IKEA KULINARISK 70322040 User Manual

AU
KULINARISK
ENGLISH
4
4
ENGLISH
Contents
Safety information
Conditions of Use
Safety instructions
Installation
Product description
Control panel
Before first use
Daily use
Clock functions
Automatic programmes
4
5
6
8
9
9
11
12
17
19
Using the accessories
Additional functions
Hints and tips
Care and cleaning
Troubleshooting
Technical information
Energy efficiency
ENVIRONMENT CONCERNS
IKEA GUARANTEE
19
21
23
23
27
29
29
30
31
Subject to change without notice.
Safety information
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible if
an incorrect installation and use causes injuries and damages.
Always keep the instructions with the appliance for future
reference.
Children and vulnerable people safety
•
•
•
•
•
•
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
Do not let children play with the appliance.
Keep all packaging away from children.
Keep children and pets away from the appliance when it
operates or when it cools down. Accessible parts are hot.
If the appliance has a child safety device, we recommend you
activate it.
Cleaning and user maintenance shall not be made by
children without supervision.
ENGLISH
•
5
Children of less than 3 years should be kept away unless
continuously supervised.
General Safety
•
•
•
•
•
•
•
•
•
•
Only a qualified person must install this appliance and
replace the cable.
Internally the appliance becomes hot when in operation. Do
not touch the heating elements that are in the appliance.
Always use oven gloves to remove or put in accessories or
ovenware.
Before maintenance cut the power supply.
Ensure that the appliance is switched off before replacing the
lamp to avoid the possibility of electric shock.
Do not use a steam cleaner to clean the appliance.
Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the glass door since they can scratch the surface,
which may result in shattering of the glass.
If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
To remove the shelf supports first pull the front of the shelf
support and then the rear end away from the side walls.
Install the shelf supports in the opposite sequence.
The means for disconnection must be incorporated in the
fixed wiring in accordance with the wiring rules.
Only use the core temperature sensor recommended for this
appliance.
Conditions of Use
This appliance is intended to be used in
household and similar applications such as:
• Farm houses
• By clients in serviced apartments, holiday
apartments and other residential type
environments.
6
ENGLISH
Safety instructions
Installation
Warning! Only a qualified
person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Obey the installation instruction supplied
with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Do not pull the appliance by the handle.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is installed
below and adjacent safe structures.
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
Electrical connection
Warning! Risk of fire and
electrical shock.
• All electrical connections should be made
by a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical information
on the rating plate agrees with the
power supply. If not, contact an
electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Should the mains cable need to be
replaced, this must be carried out by our
Authorised Service Centre.
• Do not let mains cables touch or come
near the appliance door, especially
when the door is hot.
• The shock protection of live and
insulated parts must be fastened in such
a way that it cannot be removed without
tools.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains
plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
Use
Warning! Risk of injury, burns
and electrical shock or explosion.
• Use this appliance in a household only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended
during operation.
• Deactivate the appliance after each use.
• Be careful when you open the appliance
door while the appliance is in operation.
Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not apply pressure on the open door.
7
ENGLISH
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully. The
use of ingredients with alcohol can cause
a mixture of alcohol and air.
• Do not let sparks or open flames to come
in contact with the appliance when you
open the door.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
Warning! Risk of damage to the
appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other objects
in the appliance directly on the
bottom.
– do not put aluminium foil directly on
the bottom of the appliance.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food in
the appliance after you finish the
cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel has no effect
on the performance of the appliance. It is
not a defect in the sense of the warranty
law.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
• Always cook with the oven door closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure
the door is never closed when the
appliance is in operation. Heat and
moisture can build up behind a closed
furniture panel and cause subsequent
damage to the appliance, the housing
unit or the floor. Do not close the
furniture panel until the appliance has
cooled down completely after use.
Steam Cooking
Warning! Risk of burns and
damage to the appliance.
• Released Steam can cause burns:
– Do not open the appliance door
during the steam cooking operation.
– Open the appliance door with care
after the steam cooking operation.
Care and Cleaning
Warning! Risk of injury, fire, or
damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
• Make sure the appliance is cold. There is
a risk that the glass panels can break.
• Replace immediately the door glass
panels when they are damaged. Contact
the Authorised Service Centre.
• Be careful when you remove the door
from the appliance. The door is heavy!
• Clean regularly the appliance to prevent
the deterioration of the surface material.
• Remaining fat or food in the appliance
can cause fire.
• If you use an oven spray, obey the safety
instructions on the packaging.
Internal light
• The type of light bulb or halogen lamp
used for this appliance is only for
household appliances. Do not use it for
house lighting.
Warning! Risk of electrical shock.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
ENGLISH
Disposal
Warning! Risk of injury or
suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children and
pets to get closed in the appliance.
• Packaging material:
The packaging material is
environmentally-friendly and recyclable.
8
Plastic parts are marked with
international abbreviations such as PE,
PS, etc. Dispose of the packaging
material in the containers provided for
this purpose at your local waste
management facility.
Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
Installation
Warning! Refer to Safety
chapters.
Assembly
Refer to the Assembly Instructions
for the installation.
Electrical installation
Warning! Only a qualified
person must do the electrical
installation.
The manufacturer is not
responsible if you do not follow
the safety precautions from the
Safety chapters.
This appliance is supplied without a main
plug and a main cable.
