Quick Start Guide
Confirming the Package Contents
First Steps
Shooting and Playback
Using ViewNX 2
Other Functions
For Your Safety
3
6
14
21
27
36
En
En_01
Thank you for purchasing the Nikon COOLPIX P7800 digital camera. This guide introduces the
procedures necessary for first time use of this camera.
To ensure proper use, please read and thoroughly understand the information provided in “For Your
Safety” (A36) before using the camera.
For more detailed information, please refer to the digital Reference Manual, which is located on the
included CD-ROM. For information on viewing the camera's digital Reference Manual, see “Viewing the
Reference Manual CD“ described below.
Should you need technical support, we offer a number of options.
Internet
Please visit the Nikon support home page, where you can:
• Search Nikon's continuously updated Knowledge Database for the latest technical support
information.
• Use “Ask Nikon a Question” to receive a prompt reply from a Nikon professional advisor to your
e-mail.
• Download the latest versions of Nikon software or firmware updates for your product, or register to
receive e-mail notification for software or firmware updates.
For customers in the United States: www.nikontechusa.com
For customers in Canada: help.nikon.ca (English), nikoncanada-fr.custhelp.com (Français)
For customers in Mexico: nikon.com.mx/soporte
For customers in Brazil: http://nikon.com.br
Telephone
Please call for technical support and other product assistance. Our professional advisers are standing by
to help with your digital camera needs.
For customers in the United States: 1-800-NIKON-UX (1-800-645-6689)
For customers in Canada: 1-877-534-9910
For customers in Mexico: 001-888-565-5452
For customers in Brazil: 0800-886-4566 (0800-88 NIKON)
C
Viewing the "Reference Manual CD"
The Reference Manual can be viewed using Adobe Reader, available for free download from the Adobe
website.
1 Start the computer and insert the "Reference Manual CD".
2 Double-click the CD (COOLPIX P7800) icon in Computer or My Computer (Windows) or on the
desktop (Mac OS).
3 Double-click the INDEX.pdf icon to display the language selection screen.
Click a language and follow the links to view the Reference Manual.
An Important Notice about Accessories
Nikon COOLPIX digital camera is designed to the highest standards and includes complex
electronic circuitry. Only Nikon accessories, such as battery chargers, batteries and AC adapters
are certified by Nikon specifically for your Nikon COOLPIX camera and are engineered and
tested to operate within the requirements of the electronic circuitry of our cameras.
THE USE OF NON-NIKON ACCESSORIES MAY DAMAGE YOUR CAMERA AND WILL VOID YOUR
NIKON WARRANTY.
Genuine Nikon accessories are available through your Nikon-authorized dealer.
2
En_01
Confirming the Package Contents
In the event that any items are missing, please contact the store
where you purchased the camera.
COOLPIX P7800
Digital Camera
(with Accessory Shoe Cover
BS-1)
Camera Strap
Lens Cap LC-CP26
(attached to the camera
body)
Rechargeable Li-ion Battery
EN-EL14
(with terminal cover)
Battery Charger MH-24*
USB Cable UC-E16
ViewNX 2 CD
Reference Manual CD
(Reference Manual CD)
• Quick Start Guide (this guide)
• Warranty
* A plug adapter is included if the camera was purchased in a country or region that
requires a plug adapter. The shape of the plug adapter varies with the country or region
of purchase (A6).
The included Battery Charger is MH-24 in countries other than Brazil, and MH-24C in
Brazil.
NOTE: A Secure Digital (SD) memory card, hereafter referred to as a “memory
card”, is not provided.
A: This icon indicates that more information is available elsewhere in this guide.
Confirming the Package Contents
En_01
3
Parts of the Camera
1 2 3
7
4
5
8 9 10 11
1 Exposure compensation dial
2 Exposure compensation dial
mark
3 Shutter-release button
4 Mode dial
5 Accessory shoe
6 Flash
7 w2 (function 2) button
8 Sub-command dial
9 Zoom control
f : wide-angle
g : telephoto
h : thumbnail playback
i : playback zoom
j : help
10 w1 (function 1) button
4
12
6
21 22 23 24 25
11
12
13
14
15
16
17
18
19
20
21
22
AF-assist illuminator
K (flash pop-up) control
Electronic viewfinder
Diopter adjustment control
x (monitor) button
n (quick menu) button
Power switch/power-on lamp
Main command dial
g (AE-L/AF-L) button
c (playback) button
Monitor
Rotary multi selector (multi
selector)
23 k (apply selection) button
24 d (menu) button
25 l (delete) button
Confirming the Package Contents
En_01
15 17 19
13 14 16 18 20
Opening and Adjusting the Angle of the
Monitor
The orientation and tilt of the monitor can be changed. This is useful
when shooting with the camera in a high or a low position, or when
taking self-portraits.
