English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
中文 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Safety and usage information....................................................2
Your headset overview .............................................................3
Charging the headset ...............................................................4
Turning the headset on or off ....................................................5
Understanding various modes....................................................5
Pairing with your Bluetooth phone..............................................6
Using call functions ..................................................................7
Warranty and parts replacement ................................................8
Correct disposal of this product .................................................9
Specifications........................................................................ 10
1
English
Contents
Bluetooth® is a registered trademark of the Bluetooth SIG, Inc.
worldwide. Bluetooth QD ID: B013814
Safety and usage information
• Never disassemble or modify your headset for any reason.
Doing this may cause the headset to malfunction or become
combustible. Bring the headset to an authorised service
centre to repair it or replace the battery.
• When using your headset while driving, follow local
regulations in the country or region you are in.
• Avoid storage at high temperatures (above 50° C/122° F),
such as in a hot vehicle or in direct sunlight, as this can
damage performance and reduce battery life.
• Do not expose the headset or any of its supplied parts to
rain or other liquids.
At very high volumes, prolonged listening to the
headset can damage your hearing.
2
Volume down
button
Volume up
button
Indicator light
English
Your headset overview
Earhook
Multi-function
button
Adapter jack
Earpiece
Microphone
3
Charging the headset
Put the adapter into the jack on the
headset and into the electrical outlet.
Charge the headset until the red
indicator light turns blue.
Do not attempt to charge the headset with anything
other than the adapter provided.
4
English
Turning the headset on or off
To turn the headset on, press and hold the Multi-function
button until the blue indicator light flashes 4 times.
To turn the headset off, press and hold the Multi-function
button until both blue and red indicator lights flash.
Understanding various modes
• Standby mode: The headset is waiting for a call. The blue
indicator light flashes every 3 seconds.
• Active mode: The headset has a call in progress. The blue
indicator light flashes every 8 seconds.
• Pairing mode: The blue indicator light stays lit. You can
discover and connect to your headset on your phone.
• Low battery mode: There is less than 10% of battery
power left. The red indicator light flashes. You must
recharge the battery.
5
Pairing with your Bluetooth phone
1 Enter Pairing mode.
• Turn off your headset and press and hold the Multifunction button until the blue indicator light remains lit
after blinking.
• If you turn it on for the first time, it proceeds into Pairing
mode immediately.
2 Search for and pair with your phone according to your
phone’s user guide. (Bluetooth PIN: 0000, 4 zeros)
• If the pairing is successful, the blue indicator light will
flash 10 times rapidly before entering Standby mode.
• If the blue indicator light remains lit, retry pairing.
When the headset and the phone are paired, the
headset attempts to reconnect automatically each
time it turns on. Otherwise, press the Multi-function
button to reconnect.
6
English
Using call functions
Some functions may not be supported by your phone.
In Standby mode
Press the Multi-function button to:
• Answer an incoming call
• Redial the last number called
Press and hold Multi-function button to:
• Make a voice-activated call
• Reject an incoming call
In Active mode
Press the Multi-function button to:
• End a call
• Transfer a call from the phone to the headset
Press and hold Multi-function button to:
• Place a call on hold
• Answer a second call
• Retrieve a call on hold
Press [+] or [-] to adjust the volume.
Press and hold [+] or [-] to turn the microphone off or on.
7
Warranty and parts replacement
Samsung warrants this product as free of defects in material,
design and workmanship for the period of one year from the
original date of purchase. (Depending on your country, the
length of warranty may vary.)
If during the period of warranty this product proves defective
under normal use and service you should return the product to
the retailer from whom it was originally purchased or qualified
service center. The liability of Samsung and its appointed
maintenance company is limited to the cost of repair and/or
replacement of the unit under warranty.
• The warranty is limited to the original purchaser
• A copy of your receipt or other proof of purchase is required
for a proper warranty service
• The warranty is void if the serial number, date code label or
product label is removed, or if the product has been subject
to physical abuse, improper installation modification, or
repair by unauthorised third parties
• Specifically exempt from any warranty are limited-life
consumable components such as batteries and other
accessories
8
English
• Samsung will not assume any responsibility for any loss or
damage incurred in shipping. All repair work on Samsung
products by unauthorised third parties voids any warranty
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life.
To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they
purchased this product, or their local government office, for
details of where and how they can take this item for
environmentally safe recycling.
Business users should contact their supplier and check the
terms and conditions of the purchase contract. This product
should not be mixed with other commercial wastes for disposal.
9
Specifications
Item
Specifications and description
Bluetooth version
2.0 + EDR
Support profile
Headset Profile, Hands-Free Profile
Operating range
Up to 30 feet (10 metres)
Maximum Standby
time
Up to 100 hours*
Maximum Active
time
Up to 6 hours*
* Depending on the phone type and usage, the actual time may
vary.
