Bosch NKG645P14G Electric hotplate Instruction manual

NKC6..., NKE6..., NKF6..., NKG6..., NKN6...
Hob
[en] Instruction manual
1.(
‘
‘
1.)
‘
‘
‘
‘
1.1
‘
‘
‘
‘
1.&
‘
‘
‘
‘
‘
‘
1.*
‘
‘
‘
‘
Ú Table of contents
nsomanuitr[e]I nctl
Safety precautions..................................................................... 3
Causes of damage .............................................................................4
Environmental protection ......................................................... 4
Environmental protection...................................................................4
Tips for saving energy .......................................................................4
Getting to know your appliance................................................ 5
The control panel................................................................................5
The hotplates .......................................................................................5
Residual heat indicator ......................................................................5
Setting the hob........................................................................... 6
Switching the hob on and off ...........................................................6
Setting a hotplate................................................................................6
Table of cooking times ......................................................................6
Electronic boil start control ...................................................... 7
Setting the electronic boil start control...........................................7
Table of cooking times for electronic boil start control...............7
2
Tips for the electronic boil start control.......................................... 8
Childproof lock and pause function .........................................8
Childproof lock.................................................................................... 8
Pause function..................................................................................... 9
Automatic time limit ...................................................................9
Cleaning and care.......................................................................9
Ceramic ................................................................................................ 9
Hob surround ...................................................................................... 9
Rectifying faults..........................................................................9
After-sales service....................................................................10
Produktinfo
Additional information on products, accessories, replacement
parts and services can be found at www.bosch-home.com and
in the online shop www.bosch-eshop.com
Ø = cm
ã=Safety precautions
Please read this manual carefully.
Please keep the instruction and
installation manual as well as the
appliance certificate in a safe place
for later use or for subsequent
owners.
Check the appliance for damage
after unpacking it. Do not connect
the appliance if it has been
damaged in transport.
This appliance is intended for
domestic use only. The appliance
must only be used for the
preparation of food and drink. The
appliance must be supervised
during operation. Only use this
appliance indoors.
This appliance is not intended for
operation with an external clock
timer or a remote control.
This appliance may be used by
children 8 years old and older and
by persons with reduced physical,
sensory or mental capacity or a
lack of experience or knowledge if
they are supervised or they have
been instructed about the safe use
of the appliance and have
understood the associated
dangers.
Never let children play with the
appliance. Cleaning and user
maintenance must not be carried
out by unsupervised children.
Risk of fire!
■ Hot oil and fat can ignite very
quickly. Never leave hot fat or oil
unattended. Never use water to
put out burning oil or fat. Switch
off the hotplate. Extinguish flames
carefully using a lid, fire blanket or
something similar.
The hotplates become very hot.
Never place combustible items on
the hob. Never place objects on
the hob.
Risk of fire!
■
The appliance gets hot. Do not
keep combustible objects or
aerosol cans in drawers directly
underneath the hob.
Risk of fire!
■
Risk of burning!
■ The hotplates and the area around
them get very hot. Never touch the
hot surfaces. Keep children away.
The hotplate heats up but the
display does not work. Switch off
the circuit breaker in the fuse box.
Contact the after-sales service.
Risk of burns !
■
Risk of electric shock!
■ Cracks or fractures in the glass
ceramic may cause electric
shocks. Switch off the circuit
breaker in the fuse box. Contact
the after-sales service.
Penetrating moisture may cause
an electric shock. Do not use any
high-pressure cleaners or steam
cleaners.
Risk of electric shock.!
■
Risk of electric shock!
3
■
Incorrect repairs are dangerous.
Repairs must only be carried out
by a trained after-sales engineer. If
the appliance is defective, switch
off the circuit breaker in the fuse
box.
Risk of injury!
Saucepans may suddenly jump due
to liquid between the pan base and
the hotplate. Always keep the
hotplate and saucepan bases dry.
Causes of damage
Caution!
Overview
■
Rough pot and pan bases scratch the ceramic.
