L 98699 FL
L 98499 FL
WASHING MACHINE
USER MANUAL
2
CONTENTS
4
5
6
7
7
12
17
18
18
18
19
20
21
22
23
27
30
31
SAFETY INFORMATION
ENVIRONMENT CONCERNS
PRODUCT DESCRIPTION
ACCESSORIES
CONTROL PANEL
WASHING PROGRAMMES
BEFORE FIRST USE
USING THE APPLIANCE
ACTIVATING THE APPLIANCE AND SETTING A
PROGRAMME
LOADING THE LAUNDRY
USING THE DETERGENT AND ADDITIVES
STARTING A PROGRAMME
AT THE END OF PROGRAMME
HELPFUL HINTS AND TIPS
CARE AND CLEANING
TROUBLE SHOOTER AND SERVICE
TECHNICAL DATA
INSTALLATION
The following symbols are used in this
user manual:
Important information concerning your
personal safety and information on how
to avoid damaging the appliance.
General information and tips
Environmental information
Subject to change without notice
ENGLISH
3
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please spend
a few minutes reading to get the very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to keep all your AEG
appliances looking spotless and working perfectly. Along with a wide range of
accessories designed and built to the high quality standards you would expect, from
specialist cookware to cutlery baskets, from bottle holders to delicate laundry bags…
Visit the webshop at:
www.aeg-electrolux.com/shop
VISIT OUR WEBSITE FOR:
- Brochures
- Products
- Service information
- Trouble shooter
- User manuals
www.aeg.com
4
SAFETY INFORMATION
Before the installation and use, read
this manual carefully:
• For your safety and the safety of your
property
• To help the environment
• For the correct operation of the appliance.
Always keep these instructions with the
appliance also if you move or give it to
a different person.
The manufacturer is not responsible if
an incorrect installation and use causes
damage.
CHILDREN AND VULNERABLE
PERSON SAFETY
• Do not let persons, children included, with reduced physical sensory,
reduced mental functions or lack of
experience and knowledge use the
appliance. They must have supervision or instruction for the operation
of the appliance by a person who is
responsible for their safety.
• Keep all packaging away from children. There is the risk of suffocation
or injury.
• Keep all detergents away from children.
• Keep children and pets away from
the appliance when the door is open.
• Before you close the appliance door,
make sure that children and pets are
not into the drum.
• If the appliance has a child safety device, we recommend to activate it.
CHILD SAFETY DEVICE
• When you activate this device, you
cannot close the door. This prevents
children or pets to be closed in the
drum. To activate the device, turn it
clockwise, until the groove is horizontal. To deactivate the device, turn it
counterclockwise, until the groove is
vertical.
GENERAL SAFETY
• Do not use the appliance for professional use. The appliance is only for
domestic use.
• Do not change the specifications of
this appliance. There is the risk of injury and damage to the appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
Risk of explosion or fire.
• Obey the safety instructions on the
detergent packaging to prevent
burns to eyes, mouth and throat.
• Make sure that you remove all metal
objects from the laundry. Hard and
sharp material can cause damage to
the appliance.
• Do not touch the glass of the door
while a programme operates. The
glass can be hot.
CARE AND CLEANING
• Deactivate the appliance and disconnect the mains plug from the mains
socket.
• Do not use the appliance without the
filters. Make sure that the installation
of the filters is correct. An incorrect
installation causes water leakages.
INTERNAL LAMP
This appliance has an internal lamp that
comes on when you open the door and
goes off when the door is closed.
WARNING!
Visible led radiation, do not look
directly into the beam.
ENGLISH
To replace the internal lamp,
contact the service centre.
Disconnect the mains plug from
the mains socket before the replacement of the internal lamp.
5
time. Let the water flow for some minutes, then connect the inlet hose.
• The first time you use the appliance,
make sure that the water hoses and
the couplings do not have leakages.
INSTALLATION
ELECTRICAL CONNECTION
• The appliance is heavy, be careful
when you move it.
• Do not install and connect a damaged appliance.
• Make sure to remove all packaging
and transport bolts.
• Make sure that the mains plug is disconnected from the mains socket
during installation.
• Only a qualified person must do the
electrical installation, the plumbing
and the installation of the appliance.
This to prevent the risks of structural
damage or injury.
• Do not install or use the appliance
where the temperature is less than 0
°C.
• When you install the appliance on a
carpet floor, make sure that there is
air circulation between the appliance
and the carpet. Adjust the feet to
have the necessary space between
the appliance and the carpet.
• Make sure that the appliance is
earthed.
• Make sure that the electrical data on
the rating plate agrees with the power supply.
• Always use a correctly installed
shockproof socket.
• Do not use multiple plugs and extension cables. There is a risk of fire.
• Do not replace or change the mains
cable. Contact the service centre.
• Make sure not to cause damage to
the mains plug and cable.
• Connect the mains plug to the mains
socket only at the end of the installation. Make sure that there is access
to the mains plug after the installation.
• Do not pull the mains cable to disconnect the appliance. Always pull
the mains plug.
WATER CONNECTION
1. Disconnect the mains plug from the
mains socket.
2. Cut off the mains cable and discard
it.
3. Discard the door catch. This prevents children or pets to be closed
in the appliance. There is a risk of
suffocation.
• Do not connect the appliance with
old hoses already used. Only use
new hoses.
• Make sure not to cause damage to
the water hoses.
• Do not connect the appliance to new
pipes or pipes not used for a long
DISCARD THE APPLIANCE
ENVIRONMENT CONCERNS
PACKAGING MATERIALS
Recycle the materials with the symbol
.
