Getting to Know
Your Machine
Digital Imaging Systems
DP-8060 / 8045 / 8035
Before operating this machine, please carefully read this manual, and keep this
documentation in a safe place for future reference.
(Illustration shows optional accessories that may not be installed on your machine.)
English
Appendix
Printing Journals
Problem Solving
and Lists
Advanced
Setting
Printout Journals Advanced
Internet
Fax
Internet Advanced Internet
Facsimile
Your
Machine
Features
Fax Features
Fax Features
Features
and Lists
Model No.
Facsimile
Features
(For Facsimile and Internet Fax/
Email Functions)
Internet Fax
Features
Operating Instructions
Getting to Know Your Machine
Operating Instructions
The following Operating Instruction manuals are included with this machine. Please refer to the appropriate
manual and keep all manuals in a safe place for future reference. If you lose a manual, contact an authorized
Panasonic dealer.
Operating Instructions (For Setting Up)
This manual contains essential information for
setting up the machine.
Operating Instructions (For Basic Operations)
Accessories
This manual contains essential information for
proper operation of the machine.
It describes basic Copy, Print, Network Scan,
Facsimile/Internet Fax/Email, and other functions.
For a more detailed explanation of each function,
please refer to the Operating Instruction manuals
included on two CD-ROM as illustrated below.
Operating Instructions
Adobe Reader 5.0 or newer is required and
must be installed to read the Operating
Instructions.
Unauthorized copying and distribution is a
violation of law.
Panasonic Communications Co., Ltd.
Digital Imaging Company
Microsoft, Windows, Windows NT and Windows Server are either registered trademarks or trademarks
of Microsoft Corporation in the United States and/or other countries.
Adobe, the Adobe logo, and Reader are either registered trademarks or trademarks of
Adobe Systems Incorporated in the United States and/or other countries.
2005 Panasonic Communications Co., Ltd. All Right Reserved.
Made in Japan
PJJXC0110ZB
Operating Instructions CD
Contains manuals with detailed information for
Copy & Function Paremeters, Facsimile/Internet
Fax/Email Functions and User Authentication.
Document Management System CD
Adobe Reader 5.0 or newer is required and
must be installed to read the Operating
Instructions.
Unauthorized copying and distribution is a
violation of law.
Panasonic Communications Co., Ltd.
Digital Imaging Company
PJJXC0097ZB
Operating Instructions CD
Document Management System CD
Copy Function
Print Function
Describes how to make a copy with
creative features.
Describes how to print, change
default printer settings, or describes
the course of action to take when a
problem message appears, etc.
Function Parameters
Describes how to change the default
settings of each function using the
Control Panel of the machine.
Facsimile and Internet Fax/Email
Function
(The Facsimile function is available
when optional Fax Communication
Board (DA-FG600) is installed.)
Describes how to send/receive a
Facsimile/Internet Fax/Email, or
describes the course of action to take
when a trouble message appears, etc.
User Authentication
Describes how to enable and use the
user authentication function.
2
Contains the Application Software, and manuals
with detailed information for the Print function, and
Application software.
Application Software
Describes how to use the application
software.
Ex: Quick Image Navigator, Network
Scanner, Utilities (Network Status
Monitor, Address Book Editor,
Device Configuration Editor)
Getting to Know
Your Machine
Symbol Marks/Icons
The following symbol marks/Icons are used in this operating instructions manual.
Place original(s) on the ADF
Getting to know your machine before
starting
Place original on the Platen
(Book)
When sending/receiving document(s)
with FAX
Place original on the Platen
(Sheet)
Hard keys on the Control Panel are
depicted as **** key, soft buttons on
the Touch Panel are depicted as "xxx".
Ex: Press the Start key and select "Mode
Settings".
When sending/receiving document(s)
with Email
When setting the machine modes
Press Hard Key
Touch any Button
