EKC4461AEW
EN COOKER
USER MANUAL
2
www.electrolux.com
CONTENTS
1. SAFETY INFORMATION...................................................................................... 3
2. SAFETY INSTRUCTIONS.....................................................................................4
3. PRODUCT DESCRIPTION................................................................................... 7
4. BEFORE FIRST USE............................................................................................ 8
5. HOB - DAILY USE............................................................................................... 8
6. HOB - HINTS AND TIPS...................................................................................... 9
7. HOB - CARE AND CLEANING............................................................................. 9
8. OVEN - DAILY USE .......................................................................................... 10
9. OVEN - CLOCK FUNCTIONS............................................................................ 12
10. OVEN - HINTS AND TIPS................................................................................ 13
11. OVEN - CARE AND CLEANING....................................................................... 19
12. TROUBLESHOOTING......................................................................................21
13. INSTALLATION................................................................................................22
14. ENERGY EFFICIENCY..................................................................................... 23
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can be
safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
ENGLISH
1.
3
SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible if an incorrect installation and use causes
injuries and damages. Always keep the instructions with
the appliance for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
•
•
•
•
•
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Do not let children play with the appliance.
Keep all packaging away from children.
Keep children and pets away from the appliance when it
operates or when it cools down. Accessible parts are
hot.
Cleaning and user maintenance shall not be made by
children without supervision.
1.2 General Safety
•
•
•
•
•
•
Only a qualified person must install this appliance and
replace the cable.
Do not operate the appliance by means of an external
timer or separate remote-control system.
Unattended cooking on a hob with fat or oil can be
dangerous and may result in fire.
Never try to extinguish a fire with water, but switch off
the appliance and then cover flame e.g. with a lid or a
fire blanket.
Do not store items on the cooking surfaces.
Do not use a steam cleaner to clean the appliance.
4
www.electrolux.com
•
•
•
•
•
•
•
•
•
Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they can
get hot.
If the glass ceramic surface / glass surface is cracked,
switch off the appliance to avoid the possibility of
electric shock.
Internally the appliance becomes hot when in operation.
Do not touch the heating elements that are in the
appliance. Always use oven gloves to remove or put in
accessories or ovenware.
Before maintenance cut the power supply.
Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch
the surface, which may result in shattering of the glass.
If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the side
walls. Install the shelf supports in the opposite
sequence.
The means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring rules.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Obey the installation instruction
supplied with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Do not pull the appliance by the
handle.
• The kitchen cabinet and the recess
must have suitable dimensions.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is
installed below and adjacent safe
structures.
• Parts of the appliance carry current.
Close the appliance with furniture to
prevent touching the dangerous parts.
ENGLISH
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
• Do not install the appliance on a
platform.
• Do not install the appliance adjacent to
a door or under a window. This
prevents hot cookware to fall from the
appliance when the door or the
window is opened.
• Make sure to install a stabilizing means
in order to prevent tipping of the
appliance. Refer to Installation chapter.
2.2 Electrical Connection
WARNING!
Risk of fire and electrical
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not let mains cables touch or come
near the appliance door, especially
when the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation device
5
must have a contact opening width of
minimum 3 mm.
• Fully close the appliance door, before
you connect the mains plug to the
mains socket.
2.3 Use
WARNING!
Risk of injury and burns.
Risk of electrical shock.
• Use this appliance in a household only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is in
operation. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not use the appliance as a work
surface or as a storage surface.
WARNING!
Risk of fire and explosion
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases
can cause spontaneous combustion.
• Used oil, that can contain food
remnants, can cause fire at a lower
temperature than oil used for the first
time.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Open the appliance door carefully. The
use of ingredients with alcohol can
cause a mixture of alcohol and air.
WARNING!
Risk of damage to the
appliance.
6
www.electrolux.com
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other
objects in the appliance directly on
the bottom.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and food
in the appliance after you finish the
cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel has no
effect on the performance of the
appliance. It is not a defect in the
sense of the warranty law.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• Do not keep hot cookware on the
control panel.
• Do not let cookware boil dry.
• Be careful not to let objects or
cookware fall on the appliance. The
surface can be damaged.
• Do not activate the cooking zones with
empty cookware or without cookware.
