Air conditioner
User&Installation manual
AC∗∗∗NNMSEC
•• Thank you for purchasing this Samsung air conditioner.
•• Before operating this unit, please read this manual carefully and retain it for future reference.
DB68-07419A-01
Features of your new air conditioner
Cool Summer Offer
Contents
USING PARTS
On those hot sweltering summer days and long restless
nights, there is no better escape from the heat than
the cool comforts of home. Your new air conditioner
brings an end to exhausting hot summer days and lets
you rest.
This summer, beat the heat with your own air
conditioner.
Safety precautions ............................................................ 3
Checking before use ......................................................... 8
Viewing the parts ............................................................ 10
Cleaning and maintaining the air conditioner .......... 11
Appendix ........................................................................... 13
Flexible installation
Safety precautions .......................................................... 15
Preparation for installation ......................................... 18
Deciding on where to install the indoor unit ........... 19
Indoor unit installation ................................................. 24
Purging the unit .............................................................. 25
Connecting the refrigerant pipe ................................. 26
Cutting/Flaring the pipes ............................................ 27
Performing leak test & insulation .............................. 28
Drainpipe and drain hose installation ..................... 30
Connecting the connection cord ................................ 32
Extending the power cable ........................................... 34
Adjusting air flow............................................................. 36
Easy Tuning........................................................................ 37
Setting the indoor unit option code........................... 38
Setting an indoor unit address and installation option..
.............................................................................................. 39
Troubleshooting ............................................................. 42
Duct type air conditioner is designed to be slimmer and
offers different solutions for any shape room allowing
for specific air flow requirements. Also, the air intake
can be set up on either the bottom or rear of the unit, so
there is more flexibility in installation.
INSTALLATION PARTS
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset,
USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle
them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of
where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for disposal.
2 English
USING PARTS
Safety precautions
Before using your new air conditioner, please read this manual thoroughly to ensure that you know
how to safely and efficiently operate the extensive features and functions of your new appliance.
Important safety symbols and precautions:
WARNING
Hazards or unsafe practices that may result in severe personal injury or
death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or
property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Unplug the power plug from the wall socket.
Do NOT disassemble.
FOR INSTALLATION
WARNING
Use the power line with the power specifications of the product or higher and use the power
line for this appliance only. In addition, do not use an extension line.
Extending the power line may result in electric shock or fire.
Do not use an electric transformer. It may result in electric shock or fire.
If the voltage/frequency/rated current condition is different, it may cause fire.
The installation of this appliance must be performed by a qualified technician or service
company.
Failing to do so may result in electric shock, fire, explosion, problems with the product, or
injury.
Install a switch and circuit breaker dedicated to the air conditioner.
Failing to do so may result in electric shock or fire.
Fix the outdoor unit firmly so that the electric part of the outdoor unit is not exposed.
Failing to do so may result in electric shock or fire.
Do not install this appliance near a heater, inflammable material. Do not install this
appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water
(rain drops). Do not install this appliance in a location where gas may leak.
This may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high external wall where it could fall.
If the outdoor unit falls, it may result in injury, death or property damage.
English 3
ENGLISH
Because the following operating instructions cover various models, the characteristics of your air
conditioner may differ slightly from those described in this manual. If you have any questions, call
your nearest contact center or find help and information online at www.samsung.com.
Safety precautions
This appliance must be properly grounded. Do not ground the appliance to a gas pipe, plastic
water pipe, or telephone line.
Failure to do so may result in electric shock, fire, an explosion, or other problems with the
product.
Never plug the power cord into a socket that is not grounded correctly and make sure that
it is in accordance with local and national codes.
FOR INSTALLATION
CAUTION
Install your appliance on a level and hard floor that can support its weight.
Failing to do so may result in abnormal vibrations, noise, or problems with the product.
FOR POWER SUPPLY
WARNING
When the circuit breaker is damaged, contact your nearest service center.
Do not pull or excessively bend the power line. Do not twist or tie the power line. Do not hook
the power line over a metal object, place a heavy object on the power line, insert the power
line between objects, or push the power line into the space behind the appliance.
This may result in electric shock or fire.
FOR POWER SUPPLY
CAUTION
When not using the air conditioner for a long period of time or during a thunder/lightning
storm, cut the power at the circuit breaker.
 Failing to do so may result in electric shock or fire.
FOR USING
WARNING
If the appliance is flooded, please contact your nearest service center.
Failing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or smoke, unplug the power plug
immediately and contact your nearest service center.
Failing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without
touching the power line.
Do not touch the appliance or power line.
Do not use a ventilating fan.
A spark may result in an explosion or fire.
4 English
Do not touch the circuit breaker with wet hands.
This may result in electric shock.
Do not strike or pull the air conditioner with excessive force.
This may result in fire, injury, or problems with the product.
Do not place an object near the outdoor unit that allows children to climb onto the machine.
This may result in children seriously injuring themselves.
Do not turn the air conditioner off with the circuit breaker while it is operating.
Turning the air conditioner off and then on again with the circuit breaker may cause a spark
and result in electric shock or fire.
After unpacking the air conditioner, keep all packaging materials well out of the reach of
children, as packaging materials can be dangerous to children.
If a child places a bag over its head, it may result in suffocation.
Do not insert your fingers or foreign substances into the outlet when the air conditioner is
operating or the front panel is closing.
Take special care that children do not injure themselves by inserting their fingers into the
product.
Do not touch the front panel with your hands or fingers during the heating operation.
This may result in electric shock or burns.
Do not insert your fingers or foreign substances into the air inlet/outlet of the air conditioner.
Take special care that children do not injure themselves by inserting their fingers into the
product.
Do not use this air conditioner for long periods of time in badly ventilated locations or near
infirm people.
Since this may be dangerous due to a lack of oxygen, open a window at least once an hour.
English 5
ENGLISH
To reinstall the air conditioner, please contact your nearest service center.
Failing to do so may result in problems with the product, water leakage, electric shock, or
fire.
A delivery service for the product is not provided. If you reinstall the product in another
location, additional construction expenses and an installation fee will be charged.
Especially, when you wish to install the product in an unusual location such as in an
industrial area or near the seaside where it is exposed to the salt in the air, please contact
your nearest service center.
Safety precautions
If any foreign substance such as water has entered the appliance, cut the power by
unplugging the power plug and turning the circuit breaker off and then contact your nearest
service center.
Failing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, or modify the appliance yourself.
Do not use any fuse (such as cooper, steel wire, etc.)other than the standard fuse.
Failing to do so may result in electric shock, fire, problems with the product, or injury.
FOR USING
CAUTION
Do not place objects or devices under the indoor unit.
Water dripping from the indoor unit may result in fire or property damage.
Check that the installation frame of the outdoor unit is not broken at least once a year.
Failing to do so may result in injury, death or property damage.
Max current is measured according to IEC standard for safety and current is measured
according to ISO standard for energy efficiency.
Do not stand on top of the appliance or place objects (such as laundry, lighted candles,
lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
This may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
This may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the appliance.
As well as being harmful to humans, it may also result in electric shock, fire or problems
with the product.
Do not drink the water from the air conditioner.
