Aeg T86280IC User Manual

LAVATHERM 86280IC
TUMBLE DRYER
USER MANUAL
2
CONTENTS
4
6
7
8
10
11
11
13
16
18
24
26
27
SAFETY INFORMATION
ENVIRONMENT CONCERNS
PRODUCT DESCRIPTION
ACCESSORIES
CONTROL PANEL
BEFORE FIRST USE
PROGRAMMES
USING THE APPLIANCE
HINTS AND TIPS
CARE AND CLEANING
TROUBLESHOOTING
TECHNICAL INFORMATION
INSTALLATION
SERVICE
When contacting Service, ensure that
you have the following data available.
The information can be found on the
rating plate.
Model
PNC
Serial Number
The following symbols are used in this
user manual:
Warning - Important Safety information.
General information and tips
Environmental information
Subject to change without notice
ENGLISH
3
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please spend
a few minutes reading to get the very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to keep all your AEG
appliances looking spotless and working perfectly. Along with a wide range of
accessories designed and built to the high quality standards you would expect, from
specialist cookware to cutlery baskets, from bottle holders to delicate laundry bags…
Visit the webshop at:
www.aeg.com/shop
VISIT OUR WEBSITE FOR:
- Products
- Brochures
- User manuals
- Trouble shooter
- Service information
www.aeg.com
4
SAFETY INFORMATION
In the interest of your safety and to
ensure the correct use, before installing and first using the appliance,
read this user manual carefully, including its hints and warnings. To
avoid unnecessary mistakes and accidents, it is important to ensure that
all people using the appliance are
thoroughly familiar with its operation
and safety features. Save these instructions and make sure that they
remain with the appliance if it is
moved or sold, so that everyone using it through its life will be properly
informed on appliance use and safety.
- Read the instruction manual before the appliance use.
GENERAL SAFETY
• It is dangerous to alter the specifications or attempt to modify this product in any way.
• This appliance is not intended for use
by persons (including children) with
reduced physical and sensory conditions or lack of experience and
knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Make sure that small children and
pets do not climb inside the drum.
To avoid this, please check into the
drum before using.
• Any objects such as coins, safety
pins, nails, screws, stones or any other hard, sharp material can cause extensive damage and must not be
placed into the machine.
• Items such as foam rubber (latex
foam), shower caps, waterproof textiles (if there is no special drying programme), rubber backed articles and
clothes or pillows fitted with foam
rubber pads must not be dried in the
tumble dryer.
• Make sure that there is access to the
mains plug after the installation.
• Always unplug the appliance after
use, cleaning and maintenance.
• Under no circumstances should you
attempt to repair the machine yourself. Repairs carried out by inexperienced persons may cause injury or
serious malfunctioning. Contact your
local Service Centre. Always insist on
genuine spare parts.
• Items that have been soiled with substances such as cooking oil acetone,
petrol, kerosene, spot removers, turpentine, waxes and wax removers
should be washed in hot water with
an extra amount of detergent before
being dried in the tumble dryer.
• Danger of explosion: Never tumble
dry items that have been in contact
with inflammable solvents (petrol,
methylated spirits, dry cleaning fluid
and the like). As these substances are
volatile, they could cause an explosion. Only tumble dry items washed
with water.
• Risk of fire: items that have been
spotted or soaked with vegetable or
cooking oil constitute a fire hazard
and should not be placed in the tumble dryer.
• If you have washed your laundry with
stain remover you must execute an
extra rinse cycle before loading your
tumble dryer.
• Please make sure that no gas lighters
or matches have accidentally been
left in pockets of garments incase
they are loaded into appliance
• The condensed water is not applicable to drink or to prepare food. It can
cause health problems to people and
pets.
• Do not seat or lean on the load door.
The appliance can tilt.
ENGLISH
WARNING!
• Risk of fire! To prevent from
the risk of self combustion
do not stop a tumble dryer
before the end of the drying cycle unless all items are
quickly removed and spread
out so that the heat is dissipated.