■
Avoid boiling pots dry. This may cause damage.
■
■
■
The following table provides an overview of the most frequent
kinds of damage:
Never place hot pots or pans on the control panel, the
display area or the surround. This may cause damage.
Damage can occur if hard or pointed objects fall on the hob.
Aluminium foil and plastic containers melt on hot hotplates.
Oven protective foil is not suitable for your hob.
Damage
Stains
Scratches
Cause
Action
Food spills
Remove spills immediately with a glass scraper.
Unsuitable cleaning agents
Only use cleaning agents which are suitable for ceramic
Salt, sugar and sand
Do not use the hob as a work surface or storage space.
Rough pot and pan bases scratch the Check your cookware.
ceramic.
Discolouration
Unsuitable cleaning agents
Only use cleaning agents which are suitable for ceramic
Pan abrasion (e.g. aluminium)
Lift the pots and pans when moving them.
Blisters
Sugar, food with a high sugar content Remove spills immediately with a glass scraper.
Environmental protection
Unpack the appliance and dispose of the packaging in an
environmentally-responsible manner.
Environmental protection
This appliance is labelled in accordance with the
European Directive 2002/96/EU concerning used
electrical and electronic appliances (WEEE –
waste electrical and electronic equipment). The
guideline determines the framework for the return
and recycling of used appliances as applicable.
Tips for saving energy
■
■
■
■
■
4
Always use a correctly fitting lid for the pan.Cooking without
the lid requires four times as much energy. A glass lid allows
you to observe the cooking without having to lift the lid off.
Use pots and pans with level bases. Using cookware with
unlevel bases increases energy consumption.
The diameter of the base of your pot or pan should match the
size of the hotplate. In particular, if pots that are too small are
placed on a hotplate, energy is wasted. Please note:
Cookware manufacturers often specify the diameter of the
top of the pan. This is usually bigger than the diameter of the
base of the pan.
Use a small pan for small quantities of food. A large
saucepan containing little food requires more energy.
Use only a little water when cooking. This will save energy. It
also preserves vitamins and minerals in vegetables.
■
■
Switch to a lower heat setting as soon as possible.
Use the residual heat of the hob. For longer cooking times,
you can switch the hotplate off as early as 5 - 10 minutes
before the end of the cooking time.
Getting to know your appliance
The instruction manual is the same for various different hobs.
An overview of the models with their dimensions is given on
page 2.
The control panel
'LVSOD\VIRU
³É
KHDWVHWWLQJ
‡¤
UHVLGXDOKHDW
©HOHFWURQLFERLOVWDUWFRQWURO
&RQWUROIRU
&RQWUROVIRU
,FKLOGSURRIORFN
pH[WHQGHGFRRNLQJ]RQH
sGXDOFLUFXLWKRWSODWH
RQKRWSODWHVZLWKH[WHQGHGFRRNLQJ]RQH
Controls
When you touch a symbol, the respective function is activated.
&RQWUROIRU
ÍGXDOFLUFXLWKRWSODWH
Notes
The settings will remain unchanged if you touch several
symbols at once. This allows you to wipe up spills on the
control panel.
■
■
Always keep the controls dry. Moisture reduces their
effectiveness.
The hotplates
Hotplate
Activating and deactivating
$
Single-circuit hotplate
ð
Dual-circuit hotplate
Touch the ñ symbol
æ
Extended cooking zone
Touch the é symbol
ë
Dual-circuit hotplate with
extended cooking zone
Touch the ë symbol; the 2nd filament circuit is activated
Touch the é symbol; the extended cooking zone is activated
When the hotplate is activated: the corresponding indicator lights up.
When the hotplate is switched on: the last selected size is automatically selected again
Residual heat indicator
The hob has a two-stage residual heat indicator for each
hotplate.
If • appears in the display the hob is still hot. It may be used,
for example, to keep a small meal warm or to melt cooking
chocolate. As the hotplate cools down further, the display
changes to œ. The display remains lit until the hotplate has
cooled sufficiently.
