Technics
AV CONTROL STEREO RECEIVER
SA-GX230D
STEREO SYNTHESIZER RECEIVER
SA-GX130D
Operating Instructions
— aSbecinications differ accordi ña to the area code.
The EB Area: code. for example, indicates United Kingdom
==
Di A. PEE e
We want to thank you for selecting this product and trom this new addition to your home.
to welcome you to the growing family of satisfied Piease read thesa operating instructions carefully,
Technics product owners around the world. and be sure to keep them handy for convenient
We feel certain you will get maximum enjoyment reference.
== ото ==. Y
E ELE € 7
== a
> = __ —
“these operating nsiructione are applicable to to the ss SA GX230D я and Sn aX1300 models.
Thess operating instructions, however, fundamentally explain the operation of the SA-GX230D model.
Contents
® Ассезвойев ............................. 2 * Recording i... 18
oe Caution for AC mains lead ............... 3 » Remote Controi Operation................ 20
*s Connections . . ........................... 4 * Suggestions for Safety. .................. 23
* Remote Control Transmitter. ............. 9 e Troubleshooting Guide ................... 24
* Front Panel Controls and Functions ...... 10 e Maintenance. 25
s Mutual Operations ....................... 12 * Technical Specifications ................. 26
* Listening to Radio Broadcasts ........... 14
CAUTION:
The AC voltage Is different according to the area.
Be sure to set the proper voltage In your area before use.
(For details, presse refer to the page 8.)
- - ac Se В — В . си РЯ жи кет LI
— a 5 = = = E GEE) ee on
"= SE "TT a oa er = y TA TI TT A TA => TEE E —— Cr Pre No Ьноданнный 2 EE EE DD ——
TER ee TE ED =
o a == e Err ee —
e UNC ye or ru UP a —
тали
1
a
|
Accessories
« Remote control transmitter
(RAK-SAJ1 1 XH}
Caution for AC mains lead
(United Kingdom only)
(“EB” area code model only)
This appliance is supplied with a moulded three pin
mains plug for your safety and convenience.
‚ А 5-атреге fuse ls fitted in this plug.
Should the fuse need to be replaced please ensure
that the replacement fuse has a rating of 5-ampere
and that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark @ or the BSI mark
on the body of the fuse.
If the plug contains a removable fuse cover you
must ensure that it is refitted when the fuse is replac-
ed.
If you lose the fuse cover the plug must not be used
until a replacement cover is obtained.
A replacement fuse cover can be purchased from
your local dealer.
IF THE FITTED MOULDED PLUG IS UN-
SUITABLE FOR THE SOCKET OUTLET IN YOUR
HOME THEN THE FUSE SHOULD BE REMOVED
AND THE PLUG CUT OFF AND DISPOSED ОЕ
SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL
SHOCK [F THE CUT OFF PLUG IS INSERTED
INTO ANY 13-AMPERE SOCKET.
If a new plug is to be fitted piease observe the wiring
code as shown below.
If in any doubt please consult a qualified electriclan.
IMPORTANT
The wires in this mains lead are coloured in accor-
dance with the following code:
Blue: Neutral
Brown; Live
As the colours of the wires in the mains lead of this
appliance may not correspond with the coloured
markings identifying the terminals in your plug, pro-
ceed as follows:
The wire which Is coloured BLUE must be con-
nected to the terminal in the plug which is marked
with the letter N or coloured BLACK.
The wire which is coloured BROWN must be con-
nected io the terminal in the plug which is marked
r rod DET
with tha lattar | Ar sale
YYIL ww E —_ il od LT a ый ELL ka
Under no circumstances should either of these
wires be connected ta the earth terminal of the
three pin plug, marked with the letter E or the Earth
Symbol — .
Before use
Remove the connector cover as follows.
Connector
cover
‘How to replace the fuse
1. Remove tha fica cover with a qorewdrivar,
EO ThA Al и Nf ат КО! E "FE азам
Fuse
{5 ampere)
Ч
Do not place books, etc., on top of this unit so that the heat radiation vents remain unblocked.
7 Connections neo EE
Ÿ ? ® @ ® ® @ ©
me sa-ax230
FM ANT
750 cp |VCR 1 TAPE | VCR 1 :
à jvoir ao]
a ANT QUT IN (OUT) (IN) DEQ a)
A Loos 000000 -
Ш 3 E. rd rase о ке жа ae
CT &
(1) Antenna connection terminals
See pages 6 —7 for detailed information.
2 “PHONO” terminals
Connect a turntable only. Do not connect any other sound
source to these terminals.
40 (only for SA-GX230D)
® “VCR 1” terminals
Connect a VCR.
(See the operating instructions of the VCR)
This unit
This unit
GND 3 TT
PHONO
— + 1 es = -—--——1 Stereo connection
a cables
Stereo connection | Ground wire {not included)
cable (not included)
(not included) not
ы no
; vi T
D included) 7 Déc ou
{Fy (L GND —— } es
Turntable AL | Video connection
{not included) | OUTFUTD & & | cable
{not included)
— | y ‘|
(not included) f
® “CD” terminals Som
Connect a compact disc player.
This unit co A ET a
— ® © —
: A
Stereo connection
cable
(not included)
9 u
Compact disc I a TTT _ 7 TT
player
not included) OUT
E L J TT - —
(5) ( for SA-QX230D )
“TAPE” terminals
Connect a tape deck.
This unit TAPE
RECTOUT) PLAY (IN)
[e €,
star "ma As TT. a
A Lik)
+ A
Stereo connection
cables
(not included)
- TE
во um _
Tape deck & $
(not included)
LINE IN LINE OUT
(_ for SA-GX130D )
“TAPENCR 2” terminals
Connect a tape deck or second VCR. (This corresponds to
the "TAPE" terminals in the above illustration).
EG Remote control OUT terminal
(REMOTE CONTROL OUT)
This terminal can be used only with Technics components
which have the appropriate remote control terminal.
(Consult your dealer for details.)
Proper connection with remote control connection cables
SJP2257T will allow control of some functions from this
unit's remote control transmitter. (See pages 20—22- for
details.)
Connect to a tape deck and/or compact disc player as shown
below.
If a tape deck is not being used, the compact disc player can
be connected directly {dotted line).
This unit
REMOTE
CONTROL
OUT
=== I 1 —-
CU Connection cable
“— for remote control
A {Included with tape
deck)
Tape deck
{not included) | REMOTE
© CONTROL,
I EN OUT
— 1 i. TE
1 Connection cable
! for remote control
1 {Included with
| compact disc
7 player)
Compact disc |
player ©
{not included) REMOTE
Mo E
Note:
— - For a compact disc player with a remote control sensor the
ahove connection is not necessarv
== ER НН в -
7 Cooling fan
{® Speaker connection terminals
See page 8 for detailed information,
The cooling tan operates at high output power levels only.
'9) Voltage selector (VOLT ADJ)
(only for SA-GX230D)
10 “VIDEO OUT” terminal
See page 8 for detailed information.