• Do not put aluminium foil on the
appliance or directly on the bottom of
the appliance.
• Cookware made of cast iron,
aluminium or with a damaged bottom
can cause scratches. Always lift these
objects up when you have to move
them on the cooking surface.
• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
2.4 Care and Cleaning
WARNING!
Risk of injury, fire, or damage
to the appliance.
• Before maintenance, deactivate the
appliance.
Disconnect the mains plug from the
mains socket.
• Make sure the appliance is cold. There
is the risk that the glass panels can
break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service Centre.
• Be careful when you remove the door
from the appliance. The door is heavy!
• Clean regularly the appliance to
prevent the deterioration of the surface
material.
• Remaining fat or food in the appliance
can cause fire.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
• If you use an oven spray, obey the
safety instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
2.5 Internal light
• The type of light bulb or halogen lamp
used for this appliance is only for
household appliances. Do not use it for
house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
2.7 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
ENGLISH
7
3. PRODUCT DESCRIPTION
3.1 General overview
7
1
2
3
4
5
3
2
1
5
4
3
2
1
2
3
4
5
6
7
Control panel and hob
Air vents for the cooling fan
Heating element
Lamp
Shelf support, removable
Fan
Shelf positions
4
5
6
1
3.2 Cooking surface layout
1
145 mm
180 mm
180 mm
6
1 Cooking zone 1200 W
2 Steam outlet - number and position
depend on the model
3 Cooking zone 1700 W
4 Cooking zone 1200 W
5 Residual heat indicator
6 Cooking zone 1700 W
3
2
145 mm
5
4
3.3 Cooker control panel
1
2
6
3
4
1
5
Knobs for the hob
Knob for the top oven functions
Electronic programmer
Knob for the main oven functions
Temperature lamp / symbol / indicator
for the main oven
6 Temperature lamp / symbol / indicator
for the top oven
1
2
3
4
5
8
www.electrolux.com
3.4 Accessories
• Wire shelf
For cookware, cake tins, roasts.
• Grill- / Roasting pan
To bake and roast or as pan to collect
fat.
• Trivet
For roasting and grilling.
Use the trivet only with the
Grill- / roasting pan.
4. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
4.3 Changing the time
You cannot change the time
of day if the Duration
4.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the appliance.
Refer to "Care and cleaning"
chapter.
Clean the appliance before first use.
Put the accessories and the removable
shelf supports back to their initial position.
4.2 Setting the time
You must set the time before you operate
the oven.
Only the top oven works
without the set time.
The indicator for the Time of day function
flashes when you connect the appliance
to the electrical supply, when there was a
power cut or when the timer is not set.
or
button to set the
Press the
correct time.
After approximately five seconds, the
flashing stops and the display shows the
time of day you set.
End
Press
again and again until the
indicator for the Time of Day function
flashes.
To set a new time, refer to "Setting the
time".
4.4 Preheating
Preheat the empty appliance to burn off
the remaining grease.
Preheat the two ovens. Heat
up one oven at a time.
1. Set the maximum temperature.
2. Let the appliance operate for 1 hour.
3. Set the function .
4. Let the appliance operate for 15
minutes.
Accessories can become hotter than
usual. The appliance can emit an odour
and smoke. This is normal. Make sure that
the airflow is sufficient.
5. HOB - DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Heat setting
Symbols Function
Off position
or
function operates.
Symbols Function
1-6
Heat settings
ENGLISH
Use the residual heat to
decrease energy
consumption. Deactivate the
cooking zone approximately
5 - 10 minutes before the
cooking process is
completed.
9
5.2 Residual heat indicator
WARNING!
There is a risk of burns from
residual heat.
The indicator comes on when a cooking
zone is hot.
Turn the knob to a necessary heat setting.
To complete the cooking process, turn the
knob to the off position.
6. HOB - HINTS AND TIPS
WARNING!
Refer to Safety chapters.
6.1 Cookware
The bottom of the cookware
must be as thick and flat as
possible.
Cookware made of
enamelled steel and with
aluminium or copper bottoms
can cause the colour change
on the glass-ceramic surface.
Heat
setting:
Application:
2
Gentle simmering
3
Simmering
4
Frying / browning
5
Bringing to the boil
6
Bringing to the boil / quick frying / deep-frying
6.2 Examples of cooking
applications
Heat
setting:
Application:
1
Keeping warm
7. HOB - CARE AND CLEANING
WARNING!