• Lint must not be allowed to
accumulate around the tumble dryer.
• Risk of electric shock! Do not spray
down the appliance with jets of water.
• The final part of a tumble dryer cycle
occurs without heat ( cool down cycle ) to ensure that the items are left
at a temperature that ensures that
items will not be damaged.
• The tumble dryer is not to be used if
industrial chemicals have been used
for cleaning.
• Ensure you have good ventilation in
the installation room to avoid the
back flow of gases into the room
from appliances burning other fuels,
including open fires.
INSTALLATION
• This appliance is heavy. Be careful
when you move the appliance.
• When unpacking the appliance,
check that it is not damaged. If in
doubt, do not use it and contact the
Service Centre.
• All packaging must be removed before use. Dangerous damage can occur to the product and to property if
this is not adhered to. See relevant
section in the user manual.
• Each electrical work necessary to install this appliance must be done by
a qualified electrician or competent
person.
• The rear surface of the appliance
must be put against the wall
• If the appliance is installed on the
carpet or equivalent, adjust the feet.
5
Air must flow freely below the appliance.
• After the appliance installation, check
that it is not squeeze or stay on the
electrical supply cable.
• If the tumble dryer is put on top of a
washing machine, it is mandatory to
use the stacking kit (optional accessory - see chapter: "ACCESSORIES").
USE
• This appliance is for domestic use
only. It must not be used for other
functions .
• Only dry fabrics which are applicable
to dry in the tumble dryer. Follow the
instructions on each piece of clothing
label.
• Do not dry not washed items in the
tumble dryer.
• Do not put more load than recommended. Obey the maximum load
volume. See the related chapter in
the user manual.
• Clothes which are dripping wet must
not be put in the tumble dryer.
• Garments which have been in contact
with volatile petroleum products
should not be machine dried. If volatile cleaning fluids are used, care
should be taken to ensure that the
fluid is removed from the garment
before placing in the appliance.
• Do not use the tumble dryer if the
power supply cable, the control panel, the working surface or the base
are damaged so that the inside of
the tumble dryer is accessible.
• Fabric softener or equivalent products must be used as specified by the
fabric softener manufacturer.
• Risk of fire! Do not dry the damaged
items which contain padding or fillings (pillows, jackets, duvets, etc.).
The padding or fillings can get out
and cause the fire.
6
CHILD SAFETY
• This machine is not intended for use
by young children or infirm persons
without supervision.
• Children often do not recognise the
hazards associated with electrical appliances. Children should be supervised to ensure that they do not play
with the appliance.
WARNING!
• Danger of suffocation! The
packaging components (e.g.
plastic film, polystyrene) can
be dangerous to children Keep them out of children’s
reach.
• Keep all detergents in a safe place
out of children’s reach.
• Make sure that children or pets do
not climb inside the drum.
DISCARD THE APPLIANCE
• Disconnect the mains plug from the
mains socket.
• Cut off the mains cable and discard
it.
• Discard the door catch. This prevents
children or pets to be closed in the
appliance. There is a risk of suffocation.
ENVIRONMENT CONCERNS
PACKAGING MATERIALS
Recycle the materials with the symbol
. Put the packaging in applicable
containers to recycle it.
on the product or on its
The symbol
packaging indicates that this product
may not be treated as household
waste. Instead it should be taken to the
appropriate collection point for the
recycling of electrical and electronic
equipment. By ensuring this product is
disposed of correctly, you will help
prevent potential negative
consequences for the environment and
human health, which could otherwise
be caused by inappropriate waste
handling of this product. For more
detailed information about recycling of
this product, please contact your local
council, your household waste disposal
service or the shop where you
purchased the product.
ENGLISH
PRODUCT DESCRIPTION
1
2
3
4
5
12
6
11
7
10
8
9
1 Water container
2 Control panel
7 Airflow slots
8 Adjustable feet
3 Drum light
4 Load door (reversible)
9 Condenser door
10 Condenser cover
5 Filter
6 Sliding button to open the condenser door
11 Lock knobs
12 Rating plate
7
8
ACCESSORIES
STACKING KIT
1 m from floor level. The hose cannot
be in loop. If possible decrease the
length of the hose.