®
Connect a video connection cable (not included) to the video
input terminal of the YCR connected to the "VCR 1” ter-
vr lm me
1 LNFS.
When this connection is made, tape-to-tape recording (audio
and video) can be carried out simply by connecting a video
camera or second VCR (for playback) to the "VCR 2" ter-
minals of this unit.
VCR
This unit
(not included)
@ VIDEO OUT
a)
Video connection
cable
(not included)
J VIDEO IN
AC IN socket (AC IN)
See page 8 for detailed information.
Connections continues
| FM antenna connections
hd
Note: An outdoor antenna should be installed by a competent technician only.
FM indoor antenna FM outdoor antenna
(included) (not included)
{y Tape и
75-0hma coaxial cable
_ {not included)
A
3 Attachment
This unit a (ICHS) De
Fm ¡pro
FM ANT FM ANT.
750 > or 75 Q
ES E
E ALL a
( FM indoor antenna (included) _) (FM outdoor antenna (not included) >
Attach to a wall (using a tape} facing in the direction of best recep-
if the FM indoor antenna does not provide satisfactory reception,
tion,
an outdoor antenna should be used.
For beat reception sound quality: The outdoor antenna may be required in a mountainous region,
An FM outdoor antenne is recommended. or if this unit Is located inside a reinforced-concrete building, etc.
Note:
Тулы нь? tha antanna iF an EM Aatdnsr antanna le Inotallar DIT TT TT TT TTT
Er IFW fl =| PAL RPE? NEI ALTFI ITILA NF ART E FF ARA LA IELTS ND RE OA CPE CA -
AA ss -- ==
ARS loan antanna
Fan aa FT
(Included)
3) | i |
J
FR
AM outdoor antenna
(not inciuded)
zz af] |
Vinyl-covered wire
(not Included)
/ This unit
AM ANT EY - ao —-
ES -
AM LOOP ANT
1 : = an LL -
( АМ loop antenna (included) > When mounting the antenna to the unit
Connect the AM loop antenna to the AM loop antenna terminals,
and mount it vertically to a column, a wall or rack.
= [f this antenna is not properly installed, MWI/LW broadcasts will
not be received.
+ Be sure to connect the AM loop antenna even when an outdoor
antenna is used,
Pay attention to the following points when mounting the
antenna.
+ Do not mount it horizontally (Doing so will impair reception).
= Do not mount it close to power cords, speaker wires or metal
surfaces (Doing so will result in noise).
* Do not mount it close to a tape deck, When the tape deck is be-
ing used, chirping or beeping sounds may result.
When mounting the antenna to a column, a wall
or rack
Mount it vertically.
Move the antenna toward the right or left to find the point of best
ti i ite tn, ll] te m
DELL.
This type of installation may cause impaired reception or result in
signal noise. If possible, mount the antenna to a column, a wall or
rack.
Move the antenna toward the right or left to find the point of best
reception.
Rear panel of —
the unit
AM antenna holder
{included)
Screws (included)
AM antenna holder |
| (included) \
C AM outdoor antenna (not included) р
An outdoor antenna may be required In a mountainous region, or
if this unit Is located inside a reinforced-concrete building, etc.
Use 5—12 m of vinyl-covered wire horlzontally at the window, or
convenient location.
Note:
When the unit is not in use, disconnect the outdoor antenna to
prevent possible damage that may be caused by lightning. Never
use an outdoor antenna during an electrical storm.
“|
7 Connections (continued)
| Connection to speaker systems | | To set the power voltage !
Right speaker Left speaker Set the voltage selector to the voltage setting for the area in
system —— system which the unit will be used.
{not inciuded) a {not included) _ De {Use 2 minus {—) screwdriver] — ana _
This unit
Q
Speaker connection cables |
{not included) | |
co ‘ |
This unit Note: :
Note that this unit will be seriously damaged if this setting is not
made correciiy.
ji o Y ` ia fn
MW “B” terminals
For connection to a second palr of speakers. | To connect the AC power supply cord |
E Speaker impedance (included)
. wW ly the “A” only the “B” speak e con
416 ohms. ° or only The TB" Speakers are connected Connect the AC power supply cord (included) after all other
«When both the "A" and the “B” speakers are connected cabies are connected.
simultaneously: 8— 18 ohms. a
FOR UNITED KINGDOM ONLY
BE SURE TO READ THE CAUTION FOR THE
AC POWER SUPPLY CORD ON PAGE 3
—==={ BEFORE THE FOLLOWING CONNECTION.
aie JE Ar EA = =
To connect speaker connection cables to
terminals
Be sure to only connect positive (+) wires to positive (+) ter-
minals, and negative (—) wires to negative (—) terminals,
This unit
{> Twist the core of the speaker cables. mm
- © a AC INN
15 mm Twist |
A — ms — — ——]]]oLz;—.—— EI TANTA Er r I у
@ Open the lever, and insert the core until K can no tonger be
seen. AC power Supply cord _
= еоны ща ще DIA A AA — (UY a TT === E E nn
\
Household Y
AC outlet
Insertion of Connector
| Even when the connector is pertectiy
($ Close the lever, and pull the cable to assure a proper connec- let used, the front part of the connec-
tion. tor may jut out as shown in the draw.
ing.
Note: However thera is no problem using the
To prevent damage to circuitry, never short-circuit positive (+) unit.
and negative (—) speaker wires.
Remote Control Transmitter
| Insertion of remote control transmitter batteries
1. Open the cover.
2. Insert the batteries.
* De Sure (o insert according io the
{+) and {—) indications in the
battery compartment.
+ Use two UM-4, "AAA" (803: 15 W
size batteries.
3. Close the covar.
M Battery life
Battery life is about one year. (Battery life
may vary depending upon the frequency of
use and other conditions of use.)
The batteries should be replaced if the unit
cannot be operated even when the remote
unit.
Ш Battery notes
» Be sure that batteries are inserted so that
they are placed correctly with respect to
the (+) and (—) indications in the battery
MATEOS If dha attarias ara nat in.
A ROI A] KIT LACARRA Eis PILA PES
serted correctly, they may leak and
damage the remote control transmitter.
+ Do not use rechargeable (nickel-cadmium)
type batteries.
control transmitter is brought close to the.
« Do not mix old and new batteries, or bat-
teries of different types (carbon and
alkaline, etc)
e |[f the remote control transmitter is not to be
used for a long period of time, take cut the
batteries and store them in a cool, dark
place.
e Remove and dispose of worn-out batteries.
+ Never attempt to recharge or short-circuit
the batteries. and do not disassemble them
or expose them to excessive heat or throw
them into a fire.
+ |f a battery leaks, remove both batteries
and dispose of them, and then thoroughly
ciean the battery compartment before in-
eartinn naw hattoriac
a LIFE 4 LA -
TIN FT FA
| Remote control transmitter operation notes
Use the remote control
transmitter within 7 meters.
Face it toward the remote control
signal receptor of this unit.
(Obstacles shouid be
avoided.)
Be sure the transmitter part of the remote control
transmitter and the receptor part of this unit are
free from dust.
Excessive dust might prevent reception.
A CO
= = 962 |
O
Avaid dust
Other notes
1. Do not expose the receptor {on this unit)
to direct sunlight or other strong light,
because to do so might result in incorrect
operation.
