KEYBOARD
SX-KC611
ENGLISH
QQTG0588A
Caution for AC Mains Lead
(For the types as shown in figures A
and B)
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three pin
mains plug for your safety and convenience. A 5ampere fuse is fitted in this plug. Should the fuse
need to be replaced please ensure that the replacement fuse has a rating of 5-ampere and that it is
approved by ASTA or BSI to BS1362. Check for the
ASTA mark
or the BSI mark
on the body
of the fuse.
If the plug contains a removable fuse cover you must
ensure that it is refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used
until a replacement cover is obtained.
A replacement fuse cover can be purchased from
your local dealer.
WARNING: DO NOT CONNECT EITHER WIRE TO
THE EARTH TERMINAL WHICH IS MARKED WITH
THE LETTER E, BY THE EARTH SYMBOL
OR
COLOURED GREEN OR GREEN/ YELLOW.
THIS PLUG IS NOT WATERPROOF
—KEEP DRY.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type
of AC mains plug (figures A and B). Confirm the AC
mains plug fitted and follow the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
Figure A
CAUTION!
IF THE FITTED MOULDED PLUG IS
UNSUITABLE FOR THE SOCKET OUTLET IN
YOUR HOME THEN THE FUSE SHOULD BE
RE-MOVED AND THE PLUG CUT OFF AND
DIS-POSED OF SAFELY. THERE IS A
DANGER OF SEVERE ELECTRICAL SHOCK
IF THE CUT OFF PLUG IS INSERTED INTO
ANY 13-AMPERE SOCKET.
Figure B
Fuse cover
If a new plug is to be fitted please observe the wiring
code as stated below. If in any doubt please consult
a qualified electrician.
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
The wire which is coloured Blue must be connected
to the terminal which is marked with the letter N or
coloured Black or Blue.
The wire which is coloured Brown must be connected to the terminal which is marked with the letter
L or coloured Brown or Red.
2. Replace
the fuse and close or attach the fuse
cover.
Figure A
Fuse
(5 ampere)
Figure B
Fuse
(5 ampere)
2
QQTG0588
OWNER’S MANUAL
Caution
Voltage (except North America, Mexico, Europe, Australia, New Zealand, China and
Russia)
Be sure the voltage adjuster located on the AC adaptor is in accordance with local voltage
in your area before using this unit. Use a screwdriver to set the voltage adjuster to the local
voltage.
(for Canada)
CAUTION:
TO PREVENT ELECTRIC SHOCK MATCH
WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
BEFORE YOU PLAY, PLEASE READ THE CAUTIONARY COPY APPEARING ON
PAGE 4.
Before you play
For long and pleasurable use of this instrument, and to gain a thorough understanding of your KC611
Keyboard, it is strongly recommended that you read through this Owner’s Manual once.
The Owner’s Manual is comprised of the following parts.
BASIC FUNCTIONS
This part includes an explanation of basic procedures and points you should be aware of for
proper operation of your instrument.
PRACTICAL APPLICATIONS
This part comprises a detailed explanation of sound, effect, rhythm, Recording, Disk Drive and
Setting functions.
REFERENCE GUIDE (separate booklet)
Reference guide for the contents of the Sound List, Drum Kits, MIDI Implementation Chart.
3
QQTG0588
Cautions for safest use of this unit
Installation location
If operation seems abnormal
1. A well-ventilated place.
Take care not to use this unit in a place where it
will not receive sufficient ventilation, and not to permit the ventilation holes to be covered by curtains,
or any similar materials.
2. Place away from direct sunlight and excessive heat
from heating equipment.
3. A place where humidity, vibration and dust are minimized.
Immediately turn off the power, disconnect the power
cord plug from the electrical outlet, and contact the
store where it was purchased.
Power source
A word about the power cord
1. For the power source, use ONLY the included AC
adaptor. Use of a different AC adaptor may result in
malfunction or even damage to the equipment.
2. If the unit is not to be used for some time, remove
the AC adaptor from the wall socket.
If the power cord is scarred, is partially cut or broken,
or has a bad contact, it may cause a fire or serious
electrical shock if used. NEVER use a damaged
power cord for any appliance. Moreover, the power
cord should never be forcibly bent.
Handling the power cord
Don’t touch the inside parts of this unit.
1. Never touch the power cord, or its plug, with wet
hands.
2. Don’t pull the power cord.
Some places inside this unit have high voltage potential. Never try to remove the top or back panels of this
unit, or to touch inside parts by hand or with tools.
Metal items inside the unit may result in electric shock or damage.
Contact someone who is qualified in order to inspect
the inside, or to replace a fuse, if such becomes necessary. Never attempt to do these things yourself.
Discontinue using the unit at once. Failure to do so
may result in additional damage or some other unexpected damage or accident.
• Because the power source is located inside the unit,
it is normal for the cabinet to become warm.
Do not permit metal articles to get inside the unit.
Maintenance
Be especially careful with regard to this point if children are near this unit. They should be warned never
to try to put anything inside.
If, nevertheless, some such article does get inside, disconnect the power cord plug from the electrical outlet,
and contact the store where the unit was purchased.
If water gets into the unit
Disconnect the power cord plug from the electrical outlet, and contact the store where it was purchased.
As a precaution, it is suggested that flower vases and
other containers which hold liquids not be placed on
the top of this unit.
The following suggestions will assist you in keeping
the unit in top condition.
• Be sure to switch the instrument off after use, and
do not switch the unit on and off in quick succession, as this places an undue load on the electronic
components.
• To keep the luster of the surface and buttons,
simply use a clean, damp cloth; polish with a soft,
dry cloth. Polish may be used but do not use thinners or petro-chemical-based polishes.
• A wax-based polish may be used on the cabinet, although you will find that rubbing with a soft cloth will
suffice.
Marking sign is located on bottom of the unit.
SERVICE MUST BE CARRIED OUT BY DEALER
OR OTHER QUALIFIED PERSON
4
QQTG0588
Contents
Cautions for safest use of this unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Controls and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
BASIC FUNCTIONS
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Playing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Listen to the demonstration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Add an automatic accompaniment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Play back the included Song Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Record your performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Beat Master . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
PRACTICAL APPLICATIONS
About the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Part I Sounds and effects
Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Conductor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Solo Piano . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Transpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Harmony . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Part II Playing the rhythm
Rhythm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Synchro Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Tempo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Rhythm performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Auto Play Chord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
One Touch Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Panel Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Party Pads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Part III Recording
Record your performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Playing back your recorded song . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Store a chord progression . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Part IV Disk Drive
Parts of the floppy disk drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Playing the included Song Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Playback of commercial disks (Direct Play) . . . . . . . . . . . . . . . . . . . . . . . 37
Save your recorded song . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Part V Menu
Outline of the procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Setting menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Symptoms which appear to be signs of trouble . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Separately sold option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Demo Performance List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Supplied accessories
Please check the supplied accessories.
Music stand
AC adaptor
SONG BOOK
SONG DISK
5
QQTG0588
Controls and functions
SONG
Record and play back
your performance. (Refer
to page 33.)
AUTO PLAY CHORD
An automatically accompaniment is
added to your playing merely by
specifying a chord. (Refer to page 28.)
BEAT MASTER
A fun way to develop your sense
of rhythm. (Refer to page 16.)
XBC
APC
COUNT
INTRO/ENDING
SYNCHRO
PLAY
DEMO
e
OFF/ON
TEMPO
BEAT MASTER
TRAINING
APC/SONG AUTO PLAY
VOLUME
CHORD
SONG
PLAY
REC
PROGRAM
BEAT MASTER
CHALLENGE
CHORD
FINDER
PARTY PADS / BEAT MASTER
MAIN VOLUME
UP
PARTY PADS
BANK
FIL
RE L IN 1
SET
3.5 inch
Disk Drive
DOWN
1
PARTY PADS/BEAT MASTER
Just press a pad button to add a fun sound effect to
your playing. You can also tap the pad buttons in
time with the beat. (Refer to pages 16, 32.)
6
QQTG0588
2
3
4
ONE TOUCH PLAY
ONE TOUCH PLAY
An appropriate combination of sounds,
etc. for your selected rhythm are
automatically set up for the automatic
accompaniment. (Refer to page 30.)
MUSIC TRAINER
The MUSIC TRAINER function incorporated in this instrument can
be a helpful aid to improving your performance.
Example
BEAT MASTER, to develop your sense of rhythm.
CHORD FINDER, to teach you how to play chords.
MINUS ONE lets you practice the melody part while listening to
the other song parts.
The display shows a visual illustration of the keys and notes
you play.
Display
Displays the status of your
instrument and is also used
for setting the various
functions. (Refer to page 19.)
CONDUCTOR
Specify the performance parts of
the keyboard. (Refer to page 21.)
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
TRANSPOSE
DISK
SONG
TOUCH
SUSTAIN
2
3
REVERB
CHORUS
HARMONY
PROGRAM
MINUS
ONE
MENU
0
1
CONDUCTOR
RIGHT 1
SOLO
PIANO
+
4
5
6
CANCEL –
SOUND
7
8
9
RHYTHM
P
STO E
RT/ PAUS
A
T
/
S AY
PL
DISK
MENU
VARIATION
NDING
INTRO/E
LEFT
RIGHT 2
PANEL MEMORY
SYNCHRO START
DISK SONG
Play back song data
from a floppy disk.
(Refer to page 36.)
Number buttons
Specify the desired sounds
and rhythms etc. by
number.
PANEL MEMORY
Store the current instrument settings for easy
recall later. (Refer to page 31.)
7
QQTG0588
Getting started
1
Connect the AC adaptor (included).
L
OUT
MIDI
IN
FOOT
SW
PHONES/
LINE OUT
AUX IN
DC IN
12V
R
(Rear panel)
• Do not disconnect and connect the AC adaptor when the PLAY button is on, as doing so
may cause the the programmed settings and
recorded contents to be deleted.
