Operating Instructions
BM-ED500
ITALIANO
ESPAÑOL
FRANÇAIS
DEUTSCH
Model No.
ENGLISH
Control Unit
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
ENGLISH VERSION
We declare under our sole responsibility that the product to which this
declaration relates is in conformity with the standards or other normative documents following the provisions of Directives EEC/73/23 and
EEC/89/336.
Ilmoitamme yksinomaisella vastuullamme, että tuote, jota tämä ilmoitus koskee, noudattaa seuraavia standardeja tai muita ohjeellisia asiakirjoja, jotka noudattavat direktiivien 73/23/EEC ia 89/336/EEC.
säädöksiä.
Wij verklaren als enige aansprakelijke, dat het product waarop deze
verklaring betrekking heeft, voldoet aan de volgende normen of
andere normatiefve dokumenten, overeenkomstig de bepalingen van
Richtlijnen 73/23/EEC en 89/336/EEC.
Vi erklærer oss alene ansvarlige for at produktet som denne erklæringen gjelder for, er i overensstemmelse med følgende normer eller
andre normgivende dokumenter som fælger bestemmelsene i direktiven 73/23/EEC og 89/336/EEC.
Vi erklærer os eneansvarlige for, at dette produkt, som denne deklaration omhandler, er i overensstemmelse med den følgende standarder
eller andre normative dokumenter i følge bestemmelserne i direktivene
73/23/EEC og 89/336/EEC.
Vi deklarerar härmed värt fulla ansvar för att den produkt till vilken
denna deklaration hänvisar är i överensstämmelse med standarddokument, eller andra normativa dokument som framstölls i Direktiv
73/23/EEC och 89/336/EEC.
CAUTION
Cautions:
• This unit is for indoor use only.
• Before attempting to connect or operate this product,
please read the label on the bottom.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
Power disconnection. Unit with or without
ON-OFF switches have power supplied to the
unit whenever the power cord is inserted into
the power source; however, the unit is operational only when the ON-OFF switch is in the
ON position. Unplug the power cord to disconnect the main power for all unit.
The serial number of this product may be found on the bottom of the unit.
You should note the serial number of this unit in the space
provided and retain this book as a permanent record of your
purchase to aid identification in the event of theft.
Model No.
For U.K.
FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT CAREFULLY.
This appliance is supplied with a moulded three pin mains plug for your
safety and convenience.
A 13 amp fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the replacement
fuse has a rating of 13 amp and that it is approved by ASTA or BSI to
BS1362.
or the BSI mark
on the body of the
Check for the ASTA mark
fuse.
If the plug contains a removable fuse cover you must ensure that it is
refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used until a replacement
cover is obtained.
A replacement fuse cover can be purchased from your local Panasonic
Dealer.
H
G
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE
REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE
CUT OFF PLUG IS INSERTED INTO ANY 13 AMP SOCKET.
If a new plug is to be fitted please observe the wiring code as shown
below.
If in any doubt please consult a qualified electrician.
WARNING: This apparatus must be earthed.
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code.
Green-and-yellow:
Earth
Blue:
Neutral
Brown:
Live
As the colours of the wire in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your
plug, proceed as follows.
The wire which is coloured green-and-yellow must be connected to
the terminal in the plug which is marked with the letter E or by the earth
symbol I or coloured green or green-and-yellow.
The wire which is coloured blue must be connected to the terminal in
the plug which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal
in the plug which is marked with the letter L.
How to replace the fuse
Open the fuse compartment with
a screwdriver and replace the fuse
and fuse cover.
FUSE
BM-ED500/G
Serial No.
WARNING: To prevent fire or electric shock hazard, do not expose this appliance to rain or moisture. The apparatus shall not be exposed to
dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
2
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not use near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles and the points
where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-overs.
S3125A
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
3
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ........................................................................................................................................ 3
PREFACE ...................................................................................................................................................................................... 5
FEATURE ...................................................................................................................................................................................... 5
PRECAUTIONS ............................................................................................................................................................................. 6
DOCUMENT CONVENTION ......................................................................................................................................................... 7
MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS ...................................................................................................... 8
■ External View ......................................................................................................................................................................... 8
■ Internal View .......................................................................................................................................................................... 8
INSTALLATIONS AND SETTINGS ................................................................................................................................................ 11
INSTALLATIONS .......................................................................................................................................................................... 11
■ Caution on Installation ........................................................................................................................................................... 11
■ Preparation ............................................................................................................................................................................ 12
■ Installation .............................................................................................................................................................................. 13
SETTINGS ..................................................................................................................................................................................... 16
■ Description ............................................................................................................................................................................ 16
■ To Do Setting without the Buzzer Sound ............................................................................................................................... 16
■ Operation Mode Setting ........................................................................................................................................................ 16
OPERATING PROCEDURES ........................................................................................................................................................ 19
■ Turning the Power On ............................................................................................................................................................ 19
■ Turning the Power Off ............................................................................................................................................................ 19
■ When the Door Trouble is Automatically Unrecoverable ....................................................................................................... 20
■ When the Door Trouble is Unrecoverable ............................................................................................................................. 20
APPENDIX .................................................................................................................................................................................... 21
ADDITIONAL SYSTEM COMPONENTS ....................................................................................................................................... 21
■ Iris Camera BM-ET500E ........................................................................................................................................................ 21
■ Administration Software BM-ES500E ..................................................................................................................................... 21
SPECIFICATIONS OF ELECTRICAL LOCK CONNECTORS (GATE 1) ......................................................................................... 22
SPECIFICATION OF ALARM OUTPUT CONNECTORS (ALARM OUT) ........................................................................................ 23
TROUBLESHOOTING .................................................................................................................................................................. 24
SPECIFICATIONS ......................................................................................................................................................................... 25
STANDARD ACCESSORIES ......................................................................................................................................................... 25
4
PREFACE
This system is designed for an iris physical access system,
which identifies the person with one’s iris data.