Read carefully the instructions supplied
with the kit.
PEDESTAL WITH THE DRAWER
Product name: SKP11
Available from your authorized dealer.
Stacking kit can be used only with the
washing machines specified in the leaflet. See leaflet attached.
Read carefully the instructions supplied
with the kit.
DRAINING KIT
Product name: PDSTP10.
Available from your authorized dealer.
To put the appliance higher at the level
which helps to easy load and remove
the laundry .
The drawer can be use for laundry storage e.g. : towels, cleaning products and
more.
Read carefully the instructions supplied
with the accessory.
DRYING RACK
Product name: DK11.
Available from your authorized dealer
(can be attached to some types of the
tumble dryers)
Installation kit for through draining of
the condensed water into a basin, siphon, gully, etc. After installation the
water container is drained automatically. The water container must stay in the
appliance.
Installed hose must be on the height
from minimum of 50 cm to maximum of
Product name: RA11.
ENGLISH
Available from your authorized dealer
(can be attached to some types of the
tumble dryers)
Drying rack accessory let to dry safely in
the tumble dryer:
• sport shoes
9
• wool
• soft toys
• lingerie
Read carefully the instructions supplied
with the kit.
10
CONTROL PANEL
1
6
2
5
4
3
1 Programme dial
2 Display
4 The function push buttons
5 Programme indicators
3 Push button Start/Pause
6 Push button Auto Off
DISPLAY
Symbol
,
extra dryness level: minimum, moderate, maximum
,
,
delicacy level: default, moderate, maximum
,
,
Description
—
anti-crease time: default, interval (0 min. - 120 min.)
buzzer activated
child lock activated
time drying function activated
drain the water container indicator
clean the filter indicator
clean the condenser indicator
drying cycle phase indicator
cooling cycle phase indicator
ENGLISH
Symbol
11
Description
crease guard cycle phase indicator
delay start activated
cycle time
time programme interval (10 min. - 2h.)
-
delay start interval (30 min. - 20h.)
-
BEFORE FIRST USE
Clean the tumble dryer drum with a
moist cloth or set a short programme
(e.g. 30 minutes time programme) with
the load of moist cloths.
PROGRAMMES
Programmes
Load
1)
Properties
Available
functions
Cottons
Extra Dry
8 kg
To dry cotton pieces of clothing.
Drying level: extra dry.
all except
Time Drying
Cupboard
Dry 2)
8 kg
To dry cotton pieces of clothing.
Drying level: cupboard dry.
all except
Time Drying
Iron Dry 2)
8 kg
To dry cotton pieces of clothing.
Drying level: applicable to iron.
all except
Time Drying
Extra Silent
8 kg
To gently dry cotton pieces of
clothing with the noise decreased
to the minimum. The programme
can be used at night.
all except
Time Drying
Bed Linen
3 kg
To dry bed linen such as: single
and double sheet, pillowcase,
bedspread.
all except
Time Drying
Duvets
3 kg
To dry single or double duvet and
pillows (with feather, down or synthetic fillings).
all except
Time Drying
and Anticrease 3)
Time Drying
8 kg
To dry laundry with the time set by
the user.
all except
Dry Plus
Extra Quick
Mixed
3 kg
To dry cotton and synthetic fabrics, uses low temperature.