Put the packaging in applicable containers to recycle it.
on the product or on its
The symbol
packaging indicates that this product
may not be treated as household
waste. Instead it should be taken to the
appropriate collection point for the
recycling of electrical and electronic
6
equipment. By ensuring this product is
disposed of correctly, you will help
prevent potential negative
consequences for the environment and
human health, which could otherwise
be caused by inappropriate waste
handling of this product. For more
detailed information about recycling of
this product, please contact your local
council, your household waste disposal
service or the shop where you
purchased the product.
PRODUCT DESCRIPTION
1
2
3
8
9
10
4
5
6
11
7
8
12
1 Worktop
2 Detergent dispenser
8 Feet for appliance level
9 Water drain hose
3 Control panel
4 Door handle
10 Water inlet hose
11 Mains cable
5 Internal lamp
6 Rating plate
12 Transit bolts
13 Feet for appliance level
7 Drain pump
ENGLISH
7
ACCESSORIES
1
1 Spanner
To remove the transit bolts.
2 Plastic caps
To close the hoses on the rear side
of the cabinet, when you remove
the transit bolts.
3 Sound barrier
To install on the bottom of the appliance to decrease the noise of the
spin phase.
4 Plastic hose guide
To connect the drain hose on the
edge of a sink.
5 Anti-flood inlet hose
To prevent possible leakage.
2
5
4
3
CONTROL PANEL
1
2
3
Ontkreuk
Katoen
Opfrissen
Extra Stil
Eco
Stoom
Synthetica
Super Eco
Geheugen 1
Strijkvrij
20 Min. - 3 kg
Fijne Was
Outdoor
Wol/Zijde
Spoelen
Centrifugeren/
Pompen
Beladingssensor
Geheugen 2
Dekbed
Auto Off
Anti-Allergie
Temp.°C
12
TPM
11
Vlekken/ Extra
Tijd
Voorw. Spoelen Besparen
10
9
8
Startuitstel
Start/Pauze
7
6
4
5
1 Auto Off button
2 Programme knob
8 Zeit Sparen touch button
9 Extra Spülen touch button
3 Display
4 Dampf touch button
10 Flecken/Vorwäsche/Einweichen
touch button
11 Spin reduction touch button (U./
Min.))
12 Temperature touch button (Temp.)
5 Memory touch buttons
6 Start/Pause touch button
7 Zeitvorwahl touch button
8
TOUCH SCREEN
Do not wear gloves when you
touch the buttons.
Make sure the touch screen and
buttons are always clean and
dry.
AUTO OFF BUTTON 1
Press this button to activate or deactivate the appliance. A tune sounds
when the appliance is activated.
The AUTO OFF function automatically
deactivates the appliance to decrease
energy consumption when:
• The washing programme is completed since five minutes.
• You do not use the appliance for five
minutes.
PROGRAMME KNOB 2
Turn this knob to set a programme.
The related programme indicator goes
on.
DISPLAY 3
A
J
I
A
B
H
G
C
F
D
E
The text bar:
• Guides you in the use of the appliance.
• Tells you about the programme status and phase.
• Shows alarm messages. Refer to 'Trouble shooter and service' .
The symbols appear on the display when the related phase or function is set.
B
Child lock
C
Door locked
The symbol comes on when the programme starts.
You cannot open the door when the symbol is on.
You can open the door only when the symbol goes on.
The symbol stays on, but the programme is completed:
• There is water in the drum.
• The ' Rinse Hold ' function is on.
ENGLISH
9
• The time of the day
When you activate the appliance the display shows the time of the
day for some seconds. To adjust the clock, refer to "Clock setting".
• The programme duration
When the washing programme starts, the programme time decreases
every minute.
Programme duration symbol
The symbol comes on when the digits shows the programme duration.
D
• The end time of the washing programme .
Programme end symbol
The symbol comes on when the digits shows the programme end time.
• The time of delay
– When you set the delayed start the time of the programme end increases by steps of 30 minutes till 10 hours and by steps of one
hour till 20 hours.
• The end of the programme
The display shows a zero.
This part comes on only if the door is open - Refer to 'Loading the laundry'.
The programme maximum load
E
The weight of the laundry
The indicator bar fills accordingly the weight of the laundry.
The indicator fully fills when you put the maximum load.
If you need to set a function
• An empty indicator bar comes on when the related function is available with the set programme. If an indicator bar does not come on, it
means that it is not available.
• The function symbol comes on when the function is set.
• The indicator bar fills accordingly the function set.
• If you make an incorrect selection the text bar on the display tells that the selection is not possible.
Time save
The symbol comes on when you set the following functions:
F
Shortened duration
Extra quick
10
Extra rinsing
G
The indicator bar fills accordingly the numbers of rinses.
Stains
Prewash
H
Soak
The indicator bar fills accordingly when you set the functions.
The default spin speed of the programme.
I
___
No spin
Rinse hold
The default temperature of the programme.
J
Cold wash
DAMPF BUTTON 4
Touch the button 4 to set one of the
three steam level in the programmes
where steam function is available. The
duration of the steam phase change accordingly your selection.
2. The programme indicator comes on
and the display shows all the information.
To cancel a memorised programme you can only memorise
a new programme.
MEMORY BUTTONS 5
START/PAUSE BUTTON 6
Touch one of the button 5 to memorise a programme or to set a memorised programme.
Touch the button 6 to start or interrupt a programme.
Memorise a programme
1. Press the button 1 to activate the
appliance.
2. Turn the programme knob ( 2 ) to
your favourite programme.
3. If it is necessary, set the one or
more functions.
4. Hold touched one of the button 5
for some seconds. The buzzer
sounds and the display tells that the
programme is saved.
ZEITVORWAHL BUTTON 7
Set a memorised programme
1. Touch the button where you memorised the programme you want to
set.
