SAFETY INFORMATION
ENVIRONMENT CONCERNS
PRODUCT DESCRIPTION
ACCESSORIES
CONTROL PANEL
WASHING PROGRAMMES
BEFORE FIRST USE
USING THE APPLIANCE
ACTIVATING THE APPLIANCE AND SETTING A
PROGRAMME
LOADING THE LAUNDRY
USING THE DETERGENT AND ADDITIVES
STARTING A PROGRAMME
AT THE END OF PROGRAMME
HELPFUL HINTS AND TIPS
CARE AND CLEANING
TROUBLE SHOOTER AND SERVICE
TECHNICAL DATA
INSTALLATION
SERVICE
When contacting Service, ensure that
you have the following data available.
The information can be found on the
rating plate.
Model
PNC
Serial Number
The following symbols are used in this
user manual:
Warning - Important Safety information.
General information and tips
Environmental information
Subject to change without notice
ENGLISH
3
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please spend
a few minutes reading to get the very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to keep all your AEG
appliances looking spotless and working perfectly. Along with a wide range of
accessories designed and built to the high quality standards you would expect, from
specialist cookware to cutlery baskets, from bottle holders to delicate laundry bags…
Visit the webshop at:
www.aeg.com/shop
VISIT OUR WEBSITE FOR:
- Products
- Brochures
- User manuals
- Trouble shooter
- Service information
www.aeg.com/shop
4
SAFETY INFORMATION
Before the installation and use, read
this manual carefully:
• For your safety and the safety of your
property
• To help the environment
• For the correct operation of the appliance.
Always keep these instructions with the
appliance also if you move or give it to
a different person.
The manufacturer is not responsible if
an incorrect installation and use causes
damage.
CHILDREN AND VULNERABLE
PERSON SAFETY
• Do not let persons, children included, with reduced physical sensory,
reduced mental functions or lack of
experience and knowledge use the
appliance. They must have supervision or instruction for the operation
of the appliance by a person who is
responsible for their safety.
• Keep all packaging away from children. There is the risk of suffocation
or injury.
• Keep all detergents away from children.
• Keep children and pets away from
the appliance when the door is open.
• Before you close the appliance door,
make sure that children and pets are
not into the drum.
• If the appliance has a child safety device, we recommend to activate it.
CHILD SAFETY DEVICE
• When you activate this device, you
cannot close the door. This prevents
children or pets to be closed in the
drum. To activate the device, turn it
clockwise, until the groove is horizontal. To deactivate the device, turn it
counterclockwise, until the groove is
vertical.
GENERAL SAFETY
• Do not use the appliance for professional use. The appliance is only for
domestic use.
• Do not change the specifications of
this appliance. There is the risk of injury and damage to the appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
Risk of explosion or fire.
• Obey the safety instructions on the
detergent packaging to prevent
burns to eyes, mouth and throat.
• Make sure that you remove all metal
objects from the laundry. Hard and
sharp material can cause damage to
the appliance.
• Do not touch the glass of the door
while a programme operates. The
glass can be hot (only for front-loading appliances).
CARE AND CLEANING
• Deactivate the appliance and disconnect the mains plug from the mains
socket.
• Do not use the appliance without the
filters. Make sure that the installation
of the filters is correct. An incorrect
installation causes water leakages.
INTERNAL LAMP
This appliance has an internal lamp that
comes on when you open the door and
goes off when the door is closed.
ENGLISH
WARNING!
Do not look directly into the
beam of the lamp.
To replace the internal lamp,
contact the service centre.
Disconnect the mains plug from
the mains socket before the replacement of the internal lamp.
INSTALLATION
• The appliance is heavy, be careful
when you move it.
• Do not transport your appliance without the transit bolts, you can damage
internal components and cause leakages or malfunctions.
• Do not install and connect a damaged appliance.
• Make sure to remove all packaging
and transport bolts.
• Make sure that the mains plug is disconnected from the mains socket
during installation.
• Only a qualified person must do the
electrical installation, the plumbing
and the installation of the appliance.
This to prevent the risks of structural
damage or injury.
• Do not install or use the appliance
where the temperature is less than 0
°C.
• When you install the appliance on a
carpet floor, make sure that there is
air circulation between the appliance
and the carpet. Adjust the feet to
have the necessary space between
the appliance and the carpet.
Water connection
• Do not connect the appliance with
old hoses already used. Only use new
hoses.
• Make sure not to cause damage to
the water hoses.
5
• Do not connect the appliance to new
pipes or pipes not used for a long
time. Let the water flow for some minutes, then connect the inlet hose.
• The first time you use the appliance,
make sure that the water hoses and
the couplings do not have leakages.
Electrical connection
• Make sure that the appliance is
earthed.
• Make sure that the electrical information on the rating plate agrees with
the power supply.
• Always use a correctly installed
shockproof socket.
• Do not use multiple plugs and extension cables. There is a risk of fire.
• Do not replace or change the mains
cable. Contact the service centre.
• Make sure not to cause damage to
the mains plug and cable.
• Connect the mains plug to the mains
socket only at the end of the installation. Make sure that there is access
to the mains plug after the installation.
• Do not pull the mains cable to disconnect the appliance. Always pull
the mains plug.
DISCARD THE APPLIANCE
1. Disconnect the mains plug from the
mains socket.
2. Cut off the mains cable and discard
it.
3. Discard the door catch. This prevents children or pets to be closed
in the appliance. There is a risk of
suffocation (only for front-loading
appliances).
6
ENVIRONMENT CONCERNS
PACKAGING MATERIALS
Recycle the materials with the symbol
.
Put the packaging in applicable containers to recycle it.