2
Affix the music stand as shown.
• The unit is in the standby condition when the AC
adaptor is connected. The primary circuit is always
“live” as long as the AC adaptor is connected to an
electrical outlet.
• When leaving the product unused for a long time,
turn off the PLAY button of the unit and pull the AC
adaptor out of the socket for power saving. (The product consumes a power of 2 W even with the PLAY
button of the unit turned off.)
8
QQTG0588
Playing
1 5
1
4
3 2
• The list of SOUNDS is found near the right
side of the panel.
• The name and number of the selected sound
are shown on the display.
Press the PLAY button to turn it on.
PLAY
OFF/ON
SOUND
GENERAL
2
Press the RIGHT 1 button in the CONDUCTOR.
CONDUCTOR
RIGHT 1
LEFT
RIGHT 2
• The CONDUCTOR status is shown on the display like this:
4
Play the keyboard.
5
Set the MAIN VOLUME to an appropriate level.
MAIN VOLUME
UP
CONDUCTOR
R1
DOWN
• The volume setting is shown on the display.
3
Press the SOUND button, and use the number
buttons to select a sound number (three digits).
MENU
0
1
2
3
Volume setting
VOLUME
+
4
5
6
CANCEL —
SOUND
7
8
9
RHYTHM
VARIATION
• Each graduation represents two degrees of
volume change.
9
QQTG0588
A
PARTY PADS
A
SOLO PIANO
Press one of the PARTY PAD buttons while
you play.
PARTY PADS / BEAT MASTER
1
2
3
4
• Have fun with more sound effects by selecting
another PARTY PAD bank. (Refer to page 32.)
QQTG0588
B
Press the SOLO PIANO button.
SOLO
PIANO
• Each of the buttons plays a fun sound effect.
10
B
• The instrument settings automatically change
to those appropriate for performing with piano
sounds.
• The pitch of this instrument can be adjusted, for example, when playing with other instruments. (Refer
to page 44.)
• For detailed information about selecting sounds,
refer to page 20.
Listen to the demonstration
12
1
Press the DEMO button.
DEMO
e
• The demonstration performance begins.
• The two demo tunes are playing continuously.
2
When you are finished listening to the demonstration performances, press the DEMO button
again.
• Some of the buttons do not work during the demonstration performance.
11
QQTG0588
Add an automatic accompaniment
2
1
4 31
C
F
G7
C
C
F
G7
C
Press the RHYTHM button, and use the number
buttons to select a rhythm number (three digits).
MENU
0
1
2
Use the TRANSPOSE/PROGRAM buttons to
show “1 Finger” on the display.
3
TRANSPOSE TEMPO
GENERAL
+
4
5
6
CANCEL —
SOUND
7
8
9
RHYTHM
3
XBS
APC
COUNT
NTRO / ENDING
SYNCHRO
R1 R2 L C
R1
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
PROGRAM
VOLUME
VARIATION
CONDUCTOR
CHORD
TRANSPOSE
PROGRAM
• The list of RHYTHMS is shown near the left
end of the panel.
• The rhythm number and name are shown on
the display.
• Perform this operation while the PROGRAM indication is flashing on the display.
4
Press the ONE TOUCH PLAY button.
RHYTHM
GENERAL
ONE TOUCH PLAY
2
Press the AUTO PLAY CHORD button.
AUTO PLAY
CHORD
12
QQTG0588
• The sounds, etc. appropriate for the selected
rhythm are automatically set up.
5 6
5
Play the chord with your left hand, and the
melody with your right hand.
6
When you are finished playing the song, press
the START/STOP button.
C3
Chord
Melody
P
STO E
RT/ US
STA AY/PA
PL
• When you play the keyboard with your left
hand, the automatic accompaniment starts
(SYNCHRO START).
• For example, when you press a C key, an
automatic accompaniment in the C major
chord begins to play.
C chord
• The automatic accompaniment stops.
• To end your performance with the automatic
accompaniment, press the AUTO PLAY
CHORD button again.
G7 chord
F chord
• For information about selecting rhythms, refer to
page 25.
• For information about the automatic accompaniment,
refer to page 28.
13
QQTG0588
Play back the included Song Disk
3 4 2
1
Insert the included SONG DISK into the Disk
Drive slot.
3
Press the EXECUTE button.
EXECUTE
• When the data has been loaded to this instrument, “COMPLETE” appears on the display.
4
• Insert the floppy disk correctly oriented with
the label side up. Push it all the way in until it
clicks into place.
2
Use the number buttons to select a song number (3 digits).
0
1
2
Press the PLAY/PAUSE (START/ STOP) button.
P
STO E
RT/ PAUS
A
T
/
S AY
PL
• The selected song is played back.
3
+
4
5
6
CANCEL —
7
8
9
An illustration of a floppy disk appears on the display when data is being loaded from or saved to a
disk. To prevent data loss, do not remove the disk
from the Disk Drive or turn off the power while this
illustration is shown.
Disk illustration
• The song numbers can be found on the separate music score provided.
• The selected song number and abbreviated
song name are shown on the display.
SONG
GENERAL
• For playing back commercial song disks, refer to
page 37.
14
QQTG0588
• For detailed information about playing back the
SONG DISK, refer to page 36.
Record your performance
26
4 73 5
1
Select the desired sounds and rhythm.
2
In the SONG section, press the REC button.
• You can also record a performance that has
an automatic accompaniment.
5
6
Play the song on the keyboard.
7
Press the PLAY/PAUSE (START/ STOP) button.
SONG
PLAY
REC
3
Use the TRANSPOSE/PROGRAM buttons to
select EASY REC.
TRANSPOSE TEMPO
When your performance is finished, press the
REC button, in the SONG section, again.
• The recording can also be ended by pressing
the START/STOP button.
P
STO E
RT/ US
STA AY/PA
PL
SOUND
GENERAL
REC
XBS
APC
COUNT
NTRO / ENDING
SYNCHRO
R1 R2 L C
CONDUCTOR
CHORD
R1
VOLUME
EXECUTE
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
• Your recorded performance is played back.
PROGRAM
TRANSPOSE
PROGRAM
4
Press the EXECUTE button.
EXECUTE
• All the previously recorded contents are
erased.
• For more information about SONG, refer to page 33.
• To play a normal rhythm performance after playing
back your recorded performance, press the PLAY
button in the SONG section to turn it off.
15
QQTG0588
Beat Master
BEAT MASTER is a fun feature that helps you develop your sense of rhythm while you enjoy playing, just like competing with a friend in a game.
Think of yourself as the student, and the instrument your teacher. First, the teacher “claps” out the rhythm, and
then you try to mimic it.
Teacher
Student
Teacher
Student
Your rhythm lesson uses the four pad buttons. As the instrument models the rhythm, the corresponding pad indicators light. Then you try to tap the same pad buttons, with your fingers, using the same timing.
But it’s more than just a rhythm lesson—as you tap the pad buttons, a melody is played in time with your rhythm!
With BEAT MASTER you play a game of musical Questions & Answers with the instrument.
LISTEN
PLAY
Melody
The BEAT MASTER has two levels to choose from: TRAINING (beginner) and CHALLENGE (advanced).
To learn how to use the BEAT MASTER, begin with the TRAINING song “1:Warm Up”. The structure of this song is
shown below, so take a minute to look it over before starting the lesson (following).
Number: Pad number
Note: Beat timing
PHRASE 1
PHRASE 2
INTRO
PLAY
PLAY
LISTEN
PHRASE 3
LISTEN
PHRASE 4
PLAY
LISTEN
16
QQTG0588
PLAY
LISTEN
ENDING
Evaluation of
your
performance
4 5 12 3
1
Press the BEAT MASTER TRAINING or CHALLENGE button.
3
Press the START/STOP button.
BEAT MASTER
TRAINING
BEAT MASTER
CHALLENGE
P
STO E
RT/ US
STA AY/PA
PL
• Select TRAINING if you are a beginner, or
CHALLENGE to improve your skill.
• A BGM is heard and the pad indicators light
up.
2
• The tune begins to play.
• Listen to the intro.
4
Use the TRANSPOSE/PROGRAM buttons to
select a song number.
TRANSPOSE TEMPO
The Question phrase is played. Watch the
timing of the pad indicators and try to remember it.
SONG
GENERAL
XBS
APC
COUNT
NTRO / ENDING
SYNCHRO
R1 R2 L C
BEAT MASTER
CONDUCTOR
CHORD
R1
VOLUME
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
1
2
3
4
• During this time, the display looks like this:
PROGRAM
BEAT MASTER
TRANSPOSE
PROGRAM
• Select a number from 1 to 4 (TRAINING)/C1
to C7 (CHALLENGE). The higher the number,
the more difficult the tune.
• Use the CHALLENGE button to select number
C8 to play back a song loaded from the disk.
If data has not been loaded from a disk,
“EMPTY” is shown on the display.
LISTEN
5
Mimic the Question phrase by tapping the same
pad buttons in the same order and timing.
1
2
3
4
• An evaluation of each phrase you reproduce
is shown as “Bravo!”, “Good”,“Poor.”
17
QQTG0588
6 8
• During this time, the display looks like this:
BEAT MASTER
7
Playback of BEAT MASTER
songs on the disk
• BEAT MASTER songs are recorded on the included
disk.
6
The next Question phrase is then played. Continue in the same manner.
7
After the ending plays, you will see an evaluation of your performance on the display.
• Your total performance is assessed as
“Master!”, “Good”, “Fair” or “Practice.”
• To try the same lesson again, press the
START/STOP button. Or you can try an
another song.
(1) Insert the disk with the BEAT MASTER song data
into the Disk Drive.
(2) Press either BEAT MASTER button.
(3) Press the DISK SONG button.
8
To turn off the BEAT MASTER, press the same
BEAT MASTER button that you selected in
step 1.