Cable
Cable types applicable for installation or
replacement:
H07 RN-F, H05 RN-F, H05 RRF, H05 VV-F,
H05 V2V2-F (T90), H05 BB-F
For the section of the cable refer to the total
power on the rating plate. You can also
refer to the table:
Total power (W)
Section of the cable
(mm²)
maximum 1380
3 x 0.75
maximum 2300
3x1
maximum 3680
3 x 1.5
The earth cord (green / yellow cable) must
be 2 cm longer than phase and neutral
cables (blue and brown cables).
ENGLISH
9
Product description
General overview
1
2
4
5
13
12
11
10
1
2
3
4
5
6
7
8
9
10
11
12
13
3
5
4
3
3
2
1
6
7
9
8
Control panel
Electronic programmer
Water drawer
Socket for the core temperature sensor
Grill
Lamp
Fan
Shelf support, removable
Draining pipe
Water outlet valve
Rating plate
Shelf positions
Steam inlet
• Core temperature sensor x 1
To measure how far the food is cooked.
• Telescopic runners x 2 sets
For shelves and trays.
Accessories
• Wire shelf x 2
For cookware, cake tins, roasts.
• Baking tray x 1
For cakes and biscuits.
• Grill- / Roasting pan x 1
To bake and roast or as pan to collect
fat.
Control panel
Electronic programmer
1
2 3 4
5
6
7 8 9 10 11
ENGLISH
10
Symbol
1
3
4
5
7
8
9
10
11
Comment
To activate and deactivate the appliance.
Heating Functions Touch the symbol once to choose a heating funcor Assisted Cook- tion or the menu: Assisted Cooking. Touch the syming
bol again to switch between the menus: Heating
Functions, Assisted Cooking. To activate or deactivate the light, touch the symbol for 3 seconds.
2
6
Function
ON / OFF
-
Back key
To go back one level in the menu. To show the
main menu, touch the symbol for 3 seconds.
Temperature selection
To set the temperature or show the current temperature in the appliance. Touch the symbol for 3
seconds to activate or deactivate the function: Fast
heat up.
Favourites
To save and access your favourite programmes.
Display
Shows the current settings of the appliance.
Up key
To move up in the menu.
Down key
To move down in the menu.
Time and additional functions
To set different functions. When a heating function
operates, touch the symbol to set the timer or the
functions: Function Lock, Favourites, Heat + Hold,
Set + Go. You can also change the settings of the
core temperature sensor.
Minute Minder
To set the function: Minute Minder.
OK
To confirm the selection or setting.
ENGLISH
11
Display
A
B
C
E
D
A)
B)
C)
D)
E)
Heating function
Time of day
Heat-up indicator
Temperature
Duration time or end time of a function
Other indicators of the display:
Symbol
Function
Minute Minder
The function operates.
Time of day
The display shows the current time.
Duration
The display shows the necessary time
for cooking.
End Time
The display shows when the cooking
time is complete.
Temperature
The display shows the temperature.
Time Indication
The display shows how long the heating function operates. Press and
at the same time to reset the time.
Calculation
The appliance calculates the time for
cooking.
Heat-up Indicator
The display shows the temperature in
the appliance.
Fast Heat Up Indicator
The function is active. It decreases the
heat up time.
Weight Automatic
The display shows that the automatic
weight system is active or that weight
can be changed.
Heat + Hold
The function is active.
Before first use
Warning! Refer to Safety
chapters.
ENGLISH
Initial Cleaning
Remove all accessories and removable shelf
supports from the appliance.
Refer to "Care and cleaning"
chapter.
Clean the appliance before first use.
Put the accessories and the removable shelf
supports back to their initial position.
First Connection
12
smoke. This is normal. Make sure that the
airflow in the room is sufficient.
Using the Mechanical child lock
The appliance has the child lock installed
and activated. It is below the control panel
on the right side.
To open the oven door with the child lock
installed, pull the child lock handle up as
shown in the picture.
When you connect the appliance to the
mains or after the power cut, you have to
set the language, the display contrast, the
display brightness and the time of the day.
1. Press
2. Press
or to set the value.
to confirm.
Preheating
Preheat the empty appliance before first
use.
1. Set the function: Top/Bottom Heat
and the maximum temperature.
2. Let the appliance operate for 1 hour.
3. Set the function: True Fan Cooking
and the maximum temperature.
4. Let the appliance operate for 15
minutes.
Accessories can become hotter than usual.
The appliance can emit an odour and
Close the oven door without pulling the
child lock.
To remove the child lock, open the oven
door and remove the child lock with the torx
key. The torx key is in the oven fitting bag.
Screw back the screw into the hole after
removing the child lock.
Daily use
Warning! Refer to Safety
chapters.
Navigating the menus
1. Activate the appliance.
2. Press or to select the menu option.
3. Press
to move to the submenu or
accept the setting.
At each point you can go back to
the main menu with .
ENGLISH
13
The menus in overview
Main menu
Symbol
Menu item
Application
Heating Functions
Contains a list of heating functions.
Assisted Cooking
Contains a list of automatic programmes.
Favourites
Contains a list of favourite cooking programmes
created by the user.
Basic Settings
You can use it to set other settings.
Specials
Contains a list of additional heating functions.
Submenu for: Basic Settings
Symbol
Submenu
Description
Set Time of Day
Sets the current time on the clock.
Time Indication
When ON, the display shows the current time
when you deactivate the appliance.
Set + Go
When ON, in the Select Options window you can
choose the function: Set + Go.
Heat + Hold
When ON, in the Select Options window you can
choose the function: Heat + Hold.
Time Extension
Activates and deactivates the time extension
function.
Display Contrast
Adjusts the display contrast by degrees.
Display Brightness
Adjusts the display brightness by degrees.
Set Language
Sets the language for the display.
Buzzer Volume
Adjusts the volume of press-tones and signals by
degrees.