Power cut
If there has been a power cut, the residual heat indicator
switches back on automatically. The indicator flashes for
approximately 30 minutes. The flashing stops if you briefly
switch the hotplate on again.
5
Setting the hob
This section informs you how to set the hotplates. The table
shows heat settings and cooking times for various meals.
Switching the hob on and off
You can switch the hob on and off with the hotplate controls.
When the hob is switched on, the heat setting display lights up.
Setting a hotplate
Adjust the heat setting of the hotplates using the hotplate
controls.
0 = hotplate off
Heat setting 1 = lowest setting
Heat setting 9 = highest setting
There is an intermediate setting between each heat setting. This
is identified by a dot.
Note: Hotplate temperature is regulated by the heat switching
on and off. The heat may also switch on and off at the highest
setting.
Table of cooking times
The following table provides some examples.
When heating thick liquids, stir regularly.
Cooking times and heat settings may vary depending on the
type of food, its weight and quality. Deviations are therefore
possible.
For bringing liquids to the boil, use heat setting 9.
Ongoing cooking
setting
Ongoing cooking
time in minutes
Chocolate, cooking chocolate, butter, honey
1-2
-
Gelatine
1-2
-
Stew (e.g. lentil stew)
1-2
-
Milk**
1.-2.
-
Heating sausages in water**
3-4
-
Frozen spinach
2.-3.
20-30 mins
Frozen goulash
2.-3.
10-15 mins
Dumplings
4.-5.
20-30 mins
Fish
4-5*
10-15 mins
White sauces, e.g. béchamel sauce
1-2
3-6 mins
Emulsified sauces, e.g. béarnaise sauce, hollandaise sauce
3-4
8-12 mins
Rice (with double the quantity of water)
2-3
15-30 mins
Rice pudding
1.-2.
25-35 mins
Unpeeled boiled potatoes
4-5
25-30 mins
Boiled potatoes
4-5
15-25 mins
Pasta, noodles
6-7*
6-10 mins
Stew, soups
3.-4.
15-60 mins
Vegetables
2.-3.
10-20 mins
Vegetables, frozen
3.-4.
10-20 mins
Cooking in a pressure cooker
4-5
-
Roulades
4-5
50-60 mins
Pot roasts
4-5
60-100 mins
Goulash
2.-3.
50-60 mins
Melting
Heating and keeping warm
Defrosting and heating
Poaching, simmering
Boiling, steaming, stewing
Braising
* Continue cooking without a lid
** Without lid
6
Ongoing cooking
setting
Ongoing cooking
time in minutes
Escalope, plain or breaded
6-7
6-10 mins
Escalope, frozen
6-7
8-12 mins
Cutlet, plain or breaded
6-7
8-12 mins
Steak (3 cm thick)
7-8
8-12 mins
Poultry breast (2 cm thick)
5-6
10-20 mins
Chicken breast, frozen
5-6
10-30 mins
Fish and fish fillet, plain
5-6
8-20 mins
Fish and fish fillet, breaded
6-7
8-20 mins
Fish and fish fillet, breaded and frozen, e.g. fish fingers
6-7
8-12 mins
Scampi and prawns
7-8
4-10 mins
Stir fry, frozen
6-7
6-10 mins
Pancakes
6-7
continuous
Omelette
3.-4.
continuous
Fried eggs
5-6
3-6 mins
Frozen products, e.g. chips, chicken nuggets
8-9
-
Croquettes
7-8
-
Meat balls
7-8
-
Meat, e.g. chicken portions
6-7
-
Fish, breaded or battered
5-6
-
Vegetables, mushrooms, breaded or battered
5-6
-
Small items, e.g. doughnuts, fruit in batter
4-5
-
Frying**
Deep-fat frying (fry 150-200g per portion continuously in 1-2 litres oil**)
* Continue cooking without a lid
** Without lid
Electronic boil start control
The electronic boil start control heats the hotplate using the
highest heat setting and then switches down to the simmer
setting you have selected.
The time taken for the hotplate to heat up depends on the
simmer setting selected.