• If the tempo is too fast, use the TEMPO buttons
below the display to adjust it.
18
QQTG0588
(4) Use the TRANSPOSE/PROGRAM button to
specify the file number to load from the disk.
• Note that the current SONG data is deleted when
the BEAT MASTER data has been loaded.
(5) Press the EXECUTE button.
• When the data has been loaded to this instrument,
“COMPLETE” appears on the display.
(6) Press the START/STOP button.
• Note that in some songs the Question and Answer
phrases are one measure long and in others they
are two measures long. Enjoy the challenge!
• There is an INTERLUDE (bridge) section (when
there are no Question and Answers) in the middle of
the songs so you can catch your breath! (Some
songs have no INTERLUDE section.)
About the display
The display shows the status of this instrument, the played keys, etc., and is also used for setting the various functions.
Normal display
Sound number
Sound name
Tempo
TRANSPOSE TEMPO
Chord name
SOUND
GENERAL
R1 R2 L C
XBS
APC
COUNT
INTRO / ENDING
SYNCHRO
CONDUCTOR
CHORD
m
R1
7
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
CONDUCTOR status
VOLUME
Volume
▼
•A
▲
Performance data
or
mark next to the function name to the
left or right of the display indicates that the corresponding button is ON. (In the example above, the XBS
function is On.)
• The readability (LCD CONTRAST) of the display can
be adjusted. (Refer to pages 41 and 44.)
EXECUTE
When it is necessary to confirm that you wish to execute
a function, press the EXECUTE button.
• If necessary, the EXECUTE indication on the display
will flash.
TRANSPOSE TEMPO
Setting display example
GENERAL
Example: PART VOLUME
TRANSPOSE TEMPO
XBS
APC
COUNT
INTRO / ENDING
SYNCHRO
MENU
GENERAL
R1 R2 L C
R1 R2 L C
CONDUCTOR
CHORD
R1
VOLUME
PROGRAM
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
PROGRAM
TEMPO
TRANSPOSE
PROGRAM
PROGRAM
CONDUCTOR
R1
VOLUME
XBS
APC
COUNT
INTRO / ENDING
SYNCHRO
CHORD
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
EXECUTE
• At this time if you wish to cancel the procedure instead
of executing it, press the button that you to select the
function (MENU button or DISK MENU button, etc.).
• The
display illustrations used throughout this manual
are for purposes of explanation and may differ from the
actual display you see when you are using your instrument.
EXECUTE
The
TRANSPOSE/PROGRAM
buttons
and
TEMPO/PROGRAM buttons below the display, as well
as the number buttons and + and – buttons, are used to
select the various functions and specify values, etc.
• When the TRANSPOSE/PROGRAM buttons or
TEMPO/PROGRAM buttons are used to set a function,
the corresponding PROGRAM indication flashes.
• The number buttons are convenient for entering numbers directly, and the TRANSPOSE/ PROGRAM buttons or the + and – number buttons are convenient for
selecting the modes, etc. while viewing the display.
19
QQTG0588
Part I Sounds and effects
There are 250 different sounds permanently stored in this instrument to enhance your playing enjoyment.
Sound
Select the sounds for the three parts you can play on the keyboard.
1. In the CONDUCTOR,
select a part (RIGHT 1, RIGHT
2 or LEFT).
CONDUCTOR
RIGHT 1
LEFT
RIGHT 2
CONDUCTOR
R1
2. Press the SOUND button. Use the number buttons to
select a sound number (three digits).
0
1
2
3
+
4
5
6
CANCEL —
SOUND
7
8
9
RHYTHM
VARIATION
• The list of SOUNDS is printed on the upper right portion
of the panel.
• The selected sound number and sound name are
shown on the display.
SOUND
GENERAL
• Enter three digits to specify the sound. For example,
for sound number 003, press 0, 0, 3. For sound number
030, press 0, 3, 0.
20
QQTG0588
the keyboard.
• Non-pitched (percussion) sounds are also available.
• For DRUM KITS sounds, percussion instrument
sounds corresponding to the illustration are played
with the keyboard keys.
• You can use the CONDUCTOR to assign different
parts to the keyboard.
About the number buttons
• The CONDUCTOR indication on the display shows the
selected part(s).
MENU
3. Play
The number buttons are convenient for selecting functions with assigned numbers, such as sounds and
rhythms, MENU functions, disk songs, etc.
• The + and – buttons can be used to increase or
decrease the number. When a button is pressed and
held, the numbers change quickly.
• If you wish to cancel the number you are in the midst
of entering, press the + and – buttons at the same
time. If you pause in the midst of entering a number,
the entry may automatically be canceled after a few
seconds.
Part I
Sound and effects
Conductor
The CONDUCTOR buttons are used to assign sounds to the keyboard in many different ways. For example, you can
assign two sounds to the entire keyboard so that playing one key will produce two sounds. You can even split the
keyboard into right and left sections (SPLIT), and assign a different sound to each section.
CONDUCTOR settings
How sounds are assigned to the keyboard
All keys produce the RIGHT 1 sound.
R1
RIGHT 1
All keys produce the RIGHT 2 sound.
RIGHT 2
R2
All keys produce both the RIGHT 1 sound and the RIGHT 2 sound.
R1
R2
RIGHT 1 + RIGHT 2
The left keys produce the LEFT sound and the right keys produce the RIGHT
1 sound and the RIGHT 2 sound.
L
R1
R2
LEFT
RIGHT 1 + RIGHT 2
The left keys produce the LEFT sound and the right keys produce the RIGHT
1 sound.
L
R1
LEFT
RIGHT 1
The left keys produce the LEFT sound and the right keys produce the RIGHT
2 sound.
L
•
•
•
R2
LEFT
RIGHT 2
The volume of each part can be adjusted independently. (Refer to page 42 .)
When the keyboard is divided into left and right parts, the initialized split point is at C3 (the third C from the bottom,
or left end of the keyboard), but you can change the location of the split point. (Refer to page 44.)
The following conditions are in effect when the AUTO PLAY CHORD is used.
— 1 Finger mode: The LEFT part does not sound.
— 1 Finger, Fingered mode: You cannot assign the RIGHT part sound to the whole keyboard.
— Pianist mode: The keyboard cannot be split.
21
QQTG0588
Part I
Sound and effects
Solo Piano
Press the SOLO PIANO button for a solo piano performance without having to make complicated settings.
⇒Press the SOLO
• The appropriate settings for a piano performance is
automatically set.
• Note that the settings that were in effect immediately
before this button is pressed will be lost.
PIANO button.
SOLO
PIANO
Effects
Add various effects to give expression to the sounds.
CHORUS
SUSTAIN
This effect gives the sound richness and breadth.
SUSTAIN is the gradual fading out of musical tones after
the key is released.
1. Use
the CONDUCTOR buttons to select the part to
which this effect will be applied.
2. Press the CHORUS
1. Use
the CONDUCTOR buttons to select the part to
which this effect will be applied.
button to turn it on.
2. Press the SUSTAIN
button to turn it on.
CHORUS
SUSTAIN
▼
• The
mark next to the CHORUS indication on the
right side of the display indicates that this effect is on.
• The display looks similar to the following.
TRANSPOSE TEMPO
GENERAL
XBS
APC
COUNT
INTRO / ENDING
SYNCHRO
R1 R2 L C
CHORD
CONDUCTOR
R1
VOLUME
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
PROGRAM
• If necessary, use the TEMPO/PROGRAM buttons to
adjust the depth of the effect (0–99).
• Perform this operation while the PROGRAM indication
is flashing on the display. After a few seconds, the
display returns to the previous display.
• This effect can be set to on or off for each part.
22
QQTG0588
▼
• The
mark next to the SUSTAIN indication on the
right side of the display indicates that this effect is on.
• This effect can be set to on or off for each part.
Part I
Sound and effects
REVERB
TOUCH
REVERB applies a reverberation effect to the sound.
You can add dynamics to the sound by varying the keyboard touch.
• The initialized setting is ON.
⇒Press the REVERB
button to turn it on.
⇒Press the TOUCH
REVERB
button to turn it on.
TOUCH
▼
• The
mark next to the REVERB indication on the
right side of the display indicates that this effect is on.
• The display looks similar to the following.
▼
• The
mark next to the TOUCH indication on the
right side of the display indicates that this effect is on.
• The display looks similar to the following.
TRANSPOSE TEMPO
GENERAL
TRANSPOSE TEMPO
XBS
APC
COUNT
INTRO / ENDING
SYNCHRO
R1 R2 L C
CONDUCTOR
CHORD
R1
VOLUME
PROGRAM
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
GENERAL
XBS
APC
COUNT
INTRO / ENDING
SYNCHRO
PROGRAM
• If necessary, use the TEMPO/PROGRAM buttons to
adjust the depth of the effect (0–99), and the TRANSPOSE/PROGRAM buttons to select the type of reverb
(Room1, 2, Plate 1, 2, Concert 1, 2).
• Perform this operation while the PROGRAM indication
is flashing on the display. The display returns to the
previous display a few seconds after you have
changed the setting.
R1 R2 L C
CONDUCTOR
CHORD
R1
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
PROGRAM
VOLUME
• If necessary, the TRANSPOSE/PROGRAM buttons
can be used to to select the mode (Heavy, Normal,
Light).
• Perform this operation while the PROGRAM indication
is flashing on the display. After a few seconds, the
display returns to the previous display.
Transpose
The TRANSPOSE buttons are used to change the key of the entire instrument in semitone steps across an entire
octave.
Suppose you learn to play a song—in the key of C, for example—and decide you want to sing it, only to find that it’s
either too high or too low for your voice. Your choice is to either learn the song all over again in a different key, or to
use the TRANSPOSE feature.
⇒Adjust the key with the TRANSPOSE ∧ and ∨ buttons.