Key Tones
Activates and deactivates the tone of the touch
fields. It is not possible to deactivate the tone of
the ON / OFF touch field.
Alarm/Error Tones
Activates and deactivates the alarm tones.
ENGLISH
14
Symbol
Submenu
Description
Service
Shows the software version and configuration.
Factory Settings
Resets all settings to factory settings.
Heating Functions
Heating function
Application
True Fan Cooking
To bake on up to 3 shelf positions at the same
time and to dry food. Set the temperature 20 - 40
°C lower than for the function: Top/Bottom Heat.
True Fan + Steam
To steam dishes. Use this function to decrease the
length of the cooking time and to preserve the vitamins and nutrients in the food. Select the function and set the temperature between 130 °C to
230 °C.
Top/Bottom Heat
To bake and roast food on 1 shelf position.
Pizza Setting
To cook pizza, quiche or pie with steam.
Slow Cooking
To prepare tender, succulent roasts.
Bottom Heat
To bake cakes with crispy bottom and to preserve
food.
Moist Fan Baking
To save energy when you bake and cook dry
baked goods. Also to bake baked goods in tins
on 1 shelf position. This function was used to define the energy efficiency class acc. EN50304.
It is necessary to set the cooking time first. To get
more information about the recommended settings, refer to the cooking table for this function in
the Recipe Book.
ECO Roasting
The ECO functions let you optimize the energy
consumption during cooking. It is necessary to set
the cooking time first. To get more information
about the recommended settings, refer to the
roasting tables in the recipe book.
ENGLISH
15
Heating function
Application
Frozen Foods
To make your convenience food like e.g. French
Fries, Wedges, spring rolls crispy.
Grilling
To grill flat food and to toast bread.
Fast Grilling
To grill flat food in large quantities and to toast
bread.
Turbo Grilling
To roast larger meat joints or poultry with bones
on 1 shelf position. Also to make gratins and to
brown.
Steam Regenerating
To reheat already cooked food directly on a
plate.
Specials
Heating function
Application
Bread Baking
To bake bread.
Au Gratin
For dishes such as lasagna or potato gratin. Also
to gratinate and brown.
Dough Proving
For controlled rising of yeast dough before baking.
Plate Warming
To preheat your plate for serving.
Preserving
To make vegetable preserves such as pickles.
Drying
To dry sliced fruit (e.g. apples, plums, peaches)
and vegetables (e.g. tomatoes, zucchini, mushrooms).
Keep Warm
To keep food warm.
Defrost
To defrost frozen food.
16
ENGLISH
Activating a heating function
1.
2.
3.
4.
5.
6.
7.
Activate the appliance.
Select the menu: Heating Functions.
Press
to confirm.
Set a heating function.
Press
to confirm.
Set the temperature.
to confirm.
Press
Steam cooking
The water drawer cover is in the control
panel.
Warning! Use only water. Do not
use filtered (demineralised) or
distilled water. Do not use other
liquids. Do not put flammable or
alcoholic liquids into the water
drawer.
1. Prepare the food in the correct
cookware.
2. Press the cover of the water drawer to
open it.
3. Fill the water drawer with 900 ml of
water.
The water supply is sufficient for
approximately 55 - 60 minutes.
4. Push the water drawer to its initial
position.
5. Activate the appliance.
6. Select a steam heating function and the
temperature.
7. If necessary, set the function Duration
or End Time
.
When the steam generator is
empty, an acoustic signal sounds.
The signal sounds at the end of the cooking
time.
8. Deactivate the appliance.
9. Empty the water drawer after the steam
cooking is completed.
Caution! The appliance is
hot. There is a risk of burns.
Be careful when you empty
the water drawer.
Let the appliance dry fully with the door
open.
Warning! Wait a minimum of 60
minutes after each use of the
steam cooking in order to
prevent hot water from exiting
the water outlet valve.
Tank Empty indicator
The display shows: Water required and an
acoustic signal sounds when the tank is
empty and must be refilled.
For more information refer to "Steam
Cooking".
Tank Full indicator
When the display shows: Water tank full,
you can use the steam cooking.
An acoustic signal sounds when the tank is
full.
If you put too much water into
the tank, the safety outlet moves
the excess water to the bottom of
the oven.
Remove the water with a sponge
or cloth.
Emptying the water tank
Caution! Make sure that the
appliance is cool before you start
to empty the water tank.
1. Prepare the draining pipe (C), included
in the same package with the user
manual. Put the connector (B) onto one
of the ends of the draining pipe.
ENGLISH
17
A
B
C
5. Remove the connector from the valve
when the water stops flowing.
Do not use the drained water to
fill the water tank again.
Heat-up indicator
When you activate a heating function, the
bar on the display comes on. The bar shows
that the temperature increases.
Fast Heat Up Indicator
2. Put the second end of the draining pipe
(C) into a container. Put it at a lower
position than the outlet valve (A).
3. Open the oven door and put the
connector (B) into the outlet valve (A).
4. Push the connector again and again
when you empty the water tank.
The tank can have some
water when the display
shows: Water required.
Wait until the water flow from
the water outlet valve stops.
This function decreases the heat-up time.
for 3
To activate the function, hold
seconds. The heat-up indicator alternates.
Residual heat
When you deactivate the appliance, the
display shows the residual heat. You can
use the heat to keep the food warm.
Clock functions
Clock functions table
Clock function
Minute Minder
Application
To set a countdown (max. 2 h 30 min). This
function has no effect on the operation of the
appliance.
Use
to activate the function. Press
to set the minutes and
or
to start.
