Features of your new air conditioner
Cool Summer Offer
On those hot sweltering summer days and long restless nights, there is no better escape from the heat than the cool
comforts of home. Your new air conditioner brings an end to exhausting hot summer days and lets you rest.
This summer, beat the heat with your own air conditioner.
Cost Efficient System
Your new air conditioner not only provides maximum cooling power in the summer, but can also be an efficient
heating method in the winter with the advanced “Heat pump” system. This technology is up to 300% more efficient
than electrical heating, so you can further reduce its running cost. Now, meet year-round needs with one air
conditioner.
A Look for Everywhere
The elegant and harmonious design gives priority to the aesthetics of your space and complements any of your
existing interior decor. With its soft color and rounded-edge shape, the new air conditioner adds class to any room.
Enjoy what your air conditioner offers both functionally and esthetically.
Compact and easy-to-use cassette type
Designed to be installed into most types of suspended ceiling, the cassette type air conditioner is ideal for business
and commercial accommodations.
Fresh cool/warm air can be provided through the controllable 1, 2 or 4 sides of the unit.
All functions of the air conditioner will be controlled easily via a remote control.
2
Contents
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material
resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product and its electronic accessories should not be mixed with other commercial wastes for disposal.
3
ENGLISH
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Checking before use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Viewing your air conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Cleaning and maintaining the air conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Safety precautions
Before using your new air conditioner, please read this manual thoroughly
to ensure that you know how to safely and efficiently operate the extensive
features and functions of your new appliance.
Because the following operating instructions cover various models,
the characteristics of your air conditioner may differ slightly from those
described in this manual. If you have any questions, call your nearest
contact center or find help and information online at www.samsung.com.
Important safety symbols and precautions:
Hazards or unsafe practices that may result in severe
WARNING personal injury or death.
Hazards or unsafe practices that may result in minor
CAUTION personal injury or property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric
shock.
Unplug the power plug from the wall socket.
Do NOT disassemble.
FOR INSTALLATION
WARNING
Use the power line with the power specifications of the product or
higher and use the power line for this appliance only. In addition, do
not use an extension line.
XX
Extending the power line may result in electric shock or fire.
XX
Do not use an electric transformer. It may result in electric shock or fire.
XX
If the voltage/frequency/rated current condition is different, it may
cause fire.
The installation of this appliance must be performed by a qualified
technician or service company.
XX
Failing to do so may result in electric shock, fire, explosion, problems
with the product, or injury.
4
FOR INSTALLATION
WARNING
ENGLISH
Install a switch and circuit breaker dedicated to the air conditioner.
XX
Failing to do so may result in electric shock or fire.
Fix the outdoor unit firmly so that the electric part of the outdoor
unit is not exposed.
XX
Failing to do so may result in electric shock or fire.
Do not install this appliance near a heater, inflammable material.
Do not install this appliance in a humid, oily or dusty location, in a
location exposed to direct sunlight and water (rain drops). Do not
install this appliance in a location where gas may leak.
XX
This may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high
external wall where it could fall.
XX
If the outdoor unit falls, it may result in injury, death or property
damage.
This appliance must be properly grounded. Do not ground the
appliance to a gas pipe, plastic water pipe, or telephone line.
XX
Failure to do so may result in electric shock, fire, an explosion, or other
problems with the product.
XX
Never plug the power cord into a socket that is not grounded correctly
and make sure that it is in accordance with local and national codes.
5
Safety precautions
FOR INSTALLATION
CAUTION
Install your appliance on a level and hard floor that can support its
weight.
XX
Failing to do so may result in abnormal vibrations, noise, or problems
with the product.
Install the draining hose properly so that water is drained correctly.
XX