TRANSPOSE TEMPO
SOUND
Transpose illustration
GENERAL
XBS
APC
COUNT
INTRO / ENDING
SYNCHRO
CONDUCTOR
R1 R2 L C
R1
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
VOLUME
TRANSPOSE
Key
PROGRAM
23
QQTG0588
Part I
Sound and effects
• Each press of the ∧ button raises the key in semitone
steps, and each press of the ∨
# button lowers the key
in semitone steps (G – C – F ).
• If the two buttons are pressed at the same time, the
key returns to C.
• When the TRANSPOSE function is active, the transpose illustration is shown on the display.
• When PROGRAM is shown on the display above the
buttons, these buttons are used for various settings
and cannot be used for TRANSPOSE. To access the
TRANSPOSE function in this case, first exit the setting
mode.
<Example: transposed to D>
Played keys: C major
Notes that sound: D major
Harmony
This function automatically adds harmony to the single-note melody you play in the right part, based on the chord you
specify in the left part.
1. Split
the keyboard into right and left sections. (Refer
to page 21.)
2. Press the HARMONY
button to turn it on.
HARMONY
▼
• The
mark next to the HARMONY indication on the
right side of the display indicates that this effect is on.
• The display looks similar to the following.
TRANSPOSE TEMPO
GENERAL
R1 R2 L C
XBS
APC
COUNT
INTRO / ENDING
SYNCHRO
CONDUCTOR
CHORD
R1
VOLUME
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
PROGRAM
• If necessary, the TRANSPOSE/PROGRAM buttons
can be used to select the type of harmony.
• If the “Octave”, “Hard Rock” or “Fanfare” type is
selected, HARMONY is added even when you do not
specify the chords.
• Perform this operation while the PROGRAM indication
is flashing on the display. After a few seconds, the
display returns to the previous display.
24
QQTG0588
Part II Playing the rhythm
There are 100 rhythms stored in the memory of this instrument. An additional VARIATION patterns for each rhythm is
available.
Rhythm
1. Press
the RHYTHM button. Use the number buttons
to select a rhythm number (three digits).
MENU
0
1
2
3
+
4
5
6
VARIATION
When you press the VARIATION button, the rhythm
changes to the variation pattern for the selected rhythm.
RHYTHM
RHYTHM
VARIATION
VARIATION
CANCEL —
SOUND
7
8
9
• “VARI” is shown on the display when the variation
pattern is selected.
• The list of RHYTHMS is shown near the left end of
the panel.
• The rhythm number and name are shown on the display.
RHYTHM
GENERAL
RHYTHM VARI
GENERAL
• During a rhythm performance, you can switch between
the normal pattern and the variation pattern by
pressing the VARIATION button.
• There is no VARIATION pattern for the METRONOME
rhythm.
• Enter three digits to specify the rhythm. For example,
for rhythm number 003, press 0, 0, 3. For rhythm
number 030, press 0, 3, 0.
• The + and – buttons can be used to increase or
decrease the number. When a button is pressed and
held, the numbers change quickly.
• To cancel a number you are entering, press the + and
– buttons at the same time (CANCEL).
2. Press the START/STOP
button.
P
STO E
RT/ US
STA AY/PA
PL
• The selected rhythm pattern begins to play.
• You can stop the rhythm by pressing the START/STOP
button again to turn it off.
• Since there is no DRUM part for the 091 CLASSIC
BALLAD rhythm, the pattern does not sound unless
the AUTO PLAY CHORD is used.
25
QQTG0588
Part II
Playing the rhythm
Synchro Start
With the synchronized start feature, the rhythm pattern begins to play when you press a key on the keyboard.
1. Select
3. Play
a rhythm.
2. Press the SYNCHRO
START button to turn it on.
a key to the left of the keyboard split point.
• The rhythm pattern begins to play.
• You can use the synchronized start feature even when
the keyboard is not divided into left and right sections.
To start the rhythm, press a key to the left of the
specified split point (C3 in the initialized state).
SYNCHRO START
▲
• The
mark next to the SYNCHRO indication on the
left side of the display indicates that this function is
on.
Tempo
The tempo of the rhythm pattern is adjusted with the TEMPO buttons.
⇒Press the right
button for a faster tempo, and the left
button for a slower tempo (q=40 – 300).
Beat indication
TRANSPOSE TEMPO
Tempo indication
RHYTHM
GENERAL
XBS
APC
COUNT
INTRO / ENDING
SYNCHRO
R1 R2 L C
CHORD
R1
VOLUME
TEMPO
PROGRAM
• Press both buttons at the same time to reset the tempo
to the standard q=120.
• The tempo is shown on the display.
• The beat is indicated above the displayed tempo.
• When “PROGRAM” appears on the display above the
buttons, these buttons are used for various settings
and cannot be used to adjust the TEMPO. To adjust
the TEMPO in this case, you must first exit the setting
mode.
26
QQTG0588
CONDUCTOR
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
Part II
Playing the rhythm
Rhythm performance
Intro, fill-in and ending patterns are available for each rhythm.
INTRO
FILL IN
Begin the rhythm performance with an intro pattern.
You can insert a fill-in pattern any time during the rhythm
performance. Choose from two different fill-in patterns.
1. Press the INTRO/ENDING
button to turn it on.
1. Select
a rhythm and press the START/STOP button.
2. Press the FILL
▲
• The
mark next to the INTRO/ENDING indication
on the left side of the display indicates that this function
is on.
2. Press the START/STOP
IN 1 or 2 button.
FIL
RE L IN 1
SET
button to start the rhythm.
P
STO E
RT/ PAUS
A
T
/
S AY
PL
• A fill-in pattern is heard immediately for the remainder
of the measure.
• When a FILL IN button is pressed on the last beat of
the measure, the fill-in pattern continues to the end of
the following measure.
• An intro pattern is played, after which the normal
rhythm pattern begins.
ENDING
COUNT INTRO
1. Select
You can begin the rhythm performance with a onemeasure count.
2. Press the INTRO/ENDING
1. Press
Finish the rhythm performance with an ending pattern.
a rhythm and press the START/STOP button.
button to turn it on.
the FILL IN 2/COUNT INTRO button to turn it
on.
▲
• The
mark next to the COUNT indication on the left
side of the display indicates that this function is on.
2. Press the START/STOP button to start the rhythm.
• A one-measure count is played, after which the normal
rhythm pattern begins.
• An ending pattern is produced, and then the rhythm
performance stops.
• If you accidentally press an INTRO/ENDING button in
the middle of the tune, you can press the FILL IN 1
or 2 button. The ending pattern stops, and a fill-in
pattern is produced, after which the normal rhythm
performance continues.
27
QQTG0588
Part II
Playing the rhythm
Auto Play Chord
Simply by playing a chord on the keyboard, the AUTO PLAY CHORD function automatically plays an accompaniment
pattern which matches perfectly the selected rhythm. With a real accompaniment as a background, you can concentrate
on playing the melody.
⇒Choose from
three ways of playing chords.
One Finger (1 Finger) mode
In the One Finger mode, a major chord can be played
just by pressing the key for its root note.
Example: C chord
Minor, seventh and minor seventh chords are also easily
produced.
minor chord
seventh chord
minor seventh chord
Play the root note plus a black key
to the left of it.
Play the root note plus a white key
to the left of it.
Play the root note plus a black key
and a white key to the left of it.
Example: Cm
Example: C7
Example: Cm7
Fingered mode
In the Fingered mode, you specify the chord by playing
all the notes in the chord.
• Play at least three notes to specify the chord.
• If the CHORD FINDER procedure is used, you can
see the types of chords that can be specified and the
keys you press to play them. (Refer to page 30.)
28
QQTG0588
Pianist mode
In the Pianist mode, the entire keyboard can be used to
specify chords (Fingered mode) for the automatic accompaniment; a RIGHT part is assigned to all the keys, and
the keyboard does not split.
• If the CHORD FINDER procedure is used, you can
see the types of chords that can be specified and the
keys you press to play them. (Refer to page 30.)
• When specifying chords, if you press a key a perfect
5th or more below the lowest note of the chord, the
BASS part becomes a pattern based on that note.
Part II
Playing the rhythm
How to use the AUTO PLAY CHORD
1. Select
the desired rhythm and sound(s), and set the
tempo.
2. Press the AUTO PLAY
CHORD button to turn it on.
AUTO PLAY
CHORD
▲
• The
mark next to the APC indication on the left
side of the display indicates that this function is on.
• The display looks similar to the following.
• The AUTO PLAY CHORD is comprised of five parts
(ACCOMP [ACP] 1, 2 and 3, BASS and DRUMS), the
volume balance for each of which can be adjusted with
the PART VOLUME function. (Refer to pages 41 and
42.)
• In the 1 Finger or Fingered mode, if you specify a
chord without starting the rhythm, the root bass note
(R.BS) and the chord notes (CHRD) will sound. The
volumes of these parts can be adjusted with the PART
VOLUME function. (Refer to pages 41 and 42.)
• There is no automatic accompaniment pattern for the
METRONOME rhythm.
GENERAL
3. Use
the TRANSPOSE/PROGRAM buttons to select
the chord mode (1 Finger, Fingered, Pianist).
APC/SONG VOLUME
You can lower the volume of the automatic accompaniment to balance it with the volume of the sounds you
play.
• This setting also functions for the song playback
volume.
1. Press the APC/SONG
VOLUME button to turn it on.
APC/SONG
VOLUME
TRANSPOSE
PROGRAM
• The display looks similar to the following.
• Perform this operation while the PROGRAM indication
is flashing on the display. After a few seconds, the
display returns to the previous display.
4. Start
GENERAL
the rhythm.
2. Use
5. Specify a
•
•
•
•
•
•
chord.
If the 1 Finger or Fingered mode was selected, specify
the chord on the keyboard section to the left of the
split point (C3).
The split point can be changed. (Refer to pages 41
and 44.)
An accompaniment pattern in the specified chord is
automatically played.
