DLPTV
BP68-00161A-00
DLPTV
I N S T R U C T I O N
M A N U A L
ST43L2HX/ST50L2HX/ST61L2HX
Safety Instructions
Warning! Important
Safety Instructions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This symbol indicates high voltage is present. It is dangerous to make any kind of contact
with any part inside this product.
Thank You for Choosing Samsung
Thank you for choosing Samsung! Your new Samsung projection TV represents the latest in television technology. We designed it with easy-to-use on-screen menus and closed captioning capabilities, making it
one of the best products in its class. We are proud to offer you a product that will provide convenient,
dependable service and enjoyment for years to come.
Important Safety Information
Always be careful when using your TV. To reduce the risk of fire, electrical shock, and other injuries,
keep these safety precautions in mind when installing, using, and maintaining your unit.
• Read all safety and operating instructions before operating your TV.
• Keep the safety and operating instructions for future reference.
• Heed all warnings on the TV and in the operating instructions.
This symbol alerts you that important literature concerning operation and maintenance has
been included with this product.
CAUTION: FCC/CSA regulations state that any unauthorized changes or modifications
to this equipment may void the user’s authority to operate it.
CAUTION: To prevent electric shock, match the wide blade of plug to the wide slot, and
fully insert the plug.
ATTENTION: Pour eviter les chocs electriques, introduire la lame le plus large de la
fiche dans la borne correspondante de la prise et pousser jusqu’au fond.
Note to CATV system installer: This reminder is provided to call CATV system installer’s
attention to Article 820-40 of the National Electrical Code (Section 54 of Canadian
Electrical Code, Part I), that provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as possible.
Important: One Federal Court has held that unauthorized recording of copyrighted TV
programs is an infringement of U.S. copyright laws. Certain Canadian programs may
also be copyrighted and any unauthorized recording in whole or in part may be in
violation of these laws.
To prevent damage which may result in fire or electric shock,
do not expose this appliance to rain or moisture.
2
• Unplug the TV from the wall outlet before cleaning. Use a damp cloth; do not use liquid or
aerosol cleaners.
• Never add any attachments and/or equipment without approval of the manufacturer. Such
additions can increase the risk of fire, electric shock, or other personal injury.
• Do not use the TV where contact with water is possible, such as near bath tubs, sinks, washing
machines, swimming pools, etc.
• Do not place the TV on an unstable cart, stand, tripod, bracket, or table where
it can fall. A falling TV can cause serious injury to a child or adult, and serious
damage to the appliance. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer or sold with the TV. Follow the
manufacturer’s instructions when mounting the unit, and use a mounting
accessory recommended by the manufacturer. Move the TV and cart with care.
Quick stops, excessive force, and uneven surfaces can make the unit and cart
unsteady and more likely to overturn.
• The TV is designed with slots in the cabinet for ventilation to protect it from overheating. Do not block
these openings with any object, and do not put the TV on a bed, sofa, rug, or other similar surface. Do
not put the TV near a radiator or heat register. If you do put the TV on a rack or
bookcase, make sure that there is adequate ventilation and that you’ve followed the manufacturer’s
instructions for mounting.
• Operate your TV only from the type of power source indicated on the marking label. If you are not sure
of the type of power supplied to your home, consult your appliance dealer or local power company.
• Use only a grounded or polarized outlet. For your safety, this TV is equipped with a polarized alternating current line plug having one blade wider than the other. This plug will fit into the power outlet only
one way. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug still
does not fit, contact an electrician to replace your outlet.
3
Safety Instructions
• Protect the power cord. Power supply cords should be routed so that they won’t be walked on or
pinched by objects placed on or against them. Pay particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the unit.
• Unplug the TV from the wall outlet and disconnect the antenna or cable system during a lightning storm
or when left unattended and unused for long periods of time. This will prevent damage to the unit from
lightning and power-line surges.
• Avoid overhead power lines. An outside antenna system should not be placed in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or
circuits. When installing an outside antenna system, be extremely careful to keep from touching the
power lines or circuits. Contact with such lines can be fatal.
• Do not overload the wall outlet or extension cords. Overloading can result in fire or electric shock.