ECOLOGICAL HINTS
To help the environment, use less water
and energy, obey these instructions:
• Set a programme without the prewash phase to wash laundry with normal soil.
• Always start a washing programme
with the maximum load of laundry.
• If necessary, use a stain remover
when you set a programme with a
low temperature.
• To use the correct quantity of the detergent, check the water hardness of
your domestic system
on the product or on its
The symbol
packaging indicates that this product
may not be treated as household
waste. Instead it should be taken to the
appropriate collection point for the
recycling of electrical and electronic
equipment. By ensuring this product is
disposed of correctly, you will help
prevent potential negative
consequences for the environment and
human health, which could otherwise
be caused by inappropriate waste
handling of this product. For more
detailed information about recycling of
this product, please contact your local
council, your household waste disposal
service or the shop where you
purchased the product.
PRODUCT DESCRIPTION
1
2
3
9
10
11
4
5
6
12
7
13
8
1 Worktop
2 Detergent dispenser
8 Feet for the appliance level
9 Water drain hose
3 Control panel
4 Door handle
10 Water inlet hose
11 Mains cable
5 Internal lamp
6 Rating plate
12 Transit bolts
13 Feet for the appliance level
7 Drain pump
ENGLISH
7
ACCESSORIES
1
2
4
3
1 Spanner
To remove the transit bolts.
2 Plastic caps
To close the holes on the rear side
of the cabinet after the removal of
the transit bolts.
3 Anti-flood inlet hose
To prevent possible leakage
4 Plastic hose guide
To connect the drain hose on the
edge of a sink.
CONTROL PANEL
1
2
3
Glätten
Koch/Bunt
Auffrischen
Extra Leise
Energiesparen
Super Eco
Pflegeleicht
20Min. - 3kg
Feinwäsche
Dampf
Memory 2
Wolle/Seide
Daunen
Auto Off
Anti-Allergie
4
Memory 1
Leichtbügeln
Jeans
Spülen
Schleudern/
Pumpen
Gewichtssensor
Temp.
12
U/Min. Flecken/
Vorw.
11
10
Extra
Spülen
Zeit
Sparen
9
8
Zeitvorwahl
7
5
Start/Pause
6
1 Auto Off button
2 Programme knob
8 Zeit Sparen touch button
9 Extra Spülen touch button
3 Display
4 Dampf touch button
10 Flecken/Vorwäsche/Einweichen
touch button
11 Spin reduction touch button (U./
Min.))
12 Temperature touch button (Temp.)
5 Memory touch buttons
6 Start/Pause touch button
7 Zeitvorwahl touch button
TOUCH SCREEN
Do not wear gloves when you
touch the buttons.
Make sure the touch screen and
buttons are always clean and
dry.
AUTO OFF BUTTON 1
Press this button to activate or deactivate the appliance. A tune sounds when
the appliance is activated.
The AUTO OFF function automatically
deactivates the appliance to decrease
energy consumption when:
8
• Before press button 6 , you do not
use the appliance for five minutes.
Press button 1 to activate the appliance again.
• After 5 minutes from the end of the
washing programme. Refer to 'At the
end of programme'.
PROGRAMME KNOB 2
Turn this knob to set a programme. The
related programme indicator comes on.
DISPLAY 3
A
J
I
A
B
H
G
C
F
D
E
The text bar:
• Guides you in the use of the appliance.
• Shows the programme status and phase.
• Shows alarm messages. Refer to 'Trouble shooter and service' .
The symbols appear on the display when the related phase or function is set.
B
Child lock
C
Door locked
You cannot open the door when the symbol is on.
You can open the door only when the symbol goes off.
If the symbol stays on but the programme is completed:
• There is water in the drum.
• The ' Rinse Hold ' function is on.
• The time of the day
When you activate the appliance the display shows the time of the
day for some seconds. To adjust the clock, refer to "Clock setting".
D
• The programme duration
When the washing programme starts, the programme time decreases
every minute.
Programme duration symbol
The symbol comes on when the digits shows the programme duration.
ENGLISH
9
• The end time of the washing programme .
Programme end symbol
The symbol comes on when the digits shows the programme end time.
• The time of delay
– When you set the delayed start the time of the programme end increases by steps of 30 minutes till 10 hours and by steps of one
hour till 20 hours.
• The end of the programme
The display shows a zero.
This part comes on only if the door is open - Refer to 'Loading the laundry'.
The programme maximum load
E
The weight of the laundry
The indicator bar fills accordingly to the laundry weight.
The indicator fully fills when you put the maximum load.
If you need to set a function
• An empty indicator bar comes on when the related function is available with the set programme. If an indicator bar does not come on, it
means that it is not available.
• The function symbol comes on when the function is set.
• The indicator bar fills accordingly to the set function.
• If you make an incorrect selection the text bar on the display tells that the selection is not possible.
Time save
The symbol comes on when you set the following functions:
F
Shortened duration
Extra quick
Extra rinsing
G
The indicator bar fills accordingly the numbers of rinses.
Stains
Prewash
H
Soak
The indicator bar fills accordingly to the set functions.
10
The default spin speed of the programme.
I
___
No spin 1)
Rinse hold
1) Only available for Spin/Drain programme.
The default temperature of the programme.
J
Cold wash
DAMPF BUTTON 4
ZEITVORWAHL BUTTON 7
Touch button 4 to set the steam level.
This is possible only with programmes
where the steam function is available.
The duration of the steam phase
changes accordingly to your selection.
Touch button 7 to delay the start of a
programme from 30 minutes to 20
hours.
MEMORY BUTTONS 5
Touch button 8 to decrease the programme time.
You can select:
SHORTENED DURATION
To wash items with daily soil.
EXTRA QUICK
To wash quickly items with almost no
soil.
Some programmes accept only one of
these functions.