For normal shooting, fold the monitor against the camera body with
the screen facing out (3).
When you are not using or carrying the
camera, fold the monitor against the camera
body with the screen facing inward to prevent
scratches or contamination.
B Notes About the Monitor
• When moving the monitor, do not apply excessive force and turn slowly
within the monitor’s adjustable range so that the connection will not be
damaged.
• When the monitor is turned with a cable connected to the external
microphone connector or accessory terminal, the monitor may catch on
the cable or cover. Do not apply excessive force to the cable or to the
connector of the camera.
Confirming the Package Contents
En_01
5
First Steps
Step 1
1.1
Charge the Battery
Prepare the included battery charger.
If a plug adapter* is included with your camera, attach
the plug adapter to the plug on the battery charger.
Push the plug adapter firmly until it is securely held in
place. Once the two are connected, attempting to
forcibly remove the plug adapter could damage the
product.
* The shape of the plug adapter varies according to
the country or region in which the camera was
purchased.
This step can be omitted if the plug adapter comes
permanently bonded to the battery charger.
1.2
While pushing in the battery (1), set it into the battery charger
(2).
1
6
First Steps
En_01
2
1.3
Plug the battery charger into an
electrical outlet.
• CHARGE lamp starts flashing when
charging starts.
• CHARGE lamp turns on when charging is
complete.
About 1 hour and 30 minutes are
required to charge a fully exhausted
battery.
1.4
CHARGE
lamp
When charging is complete, remove the battery and then
disconnect the battery charger from the electrical outlet.
Step 2
Attaching the Camera Strap
Attach the strap at two places.
Step 3
3.1
Insert the Battery and the Memory Card
Open the battery-chamber/memory
card slot cover.
First Steps
En_01
7
3.2
Insert the battery.
• Push the orange battery latch in the
direction indicated by the arrow (1), and
fully insert the battery (2).
• The battery locks into place when
inserted correctly.
Battery latch
Be Careful to Insert the Battery in Correct
Direction
Inserting the battery upside down or
backwards could damage the camera.
3.3
Insert the memory card.
• Slide the memory card in
until it clicks into place.
Memory
card slot
Be Careful to Insert the Memory Card in Correct
Direction
Inserting the memory card upside down or backwards
could damage the camera and the memory card.
8
First Steps
En_01
3.4
Close the battery-chamber/memory
card slot cover.
• While the battery-chamber/memory
card slot cover is open, the camera
cannot be turned on.
• Images are saved in the internal memory (approx. 86 MB) when no
memory card is inserted in the camera.
Removing the Battery and the Memory Card
Turn the camera off and make sure that the power-on lamp and the
monitor have turned off, and then open the battery-chamber/
memory card slot cover.
B High Temperature Caution
The camera, battery, and memory card may be hot immediately after using
the camera.
Removing the Battery
• Move the battery latch in the direction
indicated by the arrow (1) to eject the battery
(2).
Removing the Memory Card
• Gently push the memory card into the
camera (1) to partially eject the card (2).
First Steps
En_01
9
Step 4
4.1
Turn the Camera On
Open the monitor and remove
the lens cap.
• See “Opening and Adjusting the
Angle of the Monitor” (A5) for
more information.
4.2
Press the power switch.
• The monitor turns on.
• To turn the camera off, press the
power switch again.
B Lens Cap
At times when you are not shooting images, attach the lens cap to the lens
to protect it.
C The Auto Off Function
• If no operations are performed for a while, the monitor will turn off, the
camera will enter standby mode, and the power-on lamp will flash. If no
operations are performed for another 3 minutes, the camera will turn off
automatically.
• While the camera is in standby mode, the monitor turns back on if you
perform any of the following operations:
- Press the power switch, shutter-release button, or c button.
- Rotate the mode dial.
- Open or close the monitor.
10
First Steps
En_01
Step 5
Setting the Display Language, Date,
and Time
When the camera is turned on for the first
time, the language-selection screen and the
date and time setting screen for the camera
clock are displayed. Use the rotary multi
selector to select the settings.
• If you exit without setting the date and
time, O will flash when the shooting screen is displayed.