Touch the button 7 to delay the start
of a programme from 30 minutes to 20
hours.
ZEIT SPAREN BUTTON 8
Touch the button 8 to decrease the
programme time.
Touch the button 8 one time to wash
items with daily soil:
– The indicator bar not fully fills.
– The display shows you the reduced
programme duration.
Touch the button 8 two times to wash
quickly items with almost no soil:
– The indicator bar fully fills.
ENGLISH
– The display shows you the extra reduced programme duration.
Touch the button 8 three time to set
the programme normal duration again.
EXTRA SPÜLEN BUTTON 9
Touch the button 9 to add rinsing
phases to a programme.
Use this function for persons allergic to
detergents and in areas where the water is soft.
FLECKEN/VORWÄSCHE/
EINWEICHEN BUTTON 10
Touch the button 10 to set one of the
these functions:
FLECKEN
Use this function for laundry with hard
stains to remove.
When you set this function, put the
.
stain remover into compartment
The programme duration increases.
This function is not available
with a temperature lower than
40° C.
VORWÄSCHE
Use this function for heavy soil.
The appliance adds a prewash phase
to the main wash.
The programme duration increases.
EINWEICHEN
Use this function for heavy soil.
The appliance soak the laundry at
30°C.
At the end of the washing programme
the appliance stops automatically and
the water stays in the tub.
To empty out the water refer to 'At the
end of programme'.
SPIN BUTTON 11
Touch the button 11 to:
11
• Decrease the maximum speed of the
spin phase when you set a programme.
The display shows only the spin
speeds available with the set
programme.
• Deactivate the spin phase (' No Spin
' function).
• Activate the ' Rinse Hold ' function.
Set this function to prevent fabric
creases. The appliance does not
drain the water when the programme is completed.
TEMPERATURE BUTTON 12
Touch the button 12 to change the default temperature.
= cold water
Symbols - - - and
LANGUAGE SETTING
To change the language of the display:
1. Touch the button 11 and the button 10 at the same time for some
seconds.
2. When display shows the language
set, turn the programme knob to
set the new language.
3. Touch the button 6 to confirm the
selection.
CLOCK SETTING
To change the time of the day:
1. Touch the button 9 and the button 8 at the same time for some
seconds.
2. The hour digits flash.
3. Turn the programme knob to
change the hour.
4. Touch button 6 to confirm the selection.
5. The minute digits flash.
6. Turn the programme knob to
change the minutes.
7. Touch button 6 to confirm the selection.
12
ACOUSTIC SIGNALS FUNCTION
You can hear the acoustic signals when:
• You activate the appliance.
• You deactivate the appliance.
• You touch the buttons.
• The programme is completed.
• The appliance has a malfunction.
To deactivate/activate the acoustic
signals, touch button 3 and button 4
at the same time for 6 seconds.
If you deactivate the acoustic
signals, they continue operate
only when you touch the buttons and when a malfunction occurs.
KINDERSICHERUNG FUNCTION
This function prevents children to play
with the control panel.
• To activate the function, touch button 1 and button 2 at the same
time until the display shows the sym.
bol
• To deactivate the function, touch
button 1 and button 2 at the
same time until the symbol
goes
off.
You can activate the function:
• Before you touch the button 6 : the
appliance cannot start.
• After you touch the button 6 , all
the buttons and the programme
knob are deactivated.
PERMANENT EXTRA RINSE
FUNCTION
With this function you can keep the extra rinse function permanently on when
you set a new programme.
• To activate the function touch the
button 5 and the button 6 at the
same time until the display shows the
.
symbol
• To deactivate the function touch the
button 5 and the button 6 at the
same time until the symbol
goes
off.
WASHING PROGRAMMES
Programme
Temperature
Type of load
Weight of load
Koch/Bunt
95° - Cold
White and coloured cotton
with heavy level
of soil.
Maximum load 9
kg
Functions
Wash
Rinses
Long spin
SPIN REDUCTION
OHNE
SCHLEUDERN
SPÜLSTOPP
FLECKEN1)
VORWÄSCHE2)
EINWEICHEN
EXTRA SPÜLEN
ZEIT SPAREN3)
DAMPF1)
ENGLISH
13
Programme
Temperature
Type of load
Weight of load
Functions
Extra Leise
95° - Cold
White and coloured cotton
with normal level
of soil.
Maximum load 9
kg
Wash
Rinses
Long spin
Stop with water in the
drum
SPÜLSTOPP
FLECKEN1)
VORWÄSCHE2)
EINWEICHEN
EXTRA SPÜLEN
ZEIT SPAREN3)
DAMPF1)
Pflegeleicht
60° - Cold
Rinses
Short spin
Synthetic or
mixed fabric
items with normal soil.
Maximum load 4
kg
Wash
Rinses
Short spin
SPIN REDUCTION
OHNE
SCHLEUDERN
SPÜLSTOPP
FLECKEN1)
VORWÄSCHE2)
EINWEICHEN
EXTRA SPÜLEN
ZEIT SPAREN3)
DAMPF1)
Leichtbügeln
60° - Cold
Synthetic fabric
Wash
items with norRinses
mal soil. It preShort spin
vents the creases
of the laundry.
Maximum load
1,5 kg
SPIN REDUCTION
SPÜLSTOPP
OHNE
SCHLEUDERN
VORWÄSCHE2)
EINWEICHEN
EXTRA SPÜLEN
DAMPF1)
14
Programme
Temperature
Type of load
Weight of load
Functions
Feinwäsche
40° - Cold
Rinses
Short spin
Delicate fabrics
as acrylics, viscose, polyester
items with normal soil.
