Instruction manual
R EFR ES HMENT C ENT ER
Built-in appliance
welcome to the world of Electrolux electrolux 3
Welcome to the world of Electrolux
Thank you for choosing a first class product from Electrolux, which hopefully
will provide you with lots of pleasure in the future.
The Electrolux ambition is to offer a wide variety of quality products that
make your life more comfortable.
You find some examples on the cover in this manual.
Please take a few minutes to study this manual so that you can take
advantage of the benefits of your new machine.
We promise that it will provide a superior User Experience delivering Ease-ofMind.
Good luck!
4 electrolux contents
Contents
Built-in appliance.............................
Electrical safety...............................
Appliance description ........................
Identification plate...........................
Technical Characteristics....................
Installation.....................................
1
5
7
8
8
9
Package content ...................................9
1 Unit positioning................................ 10
2 Frontal spacer installation................... 11
3 Water mains and siphon connection ....... 12
4 Install filter cartridge ........................ 13
5 CO2 bottle connection ....................... 13
6 Startup .......................................... 14
Using the Refreshment Center................... 15
Front touch panel .................................. 15
Dispensing ........................................... 15
Alarms ......................................... 16
Maintenance .................................. 19
Sanification + filtration cartridge ............... 19
Environment care ............................ 22
Electric diagram ............................. 23
Hydraulic diagram ........................... 24
Errata corrige ................................ 25
Guarantee/Customer Service .............. 33
The following symbols are utilized with this manual:
Safety information
Environment
Disposal directives
electrical safety electrolux 5
Electrical safety
This appliance conforms to the following safety electrical European
Directives:
This manual has been written for your own safety and of others.
Please read manual carefully before installation and/or use. Please
keep this instruction manual in a safe and dry place. This appliance
conforms to the following safety electrical European Directives:
2006/95/CE, 2004/108/CE, 98/37/CEE.
Please keep this instruction manual in a safe and dry place.
This manual has been written
for you own safety and of
others. Please read manual
carefully before installation
and/or use.
Electrical safety
The unit needs to be
connected to a power supply
line that conforms fully to
local safety regulations
regarding electrical safety. If
in doubt please have your
electrical system checked by
a specialized electrician.
Please do not try to repair
the unit as you might cause
additional damage. Contact
your nearest Technical
assistance center.
Remove power supply cord
before proceeding with repair
operations.
If the power supply cord
appears to be damaged,
please ask for a replacement
cord.
6 electrolux appliance description
Installation
Please handle appliance with
care to prevent damaging of
the refrigeration circuit.
Avoid prolonged exposure of
the appliance to direct
sunlight.
Please follow instruction
carefully before, during and
after installation.
If the appliance is
transported in vertical
position, please place in
horizontal (normal) position
and wait 1 hour for the oil to
return to the compressor
before turning unit on.
Do not bend water supply and
discharge tube excessively
during installation.
Use
Do not use the Refreshment
Center for something else
other than dispense cold,
carbonated, ambient water
and ice. An incorrect use of
the appliance may harm
people or cause damage to
the appliance itself.
Do not allow children to use
the appliance if not under
the supervision of adults.
Cleaning
Do not use metallic tools to
clean the appliance as it may
cause damage.
Environment
Please follow local disposal
regulations.
appliance description electrolux 7
Appliance description
The Refreshment Center is a
domestic appliance designed to
dispense purified cold, carbonated
and ambient temperature water and
ice-cubes.
The appliance has 2 nozzles from
which the following products can be
Units
The unit is mainly composed of:
1 St. Steel front display
2 Filter head
3 Water dispense nozzle
4 Glass touch command panel
5 Ice dispense outlet
6
Drip tray
7 CO2 bottle
8 H2O pressure regulator with
gauge
9 Filter cartridge
10 Power supply socket
11 Main on/off switch
12 H2O inlet
13 H2O drainage
dispensed:
- Ambient temperature water
- Cold water
- Carbonated water
- Ice-Cubes.
1
7
2 3
4
5
6
8 9
10
11
12 13
8 electrolux identification plate
Identification plate
Should you need to contact a
technical Assistance Center,
make sure you have the serial
number handy for
identification. The serial
number is on the
identification plate in the side
of the appliance. Extract from
cabinet to identify plate.