Touch one of the buttons 5 to memorise a programme or to set a memorised programme.
Memorise a programme
1. Press button 1 to activate the appliance.
2. Turn the programme knob ( 2 ) to
your favourite programme.
3. If it is necessary, set one or more
functions.
4. Touch and hold one of the buttons
5 for some seconds. The buzzer
sounds and the display shows that
the programme is saved. .
Set a memorised programme
1. Touch the button where you memorised the programme you want to
set.
2. The programme indicator comes on
and the display shows all the information.
To cancel a memorised programme you can only memorise
a new programme.
START/PAUSE BUTTON 6
Touch button 6 to start or interrupt a
programme.
ZEITSPAREN BUTTON 8
EXTRA SPÜLEN BUTTON 9
Touch button 9 to add rinsing phases
to a programme.
Use this function for persons allergic to
detergents and in areas where the water is soft.
FLECKEN, VORWÄSCHE UND
EINWEICHEN BUTTON 10
Touch button 10 to set one of the these
functions:
FLECKEN
Use this function for laundry with hard
stains to remove.
When you set this function, put the
.
stain remover into compartment
ENGLISH
The programme duration increases.
This function is not available
with a temperature lower than
40° C.
VORWÄSCHE
Use this function for heavy soil.
The appliance adds a prewash phase to
the main wash.
The programme duration increases.
11
• You touch the buttons.
• The programme is completed.
• The appliance has a malfunction.
To deactivate/activate the acoustic
signals, touch button 10 and button 9
at the same time for 6 seconds.
If you deactivate the acoustic
signals, they continue operate
only when you touch the buttons and when a malfunction occurs.
EINWEICHEN
CHILD LOCK FUNCTION
Use this function for heavy soil.
The appliance soaks the laundry at
30°C for about half an hour before to
wash.
This function prevents children to play
with the control panel.
• To activate the function, touch button 12 and button 11 at the same
time until the display shows the sym.
bol
• To deactivate the function, touch
button 12 and button 11 at the
same time until the symbol
goes
off.
You can activate the function:
• Before you touch the button 6 : the
appliance cannot start.
• After you touch the button 6 , all
the buttons and the programme
knob are deactivated.
SPIN BUTTON 11
Touch button 11 to:
• Decrease the maximum speed of the
spin phase of the programme.
The display shows only the spin
speeds available with the set
programme.
• Deactivate the spin phase (' No Spin '
function).
• Activate the ' Rinse Hold ' function.
Set this function to prevent fabric
creases. The appliance does not
drain the water when the programme
is completed.
TEMPERATURE BUTTON 12
Touch button 12 to change the default
temperature.
= cold water
Symbols - - - and
ACOUSTIC SIGNALS
FUNCTION
You can hear the acoustic signals when:
• You activate the appliance.
• You deactivate the appliance.
PERMANENT EXTRA RINSE
FUNCTION
With this function you can keep the extra rinse function permanently on when
you set a new programme.
• To activate the function touch button 8 and button 7 at the same
time until the display shows the sym.
bol
• To deactivate the function touch
button 8 and button 7 at the
same time until the symbol
goes
off.
12
WASHING PROGRAMMES
Programme
Temperature
Type of load
Weight of load
Programme
description
Functions
Koch/Bunt
95° - Cold
White and coloured cotton
with heavy level
of soil.
Maximum load 8
kg
Wash
Rinses
Long spin
SPIN REDUCTION
SPÜLSTOPP
FLECKEN1)
VORWÄSCHE2)
EINWEICHEN
EXTRA SPÜLEN
ZEIT SPAREN3)
Extra Leise
95° - Cold
White and coloured cotton
with normal level
of soil.
Maximum load 8
kg
Wash
Rinses
Long spin
Stop with water in the
drum
SPÜLSTOPP
FLECKEN1)
VORWÄSCHE2)
EINWEICHEN
EXTRA SPÜLEN
ZEIT SPAREN3)
Pflegeleicht
60° - Cold
Rinses
Short spin
Synthetic or
mixed fabric
items with normal soil.
Maximum load 4
kg
Wash
Rinses
Short spin
SPIN REDUCTION
SPÜLSTOPP
FLECKEN1)
VORWÄSCHE2)
EINWEICHEN
EXTRA SPÜLEN
ZEIT SPAREN3)
Leichtbügeln
60° - Cold
Synthetic fabric
Wash
items with norRinses
mal soil. It preShort spin
vents the creases
of the laundry.
Maximum load
1,5 kg
SPIN REDUCTION
SPÜLSTOPP
VORWÄSCHE2)
EINWEICHEN
EXTRA SPÜLEN
ZEIT SPAREN3)
ENGLISH
13
Programme
Temperature
Type of load
Weight of load
Programme
description
Functions
Feinwäsche
40° - Cold
Rinses
Short spin
Delicate fabrics
as acrylics, viscose, polyester
items with normal soil.
Maximum load 4
kg
Wash
Rinses
Short spin
SPIN REDUCTION
SPÜLSTOPP
VORWÄSCHE2)
FLECKEN
EINWEICHEN
EXTRA SPÜLEN
ZEIT SPAREN3)
Wolle / Seide
40° - Cold
Rinses
Short spin
Machine washa- Wash
ble wool as well
Rinses
as for hand wash- Short spin
able woollens
and delicate fabrics with «hand
washing» care
symbol.
Maximum load 2
kg
SPIN REDUCTION
SPÜLSTOPP
Daunen
60° - 30°
Rinses
Short spin
Special proWash
gramme for one Rinses
synthetic blanket, Short spin
duvet, bedspread and so
on.
Maximum load 2
kg
SPIN REDUCTION
Anti-Allergie
60°
White cotton
items4).