• Do not insert anything through the openings in the unit, where they can touch dangerous voltage points
or damage parts. Never spill liquid of any kind on the TV.
• Ground outdoor antennas. If an outside antenna or cable
system is connected to the TV, be sure the antenna or cable
system is grounded so as to provide some protection against
voltage surges and built-up static charges. Section 810 of the
National Electrical Code, ANSI/NFPA No.70-1984, provides information about proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors,
location of antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
EXAMPLE OF
ANTENNA GROUNDING
ANTENNA
LEAD IN WIRE
GROUND CLAMP
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
NEC — NATIONAL ELECTRICAL CODE
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
• Do not attempt to service the TV yourself. Refer all servicing to qualified service personnel. Unplug the
unit from the wall outlet and refer servicing to qualified service personnel when:
- The power-supply cord or plug is damaged
- Liquid has been spilled on the unit or if objects have fallen into the unit
- The TV has been exposed to rain or water
- The TV does not operate normally by following the operating instructions
- The TV has been dropped or the cabinet has been damaged
- The TV exhibits a distinct degradation in performance
- When the LAMP(BULB ONLY) replacement is needed
• If you make adjustments yourself, adjust only those controls that are covered by the operating instructions. Adjusting other controls may result in damage and will often require extensive work by a qualified
technician to restore the TV to normal.
• When replacement parts are required, be sure the service technician uses replacement parts specified
by the manufacturer or those that have the same characteristics as the original part. Unauthorized
substitutions may result in additional damage to the unit.
SAMSUNG
• Upon completion of any service or repairs to this TV, ask the service technician to
perform safety checks to determine that the TV is in a safe operating condition.
4
5
Table of Contents
Your New Wide TV ..........................................................................................10
Special Features ...............................................................................................48
Replacing the Lamp .............................................................................................10
List of Features .....................................................................................................12
Checking Parts.....................................................................................................12
Side Panel Buttons................................................................................................13
Side Panel Jacks ................................................................................................. 13
Front Panel LED Indicators .....................................................................................14
Rear Panel Jacks ..................................................................................................15
Remote Control ....................................................................................................16
Installing Batteries in the Remote Control.....................................................17
Setting Up Your Remote Control .............................................................................48
Remote Control Codes ..........................................................................................51
Fine Tuning Channels ...........................................................................................52
Selecting the Color Tone .......................................................................................53
Setting the Film Mode...........................................................................................53
DNIeTM (Digital Natural Image engine)
...........................................................54
Digital Noise Reduction ........................................................................................55
Setting the Blue Screen Mode................................................................................56
Changing the Screen Size.....................................................................................57
Special Audio Options .........................................................................................59
MTS Settings: Choosing a Soundtrack ........................................................59
Dolby Virtual ...........................................................................................60
BBE ........................................................................................................61
Auto Volume ............................................................................................62
Viewing Closed Caption Information ......................................................................63
Viewing Picture-in-Picture.......................................................................................64
Selecting a Screen ...................................................................................64
Selecting an External Signal ......................................................................65
Selecting a Signal Source (Antenna or Cable) for PIP ...................................66
Swapping the Contents of the PIP and Main image......................................67
Changing the Size of the PIP image ...........................................................68
Changing the Picture-in-Picture Channel ......................................................69
Selecting the Sound Source .......................................................................70
Changing the Location of the PIP image......................................................70
Using the V-Chip ..................................................................................................71
Connections .....................................................................................................20
Connecting VHF and UHF Antennas.......................................................................20
Antennas with 300-ohm Flat Twin Leads .....................................................20
Antennas with 75-ohm Round Leads ...........................................................20
Separate VHF and UHF Antennas ..............................................................21
Connecting Cable TV and VCR..............................................................................22
Cable without a Cable Box .......................................................................22