MODEL
XXXXXXXX
PNC
xxx xxx xxx
230 V ~ 50 Hz
TYPE
Refreshment Center
SERIAL No.:
MAX 190 W
xxxxxxxx
MADE IN ITALY
Fig. 2
Technical Characteristics
Power Supply
230-240 V
Frequency
50 Hz
Power consumption
190 W
Cold water dispense capacity
2lt @ 1 l/min.
Carbonated water dispense capacity
2lt @ 1 l/min
Dispense temperature
< 13°C
Water mains pressure (water inlet)
> 2.0 bar
CO2 pressure
2.5-4 bar
Filtration
0.5 micron
Filter capacity
2840 litres
Ambient temperature conditions range
18°C-32°C
Unit dimensions L x P x H (mm)
Weight
Refrigerant gas
594x554xH378
38 Kg
R134a – 60gr
installation electrolux 9
Power supply cord
Installation
Warning
In order for the unit to work
correctly, the Technical
Characteristics specification
chart on page 6 needs to be
observed.
Installation steps:
1. Refreshment Center assembly
inside kitchen
2. Frontal spacer installation
3. Water mains connection
4. Water filter connection
5. CO2 bottle connection
6. Electric power supply
H2O inlet flexible hose and
discharge tube
2x
Filtration Cartridge
Package content
Open package and immediately check
for any transport damages. During
installation please handle with care.
Inside you should find the following
material:
A. Refreshment Center
B. 2 Sliding Rails
C. Mounting base plate
D. 6 spacers 2x1mm, 2x2mm,
2x3mm
E. Eight 3,5x16mm and three M4x8
screws
Sanitazing cartridge and liquid
A
B
C
D
E
8x
3x
10 electrolux installation
1 Unit positioning
Please install unit as far away
as possible from heat sources
50
0
54
50
Please install unit higher than
the water main in the kitchen
3
Please don’t install the
Refreshment Center farther
than 4m from the water main
or please use another water
inlet and discharge tubes.
Installing the machine into kitchen
furniture with proper characteristics
will ensure a correct operation of the
equipment.
Complying with the safety rules,
ensure a proper protection against
any contact with the electric
components and with the parts
protected only by functional
insulation, by housing the machine
correctly into the furniture.
All components that guarantee
protection, even a cover panel (for
instance, when the machine is
positioned at one of the ends of the
modular furniture), should be firmly
fixed so that they cannot be removed
without tools.
Install this machine at a certain
distance from refrigerators or
freezers, because the heat it emits
can impair their functioning.
- The dimension requirements for
the kitchen cabinet are:
1. Height(1):380mm
2. Depth(2):560mm
3. Width(3):560mm
2
-
1
Install the mounting base plate
inside the kitchen cabinet after
checking after checking
dimension requirements as shown
in Fig. 3. If necessary, please use
the spacers to fix the mounting
base plate to the cabinet (Fig.
4).
Fig. 3
Fig. 4
installation electrolux 11
Please be sure that the
frontal edge of the mounting
base plate and the frontal
edge of the piece of
furniture are coincident
-
Mount the 2 sliding rails onto the
base plate already placed in the
cabinet, using the eight
3,5x16mm self-threading screws
supplied.
Fig. 5
-
Place the Refreshment Center on
the sliding rails. Slide the
machine into the cabinet until
the “click” indicates that it is
locked into position.
Fig. 6
2 Frontal spacer installation
When installing the Refreshment
Center near to other appliances, the
height of the other appliances (for
example an oven) could be 10mm
higher. To align the Refreshment
Center frontal panel to the others,
please fix the frontal spacer part to
the frontal panel using the nr.3 M4x8
screws as in figure below:
12 electrolux installation
3 Water mains and siphon connection
Warning
Connect only to potable
water mains.
All water mains connections
should be carried out by a
certified plummer.
Warning
Water mains pressure can be
set through the H2O pressure
regulator placed near the
CO2 bottle. Please set it
after dispensing of at least
500cc of carbonated water.
Pressure should be lower
than 3.0 bars and higher than
2.0 bars.
Complete following operations (Fig.
8):
- Connect the flexible hose to the
H2O inlet (Fig.7) on the unit.
Connect water mains to flexible
hose.