The water may be harmful to humans.
Do not apply a strong impact to the remote controller and do not disassemble the remote
controller.
Do not touch the pipes connected with the product.
This may result in burns or injury.
Do not use this air conditioner to preserve precision equipment, food, animals, plants or
cosmetics, or for any other unusual purposes.
This may result in property damage.
6 English
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure that they do not play with the
appliance.
FOR CLEANING
WARNING
Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner or
alcohol to clean the appliance.
This may result in discoloration, deformation, damage, electric shock or fire.
Before cleaning or performing maintenance, unplug the air conditioner from the wall socket
and wait until the fan stops.
Failing to do so may result in electric shock or fire.
FOR CLEANING
CAUTION
Take care when cleaning the surface of the heat exchanger of the outdoor unit since it has
sharp edges.
To avoid cutting your fingers, wear thick cotton gloves when cleaning it.
Do not clean the inside of the air conditioner by yourself.
For cleaning inside the appliance, contact your nearest service center.
When cleaning the internal filter, refer to the descriptions in the ‘Cleaning and maintaining
the air conditioner’ section.
Failure to do may result in damage, electric shock or fire.
English 7
ENGLISH
Avoid directly exposing humans, animals or plants from the air flow from the air conditioner
for long periods of time.
This may result in harm to humans, animals or plants.
Checking before use
Operation ranges
The table below indicates the temperature and humidity ranges the air conditioner can
be operated within.
Refer to the table for efficient use.
OPERATIONAL TEMPERATURE
INDOOR
OUTDOOR
INDOOR
HUMIDITY
COOLING
21˚C to 32˚C
21˚C to 54˚C
80% or less
DRYING
21˚C to 32˚C
21˚C to 54˚C
-
MODE
IF OUT OF CONDITIONS
Condensation may occur on the
indoor unit with risk to have either
water blow off or drops on the floor.
NOTE
•If the cooling operation is used at over 32˚C (indoor temperature), it does not cool at its full capacity.
Maintaining your air conditioner
Internal protections via the unit control system
 This internal protection operates if an internal fault occurs in the air conditioner.
Type
Description
Anti-protection of
internal battery
The compressor will be off to protect internal battery when the air conditioner
operates in Cool mode.
Protect compressor
The air conditioner does not start operating immediately to protect the compressor
of the outdoor unit after it has been started.
8 English
Tips on using air conditioner
Here are some tips that you would follow when using your air conditioner.
RECOMMENDATION
Cooling
•If current outside temperatures are much higher than the
selected indoor temperature, it may take time to bring the inner
temperature to the desired coolness.
•Avoid drastically turning down the temperature. Energy is wasted
and the room does not cool faster.
Power failure
•If a power failure occurs during the operation of the air
conditioner, the operating immediately stops and unit will be off.
When power returns, the air conditioner will run automatically.
Protection
mechanism
•If the air conditioner has just been turned on after operation
stops or being plugged in, cool/warm air does not come out for 3
minutes to protect the compressor of the outdoor unit.
English 9
ENGLISH
TOPIC
Viewing the parts
Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air conditioner and stay
cool or warm with optimal efficiency.
Please read the user manual to get started and to make the best use of the air conditioner.
MA DUCT TYPE
Air filter (the return air side)
Ceiling
Air intake
Air outlet
NOTE
•Your air conditioner and display may look slightly different from the illustration shown above depending on
your model.
10 English
Cleaning and maintaining the air conditioner
Cleaning the filter
MA duct type
1.Slide out the Air filter on the rear side panel to the right side.
2.Clean the Air filter with a vacuum cleaner or soft brush. If dust is too heavy, then rinse it with running water and dry it
in a ventilated area.
•
For best conditions, repeat every two weeks.
•If the Air filter dries in a confined (or humid) area, odors may generate. If it occurs,
re-clean and dry it in a ventilated area.
3.Insert the Air filter back in its original position.
NOTE
• The illustration shown above may differ from yours depending on your model.
•After cleaning the filter, press the Filter Reset button on the remote control for 2 seconds to reset the filter
schedule. Filter sign indicator will be on for cleaning time.
English 11
ENGLISH
For the best performance from your air conditioner, clean it periodically. When cleaning, make sure to unplug from the
unit for user’s safety.
When cleaning the filter, make sure to unplug the power from the unit. Washable foam based Air filter captures large
particles from the air. The filter is cleaned with a vacuum or by hand washing.
Cleaning and maintaining the air conditioner
If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition.
 Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and
disconnect the power plug.
There may be internal damage if moisture is left in components.
 Before using the air conditioner again, dry the inner components of the air
conditioner again by running in Fan mode for 3 to 4 hours. This helps remove odors
which may have generated from dampness.
Periodical checks
Refer to the following chart to maintain the air conditioner properly.
Type
Description
Clean the air filter (1)
Indoor unit
Monthly
Every 4
months
●
Clean the condensate drain pan (2)
●
Thoroughly clean the heat exchanger (2)
●
Clean the condensate drain pipe (2)
●
Replace the remote control batteries (1)
Clean the heat exchanger on the outside of the unit (2)
Outdoor unit
Once a year
●
●
Clean the heat exchanger on the inside of the unit (2)
●
Clean the electric components with jets of air (2)
●
Verify that all the electric components are firmly tightened (2)
●
Clean the fan (2)
●
Verify that all the fan assembly is firmly tightened (2)
●
Clean the condensate drain pan (2)
●
●: T his check mark requires checking the indoor/outdoor unit periodically, following to the description to maintain the
air conditioner properly.
NOTE
•The described operations should be performed more frequently if the area of installation is very dusty.
CAUTION
•These operations must always be performed by qualified personnel. For more detailed
information, see the installation part in the manual.
12 English
Appendix
Troubleshooting
PROBLEM
SOLUTION
The air conditioner
does not operate
immediately after it
has been restarted.
•Because of the protective mechanism, the appliance does not
start operating immediately to keep the unit from overloading.
The air conditioner will start in 3 minutes.
The air conditioner
does not work at
all.
•Check that the power plug is properly connected. Insert the
power plug into the wall socket correctly.
• Check if the circuit breaker is switched off.
• Check if there is a power failure.
• Check your fuse. Make sure it is not blown out.
The temperature
does not change.
•Check if you selected Fan mode.
Press the Mode button on the remote control to select another
mode.
The cool air does
not come out of the
air conditioner.
•Check if the set temperature is higher (lower) than the current
temperature. Press the Temperature button on the remote
control to change the set temperature. Press the Temperature
button to decrease or increase the temperature.
•Check if the air filter is blocked by dirt. Clean the air filter every
two weeks.
•Check if the air conditioner has just been turned on. If so, wait 3
minutes. Cool air does not come out to protect the compressor
of the outdoor unit.
•Check if the air conditioner is installed in a place with a direct
exposure to sunlight. Hang curtains on windows to boost
cooling efficiency.
• Check if the cover or any obstacle is not near the outdoor unit.
• Check if the refrigerant pipe is too long.
• Check if the air conditioner is only available in Cool mode.
• Check if the remote control is only available for cooling model.