Rotary Multi Selector
Select the item above *
Select the item on the left/
Return display to the
previous screen
Select the item below *
Select the item on the
right/Display sub-menu
(apply selection)
Apply selection
* Items above or below can also be selected by rotating the rotary multi
selector.
5.1
Use the multi selector
HI to select the desired
language and press the
k button.
Language
Български
Čeština
Dansk
Deutsch
English
Español
Cancel
First Steps
11
En_01
5.2
Select Yes and press the k button.
Time zone and date
Choose time zone and
set date and time?
Yes
No
Cancel
5.3
Select your home time
zone and press the k
button.
New York
Toronto
Lima
• To enable daylight saving
time, press H. When the
Back
daylight saving time
function is enabled, W is
displayed above the map. To turn off the daylight saving time
function, press I.
5.4
12
Select the date format and press the
k button.
First Steps
En_01
Date format
Year/Month/Day
Month/Day/Year
Day/Month/Year
5.5
Set the date and time, and press the
k button.
Date and time
M
D
Y
11
15
2013
• Select a field: Press JK (changes
between M, D, Y, hour, and minute).
10
15
• Edit the date and time: Press HI. Date
Edit
and time can also be changed by
rotating the multi selector or main
command dial.
• Confirm the setting: Select the minute field and press the k button.
5.6
Select Yes and press the k button.
• When settings are finished, the lens
extends and the camera switches to
shooting mode.
Date and time
11/15/2013 15:10
OK?
Yes
No
C Imprinting the Date on Images While Taking Images
After setting the date and time, press the d button to display the
z (setup) menu and set Print date setting (A33).
• Use the rotary multi selector to select and set menu options.
• Press the d button to exit the menu.
C Changing the Current Date, Time, or Language
Press the d button to display the z (setup) menu and set Language or
Time zone and date (A33).
The next step explains basic shooting operations using A (auto) mode.
First Steps
13
En_01
Shooting and Playback
Step 1
Rotate the Mode Dial and Align the A
(auto) Icon to the Mark
Step 2
Check the Battery Level and the Number
of Exposures Remaining
Battery level indicator
1/250
F5.6
1280
Number of exposures remaining*
* When data is recorded to the internal memory, C is displayed.
Battery level indicator
Display
Description
b
The battery level is high.
B
The battery level is low.
N
Battery exhausted.
The camera cannot capture images.
Recharge the battery.
C Monitor Display
Press the w2 button to switch between showing and hiding the photo
information or shooting information that is displayed in the monitor.
14
Shooting and Playback
En_01
Built-in Flash
In situations where a flash is needed, such
as in dark locations or when the subject is
backlit, lower the K (flash pop-up)
control to raise the flash.
• When not using the flash, gently push
to lower the flash until it clicks shut.
Switching Between the Monitor
and Viewfinder (x Button)
You can use the viewfinder when
bright light under the open sky makes it
difficult to see the monitor.
Each press of the x button switches
the display between the monitor and
viewfinder.
• When you fold the monitor against
the camera body with the screen
facing inward, the display in the
monitor is switched to the
viewfinder.
Viewfinder
x (monitor) button
Diopter Adjustment of the
Viewfinder
When the image in the viewfinder is
difficult to see, adjust by rotating the
diopter adjustment control while
looking through the viewfinder.
• Take care not to scratch your eye
with your fingertips or nails.
Diopter adjustment control
Shooting and Playback
15
En_01
Step 3
3.1
Frame a Picture
Hold the camera steady.
• Keep fingers and other objects away from the lens, flash, AF-assist
illuminator, microphone, and speaker.
• When taking pictures in portrait (“tall”) orientation, turn the camera
so that the flash is above the lens.
3.2
Frame the picture.
1/250
F5.6
1280
Using the Zoom
• To zoom in closer to the subject: Move
toward g (telephoto)
• To zoom out and view a larger area: Move
toward f (wide-angle)
16
Shooting and Playback
En_01
Zoom out
Zoom in
Step 4
4.1
Focus and shoot
Press the shutter-release
button halfway.
• When the subject is in focus,
the focus area that includes the
subject or focus indicator
glows green (multiple focus
areas can glow green).
• When you are using digital
zoom, the camera focuses on
the subject in the center of the
frame and the focus area is not
displayed. When the camera
has focused, the focus indicator
glows green.
1/250 F5.6
• If the focus area or focus
indicator flashes red, the camera is unable to focus. Modify the
composition and try pressing the shutter-release button halfway
again.
