Contents
Contents
Using this user manual
4
The following symbols are used in this User Manual:
4
Safety instructions
5
Important safety instructions
5
Installation
13
Accessories13
Installation site
14
Turntable14
Maintenance
15
Cleaning15
Replacement (repair)
17
Care against an extended period of disuse
17
Quick look-up guide
18
Oven features
19
Oven19
Control panel
20
Oven use
21
How a microwave oven works
21
Checking that your oven is operating correctly
22
Setting the time
23
Cooking/Reheating24
Power levels
25
Adjusting the cooking time
25
Stopping the cooking
26
Setting the energy save mode
26
Using the healthy cooking features
27
Using the my plate features
30
Using the power defrost features
32
Using the soften/melt features
34
Using the keep warm features
36
Using the memory cook features
37
To use the memory cook setting
37
Using the deodorisation features
38
Setting a standing time (kitchen timer)
38
Safety-locking your microwave oven
39
Switching the beefer off
39
2 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 2
2015-08-13
11:45:17
40
Cooking guide
42
Contents
Cookware guide
Microwaves42
Cooking42
Troubleshooting
45
Checkpoints45
Information code
52
Technical specifications
53
English 3
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 3
2015-08-13
11:45:17
Using this user manual
Using this user manual
You have just purchased a SAMSUNG microwave oven. Your Owner’s Instructions contains
valuable information on cooking with your microwave oven:
• Safety precautions
• Suitable accessories and cookware
• Useful cooking tips
• Cooking tips
The following symbols are used in this User Manual:
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property damage.
NOTE
Useful tips, recommendations, or information that helps users manipulate the product.
4 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 4
2015-08-13
11:45:17
Safety instructions
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
Safety instructions
MAKE SURE THAT THESE SAFETY PRECAUTIONS ARE OBEYED AT ALL
TIMES.
BEFORE USING THE OVEN, CONFIRM THAT THE FOLLOWING
INSTRUCTIONS ARE FOLLOWED.
Microwave function only
WARNING: If the door or door seals are damaged, the oven must not be
operated until it has been repaired by a competent person.
WARNING: It is hazardous for anyone other than a competent person to
carry out any service or repair operation that involves the removal of a
cover which gives protection against exposure to microwave energy.
WARNING: Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
This appliance is intended to be used in household only and it is not
intended to be used such as:
•staff kitchen areas in shops, offices and other working environments;
•farm houses;
•by clients in hotels, motels and other residential environments;
•bed and breakfast type environments.
WARNING: Only allow children to use the oven without supervision
when adequate instructions have been given so that the child is able to
use the oven in a safe way and understands the hazards of improper
use.
English 5
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 5
2015-08-13
11:45:17
Safety instructions
Safety instructions
WARNING: This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be
made by children unless they are aged from 8 years and above and
supervised.
Only use utensils that are suitable for use in microwave ovens.
When heating food in plastic or paper containers, keep an eye on the
oven due to the possibility of ignition.
The microwave oven is intended for heating food and beverages.
Drying of food or clothing and heating of warming pads, slippers,
sponges, damp cloth and similar may lead to risk of injury, ignition or
fire.
If smoke is emitted (observed), switch off or unplug the appliance and
keep the door closed in order to stifle any flames.
WARNING: Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when handling the
container.
WARNING: The contents of feeding bottles and baby food jars shall be
stirred or shaken and the temperature checked before consumption, in
order to avoid burns.
Eggs in their shell and whole hard-boiled eggs should not be heated
in microwave ovens since they may explode, even after microwave
heating has ended.
The oven should be cleaned regularly and any food deposits removed.
6 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 6
2015-08-13
11:45:17
Failure to maintain the oven in a clean condition could lead to
deterioration of the surface that could adversely affect the life of the
appliance and possibly result in a hazardous situation.
Safety instructions
The appliance is not intended for installing in road vehicles, caravans
and similar vehicles etc.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the
appliance.
If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a
hazard.
The appliance should not be cleaned with a water jet.
This oven should be positioned proper direction and height permitting
easy access to cavity and control area.
Before using the your oven first time, oven should be operated with the
water during 10 minute and then used.
If the oven generates a strange noise, a burning smell, or smoke is
emitted, unplug the power plug immediately and contact your nearest
service center.
The microwave oven has to be positioned so that plug is accessible.
The microwave oven is intended to be used on the counter top
(freestanding) use only, the microwave oven shall not be placed in a
cabinet.
English 7
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 7
2015-08-13
11:45:17
Safety instructions
Oven function only - Optional
Safety instructions
WARNING: When the appliance is operated in the combination mode,
children should only use the oven under adult supervision due to the
temperatures generated.
During use the appliance becomes hot. Care should be taken to avoid
touching heating elements inside the oven.
WARNING: Accessible parts may become hot during use. Young children
should be kept away.
A steam cleaner is not to be used.
WARNING: Ensure that the appliance is switched off before replacing
the lamp to avoid the possibility of electric shock.
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the surface, which may result in
shattering of the glass.
WARNING: The appliance and its accessible parts become hot during
use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless
continuously supervised.
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children
without supervision.
8 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 8
2015-08-13
11:45:17
The temperature of accessible surfaces may be high when the appliance
is operating.
Safety instructions
The door or the outer surface may get hot when the appliance is
operating.
Keep the appliance and its cord out of reach of children less than 8
years.
Appliances are not intended to be operated by means of an external
timer or separate remote-control system.
General safety
WARNING
Only qualified staff should be allowed to modify or repair the appliance.
Do not heat liquids and other food in sealed containers for microwave function.
For your safety, do not use high-pressure water cleaners or steam jet cleaners.
Do not install this appliance; near heater, inflammable material; in a humid, oily or dusty
location, in a location exposed to direct sunlight and water or where gas may leak; on un
level ground.
This appliance must be properly grounded in accordance with local and national codes.
Remove all foreign substances such as dust or water from the power plug terminals and
contact points using a dry cloth on a regular basis.
Do not pull or excessively bend or place heavy objecton the power cord.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without
touching the power plug.
Do not touch the power plug with wet hands.
Do not turn the appliance off by unplugging the power plug while an operation is in progress.
Do not insert fingers or foreign substances, If any foreign substance such as water has
entered the appliance, unplug the power plug and contact your nearest service centre.
Do not apply excessive pressure or impact to the appliance.
Do not place the oven over a fragile object such as a sink or glass object.
English 9
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 9
2015-08-13
11:45:17
Safety instructions
Do not use benzene, thinner, alcohol, steam cleaner or high pressure cleaner to clean the
appliance.
Safety instructions
Ensure that the power voltage, frequency and current are the same as those of the product
specifications.
Plug the power plug into the wall socket firmly. Do not use a multiple plug adapter, an
extension cord or an electric transformer.
Do not hook the power cord on a metal object, insert the power cord between the objects or
behind the oven.
