ERGL4ESP
................................................ .............................................
EN CONTROL PANEL
USER MANUAL
2 electrolux
Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com
CONTENTS
Safety information
Safety instructions
Product description
Daily use
Helpful hints and tips
2
2
3
4
4
Care and cleaning
Troubleshooting
Installation
Environment concerns
5
5
5
8
Subject to change without notice.
SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference.
CHILDREN AND VULNERABLE PEOPLE SAFETY
Warning! Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they are supervised by an adult or a person who is responsible for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Cleaning and user maintenance shall not be made by children without supervision.
GENERAL SAFETY
• Do not use water spray or steam cleaner to clean the control panel.
SAFETY INSTRUCTIONS
INSTALLATION
Warning! Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Obey the installation instruction supplied
with the appliance.
electrolux 3
Electrical connection
Warning! Risk of fire and electrical
shock.
• All electrical connections must be made
by a qualified electrician.
• The appliance must be earthed.
• Before carrying out any operation make
sure that the appliance is disconnected
from the power supply.
• Use the correct electricity mains cable.
• Do not let the electricity mains cable tangle.
• Make sure the mains cable or plug (if applicable) does not touch the hot appliance or hot cookware, when you connect the appliance to the near sockets
• Make sure the appliance is installed correctly. Loose and incorrect electricity
mains cable or plug (if applicable) can
make the terminal become too hot.
• Make sure that a shock protection is installed.
• Do not use the appliance as a work surface or as a storage surface.
Warning! Risk of damage to the
appliance.
• Do not keep hot cookware on the control
panel.
• Be careful not let objects or cookware fall
on the control panel. The surface can be
damaged.
• Do not activate the cooking zones with
empty cookware or without cookware.
CARE AND CLEANING
Warning! Risk of damage to the
appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
DISPOSAL
Warning! Risk of injury or suffocation.
USE
Warning! Risk of injury, burns or
electric shock.
• Only use the appliance to operate the
hob.
• Use this appliance in a household environment.
• Do not change the specification of this
appliance.
• Do not let the appliance stay unattended
during operation.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Set the cooking zone to “off” after each
use. Do not rely on the pan detector.
• Contact your municipal authority for information on how to discard the appliance
correctly.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
SERVICE
• Contact the Service to repair the appliance. We recommend only the use of
original spare parts.
PRODUCT DESCRIPTION
GENERAL OVERVIEW
1 Control knobs
1
4 electrolux
THE CONTROL KNOB
1
2
1 Illuminated control knob
2 Assignment of the control knob
DAILY USE
To use the appliance, push the control
knob. The control knob comes out.
To switch on and increase the heat setting
turn the knob clockwise. To decrease the
heat setting turn the knob counter-clockwise. To switch off turn the knob to the 0.
0
The zone is off
Keep warm
1
Minimum heat setting
9
Maximum heat setting
Activates outside ring
the surface you cook to the dimension of
the cookware.
You can activate it only for the cooking
zones with outer rings.
To activate the outer ring turn the knob
clockwise, through a light resistance, to the
. Then turn the knob counterclockwise
to the necessary heat setting. To deactivate
turn the knob to the 0.
Do the procedure again to deactivate the
outer ring.
The knob illumination comes on when
the appliance operates.
ACTIVATION AND DEACTIVATION OF
THE OUTER RINGS
If you connect the appliance to the hob with
the multiple cooking zones, you can adjust
HELPFUL HINTS AND TIPS
EXAMPLES OF COOKING
APPLICATIONS
The data in the table is for guidance only.
Heat
setting
-1
1-2
Use to:
Time
Hints
Keep cooked foods warm
as required
Cover the food
Hollandaise sauce, melt: butter, chocolate, gelatine
5-25
min
Mix occasionally
electrolux 5
Heat
setting
Use to:
Time
Hints
1-2
Solidify: fluffy omelettes, baked eggs
10-40
min
Cook with a lid on
2-3
Simmer rice and milkbased dishes,
heating up ready-cooked meals
25-50
min
Add at least twice as much liquid as
rice, stir milk dishes part way
through
3-4
Steam vegetables, fish, meat
20-45
min
Add a few tablespoons of liquid
4-5
Steam potatoes
20-60
min
Use max. ¼ l water for 750 g of potatoes
4-5
Cook larger quantities of food, stews
and soups
60-150
min
Up to 3 l liquid plus ingredients
6-7
Gentle fry: escalope, veal cordon bleu,
cutlets, rissoles, sausages, liver, roux,
eggs, pancakes, doughnuts
as required
Turn halfway through
7-8
Heavy fry, hash browns, loin steaks,
steaks
5-15
min
Turn halfway through
9
Boil large quantities of water, cook pasta, sear meat (goulash, pot roast), deep fry chips
CARE AND CLEANING
• Clean the front of the appliance with a
soft cloth and hot water.