Failing to do so may result in water overflowing and property damage.
When installing the outdoor unit, make sure to connect the draining
hose so that draining is performed correctly.
XX
The water generated during the heating operation by the outdoor unit
may overflow and result in property damage.
In particular, in winter, if a block of ice falls, it may result in injury, death
or property damage.
FOR POWER SUPPLY
WARNING
When the circuit breaker is damaged, contact your nearest service
center.
Do not pull or excessively bend the power line. Do not twist or tie
the power line. Do not hook the power line over a metal object,
place a heavy object on the power line, insert the power line
between objects, or push the power line into the space behind the
appliance.
XX
This may result in electric shock or fire.
FOR POWER SUPPLY
CAUTION
When not using the air conditioner for a long period of time or
during a thunder/lightning storm, cut the power at the circuit
breaker.
XX
Failing to do so may result in electric shock or fire.
6
FOR USING
WARNING
7
ENGLISH
If the appliance is flooded, please contact your nearest service
center.
XX
Failing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or
smoke, unplug the power plug immediately and contact your
nearest service center.
XX
Failing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.),
ventilate immediately without touching the power line.
Do not touch the appliance or power line.
XX
Do not use a ventilating fan.
XX
A spark may result in an explosion or fire.
To reinstall the air conditioner, please contact your nearest service
center.
XX
Failing to do so may result in problems with the product, water leakage,
electric shock, or fire.
XX
A delivery service for the product is not provided. If you reinstall the
product in another location, additional construction expenses and an
installation fee will be charged.
XX
Especially, when you wish to install the product in an unusual location
such as in an industrial area or near the seaside where it is exposed to
the salt in the air, please contact your nearest service center.
Do not touch the circuit breaker with wet hands.
XX
This may result in electric shock.
Do not strike or pull the air conditioner with excessive force.
XX
This may result in fire, injury, or problems with the product.
Do not place an object near the outdoor unit that allows children to
climb onto the machine.
XX
This may result in children seriously injuring themselves.
Safety precautions
FOR USING
WARNING
Do not turn the air conditioner off with the circuit breaker while it is
operating.
XX
Turning the air conditioner off and then on again with the circuit
breaker may cause a spark and result in electric shock or fire.
After unpacking the air conditioner, keep all packaging materials
well out of the reach of children, as packaging materials can be
dangerous to children.
XX
If a child places a bag over its head, it may result in suffocation.
Do not insert your fingers or foreign substances into the outlet
when the air conditioner is operating or the front panel is closing.
XX
Take special care that children do not injure themselves by inserting
their fingers into the product.
Do not touch the front panel with your hands or fingers during the
heating operation.
XX
This may result in electric shock or burns.
Do not insert your fingers or foreign substances into the air inlet/
outlet of the air conditioner.
XX
Take special care that children do not injure themselves by inserting
their fingers into the product.
Do not use this air conditioner for long periods of time in badly
ventilated locations or near infirm people.
XX
Since this may be dangerous due to a lack of oxygen, open a window at
least once an hour.
If any foreign substance such as water has entered the appliance,
cut the power by unplugging the power plug and turning the circuit
breaker off and then contact your nearest service center.
XX
Failing to do so may result in electric shock or fire.
8
FOR USING
WARNING
FOR USING
ENGLISH
Do not attempt to repair, disassemble, or modify the appliance
yourself.
XX
Do not use any fuse (such as cooper, steel wire, etc.)other than the
standard fuse.
XX
Failing to do so may result in electric shock, fire, problems with the
product, or injury.
CAUTION
Do not place objects or devices under the indoor unit.
XX
Water dripping from the indoor unit may result in fire or property
damage.
Check that the installation frame of the outdoor unit is not broken at
least once a year.
XX
Failing to do so may result in injury, death or property damage.
Max current is measured according to IEC standard for safety and
current is measured according to ISO standard for energy efficiency.
Do not stand on top of the appliance or place objects (such as
laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal
objects, etc.) on the appliance.