- Connect discharge tube to
discharge barbed connection on
unit and to sink siphon (Fig.7).
Warning
Please do not install
Refreshment Center farther
than 4 meters or please get
longer inlet and discharge
tubes.
2x
Water Inlet 3/4”
Water discharge 3/4”
Fig. 7
installation electrolux 13
4 Install filter cartridge
Lift locking spring placed under drip
tray (Fig. 8).
Fig. 8
Pull unit from cabinet (Fig. 9). On the
left side of the unit please find the
filter cartridge (Fig. 1a).
Fig. 9
Remove filter plastic cap and install
filter in filter head as shown on filter
instruction booklet (Fig. 11).
Fig. 10
Check for water leaks.
5 CO2 bottle connection
Make sure the CO2 bottle is tightly
fixed on the CO2 pressure regulator.
Fig. 11
Open the pressure regulator valve and
set pressure to 3 bars on gauge (Fig.
12). Pressure can be increased to 4
bars to increase carbonation levels.
Fig. 12
14 electrolux installation
6 Startup
Warning
Before plugging unit to
power supply, please check
for correct power supply
voltage and frequency as
stated on Technical
Characteristics chart (see
page 8).
Fig. 13
Connect unit to 230V through
supplied cord (Fig. 13).
Electric supply circuit should conform
to local laws and regulations.
Warning
The supplier declines any
responsibility should any
safety rule not be respected
during installation.
Turn unit on through main on/off
switch on side of unit (Fig. 14). The
unit will undergo an initialization
process which will take approx. 4
minutes.
on/off switch inside the cabinet.
During this process the touch control
panel is inactive.
After 4 minutes it’s possible to turn
unit on through on/off button on
touch control panel to activate all
functions.
At this point please wait approx.
2 hours before the unit reaches final
working temperatures in order to
dispense cold water, carbonated
water and ice-cubes. Ambient water
is ready immediately.
Fig. 14
This preliminary operation will be
carried out every time the unit is
turned off and on through the main
installation electrolux 15
Using the Refreshment Center
Front touch panel
1
2
3
4
5
6
7
1 Empty CO2 bottle led
5 Cold water button
2 On/Off switch
6 Ice dispense button
3 Water ambient temperature
button
7 Light button On/Off
4 Carbonated water button
Dispensing
After turning appliance on through
on/off switch on touch screen, wait
for cooling time before dispensing.
Place a glass under dispense nozzle.
Press button corresponding to desired
selection. Release until desired
dispense water level or number of icecubes is reached. If you experience
CO2 exhaust from nozzle, please wait
20 secons and restart dispensing
carbonated water.
8 Exhaust filter led
8
16 electrolux alarms
Dispensing is signaled by the
corresponding led.
In order to dispense in bottles or
carafes, please extract dispense
nozzle by grabbing on sides of nozzle
and pulling forward.
Alarms
Led indications
Led blinks slowly
Message
Filter is about to exhaust. 2800 liters have
been dispensed.
Please change filter as described in the
following chapters.
Led is lit
Filter is about to exhaust. 2900 liters have
been dispensed. Please change filter as
described in the following chapters.
Led is lit
All dispense buttons disabled.
3000 liters have been reached.
Please change filter as described in the
following chapters.
alarms electrolux 17
Carbonated
water led blinks
slowly
Carbonated water is disabled.
Protection on carbonation pump activated.
To reset status please turn unit off/on on
touch control panel after waiting for a while.
CO2 bottle led on
Carbonated water is disabled.
CO2 bottle is empty.
Replace CO2 bottle to restore carbonated
water dispensing.
Please change CO2 bottle as described in the
following chapters.
Leds
- ambient water
- ice
blink
simultaneously
Ice forming bin block alarm.
Restart unit through main on/off switch on side of unit
(Fig. 1b).
Leds
- ambient water
- cold water
- carbonated
water
Volumetric turbine alarm. Two possible causes:
blink
1. No water supply to unit
simultaneously
2. There’s water supplied to unit (dispensing
enabled) but volumetric turbine malfunction.
For the first case verify the presence of water supplied to
unit.
For the second case restart unit through on/off switch on
touch panel.