• Do not use scouring agents and abrasive
sponges.
TROUBLESHOOTING
Problem
Possible cause and remedy
The appliance does not operate.
Examine the fuse in the electrical system of the house in the fuse
box. If the fuses blow time after time, speak to an authorized
electrician.
If you tried the above solutions and cannot
repair the problem, speak to your dealer or
the Customer Care Department. Give the
data from the rating plate.
If you operated the appliance incorrectly,
the servicing by a customer service techni-
cian or dealer will not be free of charge,
even during the warranty period. The instructions about the customer service and
conditions of guarantee are at the end of
this manual or in the guarantee booklet.
INSTALLATION
SAFETY INSTRUCTIONS
TECHNICAL DATA
Dimensions
Height / Width
124 mm / 547 mm
Warning! During installation in
combustible matter, NIN SEV 1000 and
fire protection guidelines and
regulations of the Association of
Cantonal Fire Insurance shall be strictly
adhered to.
Warning! You must read these!
Fully obey the laws, ordinances, directives and standards in force in the
country where you use the appliance
(safety regulations, recycling regulations, electrical safety rules etc.)!
Only a qualified electrician must install
the appliance!
6 electrolux
Warning! Risk of injury from electrical
current.
The combination appliance is live.
• Observe electrical safety rules.
• Rated voltage of the combined appliances must match.
• Fit plug and socket connections together
properly.
• Install correctly to give anti-shock protection.
• Loose and incorrect plug and socket
connections can make the terminal become too hot.
• A qualified electrician must install the
clamping connections correctly.
plate no. 374 2706 00 (cross member).
Fit the screws (F) loosely with the clamp.
• If necessary, you can adjust the height of
the control panel. To do that, remove the
screws D on each side of the control
panel. Loosen the screws E, adjust the
height (only +/- 10 mm is possible) and
tighten the screws again.
• Move the control panel into the recess
and make sure that the safety clamps are
above the angle brackets. Align the control panel and tighten from below.
Caution! Put the second rating plate in
the cabinet B (see the graphic below).
You must put it in a position that is
easy to see, on a surface free of dust
and grease.
ASSEMBLY
• Drill the installation holes for the control
panel into the recess floor. Use the temDetail C
min. 20
min. 30
3
1
32
D
88
124
±10
127
68
E
2
F
50
min. 60
205
240 (220)
2
electrolux 7
600
580
B
800
20
C
Top view:
96
96
547
ELECTRICAL CONNECTION
Use a power cable of H05VV-F or higher.
Connect the appliance to a socket supply
line. If there is no socket supply line, the
electrical installation must have an isolation
device which lets you disconnect the appliance from the power supply. The isolation
device must have a contact opening width
of minimum 3 mm (in reference to NIN SEV
1000). The customer must have a socket
for the electrical connection that is accessible and outside the coordination room. The
length of the connection cable must be approximately 120 cm with lines connected
directly to the power supply.
8 electrolux
400V
400V 2~
400V
400V 3~
PE L1 L2 L3
1
2
3
5
4
PE L1
1
L2
2
3
5
4
Important! Only a qualified person can
connect the appliance to the electricity
supply.
1. Do the electrical connections as in the
connection illustration.
Connection diagram 400V
Phase definitions: L1, L2, L3 (or R, S,
T).
2. Secure the cable grip.
Warning! If service is required always
disconnect the appliance from the
power supply.
2
3
4
1
1 = 45 mm
2 = 45 mm
3 = 60 mm
4 = 60 mm
= 70 mm
1
2
3
4
ENVIRONMENT CONCERNS
The symbol on the product or on its
packaging indicates that this product may
not be treated as household waste. Instead
it should be taken to the appropriate
collection point for the recycling of electrical
electrolux 9
and electronic equipment. By ensuring this
product is disposed of correctly, you will
help prevent potential negative
consequences for the environment and
human health, which could otherwise be
caused by inappropriate waste handling of
this product. For more detailed information
about recycling of this product, please
contact your local council, your household
waste disposal service or the shop where
you purchased the product.
PACKAGING MATERIAL
The packaging materials are friendly to
the environment and can be recycled.
The plastic components are identified
by marking: >PE<,>PS<, etc. Discard
the packaging materials as household
waste at the waste disposal facilities in
your municipality.
Dispose of the appliance at any shop that
sells new appliances or at the official SENS
collection point. You can find the list of the
official SENS collection points at
www.sens.ch.