XX
This may result in electric shock, fire, problems with the product, or
injury.
Do not operate the appliance with wet hands.
XX
This may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of
the appliance.
XX
As well as being harmful to humans, it may also result in electric shock,
fire or problems with the product.
Do not drink the water from the air conditioner.
XX
The water may be harmful to humans.
9
Safety precautions
FOR USING
CAUTION
Do not apply a strong impact to the remote controller and do not
disassemble the remote controller.
Do not touch the pipes connected with the product.
XX
This may result in burns or injury.
Do not use this air conditioner to preserve precision equipment,
food, animals, plants or cosmetics, or for any other unusual
purposes.
XX
This may result in property damage.
Avoid directly exposing humans, animals or plants from the air flow
from the air conditioner for long periods of time.
XX
This may result in harm to humans, animals or plants.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
10
FOR CLEANING
WARNING
FOR CLEANING
CAUTION
Take care when cleaning the surface of the heat exchanger of the
outdoor unit since it has sharp edges.
XX
To avoid cutting your fingers, wear thick cotton gloves when cleaning it.
Do not clean the inside of the air conditioner by yourself.
XX
For cleaning inside the appliance, contact your nearest service center.
XX
When cleaning the internal filter, refer to the descriptions in the
‘Cleaning and maintaining the air conditioner’ section.
XX
Failure to do may result in damage, electric shock or fire.
11
ENGLISH
Do not clean the appliance by spraying water directly onto it. Do not
use benzene, thinner or alcohol to clean the appliance.
XX
This may result in discoloration, deformation, damage, electric shock or
fire.
Before cleaning or performing maintenance, unplug the air
conditioner from the wall socket and wait until the fan stops.
XX
Failing to do so may result in electric shock or fire.
Checking before use
Operation ranges
The table below indicates the temperature and humidity ranges the air
conditioner can be operated within. Refer to the table for efficient use.
OPERATIONAL TEMPERATURE
INDOOR
OUTDOOR
INDOOR
HUMIDITY
IF OUT OF CONDITIONS
COOLING
18˚C to 32˚C
-5˚C to 48˚C
80% or less
Condensation may occur on
the indoor unit with risk to
have either water blow off or
drops on the floor.
HEATING
27˚C or less
-15˚C to 24˚C
-
Internal protection triggers
and the air conditioner will
stop.
DRYING
18˚C to 32˚C
-5˚C to 48˚C
-
Condensation may occur on
the indoor unit with risk to
have either water blow off or
drops on the floor.
MODE
NOTE
• The standardized temperature for heating is 7˚C. If the outdoor temperature drops to 0˚C or below, the
heating capacity can be reduced depending on the temperature condition.
If the cooling operation is used at over 32˚C (indoor temperature), it does not cool at its full capacity.
• The use of the air conditioner at a relative humidity above the expected one (80%) may cause the
formation of condensate and the leakage of water drops on the floor.
Maintaining your air conditioner
Internal protections via the unit control system
• This internal protection operates if an internal fault occurs in the air conditioner.
Type
Against cold air
The internal fan will be off to against cold air when the heat pump is heating.
De-ice cycle
(Defrost cycle)
The internal fan will be off to against cold air when the heat pump is heating.
Anti-Freezing of Indoor
Heat Exchanger
Protect compressor
NOTE
12
Description
The compressor will be off if the heat exchanger temp of indoor unit decrease to
0˚C or more to protect from ice build up on the heat exchanger.
The air conditioner does not start operating immediately to protect the compressor
of the outdoor unit after it has been started.
• If the heat pump is operating in Heat mode, De-ice cycle is actuated to remove frost from an outdoor
unit that may have deposited at low temperatures.
The internal fan is switched off automatically and restarted only after the de-ice cycle is completed.
Tips on using air conditioner
Here are some tips that you would follow when using your air conditioner.
TOPIC
NOTE
Fan
The unit will not operate when it starts to de-ice.
• Fan may not operate for about 3~5 minutes at the
beginning to prevent any cold blasts while the air
conditioner is warming up.
13
ENGLISH
RECOMMENDATION
• If current outside temperatures are much higher than
the selected indoor temperature, it may take time to
bring the inner temperature to the desired coolness.
Cooling
• Avoid drastically turning down the temperature.
Energy is wasted and the room does not cool faster.
• Since the air conditioner heats the room by taking
heat energy from outdoor air, the heating capacity
may decrease when outdoor temperatures are
