Operating Instructions
LCD PROJECTOR
Model No.
PT-AE500U
Before operating this product, please read the instructions carefully and save this
manual for future use.
For assistance, please call : 1-888-View-PTV(843-9788)
or send e-mail to : [email protected]
or visit us at www.panasonic.com
(U.S.A)
For assistance, please call : 787-750-4300
or visit us at www.panasonic.co.jp/global/
(Puerto Rico)
TQBJ 0133
ENGLISH
R
This instruction booklet provides all the necessary operating information that
you might require. We hope it will help you to get the most out of your new
product, and that you will be pleased with your Panasonic LCD projector.
The serial number of your product may be found on its back. You should
note it in the space provided below and retain this booklet in case service is
required.
Model number: PT-AE500U
Serial number:
IMPORTANT SAFETY NOTICE
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
Power Supply: This LCD Projector is designed to operate on 100 V – 240 V, 50 Hz/60
Hz AC, house current only.
CAUTION: The AC power cord which is supplied with the projector as an accessory can
only be used for power supplies up to 125 V, 7 A. If you need to use higher
voltages or currents than this, you will need to obtain a separate 250 V
power cord. If you use the accessory cord in such situations, fire may result.
CAUTION: This equipment is equipped with a threepin grounding-type power plug. Do not
remove the grounding pin on the power
plug. This plug will only fit a groundingtype power outlet. This is a safety feature.
If you are unable to insert the plug into
the outlet, contact an electrician. Do not
defeat the purpose of the grounding plug.
Do not remove
WARNING:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION: To assure continued compliance, use only shielded interface cables when
connecting to computers or peripheral devices.
Any unauthorized changes or modifications to this equipment will void the
users authority to operate.
WARNING:
Not for use in a computer room as defined in the Standard for the Protection
of Electronic Computer/Data Processing Equipment, ANSI/NFPA 75.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.
2-ENGLISH
Declaration of Conformity
Model Number:
PT-AE500U
Trade Name:
Panasonic
Responsible party: Matsushita Electric Corporation of America.
Address:
One Panasonic Way Secaucus New Jersey 07094
Telephone number: 1-888-View-PTV(843-9788)
This device complies with Part 15 of the FCC Rules, Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
ENGLISH-3
Preparation
Dear Panasonic Customer:
Preparation
IMPORTANT SAFETY NOTICE ...2
Precautions with regard to
safety .........................................5
Accessories .................................9
Before use ....................................9
Location and function of each
part...........................................11
Getting started
Setting-up...................................16
Projection methods, Projector
position, Projection distances
Connections...............................18
Connecting to video equipment,
Connecting to equipment
compatible with YPBPR (CBCR)
signals,
Connecting to computer
Preparation for the remote
control unit..............................21
Basic operation
Turning on the power................22
Turning off the power................24
Useful functions
Correcting keystone distortion ...26
Selecting the picture mode.......27
Setting the aspect ratio.............28
Turning on the button lights.....30
Pausing a picture.......................30
Retrieving the saved picture
settings....................................31
Adjustments and settings
On-screen menus ......................32
Menu screens, Menu operation
guide, Returning a setting to the
factory default
Adjusting the picture.................36
PICTURE MODE, CONTRAST,
BRIGHT, COLOR, TINT,
SHARPNESS, COLOR TEMP.,
AI, ADVANCE MENU,
MEMORY SAVE, MEMORY LOAD,
4-ENGLISH
Precautions with regard to safety
TV-SYSTEM, SIGNAL MODE,
Projecting sRGB-compatible pictures
Adjusting the position...............40
Horizontal position, Vertical position,
DOT CLOCK, CLOCK PHASE,
ASPECT,AUTO SETUP
Turning off the picture
momentarily (SHUTTER)........41
Changing the display language...41
Option settings ..........................42
OSD, Noise Reduction (NR),
PC PRIORITY, BACK COLOR,
EDID, FRONT/REAR,
DESK/CEILING, FAN CONTROL,
LAMP POWER, LAMP RUNTIME
Care and maintenance
When the TEMP indicator and the
LAMP indicator are illuminated...44
Cleaning and replacing
the air filter ..............................46
Replacing the lamp unit ............47
Before calling for service..........50
Cleaning and maintenance .......51
Others
Specifications ............................52
Appendix ....................................54
List of compatible signals,
Connector pin wiring, Projection
dimensions calculation methods
Dimensions ................................57
Trademark acknowledgements...58
WARNING
If a problem occurs (such as no image or no sound) or if you notice
smoke or a strange smell coming from the projector, turn off the power
and disconnect the power cord from the wall outlet.
B Do not continue to use the projector in such cases, otherwise fire or
electric shocks could result.
B Check that no more smoke is coming out, and then contact an Authorized
Service Center for repairs.
B Do not attempt to repair the projector yourself, as this can be dangerous.
Do not install this projector in a place which is not strong enough to
take the full weight of the projector.
B If the installation location is not strong enough, it may fall down or tip over,
and severe injury or damage could result.
Installation work (such as ceiling suspension) should only be carried
out by a qualified technician.
B If installation is not carried out correctly, there is the danger that injury or
electric shocks may occur.
If foreign objects or water get inside the projector, or if the projector is
dropped or the cabinet is broken, turn off the power and disconnect the
power cord from the wall outlet.
B Continued use of the projector in this condition may result in fire or electric
shocks.
B Contact an Authorized Service Center for repairs.
Do not overload the wall outlet.
B If the power supply is overloaded (for example, by using too many
adapters), overheating may occur and fire may result.
Do not remove the cover or modify it in any way.
B High voltages which can cause fire or electric shocks are present inside
the projector.
B For any inspection, adjustment and repair work, please contact an
Authorized Service Center.
Clean the power cord plug regularly to prevent it from becoming
covered in dust.
B If dust builds up on the power cord plug, the resulting humidity can
damage the insulation, which could result in fire. Pull the power cord out
from the wall outlet and wipe it with a dry cloth.
B If not using the projector for an extended period of time, pull the mains
plug out from the wall outlet.
ENGLISH-5
Preparation
Contents
6-ENGLISH
Do not look into the lens while the projector is being used.
B Strong light is emitted from the projector’s lens. If you look directly into this
light, it can hurt and damage your eyes.
B Be especially careful not to let young children look into the lens. In
addition, turn off the power when you are away from the projector.
Do not place your hands or other objects close to the air outlet port.
B Heated air comes out of the air outlet port. Do not place your hands or
face, or objects which cannot withstand heat close to this port, otherwise
burns or damage could result.
Replacement of the lamp unit should only be carried out by a qualified
technician.
B The lamp unit has high internal pressure. If improperly handled, explosion
might result.
B The lamp unit can easily become damaged if struck against hard objects
or dropped, and injury or malfunctions may result.
When replacing the lamp, allow it to cool for at least one hour before
handling it.
B The lamp cover gets very hot, and contact with it can cause burns.
Before replacing the lamp, be sure to unplug the power cord from the
wall outlet.
B Electric shocks or explosions can result if this is not done.
Caution
Do not cover the air inlet or the air outlet.
B Doing so may cause the projector to overheat, which can cause fire or
damage to the projector.
B Do not place the projector in narrow, badly ventilated places such as
closets or bookshelves.
Do not set up the projector in humid or dusty places or in places where
the projector may come into contact with smoke or steam.
B Using the projector under such conditions may result in fire or electric shocks.
When disconnecting the power cord, hold the plug, not the cord.
B If the power cord itself is pulled, the cord will become damaged, and fire,
short-circuits or serious electric shocks may result.
Always disconnect all cables before moving the projector.
B Moving the projector with cables still attached can damage the cables,
which could cause fire or electric shocks to occur.
Do not place any heavy objects on top of the projector.
B Failure to observe this may cause the projector to become unbalanced
and fall, which could result in damage or injury.
Do not short-circuit, heat or disassemble the batteries or place them
into water or fire.
B Failure to observe this may cause the batteries to overheat, leak, explode
or catch fire, and burns or other injury may result.
ENGLISH-7
Preparation
Do not do anything that might damage the power cord or the power
cord plug.
B Do not damage the power cord, make any modifications to it, place it near
any hot objects, bend it excessively, twist it, pull it, place heavy objects on
top of it or wrap it into a bundle.
B If the power cord is used while damaged, electric shocks, short-circuits or
fire may result.
B Ask an Authorized Service Center to carry out any repairs to the power
cord that might be necessary.
Do not handle the power cord plug with wet hands.
B Failure to observe this may result in electric shocks.
Insert the power cord plug securely into the wall outlet.
B If the plug is not inserted correctly, electric shocks or overheating could
result.
B Do not use plugs which are damaged or wall outlets which are coming
loose from the wall.
Do not place the projector on top of surfaces which are unstable.
B If the projector is placed on top of a surface which is sloped or unstable, it
may fall down or tip over, and injury or damage could result.
Do not place the projector into water or let it become wet.
B Failure to observe this may result in fire or electric shocks.
Do not place liquid containers on top of the projector.
B If water spills onto the projector or gets inside it, fire or electric shocks
could result.
B If any water gets inside the projector, contact an Authorized Service
Center.
Do not insert any foreign objects into the projector.
