Aeg-Electrolux HK834060XB User Manual

HK834060XB
User manual
Ceramic glass hob
2
Contents
Thank you for choosing one of our high-quality products.
To ensure optimal and regular performance of your appliance please read this
instruction manual carefully. It will enable you to navigate all processes perfectly
and most efficiently. To refer to this manual any time you need to, we recommend
you to keep it in a safe place. And please pass it to any future owner of the appliance.
We wish you much joy with your new appliance.
Contents
Safety information
2
Installation instructions
Product description
3
6
Operating instructions
On and Off
Automatic Switch Off
The heat setting
/ Switching the outer rings on and off
7
7
7
7
Automatic Heat Up
8
8
Starting the STOP+GO
Using the Timer
Locking / unlocking the control panel
The child safety device
Helpful hints and tips
8
8
9
9
9
Care and cleaning
10
What to do if…
Environment concerns
Packaging material
11
12
12
Subject to change without notice
Safety information
For your safety and correct operation of the appliance, read this manual carefully before
installation and use. Always keep these instructions with the appliance even if you move
or sell it. Users must fully know the operation and safety features of the appliance.
General safety
WARNING!
Persons (including children) with reduced physical sensory, mental capabilities or lack of
experience and knowledge must not use the appliance. They must have supervision or
instruction for the operation of the appliance by a person responsible for their safety.
Child safety
• Only adults can use this appliance. Children must get supervision to make sure that they
do not play with the appliance.
• Keep all packaging away from children. There is a risk of suffocation.
• Keep children away from the appliance when it is on.
WARNING!
Start the child safety device to prevent small children and pets from an accidental activation
of the appliance.
Installation instructions
3
Safety during operation
• Remove all packaging, stickers and layers from the appliance before the first use.
• Set the cooking zones to "off" after each use.
• Risk of burns! Do not put cutlery or saucepan lids on the cooking surface, as they can
become hot.
WARNING!
Fire danger! Overheated fats and oils can ignite very quickly.
Correct operation
•
•
•
•
Always monitor the appliance during operation.
Only use the appliance for domestic cooking tasks!
Do not use the appliance as a work or a storage surface.
Do not put or keep very flammable liquids and materials, or fusible objects (made of
plastic or aluminium) on or near the appliance.
• Be careful when you connect the appliance to the near sockets. Do not let electricity
bonds touch the appliance or hot cookware. Do not let electricity bonds tangle.
How to prevent a damage to the appliance
• If the objects or cookware fall on the glass ceramic, the surface can be damaged.
• Cookware made of cast iron, cast aluminium or with damaged bottoms can scratch the
glass ceramic if you move them on the surface.
• Do not let cookware boil dry to prevent the damage to cookware and glass ceramics.
• Do not use the cooking zones with empty cookware or without cookware.
• Do not cover any part of the appliance with aluminium foil.
WARNING!
If there is a crack on the surface, disconnect power supply to prevent the electric
shock.
Installation instructions
Before the installation , note down this data from the rating plate:
• Model description (Modell)................
• Product number (Prod. Nr.) ............. ....
• Serial number (Ser. Nr.) ...............
You find the rating plate of the appliance on its lower casing.
949 593 339 00
HK834060XB
58 HBD 47 AO 220-240 V 50-60-Hz
7,0 kW
AEG-ELECTROLUX
4
Installation instructions
Safety instructions
WARNING!
You must read these!
Make sure that the appliance is not damaged because of transportation. Do not connect a
damaged appliance. If it is necessary, speak to the supplier.
Only an authorised service technician can install, connect or repair this appliance. Use only
original spare parts.
Only use built-in appliances after you assemble the appliance into correct built-in units
and work surfaces that align to the standards.
Do not change the specifications or modify this product. Risk of injury and damage to the
appliance.
Fully obey the laws, ordinances, directives and standards in force in the country where you
use the appliance (safety regulations, recycling regulations, electrical safety rules etc.)!
Keep the minimum distances to other appliances and units!
