, thinner, commercially available
cleaners, or anti-static spray intended for older
vinyl records.
HB805PH-D0_BGBRLL_ENG_0033.indd 65
5
Maintenance
Never stick paper or tape on the disc.
Maintaining the Unit
The unit is a high-tech, precision device. If
the optical pick-up lens and disc drive parts
are dirty or worn, the picture quality could be
diminished. For details, please contact your
nearest authorized service centre.
2010-08-19
6:49:54
66
Troubleshooting
6
Troubleshooting
General
6
Troubleshooting
The Power does not turned
on.
•
Plug the power cord into the wall outlet securely.
The unit does not start
playback.
•
Insert a playable disc. (Check the disc type, colour system,
and regional code.)
•
Place the disc with the playback side down.
•
Place the disc on the disc tray correctly inside the guide.
•
Clean the disc.
•
Cancel the rating function or change the rating level.
The angle cannot be
changed.
•
Multi-angles are not recorded on the DVD Video being
played.
The subtitle language
cannot be changed or
turned off.
•
Subtitles are not recorded on the DVD Video being played.
Cannot play MP3/WMA/
JPEG/DivX files.
•
The files are not recorded in a format that the unit can play.
•
The unit does not support the codec of the movie file.
The remote control does
not work properly.
•
The remote control is not pointed at the remote sensor of
the unit.
•
The remote control is too far from the unit.
•
There is an obstacle in the path of the remote control and
the unit.
•
The Battery in the remote control is exhausted.
HB805PH-D0_BGBRLL_ENG_0033.indd 66
2010-08-19
6:49:54
Troubleshooting
67
There is no picture.
Picture noise appears
•
Select the appropriate video input mode on the TV so the
picture from the unit appears on the TV screen.
•
Connect the video connection securely.
•
Check the [HDMI Color Setting] in the [Setup] menu is
set to the appropriate item that conforms to your video
connection.
•
Your TV may not suppot the resolution you have set on the
player. Change the resolution that your TV accepts.
•
The player’s HDMI OUT jack is connected to a DVI device that
does not support copyright protection.
•
You are playing a disc recorded in a colour system that is
different from your TV.
•
Set the resolution which your TV accepts.
•
The unit is in scan, slow motion, or pause mode.
•
The sound volume is low.
•
Check the speaker cable connection. (page 17)
Sound
There is no sound or the
sound is distorted.
Troubleshooting
6
HB805PH-D0_BGBRLL_ENG_0033.indd 67
2010-08-19
6:49:54
68
Troubleshooting
Network
BD-LIVE feature does not
work.
Streaming video services
(such as YouTubeTM, etc.)
are often stopped or
“buffer” during playback.
•
The connected USB storage may not have enough space.
Connect the USB storage with at least 1GB free space.
•
Ensure that the unit is correctly connected to the local area
network and can access the internet (see pages 25-27).
•
Your broadband speed may not fast enough to use the BDLIVE features. Contact your Internet Service Provider (ISP) and
increase the broadband speed is recommended.
•
The [BD-LIVE connection] option in the [Setup] menu is set
to [Prohibited]. Set the option to [Permitted].
•
Your broadband service speed may not be fast enough to
stream video services. Contact your Internet Service Provider
(ISP) and increase the broadband speed is recommended.
Design and specifications are subject to change without notice.
Customer Support
You can update the Player using the latest software to enhance the products operation and/or
add new features. To obtain the latest software for this player (if updates have been made),
please visit http://lgservice.com or contact LG Electronics customer care centre.
6
Troubleshooting
HB805PH-D0_BGBRLL_ENG_0033.indd 68
2010-08-19
6:49:54
Appendix
69
7
Appendix
Controlling a TV with
the Supplied Remote
Control
You can control your TV using the buttons
below.
Setting up the remote to
control your TV
You can operate your LG/GoldStar TV with the
supplied remote control.
While holding down TV POWER button, press
PR/CH U/u. Release the TV POWER button to
complete setting.
When you replace the Battery of the remote,
you may have reset the remote control.
Button
Operation
1 (TV Power)
Turn the TV on or off.
AV/ INPUT
Switch the TV’s input source
between the TV and other
input sources.