Maximum load 8
kg
Wash at 60°
Rinses
Short spin
SPIN REDUCTION
SPÜLSTOPP
FLECKEN
VORWÄSCHE2)
EINWEICHEN
EXTRA SPÜLEN
Schleudern /
Pumpen5)
0°
All fabrics
The maximum
load of the laundry is related to
the type of laundry.
Drainage of
the water
Spin phase at
the maximum
speed
SPIN REDUCTION
OHNE
SCHLEUDERN6)
14
Programme
Temperature
Type of load
Weight of load
Programme
description
Functions
Spülen
0°
All fabrics
Maximum load 8
kg
Rinse with ad- SPIN REDUCditives
TION
Spin phase
SPÜLSTOPP
EXTRA SPÜLEN7)
Jeans
60° - Cold
Items like pants, Wash
shirts or jackets
Rinses
in Jeans and also Short spin
jersey realized
with hi-tech materials.
Maximum load
3,5 kg
SPIN REDUCTION
SPÜLSTOPP
VORWÄSCHE
2)
EINWEICHEN
EXTRA SPÜLEN
ZEIT SPAREN3)
20 min. - 3 kg
40° or 30°
Quick wash of
sport items or
cotton and synthetic items,
lightly soiled or
worn once.
Maximum load 3
kg
Wash
Rinses
Short spin
SPIN REDUCTION
Super Eco
0°
Mixed fabrics
(cotton and synthetic items)8).
Maximum load 3
kg
Wash
Rinses
Long spin
SPIN REDUCTION
SPÜLSTOPP
EXTRA SPÜLEN
Energiesparen
60° or 40°
White and fast
coloured cotton
with the normal
soil9).
Maximum load 8
kg
Wash
Rinses
Short spin
SPIN REDUCTION
SPÜLSTOPP
FLECKEN
VORWÄSCHE2)
EINWEICHEN
EXTRA SPÜLEN
ZEIT SPAREN3)
1) Not available with temperature lower than 40°C.
2) If you use liquid detergent, set a programme without PREWASH.
3) If you touch the button 8 to set the Extra Kurz function, we recommend that you decrease
the quantity of the load. It is possible to keep the full load but the washing results are not
good.
4) This program removes the micro-organisms thanks to the washing by 60°C and adds on
rinse. In this way the action is more effective. Important! Put into the compartment Stain
a special additive for hygiene and select the option Stain.
ENGLISH
15
5) The default spin speed is for cotton items. Set the spin speed applicable with your laundry.
6) If you select this function the appliance performs only a drain phase.
7) Press button to add rinses. With a low spin speed the appliance performs delicate rinses
and a short spin.
8) Use a special detergent for very low temperature.
9) Set this programme to have a good washing results and decrease the energy consumption.
The time of the washing programme is extended.
STEAM PROGRAMMES
Programme1)
Type of load
Load
Dampf Auffrischen2)
This cycle removes odour from
the laundry.
Cotton and synthetic items.
Do not set the Steam programme for
this type of clothes:
• Clothes which is not specified on
the care label as being suitable for
tumble-drying.
• Clothes with inclusion of plastic,
metal, wooden parts or alike.
up to
1,5 Kg
Steam does not remove
animal odours.
Dampf Glätten2)
This programme helps to dewrinkle odour from the laundry.
up to
1,5 Kg
Steam can be used for dried, washed or worn once laundry. These programmes can reduce creases and odours and make your laundry more
smooth.
Do not use any detergent. If necessary, remove stains by washing or using
localized stain removal.
Steam programmes do not perform any hygienic cycle.
Touch the button 4 to change the duration of steam phase.
1) If you set a Steam programme with dried laundry, at the end of the cycle the laundry feel
humid. It is better to expose clothes to the open air for about 10 minutes to let the humidity
go away. Laundry should be removed from the drum as quick as possible. After a steam
cycle, clothes may to be ironed anyway, but with less effort!
2) For the programme time, refer to the display.
CONSUMPTION VALUES
Programme1)
Energy consumption
(KWh)2)
Water consumption (litre)2)
White Cottons 95 °C
2.40
70
Cottons 60 °C
1.50
66
Cottons 40 °C
0.90
66
Synthetics 40 °C
0.60
48
Delicates 40 °C
0.70
58
Wool/ Handwash 30 °C
0.35
57
0.88
57
Programmes for energy saving
Cotton 60 °C economy3)
16
Programme1)
Energy consumption
(KWh)2)
Water consumption (litre)2)
0.70
57
Cotton 40 °C economy3)
The cotton 60 °C economy and cotton 40 °C economy are the standard
cotton programmes for normally soiled cotton laundry. They are suitable
to clean normally soiled cotton laundry and they are the most efficient
programmes in terms of combined energy and water consumption for
washing that type of cotton laundry. The actual water temperature may
differ from the declared cycle temperature.
1) Refer to the display for the programme time.
2) The consumption information shown in this chart is indicative. It can vary depending on the
quantity and the type of laundry, on the temperature of the water supply and on the
ambient temperature.
3) This is the programme for test institutes. It agrees with EN60456.
BEFORE FIRST USE
1. To activate the drain system, put 2
litre of water in the main wash compartment of the detergent dispenser.
2. Put a small quantity of detergent in
the main wash compartment of the
detergent dispenser. Set and start a
programme for cotton at the highest temperature without laundry.
This removes all possible dirt from
the drum and the tub.
LANGUAGE SETTING
The first time you activate the appliance, the display shows the default language and tells you to confirm it or
change it:
• Turn the programme knob to set the
desired language.
• When the display shows the necessary language, touch button 6 to confirm the selection.
Change the language after the
first activation
1. Touch button 11 and button 10 at
the same time for some seconds.