Synthetics
3)
all except:
Delicate and
Time Drying
Fabric
mark
12
Programmes
Load
1)
Properties
Available
functions
Extra Dry
To dry thick or multi-layered fab3,5 kg rics, e. g. pullovers, bedding, table
linen.
all except
Time Drying
Cupboard
Dry 2)
To dry thin fabrics which are not ironed, e.g. easy care shirts, table
3,5 kg
linen, baby clothes, socks, lingerie
with bones or wires.
all except
Time Drying
Iron Dry
3,5 kg
To dry thin fabrics which are also
to be ironed, e.g. knitwear, shirts.
all except
Time Drying
Extra Silent
3,5 kg
To gently dry synthetic pieces of
clothing with the noise decreased
to the minimum. The programme
can be used at night.
all except
Time Drying
1 kg
(or 5
shirts)
To dry easy care fabrics such shirts
and blouses; for minimum ironing
effort. The results can be different
all except
for to the different types of fabric
Time Drying
and its finish. Put fabrics in the
3)
tumble dryer straight. After the cycle, immediately remove dried
fabrics and put on a cloths hanger.
Active Wear
2 kg
To dry outdoor pieces of clothing,
all except
technical, sports, pile fabrics, waTime Drying
terproof and breathable jackets,
and Antishell jacket teamed with a removacrease 3)
ble fleece or inner insulation.
Delicates
3 kg
To dry delicate fabrics.
all except
Time Drying
1 kg
To dry the cloths made of wool .
The cloths become soft and cosy.
We recommend to remove the
cloths immediately after the programme end.
Dry Plus ,
Buzzer ,
Time Drying
4), Delay
Start 3)
Easy Iron
Wool
Fabric
mark
3)
3)
1) maximal weight of dry clothes
2) For test institutes only:
To make a performance test use the standard programmes which are specified in the EN
61121 document. If the remaining moisture level of the laundry, is out of tolerance, adjust the
programme with the Dry Plus function .
3) Delicate activated by default
4) Only with the drying rack RA11 — see chapter ACCESSORIES
ENGLISH
13
USING THE APPLIANCE
PREPARING THE LAUNDRY
LOADING THE LAUNDRY
Dry only the laundry applicable
to dry in the tumble dryer. Make
sure if the laundry is applicable
to dry in the tumble dryer. Do
the check of the fabric mark on
the clothes.
Fabric
mark
Property
Applicable to dry in the tumble dryer
Applicable to dry in the tumble dryer at standard temperature
Applicable to dry in the tumble dryer at decreased temperature
Not applicable to dry in the
tumble dryer
Correctly prepare the laundry:
• close zips, button up duvet covers
and attach loose ties or ribbons (e.g.
ribbons of aprons) - laundry can tangle
• make sure the pockets are empty remove metal items (paper clips,
safety pins, etc.).
• turn items with 2 fabric layers inside
out (e.g. cotton lined anoraks, the
cotton fabric layer must be external).
Dry only:
• cotton and linen with Cottons programmes
• synthetic and mixtures with Synthetic
programmes
• separately the strong coloured textiles and the light coloured textiles colours can bleed
• cotton jersey and knitwear only with
the applicable programmes - items
can shrink
Do not put more laundry than
the maximum load which is 8kg.
1. Pull the appliance door
2. Load loosely the laundry.
3. Close the appliance door.
CAUTION!
Do not lock the laundry in between the appliance door and
rubber seal.
SWITCHING ON THE
APPLIANCE
Push the Auto Off button to activate or
to deactivate the appliance. When the
appliance is on, some indications come
in to the view on the display.
AUTO OFF FUNCTION
To decrease the energy consumption,
the automatic standby function deactivates the appliance:
• if the Start/Pause button was not
pushed in the time of 5 minutes.
• after 5 minutes from the programme
end.
Push the Auto Off button to activate
the appliance.
14
SETTING A PROGRAMME
THE DRY PLUS FUNCTION
This function helps to get the laundry
more dried. There are 3 possible selections:
minimum - the default selection which
is related to the programme.
moderate — the selection to get the
laundry lightly dried.
maximum — the selection to get the
laundry more dried.
THE DELICATE FUNCTION
To dry more lightly the sensitive and
temperature sensitive textiles (e.g.
acrylic, viscose). For fabrics with the
on the fabric label. Prosymbol
gramme operates with decreased heat.
Use the programme dial to set the programme. The possible time to complete the programme come into view
on the display.