FEATURE
This system is composed of an iris camera, control unit,
and the administration PC (you need Administration
Software BM-ES500E, an additional system component). In
combination with electric locks, you can provide a complete iris-enabled physical access system for a single door.
Notes:
• These operating instructions describe the details on the
control unit. Refer to the iris camera’s operating instructions on how to identify people through iris cameras.
• To execute identification, you need to register iris data
in advance. (Refer to Administration Software BMES500E Operating Instructions.) The control unit (BMED500) enables you to register a person’s iris data into
the iris camera (BM-ET500E) for subsequent recognition.
5
PRECAUTIONS
• Refer all work related to the installation of this
product to qualified service personnel or system
installers.
Consult an expert on the load bearing capacity of the
installation surface and structure. If the surface is not
strong enough, the camera may fall down. Refer to the
product specifications for weights.
• Do not drop metallic parts through slots.
This could permanently damage the appliance. Turn
the power off immediately and contact qualified service
personnel for service.
• Do not attempt to disassemble the appliance.
To prevent electric shock, do not remove screws or
covers.
There are no user-serviceable parts inside. Contact
qualified service personnel for maintenance.
• Handle the appliance with care.
Do not strike or shake, as this may damage the appliance.
• Do not expose the appliance to water or moisture.
Do not try to operate it in wet areas.
Take immediate action if the appliance gets wet. Turn
the power off and refer servicing to qualified service
personnel. Moisture can damage the appliance and
also cause electric shocks.
• Do not use strong or abrasive detergents when
cleaning the appliance body.
Use a dry cloth to clean the appliance when it is dirty.
When the dirt is hard to remove, use a mild detergent
and wipe gently.
• Do not operate the appliance beyond its specified
temperature, humidity, or power source ratings.
Use the appliance at temperatures between 0 °C and
40 °C (between 32 °F and 104 °F) and humidity
between 30% and 80 %. The input power source for
this appliance is 100 to 120 V/220 to 240 V AC, 50/60
Hz. Do not share an AC outlet with devices that consume much electricity (such as a copy machine or air
conditioner).
• Do not operate the appliance while the door is open.
• Power switch
Power supply is not shut down only by turning off the
power switch. To shut it down, remove the power cord
from the AC socket, or turn off the external power-control device. Refer to p.19 for how to turn on/off the
power.
Note: While the power is turned off, recognition and
6
entrance will be unavailable.
• Replacement part
Exchange the following parts for the same type.
F1: K5D632AQ0001
F101: K5D122AQ0001
• Indication
Refer to the bottom of the unit as to the indications of
equipment classification and power source, etc.
• This product is not designed to prevent theft in
advance. We shall not guarantee you for any trouble
caused by using this unit.
• If you are in a situation that iris recognition is
impossible from the exterior, recognition or
enrollment will be invalid.
• Iris data is privacy. Take enough care not to leak the
data out of the administration PC. It is also
recommended that you should get an agreement
from a person to register his or her data.
• We recommend that you note down your settings
and save them. Power or battery failure may erase
the settings you enter.
• Do the self-diagnostic test, when you open this unit
door for maintenance, etc. The self-diagnostic test
can be carried out by turning on a power supply.
(Refer to p. 19.)
DOCUMENT CONVENTION
These operating instructions use the following convention when describing the use and operation of this system.
Control unit (or this unit): Panasonic Control Unit BM-ED500
Iris camera: Panasonic Iris Camera BM-ET500E
Administration software: Panasonic Administration Software BM-ES500E
Caution: Text with this appearance is a special instruction which you should heed for your safety.
Note: Text with this appearance is a special instruction, rule, or side comment related to the topic.