2. Do not use a remote control transmitter
for a TV set, a YCR or other video compo-
do so might result in incorrect operation.
nent at the same time as this remote con-
trol transmitter 1s being used, because 10
3. If this unit is installed in a rack with
glass doors, the glass door's thickness
or color might make it necessary to use
the remote control transmitter a shorter
distance from the unit.
Front Panel Controls and Functions
| Tuner section 5
SA-GX230D
Boo
FE ua
“oo oo.
MD Power “ d STANDBY/ON” switch A) Band Indicators (FM, LW, MW)
(POWER, (> STANDBY/ON) indicates the selected band.
Press to switch the unlit from on to standby mode or vice ver-
amount of powe mode. the unit is stil consuming a small au input selector/trequ ency display
(INPUT SELECTOR/FREQUENCY)
Displays the selected source or broadcast frequency.
®
Remote control signal receptor
(REMOTE SENSOR) a
Receives the signals from the remote control.
Memory scan button (MEMORY SCAN)
This button Is used to locate a desired broadcast station;
each broadcast station ls selected for about 3 seconds.
9) “STANDBY?” Indicator (STANDBY)
When the unit is connected to the AC mains supply, this in- (2 Tuning buttons (TUNING)
dicator lights up In standby mode and goes out when the unit These buttons are used for tuning to the desired broadcast
is turned on. station.
@ Channei dispiay (3 Memory bution (MEMORY)
This display shows the channel number selected by one of This button is used when presetting broadcast station fre-
the preset-tuning buttons. quenties into memory. (Refers 10 pages 15-— 16)
Also this display shows the channel number for about 3
seconds during Memory scan operation.
(1 Preset-tuning buttons (1 —0)
(30 CHANNEL RANDOM PRESET TUNING)
E Quartz-lock indicator (QUARTZ LOCK) These buttons are used to preset broadcast frequencies into
This indicator illuminates when the unit is tuned precisely to the memory of this unit and to recall the desired prese! sta-
a broadcast statlon. tions. (Refer to pages 16-17)
6) Memory indicator (MEMORY) (5 Band selactors (FM, LW, MW)
This Indicator illuminates when the memory button Is press- FM: Press this bution 10 listen to an FM broadcast.
ed. LW: Press this button to listen to an LW broadcast.
MW: Press this button to tisten to an MW broadcast
AL LOCATION: When the MW bution is pressed for about 3
@ FM stereo indicator (FM ST) seconds, the MW frequency step will change to 10 kHz per
This Indicator automatically illuminates when an FM stereo step. {This step Is set tc 9 kHz before shipment) in order to
broadcast is being received. return to the original frequency indication, press this button
Note: for about 3 seconds again.
It will not lMuminate if the FM mode selector is set to the
monaural mode.
de FM mode selector (FM MODE)
This unit automaticaliy switches to the stereo mode when an
(a lara amar Indlaatar PM Crean PRE máximo kermadama ES aha Flo las Te a da
NE, LIA Y DUE TENIAN TA LA IV. PITA TN SEO DELICIAS 15 ПЕНЫ. Кб ТЕРПЕЛ OT IS USE 10
This indicator illuminates when the memory scan button is select the mode (stereo or monaural} of FM broadcast
pressed. signals.
| Amplifier section
—_——
De =
177 :
= 8 0 tu = -
o
Lan} AE
E ae Bumper Spa om
see
“Еее СС
TA "7 x ПМЕ Е
(I: Speaker selectors (SPEAKERS)
These selectors are used to select the speaker system(s) {A
and/or B).
Muting indicator (MUTING)
This indicator will illuminate when tha muting button (on the
remota control transmitter) is nressad
Loudness indicator (LOUDNESS)
This indicator will illuminate when the loudness button Is
pressed.
Tape Indicator { 3 )
This indicator will illuminate when the tape-monltor button Is
pressed,
(On the SA-GX130D, it will Hluminate when the tape-
ha EA DD A a ab las mal
ee PIDO SZ
® Volume control (VOLUME)
e
Tone controls (BASS, TREBLE)
The bass control is used to adjust the low-frequency sound
range, and the treble control is used to adjust the high-fre-
quency sound range.
Headphones jack (PHONES)
® Input selector buttons
These buttons are used to select the sound source to be
heard, such as a disc, radio broadcasts, etc. The selected
sound source is shown on the input selector/frequency
display.
The "PHONO” input selector has two functions: when press-
ed momentarily it selects "PHONO”. When pressed and held
tar about 4 seconds, A de-activates the muting function,
(There is no "VCR 2” button on the SA-GX130D.
Pe
SA-GX230D
— JR STR, ooo]
a
La XA
S
di
(. for SA-GX230D ) oo
Tape-monitor button (TAPE MONITOR)
Press this button to listen to a tape.
To listen to some other source, press this button once again
(so that the Indicator Is switched OFF).
(_ fer SA-GX130D )
Tape-monitor/VCR 2 button
(TAPE MONITORIVCR 2)
T
TAPE MONITORS со
VOR?
VCR PHONO
Press this button to listen to a tape or second VCR con-
nected to the "TAPE/VCR 2" terminals.
To listen to some other source, press this button once again
{so that the indicator is switched OFF).
Loudness button (LOUDNESS)
Set to the "ON” position (the loudness Indicator will il-
luminate); when listening to music at low volume, Auditory
perception of sound in the low frequency range falls off at
low volume, but when the switch is in this position, this defi-
clency Is compensated for, so that the full impact of the
musical performance can be enjoyed.
Balance control (BALANCE)
( only for SA-GX230D)
“VCR 2” terminals (VCR 2)
These terminals are used for tape-to-tape recording if a se-
cond VCR is connected here,
Tey
= Mutual Operations
#Tape-monitor button
Before operation, set the volume contral to the "0” position.
7 Set the power switch to ON.
Select the “A” and/or “B” speaker system(s)
to be used.
Check to be sure the tape indicator is по! |-
J luminated.
To listen to sources other than a tape (and VCR 2 for
SA-GX130D), be sure to turn off the tape Indicator.
If the tape indicator is illuminated:
т
Е
Tape Indicator
(for SA-GX230D )
Press the tape-monitor button.
( far SAA MITIN X
EFE MPA MAA SF вы" A
Press the tape- поло 2 button.
VCR 1 TAPE MONITOR; со TUNER
veR2
PROMO
( for SA-GX230D )
Select the sound source.
VCR 1: Press to listen to the playback sound from tha VCR
connected to the “VCR 1” terminals.
VCR 2: Press to listen to the playback sound from the VCR
connected to the "VCR 2" terminals on the front panel.
TAPE MONITOR: Press to listen to tape. (Thé tape in-
dicator will illuminate.)
When listening to tapes is finished, be sure to press the
tape-monitor button to tum off the tape indicator.
CD: Press to listen to compact discs.
TUNER: Press to listen to radio broadcasts.
PHONO: Press to listen to phono discs.
* Volume control
( for SA-GX:30D )
Select the sound source.
VCR 1: Press 10 Hsten to the playback sound from the VCR
connected to the “VCH 17 terminals.
