Operating Instructions
en
10
9
1
8
7
4
3
5
2
6
1
2
3
Picture 1
2
TT 22E UK
en
10
1
9
8
7
4
3
5
2
6
1
2
3
Picture 2
TT 44E UK
3
en
SAFETY INSTRUCTIONS
IMPORTANT TO BE READ AND OBSERVED
• Before using the appliance carefully read Health and Safety and Use and Care
guides.
• Keep these instructions close at hand for future reference.
• YOUR SAFETY AND SAFETY OF OTHERS IS VERY IMPORTANT
• This manual and the appliance itself provide important safety warnings, to be
read and observed at all times
• All safety warnings give specific details of the potential risk presented and indicate
how to reduce risk of injury, damage and electric shock resulting from improper
use of the appliance. Carefully observe the following instructions.
• Failure to observe these instructions may lead to risks. The Manufacturer
declines any liability for injury to persons or animals or damage to property if
this advice and relevant precautions are not respected.
• This product should not be used by children under 8 years old, unless
supervised by an adult.
• Children from 8 years old and above and persons with reduced
physical, sensory or mental capabilities or lack of experience
and knowledge can use this appliance only if they are
supervised. Alternatively these people can use if have been
given instructions on safe appliance use and if they understand
the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by childern
without supervision.
• Keep the appliance and its cord out of reach of children less
than 8 years.
INTENDED USE OF THE PRODUCT
• This appliance is designed solely for domestic use. This product is not
intended for commercial use. The manufacturer declines all responsibility
for innapropiate use or incorrect setting of the controls. 4
en
• CAUTION : The appliance is not intended to be operated
by means of an external timer or separate remote control
system. • Do not use the appliance outdoors.
• Do not store explosive or flammable substances such as aerosol cans and do
not place or use gasoline or other flammable materials in or near the appliance:
a fire may break out if the appliance is inadvertently switched on. INSTALLATION
• Repairs must be carried out by a qualified technician, in compliance with
the manufacturer’s instructions and local safety regulations. Do not repair or
replace any part of the appliance unless specifically stated in the user manual.
• Children should not perform installation operations. Keep children away during
installation of the appliance. Keep the packaging materials (plastic bags,
polystyrene parts, etc.) out of reach of children, during and after the installation
of the appliance.
• After unpacking the appliance, make sure that it has not been damaged during
transport. In the event of problems, contact the dealer or your nearest Aftersales Service. • Keep children away during installation of the appliance.
• The appliance must be disconnected from the power supply before carrying out
any installation operation.
• During installation, make sure the appliance does not damage the power
cable.
• Only activate the appliance when the installation procedure has been
completed.
ELECTRICAL WARNINGS
• Make sure the voltage specified on the rating plate corresponds to that of your
home.
• Regulations require that the appliance is connected to an earthed supply outlet.
• For appliances with fitted plug, if the plug is not suitable for you socket outlet,
contact a qualified technician. 5
en
• Do not use extension leads, multiple sockets or adapters. Do not connect the
appliance to a socket which can be operated by remote control.
• The power cable must be long enough for connecting the appliance, once fitted
in its housing, to the main power supply. • Do not pull the power supply cable. • If the power cable is damaged it must be replaced with an identical one. The
power cable must only be replaced by a qualified technician in compliance
with the manufacturer instructions and current safety regulations. Contact an
authorized service center. • Do not operate this appliance if it has a damaged mains cord or plug, if it is not
working properly, or if it has been damaged or dropped. Do not immerse the
mains cord or plug in water. Keep the cord away from hot surfaces. • Do not touch the appliance with any wet part of the body and do not operate it
when barefoot.