7
MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS
S2
E10
S1
DC-OUT
ALARM S3
S2
IC11
+32V
CN1
S1
E5
POWER
IC13
IC12
C34
1
2
3
4
5
6
7
–
OFF
1
2
3
4
6
7
8
9
5
*
0
#
E10
8
1
9
FSK
C32
+32V
C35
+
R1
R7
R6
R4
R5
CN4
–
BZ1
MAX
RESET
L29
–
CN2
VR1
E4
L25
MIN
CN3
ALARM S3
Fixing screws
q
C47
POWER
er
C40
w
■ Internal View
C41
■ External View
C31
1
2
3
4
5
6
2
3
4
5
6
7
D21
8
1
9
L23
FSK
T1
8
FSK
IC102
Q1
7
CN201
1
OFF
MED50JRZ3A
OFF
9
3
CN101
C56
q
CN504
E101
E102
C55
CN503
CN903
GATE 1
CN906
CN901
CN905
19
20
E901
4
3
2
1
19
G
5
G
4
G
3
G
2
G
C7
1
CNT/TRM_2
CNCN911
ALARM OUT
6
T6,3AL 250V
3
E1
G
AC-IN (N)
G 7
(L)
G 8
E2 F1 E1
10BASE-T/
100BASE-TX
20
E901
ALARM IN
D1
5
L2
6
L1
7
E6
GATE 2
8
C8
G 9
CN1
SW1
CAMERA 3
CAMERA 2
CAMERA 1
CNCN904
w
t
e
r
y
q Door/Key hole
You can open the control box door by using the supplied key. When you close the door, turn the key counterclockwise to lock.
Caution: When you open the door with the power on
and 10 seconds have passed after your turning on
the power and opening the door, the buzzer will
beep to notify you that the door is open. Then, the
recognition with iris cameras will be disabled. To
recover from the disabled condition, you need to
reset the control unit through the administration PC.
(Refer to the administrator’s guide of the administration software.)
When you open the door for maintenance, refer to
p.16.
w Power indicator (POWER)
Lights up when the power is turned on.
q Setting board
w Input/Output board
e Power board
This board is shielded for safety. Before the connections, do the following.
1. Loosen the three screws fixing the shield.
2. Remove the shield.
After the connections, attach the shield to the control
unit as it was.
r Ground terminal
t Clamping bar
This bar is used for clamping the cables.
After the connections, fix them with the supplied clamping tools.
y AC power cable
e Alarm indicator (ALARM)
Lights up when trouble occurs to the control unit.
r Status indicators (S1 to S3)
These indicators show the operation status of the control unit. (Refer to p.19.)
8
● Setting board
i Setting switches 1 (DSW 1)
These switches are reserved for service.
q
POWER
ALARM S3
r
w
e
BZ1
+
R1
R7
R6
R4
R5
1
2
3
4
5
6
7
S2
–
CN1
S1
y
1
2
3
4
6
7
8
9
5
8
1
9
OFF
Notes:
• Do not change the positions of these switches.
Error may occur.
• Keep hands away from these switches except for service personnel.
In the factory default setting, 6 and 7 have been set to
ON and others to OFF.
FSK
MIN
VR1
0
#
MAX
RESET
t
1
u
i
2
3
4
5
6
OFF
7
1
2
3
4
5
6
7
9
3
DSW1
8
DSW2
OFF
3
4
5
6
7
8
DSW1
8
FSK
CN201
o
1
1
9
2
FSK
OFF
IC102
CN101
CN503
CN504
E101
E102
q Door sensor
Detects the door opening or closing. When you open
the door with the power on or 10 seconds have passed
after your turning on the power and opening the door,
the buzzer will beep to notify the administration PC that
the door is open. When you open the door for setting or
maintenance, refer to p.16.
Note: During normal operation, door-opening for more
than 10 seconds will disable the control unit. To
reset the disabled status, use the administration
software.
w Setup indicator
Shows the setting data or which numeric key has been
pressed.
e Operation mode switch (DSW3)
These switches are used for setting the operation mode
of the control unit.
r Buzzer
Beeps when the door is open or trouble has occurred to
the control unit.
t Buzzer-level adjustment knob
You can adjust the buzzer volume with this knob.
y Numeric buttons (0 to 9, ✽ and #)
These buttons are pressed when you set the IP address
or confirm the setting data of the control unit.
u Reset button (RESET)
This button is reserved for service.
Note: Keep hands away from this button except for service personnel.
9
o Setting switches 2 (DSW 2)
These buttons are used for setting electric lock type
when you use electric locks. (Refer to p.18.)
● Input/Output Board
CN903
● Power board
CN906
CN901
CN905
E10
E901
GATE 1
DC-OUT
6
5
4
3
2
1
IC11
+32V
E5
E902
10BASE-T/
100BASE-TX
IC13
IC12
C34
–
ALARM IN
q
E10
C32
G
7
G
6
G
5
G
4
G 3
G
2
G
L25
1
C41
8
L29
E4
G
C35
+32V
w
CN3
7
CN4
8
C47
9
GATE 2
C40
q
r
ALARM OUT
CN2
–
C31
D21
CAMERA 3
T1
L23
e
Q1
CAMERA 2
CAMERA 1
C56
CN904
C55
q Electric lock connectors
An electric lock is connectable to GATE 1.
C8
Note: GATE 2 is not usable.
Do not connect anything to GATE 2.
e Iris camera connectors (CAMERA 1 to 3)
These are connectors for communication between iris
cameras and the control unit. Up to 3 iris cameras are
connectable (x 2 for recognition cameras and x 1 for an
enrollment camera).
r Ethernet port (10Base-T/100Base-TX)
This is a port to connect the control unit to LAN (Local
Area Network).