Leds
- carbonated
water
- ambient water
- cold water
Main water tank fill alarm. Please check water supply to
- ice
unit. To reset status restart unit through main switch inside
blink
cabinet (Fig 1b).
simultaneously
18 electrolux maintenance
All leds on
simultaneously
All dispense buttons disabled. 2 main causes:
1. Water present on base of unit. Possible leak.
2. Water level too high inside water tank. Water discharge
blocked.
For the first case switch off and dry the base of the unit.
For the second case restart unit through main switch inside
cabinet.
Should alarms repeat
themselves after all restart
attempts, please call service
assistance.
maintenance electrolux 19
Maintenance
Before any maintenance or
cleaning procedure, please
switch off the appliance and
disconnect it from main by
unplugging the power plug.
CO2 bottle replacement
When the CO2 led turns on, it’s
necessary to replace the CO2 bottle
as described below:
1. Lift locking spring placed under drip
tray (Fig. 8).
2. Pull appliance from cabinet
(Fig. 15).
3. Grab the CO2 bottle (Fig. 1a) and
extract it from it’s locking clip.
4. By holding the bottle fixed, turn
the pressure regulator clockwise to
remove from the bottle (Fig. 16).
Fig. 15
Fig. 16
5. Place new bottle under the
regulator and screw counter
clockwise till fully tightened (Fig.
17).
6. Lock bottle in place and pull the
unit into the cabinet.
Fig. 17
Sanification + filtration cartridge
When the exhaust filter led turns on, it is time to replace the filter cartridge:
20 electrolux maintenance
7. Lift locking spring placed under drip
tray (Fig. 8). Pull appliance from
cabinet (Fig. 15).
8. Turn unit off through main on/off
switch (Fig. 1b).
9. Remove the filter cartridge form its
housing by rotating anti clock-wise
about a quarter turn (Fig. 18). This will
free the filter. Pull downward and
remove it paying attention to avoid water
leaks.
10. Fill sanitizing cartridge with Neutral
Detergent. Insert the sanitizing
cartridge on the filter head by rotating
clock-wise a quarter turn (Fig. 19).
11. Dry any water from the base, that
could have leaked during this
operation.
12. Position under the water dispense
nozzle a container or large cup.
13. Turn on the appliance through the main
switch (Fig. 1b) while pressing the
“light” button for 3 seconds. This starts
the sanitizing mode. This will be shown
in the display as a moving red led
through all the buttons. During this
operation, the inside of the unit will be
sanitized. After this initial cleaning
cycle, the unit will dispense
automatically some cold and ambient
water mixed with sanitizing product.
Fig. 18
Fig. 19
maintenance electrolux 21
14. Shut off unit from main on/off switch
(Fig 1b).
15. Remove the sanitizing cartridge and
install the new filter cartridge as shown
on filter cartridge instructions (Fig. 20).
Turn main switch on (Fig. 1b) and push
appliance into cabinet(Fig. 21).
16. Wait 4 minutes before turning unit on
through the touch panel button.
17. Dispense 1 liter of cold, ambient and
carbonated water to fully rinse any
sanitizing residue.
Fig. 20
Fig. 21
Warning
During the sanitizing
procedure please don’t
dispense carbonated water.
SYMPTOM
Water is not dispensed
The unit has been on for
over 3 hours, but no cold
water nor ice is available
The following is a troubleshooting
section for malfunctions that are not
in the Alarms list above:
PROBABLE CAUSE
No water supply
Water main inlet
solenoid valve
failure
Probable
refrigerant gas leak
Motor fan failure
Compressor failure
Low carbonation level
Brand new
appliance
RESOLUTION
Check water supply
Call technical
assistance
Call technical
assistance
Call technical
assistance
Call technical
assistance
Utilize for few days
and check
carbonation
22 electrolux environment care
Low CO2 pressure
CO2 bottle is nearly
empty
Air inside
carbonator
Cold water occasionally
sprays CO2 gas
Carbonation pump
malfunction
Non return valve on
carbonator open
Increase CO2
pressure by rotating
knob on CO2
pressure regulator
clock-wise
Change CO2 bottle
Dispense few liter
of carbonated water
and check
carbonation
Call technical
assistance
Call technical
assistance
Warning
All repairs should be carried
out by authorized
technicians.