Do not use a damaged power plug, damaged power cord or loose wall socket. When the
power plug or power cord is damaged, contact your nearest service centre.
Do not pour or directly spray water onto the oven.
Do not place objects on the oven, inside or on the door of the oven.
Do not spray volatile material such as insecticide onto the surface of the oven.
Do not store flammable materials in the oven. Take special care when heating dishes or
drinks that contain alcohol as alcohol vapours may contact a hot part of the oven.
Keep children away from the door when opening or closing it as they may bump themselves
on the door or catch their fingers in the door.
WARNING: Microwave heating of beverages can result in delayed eruptive boiling, therefore
care must be taken when handling the container; To prevent this situation ALWAYS allow
a standing time of at least 20 seconds after the oven has been switched off so that the
temperature can equalize. Stir during heating, if necessary, and ALWAYS stir after heating.
In the event of scalding, follow these FIRST AID instructions:
• Immerse the scalded area in cold water for at least 10 minutes.
• Cover with a clean, dry dressing.
• Do not apply any creams, oils or lotions.
Do not put the tray or rack in water shortly after cooking because it may cause breakage or
damage of the tray or rack.
Do not operate the microwave oven for deep fat frying because the oil temperature cannot
be controlled. This could result in a sudden boil over of the hot liquid.
10 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 10
2015-08-13
11:45:17
CAUTION
Only use utensils that are suitable for use in microwave ovens; DO NOT use any metallic
containers, Dinnerware with gold or silver trimmings, Skewers, forks, etc.
Safety instructions
Remove wire twist ties from paper or plastic bags.
Reason: Electric arcing or sparking may occur and may damage the oven.
Do not use your microwave oven to dry papers or clothes.
Use shorter times for smaller amounts of food to prevent overheating and burning food.
Do not immerse the power cable or power plug in water and keep the power cable away
from heat.
Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens
since they may explode, even after microwave heating has ended; Also do not heat airtight
or vacuum-sealed bottles, jars, containers, nuts inshells, tomatoes etc.
Do not cover the ventilation slots with cloth or paper. They may catch fire as hot air escapes
from the oven. The oven may also overheat and switch itself off automatically, and will
remain off until it cools sufficiently.
Always use oven mitts when removing a dish from the oven to avoid unintentional burns.
Stir liquids halfway during heating or after heating ends and allow the liquid stand at least
20 seconds after heating to prevent eruptive boiling.
Stand at arms length from the oven when opening the door to avoid getting scalded by
escaping hot air or steam.
Do not operate the microwave oven when it is empty. The microwave oven will automatically
shut down for 30 minutes for safety purposes. We recommend placing a glass of water inside
the oven at all times to absorb microwave energy in case the microwave oven is started
accidentally.
Install the oven in compliance with the clearances stated in this manual. (See installing your
microwave oven.)
Take care when connecting other electrical appliances to sockets near the oven.
English 11
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 11
2015-08-13
11:45:17
Safety instructions
Precautions to avoid possible exposure to excessive microwave
energy. (Microwave function only)
Safety instructions
Failure to observe the following safety precautions may result in harmful exposure to
microwave energy.
A. Under no circumstances should any attempt be made to operate the oven with the door
open or to tamper with the safety interlocks (door latches) or to insert anything into the
safety interlock holes.
B. Do NOT place any object between the oven door and front face or allow food or cleaner
residues to accumulate on sealing surfaces. Ensure that the door and door sealing surfaces
are kept clean by wiping after use first with a damp cloth and then with a soft dry cloth.
C. Do NOT operate the oven if it is damaged until it has been repaired by a qualified
microwave service technician trained by the manufacturer. It is particularly important
that the oven door closes properly and that there is no damage to the:
1) door (bent)
2) door hinges (broken or loose)
3) door seals and sealing surfaces
D. The oven should not be adjusted or repaired by anyone other than a properly qualified
microwave service technician trained by the manufacturer.
Samsung will charge a repair fee for replacing an accessory or repairing a cosmetic defect
if the damage to the unit and/or damage to or loss of the accessory was caused by the
customer. Items this stipulation covers include:
A. A dented, scratched, or broken door, handle, out-panel, or control panel.
B. A broken or missing tray, guide roller, coupler, or wire rack.
• Use this appliance only for its intended purpose as described in this instruction manual.
Warnings and Important Safety Instructions in this manual do not cover all possible
conditions and situations that may occur. It is your responsibility to use common sense,
caution, and care when installing, maintaining, and operating your appliance.
• Because these following operating instructions cover various models, the characteristics
of your microwave oven may differ slightly from those described in this manual and not
all warning signs may be applicable. If you have any questions or concerns, contact your
nearest service centre or find help and information online at www.samsung.com.
• This microwave oven is supposed for heating food. It is intended for domestic home-use
only. Do not heat any type of textiles or cushions filled with grains, which could cause
burns and fire. The manufacturer cannot be held liable for damage caused by improper or
incorrect use of the appliance.
• Failure to maintain the oven in a clean condition could lead to deterioration of the surface
that could adversely affect the life of the appliance and possible result in a hazardous
situation.
12 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 12
2015-08-13
11:45:17
Installation
Accessories
Depending on the model that you have purchased, you are supplied
with several accessories that can be used in a variety of ways.
01 Roller ring, to be placed in the
centre of the oven.
Installation
Purpose: The roller ring
supports the
turntable.
02 Turntable, to be placed on
the roller ring with the centre
fitting to the coupler.
Purpose: The turntable
serves as the main
cooking surface;
it can be easily
removed for
cleaning.
NOTE
DO NOT operate the microwave
oven without the roller ring and
turntable.
English 13
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 13
2015-08-13
11:45:18
Installation
Installation site
20 cm
above
Installation
85 cm of
the floor
10 cm
behind
10 cm on
the side
•Do not install the oven in hot or
damp surroundings, such as next
to other microwave ovens or
radiators.
•Conform to the power supply
specifications of this oven. Use
only approved extension cables
if you need to use.
•Select a flat, level surface
approx. 85 cm above the floor.
The surface must support the
weight of the oven.
•Secure room for ventilation, at
least 10 cm from the rear wall
and both sides, and 20 cm from
above.
•Wipe the interior and the door
seal with a damp cloth before
using your oven for the first
time.
Turntable
Remove all packing materials
inside the oven. Install the roller
ring and turntable. Check that the
turntable rotates freely.
14 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 14
2015-08-13
11:45:18
Maintenance
Cleaning
Clean the oven regularly to prevent impurities from building up on or
inside the oven. Also pay special attention to the door, door sealing,
and turntable and roller ring (applicable models only).
If the door won’t open or close smoothly, first check if the door seals
have built up impurities. Use a soft cloth in soapy water to clean both
the inner and outer sides of the oven. Rinse and dry well.
To remove stubborn impurities with bad smells from inside the oven
Maintenance
1. With an empty oven, put a
cup of diluted lemon juice on
the centre of the turntable.