Maximum load 4
kg
Wash
Rinses
Short spin
SPIN REDUCTION
SPÜLSTOPP
OHNE
SCHLEUDERN
VORWÄSCHE2)
FLECKEN
EINWEICHEN
EXTRA SPÜLEN
ZEIT SPAREN3)
Wolle / Seide
40° - Cold
Rinses
Short spin
Machine washa- Wash
ble wool as well
Rinses
as for hand wash- Short spin
able woollens
and delicate fabrics with «hand
washing» care
symbol.
Maximum load 2
kg
SPIN REDUCTION
SPÜLSTOPP
OHNE
SCHLEUDERN
Daunen
60° - 30°
Rinses
Short spin
Special proWash
gramme for one Rinses
synthetic blanket, Short spin
duvet, bedspread and so
on.
Maximum load 2
kg
SPIN REDUCTION
DAMPF1)
Anti-Allergie
60°
White cotton
items4).
Maximum load 9
kg
SPIN REDUCTION
SPÜLSTOPP
OHNE
SCHLEUDERN
FLECKEN
VORWÄSCHE2)
EINWEICHEN
EXTRA SPÜLEN
DAMPF1)
Wash at 60°
Rinses
Short spin
ENGLISH
15
Programme
Temperature
Type of load
Weight of load
Functions
Schleudern /
Pumpen5)
0°
All fabrics.
The maximum
load of the laundry is related to
the type of laundry.
Drainage of
the water
Spin phase at
the maximum
speed
SPIN REDUCTION
OHNE
SCHLEUDERN6)
Spülen
0°
Hand washed
items.
Maximum load 9
kg
Rinse
Long spin
SPIN REDUCTION
SPÜLSTOPP
OHNE
SCHLEUDERN
EXTRA SPÜLEN
Outdoor
40° - Cold
Waterproof,
sports and outdoor clothing.
Do not use any
fabric softener!
Maximum load
2,5 kg
Wash
Rinses
Short spin
SPIN REDUCTION
SPÜLSTOPP
OHNE
SCHLEUDERN
EXTRA RINSE
20 min. - 3 kg
40° or 30°
Quick wash of
sport items or
cotton and synthetic items,
lightly soiled or
worn once.
Maximum load 3
kg
Wash
Rinses
Short spin
SPIN REDUCTION
OHNE
SCHLEUDERN
Super Eco
0°
Mixed fabrics
(cotton and synthetic items)7).
Maximum load 3
kg
Wash
Rinses
Long spin
SPIN REDUCTION
SPÜLSTOPP
OHNE
SCHLEUDERN
EXTRA SPÜLEN
16
Programme
Temperature
Type of load
Weight of load
Energiesparen
60° or 40°
White and fast
coloured cotton
with the normal
soil8).
Maximum load 9
kg
Functions
Wash
Rinses
Short spin
SPIN REDUCTION
SPÜLSTOPP
OHNE
SCHLEUDERN
FLECKEN
VORWÄSCHE2)
EINWEICHEN
EXTRA SPÜLEN
ZEIT SPAREN3)
1) Not available with temperature lower than 40°C.
2) If you use liquid detergent, set a programme without PREWASH.
3) If you touch the button 8 to set the Extra Quick function, we recommend that you
decrease the quantity of the load. It is possible to keep the full load but the washing results
are not good.
4) This program removes the micro-organisms thanks to the washing by 60°C and adds on
rinse. In this way the action is more effective. Important! Put into the compartment Stain
a special additive for hygiene and select the option Stain.
5) The default spin speed is for cotton items. Set the spin speed applicable with your laundry.
6) If you select this function the appliance performs only a drain phase.
7) Use a special detergent for very low temperature.
8) Set this programme to have a good washing results and decrease the energy consumption.
The time of the washing programme is extended.
STEAM PROGRAMMES
Programme 1)
Type of load
Load
Dampf Auffrischen2)
This cycle removes odour from
the laundry.
Cotton and synthetic items.
Do not set the Steam programme for
this type of clothes:
• Clothes which is not specified on
the care label as being suitable for
tumble-drying.
• Clothes with inclusion of plastic,
metal, wooden parts or alike.
up to
1,5 Kg
Steam does not remove
animal odours.
Dampf Glätten2)
This programme helps to dewrinkle odour from the laundry.
up to
1,5 Kg
Steam can be used for dried, washed or worn once laundry. These programmes can reduce creases and odours and make your laundry more
smooth.
Do not use any detergent. If necessary, remove stains by washing or using
localized stain removal.
Steam programmes do not perform any hygienic cycle.
Touch the button 4 to change the duration of steam phase.
ENGLISH
17
1) If you set a Steam programme with dried laundry, at the end of the cycle the laundry feel
humid. It is better to expose clothes to the open air for about 10 minutes to let the humidity
go away. Laundry should be removed from the drum as quick as possible. After a steam
cycle, clothes may to be ironed anyway, but with less effort!
2) For the programme time, refer to the display.
CONSUMPTION VALUES
Programme1)
Energy consumption (KWh)
Water consumption (litre)
White Cottons 95° C
2.1
62
Cottons 60°
1.3
59
Cotton economy at 60° C2)
1.02
52
Cottons 40°
0.75
59
Cotton economy at 40° C 2)
0.75
52
Synthetics 40°
0.5
45
Delicates 40°
0.55
55
Wool/ Handwash 30°
0.3
50
The consumption data shown on this chart is to be considered purely indicative, as it may vary depending on the quantity and type of laundry, on
the inlet water temperature and on the ambient temperature.
1) For the programme time, refer to the display.
2) This is the programme for the test institutes with a maximum load of cotton at the
maximum spin speed agrees with the last approved version of the EN60456.
BEFORE FIRST USE
1. Put 2 litre of water in the main wash
compartment of the detergent dispenser to activate the drain system.