TAPE MONITORIVCR 2: Press to listen to tape cr second
VCR. (The tape indicator will Hluminate )
| When listening to tapes is finished, be sure lo press the
1 tape-monitor/VCR 2 button to turn off the tape in- |
| dicator. |
CD: Press to listen to compact discs.
TUNER: Press to listen to radio broadcasts.
PHONO: Press to listen to phono discs.
Start the sound source.
{Refer to the appropriate operating instructions for details}
G Adjust the volume level.
| After listening is finished |
Be sure to reduce the volume level, and switch the power to
standby mode from the remote control transmitter or by the
power * E STANDEY7/ON” switch cf this un.
Mote: The input selection, loudness and the muting settings will
be retained (as they wera al the time when the power was switch-
ed to standby mode) by the memory back-up function.
e LT ML TRS E
y Loudness indicator ‚BASS: TREBLE,
SA-GX230D ___
Technics A oShTRO STEGES RECENERR - EE
= | =5" ) ITA]
EN CT] e,
La (OE EEN = ноет екон
EL. =
wn “CRT TARE = 1er Faja pr —
LaCie Ля us Ba
= о
тей чаи
LOOM
E Ca a
foi
_7R.
Headphones {not included)
Plug type:
6.3 mm phone plug stereo type
[To adjust to the desired tone
quality
Maco!
¡pao!
Adjust the low-frequency sound to the desired
tone quality.
TREBLE]
Adjust the high-frequency sound to the desired
tone quality.
| To emphasize low-frequency
sound
LOUDNESS ;
Set the loudness switch to “ON” position.
The loudness indicator will illuminate.
(Refer to item 18 an page 11.)
| To adjust the left/right sound balance |
[BALANCE |
Adjust the balance control.
: E um
| |
[LOUDNESS | BALANCE]
| When listening through headphones |
e Use the volume control to reduce the volume level, and con-
nect the headphones to the headphones jack.
e If sound from the speakers is not wanted, set the speaker selec-
tors ("SPEAKERS") to the “OFF” position.
= Avoid listening tor prolonged periods of time to prevent hearing
damage.
Y” Listening to Radio Broadcasts
| Manual tuner operation
To listen to broadcasts by using the tuning buttons.
FM stereo indicator
Have vou completed the steps 1-3 (on page 12)
of “Mutual Operations” ?
1 Press the “TUNER” button.
Press the “FM”, “LW” or “MW” button.
EM: for FM broadcast
LW: for LW broadcast
MW: for MW broadcast
Helore presenting MW broadcast stations, press to select
the appropriate frequency step for your locality. (Refer to
item 15 on page 10.)
Press the appropriate tuning button to tune
to the desired broadcast.
{fRefer 10 "Frequency tuning” below.)
{ IE alas lea avraselua Im ha EM m = \
NE SESSIONS 19 AVES 115 ETE I TUN VILLE 7
[FM MODE)
Press the FM mode selector.
The sound wiil then be heard in monaural and the FM stereo in-
dicator will not illuminate. If the broadcast signal is weak, or if
there is a large amount of interference. sounds can be heard
more clearly,
| Frequency tuning (“TUNING” buttons)
TUNING OT
(-MANUAL — AUTO)
DOWN UP
| |
Press to change |, Press to change the
frequency downward frequency upward.
crm ro sora ee Ls E
AR A A = AA
|
I Automatic tuning Ш a
Press the button. When the frequency indication begins to
selected automatically) Repeat this operation nti the desired
station is found.
E Manus! tuning — _
Prass the button momentarily (trenuency will chance aach time
- — ла = - TT
the button is pressed), and tune to the desired frequencies.
| Memory presettings
|
You can program 30 FM/MW/LW radio broadcast stations into memory, so that any desired station may be selected by simply touching one or
two buttons. There are two methods for presetting broadcast frequencies in the memory: the automatic method (see below) and the manual
method {refer to page 16); select whichever method you prefer.
C Automatic memory presetting
When this method Is used, the frequencies of the selected broad-
cast stations are automatically preset (in sequence to higher fre-
quencies) Into memory: “channeis™ 1 to 30 are available for the
presetting of FM stations, “channels” 21 to 30 are available for
MW stations, and “channels” 27 to 30 are available for LW sta-
tions.
When a presetting Is made to a channel that has already been
preset, the prior presetting wilt be erased, so if, for example, FM
frequencies are preset to channel 1 to 30 and then MW frequen-
cies are preset, the first MW frequency will be preset to channel
21 (thus erasing the FM presetting to channel 21), the second
MW frequency will be preset to 22 (erasing FM 22), and so on.
Have you completed the steps 1 —3 (on page 12)
of “Mutual Operations” ?
1 Press the “TUNER” button.
Press the “FM”, “LW” or “MW” button.
FM: for FM broadcast
LW: for LW broadcast
My: IOF MY Droaacast
Befora presetting MW broadcast stations, press to select
the appropriate frequency step for your locality. (Refer to
item 18 on page 10.)
Set to the frequency from which you want to
start automatic memory presetting.
4 Press and hold the memory button until the
I frequency begins to change.
(Automatic memory presetting will start.)
SA-GX230D
OC
a eng — --
Notes:
e For automatic pressetting in areas where there are fewer than
30 stations for FM broadcasts, the remaining channels will be
left unused. The unused channels can be filled by following
steps 2 through 5 on page 16.
* For MW/LW broadcasts with extremely strong signal transmis-
sions, the frequency memorized may be slightly different than
the correct frequency. H this occurs, make a manual preset-
ting.
e |f a new broadcast station is preset into a channel, the broad-
cast station which was previously entered in that channel will
be automatically erased.
5
Listening to Radio Broadcasts comme
| Memory presettings (continued)
Memory indicator
1
“Stations ¢ can à be freely p preset to any desired channel.
A maximum of 30 broadcast stations can be memorized.
Have vou completed the steps 1—3 (on page 1
SARA ==
of “Mutual Operations” ?
1 Press the “TUNER” button.
Press the “FM”, “LW” or “MW” button.
EM: for FM broadcas!
LL tor ru hrnadeaet
am EW a a TW Ba 1 Ta al el ek
MW: for MW broadcast
Before presetting MW broadcast stations, press to select
the appropriate frequency step for your locality. (Refer to
item 13: on page 10)
Press the appropriate tuning button to tune
to the desired broadcast.
(Refer to “Frequency tuning”, on page 14.)
Press the memory button momentarily.
{The memory indicator will illuminate }
Note:
if the memory button 15 pressed and heid untif the frequen-
cy begins to change, the automatic memory presetting (See
to page 15.) Is activated. To stop the automatic memory
presetting, press one of the tuning bultons (TUNING.
Then begin again from step 3
To cancel the memory function. press the memory button
again.
Select the desired “CHANNEL”.
(Refer to "Ном 10 designate preset channels’ below)
Repeat steps 2 through 5 to make additional
memory presettings; for later reference,
note the presettings In the station memory
fiie on page 17. CT
| How to designate preset channels
To designate channels 1—9:
Press the appropriate (1 —9) preset-tuning button.