Install anti-shock protection, for example install the drawers only with a protective floor
directly below the appliance!
Protect the cut surfaces of the worktop against moisture with a correct sealant!
Seal the appliance to the work top with no space left with a correct sealant!
Protect the bottom of the appliance from steam and moisture, e.g. from a dishwasher or
oven!
Do not install the appliance adjacent to doors and below windows! If not, hot cookware
can be hit off the hob when you open doors or windows.
WARNING!
Risk of injury from electrical current. Carefully obey the instructions for electrical connections.
•
•
•
•
•
•
•
The electrical mains terminal is live.
Make electrical mains terminal free of voltage.
Install correctly to give anti-shock protection.
Loose and incorrect plug and socket connections can make the terminal become too hot.
A qualified electrician must install the clamping connections correctly.
Use a strain relief clamp on cable.
Use the correct mains cable of type H05BB-F Tmax 90°C (or higher) for a single-phase
or two-phase connection.
• Replace the damaged mains cable with a special cable (type H05BB-F Tmax 90°C; or
higher). Speak your local Service Force Centre.
The appliance must have the electrical installation which lets you disconnect the appliance
from the mains at all poles with a contact opening width of minimum 3 mm.
You must have correct isolation devices: line protecting cut-outs, fuses (screw type fuses
removed from the holder), earth leakage trips and contactors.
Installation instructions
Assembly
min.
50 mm
min. 500 mm
min.
50 mm
R 5mm
=
600mm
490+1mm
750+1mm
=
min.
25 mm
min.
20 mm
min.
30 mm
If you use a protection box (additional accessory),
the protective floor directly below the appliance
is not necessary.
5
6
Product description
Product description
Cooking surface layout
1
2
145
265
mm
170
mm
145
120/210
1
2
3
4
5
mm
3
mm
mm
5
Single cooking zone 1200 W
Oval cooking zone 1500/2400 W
Single cooking zone 1200 W
Control panel
Double cooking zone 750/2200 W
4
Control panel layout
1
2
11
3
10
4
9
5
6
7
8
Use the sensor fields to operate the appliance. Displays indicators and sounds tell which
functions operate.
sensor field
function
1
starts and stops the hob
2
locks/unlocks the control panel
3
a heat setting display
shows the heat setting
4
cooking zones' indicators of timer
shows for which zone you set the time
5
the timer display
shows the time in minutes
6
/
starts and stops the outer ring
7
8
increase or decrease heat setting
/
increase or decrease the time
9
selects the cooking zone
10
starts and stops the outer ring
Operating instructions
sensor field
7
function
starts and stops the STOP+GO function
11
Heat setting displays
Display
Description
The cooking zone is off
The cooking zone operates
-
Keep Warm /
function is on
The automatic heat-up function is on
There is a malfunction
A cooking zone is still hot (residual heat)
Lock/Child safety function is on
The automatic switch off is on
Residual heat indicator
WARNING!
Risk of burns from residual heat!
Operating instructions
On and Off
Touch
for 2 seconds to start the appliance. Touch
for 1 second to stop the appliance.
Automatic Switch Off
The function stops the hob automatically if:
• all cooking zones are off .
• you do not set the heat setting after you start the hob.
• you cover a sensor field with an object (a pan, a cloth, etc.) for longer than 10 seconds.
The sound operates some time and the hob stops. Remove the object or clean the control
panel.
• you do not stop a cooking zone or change the heat setting. After some time comes
on and the hob stops. See the table.
Automatic Switch Off times
Heat setting
-
-
Stops after
6 hours
5 hours
4 hours
1.5 hours
The heat setting
Touch to increase the heat setting. Touch to decrease the heat setting. The display
shows the heat setting. Touch and at the same time to switch off the cooking zone.
8
/
Operating instructions
Switching the outer rings on and off
You can match the effective heating surface to the size of the cookware.
. The indicator comes on. For
To switch on the outer ring touch the sensor field /
more outer rings touch the same sensor field again. The next indicator comes on.
