Aeg-Electrolux SWD81800G1 User Manual

SWD81800G1
WINE CELLAR
USER MANUAL
2
CONTENTS
4
7
9
12
14
17
21
22
SAFETY INFORMATION
CONTROL PANEL
DAILY USE
CARE AND CLEANING
WHAT TO DO IF…
INSTALLATION
NOISES
TECHNICAL DATA
ENVIRONMENT CONCERNS
Recycle the materials with the symbol . Put the packaging in applicable containers to
recycle it.
Help protect the environment and human health and to recycle waste of electrical and
electronic appliances. Do not dispose appliances marked with the symbol with the
household waste. Return the product to your local recycling facility or contact your
municipal office.
VISIT OUR WEBSITE FOR:
- Products
- Brochures
- User manuals
- Trouble shooter
- Service information
www.aeg.com
LEGEND
Warning - Important Safety information.
General information and tips
Environmental information
Subject to change without notice.
ENGLISH
3
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please spend
a few minutes reading to get the very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to keep all your AEG
appliances looking spotless and working perfectly. Along with a wide range of
accessories designed and built to the high quality standards you would expect, from
specialist cookware to cutlery baskets, from bottle holders to delicate laundry bags…
Visit the webshop at:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available. The
information can be found on the rating plate.
Model
PNC
Serial Number
4
SAFETY INFORMATION
In the interest of your safety and to ensure
the correct use, before installing and first
using the appliance, read this user manual
carefully, including its hints and warnings.
To avoid unnecessary mistakes and accidents, it is important to ensure that all
people using the appliance are thoroughly familiar with its operation and safety
features. Save these instructions and
make sure that they remain with the appliance if it is moved or sold, so that everyone using it through its life will be properly informed on appliance use and safety.
For the safety of life and property keep
the precautions of these user's instructions as the manufacturer is not responsible for damages caused by omission.
CHILDREN AND VULNERABLE
PEOPLE SAFETY
• This appliance is not intended for use
by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
• Keep all packaging well away from children. There is risk of suffocation.
• If you are discarding the appliance pull
the plug out of the socket, cut the connection cable (as close to the appliance
as you can) and remove the door to
prevent playing children to suffer electric shock or to close themselves into it.
• If this appliance featuring magnetic
door seals is to replace an older appliance having a spring lock (latch) on the
door or lid, be sure to make that spring
lock unusable before you discard the
old appliance. This will prevent it from
becoming a death trap for a child.
GENERAL SAFETY
WARNING!
Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction.
• This appliance is intended to be used
exclusively for the storage of wine.
• Do not use a mechanical device or any
artificial means to speed up the thawing process.
• Do not use other electrical appliances
(such as ice cream makers) inside of refrigerating appliances, unless they are
approved for this purpose by the manufacturer.
• Do not damage the refrigerant circuit.
• The refrigerant isobutane (R600a) is
contained within the refrigerant circuit
of the appliance, a natural gas with a
high level of environmental compatibility, which is nevertheless flammable.
During transportation and installation
of the appliance, be certain that none
of the components of the refrigerant
circuit become damaged.
If the refrigerant circuit should become
damaged:
– avoid open flames and sources of ignition
– thoroughly ventilate the room in
which the appliance is situated
• It is dangerous to alter the specifications or modify this product in any way.
Any damage to the cord may cause a
short-circuit, fire and/or electric shock.
WARNING!
Any electrical component (power
cord, plug, compressor) must be
replaced by a certified service
agent or qualified service personnel.
1.
Power cord must not be lengthened.
2. Make sure that the power plug is
not squashed or damaged by the
back of the appliance. A squashed
or damaged power plug may overheat and cause a fire.
3. Make sure that you can come to
the mains plug of the appliance.
4. Do not pull the mains cable.
ENGLISH
If the power plug socket is loose,
do not insert the power plug. There
is a risk of electric shock or fire.
6. You must not operate the appliance without the lamp cover (If the
lamp cover is foreseen) of interior
lighting.
This appliance is heavy. Care should be
taken when moving it.
Do not remove nor touch items from
the freezer compartment if your hands
are damp/wet, as this could cause skin
abrasions or frost/freezer burns.