Note: When selecting channel 1, 2 or 3. enter the selection
“017,02” or "037. H only “17,2” ar 37 is pressed, channel ac-
cess will be delayed by two seconds.
To designate channals 10 — 30:
1 Press the button for the “tens” digit (1, 2 or 3).
7 Press the button for the "upite™ digit {1 —Q) within 2 seconds
rar Er == wm IF WA Wd er
after pressing the first button.
Note:
If the interval between pressing the first button and pressing the
second button is more than about 2 seconds, the setting may not
be made correctly if this happens, make the setting once again.
When making a memory preseiting manually. once again
designate the channel to be selected after pressing the memory
button.
| Using memory preset
To listen to broadcast stations
preset [nto memory. = 7
E
SA-GX230D
Technics — av CONTA STEREQ RECE VER e o 2 Les к ктото
бе! ‚©... о ©. 0
— — — т - = === — = - _
Memory scan Indicator 8 [MEMORY SCAN | [FM MODE:
Have you completed the “Memory presettings”
on page 15-— 16 and steps 1— 3 of “Mutual Opera-
tions” on page 12 ?
1 Press the “TUNER” button.
Select the desired “CHANNEL”.
(Refer to "How to designate preset tuning" on page 16.)
Channel selection using the memory scan
button
This feature is convenient for use when trying to locate a certain
broadcast, or to listen to each station briefly to hear what is being
broadcast.
[MEMORY SCAN |
Press the memory scan button.
{The memory scan indicator will illuminate.)
Each frequency will then be heard (in sequence) for about 3
seconds.
The preset channel number will be displayed in the channel
display.
Preset channel number
xs ©
Station Memory File (Use this file to record your memory selections.)
When the deslred broadcast ls found:
[MEMORY SCAN:
Press the memory scan button
{The memory scan indicator will switch OFF.)
The broadcast will continue. even after 3 seconds have passed.
( If noisa is excessive In the FM mode 3
[FM MODE:
Press the FM mode selector.
The sound will then be heard in monaural and the FM stereo In-
dicator will not illuminate. If the broadcast signal is weak, or if
there is a large amount of interference, sounds can be heard
more clearly.
| Back-up memory |
Tha harskb. 1 fi motion malntaine +
> = сх глыбы marras amd tha maoat.
E A AE ol pr Da 8 © I 1
METE ERA TE IA KI EA OR RA OY EAR 0d LIE LEA
recent memory (see below) when the power is switched OFF, in
the event of a power failure, or if the power cord is disconnected.
The memory will be maintained for as long as approximately one
month.
Most-recent memory
The most-recent memory system "remembers” the broadcast
station fast tuned to when the unit was switched OFF. That sta-
tion will be automatically tuned to when the power is switched
ON.
if frequency presettings are accidentally erased
from the back-up memory
Make ine frequency preseiiings {on page 15 or 16) ónce again.
The power cord should remain connected for one hour or more
for the memory back-up to be effective.
CH. 1 | CH.2 | CH.3 | CH.4 | CH.5 | CH.6 | CH.7
CH.8a
CH.9 | CH. 10 | CH. 11 | CH. 12 | CH. 13 | CH. 14 | CH. 16
T—e pa 2 — a
CH. 18 | CH. 17 | CH. 18 | CH. 19 | CH. 20 | CH. 21 | CH. 22
CH. 23
CH. 24 CH. 25 | CH. 26 | CH. 27 | CH. 28 | CH. 29
Recording
| Tape recording |
To record on the tape deck connected to the "TAPE” ferminals
{"TAPE /VCR 2” terminals on the SA-GX130D).
Before recording, prepare the tape deck for recording (recording
leve! adjustment, etc).
Sea the tape deck's operating instructions for details.
Have you completed the steps 1 — 3 (on page 12)
of “Mutual Operations” ?
1 Select the sound source to be recorded.
Begin recording.
Follow your tape deck's operating instructions.
3 Begin the sound source to be recorded.
Tape indicator
| VCR (VCR 1) recording (Audio only) |
To record on the VCR connected 10 the “VCR 1" terminals.
Before recording, prepare the VCR for recording (recording level
adjustment, input selector setting, etc.)
Ses the VCH's operating Instructions for details.
Have you completed tha steps 1 — 3 (on page 12)
o! “Mutual Operations” ?
1 Select the sound source to be recorded.
Begin recording.
Follow your VCR's operating Instructions.
3 Begin ths sound source to be recorded.
( To check the sound recorded while — В) Ша
recording is being made
With a tape deck with 3 heads. it is possible to check the sound
= ты ай ий tha om wm
FOWL LITLE EE Ig LEAD:
[TAPE MONITOR]
Press the tape-monitor button on this unit (the
tape Indicator will illuminate), and set the
monitor button on the tape deck to “TAPE”.
(only for SA-GX130D)
On the SA-GX130D model, press the tape-
monitor/VCR 2 button.
= - a A, - - A
See 5 OST VERS ESS EE. ST SEL
CR TAPE MONITOR со TUNER PHOMO
vCA2
во пд DE EEE ES 00 SEGA DLE СТ
| Tape-to-tape recording (Audio only) |
To record from the tape deck connected to the “TAPE” terminals
CTAPENCR 27 terminals on the SA-GX130D) to the VCR con-
nected to the "VCR 17 terminals and vice versa,
Before recording, prepare the VCR (or tape deck) for recording
(recording level adjustment, input selector setting for VCR, etc).
See the operating instructions of each unit for details.
SA-GX230D
A
|
Tape to tape recording from VCR 2 to
VCR 1 (Audio and video) (only for SA-GX230D) OT
( Connections
1b Та |" indicator
[|
— e A —
With a VCR connected to the “VCR 1" terminals and a second
YCR connected to the "VCR 2” terminals, tape-to-tape recording
of video tapes is possible from VCR 2 to VCR 1.
Note:
In this case, be sure to connect the VCR for recording to the
“MCR 1 ыы terminale and tha VEA tor Alava Le tn на ' ICE DO tar.
minals.
БАЙ ЛАЯ + hE 1% - py вы! ый Зы 1 E > E Em Ak
Have you completed the steps 1 — 3 (on page 12)
of “Mutual Operations” ?
Та То record from the tape deck to the >
la ver
Press the tape-monitor button.
The tape Indicator will illuminate.
Note:
You may select any of the input selectors other than
VOR 1.
( only for SA-GX130D)
On the SA-GX130D model, press the
tape-monitor/VCR Z button.
E
VEA! CAPE MONITOR: co TUNER PHONO
VCR 2
1 b To record from the YCR to the tape |
deck
Press the “VCR 1” button.
Begin recording on VCR (or tape deck) and
playback of the tape deck (or VCR).
Follow the operating instructions of each unit.
(only for SA-GX130D)
If a second VCR is connected to the "TAPENCA 2" terminals,
tanetotane recording ‘audio only) is possible by following the
above nrocediures.
ii A =
Video connection cable À
(not included) N 3
Playback VCR {not included) Î e © Stereo connection
. KLEE Wi MUL
=| , QUTPUT
ANTONT > ma
3 - - cable
VIDED 1 4 | {not Included)
cs
(Rear side)
1 Press the “VCR 2” button.
( Operations В
Have you completed the steps 1 —3 {on page 12)
of “Mutual Operations” ?