The specified chord is shown in the CHORD section
on the display.
When you use the fill-in, intro and ending patterns, the
automatic accompaniment is also used in these patterns.
Once a chord is specified, it continues to play even
when the keys are released, until you specify another
chord.
the TEMPO/PROGRAM buttons to adjust the
volume (0 to 10).
• A setting of 10 is the normal volume.
• Perform this operation while the PROGRAM indication
is flashing on the display. After a few seconds, the
display returns to the previous display.
• After the volume setting is changed, the volumes of
all the parts other than the one you are playing (for
example, BEAT MASTER, etc.) are also changed.
6. To
stop the automatic accompaniment, press the
START/STOP button.
29
QQTG0588
Part II
Playing the rhythm
CHORD FINDER
This feature shows you the keys to press for a specific
chord. You may find this convenient when you don’t know
how to play certain chords indicated in the sheet music.
1. Select the chord mode. (Refer to page 29.)
• Select Fingered or Pianist.
2. Press the CHORD
3. Use
the TEMPO/PROGRAM buttons to specify the
chord’s root note, and the TRANSPOSE/PROGRAM
buttons to specify the chord type.
• On the display, the keys you press to play the specified
chord are indicated on the keyboard illustration.
• If you press the EXECUTE button, the selected chord
will sound.
FINDER button to turn it on.
4. Press
the CHORD FINDER button again to turn this
function off.
CHORD
FINDER
• The display looks similar to the following.
TRANSPOSE TEMPO
GENERAL
R1 R2 L C
XBS
APC
COUNT
INTRO / ENDING
SYNCHRO
CHORD FINDER
R1
M7
VOLUME
PROGRAM
CONDUCTOR
TOUCH
SUSTA
REVER
CHORU
HARMO
PROGRAM
One Touch Play
ONE TOUCH PLAY automatically sets the sounds, etc. that match your chosen rhythm. Just by pressing a button you
can immediately perform using the automatic accompaniment.
• Note that when the automatic settings are executed, the previous settings are canceled.
1. With
the rhythm stopped, select a rhythm pattern.
2. Press the ONE
TOUCH PLAY button.
ONE TOUCH PLAY
• Sounds and effects, tempo, etc. that match your
selected rhythm are automatically set, and the AUTO
PLAY CHORD and SYNCHRO START are turned on.
3. Play the keyboard.
• When you specify a chord, the automatic rhythm
begins to play immediately.
30
QQTG0588
Part II
Playing the rhythm
Panel Memory
This function lets you store up to ten combinations of panel settings for easy recall at any time.
How to store the panel settings
The settings are stored in buttons 0 to 9.
1. Set
up the desired panel settings (sounds, rhythms,
etc.).
2. While
pressing the PANEL MEMORY button, press
one of the number buttons (0 to 9).
REVERB
0
1
2
CHORUS
HARMONY
CONDUCTOR
3
RIGHT 1
+
4
5
6
CANCEL —
7
8
9
LEFT
RIGHT 2
PANEL MEMORY
• “COMPLETE” appears on the display, and the current
panel settings will be stored in the selected number.
Recall the panel setup
1. Press the PANEL
MEMORY button.
2. Press the desired number button.
• The panel setup changes to the one stored in the
specified memory.
• When you press the PANEL MEMORY button, the P.
MEMORY indication appears in the upper part of the
display for a few seconds. Press the desired number
button while this indication is shown.
• You can then change the sound settings, etc.; however, the memory itself remains unchanged until you
store it again.
31
QQTG0588
Part II
Playing the rhythm
Party Pads
You can insert fun sound-effects just by pressing the pad buttons.
Pad performance
Select a bank
You can use the four pad buttons to produce four different
sound effects.
Four banks have been prepared so that you can play
sound effects that match the selected theme.
PARTY PADS / BEAT MASTER
1
2
3
⇒Press
the PARTY PADS BANK button to select the
desired bank on the display.
4
• Playback will stop if you press the same pad button
again.
PARTY PADS
BANK
• The display looks similar to the following.
MENU
GENERAL
• Each time the button is pressed, the bank number
changes in order from 1 to 4.
• The list of PARTY PADS BANKS is found on the panel
above the pad buttons.
• After a few seconds, the display returns to the previous
display.
• Each pad produces a phrase that matches the selected
bank.
32
QQTG0588
Part III Recording
Use the SONG function to record your performance.
Record your performance
Record your performance just as you played it on the keyboard.
are going to record.
• In the CONDUCTOR, turn on the parts that you want
to record.
• A flashing ● mark in both the REC line and the PLAY
line means that you have selected a part that has
already been recorded. If you record this part again,
the previous contents will be overwritten (deleted).
2. In the
5. Press the START/STOP
1. Set the sounds, effects, rhythms, etc. for the parts you
SONG section, press the REC button.
button.
SONG
PLAY
REC
P
STO E
RT/ US
STA AY/PA
PL
• The display looks similar to the following.
SOUND
GENERAL
3. Use
the TRANSPOSE/PROGRAM buttons to select
the recording mode.
1 EASY REC: Your performance, including the automatic
accompaniment, is recorded.
• All the previously recorded contents are erased.
2 MELODY: Your performance of those parts selected in
the CONDUCTOR is recorded.
3 APC REAL: The automatic accompaniment (specified
chords) only is recorded.
• Be sure to turn on the AUTO PLAY CHORD button
before beginning recording. Also note that recording
in this mode should be completed before starting to
record in the MELODY mode.
4 APC STEP: The chord progression is recorded one
chord at a time. (Refer to page 34.)
4. Press the EXECUTE button.
• On the display, a flashing ● mark in the REC line
indicates the part that you selected to record.
• The recording begins. Play the keyboard to record your
performance.
• If you record a performance without the rhythm, begin
your performance without pressing the START/STOP
button. Recording begins immediately when you play
the keyboard.
• The measure number is shown on the display.
TRANSPOSE TEMPO
measure number
REC
XBS
R1 R2 L C
6. When
you have finished recording, press the
START/STOP button.
• On the display, a ● mark in the PLAY line indicates
the part that you recorded.
TRANSPOSE TEMPO
PLAY indication
PLAY
XBS
R1 R2 L C
TRANSPOSE TEMPO
• If you press the START/STOP button at this time, your
recorded performance will be played back.
REC indication
REC
XBS
R1 R2 L C
You can record your performance using four tracks—
RIGHT 1 (R1), RIGHT 2 (R2), LEFT (L) and CHORD
(C).
33
QQTG0588
Part III
Recording
Multiplex recording
Multiplex recording of the MELODY mode and APC
REAL mode is possible by repeating steps 1 to 6.
• In multiplex recording, recording cannot be started by
playing the keyboard. You must press the
START/STOP button to begin recording.
Playing back your recorded song
1. In the SONG section, press the PLAY button.
2. Press the
PLAY/PAUSE (START/STOP) button.
• Your recorded performance is played back.
• For information about the function of each button
during playback, refer to page 37.
• If you wish to play back the rhythm, turn the PLAY
button off.
SONG
PLAY
REC
• This step is not necessary if the PLAY indication already appears on the display.
Store a chord progression
Store the chord progression for the AUTO PLAY CHORD in the track for the CHORD part. Then, when the AUTO
PLAY CHORD is used during playback, even if you do not specify the chords with your left hand, the chords change
automatically.
• The chord length is specified with the CHORD STEP RECORD keys on the keyboard.
&
e
q
q.
h
h.
w
▲
DELETE
Move back one step.
▼
Correction keys
Move forward one step.
Repeat key
Press to end the chord-storing procedure and
to specify automatic repeat playback of the
stored progression.
End key
Note value keys
w
Whole note
h.
Dotted half-note
h
Half-note
q.
Dotted quarter-note
q
Quarter-note
e
Eighth-note
Press after the whole chord progression has
been stored.
DELETE key
DELETE Press to erase data.
• To erase all the data from the current track, while
pressing the DELETE key, press the End key
(
).
Reset key
&
•
Press to begin storing from the beginning.
Note that executing this procedure will delete the recorded APC REAL data.
34
QQTG0588
Part III
• To make corrections to the recorded chord progression, use the
and
keys or TRANSPOSE/PROGRAM button to display the chord you wish to modify.
Next, press the DELETE key to erase the stored chord
and then store a new chord. When you use the DELETE key to erase a chord, the recorded contents that
follow are shifted forward by the note value of the
deleted chord.
• To go to the end of the chord progression, while
pressing the Reset key ( & ), press the
key.
• The CHORD FINDER feature, which shows you how
to finger a specified chord, is available. (Refer to page
30.)
2. Use the TRANSPOSE/PROGRAM buttons to select 4:
APC STEP.
SOUND
▼
GENERAL
▼
SONG section, press the REC button .
▲
1. In the
Recording
3. Press the EXECUTE
button.
4. While
playing a chord with your left hand, press the
desired note value key with your right hand to specify
the chord length. Repeat this step to store all the
chords.
• When a note value key is pressed, a “beep” tone
indicates that the chord has been stored.
• Store a rest by pressing a note value key without
specifying a chord.
• The display during chord recording:
Measure number
Beat number
5. At
the end of the chord progression, press the End
key (
).
• The instrument exits the recording mode.
• If you wish automatic repeat playback of the chord
progression, press the Repeat key (
) instead of
the End key (
).
• To store chords using the 1 Finger mode, select this
mode before beginning the recording procedure.
(Refer to page 29.)
TRANSPOSE TEMPO
GENERAL
REC
XBS
APC
COUNT
RO / ENDING
SYNCHRO
R1 R2 L C
CONDUCTOR
CHORD
m
R1
7
TOUCH
SUSTAIN
REVERB
CHORUS
HARMONY
PROGRAM
VOLUME
Chord name
• The beat number is indicated in increments of e. For
example, “B3.5” indicates 3-1/2 beats.