Avoid prolonged exposure of the appliance to direct sunlight.
Bulb lamps (If the lamp is foreseen)
used in this appliance are special purpose lamps selected for household appliances use only. They are not suitable
for household room illumination.
5.
•
•
•
•
DAILY USE
• Do not put hot pot on the plastic parts
in the appliance.
• Do not store flammable gas and liquid
in the appliance, because they may explode.
• Appliance's manufacturers storage recommendations should be strictly adhered to. Refer to relevant instructions.
CARE AND CLEANING
• Before maintenance, switch off the appliance and disconnect the mains plug
from the mains socket.
• Do not clean the appliance with metal
objects.
• Do not use sharp objects to remove
frost from the appliance. Use a plastic
scraper.
• Regularly examine the drain in the refrigerator for defrosted water. If necessary, clean the drain. If the drain is
blocked, water will collect in the bottom of the appliance.
INSTALLATION
For electrical connection carefully
follow the instructions given in
specific paragraphs.
5
• Unpack the appliance and check if
there are damages on it. Do not connect the appliance if it is damaged. Report possible damages immediately to
the place you bought it. In that case retain packing.
• It is advisable to wait at least four hours
before connecting the appliance to allow the oil to flow back in the compressor.
• Adequate air circulation should be
around the appliance, lacking this leads
to overheating. To achieve sufficient
ventilation follow the instructions relevant to installation.
• Wherever possible the back of the
product should be against a wall to
avoid touching or catching warm parts
(compressor, condenser) to prevent
possible burn.
• The appliance must not be located
close to radiators or cookers.
• Make sure that the mains plug is accessible after the installation of the appliance.
• Connect to potable water supply only
(If a water connection is foreseen).
SERVICE
• Any electrical work required to do the
servicing of the appliance should be
carried out by a qualified electrician or
competent person.
• This product must be serviced by an authorized Service Centre, and only genuine spare parts must be used.
6
ENVIRONMENT PROTECTION
This appliance does not contain
gasses which could damage the
ozone layer, in either its refrigerant circuit or insulation materials.
The appliance shall not be discarded together with the urban refuse and rubbish. The insulation
foam contains flammable gases:
the appliance shall be disposed
according to the applicable regulations to obtain from your local
authorities. Avoid damaging the
cooling unit, especially at the rear
near the heat exchanger. The materials used on this appliance
are remarked by the symbol
cyclable.
ENGLISH
7
CONTROL PANEL
1
8
7
6
5
4
3
2
2.
1 Display
6 Top Compartment Temperature
Press the ON/OFF button if the display is off.
3. If "dEMo" appears on the display, the
appliance is in demonstration mode.
Refer to "What to do if...".
4. The temperature indicators show the
set default temperature.
To select a different set temperature refer
to "Temperature regulation".
7 Top Compartment Temperature cold-
SWITCHING OFF
2 Bottom Compartment Temperature
warmer button
3 Bottom Compartment Temperature
colder button
4 Alarm button
5 Light button
warmer button
er button
8 Appliance ON/OFF button
It is possible to change predefined sound
of buttons to a loudly one by pressing together Light button and Temperature
colder button for some seconds. Change
is reversible.
DISPLAY
1
2
TEMPERATURE REGULATION
3
min
5
To switch off the appliance do these
steps:
1. Press the ON/OFF button for 5 seconds.
2. The display switches off.
3. To disconnect the appliance from the
power disconnect the mains plug
from the power socket.
4
1 Top Compartment indicator
2 Top Compartment temperature indi-
cator and timer indicator
3 Bottom Compartment temperature
indicator
4 Bottom Compartment indicator
5 Alarm indicator
SWITCHING ON
To switch on the appliance do these
steps:
1. Connect the mains plug to the power
socket.
The set temperature of the wine cellar
may be adjusted by pressing the temperature regulators.
The temperature indicators show the set
temperature.
The set temperature will be reached within 24 hours.
Refer to "Daily use - Wine Arrangement".
After a power failure the set temperature remains stored.
LIGHT BUTTON
If you want to maintain the light on with
the door closed, it is sufficient to open
and close the door and the light will remain ON automatically for 10 minutes.