Start recording on the VCR 1 and playback
the tape on the playback VCR (VCR 2).
(See the operating instructions of each VCR.)
Remote Control Operation
This remote control can be used to operate units manufactured
by this company other than this receiver unit, including CD
players/changers, tape decks and also TVs and VCRs.
For detailed information concerning operation steps etc., please
refer to the appropriate page for each unit manufactured by this
company (other than this receiver unit) including CD
players/Changers, tape decks and also Tvs and VCRs.
Furthermore, the remote control may not operate the unit in
some cases due to differences in the remote control signal. (Ses
page 22.)
| Before Use |
In order to minimize the number of buttons on the remota control,
buttons [A] ¡B] and Cc] each perform a variety of functions.
In order to ensura correct oneratioan, be sure lo carefully read tha
Tr gr ra Y Ry RN WT OE wr we RR RF WER RA a We | mma = чая
explanations provided below.
Ter w =) e |
CET
E С STE = =
ses 5
SOL
DOS
SEOa
DECK #2 a BHP we
OME
©]
For ir
JL Г J
A! Power button
This button is used to switch the receiver, TV, and VCR on
and off.
TVIVCR channsi selsct buttons
These buttons are used to change the channel for both the
TV and the VCR.
[=]
le)
Numeric buttons
These buttons are used for the following two functions.
{1} Tn calart a nraceat rhannal nr tha rasaibar
To FE A pra Tr DE AFR FE RIA Fa YA
(2) To select a disc or track on the CD playerichanger.
NOTE
To operate, first press the [TUNER], [TV], or button on the
remote contro! to select the appropriate mode for the unit you
wish to operate. and than proceed.
“Yo designate channeis 10— 30:
| To control the receiver |
(TUNER
Press this button to switch the input of the receiver and the opera-
tion mode of the remate contro! to “TUNER.
POWER]
Press this button to turn the unit ON and OFF. When this button is
used. be sure to first press TUNER” button.
m - ©
Press these buttons to select the desired preset channel.
When these buttons are used, be sure to first press the "TUNER"
button.
To designate channels 1— 9:
Pracc the annmnriate ri —Q preset tuning button.
(D Press the button for the “tens” digit {1. 2 or 3).
@ Press the button for the "units" digit (1 —0) within 2 seconds
after pressing the first button.
if the interval between pressing the first button and pressing the
second button is more than about 2 seconds, the setting may not
be made correctly. if this happens, make the setting once again
65]
Press this button to switch the input of the receiver to "CD".
TAPE!
Press this button to switch the input of the receiver to "TAPE".
Гуси +:
Press this button to switch the input of the receiver lo "VCR 17.
MUTINC!
Press this button to temporarity reduce the volume level.
The volume levei is attenuated by 20 dB {approx 1/10)
Press once again to retum to the previous volume fevel.
E Ta PE
Press one of these buttons to adjust the volume levet.
[=n yma a)
== |
== eh] =" - ==.
Fr
POWER
[| со
С СЭ ССЭ
т TVACH 4 TAPE
SS -
р
(>
VCR
PLAY — MSTOP
REMOTE CONTROL TRANSMITTER
FAK - Ean KH
| To contro! the compact disc player |
[cD
Press this button to switch the numeric buttons to control the CD
player!/changer.
—
NOTE
in this case, the input of the receiver also switches to "CD".
If a Technics CD changer is used in combination with thls unit,
the disc to be played can be selected by first pressing this button
and then pressing the appropriate numeric button ( 1 — {5 ).
[ — © (016;
Press these buttons to select the desired track.
Playback begins from the track selected.
When these buttons are used, be sure to first press the "CO" but-
ton.
Tracks 1—9:
Press the appropriate numeric button 1! — © directly.
To select a two-digit track number over 10:
Press the [CD+10 button the necessary number of time to select
the "tens” digit, and then one of the [1] — ivi buttons to select the
“units” digit.
¡PROGRAM MODE
Press this button to select the desired play mode (“program
mode” ar “sequential mode’). If you have a Technics changer,
you can select “delete mode”,
FFE) bed |
1 = TTR Ww ww [. J
Press one of these buttons briefly to move the pick-up to the
beginning af a specific track.
Y
PLAY.
Press this button to start play.
E STOP
Press this button to stop play.
When operating a compact disc player with a remote contro! sen-
sor, face this remote control transmitter toward the remote con-
trol sensor of the compact disc player.
co
FELAY STOP
At.
RENTE CONTROL TRANSMITTEH
RAK-SAOITXH
| To control the tape deck |
pere
Press this button to select the deck ("DECK 1" or "DECK 2'') to
be controlled.
PLAY
Press one of these buttons to begin playback or recording, select:
ing the button corresponding 10 the side of the tape to be played
back (or recorded).
D> : For the "forward (Ay' side of the tape
«€ : For the "reverse (B)” side of the tape
Depending on which Technics tape deck is used in combination
with this unit, tape deck 1 might be the “A"-side playback-only
type.
Fe >
Press one of these buttons to advance or rewind the tape while
the unit Is In the stop mode.
Press one of these buttons to select the desired tune while the
unit is in the play mode. (Only applicable to a Technics tape deck
with the “music select” functions.)
-I STOP
Press this button to stop tape movement.
Remote Control Operation mes
Ee
Jo
Sol
ODO OE
EEE EE es
тет
SE Tes pe pr pe
MUTIG - +
CN |
REMOTE CONTROL TRAMSAHTTER
MA - Bal XM
| To control TV |
To perform the following operations, aim the remote control at
the TV.
Tv)
Press this button to set the power button and TVIVCR channel
select buttons to the TV mode.
POWER:
Press this button to switch the unit ON and OFF.
When this button is used, be sure to first press ‘TV button.
| TV/VCR ry
Press these buttons to change the channel on the TV.
| To control VCR |
NOTE
When pressing the POWER), Y TVIVCR 4), > PLAY. and ME STOP but-
tons, atm the remote control at the VCR.
VCR]
Press this button to switch the power button and TY/VCR channel
select buttons to the YCR mode,
ГУСЯ т)
Press this button to change the input selector on the receiver to
the "VCR 17 position,
POWER
Press this button to switch the unit ON and OFF.
When this button is used, be sure to first press "VCR" button.
Y TVIVCA A
Press these bu
m PLAY]
Press this button to begin play on the VCR.
E STOP:
Press this button to stop play on the VCR.
To operate VCR 2, set the input selector on the receiver to the
VCR 2 position.
If you operate a TV, VCR, CD player {or CD changer) or à tape
deck using this remote control, the unit may fail to operate
due to the differing nature of the remote contro! signa!
if the remote control falls to operate:
It Is necessary to reprogram the signal within the remote con-
trol by following this simpie procedure.
4 a
Os
DO С
DOOOO
EE
СЭ со 5 се
a ma po
doser
a
USA
For CD player (or CD changer) operation
POE со Press POWER and CD simultanecusty, hotd
tor 7 seconds.