ENGLISH
Refer to the following chart if the air conditioner operates abnormally. This
may save time and unnecessary expenses.
English 13
Appendix
PROBLEM
SOLUTION
The fan speed does
not change.
•Check if you selected Auto or Dry mode.
The air conditioner automatically adjusts the fan speed to Auto
in Auto/Dry mode.
Timer function does
not set.
•Check if you press the Power button on the remote control after
you have set the time.
Odors permeate
in the room during
operation.
•Check if the appliance is running in a smoky area or if there is a
smell entering from outside. Operate the air conditioner in Fan
mode or open the windows to air out the room.
The air conditioner
makes a bubbling
sound.
•A bubbling sound may be heard when the refrigerant is
circulating through the compressor. Let the air conditioner
operate in a selected mode.
•When you press the Power button on the remote control, noise
may be heard from the drain pump inside the air conditioner.
Remote control is
not working.
• Check if your batteries are depleted.
• Make sure batteries are correctly installed.
• Make sure nothing is blocking your remote control sensor.
•Check that there are strong lighting apparatus near the air
conditioner. Strong light which comes from fluorescent bulbs or
neon signs may interrupt the electric waves.
The air conditioner
does not turn on or
off with the wired
remote control.
• Check if you set the wired remote control for group control.
The wired remote
control does not
operate.
•Check if TEST indicator is displayed on the wired remote
control. If so, turn off the unit and switch off the circuit breaker.
Call your nearest contact center.
The indicators of
the digital display
flashes.
•Press the Power button on the remote control to turn the unit
off and switch the circuit breaker off. Then, switch it on again.
14 English
INSTALLATION PARTS
Safety precautions
Carefully follow the precautions listed below because they are essential to guarantee the safety of
the equipment.
ENGLISH
WARNING
• Always disconnect the air conditioner from the power supply before
servicing it or accessing its internal components.
• Verify that installation and testing operations are performed by qualified
personnel.
• Verify that the air conditioner is not installed in an easily accessible area.
General information

Carefully read the content of this manual before installing the air conditioner and store the
manual in a safe place in order to be able to use it as reference after installation.
For maximum safety, installers should always carefully read the following warnings.
Store the operation and installation manual in a safe location and remember to hand it over to
the new owner if the air conditioner is sold or transferred.
This manual explains how to install an indoor unit with a split system with two SAMSUNG
units. The use of other types of units with different control systems may damage the units
and invalidate the warranty. The manufacturer shall not be responsible for damages arising
from the use of non compliant units.
The manufacturer shall not be responsible for damage originating from unauthorized
changes or the improper connection of electric and requirements set forth in the “Operating
limits” table, included in the manual, shall immediately invalidate the warranty.
The air conditioner should be used only for the applications for which it has been designed:
the indoor unit is not suitable to be installed in areas used for laundry.
Do not use the units if damaged. If problems occur, switch the unit off and disconnect it from
the power supply.
In order to prevent electric shocks, fires or injuries, always stop the unit, disable the protection
switch and contact SAMSUNG’s technical support if the unit produces smoke, if the power
cable is hot or damaged or if the unit is very noisy.
Always remember to inspect the unit, electric connections, refrigerant tubes and protections
regularly. These operations should be performed by qualified personnel only.
The unit contains moving parts, which should always be kept out of the reach of children.
Do not attempt to repair, move, alter or reinstall the unit. If performed by unauthorized
personnel, these operations may cause electric shocks or fires.
Do not place containers with liquids or other objects on the unit.
All the materials used for the manufacture and packaging of the air conditioner are
recyclable.
The packing material and exhaust batteries of the remote controller(optional) must be
disposed of in accordance with current laws.
The air conditioner contains a refrigerant that has to be disposed of as special waste. At the
end of its life cycle, the air conditioner must be disposed of in authorized centers or returned
to the retailer so that it can be disposed of correctly and safely.
English 15
Safety precautions
Installing the unit
IMPORTANT: When installing the unit, always remember to connect first the refrigerant tubes, then
the electrical lines.
Always disassemble the electric lines before the refrigerant tubes.

Upon receipt, inspect the product to verify that it has not been damaged during transport. If
the product appears damaged, DO NOT INSTALL it and immediately report the damage to the
carrier or retailer (if the installer or the authorized technician has collected the material from
the retailer.)

After completing the installation, always carry out a functional test and provide the
instructions on how to operate the air conditioner to the user.

Do not use the air conditioner in environments with hazardous substances or close to
equipment that release free flames to avoid the occurrence of fires, explosions or injuries.

Our units should be installed in compliance with the spaces shown in the installation
manual, to ensure accessibility from both sides and allow repairs or maintenance operations
to be carried out. The unit’s components should be accessible and easy to disassemble
without endangering people and objects.
For this reason, when provisions of the installation manual are not complied with, the cost
required to access and repair the units (in SAFETY CONDITIONS, as set out in prevailing
regulations) with harnesses, ladders, scaffolding or any other elevation system will NOT be
considered part of the warranty and will be charged to the end customer.
Power supply line, fuse or circuit breaker

Always make sure that the power supply is compliant with current safety standards. Always
install the air conditioner in compliance with current local safety standards.

Always verify that a suitable grounding connection is available.
 Verify that the voltage and frequency of the power supply comply with the specifications and
that the installed power is sufficient to ensure the operation of any other domestic appliance
connected to the same electric lines.
 Always verify that the cut-off and protection switches are suitably dimensioned.
 Verify that the air conditioner is connected to the power supply in accordance with the
instructions provided in the wiring diagram included in the manual.
 Always verify that electric connections (cable entry, section of leads, protections…) are
compliant with the electric specifications and with the instructions provided in the wiring
scheme. Always verify that all connections comply with the standards applicable to the
installation of air conditioners.
 Devices disconnected from the power supply should be completely disconnected in the
condition of overvoltage category.
 Be sure not to perform power cable modification,extension wiring, and multiple wire
connection.
- It may cause electric shock or fire due to poor connection, poor insulation, or current limit
override.
- When extension wiring is required due to power line damage, refer to: Extending the power
cable" in the installation manual.
16 English
CAUTION
ENGLISH
 Make sure that you earth the cables.
- Do not connect the earth wire to the gas pipe, water pipe, lighting rod or telephone wire. If
earthing is not complete, electric shock or fire may occur.
 Install the circuit breaker.
- If the circuit breaker is not installed, electric shock or fire may occur.
 Make sure that the condensed water dripping from the drain hose runs out properly and safely.
 Install the power cable and communication cable of the indoor and outdoor unit at least 1m away
from the electric appliance.
 Install the indoor unit away from lighting apparatus using the ballast.
- If you use the wireless remote control, reception error may occur due to the ballast of the
lighting apparatus.
 Do not install the air conditioner in following places.
- Place where there is mineral oil or arsenic acid. Resin parts flame and the accessories may drop
or water may leak. The capacity of the heat exchanger may reduce or the air conditioner may be
out of order.
- The place where corrosive gas such as sulfurous acid gas generates from the vent pipe or air outlet.
The copper pipe or connection pipe may corrode and refrigerant may leak.