Duration
To set the length of an operation (max. 23 h
59 min).
End Time
To set the switch-off time for a heating function (max. 23 h 59 min).
If you set the time for a clock function, the
time starts to count down after 5 seconds.
18
ENGLISH
If you use the clock functions:
Duration, End Time, the
appliance deactivates the
heating elements after 90 % of
the set time. The appliance uses
the residual heat to continue the
cooking process until the time
ends (3 - 20 minutes).
Setting the clock functions
• Before you use the functions:
Duration, End Time, you must
set a heating function and
temperature first. The
appliance deactivates
automatically.
• You can use the functions:
Duration and End Time at the
same time if you want to
automatically activate and
deactivate the appliance on a
given time later.
• The functions: Duration and
End Time do not work when
you use the core temperature
sensor.
1. Set a heating function.
again and again until the
2. Press
display shows the necessary clock
function and the related symbol.
3. Press or to set the necessary time.
to confirm.
4. Press
When the time ends, an acoustic signal
sounds. The appliance deactivates. The
display shows a message.
5. Press any symbol to stop the signal.
Heat + Hold
Conditions for the function:
• The set temperature is more than 80 °C.
• The function: Duration is set.
The function: Heat + Hold keeps prepared
food warm at 80 °C for 30 minutes. It
activates after the baking or roasting
procedure ends.
You can activate or deactivate the function
in the menu: Basic Settings.
1.
2.
3.
4.
Activate the appliance.
Select the heating function.
Set the temperature above 80 °C.
Press
again and again until the
display shows: Heat + Hold.
5. Press
to confirm.
When the function ends, an acoustic signal
sounds.
The function stays on if you change the
heating functions.
Time Extension
The function: Time Extension makes the
heating function continue after the end of
Duration.
Applicable to all heating
functions with Duration or Weight
Automatic.
Not applicable to heating
functions with the core
temperature sensor.
1. When the cooking time ends, an
acoustic signal sounds. Press any
symbol.
The display shows the message.
to activate or to cancel.
2. Press
3. Set the length of the function.
4. Press
.
ENGLISH
19
Automatic programmes
Warning! Refer to Safety
chapters.
Recipes online
You can find the recipes for the
automatic programmes specified
for this appliance on the website
www.ikea.com. To find the
proper Recipe Book check the
article number on the rating
plate on the front frame of the
appliance cavity.
Assisted Cooking with Recipe Automatic
This appliance has a set of recipes you can
use. The recipes are fixed and you cannot
change them.
1. Activate the appliance.
2. Select the menu: Assisted Cooking. Press
to confirm.
3. Select the category and dish. Press
to confirm.
to confirm.
4. Select a recipe. Press
When you use the function:
Manual, the appliance uses the
automatic settings. You can
change them as with other
functions.
Assisted Cooking with Weight Automatic
This function automatically calculates the
roasting time. To use it, it is necessary to
input the food weight.
1. Activate the appliance.
2. Select the menu: Assisted Cooking. Press
to confirm.
3. Select the category and dish. Press
to confirm.
4. Select the function: Weight Automatic.
Press
to confirm.
5. Touch or to set the food weight.
to confirm.
Press
The automatic programme starts.
6. You can change the weight at any time.
Press or to change the weight.
7. When the time ends, an acoustic signal
sounds. Press any symbol to deactivate
the signal.
With some programmes turn over
the food after 30 minutes. The
display shows a reminder.
Using the accessories
Warning! Refer to Safety
chapters.
Core temperature sensor
There are two temperatures to be set: the
oven temperature and the core
temperature.
The core temperature sensor measures the
core temperature of the meat. When the
meat is at the set temperature, the
appliance deactivates.
20
ENGLISH
Caution! Only use the core
temperature sensor supplied or
the correct replacement parts.
The core temperature sensor
must stay in the meat and in the
socket during the cooking.
1. Activate the appliance.
2. Put the tip of the core temperature
sensor into the centre of the meat.
3. Put the plug of the core temperature
sensor into the socket at the top of the
cavity.
When the meat is at the set core
temperature, an acoustic signal sounds. The
appliance deactivates automatically.
7. Touch any symbol to stop the signal.
8. Remove the core temperature sensor
plug from the socket and remove the
meat from the oven.
Warning! The core temperature
sensor is hot. There is a risk of
burns. Be careful when you
remove the tip and the plug of
the core temperature sensor.
Using the telescopic runners
Keep the installation instructions
for the telescopic runners for
future use.
With telescopic runners you can put in and
remove the shelves more easily.
Caution! Do not clean the
telescopic runners in the
dishwasher. Do not lubricate the
telescopic runners.
1
2
°C
The display shows the core temperature
sensor symbol.
4. Press or in less than 5 seconds to set
the core temperature.
5. Set the heating function and, if
necessary, the oven temperature.
The appliance calculates an approximate
end time. The end time is different for the
different quantities of the food, the set oven
temperatures (minimum 120 °C) and the
operating modes. The appliance calculates
the end time in approximately 30 minutes.
6. To change the core temperature, press
.
Pull out the right
and left hand
telescopic runners.
°C
Put the wire shelf on
the telescopic
runners and
carefully push them
into the appliance.
Make sure you push back the telescopic
runners fully in the appliance before you
close the oven door.
21
ENGLISH
You can also use the telescopic
runners with the trays or pans
supplied with the appliance.
Warning! Refer to
"Product description"
chapter.
Additional functions
Favourites
Activating the programme
You can save your favourite settings, such
as duration, temperature or heating
function. They are available in the menu:
Favourites. You can save 20 programmes.
1.
2.
3.
4.
5.