Jo
For TV operation
poses Press POWER and TV gimultaneousty, hold
= for 2 seconds. i
For VCR operation
Press POWER and VCR simultaneously.
= hold for 2 seconds.
as
LJ
For Tape deck operation
Press POWER and TAPE simultanecusiy,
hold for 2 seconds.
Depending on the model, there may be cases where opera-
tion is still not possible even if the remote contra! signal is
switched over due to differences in frequency range
+ characteristics.
BL I-II A a E E LT = == == = по т = Еле STEER CORTE ST = “те.
Suggestions for Safety
ll Use a standard AC wall outlet
1. Use from an AC power source of high voltage, such as for
an air conditioner, is very dangerous.
There Is the possibility that a fire might be caused by making
such a connection.
A DC power soLirce Cannot bes used.
Be sure to check the power source carefully, especially on a
ship or other place where DC is used.
№
Hl Grasp the plug when disconnecting the power
supply cord
1. Wet hands ars dangerous.
A dangerous electric shock may result if the plug is touched
by wet hands.
2. Never place heavy items on top of the power supply cord,
and never force it to bend sharply.
El Place the unit where it wil! be well ventilated
Place thls unlit at least 10 cr (4°) away from wall surfaces, etc.
Be careful that curtains and similar materials do not obstruct the
ventilation holes,
ll Avoid places such as the following:
In direct sunlight or in other places where the temperature is
high.
in piaces where there is excessive vibration or humidity.
Such conditions might damage the cabinet and/or other compo-
nent parts and thereby shorten the unit's service life.
H Be sure to place the unit on a flat, level sur-
face.
If the surface Is Inclined. a malfunction may result.
EN Never attempt to repair or reconstruct this
unit
A serious electric shock might occur if this unit is repalred,
disassembled or reconstructed by unauthorized persons, or if the
Internal parts are accidentally touched.
\
IB Take particular care if children are present
Never permit children to put anything, especially metal, inside
this unit. A serious electric shock or malfunction could occur if
articles such as coins, needles, screwdrivers, etc. are Inserted
through the ventilation holes, atc. of this unit.
H If water Is spliled on the unit
Be extremely careful if water is spilled on the unit, because a fire
or serious electric shock might occur. Immediately disconnect
the power cord plug, and consult with your dealer.
Hl Avoid spray-type insecticides
Insecticides might cause cracks or “cloudiness” in the cabinet
and plastic parts of this unit. The gas used in such sprays might,
moreovar, be ignited suddenly.
HB Never use alcohol or paint thinner
These and similar chemicals should never be used, because they
might cause flaking or cloudiness of the cabinet finish,
Ш Disconnect the power supply cord if the unit
wlll not be used for a long time
If the unit is left for a long time with the power ON, this will not
only shorten its useful operation life, but may aiso cause other
troubles.
Hi If trouble occurs
if, during operation, the sound is interrupted or indicators no
longer illuminate, or if abnormal odor or smoke Is detected, im-
mediately disconnect the power cord plug, and contact your
dealer or an Authorlzed Service Center,
|
Troubleshooting Guide
Before requesting service for this unit, check the chart below far a possible cause of the problem you are experiencing. Some simple chacks ara
minor adjustment on your part may eliminate the problem and restore proper operation
If you are in doubt about some of the check points, or if the remedies indicated in the chart do not solve the problem, refer to the directory of
Authorized Service Centers (enciosed with this unit) to locate a convenient service center, Or consul your Technics deater for instructions.
Problem
Probable cause(s)
жет
Т
i
L
Sugge sated remedy —
laa ем ны —
|
While listening to FM broadcasts
An unusual hissing noise is
heard when listening to the
broadcast in stereo, but not
heard when listening
monauraliy.
A slight noise may be heard bacause the method = Try reducing the treble sound by using the treble
used for modulation of FM stereo broadcasts is
different than that used for monaural broadcasts.
Noise is excessive in both
stereo and monaural
| rr ry
RAIL SD ERA.
Poor location and/or direction of the antenna.
Transmitting statlon Is too far away.
= Try changing the location, height and/or direction of
|. H an indoor antenna is being used chanas to an
control.
« Sat the FM mode selector 10 the monaural position.
{Note tha! the broadcast wii then be heard as
monaural sound.)
the antenna.
outdoor antenna.
= Try using an anienna with more elements
The FM stereo indicator or
the quartz lock indicator
flickers, without completely
illuminating.
Poor location and/or direction of tha antenna.
Transmitting station is too far away.
Excessive distortion in the
sound of stereo
broadcasts.
Nearby building or mountain.
[Multipath distortion is being caused by the mutual
interference of broadcast signals received
directly from the transmitting station {direct
waves) and signals being reflected from nearby
buildings or mountains {reflected waves).]
e Try using an antenna with more elements.
« Try changing the location, height and/or direction of
the antenna.
= If an indoor antenna is being used, change to an
outdoor antenna.
Sound is distorted,
“popping” noise is heard,
and/or the volume level
becomes low.
Broadcast signals are being disturbed by nearby
automobile traffic or alrplanes.
* Relocate the antenna and the connection wires toc a
piace farther away from where automobites pass.
While listening to AM broadcasts
"5-е FRI El
mu ==
An unusual “bast” sound is
heard.
Unit is being used at tha same time as the
television set
e Turn off the television set, or use this unit farther
away from it.
interference from adjacent broadcast signal.
* Try reducing the treble sound by using the treble
control.
A low-pitched “hum” sound
is heard when the
broadcast is tuned.
The AM loop antenna connection wires are 100
close to thé power cord.
» Place the antenna connection aires and the power
card farther apart.
- “ее =.
: The power supply frequency from the power cord
: is modulated and heard from the speakers.
* Install a special outdoor antenna.
A strange hissing noise is
produced continuously or
intermittently.
_ Caused by the “discharge phenomenon" and the
‘oscillation phenomenon’ of electric appliances
(such as fluorescen! lights, TV, small series-type
= Try placing this unit farther away fom such
equipment.
» Install noise-prevention equipment on this unit or on |
motors, rectification equipment, stc.}
=—
the electric lian
io E IA т
т Е == -- - Err FC er re A = а
К
Problem
Problems noted at
all times
Power will not switch ON.
The power cord plug is not completely inserted.
- «Confirm that the power cord plug is connected
completely.
No sound is heard when the
powar is switched ON.
“The speaker selectors are incorrectly set to the
“OFF” position.
. *Set to the “ON” position.
The incorrect Input selector has been pressed.
» Check to be sure that the correct selector is
pressed.
Tape indicator is illuminated.
# Press the tape-monitor button (tape-monitor/VCR 2
button on the SA-GX130D) to turn off the tape
indicatar
FF Ll By
Connections are incomplete or incorrect to the
speaker systems, etc. .
* Check to be sure that all connection wlres are
correctly connected.
Sound stops during a
performance, or no sound
is heard when the power is
switched ON.
The protection circuitry has functioned because
the positive and negative speaker connection
wires are “shorted” or speaker systems with an
impedancs less than the indicated rated
impedance of this unit are used.