2. Heat the oven for 10 minutes
at max power.
3. When the cycle is complete,
wait until the oven cools
down. Then, open the door
and clean the cooking
chamber.
English 15
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 15
2015-08-13
11:45:18
Maintenance
To clean inside swing-heater models
To clean the upper area of the
cooking chamber, lower the top
heating element by 45° as shown.
This will help clean the upper
area. When done, reposition the
top heating element.
CAUTION
Maintenance
•Keep the door and door sealing
clean and ensure the door opens
and closes smoothly. Otherwise,
the oven’s lifecycle may be
shortened.
•Take caution not to spill water
into the oven vents.
•Do not use any abrasive
or chemical substances for
cleaning.
•After each use of the oven, use
a mild detergent to clean the
cooking chamber after waiting
for the oven to cool down.
16 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 16
2015-08-13
11:45:18
Replacement (repair)
WARNING
Maintenance
This oven has no user-removable parts inside. Do not try to replace or
repair the oven yourself.
•If you encounter a problem with
•If you encounter a problem with
hinges, sealing, and/or the door,
the outer housing of the oven,
contact a qualified technician or
first unplug the power cord
a local Samsung service centre
from the power source, and then
for technical assistance.
contact a local Samsung service
•If you want to replace the light
centre.
bulb, contact a local Samsung
service centre. Do not replace it
yourself.
Care against an extended period of disuse
•If you don’t use the oven for an extended period of time, unplug the
power cord and move the oven to a dry, dust-free location. Dust and
moisture that builds up inside the oven may affect the performance of
the oven.
English 17
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 17
2015-08-13
11:45:18
Quick look-up guide
If you want to cook some food.
1. Place the food in the oven. Press
Microwave button to start cooking.
1
2. Press Up/Down button until the
appropriate power level is displayed. At
that time, press the Select button to set
the power level.
2
2
3. Set the cooking time by Pressing Up/
Down button.
3
Quick look-up guide
4
4. Press the START button.
Result: Cooking starts. The oven beeps
4 times when cooking is over.
If you want to Power defrost some food.
1. Place the frozen food in the oven. Press
the Power Defrost button.
1
2. Set the cooking category by Pressing
Up/Down button. Press the Select button
to set desired.
2
2
3. Select the weight by turning the
Pressing Up/Down button required.
3
4. Press the START button.
4
If you want to add extra 30 seconds.
Leave the food in the oven.
Press the +30s one or more times for each
extra 30 seconds that you wish to add.
Pressing the START button
18 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 18
2015-08-13
11:45:19
Oven features
Oven
01
05
06
07
08
03
09
10
Oven features
04
02
11
01 Ventilation holes
02 Light
03 Display
04 Door latches
05 Door
06 Turntable
07 Coupler
08 Roller ring
09 Safety interlock holes
10 Open door push button
11 Control panel
English 19
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 19
2015-08-13
11:45:19
Oven features
Control panel
01
02
Oven features
03
04
05
06
07
08
09
10
11
01 Healthy Cooking Selection
02 My Plate Button
03 Power Defrost Button
04 Soften/Melt Button
05 Keep Warm Button
06 Microwave Mode Button
07 Memory Cook Button
08 Deodorisation Button
09 Kitchen Timer Button
10 Clock Button
11 Child Lock Button
12 Up/Down Button (Cooking time, Weight
and serving size)
13 Select Button
14 Stop/Energy save Button
15 +30s Button
16 Start Button
12
13
14
16
15
20 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 20
2015-08-13
11:45:19
Oven use
How a microwave oven works
Microwaves are high-frequency electromagnetic waves; the energy released enables food to
be cooked or reheated without the foods form or colour changing.
You can use your microwave oven to:
• Defrost (manual & auto)
• Cook
• Reheat
Cooking Principle.
Oven use
1. The microwaves generated by the
magnetron are distributed uniformly as
the food rotates on the turntable. The
food is thus cooked evenly.
2. The microwaves are absorbed by the
food up to a depth of about 1 inch
(2.5 cm). Cooking then continues as the
heat is dissipated within the food.
3. Cooking times vary according to the
recipient used and the properties of the
food:
• Quantity and density
• Water content
• Initial temperature (refrigerated or not)
NOTE
As the centre of the food is cooked by heat
dissipation, cooking continues even when
you have taken the food out of the oven.
Standing times specified in recipes and in
this booklet must therefore be respected to
ensure:
• Even cooking of the food right to the
centre.
• The same temperature throughout the
food.
English 21
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 21
2015-08-13
11:45:19
Oven use
Checking that your oven is operating correctly
The following simple procedure enables you to check that your oven is working correctly at
all times.
Open the oven door, and place a glass of water on the turntable. Then, close the door.
1. Press the +30s button and set the time
to 4-5 minutes by pressing +30s button
the appropriate number of times.
1
2
2. Press the START button.
Result: The oven heats the water for
4 to 5 minutes. The water
should then be boiling.
NOTE
The oven must be plugged into an
appropriate wall socket. The turntable must
be in position in the oven. If a power level
other than the maximum is used, the water
takes longer to boil.
Oven use
22 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 22
2015-08-13
11:45:19
Setting the time
When power is supplied, “88:88” and then “12:00” is automatically displayed on the display.
Please set the current time. The time can be displayed in either the 24-hour or 12-hour
notation. You must set the clock:
• When you first install your microwave
NOTE
oven
Do not forget to reset the clock when you
• After a power failure
switch to and from summer and winter time.
1. Press the Clock button.
2. Press Up/Down button to set time
display type. (12H or 24H)
3. Press the Select button to complete the
setup.
1
2
3
4
6
5
7
4.
5.
6.
7.
Oven use
Press Up/Down button to set the hour.
Press the Select button.
Press Up/Down button to set the minute.
When the right time is displayed, press
the Select button to start the clock.
Result: The time is displayed
whenever you are not using
the microwave oven.
English 23
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 23
2015-08-13
11:45:20
Oven use
Cooking/Reheating
The following procedure explains how to cook or reheat food.
NOTE
ALWAYS check your cooking settings before
leaving the oven unattended.
Open the door. Place the food in the centre
of the turntable. Close the door. Never
switch the microwave oven on when it is
empty.
1. Press the Microwave button.
Result: The following indications are
displayed:
1
(microwave mode)
2. Press Up/Down button until the
appropriate power level is displayed. At
that time, press the Select button to set
the power level.
• If don’t set the power level within
5 seconds, automatically changes to
the cooking time setting stage.
2
2
Oven use
3
4
NOTE
Never switch the microwave oven on when
it is empty.
3. Set the cooking time by pressing Up/
Down button.
Result: The cooking time is displayed.
4. Press the START button.
Result: The oven light comes on and
the turntable starts rotating.
Cooking starts and when it has
finished.
• The oven beep and flash “End” 4 times.
The oven will then beep one time per
minute.