Heating
extremely low. If you feel the air conditioner
insufficiently heats, using an additional heating
appliance in combination with the air conditioner is
recommended.
• When the air conditioner runs in Heat mode, due to
temperature difference between the unit and the
outside air, frost will form.
If this happens:
-- The air conditioner stops heating.
-- The air conditioner will operate automatically in
De-ice mode for 10 minutes.
Frost & De-ice
-- The steam produced on the outdoor unit in De-ice
mode is safe.
No intervention is required; after about 10 minutes, the
air conditioner operates again normally.
Checking before use
TOPIC
High indoor/
outdoor
temperatures
•
•
Power failure
Protection
mechanism
•
•
Automatic air
flow blade
control
14
RECOMMENDATION
If both indoor and outdoor temperatures are high
and the air conditioner is running in Heat mode, the
outdoor unit’s fan and compressor may stop at times.
This is normal; wait until the air conditioner turns on
again.
If a power failure occurs during the operation of the
air conditioner, the operating immediately stops
and unit will be off. When power returns, the air
conditioner will run automatically.
If the air conditioner has just been turned on after
operation stops or being plugged in, cool/warm
air does not come out for 3 minutes to protect the
compressor of the outdoor unit.
If the air conditioner is operating in abnormal
conditions (such as operating the air conditioner
with windows open or when small capacity indoor
unit is installed and operating in a room that is too
large) indoor can become very humid when the
angle of the air flow blade is small and performance
of the product may decrease. When indoor humidity
increases, indoor unit will automatically detect it and
open the air flow blade in wider angle to make sure
that performance of the product is stable.
Viewing your air conditioner
Main parts and Display
Air flow blade
ENGLISH
Air intake
Air filter (under the grille)
Display
On/Off operation indicator
Removing frost indicator
Timer indicator
Filter reset indicator
Remote control sensor
NOTE
Your air conditioner may slightly look different from illustration shown above depending on your model.
15
Cleaning and maintaining the air conditioner
Cleaning the exterior
Wipe the surface of the unit with a slightly wet or dry cloth when needed. Wipe
off dirt of odd-shaped area by using a soft brush.
CAUTION
Do not use Benzene or Thinner.
They may damage the surface of the air
conditioner and can create a risk of fire.
Cleaning air filter and grille
1. Open the front grille.
• Pull both hooks and take the grille downward. Two safety clips are
mounted to the front grille to prevent it from dropping.
PULL
2. Detach the front grille.
• Remove the safety clip from panel front. (There are two safety clips between
grille and panel base.)
NOTE
If you want to clean the filter only, you do not have to detach the
grille. Follow step 4 and 5
3. Pull out the Air filter.
16
PULL
4. Clean the grille and Air filter with a vacuum cleaner or soft brush. If dust is
too heavy, then rinse it with running water and dry it in a ventilated area.
• For best conditions, repeat every two weeks.
• If the Air filter dries in a confined (or humid) area, odors may generate. If it
occurs, re-clean and dry it in a well-ventilated area.
ENGLISH
5.
•
6.
•
Insert the Air filter back in its original position.
You will hear a click sound when the Air filter is properly placed.
Attach the front grille.
Reverse the above steps to attach the front grille.
NOTE
• The illustration shown above may differ from yours depending on your model.
• After cleaning the filter, press the Filter Reset button on the remote control for 2 seconds to reset the
filter schedule. Filter sign indicator will be on for cleaning time.
• If the angle on the air flow blades has been changed by user due to opening the front grille for
installation or maintenance, you must turn off the circuit breaker and turn it on again before using the
air conditioner.
Otherwise, angles of the each angle can be different or some of the blade may not close when the
product is off.
Maintaining your air conditioner
If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best
condition.
1. Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4
hours and disconnect the power plug.
There may be internal damage if moisture is left in components.
2. Before using the air conditioner again, dry the inner components of the
air conditioner again by running in Fan mode for 3 to 4 hours. This helps
remove odors which may have generated from dampness.
17
Cleaning and maintaining the air conditioner
Periodical checks
Refer to the following chart to maintain the air conditioner properly.
Type
Description
Clean the air filter (1)
Indoor unit
Monthly
Every 4
months