VOL +/-
Adjust the volume of the
TV.
PR/CH U/u
Scan up or down through
memorized channels.
MUTE
Mutes the sound.
Appendix
TV Control
Buttons
7
NOTE
Depending on the unit being connected, you may
not be able to control your TV using some of the
buttons.
HB805PH-D0_BGBRLL_ENG_0033.indd 69
2010-08-19
6:49:54
70
Appendix
Area Code List
Choose an area code from this list.
Area
Afghanistan
Appendix
7
Code Area
AF Fiji
Code Area
Code Area
Code
FJ Monaco
MC Singapore
SG
SK
Argentina
AR Finland
FI Mongolia
MN Slovak Republic
Australia
AU France
FR Morocco
MA Slovenia
Austria
AT Germany
DE Nepal
NP South Africa
ZA
Belgium
BE Great Britain
GB Netherlands
NL South Korea
KR
Bhutan
BT Greece
GR Netherlands
GL Antilles
Bolivia
BO Greenland
Brazil
BR Hong Kong
Cambodia
KH Hungary
Canada
CA India
Chile
CL Indonesia
China
CN Israel
Colombia
CO Italy
Congo
CG Jamaica
Costa Rica
CR Japan
Croatia
HR Kenya
Czech Republic
CZ Kuwait
Denmark
DK Libya
Ecuador
EC Luxembourg
Egypt
EG Malaysia
El Salvador
SV Maldives
Ethiopia
ET Mexico
HB805PH-D0_BGBRLL_ENG_0033.indd 70
HK New Zealand
HU Nigeria
IN Norway
ID Oman
IL Pakistan
IT Panama
JM Paraguay
JP Philippines
KE Poland
KW Portugal
LY Romania
LU Russian
Federation
MY
Saudi Arabia
MV
Senegal
MX
Spain
SI
ES
AN Sri Lanka
NZ Sweden
LK
NG Switzerland
NO Taiwan
CH
SE
TW
OM Thailand
PK Turkey
TH
PA Uganda
PY Ukraine
UG
PH United States
PL Uruguay
TR
UA
US
UY
PT Uzbekistan
RO Vietnam
UZ
Zimbabwe
ZW
RU
VN
SA
SN
2010-08-19
6:49:54
Appendix
71
Language code List
Use this list to input your desired language for the following initial settings: [Disc Audio],
[Disc Subtitle] and [Disc Menu].
Code Language
Code Language
Code Language
Code
Afar
6565
French
7082
Lithuanian
7684
Sindhi
8368
Afrikaans
6570
Frisian
7089
Macedonian
7775
Singhalese
8373
Albanian
8381
Galician
7176
Malagasy
7771
Slovak
8375
Ameharic
6577
Georgian
7565
Malay
7783
Slovenian
8376
Arabic
6582
German
6869
Malayalam
7776
Spanish
6983
Armenian
7289
Greek
6976
Maori
7773
Sudanese
8385
Assamese
6583
Greenlandic
7576
Marathi
7782
Swahili
8387
Aymara
6588
Guarani
7178
Moldavian
7779
Swedish
8386
Azerbaijani
6590
Gujarati
7185
Mongolian
7778
Tagalog
8476
Bashkir
6665
Hausa
7265
Nauru
7865
Tajik
8471
Basque
6985
Hebrew
7387
Nepali
7869
Tamil
8465
Bengali; Bangla 6678
Hindi
7273
Norwegian
7879
Telugu
8469
Bhutani
6890
Hungarian
7285
Oriya
7982
Thai
8472
Bihari
6672
Icelandic
7383
Panjabi
8065
Tonga
8479
Breton
6682
Indonesian
7378
Pashto, Pushto 8083
Turkish
8482
Bulgarian
6671
Interlingua
7365
Persian
7065
Turkmen
8475
Burmese
7789
Irish
7165
Polish
8076
Twi
8487
Byelorussian
6669
Italian
7384
Portuguese
8084
Ukrainian
8575
Chinese
9072
Japanese
7465
Quechua
8185
Urdu
8582
Croatian
7282
Kannada
7578
8590
6783
Kashmiri
7583
Rhaeto-Romance
8277
Uzbek
Czech
Vietnamese
8673
Danish
6865
Kazakh
7575
Rumanian
8279
Volapük
8679
Dutch
7876
Kirghiz
7589
Russian
8285
Welsh
6789
English
6978
Korean
7579
Samoan
8377
Wolof
8779
Esperanto
6979
Kurdish
7585
Sanskrit
8365
Xhosa
8872
7168
Yiddish
7473
8382
Yoruba
8979
Zulu
9085
Estonian
6984
Laothian
7679
Scots Gaelic
Faroese
7079
Latin
7665
Serbian
Fiji
7074
Latvian, Lettish 7686
Serbo-Croatian 8372
Finnish
7073
Lingala
Shona
HB805PH-D0_BGBRLL_ENG_0033.indd 71
7678
Appendix
Language
7
8378
2010-08-19
6:49:54
72
Appendix
Network Software
Update
Network update notification
From time to time, performance improvements
and/or additional features or services may be
made available to units that are connected to
a broadband home network. If there is new
software available and the unit is connected
to a broadband home network, the player will
inform you about the update as follows.