B Do not insert any metal objects or flammable objects into the projector or
drop them onto the projector, as doing so can result in fire or electric shocks.
Keep the batteries out of the reach of infants.
B If the batteries are swallowed, death by suffocation may result. If you
believe that the batteries may have been swallowed, seek medical advice
immediately.
Do not allow the + and - terminals of the batteries to come into contact
with metallic objects such as necklaces or hairpins.
B Failure to observe this may cause the batteries to leak, overheat, explode
or catch fire.
B Store the batteries in a plastic bag and keep them away from metallic objects.
During a thunderstorm, do not touch the projector or the cable.
B Electric shocks can result.
Do not use the projector in a bath or shower.
B Fire or electric shocks can result.
Accessories
Check that all of the accessories shown below have been included with your
projector.
Remote control unit
(N2QAEA000019 x1)
Video cable
[3.0 m (9´10˝),
K2KA2FA00003 x1]
AAA batteries for
remote control unit (x2)
Power cord
(K2CG3FR00001 x 1)
Carrying bag
(TPEP008 x1)
POWER
LIGHT
INPUT
VID E O
CMPNT
PC
COMPONENT
KEYSTONE
MENU
ENTER
NORMAL
ASPECT
FREEZE
MODE
MEMORY
USER
LCD PROJECTOR
Before use
Cautions when moving the projector
Be sure to attach the lens cover before moving the projector.
The projection lens is extremely susceptible to vibration and shocks. When
moving the projector, use the accessory carrying bag. When placing the
projector inside the carrying bag, position it so that the lens is facing upward.
Cautions regarding setting-up
Avoid setting up in places which are subject to vibration or shocks.
The internal parts can be damaged, which may cause malfunctions or
accidents.
NOTICE:
B This product has a High Intensity Discharge (HID) lamp that contains a
small amount of mercury. It also contains lead in some components.
Disposal of these materials may be regulated in your community due to
environmental considerations. For disposal or recycling information
please contact your local authorities, or the Electronics Industries
Alliance: <http://www.eiae.org.>
8-ENGLISH
Do not set up the projector near high-voltage power lines or near
motors.
The projector may be subject to electromagnetic interference.
If installing the projector to the ceiling, ask a qualified technician to
carry out all installation work.
You will need to purchase the separate installation kit (Model No.ET-PKE300).
Furthermore, all installation work should only be carried out by a qualified
technician.
ENGLISH-9
Preparation
When inserting the batteries, make sure the polarities (+ and -) are
correct.
B If the batteries are inserted incorrectly, they may explode or leak, and fire,
injury or contamination of the battery compartment and surrounding area
may result.
Use only the specified batteries.
B If incorrect batteries are used, they may explode or leak, and fire, injury or
contamination of the battery compartment and surrounding area may
result.
Do not mix old and new batteries.
B If the batteries are inserted incorrectly, they may explode or leak, and fire,
injury or contamination of the battery compartment and surrounding area
may result.
Do not put your weight on this projector.
B You could fall or the projector could break, and injury may result.
B Be especially careful not to let young children climb onto the projector.
Disconnect the power cord plug from the wall outlet as a safety
precaution before carrying out any cleaning.
B Electric shocks can result if this is not done.
Ask an Authorized Service Center to clean inside the projector at least
once a year.
B If dust is left to build up inside the projector without being cleaned out, it
can result in fire or problems with operation.
B It is a good idea to clean the inside of the projector before the season for
humid weather arrives. Ask your nearest Authorized Service Center to
clean the projector when required. Please discuss with the Authorized
Service Center regarding cleaning costs.
We are constantly making efforts to preserve and maintain a clean
environment. Please take non repairable units back to your dealer or a
recycling company.
Notes on use
In order to get the best picture quality
Draw curtains or blinds over any windows and turn off any fluorescent lights
near the screen to prevent outside light or light from indoor lamps from
shining onto the screen.
Do not touch the surfaces of the lens with your bare hands.
If the surface of the lens becomes dirty from fingerprints or anything else, this
will be magnified and projected onto the screen. Moreover, when not using
the projector, retract the lens and then cover it with the accessory lens cover.
Screen
Do not apply any volatile substances which may cause discoloration to the
screen, and do not let it become dirty or damaged.
Lamp
The lamp may need to be replaced earlier due to variables such as individual
lamp characteristics, usage conditions and the installation environment,
especially when the projector is subjected to continuous use for more than
10 hours or the power is frequently turned on and off.
Liquid crystal panel
B Do not project the same image for long periods of time, as this may remain
as an afterimage on the liquid crystal panel.
B The liquid crystal panel of the projector is built with very high precision
technology to provide fine picture details. Occasionally, a few non-active
pixels may appear on the screen as fixed points of blue, green or red.
Please note that this does not affect the performance of your LCD.
10-ENGLISH
Location and function of each part
Projector <Top, right and front>
&%$
Preparation
If using this projector at high elevations (above 1 400 m),
set the “FAN CONTROL” to “HIGH”. (Refer to page 43.)
Failure to observe this may result in malfunctions.
#
'
'
,
(
+
)
*
# Projector control panel (page 14)
$ Zoom ring (page 23)
% Focus ring (page 23)
& Projection lens
' Air inlet ports
Do not cover these ports.
( Front adjustable legs(L/R) (page 23)
) Lens cover
* Leg adjuster buttons(L/R) (page 23)
These buttons are used to unlock the front adjustable legs. Press to adjust
the angle of tilt of the projector.
+ Air filter (page 46)
, Remote control signal receptor (page 21)
- MAIN POWER switch (pages 22 and 24)
ENGLISH-11
Preparation
Projector <Back and bottom>
$
Connector panel
#
#
$
%
&
'
'
%
&
# Air outlet port
Do not cover this port.
$ Connector panel (page 13)
% Power input socket (AC IN) (page 22)
The accessory power cord is connected here. Do not use any power cord
other than the accessory power cord.
& Lamp unit holder (page 47)
' Security lock
This can be used to connect a commercially-available theft-prevention
cable (manufactured by Kensington). This security lock is compatible with
the Microsaver Security System from Kensington.
WARNING
Do not place your hands or other objects close to the air outlet port.
B Heated air comes out of the air outlet port. Do not place your hands or
face, or objects which cannot withstand heat close to this port, otherwise
burns or damage could result.
12-ENGLISH
(
# TRIGGER output jack (pages 18, 19 and 20)
This jack outputs 12 V when the power is turned on. Connect this jack to
equipment such as an electric screen.
$ S-VIDEO input connector (page 18)
This connector is used to input signals from an S-VIDEO-compatible
equipment such as a video deck.
% DVI-D IN connector (page 20)
This connector is used to input DVI-D signals.
& RGB input connector (page 20)
This connector is used to input RGB signals from a PC.
' YPBPR(CBCR) input jacks(page 19)
These jacks are used to input YPBPR signals from compatible equipment
such as a DVD player.
( VIDEO input jack (page 18)
This jack is used to input video signals from a video equipment such as a
video deck.
ENGLISH-13
'
(
)
#
$
%
*
&
+
Remote control unit
.
POWER
&
LIGHT
INPUT
VID E O
CMPNT
PC
*
COMPONENT
'
(
KEYSTONE
MENU
+
ENTER
)
,
-
/
NORMAL
ASPECT
FREEZE
MODE
MEMORY
USER
LCD PROJECTOR
14-ENGLISH
0
1
# TEMP indicator (page 44)
This indicator illuminates if an abnormally high temperature is detected
inside the projector. If the temperature rises above a certain level, the
power supply will be turned off automatically and the indicator will flash.
$ LAMP indicator (page 45)
This indicator illuminates when it is time to replace the lamp unit. It flashes
if a circuit abnormality is detected.
% Power indicator (pages 22, 24 and 25)
This indicator illuminates red when the main power is switched on (standby
mode), and it illuminates green when projection of an image begins.
& POWER button (pages 22 and 24)
' MENU button (page 32)
This button is used to display the “MAIN MENU”. When a menu screen is
being displayed, it can be used to return to a previous screen or to clear the
screen.
F, G, I and H) buttons (page 34)
( Arrow (F
These buttons are used to select and adjust items in the on-screen menus.
) ENTER button (page 34)
This button is used to accept and to activate items selected in the
on-screen menus.
* INPUT select button (page 23)
These buttons are used to switch the input signals from the connected
equipment.
+ KEYSTONE button (page 26)
This button is used to correct keystone distortion of the projected image
when the projector position is tilted upward or downward.
, NORMAL button (page 35)
This button is used to reset the projector adjustment values to the factory
default settings.
- ASPECT button (page 28)
This button is used for aspect adjustment (vertical and horizontal
proportions).
. LIGHT button (page 30)
This button is used to illuminate the buttons on the remote control unit.
/ FREEZE button (page 30)
This button is used to momentarily freeze projection so that a still picture is
displayed.
0 PICTURE MODE button (page 27)
This button is used to display the “PICTURE MODE” menu.
1 USER MEMORY button (page 31)
This button is used to display the “MEMORY LOAD” menu.