4.2
Without lifting your finger, press the shutter-release button the
rest of the way down.
Flash Status Display
When you press the shutter-release button
halfway, you can check the flash status by the
flash mode icon at the top of the monitor.
• On: The flash fires in accordance with the flash
mode when you press the shutter-release
button all the way down. When U (auto) is
set, the flash fires when W is displayed.
• Flashing: The flash is charging. The camera cannot shoot images.
• Off: The flash does not fire when an image is taken.
Shooting and Playback
17
En_01
C
Focusing
To set focus and exposure (shutter speed and aperture value), press the
shutter-release button halfway.
The focus area varies depending on the shooting mode.
In A (auto) mode, the camera automatically selects one or more of the 9
focus areas containing the subject closest to the camera when the shutterrelease button is pressed halfway.
B High Temperature Caution
If you are taking images repeatedly with the flash within a short period of
time, the flash unit and its surrounding area can become hot. Before
lowering the flash, make sure to allow the flash unit and its surrounding area
to cool down.
18
Shooting and Playback
En_01
Step 5
5.1
Play Back Images
Press the c (playback)
button.
• If you press and hold
down the c (playback)
button while the camera
is turned off, the camera
turns on in playback
mode.
5.2
11/15/2013 15:30
c (playback)
button
4 132
Multi selector
Use the multi selector to select an
image to display.
Display the previous image
• Press and hold down HIJK to scroll
through the images quickly.
• Images can also be selected by rotating
the multi selector or command dial.
• To return to shooting mode, press the
c button or shutter-release button.
Display the next image
C Switching the Information in the Monitor
Press the w2 button to switch between showing and hiding the photo
information or shooting information that is displayed in the monitor.
Shooting and Playback
19
En_01
Step 6
6.1
Delete an Image
Press the l button to delete
the image currently
displayed in the monitor.
11/15/2013 15:30
4 132
6.2
Use the multi selector HI to select
Yes and press the k button.
• The deleted image cannot be recovered.
• To cancel, select No and press the k
button.
Erase 1 image?
Yes
No
C Deleting Multiple Images
To delete multiple images, select Delete from the playback menu (A32).
Step 7
Turn Off the Camera
Press the power switch to turn the camera off.
• When the flash is raised, gently
press the flash down to lower it.
20
Shooting and Playback
En_01
Using ViewNX 2
ViewNX 2 is an all-in-one software package which enables you to
transfer, view, edit and share images. Install ViewNX 2 using the
included ViewNX 2 CD-ROM.
Your Imaging Toolbox
Step 1
ViewNX 2™
Installing ViewNX 2
Compatible Operating Systems
Windows
Windows 8, Windows 7, Windows Vista, Windows XP
Macintosh
Mac OS X 10.6, 10.7, 10.8
Refer to the Nikon website for details on system requirements,
including the latest information on operating system compatibility.
Using ViewNX 2
21
En_01
1.1
Start the computer and insert the ViewNX 2 CD-ROM into the
CD-ROM drive.
• Windows: If instructions for operating the CD-ROM are displayed in
the window, follow the instructions to proceed to the installation
window.
• Mac OS: When the ViewNX 2 window is displayed, double-click the
Welcome icon.
1.2
Select a language in the language selection dialog to open the
installation window.
• If the desired language is not available, click Region Selection to
choose a different region and then choose the desired language (the
Region Selection button is not available in the European release).
• Click Next to display the installation window.
22
Using ViewNX 2
En_01
1.3
Start the installer.
• We recommend clicking Installation Guide in the installation
window to check the installation help information and system
requirements before installing ViewNX 2.
• Click Typical Installation (Recommended) in the installation
window.
• Follow the on-screen instructions to install the software.
1.4
Exit the installer when the installation completion screen is
displayed.
• Windows: Click Yes.
• Mac OS: Click OK.
The following software is installed:
• ViewNX 2 (consisting of the three modules below)
– Nikon Transfer 2: For transferring images to the computer
– ViewNX 2: For viewing, editing, and printing transferred images
– Nikon Movie Editor: For basic editing of transferred movies
• Panorama Maker (for creating a single panorama photo using a
series of images shot in panorama assist scene mode)
1.5
Remove the ViewNX 2 CD-ROM from the CD-ROM drive.
Using ViewNX 2
23
En_01
Step 2
2.1
Transferring Images to the Computer
Choose how images will be copied to the computer.