Option 1:
1. The update menu will appear on the screen
when you turn on the player.
2. Use I/i to select a desired option and then
press ENTER ( ).
Option 2:
If the software update is available from the
update server, the “Update” icon appears at
the bottom of the Home menu. Press blue (B)
coloured button to start the update procedure.
Software Update
You can update the player using the latest
software to enhance the products operation
and/or add new features. You can update the
software by connecting the unit directly to the
software update server.
CAUTION
• Before updating the software in your player,
remove any disc and USB Device from the player.
• Before updating the software in your player, turn
the player off and then turn it back on.
• During the software update procedure, do
not turn off the player or disconnect AC
power, or do not press any button.
• If you cancel the update, turn off the power and
turn it on for stable performance.
Appendix
• This unit cannot be updated to previous
software version.
[OK]
Starts the software update.
7
[Cancel]
Exits the update menu and displays it next
booting.
1. Check the network connection and settings
(page 25-27).
2. Select [Software] option in the [Setup]
menu then press ENTER ( ).
3. Select [Update] option, and press ENTER
( ).
The player will check for the newest update.
HB805PH-D0_BGBRLL_ENG_0033.indd 72
2010-08-19
6:49:54
Appendix
NOTE
• Pressing ENTER ( ) while checking for the
update will end the process.
• If there is no update available, the Message,
“No update is found.” appears. Press ENTER ( )
to return to the [Home Menu].
4. If newer version exists, the message “A
new update was found. Do you want to
download it?” appears.
73
CAUTION
Do not turn off the power during the software
update.
NOTE
If the software includes the driver update, disc tray
may open during the process.
9. When update is completed, the message,
“Update is complete.” will appear, and then
power will turn off automatically after 5
seconds.
10. Turn the power back on. The system now
operates with the new version.
6. The player starts downloading the newest
update from the server. (Downloading will
takes several minutes depending on your
home network condition)
7. When downloading is completed, the
message, “Download is complete. Do you
want to update?” appears.
NOTE
The Software Update function may not work
properly depending on your internet environment.
In this case, you can obtain the latest software from
the authorized LG Electronics Service Centre then
update your player. Refer to “Customer Support” on
page 68.
Appendix
5. Select [OK] to download the update.
(Selecting [Cancel] will end the update.)
8. Select [OK] to start updating.
(Selecting [Cancel] will end the update and
downloaded file will not be re-usable. To
update software the next time, the software
update procedure has to be started from
the beginning again.)
HB805PH-D0_BGBRLL_ENG_0033.indd 73
7
2010-08-19
6:49:54
74
Appendix
Video output resolution
When the non-copy protected media is playing back
Video Out
HDMI OUT
Resolution
COMPONENT VIDEO OUT
HDMI connected
HDMI disconnected
576i
576p
576i
576p
576p
576p
720p
720p
720p
1080i
1080i
1080i
1080p / 24 Hz
1080p / 24 Hz
1080p / 50 Hz
1080p / 50 Hz
-
1080i
1080i
When the copy protected media is playing back
Video Out
HDMI OUT
Resolution
HDMI disconnected
576i
576p
576p
576p
720p
720p
-
576i
1080i
1080i
-
576i
1080p / 24 Hz
1080p / 24 Hz
-
576i
1080p / 50 Hz
1080p / 50 Hz
-
576i
Appendix
HDMI OUT connection
•
For the 576i resolution setting, real output
resolution of HDMI OUT will change to
576p.