- The place where there is a machine that generates electromagnetic waves. The air conditioner
may not operate normally due to control system.
- The place where there is a danger of existing combustible gas, carbon fiber or flammable dust.
The place where thinner or gasoline is handled. Gas may leak and it may cause fire.
English 17
Preparation for installation
When deciding on the location of the air conditioner with the owner, the following restrictions must be taken into
account.
General
Do NOT install the air conditioner in a location where it will come into contact with the following elements :
◆ Combustible gases
◆ Saline air
◆ Machine oil
◆ Sulphide gas
◆ Special environmental conditions
If you must install the unit in such conditions, first consult your dealer.
Avoid installing the air conditioner :
◆ In areas where it is exposed to direct sunlight. Close to heat sources.
◆ In damp areas or locations where it could come into contact with water. (for example rooms used for laundry)
◆ In areas where curtains and furniture could affect the supply and discharge of air.
◆ Without leaving the required minimum space around the unit. (as shown in the drawing)
◆ In scarcely ventilated areas.
◆ On surfaces that are unable to support the weight of the unit without deforming, breaking or causing
vibrations during the use of the air conditioner.
◆ In a position that does not enable the condensate drainage pipe to be correctly installed. (at the end of the
installation. It is always essential to check the efficiency of the drainage system)
Accessories
◆ The following accessories are supplied with the indoor unit.
The type and quantity may differ depending on the specifications.
User & Installation
manual(1)
Rubber(8)
Clamp hose(1)
Flexible hose (1)
Thermal insulation
sponge A (1)
Thermal insulation
sponge B (1)
Thermal insulation
sponge C (1)
Cable-tie(8)
18 English
Insulation drain (1)
Deciding on where to install the indoor unit
Indoor unit
There must be no obstacles near the air inlet and outlet.
Install the indoor unit on a ceiling that can support its weight.
Maintain sufficient clearance around the indoor unit.
Make sure that the water dripping from the drain hose runs away correctly and safely.
The indoor unit must be installed in this way, that they are out of public access. (Not touchable by the users)
After connecting a chamber, insulate the connection part between the indoor unit and the chamber with t10
or thicker insulation. Otherwise, there can be air leak or dew from the connection part.
ENGLISH
◆
◆
◆
◆
◆
◆
Space requirements for installation & service
■ Construction Standard for Inspection Hole
Unit Depth(D)
1) In case, the ceiling is tex tile, Inspection hole dose not need.
2) In case, the ceiling is plaster board, Inspection hole depends on Inside height of the ceiing.
a. Height is more than 0.5m : Only "B" [Inspection for PBA] is applied.
b. Height is less than 0.5m : Both "A"&"B" are applied.
c. "A"&"B" are inspection holes .
Unit Width(W)
"A"=W+100mm
"B"=500mm
20mm or more
20mm or more
 You must have20mm or more space between the ceiling and the bottom of indoor unit. Otherwise, the noise
from the vibration of indoor unit may bother the user.When the ceiling is under construction, the hole for
check-up must be made to take service, clean and repair the unit.
 It is possible to install the unit at an height of between 2.2~2.5m from the ground,if the unit has a duct with a
well defined lenght (300mm or more), to avoid fan motor blower contact.
If you install the cassette or duct type indoor unit on the ceiling with humidity over 80%, you must apply extra
10mm of polyethylene foam or other insulation with similar material on the body of the indoor unit.
English 19
Deciding on where to install the indoor unit
Insulation Guide
B
D
Back
Front
A
C
Thickness: more than 10mm
Indoor Unit
AC052NNMSEC
1150x480x260
AC071NNMSEC
AC090NNMSEC
1150x480x320
AC100NNMSEC
AC120NNMSEC
AC140NNMSEC
1200x650x360
AC160NNMSEC
A
B
C
D
1150x480 1150x480 480x260 480x260
Insulate the front and
back side in proper size
1150x480 1150x480 480x320 480x320 at the same time when
insulating the suction
duct and discharge
1200x650 1200x650 650x360 650x360
duct.
◆ Insulate the end of the pipe and some curved area by using separate insulator.
◆ Insulate the discharge and suction part at the same time when you insulate connection duct.
20 English
Front/Back
AC052NNMSEC / AC071NNMSEC
Unit:mm
ENGLISH
530
480
18-Ø3.2 hole
1150
904 (Air outlet duct flange)
6X135=810
97
1188 (Suspension position)
1150
1250
397 (Suspension position)
(Air around)
220
500
90
67
117
90
260
185
Inspection hole
Discharge side
ODØ32
No.
Suction side
76
132
144
Name
1
Liquid pipe connection
2
Gas pipe connection
3
4
5
6
7
8
Drain pipe connection
Drain pipe connection
Power supply connection
Air discharge flange
Air filter
Hook
Description
ø6.35(1/4")
∗∗052∗∗ : ø12.70(1/2");
∗∗071∗∗ : ø15.88(5/8")
OD25 ID20(without drain pump)
Using drain pump (Optional)
M8~M10
English 21
Deciding on where to install the indoor unit
AC090NNMSEC / AC100NNMSEC
Unit:mm
530
500
102
1150
1250
(Air outlet duct flange)
(Suspension position)
(Suspension position)
Discharge side
No.
1
2
3
4
5
6
7
8
22 English
Inspection hole
Suction side
Name
Liquid pipe connection
Gas pipe connection
Drain pipe connection
Drain pipe connection
Power supply connection
Air discharge flange
Air filter
Hook
Description
ø9.52(3/8")
ø15.88(5/8")
OD25 ID20(without drain pump)
Using drain pump (Optional)
M8~M10
AC120NNMSEC / AC140NNMSEC / AC160NNMSEC
Unit:mm
ENGLISH
700
650
1300
1200
1000 (Air outlet duct flange)
500
102
1236 (Suspension position)
534 (Suspension position)
Discharge side
No.
Suction side
Inspection hole
Name
1
Liquid pipe connection
2
Gas pipe connection
3
4
5
6
7
8
Drain pipe connection
Drain pipe connection
Power supply connection
Air discharge flange
Air filter
Hook
Description
ø9.52(3/8")
∗∗120/140∗∗ : ø15.88(5/8");
∗∗160∗∗ : ø19.05(3/4")
OD25 ID20(without drain pump)
Using drain pump (Optional)
M8~M10
English 23
Indoor unit installation
When deciding on the location of the air conditioner with the owner, the following restrictions must be taken into account.
1
Place the pattern sheet on the ceiling at the spot where you
want to install the indoor unit.
NOTE
•Since the diagram is made of paper, it may shrink or stretch slightly
due to temperature or humidity. For this reason, before drilling the
holes maintain the correct dimensions between the markings.
2
Insert bolt anchors. Use existing ceiling supports or construct a
suitable support as shown in figure.
3
Install the suspension bolts depending on the ceiling type.
CAUTION
• Ensure that the ceiling is strong enough to support the
weight of the indoor unit. Before hanging the unit, test the
strength of each attached suspension bolt.
• If the length of suspension bolt is more than 1.5m,
it is required to prevent vibration.