• You can press the INTRO [INTR], FILL IN [FIL 1/2] or
ENDING [ENDG] button to store the corresponding
pattern. (An INTRO or COUNT INTRO can be stored
only at the beginning.) When storing a pattern or
searching for a pattern, the abbreviated name is shown
within square brackets [ ].
Note
• When the recording procedure is performed, the previously recorded contents and song data loaded from a song
disk as well as BEAT MASTER data are erased.
• You cannot record more than 999 measures.
• The total recording capacity of all tracks combined is approximately 4500 notes.
• When “MEM FULL” appears on the display, no more data can be stored and recording ends automatically.
• You cannot begin recording from the middle of a song.
• The playback volume can be adjusted. (Refer to page 29.)
• Specific tracks can be muted so they are not played back. (Refer to pages 41 and 43.)
• If you wish to keep your recorded performance, save it to a floppy disk. (Refer to page 38.)
• If you record in the MELODY mode on top of the chord track (C) in which the ending pattern is stored, recording
will automatically end at that point.
35
QQTG0588
Part IV Disk Drive
A 3.5 inch disk drive is built into this instrument, so you can play back the included disk and commercially sold song
disks, as well as store your recorded performances on floppy disks and play them back.
Parts of the floppy disk drive
Disk slot
• An illustration of a floppy disk appears on the display
when data is being loaded from or saved to a disk. To
prevent data loss, do not remove the disk from the
Disk Drive or turn off the power while this illustration
is shown.
Disk illustration
Lights when the power is on
Eject button
Press to remove the disk
from the Disk Drive.
Playing the included Song Disk
Data for 100 songs is stored on the included SONG DISK for you to enjoy. These songs correspond to the separate
music score provided.
• Note that recorded song data in the instrument memory will be deleted when a song on the disk is played back.
1. Insert
the SONG DISK into the Disk Drive.
• Insert the floppy disk correctly oriented with the label
side up. Push it all the way in until it clicks into place.
• The display changes to show the song name. If it does
not change, press the DISK SONG button.
DISK
SONG
2. Use
the number buttons to select a song number (3
digits).
0
1
2
3
+
4
5
6
CANCEL —
7
8
9
• The song numbers can be found on the separate music
score provided.
• The selected song number and abbreviated song name
are shown on the display.
SONG
GENERAL
• The TRANSPOSE/PROGRAM buttons and the + and
– buttons can also be used to select the song.
• If 000 MEDLEY is selected, the entire contents of the
disk are played back repeatedly.
36
QQTG0588
Part IV
3. Press the EXECUTE
Disk Drive
button.
Function of each button during playback
EXECUTE
• The selected song data is loaded into this instrument’s
memory. “COMPLETE” appears on the display.
• This step is not necessary if MEDLEY was selected.
4. Press the PLAY/PAUSE
(START/STOP) button.
Return to top
(during stop)
P
STO E
RT/ US
STA AY/PA
PL
• Playback begins.
• Playback ends at the end of the song. Use the same
procedure to play other songs.
• If the APC/SONG VOLUME button is pressed, the
playback volume can be adjusted. This is useful when
playing the keyboard along with a song on the disk.
(Refer to page 29.)
Fast forward
(during stop; by
measure)
Stop (pause)
• If the PLAY/PAUSE button is pressed during MEDLEY
playback, the MEDLEY is canceled.
• If the SONG TRACK MUTE function is used, playback
of a desired track is muted, allowing you to perform
that part on the keyboard. (Refer to pages 41 and 43.)
• When the MINUS ONE button is pressed, the melody
(RIGHT 1) part is muted so that you can try playing it
yourself. Press the MINUS ONE button again to cancel
the mute.
Playback of commercial disks
(Direct Play)
You can enjoy immediate playback of disks with the GM (General MIDI) mark as well as SMF (Standard MIDI File;
FORMAT 0/1) song disks.
• Note that recorded song data in the instrument memory will be deleted when a song on the disk is played back.
• During the direct play, MIDI does not function.
1. Insert the song data disk into the Disk Drive.
• The display changes to show the song name. If it does
not change, press the DISK SONG button.
2. Use the TRANSPOSE/PROGRAM buttons or the number buttons to select a song.
• The song number and song name (file name) are
shown on the display.
• When using the number buttons, be sure enter 3 digits
for the song number.
• If 000 MEDLEY is selected, the entire contents of the
disk are played back repeatedly.
• If both SONG data and SMF (Standard MIDI File) data
are stored on the same disk, following the TYPE indication, the display changes to the select display. In
this case, use the TRANSPOSE/PROGRAM buttons
to select 02 SMF. Press the EXECUTE button.
3. Press the PLAY/PAUSE
(START/STOP) button.
• Playback begins.
• The RESET/FORWARD button can also be used
during playback.
• The APC/SONG VOLUME button can also be used.
(Refer to page 29.)
37
QQTG0588
Part IV
Disk Drive
MINUS ONE
You can mute a specified part of the song data. When
you wish to play the keyboard in time with the song, you
can mute one part, and the other parts become your background when the song data is played back.
1. Press the MINUS
2. Use
ONE button.
the TRANSPOSE/PROGRAM buttons to specify
the part number (it flashes) of the part you wish to
mute.
• After a few seconds, the display returns to the previous
display.
• To cancel the mute function, press the MINUS ONE
button again.
MINUS
ONE
• The display looks similar to the following.
TRANSPOSE TEMPO
GENERAL
1
R1 R2 L C
XBS
APC
COUNT
INTRO / ENDING
SYNCHRO
2
3
4
5
6
7
8
9
CHORD
DIRECT
PLAY
10
11
12
13
14
15
16
MINUS CONDUCTOR
ONE
R1
TOU
SUS
REV
CHO
HAR
PROGRAM
VOLUME
Save your recorded song
The recorded contents of this instrument’s SONG memory can be stored on a floppy disk. Only one song can be
recorded in this instrument’s memory, but several songs can be saved in one floppy disk.
SONG SAVE
The SONG recorded contents, PANEL MEMORY stored
settings, and the current panel settings, etc. are all stored
when you save a song to a disk.
• If you attempt to save a song to an unformatted disk,
“UNFORMAT” is shown on the display. Follow the
DISK FORMAT procedure to format the disk. (Refer
to page 40.)
1. Record
4. Press the EXECUTE
button.
EXECUTE
• The display looks similar to the following.
your performance with the SONG function.
DISK
GENERAL
2. Press the DISK
MENU button.
5. If necessary, assign a song name (up to 6 characters).
• Use the TEMPO/PROGRAM buttons to specify the
character position, and the TRANSPOSE/PROGRAM
buttons to select the alphanumeric character. Repeat
these steps to enter the whole name.
• If you wish to erase all the characters, press both
TRANSPOSE/PROGRAM buttons at the same time.
DISK
MENU
3. Use the TRANSPOSE/PROGRAM buttons to select 1:
SONG SAVE.
DISK
7. Use
GENERAL
38
QQTG0588
6. Press the EXECUTE
button.
the TRANSPOSE/PROGRAM buttons to specify
the song (file) number to save to (001 to 100).
Part IV
Disk Drive
8. Press the EXECUTE button.
• The SAVE operation begins. “COMPLETE” appears
on the display.
• If you attempt to save song data to a song number in
which data is already stored, “SURE?” appears on the
display. Press the EXECUTE button to overwrite the
existing song data, or press the DISK MENU button if
you wish to cancel the procedure.
• The number of songs that can be saved to one floppy
disk is limited.
About playback
The method to play back a song you saved is the same
as that to play back a song on the included disk. (Refer
to page 37.)
• If both SONG data and SMF (Standard MIDI File) data
are stored on the same disk, following the TYPE indication, the display changes to the select display. In
this case, use the TRANSPOSE/PROGRAM buttons
to select 01 SONG. Press the EXECUTE button.
• During MEDLEY playback, playback will stops at a file
that has no song data.
SONG DELETE
You can delete songs that you no longer want to keep
from the disk.
1. Press the DISK
MENU button.
2. Use the TRANSPOSE/PROGRAM buttons to select 2:
SONG DEL.
DISK
GENERAL
3. Press the EXECUTE button.
• The display looks similar to the following.
DISK
GENERAL
4. Use
the TRANSPOSE/PROGRAM buttons select the
song number you wish to delete.
5. Press the EXECUTE button.
• “SURE?” appears on the display.
6. Press the EXECUTE button again.
• “COMPLETE” appears on the display, and the selected
song is deleted.
39
QQTG0588
Part IV
Disk Drive
1. Insert
DISK FORMAT
the floppy disk to be formatted into the Disk
Drive.
It may be necessary to format a floppy disk for saving
songs when you first use it. Also, this is a convenient
way to erase all the data stored on a disk.
• This procedure clears the entire contents of the disk.
• Reformat a disk if it cannot be saved to or loaded from
properly because of exposure to a magnetic field.
• You can use 3.5 inch 2DD (720KB) or 2HD (1.44MB)
floppy disks.
• Be sure to specify the type of format which is suitable
for the disk.
• How to distinguish the two disk types:
2DD
2HD
2. Press the DISK
MENU button.
DISK
MENU
3. Use the TRANSPOSE/PROGRAM buttons to select 3:
FORMAT.
No hole
DISK
Hole
GENERAL
• Although 2HD floppy disks can hold more data and
are convenient for quick loading and saving, some
models may be able to read only 2DD disks. Therefore,
you may not be able to use your 2HD disk data with
other musical instrument models.
• To format the floppy disk, the write-protect window
must be closed, as illustrated.
Storage is not
possible
Storage is
possible
4. Press the EXECUTE
•
button.
The display returns to the previous display.
DISK
GENERAL
5. Use the TRANSPOSE/PROGRAM buttons to select a
disk type (2DD or 2HD).
• Be sure to select the type which is the same as your
disk type.
Open
Closed
6. Press the EXECUTE
button.
• “SURE?” appears on the display.