Cable with a Cable Box that Descrambles All Channels ...............................22
Connecting a Cable Converter Box............................................................23
Connecting a Cable Converter Box and a VCR ...........................................23
Connecting a Camcorder......................................................................................24
Connecting a DVD Player .....................................................................................25
Connecting a DTV Set Top Box ..............................................................................26
Operation........................................................................................................30
Turning the TV On and Off....................................................................................30
Viewing the Menus and Displays ...........................................................................30
Selecting the Menu Language................................................................................31
Selecting the Antenna Input ...................................................................................31
Channel Memory .................................................................................................33
Changing Channels..............................................................................................34
Selecting Your Favorite Channels ...........................................................................35
Labeling the Channels ..........................................................................................36
Setting The On/Off Melody ..................................................................................37
Picture Control .....................................................................................................38
Sound Control .....................................................................................................40
Setting the Clock..................................................................................................42
Setting the Timers .................................................................................................43
Viewing an External Signal Source ........................................................................45
6
PC Display.......................................................................................................78
Using Your TV as a Computer (PC) Display .............................................................78
How to connect Your PC to the TV .............................................................78
How to Set up Your PC Software (Windows only) ........................................79
Display Modes.........................................................................................80
How to Set up Your TV as a PC display ..................................................................81
Picture Quality Adjustment ....................................................................................82
Changing the Position of the Image (Moving left, right, up and down) .......................83
Changing the Screen Size (PC mode).....................................................................84
Appendix.........................................................................................................88
Troubleshooting ...................................................................................................88
Care and Maintenance.........................................................................................89
Using Your TV in Another Country..........................................................................89
Specifications ......................................................................................................89
7
SAMSUNG
Your New Wide TV
Your New Wide TV
Replacing the Lamp
• A Projection TV lamp is a consumable item, and should be replaced from time to time for best projector operation. If the screen image becomes dark, or timer, lamp and Temp LEDs flicker off at the same
time, you may have to replace the lamp.
• When changing the lamp, you should first verify the type/model, and then use only the correct lamp
replacement. The code for lamp regulation and usage is marked on the label. If you remove the lamp,
you can identify this replacement code. You should only replace the lamp with the one of the same regulation code.
1
Use a screwdriver to
remove the screw as
shown in the picture.
2
Remove the Lamp cover.
3
Use a screwdriver to
remove the screws
securing the Lamp.
There are 2 screws: one
on the left and one on the
right. When the screws
have been completely
unfastened, they will still
be connected to the body
of the Lamp.
4
Separate the Lamp from
the engine by holding the
handle and pulling it out.
5
To reinstall the Lamp, follow these steps in reverse
order.
• If you wish to buy a new lamp, please phone your Service Center or a nearby TV dealer, and tell them
the model of your projection unit.
• You can identify the lamp type on the left side of TV and the lamp cover.
• The TV will be damaged if you use a lamp that is different from the original supplied by the manufacturer.
• Please don't remove the lamp except when replacing with a new one.
• Please turn off TV power before changing a lamp and then unplug after waiting 1 minute.
• The cooling fan will help cool the lamp so you can safely remove it. The surface of the Lamp is very
hot. Please wait for 30 minutes after turning off your projection TV to handle the lamp.
• Please keep the old lamp away from flammable articles and children. Dispose of properly.
• Don't allow dirt or dust to accumulate inside the lamp cover or on the Lamp.
• A dirty cover or lamp can catch fire, explode and cause electric shock.
• Please don't touch the front glass of a new lamp or the glass of the lamp container.
• If a new lamp is improperly handled, the quality of the screen image can be affected and the expected
life span of the lamp can be reduced.
• Be sure to tighten the lamp cover on the TV after changing the lamp. Note that the TV will not function
if the lamp cover is not securely attached. Please tighten the holding screw on the lamp cover after it
has been attached to the TV.
NOTE
• Be sure the replacement Lamp is the same model.
10
11
Your New Wide TV
List of Features
Side Panel Buttons
Your TV was designed and engineered using the latest technology. It is a full-featured,
high-performance unit that exceeds industry standards. In addition, it has these special features:
•
•
•
•
•
•
•
•
•
•
•
•
The buttons on the side panel control your TV’s basic features, including the on-screen menu system.
To use the more advanced features, you must use the remote control.