Refer to Safety chapters.
7.1 General information
• Clean the hob after each use.
• Always use cookware with clean
bottom.
• Scratches or dark stains on the surface
have no effect on how the hob
operates.
• Use a special cleaner applicable for the
surface of the hob.
• Use a special scraper for the glass.
7.2 Cleaning the hob
• Remove immediately: melted plastic,
plastic foil, and food with sugar. If not,
the dirt can cause damage to the hob.
Put the special scraper on the glass
surface at an acute angle and move
the blade on the surface.
• Remove when the hob is
sufficiently cool: limescale rings,
water rings, fat stains, shiny metallic
10
www.electrolux.com
discoloration. Clean the hob with a
moist cloth and some detergent. After
cleaning, rub the hob dry with a soft
cloth.
8. OVEN - DAILY USE
WARNING!
Refer to Safety chapters.
8.1 Activating and deactivating
the top / main oven
1. Turn the knob for the top / main oven
functions to select an oven function.
2. To deactivate the oven turn the knob
for the top / main oven functions to
the off position.
It depends on the model if
your appliance has knob
symbols, indicators or
lamps:
• The indicator comes on
when the oven heats up.
• The lamp comes on when
the oven operates.
• The symbol shows
whether the knob controls
one of the cooking zones,
the oven functions or the
temperature.
8.2 Top oven functions
Symbol
100 - 250
Oven function
Application
Off position
The appliance is off.
Oven Lamp
To activate the lamp without a cooking function.
Conventional Cooking
To bake and roast food on 1 shelf position.
Dual Circuit Grill
To grill food items in medium quantities in the middle of the shelf. To make toasts.
Full Grill
To grill flat food and to toast bread.
8.3 Main oven functions
Symbol
Oven function
Application
Off position
The appliance is off.
ENGLISH
Symbol
100 - 250
Oven function
Application
Oven Lamp
To activate the lamp without a cooking function.
Defrost
To defrost frozen food.
Thermaflow®
To bake on 1 shelf position and to dry food. Set
the temperature 20 - 40 °C lower than for Conventional Cooking.
11
8.4 Cooling fan
When the appliance operates, the cooling
fan activates automatically to keep the
surfaces of the appliance cool. If you
deactivate the appliance, the cooling fan
can continue to operate until the appliance
cools down.
8.5 Inserting the oven
accessories
Deep pan:
Push the deep pan between the guide
bars of the shelf support.
• All accessories have small
indentations at the top of
the right and left side to
increase safety. The
indentations are also antitip devices.
• The high rim around the
shelf is a device which
prevents cookware from
slipping.
8.6 Trivet and Grill- / Roasting
pan
Wire shelf and the deep pan together:
Push the deep pan between the guide
bars of the shelf support and the wire shelf
on the guide bars above.
WARNING!
Be careful when you remove
the accessories from a hot
appliance. There is a risk of
burns.
You can use the trivet to roast larger
pieces of meat or poultry on one shelf
position.
1. Put the trivet into the deep pan so that
the supports of the wire shelf point up.
12
www.electrolux.com
2. Put the deep pan into the oven on the
necessary shelf position.
You can use the trivet to grill flat dishes in
large quantities and to toast.
2. Put the deep pan into the oven on the
necessary shelf position.
1. Put the trivet into the deep pan so that
the supports of the wire shelf point
down.
9. OVEN - CLOCK FUNCTIONS
9.1 Display
The electronic programmer
works only with the main
oven.
A
B
A) Function indicators
B) Time display
C) Function indicator
C
9.2 Buttons
Button
Function
Description
MINUS
To set the time.
CLOCK
To set a clock function.
PLUS
To set the time.
9.3 Clock functions table
Clock function
Time of day
Application
To set, change or check the time of day.
ENGLISH
Clock function
13
Application
Minute Minder
To set countdown time. This function has no effect on the
operation of the appliance.
Duration
To set the cooking time of the oven.
End
To set the time of day when the oven should deactivate.
For the Minute Minder
function the display shows
the time left.
3. When the time ends the indicator of
the clock function flashes and an
acoustic signal sounds. Press a
button to stop the signal.
4. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
You can use the functions
Duration
and End
at
the same time to set the time
for how long the appliance
should operate and when the
appliance should deactivate.
This lets you activate the
appliance with a delay in
time. First set the Duration
and then the End
.
With the Duration
9.4 Setting the clock functions
For Duration
and End
, set an oven
function and temperature of cooking. This
is not necessary for the Minute Minder
.
and
End
functions, the
appliance deactivates
automatically.
The functions work only for
the main oven.
1. Press
again and again until the
indicator for the necessary clock
function starts to flash.
9.5 Cancelling the clock
functions
or
to set the time for the
2. Press
necessary clock function.
The clock function operates. The display
shows the indicator for the clock function
you set.
1. Press the
again and again until the
necessary function indicator flashes.
2. Press and hold .
The clock function goes out after some
seconds.
10. OVEN - HINTS AND TIPS
WARNING!
Refer to Safety chapters.
The temperature and baking
times in the tables are
guidelines only. They depend
on the recipes and the quality
and quantity of the
ingredients used.
10.1 Top oven
The top oven is the smaller of the two
ovens. It has 3 shelf positions. Use it to
cook smaller quantities of food. It gives
especially good results when used to cook
fruitcakes, sweets and savoury flants or
quiche.
10.2 Main oven
The main oven is particularly suitable for
cooking larger quantities of food.
10.3 Baking
• Your oven can bake or roast differently
to the appliance you had before. Adapt
your usual settings (temperature,
14
www.electrolux.com
•
•
•
•
cooking times) and shelf positions to
the values in the tables.
The manufacturer recommends that
you use the lower temperature the first
time.
If you cannot find the settings for a
special recipe, look for the one that is
almost the same.
You can extend baking times by 10 –
15 minutes if you bake cakes on more
than one shelf position.
Cakes and pastries at different heights
do not always brown equally at first. If
this occurs, do not change the
temperature setting. The differences
equalize during the baking procedure.
• With longer baking times, you can
deactivate the oven approximately 10
minutes before the end of the baking
time and then use the residual heat.
When you cook frozen food, the trays in
the oven can twist during baking. When
the trays become cold again, the
distortions are gone.
10.4 Tips on baking
Baking results
Possible cause
Remedy
The bottom of the cake is
not browned sufficiently.
The shelf position is incorrect.
Put the cake on a lower
shelf.
The cake sinks and becomes soggy, lumpy or
streaky.
The oven temperature is too The next time you bake, set
high.
a slightly lower oven temperature.
The cake sinks and becomes soggy, lumpy or
streaky.
The baking time is too
short.
Set a longer baking time.
You cannot decrease
baking times by setting
higher temperatures.
The cake sinks and becomes soggy, lumpy or
streaky.
There is too much liquid in
the mixture.
Use less liquid. Be careful
with mixing times, especially
if you use a mixing machine.
The cake is too dry.
The oven temperature is too The next time you bake, set
low.
a higher oven temperature.
The cake is too dry.
The baking time is too long. The next time you bake, set
a shorter baking time.
The cake browns unevenly.
The oven temperature is too Set a lower oven temperahigh and the baking time is ture and a longer baking
too short.
time.
The cake browns unevenly.
The mixture is unevenly dis- Spread the mixture evenly
tributed.
on the baking tray.
The cake is not ready in the The oven temperature is too The next time you bake, set
baking time given.
low.
a slightly higher oven temperature.
ENGLISH
10.5 Conventional Baking - Top Oven
Food
Temperature (°C)
Time (min)
Shelf position
Biscuits
170 - 190
10 - 20
2
Bread
200 - 220
30 - 35
2
Bread rolls / buns
200 - 220
10 - 15
2
Cakes: Small & Queen
160 - 180
18 - 25
2
Cakes: Sponges
160 - 175
20 - 30
2
Cakes: Victoria Sandwich
160 - 170
18 - 25
2
Cakes: Madeira
140 - 150
75 - 90
2
Cakes: Rich Fruit
140 - 150
120 - 150
2
Cakes: Gingerbread
140 - 150
80 - 90
2
Cakes: Meringues
90 - 100
150 - 180
2
Cakes: Flapjack
160 - 170
25 - 30
2
Cakes: Shortbread
130 - 150
45 - 60
2
Cakes: Apple Pie
170 - 180
50 - 60
2
Casseroles: Beef / Lamb
160 - 170
150 - 180
2
Casseroles: Chicken
160 - 180
80 - 90
2
Convenience Foods
Follow manufacturer`s instructions.