ENGLISH-15
Preparation
Projector control panel
Setting-up
Projector position
BFront-ceiling projection
Screen
L: Projection distance
SH: Image height
SW:Image width
H1: Distance from center
of lens to bottom edge
of projected image
L
H1
BFront-desk projection
<Units: mm (inch)>
Top edge of screen
Menu items
Setting
Menu items
Setting
FRONT/REAR
FRONT
FRONT/REAR
FRONT
DESK/CEILING
DESK
DESK/CEILING
CEILING
BRear-desk projection
(Using a translucent screen)
BRear-ceiling projection
(Using a translucent screen)
SW
65.4
(2-9/16)
Bottom edge of screen
L
Screen
Projection distances
Screen size (16:9)
Diagonal
length
Menu items
Setting
Menu items
Setting
FRONT/REAR
REAR
FRONT/REAR
REAR
DESK/CEILING
DESK
DESK/CEILING
CEILING
NOTE:
B You will need to purchase the separate ceiling bracket (ET-PKE300)
when using the ceiling installation method.
B If you set up the projector vertically, it may cause
damage to the projector.
B It is recommended that you set up the projector
in a place that is tilted at less than ±30°. Setting
up the projector in places that are tilted at more
than ±30° may cause malfunctions.
16-ENGLISH
1.01 m(40˝)
1.27 m(50˝)
1.52 m(60˝)
1.77 m(70˝)
2.03 m(80˝)
2.28 m(90˝)
2.54 m(100˝)
3.81 m(150˝)
5.08 m(200˝)
Projection distance (L)
Height
(SH)
Width
(SW)
Wide
(LW)
0.50 m(1´7˝)
0.62 m(2´)
0.75 m(2´5˝)
0.87 m(2´10˝)
1.00 m(3´3˝)
1.12 m(3´8˝)
1.24 m(4´)
1.87 m(6´1˝)
2.49 m(8´2˝)
0.89 m(2´11˝)
1.11 m(3´7˝)
1.33 m(4´4˝)
1.55 m(5´1˝)
1.77 m(5´9˝)
1.99 m(6´6˝)
2.21 m(7´3˝)
3.32 m(10´10˝)
4.43 m(14´6˝)
1.2 m(3´11˝)
1.6 m(5´2˝)
1.9 m(6´2˝)
2.2 m(7´2˝)
2.5 m(8´2˝)
2.8 m(9´2˝)
3.1 m(10´2˝)
4.7 m(15´5˝)
6.2 m(20´4˝)
Height
position
(H1)
Telephoto
(LT)
1.4 m(4´7˝)
1.8 m(5´10˝)
2.2 m(7´2˝)
2.5 m(8´2˝)
2.9 m(9´6˝)
3.3 m(10´9˝)
3.7 m(12´1˝)
5.6 m(18´4˝)
7.4 m(24´3˝)
0.03 m(1-5/32˝)
0.04 m(1-9/16˝)
0.04 m(1-9/16˝)
0.05 m(1-15/16˝)
0.06 m(2-11/32˝)
0.06 m(2-11/32˝)
0.07 m(2-3/4˝)
0.10 m(3-29/32˝)
0.14 m(5-1/2˝)
NOTE:
B The dimensions in the table above are approximate.
B For details about projected image distances, refer to page 56.
ENGLISH-17
Getting started
In way of installing projector, any one of the following four projection methods
are used. Select whichever projection method matches the setting-up
method. (The projection method can be set from the “OPTION” menu. Refer
to page 43 for details.)
SH
Projection methods
Connections
B Read the instruction manual for each system component carefully before
connecting it.
B Turn off the power supply for all components before making any
connections.
B If the cables necessary for connecting a component to the system are not
included with the component or available as an option, you may need to
fashion a cable to suit the component concerned.
B Refer to the list on page 54 for details on compatible signals which can be
input to the projector.
B An audio system circuit is not provided with this projector. Connect the
audio output of the components to a separate audio system.
Connecting to equipment compatible with YPBPR
(CBCR) signals
DVD player
Getting started
Notes on connections
To YPBPR
output
Connecting to video equipment
To S-Video output
DVD player
Equipment such as
an electric screen
Equipment such as
an electric screen
Video cable
(accessory)
To Video output
Video deck
18-ENGLISH
ENGLISH-19
Preparation for the remote control unit
Connecting to computer
# Open the cover.
To RGB
output
Getting started
Computer
$ Insert the batteries so that the
polarities are correct, and then close the
cover.
Equipment such as
an electric screen
AAA batteries
(two)
NOTE:
B Do not drop the remote control unit.
B Keep the remote control unit away from liquids.
B Remove the batteries if not using the remote control unit for long periods.
B Do not use rechargeable batteries.
Computer
Operating range
To DVI-D
output
NOTE:
B Shut down the computer before turning off the MAIN POWER switch of
the projector.
20ENGLISH
If the remote control unit is held so that it is facing directly in front of the
remote control signal receptors on the front or rear of the projector, the
operating range is within approximately 7 m (23´) from the surfaces of the
receptors. Furthermore, the remote control unit can be operated from an
angle of ±30° to the left or right and ±15° above or below the receptors.
NOTE:
B If there are any obstacles in between the remote control unit and the
receptors, the remote control unit may not operate correctly.
B If strong light is allowed to shine onto the remote control signal receptor,
correct projector operation may not be possible. Place the projector as
far away from light sources as possible.
B If facing the remote control unit toward the screen to operate the projector,
the operating range of the remote control unit will be limited by the amount
of light reflection loss caused by the characteristics of the screen used.
ENGLISH-21
Turning on the power
Before turning on the power
1, Ensure that all components
are connected properly.
2, Connect the accessory power cord.
3, Remove the lens cover.
&
˛$
power cord
Control
panel
Changing
signals
VIDEO
LIGHT
˛&
INPUT
VID E O
CMPNT
Input select
button
PC
COMPONENT
KEYSTONE
MENU
Remote
control
unit
˛(
ENTER
Changing
signals
S-VIDEO
Y·PB·PR
DVI
PC
CMPNT
PC
VI D E O
VIDEO
PC
Y·PB·PR
S-VIDEO
NORMAL
ASPECT
BA picture will be projected in accordance with the selected input signal.
FREEZE
MODE
MEMORY
USER
˛'
Lens cover
DVI
˛)
˛'
Follow the procedure below when you set the projector up first, and when
you change the setup place.
Power indicator
the MAIN POWER switch to turn on the
# Press
power.
BThe power indicator on the projector will illuminate red.
the angle
' Adjusting
BWhile pressing the adjuster buttons,
adjust the forward/back angle of tilt
of the projector. Adjust so that the
projector is as vertical to the screen
as possible.
the POWER button.
$ Press
BThe power indicator on the projector will flash green. After a short
period, the indicator will illuminate green, and a picture will be
projected.
the size
( Adjusting
BTurn the zoom ring to adjust
the size of the projected image.
on the power of all connected devices.
% Turn
BStart the play function of a device such as a DVD player.
Zoom
Focus
Adjusting the focus
) BTurn the focus ring to adjust
NOTE:
B A tinkling sound may be heard when the lamp unit is turned on, but
this is not a sign of a malfunction.
22-ENGLISH
the focus of the projected image.
ENGLISH-23
Basic operation
Input select
button
˛#
POWER
Press the input select button to select the
input signal.
Turning off the power
˛#
POWER
LIGHT
INPUT
VID E O
CMPNT
PC
COMPONENT
KEYSTONE
˛$
ENTER
NORMAL
ASPECT
FREEZE
MODE
MEMORY
USER
Power indicator
the POWER button.
# Press
B“POWER OFF” is displayed on the
˛%
POWER OFF
OK
CANCEL
screen.
$
Press the I or H button to select “OK”, and
then press the ENTER button.
BThe lamp unit will switch off and the picture will stop being projected.
(The power indicator on the projector will illuminate orange while the
cooling fan is still operating.)
NOTE:
B During projection of an image, the cooling fan will operate, emitting a
small noise as it operates. Turning the lamp on or off will cause this
noise to increase a little.
B By using the “OPTION” menu to set “LAMP POWER” to “LOW”, the
operating sound of the fan can be reduced. (Refer to page 43.)
B You can also turn off the power by pressing the POWER button twice or
by holding it down for at least 0.5 seconds.
B When the projector is in standby mode (the power indicator on the
projector is illuminated red), the projector will still draw a maximum 1.0 W
of power, even when the cooling fan has stopped.
Power indicator
Power indicator status
Red
Green
the MAIN POWER switch to turn off the
% Press
power after the power indicator on the
24-ENGLISH
Flashing
Illuminated
projector illuminates red.
BDo not cut power to the projector in any way while the cooling fan is
still operating. Be careful not to switch off the MAIN POWER switch
of the projector or unplug the power cord from the wall outlet.
Illuminated
Illuminated
Orange
Flashing
Projector status
The projector is in standby mode and image projection
is possible by pressing the POWER button.
The projector is preparing for projection after the
power is turned on while the power indicator is
illuminated red. (After a short period, a picture will be
projected.)
A picture is being projected.
The lamp is cooling down after the power is turned
off. (The cooling fan is operating.)
The projector is preparing for projection after the
power is turned on while the power indicator is
illuminated orange. (After a short period, a picture
will be projected.)
ENGLISH-25
Basic operation
MENU
Correcting keystone distortion (KEYSTONE)
Selecting the picture mode (PICTURE MODE)
When either the projector or the screen is tilted, the keystone distortion will
affect the image. You can correct the image proportions by the following
procedure.