Environment care
The symbol
on the product or
on its packaging indicates that this
product may not be treated as
household waste. Instead it shall be
handed over to the applicable
collection point for the recycling of
electrical and electronic equipment.
By ensuring this product is disposed
of correctly, you will help prevent
potential negative consequences for
the environment and human health,
which could otherwise be caused by
inappropriate waste handling of this
product. For more detailed
information about recycling of this
product, please contact your local
city office, your household waste
disposal service or the shop where
you purchased the product.
electrolux 23
Electric diagram
EV1
EV2
EV3
EV4
EV5
EV6
SW1
SW2
SW3
SW4
L1-L8
L9
P1
P2
C1
Ambient water electric valve
Carbonated water electric valve
Cold water electric valve
Water main electric valve
Hot gas cycle electric valve
Ice bin water charge electric valve
Microswitch work position
Microswitch discharge position
CO2 pressure switch
Main on-off double pole switch
Command panel leds
Light bar
Carbonator pump
Tank discharge pump
Compressor
PR1
PR2
PR3
PR4
PR5
PR6
M1
M2
M3
F1
T1-T6
TR1
Ice probe
Dryer filter probe
Flooding probe
Minimum water tank level probe
MAX Carbonator level probe
MIN Carbonator level probe
Auger motor
Water ice bin motor
Motor fan
Flow meter
Command panel buttons
AC-DC adapter
24 electrolux hydraulic diagram
Hydraulic diagram
A
B
C
D
E
F
G
1
2
3
4
5
6
7
8
9
10
Water inlet
Water drainage
Ice cube tray
Cold water
Carbonated/Sparkling water
Ambient water
Water dispense nozzle
Cooling coil
No return valve
Pressure reducer
Valve
CO2 Cylinder
Turbine
Electric valve
Pump
Cartridge filter
Carbonator device
errata corrige electrolux 25
Errata Corrige
Package content
The package contains the mentioned material with
the addition of:
- 10 screws 3.5x16 and 3 screws M4x8
- user instruction manual
Installation
Cabinet dimensions
50
1.The required dimensions of the cabinet space for
the positioning of the unit are:
a. Height (1): 380mm
b. Depth (2): 560mm
c. Width (3): 560mm
0
54
50
3
2
1
Unit position inside the cabinet
-
After making sure that the overall size of the
unit fits the cabinet space, install the base
plate (Fig.3). If necessary, please use the
spacers to adapt and fix the base plate to the
cabinet space (Fig.4)
Fig. 4
−
−
Mount the sliding rails onto the base plate
using the included 10 self-tapping screws
3.5x16 (Fig. 5)
Fig. 5
Place the Refreshment Center on the
telescopic runners and push it slowly until the
confirming "click" sound.
Fig. 6
26 electrolux errata corrige
Filter cartridge first installation
Lift the drip tray and pull upward the locking
spring of the Refreshment center util it unblocks
(Fig.8)
Fig. 8
Pull the bottom edge of the unit and extract the
Refreshment Center (Fig.9).
After pulling out the unit it is easier to access the
left side, that contains the filter cartridge.
Fig. 9
Remove the capsule. Connect the filter cartridge
to the filter head turning it counter-clockwise
(Fig.10)
Fig. 10
Check for water leaks. Dry the area before
installing the unit in the opening.
Aligner installation
-
After making sure that the overall size of the
unit fits the cabinet space, install the base
plate (Fig.3). If necessary, please use the
spacers to fix the base plate to the cabinet
space (Fig.4). Its function is to line up the
Refreshment Centre to the other possible builtin appliances in the kitchen.
Fig. 4
errata corrige electrolux 27
CO2 bottle first installation
Disposable Bottle
The CO2 bottle can be found on the left side of the
unit. Remove the green cap and screw the
pressure reducer onto the bottle until fully
tightened (Fig.11).
Open the valve on the reducer until it reaches a
pressure of about 3 bar (Fig.12).
In order to obtain a higher level of CO2
concentration, it is possible to increase the
pressure up to a maximum of about 4 bar.
Fig. 11
Rechargeable bottle
The CO2 bottle can be found on the left side of
the unit. Together with the pressure reducer is a
fitting adaptor with seal ring included. The
adaptor is to be screwed onto the bottle head. For
a complete assembly, screw the pressure reducer
onto the adaptor.