The drying time you see is related to the load of 5 kg for cotton and jeans programmes. For
the other programmes the drying time is related to the recommended loads. The drying time
of the cotton and jeans programmes with the load more
than 5 kg is longer.
SPECIAL FUNCTIONS
Together with the programme you can
set 1 or more special functions.
To activate or deactivate the function
push the applicable push button.
THE ANTICREASE FUNCTION
Extends anticrease phase (30 minutes)
at the end of the drying cycle to 90 minutes. This function prevents laundry
from creases. Laundry can be removed
during the anticrease phase.
THE BUZZER FUNCTION
When the buzzer function is activated
you can hear the buzzer at the:
• cycle end
• anti-crease phase start and end
• cycle interruption
The buzzer function is by default always
on. You can use this function to activate
or deactivate the sound.
THE TIME DRYING FUNCTION
Operates only with the Time Drying
programme. Lets the user to set special
time of drying programme from minimum 10 min. to maximum of 2 hours (in
10 min. steps).
When the function is activated the applicable symbol comes into the view on
the display.
THE DELAY START FUNCTION
Let to delay the start of a drying
programme from minimum of
30 minutes to maximum of 20
hours.
ENGLISH
1. Set the drying programme and
functions.
2. Push the Delay start button again
and again until the necessary time
of the delay come into the view on
if the prothe display (e.g.
gramme has to start after 12 hours.)
15
To activate the programme push the
button as on the illustration. The LED
above the button illuminates in red colour.
CHANGE A PROGRAMME
3. To activate the Delay start function,
push the Start/Pause button. The
time to start decreases on the display.
To change a programme, push the Auto/Off button to deactivate appliance.
Push the Auto/Off to activate the appliance and then set the programme
again.
CHILD LOCK FUNCTION
AT THE END OF PROGRAMME
The child lock can be set to prevent the
children to play with the appliance. The
child lock function locks all push buttons and the programme dial (this function does not lock Auto/Off button). To
activate the child lock function push the
Dry Plus and Delicate buttons at the
same time until the symbol come into view on the display. To deactivate
push again the above buttons until the
symbol go out of view.
You can activate the child lock function:
• before you push the Start/Pause button - the appliance cannot start
• after you push the Start/Pause button
- all the push buttons and the programme dial are deactivated
When the drying cycle is completed,
the symbol flashes on the display. If
the Buzzer function is on, an acoustic
signal sounds intermittently for one minute.
To remove the laundry:
1. Push the Auto/Off button for 2 seconds to deactivate the appliance.
2. Open the appliance door.
3. Remove the laundry.
4. Close the appliance door.
STARTING A PROGRAMME
After each drying cycle:
• clean the filter
• drain the water container
(See chapter CARE AND CLEANING.)
16
HINTS AND TIPS
ECOLOGICAL HINTS
• Do not use fabric softener to wash
and then dry. In the tumble dryer
laundry becomes soft automatically.
• Use the condensate as distilled water, e.g. for steam ironing. If necessary clean the condensate before (e.g.
with a coffee filter) to remove possible small pieces of fluff.
• Always keep the airflow slots on the
bottom of the appliance clear.
• Use the load volumes specified in the
programmes chapter.
• Make sure that is good airflow in the
appliance installation position.
• Clean the filter after each drying cycle.
• Spin good the laundry before drying.
AVERAGE LAUNDRY WEIGHTS
bathrobe
1200 g
quilt cover
700 g
man’s work shirt
600 g
man’s pyjamas
500 g
sheet
500 g
tablecloth
250 g
man’s shirt
200 g
night dress
200 g
pillow case
200 g
towelling towel
200 g
blouse
100 g
ladies’ briefs
100 g
men’s underpants
100 g
napkin
100 g
tea cloth
100 g
WATER HARDNESS AND
CONDUCTIVITY
Water hardness can be different for different locations. Water hardness has an
effect on the water conductivity and the
operation of the conductivity sensor in
the appliance. If you know the value of
the water conductivity you can adjust
the sensor to dry with the better results.