7. Press the EXECUTE
button again.
• Disk format begins. After a few minutes, “COMPLETE”
appears on the display and formatting is completed.
• No sound is generated even if you play the keyboard
during formatting. If the keyboard is played during
formatting, sound may be produced when formatting
is completed.
40
QQTG0588
Part V Menu
Various settings that enhance the functions of this instrument are accessed through the MENU function.
Outline of the procedure
1. Press the MENU
0
1
2
3
+
4
5
6
CANCEL —
SOUND
7
8
9
MENU
RHYTHM
VARIATION
button.
16: FOOT SWITCH ASSIGN [FOOT SW]
Assign a function to the Foot Switch (sold separately).
17: LCD CONTRAST [CONTRAST]
Adjust the readability of the display.
18: DEMO LED [DEMO LED]
ON/OFF settings for the LED lighting of the pad
buttons during a DEMO performance.
19: ALL INITIAL [ALL INIT]
Reset this instrument to the original settings.
3. Press the EXECUTE
2. Use the number buttons to enter the menu number of
the setting you wish to display (two digits).
• The + and – buttons and the TRANSPOSE/ PROGRAM buttons can also be used to select the menu
number.
MENU list:
[ ] indicates the name shown on the display.
01: XBS [XBS]
ON/OFF setting for the EXTRA BASS SYSTEM
(emphasizes low-range sound).
02: PART VOLUME [PT VOL]
Volume settings for each part.
03: PART SOUND [PT SOUND]
Sound settings for each part.
04: PART PANPOT [PT PAN]
Stereo setting for each part.
05: PART REVERB SEND [PT REV]
Depth settings for the REVERB for each part.
06: PART CHORUS SEND [PT CHORS]
Depth settings for the CHORUS of each part.
07: PART MIDI CHANNEL [PT MIDI]
MIDI channel settings for each part
08: PART LOCAL SETTING [PT LOCAL]
MIDI LOCAL CONTROL settings for each part.
09: SONG TRACK MUTE [TR MUTE]
Mute setting for each track of a SONG.
10: SONG ALL CLEAR [SONG CLR]
Clear all SONG tracks.
11: SONG TRACK CLEAR [TR CLEAR]
Clear specified SONG tracks.
12: MIDI CLOCK [MIDI CLK]
MIDI CLOCK mode settings.
13: MIDI REALTIME COMMAND [MIDI RTC]
Setting to enable or disable the transmission/reception of MIDI REALTIME COMMAND data.
14: SPLIT POINT [SPLIT]
Change the split point on the keyboard.
15: MASTER TUNING [TUNING]
Fine adjustment of the tuning for the whole instrument.
button.
• The display changes to the setting display for the
selected MENU.
4. Use
the TEMPO/PROGRAM buttons, the TRANSPOSE/PROGRAM buttons, or the EXECUTE button to
adjust the settings in the selected menu.
TEMPO
TRANSPOSE
PROGRAM
PROGRAM
EXECUTE
0
1
2
3
+
4
5
6
CANCEL —
7
8
9
5. When
you have finished making the settings, press
the MENU button again.
• If you execute a setting, there is also a menu to exit
the setting mode.
41
QQTG0588
Part V
Menu
Setting menus
XBS
PART PANPOT
MENU
MENU
GENERAL
GENERAL
▲
Use the TRANSPOSE/PROGRAM buttons to set the XBS
to ON or OFF.
ON: Low-range sound is emphasized.
OFF: Low-range sound is not emphasized.
• When XBS is on, a
mark on the display appears
next to the XBS indication.
PART VOLUME
1. Use
the TRANSPOSE/PROGRAM buttons to select
the part you wish to set.
2. Use
the TEMPO/PROGRAM buttons to adjust the
stereo midpoint (0 to 127).
• At 0 the center is all the way to the left, at 64 the
center is midway between right and left, and at 127
the center is all the way to the right.
PART REVERB SEND
MENU
GENERAL
MENU
1. Use
the TRANSPOSE/PROGRAM buttons to select
the part you wish to set.
• RT is the abbreviation for RIGHT, PT for part and ACP
for ACCOMP.
• For an explanation of CHRD and R.BS, refer to page
28.
GENERAL
1. Use
the TRANSPOSE/PROGRAM buttons to select
the part you wish to set.
2. Use
2. Use
the TEMPO/PROGRAM buttons to adjust the
volume (0 to 127).
• Repeat these steps for each part as necessary.
the TEMPO/PROGRAM buttons to adjust the
depth of the REVERB (0 to 127).
PART CHORUS SEND
PART SOUND
MENU
GENERAL
MENU
GENERAL
1. Use
the TRANSPOSE/PROGRAM buttons to select
the part you wish to set.
1. Use
the TRANSPOSE/PROGRAM buttons to select
the part you wish to set.
2. Use
the TEMPO/PROGRAM buttons to adjust the
depth of the CHORUS (0 to 127).
2. Use
the TEMPO/PROGRAM buttons or the number
buttons to select a sound for the part.
PART MIDI CHANNEL
MENU
GENERAL
1. Use
the TRANSPOSE/PROGRAM buttons to select
the part you wish to set.
2. Use the TEMPO/PROGRAM buttons to set the channel
(OFF, 01 to 16).
42
QQTG0588
Part V
Menu
PART LOCAL SETTING
TRACK CLEAR
MENU
MENU
GENERAL
1. Use the TEMPO/PROGRAM buttons to select the part
you wish to set.
2. Use
the TRANSPOSE/PROGRAM buttons to set the
LOCAL CONTROL setting (ON or OFF).
• When set to OFF, the performance for the part is
transmitted as MIDI data but does not sound from this
instrument.
GENERAL
1. Use
the TRANSPOSE/PROGRAM buttons to select
the track you wish to clear.
• R is the abbreviation for RIGHT and L for LEFT. C
indicates the CHORD part.
2. Press the EXECUTE
button.
• “CLEAR?” appears on the display.
3. Press the EXECUTE
button again.
• “COMPLETE” appears on the display, and the
specified track is cleared.
SONG TRACK MUTE
MENU
MIDI CLOCK
GENERAL
MENU
1. Use the TEMPO/PROGRAM buttons to select the track
you wish to mute.
• R is the abbreviation for RIGHT and L for LEFT. C
indicates the CHORD part.
2. Use
the TRANSPOSE/PROGRAM buttons to display
the MUTE indication.
• “– – –” indicates that the MUTE function is turned off
for the track.
SONG CLEAR
GENERAL
Press the EXECUTE button.
• “COMPLETE” appears on the display, and all the
tracks of the SONG are cleared.
GENERAL
Use the TRANSPOSE/PROGRAM buttons to select the
MIDI CLOCK mode.
INT: This instrument’s internal clock is used to control the connected MIDI equipment.
EXT: The clock of the connected MIDI equipment is
used to control this instrument. (The tempo is displayed as “q= – – –”.)
• For information about MIDI connections, refer to page
46.
• The setting is always set to INT when the power to
this instrument is turned on.
MIDI REALTIME COMMAND
MENU
GENERAL
Use the TRANSPOSE/PROGRAM buttons to enable or
disable the transmission/reception of MIDI REALTIME
COMMAND data.
ON: REALTIME COMMAND (START/STOP, CONTINUE) data are transmitted/received.
OFF: REALTIME COMMAND data are not transmitted/received.
43
QQTG0588
Part V
Menu
SPLIT POINT
DEMO LED
MENU
MENU
GENERAL
GENERAL
Press the keyboard key to specify the desired split position.
• The name of the specified note is shown on the display.
• The initialized setting is at C3.
• The key at the split point is the lowest note of the right
keyboard section.
Use the TRANSPOSE/PROGRAM buttons to specify
whether or not the pad button LEDs light during a DEMO
performance.
ON: The pad button LEDs light also during a DEMO
performance.
OFF: The pad button LEDs do not light during the
DEMO performance.
MASTER TUNING
ALL INITIAL
MENU
GENERAL
GENERAL
Use the TRANSPOSE/PROGRAM buttons to adjust the
tuning value (–38 – Center – +39).
FOOT SWITCH ASSIGN
MENU
GENERAL
Use the TRANSPOSE/PROGRAM buttons to select a
function to assign to the Foot Switch (separately sold
option).
• Select from SUSTAIN, START/STOP [ST/STOP] and
GLIDE.
• In cases where the switch polarity is reversed, select
a function name that is preceded by a “–” indication.
• Pressing the Foot Switch will turn the assigned function
on.
• GLIDE “bends” the pitch down by about one semitone.
• For information about connecting a Foot Switch, refer
to page 46.
LCD CONTRAST
MENU
GENERAL
Use the TRANSPOSE/PROGRAM buttons to adjust the
readability of the display (1 to 10).
44
QQTG0588
Press the EXECUTE button.
• “COMPLETE” appears on the display, and all the settings of the instrument (except for MAIN VOLUME)
are reset to the factory-preset status. Note that the
SONG and PANEL MEMORY contents are cleared
with this procedure.
• You can also reset the instrument with the following
procedure: While pressing the TEMPO ∧ and ∨ at
the same time, turn on the power to the instrument.
With this method, the MAIN VOLUME setting is also
initialized.
Memory function
The various settings and memory contents of this instrument are maintained as long as the AC adaptor is connected to this instrument and plugged into an outlet. In
addition, the settings are preserved for about one week
after the AC adaptor is unplugged.
• The memory function does not function until the power
has been on for about 10 minutes.
• It is recommended that you save your SONG performances on floppy disks. (Refer to page 38.)
Symptoms which appear to be signs of trouble
The following changes in performance may occur in the Keyboard but do not indicate trouble.
Phenomenon
The buttons, keys, etc. malfunction.
Remedy
• Turn off the PLAY button once, then turn it on again.