2
Fish
170 - 190
20 - 30
2
Fish Pie (Potato Topped)
190 - 200
20 - 30
2
Fruit Pies, Crumbles
190 - 200
30 - 50
2
Milk Puddings
150 - 170
90 - 120
2
Pasta Lasagne etc.
170 - 180
40 - 50
2
Pastry: Choux
180 - 190
30 - 40
2
Pastry: Eclairs, Profiteroles
180 - 190
30 - 40
2
Pastry: Flaky / Puff Pies
210 - 220
30 - 40
2
Shortcrusts: Mince Pies
190 - 200
15 - 20
2
Shortcrusts: Meat Pies
190 - 210
25 - 35
2
Shortcrusts: Quiche, Tarts,
Flans
180 - 200
25 - 50
2
Scones
220 - 230
8 - 12
3
Shepard`s Pie
190 - 200
30 - 40
2
15
16
www.electrolux.com
Food
Temperature (°C)
Time (min)
Shelf position
Souffles
170 - 180
20 - 30
2
Vegetables: Baked Jacket Potatos
180 - 190
60 - 90
2
Vegetables: Roast Potatos
180 - 190
60 - 90
2
Yorkshire Pudding Large
220 - 210
25 - 40
2
Yorkshire Pudding Individual
210 - 220
15 - 25
2
Roasting Meat, Poultry
Refer to the Roasting table.
2
10.6 Thermaflow® Baking Main Oven
Shelf positions are not critical
but ensure that the oven
accessories are evenly
spaced when more than one
is used.
Food
Temperature
(°C)
Time (min)
Shelf position
Biscuits
180 - 190
10 - 20
1–3
Bread
190 - 210
30 - 35
2
Cakes: Small & Queen
150 - 170
18 - 25
1–3
Cakes: Sponges
160 - 170
20 - 25
3
Cakes: Madeira
140 - 160
60 - 80
3
Cakes: Rich Fruit
130 - 140
120 - 150
3
Cakes: Christmas
130 - 140
180 - 270
3
Cakes: Apple Pie
160 - 170
50 - 60
3
- Shortbread
130 - 150
45 - 60
1–3
Fish
160 - 180
30 - 40
3
Fruit Pies, Crumbles
170 - 180
30 - 50
3
Milk Puddings
140 - 160
60 - 90
3
Pastry: Choux
180 - 190
30 - 40
3
Pastry: Shortcrust
180 - 190
25 - 35
3
Pastry: Flaky
180 - 190
30 - 40
3
ENGLISH
Food
Temperature
(°C)
Pastry: Puff
Follow manufacturer`s instructions.
Reduce the temperature for Fan oven
by 20 °C.
3
Plate Tarts
180 - 190
25 - 45
3
Quiches / Flans
170 - 180
25 - 45
3
Scones
210 - 230
8 - 12
1–3
Roasting: Meat, Poultry
160 - 180
Refer to the
Roasting table.
2
10.7 Roasting
• Use heat-resistant ovenware to roast
(refer to the instructions of the
manufacturer).
• You can roast large roasting joints
directly in the deep pan (if present) or
on the wire shelf above the deep pan.
• Roast lean meats in the roasting tin
with the lid. This keeps the meat more
succulent.
• All types of meat that can be browned
or have crackling can be roasted in the
roasting tin without the lid.
• We recommend that you cook meat
and fish weighing 1 kg and above in
the appliance.
Time (min)
17
Shelf position
• To prevent the meat juices or fat from
burning onto the pan, put some liquid
into the deep pan.
• If necessary, turn the roast (after 1/2 2/3 of the cooking time).
• Baste large roasts and poultry with
their juices several times during
roasting. This gives better roasting
results.
• You can deactivate the appliance
approximately 10 minutes before the
end of the roasting time, and use the
residual heat.