Open the valve on the reducer until it reaches a
pressure of about 3 bar (Fig.12).
In order to obtain a higher level of CO2
concentration, it is possible to increase the
pressure up to a maximum of about 4 bar.
Using the Refreshment Center
Warning
Use the general switch on the right side of
the unit to switch it on. The on/off switch of
the front panel does not have a stand-by
function; the unit is still on, but all
functions are disabled. To switch on and off
the unit always use the internal general
switch, even when resetting.
Fig. 12
28 electrolux errata corrige
Alarms
Led indications
Filter red led
blinks slowly
Filter red led is
on
Filter red led
stays lit
Carbonated water
led blinks slowly
CO2 bottle led
stays lit
Meaning
Filter is about to exhaust. 2,700 liters of
water have been dispensed.
Please replace the filter cartridge as
described in the paragraph "Filter
replacement"
Filter exhausted. 2,800 liters of water have
been dispensed.
Please replace the filter cartridge as
described in the paragraph "Filter
replacement"
All dispense buttons disabled.
The limit has been reached of 2,840 liters.
To reset all dispense functions, please replace
the filter cartridge as described in the
paragraph "Filter reaplacement"
Carbonated water is disabled.
A protection device on the pump activated.
To reset the unit, please turn it off and after
few seconds switch it back on using the on/off
button on the control panel.
Carbonated water is disabled.
CO2 bottle is empty.
To restore carbonated water dispensing,
please replace the bottle as described in the
paragraph "CO2 bottle replacement".
- Ambient water
- ice cubes
leds blink
simultaneously
Ice forming bin blocked.
To reset the unit switch it off and then back on pushing the
on/off button on the front panel.
errata corrige electrolux 29
Led indications
Meaning
- Ambient water
- cold water
- carbonated
water
leds blink
Volumetric turbine malfunctioning. The two possible causes
simultaneously
are:
and fast
1. Lack of water supply from the water main;
2. Low pressure in the water inlet.
Please check the presence of water supply to the unit.
Turn unit off and then back on using the on/off switch on
the front panel.
- carbonated
water
- ambient water
- cold water
- ice cubes
This alarm comes on only when the unit is turned on through
leds blink
the main on/off switch. It means that the main tank is
simultaneously
empty due to a lack of water supply from the main. To reset
the unit, turn off the main switch on the side of the
Refreshment Center. Check and make sure there is water
supply to the unit, then turn the unit back on.
All leds blink
simultaneously
All dispense buttons disabled. The two possible causes are:
1. Presence of water on the base of
the unit;
2. The water level inside the tank is
too high.
In the first case, switch off the unit and dry the base.
In the second case, reset the unit by turning it off and then
back on through the main switch on the side of the
Refreshment Center.
Maintenance and cleaning
Please do not touch the front control panel with wet or oily hands, in order
to avoid the malfunctioning of the touch control.
30 electrolux errata corrige
Ice melting
Do not block ice exit with any object,
since it may damage the unit or prevent
the correct closing of the exit. This would
cause a rise in the internal temperature
with subsequent rapid ice melting
CO2 bottle replacement (for food)
When CO2 led turns on, please replace the old bottle with a new one as
described below:
1. unblock the locking spring from under the
drip tray (Fig. 8). Pull out with both hands the
bottom of the unit, letting the Refreshment
center slide on the telescopic runners
(Fig.15). After pulling out the unit it is easier
to access the left side, where the CO2 bottle
is installed;
2. grab the bottle and extract it;
Fig. 15
3. hold the pressure reducer and turn the bottle
clockwise (fig.16) to separate the bottle from
the pressure reducer;
4. screw the new bottle to the reducer counterclockwise till fully tightened (Fig. 11);
5. lock the new bottle on the side of the unit.