To change the sensor conductivity:
1. Turn the programme dial to available programme.
2. Push at the same time 2 buttons
(see the illustration). Hold down until one of the symbols come into
view on the display:
–
low conductivity <300
μS/cm
–
moderate conductivity
300-600 μS/cm
–
high conductivity >600
μS/cm
3. Push the button again and again
until you set necessary level (see
the illustration).
4. To memorise the setting push at
the same time 2 buttons as are
specified in the point 2.
WATER CONTAINER FULL —
INDICATION
By default the indication
is always
on. It comes into the view at the end of
the cycle or when the water container is
full. When you use an external equipment to drain the container, the indication can be off.
ENGLISH
To activate or deactivate the indication:
1. Turn the programme dial to available programme.
2. Push at the same time 2 buttons
(see the illustration) and hold down
until you see the correct setting:
17
– the indication
is off and the
comes into the
indicator
is perview — the indication
manently off
– the indication
is on and the
indicator
comes into the
view — the indication
is activated
18
CARE AND CLEANING
CLEANING THE FILTER
At the end of each cycle the indicator
(clean the filter) is on to tell you that
the filter must be cleaned.
The filter collects the fluff. The
fluff occurs while the cloths are
dried in the tumble dryer.
To clean the filter:
1. Open the door.
2. Pull the filter.
3. Open the filter.
ENGLISH
19
4. Use a moist hand to clean the filter.
5. If necessary clean the filter with
warm water using a brush.
Close the filter.
6. Remove fluff from the filter socket.
For this a vacuum cleaner can be
used.
7. Put the filter inside the filter socket.
CAUTION!
Do not operate the tumble dryer without the filter or with damaged or blocked filter.
Clean the filter after each drying
cycle. Clogged filter increases
the cycle time and causes higher
energy consumption.
DRAINING THE WATER
CONTAINER
Drain the water container after each
drying cycle.
If the water container is full, the programme breaks off automatically and
drain the water conthe indicator
tainer is on. To continue the programme, drain the water container and
press the start button.
To drain the water container automatically you can install draining accessory (see chapter: ACCESSORIES)
20
To drain the water container:
1. Pull the water container.
2. Move the water container in horizontal position.
3. Move the plastic connection out
and drain the water container into a
sink or equivalent receptacle.
4. Move plastic connection in and install water container.
WARNING!
Risk of poisoning. The condensed water is not applicable
to drink or to prepare food.
The condensed water can be
used as distilled water, e.g. for
steam ironing. If necessary filter
the condensed water (e.g. with a
coffee filter) to remove possible
residue and small pieces of fluff.
CLEANING THE CONDENSER
If the indicator
clean the condenser is on, the condenser must be
cleaned.
ENGLISH
21
To clean the condenser:
1. Open the loading door.
2. Move the release button on the
bottom of the door opening and
open the condenser door.
3. Turn the 2 blockages to unlock the
condenser lid.
4. Lower the condenser lid.
22
5. Catch the handle and pull the condenser out from the bottom compartment. Move condenser horizontally to do not spill remaining
water.
6. Clean the condenser in vertical position over a basin or paddling.
Rinse through with a hand shower.
7. Clean the condenser filter. Rinse
through with a hand shower.
8. Put the condenser back inside the
bottom compartment.
9. Close the condenser lid.
10. Lock the 2 blockages until they
snap.
11. Close the condenser door.
ENGLISH
CAUTION!
Do not operate the tumble dryer when the condenser is
blocked with fluff. This could
cause the damage to the tumble dryer. This also increases energy consumption.
Do not use sharp objects to
clean the condenser. The damaged condenser could cause
leaks.
Do not operate the tumble dryer without the condenser.
CLEANING THE DRUM
WARNING!
Disconnect the appliance before you clean it.
Use a standard neutral soap detergent
to clean the inner surface of the drum
23
and drum ribs. Dry the cleaned surfaces
with a soft cloth.
CAUTION!
Do not use abrasive materials or
steel wool to clean the drum.
