Canon VB-S910F, VB-S900F Mark II, VB-S905F Mark II Installation guide

Canon VB-S910F, VB-S900F Mark II, VB-S905F Mark II Installation guide
BIE-7203-000
ENGLISH
Network Camera
/
4
4
5
5
/
Installation Guide
6
Please be sure to read the “Safety Precautions” section for
correct use. After reading this Installation Guide, keep it in a
readily accessible location for future reference. This camera
is for indoor use only.
* Some cameras are not available in certain countries or regions.
not expose this product to rain or moisture.
Caution Request a professional installer for all installation
work. Never try to install the camera yourself.
Doing so may result in unforeseen accidents
such as dropping the camera or electric shock.
Check Included Items
Camera
Installation Guide (This document)
Warranty Card
1
a
9
WARNING T o reduce a risk of fire or electric shock, do
If Using a Memory Card
Installing the Camera
9
b
6
7
10
8
8
Weight: Approx. 180 g (6.4 oz.)
(camera only)
4.Memory card slot cover
5.100Base-TX LAN connector
6.External device I/O terminal
7.Audio output terminal
8.Reset switch (please refer to the “Operation Guide”)
9.LED
10. Audio input terminal
a. Mounting pole
b. Mounting screw hole
Example installations
Using a ceiling
mounting pole
Using a wall mounting pole
External Dimensions
e. Memory Card Slot
Symbols Indicating Camera Model
© CANON INC. 2017
: VB-S900F Mk II/VB-S905F Mk II
16.0 (0.63)
: VB-S910F
e
Printed in Taiwan
Part Names
69.9 (2.75)
32 (1.26)
*1
Insert a memory card before installing the camera.
11.4 (0.45)
Only for European Union and EEA (Norway,
Iceland and Liechtenstein)
13.6 (0.54)
54 (2.13)
1
*1 tripod screw holes
3
d
Unit: mm (in.)
67 (2.64)
LED
: When powered on, during reboot,
during normal use
Please refer to the
reverse side of this
guide for details.
: When [Turn Off] is selected
(please refer to the “Operation Guide”)
MAC_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
114 (4.49)
11.4 (0.45)
d. LED
3
Set the camera angle
Please manually adjust the camera angle while checking the
video on a computer (please refer to the “Operation Guide”).
54 (2.13)
32 (1.26)
13.6 (0.54)
c. LAN cable
1.Mounting Screw Hole (a 1/4-20 UNC mounting screw less than
5.5 mm (0.22 in.) in length will fit the screw hole)
2.Microphones
3.Lens
Unit : mm (in.)
The contents of this guide are subject to change without any prior
notice.
Important
c
117 (4.61)
Serial_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
2
To remove the memory card, push it in all the way until the card
slightly pops out and remove.
2
These symbols indicate that this
product is not to be disposed of with
your household waste, according to the
WEEE Directive (2012/19/EU), the Battery
Directive (2006/66/EC) and/or national
legislation implementing those Directives.
If a chemical symbol is printed beneath the symbol shown
above, in accordance with the Battery Directive, this indicates
that a heavy metal (Hg = Mercury, Cd = Cadmium, Pb = Lead)
is present in this battery or accumulator at a concentration
above an applicable threshold specified in the Battery Directive.
This product should be handed over to a designated
collection point, e.g., on an authorized one-for-one basis
when you buy a new similar product or to an authorized
collection site for recycling waste electrical and electronic
equipment (EEE) and batteries and accumulators. Improper
handling of this type of waste could have a possible impact
on the environment and human health due to potentially
hazardous substances that are generally associated with EEE.
Your cooperation in the correct disposal of this product will
contribute to the effective usage of natural resources.
For more information about the recycling of this product,
please contact your local city office, waste authority, approved
scheme or your household waste disposal service or visit
www.canon-europe.com/weee, or www.canon-europe.com/
battery.
Please refer to the “Specifications” for specifications not listed below.