Fig. 16
errata corrige electrolux 31
Sanification + filter cartridge replacement
if few days after the
installation the filter
replacement led turns on,
please activate the sanitation
procedure to restore all
functions. In such case, filter
replacement is not necessary
When the “filter” led turns on, it is necessary to replace the cartridge filter
as described below:
6. unblock the locking spring (Fig.8) and pull
out the Refreshment Center unit (Fig.15);
7. turn off the unit through the main on/off
switch;
8. see filter cartridge on the left (Fig. 1a);
9. rotate the exhausted cartridge clockwise
about a quarter of a turn to remove it
from the head (fig.17) and extract it
avoiding water spillage;
10. fill the sanification cartridge with
“Neutral Detergent”. Insert the sanitizing
cartridge on the filter head by rotating it
counter-clockwise about a quarter turn
(Fig.18);
11. in case of water spillage, dry the base and
make sure there are no leaks;
12. place a big cup under the water dispense
nozzle (the appliance will deliver round
250ml of water);
13. turn on the main switch pushing at the
same time the light-switching button for
approximately 5". Press the "light" button
two more times, each time for 5". This
will activate the sanitizing mode,
displayed as a red led moving through all
the buttons of the front panel; during this
operation, the inner tank will be
sanitized. After this initial cleaning cycle,
the unit will automatically dispense some
cold and ambient water mixed with the
Fig. 17
Fig. 18
Fig. 19
32 electrolux errata corrige
sanitizing solution;
14. turn off the unit through the main switch;
15. remove the sanification cartridge (Fig.19)
and connect the new filter cartridge to
the head as shown on filter cartridge
instructions (Fig.20);
16. turn on the main switch and push the
Refreshment Center into the cabinet until
the locking spring clicks (Fig.21);
17. wait 4 minutes before activating the unit
pushing the on/off button on the control
panel;
18. dispense 1 liter of cold, carbonated and
ambient water to fully rinse the lines and
eliminate any residual of sanitizing
solution.
Warning
During the sanitizing
procedure please do not
dispense carbonated water.
Fig. 20
Fig. 21
errata corrige electrolux 33
Guarantee/Customer Service
Standard guarantee conditions
We, Electrolux, undertake that if
within 12 months of the date of the
purchase this Electrolux appliance or
any part thereof is proved to be
defective by reason only of faulty
workmanship or materials, we will,
at our option repair or replace the
same FREE OF CHARGE for labour,
materials or carriage on condition
that:
- The appliance has been correctly
installed and used only on the
electricity supply stated on the
rating plate.
- The appliance has been used for
normal domestic purposes only,
and in accordance with the
manufacturer’s instructions.
- The appliance has not been
serviced, maintained, repaired,
taken apart or tampered with by
any person not authorizsed by us.
- Electrolux Service Force Centre
must undertake all service work
under this guarantee.
- Any appliance or defective part
replaced shall become the
Company’s property.
- This guarantee is in addition to
your statutory and other legal
rights.
Exclusions
- Damage or calls resulting from
transportation, improper use or
neglect, the replacement of any
light bulbs or removable parts of
glass or plastic.
- Costs incurred for calls to put
right an appliance which is
improperly installed or calls to
appliances outside the United
Kingdom.
- Appliances found to be in use
within a commercial
environment, plus those which
are subject to rental agreements.
- Products of Electrolux
manufacturer that are not
marketed by Electrolux.
Service and Spare Parts
In the event of your appliance
requiring service, or if you wish to
purchase spare parts, please contact
your local Service Force Centre by
telephoning 0870 5 929 929
Your telephone call will be
automatically routed to the Service
Force Centre covering your postcode
area.
For the address of your local Service
Force Centre and further information
about Service Force, please visit the
website at www.serviceforce.co.uk
Before calling out an engineer,
please ensure you have read the
details under the heading “Something
not working” When you contact the
Service Force Centre you will need to
give the following details:
1. Your name, address and
postcode.
2. Your telephone number.
3. Clear concise details of the fault.
4. The model and Serial number of
the appliance (found on the
rating plate).
5. The purchase date. Please note a
valid purchase receipt or
guarantee documentation is
required for in guarantee service
calls.
34 electrolux errata corrige
Customer Care
For general enquiries concerning your
Electrolux appliance, or for further
information on Electrolux products
please contact our Customer Care
Department by letter or telephone at
the address below or visit our
website at www.electrolux.co.uk
Customer Care Department
Electrolux Major Appliances
Addington Way
Luton
Bedfordshire, LU4 9QQ
Tel: 08705 950 950 (*)
(*) Calls may be recorded for training
purposes
guarantee/customer service electrolux 35
European Guarantee
This appliance is guaranteed by
Electrolux in each of the countries
listed at the back of this user manual,
for the period specified in the
appliance guarantee or otherwise by
law. If you move from one of these
countries to another of the countries
listed below the appliance guarantee
will move with you subject to the
following qualifications:
- The appliance guarantee starts
from the date you first purchased
the appliance which will be
evidenced by production of a valid
purchase document issued by the
seller of the appliance.