2. When display shows the language
set, turn the programme knob to set
the new language.
3. Touch button 6 to confirm the selection.
CLOCK SETTING
After you set the language, the display
tells to set the clock:
• The hour digits flash.
• Turn the programme knob to change
the hour.
• Touch button 6 to confirm the selection.
• The minute digits flash.
• Turn the programme knob to change
the minutes.
• Touch button 6 to confirm the selection.
Change the time of the day
after the first activation
1. Touch button 9 and the button 8
at the same time for some seconds.
2. The hour digits flash.
3. Turn the programme knob to
change the hour.
4. Touch button 6 to confirm the selection.
5. The minute digits flash.
6. Turn the programme knob to
change the minutes.
ENGLISH
17
7. Touch button 6 to confirm the selection.
USING THE APPLIANCE
1. Open the water tap.
2. Connect the mains plug to the
mains socket.
ACTIVATING THE APPLIANCE AND SETTING A PROGRAMME
For a correct operation of the weight sensor, activate the appliance and
set the programme BEFORE you put the laundry in the drum.
1. Press button 1 to activate the appliance.
2. Turn the programme knob ( 2 ) to
the necessary programme or touch
one of the buttons 5 to set a
memorised programme. The programme indicator comes on.
3. The indicator of button 6 flashes
with red colour.
4. The display shows the default temperature and spin. If it is necessary,
touch button 12 and button 11 to
change the water temperature and
the spin speed.
5. If it is necessary, touch the other
buttons to add some functions or to
set a delayed start. The display
shows the symbol of the set function and the digit ( D ) shows the
delayed time.
LOADING THE LAUNDRY
1. Open the appliance door.
2. The display (E) shows the maximum
programme load for the programme (MAX ) and the weight of
the laundry (KG). The text bar on
the display tells to add the laundry.
3. Put the laundry in the drum, one
item at a time. Shake the items before you put them in the appliance.
4. On the display the weight of the
laundry updates by step of kg 0.5.
The weight is indicative and
changes with the type of the laundry.
If you put more laundry than the
maximum load, the display tells
that you put more than the maximum load.
You can wash your laundry but
the energy and water consumption increase.
To have the best consumption
and washing performance remove some items.
The overload indication is available only for programmes with a
maximum load lower than the
appliance maximum load.
5. Close the door. The text bar on the
display tells the percentage of detergent to use. This data is indicative and refers to the detergent
quantity for a maximum load that
the manufacturer recommends.
18
Make sure not to have the laundry out
of the drum between the seal and the
door. There is the risk of water leakage
or damage laundry.
USING THE DETERGENT AND ADDITIVES
The detergent compartment for the prewash phase and the soak
programme.
Add the detergent for prewash and soak before the start of the
programme.
The detergent compartment for the washing phase.
If you use a liquid detergent, put it immediately before you start
the programme.
Liquid additives compartment (fabric conditioner, starch).
Put the product in the compartment before you start the programme.
This is the maximum level for the quantity of liquid additives.
The compartment for the stain remover.
Put the product in the compartment and set the stain function before you start the programme.
Flap for powder or liquid detergent
Turn it (up or down) in the correct position to use powder or liquid
detergent.
Always obey the instructions that you find on the packaging of the detergent products.
ENGLISH
19
Check the position of the flap
1. Pull out the detergent dispenser until it stops.
2. Press the lever down to remove the
dispenser.
3. To use powder detergent, turn the
flap up.
4. To use liquid detergent, turn the
flap down.
With the flap in the position
DOWN:
– Do not use gelatinous or thick
liquid detergents.
– Do not put more liquid detergent than the limit showed in
the flap.
– Do not set the prewash
phase.
– Do not set the delay start
function.
5. Measure out the detergent and the
fabric conditioner.
6. Carefully close the detergent dispenser. Make sure that the flap
does not cause a blockage when
you close the drawer.
SET THE DELAY START
1. Touch button 7 again and again to
set the desired delayed start. The
display shows the expected end of
the programme
2. Touch button 6 , the appliance
starts the countdown of the delay
start.
When the countdown is completed,
the programme starts automatically.
20
Before you touch button 6 to
start the appliance, you can cancel or change the set of the delay start.
You cannot set the delay start
with the Steam programme.
STARTING A PROGRAMME
1. Touch button 6 to start the programme. The indicator of button 6
stops to flash and is on with red colour.
If a delayed start is set, the appliance
starts the countdown.
The appliance adjust automatically the cycle time to the
laundry you have put in the
drum to have perfect washing
results in the minimum necessary time. After approximately
15 minutes from the start of
the programme, the display
shows the new time value.
INTERRUPT A PROGRAMME
1. Touch button 6 . The indicator
flashes.
2. Touch button 6 again. The washing programme continues.
CANCEL A PROGRAMME
1. Press button 1 to cancel the programme and to deactivate the appliance.
2. Press button 1 again to activate
the appliance. Now, you can set a
new washing programme.
The appliance does not drain
the water.
1. Touch button 6 . The indicator
flashes.
2. Change the function set.
3. Touch button 6 again. The washing programme continues.
OPEN THE DOOR
While a programme or the delay start
operates, the appliance door is locked.
To open the appliance door:
1. Touch button 6 . The door lock
symbol in the display goes off and a
message tells you that the door is
unlocked.
2. Open the appliance door.
3. Close the appliance door and touch
button 6 again. The programme
or the delay start continues.
If the temperature and the level
of the water is too high, the
door lock symbol stays on. You
cannot open the door. If necessary, do the following procedure
to open the door:
1. Deactivate the appliance.
2. Wait for some minutes.
3. Make sure that no water is in
the drum.
If you deactivate the appliance,
it is necessary to set the programme again.