If you want to switch off the light before
the automatic turn off time, open the
door and press the light button.
8
The light has no negative effect on the
quality on the wine.
DOOR OPEN ALARM
An acoustic alarm will sound if the door is
left open for a few minutes. The door
open alarm conditions are indicated by:
• flashing Alarm indicator
• acoustic buzzer
When normal conditions are restored
(door closed), the alarm will stop.
During the alarm, the buzzer can be
switched off by pressing any button.
ENGLISH
9
DAILY USE
CLEANING THE INTERIOR
Before using the appliance for the first
time, wash the interior and all internal accessories with lukewarm water and some
neutral soap so as to remove the typical
smell of a brand-new product, then dry
thoroughly.
If “dEMo” appears on the Display, the appliance is in demonstration mode: refer to
“WHAT TO DO IF...” paragraph.
Do not use detergents or abrasive
powders, as these will damage
the finish.
WINE ARRANGEMENT
Top Compartment:
The temperature can be adjusted between +6 and + 11°C. This compartment
is ideal for wines, especially new reds and
whites, to be consumed immediately. Operation compartments with differentiated
temperatures.
Bottom Compartment:
The temperature can be adjusted between + 11 and + 18°C. This compartment is ideal for storing and refining red
or white wines for long periods.
The temperatures of this compartment
are suitable for storing aged and full-bodied wines.
Lay the bottles down in such a way that
the corks do not dry.
Keep the wine in the dark. The door is in
anti-UV darkened double glass to protect
the wine from the light in case the refrigerator is located in a well-lit place.
Avoid switching the appliance light on too
often or for too long. Wine keeps better
in the dark.
Handle the bottles with care, to avoid agitating the wine.
Follow the recommendations and advice
received at the time of purchase or given
in the technical documentation regarding
the quality, duration and optimum storage temperature of the wine.
STORAGE ADVICE
The storage time for wine depends on
ageing, the type of grapes, alcoholic content and level of fructose and tannin contained in it.At the time of purchase, check
if the wine is already aged or if it will improve over time.
Recommended storage temperatures:
• For champagne and sparkling wines,
between 6 and 8°C
• For white wines, between 10 and 12°C
• For rose’ and light red wines, between
12 and 16°C
• Aged red wines, 14 -16°C
10
When placing various bottles on top of
each other, make sure they do not touch
the refrigerator cooling plate.
WINE CELLAR SHELVES
Remove the shelves for cleaning.
WINE CELLAR BOTTLE HOLDER
Remove the shelf and insert it between
the two guides.
The maximum possible weight on the
bottle shelves is 30 kg.
The bottom compartment is fitted with a
basket useful for placing upright and sloping bottles.
ENGLISH
11
HUMIDIFIER
The right humidity is vitally important for
the proper storage of wine.
Your Wine Cellar is fitted with a special
humidifying device that increases the humidity inside the appliance.
Spread out the lava stones provided
along the small tray as show in the picture. Then fill the tray with water up to the
half of its capacity.
In normal operation, the lava stones are
regularly humidified by the water, periodically check at water present inside the tray
and refill it when needed.
Note that if the humidity in the area in
which your appliance is installed is particularly high, the interior of your Wine Cellar
will also be relatively more humid.
This may result in bottles misting up when
the door is opened or labels peeling off.
In this case reduce the quantity of water in
the tray accordingly.
AIR CIRCULATION
The refrigerator compartment has a special AIRLIGHT fan which is automatically
activated in function of the appliance
thermostat setting and ambient conditions.
12
CARE AND CLEANING
CAUTION!
Unplug the appliance before carrying out any maintenance operation.
This appliance contains hydrocarbons in its cooling unit; maintenance and recharging must therefore only be carried out by authorized technicians.
PERIODIC CLEANING
The equipment has to be cleaned regularly:
• clean the inside and accessories with
lukewarm water and some neutral soap.
• regularly check the door seals and wipe
clean to ensure they are clean and free
from debris.
• rinse and dry thoroughly.
Clean the condenser (black grill) and the
compressor at the back of the appliance
with a brush. This operation will improve
the performance of the appliance and
save electricity consumption.
Take care of not to damage the
cooling system.