You can select the appropriate picture mode for the type of projected image
by the following procedure.
Press the KEYSTONE button.
INPUT
VID E O
CMPNT
VID E O
PC
CMPNT
PC
Press the PICTURE MODE button.
COMPONENT
KEYSTONE
COMPONENT
KEYSTONE
PICTURE MODE
MENU
NORMAL
MENU
KEYSTONE
H-KEYSTONE
0
V-KEYSTONE
0
SELECT
ENTER
ENTER
NORMAL
FREEZE
FREEZE
Projector control panel
B Press the F or G button to select the item you
want to correct, and then press the ENTER
button. Follow the procedures in the table below
to correct the keystone distortion.
ASPECT
MODE
MEMORY
USER
PICTURE MODE
NORMAL
[
DYNAMIC
[
CINEMA1
[
CINEMA2
[
VIDEO
[
NATURAL
Horizontal
keystone
distortion
correction
Operation
NORMAL ............When watching various image sources.
Press the H button.
Press the I button.
CINEMA1 ............When watching movies. The projected image will be
refined. This mode was well tuned to the look of Hollywood
movie.
Vertical
keystone
distortion
correction
Operation
DYNAMIC ...........When the projector is used in a bright room.
Press the H button.
Press the I button.
CINEMA2 ............When watching movies. The projected image will be clear
and have high contrast.
B Press the MENU button to return to the previous screen.
NOTE:
B You can also correct keystone distortion from the “KEYSTONE” in the
“MAIN MENU”.
B Vertical and horizontal keystone distortion can be corrected to ±30° of the angle
of tilt. However, the greater the correction amount, the more the picture quality
will deteriorate, and the harder it will become to achieve a good level of focus.
To obtain the best picture quality, set up the projector and screen in such a way
that the amount of keystone correction required is as minimal as possible.
B The picture size will also change when correction of keystone distortion is carried out.
26-ENGLISH
VIDEO .................When watching video sources such as music or sports
programs.
NATURAL...........To reproduce the color of the image faithfully from the
image source.
NOTE:
B The picture mode can be also selected in the “PICTURE” menu.
ENGLISH-27
Useful functions
NORMAL
B Press the I or H button to select an item.
ENTER
ESC
Setting the aspect ratio (ASPECT)
ASPECT
This projector allows you to change the aspect ratio to match the type of
input signal.
4:3
4:3 input signal
4:3
16:9
Squeezed signal (image
contracted horizontally)
Horizontal expansion of
projected image
JUST
4:3 input signal
Horizontal expansion of projected image
(Center of image is less distorted.)
ZOOM
Letterbox signal
Expansion preserves
original ratio
NORMAL
ASPECT
FREEZE
MODE
MEMORY
USER
S-VIDEO/VIDEO/
YPBPR
PC
DVI
Press the ASPECT button.
BPressing the ASPECT button will change the
aspect ratio according to the successive settings
shown below.
BIllustrations for aspect ratio settings are shown
on the next page. Refer to this illustration for
assistance in selecting a suitable aspect ratio.
AUTO\4:3\16:9\JUST\ZOOM
4:3\16:9\V SCROLL
4:3\16:9
(When a 525p/625p signal is being input)
4:3\16:9\JUST\ZOOM
BWhen set to “AUTO”, the aspect ratio will be automatically selected if the
input signal has a detector signal.
NOTE:
B If a selected mode does not match the aspect ratio of the input signal, it
may affect the quality of viewing of the original picture. Keep this in
mind when selecting the aspect ratio.
B If using this projector in places such as cafes or hotels to display programs
for a commercial purpose or for public presentation, note that if the aspect
ratio (16:9) selection function is used to change the aspect ratio of the
screen picture, you may be infringing the rights of the original copyright
owner for that program under copyright protection laws.
B If a normal (4:3) picture which was not originally intended for wide-screen
viewing is projected onto a wide screen, distortion may occur around the
edges of the picture so that part of the picture is no longer visible. Such
programs should be viewed in 4:3 mode to give proper consideration to the
aims and intentions of the original program’s creator.
B The following signals have resolutions that are 16:9 image sizes. The
aspect ratios for these signals cannot be changed while being played
because they are already established. (Refer to page 54.)
HDTV60, HDTV50, 750p, WIDE 480/600/720/768/768-2
*WIDE768 signals can be set to “V SCROLL”.
B Image sizes such as Cinema-Vision that project wider than the 16:9
ratio will have narrow black fields at the top and bottom.
B You can also change the aspect ratio from the “POSITION” menu.
28-ENGLISH
Projected image
V SCROLL
4:3 input signal
(XGA/MXGA/SXGA/
WIDE768 only)
A picture is projected without expansion
or reduction. (Vertical position can be
adjusted by the G and F buttons.)
ENGLISH-29
Useful functions
ENTER
Input signal
Turning on the button lights (LIGHT)
LIGHT
INPUT
VID E O
CMPNT
PC
COMPONENT
KEYSTONE
MENU
Press the LIGHT button.
B The buttons on the remote control unit will be
illuminated.
B Press the LIGHT button again to turn off the
button lights. The button lights will be turned off
automatically when no buttons on the remote
control unit are pressed for 10 seconds.
The picture settings adjusted according to the instructions on page 36 can be
saved and retrieved.
Press the USER MEMORY button.
POWER
LIGHT
INPUT
VID E O
CMPNT
PC
COMPONENT
KEYSTONE
MENU
ENTER
NORMAL
ASPECT
MODE
MEMORY
USER
ESC
ENTER
FREEZE
MEMORY LOAD
MEMORY 1
MEMORY 2
MEMORY 3
SELECT
ENTER
NORMAL
ASPECT
Pausing a picture (FREEZE)
FREEZE
MODE
MEMORY
USER
BThe “MEMORY LOAD” menu will be displayed.
Press the F or G button to select the setting
you want to retrieve, then press the ENTER
button.
Useful functions
POWER
Retrieving the saved picture
settings (USER MEMORY)
LCD PROJECTOR
Press the FREEZE button.
POWER
LIGHT
INPUT
VID E O
CMPNT
PC
COMPONENT
KEYSTONE
MENU
Still picture
NOTE:
B Only the settings saved in the “MEMORY SAVE” menu will be
displayed in the “MEMORY LOAD” menu.
ENTER
NORMAL
ASPECT
FREEZE
MODE
MEMORY
USER
30-ENGLISH
B The picture being projected will be paused.
B Press the FREEZE button again to cancel the
still picture.
ENGLISH-31
On-screen menus
Menu screens
The various settings and adjustments for this projector can be carried out by
selecting the operations from on-screen menus.
The general arrangement of these menus is shown below.
MENU
KEYSTONE
POSITION
SHUTTER
LANGUAGE
OPTION
SELECT
ENTER
PICTURE menu (page 36)
When an S-VIDEO/VIDEO
signal is being input
PICTURE MODE
NORMAL
CONTRAST
0
BRIGHT
0
COLOR
0
TINT
0
SHARPNESS
0
COLOR TEMP.
0
AI
OFF
ADVANCE MENU
MEMORY SAVE
MEMORY LOAD
TV-SYSTEM
AUTO
SELECT
ADJ
ESC
EXIT
B Press the MENU button to
display the “MAIN MENU”.
Refer to page 34 for details on
how to operate the on-screen
menus.
When a YPBPR/PC signal is being input
KEYSTONE correction (page 26)
KEYSTONE
H-KEYSTONE
0
V-KEYSTONE
0
SELECT
ENTER
PICTURE MODE
NORMAL
CONTRAST
0
BRIGHT
0
COLOR
0
TINT
0
SHARPNESS
0
COLOR TEMP.
0
AI
OFF
ADVANCE MENU
MEMORY SAVE
MEMORY LOAD
SIGNAL MODE
525I
SELECT
ADJ
ESC
POSITION menu (page 40)
When an S-VIDEO/VIDEO/
DVI signal is being input
POSITION
H-POSITION
0
V-POSITION
0
ASPECT
16:9
SELECT
ENTER
ESC
B When a DVI signal is being
input, only “ASPECT” can be
adjusted.
When a YPBPR signal is being input
POSITION
H-POSITION
0
V-POSITION
0
CLOCK PHASE
0
ASPECT
4:3
SELECT
ENTER
ESC
When a PC signal is being input
POSITION
H-POSITION
0
V-POSITION
0
DOT CLOCK
0
CLOCK PHASE
0
ASPECT
4:3
AUTO SETUP
SELECT
ENTER
ESC
LANGUAGE menu (page 41)
LANGUAGE
ENGLISH
DEUTSCH
FRANÇAIS
ESPAÑOL
ITALIANO
SELECT
ENGLISH
ENTER
ESC
OPTION menu (page 42)
OPTION
OSD
ON
NR
ON
PC PRIORITY
NORMAL
BACK COLOR
BLACK
EDID
EDID1
FRONT/REAR
FRONT
DESK/CEILING
DESK
FAN CONTROL
NORMAL
LAMP POWER
HIGH
LAMP RUNTIME
5H
SELECT
ADJ
ESC
ESC
When a DVI signal is being input
PICTURE MODE
NORMAL
CONTRAST
0
BRIGHT
0
SHARPNESS
0
COLOR TEMP.