œST43L2HX
œST50L2HX
Easy-to-operate remote control
Easy-to-use on-screen menu system you can access from the side panel or remote control
Automatic timer to turn the TV on and off at any time you choose
Adjustable picture and sound settings and the ability to memorize your favorite settings
Automatic channel tuning for up to 181 channels
A special filter to reduce or eliminate reception problems
Fine tuning control for the sharpest picture possible
A built-in multi-channel sound decoder for stereo and bilingual listening
Built-in, dual channel speakers
A special sleep timer
Picture-in-Picture capability that lets you watch two channels at once
Widescreen TV with adjustable image size
ΠTV/VIDEO
Press to switch between viewing TV programs and signals from connected components.
´ MENU
Press to see the on-screen menu.
ˇ ▼ CHANNEL ▲
Press to change channels and move between items on the on-screen
menu.
¨ VOLUME +, –
œST61L2HX
Press to lower or raise the volume and to select items when using
the on-screen menu.
ˆ POWER
Press to turn the TV on and off.
Checking Parts
Once you have unpacked your TV, check to make sure that you have all the parts shown here.
If any piece is missing or broken, call your dealer.
Side Panel Jacks
Use the side panel jacks to connect a component that is used only occasionally (a camcorder or video
game, for example).
ΠVIDEO Input jack
Connect the video signal from a camcorder or video game.
This
Manual
´ AUDIO Input jacks
A/V Cable
Connect the audio signal from a camcorder or video game.
(AA39-40001B)
ˇ S-VIDEO Input jack
Connect an S-video signal from a camcorder or video game.
(S-Video 3 jack and Audio L/R input 3 are used in conjunction.)
Television
Remote Control
(BP59-00016A)/
AAA Batteries
(4301-000121)
Warranty
Card
▲ ST43L2HX
œ ST50L2HX
œ ST61L2HX
12
13
Your New Wide TV
Front Panel LED Indicators
Rear Panel Jacks
The three lights on the front panel indicate the status of your TV.
Use the rear panel jacks to connect components such as a VCR.
You can connect two different components such as two VCRs, Set-Top Box and a DVD player etc.,
because there are two sets of video input jacks and one set of component video input jacks on the rear
panel of your TV. For more information, please see “Connections”.
Indicator Light Key
: Light is On
: Light is Blinking
: Light is Off
Timer
Lamp
Temp
Indication
Auto Timer ON/OFF has been set
The set is operating normally .
Standby state.
The picture will automatically appear in about 25 seconds.
Auto Timer ON/OFF has been set and the set is normally operating.
Auto Timer ON/OFF has been set and the set will automatically be turned on in
about 25 seconds.
A cooling fan inside the set is not operating normally.
Lamp cover on rear of the set is not properly shut.
Check if the ventilation hole on the rear of the set is blocked, because if the
inner temperature is too high, the power will shut off.
Lamp may be defective. Please contact a certified technician.
ΠANTENNA terminals
Two independent cables or antennas can be connected to these terminals. Use ANT-A and ANT-B terminals to receive a signal from
VHF/UHF antennas or your cable system. Use the ANT A-OUT terminal to send the signal being received by the ANT-A terminal out to
another component (such as a Cable Set Top Box).
The PIP channel can be received only when a signal source is
connected to ANT-A.
´ S-VIDEO INPUT jacks
Connects an S-Video signal from an S-VHS VCR or DVD player.
ˇ VIDEO/AUDIO INPUT jacks(VCR1, VCR2)
Connect video/audio signals from external sources, such as a VCR or
DVD players.
¨ VIDEO/AUDIO MONITOR OUTPUT jacks
Sends a video signal from the TV to an external source, such as a
VCR.
Note: Monitor Out is available only in RF, Video and S-Video modes.
ˆ Component1 jacks (Y, Pb, Pr, L, R)
Use these jacks to connect the component video/audio signals from a
DVD player when using the component video input jacks.
Note: Only 480i and 408p formats are supported.
Ø Component 2, 3 jacks (Y, Pb, Pr, L, R)
Receives the DTV video/audio signals from a set top box.
Note: Only 480p, 720p and 1080i formats are supported.
∏ PC AUDIO INPUT jacks
Connect these to the audio-output jacks on your PC.
” DVI (Digital Video Interface) jack
Receives the digital signals from a set top box or PC etc.
’ RS-232C jack
˝ PC VIDEO INPUT jack
Connect to the video output port on your PC.