Saving a programme
1. Activate the appliance.
2. Set a heating function or an automatic
programme.
3. Touch
again and again until the
display shows: SAVE.
4. Press
to confirm.
The display shows the first free memory
position.
to confirm.
5. Press
6. Enter the name of the programme.
The first letter flashes.
7. Touch or to change the letter.
8. Press
.
The next letter flashes.
9. Do step 7 again as necessary.
to save.
10. Press and hold
You can overwrite a memory position.
When the display shows the first free
memory position, touch
or
and press
to overwrite an existing programme.
You can change the name of a programme
in the menu: Edit Programme Name.
Activate the appliance.
Select the menu: Favourites.
Press
to confirm.
Select your favourite programme name.
Press
to confirm.
Press
to go directly to menu: Favourites.
Using the Child Lock
The Child Lock prevents an accidental
operation of the appliance.
1. Activate the appliance.
2. Touch
and
at the same time until
the display shows a message.
To deactivate the Child Lock function repeat
step 2.
Function Lock
This function prevents an accidental change
of the heating function. You can activate it
only when the appliance operates.
1. Activate the appliance.
2. Set a heating function or setting.
again and again until the
3. Press
display shows: Function Lock.
4. Press
to confirm.
To deactivate the function, press
. The
display shows a message. Press
again
and then
to confirm.
22
ENGLISH
When you deactivate the
appliance, the function also
deactivates.
Set + Go
The function lets you set a heating function
(or a programme) and use it later with one
press of any symbol.
1. Activate the appliance.
2. Set a heating function.
3. Press
again and again until the
display shows: Duration.
4. Set the time.
again and again until the
5. Press
display shows: Set + Go.
6. Press
to confirm.
Press any symbol (except for ) to start the
function: Set + Go. The set heating function
starts.
When the heating function ends, an acoustic
signal sounds.
• Function Lock is on when the
heating function operates.
• The menu: Basic Settings lets
you activate and deactivate
the function: Set + Go.
Automatic Switch-off
For safety reasons the appliance
deactivates automatically after some time if
a heating function operates and you do not
change any settings.
Temperature (°C)
Switch-off time (h)
30 - 115
12.5
120 - 195
8.5
200 - 245
5.5
Temperature (°C)
250 - maximum
Switch-off time (h)
1.5
The Automatic switch-off does
not work with the functions: Light,
core temperature sensor, End
Time, Duration.
Brightness of the display
There are two modes of display brightness:
• Night brightness - when the appliance is
deactivated, the brightness of the
display is lower between 10 PM and 6
AM.
• Day brightness:
– when the appliance is activated.
– if you touch a symbol during the
night brightness (apart from ON /
OFF), the display goes back to the
day brightness mode for the next 10
seconds.
– if the appliance is deactivated and
you set the function: Minute Minder.
When the function ends, the display
goes back to the night brightness.
Cooling fan
When the appliance operates, the cooling
fan activates automatically to keep the
surfaces of the appliance cool. If you
deactivate the appliance, the cooling fan
can continue to operate until the appliance
cools down.
Safety thermostat
Incorrect operation of the appliance or
defective components can cause dangerous
overheating. To prevent this, the oven has a
safety thermostat which interrupts the
power supply. The oven activates again
automatically when the temperature drops.
ENGLISH
23
Hints and tips
General information
Baking cakes
• Whenever preheating, remove the wire
shelves and trays from the cavity to have
the fastest performance.
• The appliance has five shelf positions.
Count the shelf positions from the bottom
of the appliance floor.
• The appliance has a special system
which circulates the air and constantly
recycles the steam. With this system you
can cook in a steamy environment and
keep the food soft inside and crusty
outside. It decreases the cooking time
and energy consumption to a minimum.
• Moisture can condense in the appliance
or on the door glass panels. This is
normal. Always stand back from the
appliance when you open the appliance
door while cooking. If you notice
moisture inside of the oven, keep the
door open for a couple of minutes.
• Clean the moisture after each use of the
appliance.
• Do not put the objects directly on the
appliance floor and do not put
aluminium foil on the components when
you cook. This can change the baking
results and cause damage to the enamel.
• Do not open the oven door before 3/4 of
the set cooking time is up.
• If you use two baking trays at the same
time, keep one empty level between
them.
Cooking meat and fish
• Use a deep pan for very fatty food to
prevent the oven from stains that can be
permanent.
• Leave the meat for approximately 15
minutes before carving so that the juice
does not seep out.
• To prevent too much smoke in the oven
during roasting, add some water into the
deep pan. To prevent the smoke
condensation, add water each time after
it dries up.
Cooking tables
For cooking tables please refer to the
Recipe Book which you can find on our
website.
Care and cleaning
Warning! Refer to Safety
chapters.
Notes on cleaning
• Clean the front of the appliance with a
soft cloth with warm water and a
cleaning agent.
• To clean metal surfaces, use a usual
cleaning agent.
• Clean the appliance interior after each
use. Fat accumulation or other food
remains may result in a fire. The risk is
higher for the grill pan.
• Clean stubborn dirt with a special oven
cleaner.
• Clean all accessories after each use and
let them dry. Use a soft cloth with warm
water and a cleaning agent.
• If you have nonstick accessories, do not
clean them using aggressive agents,
sharp-edged objects or a dishwasher. It
can cause damage to the nonstick
coating.
24
ENGLISH
Stainless steel or aluminium appliances
Clean the oven door with a wet
sponge only. Dry it with a soft
cloth.
Do not use steel wool, acids or
abrasive materials as they can
damage the oven surface. Clean
the oven control panel with the
same precautions.