Choose one of the following methods:
• Direct USB connection: Turn the camera off and ensure that the
memory card is inserted in the camera. Connect the camera to the
computer using the included USB cable. The camera automatically
turns on.
To transfer images that are saved in the camera’s internal memory,
remove the memory card from the camera before connecting it to
the computer.
• SD card slot: If your computer is equipped with an SD card slot, the
card can be inserted directly in the slot.
• SD card reader: Connect a card reader (available separately from
third-party suppliers) to the computer and insert the memory card.
24
Using ViewNX 2
En_01
If a message is displayed prompting you to choose a program, select
Nikon Transfer 2.
• When using Windows 7
If the dialog shown at right
is displayed, follow the
steps below to select Nikon
Transfer 2.
1 Under Import pictures
and videos, click
Change program. A program selection dialog will be displayed;
select Import File using Nikon Transfer 2 and click OK.
2 Double-click Import File.
If the memory card contains a large number of images, it may take a
while for Nikon Transfer 2 to start. Wait until Nikon Transfer 2 starts.
P7800
P7800
P7800
B Connecting the USB Cable
The connection may not be recognized if the camera is connected to the
computer via a USB hub.
Using ViewNX 2
25
En_01
2.2
Transfer images to the computer.
• Confirm that the name of the connected camera or removable disk
is displayed as the “Source” on the “Options” title bar of Nikon
Transfer 2 (1).
• Click Start Transfer (2).
1
P7800
2
• At default settings, all the images on the memory card will be copied
to the computer.
• Images are displayed in ViewNX 2 when transfer is complete.
2.3
Terminate the connection.
• If the camera is connected to the computer, turn the camera off and
disconnect the USB cable.
• If you are using a card reader or card slot, choose the appropriate
option in the computer operating system to eject the removable
disk corresponding to the memory card and then remove the card
from the card reader or card slot.
C Starting ViewNX 2 Manually
• Windows: Double-click the ViewNX 2 shortcut on the desktop.
• Mac OS: Click the ViewNX 2 icon in the Dock.
• Consult online help for more information on using ViewNX 2.
26
Using ViewNX 2
En_01
Other Functions
Functions That Can Be Set Using the Multi
Selector
Press the multi selector H (m), J (n), I (D), or K (G) while
shooting to operate the following functions.
1
2
4
3
Function
1 m Flash mode
Description
The flash modes available are U (auto),
V (auto with redeye reduction), X (fill flash),
S (manual), Y (slow sync), Z (rearcurtain
sync) and z (commander mode) modes.
• z (commander mode) can be used when
A, B, C, D, E, F or N mode is selected.
Self-timer
The camera is equipped with 10s, 2s, 1s timers.
Smile timer
The camera detects smiling faces using face
priority and releases the shutter automatically.
Remote control
The camera shutter can be released using the
Remote Control ML-L3 (available separately
from Nikon).
2 n
Other Functions
27
En_01
Function
Description
3 p Focus mode
Choose from A (autofocus), C (close range
only), D (macro close-up), B (infinity), and
E (manual focus).
• E can be selected when the shooting mode
is A, B, C, D, E, F, N, special effects
mode or the Sports scene mode.
4 G AF area mode
In shooting modes A, B, C, D, E, F, N
and u (special effects), you can change
how the camera selects the focus area for
autofocus.
Selecting a Shooting Mode
When the mode dial is rotated next to the mark, the camera switches
to the corresponding shooting mode shown below.
A Auto mode
Used for general shooting.
y Scene mode
Camera settings are optimized according to the scene that you
select.
When using scene auto selector, the camera automatically selects
the optimum scene mode when you frame an image, making it
even easier to take images using settings that suit the scene.
28
Other Functions
En_01
u Special effects
Effects can be applied to images during shooting.
A, B, C, D mode
Select these modes for greater control over shutter speed and
aperture value.
E, F, N User settings mode
Setting combinations that are frequently used for shooting can be
saved. The saved settings can be immediately retrieved for shooting
simply by rotating the mode dial to E, F or N.
e Movie mode
You can record slow motion and fast motion movies, in addition to
basic movies.
h Movie custom setting mode
You can use aperture-priority auto or manual mode, or change the
settings for image recording.
Other Functions
29
En_01
Basic Quick Menu Operations
1
Press the n button.
Image quality
Image size
1342
Normal
2
Use the multi selector HI to move
to the tabs at the top of the screen.
• You can also move to the tabs by
rotating the sub-command dial.