0
AI
OFF
ADVANCE MENU
MEMORY SAVE
MEMORY LOAD
SIGNAL MODE
XGA
SELECT
ADJ
ESC
32-ENGLISH
SHUTTER function (page 41)
ENGLISH-33
Adjustments and settings
MAIN MENU
Menu operation guide
& Press the F or G button to select an
item, and then press the I or H
button to change or adjust the
setting.
An individual adjustment screen such as
the one shown below will be displayed
for bar scale items.
# Press the MENU button.
LIGHT
INPUT
VID E O
CMPNT
PC
COMPONENT
KEYSTONE
MENU
ENTER
NORMAL
ASPECT
FREEZE
MODE
MEMORY
USER
LCD PROJECTOR
Projector control panel
MENU
KEYSTONE
POSITION
SHUTTER
LANGUAGE
OPTION
SELECT
ENTER
BRIGHT
EXIT
The “MAIN MENU” screen will be
displayed.
$ Press the F or G button to select an item.
MENU
KEYSTONE
POSITION
SHUTTER
LANGUAGE
OPTION
SELECT
ENTER
EXIT
Selected items will be displayed in
blue.
PICTURE MODE
NORMAL
CONTRAST
0
BRIGHT
0
COLOR
0
TINT
0
SHARPNESS
0
COLOR TEMP.
0
AI
OFF
ADVANCE MENU
MEMORY SAVE
MEMORY LOAD
TV-SYSTEM
AUTO
SELECT
ADJ
ESC
34-ENGLISH
The bar scale will turn green when any
adjustment changes the setting from the
factory set value.
For items without any selective arrow or
bar scale, press the ENTER button. The
menu screen for the item will then be
displayed.
This projector has
unadjustable items and
unusable functions
depending on the signal
being input.
When an item cannot be
adjusted or a function cannot
be used, the corresponding
on-screen menu display
does not appear, and the
item or function will not work
even if the ENTER button is
pressed.
Returning a setting to the factory default
% Press the ENTER button to accept the
selection.
NOTE:
B Press the MENU
button to return to
the previous
screen.
0
Unavailable onscreen menu items
The selected menu screen or
adjustment screen will then be
displayed. (Example: “PICTURE”
menu)
If you press the NORMAL button on the remote control unit, you can return
settings to the factory default settings. However, the operation of this function
varies depending on which screen is being displayed.
B When a menu screen is being displayed
All items displayed will be returned to their factory default settings, and the
bar scale will appear white.
B When an individual adjustment screen is being displayed
Only the item displayed will be returned to the factory default setting, and
the bar scale will appear white.
NOTE:
B Triangle symbols above and below a
menu bar indicate the factory default
setting. Items which do not have these
triangle symbols cannot be returned to
the factory default setting.The positions
of triangle symbols vary depending on
the type of signal being input.
Indicates the standard
factory default setting
Indicates the current
adjustment value
ENGLISH-35
Adjustments and settings
POWER
Press the F or G button to select an
item, and then press the I or H
button to change the setting.
For items with bar scales, press the
ENTER button or the I or H button
to display the adjustment screen,
and then press the I or H button to
make the adjustment.
For items without any selective
arrow or bar scale, press the ENTER
button. The menu screen for the item
will then be displayed.
When an S-VIDEO/VIDEO signal is
being input
PICTURE MODE
NORMAL
CONTRAST
0
BRIGHT
0
COLOR
0
TINT
0
SHARPNESS
0
COLOR TEMP.
0
AI
OFF
ADVANCE MENU
MEMORY SAVE
MEMORY LOAD
TV-SYSTEM
AUTO
SELECT
ADJ
ESC
When a YPBPR/PC signal is being
input
PICTURE MODE
NORMAL
CONTRAST
0
BRIGHT
0
COLOR
0
TINT
0
SHARPNESS
0
COLOR TEMP.
0
AI
OFF
ADVANCE MENU
MEMORY SAVE
MEMORY LOAD
SIGNAL MODE
525I
SELECT
ADJ
ESC
When a DVI signal is being input
PICTURE MODE
NORMAL
CONTRAST
0
BRIGHT
0
SHARPNESS
0
COLOR TEMP.
0
AI
OFF
ADVANCE MENU
MEMORY SAVE
MEMORY LOAD
SIGNAL MODE
XGA
SELECT
ADJ
ESC
TINT
ADVANCE MENU
(NTSC/NTSC 4.43/YPBPR/PC only)
This adjusts the flesh tones in the
picture.
The flesh tones are greenish: I button
The flesh tones are reddish: H button
Picture settings can be adjusted in
more detail.
Press the ENTER button to display
the “ADVANCE MENU”
NOTE:
B When PC signals are being
input, adjustment can be made
only when HDTV60/HDTV50
signals are being input.
PICTURE MODE
SHARPNESS
Refer to page 27 for details.
To soften the picture details: I button
To sharpen the picture details: H button
CONTRAST
This adjusts the contrast of the
picture. (Adjust the “BRIGHT”
setting first if required before
adjusting the “CONTRAST” setting.)
The picture is bright: I button
The picture is dark: H button
BRIGHT
This adjusts the darker areas (black
areas) in the picture.
Black areas are too light: I button
Dark areas are too solid: H button
COLOR
(S-VIDEO/VIDEO/YPBPR/PC only)
The color is too deep: I button
The color is too pale: H button
NOTE:
B When PC signals are being
input, adjustment can be made
only when HDTV60/HDTV50
signals are being input.
COLOR TEMP.
COLOR TEMP.
-2
COLOR TEMP.
-1
[
[
COLOR TEMP.
0
[
COLOR TEMP.
+1
COLOR TEMP.
+2
ADVANCE MENU
GAMMA HIGH
0
GAMMA MID
0
GAMMA LOW
0
CONTRAST R
0
CONTRAST G
0
CONTRAST B
0
BRIGHT R
0
BRIGHT G
0
BRIGHT B
0
SELECT
ENTER
ESC
“GAMMA HIGH/MID/LOW” is used
for correcting the gradation of a
bright or dark projected image.
B Adjust “GAMMA HIGH” mainly to
correct the gradation of a bright
projected image.
B Adjust “GAMMA LOW” mainly to
correct the gradation of a dark
projected image.
[
This is used to adjust the white
areas of the picture if they appear
bluish or reddish.
AI
The lamp is controlled according to
the input signals to project images
with the best quality.
AI-1 For image sources with many
dark scenes such as movies.
AI-2 For image sources with many
bright scenes such as general
programs.
OFF “AI” is disabled.
“CONTRAST R/G/B” and “BRIGHT
R/G/B” are used for correcting the
color temperature in more detail.
B Adjust “CONTRAST R/G/B”
mainly to correct the white areas
of the projected image.
B Adjust “BRIGHT R/G/B” mainly to
correct the black areas of the
projected image.
NOTE:
B “AI” is disabled when “LAMP
POWER” is set to “LOW”.
(Refer to page 43.)
36-ENGLISH
ENGLISH-37
Adjustments and settings
Adjusting the picture
TV-SYSTEM
Press the ENTER button to display
the “MEMORY SAVE” menu.
(S-VIDEO/VIDEO only)
MEMORY SAVE
MEMORY 1
MEMORY 2
MEMORY 3
SELECT
ENTER
TV-SYSTEM
AUTO
[
NTSC
[
NTSC4.43
[
PAL
ESC
[
PAL-M
The settings adjusted in “PICTURE”
menu can be saved. Press the F or
G button to select the number in
which you want to save the setting,
and then press the ENTER button.
The confirmation screen will then be
displayed. Press the I or H button
to select “OK” and then press the
ENTER button.
The current picture setting will be
saved.
MEMORY SAVE
OK
CANCEL
NOTE:
B You can save up to 3 settings
for each of the 2 signal groups
described below (up to 6
settings can be saved).
S-VIDEO, VIDEO, YPBPR, and
HDTV50/HDTV60 signals from
DVIs and PCs
PC and DVI (except for
HDTV50/HDTV60 signals)
[
PAL-N
[
SECAM
This should normally be set to
“AUTO”. If the signal is of such poor
quality that the correct format
cannot be automatically
distinguished, change the setting
manually to the required TV system.
NOTE:
B When set to “AUTO”, the
projector automatically
distinguishes between
NTSC/NTSC 4.43/PAL/PAL60/
PAL-M/PAL-N/SECAM signals.
Projecting sRGBcompatible pictures
sRGB is an international color
reproduction standard (IEC61966-21) established by the International
Electrotechnical Commission (IEC).
If you would like the colors in sRGBcompatible pictures to be
reproduced more faithfully, make
the following settings.
# Press the F or G button to
select “PICTURE MODE”, and
then press the I or H button
to select “NATURAL”.
$ Press the NORMAL button on
the remote control unit.
% Press the F or G button to
select “LAMP POWER” in the
“OPTION” menu, and then
press the I or H button to
select “HIGH”.
Adjustments and settings
MEMORY SAVE
SIGNAL MODE
(PC/YPBPR/DVI only)
This displays the type of signal
which is currently being projected.
Refer to the table on page 54 for
details on each type of signal.