• It takes about 30 seconds for the TV to warm up, so normal brightness may not appear immediately.
• The TV has a fan to keep the inside lamp from overheating. You’ll occasionally hear it working.
14
15
Your New Wide TV
Remote Control
Installing Batteries in the Remote Control
You can use the remote control up to a distance of about 23 feet from the TV. When using the remote,
always point it directly at the TV. The remote control can also operate your VCR, cable box, and DVD
player.
With normal use, the batteries in the remote control should last about a year. If you notice a performance
degradation while using the remote, the batteries may need to be replaced. Make sure you replace both
batteries and do not mix old and new batteries in the remote control. If you won’t be using the remote
control for a long time, remove the batteries and store them in a cool dry place.
1.
POWER
Turns the TV on and off.
2.
+100
Press to select cable channels over 100 on
TV.
3.
Menu
4.
CH(Channel) and
VOL(Volume)
5.
Mute
Displays the main on-screen menu.
Controls volume, channel selection.
Press to mute the TV sound.
6.
Display
Press to display information on the TV
screen.
7.
Aspect
Press to change the screen size.
8.
9.
Surround
Press to stop the action during a particular
scene. Press again to resume normal video.
17. Fav.CH (Favorite
Channel)
Adjust the TV picture by selecting one of the
preset factory settings (or select your personal, customized picture settings.)
20. VCR controls
Controls VCR tape functions: Rewind, Play,
Fast Forward, Stop, Pause.
13. Joystick
Use to highlight on-screen menu items and
change menu values.
14. DNIe
Activates DNIe (Digital Natural Image
engine).
15. PIP
Activates picture in picture.
Slide the cover back into place.
Source ; Press to select one of the available
signal sources for the PIP window.
Swap; Exchanges the video signal that is
currently displayed on the main screen with
the signal in the PIP window.
Press to display all of the available video
sources (i.e., TV, VCR, DVD, DTV, PC).
3
21. PIP controls
Locate; Press to move the PIP window to
any of the four corners of the TV screen.
Tunes to the previous channel.
Install two AAA size batteries.
Make sure to match the “+” and
“–” ends of the batteries with the
diagram inside the compartment.
19. P.Mode
MTS(Multichannel
Television Stereo)
12. TV/Video
2
Adjust the TV sound by selecting one of the
preset factory settings (or select your personal, customized sound settings.)
Press to choose stereo, mono or Separate
Audio Program (SAP broadcast).
11. Pre-ch
Slide the back cover all the way out
to open the battery compartment of
the remote control.
18. S.Mode
Scan; Press to scan the memorized
channels.
Selects a target device to be controlled by
the Samsung remote control (i.e., TV, VCR,
Cable, or DVD).
1
Press to switch between your favorite channels.
Press to hear the Dolby surround effect.
10. Mode
16
16. Still
Size; Press to make the PIP window larger
or smaller.
CH(PIP); Displays the available channels in
sequence. (These buttons change channels
in the PIP window only.)
22. V.chip
Press to set up and activate the parental
locks.
23. Set
Used during set up of this remote control,
so that it will work compatibly with other
devices (VCR, cable box, DVD, etc.)
24. Sleep
Press to select a preset time interval for
automatic shutoff.
25. Add/Erase
Press to add or erase channels in the TV’s
memory.
Use the Add/Erase button to
memorize/erase the fine tuning after fine
tuning channels.
17
SAMSUNG
Connections
Connections
Connecting VHF and UHF Antennas
Separate VHF and UHF Antennas
If you do not have a cable system, you will need to connect an antenna to your TV.
If you have two separate antennas for your TV (one VHF and one UHF), you must combine the
two antenna signals before connecting them to the TV. This requires a combiner attachment, which
you can buy at an electronics store.
Antennas with 300-ohm Flat Twin Leads
If your antenna looks like this:
1
2
it has 300-ohm flat twin leads.
1
Connect both antenna
leads to the combiner.
2
Plug the combiner into the
ANT-A terminal on the
back panel of the TV.
Place the wires from the twin
leads under the screws on the
300-75 ohm adapter. Use a
screwdriver to tighten the
screws.
Plug the adapter into the
ANT-A terminal on the back
panel of the TV.