CLEANING THE CONTROL
PANEL AND HOUSING
Use a standard neutral soap detergent
to clean the control panel and housing.
Use a moist cloth to clean. Dry the
cleaned surfaces with a soft cloth.
CAUTION!
Do not use furniture cleaning
agents or cleaning agents which
can cause corrosion to clean the
appliance.
24
TROUBLESHOOTING
TROUBLESHOOTING
Problem1)
Possible cause
Remedy
The tumble dryer is not connected to mains supply.
Connect in at mains socket.
Check fuse in fuse box (domestic installation).
The loading door is opened.
The tumble
The Auto/Off button was not
dryer does
pushed.
not operate.
The Start/Pause button was not
pushed.
Unsatisfactory drying
results.
The door
does not
close.
Err (Error)
on the display.
No drum
light
Close the loading door.
Push the Auto/Off button.
Push the Start/Pause button.
The appliance is in the standby
mode.
Push the Auto/Off button.
Incorrect programme selection.
Do the selection of the applicable programme. 2)
The filter is clogged.
Clean the filter. 3)
The Dry Plus function was in
minimum mode.
Change the Dry Plus function to
the moderate or maximum
mode.
The condenser is clogged.
Clean the condenser. 3)
Too high volume of the load.
Obey the maximum load volume.
The airflow grill is clogged.
Clean the airflow grill in the bottom of the appliance.
Dirt on the inner surface of the
drum.
Clean the inner surface of the
drum.
Too high water hardness.
Set applicable water hardness4).
The filter not locked in the position.
Put the filter in the correct position.
The laundry is locked between
the door and the seal.
Put the load correctly in the
drum.
You try to change the programme or the function after
the start of the cycle.
Turn the tumble dryer off and
on. Make the new selection.
The function you try to activate
is not applicable with the selected programme.
Turn the tumble dryer off and
on. Make the new selection.
Defective drum light.
Contact the service centre to replace the drum light.
ENGLISH
Problem1)
Possible cause
25
Remedy
Abnormally
elapsing
time on the
display.)
The time to end is calculated on
The automatic procedure — this
the basis of the volume and
is not the appliance malfunction.
dampness of the laundry.
Programme
inactive.
The water container is full.
Drain the water container3) ,
push the Start/Pause button.
Too small laundry volume.
Do the selection of time programme.
The laundry is too dry.
Do the selection of time programme or higher drying level
(e.g. Extra Dry )
The filter is clogged.
Clean the filter.
Too high volume of the load.
Obey the maximum load volume.
The laundry not spun sufficiently.
Spin correctly the laundry.
Very high room temperature this is not the appliance malfunction.
If possible, lower the room temperature.
Drying cycle
too short.
Drying cycle
too long 5)
1) If there is an error message on the display (e.g. E51): Turn the tumble dryer off and on.
Make a selection of the new programme. Push the Start/Pause button. Does not operate? contact the service centre and give the error code.
2) follow the programme description — see PROGRAMMES chapter
3) see CARE AND CLEANING chapter
4) see section WATER HARDNESS in HINTS AND TIPS chapter
5) Note: After maximum 5 hours the drying cycle ends automatically (see Drying cycle
complete section).
DRUM LIGHT
This appliance has an internal lamp that
comes on when you open the door and
goes off when the door is closed.
WARNING!
Visible LED radiation, do not
look directly into the beam.
To replace the internal lamp,
contact the service centre.
The LED of the lamp is CLASS 1 and
agrees with IEC 60825-1:1993 + A1:1997
+ A2:2001.
26
TECHNICAL INFORMATION
height x width x depth
850 x 600 x 600 mm (maximal 640 mm)
drum volume
118 l
maximum depth with the load door
opened
1090 mm
maximum width with the load door
opened
950 mm
adjustable height
850 mm (+ 15 mm - feet regulation)
the appliance weight
43 kg
maximum load volume
8 kg
voltage
230-240 V
frequency
50 Hz
necessary fuse
13 A
total power
2800 W
energy efficiency class
B
energy consumption kWh/cycle 1)
4,48 kWh
annual energy consumption
271,4 kWh
type of use
Domestic
permitted ambient temperature
+ 5°C to + 35°C
1) 8 kg of cotton, centrifuged at 1000 rpm with reference to EN 61121
ENGLISH
27
INSTALLATION
APPLIANCE POSITIONING
• The tumble dryer must be installed in
a clean position, where dirt does not
collect.