NOTE
If you wish to heat a dish for a short
period of time at maximum power (800 W),
simply press the +30s button once for each
30 seconds of cooking time. Press the START
button to start cooking.
24 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 24
2015-08-13
11:45:20
Power levels
You can choose among the power levels below.
Power level
NOTE
Output
HIGH
800 W
MEDIUM HIGH
600 W
MEDIUM
450 W
MEDIUM LOW
300 W
DEFROST
180 W
LOW
100 W
If you select higher power level, the cooking
time must be decreased.
NOTE
If you select lower power level, the cooking
time must be increased.
Adjusting the cooking time
You can increase the cooking time by pressing the +30s button once for each 30 seconds to
be added.
1. Press the +30s button once for each
30 seconds to be added.
1
Oven use
2. Press the START button.
2
English 25
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 25
2015-08-13
11:45:20
Oven use
Stopping the cooking
You can stop cooking at any time to check the food.
1. To stop temporarily;
Open the door.
Result: Cooking stops. To resume
cooking, close the door and
press the START button again.
2
2. To stop completely;
Press the STOP/ECO button.
Result: The cooking stops. If you wish
to cancel the cooking settings,
press the STOP/ECO button
again.
NOTE
Oven use
You can cancel any setting before starting
cooking by simply pressing the STOP/ECO
button.
Setting the energy save mode
The oven has an energy save mode.
• Press the STOP/ECO button.
Result: Display off.
• To remove energy save mode, open the
door or press the STOP/ECO button and
then display shows current time. The oven
is ready for use.
NOTE
Auto energy saving function
If you do not select any function when
appliance is in the middle of setting or
operating with temporary stop condition,
function is canceled and clock will be
displayed after 25 minutes.
Oven Lamp will be turned off after
5 minutes with door open condition.
26 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 26
2015-08-13
11:45:21
Using the healthy cooking features
The 16 Healthy Cooking features provide pre-programmed cooking times.
You do not need to set either the cooking times or the power level.
NOTE
Use only recipients that are microwave-safe.
Open the door. Place the food in the centre
of the turntable. Close the door.
1. Press the Healthy Cooking button.
1
2
3
Oven use
2. Select the type of food that you are
cooking by pressing Up/Down button.
Refer to the table on the following
page for a description of the various
preprogrammed settings.
3. Press the START button.
Result: The food is cooked according
to the pre-programmed setting
selected.
• When cooking has finished, the oven
will beep and flash “End” 4 times.
The oven will then beep one time per
minute.
English 27
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 27
2015-08-13
11:45:21
Oven use
Healthy cooking guide
1. Vegetable/Grains
Oven use
Code/Food
Serving Size
Instructions
1
Broccoli Florets
250 g
Rinse and clean fresh broccoli and prepare florets.
Put them evenly into a glass bowl with lid. Add 30 ml
(2 tbsp) water when cooking for 250 g. Put bowl in the
centre of turntable.
Cook covered. Stir after cooking. Stand for 1-2 minutes.
2
Sliced Carrots
250 g
Rinse and clean carrots and prepare even slices. Put them
evenly into a glass bowl with lid. Add 30 ml (2 tbsp)
water when cooking for 250 g. Put bowl in the centre of
turntable.
Cook covered. Stir after cooking. Stand for 1-2 minutes.
3
Green Beans
250 g
Rinse and clean green beans. Put them evenly into a
glass bowl with lid. Add 30 ml (2 tbsp) water when
cooking 250 g. Put bowl in the centre of turntable. Cook
covered. Stir after cooking. Stand for 1-2 minutes.
4
Spinach
150 g
Rinse and clean spinach. Put into a glass bowl with lid.
Do not add water. Put bowl in the centre of turntable.
Cook covered. Stir after cooking. Stand for 1-2 minutes.
5
Corn on the cob
250 g
(1 pcs)
Rinse and clean corn on the cob and put into an oval
glass dish. Cover with microwave cling film and pierce
film. Stand for 1-2 minutes.
6
Peeled Potatoes
250 g
Wash and peel the potatoes and cut into a similar size.
Put them into a glass bowl with lid. Add 45-60 ml
(3-4 tbsp) water. Put bowl in the centre of turntable. Cook
covered. Stand for 2-3 minutes.
7
Brown Rice
125 g
Use a large glass ovenware dish with lid. Add double
quantity of cold water (250 ml). Cook covered. Stir
before standing time and add salt and herbs. Stand for
5-10 minutes.
8
Wholemeal
Macaroni
125 g
Use a large glass ovenware dish with lid. Add 500 ml
hot boiling water, a pinch of salt and stir well. Cook
uncovered. Stir before standing time and drain
thoroughly afterwards. Stand for 1 minutes.
28 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 28
2015-08-13
11:45:21
Code/Food
Serving Size
Instructions
9
Quinoa
125 g
Use a large glass ovenware dish with lid. Add double
quantity of cold water (250 ml). Cook covered. Stir
before standing time and add salt and herbs. Stand for
1-3 minutes.
10
Bulgur
125 g
Use a large glass ovenware dish with lid. Add double
quantity of cold water (250 ml). Cook covered. Stir
before standing time and add salt and herbs. Stand for
2-5 minutes.
2. Poultry/Seafood
Serving Size
Instructions
1
Chicken Breasts
300 g
(2 pcs)
Rinse pieces and put on a ceramic plate. Cover with
microwave cling film. Pierce film. Put dish on turntable.
Stand for 2 minutes.
2
Turkey Breasts
300 g
(2 pcs)
Rinse pieces and put on a ceramic plate. Cover with
microwave cling film. Pierce film. Put dish on turntable.
Stand for 2 minutes.
3
Fresh Fish
Fillets
300 g
(2 pcs)
Rinse fish and put on a ceramic plate, add 1 tbsp lemon
juice. Cover with microwave cling film. Pierce film. Put
dish on turntable. Stand for 1-2 minutes.
4
Fresh Salmon
Fillets
300 g
(2 pcs)
Rinse fish and put on a ceramic plate, add 1 tbsp lemon
juice. Cover with microwave cling film. Pierce film. Put
dish on turntable. Stand for 1-2 minutes.
5
Fresh Prawns
250 g
Rinse prawns on a ceramic plate, add 1 tbsp lemon juice.
Cover with microwave cling film. Pierce film. Put dish on
turntable. Stand for 1-2 minutes.
6
Fresh Trout
200 g
(1 fish)
Put 2 fresh whole fish into an ovenproof dish. Add a
pinch salt, 1 tbsp lemon juice and herbs. Cover with
microwave cling film. Pierce film. Put dish on turntable.
Stand for 2 minutes.
Oven use
Code/Food
English 29
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 29
2015-08-13
11:45:21
Oven use
Using the my plate features
The My Plate features has two pre-programmed cooking times.
You do not need to set either the cooking times or the power level. You can adjust the
number of servings by Pressing Up/Down button.
