Vacuum cleaner
User manual
SS60K60✴✴✴✴ Series / SS60M60✴✴✴✴ Series
• Before operating this unit, please read the instructions carefully.
• For indoor use only.
Stick_VS6000_EN_00745K-02_HK.indd 1
2017-03-27 오후 6:27:42
Contents
PREPARATION
MAINTENANCE
Safety information
3
INSTALLATION
Name of the parts
11
OPERATIONS
Maintaining the vacuum cleaner
15
Disassembling / Assembling the dustbin
15
Cleaning the dustbin
15
Cleaning the sponge filter
15
Cleaning the air intake
15
APPENDICES
Using the vacuum cleaner
12
Charging the stick vacuum cleaner
12
Assembling and Disassembling a battery 12
Using the stick vacuum cleaner
13
Using the handy vacuum cleaner
13
Using the crevice tool and dusting brush 14
Using the Long Reach Tool (option)
Notes and cautions
16
Battery usage
16
Operation16
Maintenance17
Troubleshooting18
14
Accessories
Crevice tool / Dusting
brush
Power cord
Charger / battery
User manual
Long Reach Tool (option)
Spare filter
(Option)
2 English
Stick_VS6000_EN_00745K-02_HK.indd 2
2017-03-27 오후 6:27:43
PREPARATION
Safety information
• Because these following operating instructions cover various models, the
characteristics of your vacuum cleaner may differ slightly from those
described in this manual.
Preparation
• Before operating the appliance, please read this manual thoroughly and
retain it for your reference.
Caution/Warning symbols used
WARNING
Indicates that a danger of death or serious injury exists.
CAUTION
Indicates that a risk of personal injury or material damage exists.
Other symbols used
NOTE
Indicates that the following text contains additional important information.
Failure to meet these requirements could cause damage to the internal
parts and void your warranty.
English 3
Stick_VS6000_EN_00745K-02_HK.indd 3
2017-03-27 오후 6:27:43
Preparation
General
• Read all instructions carefully. Before switching on, make sure that the
voltage of your electricity supply is the same as that indicated on the
rating plate on the bottom of the cleaner.
• WARNING : Do not use the vacuum cleaner when rug or floor is wet.
• Close supervision is necessary when any appliance is used by or near
children. Do not allow the vacuum cleaner to be used as a toy. Do not
allow the vacuum cleaner to run unattended at any time. Use the vacuum
cleaner only for its intended use as described in these instructions.
• Do not use the vacuum cleaner without a dustbin.
• Empty the dustbin before it is full in order to maintain the best efficiency.
• Do not use the vacuum cleaner to pick up matches, live ashes or cigarette
butts. Keep the vacuum cleaner away from stoves and other heat sources.
Heat can deform and discolour the plastic parts of the unit.
• Avoid picking up hard, sharp objects with the vacuum cleaner as they
may damage the cleaner parts.
• Do not block the suction or the exhaust port.
• Switch the vacuum cleaner off on the body of the machine before
unplugging from the electrical outlet. Disconnect the plug from the
electrical outlet before emptying the dustbin. To avoid damage, please
remove the plug by grasping the plug itself, not by pulling on the cord.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
• Children should be supervised to ensure that they do not play with the
appliance.
4 English
Stick_VS6000_EN_00745K-02_HK.indd 4
2017-03-27 오후 6:27:43
• The use of an extension cord is not recommended.
• If your vacuum cleaner is not operating correctly, switch off the power
supply and consult an authorized service agent.
Preparation
• The plug must be removed from the socket outlet before cleaning or
maintaining the appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid a
hazard.
• Unplug the cleaner when not in use. Turn off the power switch before
unplugging.
• Do not use to suck up water.
• Do not immerse in water for cleaning.
• Please contact the manufacturer or service agent for a replacement.
Battery charger
• Do not modify the polarized plug to fit a non-polarized outlet or
extension cord.
• Do not use outdoors or on wet surfaces.
• Unplug the charger from the outlet when not in use and before servicing.