•
If you select a resolution manually and then
connect the HDMI jack to TV and your TV
does not accept it, the resolution setting is
set to [Auto].
•
If you select a resolution that your TV
does not accept, the warning message
will appear. After resolution change,
if you cannot see the screen, please
wait 20 seconds and the resolution will
automatically revert back to the previous
resolution.
7
COMPONENT VIDEO OUT
HDMI connected
HB805PH-D0_BGBRLL_ENG_0033.indd 74
576i
576i
•
The 1080p video output frame rate may be
automatically set to either 24 Hz or
50 Hz depending both on the capability
and preference of the connected TV and
based on the native video frame rate of the
content on the BD-ROM disc.
COMPONENT VIDEO OUT
connection
BD or DVD could prevent up-scaling on
analogue output.
VIDEO OUT connection
The resolution of the VIDEO OUT jack is always
outputted at 576i resolution.
When you set the HDMI Resolution, over 720p
is not outputted to Composit Video.
2010-08-19
6:49:55
Appendix
75
Trademarks and Licences
“BD-LIVE” logo is a trademark of Blu-ray Disc
Association.
“BONUSVIEW” is trademark of Blu-ray Disc
Association.
Java and all Java-based trademarks and logos
are trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and other
countries.
Manufactured under licence from Dolby
Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI licensing LLC.
“DVD Logo” is a trademark of DVD Format/Logo
Licensing Corporation.
DivX, DivX Certified and associated logos are
registered trademarks of DivX, Inc. and are used
under license.
“x.v.Colour” is a trademark of Sony Corporation.
Appendix
“Blu-ray Disc” is a trademark.
YouTubeTM is a trademark of Google Inc.
PicasaTM Web Albums is a trademark of Google Inc.
7
2010-08-19
6:49:55
Manufactured under license under U. S. Patent
#’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;
6,226,616; 6,487,535; 7,392,195; 7,272,567;
7,333,929; 7,212,872 & other U.S. and worldwide
patents issued & pending. DTS and the Symbol are
registered trademarks, & DTS-HD, DTS-HD Master
Audio | Essential and the DTS logos are trademarks
of DTS, Inc. Product includes software. © DTS, Inc.
All Rights Reserved.
HB805PH-D0_BGBRLL_ENG_0033.indd 75
76
Appendix
“AVCHD” and the “AVCHD” logo are trademarks of
Panasonic Corporation and Sony Corporation.
This product is licenced under the AVC patent
portfolio licence and VC-1 patent portfolio licence
for the personal and non-commercial use of a
consumer to (i) encode video in compliance with
the AVC Standard and VC-1 Standard (“AVC/VC-1
Video”) and/or (ii) decode AVC/VC-1 Video that was
encoded by a consumer engaged in a personal and
non-commercial activity and/or was obtained from a
video provider licenced to provide AVC/VC-1 Video.
No licence is granted or shall be implied for any
other use. Additional information may be obtained
from MPEG LA, LLC. See http://www.mpegla.com.