CHANGE A FUNCTION
You can change only some functions
before they operate.
AT THE END OF PROGRAMME
1. The appliance stops automatically.
2. The acoustic signals operate, if it is
active.
3. In the display
goes on and the
message tells you that the programme is completed.
ENGLISH
4. The indicator of button 6 goes off.
5. The door lock symbol goes off.
6. Press button 1 to deactivate the
appliance. After five minutes from
the end of the programme, the AUTO OFF function automatically deactivates the appliance.
When you activate the appliance again, the display shows
the end of the last set programme. Turn the programme
knob to set a new cycle.
7. Remove the laundry from the appliance. Make sure that the drum is
empty.
8. Keep the door ajar, to prevent mildew and odours.
9. Close the water tap.
21
– The door stays locked.
– You must drain the water to open the
door.
To drain the water:
1. If necessary, decrease the spin
speed.
2. Touch button 6 . The appliance
drains the water and spins.
3. When the programme is completed
and the door lock symbol goes off,
you can open the door
4. Press button 1 to deactivate the
appliance.
The appliance drain and spin
automatically after approximately 18 hours.
The washing programme is
completed, but there is water in the
drum:
– The drum turns regularly to prevent
the creases in the laundry.
HELPFUL HINTS AND TIPS
THE LAUNDRY LOAD
• Divide the laundry in: white, coloured, synthetics, delicates and wool.
• Obey the washing instructions that
are on the laundry care labels.
• Do not wash together white and coloured items.
• Some coloured items can discolour
with the first wash. We recommend
that you wash them separately for the
first times.
• Button up pillowcases, close zippers,
hooks and poppers. Tie up belts.
• Empty the pockets and unfold the
items.
• Turn inside out multilayered fabrics,
wool and items with painted illustrations.
• Remove hard stains.
• Wash with a special detergent heavy
soil stains.
• Be careful with the curtains. Remove
the hooks or put the curtains in a
washing bag or pillowcase.
• Do not wash in the appliance :
– Laundry without hems or with cuts
– Underwired bras.
– Use a washing bag to wash small
items.
• A very small load can cause balance
problems with the spin phase. If this
occurs, adjust manually the items in
the tub and start the spin phase
again.
STUBBORN STAINS
For some stains, water and detergent is
not sufficient.
We recommend that you remove these
stains before you put the items in the
appliance.
Special stain removers are available.
Use the special stain remover that is applicable to the type of stain and fabric.
22
DETERGENTS AND ADDITIVES
WATER HARDNESS
• Only use detergents and additives
specially made for washing machines.
• Do not mix different types of detergents.
• To help the environment, do not use
more than the correct quantity of detergent.
• Obey the instructions that you find
on the on packaging of these products.
• Use the correct products for the type
and colour of the fabric, the programme temperature and the level of
soil.
• If you use liquid detergents, do not
set the prewash phase.
• If your appliance has not the detergent dispenser with the flap device,
add the liquid detergents with a dosing ball.
If the water hardness in your area is
high or moderate, we recommend that
you use a water softener for washing
machines. In areas where the water
hardness is soft it is not necessary to
use a water softener.
To know the water hardness in your
area, contact your local water authority.
Obey the instructions that you find on
the packaging of the products.
Equivalent scales measure the water
hardness:
• German degrees (°dH).
• French degrees (°TH).
• mmol/l (millimol for each litre - international unit for the hardness of water).
• Clarke degrees.
Water hardness table
Level
Type
Water hardness
°dH
°T.H.
mmol/l
Clarke
1
soft
0-7
0-15
0-1.5
0-9
2
medium
8-14
16-25
1.6-2.5
10-16
3
hard
15-21
26-37
2.6-3.7
17-25
4
very hard
> 21
> 37
>3.7
>25
CARE AND CLEANING
WARNING!
Disconnect the appliance from the
mains supply before you clean it.
DESCALING
The water we use contains limescale. If
it becomes necessary, use a water softener to remove limescales.
Use a special product made for washing machines. Obey the instructions
that you find on the packaging of the
manufacturer.
Do this separately from the laundry
wash.
EXTERNAL CLEANING
Clean the appliance only with soap and
warm water. Fully dry all the surfaces.
CAUTION!
Do not use alcohol, solvents or
chemical products.
MAINTENANCE WASH
With the low temperature programmes
it is possible that some detergent stays
in the drum. Make regularly a maintenance wash. To do this:
• Empty the laundry from the drum.
ENGLISH
• Set the hottest cotton wash programme
• Use a correct quantity of powder detergent with biological properties.
23
After each wash, keep the door open
for a while to prevent mould and to let
unpleasant smells go out.
DOOR SEAL
Regularly examine the seal and remove
all objects from the inner part.
DRUM
Regularly examine the drum to prevent
limescale and rust particles.
Only use special products to remove
rust particles from the drum.
To do this:
• Clean the drum with special product
for stainless steel.
• Start a short programme for cotton at
the maximum temperature with a
small quantity of detergent.
DETERGENT DISPENSER
To clean the dispenser:
1
1. Press the lever.
2. Pull the dispenser out.
2
3. Remove the top part of the liquid
additive compartment.
4. Clean all the parts with water.
24
5. Clean the dispenser recess with a
brush.
6. Put back the dispenser in the recess.
DRAIN PUMP
Regularly examine the drain
pump and make sure that it is
clean.
Clean the pump if:
• The appliance does not drain the water.
• The drum cannot turn.
• The appliance makes an unusual
noise because of the blockage of the
drain pump.
• The display shows an alarm code because of the problem with water
drain.
WARNING!
1. Disconnect the mains plug
from the mains socket.