Many proprietary kitchen surface cleaners
contain chemicals that can attack/damage
the plastics used in this appliance. For this
reason it is recommended that the outer
casing of this appliance is only cleaned
with warm water with a little washing-up
liquid added.
After cleaning, reconnect the equipment
to the mains supply.
Do not pull, move or damage any
pipes and/or cables inside the
cabinet.
Never use detergents, abrasive
powders, highly perfumed cleaning products or wax polishes to
clean the interior as this will damage the surface and leave a strong
odour.
DEFROSTING OF THE REFRIGERATOR
Frost is automatically eliminated from the
evaporator of the refrigerator compartment every time the motor compressor
stops, during normal use. The defrost water drains out through a trough into a special container at the back of the appliance, over the motor compressor, where
it evaporates.
Periodically clean the defrost water drain
hole in the middle of the refrigerator
compartment channel to prevent the water overflowing and dripping onto the
food inside. Use the special cleaner provided, which you will find already inserted
into the drain hole.
PERIODS OF NONOPERATION
When the appliance is not in use for long
periods, take the following precautions:
• disconnect the appliance from electricity supply
• remove all food
ENGLISH
• defrost (if foreseen) and clean the appliance and all accessories
• leave the door/doors ajar to prevent
unpleasant smells.
If the cabinet will be kept on, ask somebody to check it once in a while to prevent the food inside from spoiling in case
of a power failure.
13
14
WHAT TO DO IF…
WARNING!
Before troubleshooting, disconnect the mains plug from the
mains socket.
Only a qualified electrician or
competent person must do the
troubleshooting that is not in this
manual.
Problem
Possible cause
Solution
The appliance does
not operate. The
lamp does not operate.
The appliance is switched
off.
Switch on the appliance.
The mains plug is not connected to the mains socket correctly.
Connect the mains plug to
the mains socket correctly.
The appliance has no
Connect a different electripower. There is no voltage cal appliance to the mains
in the mains socket.
socket.
Contact a qualified electrician.
The lamp does not
work.
The compressor operates continually.
The lamp is in stand-by.
Close and open the door.
The lamp is defective.
Refer to "Replacing the
lamp".
The temperature is not set Set a higher temperature.
correctly.
The door is not closed cor- Refer to "Closing the
rectly.
door".
The door has been
opened too frequently.
Do not keep the door open
longer than necessary.
The product temperature
is too high.
Let the product temperature decrease to room temperature before storage.
The room temperature is
too high.
Decrease the room temperature.
Water flows on the
rear plate of the appliance.
During the automatic defrosting process, frost defrosts on the rear plate.
This is correct.
Water flows into the
appliance.
The water outlet is clogged.
Clean the water outlet.
Products prevent that water flows into the water
collector.
Make sure that products do
not touch the rear plate.
ENGLISH
Problem
Possible cause
Solution
Water flows on the
ground.
The melting water outlet
does not flow in the evaporative tray above the
compressor.
Attach the melting water
outlet to the evaporative
tray.
The temperature in
the appliance is too
low.
The temperature regulator Set a higher temperature.
is not set correctly.
The temperature in
the appliance is too
high.
The temperature regulator Set a lower temperature.
is not set correctly.
15
The door is not closed cor- Refer to "Closing the
rectly.
door".
Many bottles are stored at
the same time.
Store less bottles at the
same time.
There is no cold air circula- Make sure that there is cold
tion in the appliance.
air circulation in the appliance.
dEMo appears on the The appliance is in demDisplay.
onstration mode (dEMo)
Keep pressed approximately 10sec the Alarm button
since a long sound of buzzer is heard and the Display
shut off for a short while:
appliance start works regularly.
Upper or lower
square is shown in
the temperature Display.
Call your service representative (the cooling system
will continue to keep food
products cold, but temperature adjustment will not be
possible).
An error has occurred in
measuring the temperature.
REPLACING THE LAMP WINE
CELLAR
Disconnect the mains plug from the mains
socket.
Remove the lamp cover by pressing it inwards with a tool (e.g. screwdriver) to free
the rear side hookings.
16
At the same time, free the middle hook
and slide off the cover in the direction of
the arrows.