ELECTRICAL CONNECTIONS
Fuse replacement
If the mains lead of this appliance is fitted with a BS 1363A 13amp fused plug, to
change a fuse in this type of plug use an A .S .T .A . approved fuse to BS 1362 type
and proceed as follows:
B
1.Remove the fuse cover (A) and fuse (B)
2.Fit replacement 13A fuse into fuse cover
A 3.Refit both into plug
Important:
The fuse cover must be refitted when changing a
fuse and if the fuse cover is lost, the plug must not
be used until a correct replacement is fitted. Correct
replacements are identified by the colour insert or the
colour embossed in words on the base of the plug.
Replacement fuse covers are available from your local
electrical store.
Socket outlet / plug
If the fitted plug is not suitable for your socket outlet, contact After-Sales Service for
further instruction. Do not attempt to change the plug yourself. This procedure needs
to be carried out by a qualified technician in compliance with the manufacturer’s
instructions and current standard safety regulations.
6
en
CORRECT USE
• Never cover the toaster slot.
• Do not touch parts other than the operating controls, as the
toaster will can become hot during toasting.
• Do not introduce any object inside the toaster, as this may cause damage or
risks.
• Pull down the operating lever only for toasting: never block it.
• Make sure the crumb tray is perfectly in place before using.
• Never place aluminium foil on the warming rack. Never warm and toast at the
same time.
• Avoid toasting food with extremely runny ingredients such as butter.
• As bread may burn, do not use toaster near or below curtains
and other flamable materials.
• If the toaster starts to smoke, press the CANCEL button to stop toasting
immediately.
• Do not attempt to remove the food when the toaster is in operation.
• Remove the bread carefully after toasting to avoid any injuries.
• Warning: When toasting small bread slices less than 8.5 mm high, be careful of
the potential risk of burning when taking out the slice.
• Be careful not to damage the internal mechanism or heating elements when
removing the bread.
CLEANING AND MAINTENANCE
• The appliance must be disconnected from the power supply before carrying out
any cleaning or maintenance.
• Never use steam cleaning equipment.
• Allow the unit to cool down completely before cleaning or storing it.
7
en
PARTS AND FEATURES
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Operating lever
Cancel button
Bagel/Sandwich button
Defrost button
Reheat button
Toasting level buttons
Display
Cord wrap
Removable crumb tray
Warming rack
If you toast only one slice, set the toasting
level lower than for two slices. If you toast
the food continuously, the toasting colour of the
different slices can be slightly different or darker,
even if the same level is used.
4.
The operating lever can rest on the bottom
of the slot only if the plug was connected.
INTRODUCTION
5.
Thank you for purchasing our product.
In doing so, you have opted for an effective highperformance appliance.
6.
If the instructions on the correct use of this appliance
are not observed, the manufacturer shall assume no
responsibility for any resulting damage.
The operating instructions may refer to different
models: any difference is clearly identified.
7.
BEFORE FIRST USE
Carefully wipe the outside of the appliance to remove
any dust that may have accumulated. Dry with a dry
cloth. Remove any stickers. As there is manufacturing
residue or oil remained in the toaster or heat element,
it usually will emit an odor for the first use. It is normal
and will not occur after several times use. Before the
first use, with the window open operate without any
bread inside. Then let the toaster cool down and begin
toasting.
USING THE TOASTER
1.
2.
3.
8
Put the food to be toasted into the bread slot.
No more than one slice for each slot can be
introduced at any one time.
Make sure the crumb tray is perfectly in
place before using.
Plug the power cord into the outlet.
Set the toasting level to the desired colour using
the toasting level buttons. The lowest level is 1
and the highest level is 8. The bar at the bottom
of the display will show the set level.
Pull down the operating lever until it engages:
toasting will begin at once. The display will show
the countdown till the end of toasting. Once the
bread has been toasted to the preset level, the
operating lever will automatically spring up.
During the toasting process, if the browning is
satisfactory, press the CANCEL button to stop
toasting.
If the bread was taken out of the freezer, set
the toasting level according to your preference.
Press the DEFROST button to toast it to your
desired color, then pull down the operation lever
until it is in place. The related symbol will appear
on the display.