10
English
11
12
目錄
13
中文
安全與使用資訊 .........................................................................................14
耳機相關概述 .............................................................................................15
耳機充電 .....................................................................................................16
開/關耳機電源 .........................................................................................17
瞭解各種模式 .............................................................................................17
與藍牙手機配對 .........................................................................................18
使用通話功能 .............................................................................................19
保固與零件更換 .........................................................................................20
正確的產品廢棄方式 .................................................................................21
規格 .............................................................................................................22
Bluetooth® 為 Bluetooth SIC, Inc. 全球的註冊商標。Bluetooth QD
ID:B013814
安全與使用資訊
• 絕不可拆卸或改裝本耳機,以免耳機故障或燒毀。請將耳機送
至授權服務中心維修或更換電池。
• 若開車時需使用耳機,請遵守所在國家或地區的法律。
• 避免將耳機存放在溫度高 (50° C / 122° F 以上)的地方,例如
高溫車內或日光直射處,可能會使效能受損並縮短電池壽命。
• 請勿讓耳機或任何隨附零件淋雨或接觸其他液體。
若音量過高,長時間使用耳機可能會傷害您的聽力。
• 本機限在不干擾合法電臺與不受被干擾保障條件下於室內使用
14
耳機相關概述
耳掛
降低音量鈕
指示燈
多功能鈕
中文
提高音量鈕
轉接器插孔
耳機
麥克風
15
耳機充電
將電源轉接器插入耳機的插孔與電源插
座。
讓耳機充電直到耳機上的紅燈變成藍燈。
請勿試圖使用隨附轉接器以外的任何轉接器進行充電。
16
開/關耳機電源
若要開啟耳機電源,請按住多功能鈕直到藍色指示燈閃爍 4 次。
若要關閉耳機電源,請按住多功能鈕直到藍色與紅色指示燈閃
爍。
• 待機模式:耳機正在等候來電。藍色指示燈每 3 秒閃爍一次。
• 使用中模式:目前正使用耳機通話中。藍色指示燈每 8 秒閃爍
一次。
• 配對模式:藍色指示燈亮起。您可以搜尋到耳機,並將耳機連
與您的手機連線。
• 低電力模式:剩餘電力不到 10%。紅色指示燈閃爍。您必須將
電池重新充電。
17
中文
瞭解各種模式
與藍牙手機配對
1 請進入配對模式。
• 關閉耳機並按住多功能鈕,直到藍色指示燈閃爍之後亮
起。
• 若您第一次啟動耳機,耳機便會立即進入配對模式。
2 根據手機使用指南,使用手機搜尋耳機及配對。(藍牙 PIN
碼:0000,4 個 0)
• 若配對成功,藍色指示燈便會快速閃爍 10 次,然後進入待
機模式。
• 若藍色指示燈持續亮起,請重新配對一次。
將耳機與手機配對完成之後,耳機便會在每次啟動時自
動嘗試與手機重新連線。否則,便請按下 [ 多功能 ] 鈕
重新連線。
18
使用通話功能
您的手機可能不支援某些功能。
待機模式中
中文
按下 [ 多功能 ] 鈕可以:
• 接聽來電。
• 重撥最後一個撥打的號碼。
按住 [ 多功能 ] 鈕可以:
• 語音聲控撥號。
• 拒絕來電。
使用中模式:
按下 [ 多功能 ] 鈕可以:
• 結束通話。
• 將通話從手機轉接至耳機。
按住 [ 多功能 ] 鈕可以:
• 保留來電。
• 接聽第二通來電。
• 與保留來電恢復通話。
按下 [+] 或 [-] 可調整音量。
按住 [+] 及 [-] 鈕則可開啟或關閉麥克風。
19
保固與零件更換
本產品自原購買日期起,Samsung 對產品素材、設計與工藝提供
一年無瑕疵保固。(保固期視各國情況可能有所不同。)
若於保固期限內在正常使用情況下證實本產品有缺陷,請您將產
品送回至當初購買產品的零售商或合格的服務中心。Samsung 與
其指定維護公司的責任僅限於負擔在保固範圍內維修及/或更換
裝置的成本。
• 限原消費者才能享有保固。
• 若要享有適當的保固服務,您必須提供收據或其他購買證明。
• 若產品序號、日期碼標籤或產品標籤遭移除,或若產品曾遭未
經授權之協力廠商濫用、不適安裝、修改或維修,則本公司無
責任提供保固。
• 電池和其他配件等有使用期限的耗材皆不在保固範圍內。
• Samsung 對產品運送過程所造成的損失或損毀,不負任何損害
賠償責任。若由未經授權的第三方執行 Samsung 產品所有的
維修工作,將會使保固失效。
20
正確的產品廢棄方式
(廢棄的電機與電子設備)
在產品或印刷品上出現的這個標記,代表當產品不堪使
用時,不得將產品與其他家庭廢棄物一同丟棄。
家庭使用者應洽當初購買本產品的零售商或與當地政府相關部門
聯絡,取得可處理本裝置的地點與處理方式的相關資訊,以便執
行資源回收及保護環境。
企業使用者應洽供應商,並確認購買合約的條款與條件。本產品
不得與其他商業廢棄物混合丟棄。
21
中文
為避免可能因廢棄作業未受控制而對環境或人們的健康造成傷
害,請將本產品與其他類型的廢棄物分開,並執行資源回收以便
重複使用資源。
規格
項目
規格與說明
藍牙版本
2.0 + EDR
支援設定檔樣版
耳機設定檔、免持聽筒設定檔
操作範圍
最遠 30 呎 (10 公尺)
最長待機時間
可達 100 小時 *
最長使用時間
可達 6 小時*
* 視手機的類型和使用狀態而定,實際時間可能不同。
22
Would Wide Web
http://www.samsungmobile.com
Printed in Korea
Code NO.: GH68-18477A
05/2008. Rev.1.0