First, place the food in the centre of the turntable and close the door.
1
1
1. Press the My Plate button. Select the
type of food that you are cooking by
pressing Up/Down button. Press the
Select button.
1) Ready Meal (Chilled)
2) Vegetarian Meal (chilled)
1
2
3
Oven use
2. Select the size of the serving by Pessing
Up/Down button. (Refer to the table on
the side.)
3. Press the START button.
Result: Cooking starts. When it has
finished.
1) The oven beeps 4 times.
2) The end reminder signal will beep
3 times (once every minute).
3) The current time is displayed again.
NOTE
Use only recipients that are microwave-safe.
30 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 30
2015-08-13
11:45:21
The following table presents the My Plate auto reheat programmes, quantities and
appropriate Instructions. Those programmes are running with microwave energy only.
Code/Food
Serving Size
Instructions
1
Chilled
Ready Meal
300-350 g
400-450 g
Put on a ceramic plate and cover with microwave cling
film. This programme is suitable for meals consisting of
3 components (e.g. meat with sauce, vegetables and a side
dishes like potatoes, rice or pasta). Stand for 2-3 minutes.
2
Chilled
Vegetarian
Meal
300-350 g
400-450 g
Put meal on a ceramic plate and cover with microwave
cling film. This programme is suitable for meals consisting
of 2 components (e.g. spaghetti with sauce or rice with
vegetables). Stand for 2-3 minutes.
Oven use
English 31
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 31
2015-08-13
11:45:21
Oven use
Using the power defrost features
The Power Defrost features enable you to defrost meat, poultry, fish, bread/cake.
The defrost time and power level are set automatically. You simply select the programme and
the weight.
NOTE
Use only containers that are microwavesafe.
Open the door. Place the frozen food on a
ceramic in the centre of the turntable. Close
the door.
1. Press the Power Defrost button.
1
2. Select the type of food that you are
cooking by Pressing Up/Down button.
Refer to the table on the following
page for a description of the various
preprogrammed settings. At that time,
press the Select button to select the type
of food.
2
2
Oven use
3
4
5
3. Select the size of the serving by
Pressing Up/Down button.
4. Press the START button.
Result:
• Defrosting begins.
• The oven beeps through defrosting to
remind you to turn the food over.
5. Press the START button again to
continue defrosting.
Result: When cooking has finished, the
oven will beep and flash “End”
4 times. The oven will then
beep one time per minute.
32 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 32
2015-08-13
11:45:21
The following table presents the various Power Defrost programmes, quantities and
appropriate instructions. Remove all kind of package material before defrosting.
Place meat, poultry, fish, bread/cake on a ceramic plate.
Code/Food
Serving Size
Instructions
1
Meat
200-1500 g
Shield the edges with aluminium foil. Turn the meat over
when the oven beeps. This programme is suitable for beef,
lamb, pork, steaks, chops and minced meat.
Stand for 20-60 minutes.
2
Poultry
200-1500 g
Shield the leg and wing tips with aluminium foil. Turn the
poultry over when the oven beeps. This programme is
suitable for whole chicken and chicken portions. Stand for
20-60 minutes.
3
Fish
200-1500 g
Shield the tail of the whole fish with aluminium foil. Turn
the fish over when the oven beeps. This programme is
suitable for whole fishes and fish fillets.
Stand for 20-50 minutes.
4
Bread/Cake
125-625 g
Oven use
Put bread on a piece of kitchen paper and turn over, as
soon as the oven beeps. Place cake on a ceramic plate and if
possible, turn over, as soon as the oven beeps. (Oven keeps
operating and is stopped, when you open the door.
This programme is suitable for all kinds of bread, sliced or
whole, as well as for bread rolls and baguettes.
Arrange bread rolls in a circle. This programme is suitable
for all kinds of yeast cake, biscuit, cheese cake and puff
pastry. It is not, suitable for short/crust pastry, fruit and
cream cakes as well as for cake with chocolate topping.
Stand for 5-20 minutes.
English 33
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 33
2015-08-13
11:45:21
Oven use
Using the soften/melt features
The Soften/Melt features has four pre-programmed cooking times.
You do not need to set either the cooking times or the power level. You can adjust the
number of servings by Pressing Up/Down button.
First, place the food in the centre of the turntable and close the door.
1. Press the Soften/Melt button.
1
2. Select the type of food that you are
cooking by pressing Up/Down button
then press Select button.
2
2
3. Select the size of the serving by
Pressing Up/Down button. (Refer to the
table on the side.)
3
Oven use
4
4. Press the START button.
Result: Cooking starts. When it has
finished.
1) The oven beeps 4 times.
2) The end reminder signal will beep
3 times (once every minute).
3) The current time is displayed again.
NOTE
Use only recipients that are microwave-safe.
34 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 34
2015-08-13
11:45:22
The following table presents the Soften/Melt programmes, quantities and appropriate
Instructions. Those programmes are running with microwave energy only.
Code/Food
Serving Size
Instructions
1
Melting Butter
50 g
100 g
Cut butter into 3 or 4 pieces and Put them on small
glass bowl. Melt uncovered. Stir after cooking. Stand for
1-2 minutes.
2
Melting Dark
Chocolate
50 g
100 g
Grate dark chocolate and put in small glass bowl. Melt
uncovered. Stir after melting. Stand for 1-2 minutes.
3
Melting Sugar
25 g
50 g
Put sugar on small glass bowl. Add 10 ml water for 25 g
and add 20 ml water for 50 g. Melt uncovered. Take
out carefully, use oven gloves! Use spoon or fork and
pour caramel decorations on baking paper. Let stand for
10 minutes until dry and remove from paper.
4
Soften Butter
50 g
100 g
Cut butter into 3 or 4 pieces and Put them in small glass
bowl. Soften uncovered. Stir after cooking. Stand for
1-2 minutes.
Oven use
English 35
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 35
2015-08-13
11:45:22
Oven use
Using the keep warm features
The Keep warm feature keeps food hot until it’s served. Use this function to keep food warm
until ready to serve. Keep warm mode operates for 99 minute.
1. Press the Keep warm button.
1
2
3
NOTE
Do not cover with lids or plastic wrap.
NOTE
Oven use
Use oven gloves when taking out food.
2. Press the Up/Down button if you want
to set the warming time.
(Warming time is set as 99 minute at
first)
3. Press the START button.
To stop warming the food, open the door
or press STOP/ECO button.
NOTE
Do not use this function to reheat cold
foods. This programmes are for keeping
food warm that has just been cooked.
NOTE
Do not recommend food being kept warm
for too long (more than 1 hour), as it will
continue to cook. Warm food spoils more
quickly.
36 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 36
2015-08-13
11:45:22
Using the memory cook features
If you often cook or reheat the same types of dishes, you can store the cooking times and
power levels in the oven’s memory, so that you do not have to reset them each order.
you can store two different setting.