10.8 Thermaflow® - Main Oven
Roasting
Food
Temperature
(°C)
Time (min)
Beef / Beef boned
170 - 190
20 - 35 minutes per 0.5 kb (1 lb) and 20 - 30
minutes over
Mutton / Lamb
170 - 190
20 - 35 minutes per 0.5 kb (1 lb) and 25 - 35
minutes over
Pork / Veal / Ham
170 - 190
30 - 40 minutes per 0.5 kb (1 lb) and 30 - 40
minutes over
Chicken
180 - 200
20 - 25 minutes per 0.5 kb (1 lb) and 20 minutes over
Turkey / Goose
170 - 190
15 - 20 minutes per 0.5 kg (1 lb) up to 3.5 kg
(7 lb) then 10 minutes per 0.5 kg (1 lb) over 3.5
kg (7 lb)
18
www.electrolux.com
Food
Temperature
(°C)
Time (min)
Duck
180 - 200
25 - 35 minutes per 0.5 kb (1 lb) and 25 - 30
minutes over
Pheasant
170 - 190
35 - 40 minutes per 0.5 kb (1 lb) and 35 - 40
minutes over
Rabbit
170 - 190
20 minutes per 0.5 kb (1 lb) and 20 minutes
over
10.9 Grilling in general
• Grill only flat pieces of meat or fish.
• Always preheat an empty oven with
the grill functions for 5 minutes.
WARNING!
Always grill with the oven
door closed.
• Always grill with the maximum
temperature setting.
• Set the shelf into the shelf position as
recommended in the grilling table.
• Always set the deep pan to collect the
fat into the first shelf position.
• Set the deep pan and the trivet as
recommended in the grilling table.
The grilling area is set in centre of the
shelf.
10.10 Dual Grill - Top Oven
Food
Time (min)
Shelf position
Bacon Rashers
5-6
3
Beefburgers
10 - 20
3
Chicken Joints
20 - 40
2
Chops - Lamb
15 - 25
2-3
Chops - Pork
20 - 25
2-3
Fish - Whole / Trout / Makarel
10 - 12
2
Fillets - Plaice / Cod
4-6
2
Kebabs
12 - 18
2-3
Kidneys - Lamb / Pig
6 - 10
2-3
Sausages
20 - 30
3
Steaks: Rare
4-6
3
Steaks: Medium
6-8
3
Steaks: Well Done
12 - 15
3
Toasted Sandwiches
3-4
3
ENGLISH
10.11 Defrost
• Remove the food packaging. Put the
food on a plate.
• Do not cover it with a bowl or a plate.
This can extend the defrost time.
19
• Use the first shelf position. The one on
the bottom.
11. OVEN - CARE AND CLEANING
WARNING!
Refer to Safety chapters.
11.1 Notes on cleaning
• Clean the front of the appliance with a
soft cloth with warm water and a
cleaning agent.
• To clean metal surfaces, use a usual
cleaning agent.
• Clean the appliance interior after each
use. Fat accumulation or other food
remains may result in a fire. The risk is
higher for the grill pan.
• Clean stubborn dirt with a special oven
cleaner.
• Clean all accessories after each use
and let them dry. Use a soft cloth with
warm water and a cleaning agent.
• If you have nonstick accessories, do
not clean them using aggressive
agents, sharp-edged objects or a
dishwasher. It can cause damage to
the nonstick coating.
11.2 Stainless steel or aluminium
appliances
Clean the oven door with a
wet sponge only. Dry it with a
soft cloth.
Do not use steel wool, acids
or abrasive materials as they
can damage the oven
surface. Clean the oven
control panel with the same
precautions.
11.3 Catalytic cleaning
CAUTION!
Do not clean the catalytic
surface with oven sprays,
abrasive cleaning agents,
soap or other cleaning
agents. This will damage the
catalytic surface.
Spots or discolouration of the
catalytic surface have no
effect on catalytic properties.
WARNING!
Keep children away when
you clean the oven at a high
temperature. The oven
surface becomes very hot
and there is a risk of burns.
CAUTION!
Always turn the oven light on
while using the catalytic
cleaning (if applicable).
Before activating the catalytic
cleaning remove all the
accessories from the oven.
The walls with a catalytic coating are selfcleaning. They absorb fat which collects
on the walls while the appliance operates.