Appendix
7
HB805PH-D0_BGBRLL_ENG_0033.indd 76
2010-08-19
6:49:55
Appendix
Specifications
77
Tuner
• FM Tuning Range:
87.5 to 108.0 MHz or 87.50 to 108.00 MHz
• Power requirements:
200 - 240 V, 50/60 Hz
• Power consumption:
110 W
• Dimensions (W x H x D):
Approx. 360 x 313 x 62.5 mm without foot
• Net Weight (Approx.):
2.9 kg
• Operating temperature:
41 °F to 95 °F (5 °C to 35 °C)
• Operating humidity:
5 % to 90 %
• Bus Power supply (USB):
DC 5 V
500 mA
Amplifier
• Stereo mode:
136 W + 136 W (4 Ω at 1 kHz)
• Surround mode:
Front
Center
Surround
Subwoofer
136 W + 136 W (4 Ω at 1 kHz)
136 W (4 Ω at 1 kHz)
136 W + 136 W (4 Ω at 1 kHz)
170 W (3 Ω at 60 Hz)
System
• Laser:
Semiconductor laser
Wavelength: 405 nm / 650 nm
• Signal system:
Standard NTSC/PAL colour TV system
Inputs/ Outputs
• Frequency response:
20 Hz to 20 kHz (48 kHz, 96 kHz, 192 kHz sampling)
• VIDEO OUT:
1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
• Signal-to-noise ratio:
More than 80 dB
• COMPONENT VIDEO OUT:
(Y) 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1,
(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2
• Total harmonic distortion:
0.05 % at 1 W
• HDMI OUT (video/audio):
19 pin (HDMI standard, Type A, Version 1.3)
• Analogue AUDIO IN:
2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
• Dynamic range:
More than 85 dB
• LAN port:
Ethernet jack x 1, 10BASE-T/100BASE-TX
Appendix
General
• DIGITAL IN (OPTICAL IN):
3 V (p-p), Optical jack x 1
• PORT. IN:
0.5 Vrms (3.5 mm stereo jack)
HB805PH-D0_BGBRLL_ENG_0033.indd 77
7
2010-08-19
6:49:55
78
Appendix
Speakers
• Front speaker (Left/ Right)
Type:
Impedance Rated:
Input Power:
Max. Input power:
Net Dimensions
(W x H x D):
Net Weight:
• Rear speaker (Left/ Right)
Type:
Impedance
Input Power:
Max. Input power:
Net Dimensions
(W x H x D):
Net Weight:
• Centre speaker
Type:
Impedance Rated:
Input Power:
Max. Input power:
Net Dimensions
(W x H x D):
Net Weight:
Appendix
• Subwoofer
Type:
Impedance Rated:
Input Power:
Max. Input power:
Net Dimensions
(W x H x D):
Net Weight:
2 Way 2 speaker
4Ω
136 W
272 W
270 x 1022 x 225 mm
2.7 kg
1 Way 1 speaker
4Ω
136 W
272 W
100 x 186 x 100 mm
0.4 kg
2 Way 2 speaker
4Ω
136 W
272 W
200 x 103 x 88 mm
0.48 kg
1 Way 1 speaker
3Ω
170 W
340 W
190 x385 x 275 mm
4.6 kg
7
HB805PH-D0_BGBRLL_ENG_0033.indd 78
2010-08-19
6:49:55
Appendix
PLEASE READ CAREFULLY. USE OF THE NETWORK
SERVICES IS SUBJECT TO THE FOLLOWING TERMS
AND CONDITIONS.
Use of the Network Services requires an Internet
connection which is sold separately and for which
you are solely responsible. The Network Services may
be limited or restricted depending upon the quality,
capabilities and technical limitations of your Internet
service.
The Network Services belong to third parties and
may be protected by copyright, patent, trademark
and/or other intellectual property laws. The Network
Services are provided sol\ely for your personal and
noncommercial use. Unless expressly authorized by
the respective content owner or service provider,
you shall not modify, copy, republish, upload, post,
transmit, translate, sell, create derivative works,
exploit, or distribute in any manner or medium any
content or services accessible through this product.