2
2
3
3
1. Set your cooking programme as usual
(cooking time and power level) see
Cooking/Reheating page again if
necessary.
2. Press Memory Cook button, then select
the program that you want to save by
pressing Up/Down button.
• P1 : First setting
• P2 : Second setting
3. Press the Select button to finish the
setting. Or, press the START button to
start the program immediately.
Result: Your setting are now stored in
the oven’s memory.
Oven use
To use the memory cook setting
First, place the food in the centre of the turntable and close the door.
1. Press Memory Cook button, then select
the program by pressing Up/Down
button.
• P1 : First setting
• P2 : Second setting
2. Press the START button.
Result: The food is cooked as
requested.
1
1
2
English 37
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 37
2015-08-13
11:45:22
Oven use
Using the deodorisation features
Use this features after cooking odorous food or when there is a lot of smoke in the oven
interior. First clean the oven interior.
Press the Deodorisation button after you
have finished cleaning and press the START
button. You will hear four beeps when it has
finished.
NOTE
The deodorisation time has been specified
as 5 minutes. It increases by 30 seconds
whenever the +30s button is pressed.
NOTE
The maximum deodorisation time is
15 minutes.
Setting a standing time (kitchen timer)
Oven use
The Kitchen Timer can be used to set a standing time automatically (without microwave
cooking).
First, place the food in the centre of the turntable and close the door.
1. Press the Kitchen Timer button.
2. Select the Standing time by pressing Up/
Down button.
3. Press the START button.
Result: Standing time starts. When it
has finished.
• The oven beeps 4 times.
• The current time is displayed again.
1
2
3
38 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 38
2015-08-13
11:45:23
Safety-locking your microwave oven
Your microwave oven is fitted with a special Child Safety programme, which enables
the oven to be “locked” so that children or anyone unfamiliar with it cannot operate it
accidentally.
The oven can be locked at any time.
1. Press the Child Lock button for
3 seconds.
Result:
• The oven is locked (no functions can
be selected).
• The display shows “L”.
1
2
2. To unlock the oven, press the Child Lock
button again for 3 seconds.
Result: The oven can be used
normally.
Switching the beefer off
1
1
2
2
Oven use
You can switch the beeper off whenever you want.
1. Press the STOP/ECO and START button
at the same time.
Result: The oven will not beep each
time you press a button.
• The following indication is displayed.
2. To switch the beeper back on, press the
STOP/ECO and START buttons again at
the same time.
Result: The oven will not beep each
time you press a button.
• The following indication is displayed.
English 39
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 39
2015-08-13
11:45:23
Cookware guide
To cook food in the microwave oven, the microwaves must be able to penetrate the food,
without being reflected or absorbed by the dish used.
Care must therefore be taken when choosing the cookware. If the cookware is marked
microwave-safe, you do not need to worry.
The following table lists various types of cookware and indicates whether and how they
should be used in a microwave oven.
Cookware
Microwave-safe
Comments
Aluminum foil
✓✗
Can be used in small quantities to protect areas
against overcooking. Arcing can occur if the foil
is too close to the oven wall or if too much foil
is used.
Crust plate
✓
Do not preheat for more than 8 minutes.
China and
earthenware
✓
Porcelain, pottery, glazed earthenware and bone
china are usually suitable, unless decorated with
a metal trim.
Disposable polyester
cardboard dishes
✓
Some frozen foods are packaged in these
dishes.
• Polystyrene cups
containers
✓
Can be used to warm food. Overheating may
cause the polystyrene to melt.
• Paper bags or
newspaper
✗
May catch fire.
• Recycled paper or
metal trims
✗
May cause arcing.
• Oven-to-tableware
✓
Can be used, unless decorated with a metal trim.
• Fine glassware
✓
Can be used to warm foods or liquids. Delicate
glass may break or crack if heated suddenly.
• Glass jars
✓
Must remove the lid. Suitable for warming only.
• Dishes
✗
May cause arcing or fire.
• Freezer bag twist
ties
✗
Fast-food packaging
Cookware guide
Glassware
Metal
40 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 40
2015-08-13
11:45:23
Cookware
Microwave-safe
Comments
Paper
• Plates, cups,
napkins and kitchen
pape
✓
For short cooking times and warming. Also to
absorb excess moisture.
• Recycled paper
✗
May cause arcing.
• Containers
✓
Particularly if heat-resistant thermoplastic.
Some other plastics may warp or discolour at
high temperatures. Do not use Melamine plastic.
• Cling film
✓
Can be used to retain moisture. Should not
touch the food. Take care when removing the
film as hot steam will escape.
• Freezer bags
✓✗
Only if boilable or oven-proof. Should not be
airtight. Prick with a fork, if necessary.
Wax or grease-proof
paper
✓
Can be used to retain moisture and prevent
spattering.
Plastic
✓
: Recommended
✓✗
: Use caution
✗
: Unsafe
Cookware guide
English 41
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 41
2015-08-13
11:45:23
Cooking guide
Microwaves
Microwave energy actually penetrates food,
attracted and absorbed by its water, fat and
sugar content.
The microwaves cause the molecules in the
food to move rapidly. The rapid movement
of these molecules creates friction and the
resulting heat cooks the food.
Cooking
Cookware for microwave cooking:
Covering during cooking
Cookware must allow microwave energy to
pass through it for maximum efficiency.
Microwaves are reflected by metal, such as
stainless steel, aluminium and copper, but
they can penetrate through ceramic, glass,
porcelain and plastic as well as paper and
wood. So food must never be cooked in
metal containers.
To cover the food during cooking is very
important, as the evaporated water rises as
steam and contributes to cooking process.
Food can be covered in different ways:
e.g. with a ceramic plate, plastic cover or
microwave suitable cling film.
Food suitable for microwave cooking:
Cooking guide
Many kinds of food are suitable for
microwave cooking, including fresh or
frozen vegetables, fruit, pasta, rice, grains,
beans, fish, and meat. Sauces, custard, soups,
steamed puddings, preserves, and chutneys
can also be cooked in a microwave oven.
Generally speaking, microwave cooking
is ideal for any food that would normally
be prepared on a hob. Melting butter or
chocolate, for example (see the chapter with
tips, techniques and hints).
Standing times
After cooking is over food the standing time
is important to allow the temperature to
even out within the food.
42 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 42
2015-08-13
11:45:23
Reheating liquids and food
Use the power levels and times in this table as a guide lines for reheating.
Food
Drinks (Coffee, Tea
and Water)
Serving Size
Power
Time (min.)
150 ml (1 cup)
250 ml (1 mug)
800 W
1-1½
1½-2
Instructions
Pour into cup and reheat uncovered. Put cup/mug in the centre of
turntable. Keep in microwave oven during standing time and stir
well. Stand for 1-2 minutes.