• If this is not possible, create an opening on the false ceiling
in order to be able to use it to perform the required operations on the indoor unit.
4
Concrete
Insert
Hole in anchor
hole in plug
Suspension bolt(M8)-field supply
Ceiling support
Screw eight nuts to the suspension bolts making space for hanging the indoor unit.
NOTE
• You must install all the suspension rods.
5
Hang the indoor unit to the suspension bolts between two nuts.
CAUTION
• Piping must be laid and connected inside the ceiling when
suspending the unit. If the ceiling is already constructed,
lay the piping into position for connection to the unit before
placing the unit inside the ceiling.
6
Screw the nuts to suspend the unit.
7
Adjust level of the unit by using measurement plate for all 4 sides.
CAUTION
•For proper drainage of condensate, give a 3mm slant to the
left or right side of the unit which will be connected with
the drain hose, as shown in the figure. Make a tilt when you
wish to install the drain pump, too.
•When installing the indoor unit, make sure it is not tilted
toward front or back side.
24 English
When the drain hose is installed to the right.
3mm
Drain hose port
Purging the unit
From factory the unit is supplied and set with a pre-charge of nitrogen gas. (insert gas) Therefore, all insert gas must be
purged before connecting the assembly piping.
Unscrew the pinch pipe at the end of each refrigerant pipe.
Liquid refrigerant port
Gas refrigerant port
NOTE
ENGLISH
RESULT : All inert gas escapes from the indoor unit.
•To prevent dirt or foreign objects from getting into the pipes during
installation, do NOT remove the pinch pipe completely until you are
ready to connect the piping.
CAUTION
•Connect the indoor and outdoor units using pipes with flared
connections(not supplied). For the lines, use insulated,
unwelded, degreased and deoxidized copper pipe (Cu DHP
type to ISO 1337 or UNI EN 12735-1), suitable for operating
pressures of at least 4200kPa and for a burst pressure of at
least 20700kPa. Copper pipe for hydro-sanitary applications
is completely unsuitable.
•For sizing and limits (height difference, line length, max.
bends, refrigerant charge, etc.) see the outdoor unit
installation manual.
• All refrigerant connection must be accessible, in order to
permit either unit maintenance or removing it completely.
 The designs and shape are subject
to change according to the model.
English 25
Connecting the refrigerant pipe
There are two refrigerant pipes of different diameters :
◆ A smaller one for the liquid refrigerant
◆ A larger one for the gas refrigerant
◆ The inside of copper pipe must be clean & has no dust
1. Remove the pinch pipe on the pipes and connect the assembly pipes to each pipe, tightening the nuts, first
manually and then with a torque wrench, a spanner applying the following torque.
Refrigerant oil
Torque wrench
Spanner
Flare nut
Union
Outer Diameter (D)
ø6.35 mm
ø9.52 mm
ø12.70 mm
ø15.88 mm
ø19.05 mm
Torque (N•m)
14 ~18
34 ~ 42
49 ~ 61
68 ~ 82
100 ~ 120
NOTE
•If the pipes must be shortened refer to page 27.
2. Must use insulator which is thick enough to cover the refrigerant tube to protect the condensate water on the
outside of pipe falling onto the floor and the efficiency of the unit will be better.
3. Cut off any excess foam insulation.
4. Be sure that there must be no crack or wave on the bended area.
5. It would be necessary to double the insulation thickness(10mm or more) to prevent condensation even on the
insulator when if the installed area is warm and humid.
6. Do not use joints or extensions for the pipes that connect the indoor and outdoor unit. The only permitted
connections are those for which the units are designed.
Liquid refrigerant port
Gas refrigerant
port
Drain hose connection port
 The designs and shape are subject to change according to the model.
26 English
Cutting/Flaring the pipes
1. Make sure that you have the required tools available. (pipe cutter, reamer, flaring tool and pipe holder)
2. If you wish to shorten the pipes, cut it with a pipe cutter, taking care to ensure that the cut edge remains at a 90°
angle with the side of the pipe. Refer to the illustrations below for examples of edges cut correctly and incorrectly.
Oblique
Rough
ENGLISH
Pipe
cutter
Burr
Pipe
3. To prevent any gas from leaking out, remove all burrs at the cut edge of the pipe, using a reamer.
4. Slide a flare nut on to the pipe and modify the flare.
Pipe
Flare
Outer Diameter (D)
ø6.35 mm
ø9.52 mm
ø12.70 mm
ø15.88 mm
ø19.05 mm
Depth (A)
1.3 mm
1.8 mm
2.0 mm
2.2 mm
2.2 mm
5. Check that the flaring is correct, referring to the illustrations below for examples of incorrect flaring.
Damaged
Surface
Cracked
Connection torque (N•m) Flare dimension (L,mm)
Ø 6.35
14~18
8.7~9.1
Ø 9.52
34~42
12.8~13.2
Ø 12.70
49~61
16.2~16.6
Ø 15.88
68~82
19.3~19.7
Ø 19.05
100~120
23.6~24.0
Uneven
Thickness
Flare shape (mm)
90° ±2°
Outer diameter (D,mm)
Inclined
45° ±2°
Correct
L
R 0.4~0.8
D
CAUTION
•If the pipes require brazing ensure that OFN (Oxygen Free Nitrogen) is flowing through the
system.
•Nitrogen blowing pressure range is 0.02 ~ 0.05MPa.
English 27
Performing leak test & insulation
Leak test
◆ LEAK TEST WITH NITROGEN (before opening valves)
In order to detect basic refrigerant leaks, before recreating the vacuum
and recirculating the R410A, it’s responsable of installer to pressurize the
whole system with nitrogen (using a cylinder with pressure reducer) at a
pressure above 2 bar, less than 40 bar (gauge).
◆ LEAK TEST WITH R410A (after opening valves)
Before opening valves, discharge all the nitrogen into the system and
create vacuum. After opening valves check leaks using a leak detector for
refrigerant R410A.
CAUTION
•Discharge all the nitrogen to create a vacuum and charge
the system.
 The designs and shape are subject to
change according to the model.
Insulation
Once you have checked that there are no leaks in the system, you can insulate the piping and hose.
1 To avoid condensation problems, place Acrylonitrile Butadien Rubber
separately around each refrigerant pipe.
No gap
NOTE
•Always make the seam of pipes face upwards.
2 Wind insulating tape around the pipes and drain hose avoiding to
compress the insulation too much.
3 Finish wrapping insulating tape around the rest of the pipes leading to the outdoor
unit.
4 The pipes and electrical cables connecting the indoor unit with the
outdoor unit must be fixed to the wall with suitable ducts.
NBR
Insulation cover pipe
Insulation pipe
Indoor unit
CAUTION
•All refrigerant connection must be accessible, in order to
permit either unit maintenance or removing it completely.
5 Select the insulation of the refrigerant pipe.
 Insulate the gas side and liquid side pipe referring to the thickness according to the pipe size.
 Indoor temperature of 30°C and humidity of less than 85% is the standard condition.
If installing in a high humidity condition, use one grade thicker insulator by
referring to the table below.
If installing in an unfavorable conditions, use thicker one.
 Insulator’s heat-resistance temperature should be more than 120°C.