MEMORY LOAD
Press the ENTER button to display
the “MEMORY LOAD” menu.
(If any setting is not saved in the
“MEMORY SAVE” menu, the
“MEMORY LOAD” menu will not be
displayed.)
Refer to page 31 on how to retrieve
the saved settings.
38-ENGLISH
ENGLISH-39
Adjusting the position
When the input signal is from a
PC, first select “AUTO SETUP”
and then press the ENTER button
to initiate automatic positioning.
If the optimum setting is not
obtained when “AUTO SETUP” is
carried out, adjust by the following
procedure.
Horizontal position
(H-POSITION)
Press the F or G button to select
an item, and then press the I or H
button to change the setting.
For items with bar scales, press the
ENTER button or the I or H button
to display the adjustment screen,
and then Press the I or H button
to make the adjustment.
(S-VIDEO/VIDEO/YPBPR/PC only)
To move the picture down: I button
To move the picture up: H button
Vertical position
(V-POSITION)
AUTO SETUP
(PC only)
“H-POSITION”, “V-POSITION”,
“DOT CLOCK” and “CLOCK
PHASE” are automatically adjusted
according to the input signal.
NOTE:
B When the “ASPECT” is set to
“V SCROLL” (page 28), “AUTO
SETUP” cannot be performed.
ASPECT
Refer to page 28.
DOT CLOCK
(PC only)
Periodic striped pattern interference
(noise) may occur when a striped
pattern such as the one below is
projected. If this happens, press the
I or H button to adjust so that any
such noise is minimised.
POSITION
H-POSITION
0
V-POSITION
0
ASPECT
16:9
SELECT
ENTER
ESC
B When a DVI signal is being input,
only “ASPECT” can be adjusted.
Turning off the picture momentarily
(SHUTTER)
The “SHUTTER” function can be used to momentarily turn off the picture
when the projector is not being used for short periods of time. The projector
uses less power in “SHUTTER” mode than it does in normal projection
mode.
# Select “SHUTTER” from the “MAIN MENU” and then press the
ENTER button.
$ Press any button on either the projector or remote control unit
(except the LIGHT button) to return to normal operating mode.
When a YPBPR signal is being input
POSITION
H-POSITION
0
V-POSITION
0
CLOCK PHASE
0
ASPECT
4:3
SELECT
ENTER
ESC
When a PC signal is being input
POSITION
H-POSITION
0
V-POSITION
0
DOT CLOCK
0
CLOCK PHASE
0
ASPECT
4:3
AUTO SETUP
SELECT
ENTER
ESC
40-ENGLISH
CLOCK PHASE
(PC/YPBPR only)
Adjust the “DOT CLOCK” setting
first before carrying out this
adjustment. Press the I or H
button to adjust so that the noise
level is least noticeable.
NOTE:
B If signals with a dot clock
frequency of 100 MHz or higher
are being input, interference
may not be completely
eliminated when the “DOT
CLOCK” and “CLOCK PHASE”
adjustments are carried out.
Changing the display language
# Select “LANGUAGE” from the “MAIN MENU” and then press the
ENTER button.
$ Press the F or G button to select a language and then press the
ENTER button.
LANGUAGE
ENGLISH
DEUTSCH
FRANÇAIS
ESPAÑOL
ITALIANO
SELECT
ENTER
ENGLISH
Indicates the language which is
currently set
ESC
ENGLISH-41
Adjustments and settings
When an S-VIDEO/VIDEO/DVI
signal is being input.
(S-VIDEO/VIDEO/YPBPR/PC only)
To move the picture to the left: I button
To move the picture to the right: H button
B When YPBPR signals are being
input, “CLOCK PHASE” can be
adjusted only when HDTV60/
HDTV50/750p signals are
being input.
Option settings
OPTION
OSD
ON
NR
ON
PC PRIORITY
NORMAL
BACK COLOR
BLACK
EDID
EDID1
FRONT/REAR
FRONT
DESK/CEILING
DESK
FAN CONTROL
NORMAL
LAMP POWER
HIGH
LAMP RUNTIME
5H
SELECT
ADJ
ESC
PC PRIORITY
FRONT/REAR
(PC only)
FRONT/REAR
LAMP POWER
FRONT
NORMAL
REAR
[
WIDE
NORMAL The PC screen data is
displayed in a 4:3
aspect ratio.
WIDE
The PC screen data is
displayed in a 16:9
aspect ratio.
This setting should be changed in
accordance with the projector
setting-up method. (Refer to page 16.)
FRONT When the projector is
placed in front of a screen.
REAR When using a translucent
screen.
BACK COLOR
DESK/CEILING
BACK COLOR
BLACK
DESK/CEILING
DESK
[
[
CEILING
BLUE
OSD
OSD
ON
[
OFF
ON
The signal name is displayed
in the top-right corner of the
screen when the input signal
is changed.
OFF Use this setting when you do
not want the signal name to
be displayed.
Noise Reduction (NR)
(YPBPR only)
NR
ON
[
OFF
If noise occurs from the projector
because of a poor input signal, set
“NR” to “ON”.
To turn off the “NR” feature, set it to
“OFF”.
42-ENGLISH
LAMP POWER
HIGH
[
PC PRIORITY
This sets the color which is projected
onto the screen when no signal is
being input to the projector.
EDID
(DVI only)
EDID
EDID1
[
EDID2
When DVI signals such as 525p,
625p, HDTV60, HDTV50, or 750p
signals are being input, set to
“EDID1”. Set to “EDID2” when other
signals are being input.
NOTE:
B “EDID” stands for “Extended
Display Identification Data”. It
is used to transmit information
such as the model name of this
projector or the settings to the
computer connected to DVI-D
IN connector. This is useful for
projecting the images with the
proper resolution.
This setting should be changed in
accordance with the projector
setting-up method. (Refer to page 16.)
DESK When the projector is
placed on a desk or
similar.
CEILING When the projector is
suspended from a ceiling
using the ceiling bracket
(sold separately).
FAN CONTROL
FAN CONTROL
NORMAL
[
HIGH
Set “FAN CONTROL” to “HIGH”,
when using this projector at high
elevations (above 1 400 m) only.
[
LOW
This setting changes the lamp
brightness. When set to “LOW”, the
luminance of the lamp is reduced,
but the projector uses less power,
and the operating noise is also
reduced.
The “LOW” setting is recommended
for narrow rooms where a high
picture luminance is not essential or
for watching movies.
NOTE:
B “LAMP POWER” cannot be set
when no signal is being input.
LAMP RUNTIME
This setting displays the usage time
for the lamp unit which is currently
being used. When replacing the
lamp unit, follow the instructions on
page 48, and reset “LAMP
RUNTIME” to “0”.
NOTE:
B The lamp’s operating life varies
depending on the usage
conditions (such as the “LAMP
POWER” setting and the
number of times the power is
turned on and off).
ENGLISH-43
Adjustments and settings
Press the F or G button to select
an item, and then press the I or H
button to change the setting.
When the TEMP indicator and the
LAMP indicator are illuminated
There are two indicators on the control panel of the projector which give
information about the operating condition of the projector. These indicators
illuminate or flash to warn you about problems that have occurred inside the
projector, so if you notice that one of the indicators is on, turn off the power
and check the table below for the cause of the problem.
TEMP indicator
LAMP indicator
Flashing (red)
(Lamp unit on)
The temperature
inside the projector
has become
dangerously high, or
the temperature has
suddenly changed.
Flashing (red)
(Lamp unit off)
The surrounding
temperature or the
temperature inside
the projector has
become dangerously
high, causing the
lamp unit to
automatically shut
off.
B The ventilation holes may be covered.
Possible B The ambient temperature in the place of use may be too high.
cause B The air filter may be blocked.
B Uncover the ventilation holes.
B Set up the projector in a place where the temperature is
between 0 °C (32 °F) and 40 °C (104 °F) and the humidity is
between 20% and 80% (with no condensation). [If you set the
“FAN CONTROL” to “HIGH” (page 43), set up the projector in a
Remedy
place where the temperature is between 0 °C (32 °F) and 35 °C
(95 °F) and the humidity is between 20% and 80% (with no
condensation).]
B Turn off the MAIN POWER switch by following the procedure
on page 24, and then clean the air filter. (Refer to page 46.)
44-ENGLISH
Illuminated (red)
It is nearly time to
Problem replace the lamp
unit.
Flashing (red)
An abnormality has been detected in the lamp
circuit.
B Turn off the MAIN
B This occurs when B Wait for a while
POWER switch by
the operation time
until the lamp unit
following the
for the lamp unit is
cools down before
nearing 1 800
turning the power
procedure given
hours (when
back on again.
on page 24, and
then contact an
“LAMP POWER”
Authorized
has
been
set
to
Remedy
Service Center.
“HIGH”). Ask your
dealer or an
Authorized
Service Center to
replace the lamp
unit.
NOTE:
B Be sure to turn off the MAIN POWER switch by following the procedure
given in “Turning off the power” on page 24 before carrying out any of
the procedures in the “Remedy” column.
B If the main power turns off after the TEMP indicator starts flashing, it
means that an abnormality has occurred. Please contact an Authorized
Service Center so that the necessary repairs can be made.