If you want to reheat any cold toasted bread,
press the REHEAT button. Toasting time is fixed
in this mode: when time is over the operating
lever will automatically spring up and stop the
reheating process. The related symbol will
appear on the display.
Press the BAGEL/SANDWICH function to
switch among bagel function - sandwich
function - no special function activated. Related
symbols will appear on the display.
8.
The Bagel function makes it possible to toast
bread, bagels, muffins etc on one side only
(external side), while the other side (internal
side) remains warm. Bagels and muffins should
be sliced in half before toasting.
9. The sandwich function allows the user to toast
sandwiches or different kinds of bread slowly.
By such function, your sandwich will be well
browned on the outside and cooked inside.
This function can also be used in combination
with the warming rack, for better warming
results of any kind of bread or bakery products.
During working condition, the functions like
Defrost, Sandwich/Bagel and Reheat can not
be switched to each other unless you press down the
CANCEL button to make the carriage handle spring
up automatically and make the appliance goes back
to the standby mode.
en
The function is not available on levels 1 and
2; in these cases, when the reheat button is
hold down, the display will quickly flash 3 times
and Reheat function will be turned off.
4.
Toast any items only until they are golden
brown and not brown or too dark.
Remove any burnt edges. Do not over-toast food
containing starch - especially grain and potato
products - to reduce the production of acryl
amides.
If a slice gets stuck at the end of the toasting
process, pull the power plug and carefully remove
the bread after the toaster has cooled down.
DISPOSAL OF PACKAGING MATERIALS
The use of browning levels from 4 to 6 is
recommended for the preparation of
sandwiches.
Depending on the quantity or quality of
stuffing, it can happen that the inside of the
sandwich is not warm enough or completely melt:
in case, please leave the sandwich into the slot for
about one minute after ending the toasting.
Using the warming rack
The food that cannot be placed inside the slots (e.g.
rolls, baguettes, croissants) can be warmed on the
warming rack
1.
2.
3.
Place the support on the slot (see pic. 1 and 2)
Use the button to set the desired toasting level.
Pull down the operating lever until it engages.
time!
Never place aluminium foil on the warming
rack. Never warm and toast at the same
Only set browning levels 1 and 2 when
using the warming rack with the four-slots
toaster.
CLEANING AND MAINTENANCE
1.
2.
3.
Wipe the outside with a soft dry cloth after the
toaster has cooled down. Never use metal polish.
Pull out the crumb tray from the bottom of
the toaster and empty it. If the toaster is used
frequently, accumulated bread crumbs should be
removed at least once a week. Make sure the
crumb tray is completely closed before using the
toaster again.
When the toaster is not used or is stored, the power
cord may be wound under the bottom of the toaster.
If you use specific products for cleaning steel, be
careful with the chrome parts, to avoid staining.
SAFEGUARDING THE ENVIRONMENT
The packaging material is 100%
recyclable and is marked with the recycle
symbol (*). The various parts of the
packaging must therefore be disposed of
responsibility and in full compliance with
local authority regulations governing waste disposal. SCRAPPING OF HOUSEHOLD APPLIANCES
When scrapping the appliance, make it unusable by
cutting off the power cable and removing the doors
and shelves (if present) so that children cannot easily
climb inside and become trapped. This appliance is manufactured with
recyclable (*) or reusable materials.
Dispose of it in accordance with local
waste disposal regulations.
For further information on the treatment,
recovery and recycling of household electrical
appliances, contact your competent local authority,
the collection service for household waste or the store
where you purchase the appliance. This appliance is marked in compliance with European
Directive 2012/19/EU, Waste Electrical and Electronic
Equipment (WEEE).
By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences
for the environment and human health, which could
otherwise be caused by inappropriate waste handling
of this product.
The symbol (*) on the product or on the
accompanying documentation indicates that
it should not be treated as domestic waste
but must be taken to an appropriate
collection centre for the recycling of electrical
and electronic equipment.