28 English
Be sure to overlap
the insulation
CAUTION
•Must fit tightly against
body without any gap.
Pipe size
Liquid
pipe
Ø6.35 ~ Ø9.52
Ø12.7 ~ Ø19.05
Ø6.35
Ø9.52
Ø12.70
Ø15.88
Ø19.05
Gas
pipe
19t
25t
Remarks
Internal temperature
is higher than 120°C
ENGLISH
Pipe
Insulation Type (Heating/Cooling)
High humidity [30°C, over
Standard [30°C, 85%]
85%]
EPDM, NBR
9t
9t
13t
13t
13t
19t
◆ When installing insulation in places and conditions below, use the same insulation that is used for high humidity
conditions.
<Geological condition>
- High humidity places such as shoreline, hot spring, near lake or river, and ridge (when the part of the building is
covered by earth and sand.)
<Operation purpose condition>
- Restaurant ceiling, sauna, swimming pool etc.
<Building construction condition>
- The ceiling frequently exposed to moisture and cooling is not covered.
e.g. The pipe installed at a corridor of a dormitory and studio or near an exit that opens and closes frequently.
- The place where the pipe is installed is highly humid due to the lack of ventilation system.
English 29
Drainpipe and drain hose installation
Care must be taken when installing the drain hose for the indoor unit to ensure that any condensate
water is correctly drained outside.
The drain hose can be installed to the right of the base pan.
1
Installing the drain hose should be the shorter, the better.
◆ In order to discharge condensation water, the drain hose should keep tilted.
◆ Fix the drain hose with Cable-Tie, so that it will not separate from the machine.
◆ While using draining pump, connect the end with draining pump.
2
Insulate and fix the drain hose according to the figure.
◆ Insert the drain hose to bottom of the outfall of water basin.
◆ Lock steel ring of the drain hose according to the figure.
◆ Wind and wrap steel ring and drain hose fully with thermal insulation sponge; fix both ends of
external layer with ribbon for thermal insulation.
◆ After being installed, drain hose must be insulated fully by heat insulating material. (To be
provided at site.)
Indoor unit
Steel ring of drain hose
Fix with Cable-Tie
Joint of drain hose
Drain hose
Drain hose
As shown in the figure, tighten steel ring
of the drain hose.
A-A’
Wrap thermal sleeve hose
Drainpipe Connection
Without the drain pump
1.
Install horizontal drainpipe with a slope of 1/100 or more and fix it by hanger space of 1.0~1.5m.
2. Install U-trap at the end of the drainpipe to prevent a nasty smell to reach the indoor unit.
3. Do not install the drainpipe to upward position. It may cause water flow back to the unit.
1~1.5m
Flexible hose
Ceiling
30 English
Hanger
Horizontal drainpipe
more than 1/100 slope
With the drain pump
2. Install horizontal drainpipe with a slope of 1/100 or more and fix it by hanger space of 1.0~1.5m.
3 Install the air vent in the horizontal drainpipe to prevent water flow back to the indoor unit.
ENGLISH
1. The drain pipe should be installed within 300mm to 550mm from the flexible hose and then lift down
20mm or more.
NOTE
• You may not need to install it if there were proper slope in the horizontal drainpipe.
4 The flexible hose should not be installed upward position, it may cause water flow back to the indoor
unit.
1~1.5m
Air vent
200mm
or more
300mm or less
Hanger
20mm
or more
Within
300~550mm
Flexible hose Ceiling
Horizontal drainpipe
more than 1/100 slope
Testing the drainage
Prepare a little water about 2 liter.
1
Pour water into the base pan in the indoor unit as shown in
figure.
2
Confirm that the water flows out through the drain hose.
English 31
Connecting the connection cord
CAUTION
•Always remember to connect the refrigerant pipes before performing the electric connections.
When disconnecting the system, always disconnect the electric cables before disconnecting the
refrigerant pipes.
•Always remember to connect the air conditioner to the grounding system before performing the
electric connections.
The indoor unit is powered by the outdoor unit by means of a H07 RN-F connection cable (or a more power model),
with insulation in synthetic rubber and jacket in polychloroprene(neoprene), in accordance with the
requirements of standard EN 60335-2-40.
1. Remove the screw on the electrical component box and remove the cover plate.
2. Route the connection cord through the side of the indoor unit and connect the cable to terminals; refer to the
figure below.
3. Route the other end of the cable to the outdoor unit through the ceiling & the hole on the wall.
4. Reassemble the electrical component box cover, carefully tightening the screw.
Wiring diagram
1 phase (∗∗052/071/090∗∗)
3 phase (∗∗100/120/140/160∗∗)
Indoor Unit
1(L)
2(N)
1
1(L) 2(N)
2
L
Indoor Unit
F1
F2
V1
V2
F3
F4
1(L)
2(N)
1
2
F2
V1
V2
F3
F4
N
1(L) 2(N) L1(R) L2(S) L3(T)
Cable tie
Indoor Power
Communication cable
Main power cable Cable clamp
32 English
F1
N
F1
F2
Cable tie
Cable clamp
Indoor Power
3 Phase 4 Wires Communication cable
power cable
(AC 380V)
Between Indoor and Outdoor Connection cable Specifications(Common in use)
Indoor Power supply
Max/Min(V)
Indoor Power cable
220-240V~/50Hz
±10%
1.5mm²↑,3wires
Communication Cable
0.75~1.5mm²,2wires
❈ Power supply cords of parts of appliances for outdoor use shall not be lighter than polychloroprene sheathed flexible
cord. (Code designation IEC:60245 IEC 57 / CENELEC: H05RN-F or IEC:60245 IEC 66 / CENELEC: H07RN-F)
❈ Screws on terminal block must not be unscrewed with the torque less than 12 kgf•cm.
❈ Since it has the external power supply, refer to the outdoor unit installation manual for MAIN POWER.
ENGLISH
Power Supply
When installing the indoor unit in a computer room, use the double
shielded(Tape aluminum / polyester braid + copper)cable of FROHH2R type.
Terminal Block SPEC (Indoor)
13
COMMUNICATION : M3.5 SCREW
7.5
18
11
9.0
13
AC POWER : M4 SCREW
English 33
Extending the power cable
1) Prepare the following tools.
Tools
Crimping pliers
Connection sleeve
(mm)
Insulation tape
Contraction tube
(mm)
Spec
MH-14
20xØ6.5(HxOD)
Width 19mm
70xØ8.0(LxOD)
Shape
2) As shown in the figure, peel off the shields from the rubber and wire
of the power cable.
Power cable
-- Peel off 20 mm of cable shields from the pre-installed tube.
20
CAUTION
20
20
60
120
•For information about the power cable specifications for indoor
and outdoor units, refer to the installation manual.
•After peeling off cable wires from the pre-installed tube, insert
a contraction tube.
180
(Unit: mm)
20
Pre-installed tube for the power cable
3) Insert both sides of core wire of the power cable into the connection
sleeve.
ffMethod 1
Push the core wire into the sleeve from both sides.
Connection sleeve
ffMethod 2
Twist the wire cores together and push it into the sleeve.