• Use only the charger supplied by the manufacturer to recharge.
• Do not use with a damaged cord or plug.
• Do not pull or carry by the cord, use the cord as a handle, close the door
on the cord, or pull the cord around sharp edges or corners. Keep the
cord away from heated surfaces.
• Do not use extension cords or outlets with inadequate current carrying
capacity.
• Do not unplug by pulling on the cord. To unplug, grasp the plug, not the
cord.
• Do not charge the non-rechargeable batteries with charger.
English 5
Stick_VS6000_EN_00745K-02_HK.indd 5
2017-03-27 오후 6:27:43
Preparation
• Do not mutilate or incinerate batteries as they will explode at high
temperatures.
• Do not attempt to open the charger. Repairs should only be carried out
by a qualified customer care centre.
• Do not expose the charger to high temperatures or allow moisture or
humidity of any kind to come into contact with the charger.
Stick vacuum cleaner
• Do not pick up hard or sharp objects such as glass, nails, screws, coins,
and etc.
• Do not use without a filter in place. When servicing the unit, never put
fingers or other objects into the fan chamber in case the unit accidentally
turns on.
• Do not put any objects into openings. Do not use with any openings
blocked; keep openings free of dust, lint, hair, and anything that may
reduce air flow.
• Do not pick up toxic materials (chlorine bleach, ammonia, drain cleaner,
etc.).
• Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
• Do not use to pick up flammable or combustible liquids such as gasoline,
nor use on areas where they may be present.
• Do not use STICK vacuum cleaner in an enclosed space filled with
vapours given off by oil based paint, paint thinner, moth proofing
substances, flammable dust, or other explosive or toxic vapours.
• Leaks from battery cells can occur under extreme usage or temperature
conditions. If the liquid gets on skin, wash quickly with water. If the
liquid gets into the eyes, flush them immediately with clean water for a
minimum of 10 minutes. Seek medical attention.
6 English
Stick_VS6000_EN_00745K-02_HK.indd 6
2017-03-27 오후 6:27:43
Preparation
Power related
WARNING
• Do not bend the power cord with excessive force or do not put heavy
object on the power cord.
––Otherwise, electric shock or fire may occur.
• If there is dust, water, etc. on the pin or contact point of the power plug,
wipe them carefully.
––Otherwise, abnormal operation or electric shock may occur.
• Do not use a power source other than national rated voltage, do not use a
multi outlet to supply power for multiple electronic appliances and do not
leave the power cord carelessly on the floor.
––Otherwise, electric shock or fire may occur.
• Do not use a damaged power plug, power cord or loose power outlet.
––Otherwise, electric shock or fire may occur.
• If the power cord is damaged, replace the power cord with a new one by
a certified repairman.
––Otherwise, electric shock or fire may occur.
Operation
WARNING
• Do not touch the terminal of a charger with chop sticks, driver, etc.
––Otherwise, fatal damage to the charger may occur.
• Make sure that the terminal of a charger should not come into contact
with a conductor such as a bracelet, watch, metal rod, nail, etc.
• Make sure that any liquid such as water or juice is not allowed to enter
the charger.
––Otherwise, electric shock or fire may occur.
English 7
Stick_VS6000_EN_00745K-02_HK.indd 7
2017-03-27 오후 6:27:43
• Do not use a charger for other purposes.
Preparation
––Otherwise, fatal damage to the charger or fire may occur.
• Do not vacuum liquid, blade, pin, ember, etc. during the cleaning.
––Otherwise, abnormal operation or product damage may occur.
• Do not step on the product body or do not give a shock to the product.
––Otherwise, an injury or product damage may occur.
• The air intake and air outlet should not be blocked during the cleaning.
––Otherwise, product malfunction or fire may occur due to overheating of
the product.
• This product is intended for household use, so do not use this product for
a heavy duty.
––Otherwise, abnormal operation or product damage may occur.
––Outdoor cleaning: stone and cement
––Billiards: chalk powder
––Hospital aseptic room
• Do not use the product near a heating appliance such as a heater,
combustible spray and flammable materials.