Camera
Lens
3.5x optical zoom (4x digital zoom) lens
with auto focus
Fixed focal length lens (4x digital zoom)
For 16:9 aspect ratios
Viewing Angle
Horizontal: 78.6° (W) – 20.8° (T)
Vertical: 40.9° (W) – 11.6° (T)
For 4:3 aspect ratios
Horizontal: 55.9° (W) – 15.5° (T)
Vertical: 40.9° (W) – 11.6° (T)
For 16:9 aspect ratios Horizontal: 96.0°
Vertical: 60.5°
For 4:3 aspect ratios Horizontal: 77.0°
Vertical: 60.5°
Interface
Network Terminal*LAN x 1 (RJ45, 100Base-TX (auto/fullduplex/half-duplex))
* Use a category 5 or better LAN cable,
100 m (328 ft.) or less in length.
Audio Input Internal microphone
Audio Input Terminal
3.5 mm ( 0.14 in.) mini-jack connector
(common for LINE IN & MIC IN) (monaural)
3.5 mm ( 0.14 in.) mini-jack connector
Audio Output Terminal (LINE OUT) (monaural)
External Device I/O Terminal Input x 1, Output x 1
Memory Card microSD Memory Card, microSDHC
Memory Card, microSDXC Memory Card
Compatible.
Others
Operating Environment Temperature: -10°C – +50°C (+14°F –
+122°F)
Humidity: 5% – 85% (without condensation)
Storage Environment Temperature: -30°C – +60°C (-22°F –
+140°F)
Humidity: 5% – 90% (without condensation)
Installation With use of mounting pole (third party
product)
Power Supply PoE : PoE power supply via LAN connector
(IEEE802.3at Type1 compliant)
Power Consumption
Max. 4.8 W
Max. 4.3 W
– Class 2 power sourcing equipment
(requests 7.0 W)
Weight Approx. 180 g (6.4 oz.) (camera only)
Connecting the Camera
Safety Precautions
Important
When connecting sensors and switches, use those that have terminals
which are isolated from internal power and GND.
 External Device Output Terminals (OUT)
The external device output terminal consists of an OUT terminal and
a GND terminal. Controls from the viewer can be used to open and
close the circuit between the terminals. A MOSFET device is used
for the output terminal.
Rating range for load connected to output terminals.
Rating between output terminals:
Maximum voltage 50 V DC
Continuous load current at or below 100 mA
On resistance: Below 1 Ω
Adaptive wiring for external device cables
Rating Range: (same for contact input and output)
Solid wire/Stranded wire AWG: No. 26 – 20
Stripped cable length should be approximately 11 mm (0.43 in.)
•The External Device I/O Terminal consists of three terminals (IN, OUT,
and GND). The GND terminal serves as both the external device input
GND and the external device output GND.
•The GND terminal is connected to the camera interior GND.
•When using the external device input and output at the same time,
couple the GND wire from the input cable with the GND wire from the
output cable, conforming to the rating range, and connect it to the
GND terminal.
•Do not push the external device I/O terminal button with too much
force. Doing so may cause the button to remain pushed-in.
Internal Connection Diagram
1 kΩ
10 kΩ
10 kΩ
IN
0.1 µF
Input terminal
GND
OUT
Output terminal
GND
Power Supply
Please refer to the “Specifications” > “Other” > “Power Supply”.
Note
•Power supply should conform to all local codes.
•The power supply should also comply with IEC/UL60950-1 (SELV/
LPS) standards.
Important
•Check with your dealer for more information about PoE devices.
•Some PoE devices allow power limits for each port, but applying
limits may interfere with performance. If using this type of PoE
device, do not limit the operating power.
•Some PoE devices have total consumption power limits for ports,
which can interfere with performance when multiple ports are in use.
For more information, check the instruction guide for your PoE device.
Audio Input Terminals Common LINE IN/MIC IN
Camera has single audio input system supporting two types of
microphone input: LINE IN and MIC IN. Before use, change [Audio
Input Mode] on the Setting Page (please refer to the “Operation
Guide”). LINE IN is selected by default.