To support the self-cleaning procedure,
heat the empty oven on a regular basis.
1. Clean the oven floor with warm water
and washing up liquid, then dry it.
2. Set the oven temperature to 250 °C
and let the oven operate for 1 hour.
3. When the appliance is cool, clean it
with a soft and moist sponge.
20
www.electrolux.com
11.4 Removing the shelf
supports
2. Hold the door trim on the top edge of
the door at the two sides and push
inwards to release the clip seal.
To clean the oven, remove the shelf
supports.
1
1. Pull the front of the shelf support away
from the side wall.
2
1
2. Pull the rear end of the shelf support
away from the side wall and remove it.
3. Pull the door trim to the front to
remove it.
4. Remove the glass panels.
To install the panels, do the same steps in
reverse.
11.6 Removing and cleaning the
door glasses - main oven
1
2
Install the shelf supports in the opposite
sequence.
CAUTION!
Make sure that the longer
fixing wire is in the front. The
ends of the two wires must
point to the rear. Incorrect
installation can cause
damage to the enamel.
11.5 Removing and cleaning the
door glasses - top oven
The door glass in your
product can be different in
type and shape from the
example you see in the
image. The number of
glasses can also be different.
1. Push the door trim at one side to
remove it.
A
2
1
The door glass in your
product can be different in
type and shape from the
examples you see in the
image. The number of
glasses can also be different.
1. Open the door.
2. Pull up the trim.
3. Remove the glass panels.
ENGLISH
To replace the glass panels,
do the same steps in reverse.
Before you lower the trim,
attach the A trim part to the
door. Refer to the image.
1. Deactivate the appliance.
2. Remove the fuses from the fuse box
or deactivate the circuit breaker.
The back lamp
The lamp glass cover is at the
back of the cavity.
11.7 Replacing the lamp
Put a cloth on the bottom of the interior of
the appliance. It prevents damage to the
lamp glass cover and the cavity.
WARNING!
Danger of electrocution!
Disconnect the fuse before
you replace the lamp.
The lamp and the lamp glass
cover can be hot.
21
1. Turn the lamp glass cover
counterclockwise to remove it.
2. Clean the glass cover.
3. Replace the oven lamp with a suitable
300 °C heat-resistant oven lamp.
Use the same oven lamp type.
4. Install the glass cover.
12. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
12.1 What to do if...
Problem
Possible cause
Remedy
You cannot activate the ap- The appliance is not conpliance.
nected to an electrical supply or it is connected incorrectly.
Check if the appliance is
correctly connected to the
electrical supply.
You cannot activate the ap- The fuse is released.
pliance.
Make sure that the fuse is
the cause of the malfunction. If the fuse releases
again and again, contact a
qualified electrician.
Residual heat indicator
does not come on.
If the zone operated sufficiently long to be hot,
speak to an Authorised
Service Centre.
The zone is not hot because it operated only for a
short time.
The oven does not heat up. The oven is deactivated.
Activate the oven.
The oven does not heat up. The clock is not set.
Set the clock.
The oven does not heat up. The necessary settings are
not set.
Make sure that the settings
are correct.
The lamp does not operate. The lamp is defective.
Replace the lamp.
The display shows "12.00".
Reset the clock.
There was a power cut.
22
www.electrolux.com
Problem
Possible cause
Remedy
Steam and condensation
You left the dish in the oven Do not leave the dishes in
settle on the food and in the for too long.
the oven for longer than 15
cavity of the oven.
- 20 minutes after the cooking process ends.
12.2 Service data
If you cannot find a solution to the
problem yourself, contact your dealer or
an Authorised Service Centre.
the front frame of the appliance cavity. Do
not remove the rating plate from the
appliance cavity.
The necessary data for the service centre
is on the rating plate. The rating plate is on
We recommend that you write the data here:
Model (MOD.)
.........................................
Product number (PNC)
.........................................
Serial number (S.N.)
.........................................
13. INSTALLATION
WARNING!
Refer to Safety chapters.
13.1 Technical data
B
Dimensions
Height
894 - 912 mm
Width
550 mm
Depth
A
A
600 mm
13.2 Location of the appliance
You can install your freestanding
appliance with cabinets on one or two
sides and in the corner.