––Otherwise, fire or product deformation may occur.
• Before using the product, the sponge filter should be inserted.
––Otherwise, dust can enter the motor inside the main body and it may
cause product damage.
• When there is gas leakage or combustible spray is used, do not touch the
power outlet with with hands and open the window for ventilation.
––Otherwise, explosion or fire may occur.
• When a strange sound, smell, smoke arises, turn off the product
immediately and contact a service center.
––Otherwise, electric shock or fire may occur.
8 English
Stick_VS6000_EN_00745K-02_HK.indd 8
2017-03-27 오후 6:27:43
CAUTION
––When the handy vacuum cleaner is not assembled to the main body, the
stick vacuum cleaner does not work.
Preparation
• Before using the stick vacuum cleaner, check that the handy vacuum
cleaner is assembled to the main body correctly.
• Do not use the product near a combustible material.
––In a place where candlelight or desk lamp is placed on the floor.
––In a place where heating is turned on without supervision or an ember
exists.
––In a place where combustible materials such as gasoline, alcohol,
thinner, ashtray with unextinguished cigarette, etc. exist.
• Make sure a child does not step onto the charger or sit on the charger.
––Otherwise, the child may fall and be injured or fatal product damage
may occur.
• Before plugging or unplugging the charger, turn off the main body and
handy vacuum cleaner and make sure that the pin of power plug should
not come into contact with your hands.
––Otherwise, fire or electric shock may occur.
Maintenance
WARNING
• Do not use the vacuum cleaner for other than cleaning purpose.
––Otherwise, an injury or product damage may occur.
• When removing foreign matters inside the product, you should turn
off the the vacuum cleaner first and use a tool to remove the foreign
matters.
––If the product operates while you are removing the foreign matters, an
injury or product damage may occur.
English 9
Stick_VS6000_EN_00745K-02_HK.indd 9
2017-03-27 오후 6:27:43
Preparation
• When cleaning the exterior of the product, turn off the product first and
then wipe it with dry towel. Do not spray water directly onto the product
or wipe it with volatile materials such as benzene, thinner or alcohol.
––If water gets into the product and an error occurs, turn off the product
and contact a service center.
• After unplugging the product, clean the charger.
• When cleaning the washable parts, do not use alkaline detergent, acid,
industrial detergent, air freshener, acetic acid, etc.
––Otherwise, product damages such as plastic breakage, deformation,
discoloration, printing deterioration, etc. may occur.
Washable Parts
Available detergent
Dustbin, sponge
Neutral
Dish washing detergent
Alkaline
Lox, mold cleaner, etc.
Acid
Prohibited
detergent
Industrial cleaners
Air freshener
Paraffin oil, an emulsifier, etc.
NV-I, PB-I, Opti, alcohol, acetone, benzene,
thinner, etc.
Jet spray air fresheners (coffee flavor, herb,
etc.)
Oils
Animal oils, vegetable oils
Etc.
Edible acetic acid, vinegar, glacial acetic
acid, etc.
CAUTION
• Do not push the stick vacuum cleaner while it stands as it may fall.
––Otherwise, an injury, product damage, or floor damage may occur.
10 English
Stick_VS6000_EN_00745K-02_HK.indd 10
2017-03-27 오후 6:27:43
INSTALLATION
Name of the parts
09
08
07
10
06
"Click"
Installation
05
11
04
12
03
13
14
02
01
15
01 Air intake
02 Dustbin
03 Dustbin release button
04 Handy vacuum cleaner power button
05 Handy vacuum cleaner
06 Handy vacuum cleaner release button
07 Turbo button
08 Power button
09 Handle
10 Crevice tool / Dusting brush
11 LED display
12 Battery
13 Air outlet
14 Battery release button
15 Air intake release button
❇❇ Battery Spec
SS60K60✴✴✴✴ series : Lithium-ion 21.6 V , 1800 mAh, 6 cell
SS60M60✴✴✴✴ series : Lithium-ion 18.0 V , 1800 mAh, 5 cell
❇❇ Those two batteries are not compatible with each other.