•Dynamic MIC IN
Input impedence: 20 kΩ – 40 kΩ
•Condenser MIC IN
Input impedence (microphone bias resistance): 2.2 kΩ ±20%
Microphone power supply: plug-in power (voltage: 2.3 V)
*Supported microphones: Condenser microphones with plug-in
power support
•LINE IN
Input level: up to 1 Vp-p
*Use a microphone with an amplifier
External Device I/O Terminals
Audio Output Terminal LINE OUT (monaural output)
 External Device Input Terminals (IN)
Connect the camera to a speaker with an amplifier. Audio can be
sent to the speaker from the Viewer.
Output terminal: 3.5 mm ( 0.14 in.) mini jack (monaural)
Output level: Max. 1 Vp-p
The external device input terminal consists of an IN terminal and
a GND terminal. Connecting cables to the IN and GND terminals
and opening or closing the circuit notifies the Viewer.
Installation Precautions
Warning Failure to follow the instructions may result
in death or serious injury.
Do not install in the following places:
•Places in direct sunlight, near heat-generating objects, or
locations subject to high temperatures
•Places near fire sources or flammable solvents (alcohol,
thinner, fuel, etc.)
•Humid or dusty places
•Places subject to oily smoke or steam
•Places subject to sea air
•Confined or enclosed places
Failure to do so may result in fire or electric shock.
Precautions for the LAN (power) cable:
•Do not set any heavy objects on the LAN cable.
•Do not pull, forcibly bend, scratch, or modify the LAN cable.
Failure to do so may result in fire or electric shock.
Note
Internal controller
Specifications
Caution
Failure to follow the instructions may result in
injury.
For installation or inspection of this camera, consult the
dealer where you purchased the product.
•This installation should be made by a qualified service
person and should conform to all local codes.
•When installing, make sure the surface is capable of
withstanding the total weight of the camera and mounting
pole, and sufficiently reinforce if necessary.
•Be sure to use installation screws designed for the type of
surface the camera is to be installed.
•Periodically check the parts and screws for rust and
loosening, in order to prevent injuries and equipment
damage due to falling items.
•Do not install in unstable places, places subject to
significant vibration or impact, or places subject to salt
damage or corrosive gas.
Failure to do so may result in the camera falling or other
accidents.
Important
We recommend the installation of a lightning arrester (a surge
protection device) as a measure against failures caused by lightning
strikes. Please refer to our website for details.
Precautions for Use
Warning Failure to follow the instructions may
result in death or serious injury.
•If you discover defective conditions such as smoke,
strange sounds, heat or strange odors, immediately stop
using the camera and contact your nearest dealer.
Fire or electric shock may result from continued use of the
product.
•If thunder starts, stop installation or inspection etc. and do
not touch the camera or continue connecting the cable.
•Do not disassemble or modify the camera.
•Do not damage the connecting cable.
•Do not spray the camera with water, or otherwise make it
wet.
•Do not insert foreign objects such as water or metal into
the camera.
•Do not use flammable sprays near the camera.
•Do not leave LAN cables connected when the camera is
not in use for long periods.
•Do not use flammable solvents such as alcohol, paint
thinner or benzine when cleaning the camera.
Failure to do so may result in fire or electric shock.
•This camera should not be used with medical devices or
other life-support systems.
•Depending on the computer and network environment,
high-precision video transmission cannot be guaranteed
due to video lag or loss.
Canon will assume no liability for any accident or damage
resulting from use of the camera under the conditions
above.
•Be careful not to get your fingers caught when installing.
Failure to do so may result in injuries.
Caution
Failure to follow the instructions may result in
property damage.
•Do not install on an unstable surface.
•After turning off the power, do not turn the power on again
for at least five seconds.
•Take measures to remove static electricity before
performing any procedures.
•If there is condensation, please wait to power on, until the
condensation dissipates.
•The network camera is only intended for a connection to
an Ethernet or PoE network without routing to the outside
plant.
Failure to do so may result in malfunctions.
•Take care not to damage wiring or piping.
Failure to do so may result in damage to peripheral items.
CANON INC.
30-2, Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan
CANON EUROPA N.V.
Bovenkerkerweg 59, 1185 XB Amstelveen, The Netherlands
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