Tabs
Image quality
Image size
1342
Normal
3
Use J K to select the tab for the
function to be set.
• You can also select a tab by rotating the
main command dial.
1 a Image quality/Image size
* Movie options will be shown when the
mode dial is rotated to e or h.
2 b ISO sensitivity
3 c White balance
4 d Auto bracketing
5 I My Menu
6 a Picture Control
1
2 3 4 5 6
ISO sensitivity
Minimum shutter speed
Auto
The functions that can be set vary depending on the shooting mode.
30
Other Functions
En_01
4
Use HI to select an item and
change the setting using J K.
• You can also change the setting by
rotating the main command dial.
ISO sensitivity
Minimum shutter speed
Auto
5
Press the k button or n button when setting is complete.
• You can also press the shutter-release button to finish setting.
Other Functions
31
En_01
Using Menus (the d Button)
Use the multi selector and k button to navigate the menus.
1
Press the d button.
• The menu that matches the status of the camera, such as shooting
or playback menu, is displayed.
Unavailable menu items are displayed in gray and cannot be
selected.
Shooting menu
1/250
2
F5.6
1280
Custom Picture Control
Metering
Continuous
AF area mode
Autofocus mode
Flash exp. comp.
Noise reduction filter
Use the multi selector to select a
menu item.
• HI or rotation: Select an item
above or below.
Apply selection
• J K: Select an item on the left or
right, or move between menu levels.
• k: Apply a selection. Pressing K also applies a selection.
3
After completing the settings, press the d button or shutterrelease button.
• Press the shutter-release button to display the shooting screen.
32
Other Functions
En_01
Switching Among Menu Tabs
To display a different menu, such as the setup menu, use the multi
selector to switch to another tab.
Tabs
Shooting menu
Shooting menu
Custom Picture Control
Metering
Continuous
AF area mode
Autofocus mode
Flash exp. comp.
Noise reduction filter
Custom Picture Control
Metering
Continuous
AF area mode
Autofocus mode
Flash exp. comp.
Noise reduction filter
Use J to move to the
tabs.
Set up
Welcome screen
Time zone and date
Monitor settings
Print date
Self-timer: after release
Vibration reduction
AF assist
Use HI to select a tab,
and press the k button or
K to apply the selection.
Tab Types
For shooting
Shooting
Custo
Meter
Contin
AF are
Autof
Flash
Noise
User setti
Save u
Reset
Shoot
Focal le
Virtua
Initial
For playback
Set up
Playback
Welco
Time z
Monit
Print d
Self-ti
Vibrat
AF ass
Qu
D-L
Ski
Filt
Pri
Slid
De
A tab:
Displays the settings available for the current
c tab:
shooting mode. Depending on the current shooting
Displays the
mode, the tab icon that is displayed will be different.
settings
In A (auto) mode, only z tab is displayed.
available for the
E/F/N tab:
playback mode.
Displays the settings for the specialized menu in E,
F or N mode.
z tab:
Displays the setup menu, where you can change general settings.
Other Functions
33
En_01
Playback Mode
The following options can be performed in full-frame playback
mode.
Control
Name
Main Functions
Zoom control
• Move toward g (i) to zoom in on the
image, and move toward f (h) to
display images as thumbnails or the
calendar.
• Adjust the volume for voice memo
and movie playback.
Multi selector
• While the playback screen is displayed:
Change the displayed image using up
(H), left (J), down (I), right (K), or
by rotating the multi selector.
• While the setting screen is displayed:
Select an item using HIJ K or by
rotating the multi selector.
• While an enlarged image is displayed:
Move the display area.
• Display individual images of a
sequence in full-frame playback mode.
• Scroll an image shot with Easy
panorama.
k (apply
• Play back movies.
selection) button • Switch from thumbnail playback or
zoomed image display to full-frame
playback.
• While the setting screen is displayed,
apply the selection.
34
Other Functions
En_01
Control
Name
Main command
dial
Sub-command
dial
Main Functions
• Select images and date.
• Switch the magnification of an
enlarged image.
d (menu)
button
Display and hide the menu.
l (delete)
button
Delete an image.
w2 (function 2)
button
Switch the information displayed in the
monitor screen.
x (monitor)
button
Switch between the monitor and
viewfinder.
Other Functions
35
En_01
For Your Safety
To prevent damage to your Nikon product or injury to yourself or to
others, read the following safety precautions in their entirety before
using this equipment. Keep these safety instructions where all those who
use the product will read them.