T6,3AL 250V
L2
w
AC-IN
w Alarm input/output connectors
(ALARM IN, ALARM OUT)
ALARM IN: These are connectors to input the alarm
signal from the external devices to the control unit.
Alarm-related operations are configurable through
the administration PC. (Refer to the administrator’s
guide of the administration software.)
ALARM OUT: These are connectors to output the alarm
signal from the control unit to the external devices.
Alarm-related parameters are configurable through
the administration PC. (Refer to the administrator’s
guide of the administration software.)
L1
C7
D1
E2 F1 E1
SW1
CN1
e
q Camera power connectors
These are connectors to supply iris cameras with 32 V
DC power. One connector can supply power to one
camera.
Note: Power supply from one connector to more than
one camera may cause trouble.
w Power input connectors
e Power switch
Turns on/off the power of the control unit. When
pressed, the power is on.
When the power is turned on, the power indicator lights
up and 32 V DC power is supplied from the camera
power connectors to iris cameras.
Note: Do not turn off the power during setting/initialization.
10
INSTALLATIONS AND SETTINGS
INSTALLATIONS
WARNING
The installations described in the figures should be made by qualified service personnel or system installers.
■ Caution on Installation
Secure the control unit with the supplied mounting bracket to prevent vibration, dropping and injury.
Notes:
• Keep the unit:
in the temperature between 0 °C and 40 °C (between 32 °F and 104 °F) and the humidity between 30 % and 80 %.
·
• Keep the unit away from:
vibration. (It may cause invalid recognition or injury.)
noise. (for example, places near air conditioners or ventilators)
electricity.
·
·
·
• This unit is for indoor use only.
System Instruction (Maximum System)
Coaxial cable(BNC)
Camera power cable
Coaxial cable(BNC)
OK
NG
BM-ET500E
(For identification)
OK
BM-ET500E
(For
enrollment)
NG
General-purpose
power supply
(24V DC,UL listed)
BM-ED500
POWER
ALARM S3
S2
S1
Camera 1
Electric lock*
Camera 3
Administration PC*
Camera 2
OK
NG
BM-ET500E
(For identification)
LAN cable
*UL not verified
11
■ Preparation
Prepare the following items before the installation. The necessary items and their lengths differ depending on condition.
● Preparing the necessary items
Item
Item number/Recommended type
Use
DC power cable
UL style 1015 or equivalents*1
(resistance of both ends: 0.03 Ω/m or
less)
Necessary when supplying DC power
from the control unit to iris cameras
Maximum distance: 20 m
Solder both ends of the cable with M3
screw clamp terminals.
UL Listed IEC type CM or
CL2, RG-6/U type
For communication between iris
cameras and the control unit
Recommended distance: 20 m or less
Maximum distance: 100 m
Solder both ends with BNC plugs.
UL style 1666, CSA-FT4 or equivalents
Necessary for communication between
the administration PC and the control
unit
Coaxial cable
LAN cable
10Base-T/100Base-TX (Category 5)*2
Anchor bolt
M8
Necessary for mounting the control unit
over the wall with the unicorn anchor
Unicorn anchor
UC-830 or equivalents
Necessary for mounting the control unit
over the wall
*1
Flexible Metal Conduit (According to IEC)
2
Total area: 1.277 in. /100 %
Trade size: 1-1/4 in.
Total number of
iris cameras connected
Dimension and percent area of
conduit and tubing
1
0.677 in.2/53 %
2
0.396 in.2/31 %
*2 Cables with connector covers are unusable.
Note: When you use ALARM IN/OUT, GATE 1, you need another cable suited for the connectors of the external device or control unit. Use the UL style 1571 or equivalents, AWG 22 - 16 wire.
12
■ Installation
The following is the procedure to mount the control unit over the wall with the supplied mounting bracket.
When mounting, follow the procedure. After mounting the plate, secure the control unit to the mounting plate. Otherwise, it may
drop and cause damage or injury.
Caution: This system must be installed within the protected promise in accordance with the International Electrotechnical
Commission, and the local authorities having jurisdiction.
1. Attach the anchor into the wall and attach the supplied mounting bracket to the anchor.
Use an anchor bolt which meets the standards shown in the following figure.
Wall
10 mm (2/5 in.) or less
Mounting bracket
2 mm (2/25 in.) (D)
Hit the anchor into the wall by referring the following figure.
362.4
250
30
13
2-4M
13
5
4.
8
R
4-
9
13
342
324.2
280
4-φ20
The unit of length: mm
13
2. Pass the power cable through the upper cable holes, and then mount the control unit over the wall.
Make two holes to attach a flexible metal conduit.
Use a metal conduit.
Cable holes
Use a metal conduit.
Note: Use metal conduits when designated by the electrical regulation.