Replace the used lamp with a new lamp of
the same type and specifically designed
for household appliances and having the
same characteristics.
Install the lamp cover.
Connect the mains plug to the mains
socket.
Open the door. Make sure that the lamp
comes on.
CLOSING THE DOOR
1.
2.
Clean the door gaskets.
If necessary, adjust the door. Refer to
"Installation".
3. If necessary, replace the defective
door gaskets. Contact the Service
Center.
ENGLISH
17
INSTALLATION
POSITIONING
A
B
WARNING!
If you are discarding an old appliance that has a lock or catch on
the door, you must ensure that it
is made unusable to prevent
young children being trapped inside.
The appliance shall have the plug
accessible after installation.
Install this appliance at a location where
the ambient temperature corresponds to
the climate class indicated on the rating
plate of the appliance:
Climate
class
Ambient temperature
SN
+10°C to + 32°C
N
+16°C to + 32°C
ST
+16°C to + 38°C
T
+16°C to + 43°C
ELECTRICAL CONNECTION
CAUTION!
Any electrical work required to install this appliance should be carried out by a qualified electrician
or competent person.
WARNING!
This appliance must be earthed.
The manufacturer declines any liability should these safety measures not be observed.
C
E
D
The wires in the mains lead are
coloured in accordance with the
following code:
A Green and Yellow:
Earth
C Brown:
Live
E Blue:
Neutral
As the colours of the wires in the mains
lead of this appliance may not correspond
with the coloured markings identifying the
terminals in your plug, proceed as follows:
1. Connect the wire coloured green and
yellow to the terminal marked either
with the letter “E“ or by the earth
or coloured green and yelsymbol
low.
2. Connect the wire coloured blue to
the terminal either marked with the
letter “N“ or coloured black.
3. Connect the wire coloured brown to
the terminal either marked with the
“L“ or coloured red.
4. Check that no cut, or stray strands of
wire is present and the cord clamp D
is secure over the outer sheath.
5. Make sure the electricity supply voltage is the same as that indicated on
the appliance rating plate.
6. Switch on the appliance.
The appliance is supplied with a 13 amp
plug fitted B. In the event of having to
change the fuse in the plug supplied, a 13
18
amp ASTA approved (BS 1362) fuse must
be used.
WARNING!
A cut off plug inserted into a 13
amp socket is a serious safety
(shock) hazard. Ensure that it is
disposed of safely.
VENTILATION REQUIREMENTS
5 cm
The airflow behind the appliance must be
sufficient.
min.
200 cm2
min.
200 cm2
INSTALLING THE APPLIANCE
Do the following steps:
CAUTION!
Make sure that the mains cable
can move freely.
Apply the adhesive sealing strip to the appliance as shown in figure.
ENGLISH
Install the appliance in the niche.
Attach the appliance to the niche with 4
screws.
Fix the covers on the screws.
Do a final check to make sure that:
• All screws are tightened.
19
20
• The sealing strip is attached tightly to
the cabinet.
• The door opens and closes correctly.
ASSEMBLY INSTRUCTIONS FOR THE COMPENSATOR LOWER
PART OF THE DOOR
With the door open, loosen the two
screws situated in the lower part without unscrewing them completely.
Position the steel compensator as indicated in the figure and insert the upper
part under the head of the screws.
Align the compensator with the steel
door panel and tighten the screws.
Insert the steel carter inside the compensator as indicated in the figure.
ENGLISH
21
NOISES
There are some sounds during normal
running (compressor, refrigerant circulation).
SSS
RRR
!
HISSS!
OK
BRRR!
!
BB
U
BL
CLICK!
BRRR!
BLUBB!
!
ICK
CL
CR
AC
K!
CLICK!
BRRR!
BLUBB!
22
HISSS!
HISSS!
SSSRRR!
SSSRRR!
CRACK!
CRACK!
TECHNICAL DATA
Dimension of the recess
Height
1780 mm
Width
560 mm
Depth
550 mm
Voltage
230-240 V
Frequency
50 Hz
The technical information are situated in
the rating plate on the internal left side of
the appliance and in the energy label.
ENGLISH
23
www.aeg.com/shop
222354131-A-412011

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