ENGLISH-45
Care and maintenance
Illuminated (red)
(Lamp unit on)
The surrounding
temperature or the
temperature inside
the projector has
Problem become unusually
high.
Indicator
display
B There may be an
B Does “REPLACE B The power may
abnormality in the
LAMP” appear on
have been turned
Possible
lamp circuit.
the screen after
on straight away
cause
the projector is
after it was turned
turned on?
off.
TEMP indicator
Indicator
display
LAMP indicator
If the air filter becomes clogged with dust, the internal temperature of the
projector will rise, the TEMP indicator will flash and the projector power will
turn off. The air filter should be cleaned after every 100 hours of use.
# Turn off the MAIN POWER
switch and disconnect the
power cord plug from the wall
outlet.
Turn off the MAIN POWER switch
according to the procedure given
in “Turning off the power” on
page 24 before disconnecting the
plug from the wall outlet.
$ Gently turn the projector
upside down.
& Clean the air filter.
Soak the air filter in water and
wash out dirt by hand.
% Remove the air filter.
Put your fingernails under the air
filter and pull the air filter out of
the projector.
Air filter
46-ENGLISH
NOTE:
B If you need the lamp replacement, please purchase the lamp unit from
our customer service.
Lamp unit product no.: ET-LAE500
CAUTION:
B Do not use any lamp unit other than the one with the product number
indicated above.
Warning
When replacing the lamp, allow it
to cool for at least one hour
before handling it.
B The lamp cover gets very hot,
and contact with it can cause
burns.
NOTE:
B Do not use detergent.
B Be careful not to separate the
air filter cover from the frame
when washing the air filter.
NOTE:
B Place the projector on top of a
soft cloth so that it will not
become scratched.
Replacing the lamp unit
' Dry the air filter and install it to
the projecter.
NOTE:
B Be sure to install the air filter
before using the projector. If
the projector is used without
the air filter installed, dust and
other foreign particles will be
drawn into the projector, and
malfunctions will result.
B If the dust cannot be removed
by cleaning, it is time to
replace the air filter. Please
consult your dealer.
Furthermore, if the lamp unit is
being replaced, replace the air
filter at this time also.
Notes on replacing the lamp
unit
B The light generating lamp is
made of glass, so dropping it or
allowing it to hit hard objects may
cause it to burst. Be careful when
handling the lamp.
B Dispose of the removed old lamp
with the same care that would be
taken with a fluorescent light.
B A Phillips screwdriver is
necessary for removing the lamp
unit.
Lamp unit replacement
period
The lamp is a consumable product.
Even when the full life of the bulb
has not been exhausted, the
brightness of the light will gradually
decline. Therefore periodic
replacement of the lamp is
necessary.
The intended lamp replacement
interval is 2 000 hours, but it is
possible that the lamp may need to
be replaced earlier due to variables
such as a particular lamp’s
characteristics, usage conditions
and the installation environment.
Early preparation for lamp
replacement is encouraged.
The lamp will automatically shut off
when 2 000 hours of use have been
reached because of a much greater
chance of it exploding after this
time.
NOTE:
B The usage hours explained
above are for use when the
“HIGH” setting has been
selected for “LAMP POWER”
in the “OPTION” menu. If the
“LOW” setting is selected, the
brightness of the lamp will be
less and life of the lamp can be
extended.
B While 2 000 hours is the
intended replacement interval,
it is not a period of time
covered by warranty.
ENGLISH-47
Care and maintenance
Cleaning and replacing the air filter
Displayed for 30
seconds. Pressing any
More than 1 800 hours
button will clear the
display.
More than 2 000 hours
Remains displayed until
any button is pressed.
Lamp indicator warning
light
Illuminates red during
image projection and
standby mode.
Lamp unit replacement procedure
NOTE:
B If the lamp usage time has passed 2 000 hours (when “LAMP POWER”
has been set to “HIGH”), the projector will switch to standby mode after
approximately 10 minutes of operation. The steps ) to , on the next
page should thus be completed within 10 minutes.
# Turn off the MAIN POWER
switch according to the
procedure given in “Turning off
the power” on page 24, and
then disconnect the power
cord plug from the wall outlet
and check that the area around
the lamp unit has cooled down.
$ Use a Phillips screwdriver to
turn the lamp unit cover fixing
screws at the bottom of the
projector, and then remove the
lamp unit cover from the
projector.
% Use a Phillips screwdriver to
loosen the two lamp unit fixing
screws until the screws turn
freely. Then hold the handle of
the lamp unit and gently pull it
out from the projector.
Lamp unit fixing screws
Handle
48-ENGLISH
MENU
KEYSTONE
POSITION
SHUTTER
LANGUAGE
OPTION
SELECT
ENTER
EXIT
+ Press the ENTER button to
display the “OPTION” menu,
and then press the F or G
button to select “LAMP
RUNTIME”.
OPTION
OSD
ON
NR
ON
PC PRIORITY
NORMAL
BACK COLOR
BLACK
Lamp unit cover
Lamp unit cover fixing screws
' Install the lamp unit cover, and
then use a Phillips screwdriver
to securely tighten the lamp
unit cover fixing screws.
( Insert the power cord plug into
the wall outlet and then press
the MAIN POWER switch.
) Press the POWER button so
that a picture is projected onto
the screen.
* Press the MENU button to
display the “MAIN MENU”, and
then press the F or G button
to select “OPTION”.
EDID
FRONT/REAR
DESK/CEILING
FAN CONTROL
LAMP POWER
LAMP RUNTIME
SELECT
, Press and hold the ENTER
button for approximately 3
seconds.
OPTION
OSD
ON
NR
ON
PC PRIORITY
NORMAL
BACK COLOR
BLACK
EDID
EDID1
FRONT/REAR
FRONT
DESK/CEILING
DESK
FAN CONTROL
NORMAL
LAMP POWER
HIGH
TIME RESET [POWER OFF]
SELECT
ESC
The “LAMP RUNTIME” will
change to “TIME RESET
[POWER OFF]”.
B If the MENU button is pressed,
the lamp time resetting screen
will be cancelled.
- Turn off the power.
This will reset the cumulative
usage time for the lamp unit to
zero.
Refer to page 24 for details on
how to turn off the power.
NOTE:
B Be sure to install the lamp unit
and the lamp unit cover
securely. If they are not
securely installed, it may cause
the protection circuit to operate
so that the power cannot be
turned on.
EDID1
FRONT
DESK
NORMAL
HIGH
1820H
ESC
& Insert the new lamp unit while
making sure that the direction
of insertion is correct, and then
use a Phillips screwdriver to
securely tighten the lamp unit
fixing screws.
ENGLISH-49
Care and maintenance
On-screen display
Before calling for service
Cleaning and maintenance
Before calling for service, check the following points.
50-ENGLISH
Page
–
–
–
44
45
–
–
23
36
Before carrying out cleaning and maintenance, be
sure to disconnect the power cord plug from the
wall outlet.
Wipe the cabinet with a soft, dry cloth.
If the cabinet is particularly dirty, soak the cloth in water with a small amount
of neutral detergent in it, squeeze the cloth very well, and then wipe the
cabinet. After cleaning, wipe the cabinet dry with a dry cloth. If using a
chemically-treated cloth, read the instructions supplied with the cloth before
use.
Do not wipe the lens with a cloth that is dusty or which produces lint.
If any dust or lint gets onto the lens, such dust or lint will be magnified and
projected onto the screen. Use a blower to clean any dust and lint from the
lens surface, or use a soft cloth to wipe off any dust or lint.
41
–
23
17
–
17
36
–
–
21
21
Care and maintenance
Problem
Possible cause
Power does not B The power cord may not be connected.
turn on.
B The MAIN POWER switch is turned off.
B The main power supply is not being supplied to the
wall outlet.
B TEMP indicator is illuminated or flashing.
B LAMP indicator is illuminated or flashing.
B The lamp unit cover has not been securely installed.
No picture
B The video signal input source may not be
appears.
connected properly.
B The input selection setting may not be correct.
B The “BRIGHT” adjustment setting may be at the
minimum possible setting.
B The shutter function may be in use.
The picture is B The lens cover may still be attached to the lens.
B The lens focus may not have been set correctly.
fuzzy.
B The projector may not be at the correct distance
from the screen.
B The lens may be dirty.
B The projector may be tilted too much.
B “COLOR” or “TINT” adjustment may be incorrect.
COLOR is too
B The input source which is connected to the
light or TINT is
projector may not be adjusted correctly.
poor.
B The batteries may be weak.
The remote
B The batteries may not be inserted correctly.
control unit
B The remote control signal receptor on the projector
does not
may be obstructed.
operate.
B The remote control unit may be out of the operation range.
The picture does B The signal format (“TV-SYSTEM”) may not be set correctly.
B There may be a problem with the video tape or
not display
other signal source.
correctly.
B A signal which is not compatible with the projector
may be being input.
B The cable may be too long.
Picture from
computer does B The external video output for the laptop computer
may not be set correctly.
not appear.
(You may be able to change the external output
settings by pressing the [Fn]+[F3] or [Fn]+[F10] keys
simultaneously. The actual method varies depending
on the type of computer, so refer to the documentation
provided with your computer for further details.)