3. Connect iris cameras and electric locks as following, and then LAN cable to the Ethernet port.
E10
DC-OUT
IC13
IC12
C34
2
3
4
5
6
7
2
3
4
6
7
8
9
5
*
0
#
E10
C32
8
FSK
+32V
L25
VR1
MAX
L29
E4
MIN
C41
1
1
9
OFF
1
C35
R1
R7
R6
R4
R5
–
CN4
–
BZ1
+
CN3
IC11
+32V
CN1
S1
C47
S2
C40
ALARMS3
E5
POWER
RESET
–
1
2
3
4
5
6
2
3
4
5
6
7
D21
8
1
9
L23
FSK
T1
8
FSK
IC102
9
C56
CN101
CN504
CN901
E101
E102
8
7
6
5
4
3
2
1
To electric locks
C55
CN503
CN903
Q1
OFF
MED50JRZ3A
7
CN201
1
9
3
Unlocking in emergency ground
Unlocking in emergency
Lock status ground
Lock status (unlocking)
Lock status (locking)
Gate status ground
Gate status
Lock control ground
Lock control
OFF
CN2
GATE1
C31
CN905
19
20
E901
5
4
3
2
1
6
G
5
G 4
G 3
G
2
G
1
C7
E6
CNCN911
ALARM OUT
T6,3AL 250V
3
E1
G
AC-IN (N)
7
(L)
G
E2 F1 E1
10BASE-T/
100BASE-TX
20
E901
D1
6
SW1
L2
7
CNCN912
8
8
19
GATE 2
ALARM IN
G
9
C8
G
L1
GATE 1
CN906
CN1
CNT/TRM_2
CAMERA 3
CAMERA 2
CAMERA 1
CNCN904
BZ1
Coaxial cable (with BNC connectors)
+
R1
R7
R6
R4
R5
1
2
3
4
5
6
7
–
OFF
1
2
3
4
6
7
8
9
5
8
1
9
FSK
MIN
VR1
0
#
MAX
RESET
To iris cameras
To electric locks
To the hub or router
(Connecting to the administration PC via LAN)
Wrap the supplied ferrite cores around the cables connected to the electric locks and LAN.
14
4. If you make the control unit output alarm signals to external devices and relate them to the alarm signals from the iris cameras or the control unit, connect the devices to ALARM OUT 1 to 8. For example, you can start alarm-related recording by
connecting ALARM OUT and a recorder’s alarm input connector.
G 8
G 7
G
6
G
5
G 4
G 3
G 2
G
1
ALARM OUT
Notes:
• Alarm-related operations and alarm output timing are configurable through the administration PC. (Refer to the administrator’s guide supplied with the administration software.)
• The alarm output connectors are not UL verified.
5. After removing the power board’s cover, connect the camera power cable to the control unit, as described in the figure.
Camera power cable connection
E10
DC-OUT
IC13
2
3
4
5
OFF
6
7
1
2
3
4
5
*
6
7
8
9
0
#
E10
C32
+32V
L25
VR1
MAX
E4
MIN
+32V
To iris cameras
+32 V connectors
CN4
—
8
FSK
C35
1
1
9
CN3
IC12
C34
—
BZ1
+
R1
R7
R6
R4
R5
C47
IC11
+32V
CN1
S1
RESET
C41
S2
C40
ALARMS3
E5
POWER
L29
—
2
3
4
5
6
2
3
4
5
6
7
D21
8
1
9
L23
FSK
T1
8
OFF
IC102
To iris cameras
0 V connectors
Q1
7
CN201
1
9
3
MED50JRZ3A
OFF
0V
CN2
C31
1
CN101
CN503
CN504
CN903
CN901
E101
E102
C55
Secure 4 points
with the supplied
clamping tools.
GATE 1
CN906
CN905
19
20
E901
2
1
6
G
5
G 4
G 3
G
2
G
1
C7
SW1
T6,3AL 25
CN1
G
2
G
1
CAMERA 1
AC-IN (N)
CNT/TRM_2
CAMERA 3
CAMERA 2
F1
10BASE-T/
100BASE-TX
(L)
ALARM OUT
T6,3AL 250V
3
E1
G
E6
7
AC-IN (N)
G
E2 F1 E1
10BASE-T/
100BASE-TX
C7
3
3
E1
4
D1
5
L2
6
L1
7
(L)
8
8
20
E901
ALARM IN
G
9
C8
G
19
GATE 2
E6
CNCN904
Use a clamping tool to separate
the AC cable from other cables.
SW1
The AC socket should be installed near the equipment.
Start setting after finishing the installation.
Tighten the cables (except the AC power cable)
and the clamping bar with two clamping tools.
Note: Connect the power cable and camera power cable after connecting electric locks and LAN cables to the control
unit. The cables should be covered to prevent from pulling and pushing.
15
SETTINGS
■ Operation Mode Setting
■ Description
The control unit has four operation modes. They are configurable with 1 to 3 of the operation mode switches. (The factory default setting is shown in the figure.)
To use the control unit, the following settings are necessary
with the setting switches or numeric buttons on the setting
board.
• Setting/confirmation of the operation mode/IP address
(Operation mode switches)
• Electric lock setting (DSW 2)
You will set the existence, type, polarity and unlocking
timer of electric locks.
• IP address
You will set if you connect the control unit to the PC via
LAN and control this unit from the PC.
In addition to these settings, you need the configuration
through the administration PC. (Refer to the administrator’s
guide of the administration software.)