2. Do not remove the filter
while the appliance operates. Do not clean the drain
pump if the water in the appliance is hot. The water
must be cold before you
clean the drain pump.
To clean the drain pump:
1. Open the drain pump door.
2. Pull the flap out to remove it.
3. Put a container below the recess of
the drain pump to collect the water
that flows out.
4. Press the two levers and pull forward the drainage duct to let the
water flow out.
ENGLISH
25
5. When the container is full of water,
put the drainage duct back again
and empty the container. Do steps 4
and 5 again and again until no more
water flows out from the drain
pump.
6. Pull back the drainage duct and turn
the filter to remove it.
1
2
7. Remove fluff and objects from the
pump.
8. Make sure that the impeller of the
pump can turn. If this does not occur, contact the service centre.
2
1
THE INLET HOSE FILTER AND
THE VALVE FILTER
It could be necessary to clean the filters
when:
• The appliance does not fill with water.
• The appliance fills with the water for
a long time.
9. Clean the filter under the water tap
and put it back in the pump into the
special guides.
10 Make sure that you tighten correctly
. the filter to prevent leakages.
11 Put the flap back and close the
. drain pump door.
• The indicator of button 6 flashes
and the display shows the related
alarm. Refer to 'Trouble shooter and
service'.
WARNING!
Disconnect the mains plug from
the mains socket.
26
To clean the water inlet filters:
1. Close the water tap.
2. Remove the water inlet hose from
the water tap.
3. Clean the filter in the inlet hose with
a stiff brush.
4. Remove the inlet hose behind the
appliance.
5. Clean the filter in the valve with a
stiff brush or a towel.
6. Install again the inlet hose. Make
sure that the couplings are tight to
prevent leakages.
7. Open the water tap.
35°
45°
EMERGENCY DRAIN
Because of a malfunction, the appliance
cannot drain the water.
If this occurs, do steps (1) through (6) of
'To clean the drain pump'.
If necessary, clean the pump.
Put the drainage duct back and close
the drain pump flap.
When you drain the water with the
emergency drain procedure, you must
activate again the drain system:
1. Put 2 litres of water in the main wash
compartment of the detergent dispenser.
2. Start the programme to drain the
water.
FROST PRECAUTIONS
If the appliance is installed in an area
where the temperature can be less than
0 °C, remove the remaining water from
the inlet hose and the drain pump.
1. Disconnect the mains plug from the
mains socket.
2. Close the water tap.
3. Remove the water inlet hose
4. Put the two ends of the inlet hose in
a container and let the water flow
out of the hose.
5. Empty the drain pump. Refer to the
emergency drain procedure
6. When the drain pump is empty, install the inlet hose again.
WARNING!
Make sure that the temperature
is more than 0 °C before you
use the appliance again.
The manufacturer is not responsible for damages caused by
low temperatures.
ENGLISH
27
TROUBLE SHOOTER AND SERVICE
The start of the appliance does not occur or it stops during operation.
Try to find a solution to the problem
before you contact the service centre
(refer to the table).
With some problems, the acoustic
signals operate and the display
shows an alarm message.
WARNING!
Deactivate the appliance before
you do the checks.
Problem
Possible cause
Possible solution
The display tells
to check the tap:
the appliance
does not fill with
water.
The water tap is closed.
Open the water tap.
The water inlet hose is
damaged.
Make sure that the water inlet
hose has no damages.
The filters in the water in- Clean the filters. Refer to 'Care
let hose is blocked .
and cleaning'.
The connection of the
water inlet hose is not
correct.
Make sure that the connection is
correct.
The water pressure is too
low.
Contact your local water authority.
The water tap is blocked
or is furred with limescale.
Clean the water tap.
The water drain hose is
damaged.
Make sure that the water drain
hose has no damages.
The filter of the drain
pump is blocked.
Clean the filter of the drain
pump. Refer to 'Care and cleaning'.
The connection of the
water drain hose is not
correct.
Make sure that the connection is
correct.
The display tells
to check the
door.
The appliance door is
open or not closed correctly.
Close the door correctly.
The display tells
there is a water
alert.
The anti-flood device is
activated.
• Disconnect the appliance.
• Close the water tap.
• Contact the service centre.
The display tells
to check the
drain filter: the
appliance does
not drain the water.
28
PROBLEM WITHOUT ALARM MESSAGE
Problem
Possible cause
Possible solution
The appliance
does not drain
the water.
A washing programme
without the drain phase
is set.
Set the drain programme.
The function Rinse Hold
is on.
Set the drain programme.
The spin phase
The spin phase is off.
does not operate.
The programme
does not start.
Set the spin programme.
The filter of the drain
pump is blocked.
Clean the filter of the drain
pump. Refer to 'Care and cleaning'.
Balance problems with
the laundry load.
Adjust manually the items in the
tub and start the spin phase
again.
The mains plug is not
connected in the mains
socket.
Put in the mains plug.
Blow out fuse in the
household fuse box.
Replace the fuse.
You did not touch button Touch button 6 .
6 .
There is water on
the floor.
You cannot open
the appliance
door.
The appliance
makes an unusual
noise.
The delay start is set.
If necessary to wash the laundry
immediately, cancel the delay
start.
The Child Lock function
is activated.
Deactivate the Child Lock function.
Leakages from the couplings of the water hoses.
Make sure that the couplings are
tight.
Leakages from the drain
pump.
Make sure that the drain pump
filter is tight.
The water drain hose is
damaged.
Make sure that the water inlet
hose has no damages.
The washing programme Let the washing programme end.
is in operation.
There is water in the
drum.
Set the drain or the spin programme.
Incorrect level of the appliance.
Adjust the level of the appliance.
Refer to 'Installation'.