» Switch off the power, and, after determining and
correcting the cause, switch on the power once
again.
* Use a speaker system of the proper impedance
rating.
When listening to stereo
sound, the sound lacks
depth (La. thin bass, tinny
sound.)
One of the speakers is connected out af phase
(+) +(—h(-) — (+).
* Heconnect the speakers, malntalning proper polarity
[Le.. (+) > (+) (-) > (—)]
EA FE E E E A
wien ¡Stenming to siereo
sound, the left and right
sounds are reversad.
Tre {eft and right Ss
connections are reversed.
‚ = Check ail connections and correct them if necessary.
À low-pitched noise (“hum”
or “buzz” is heard.
. The power cord or a fluorescent light, etc. is near
: the connection wires. :
* Try separating this unit as far as possible from the
electric appliance.
Sound is not heard from
one of the speaker
systems.
The speaker wires are disconnected.
- «Check and correct the connections of the speaker
wires.
: The balance control is set tog far to one side.
e Set so that sounds are heard at the center, between
the speaker systems.
While using the remote control transmitter
The remote control
transmitter does not
function.
¡ Batteries are Incorrectly placed
- e Insert the batteries so that the positive { +) and
negative (—) polarities are correct.
- The remote control transmitter batteries are
- consumed.
; «Replace them with new batteries.
; There is an obstruction between the remote
© control transmitter and this unit.
* Remove the obstruction.
The remote control transmitter is not correctly
~ facing this unit.
+ Face the remote control transmitter correctly
toward this unit.
Maintenance
To clean this unit, use a soft, dry cloth,
Fot vary dirty surfaces, dip 2 soit cioth in a weak soap-and-watet
solution and wring well. After cleaning, wipe with a soft, dry cloth.
Never use alcohol, paint thinner, benzine, or a chemically treated
cloth to clean this unit.
Such chemicals may damage the unit's finish.
Technical Specifications wm as soo
E AMPLIFIER SECTION
Power output
DIN 1 kHz (T.H.D. 1%) (SA-GX230D} : 2 x 80 W (4 M
[SA-GX130D1 : 2 x 60 W (4 ©)
40 Hz— 20 kHz continuous power output
both channels driven
[SA-GX230D] : 2 x 50 W (8 ©
[SA-GX1300) : 2 x 40 W (6 O)
Total harmonic distortion
rated power at 40 Hz— 20 kHz
half power at 1 kHz
Intermodulation distortion
0.5% (8 Y
0.03% (8 ©)
rated power at 80 Hz: 7 kHz = 4:1, SMPTE 05% (8 0)
Power bandwidth
both channels driven, — 3 dB
FS oe evn om ee om. JE an. zn as
HEaIpPINY 1aGion
Input sensitivity and impedance
PHONO 3 mv/ia7 kQ2
CD, VCR 1 200 mV/22 KO
VCR 2, TAPE : [SA-GX230D] 200 mV/22 ко.
TAPE/VCR 2 : [SA-GX130D] 200 mVi22 «2
PHONO maximum input voltage (1 kHz, RMS) 150 mV
SIN at rated power (В 52)
PHONO 70 dB (IHF, A: 80 di)
CD, VCR 1 80 dB (HF, A: 90 dB)
VCR 2, TAPE : [SA-GX230D]
TAPENCR 2 : [SA-GX130D]
Frequency response
PHONO
10 Hz-— 40 kHz (8 Y
AÑ ÍA FA
“(0 1d)
80 dB (IHF, A: 90 dB)
80 dB (IHF, A: 90 dB)
RIAA standard curve
+0.8 dB (30 Hz— 15 kHz)
CD, VCR 1
VCR 2, TAPE : [SA-GX230D]
TAPE/VCR 2 : (SA-GX130D1
Tone controls
10 Hz— 46 kHz (+3 dB)
10 Hz—40 kHz {£3 dB)
10 Hz—40 kHz (3 dB)
Bass 50 Hz, +10 dB ta — 10 de
Treble 20 kHz, +10 dB to —10 dB
Loudness control (volume at —30 dB) 50 Hz, +9 de
Output voltage
VCR 1 OUT 200 mV
ТАРЕ REC (OUT) : [SA-GX230D] 200 mV
TAPE/VCR 2 REC (OUT) : FSA-GX 13001 200 mv
Channei balance, 250 Hz—6.3 kHz +1 dB
Channel separation 55 dB
Headphones output level and impedance 430 mv/330 Q
Load impedance
AorB 40-160
A and B 80-160
Ш FM TUNER SECTION
Fraquency range
Sensitivity
SIN 30 dB
S/N 26 dB
SIN 20 de
IHF usable sensitivity
IHF 46 dB stereo quieting senaltivity
Total harmonic distortion
MONO
STEREO
87.50— 108.00 MHz
1.5 UV (75 O)
1.3 uy (75 O)
1.2 UY (75 à
1.5 UV (HF'58, 75 O)
22 kY/75 0
0.2%
0.3%
SIN
MONO ED dB 75 de, 1HF)
STEREO 58 dB 171 de. IHA)
Frequency responsa 20 Нх- 15 kHz. +1 da, —2 dB
AIRSIMALS GHENT SEC)
+ 400 kHz 65 dB
Capture ratio 1.008
Image rejection at 98 MHz 40 dB
IF rejection at 98 MHz 70 48
Spurious response rejection st 98 MHz 70 de
AM suppression 50 de
Stereo separation
1 kHz 40 48
Carrier leak
19 kHz —55 dB {-— 60 dB, IHF)
38 kHz — 50 dB {(- 55 JB, IHF)
Channel! balance (250 Hz— 6.3 kHx) +1.5 d8
Limiting point 1.2 НУ
Bandwidth
iF amplifier +80 kHz
FM demodulator 1000 kHz
Antenna terminals 75 Q (unbalanced)
EH AM TUNER SECTION
Frequency range
MW 10011522 kKHz— t611 kHz (9kHz steps)
В В 530 kHz — 1620 kHz (10-kHz steps)
¿W 144 kHz — 288 kHz
Sensitivity am
MW — 20 pV. 320 pvim
LW 45 uv
Selectivity
MW {at 999 kHz) 55 dB
LW (at 252 kHz} 55 dB
Image rejection
MW {at 999 kHz) 40 dB
LW (at 252 kHz) 40 d8
IF rejection
MW {st 989 КНУ) 85 dB
LW (nt 757 kHz) 55 de
E GENERAL
Fower consumption (SAGX230D] : 250 W
(SAGX 1300] : 200 W
Power supply AC 50 Hz/SC Hz, 230 V/240 Y
Dimensions (WxHxD) 430 x 125 x 305 mm
Welght [SA-GX230D1] : 7 kg
[SA-GX130D]) : 6.5 kg
Notes:
1. Specifications are sublect to change without notice.
Weight and dimensions are approximate.
2. Total harmonic distortion ls measured by the dighta! spectrum
analyrer.
This apparatus was produced to 55 800.
Was this manual useful for you? Yes No
Thank you for your participation!

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project

Download PDF

advertisement