Minimum distances
Dimension
mm
A
2
B
685
ENGLISH
13.3 Levelling of the appliance
Use small feet on the bottom of appliance
to set the appliance top surface level with
other surfaces.
• The recommended cross-section area
is six square millimetres (6 mm²).
• When you refit the mains terminal
cover, make sure that the lower tabs
are located inside the bottom edge of
the aperture, before you fix the two
screws into the top edge of the mains
terminal cover.
• Make sure that the cover is securely
fastened.
To open the cover of terminal
board obey the procedure in
opposite sequence.
13.6 Terminal board
Do not remove blanking
plates.
13.4 Electrical installation
WARNING!
The manufacturer is not
responsible if you do not
follow the safety precautions
from Safety chapters.
23
Make sure that the links are fitted as
shown.
This appliance is supplied without a main
plug or a main cable.
13.5 Covering terminal board
L
L
N
N
14. ENERGY EFFICIENCY
14.1 Product information for hob according to EU 66/2014
Model identification
EKC4461AEW
Type of hob
Hob inside Freestanding Cooker
Number of cooking zones
4
Heating technology
Radiant Heater
N
24
www.electrolux.com
Diameter of circular cooking
zones (Ø)
Left front
Left rear
Right front
Right rear
18.0 cm
14.5 cm
14.5 cm
18.0 cm
Energy consumption per
cooking zone (EC electric
cooking)
Left front
Left rear
Right front
Right rear
177.3 Wh/kg
180.3 Wh/kg
180.3 Wh/kg
179.4 Wh/kg
Energy consumption of the hob (EC electric hob)
EN 60350-2 - Household electric cooking
appliances - Part 2: Hobs - Methods for
measuring performance.
14.2 Hob - Energy saving
You can save energy during everyday
cooking if you follow below hints.
• When you heat up water, use only the
amount you need.
• If it is possible, always put the lids on
the cookware.
179.3 Wh/kg
• Before you activate the cooking zone
put the cookware on it.
• The cookware bottom should have the
same diameter as the cooking zone.
• Put the smaller cookware on the
smaller cooking zones.
• Put the cookware directly in the centre
of the cooking zone.
• Use the residual heat to keep the food
warm or to melt it.
14.3 Product Fiche and information for ovens according to EU
65-66/2014
Supplier's name
Electrolux
Model identification
EKC4461AEW
Energy Efficiency Index
Top oven: 105.6
Main oven: 104.6
Energy efficiency class
Top oven: A
Main oven: A
Energy consumption with a standard load, conventional mode
Top oven: 0.75 kWh/cycle
Main oven: not applicable
Energy consumption with a standard load, fanforced mode
Top oven: not applicable
Main oven: 0.91 kWh/cycle
Number of cavities
2
Heat source
Electricity
Volume
Top oven: 39 l
Main oven: 77 l
Type of oven
Oven inside Freestanding Cooker
Mass
52.4 kg
ENGLISH
EN 60350-1 - Household electric cooking
appliances - Part 1: Ranges, ovens, steam
ovens and grills - Methods for measuring
performance.
14.4 Oven - Energy saving
The appliance contains features which
help you save energy during everyday
cooking.
• General hints
– Make sure that the oven door is
closed properly when the
appliance operates and keep it
closed as much as possible during
the cooking.
– Use metal dishes to improve the
energy saving.
– When possible, put the food inside
the oven without heating it up.
25
– When the cooking duration is
longer than 30 minutes, reduce the
oven temperature to minimum, 3 10 minutes before the end of the
cooking time, depending on the
duration of the cooking. The
residual heat inside the oven will
continue to cook.
– Use the residual heat to warm up
other foods.
• Cooking with fan - when possible,
use the cooking functions with fan to
save energy.
• Keep food warm - if you want to use
the residual heat to keep the meal
warm, choose the lowest possible
temperature setting.
15. ENVIRONMENT CONCERNS
Recycle the materials with the symbol .
Put the packaging in applicable containers
to recycle it. Help protect the environment
and human health and to recycle waste of
electrical and electronic appliances. Do
*
not dispose appliances marked with the
symbol with the household waste.
Return the product to your local recycling
facility or contact your municipal office.
26
www.electrolux.com
ENGLISH
27
867307933-A-432014
www.electrolux.com/shop
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