Do the procedure again to switch off the outer ring. The indicator goes out.
Automatic Heat Up
You can get a necessary heat setting in a shorter
time if you activate the Automatic Heat Up function. This function sets the highest heat setting for
some time (see the graphic), and then decreases
to the necessary heat setting.
To start the Automatic Heat Up function the cooking zone must be cold (no in the display). Touch
of the cooking zone again and again until the
necessary heat setting comes on. After 3 seconds
comes on in the display.
To stop the function touch .
11
10
9
8
7
6
5
4
3
2
1
0
1
2
3
4
5
6
7
8
9
Starting the STOP+GO
The
function sets all cooking zones that operate to a keep warm setting.
• Touch
to start this function. The symbol comes on.
• Touch
to stop this function. The heat setting that you set before comes on.
does not stop the timer function.
fully locks the control panel but not the sensor field .
Using the Timer
Use the timer to set how long the cooking zone operates for one cooking session.
Set the timer after the selection of the cooking zone.
You can set the heat setting before or after you set the timer.
• Selection of the cooking zone: touch again and again until the indicator of a
necessary cooking zone comes on.
• Starting or changing the timer: touch or of the timer to set the time ( 00 99 minutes). When the indicator of the cooking zone flashes slower, the time counts
down.
• Stopping the timer: select the cooking zone with and touch to switch off the
timer. The remaining time counts backwards to 00 . The indicator of the cooking zone
goes out.
• Checking the remaining time: select the cooking zone with . The indicator of the
cooking zone flashes faster. Display shows the remaining time.
When the time elapses, the sound operates and 00 flashes. The cooking zone switches off.
• Stopping the sound: touch
You can use the timer as a minute minder while cooking zones do not operate. Touch
. Touch or to select the time. When the time elapses, the sound operates and
00 flashes
Helpful hints and tips
9
Locking / unlocking the control panel
You can lock the control panel, but not . It prevents an accidental change of the heat
setting during a cooking session.
Touch the symbol . The symbol comes on for 4 seconds.
The Timer still operates.
Touch the symbol to switch off this function. The heat setting that you set before comes
on.
When you switch off the appliance, you also switch off this function.
The child safety device
This function prevents an accidental operation of the hob.
Starting the child safety device
• Start the hob with . Do not set the heat settings .
• Touch for 4 seconds. The symbol comes on.
• Stop the hob with .
Switching off the child safety device
• Start the hob with . Do not set the heat settings . Touch for 4 seconds. The
symbol comes on.
• Stop the hob with .
Overriding the child safety device for one cooking session
• Start the hob with . The symbol comes on.
• Touch for 4 seconds. Set the heat setting in less than 10 seconds. You can operate
the hob.
• When you stop the hob with , the child safety device operates again.
Helpful hints and tips
Cookware
• The bottom of the cookware must be as thick and flat as possible.
• Cookware made of enamelled steel and with aluminium or copper bottoms can cause
discoloration on glass ceramic surface.
Energy saving
•
•
•
•
If possible, always put the lids on the cookware.
Put cookware on a cooking zone before you start it.
Stop the cooking zones before the end of the cooking time to use residual heat.
The bottom of pans and cooking zones must have the same dimension.
Examples of cooking applications
The data in the table is for guidance only.
10
Care and cleaning
Heat
setting
1
Use to:
Keep cooked foods warm
Time
as required
Hints
Cover
1-2
Hollandaise sauce, melt: butter, choco- 5-25
late, gelatine
min
Mix occasionally
1-2
Solidify: fluffy omelettes, baked eggs
Cook with a lid on
2-3
Simmer rice and milkbased dishes, heat- 25-50
ing up ready-cooked meals
min
Add at least twice as much liquid as
rice, stir milk dishes part way
through
3-4
Steam vegetables, fish, meat
20-45
min
Add a few tablespoons of liquid
4-5
Steam potatoes
20-60
min
Use max. ¼ l water for 750 g of potatoes
4-5
Cook larger quantities of food, stews
and soups
60-150
min
Up to 3 l liquid plus ingredients
6-7
Gentle fry: escalope, veal cordon bleu,
cutlets, rissoles, sausages, liver, roux,
eggs, pancakes, doughnuts
as required
Turn halfway through
7-8
Heavy fry, hash browns, loin steaks,
steaks
5-15
min
Turn halfway through
9
Boil large quantities of water, cook pasta, sear meat (goulash, pot roast), deep fry chips
10-40
min
Information on acrylamides
According to the newest scientific knowledge, if you brown food (specially the one which
contains starch), acrylamides can pose a health risk. Thus, we recommend that you cook at
the lowest temperatures and do not brown food too much.