Soup (Chilled)
250 g
800 W
3-3½
Instructions
Pour into a deep ceramic plate. Cover with plastic lid. Stir well after
reheating. Stir again before serving. Stand for 2-3 minutes.
Stew (Chilled)
350 g
600 W
5½-6½
Instructions
Put stew in a deep ceramic plate. Cover with plastic lid. Stir
occasionally during reheating and again before standing and
serving. Stand for 2-3 minutes.
Pasta with Sauce
(Chilled)
Plated Meal (Chilled)
600 W
4½-5½
Instructions
Put pasta (e.g. spaghetti or egg noodles) on a flat ceramic plate.
Cover with microwave cling film. Stir before serving. Stand for
3 minutes.
350 g
600 W
Cooking guide
Filled Pasta with
Sauce (Chilled)
350 g
5-6
Instructions
Put filled pasta (e.g. ravioli, tortellini) in a deep ceramic plate. Cover
with plastic lid. Stir occasionally during reheating and again before
standing and serving. Stand for 3 minutes.
350 g
600 W
5½-6½
Instructions
Plate a meal of 2-3 chilled components on a ceramic dish. Cover
with microwave cling-film. Stand for 3 minutes.
English 43
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 43
2015-08-13
11:45:23
Cooking guide
Food
Pasta (Frozen)
(Cannelloni,
Macaroni, Lasagne)
Instant Noodle
Serving Size
Power
Time (min.)
400 g
450 W
16-16½
Instructions
Put frozen pasta into a small flat rectangular glass pyrex dish. Put
the dish directly on the turntable. Stand for 2-3 minutes.
1 Small pack (80 g)
1 Big pack (120 g)
800 W
7½-8
9½-10
Instructions
Use a glass pyrex bowl. Put the noodle and add room temperature
350 ml water in bowl. Cook covered with wrap and pierce at
several times. After cooking, drain water and mix instant noodle
spices.
Boiled Yam
350 g
800 W
12½-13
Instructions
Peel and cut yam 3 cm thick and put on pyrex bowl. Add room
temperature 250 ml water in bowl. Cook covered with wrap and
pierce at several times. After cooking, drain water and serve.
Stand for 1-2 minutes.
Cooking guide
44 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 44
2015-08-13
11:45:23
Troubleshooting
You may encounter a problem using the oven. In that case, first check the table below and
try the suggestions. If a problem persists, or if any information code keeps appearing on
the display, contact a local Samsung service centre.
Checkpoints
If you encounter a problem with the oven, first check the table below and try the
suggestions.
Problem
Cause
Action
General
Remove the foreign matter and
try again.
For touch models: Moisture
is on the exterior.
Wipe the moisture from the
exterior.
Child lock is activated.
Deactivate Child lock.
The time is not
displayed.
Power is not supplied.
Make sure power is supplied.
The Eco (power-saving)
function is set.
Turn off the Eco function.
The oven does not work.
Power is not supplied.
Make sure power is supplied.
The door is open.
Close the door and try again.
The door open safety
mechanisms are covered in
foreign matter.
Remove the foreign matter and
try again.
The user has opened the
door to turn food over.
After turning over the food,
press the Start button again to
start operation.
The oven stops while in
operation.
Troubleshooting
Foreign matter may
be caught between the
buttons.
The buttons cannot be
pressed properly.
English 45
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 45
2015-08-13
11:45:23
Troubleshooting
Problem
Cause
Action
The oven has been cooking
for an extended period of
time.
After cooking for an extended
period of time, let the oven cool.
The cooling fan is not
working.
Listen for the sound of the
cooling fan.
Trying to operate the oven
without food inside.
Put food in the oven.
There is not sufficient
ventilation space for the
oven.
There are intake/exhaust outlets
on the front and rear of the
oven for ventilation. Keep the
gaps specified in the product
installation guide.
Several power plugs are
being used in the same
socket.
Designate only one socket to be
used for the oven.
There is no power to the
oven.
Power is not supplied.
Make sure power is supplied.
There is a popping
sound during operation,
and the oven doesn’t
work
Cooking sealed food or
using a container with a
lid may causes popping
sounds.
Do not use sealed containers
as they may burst during
cooking due to expansion of the
contents.
The oven exterior is too
hot during operation.
There is not sufficient
ventilation space for the
oven.
There are intake/exhaust outlets
on the front and rear of the
oven for ventilation. Keep the
gaps specified in the product
installation guide.
Objects are on top of the
oven.
Remove all objects on the top of
the oven.
Food residue is stuck
between the door and oven
interior.
Clean the oven and then open
the door.
The power turns off
during operation.
Troubleshooting
The door cannot be
opened properly.
46 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 46
2015-08-13
11:45:23
Cause
Action
The oven does not heat.
The oven may not work, too
much food is being cooked,
or improper cookware is
being used.
Put one cup of water in a
microwave-safe container
and run the microwave for
1-2 minutes to check whether
the water is heated. Reduce the
amount of food and start the
function again. Use a cooking
container with a flat bottom.
Heating is weak or slow.
The oven may not work, too
much food is being cooked,
or improper cookware is
being used.
Put one cup of water in a
microwave-safe container
and run the microwave for
1-2 minutes to check whether
the water is heated. Reduce the
amount of food and start the
function again. Use a cooking
container with a flat bottom.
The warm function does
not work.
The oven may not work, too
much food is being cooked,
or improper cookware is
being used.
Put one cup of water in a
microwave-safe container
and run the microwave for
1-2 minutes to check whether
the water is heated. Reduce the
amount of food and start the
function again. Use a cooking
container with a flat bottom.
The thaw function does
not work.
The oven may not work, too
much food is being cooked,
or improper cookware is
being used.
Put one cup of water in a
microwave-safe container
and run the microwave for
1-2 minutes to check whether
the water is heated. Reduce the
amount of food and start the
function again. Use a cooking
container with a flat bottom.
Troubleshooting
Problem
English 47
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 47
2015-08-13
11:45:23
Troubleshooting
Problem
Cause
Action
The door has been left open
for a long time.
The interior light may
automatically turn off when the
Eco function operates. Close and
reopen the door or press the
Cancel button.
The interior light is covered
by foreign matter.
Clean the inside of the oven and
check again.
A beeping sound occurs
during cooking.
If the Auto Cook function
is being used, this beeping
sound means it’s time to
turn over the food during
thawing.
After turning over the food,
press the Start button again to
restart operation.
The oven is not level.
The oven is installed on an
uneven surface.
Make sure the oven is installed
on flat, stable surface.
There are sparks during
cooking.
Metal containers are used
during the oven/thawing
functions.
Do not use metal containers.
When power is
connected, the oven
immediately starts to
work.
The door is not properly
closed.
Close the door and check again.
There is electricity
coming from the oven.
The power or power socket
is not properly grounded.
Make sure the power and power
socket are properly grounded.
There is water dripping.
There may be water or
steam in some cases
depending on the food. This
is not an oven malfunction.
