Recordable DVD
Home Theater System
INTRO
7061en.book
Model No.
Operations Guide
SC-HT1000
Dear customer
Region number supported by this unit
Thank you for purchasing this product. For optimum performance
and safety, please read these instructions carefully.
Region numbers are allocated to DVD players and software
according to where they are sold.
Before connecting, operating or adjusting this product, please read
these instructions completely. Please keep this manual for future
reference.
≥The region number of this unit is “1”.
≥The unit will play DVDs marked with labels containing “1” or
“ALL”.
Example:
ALL
1
2
4
INFO
1
[For\U.S.A.]only]
The warranty can be found on page 54.
[For\Canada]only]
The warranty can be found on page 55.
PP p q
SETTINGS
RADIO &
SOUND
EDITING
ON-SCREEN
DISPLAYS
PLAYING
Before using this product, perform setup and connections
after carefully reading the Setup Guide.
RECORDING
Operating Instructions
RQT7061-1Y
F0603NT1063
7061en.book
2 ページ
2003年7月1日 火曜日 午前11時44分
Accessories
Please check and identify the supplied
accessories. Use numbers indicated in
parentheses when asking for replacement parts.
INTRO
Only for U.S.A.: To order accessories contact 1-800-332-5368
or the website (http://www.panasonic.com).
Only for Canada: To order accessories, call the dealer from
whom you have made your purchase.
∏ 1 Remote control
(EUR7624KP0)
∏ 2 Batteries
for remote control
System
SC-HT1000
Main unit
SA-HT1000
Front speakers
SB-PF1000
Center speaker
SB-PC1000
Surround speakers
SB-PS1000
Active subwoofer
SB-WA351
Operations in these instructions are described mainly with
the remote control, but you can do the operations on the
main unit if the controls are the same.
The remote control
∫ Batteries
∏ 2 AC power supply cords
(RJA0065-1D)
Opening the rear cover.
1
Closing the rear cover.
Press with your
finger.
PU
SH
∏ 1 Video cable
(RJL1P016B15A)
+
PU
SH
∏ 1 75 ≠ coaxial cable
(K1TXAAA00001)
3
-
2
∏ 1 System cable
(K1HA25HA0001)
∏ 1 AM loop antenna
(N1DAAAA00002)
∏ 1 FM indoor antenna
(RSA0007-L)
∏ 3 Speaker cables
1a4 m (13 foot) cable (REE1203A-J)
2a10 m (33 foot) cables (REE1203C-J)
∏ 1 DVD-RAM disc
∏ 1 Sheet of speaker-cable stickers
Slide into place.
-
+
≥When the cover
comes off
1
R6/LR6, AA, UM-3
PU
SH
2
≥Insert so the poles (i and j) match those in the remote control.
≥Do not use rechargeable type batteries.
Do not:
≥Mix old and new batteries.
≥Use different types at the same time.
≥Heat or expose to flame.
≥Take apart or short circuit.
≥Attempt to recharge alkaline or manganese batteries.
≥Use batteries if the covering has been peeled off.
Mishandling of batteries can cause electrolyte leakage which can
damage items the fluid contacts and may cause a fire.
Remove if the remote control is not going to be used for a long
period of time. Store in a cool, dark place.
[Note]
∏ 1 Antenna plug
(K2RC021B0001)
If you cannot operate the unit or television using the remote control
after changing the batteries, please re-enter the codes (television
➡page 11, main unit ➡page 42).
∫ Use
∏ 8 Front speaker screws
4 large screws (XSS6i14FZ)
4 small screws (XSN5i10FN)
[Note]
The included AC power supply cord is for use with this unit only.
Do not use it with other equipment.
(U.S.A. only)
Product Registration Card
Please complete and return the included product registration card,
or register via the Internet at: http://www.prodreg.com/panasonic/
RQT7061
2
Aim at the sensor, avoiding obstacles, at a maximum range of 7 m
(23 feet) directly in front of the unit.
7061en.book
3 ページ
2003年7月1日 火曜日 午前11時44分
Table of contents