2. Put a small quantity of detergent in
the main wash compartment of the
detergent dispenser. Set and start a
programme for cotton at the highest temperature without laundry.
This removes all possible dirty from
the drum and the tub.
LANGUAGE SETTING
The first time you activate the appliance, the display shows the default language and tells you to confirm it or
change it:
• Turn the programme knob to set the
desired language.
• When the display shows the necessary language, touch the button 6 to
confirm the selection.
CLOCK SETTING
After you set the language, the display
tells to set the clock:
• The hour digits flash.
• Turn the programme knob to change
the hour.
• Touch button 6 to confirm the selection.
• The minute digits flash.
• Turn the programme knob to change
the minutes.
• Touch button 6 to confirm the selection.
18
USING THE APPLIANCE
ACTIVATING THE APPLIANCE AND SETTING A PROGRAMME
1. Press the button 1 to activate the
appliance.
2. Turn the programme knob ( 2 ) to
the necessary programme or touch
on the buttons 5 to set a memorised programme. The programme
indicator comes on.
3. The indicator of the button 6 flashes with red colour.
4. The display shows the default temperature and spin. If it is necessary,
touch the button 12 and the button
11 to change the water temperature and the spin speed.
5. If it is necessary, touch the other
buttons to add some functions or to
set a delayed start. The display
shows the symbol of the set function and the digit ( D ) shows the
delayed time.
LOADING THE LAUNDRY
1. Open the appliance door.
2. The display ( E ) shows the maximum programme load for the programme ( MAX ) and the weight of
the laundry ( KG ). The text bar on
the display tells to add the laundry.
3. Put the laundry in the drum, one
item at a time. Shake the items before you put them in the appliance.
4. On the display the weight of the
laundry is updated by step of kg 0.5.
The weight is purely indicative and
depends on the type of the laundry.
If you overload the appliance,
the text bar on the display tells
that you put more than the maximum load. The overload indication is available only for programmes with a maximum load
lower than the appliance maximum load.
5. Close the door. The text bar on the
display tells the quantity of detergent to put. This data is purely indicative and depends on the type of
detergent.
Make sure not to have the laundry out
of the drum between the seal and the
door. There is the risk of water leakage
or damage laundry.
ENGLISH
19
USING THE DETERGENT AND ADDITIVES
The detergent compartment for the prewash phase and the soak
programme.
Add the detergent for prewash and soak before the start of the
programme.
The detergent compartment for the washing phase.
If you use a liquid detergent, put it immediately before you start
the programme.
Liquid additives compartment (fabric conditioner, starch).
Put the product in the compartment before you start the programme.
This is the maximum level for the quantity liquid additives.
The compartment for the stain remover.
Put the product in the compartment and set the stain function before you start the programme.
Flap for powder or liquid detergent
Turn it (up or down) in the correct position to use powder or liquid
detergent.
Always obey the instructions that you can find on the packaging of the detergent products.
CHECK THE POSITION OF THE FLAP
1. Pull out the detergent dispenser until it stops. Press the lever down to
remove the dispenser.
20
2. To use powder detergent, turn the
flap up.
3. To use liquid detergent, turn the
flap down.
With the flap in the position
DOWN:
– Do not use gelatinous or thick
liquid detergents.
– Do not put more liquid detergent than the limit showed in
the flap.
– Do not set the prewash
phase.
– Do not set the delay start
function.
4. Measure out the detergent and the
fabric softener.
5. Carefully close the detergent dispenser.
SET THE DELAY START
1. Touch the button 7 again and
again to set the desired delayed
start. The display shows the expected end of the programme
2. Touch the button 6 , the appliance
starts the countdown of the delay
start.
When the countdown is completed,
the programme starts automatically.
Before you touch the button 6
to start the appliance, you can
cancel or change the set of the
delay start.
You cannot set the delay start
with the Steam programme.
CANCEL THE DELAY START
1. Touch the button 6 . The related
indicator flashes.
2. Touch the button 7 again and
again until the display tells that
there is no delay start.
3. Touch the button 6 . The programme starts.
STARTING A PROGRAMME
1. Touch the button 6 to start the
programme. The indicator of the
button 6 stops to flash and is on
with red colour.
If a delayed start is set, the appliance
starts the countdown.
ENGLISH
INTERRUPT A PROGRAMME
1. Touch the button 6 . The indicator
flashes.
2. Touch the button 6 again. The
washing programme continues.
CANCEL A PROGRAMME
1. Press the button 1 to cancel the
programme and to deactivate the
appliance.
2. Press the button 1 again to activate the appliance. Now, you can
set a new washing programme.
The appliance does not drain
the water.
CHANGE A FUNCTION
You can change only some functions
before they operate.
1. Touch the button 6 . The indicator
flashes.
2. Change the function set.
3. Touch the button 6 again. The
washing programme continues.
21
To open the appliance door:
1. Touch the button 6 . The door
lock symbol in the display goes off
and a message tells you that the
door is unlocked.
2. Open the appliance door.
3. Close the appliance door and touch
the button 6 again. The programme or the delay start continues.
If the heating element operates
or the level of water in the drum
is too high, the door lock symbol stays on. You cannot open
the door, but it is necessary
open it.
1. Deactivate the appliance.
2. Wait for some minutes.
3. Make sure that no water is in
the drum.
If you deactivate the appliance,
it is necessary to set the programme again.
OPEN THE DOOR
While a programme or the delay start
operates, the appliance door is locked.
AT THE END OF PROGRAMME
1. The appliance stops automatically.
2. The acoustic signals operate, if it is
active.
3. In the display
flashes and the
message tells you that the programme is completed.
4. The indicator of the button 6 goes
off.