Connection sleeve
4) Using a crimping tool, compress the two points and flip it over and compress another two points in the
same location.
-- The compression dimension should be 8.0.
-- After compressing it, pull both sides of the wire to make sure it is firmly pressed.
Compression
dimension
ffMethod 1
ffMethod 2
Compress it 4 times.
5 mm
34 English
Compress it 4 times.
5 mm
5) Wrap it with the insulation tape twice or more and position your contraction tube in the middle of the
insulation tape.
Three or more layers of insulation are required.
ffMethod 2
Insulation tape
ENGLISH
ffMethod 1
Insulation tape
40 mm
35 mm
6) Apply heat to the contraction tube to contract it.
Contraction tube
7) After tube contraction work is completed, wrap it with the insulation tape to finish.
CAUTION
•Make sure that the connection parts are not exposed to outside.
•Be sure to use insulation tape and a contraction tube made of approved reinforced insulating
materials that have the same level of withstand voltage with the power cable. (Comply with the
local regulations on extensions.)
Insulation tape
WARNING
•In case of extending the electric wire, please DO NOT use a round-shaped Pressing socket.
-- Incomplete wire connections can cause electric shock or a fire.
English 35
Adjusting air flow
E. S. P(External Static Pressure) setting for phase control motor
With its phase control motor, you can adjust the indoor unit fan speed depending on the installation condition.
If the external static pressure is high so that the duct becomes longer or if the external static pressure is low so
that the duct becomes shorter, adjust the fan speed by referring the following table.
Model
AC052NNMSEC
Static Pressure (mmAq)
SP=3
AC071NNMSEC
Option code for indoor unit
01B152-1D0561-234700-340102
01B152-1D0928-247700-340102
3<SP≤6
01B152-1D05E8-234700-340102
01B152-1D098D-247700-340102
6<SP≤9
01B152-1D0A60-234700-340102
01B152-1D0AF2-247700-340102
9<SP≤12
01B152-1D0AD4-234700-340102
01B152-1D0E46-247700-340102
12<SP≤15
01B152-1D0E39-234700-340102
01B152-1D0E9B-247700-340102
Model
AC090NNMSEC
AC100NNMSEC
Static Pressure (mmAq)
Option code for indoor unit
SP=4
01B152-1D0921-25A700-340122
01B152-1D0921-264710-340122
4<SP≤8
01B152-1D09C7-25A700-340122
01B152-1D09C7-264710-340122
8<SP≤12
01B152-1D0D2C-25A700-340122
01B152-1D0D2C-264710-340122
12<SP≤15
01B152-1D0E60-25A700-340122
01B152-1D0E60-264710-340122
Model
AC120NNMSEC
Static Pressure (mmAq)
AC140NNMSEC
AC160NNMSEC
Option code for indoor unit
SP=5.2
01B152-1D047C278710-340142
01B152-1D047C28C710-340142
01B152-1C09242A0710-340142
5.2<SP≤8
01B152-1D04CD278710-340142
01B152-1D04CD28C710-340142
01B152-1C09782A0710-340142
8<SP≤12
01B152-1D0912278710-340142
01B152-1D091228C710-340142
01B152-1C09CC2A0710-340142
12<SP≤15
01B152-1D0974278710-340142
01B152-1D097428C710-340142
01B152-1C09FF2A0710-340142
NOTE
•
represents E. S. P(External Static Pressure) range of factory setting.
You don’t have to adjust the fan speed separately if the external static pressure of the installation place is in
. When it is out of
, input the appropriate option code.
• If you input the inappropriate option code, error may occur or the air conditioner is out of order. The
option code must be inputted correctly by the installation specialist or service agent.
36 English
Easy Tuning
EASY Tuning
SEG Used
Main Menu Sub-menu
56
ENGLISH
If the more cooling and heating airflow rate which set up when installing is wanted, or if the more Silent operation which sets up when installing is wanted, air conditioner is tuned for comfort.
Indoor unit airflow rate for high, mid, low mode increases or decreases for +2 ~ -2 Steps with wired remocon.
1 2 3 4
1. Press the User Set button.
 (Main Menu) will be displayed, and you can press the
[Λ]/[V] buttons to select No. 8, which will set the Easy
Tuning.
2. Press the [>] button to select airflow step.
 Press the [Λ]/[V] buttons to select airflow step(-2,1,0,1,2) tuning (During the Easy Tuning setting, AC Fan
Speed icon will be displayed)
3) Press the
button to complete the Easy Tuning.
(When the Easy Tuning setting complete, AC Fan Speed icon will be off)
4) Press the
Main menu
8
button to to exit to normal mode.
Sub menu
-
Functions
Easy Tuning
SEG used
1,2
Default
Range
0
-2 : -2 Step
-1 : -1 Step
0 : No Use
1 : +1 Step
2 : +2 Step
NOTE
•Press the
button anytime during setup to exit without setting.
•According to airflow changed from the Easy Tuning,Air conditioning performance reducing is
possible.
English 37
Setting the indoor unit option code
In order to set the indoor unit option code use the wired remote controller and follow the directions below.
Data bit
Main Menu Sub-menu
56
Page number
Option Code Option Code
1 2 3 4
56
SEG1
0
1 2 34
SEG2
SEG3
SEG4
SEG5
SEG6
✴
✴
✴
✴
✴
Page number
SEG7
1
SEG8
SEG9
✴
✴
SEG10 SEG11 SEG12
✴
✴
✴
Page number
SEG13 SEG14 SEG15 SEG16 SEG17 SEG18
✴
✴
✴
✴
✴
2
Page number
SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
✴
✴
✴
✴
✴
3
Page number
1) Press the
displayed.
and
buttons at the same time for more than 3 seconds and then a Main menu will be
2) Press the
/
button to select
3) Press the
/
button to select
and then press
and then press
button to enter a Sub-menu setting screen.
button to enter a Indoor unit option code setting screen.
NOTE
•The first digit represents the page number and the remaining five digits are option codes.
•The option code which is currently setting will flicker.
4) Press the
/
5) Press the
button to save and complete the option setting.
6) Press the
button to exit to normal mode.
button to set the option code in order. Press
button to go to the next page.
NOTE
•Press the
button anytime during setup to exit without setting.
CAUTION
•Option code will not be applied if you don’t press the
•Setting indoor unit option code is only possible in Master wired remote controller.
You can only check the indoor unit option code in Slave wired remote controller.
•Setting indoor unit option code is possible when one indoor unit is connected. If more than 2
indoor units are connected, you can only check the Master indoor unit option code.
38 English
Setting an indoor unit address and installation option
Set the indoor unit address and installation option with remote controller option. Set the each option
separately since you cannot set the ADDRESS setting and indoor unit installation setting option at the
same time. You need to set twice when setting indoor unit address and installation option.
1) Press the
displayed.
and
buttons at the same time for more than 3 seconds and then a Main menu will be
2) Press the
/
button to select
3) Press the
/
button to select and then press
and then press
ENGLISH
Setting an indoor unit address
button to enter a Sub-menu setting screen.
button to enter a Indoor Address setting screen.