Let the oven cool and then wipe
with a dry dish towel.
There is steam through a
crack in the door.
There may be water or
steam in some cases
depending on the food. This
is not an oven malfunction.
Let the oven cool and then wipe
with a dry dish towel.
The interior light is dim
or does not turn on.
Troubleshooting
48 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 48
2015-08-13
11:45:23
Problem
Cause
Action
There is water left in the
oven.
There may be water or
steam in some cases
depending on the food. This
is not an oven malfunction.
Let the oven cool and then wipe
with a dry dish towel.
The brightness inside
the oven varies.
Brightness changes
depending on power output
changes according to
function.
Power output changes during
cooking are not malfunctions.
This is not an oven malfunction.
Cooking is finished, but
the cooling fan is still
running.
To ventilate the oven, the
cooling fan continues to run
for about 3 minutes after
cooking is complete.
This is not an oven malfunction.
Pressing the +30s button
operates the oven.
This happens when the
oven was not operating.
The microwave oven is designed
to operate by pressing the
+30s button when it was not
operating.
While turning, the
turntable comes out of
place or stops turning.
There is no roller ring,
or the roller ring is not
properly in place.
Install the roller ring and then
try again.
The turn table drags
while turning.
The roller ring is not
properly in place, there
is too much food, or the
container is too large and
touches the inside of the
microwave.
Adjust the amount of food and
do not use containers that are
too large.
The turn table rattles
while turning and is
noisy.
Food residue is stuck to the
bottom of the oven.
Remove any food residue stuck
to the bottom of the oven.
Turntable
Troubleshooting
English 49
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 49
2015-08-13
11:45:23
Troubleshooting
Problem
Cause
Action
Smoke comes out during
operation.
During initial operation,
smoke may come from the
heating elements when you
first use the oven.
This is not a malfunction, and if
you run the oven 2-3 times, it
should stop.
Food is on the heating
elements.
Let the oven cool and then
remove the food from the
heating elements.
Food is too close to the
grill.
Put the food a suitable distance
away while cooking.
Food is not properly
prepared and/or arranged.
Make sure food is properly
prepared and arranged.
The oven does not heat.
The door is open.
Close the door and try again.
Smoke comes out during
preheating.
During initial operation,
smoke may come from the
heating elements when you
first use the oven.
This is not a malfunction, and if
you run the oven 2-3 times, it
should stop.
Food is on the heating
elements.
Let the oven cool and then
remove the food from the
heating elements.
There is a burning or
plastic smell when using
the oven.
Plastic or non heat-resistant
cookware is used.
Use glass cookware suitable for
high temperatures.
There is a bad smell
coming from inside the
oven.
Food residue or plastic has
melted and stuck to the
interior.
Use the steam function and then
wipe with a dry cloth.
You can put a lemon slice inside
and run the oven to remove the
odour more quickly.
Grill
Oven
Troubleshooting
50 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 50
2015-08-13
11:45:23
Problem
The oven does not cook
properly.
Cause
Action
The oven door is frequently
opened during cooking.
Do not frequently open the door
unless you are cooking things
that need to be turned. If you
open the door often, the interior
temperature will be lowered and
this may affect the results of
your cooking.
The oven controls are not
correctly set.
Correctly set the oven controls
and try again.
The grill or other
accessories are not
correctly inserted.
Correctly insert the accessories.
The wrong type or size of
cookware is used.
Reset the oven controls or use
suitable cookware with flat
bottoms.
NOTE
If the above guidelines do not enable you to solve the problem, then contact your local
SAMSUNG customer service centre.
Please have the following information read;
• The model and serial numbers, normally printed on the rear of the oven
• Your warranty details
• A clear description of the problem
Then contact your local dealer or SAMSUNG aftersales service.
Troubleshooting
English 51
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 51
2015-08-13
11:45:24
Troubleshooting
Information code
Code
C-d0
Description
Action
Control buttons are pressed
over 10 seconds.
Clean the keys and check if there is water
on the surface around key. If it occurs
again, turn off the microwave oven over
30 seconds and try setting again. If it
appears again, call your local SAMSUNG
Customer Care Centre.
NOTE
If the above guidelines do not enable you to solve the problem, then contact your local
SAMSUNG customer service centre.
Troubleshooting
52 English
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 52
2015-08-13
11:45:24
Technical specifications
SAMSUNG strives to improve its products at all times. Both the design specifications and
these user instructions are thus subject to change without notice.
Model
MS23J5133A*
Power source
220 V ~ 50 Hz
Power consumption
Microwave
1150 W
Output power
100 W / 800 W (IEC-705)
Operating frequency
2450 MHz
Dimensions (W x H x D)
Outside (include handle)
489 x 275 x 338 mm
Oven cavity
330 x 211 x 324 mm
Volume
23 liter
Weight
Net
12 kg approx.
Technical specification
English 53
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 53
2015-08-13
11:45:24
Memo
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 54
2015-08-13
11:45:24
Memo
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 55
2015-08-13
11:45:24
Please be advised that the Samsung warranty does NOT cover service calls to explain product
operation, correct improper installation, or perform normal cleaning or maintenance.
QUESTIONS OR COMMENTS?
COUNTRY
CALL
OR VISIT US ONLINE AT
www.samsung.com/mx/support
MEXICO
01-800-SAMSUNG(726-7864)
ARGENTINE
0800-555-SAMS(7267)
URUGUAY
0800-SAMS(7267)
PARAGUAY
0800-11-SAMS(7267)
BRAZIL
0800-124-421
(Demais cidades e regiões)
4004-0000
(Capitais e grandes centros)
www.samsung.com/br/support
CHILE
800-SAMSUNG(726-7864)
www.samsung.com/cl/support
BOLIVIA
800-10-7260
www.samsung.com/cl/support
COLOMBIA
Bogotá en el 600 12 72
Sin costo en todo el pais 01 8000 112
112
Y desde tu celular #726
www.samsung.com/co
COSTA RICA
00-800-1-SAMSUNG (726-7864)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
DOMINICAN REPUBLIC
1-800-751-2676
ECUADOR
1-800-SAMSUNG (72-6786)
EL SALVADOR
8000-SAMSUNG (726-7864)
GUATEMALA
1-800-299-0033
HONDURAS
800-2791-9111
JAMAICA
1-800-SAMSUNG (726-7864)
www.samsung.com/latin_en/support (English)
NICARAGUA
001-800-5077267
www.samsung.com.ar
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
PANAMA
800-0101
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
PERU
0-800-777-08
www.samsung.com/pe/support
PUERTO RICO
1-800-682-3180
TRINIDAD & TOBAGO
1-800-SAMSUNG(726-7864)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
VENEZUELA
0-800-SAMSUNG (726-7864)
www.samsung.com/ve/support
DE68-04328H-00
MS23J5133AM_ZS_DE68-04328H-00_EN.indd 56
2015-08-13
11:45:24
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