Setting the electronic boil start control
The electronic boil start control can only be activated in the first
10 seconds after you have switched on the hotplate:
1. Set the desired simmer setting with the hotplate control.
2. Press the hotplate control.
The electronic boil start control is activated. ‘ and the ongoing
cooking setting flash alternately.
After the food has been brought to the boil, only the simmer
setting remains lit in the display.
Table of cooking times for electronic boil start control
The table below shows which dishes electronic boil start control
can be used for.
Dish with electronic boil start control
The smaller quantities specified are for the smaller hotplates
and the larger quantities are for the larger hotplates. The values
given are guidelines.
Quantity
Heat setting
Total cooking time
in minutes
Stock
500 ml-1 litre
A 7-8
4-7 mins
Thick soups
500 ml-1 litre
A 2-3
3-6 mins
Milk**
200-400 ml
A 1-2
4-7 mins
400-800 g
A 1-2
-
Heating
Heating and keeping warm
Stew (e.g. lentil stew)
* Continue cooking without a lid
** Without lid
7
Dish with electronic boil start control
Quantity
Heat setting
Total cooking time
in minutes
Frozen spinach
300-600 g
A 2.-3.
10-20 mins
Frozen goulash
500g-1 kg
A 2.-3.
20-30 mins
300-600 g
A 4-5*
20-25 mins
Rice (with double the quantity of water)
125-250 g
A 2-3
20-25 mins
Unpeeled boiled potatoes with 1-3 cups of water
750 g-1.5 kg
A 4-5
30-40 mins
Boiled potatoes with 1-3 cups of water
750 g-1.5 kg
A 4-5
20-30 mins
Vegetables with 1-3 cups of water
500g-1 kg
A 2.-3.
15-20 mins
Frozen vegetables with 1-3 cups of water
500g-1 kg
A 4.-5.
15-20 mins
Roulades
4 pieces
A 4-5
50-60 mins
Pot roasts
1 kg
A 4-5
80-100 mins
Escalope, plain or breaded
1-2
A 6-7
8-12 mins
Cutlet, plain or breaded
1-2
A 6-7
8-12 mins
Steak (3 cm thick)
1-2
A 7-8
8-12 mins
Fish and fish fillet, breaded
1-2
A 6-7
8-12 mins
Fish and fish fillet, breaded and frozen, e.g. fish fingers
200-300 g
A 6-7
8-12 mins
A 6-7
continuous frying
Defrosting and heating
Poaching
Fish
Boiling
Braising
Frying**
Pancakes
* Continue cooking without a lid
** Without lid
Tips for the electronic boil start control
■
Electronic boil start control is designed to conserve food's
nutritional value while using little water for cooking.
■
■
Add only approximately 3 cups of water to the food for large
hotplates and approximately 2 cups of water for small
hotplates.
Place a lid on the saucepan.
Electronic boil start control is not suitable for food that is
cooked in a large volume of water (e.g. pasta).
Childproof lock and pause function
■
■
You can use the childproof lock to prevent children from
switching on the hotplates.
The pause function allows you to interrupt the heating
process.
Caution!
Water used for cleaning, spilt food and objects placed on the
@ symbol can cause the childproof lock/pause function to be
unintentionally activated or deactivated.
■
■
‹ flashes in the hotplate indicator, or the residual heat
indicator alternates with ‹.
The indicator lamp next to the I symbol lights up.
Switch the hotplate off. Release the lock.
Note: The residual heat is displayed, even when the hob is
locked.
Shortening the switch-on time
Childproof lock
You can shorten the switch-on time of the childproof lock from
4 seconds to 1 second:
Locking the hob
The hotplates must be switched off.
Switch off all hotplates. Within a minute, touch the I symbol
until the indicator lamp above the symbol lights up. This takes
approx. 4 seconds. The indicator lamp goes out after approx.
10 seconds.
1. Set all 4 hotplates to heat setting 2.
Releasing the lock
4. Switch off the hotplate control.
Switch on a hotplate. Touch the I symbol until the indicator
lamp goes out. This takes approx. 4 seconds. The hob is
unlocked.