5. The door lock symbol goes off from
the display.
6. Press the button 1 to deactivate
the appliance.
7. Remove the laundry from the appliance. Make sure that the drum is
empty.
8. Keep the door ajar, to prevent mildew and odours.
9. Close the water tap.
The washing programme is
completed, but there is water in the
drum:
– The drum turns regularly to prevent
the creases in the laundry.
– The door stays locked.
– You must drain the water to open
the door.
To drain the water:
1. Press the button 1 to deactivate
and activate the appliance.
22
2. Set the drain or spin programme. If
necessary, decrease the spin speed.
3. Touch the button 6 to start the
programme.
4. When the programme is completed
and the door lock symbol goes off,
you can open the door
5. Press the button 1 deactivate the
appliance.
HELPFUL HINTS AND TIPS
THE LAUNDRY LOAD
• Divide the laundry in: white, coloured, synthetics, delicates and wool.
• To wash correctly, obey the instructions that are on the laundry care labels.
• Do not wash together white and coloured items.
• Some coloured items can discolour in
the first wash. We recommend that
you wash them separately for the first
times.
• Button up pillowcases, close zippers,
hooks and poppers. Tie up belts.
• Remove hard stains.
• Wash with a special detergent areas
with heavy soil.
• Be careful with the curtains. Remove
the hooks or put the curtains in a
bag.
• Do not wash in the appliance :
– Laundry without hems or with cuts
– Underwired bras.
– Use a washing bag to wash small
items.
• A very small load can cause balance
problems with the spin phase. If this
occurs, adjust manually the items in
the tub and start the spin phase
again.
DETERGENTS AND ADDITIVES
• Only use detergents and additives
specially made for washing machines.
• To help the environment, do not use
more than the correct quantity of detergent.
• Obey the instructions that you find
on the on packaging of these products.
• Use the correct products for the type
and colour of the fabric, the programme temperature and the level of
soil.
• If you use liquid detergents, do not
set the prewash phase.
ECOLOGICAL HINTS
To help the environment, use less water
and energy, obey these instructions:
• Set a programme without prewash
phase to wash laundry with normal
soil.
• Always wash with the maximum load
of the laundry.
• To set a programme with lower temperature, use a stain remover before
to wash.
• To use the correct quantity of the detergent, check the water hardness of
your domestic system
WATER HARDNESS
If the water hardness in your area is
high or moderate, we recommend that
you use a water softener for washing
machines. In areas where the water
hardness is soft it is not necessary to
use a water softener.
To know the water hardness in your
area, contact your local water authority.
Obey the instructions that you find on
the packaging of the products.
Equivalent scales measure the water
hardness:
• German degrees (°dH).
• French degrees (°TH).
• mmol/l (millimol for each litre - international unit for the hardness of water).
• Clarke degrees.
ENGLISH
23
Water hardness table
Level
Type
1
soft
2
3
4
Water hardness
°dH
°T.H.
mmol/l
Clarke
0-7
0-15
0-1.5
0-9
medium
8-14
16-25
1.6-2.5
10-16
hard
15-21
26-37
2.6-3.7
17-25
very hard
> 21
> 37
>3.7
>25
CARE AND CLEANING
WARNING!
Disconnect the appliance from the
electricity supply before you clean it.
DESCALING
The water we use contains limescale. If
it becomes necessary, use a water softener to remove limescales.
Use a special product made for washing machines. Obey the instructions
that you find on the packaging of the
manufacturer.
Do this separately from the laundry
wash.
EXTERNAL CLEANING
CAUTION!
Do not use alcohol, solvents or
chemical products.
MAINTENANCE WASH
With the low temperature washes it is
possible that some detergent stays in
the drum. Make regularly a maintenance wash. To do this:
• Empty the laundry from the drum.
• Set the hottest cotton wash programme
• Use a correct quantity of powder detergent with biological properties.
After each wash, keep the door open
for a while to prevent mould and to let
unpleasant smells go out.
Clean the appliance only with soap and
warm water. Fully dry all the surfaces.
DOOR SEAL
Regularly examine the seal and remove
all objects from the inner part.
DRUM
Regularly examine the drum to prevent
limescale and rust particles.
Only use special products to remove
rust particles from the drum.
To do this:
• Clean the drum with special product
for stainless steel.
• Start a short programme for cotton
at the maximum temperature with a
small quantity of detergent.
24
DETERGENT DISPENSER
To clean the dispenser:
1
1. Press the lever.
2. pull the dispenser out firmly.
2
3. Remove the top part of the liquid
additive compartment.
4. Clean all the parts with water.
5. Clean the dispenser recess with a
brush.
6. Put back the dispenser in the recess.
DRAIN PUMP
Regularly examine the drain
pump and make sure that it is
clean.
Clean the pump if:
• The appliance does not drain the water.
• The drum cannot turn.
• The appliance makes an unusual
noise because of the blockage of the
drain pump.
• The display shows an alarm code because of the problem with water
drain.
WARNING!
1. Disconnect the mains plug
from the socket.
2. Do not remove the filter
while the appliance operates. Do not clean the drain
pump if the water in the appliance is hot. The water
must be cold before you
clean the drain pump.
ENGLISH
25
To clean the drain pump:
1. Open the drain pump door.
2. Pull the flap out to remove it.
3. Put a container below the recess of
the drain pump to collect the water
that flows out.
4. Press the two levers and pull forward the drainage duct to let the
water flow out.
1
5. When the container is full of water,
put the drainage duct back again
and empty the container. Do previous step again until no more water
flows out from the drain pump.
6. Pull back the drainage duct and turn
the filter to remove it.
2
7. Remove fluff and objects from the
pump.