POWER
ALARM S3
BZ1
+
R1
R7
R6
R4
R5
1
2
3
4
5
6
7
OFF
FSK
MIN
3
4
1
2
3
4
5
6
7
8
9
VR1
0
MAX
RESET
1
2
—
CN1
S1
8
1
9
Operation mode switches
(DSW3)
1
S2
5
6
2
OFF
1
3
4
5
6
5
6
7
1
9
2
3
4
7
FSK
7
9
3
8
8
DSW1
8
DSW2
OFF
FSK
IC102
OFF
Operation mode
setting
CN101
Note: When you set the control unit's operations through
the administration PC, you need to change the operation mode to the SETUP mode.
CN503
■ To Do Setting without the
Buzzer Sound
When you open the door, the buzzer will beep to notify you
that the door is open. Then, the recognition procedures with
iris cameras will be unavailable. If you open the door for
maintenance, etc., do the following procedure.
1. Open the door with the supplied key.
The buzzer will beep and recognition is stopped.
2. Pull the door sensor.
3. Restart the recognition from the administration PC.
You can do setting without the buzzer sound and you
can continue the recognition with iris camera during the
setting. (Setting changes will not be reflected until turning on the power again.)
4. After the setting, close the door.
The buzzer will beep again.
5. Restart the recognition from the administration PC.
When you open the door again for setting, do steps 1 to
3 again.
CN504
E101
Unsettable
(Do not change these positions. Error may occur.)
Notes:
• Change the operation mode after turning off the power
of the control unit. When you change the mode while
power is on, the setting will not be reflected to the control unit until turning on the power again.
• To turn the power off, refer to p.19.
Operation mode
Description and setting
IP setting mode
This is the mode to set/confirm the IP
address/gateway address of the
control unit.
1 2 3 4 5 6 7 8
1
9
OFF
SETUP mode
FSK
Set to this mode when you configure
the control unit's operations via the
administration PC. (Refer to the
administrator’s guide supplied with
the administration software.)
1
2
3
4
5
6
ALARM S3
+
R1
R7
R6
R4
R5
1
2
3
4
5
6
7
BZ1
Recognition
mode
Set to this mode when you make iris
cameras recognize people.
1
2
3
4
5
6
–
FSK
1
2
3
4
5
6
7
8
9
0
MIN
VR1
RESET
16
FSK
2
3
4
5
6
7
1
9
OFF
MAX
8
Set to this mode when you make iris
cameras enroll people.
1
#
7
1
9
Enrollment mode
CN1
S1
8
1
9
OFF
S2
8
FSK
OFF
POWER
7
1
9
OFF
Door sensor
Pull this immediately after
opening the door.
E102
FSK
8
● IP address/Subnet mask/Gateway
address setting
Note: Before turning on the power again, change the
operation mode switch to recognition or enrollment
mode.
The following are the factory default settings of IP address
and default gateway address.
IP address: 172.27.1.2
Subnet mask: 255.255.255.0
Gateway address: 172.27.1.254
Note: You need to change these addresses depending on
the classification or condition of LAN, which connects
the control unit. If the settings of IP address and default
gateway address are not correspondent with those in
the LAN classification or condition, you cannot control
this unit through the administration PC.
● IP address/Subnet mask/Gateway
address confirmation
The following is the procedure to confirm the IP address
and default gateway address with the Setup indicator.
1. Turn off the power of the control unit, and then change
the operation mode switches to the IP setting mode.
2. Turn on the power.
Wait until the Setup indicator changes from “8” to “0”.
IP address, subnet mask, or gateway address is changeable through the following procedure.
1. Turn off the power of the control unit, and then change
the operation mode switches to the IP setting mode.
2. Turn on the power.
Wait until the Setup indicator changes from “8” to “0”.
During the
mode setting
Waiting an entry
3. Enter the command with the numeric buttons.
IP address setting command: “112✽002#”
Subnet mask setting command: “112✽003#”
Gateway address setting command: “112✽004#”
During the
mode setting
Waiting an entry
3. Enter the command with the numeric keys to select the
address setting.
IP address setting command: “113✽002#”
Subnet mask setting command: “113✽003#”
Gateway address setting command: “113✽004#”
4. Enter 12-digit numbers without period.
(The address is composed of numbers up to 255.)
Note: Enter “0” before the numerics from 0 to 99 to
make it 3-digit.
Example: When you enter an IP address
“192.168.1.20”, enter “192168001020”.
5. Enter the address check command “113✽000#”.
Address will be checked. After the checking, the result
will appear on the Setup indicator.
Completed: 0
Failed: 1 (The address may be wrong.)
Parameter error: E (The digits may be wrong./✽ or #
may be used in the address.)
6. Turn off the power of the unit.
The address will become available when you turn on
the power again.
17
4. The address will appear on the LED display.
The display will be switched every second to show the
address.
5. Turn off the power of the unit.
Note: Before turning on the power again, change the
operation mode switch to recognition or enrollment
mode.
● Electric lock Setting
You can set the lock existence or types of electric locks with DSW 2.
Electric lock 1: An electric lock which is connected to GATE 1.
The factory default setting is shown in the figure.