Locked hob
If you set a hotplate on a locked hob, the following occurs:
8
2. Switch off the hotplates one after the other from right to left.
3. Select a heat setting for any hotplate and press the hotplate
control.
All displays light up briefly. The switch-on time is shortened.
You can also increase the switch-on time to 4 seconds again.
Proceed in exactly the same way as for shortening it.
Pause function
Continuing cooking
Activating the pause function
Tap the I symbol again within 3 minutes. The hotplates
continue to heat.
Tap the I symbol. The selected heat setting flashes on the
hotplate indicator. Heating is interrupted.
Pause time exceeded
After 3 minutes, a ‹ flashes in the display. Switch the hotplate
off and make your settings again.
Automatic time limit
If a hotplate is in use for a long time without the setting being
changed, the automatic time limit is activated.
When the time limit is activated depends on the heat setting
selected (1 to 10 hours).
The hotplate stops heating. ‹ flashes in the hotplate indicator.
Note: You can switch the hotplate back on again at any time.
Switch the hotplate off.
Cleaning and care
The information in this section provides help on how best to
care for your hob.
Suitable maintenance and cleaning products can be purchased
from the after-sales service or in our e-Shop.
Ceramic
Clean the hob after each use. This will prevent spills from
burning onto the ceramic.
■
Harsh cleaning agents such as oven spray or stain remover
■
Abrasive sponges
■
High-pressure cleaners or steam jet cleaners
Ground-in dirt can be best removed with a glass scraper,
available from retailers. Please note the manufacturer's
instructions.
You can also obtain a suitable glass scraper from our aftersales service or from the e-Shop.
Only clean the hob when it has cooled down sufficiently.
Use only cleaning agents which are suitable for ceramic. Follow
the cleaning instructions on the packaging.
Never use:
Hob surround
To prevent damage to the hob surround, please observe the
following instructions:
■
Undiluted washing-up liquid
■
Use only warm, soapy water.
■
Detergent intended for dishwashers
■
Do not use harsh or abrasive agents.
■
Scouring agents
■
Do not use the glass scraper.
Rectifying faults
Malfunctions often have simple explanations. Please read the
following notes before calling the after-sales service.
Indicator
Fault
Action
Blank
There is no power supply.
Check the household fuse for the appliance. Check whether there is a
power cut by trying other electronic appliances.
‹ is flashing
Automatic time limit activated.
Switch the hotplate off. Make your new settings.
“ is flashing
The controls are damp or an object is
resting on them.
Dry the controls or remove the object.
”‹
Display faulty.
Switch the appliance off and back on again after about 30 seconds
using either the household fuse or the circuit breaker in the fuse box.
Contact the after-sales service if this appears in the display again.
”…, all hotplates Childproof lock faulty.
are switched off.
Switch the appliance off and back on again after about 30 seconds
using either the household fuse or the circuit breaker in the fuse box.
Contact the after-sales service if this appears on the display again. You
can still cook with a faulty childproof lock.
9
After-sales service
Our after-sales service is there for you if your appliance should
need to be repaired. We are committed fo find the best solution
also in order to avoid an unnecessary call-out.
E number and FD number:
Please quote the E number (product number) and the FD
number (production number) of your appliance when
contacting the after-sales service. The rating plate bearing
these numbers can be found on the appliance certificate.
Please note that a visit from an after-sales service engineer is
not free of charge, even during the warranty period.
Please find the contact data of all countries in the enclosed
customer service list.
To book an engineer visit and product advice
GB
0844 8928979
Calls from a BT landline will be charged at up to 3
pence per minute. A call set-up fee of up to 6 pence may
apply.
IE
01450 2655
Trust the expertise of the manufacturer, and rest assured that
the repair will be carried out by trained service technicians
using original spare parts for your domestic appliance.
10
Robert Bosch Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München
Germany
www.bosch-home.com
*9000702301*
9000702301
910829

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