DECLARATION OF CONFORMITY
This appliance has been designed, constructed and
distributed in compliance with the safety requirements
of European Directives:
•
2006/95/EC Low Voltage Directive
9
en
•
2004/108/EC
Directive
Electromagnetic
Compatibility
Guarantee
12 months Standard Guarantee
Enhanced to 2 years upon product registration
This certificate of guarantee represents the guarantee
(“Guarantee” hereinafter) offered by Indesit Company
UK Limited with registered office at Peterborough PE2
9JB in relation to products purchased in the United
Kingdom and Indesit Ireland Limited with registered
office in Dublin 9, Ireland for products purchased in
the Republic of Ireland. This Guarantee does not
affect your statutory rights.
Your product has the benefit of our manufacturer’s
Guarantee, which covers the product for twelve
months from the date of purchase.
This gives you the reassurance that if, within that
time, your product is proven to be defective because
of either workmanship or materials, we will, at our
discretion, either repair or replace the product at no
cost to you.
This Guarantee is subject to the following conditions:
•
•
•
•
•
•
•
•
•
10
Documentary proof of original purchase date is
provided.
Cosmetic damage must be reported within 14
days from the date of purchase.
The product has been installed and operated
correctly and in accordance with our operating
and maintenance instructions.
The product is used only on the electricity supply
printed on the rating plate.
The product has been used for normal domestic
purposes only.
The product has not been altered, serviced,
maintained, dismantled, or otherwise interfered
with by any person not authorised by us.
Any repair work must be undertaken by us or our
appointed agent.
Any parts removed during repair work or any
product that is replaced become our property.
The product is used in the United Kingdom or
Republic of Ireland.
The Guarantee does not cover:
•
•
•
•
•
Damage resulting from transportation, improper
use, neglect or interference or as a result of
improper installation.
Accidental damage, this includes but is not
limited to, damage which occurs as a result of an
external action.
Replacement of any consumable item or
accessory. These include but are not limited to:
plugs, cables, light bulbs, hoses, brushes,
covers and filters.
Replacement of any removable parts made of
glass or plastic.
After Sales Service
No one is better placed to care for your Hotpoint
product during the course of its working life than us –
the manufacturer.
Essential Contact Information
Advice Line
We have a dedicated team who can provide free
advice and assistance with your product if you
experience any technical difficulties. Simply call our
Hotpoint Service Hotline for telephone assistance.
UK: 08448 240055
Republic of Ireland 0818 904 041
www.hotpointservice.co.uk
Please note:
Our advisors will require the following
information:
Model number:
Serial number:
en
Consumables and Accessories
We supply a full range of consumables and accessories
to keep your product functioning efficiently throughout
its life.
UK: 08448 225225
Republic of Ireland: 0818 313 413
parts.hotpoint.co.uk/shop
Recycling and Disposal Information
As part of Hotpoint’s continued commitment to helping
the environment, Hotpoint reserves the right to use
quality, recycled components to keep down customer
costs and minimise material wastage.
Please dispose of packaging and old products
carefully.
Register your new product and receive 1 additional
year FREE!
As an additional benefit of owning your Hotpoint
product, we are offering 1 years additional free
guarantee. To be eligible for this you will need to
contact us to register your product within 28 days
of purchase. If you do not register your appliance
within the 28 days you will still be entitled to 1 years
manufacturer’s guarantee. To activate your 2 year
guarantee register online at www.hotpoint.co.uk.
Please note that the extended guarantee is only
available in the UK and Ireland and is subject to the
same terms and conditions as the 1 year guarantee.
Please refer to the certificate of guarantee for more
information.
11
www.indesitcompany.com
TT 22E UK - TT 44E UK
07/2015 - ver.1.0
Indesit Company UK Ltd
Morley Way,
Peterborough PE2 9JB
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