Cleaning the door gasket
• Regularly do a check of the door gasket.
The door gasket is around the frame of
the oven cavity. Do not use the
appliance if the door gasket is
damaged. Contact the Service.
• To clean the door gasket, use a soft cloth
with warm water and a cleaning agent.
Removing the shelf supports
To clean the oven, remove the shelf
supports.
1
2
2
1
Pull the front of the
shelf support away
from the side wall.
Pull the rear end of
the shelf support
away from the side
wall and remove it.
Install the shelf supports in the opposite
sequence.
The retaining pins on the
telescopic runners must point to
the front.
Cleaning the water tank
Warning! Do not put water into
the water tank during the
cleaning procedure.
During the cleaning procedure,
some water can drip from the
steam inlet onto the cavity of the
oven. Put a dripping pan on the
shelf level directly below the
steam inlet to prevent water from
falling onto the bottom of the
oven cavity.
After some time, you can have lime deposits
in your oven. To prevent this, clean the parts
of the oven that generate the steam. Empty
the tank after each steam cooking.
Types of water
• Soft water with low lime content - the
manufacturer recommends this because
it decreases the quantity of cleaning
procedures.
• Tap water - you can use it if your
domestic water supply has purifier or
water sweetener.
• Hard water with high lime content - it
does not have an effect on the
performance of the appliance but it
increases the quantity of cleaning
procedures.
ENGLISH
25
CALCIUM QUANTITY TABLE INDICATED FROM W.H.O. (World Health Organization)
Calcium deposit
Water hardness
(French degrees) (German degrees)
Water classifica- Run decalcification
tion every
0 - 60 mg/l
0-6
0-3
Sweet of soft
75 cycles - 2.5
months
60 - 120 mg/l
6 - 12
3-7
Medium hardness
50 cycles - 2
months
120 - 180 mg/l
12 - 18
8 - 10
Hard or calcare- 40 cycles - 1.5
ous
months
over 180 mg/l
over 18
over 10
Very hard
1. Fill in the water tank with 850 ml of
water and 50 ml of citric acid (five
teaspoons). Deactivate the oven and
wait for approximately 60 minutes.
2. Activate the oven and set the function:
True Fan + Steam. Set the temperature
230 °C. Deactivate it after 25 minutes
and let it cool down for 15 minutes.
3. Activate the oven and set the function:
True Fan + Steam. Set the temperature
between 130 and 230 °C. Deactivate it
after 10 minutes.
Let it cool down and continue with the
removal of the tank contents. Refer to
"Emptying the water tank".
4. Rinse the water tank and clean the
remaining lime residue in the oven with
a cloth.
5. Clean the drain pipe by hand in warm
water with soap. To prevent damage,
do not use acids, sprays or similar
cleaning agents.
Cleaning the oven door
The oven door has three glass panels.You
can remove the oven door and the internal
glass panels to clean them.
30 cycles - 1
month
The oven door can close if you
try to remove the glass panels
before you remove the oven
door.
Caution! Do not use the
appliance without the glass
panels.
1
Open the door fully
and hold the two
door hinges.
2
Lift and turn the
levers on the two
hinges.
26
ENGLISH
When the cleaning is completed, install the
glass panels and the oven door. Do the
above steps in the opposite sequence.
4
3
Close the oven door
halfway to the first
opening position.
Then pull forward
and remove the
door from its seat.
5
Put the door on a
soft cloth on a
stable surface.
Make sure that you put the glass panels (A
and B) back in the correct sequence. The
first panel (A) has a decorative frame. The
screen-printing zone must face the inner
side of the door. Make sure that after the
installation the surface of the glass panel
frame (A) on the screen-printing zones is
not rough when you touch it.
A
B
6
90°
Release the locking
system to remove
the glass panels.
Turn the two
fasteners by 90°
and remove them
from their seats.
7
Make sure that you install the middle panel
of glass in the seats correctly.
1
2
First lift carefully
and then remove
the glass panels one
by one. Start from
the top panel.
Clean the glass panels with water and
soap. Dry the glass panels carefully.
ENGLISH
27
Replacing the lamp
Put a cloth on the bottom of the interior of
the appliance. It prevents damage to the
lamp glass cover and the cavity.
Warning! Danger of
electrocution! Disconnect the fuse
before you replace the lamp.
The lamp and the lamp glass
cover can be hot.
1. Deactivate the appliance.
2. Remove the fuses from the fuse box or
deactivate the circuit breaker.
3. Turn the lamp glass cover
counterclockwise to remove it.
4. Clean the glass cover.
5. Replace the oven light bulb with a 40
W, 220 - 240 V (50 Hz), 300 °C heat
resistant oven light bulb (connection
type: G9).
6. Install the glass cover.
Caution! Always hold the
halogen lamp with a cloth to
prevent grease residue from
burning on the lamp.
Troubleshooting
Warning! Refer to Safety
chapters.
What to do if...
Problem
Possible cause
Remedy
The oven does not heat up.
The oven is deactivated.
Activate the oven.
The oven does not heat up.
The clock is not set.
Set the clock.
The oven does not heat up.
The necessary settings are
not set.
Make sure that the settings
are correct.
The oven does not heat up.
The automatic switch-off is
activated.
Refer to "Automatic switchoff".
The oven does not heat up.
The Child Lock is on.
Refer to "Using the Child
Lock".
The oven does not heat up.
The door is not closed correctly.
Fully close the door.
The oven does not heat up.
The fuse is released.
Make sure that the fuse is
the cause of the malfunction.
If the fuse releases again
and again, contact a qualified electrician.