DSW 2
POWER
1
2
3
4
5
6
7
ALARM S3
8
+
R1
R7
R6
R4
R5
1
2
3
4
5
6
7
OFF
—
CN1
S1
1
2
3
4
6
7
8
9
FSK
VR1
0
#
MAX
FSK
RESET
1
2
3
4
5
6
7
8
1
9
OFF
1
DSW1
FSK
2
3
4
5
6
7
9
3
CN201
Electric lock 1: Existence and type of the electric lock
5
8
1
9
MIN
OFF
BZ1
S2
8
DSW2
OFF
FSK
Electric lock 1: Solenoid polarity
IC102
Electric lock 1: Unlocking timer
Unsettable
CN101
Do not change these positions.
Error may occur.
Unsettable
Unsettable
CN503
CN504
E101
E102
Existence and types of electric locks
Unlocking timer activation/deactivation setting
They are settable with Switch 1 and 2 of DSW 2.
When you activate the unlocking timer of an electric lock,
set Switch 4 of DSW 2 to ON.
Electric lock 1
Electric lock 1
Setting
#1*
#2*
Electric lock 1 not connected
OFF
ON
Locking/Unlocking with continuous
electricity
ON
Locking/Unlocking with instantaneous/
pulse electricity
ON
It is settable with Switch 2 and 3 of DSW 2.
Electric lock 1
Setting
#3*
Positive/Fail Secure
ON
Negative/Fail Safe
OFF
* The numeric shows the setting switch number.
18
#4*
Unlocking timer activated
ON
Unlocking timer
deactivated
OFF
OFF
ON
* The numeric shows the setting switch number. Be sure
to set either one of #1 or #2 to ON.
Solenoid polarity setting of electric locks
Setting
* The numeric shows the setting switch number.
OPERATING PROCEDURES
■ Turning the Power On
■ Turning the Power Off
Power switch is inside the control unit. To turn the power
on, open the door with the supplied key, and then press the
power switch. Close the door within 10 seconds after turning on the control unit.
1. To turn the power off, open the door with the supplied
key. The buzzer will beep and recognition will be
stopped.
2. Pull the door sensor.
CN906
CN906
5
5
4
4
3
3
2
2
1
1
G 3
G 3
G 2
G 2
G 1
G 1
T6,3AL
T6,3AL 250V
250V
E6
E6
G 4
G 4
AC-IN (N)
G 5
G 5
CNCN912
6
6
E2 F1 E1
E2 F1 E1
(L)
10BASE-T/
10BASE-T/
100BASE-TX
100BASE-TX
3. To reset the door-closed state, send the signal for operation start from the administration PC.
D1
D1
6
6
L2L2
7
7
C7
C7
8
8
C8
C8
G 9
G 9
CN905
CN905
L1L1
CN901
CN901
3
E1
03
03
CN1
CN1
SW1
SW1
Power switch
4. Confirm the door-closed state has been reset and
READY is lighting on the iris camera.
5. Turn off the control unit and close the door.
When you turn the power on, POWER will light up, and indicators will light up as shown in the figures.
Status indicators
POWER
S3 S2 S1
Power off
Power on
Self-diagnosis
Initializing
Ready
This indicator is lighting.
This indicator is not lighting.
Note: When 10 seconds have passed after opening the
door with the power turned on, the door sensor
detects that the door is opening, and recognition/
enrollment becomes unavailable. This condition is
not recoverable by closing the door or turning on
the power switch again. (Refer to the administrator’s
guide supplied with the administration software for
troubleshooting.)
19
Notes:
• When the power of the control unit is turned off, no
power is supplied to the electric lock. In this case,
the status may vary depending on the lock type. If
you are using a “Fail Safe” type (refer to p.18), the
door can be opened with the lock deactivation.
However, be careful when you are using a “Fail
Secure” type (refer to p.18). The door cannot be
opened with the lock activation.
• Refer to the administator's guide of the administration software for how to turn on/off the system.
■ When the Door Trouble is
Automatically Unrecoverable
■ When the Door Trouble is
Unrecoverable
When trouble has occurred to the door and it is automatically unrecoverable, ALARM and S3 light up to inform you
of the trouble status. In this case, turn off and turn on the
power again. (Refer to p.19.)
When trouble has occurred to the door and it is unrecoverable, all the indicators (POWER, ALARM, and S1 to S3) light
up to inform you of the trouble status. In this case, turn off
the power immediately and refer to service personnel.
(Refer to p.19 for how to turn on/off the power.)
Status indicators
POWER
ALARM
S3 S2 S1
POWER
Status indicators
S3 S2 S1
Trouble status
Alarm status
ALARM
All indicators are lighting.
Note: When door trouble has occurred, the electric lock
control will be stopped. In this case, the status may be
different depending on the lock type. If you are using a
“Fail Safe” type (refer to p.18), the door can be opened
with the lock deactivation. However, be careful when
you are using a “Fail Secure” type (refer to p.18). The
door cannot be opened with the lock activation.
20
APPENDIX
ADDITIONAL SYSTEM
COMPONENTS
■ Iris Camera BM-ET500E
■ Administration Software BMES500E
ACCEPT
REJECT
READY
This product is necessary to administer iris data, IDs, and
passwords.