- The appliance guarantee is for the
same period and to the same
extent for labour and parts as
exists in your new country of
residence for this particular
model or range of appliances.
- The appliance guarantee is
personal to the original purchaser
of the appliance and cannot be
transferred to another user.
- The appliance is installed and
used in accordance with
instructions issued by Electrolux
and is only used within the home,
i.e. is not used for commercial
purposes.
- The appliance is installed in
accordance with all relevant
regulations in force within your
new country of residence.
The provisions of this European
Guarantee do not affect any of the
rights granted to you by law.
36 electrolux errata corrige
www.electrolux.com
Albania
Belgique/België/
Belgien
+35 5 4 261 450
Rr. Pjeter Bogdani Nr. 7 Tirane
+32 2 363 04 44
Bergensesteenweg 719, 1502 Lembeek
Èeská republika
+420 2 61 12 61 12
Budìjovická 3, Praha 4, 140 21
Danmark
Deutschland
Eesti
+45 70 11 74 00
+49 180 32 26 622
+37 2 66 50 030
España
+34 902 11 63 88
Sjællandsgade 2, 7000 Fredericia
Muggenhofer Str. 135, 90429 Nürnberg
Mustamäe tee 24, 10621 Tallinn
Carretera M-300, Km. 29,900
Alcalá de Henares Madrid
France
www.electrolux.fr
Great Britain
+44 8705 929 929
Hellas
Hrvatska
Ireland
+30 23 10 56 19 70
+385 1 63 23 338
+353 1 40 90 75
Italia
+39 (0) 434 558500
Latvija
Lietuva
Luxembourg
+37 17 84 59 34
+370 5 2780609
+35 2 42 43 13 01
Magyarország
+36 1 252 1773
Nederland
+31 17 24 68 300
Norge
Österreich
+47 81 5 30 222
+43 18 66 400
Vennootsweg 1, 2404 CG - Alphen aan den
Rijn
Risløkkvn. 2 , 0508 Oslo
Herziggasse 9, 1230 Wien
Polska
+48 22 43 47 300
ul. Kolejowa 5/7, Warsaw
Portugal
+35 12 14 40 39 39
Quinta da Fonte - Edificio Gonçalves
Zarco - Q 352774 - 518 Paço de Arcos
Romania
+40 21 451 20 30
Str. Garii Progresului 2, S4, 040671 RO
Schweiz/Suisse/
Svizzera
+41 62 88 99 111
Industriestrasse 10, CH-5506 Mägenwil
Slovenija
+38 61 24 25 731
Slovensko
+421 2 43 33 43 22
Suomi
+35 8 26 22 33 00
Sverige
+46 (0)771 76 76 76
Türkiye
+90 21 22 93 10 25
Pоссия
+7 495 9377837
Addington Way, Luton, Bedfordshire
LU4 9QQ
4 Limnou Str., 54627 Thessaloniki
Slavonska avenija 3, 10000 Zagreb
Long Mile Road Dublin 12
C.so Lino Zanussi, 26 33080 Porcia (PN)
Kr. Barona iela 130/2, LV-1012, Riga
Verkių 29, LT_09108 Vilnius
Rue de Bitbourg, 7, L-1273 Hamm
H-1142 Budapest XIV,
Erzsébet királyné útja 87
Electrolux Ljubljana, d.o.o.Tržaška 132, 1000
Ljubljana
Electrolux Slovakia s.r.o., Electrolux Domáce
spotrebièe SK, Seberíniho 1,
821 03 Bratislava
Konepajanranta 4, 28100 Pori
Electrolux Service, S:t Göransgatan 143,S105 45 Stockholm
Tarlabaþý caddesi no : 35 TaksimIstanbul
129090 Мосва, Олимпийский проспект, 16,
БЦ, „Олимпик“
guarantee/customer service electrolux 37
38 electrolux errata corrige
guarantee/customer service electrolux 39
8910
Download PDF

advertising