Sounds and effects
If this procedure is not successful, turn off the PLAY
button once. Then, while pressing the TEMPO ∧ and
∨ buttons at the same time, turn the PLAY button on
again. (Note that, in this case, all programmable
settings, functions and memories return to their factorypreset status.)
No sound is produced when the keys are pressed. • The MAIN VOLUME is at the minimum setting. Adjust
the volume with the MAIN VOLUME control.
• The volumes for the selected parts are set to the
minimum levels. Set the volumes of the relevant parts
to appropriate levels. (Refer to pages 41 and 42.)
• The LOCAL CONTROL for a part performed on the
keyboard is set to OFF. Set the LOCAL CONTROL to
ON. (Refer to pages 41 and 43.)
Only percussive instrument sounds are produced • A DRUM KITS sound is selected.
when the keyboard is played.
The sound you hear is different from the sound you • This sometimes occurs when you play back SONG
data which was created on a different model, or when
selected.
MIDI data is received from a connected instrument.
Select the desired sounds again.
The rhythm does not start.
you are not playing back the SONG performance, turn
off the PLAY button.
• The DRUMS volume is set to the minimum level. Use
the balance buttons to set the DRUMS volume to an
appropriate level. (Refer to the page 42.)
• The 091 CLASSIC BALLAD rhythm is selected. This
rhythm does not sound unless the AUTO PLAY
CHORD is used.
• MIDI CLOCK is set to EXT. Set CLOCK to INT. (Refer
to pages 41 and 43.)
Rhythm
AUTO PLAY
CHORD
SONG
• The PLAY button in the SONG section is on. When
No sound is produced for the automatic accom- • The APC/SONG VOLUME is set to the minimum
setting. Set it to a suitable level. (Refer to page 29.)
paniment.
Storage is not possible.
• The remaining memory capacity of the SONG is 0.
Follow the SONG CLEAR or TRACK CLEAR procedure
to erase the memory. (Refer to pages 41 and 43)
Disk Drive
The Disk Drive produces a noise during recording • This occurs when the Disk Drive is reading a disk. It
does not indicate a problem.
or playback.
When the procedure to listen to a song on the disk • When performing the procedure to listen to a song on
the disk, the keyboard memory changes to that of the
is performed, the contents of the keyboard memory
data loaded from the disk. If you wish to preserve a
are erased.
song which is stored in the keyboard memory, save it
on a disk before performing the load procedure. (Refer
to page 38.)
45
QQTG0588
Phenomenon
Remedy
• This sometimes occurs when electrical equipment such
Noise from a radio or TV can be heard.
Other
as a radio or TV is used near the instrument. Try moving
such electrical equipment further away from the
instrument.
• The sound may be coming from a nearby broadcast
station or amateur radio station. If the sound is
bothersome, consult your dealer or service center.
• This instrument has a power source that heats the
The cabinet becomes warm during use.
cabinet to some degree. This is not an indication of
trouble.
Connections
(Rear panel)
L
DC IN
12V
AUX IN
OUT
IN
MIDI
MIDI OUT
Used for transmitting MIDI data. Connect the other end
of the MIDI cable to the MIDI IN terminal of another
instrument. This terminal is used, for example, to generate
sound from a connected instrument by playing this instrument.
MIDI IN
Used for receiving MIDI data. Connect the other end of
the MIDI cable to the MIDI OUT terminal of another instrument. This terminal is used, for example, to generate
sound from this instrument by playing a connected instrument.
FOOT
SW
PHONES/
LINE OUT
FOOT SW
An optional SZ-P1 Foot Switch (sold separately) can be
connected to this terminal to control various functions.
(Refer to pages 41 and 44.)
PHONES/LINE OUT (output level 1.5 Vrms, 16 Ω)
Headphones, a keyboard amplifier, or stereo equipment
can be connected to this terminal. When another apparatus is connected to this terminal, the speaker system is
automatically switched off, and sound is heard only
through the connected device.
AUX IN (stereo pin cord)
Connect to the LINE OUT terminal of another instrument
to this terminal. The sound from a connected CD player,
for example, can be output from this instrument’s
speakers.
Separately sold option
SZ-P1 Foot Switch
46
QQTG0588
R
Index
A
ALL INITIAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
APC/SOUND VOLUME . . . . . . . . . . . . . . . . . . . . . . .
AUTO PLAY CHORD . . . . . . . . . . . . . . . . . . . . . . . .
AUX IN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
44
29
28
46
B
BEAT MASTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
C
CANCEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHORD FINDER . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHORD STEP RECORD . . . . . . . . . . . . . . . . . . . . .
CHORUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLOCK (MIDI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CONDUCTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
COUNT INTRO . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20
30
34
22
43
21
46
27
D
DEMO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DIRECT PLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disk Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DISK FORMAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DISK SONG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DISK MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11
37
36
40
36
39
19
E
EASY REC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 33
ENDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
EXECUTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
F
FILL IN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
FINGERED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
FOOT SW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44, 46
Foot Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
FORWARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
G
GLIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
H
HARMONY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
I
INTRO/ENDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
L
LCD CONTRAST . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
LINE OUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
LOCAL (MIDI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
M
MAIN VOLUME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
MASTER TUNING . . . . . . . . . . . . . . . . . . . . . . . . . . 44
MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
MIDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
MIDI CLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
MIDI REALTIME COMMAND . . . . . . . . . . . . . . . . . . 43
MINUS ONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Music stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
MUTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
O
ONE FINGER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
ONE TOUCH PLAY . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
P
PAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
PANEL MEMORY . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
PART SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
PARTY PADS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
PIANIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
PLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
PLAY OFF/ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
R
REC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REVERB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RHYTHM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
33
37
23
25
S
SAVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SMF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
SOLO PIANO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
SONG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
SONG CLEAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
SONG SAVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SOUND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
SPLIT POINT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Standard MIDI File . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
START/STOP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
SUSTAIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
SYNCHRO START . . . . . . . . . . . . . . . . . . . . . . . . . . 26
T
TEMPO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
TEMPO/PROGRAM . . . . . . . . . . . . . . . . . . . . . . 19, 26
TOUCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
TRACK CLEAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
TRANSPOSE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
TRANSPOSE/PROGRAM . . . . . . . . . . . . . . . . . . . . . 19
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
V
VARIATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
X
XBS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
47
QQTG0588
Specifications
SX-KC611
KEYBOARD
61 KEYS (WITH INITIAL TOUCH)
SOUND GENERATOR
PCM
MAX. POLYPHONY
32 NOTES
SOUNDS
250 SOUNDS
EFFECT
TOUCH, SUSTAIN, REVERB, CHORUS
HARMONY
14 TYPES
TRANSPOSE
G – C – F#
RHYTHMS
100 RHYTHMS WITH VARIATION
RHYTHM CONTROLS
SYNCHRO START, START/STOP, INTRO/ENDING, COUNT INTRO,
FILL IN1, FILL IN 2, TEMPO
XBS
o
PARTY PADS
4 PADS, 4 BANKS
PANEL MEMORY
10 MEMORIES
AUTO PLAY CHORD
MODE: ONE FINGER, FINGERED, PIANIST
MUSIC TRAINER
BEAT MASTER (TRAINING/CHALLENGE), CHORD FINDER, PIANO
STYLIST, SOLO PIANO,
MINUS ONE, DISK SONG
SONG
PLAY, REC
4 TRACKS: RIGHT1, RIGHT 2, LEFT, CHORD
STORAGE CAPACITY: APPROX. 4500 NOTES
4 MODES: EASY REC, MELODY, APC REAL, APC STEP
DISK DRIVE
3.5 inch FLOPPY DISK DRIVE for 2HD (1.44MB), 2DD (720KB)
DIRECT PLAY (GM/SMF), SONG LOAD/SAVE, DELETE, FORMAT
CONTROLS
MAIN VOLUME, APC/SONG VOLUME, ONE TOUCH PLAY, EXECUTE,
MENU, CONDUCTOR
DISPLAY
CUSTOM LCD (WITH BACKLIGHT)
DEMO
o
TERMINALS
MIDI IN, MIDI OUT, FOOT SW, PHONES/LINE OUT, AUX IN
OUTPUT
10 W (5W × 2)
SPEAKERS
12 cm × 2
POWER REQUIREMENT
DC IN 12 V (WITH EXCLUSIVE AC ADAPTOR)
POWER CONSUMPTION
6.6 W (WHEN POWER IS OFF BY THE PLAY BUTTON: 2 W)
DIMENSIONS (W × H × D)
96.0 cm × 14.6 cm × 37.8 cm (37-25/32’’ × 5-3/4’’ × 14-7/8’’)
NET WEIGHT
5.9 kg (13.0 lbs)
ACCESSORIES
AC ADAPTOR, MUSIC STAND, SONG BOOK, SONG DISK
• Design and specifications are subject to change without notice.
EXCLUSIVE AC ADAPTOR
PART NO.
QFAG028A
REGION
VOLTAGE
NORTH AMERICA, MEXICO
120 V
QFAG029A
UNITED KINGDOM
230 – 240 V
QFAG030A
EUROPE, SOUTH AFRICA
230 V
QFAG031A
AUSTRALIA, NEW ZEALAND
230 – 240 V
QFAG032A
TAIWAN, MALAYSIA, SINGAPORE, ETC.
120/220/230/240 V
QFAG038B
SAUDI ARABIA, KUWAIT, HONG KONG
120/220/230/240 V
QFAG039B
ARGENTINA
120/220/230/240 V
48
QQTG0588
Demo Performance List
Axel F
Theme from the paramount Motion Picture BEVERLY
HILLS COP by Harold Faltermeyer
Copyritght© 1984, 1985 by Famous Music Corporation
International Copyright Secured
All Rights Reserved
Cool Gig
Technics Original
49
QQTG0588
50
QQTG0588
51
QQTG0588
Matsushita Electric Industrial Co., Ltd.
Central P.O. Box 288, Osaka 530-91, Japan
ENGLISH
QQTG0588A
Se0101S0