LG IS NOT RESPONSIBLE FOR YOUR USE OF
THE NETWORK SERVICES. THE NETWORK
SERVICES ARE PROVIDED “AS IS.” TO THE FULLEST
EXTENT PERMISSIBLE BY LAW, LG MAKES NO
REPRESENTATIONS OR WARRANTIES OF ANY KIND
WHATSOEVER (i) FOR THE ACCURACY, VALIDITY,
TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY
NETWORK SERVICE MADE AVAILABLE THROUGH
THIS PRODUCT; OR (ii) THAT THE NETWORK SERVICES
ARE FREE OF VIRUSES OR OTHER COMPONENTS
THAT MAY INFECT, HARM, OR CAUSE DAMAGE TO
THIS PRODUCT, YOUR COMPUTER, TELEVISION,
OTHER EQUIPMENT, OR ANY OTHER PROPERTY. LG
EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO, WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
HB805PH-D0_BGBRLL_ENG_0033.indd 79
UNDER NO CIRCUMSTANCES AND UNDER NO
LEGAL THEORY, WHETHER IN CONTRACT, TORT,
STRICT LIABILITY OR OTHERWISE, SHALL LG BE
LIABLE TO YOU OR ANY THIRD PARTY FOR ANY
DIRECT, INDIRECT, INCIDENTAL, SPECIAL, STATUTORY,
CONSEQUENTIAL OR OTHER DAMAGES OR
ATTORNEY FEES OR EXPENSES RELATING TO OR
ARISING OUT OF THE NETWORK SERVICES EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
IF SUCH DAMAGES COULD HAVE BEEN REASONABLY
FORESEEN.
The Network Services may be terminated or
interrupted at any time, and LG makes no
representation or warranty that any Network Service
will remain available for any period of time. Use of the
Network Services may be subject to additional terms
and conditions of the respective third party service
provider. The Network Services are transmitted by
third parties by means of networks and transmission
facilities over which LG has no control. LG EXPRESSLY
DISCLAIMS ANY RESPONSIBILITY OR LIABILITY
FOR ANY INTERRUPTION OR SUSPENSION OF ANY
NETWORK SERVICE.
LG shall be neither responsible nor liable for
customer service related to the Network Services.
Any question or request should be made directly to
the respective Network Service providers.
“Network Service(s)” means the third party services
accessible through this product including but
not limited to all data, software, links, messages,
video and other content found thereon or used in
connection therewith.
“LG” means LG Electronics, Inc. its parent company
and all of their respective subsidiaries, affiliates and
related companies worldwide.
Appendix
Important Information
Relating to Network
Services
79
7
2010-08-19
6:49:55
80
Appendix
Open source software
notice
The following GPL executables and LGPL libraries
used in this product are subject to the GPL2.0/
LGPL2.1 License Agreements:
GPL EXECUTABLES: Linux kernel, busybox, linux IR
control package, ntfs-3g, squashfs, u-boot
LGPL LIBRARIES: glibc, libmtp, libusb, libusbcompat
LG Electronics offers to provide source code to
you on CD-ROM for a charge covering the cost of
performing such distribution, such as the cost of
media, shipping and handling upon e-mail request
to LG Electronics at: opensource@lge.com
This offer is valid for a period of three(3) years from
the date of the distribution of this product by LG
Electronics.
You can obtain a copy of the GPL, LGPL licenses
from http://www.gnu.org/licenses/old-licenses/
gpl-2.0.html and http://www.gnu.org/licenses/oldlicenses/lgpl-2.1.html .
Appendix
7
This product includes
• curl: copyright © 1996 - 2008, Daniel Stenberg
• expat: copyright © 2006 expat maintainers
• freetype: copyright © 2003 The FreeType Project
(www.freetype.org).
• International Components for Unicode:
copyright © 1995-2010 International Business
Machines Corporation and others
• jpeg: This software is based in part on the work of
the Independent JPEG Group copyright © 1991 –
1998, Thomas G. Lane.
• OpenSSL:
– cryptographic software written by Eric Young
(eay@cryptsoft.com).
– software written by Tim Hudson
(tjh@cryptsoft.com).
– software developed by the OpenSSL Project
for use in the OpenSSL Toolkit.
(http://www.openssl.org)
• xml2 : copyright © 1998-2003 Daniel Veillard
• WPA Supplicant : Copyright © 2003-2007, Jouni
Malinen <j@w1.fi> and contributors
• zlib: copyright © 1995-2002 Jean-loup Gailly and
Mark Adler.
HB805PH-D0_BGBRLL_ENG_0033.indd 80
All rights reserved.
Permission is hereby granted, free of charge, to any
person obtaining a copy of this software and associated
documentation files (the “Software”), to deal in the
Software without restriction, including without limitation
the rights to use, copy, modify, merge, publish, distribute,
sublicense, and/or sell copies of the Software, and to
permit persons to whom the Software is furnished to do
so, subject to the following conditions:
THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT
WARRANTY OF ANY KIND, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE WARRANTIES
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL
THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR
ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER
IN AN ACTION OF CONTRACT, TORT OR OTHERWISE,
ARISING FROM, OUT OF OR IN CONNECTION WITH THE
SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
SOFTWARE.