ENGLISH
Problem
Possible cause
Possible solution
You did not remove the
packaging and/or the
transit bolts.
Remove the packaging and/or
the transit bolts. Refer to 'Installation'.
The load is very small.
Add more laundry in the drum.
The appliance fills The end of the drain
with water and
hose is too low.
drain immediately.
Make sure that the drain hose is
in the correct position.
The washing reThe detergent you used
sults are not satis- was not sufficient or corfactory.
rect.
Increase the detergent quantity
or use a different one.
You did not remove the
stubborn stains before
you wash the laundry.
Use special products to remove
the stubborn stains.
You set a not correct
temperature.
Make sure that you set the correct temperature.
29
Too much laundry load.
Decrease the laundry load.
The internal lamp
is off.
The lamp is burned.
To replace the lamp, contact the
service centre.
After a steam
programme, garments are partially wet.
The appliance is not accurately levelled.
Check the levelling and adjust
the appliance by raising or lowering the feet.
After a steam
programme, garments are not sufficiently smooth.
A wrong STEAM programme has been selected (e.g. Synthetic instead of Cotton).
Note the composition of the fabric.
Excessive laundry load.
Reduce the laundry load
The drum is emp- It is necessary to set a
ty and the display tare.
shows there is
some weight in .
Press button 1 to deactivate
the appliance and to activate it
again.
The drum is full
but the display
shows 0.0 kg.
Press button 1 to deactivate
the appliance . Empty the drum
and obey to the necessary steps.
(Refer to 'Loading the laundy')
You loaded the laundry
before to activate the
appliance.
After the check, activate the appliance.
The programme continues from the
point of interruption.
If the problem occurs again, contact the
service centre.
If the display shows other alarm message, contact the service centre.
30
SERVICE
• Refer to the information supplied
with this appliance for guarantee
condition and point of contact. The
information to give to the service is
on the rating plate.
We recommend that you write the information here:
Product number
(PNC)
..................
Model
(MOD.)
Serial number
(S.N.)
..................
..................
TECHNICAL DATA
Dimensions
Width / Height / Depth
600 / 850 / 600 mm
Total depth
640 mm
Electrical connection:
Voltage
Overall power
Fuse
Frequency
230 V
2200 W
10 A
50 Hz
Water supply pressure
Minimum
0,5 bar (0,05 MPa)
Maximum
8 bar (0,8 MPa)
Water supply 1)
Cold water
Maximum load
Cotton
Spin speed
Maximum
8 kg
1400 rpm (L98485FL)
1600 rpm (L98685FL)
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
INSTALLATION
UNPACKING
1. Use the gloves. Remove the external film. If necessary, use a cutter.
ENGLISH
31
2. Remove the cardboard top.
3. Remove the polystyrene packaging
materials.
4. Remove the internal film.
5. Open the door. Remove the polystyrene piece from the door seal
and all the items from the drum.
6. Put the front piece on the floor behind the appliance. Carefully put
down the appliance with the rear
side on it. Make sure not to damage
the hoses.
32
7. Remove the polystyrene protection
from the bottom.
8. Pull up the appliance in vertical position.
1
2
9. Remove the power supply cable and
the drain hose from the hose holders.
10 Remove the three bolts. Use the key
. supplied with the appliance.
11 Pull out the plastic spacers.
.
12 Replace the plastic spacers with the
. plastic caps. You can find these caps
in the user manual bag.
ENGLISH
WARNING!
Remove all the packaging and
the transit bolts before you install the appliance.
33
We recommend that you keep
the packaging and the transit
bolts for when you move the appliance.
POSITIONING AND LEVELLING
x4
• Install the appliance on a flat hard
floor.
• Make sure that carpets do not stop
the air circulation below the appliance.
• Make sure that the appliance does
not touch the wall or other units
• Loosen or tighten the feet to adjust
the level. A correct adjustment of the
appliance level prevents the vibration, noise and the movement of the
appliance when in operation.
• The appliance must be level and stable.
CAUTION!
Do not put cardboard, wood or
equivalent materials below the
appliance feet to adjust the level.
34
THE INLET HOSE
• Connect the hose to the appliance.
Turn the inlet hose only left or right.
Loose the ring nut to set it in the correct position.
45
O
35
O
• Connect the water inlet hose to the
cold water tap with 3/4 thread.
CAUTION!
Make sure that there are no
leaks from the couplings.
Do not use an extension hose if
the inlet hose is too short. Contact the service centre for the replacement of the inlet hose.
Water-stop device
A
WATER DRAINAGE
There are different procedures to connect the drain hose:
The inlet hose has a water stop device.
This device prevents water leaks in the
hose because of its natural ageing. The
red sector in the window «A» shows this
fault .
If this occur, close the water tap and
contact the service centre to replace
the hose.
ENGLISH
35
With the plastic hose guide.
• On the edge of a sink.
• Make sure that the plastic guide cannot move when the appliance drains.
Attach the guide to the water tap or
the wall.
• To a stand pipe with vent-hole.
Refer to the illustration. Directly into
a drain pipe at a height of not less
than 60 cm and not more than 100
cm. The end of the drain hose must
always be ventilated , i.e. the inner
diameter of the drainpipe must be
larger than the external diameter of
the drain hose.
Without the plastic hose guide.
• To a sink spigot.
Refer to the illustration. Put the drain
hose in the spigot and tighten it with
a clip. Make sure that the drain hose
makes a loop to prevent that remaining particles go in the appliance from
the sink.
• Directly to a built-in drain pipe in the
room wall and tighten it with a clip.
36
You can extend the drain hose
to maximum 400 mm. Contact
the service centre for the other
drain hose and the extension.
ENGLISH
37
38
ENGLISH
39
www.aeg.com/shop
132940551-A-492010
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