ENGLISH
Problem
28
Possible cause
Remedy
The lamp does not operate.
The lamp is defective.
Replace the lamp.
There is water inside the
oven.
There is too much water in
the tank.
Deactivate the oven and
wipe the water with a cloth
or sponge.
The steam cooking does not
work.
There is no water in the tank.
Fill the water tank.
The steam cooking does not
work.
Lime obstructs the hole.
Check the steam inlet opening. Remove the lime.
It takes more than three minutes to empty the water
tank or the water leaks from
the steam inlet opening.
There are lime deposits in
the oven.
Clean the water tank. Refer
to "Cleaning the water
tank".
The display shows F111.
The plug of the core temper- Put the plug of the core temature sensor is not correctly perature sensor as far as
installed into the socket.
possible into the socket.
The display shows an error
code that is not in this table.
There is an electrical fault.
• Deactivate the oven with
the house fuse or the
safety switch in the fuse
box and activate it again.
• If the display shows the
error code again, contact
an Authorised Service
Centre.
Steam and condensation
settle on the food and in the
cavity of the oven.
You left the dish in the oven
for too long.
Do not leave the dishes in
the oven for longer than 15 20 minutes after the cooking
process ends.
Service data
If you cannot find a solution to the problem
yourself, contact an Authorised Service
Centre.
The necessary data for the service centre is
on the rating plate. The rating plate is on
the front frame of the appliance cavity. Do
not remove the rating plate from the
appliance cavity.
ENGLISH
29
We recommend that you write the data here:
Model (MOD.)
.........................................
Product number (PNC)
.........................................
Serial number (S.N.)
.........................................
Technical information
Technical data
Dimensions (internal)
Width
Height
Depth
Area of baking tray
1438 cm²
Top heating element
2300 W
Bottom heating element
1000 W
Grill
2300 W
Ring
1900 W
Total rating
2780 W
Voltage
220 - 240 V
Frequency
50 Hz
Number of functions
21
480 mm
361 mm
416 mm
Energy efficiency
Product information according to EU 66/2014
Model identification
KULINARISK 703.220.40
Energy Efficiency Index
81.2
Energy consumption with a standard load, conventional mode
0.93 kWh/cycle
Energy consumption with a standard load, fan-forced 0.69 kWh/cycle
mode
ENGLISH
30
Number of cavities
1
Heat source
Electricity
Volume
72 l
Type of oven
Built-In Oven
Mass
36.3 kg
EN 60350-1 - Household electric cooking
appliances - Part 1: Ranges, ovens, steam
ovens and grills - Methods for measuring
performance.
Energy saving
The appliance contains features which help
you save energy during everyday cooking.
• General hints
– Make sure that the oven door is
closed properly when the appliance
operates and keep it closed as much
as possible during the cooking.
– Use metal dishes to improve the
energy saving.
– When possible, put the food inside
the oven without heating it up.
– When the cooking duration is longer
than 30 minutes, reduce the oven
temperature to minimum, 3 - 10
minutes before the end of the
cooking time, depending on the
duration of the cooking. The residual
heat inside the oven will continue to
cook.
– Use the residual heat to warm up
other foods.
• Cooking with fan - when possible, use
the cooking functions with fan to save
energy.
• Residual heat
– In some heating functions if a
programme with time selection
(Duration, End Time) is activated and
the cooking time is longer than 30
minutes, the heating elements
deactivate automatically 10%
earlier. The fan and lamp continue to
operate.
• Cooking with the lamp off - deactivate
the lamp during the cooking and activate
only when you need it.
• Keep food warm - if you want to use the
residual heat to keep the meal warm,
choose the lowest possible temperature
setting. The display shows the residual
heat temperature.
• Eco functions - refer to "Heating
Functions".
• When you use the function: Moist Fan
Baking, the lamp deactivates after 30
seconds. You can activate it again
according to your preferences.
• When you use the Eco functions, the
lamp deactivates. You can activate it
again according to your preferences.
ENVIRONMENT CONCERNS
Recycle the materials with the symbol .
Put the packaging in applicable containers
to recycle it. Help protect the environment
and human health and to recycle waste of
31
ENGLISH
electrical and electronic appliances. Do not
dispose appliances marked with the symbol
product to your local recycling facility or
contact your municipal office.
with the household waste. Return the
IKEA GUARANTEE
How long is the IKEA guarantee valid?
This guarantee is valid for five (5) years
from the original date of purchase of Your
appliance at IKEA Pty Ltd, ABN
84006270757 or at Cebas Pty Ltd, ABN 15
009 156 003 (Both Trading as IKEA) unless
the appliance is named LAGAN in which
case two (2) years of guarantee apply. The
original sales receipt is required as proof of
purchase. If service work is carried out
under guarantee, this will not extend the
guarantee period for the appliance.
Which appliances are not covered by the
IKEA five (5) years guarantee?
The range of appliances named LAGAN .
Who will execute the service?
IKEA service provider will provide the service through its own service operations or
authorized service partner network. Contact
IKEA for further information.
If you encounter any trouble with the
appliance and wish to register a service call
or make a claim, please refer to
www.ikea.com.au for your local store after
sales customer service center phone
number, online email and opening times.
The principal address and contact details in
Australia are:
For Queensland, New South Wales, and
Victorian customers please contact:
IKEA Pty Ltd
IKEA Pty Ltd
IKEA Service Office
L1 Clock Tower, 630 Princes Highway
Tempe, NSW 2044
Contact - IKEA Customer Service at
www.IKEA.com.au
For Western Australian and South
Australian customers please contact:
Cebas Pty Ltd
8c Sunray Drive, Innaloo WA 6018
Australia
Contact - IKEA Customer Service at
www.IKEA.com.au
What does this guarantee cover?