Administration Software
BM-ES500E
This product is used for recognition/enrollment of iris data.
ID-and-password authorization is also available.
21
SPECIFICATIONS OF ELECTRICAL LOCK CONNECTORS (GATE 1)
22
Port No.
I/O
Signal Description
Remarks
1
OUT
Lock control
Solenoid SW Activated
300 mA or less
2
OUT
Lock control ground
Solenoid SW Activated
3
IN
Gate status
Reed SW Activated
4
IN
Gate status ground
Reed SW Activated
5
IN
Lock status (locking)
Micro SW Activated
6
IN
Lock status (unlocking)
Micro SW Activated
7
IN
Lock status ground
Micro SW Activated
8
IN
Unlocking in emergency
Micro SW Activated
9
IN
Unlocking in emergency ground
Micro SW Activated
SPECIFICATION OF ALARM OUTPUT CONNECTORS (ALARM OUT)
23
Port No.
Signal Name
I/O
Signal Description
Remarks
1
OUT1
OUT
Alarm output 1 (+)
Open-collector output
Ground
OUT1 ground
OUT
Alarm output 1 (–)
Open-collector output
2
OUT2
OUT
Alarm output 2 (+)
Open-collector output
Ground
OUT2 ground
OUT
Alarm output 2 (–)
Open-collector output
3
OUT3
OUT
Alarm output 3 (+)
Open-collector output
Ground
OUT3 ground
OUT
Alarm output 3 (–)
Open-collector output
4
OUT4
OUT
Alarm output 4 (+)
Open-collector output
Ground
OUT4 ground
OUT
Alarm output 4 (–)
Open-collector output
5
OUT5
OUT
Alarm output 5 (+)
Open-collector output
Ground
OUT5 ground
OUT
Alarm output 5 (–)
Open-collector output
6
OUT6
OUT
Alarm output 6 (+)
Open-collector output
Ground
OUT6 ground
OUT
Alarm output 6 (–)
Open-collector output
7
OUT7
OUT
Alarm output 7 (+)
Open-collector output
Ground
OUT7 ground
OUT
Alarm output 7 (–)
Open-collector output
8
OUT8
OUT
Alarm output 8 (+)
Open-collector output
Ground
OUT8 ground
OUT
Alarm output 8 (–)
Open-collector output
TROUBLESHOOTING
Check the following before requesting repair.
If a trouble cannot be corrected even after checking and trying remedy, contact your dealer.
Problem
POWER does not light up.
External devices (such as electric locks)
do not work.
24
Check item
Remedy
AC power cord may be disconnected
from the control unit's power input connector.
Connect the power cord to the power
input connector.
(Refer to p.15.)
The power of the control unit or the
power breaker of the external powercontrol device may be turned off.
Turn on the power of the control unit or
the external power-control device.
(Refer to p. 6.)
The power of the external devices may
be turned off.
Turn on the power of the external
devices.
(Refer to pp.14 to 15.)
The connection between the control unit
and the external devices may be
wrong.
Confirm the connection.
(Refer to pp.14 to 15.)
SPECIFICATIONS
General
Power Source:
Power Consumption:
Ambient Operating Temperature:
Ambient Operating Humidity:
Dimensions:
Weight:
Input/Output/Interface
Iris camera interface:
Camera power output:
Ethernet port:
Electric lock interface:
Alarm output:
100 to 120 V/220 to 240 V AC, 2.4 A/1.2 A, 50/60 Hz
190 W
150 W (when standby)
230 W (max. when operating)
0 °C to +40 °C (32 °F to 104 °F)
30 % to 80 %
380 mm (W) x 410 mm (H) x 90 mm (D)
[15 in. (W) x 16-1/10 in. (H) x 3-1/2 in. (D)]
9.5 kg (21 lbs.)
Exclusive control, BNC x 3
32 V DC, 3A, terminal x 2
10 Base-T/100 Base-TX, RJ-45 x 1
Solenoid operation output (24 V DC, 300 mA or less) x 1
Door-opening detector input (contact signal) x 1
Locking/Unlocking detector input (contact signal) x 1
Emergency unlocking activation input (contact signal) x 1
Open collector x 8,
200 ms to 25.5 s,
Normally open or normally closed selectable
(Configurable through the administration PC,
24 V DC, 100 mA or less)
STANDARD ACCESSORIES
Mounting bracket ............................................ 1 pc.
Key .................................................................. 2 pcs.
Ferrite core....................................................... 2 pcs.
Mounting screw (M4) ....................................... 2 pcs.
Operating instructions (this book).................... 1 pc.
Clamping tools ................................................ 5 pcs.
Bushing ............................................................ 2 pcs.
25
Matsushita Electric Industrial Co., Ltd.
Web Site : http://www.panasonic.co.jp/global/
NM1002-1122
2002
© Matsushita Electric Industrial Co., Ltd. All rights reserved.
3TR001104BAA
Printed in Japan
Gedruckt in Japan
Imprimé au Japon
Impreso en Japón
Stampat in Jiappone
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