8. Make sure that the impeller of the
pump can turn. If this does not occur, contact the service centre.
26
9. Clean the filter under the water tap
and put it back in the pump into the
special guides.
10. Make sure that you tighten correctly
the filter to prevent leakages.
11. Put the flap back and close the
drain pump door.
2
1
THE INLET HOSE FILTER AND THE
VALVE FILTER
It could be necessary to clean the filters
when:
• The appliance does not fill with water.
• The appliance fills with the water for
a long time.
• The indicator of the button 6 flashes and the display shows the related
alarm. Refer to 'Trouble shooter and
service'.
WARNING!
Disconnect the mains plug from
the mains socket.
To clean the water inlet filters:
1. Close the water tap.
2. Remove the water inlet hose from
the water tap.
3. Clean the filter in the inlet hose with
a stiff brush.
4. Remove the inlet hose behind the
appliance.
5. Clean the filter in the valve with a
stiff brush or a towel.
6. Install again the inlet hose. Make
sure that the couplings are tight to
prevent leakages.
7. Open the water tap.
35°
45°
EMERGENCY DRAIN
Because of a malfunction, the appliance
cannot drain the water.
If this occurs, do steps (1) through (6) of
"Drain pump".
Clean the pump, if it becomes necessary.
Put the drainage duct back and close
the drain pump flap.
ENGLISH
When you drain the water with the
emergency drain procedure, you must
activate again the drain system:
1. Put 2 litre of water in the main wash
compartment of the detergent dispenser.
2. Start the programme to drain the
water.
FROST PRECAUTIONS
27
2. Close the water tap.
3. Remove the water inlet hose
4. Put the two ends of the inlet hose in
a container and let the water flow
out of the hose.
5. Empty the drain pump. Obey the
emergency drain procedure
6. When the drain pump is empty, install the inlet hose again.
If the appliance is installed in an area
where the temperature can be less
than 0 °C, remove the remaining water
from the inlet hose and the drain
pump.
1. Disconnect the mains plug from the
mains socket.
WARNING!
Make sure that the temperature
is more than 0 °C before you
use the appliance again.
The manufacturer is not responsible for damages that the very
low temperature can do.
TROUBLE SHOOTER AND SERVICE
The start of the appliance does not occur or it stops during operation.
First try to find a solution to the problem (refer to the table). If not, contact
the service centre.
With some problems, the acoustic
signals operate and the display
shows an alarm message.
WARNING!
Deactivate the appliance before
you do the checks.
Problem
Possible cause
Possible solution
The display tells
to check the tap:
the appliance
does not fill with
water.
The water tap is closed.
Open the water tap.
The water inlet hose is
damaged.
Make sure that the water inlet
hose has no damages.
The filters in the water in- Clean the filters. Refer to 'Care
let hose is blocked .
and cleaning'.
The connection of the
water inlet hose is not
correct.
Make sure that the connection is
correct.
The water pressure is too
low.
Contact your local water authority.
The water tap is blocked
or is furred with limescale.
Clean the water tap.
28
Problem
Possible cause
Possible solution
The display tells
to check the
drain filter: the
appliance does
not drain the water.
The water drain hose is
damaged.
Make sure that the water drain
hose has no damages.
The filter of the drain
pump is blocked.
Clean the filter of the drain
pump. Refer to 'Care and cleaning'.
The connection of the
water drain hose is not
correct.
Make sure that the connection is
correct.
The display tells
to check the
door.
The appliance door is
open or not closed correctly.
Close the door correctly.
The display tells
there is a water
alert.
The anti-flood device is
activated.
• Disconnect the appliance.
• Close the water tap.
• Contact the service centre.
PROBLEM WITHOUT ALARM MESSAGE
Problem
Possible cause
Possible solution
The appliance
does not drain
the water.
A washing programme
without the drain phase
is set.
Set the drain programme.
The function Rinse Hold
is on.
Set the drain programme.
The spin phase
The spin phase is off.
does not operate.
The programme
does not start.
Set the spin programme.
The filter of the drain
pump is blocked.
Clean the filter of the drain
pump. Refer to 'Care and cleaning'.
Balance problems with
the laundry load.
Adjust manually the items in the
tub and start the spin phase
again.
The mains plug is not
connected in the mains
socket.
Put in the mains plug.
Blow out fuse in the
household fuse box.
Replace the fuse.
You did not press the 6
button.
press the 6 button.
The delay start is set.
If necessary to wash the laundry
immediately, cancel the delay
start.
ENGLISH
Problem
There is water on
the floor.
You cannot open
the appliance
door.
The appliance
makes an unusual
noise.
29
Possible cause
Possible solution
The Child Lock function
is activated.
Deactivate the Child Lock function.
Leakages from the couplings of the water hoses.
Make sure that the couplings are
tight.
Leakages from the drain
pump.
Make sure that the drain pump
filter is tight.
The water drain hose is
damaged.
Make sure that the water inlet
hose has no damages.
The washing programme Let the washing programme end.
is in operation.
There is water in the
drum.
Set the drain or the spin programme.
Incorrect level of the appliance.
Adjust the level of the appliance.
Refer to 'Installation'.
You did not remove the
packaging and/or the
transit bolts.
Remove the packaging and/or
the transit bolts. Refer to 'Installation'.
The load is very small.
Add more laundry in the drum.
The appliance fills The end of the drain
with water and
hose is too low.
drain immediately.
Make sure that the drain hose is
in the correct position.
The washing reThe detergent you used
sults are not satis- was not sufficient or corfactory.
rect.
Increase the detergent quantity
or use a different one.
You did not remove the
stubborn stains before
you wash the laundry.
Use special products to remove
the stubborn stains.
You set a not correct
temperature.