The guarantee covers faults of the appliance, which have been caused by faulty
construction or material faults from the date
of purchase from IKEA. This guarantee applies to domestic use only. The products
have been designed and tested for
domestic purposes only and this guarantee
does not cover damage arising from use of
the Product in a commercial environment.
The exceptions are specified under the
headline "What is not covered under this
guarantee?" Within the guarantee period,
the costs to remedy the fault e.g. repairs,
parts, labour and travel will be covered,
provided that the appliance is accessible
for repair without special expenditure.
ENGLISH
Replaced parts become the property of
IKEA.
The guarantee exists only if the appliance
complies and is installed in accordance
with:
• The technical specifications.
• The Assembly Instructions and user
manual Safety Information.
IKEA's guarantee is subject to Australian
Consumer Law - see Schedule 2 to
Competition and Consumer Act, 2010. This
guarantee is in addition to (and does not
exclude, restrict or modify in any way) any
non-excludable statutory warranties in
Australia.
What will IKEA do to correct the problem?
IKEA appointed service provider will examine the product and decide, at its sole discretion, if it is covered under this guarantee.
They will notify you as to whether your
claim is covered under this guarantee. If
your claim is approved, the IKEA service
provider or its authorized service partner,
will then, at its sole discretion, either repair
the defective product or replace it with the
same or a comparable product.
What is not covered under this
guarantee?
• Normal wear and tear.
• Deliberate or negligent damage, damage caused by failure to observe operating instructions, incorrect installation or
by connection to the wrong voltage, damage caused by chemical or electro-chemical reaction, rust, corrosion or water
damage including but not limited to damage caused by excessive lime in the water supply, damage caused by abnormal
environmental conditions.
• Consumable parts including batteries
and lamps.
• Non-functional and decorative parts
which do not affect normal use of the ap-
32
pliance, including any scratches and possible colour differences.
• Accidental damage caused by foreign
objects including insect or vermin
infestation or substances and cleaning or
unblocking of filters, drainage systems or
soap drawers.
• Damage to the following parts: ceramic
glass, accessories, crockery and cutlery
baskets, feed and drainage pipes, seals,
lamps and lamp covers, screens, knobs,
casings and parts of casings. Unless such
damages can be proved to have been
caused by production faults.
• Cases where no fault could be found during a technician's visit.
• Repairs not carried out by our appointed
service providers and/or an authorized
service contractual partner or where
non-original parts have been used.
• Repairs caused by installation which is
faulty or not according to specification.
• The use of the appliance in a non-domestic environment i.e. professional use.
• Transportation damages. If a customer
transports the product to their home or
other address, IKEA is not liable for any
damage that may occur during transport.
However, if IKEA delivers the product to
the customer's delivery address, then
damage to the product that occurs
during this delivery will be covered by
this guarantee.
• Cost for carrying out the initial
installation of the IKEA appliance.
However, if an IKEA service provider or
its authorized service partner repairs or
replaces the appliance under the terms
of this guarantee, the service provider or
its authorized service partner will reinstall the repaired appliance or install
the replacement, if necessary.
• The appliance's serial number or
warranty seal has been removed or
defaced.
How country law applies
ENGLISH
33
3. Ask for clarification on user manual contents and specifications of the IKEA appliance.
Our goods come with guarantees that
cannot be excluded under the Australian
Consumer Law (ACL). You are entitled to a
replacement or refund for a major failure
and compensation for any other reasonably
foreseeable loss or damage.
To ensure that we provide you with the best
assistance, please read carefully the Assembly Instructions and/or the User Manual
section of this booklet before contacting us.
You are also entitled to have the goods
repaired or replaced if the goods fail to be
of acceptable quality and the failure does
not amount to a major failure.
How to reach us if you need our service
This guarantee is not intended in any way
to limit or exclude such rights and remedies
that you may have under law.
The IKEA after sales customer service centre
will assist you on the phone with basic
trouble shooting for your appliance at the
time of service call request. Please refer to
the IKEA catalogue or www.ikea.com.au
and select your local store for local store
phone numbers and opening times.
You can find out more information about
the Australian Consumer Law on the ACCC
website: www.accc.gov.au
Area of validity
This IKEA guarantee applies only to
products purchased and installed in
AUSTRALIA .
Please describe the problem that
you are facing with the
appliance in detail along
with your product article number
( 8 digit code ) and date of
purchase at the time of call
registration .
What you must do to make a claim under
the guarantee:
To make a claim under the guarantee
contact IKEA after sales customer service
center at the above address, the IKEA
catalogue or refer to www.ikea.com.au for
your local store customer service phone
number, online email and opening times.
Please describe the problem that you are
facing with the appliance in detail along
with your product article number (8 digit
code) and date of purchase at the time of
call registration.
SAVE THE SALES RECEIPT!
Kindly keep all these details and
original invoice of purchase
handy during the service
technician's visit to enable him to
carry out the job.
It is your proof of purchase and
required for the guarantee to
apply. Note that the receipt
reports also the IKEA article
name and number (8 digit code)
for each of the appliances you
have purchased.
Please do not hesitate to contact the
dedicated after sales customer service
center for IKEA appliances to:
1. Make a service request under this guarantee;
2. Ask for clarification on installation of the
IKEA appliance in the dedicated IKEA
kitchen furniture.
*
ENGLISH
34
ENGLISH
35
867318769-B-242015
© Inter IKEA Systems B.V. 2015
21552
AA-1755522-1

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