The consequences that could result from failure to observe the
precautions listed in this section are indicated by the following symbol:
This icon marks warnings, information that should be read before using
this Nikon product, to prevent possible injury.
WARNINGS
Turn off in the event of malfunction
Should you notice smoke or an unusual smell coming from the camera
or battery charger, unplug the battery charger and remove the battery
immediately, taking care to avoid burns. Continued operation could
result in injury. After removing or disconnecting the power source, take
the equipment to a Nikon-authorized service representative for
inspection.
Do not disassemble
Touching the internal parts of the camera or battery charger could result
in injury. Repairs should be performed only by qualified technicians.
Should the camera or battery charger break open as the result of a fall or
other accident, take the product to a Nikon-authorized service
representative for inspection, after unplugging the product and/or
removing the battery.
Do not use the camera or battery charger in the presence of
flammable gas
Do not use electronic equipment in the presence of flammable gas, as
this could result in explosion or fire.
36
For Your Safety
En_01
Handle the camera strap with care
Never place the strap around the neck of an infant or child.
Keep out of reach of children
Particular care should be taken to prevent infants from putting the
battery or other small parts into their mouths.
Do not remain in contact with the camera, battery charger, or
AC adapter for extended periods while the devices are on or in
use
Parts of the devices become hot. Leaving the devices in direct contact
with the skin for extended periods may result in low-temperature burns.
Do not leave the product where it will be exposed to extremely
high temperatures, such as in an enclosed automobile or in
direct sunlight
Failure to observe this precaution could cause damage or fire.
Observe caution when handling the battery
The battery may leak, overheat, or explode if improperly handled.
Observe the following precautions when handling the battery for use in
this product:
• Before replacing the battery, turn the product off. If you are using the
battery charger/AC adapter, be sure it is unplugged.
• Use only a Rechargeable Li-ion Battery EN-EL14 (included). Charge the
battery by using a Battery Charger MH-24 (included). For Remote
Control ML-L3 (available separately), use only 3 V CR2025 lithium
battery.
• When inserting the battery, do not attempt to insert it upside down or
backwards.
• Do not short or disassemble the battery or attempt to remove or break
the battery insulation or casing.
• Do not expose the battery to flame or to excessive heat.
• Do not immerse in or expose to water.
For Your Safety
37
En_01
• Replace the terminal cover when transporting the battery. Do not
transport or store with metal objects such as necklaces or hairpins.
• The battery is prone to leakage when fully discharged. To avoid
damage to the product, be sure to remove the battery when no charge
remains.
• Discontinue use immediately should you notice any change in the
battery, such as discoloration or deformation.
• If liquid from the damaged battery comes in contact with clothing or
skin, rinse immediately with plenty of water.
Observe the following precautions when handling the battery
charger
Keep dry. Failure to observe this precaution could result in fire or
electric shock.
Dust on or near the metal parts of the plug should be removed with a
dry cloth. Continued use could result in fire.
Do not handle the plug or go near the battery charger during lightning
storms. Failure to observe this precaution could result in electric shock.
Do not damage, modify, forcibly tug or bend the USB cable, place it
under heavy objects, or expose it to heat or flames. Should the
insulation be damaged and the wires become exposed, take it to a
Nikon-authorized service representative for inspection. Failure to
observe these precautions could result in fire or electric shock.
Do not handle the plug or battery charger with wet hands. Failure to
observe this precaution could result in electric shock.
Do not use with travel converters or adapters designed to convert from
one voltage to another or with DC-to-AC inverters. Failure to observe
this precaution could damage the product or cause overheating or fire.
•
•
•
•
•
•
Use appropriate cables
When connecting cables to the input and output jacks, use only the
cables provided or sold by Nikon for the purpose, to maintain
compliance with product regulations.
38
For Your Safety
En_01
Handle moving parts with care
Be careful that your fingers or other objects are not pinched by the lens
cover or other moving parts.
CD-ROMs
The CD-ROMs included with this device should not be played back on
audio CD equipment. Playing CD-ROMs on an audio CD player could
cause hearing loss or damage the equipment.
Using the flash close to your subject’s eyes could cause
temporary visual impairment
The flash should be no less than 1 m (3 ft 4 in.) from the subject. Particular
care should be observed when photographing infants.
Do not operate the flash with the flash window touching a
person or object
Failure to observe this precaution could result in burns or fire.
Avoid contact with liquid crystal
Should the monitor break, care should be taken to avoid injury caused by
broken glass and to prevent liquid crystal from the monitor touching the
skin or entering the eyes or mouth.