• Air must flow freely around the appliance. Make sure that the front airflow
slots in the bottom of the appliance
are not blocked .
• To keep vibration and noise at the
minimum, when the tumble dryer operates, it must be put on a stable and
flat surface.
• When the appliance is put in its permanent position, check if is fully level
with the aid of a spirit level. If it is
not, adjust the feet until it is.
• Do not remove the feet. Do not decrease the floor clearance through
thick carpets, bar of wood or equivalent. This can increase the heat which
can cause interference with the operation of the appliance.
• The temperature of the hot
air which occurs in the tumble
dryer can increase to 60 °C.
The appliance must not be installed on the floor which is
not resistant to high temperatures.
• When the tumble dryer operates, the room temperature
must not be lower than +5 °C
and higher than +35 °C. This
can cause unwanted effect on
the performance of the appliance.
• If it is necessary to move the
appliance, it must be moved
vertically.
• The appliance must not be installed behind a lockable
door, a sliding door, a door
with a hinge on the opposite
side to that of the appliance
in such a way that a full opening of the tumble dryer is restricted.
UNPACKING
CAUTION!
Before use all parts of the transport
packaging must be removed.
To remove the polystyrene blockages:
1. Open the load door.
2. Pull 2 plastic hoses with the polystyrene blockages out from the
drum.
x2
It is possible to adjust the height of the
tumble dryer. To do that adjust the feet
(see picture).
15mm
28
INSTALLATION UNDER A
COUNTER
The appliance can be installed as freestanding or below the kitchen counter
with correct space (see picture).
600 mm
> 850 mm
ing plate is behind the load door (see
the “PRODUCT DESCRIPTION” chapter).
The appliance has a power supply cable with plug fitted with 13 A fuse. If
necessary, replace the fuse in the plug
by 13 A ASTA BS 1363/A approved
fuse.
The wires in the power supply cable are
coloured as follow:
600 mm
A
B
C
D
THE LOAD DOOR REVERSAL
The load door can be installed by the
user in the opposite side if there is a
limit to install the appliance. (see separate leaflet).
ELECTRICAL CONNECTION
• Connect the appliance to a grounded socket. Refer to the applicable
electrical requirements.
• Make sure that the electrical data on
the rating plate agrees with the power supply.
• Always use a correctly installed
shockproof socket.
• Do not use multiple plugs and extension cables. There is a risk of fire.
• All replacements of power supply cable must be carried out by our Service.
• Make sure not to squash or cause
damage to the mains plug and cable
behind the appliance.
• Do not pull the mains cable to disconnect the appliance. Always pull
the mains plug.
• The plug must be dry.
The data about mains voltage, type of
current and the necessary fuse are on
the rating plate and in the “TECHNICAL INFORMATION” chapter. The rat-
A) green and yellow - ground — earth
(E)
B) brown - live (L)
C) cord clamp
D) blue - neutral (N)
The green and yellow coloured wire
must be connected to the terminal with
mark or the
E mark or the ground
green and yellow coloured terminal.
The blue coloured wire must be connected to the terminal N or black coloured .
The brown coloured wire must be connected to the terminal L or red coloured .
The wires of the cable must be no cut
or stray strands of wire present and the
cable clamp must be secure over the
outer sheath.
Permanent connection
The necessary condition of permanent
connection is to install a double-pole
isolating switch directly on the supply
terminals.
The type of switch must be correct for
the necessary load and must align with
applicable electrical requirements.
The switch must not break the yellow
and green coloured ground wire.
ENGLISH
29
30
ENGLISH
31
www.aeg.com/shop
136915940-A-072011

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