• HarfBuzz
Permission is hereby granted, without written
agreement and without license or royalty fees, to
use, copy, modify, and distribute this software and
its documentation for any purpose, provided that
the above copyright notice and the following two
paragraphs appear in all copies of this software.
IN NO EVENT SHALL THE COPYRIGHT HOLDER BE
LIABLE TO ANY PARTY FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING
OUT OF THE USE OF THIS SOFTWARE AND ITS
DOCUMENTATION, EVEN IF THE COPYRIGHT HOLDER HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
• Unicode Bidirectional Algorithm copyright ©
1999-2009, ASMUS, Inc. All Rights Reserved.
Distributed under the Terms of Use in
http://www.unicode.org/copyright.html.
THIS SOFTWARE IS PROVIDED “AS IS”, WITHOUT
WARRANTY OF ANY KIND, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE
AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. IN
NO EVENT SHALL THE COPYRIGHT HOLDER OR HOLDERS
INCLUDED IN THIS NOTICE BE LIABLE FOR ANY CLAIM, OR
ANY SPECIAL INDIRECT OR CONSEQUENTIAL DAMAGES,
OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS
OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF
CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION,
ARISING OUT OF OR IN CONNECTION WITH THE USE OR
PERFORMANCE OF THE SOFTWARE.
2010-08-19
6:49:55
HB805PH-D0_BGBRLL_ENG_0033.indd 81
2010-08-19
6:49:55
HB805PH-D0_BGBRLL_ENG_0033.indd 82
2010-08-19
6:49:55
Warranty
83
Technology with the human touch
GUARANTEE
•
LG Electronics U.K. Ltd. will provide the following services in order toexpedite this Guarantee.
1. All faulty components which fail due to defective manufacture will be replaced free of charge for a period
of 12 months from the original date of purchase.
2. The dealer (or his service agent) who sold the product will be reimbursed for any labour provided in the
repair of this LG equipment, for a period of 12 months from the original date of purchase. These claims
must be made in accordance with the published scale of service charges and relevant claims procedure.
PLEASE NOTE:
A. The dealer may restrict the guarantee to the original purchaser.
B. The dealer is not obliged to carry out service under guarantee if unauthorized modifications are made to
the apparatus, or if non standard components are used or if the serial number of the apparatus is removed,
defaced, misused, or altered.
C. Any claims made under guarantee must be directed to the dealer from whom the equipment was
originally purchased. The dealer may, before carrying out service under guarantee, require a receipted
account as evidence of the date of purchase.
D. We respectfully point out that your dealer is not obligated to replace batteries if they become exhausted
or worn in use.
E. Aerial alignment and consumer control adjustments are not covered by this guarantee.
This guarantee does not affect your statutory rights.
• REQUIREMENTS TO MAINTAIN WARRANTY COVERAGE:
RETAIN YOUR RECEIPT TO PROVE DATE OF PURCHASE. A COPY OF YOUR RECEIPT MUST BE SURRENDERED
AT THE TIME GUARANTEE SERVICE IS PROVED.
• Product Registration Card :
It is helpful to complete at least your name, address, phone, model & serial numbers and return it. This
will enable LG to assist you in the future should you lose your receipt, your units be stolen, or should
modifications be necessary.
MODEL NO.*
SERIAL NO.*
Warranty
• To obtain information or assistance: Call 0870 873 5454 Monday-Friday 9.00am-4.30pm
DATE OF PURCHASE.*
In all cases of difficulty - consult your LG dealer from whom the product was purchased
LGEUK Website : www.lge.co.uk
( service website : www.lgelectronics.co.uk )
8
HB805PH-D0_BGBRLL_ENG_0033.indd 83
2010-08-19
6:49:55
HB805PH-D0_BGBRLL_ENG_0033.indd 84
2010-08-19
6:49:55
Download PDF

advertising