Clean the condensate drain pan (2)

Thoroughly clean the heat exchanger (2)

Clean the condensate drain pipe (2)

Replace the remote control batteries (1)
Clean the heat exchanger on the outside of the unit (2)
Outdoor unit
Once a
year


Clean the heat exchanger on the inside of the unit (2)

Clean the electric components with jets of air (2)

Verify that all the electric components are firmly
tightened (2)

Clean the fan (2)

Verify that all the fan assembly is firmly tightened (2)

Clean the condensate drain pan (2)

NOTE
This check mark requires checking the indoor/outdoor unit periodically, following to the description to
maintain the air conditioner properly.
-- The described operations should be performed more frequently if the area of installation is very dusty.
CAUTION
These operations must always be performed by qualified personnel.
For more detailed information, see the Installation Manual.
18
Troubleshooting
Refer to the following chart if the air conditioner operates abnormally. This
may save time and unnecessary expenses.
SOLUTION
The air conditioner • Because of the protective mechanism, the
does not operate
appliance does not start operating immediately
immediately after it
to keep the unit from overloading.
has been restarted.
The air conditioner will start in 3 minutes.
• Check that the power plug is properly
connected. Insert the power plug into the wall
socket correctly.
The air conditioner
does not work at all. • Check if the circuit breaker is switched off.
• Check if there is a power failure.
• Check your fuse. Make sure it is not blown out.
The temperature
does not change.
• Check if you selected Fan mode.
Press the Mode button on the remote control to
select another mode.
The cool (warm)
air does not come
out of the air
conditioner.
• Check if the set temperature is higher (lower)
than the current temperature. Press the
Temperature button on the remote control
to change the set temperature. Press the
Temperature button to decrease or increase
the temperature.
• Check if the air filter is blocked by dirt.
• Check if the air conditioner has just been turned
on. If so, wait 3 minutes. Cool air does not come
out to protect the compressor of the outdoor
unit.
19
ENGLISH
PROBLEM
Troubleshooting
PROBLEM
SOLUTION
The cool (warm)
air does not come
out of the air
conditioner.
• Check if the air conditioner is installed in a
place with a direct exposure to sunlight. Hang
curtains on windows to boost cooling efficiency.
• Check if the cover or any obstacle is not near
the outdoor unit.
• Check if the refrigerant pipe is too long.
• Check if the air conditioner is only available in
Cool mode.
• Check if the remote control is only available for
cooling model.
The fan speed does
not change.
• Check if you selected Auto or Dry mode.
The air conditioner automatically adjusts the
fan speed to Auto in Auto/Dry mode.
Timer function does • Check if you press the Set button on the remote
not set.
control after you have set the time.
Odors permeate in
the room during
operation.
• Check if the appliance is running in a smoky
area or if there is a smell entering from outside.
Operate the air conditioner in Fan mode or
open the windows to air out the room.
• A bubbling sound may be heard when
the refrigerant is circulating through the
compressor. Let the air conditioner operate in a
The air conditioner
selected mode.
makes a bubbling
sound.
• When you press the Power button on the
remote control, noise may be heard from the
drain pump inside the air conditioner.
20
SOLUTION
Water is dripping
from the air flow
blades.
• Check if the air conditioner has been cooling
for an extended period of time with the air flow
blades pointed downwards. Condensation may
generate due to the difference in temperature.
Remote control is
not working.
• Check if your batteries are depleted.
• Make sure batteries are correctly installed.
• Make sure nothing is blocking your remote
control sensor.
• Check that there are strong lighting apparatus
near the air conditioner. Strong light which
comes from fluorescent bulbs or neon signs
may interrupt the electric waves.
The air conditioner
does not turn on or • Check if you set the wired remote control for
off with the wired
group control.
remote control.
The wired remote
control does not
operate.
• Check if TEST indicator is displayed on the
wired remote control. If so, turn off the unit and
switch off the circuit breaker. Call your nearest
contact center.
The indicators of
the digital display
flashes.
• Press the Power button on the remote control
to turn the unit off and switch the circuit
breaker off. Then, switch it on again.
21
ENGLISH
PROBLEM
QUESTIONS OR COMMENTS?
COUNTRY
CALL
OR VISIT US ONLINE AT
INDONESIA
021-56997777
08001128888
www.samsung.com/id/support
MALAYSIA
1800-88-9999
603-77137477 (Overseas contact)
www.samsung.com/my/support
VIETNAM
1800 588 889
www.samsung.com/vn/support
SOUTH AFRICA
BOTSWANA
0860 SAMSUNG (726 7864)
8007260000
NAMIBIA
08 197 267 864
ZAMBIA
0211 350370
MAURITIUS
800 2550
REUNION
0262 50 88 80
ANGOLA
917 267 864
MOZAMBIQUE
NIGERIA
Ghana
Cote D’Ivoire
SENEGAL
CAMEROON
847267864 / 827267864
0800-726-7864
0800-10077
8000 0077
800-00-0077
www.samsung.com/africa_fr/support
7095-0077
KENYA
0800 545 545
0800 300 300
TANZANIA
0800 755 755 / 0685 889 900
RWANDA
9999
BURUNDI
200
SUDAN
www.samsung.com/africa_en/support
0302-200077
UGANDA
DRC
www.samsung.com/support
499999
1969
www.samsung.com/support
4 Way Cassette Type
AC✴✴✴JNNDEH
Air Conditioner
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
EN FR IN DB68-05796A-00
Download PDF

advertising