English 11
Stick_VS6000_EN_00745K-02_HK.indd 11
2017-03-27 오후 6:27:43
OPERATIONS
Using the vacuum cleaner
Charging the stick vacuum cleaner
NOTE
• Assemble the battery into the charger completely.
• Battery level indicator blinks while the battery is charging.
LED display
Operations
01 Battery level indicator
01
02 Turbo mode indicator
02
SS60K60✴✴✴✴ Series
SS60M60✴✴✴✴ Series
Assembling and Disassembling a battery
02
01
CAUTION
• Before disassembling the battery from a charger, turn off the stick
vacuum cleaner.
12 English
Stick_VS6000_EN_00745K-02_HK.indd 12
2017-03-27 오후 6:27:43
Using the stick vacuum cleaner
Power on/off
The stick vacuum cleaner starts operating
in Turbo mode.
button to convert operation
Press the
mode. (Normal/Turbo)
Using the Turbo mode
Disassembling the handy vacuum
cleaner from the main body
02
Operations
Using the handy vacuum cleaner
01
Power on/off
The handy vacuum cleaner starts operating
in Turbo mode. The operation mode
cannot be changed.
English 13
Stick_VS6000_EN_00745K-02_HK.indd 13
2017-03-27 오후 6:27:44
Using the crevice tool and dusting brush
Dusting brush
When removing fine dust on curtain, furniture, sofa etc.
01
02
Crevice tool
When removing fine dust on groove of window frames, chink, corner etc.
Operations
01
02
Using the Long Reach Tool (option)
When cleaning a place which is narrow
and deep or hard to reach by hand such as
under furniture or a ceiling
01
02
14 English
Stick_VS6000_EN_00745K-02_HK.indd 14
2017-03-27 오후 6:27:44
MAINTENANCE
Maintaining the vacuum cleaner
CAUTION
• Before cleaning the stick vacuum cleaner, turn off the vacuum cleaner.
Disassembling / Assembling
the dustbin
1
02
01
2
Cleaning the sponge filter
1
2
3
4
5
6
02
01
Cleaning the dustbin
1
2
3
4
Cleaning the air intake
2
3
4
5
6
Maintenance
1
5
NOTE
• Emptying the dustbin in a simple way
English 15
Stick_VS6000_EN_00745K-02_HK.indd 15
2017-03-27 오후 6:27:45
APPENDICES
Notes and cautions
Battery usage
NOTE
• When a vacuum cleaner does not
work after charging a battery,
change the battery. If it still does
not work with the new battery,
contact a service center.
CAUTION
• Do not disassemble a battery or a
charger.
• Do not apply heat to a battery
and do not put a battery on the
fire.
• As the battery is manufactured
only for this product, do not use
the battery for other electronic
appliances or other purposes.
• Removing a battery during
operation may cause product
malfunction.
• If the battery is removed
while vacuum cleaner motor is
operating, the battery may not
work for 30 seconds after being
replaced due to safety reasons.
Appendices
• If battery charging time and
battery usage time are reduced
with battery use, replace the
exhausted battery with a new
one.
• Use a battery with genuine logo ( ) only.
• Before assembling the battery
into a charger or a vacuum
cleaner, check that the battery is
placed in the correct direction.
• When discarding a dead battery,
put it into the battery collection
box.
• When a vacuum cleaner is not
going to be used for a long time,
disassemble the battery from a
vacuum cleaner.
Operation
NOTE
• Please charge the battery for the
following cases.
––When a battery is used for the
first time after purchase or the
battery is not used for a long
time.
––When battery level indicator is
on the lowest indication.
• When you are away from
home for a long period of time,
unplug the battery charger and
disassemble the battery from
the charger. When a battery is
not being charged, it will be
discharged.
16 English
Stick_VS6000_EN_00745K-02_HK.indd 16
2017-03-27 오후 6:27:46
CAUTION
• After the handy vacuum cleaner
is assembled to the main
body, the stick vacuum cleaner
operates.