Turn the power off when using inside an airplane or the
hospital
Turn the power off while inside the aircraft during take off or landing.
Do not use wireless network functions while in the air.
Follow the instructions of the hospital when using while in a hospital.
The electromagnetic waves emitted by this camera may disrupt the
electronic systems of the aircraft or the instruments of the hospital.
If you are using wireless network devices, remove them from the camera
before boarding an aircraft or entering a hospital.
For Your Safety
39
En_01
Notices
Notices for Customers in the U.S.A.
IMPORTANT SAFETY INSTRUCTIONS -SAVE THESE INSTRUCTIONS.
DANGER - TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
CAREFULLY FOLLOW THESE INSTRUCTIONS
For connection to a supply not in the U.S.A., use an attachment plug
adapter of the proper configuration for the power outlet if needed.
The power supply unit is intended to be correctly orientated in a vertical
or floor mount position.
Federal Communications Commission (FCC) Radio Frequency
Interference Statement
This equipment has been
tested and found to comply
with the limits for a Class B
digital device, pursuant to Part
15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
40
Notices
En_01
• Consult the dealer or an experienced radio/television technician for
help.
CAUTIONS
Modifications
The FCC requires the user to be notified that any changes or
modifications made to this device that are not expressly approved by
Nikon Corporation may void the user’s authority to operate the
equipment.
Interface Cables
Use the interface cables sold or provided by Nikon for your equipment.
Using other interface cables may exceed the limits of Class B Part 15 of
the FCC rules.
Notice for Customers in the State of California
WARNING
Handling the cord on this product will expose you to lead, a chemical
known to the State of California to cause birth defects or other
reproductive harm.
Wash hands after handling.
Nikon Inc.,
1300 Walt Whitman Road,
Melville, New York 11747-3064
USA
Tel: 631-547-4200
Notice for Customers in Canada
CAN ICES-3 B / NMB-3 B
Notices
41
En_01
Caring for the Camera
To ensure continued enjoyment of this Nikon product, observe the
precautions described below in addition to the warnings in “For Your
Safety” (A36-39) when using or storing the device.
B
Do Not Drop
The product may malfunction if subjected to strong shock or vibration.
B
Handle the Lens and All Moving Parts with Care
Do not apply force to the lens, lens cover, monitor, memory card slot, or
battery chamber. These parts are easily damaged. Applying force to the
lens cover could result in camera malfunction or damage to the lens.
Should the monitor break, care should be taken to avoid injury caused by
broken glass and to prevent the liquid crystal from the display touching
the skin or entering the eyes or mouth.
B
Keep Dry
The device will be damaged if immersed in water or subjected to high
humidity.
B
Avoid Sudden Changes in Temperature
Sudden changes in temperature, such as when entering or leaving a
heated building on a cold day, can cause condensation to form inside the
device. To prevent condensation, place the device in a carrying case or a
plastic bag before exposing it to sudden changes in temperature.
B
Keep away from Strong Magnetic Fields
Do not use or store this device in the vicinity of equipment that generates
strong electromagnetic radiation or magnetic fields. Strong static charge
or the magnetic fields produced by equipment such as radio transmitters
could interfere with the monitor, damage data saved on the memory
card, or affect the product’s internal circuitry.
42
Notices
En_01
B
Do Not Point the Lens at Strong Light Sources for Extended
Periods
Avoid pointing the lens at the sun or other strong light sources for
extended periods when using or storing the camera. Intense light may
cause deterioration of the image sensor, producing a white blur effect in
photographs.
B
Turn the Product off Before Removing or Disconnecting the
Power Source or the Memory Card
Do not remove the battery while the product is on, or while images are
being saved or deleted. Forcibly cutting power in these circumstances
could result in loss of data or in damage to product memory or internal
circuitry.
B
Notes About the Monitor
• Monitors and electronic viewfinders are constructed with extremely
high precision; at least 99.99% of pixels are effective, with no more than
0.01% being missing or defective. Hence while these displays may
contain pixels that are always lit (white, red, blue, or green) or always off
(black), this is not a malfunction and has no effect on images recorded
with the device.
• Images in the monitor may be difficult to see under bright lighting.
• The monitor is lit by an LED backlight. Should the monitor begin to dim
or flicker, contact your Nikon-authorized service representative.
Notices
43
En_01
FX3H01(11)
6MN30011-01
En_01
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