Care and cleaning
Clean the appliance after each use.
Always use cookware with clean bottom.
WARNING!
Sharp objects and abrasive cleaning agents will damage the appliance.
For your safety, do not clean the appliance with steam blasters or high-pressure cleaners.
Scratches or dark stains on the glass ceramic have no effect on how the appliance operates.
Removing the dirt:
1. – Remove immediately: melting plastic, plastic foil, and food containing sugar. Use
a special glass ceramic scraper. Put the scraper on the glass ceramic surface at an
acute angle and slide the blade on the surface.
What to do if…
11
– Stop the appliance and let it cool down before you clean: limescale rings, water
rings, fat stains, shiny metallic discolorations. Use a special cleaner for glass ceramic
or stainless steel.
2. Clean the appliance with a damp cloth and some detergent.
3. At the end rub the appliance dry with a clean cloth.
What to do if…
Problem
Possible cause and remedy
You cannot start the appliance
or operate it.
• You touched 2 or more sensor fields at the same time. Only
touch one sensor field.
• There is water or fat stains on the control panel. Clean the
control panel
• The key lock or child safety device operates
. Stop the
function. See the section "Locking/unlocking the control panel" and “Child safety device”.
• The STOP+GO function operates
. Stop the function. See
the section "Starting the STOP+GO".
• Start the appliance again and set the heat setting in 10 seconds.
The residual heat indicator does The cooking zone is not hot because it operated only for a short
not come on.
time. If the cooking zone must be hot, speak to the after sales
service.
The automatic heat up function • There is still residual heat on the cooking zone
. Let the
does not start.
cooking zone cool down
• The highest heat setting is set. The highest heat setting has
the same power as the automatic heat up function.
• You set the heat setting with
sensor field. Start from
and use
only.
A sound operates and appliance You covered
starts and stops again. After 5
seconds one more sound operates.
. Uncover the sensor field.
comes on.
• The automatic switch-off operates. Stop the appliance and
start it again.
Overheating protection for the cooking zone operates. Stop the
cooking zone and start it again.
and a number come on.
There is an error in the appliance.
Disconnect the appliance from the electrical supply for some
time. Disconnect the fuse from the electrical system of the house.
Connect again. If
comes on again, speak to the after sales
service.
If you tried the above solutions and cannot repair the problem, speak to your dealer or the
Customer Care Department. Give the data from the rating plate, three-digit-letter code for
the glass ceramic (it is in the corner of the cooking surface) and an error message that
comes on.
12
Environment concerns
If you operated the appliance incorrectly, the servicing by a customer service technician or
dealer will not be free of charge, even during the warranty period. The instructions about
the customer service and conditions of guarantee are in the guarantee booklet.
Environment concerns
The symbol
on the product or on its packaging indicates that this product may not be
treated as household waste. Instead it should be taken to the appropriate collection point
for the recycling of electrical and electronic equipment. By ensuring this product is disposed
of correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this product, please contact
your local council, your household waste disposal service or the shop where you purchased
the product.
Packaging material
The packaging materials are friendly to the environment and can be recycled. The plastic
components are identified by marking: >PE<,>PS<, etc. Discard the packaging materials as
household waste at the waste disposal facilities in your municipality.
13
14
15
www.electrolux.com
892935897-C-032010
www.aeg-electrolux.be

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