• After using the handy vacuum
cleaner, assemble it to the main
body.
• Before assembling the handy
vacuum cleaner to the main body,
the handy vacuum cleaner should
be turned off.
• After assembling the handle
to the vacuum cleaner, do not
disassemble the handle again.
––Otherwise, it may cause an
injury to you.
• When the brush is rotating, do
not touch the brush.
––Otherwise, your hand can be
caught and it may cause an
injury.
Maintenance
NOTE
• Sometimes the wheel of air intake
may scratch floor. Therefore,
before using the stick vacuum
cleaner, check the wheel status of
air intake.
––When there are foreign matters
which cannot be removed easily
on the wheel of air intake,
contact a service center.
CAUTION
• Drying the parts of the stick
vacuum cleaner in the sun
for long hours may cause
deformation or discoloration.
Therefore, after cleaning the parts
of the stick vacuum cleaner, dry
them in the shade.
• Do not clean the air intake of the
stick vacuum cleaner with water
as it may cause deformation or
discoloration of parts.
Appendices
English 17
Stick_VS6000_EN_00745K-02_HK.indd 17
2017-03-27 오후 6:27:46
Troubleshooting
If the requested service is proved as not product malfunction, the service fee will be
charged. Therefore, please read the user manual carefully.
Problem
Solutions
• Check the battery level and charge the battery.
The stick vacuum
cleaner does not
work.
• Check that the product is turned off and press the power
button to turn on.
The stick vacuum
cleaner does not stop
even though I pressed
the power button.
• Check whether the handy vacuum cleaner is turned on. If so,
press the power button of the handy vacuum cleaner first
and then press the power button of the stick vacuum cleaner.
Suction force
decreases suddenly
and vibrating sound
is generated from the
stick vacuum cleaner.
• If the product has not been used for a long time, charge the
product.
• Check whether the air intake is clogged with foreign matters
or dustbin is fully filled. If so, remove them.
• Check whether the filter is dirty and clean the filter by
referring to the 'Maintaining the stick vacuum cleaner'
section of this manual.
• Check the battery level and charge the battery.
• Check current power voltage of the stick vacuum cleaner. It
should be national rated voltage.
The vacuum cleaner
cannot be charged.
The brush inside the
air intake does not
rotate.
Appendices
Odor is generated
from the air outlet
of the stick vacuum
cleaner.
• Check that the stick vacuum cleaner is turned on and then
check the LED of the battery level indicator is turned on.
• Check the status of charger terminal and remove the foreign
matters (dust) on the charger terminal with a cotton swab or
soft cloth.
• Check whether the air intake is clogged with foreign matters
and remove them.
• Check the stick vacuum cleaner is turned on and then turn
off and turn on the vacuum cleaner again.
• Frequently empty the dustbin and clean the filter.
––As your stick vacuum cleaner is a new product, it may have
slight odor for the first 3 months from the purchase.
––Accumulated dirt in the dustbin or dust on the filter may
generate an odor.
18 English
Stick_VS6000_EN_00745K-02_HK.indd 18
2017-03-27 오후 6:27:46
Memo
Appendices
English 19
Stick_VS6000_EN_00745K-02_HK.indd 19
2017-03-27 오후 6:27:46
If you have any questions or comments relating to Samsung products,
please contact the SAMSUNG customer care center.
Country
Customer Care Center
Web Site
AUSTRALIA
1300 362 603
www.samsung.com/au/support
HONG KONG
3698-4698
www.samsung.com/hk/support (Chinese)
www.samsung.com/hk_en/support (English)
MALAYSIA
1800-88-9999
www.samsung.com/my/support
SINGAPORE
1800-SAMSUNG (7267864)
www.samsung.com/sg/support
INDIA
1800 3000 8282
1800 266 8282
www.samsung.com/in/support
This product is RoHS compliant
DJ68-00745K-02
Stick_VS6000_EN_00745K-02_HK.indd 20
2017-03-27 오후 6:27:46
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Related manuals

Download PDF

advertisement