Antennas with 75-ohm Round Leads
If your antenna looks like this:
1
20
it is an antenna with 75-ohm round leads.
Plug the antenna lead into the
ANT-A terminal on the back
panel of the TV.
21
Connections
Connecting Cable TV and VCR
You can connect different cable systems to your TV, including cable without a cable box, and
cable with a cable box that descrambles some or all channels.
Connecting a Cable Converter Box
This connection allows you to watch cable and premium channels. You should keep your TV
selected to ANT-A so that you can use the TV features. When viewing premium channels, select
ANT-B and tune the TV to channel 3 or 4 (whichever channel is vacant in your area), then use the
converter box to change channels. You will need two coaxial cables.
Cable without a Cable Box
Note: When you use a converter box with
your TV, there may be features that you can
not program using the remote control, such
as programming your favorite channels and
blocking channels.
If you want to connect cable, and you do not need to use a cable box:
1
Plug the incoming cable
into the ANT-A antenna terminal on the back of the
TV.
Cable with a Cable Box that Descrambles All Channels
1
2
Find the cable that is connected to the ANTENNA
OUT terminal on your
cable box. This terminal
might be labeled “ANT
OUT,” “VHF OUT,” or simply, “OUT.”
Connect the other end of
this cable to the ANT A
antenna terminal on the
back of the TV.
Connecting a Cable Converter Box and a VCR
This connection allows you to watch and record basic and premium cable channels, as well as
watch videotapes. You should keep your TV selected to ANT-A so that you can use the TV’s features. When viewing premium channels or recording with the VCR, select ANT-B (whichever channel is vacant in your area), then use the converter box to change channels.
Caution: If you want to record one channel
while watching another channel, a splitter
(not included) must be added between the
cable and ANT-A. One output of the splitter
goes to ANT-A and the second output is
connected to IN on the cable converter
box.
If you have a mono VCR, connect L/Mono
to VCR Audio OUT using only one audio
cable.
If you have a S-VHS VCR, use the S-video
connections and remove the video cable.
Do not connect the video cable and the
S-video cable to video1 simultaneously.
When you use a converter box with your
TV there may be features that you can not
program using the remote control, such as
programming your favorite channels and
blocking channels.
22
23
Connections
Connecting a Camcorder
Connecting a DVD Player
The side panel jacks on your TV make it easy to connect a camcorder to your TV.
You can use your camcorder to view tapes without using a VCR.
The rear panel jacks on your TV make it easy to connect a DVD player to your TV.
Connecting to Y,Pb,Pr
1
Locate the A/V output jacks
on the camcorder. They are
usually found on the side or
back of the camcorder.
2
Connect an audio cable
between the AUDIO OUTPUT jack on the camcorder
and the AUDIO terminals
on the side of the TV.
If your camcorder is stereo,
you must connect two separate cables.
(The audio cables are usually included with the camcorder.)
3
24
Connect a video cable
between the VIDEO OUTPUT jack on the camcorder
and the VIDEO terminal on
the side of the TV. (A video
cable is usually included
with the camcorder.) To
watch a tape, follow your
camera’s instructions and
the section on “Viewing an
External Signal Source” in
this manual.
1
Connect a set of audio
cables between the
Component1AUDIO IN
jacks on the TV and the
AUDIO OUT jacks on the
DVD player.
2
To enable Component video
viewing, connect video
cables between the
Component1 (Y, Pb and Pr)
jacks on the TV and Y, Pb
and Pr (or Y, Cb, Cr) output
jacks on the DVD player.
Note: For an explanation of
Component video, see your
DVD player's owner's manual.
Connecting to audio and video jacks
1
Connect a set of audio
cables between the AUDIO
IN jacks on the TV and the
AUDIO OUT jacks on the
DVD player.
2
Connect video cables
between the VIDEO OUT
jack on the DVD player and
the VIDEO IN jack on the
TV.
25
Connections
Connecting a DTV Set Top Box
Connecting to Y,Pb,Pr
1
2
Connect a set of audio
cables between the
Component2 or
Component3 AUDIO IN
jacks on the TV and the
AUDIO OUT jacks on the
Download PDF