Data bit
1 2 34
56
NOTE
•The Main/RMC Address which is currently setting will flicker.
•Data bit 1 and 2 present Indoor unit main address checking
•Data bit 3 and 4 present Indoor unit main address setting(outdoor unit reset is needed to set).
•Data bit 5 and 6 present Indoor unit RMC address setting/checking.
4) Press the
/
5) Press the
button to save and complete the option setting.
button to set the Indoor unit Main/RMC Address.
6) Press the
button to exit to normal mode.
NOTE
•Press the
button anytime during setup to exit without setting.
•Address will not be applied if you don't press
button.
•Setting Main/RMC Address of an Indoor unit is available only with a master wired remote controller.
English 39
Setting an indoor unit address and installation option
Setting an indoor unit installation option
In order to check and set the indoor unit installation option code use the wired remote controller and
follow the directions below.
1) Press the
displayed.
and
2) Press the
/
buttons at the same time for more than 3 seconds and then a Main menu will be
button to select
and then press
button to enter a Sub-menu setting screen.
3) Press the
/
button to select
code setting screen.
and then press
button to enter a Indoor unit installation option
NOTE
•The first digit represents the page number and the remaining five digits are installation option.
•The total option codes are 24 digits. You can set six digits at a time and it is distinguished by page
number (0, 1, 2, 3).
4) Press the
page.
SGE1
0
/
button to set the installation option code in order. Press
SGE2
2
button to go to the next
SGE3
SGE4
SGE5
SGE6
RESERVED
Exterior temperature
sensor
Central control
RESERVED
SEG7
SEG8
SEG9
SEG10
SEG11
SEG12
1
Drain pump
RESERVED
RESERVED
RESERVED
RESERVED
SEG13
SEG14
SEG15
SEG16
SEG17
SEG18
2
External control
External control
output
S-Plasma ion
Buzzer
Number of hours
using filter
SEG19
SEG20
SEG21
-
-
-
3
Individual control of a
remote controller
Heating setting
compensation
-
-
-
40 English
Option No. : 02XXXX-1XXXXX-2XXXXX-3XXXXX
Option
SEG1
SEG2
Explanation
PAGE
MODE
Indication Details Indication Details
0
2
Option
SEG7
SEG8
Explanation
PAGE
Use of drain pump
RESERVED
SEG13
Explanation
PAGE
0
SEG14
Use of external
control
RESERVED
RESERVED
RESERVED
RESERVED
SEG15
Setting the output of
external control
SEG16
SEG17
S-Plasma ion
Buzzer control
SEG18
Number of hours
using filter
0
Thermo on
0
1
ON/OFF
Control
1
Operation
on
1
OFF
Control
SEG20
control of a remote
controller
2
SEG19
PAGE
Details
0 or 1
Indoor 1
0
Disuse
2
Indoor 2
1
2°C
3
Indoor 3
4
Indoor 4
2
5°C
3
Indication Details Indication
SEG21
Heating setting
compensation
Indication Details Indication Details Indication
Indication
and Details
Use
SEG12
Disuse
Option
1
RESERVED
SEG11
0
Explanation
Use
Disuse
SEG10
Details
2
0
1
Indication Details Indication Details Indication
Indication
and Details
Disuse
SEG6
SEG9
Indication Details Indication Details
0
Disuse
1
Use
Indication
and Details
1
Use +
2
3minute
delay
Option
SEG4
SEG5
Use of external
Use of central control
temperature sensor
Indication Details Indication Details
5. Press the
button to save and complete the option setting.
6. Press the
button to exit to normal mode.
Details
ENGLISH
Indication
and Details
SEG3
Indication Details
Disuse
0
Use of
buzzer
2
1000
Hour
Use
1
Non use
of buzzer
6
2000
Hour
-
-
-
-
-
-
-
-
-
-
-
-
NOTE
•Press
button anytime during setup to exit without setting.
•Option code will not be applied if you don't press
button.
•Setting Installation option code is available only with a master wired remote controller.
•Setting Installation option code is available when there is one on one connection between a wired
remote controller and an indoor unit.
English 41
Troubleshooting
 If an error occurs during the operation, one or more LED flickers and the operation is stopped except the LED.
 If you re-operate the air conditioner, it operates normally at first, then detect an error again.
LED Display on the receiver & display unit
Indicators
Concealed Type
Abnormal conditions
Green
Remarks
Red
Standard Type
Power reset
X
Error of Room sensor in the indoor
unit(Open/Short)
X
Error of EVA-IN,EVA-OUT sensor in the
indoor unit(Open/Short)
X
X
X
X
X
X
X
X
Error of Fan motor in the indoor unit
X
X
Error of Terminal Block's Thermal Fuse(Open)
X
X
Clogging of outdoor's service valve
Detection of the float switch
X
X
X
X
X
X
X
X
EEPROM error
EEPROM option setting error
 On
Flickering
X Off
 If you turn off the air conditioner when the LED is flickering, the LED is also turned off.
42 English
Wired remote controller
Display
Explanation
ENGLISH
◆If an error occurs,
is displayed on the wired remote controller.
If you would like to see an error code, press the Test button.
Remark
Error of Room sensor in the indoor unit(Open/Short)
Error of EVA-IN,EVA-OUT sensor in the indoor unit(Open/Short)
2nd Detection of the float switch
Error of Fan motor in the indoor unit
EEPROM error
EEPROM option setting error
Error of Terminal Block's Thermal Fuse(Open)
Clogging of outdoor's service valve
Error of communication down between the indoor unit
and wired remote controller after 3minutes.
Error of communication down between the indoor unit
and wired remote controller after completion of 10 times tracking.
COM1/COM2 Cross-installed error
Wired remote controller
error
Error of master wired remote controller and slave wired remote
controller setting
English 43
QUESTIONS OR COMMENTS?
COUNTRY
CALL
INDONESIA
021-5699-7777
0800-112-8888 (All Product, Toll Free)
0800-112-7777 (Only for HHP, Toll Free)
www.samsung.com/id/support
MALAYSIA
1800-22-8899 (HHP)
1800-88-9999 (OTH)
+603-7713 7420 (Overseas contact)
www.samsung.com/my/support
VIETNAM
1800 588 889 (OTH)
1800-588-855 (HHP)
www.samsung.com/vn/support
SOUTH AFRICA
0860 SAMSUNG (726 7864)
NAMIBIA
08197267864
ZAMBIA
3434
MAURITIUS
800 2550
REUNION
0262 50 88 80
ANGOLA
917 267 864
Zimbabwe
0808 0204
MOZAMBIQUE
847267864
NIGERIA
0800-726-7864
Ghana
0800-100-077
Cote D’Ivoire
8000-00-77
SENEGAL
800-00-0077
CAMEROON
67095-0077
KENYA
0800 545 545
UGANDA
0800 300 300
TANZANIA
0800 780 089
RWANDA
9999
BURUNDI
200
DRC
499999
SUDAN
1969
OR VISIT US ONLINE AT
www.samsung.com/support
www.samsung.com/africa_en/support
www.samsung.com/africa_fr/support
www.samsung.com/support
Was this manual useful for you? yes no
Thank you for your participation!