Make sure that you set the correct temperature.
Too much laundry load.
Decrease the laundry load.
The internal lamp
is off.
The lamp is burned.
To replace the lamp, contact the
service centre.
After a steam
programme, garments are partially wet.
The appliance is not accurately levelled.
Check the levelling and adjust
the appliance by raising or lowering the feet.
30
Problem
Possible cause
Possible solution
After a steam
programme, garments are not sufficiently smooth.
A wrong STEAM programme has been selected (e.g. Synthetic instead of Cotton).
Note the composition of the fabric.
Excessive laundry load.
Reduce the laundry load
The drum is emp- It is necessary to set a
ty and the display tare.
shows there is
some weight in .
Press the button 1 to deactivate the appliance and to activate it again.
The drum is full
but the display
shows 0.0 kg.
Press the button 1 to deactivate the appliance . Empty the
drum and obey to the necessary
steps. (Refer to 'Loading the
laundy')
You loaded the laundry
before to activate the
appliance.
After the check, activate the appliance.
The programme continues from the
point of interruption.
If the problem occurs again, contact the
service centre.
If the display shows other alarm message, contact the service centre.
SERVICE
• Refer to the information supplied
with this appliance for guarantee
condition and point of contact. The
information to give to the service is
on the rating plate.
We recommend that you write the information here:
Product number
(PNC)
..................
Model
(MOD.)
Serial number
(S.N.)
..................
..................
TECHNICAL DATA
Dimensions
Width / Height / Depth
Electrical connection:
Voltage
Overall power
Fuse
Frequency
Water supply pressure
Minimum
0,5 bar (0,05 MPa)
Maximum
8 bar (0,8 MPa)
Water supply 1)
600 / 850 / 600 mm
230 V
2200 W
10 A
50 Hz
Cold water
ENGLISH
Maximum load
Cotton
Spin speed
Maximum
31
9 kg
1400 rpm (L 98499 FL)
1600 rpm (L 98699 FL)
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
INSTALLATION
UNPACKING
1. Use the gloves. Remove the external film. Use a cutter, if it is necessary.
2. Remove the cardboard top.
3. Remove the polystyrene packaging
materials.
4. Remove the internal film.
32
5. Open the door. Remove the polystyrene piece from the door seal
and all the items from the drum.
6. Put the polystyrene front piece on
the floor behind the appliance.
Carefully put down the appliance
with the rear side on it. Make sure
that the hoses are not damaged.
7. Remove the polystyrene protection
from the bottom.
1
2
8. Clean and dry fully the surfaces of
the bottom of the appliance. Do not
use alcohol, solvents or chemical
products.
ENGLISH
A
33
9. Make sure to identify the different
sizes and the positions of the sound
barriers. Refer to the illustration:
A ( FRONT ) = Front of the appliance
B ( BACK ) = Rear of the appliance
B
x4
A
10. – Remove the adhesive strip from
the silent barriers.
– Attach the four barriers to surfaces of the bottom previously indicated. Refer to the illustration.
– Make sure that the barriers are
securely attached.
B
11. Pull up the appliance in vertical position.
12. Remove the power supply cable and
the drain hose from the hose holders.
34
13. Turn the three bolts with the key
supplied with the appliance. Pull out
the plastic spacers.
14. Replace the plastic spacers with the
plastic caps. You can find these caps
in the user manual bag.
WARNING!
Remove all the packaging and
the transit bolts before you install the appliance.
We recommend that you keep
the packaging and the transit
bolts for when you move the appliance.
POSITIONING AND LEVELLING
x4
• Install the appliance on a flat hard
floor.
• Make sure that carpets do not stop
the air circulation below the appliance.
• Make sure that the appliance does
not touch the wall or other kitchen
units
• Loosen or tighten the feet to adjust
the level. A correct adjustment of the
appliance level prevents the vibration, noise and the movement of the
appliance when in operation.
ENGLISH
35
• The appliance must be level and stable.
CAUTION!
Do not put cardboard, wood or
equivalent materials below the
appliance feet to adjust the level.
THE INLET HOSE
• Connect the hose to the appliance.
Turn the inlet hose only left or right.
Loose the ring nut to set it in the correct position.
45
O
35
O
• Connect the water inlet hose to the
cold water tap with 3/4 thread.
CAUTION!
Make sure that there are no
leaks from the couplings.
Do not use an extension hose if
the inlet hose is too short. Contact the service centre for the
replacement of the inlet hose.
36
WATER-STOP DEVICE
A
The inlet hose has a water stop device.
This device prevents damage of water
leaks in the hose because of its natural
ageing. The red sector in the window
«A» shows this fault .
If this occur, close the water tap and
contact the service centre to replace
the hose.
WATER DRAINAGE
There are some procedure to connect
the drain hose:
With the plastic hose guide.
• On the edge of a sink.
• Make sure that the plastic guide cannot move when the appliance drains.
Attach the guide to the water tap or
the wall.
• To a stand pipe with vent-hole.
Refer to the illustration. Directly into
a drain pipe at a height of not less
than 60 cm and not more than 100
cm. The end of the drain hose must
always be ventilated , i.e. the inner
diameter of the drainpipe must be
larger than the external diameter of
the drain hose.
ENGLISH
37
Without the plastic hose guide.
• To a sink spigot.
Refer to the illustration. Put the drain
hose in the spigot and tighten it with
a clip. Make sure that the drain hose
makes a loop to prevent that remaining particles go in the appliance from
the sink.
• Directly to a built-in drain pipe in the
room wall.
You can extend the drain hose
to maximum 400 mm. Contact
the service centre for the other
drain hose and the extension.
38
ENGLISH
39
www.aeg-electrolux.com/shop
132940570-A-432010
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