21
38
–
54
–
–
ENGLISH-51
Specifications
Amps:
LCD panel:
Panel size (diagonal):
Aspect ratio:
Display method:
Drive method:
Pixels:
Lens:
100 V – 240 V ~, 50 Hz/60 Hz
180 W [During standby (when fan is
stopped): Approx. 1.0 W]
2.2 A - 1.0 A
0.7 type (17.78 mm)
16:9
3 transparent LCD panels (RGB)
Active matrix method
921 600 (1 280 x 720) x 3 panels
Manual zoom (1 - 1.2) / focus lens
F 1.9 - 2.2, f 22.0 mm - 26.2 mm
Lamp:
UHM lamp (130 W)
Luminosity:
850 lm
Scanning frequency(for RGB signals):
Horizontal scanning frequency: 30 kHz–70 kHz
Vertical scanning frequency: 50 Hz–87 Hz
Dot clock frequency:
Less than 100 MHz
YPBPR signals:
525i (480i), 525p (480p), 625i (576i),
625p (576p), 750p (720p), 1 125i (1 080i)
Color system:
7 (NTSC/NTSC 4.43/PAL/PAL-M/PAL-N/
PAL60/SECAM)
Projection size:
1 016 mm - 5 080 mm (40˝ - 200˝)
Throw distance:
1.2 m - 7.4 m (3´11˝ - 24´3˝)
Optical axis shift:
17:1 (fixed)
Screen aspect ratio:
16:9
Installation:
Front/Rear/Ceiling/Desk (Menu selection
method)
Connectors
VIDEO IN:
S-VIDEO:
Single-line, Mini DIN 4-pin
Y 1.0 V [p-p], C 0.286 V [p-p], 75 Ω
VIDEO:
Single-line, RCA pin jack
1.0 V [p-p], 75 Ω
PC IN:
RGB:
Single-line, D-SUB HD 15-pin (female)
R.G.B.:
0.7 V [p-p], 75 Ω
G.SYNC:
1.0 V [p-p], 75 Ω
HD/SYNC:
TTL high impedance, automatic
plus/minus polarity compatible
VD:
TTL high impedance, automatic
plus/minus polarity compatible
52-ENGLISH
COMPONENT IN:
Y, PB/CB, PR/CR
Y:
PB,PR (CB,CR):
DVI-D IN:
TRIGGER out:
Cabinet:
Dimensions:
Width:
Height:
Length:
Weight:
Operating environment:
Temperature:
Humidity:
Certifications:
<Remote control unit>
Power supply:
Operating range:
Weight:
Dimensions:
Width:
Length:
Height:
<Options>
Ceiling bracket
Projection Screen
Single-line, RCA pin jack x 3
1.0 V [p-p], 75 Ω
0.7 V [p-p], 75 Ω
Single-line, DVI-D, 24-pin
Single-line, M3 jack
When the power is turned on (during
projection) : 12 V
When the power is turned off : 0 V
Moulded plastic (ABS/PC)
280 mm (11˝) (Not including projecting parts)
85 mm (3-11/32˝)
269 mm (10-9/16˝) (Not including lens)
2.9 kg (6.4 lbs.)
0 °C – 40 °C (32 °F – 104 °F)
[When the “FAN CONTROL” is set to “HIGH”
(page 43): 0 °C – 35 °C (32 °F – 95 °F)]
20% – 80% (no condensation)
UL60950, C-UL
FCC Class B
3 V DC (AAA battery x2)
Approx. 7 m (23´) (when operated directly
in front of signal receptor)
70 g (2.5 ozs.) (including batteries)
43 mm (1-11/16˝)
135 mm (5-5/16˝)
22.3 mm (-7/8˝)
ET-PKE300
ET-SR90CT [width: 1 800 mm(70˝)]
ET-SR70CT [width: 1 400 mm(55˝)]
Others
Power supply:
Power consumption:
ENGLISH-53
Appendix
List of compatible signals
Mode
Display
resolution
(dots)*1
NTSC/NTSC4.43/
720 x 480i
PAL-M/PAL60
PAL/PAL-N/SECAM
720 x 576i
525i
720 x 480i
625i
720 x 576i
525p
720 x 483
625p
720 x 576
HDTV60
1 920 x 1 080i
HDTV50
1 920 x 1 080i
750p
1 280 x 720
VGA480
640 x 480
640 x 480
640 x 480
640 x 480
640 x 480
640 x 480
WIDE480
856 x 480
SVGA
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
WIDE600
1 072 x 600
WIDE720
1 280 x 720
XGA
1 024 x 768
1 024 x 768
1 024 x 768
1 024 x 768
1 024 x 768
WIDE768
1 280 x 768
MXGA
1 152 x 864
1 152 x 864
SXGA
1 280 x 1 024
WIDE768-2
1 360 x 768
Connector pin wiring
Scanning
frequency
H
V
(kHz) (Hz)
15.734
Dot clock
frequency
quality*2
(MHz)
59.940
15.625 50.000
15.734 59.940
15.625 50.000
31.469 59.940
31.250 50.000
33.750 60.000
28.125 50.000
45.000 60.000
31.469 59.940
35.000 66.667
37.861 72.809
37.500 75.000
43.269 85.008
72.090 138.000
30.057 60.114
35.156 56.250
37.879 60.317
48.077 72.188
46.875 75.000
53.674 85.061
72.080 112.000
37.287 59.947
45.106 60.141
48.363 60.004
56.476 70.069
60.023 75.029
68.678 84.997
72.080 89.000
45.327 56.518
63.995 71.184
67.500 74.917
63.981 60.020
48.830 59.841
13.500
13.500
27.000
27.000
74.250
74.250
74.250
25.175
30.240
31.500
31.500
36.000
62.284
31.500
36.000
40.000
50.000
49.500
56.250
77.849
51.382
76.500
65.000
75.000
78.750
94.500
99.185
76.150
94.200
108.000
108.000
73.831
B The pin layout and signal names for the S-VIDEO input connector are
shown below.
Format
A
Video/S-Video
A
A
A
A
A
AA
AA
AA
A
A
A
A
A
A
A
A
A
A
A
A
A
A
AA
A
A
A
A
A
A
A
A
A
A
Video/S-Video
YPBPR
YPBPR
YPBPR/DVI
YPBPR/DVI
YPBPR/PC/DVI
YPBPR/PC/DVI
YPBPR/DVI
PC/DVI
PC
PC
PC
PC
PC
PC/DVI
PC
PC/DVI
PC
PC
PC
PC
PC/DVI
PC/DVI
PC/DVI
PC
PC
PC
PC
PC/DVI
PC
PC
PC/DVI
PC/DVI
#
$
%
&
Pin No.
#
$
%
&
Signal
Earth (Luminance signal)
Earth (Color signal)
Luminance signal
Color signal
External view
B The pin layout and signal names for the RGB input connector are shown
below.
-
1
(
,
#
'
External view
Pin No.
#
$
%
.
/
0
1
Signal
R
G/G·SYNC
B
SDA
HD/SYNC
VD
SCL
Pin + is spare.
Pins & – *, , and - are for earth.
Pins . and 1 functions are only valid when
supported by the computer
54-ENGLISH
Others
*1 The “i” appearing after the resolution indicates an interlaced signal.
*2 The following symbols are used to indicate picture quality.
AA Maximum picture quality can be obtained.
A Signals are converted by the image processing circuit before picture
is projected
ENGLISH-55
Dimensions
B The pin layout and signal names for the DVI-D input connector are shown
below. (interface with TMDS connector on a personal computer)
3
Pin No.
/
0
1
2
3
4
5
6
7
8
9
:
Signal
T.M.D.S data 3+
+5 V
Earth
Hot plug sense
T.M.D.S data 0T.M.D.S data 0+
T.M.D.S data 0/5 shield
T.M.D.S data 5T.M.D.S data 5+
T.M.D.S clock shield
T.M.D.S clock+
T.M.D.S clock-
269 (10-9/16)
Signal
T.M.D.S data 2T.M.D.S data 2+
T.M.D.S data 2/4 shield
T.M.D.S data 4T.M.D.S data 4+
DDC clock
DDC data
T.M.D.S data 1T.M.D.S data 1+
T.M.D.S data1/3 shield
T.M.D.S data 3-
80 (3-1/8)
Pin No.
#
$
%
&
'
(
)
*
+
,
.
#
85 (3-11/32)
*
External view
278.5 (10-15/16)
+
2
49.7 (1-15/16)
:
<Units: mm (inch)>
65.4 (2-9/16)
280 (11)
Projection dimensions calculation methods
The following methods will allow you to calculate dimensions such as screen
diagonal length and projection distances. Units in all calculations are metre.
SD
LW/LT
Screen Width: SW=SDx0.872
Screen Height: SH=SDx0.490
Minimum Projection Distance: LW=1.229xSD-0.0381
Maximum Projection Distance: LT=1.481xSD-0.0381
Image Lower Edge from Lens Center: H1=SW/29
56-ENGLISH
Others
H1
SH
16:9
SW
ENGLISH-57
Trademark acknowledgements
B VGA and XGA are trademarks of International Business Machines
Corporation.
B S-VGA is a registered trademark of the Video Electronics Standards
Association.
All other trademarks are the property of the various trademark owners.
These Operating Instructions are printed on recycled paper.
58-ENGLISH
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
